Ricoh 5446 Modification Bulletin FT6080

MODIFICATION BULLETIN NO. 95 Page 1 of 2 ISSUED ON: Mach 31, ’91

Model F2 Volt/Hz

Modified Article Upper inverter Roller

Reason for

To improve reliability and durability of upper inverter roller

Modification

Date of

Modification

Under high temperature conditions, individual rollers on the upper inverter roller assembly sometime s cracks. To improve
the reliability and durability of the upper inverter roller, the material of the rollers has been ch anged and the color of the
rollers has been changed from white to gray. The interchangeability is X/O.

Page Index Old P/N New P/N Description

65 10 54464749 A0584740 Upper Inverter Roller

Serial Number

T. Ito, Manager
Copier Technical Support

MODIFICATION BULLETIN NO. 95 Page 2 of 2 ISSUED ON: Mach 31, ’91

MODEL NAME

P.B. D460 115/60 USA 5446-11 Service Parts Only

P.B. D460 115/60 Canada 5446-12 Service Parts Only
Savin 7045 115/60 Canada 5446-14 Service Parts Only
Savin 7045 115/60 USA 5446-15 Service Parts Only

Ricoh FT6080 115/60 USA 5446-17 Service Parts Only
Ricoh FT6080 115/60 Canada 5446-19 Service Parts Only

Nashua 4790 220,240/50 Europe, etc. 5446-25 Service Parts Only

infotec 9046RED 220,240/50 Europe 5446-26 Service Parts Only

Ricoh FT6080 220,240/50 Europe, etc. 5446-27 Service Parts Only

V/Hz DESTINATION CODE SERIAL NUMBER

MODEL NAME

P.B. D500 115/60 USA 5446-51 Service Parts Only

P.B. D500 115/60 Canada 5446-52 Service Parts Only
Savin 7055 115/60 Canada 5446-54 Service Parts Only
Savin 7055 115/60 USA 5446-55 Service Parts Only

Ricoh FT6085 115/60 USA 5446-57 Service Parts Only
Ricoh FT6085 115/60 Canada 5446-59 Service Parts Only

infotec 9050 220,240/50 Europe 5446-66 Service Parts Only

Ricoh FT6085 220,240/50 Europe, etc. 5446-67 Service Parts Only

V/Hz DESTINATION CODE SERIAL NUMBER

MODIFICATION BULLETIN NO. 96 Page 1 of 2 ISSUED ON:May 31, ’91

Model F2 Volt/Hz

Modified Article Belt Cleaner

Reason for

Modification

To protect the environment, the material of the belt cleaner has been changed from CFC
type to Alcohol type. (CFC: chlorofluorocarbon)

Old P/N New P/N Description Interchangeability Parts Catalog

Page Index

23000110 22020001 Belt Cleaner O/O

1 - 127 22 F2

This modification has been applied to the service parts only. The belt cleaner packed with the production ma­chines has not been changed, because the new belt cleaner is flammable and we cannot ship it wit h the machine.

NOTE: We are now, developing another belt cleaner which is not flammable and does not contain CFC m aterial.

It will be phased in when the development and testing are complete.

Date of

Modification

Serial Number

T. Ito, Manager
Copier Technical Support

MODIFICATION BULLETIN NO. 96 Page 2 of 2 ISSUED ON:May 31, ’91

MODEL NAME

P.B. D460 115/60 USA 5446-11 Service Parts Only

P.B. D460 115/60 Canada 5446-12 Service Parts Only
Savin 7045 115/60 Canada 5446-14 Service Parts Only
Savin 7045 115/60 USA 5446-15 Service Parts Only

Ricoh FT6080 115/60 USA 5446-17 Service Parts Only
Ricoh FT6080 115/60 Canada 5446-19 Service Parts Only

Nashua 4790 220,240/50 Europe, etc. 5446-25 Service Parts Only

infotec 9046RED 220,240/50 Europe 5446-26 Service Parts Only

Ricoh FT6080 220,240/50 Europe, etc. 5446-27 Service Parts Only

V/Hz DESTINATION CODE SERIAL NUMBER

MODEL NAME

P.B. D500 115/60 USA 5446-51 Service Parts Only

P.B. D500 115/60 Canada 5446-52 Service Parts Only
Savin 7055 115/60 Canada 5446-54 Service Parts Only
Savin 7055 115/60 USA 5446-55 Service Parts Only

