FAX OPTION TYPE 2027
B576
PARTS LOCATION AND LIST
Page 2
Page 3
This section instructs you as to the numbers and names of parts on this machine.
Page 4
1.Fax Option (B576)
B576 2 Parts Location and List
Page 5
1.Fax Option (B576)
Index
No.
1 B031 5861 Shading Plate: Fax Control Unit 1
2 5488 6222 NCU-FD-U2 Board - 120V 1
2 5488 6292 NCU-FD-EA2T Board - 230V TWN 1
3 B024 5868 Bracket - Speaker 1
4 G025 1211 Speaker - GS 1
5 B024 5865 Bracket - NCU-Upper 1
6 B024 5866 Bracket - NCU-Lower 1
7 B092 5192 FCU I/F Board 1
8 B576 5270 Harness - FCU-NCUSP NA 1
8 B576 5272 Harness - FCU-NCUSP EU 1
9 B576 5180 MBU Board 1
10 B576 5170 FCU Board 1
11 B418 7151 Keytop - Fax-NA 1
11 B418 7171 Keytop - Fax - EU 1
12 B418 7150 Key Top - Copy (NA) 1
12 B418 7170 Key Top - Copy (EU) 1
13 B418 7152 Cover - Keytop-Fax-NA 1
13 B418 7172 Cover - Keytop - Fax - EU 1
14 B027 1447 Keytop - Fax 1
15 B418 1370 NCU Cover 1
16 B404 3861 SG3 Decal 1
17 H523 5350 Telephone Cable 1
18 H511 5007 Stamp 1
19 B576 8607 Operating Instructions Basic (NA) 1
21 B576 8657 Operating Instructions Advance (NA) 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0451 3006B Tapping Screw - M3x6
102 1105 0516 Clamp
103 0453 3006B Tapping Screw - M3x6
104 1105 0441 Spacer - 8mm
Part No.
Description
Q’ty Per
Assembly
B576 3 Parts Location and List
Page 6
2.FCU Board (B576)
B576 4 Parts Location and List
Page 7
2.FCU Board (B576)
B576 5 Parts Location and List
Page 8
Page 9
2.FCU Board (B576)
B576 5A Parts Location and List
Page 10
2.FCU Board (B576)
B576 6 Parts Location and List
Page 11
2.FCU Board (B576)
Index
Index
No.
No.
* B576 5170 FCU Board 1
1 B005 7101 IC - FBI 1
2 B028 5510 IC -FACE2 1
Part No.
Part No.
Description
Description
Q’ty Per
Q’ty Per
Assembly
Assembly
Index
Index
No.
No.
101 1102 4205 CT Header - 6P
102 1102 4212 CT Header - 15P
103 1102 4631 CT Connector - 2p
104 1102 7098 Connector - TX25-80P-6ST-N1
105 1102 7389 Connector - FH12-50S-0.5SV
106 1102 7455 Connector - FX6-60S-0.8SV2
107 1102 8063 Connector - 54373-0600
108 1102 8089 Connector - 53493-0801
109 1102 8189 DIMM Connector - 54534-1440
110 1204 2373 Key Board Switch - SKQDPA
111 1206 0084 Lithium Cell-Vl2330/1hf
112 1400 0398 Transistor - 2SC2412K
113 1400 0769 Transistor - 2SA1576A
114 1400 0822 Transistor - 2SA1900
115 1400 0856 Transistor - 2SC3928A
116 1400 0918 Transistor - DTC123JUA
117 1401 1116 Transistor - 2SC5053
118 1402 1336 Diode - 1SS355
119 1402 1343 Diode - RB106L-40
120 1402 1437 Diode - RB500V-40
121 1402 1487 Diode - RB480K
122 1402 1499 Diode UDZS5.1B
123 1402 1515 Diode UDZS6.2B
124 1402 1584 Diode - DAN217U
125 1402 1647 Diode - UDZS3.6B
126 1403 0953 LED - SML-310MT
127 1403 0996 LED - SML-310VT
128 1407 4845 IC TC7S66F
129 1407 5010 IC - TC7SET08FU
130 1407 5197 IC - TC7SZ126FU
131 1407 5349 IC - SN74LV4066APW
132 1407 5368 IC - 74LVC245A TSSOP
133 1407 5659 IC - RL5T882SB
134 1407 5685 IC:SH74AHC1G32HDCK
135 1407 5703 IC - CD4053BPW
Part No.
