MODIFICATION BULLETIN NO. 17 Page 1 of 3 ISSUED ON: June 15, ’91
Model
Modified Article Base Plate
Reason for
Modification
Draw
No.
Old Parts
No.
68031136 A4231126 Base Plate (Infotec, Nashua)
68031131 A4231105 Base Plate (Ricoh)
Mini Sorter for F9/F80/P201/OEM’s V25/V30/V35/V36/F85/F90/F12/F13/F24
(European Version only )
To improve reliability and durability
New Parts
A4231144 Base Roller
A4231143 Base Shaft
03140060W Philips Pan Head Screw-M4 x 6
07200040E Retaining Ring-M4
No.
Description
Volt/Hz
A.B.C.
Rank Part No. Description Index No. Page
Q’ty Used
Old → New
1 → 1
1 → 1
0 → 2
0 → 2
n → n+4
n → n+2
Inter-
change-
ability
O/O 29 47
O/O 29 47
Part needed for replacement by new part Parts Catalog
Date of
Modification
Serial Number
*60 47
*59 47
102 47
115 47
A4231145 Receive Plate
68031115 A4231127 Bin Guide
68032311 A4232311 Guide Plate
Rank: A : Replace with new parts immediately. B : Replace with new parts at time of repair. C : Replace with new parts at time of overhaul.
Interchangeability:
(1) When old and new parts are not mutually interchangeable, use additional parts or an assembly part as indicated in "Parts needed for replacement by new part" to
install the new part.
(2) The mark to the left of the slash indicates whether the old part can be used in the new machine, and the mark to the right indicates whether the new part can be used
in the old machine. x = Not interchangeable o = Interchangeable
0 → 1
2 → 2
1 → 1
O/O 54 47
O/O 26 47
*61 47
Page 2
MODIFICATION BULLETIN NO. 17 Page 2 of 3 ISSUED ON: June 15, ’91
DETAILS OF MODIFICATION
To improve reliability and durability, the production machines of the European
versions have been modified as follows:
1. To add the receive plate in order to ensure that this sorter stands steadily
when the sorter is undocked from the coier, and put on the floor.
(Figure 1)
2. To add the base roller and base shaft in order to reduce the friction
between the base plate and lowest bin. (Figure 2)
3. To change the material of the bin guide and guide plate.
61
Receive Plate
Figure 1
60
Base Roller
115
59
Base Shaft
Figure 2
102
102
59
60
115
T. Ito, Manager
Copier Technical Support
Page 3
MODIFICATION BULLETIN NO. 17 Page 3 of 3 ISSUED ON: June 15, ’91
MODEL NAME V/Hz DESTINATION
P.B. D220 115/60 USA, Canada 6803-11 6803-07
Savin
Sorter 7020
Nashua S512 115/60 S. America etc. 6803-16
Ricoh CS2050 115/60 USA, Canada 6803-17 6803-06
Nashua S512 220,240/50 Europe etc 6803-25 Service Parts Only 6803-45 7214600001
Kalle
Sorter 9032Z
Ricoh CS2050 220,240/50 Europe etc. 6803-27 Service Parts Only 6803-47 931460XXXX
115/60 USA, Canada 6803-15 6803-08
220,240/50 Europe 6803-26 Service Parts Only 6803-46 324461XXXX
JAPAN PRODUCTION REI PRODUCTION
CODE SERIAL NUMBER CODE SERIAL NUMBER
Page 4
MODIFICATION BULLETIN NO. 18 Page 1 of 2 ISSUED ON: June 15, ’91
Model
Modified Article Front and Rear Cover
Reason for
Modification
Mini Sorter for F9/F80/P201/OEM’s V25/V30/V35/V36/F85/F90/F12/F13/F24
(Ricoh and Nashua European version only)
Due to parts standardization
Due to parts srandardization, the following parts have been changed. The interchangeability is O/O.