Ricoh FT6085 115/60 USA 5446-57 Service Parts Only
Ricoh FT6085 115/60 Canada 5446-59 Service Parts Only

infotec 9050 220,240/50 Europe 5446-66 Service Parts Only

Ricoh FT6085 220,240/50 Europe, etc. 5446-67 Service Parts Only

V/Hz DESTINATION CODE SERIAL NUMBER

MODIFICATION BULLETIN NO. 97 Page 1 of 2 ISSUED ON: August 31, ’91

Model F2 Volt/Hz

Modified Article Total Counter

Reason for

Additional Information

Modification

Date of

Modification

Serial Number

Please add the following part to your parts catalog:
Page Index No. Part Number Description Q’ty
71 11 # 54395246 Totalizer Ass’y 1
# 54395246 has been registered as a spare part as per field request.
Therefore, two total counters have been registered as spare parts:

1. # 54395246 [This counter is preset at a count lower than 0 (9998920 ± 15) so that tests and inspection can be made on the production
line.]

2. # 54399015 [This counter is initially set at 0001000 ± 100.]
The following problems have been reported concerning counter # 54395246. Therefore, counter # 54399015 has been registered.
A. If counter # 54395246 is supplied as a spare part, the customer engineer cannot distinguis h between a used and a new counter since a

number like 9998920 ± 15 causes it to look like a used counter.
B. Some dealers have had problems with individuals who sell used copiers as new machines. If counter # 54395246 is supplied as a spare

part, used machines can be easily sold as new ones by replacing the total counter. This caus es great confusion with the service activities
in the field and sales activities.

Therefore, please supply # 54399015 to those dealers who have had the problems mentioned above, and supply # 54395246 to the others.
And please keep the counters in stock that meet your dealer’s requirements.

T. Ito, Manager
Copier Technical Support

MODIFICATION BULLETIN NO. 97 Page 2 of 2 ISSUED ON: August 31, ’91

MODEL NAME

P.B. D460 115/60 USA 5446-11 Service Parts Only

P.B. D460 115/60 Canada 5446-12 Service Parts Only
Savin 7045 115/60 Canada 5446-14 Service Parts Only
Savin 7045 115/60 USA 5446-15 Service Parts Only

Ricoh FT6080 115/60 USA 5446-17 Service Parts Only
Ricoh FT6080 115/60 Canada 5446-19 Service Parts Only

Nashua 4790 220,240/50 Europe, etc. 5446-25 Service Parts Only

infotec 9046RED 220,240/50 Europe 5446-26 Service Parts Only

Ricoh FT6080 220,240/50 Europe, etc. 5446-27 Service Parts Only

V/Hz DESTINATION CODE SERIAL NUMBER

MODEL NAME

P.B. D500 115/60 USA 5446-51 Service Parts Only

P.B. D500 115/60 Canada 5446-52 Service Parts Only
Savin 7055 115/60 Canada 5446-54 Service Parts Only
Savin 7055 115/60 USA 5446-55 Service Parts Only

Ricoh FT6085 115/60 USA 5446-57 Service Parts Only
Ricoh FT6085 115/60 Canada 5446-59 Service Parts Only

infotec 9050 220,240/50 Europe 5446-66 Service Parts Only

Ricoh FT6085 220,240/50 Europe, etc. 5446-67 Service Parts Only

V/Hz DESTINATION CODE SERIAL NUMBER

MODIFICATION BULLETIN NO. 98 Page 1 of 2 ISSUED ON: August 31, ’91

Model F2 Volt/Hz

Modified Article Return Pinch Roller

Reason for

To improve reliability and durability of upper inverter roller

Modification

Date of

Modification

Under high temperature conditions, individual rollers on the upper inverter roller assembly sometime s cracks. To improve the
reliability and durability of the upper inverter roller, the material of the rollers has been change d. The interchangeability is X/O.

Page Index Old P/N New P/N Description

65 24 54464817 AF040044 Return Pinch Roller

Serial Number

T. Ito, Manager
Copier Technical Support

MODIFICATION BULLETIN NO. 98 Page 2 of 2 ISSUED ON: August 31, ’91

MODEL NAME

P.B. D460 115/60 USA 5446-11 Service Parts Only

P.B. D460 115/60 Canada 5446-12 Service Parts Only
Savin 7045 115/60 Canada 5446-14 Service Parts Only
Savin 7045 115/60 USA 5446-15 Service Parts Only

Ricoh FT6080 115/60 USA 5446-17 Service Parts Only
Ricoh FT6080 115/60 Canada 5446-19 Service Parts Only