Part No.
Description
Description
Q’ty Per
Q’ty Per
Assembly
Assembly
B576 7 Parts Location and List
Page 12
Index
No.
136 1407 5881 Modem IC - MN195006-E
137 1407 5968 IC - SN74HCT244APW
138 1407 5969 IC - SN74HCT245APW
139 1408 0810 IC - BA10358F
140 1408 1246 DC/DC Converter:M5291P
141 1408 1296 Voltage Regulator - RN5RZ33B
142 1408 1388 Detector RN5VD28C
143 1408 1416 IC -RH5RI331B
144 1408 1449 IC - M62220FP
145 1408 1550 IC - LM2902PW
146 1408 1653 Opeamp - LMV324IPW
147 1503 0758 Oscillator - MC-306 32.768MHZ
148 1503 1066 Crystal Oscillator - 24.576MHZ
149 1601 7760 Resistor Array
150 1601 7866 Resistor Array - 150Ω ±5%
151 1601 7867 Resistor - 33 Ω ±5% 1/16W
152 1601 7871 Resistor - 68Ω ±5% 1/16W
153 1601 7877 Resistor Array 4.7k Ω ±5% 1/32W
154 1601 7887 Resistor Array - 10K Ω ±5% 1/32W
155 1601 7896 Resistor Array - 56 Ω ±5% 1/32W
156 1604 4333 Capacitor - 100µF±20% 10V
157 1604 4335 Capacitor - 220µF±20% 10V
158 1604 4550 Capacitor - 220µF±20% 25V
159 1604 4695 Capacitor - 100mf:±20%:35V
160 1604 5002 Capacitor - 220µF±20% 6.3V
161 1605 1122 Capacitor 1µF+80-20% 10V
162 1605 1136 Ceramic Capacitor - 33000pF ±10% 2
163 1605 1167 Capacitor - 0.22µF±10% 10V
164 1605 1190 Ceramic Capacitor - 0.022µF±10% 50V
165 1605 1226 Capacitor - 2PF ±0.25pF 50V
166 1605 1228 Capacitor - 0.1uf:±10%:25V
167 1605 1295 Capacitor - 10uf:+80-20%:10V
168 1607 0861 Filter - BK2125HS101
169 1607 1196 Inductor -220uh ±20% 0.33A
170 1607 1405 Inductor - SLF10145-101M1R0
Part No.
Description
Q’ty Per
Assembly
Index
No.
171 1607 1421 Inductor - SLF10145-221MR65
172 1610 1377 Resistor - 0.1 Ω ±2% 1/2W
173 1633 0000 Resistor - 0 Ω 1/10W
174 1634 0000 Resistor - 0 Ω 1/16W
175 1644 0100 Capacitor - 10µF±20% 10V
176 1644 0470 Capacitor - 47µF±20% 10V
177 1650 2681 Chip Resistor - 680Ω:±5%:1/4W
178 1650 3209 Chip Resistor - 2Ω:±5%:1/8W:2125
179 1650 4100 Resistor - 10Ω ±5% 1/10W
180 1650 4101 Resistor - 100Ω±5%1/10W
181 1650 4102 Resistor - 1KΩ ±5% 1/10W
182 1650 4103 Resistor - 10KΩ ±5% 1/10W
183 1650 4104 Resistor - 100KΩ±5%1/10W
184 1650 4105 Resistor - 1MΩ ±5% 1/10W
185 1650 4121 Resistor - 120Ω±5%1/10W
186 1650 4122 Resistor - 1.2KΩ ±5% 1/10W
187 1650 4123 Resistor - 12KΩ±5%1/10W
188 1650 4182 Resistor - 1.8KΩ±5%1/10W
189 1650 4184 Resistor - 180kΩ:±5%:1/10W
190 1650 4201 Resistor - 200Ω±5%1/10W
191 1650 4202 Resistor - 2KΩ±5%1/10W
192 1650 4204 Resistor - 200KΩ±5%1/10W
193 1650 4223 Resistor - 22KΩ±5%1/10W
194 1650 4304 Resistor - 300kΩ:±5%:1/10W
195 1650 4309 Resistor - 3Ω:±5%:1/10W
196 1650 4330 Chip Resistor - 33Ω ±5% 1/10W
197 1650 4331 Resistor - 330Ω±5%1/10W
198 1650 4333 Resistor - 33KΩ±5%1/10W
199 1650 4391 Resistor - 390Ω ±5% 1/10W
200 1650 4472 Resistor - 4.7KΩ ±5% 1/10W
201 1650 4473 Resistor - 47KΩ±5%1/10W
202 1650 4510 Resistor - 51Ω±5%1/10W
203 1650 4560 Chip Resistor - 56Ω ±5% 1/10W
204 1650 4562 Resistor - 5.6KΩ ±5% 1/10W
205 1650 4680 Resistor - 68Ω±5%1/10W
Part No.