Page Index Old P/N New P/N Description
47 50 # 68036111 # A4146113 Front Cover (Ricoh and Nashua)
47 14 # 68036211 # A4146213 Rear Cover (Ricoh and Nashua)
Volt/Hz
Date of
Modification
Serial Number
T. Ito, Manager
Copier Technical Support
Page 5
MODIFICATION BULLETIN NO. 18 Page 2 of 2 ISSUED ON: June 15, ’91
MODEL NAME V/Hz DESTINATION
P.B. D220 115/60 USA, Canada 6803-11 6803-07
Savin
Sorter 7020
Nashua S512 115/60 S. America etc. 6803-16
Ricoh CS2050 115/60 USA, Canada 6803-17 6803-06
Nashua S512 220,240/50 Europe etc 6803-25 Service Parts Only 6803-45
Kalle
Sorter 9032Z
Ricoh CS2050 220,240/50 Europe etc. 6803-27 Service Parts Only 6803-47
115/60 USA, Canada 6803-15 6803-08
220,240/50 Europe 6803-26 Service Parts Only 6803-46
JAPAN PRODUCTION REI PRODUCTION
CODE SERIAL NUMBER CODE SERIAL NUMBER
Page 6
MODIFICATION BULLETIN NO. 19 Page 1 of 2 ISSUED ON: July 31, ’91
Model Mini Sorter for F9/F80/P201/OEM’s V25/V30/V35/V36/F85/F90/F12/F13/F24 Volt/Hz
Modified Article Bin Motor - 220V/240V (European Version Only)
Reason for
Due to parts standardization with 115V version
Modification
Due to parts standardization with 115V version, the bin motor has been changed. The interchangeabil ity is O/O.
Old P/N Old Description New P/N New Description Page Index
68035420 Bin Motor - 220V/240V 68035400 Bin Motor - AC14/17W 47 46
Date of
Modification
Serial Number
T. Ito, Manager
Copier Technical Support
Page 7
MODIFICATION BULLETIN NO. 19 Page 2 of 2 ISSUED ON: July 31, ’91
MODEL NAME V/Hz DESTINATION
P.B. D220 115/60 USA, Canada 6803-11 6803-07
Savin
Sorter 7020
Nashua S512 115/60 S. America etc. 6803-16
Ricoh CS2050 115/60 USA, Canada 6803-17 6803-06
Nashua S512 220,240/50 Europe etc 6803-25 Service Parts Only 6803-45
Kalle
Sorter 9032Z
Ricoh CS2050 220,240/50 Europe etc. 6803-27 Service Parts Only 6803-47
115/60 USA, Canada 6803-15 6803-08
220,240/50 Europe 6803-26 Service Parts Only 6803-46
JAPAN PRODUCTION REI PRODUCTION
CODE SERIAL NUMBER CODE SERIAL NUMBER
Page 8
MODIFICATION BULLETIN NO. 20 Page 1 of 3 ISSUED ON: Aug. 15, ’91
Model Mini Sorter for F9/F80/P201 OEM’s V25/V30/V35/V36/F85/F90/F12/F13/F24 Volt/Hz
Modified Article Guide stopper plate
Reason for
Prevention of the upper guide plate dislodgment
Modification
Draw
No.
Old Parts
No.
New Parts
No.
A4142311 Spring Plate - Guide Stopper 0 2 * 65 47
Description
Date of
Modification
A.B.C.
Rank Part No. Description Index No. Page
Q’ty Used
Old New
Inter-
change-
ability
Part needed for replacement by new part Parts Catalog
* New Index
Serial Number
Rank: A : Replace with new parts immediately. B : Replace with new parts at time of repair. C : Replace with new parts at time of overhaul.
Interchangeability:
(1) When old and new parts are not mutually interchangeable, use additional parts or an assembly part as indicated in "Parts needed for replacement by new part" to
install the new part.
(2) The mark to the left of the slash indicates whether the old part can be used in the new machine, and the mark to the right indicates whether the new part can be used
in the old machine. x = Not interchangeable o = Interchangeable
Page 9
DETAILS OF MODIFICATION
The upper guide plate may be dislodged from the guide if handled roughly when removing
jammed paper from the sorter. To hold the upper guide plate, two guide stopper spring
plates (front and rear) have been added to the production line.
Upper guide plate
MODIFICATION BULLETIN NO. 20 Page 2 of 3 ISSUED ON: Aug. 15, ’91
Guide
Guide stopper spring
plate
T. Ito, Manager
Copier Technical Support
Page 10
MODIFICATION BULLETIN NO. 20 Page 3 of 3 ISSUED ON: Aug. 15, ’91
JAPAN PRODUCTION REI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER CODE SERIAL NUMBER
P.B. D220 115/60 USA, Canada 6803-11 Service Parts Only 6803-07
Savin
Sorter 7020
Nashua S512 115/60 S. America etc. 6803-16 Service Parts Only
Ricoh CS2050 115/60 USA, Canada 6803-17 Service Parts Only 6803-06
Nashua S512 220,240/50 Europe etc 6803-25 Service Parts Only 6803-95
Kalle
Sorter 9032Z
Ricoh CS2050 220,240/50 Europe etc. 6803-27 Service Parts Only 6803-47
115/60 USA, Canada 6803-15 Service Parts Only 6803-08
220,240/50 Europe 6803-26 Service Parts Only 6803-46