Nashua 4790 220,240/50 Europe, etc. 5446-25 Service Parts Only

infotec 9046RED 220,240/50 Europe 5446-26 Service Parts Only

Ricoh FT6080 220,240/50 Europe, etc. 5446-27 Service Parts Only

V/Hz DESTINATION CODE SERIAL NUMBER

MODEL NAME

P.B. D500 115/60 USA 5446-51 Service Parts Only

P.B. D500 115/60 Canada 5446-52 Service Parts Only
Savin 7055 115/60 Canada 5446-54 Service Parts Only
Savin 7055 115/60 USA 5446-55 Service Parts Only

Ricoh FT6085 115/60 USA 5446-57 Service Parts Only
Ricoh FT6085 115/60 Canada 5446-59 Service Parts Only

infotec 9050 220,240/50 Europe 5446-66 Service Parts Only

Ricoh FT6085 220,240/50 Europe, etc. 5446-67 Service Parts Only

V/Hz DESTINATION CODE SERIAL NUMBER

MODIFICATION BULLETIN NO. 99 Page 1 of 2 ISSUED ON: December 15, ’91

Model F2 Volt/Hz

Modified Article Accuride

Reason for

Due to parts standardization with other model.

Modification

To standardize the part with other model, the following part has been changed:

Old P/N New P/N Description Q’ty Used Interchangeability Index no. Page

54464616 AA070017 Accuride 2 → 2 O/O 43 61

Date of

Modification

Serial Number

T. Ito, Manager
Copier Technical Support

MODIFICATION BULLETIN NO. 99 Page 2 of 2 ISSUED ON: December 15, ’91

MODEL NAME

P.B. D460 115/60 USA 5446-11 Service Parts Only

P.B. D460 115/60 Canada 5446-12 Service Parts Only
Savin 7045 115/60 Canada 5446-14 Service Parts Only
Savin 7045 115/60 USA 5446-15 Service Parts Only

Ricoh FT6080 115/60 USA 5446-17 Service Parts Only
Ricoh FT6080 115/60 Canada 5446-19 Service Parts Only

Nashua 4790 220,240/50 Europe, etc. 5446-25 Service Parts Only

infotec 9046RED 220,240/50 Europe 5446-26 Service Parts Only

Ricoh FT6080 220,240/50 Europe, etc. 5446-27 Service Parts Only

V/Hz DESTINATION CODE SERIAL NUMBER

MODEL NAME

P.B. D500 115/60 USA 5446-51 Service Parts Only

P.B. D500 115/60 Canada 5446-52 Service Parts Only
Savin 7055 115/60 Canada 5446-54 Service Parts Only
Savin 7055 115/60 USA 5446-55 Service Parts Only

Ricoh FT6085 115/60 USA 5446-57 Service Parts Only
Ricoh FT6085 115/60 Canada 5446-59 Service Parts Only

infotec 9050 220,240/50 Europe 5446-66 Service Parts Only

Ricoh FT6085 220,240/50 Europe, etc. 5446-67 Service Parts Only

V/Hz DESTINATION CODE SERIAL NUMBER

MODIFICATION BULLETIN NO. 100 Page 1 of 2 ISSUED ON: August 18, ’92

Model F2 Volt/Hz

Modified Article Pick-up Roller

Reason for

Vender change

Modification

As the vender has been changed, the part nu mbe r of th e pick-u p rolle r is chang ed.
The quality and the dura bilit y of the new part is the same that of the old pa rt.

Old P/N New P/N Description Q’ty Used Interchangeability Index No. Page

54297069 AF030016 Pick-up Roller

1 → 1

O/O

25
13

Date of

Modification

29
31

Serial Number

T. Ito, Manager
Copier Technical Support

MODIFICATION BULLETIN NO. 100 Page 2 of 2 ISSUED ON: August 18, ’92

MODEL NAME

P.B. D460 115/60 USA 5446-11 Service Parts Only

P.B. D460 115/60 Canada 5446-12 Service Parts Only
Savin 7045 115/60 Canada 5446-14 Service Parts Only
Savin 7045 115/60 USA 5446-15 Service Parts Only

Ricoh FT6080 115/60 USA 5446-17 Service Parts Only
Ricoh FT6080 115/60 Canada 5446-19 Service Parts Only

Nashua 4790 220,240/50 Europe, etc. 5446-25 Service Parts Only

infotec 9046RED 220,240/50 Europe 5446-26 Service Parts Only

Ricoh FT6080 220,240/50 Europe, etc. 5446-27 Service Parts Only

V/Hz DESTINATION CODE SERIAL NUMBER

MODEL NAME

P.B. D500 115/60 USA 5446-51 Service Parts Only

P.B. D500 115/60 Canada 5446-52 Service Parts Only
Savin 7055 115/60 Canada 5446-54 Service Parts Only
Savin 7055 115/60 USA 5446-55 Service Parts Only