Description
Q’ty Per
Assembly
B576 8 Parts Location and List
Page 13
Index
No.
206 1650 4681 Resistor - 680Ω ±5% 1/10W
207 1650 4823 Resistor:82kΩ:±5%:1/10W
208 1654 1001 Resistor - 1KΩ±1%1/10W
209 1654 1002 Resistor - 10KΩ±5%1/10W
210 1654 1003 Resistor - 100KΩ±1%1/10W
211 1654 1100 Resistor - 110Ω±1% 1/10W
212 1654 1102 Resistor - 11KΩ±1%1/10W
213 1654 1183 Resistor - 118KΩ ±1% 1/10W
214 1654 1202 Resistor:12kΩ:±1%:1/10W
215 1654 1503 Resistor - 150KΩ±1%1/10W
216 1654 1802 Resistor - 18KΩ±1%1/10W
217 1654 2001 Chip Resistor - 2kΩ ±1% 1/10W
218 1654 2002 Resistor - 20KΩ±1%1/10W
219 1654 2402 Chip Resistor:24kΩ:±1%:1/10W
220 1654 2702 Resistor - 27KΩ±1%1/10W
221 1654 3303 Resistor - 330KΩ±1%1/10W
222 1654 3602 Resistor - 36K Ω ±1% 1/10W 1608
223 1654 3742 Resistor:37.4kΩ:±1%:1/10W
224 1654 4533 Chip Resistor:453kΩ:±1%:1/10W
225 1654 4872 Chip Resistor:48.7kΩ:±1%:1/10W
226 1654 6202 Resistor - 62KΩ±1%1/10W
227 1654 6809 Resistor - 68Ω±1%1/10W
228 1654 7323 Resistor:732kΩ:±1%:1/10W
229 1654 7502 Resistor - 75KΩ±1%1/10W
230 1654 8200 Resistor - 820Ω±1%1/10W
231 1654 9101 Resistor:9.1kΩ:±1%:1/10W
232 1660 0100 Capacitor - 10PF ±0.5pF 50V
233 1660 2101 Capacitor - 100pF - ±10% - 50V
234 1660 2120 Capacitor - 12 pF ±5% 50V
235 1660 2150 Capacitor - 15pF ±5% 50V
236 1660 2181 Capacitor - 180pF ±5% 50V
237 1660 2271 Capacitor - 270pF - +80-20% - 50V
238 1660 2471 Capacitor - 470pF - ±5% - 50V
239 1660 2820 Capacitor - 82pF ±5% 50V
240 1660 4102 Capacitor - 1000pF ±10% 50V
Part No.
Description
Q’ty Per
Assembly
Index
No.
241 1660 4152 Capacitor - 1500pF ±10% 50V
242 1660 4222 Capacitor - 2200pF - ±10% - 50V
243 1660 4332 Capacitor - 3300pF - ±10% - 50V
244 1660 4682 Capacitor - 6800pF 50V 1608
245 1660 6103 Capacitor - 10000pF - +80%-20%50V
246 1660 8104 Capacitor - 0.1µF+80-20% 25V
247 1907 0012 SDRAM - 128M 2MX16X4 133Mhz
Part No.
Description
Q’ty Per
Assembly
B576 9 Parts Location and List
Page 14
3.NCU Board 120V (B576)
B576 10 Parts Location and List
Page 15
3.NCU Board 120V (B576)
Index
No.
