MODIFICATION BULLETIN NO. 12 Page 1 of 2 ISSUED ON: July 31, ’91
Model LCT for F24/F90/F85/F12/F23/F13/F25/COSMOS - 1/F11 Volt/Hz
Modified Article Holder - Side Cover
Reason for
Due to parts standardization
Modification
Due to parts standardization, the holder for the side cover has been changed. The interchangeabilit y is O/O.
Incorrect P/N Correct P/N Description Q’ty Index No. Page
59252331 A3402331 Holder - Side Cover 1 21 5
Date of
Modification
Serial Number
T. Ito, Manager
Copier Technical Support
MODIFICATION BULLETIN NO. 12 Page 2 of 2 ISSUED ON: July 31, ’91
MODEL NAME
P.B. D645 115/60 USA, CANADA A912-11
SAVIN 7200/7400LCT 115/60 USA, CANADA A912-15
NASHUA T-1 115/60 S. AMERICA etc. A912-16
RICOH RT15 115/60 USA, CANADA A912-17
NASHUA T-1 220/50 EUROPE etc. A912-25
KALLE MAGAZIN
21/26/40
RICOH RT15 220, 240/50 EUROPE A912-27
V/Hz DESTINATION CODE SERIAL NUMBER
220/50 EUROPE A912-26
MODIFICATION BULLETIN NO. 13 Page 1 of 2 ISSUED ON: July 31, ’91
Model LCT for F24/F90/F85/F12/F23/F13/F25/COSMOS-1/F11 Volt/Hz
Modified Article Top Cover/ Side Cover
Reason for
Due to part standardization
Modification
Due to part standardization with another model, the top cover and the side cover have been changed a s shown in the figure.
Old P/N New P/N Description Q’ty Used Interchangeability Index No. Page
A9122621 A3402622 Top Cover (RICOH) 1 → 1 O/O 1 3
58971251 A3402623 Top Cover (OEM) 1 → 1 O/O 1 3
A9122631 A3402632 Side Cover (RICOH) 1 → 1 O/O 5 3
59252234 A3402633 Side Cover (OEM) 1 → 1 O/O 5 3
Date of
Modification
Serial Number
Top Cover
Side Cover
Old
New
T. Ito, Manager
Copier Technical Support
MODIFICATION BULLETIN NO. 13 Page 2 of 2 ISSUED ON: July 31, ’91
MODEL NAME
P.B. D645 115/60 USA, CANADA A912-11
SAVIN 7200/7400LCT 115/60 USA, CANADA A912-15
NASHUA T-1 115/60 S. AMERICA etc. A912-16
RICOH RT15 115/60 USA, CANADA A912-17
NASHUA T-1 220/50 EUROPE etc. A912-25
KALLE MAGAZIN
21/26/40
RICOH RT15 220, 240/50 EUROPE A912-27
V/Hz DESTINATION CODE SERIAL NUMBER
220/50 EUROPE A912-26
MODIFICATION BULLETIN NO. 14 Page 1 of 2 ISSUED ON: October 31, ’91
Model LCT for F24/ F90/ F85/ F12/ F23/ F13/ F25/ COSMOS-1/ F11 Volt/Hz
Modified Article Magnet Catch
Reason for
Parts standardization
Modification
Due to parts standardization, the magnet catch ass’y has been changed. The interchangeability is O/O.
Page Index Old P/N New P/N Q’ty Description
7 24 50540536 AG070004 2 Magnet Catch Ass’y
Date of
Modification
Serial Number
T. Ito, Manager
Copier Technical Support
MODIFICATION BULLETIN NO. 14 Page 2 of 2 ISSUED ON: October 31, ’91
MODEL NAME
P.B. D645 115/60 USA, CANADA A912-11
SAVIN 7200/7400LCT 115/60 USA, CANADA A912-15
NASHUA T-1 115/60 S. AMERICA etc. A912-16
RICOH RT15 115/60 USA, CANADA A912-17
NASHUA T-1 220/50 EUROPE etc. A912-25
KALLE MAGAZINE
21/26/40
RICOH RT15 220, 240/50 EUROPE A912-27
V/Hz DESTINATION CODE SERIAL NUMBER
220/50 EUROPE A912-26