Ricoh FT6085 115/60 USA 5446-57 Service Parts Only
Ricoh FT6085 115/60 Canada 5446-59 Service Parts Only

infotec 9050 220,240/50 Europe 5446-66 Service Parts Only

Ricoh FT6085 220,240/50 Europe, etc. 5446-67 Service Parts Only

V/Hz DESTINATION CODE SERIAL NUMBER

MODIFICATION BULLETIN NO. 101 Page 1 of 2 ISSUED ON: June 30, ’92

Model F2 Volt/Hz

Modified Article Drum

Reason for

To standardize the part number

Modification

The part number has been changed to standardize the part number of the drum.

Old P/N New P/N Description Q’ty Used Interchangeability

54469590 54469510 Drum

1 → 1

O/O

Date of

Modification

Serial Number

T. Ito, Manager
Copier Technical Support

MODIFICATION BULLETIN NO. 101 Page 2 of 2 ISSUED ON: June 30, ’92

MODEL NAME

P.B. D460 115/60 USA 5446-11

P.B. D460 115/60 Canada 5446-12
Savin 7045 115/60 Canada 5446-14
Savin 7045 115/60 USA 5446-15

Ricoh FT6080 115/60 USA 5446-17
Ricoh FT6080 115/60 Canada 5446-19

Nashua 4790 220,240/50 Europe, etc. 5446-25 Service Parts Only

infotec 9046RED 220,240/50 Europe 5446-26 Service Parts Only

Ricoh FT6080 220,240/50 Europe, etc. 5446-27 Service Parts Only

V/Hz DESTINATION CODE SERIAL NUMBER

MODEL NAME

P.B. D500 115/60 USA 5446-51

P.B. D500 115/60 Canada 5446-52
Savin 7055 115/60 Canada 5446-54
Savin 7055 115/60 USA 5446-55

Ricoh FT6085 115/60 USA 5446-57
Ricoh FT6085 115/60 Canada 5446-59

infotec 9050 220,240/50 Europe 5446-66 Service Parts Only

Ricoh FT6085 220,240/50 Europe, etc. 5446-67 Service Parts Only

V/Hz DESTINATION CODE SERIAL NUMBER

MODIFICATION BULLETIN NO. 102 PAGE 1 OF 2

ISSUED ON: September 15, ’94

Model F2 Volt/Hz

Modified Article Filter - Fan Motor

Reason for

Due to vendor change

Modification

Due to vendor change, the following pa rt has bee n mod ifie d.

Inter-

Old P/N New P/N Description Q’ty Used

54462270 AA012088 Filter - Fan Motor

1 → 1

change-

ability

O/O 19 1 - 75

Date of

Modification

Parts Catalog

Index No. Page

Serial Number

S. Hamano, Assistant General Manager
Technical Support Department

MODIFICATION BULLETIN NO. 102 PAGE 2 OF 2

ISSUED ON: September 15, ’94

MODEL NAME

P.B. D460 115/60 USA 5446-11 Service Parts Only

P.B. D460 115/60 Canada 5446-12 Service Parts Only
Savin 7045 115/60 Canada 5446-14 Service Parts Only
Savin 7045 115/60 USA 5446-15 Service Parts Only

Ricoh FT6080 115/60 USA 5446-17 Service Parts Only
Ricoh FT6080 115/60 Canada 5446-19 Service Parts Only

Nashua 4790 220,240/50 Europe, etc. 5446-25 Service Parts Only

infotec 9046RED 220,240/50 Europe 5446-26 Service Parts Only

Ricoh FT6080 220,240/50 Europe, etc. 5446-27 Service Parts Only

V/Hz DESTINATION CODE SERIAL NUMBER

MODEL NAME

P.B. D500 115/60 USA 5446-51 Service Parts Only

P.B. D500 115/60 Canada 5446-52 Service Parts Only
Savin 7055 115/60 Canada 5446-54 Service Parts Only
Savin 7055 115/60 USA 5446-55 Service Parts Only

Ricoh FT6085 115/60 USA 5446-57 Service Parts Only
Ricoh FT6085 115/60 Canada 5446-59 Service Parts Only

infotec 9050 220,240/50 Europe 5446-66 Service Parts Only

Ricoh FT6085 220,240/50 Europe, etc. 5446-67 Service Parts Only

V/Hz

DESTINATION

CODE SERIAL NUMBER

Service Parts Only