* 5488 6222 NCU-FD-U2 Board - 120V 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 1102 5007 CT Header - 14P
102 1102 6415 Modular Cord - 6-6p
103 1208 1438 Relay - EC2 5ND
104 1400 0826 Transistor - 2SA1776
105 1400 0885 Transistor - 2SC4505Q
106 1401 0821 Diode - 1SS133
107 1402 1607 Diode - S1NB60
108 1403 0598 Photo Coupler - Ps2501-2
109 1403 0620 Photo Coupler
110 1403 0812 Photocoupler - PS2532-1-V
111 1404 0129 Varistor - VR - 63B
112 1404 0276 Varistor- TNR9G331K
113 1404 0283 Varistor - TNR9G431K
114 1404 0989 Varistor - TNR7V121K
115 1601 5395 Resistor - 18Ω ±5% 1/2W
116 1606 2160 Capacitor - 0.47µF±10% 250V
117 1607 0069 Fuse - BL02RN2-R62-PB
118 1607 0396 Choke - Sbt-0180W
119 1607 1396 Transformer - Flt319
120 1611 8473 Resistor - 47kΩ±5%1/4W
121 1642 5220 Capacitor - 22µF±20% 50V
122 1642 5229 Capacitor 2.2µF±20% 50V
123 1650 4104 Resistor - 100KΩ±5%1/10W
124 1650 4151 Resistor - 150Ω ±5%1/10W
125 1650 4180 Chip Resistor - 18Ω±5%1/10W
126 1650 4392 Chip Resistor - 3.9kΩ±5%1/10W
127 1654 2002 Resistor - 20KΩ±1%1/10W
128 1654 4702 Chip Resistor - 47kΩ±1%1/10W
Part No.
Description
Q’ty Per
Assembly
B576 11 Parts Location and List
Page 16
4.NCU Board 230V (B576)
B576 12 Parts Location and List
Page 17
4.NCU Board 230V (B576)
Index
Index
No.
No.
* 5488 6292 NCU-FD-EA2T Board - 230V TWN 1
1 H545 7108 HIC - 220/240V 1
101 1102 5007 CT Header - 14P
102 1102 5943 Connector - 2P
103 1102 5944 Connector - 3P
104 1102 6415 Modular Cord - 6-6p
Part No.
Part No.
Description
Description
Q’ty Per
Q’ty Per
Assembly
Assembly
Index
Index
No.
No.
105 1104 0683 Socket - IMSA-9206H-GF
106 1208 1438 Relay - EC2 5ND
107 1400 0358 Transistor - 2SA950-0
108 1400 0576 Transistor - 2SC3621
109 1400 0826 Transistor - 2SA1776
110 1401 0821 Diode - 1SS133
111 1402 1335 Bridge-S1WB(A)60
112 1402 1556 Diode - MTZJ3.6B
113 1402 1607 Diode - S1NB60
114 1403 0791 Photocoupler - PS2561-1-V
115 1403 0812 Photocoupler - PS2532-1-V
116 1403 0950 Photocoupler- PS2532-2-V
117 1404 0283 Varistor - TNR9G431K
118 1404 0983 Arrestor- RA-102MS-V7-F(5)
119 1404 0989 Varistor - TNR7V121K
120 1600 1153 Resistor - 2W 120 Ω
121 1600 1294 Resistor - 47 Ω
122 1606 1761 Capacitor - 1.0µF250V
123 1606 1860 Capacitor - 0.47µF250V
124 1607 0069 Fuse - BL02RN2-R62-PB
125 1607 0760 Coil TLF9UB302W
126 1607 1246 Transformer P3356
127 1611 8120 Resistor - 12Ω ±5% 1/4W
128 1611 9393 Resistor - 39KΩ±5%1/4W
129 1634 0000 Resistor - 0 Ω 1/16W
130 1640 5470 Capacitor - 47µF±20% 50V
131 1640 5479 Capacitor - 4.7µF±20% 50V
132 1650 4103 Resistor - 10KΩ ±5% 1/10W
133 1650 4302 Resistor - 3KΩ±5%1/10W
134 1653 1602 Resistor - 16KΩ±1%1/8W
135 1654 2401 Resistor - 2.4KΩ ±1% 1/10W
136 1654 7501 Resistor - 7.5KΩ±1%1/10W-1608
137 1660 4102 Capacitor - 1000pF ±10% 50V
138 1660 8104 Capacitor - 0.1µF+80-20% 25V
Part No.
Part No.
Description
Description
Q’ty Per
Q’ty Per
Assembly
Assembly
B576 13 Parts Location and List
Page 18
Page 19
FAX OPTION TYPE 2027
B576
PARTS INDEX
Page 20
Page 21
This section instructs you as to the numbers and names of parts on this machine.
Page 22
Parts Index
Part No.
B576 5170 FCU Board 3 - 10
B576 5170 FCU Board 7 - *
B576 5180 MBU Board 3 - 9
B576 5270 Harness - FCU-NCUSP NA 3 - 8
B576 5272 Harness - FCU-NCUSP EU 3 - 8
B576 8607 Operating Instructions Basic (NA) 3 - 19
B576 8657 Operating Instructions Advance (NA) 3 - 21
Description
Page and
Index No.
Part No.
B005 7101 IC - FBI 7 - 1
B024 5865 Bracket - NCU-Upper 3 - 5
B024 5866 Bracket - NCU-Lower 3 - 6
B024 5868 Bracket - Speaker 3 - 3
B027 1447 Keytop - Fax 3 - 14
B028 5510 IC -FACE2 7 - 2
B031 5861 Shading Plate:Fax Control Unit 3 - 1
B092 5192 FCU I/F Board 3 - 7
B404 3861 SG3 Decal 3 - 16
B418 1370 NCU Cover 3 - 15
B418 7150 Key Top - Copy (NA) 3 - 12
B418 7151 Keytop - Fax-NA 3 - 11
B418 7152 Cover - Keytop-Fax-NA 3 - 13
B418 7170 Key Top - Copy (EU) 3 - 12
B418 7171 Keytop - Fax - EU 3 - 11
B418 7172 Cover - Keytop - Fax - EU 3 - 13
G025 1211 Speaker - GS 3 - 4
H511 5007 Stamp 3 - 18
H523 5350 Telephone Cable 3 - 17
H545 7108 HIC - 220/240V 13 - 1
Description
Page and
Index No.
B576 2 Parts Index
Page 23
Part No.
Description
Page and
Index No.
0451 3006B Tapping Screw - M3x6 3 -101
0453 3006B Tapping Screw - M3x6 3 -103
1102 4205 CT Header - 6P 7 -101
1102 4212 CT Header - 15P 7 -102
1102 4631 CT Connector - 2p 7 -103
1102 5007 CT Header - 14P 11 -101
1102 5007 CT Header - 14P 13 -101
1102 5943 Connector - 2P 13 -102
1102 5944 Connector - 3P 13 -103
1102 6415 Modular Cord - 6-6p 13 -104
1102 6415 Modular Cord - 6-6p 11 -102
1102 7098 Connector - TX25-80P-6ST-N1 7 -104
1102 7389 Connector - FH12-50S-0.5SV 7 -105
1102 7455 Connector - FX6-60S-0.8SV2 7 -106
1102 8063 Connector - 54373-0600 7 -107
1102 8089 Connector - 53493-0801 7 -108
1102 8189 DIMM Connector - 54534-1440 7 -109
1104 0683 Socket - IMSA-9206H-GF 13 -105
1105 0441 Spacer - 8mm 3 -104
1105 0516 Clamp 3 -102
1204 2373 Key Board Switch - SKQDPA 7 -110
1206 0084 Lithium Cell-Vl2330/1hf 7 -111
1208 1438 Relay - EC2 5ND 11 -103
1208 1438 Relay - EC2 5ND 13 -106
1400 0358 Transistor - 2SA950-0 13 -107
1400 0398 Transistor - 2SC2412K 7 -112
1400 0576 Transistor - 2SC3621 13 -108
1400 0769 Transistor - 2SA1576A 7 -113
1400 0822 Transistor - 2SA1900 7 -114
1400 0826 Transistor - 2SA1776 11 -104
1400 0826 Transistor - 2SA1776 13 -109
1400 0856 Transistor - 2SC3928A 7 -115
1400 0885 Transistor - 2SC4505Q 11 -105
1400 0918 Transistor - DTC123JUA 7 -116
1401 0821 Diode - 1SS133 11 -106
Part No.
Description
Page and
Index No.
1401 0821 Diode - 1SS133 13 -110
1401 1116 Transistor - 2SC5053 7 -117
1402 1335 Bridge-S1WB(A)60 13 -111
1402 1336 Diode - 1SS355 7 -118
1402 1343 Diode - RB106L-40 7 -119
1402 1437 Diode - RB500V-40 7 -120
1402 1487 Diode - RB480K 7 -121
1402 1499 Diode UDZS5.1B 7 -122
1402 1515 Diode UDZS6.2B 7 -123
1402 1556 Diode - MTZJ3.6B 13 -112
1402 1584 Diode - DAN217U 7 -124
1402 1607 Diode - S1NB60 11 -107
1402 1607 Diode - S1NB60 13 -113
1402 1647 Diode - UDZS3.6B 7 -125
1403 0598 Photo Coupler - Ps2501-2 11 -108
1403 0620 Photo Coupler 11 -109
1403 0791 Photocoupler - PS2561-1-V 13 -114
1403 0812 Photocoupler - PS2532-1-V 13 -115
1403 0812 Photocoupler - PS2532-1-V 11 -110
1403 0950 Photocoupler- PS2532-2-V 13 -116
1403 0953 LED - SML-310MT 7 -126
1403 0996 LED - SML-310VT 7 -127
1404 0129 Varistor - VR - 63B 11 -111
1404 0276 Varistor- TNR9G331K 11 -112
1404 0283 Varistor - TNR9G431K 11 -113
1404 0283 Varistor - TNR9G431K 13 -117
1404 0983 Arrestor- RA-102MS-V7-F(5) 13 -118
1404 0989 Varistor - TNR7V121K 13 -119
1404 0989 Varistor - TNR7V121K 11 -114
1407 4845 IC TC7S66F 7 -128
1407 5010 IC - TC7SET08FU 7 -129
1407 5197 IC - TC7SZ126FU 7 -130
1407 5349 IC - SN74LV4066APW 7 -131
1407 5368 IC - 74LVC245A TSSOP 7 -132
1407 5659 IC - RL5T882SB 7 -133
B576 3 Parts Index
Page 24
Part No.
Description
Page and
Index No.
1407 5685 IC:SH74AHC1G32HDCK 7 -134
1407 5703 IC - CD4053BPW 7 -135
1407 5881 Modem IC - MN195006-E 7 -136
1407 5968 IC - SN74HCT244APW 7 -137
1407 5969 IC - SN74HCT245APW 7 -138
1408 0810 IC - BA10358F 7 -139
1408 1246 DC/DC Converter:M5291P 7 -140
1408 1296 Voltage Regulator - RN5RZ33B 7 -141
1408 1388 Detector RN5VD28C 7 -142
1408 1416 IC -RH5RI331B 7 -143
1408 1449 IC - M62220FP 7 -144
1408 1550 IC - LM2902PW 7 -145
1408 1653 Opeamp - LMV324IPW 7 -146
1503 0758 Oscillator - MC-306 32.768MHZ 7 -147
1503 1066 Crystal Oscillator - 24.576MHZ 7 -148
1600 1153 Resistor - 2W 120 Ω 13 -120
1600 1294 Resistor - 47 Ω 13 -121
1601 5395 Resistor - 18Ω ±5% 1/2W 11 -115
1601 7760 Resistor Array 7 -149
1601 7866 Resistor Array - 150Ω ±5% 7 -150
1601 7867 Resistor - 33 Ω ±5% 1/16W 7 -151
1601 7871 Resistor - 68Ω ±5% 1/16W 7 -152
1601 7877 Resistor Array 4.7k Ω ±5% 1/32W 7 -153
1601 7887 Resistor Array - 10K Ω ±5% 1/32W 7 -154
1601 7896 Resistor Array - 56 Ω ±5% 1/32W 7 -155
1604 4333 Capacitor - 100µF ±20% 10V 7 -156
1604 4335 Capacitor - 220µF ±20% 10V 7 -157
1604 4550 Capacitor - 220µF ±20% 25V 7 -158
1604 4695 Capacitor:100µF:±20%:35V 7 -159
1604 5002 Capacitor - 220µF ±20% 6.3V 7 -160
1605 1122 Capacitor 1µF +80-20% 10V 7 -161
1605 1136 Ceramic Capacitor - 33000pF ±10% 2 7 -162
1605 1167 Capacitor - 0.22µF ±10% 10V 7 -163
1605 1190 Ceramic Capacitor - 0.022µF ±10% 50V 7 -164
1605 1226 Capacitor - 2PF ±0.25pF 50V 7 -165
Part No.
Description
Page and
Index No.
1605 1228 Capacitor:0.1µF:±10%:25V 7 -166
1605 1295 Capacitor:10µF:+80-20%:10V 7 -167
1606 1761 Capacitor - 1.0µF 250V 13 -122
1606 1860 Capacitor - 0.47µF 250V 13 -123
1606 2160 Capacitor - 0.47µF ±10% 250V 11 -116
1607 0069 Fuse - BL02RN2-R62-PB 13 -124
1607 0069 Fuse - BL02RN2-R62-PB 11 -117
1607 0396 Choke - Sbt-0180W 11 -118
1607 0760 Coil TLF9UB302W 13 -125
1607 0861 Filter - BK2125HS101 7 -168
1607 1196 Inductor -220uh ±20% 0.33A 7 -169
1607 1246 Transformer P3356 13 -126
1607 1396 Transformer - Flt319 11 -119
1607 1405 Inductor:SLF10145-101M1R0 7 -170
1607 1421 Inductor:SLF10145-221MR65 7 -171
1610 1377 Resistor - 0.1 Ω ±2% 1/2W 7 -172
1611 8120 Resistor - 12Ω ±5% 1/4W 13 -127
1611 8473 Resistor - 47kΩ±5%1/4W 11 -120
1611 9393 Resistor - 39KΩ±5%1/4W 13 -128
1633 0000 Resistor - 0 Ω 1/10W 7 -173
1634 0000 Resistor - 0 Ω 1/16W 13 -129
1634 0000 Resistor - 0 Ω 1/16W 7 -174
1640 5470 Capacitor - 47µF ±20% 50V 13 -130
1640 5479 Capacitor - 4.7µF ±20% 50V 13 -131
1642 5220 Capacitor - 22µF ±20% 50V 11 -121
1642 5229 Capacitor 2.2µF ±20% 50V 11 -122
1644 0100 Capacitor - 10µF ±20% 10V 7 -175
1644 0470 Capacitor - 47µF ±20% 10V 7 -176
1650 2681 Chip Resistor:680Ω:±5%:1/4W 7 -177
1650 3209 Chip Resistor:2Ω:±5%:1/8W:2125 7 -178
1650 4100 Resistor - 10Ω ±5% 1/10W 7 -179
1650 4101 Resistor - 100Ω±5%1/10W 7 -180
1650 4102 Resistor - 1KΩ ±5% 1/10W 7 -181
1650 4103 Resistor - 10KΩ ±5% 1/10W 13 -132
1650 4103 Resistor - 10KΩ ±5% 1/10W 7 -182
B576 4 Parts Index
Page 25
Part No.
Description
Page and
Index No.
1650 4104 Resistor - 100KΩ±5%1/10W 11 -123
1650 4104 Resistor - 100KΩ±5%1/10W 7 -183
1650 4105 Resistor - 1MΩ ±5% 1/10W 7 -184
1650 4121 Resistor - 120Ω±5%1/10W 7 -185
1650 4122 Resistor - 1.2KΩ ±5% 1/10W 7 -186
1650 4123 Resistor - 12KΩ±5%1/10W 7 -187
1650 4151 Resistor - 150Ω ±5%1/10W 11 -124
1650 4180 Chip Resistor - 18Ω±5%1/10W 11 -125
1650 4182 Resistor - 1.8KΩ±5%1/10W 7 -188
1650 4184 Resistor:180kΩ:±5%:1/10W 7 -189
1650 4201 Resistor - 200Ω±5%1/10W 7 -190
1650 4202 Resistor - 2KΩ±5%1/10W 7 -191
1650 4204 Resistor - 200KΩ±5%1/10W 7 -192
1650 4223 Resistor - 22KΩ±5%1/10W 7 -193
1650 4302 Resistor - 3KΩ±5%1/10W 13 -133
1650 4304 Resistor:300kΩ:±5%:1/10W 7 -194
1650 4309 Resistor:3Ω:±5%:1/10W 7 -195
1650 4330 Chip Resistor - 33Ω ±5% 1/10W 7 -196
1650 4331 Resistor - 330Ω±5%1/10W 7 -197
1650 4333 Resistor - 33KΩ±5%1/10W 7 -198
1650 4391 Resistor - 390Ω ±5% 1/10W 7 -199
1650 4392 Chip Resistor - 3.9kΩ±5%1/10W 11 -126
1650 4472 Resistor - 4.7KΩ ±5% 1/10W 7 -200
1650 4473 Resistor - 47KΩ±5%1/10W 7 -201
1650 4510 Resistor - 51Ω±5%1/10W 7 -202
1650 4560 Chip Resistor - 56Ω ±5% 1/10W 7 -203
1650 4562 Resistor - 5.6KΩ ±5% 1/10W 7 -204
1650 4680 Resistor - 68Ω±5%1/10W 7 -205
1650 4681 Resistor - 680Ω ±5% 1/10W 7 -206
1650 4823 Resistor:82kΩ:±5%:1/10W 7 -207
1653 1602 Resistor - 16KΩ±1%1/8W 13 -134
1654 1001 Resistor - 1KΩ±1%1/10W 7 -208
1654 1002 Resistor - 10KΩ±5%1/10W 7 -209
1654 1003 Resistor - 100KΩ±1%1/10W 7 -210
1654 1100 Resistor - 110Ω±1% 1/10W 7 -211
Part No.
Description
Page and
Index No.
1654 1102 Resistor - 11KΩ±1%1/10W 7 -212
1654 1183 Resistor - 118KΩ ±1% 1/10W 7 -213
1654 1202 Resistor:12kΩ:±1%:1/10W 7 -214
1654 1503 Resistor - 150KΩ±1%1/10W 7 -215
1654 1802 Resistor - 18KΩ±1%1/10W 7 -216
1654 2001 Chip Resistor - 2kΩ ±1% 1/10W 7 -217
1654 2002 Resistor - 20KΩ±1%1/10W 7 -218
1654 2002 Resistor - 20KΩ±1%1/10W 11 -127
1654 2401 Resistor - 2.4KΩ ±1% 1/10W 13 -135
1654 2402 Chip Resistor:24kΩ:±1%:1/10W 7 -219
1654 2702 Resistor - 27KΩ±1%1/10W 7 -220
1654 3303 Resistor - 330KΩ±1%1/10W 7 -221
1654 3602 Resistor - 36K Ω ±1% 1/10W 1608 7 -222
1654 3742 Resistor:37.4kΩ:±1%:1/10W 7 -223
1654 4533 Chip Resistor:453kΩ:±1%:1/10W 7 -224
1654 4702 Chip Resistor - 47kΩ±1%1/10W 11 -128
1654 4872 Chip Resistor:48.7kΩ:±1%:1/10W 7 -225
1654 6202 Resistor - 62KΩ±1%1/10W 7 -226
1654 6809 Resistor - 68Ω±1%1/10W 7 -227
1654 7323 Resistor:732kΩ:±1%:1/10W 7 -228
1654 7501 Resistor - 7.5KΩ±1%1/10W-1608 13 -136
1654 7502 Resistor - 75KΩ±1%1/10W 7 -229
1654 8200 Resistor - 820Ω±1%1/10W 7 -230
1654 9101 Resistor:9.1kΩ:±1%:1/10W 7 -231
1660 0100 Capacitor - 10PF ±0.5pF 50V 7 -232
1660 2101 Capacitor - 100pF - ±10% - 50V 7 -233
1660 2120 Capacitor - 12 pF ±5% 50V 7 -234
1660 2150 Capacitor - 15pF ±5% 50V 7 -235
1660 2181 Capacitor - 180pF ±5% 50V 7 -236
1660 2271 Capacitor - 270pF - +80-20% - 50V 7 -237
1660 2471 Capacitor - 470pF - ±5% - 50V 7 -238
1660 2820 Capacitor - 82pF ±5% 50V 7 -239
1660 4102 Capacitor - 1000pF ±10% 50V 7 -240
1660 4102 Capacitor - 1000pF ±10% 50V 13 -137
1660 4152 Capacitor - 1500pF ±10% 50V 7 -241
B576 5 Parts Index
Page 26
Part No.
Description
Page and
Index No.
1660 4222 Capacitor - 2200pF - ±10% - 50V 7 -242
1660 4332 Capacitor - 3300pF - ±10% - 50V 7 -243
1660 4682 Capacitor - 6800pF 50V 1608 7 -244
1660 6103 Capacitor - 10000pF - +80%-20%50V 7 -245
1660 8104 Capacitor - 0.1µF +80-20% 25V 13 -138
1660 8104 Capacitor - 0.1µF +80-20% 25V 7 -246
1907 0012 SDRAM - 128M 2MX16X4 133Mhz 7 -247
Part No.
Description
Page and
Index No.
5488 6222 NCU-FD-U2 Board - 120V 3 - 2
5488 6222 NCU-FD-U2 Board - 120V 11 - *
5488 6292 NCU-FD-EA2T Board - 230V TWN 3 - 2
5488 6292 NCU-FD-EA2T Board - 230V TWN 13 - *
B576 6 Parts Index
Loading...
