F08334
F24789
Industrial Caster
Blue elastic rubber caster
F08339
Elastic rubber caster, rigid or swiveling, available with or
without “FULL LOCK” break.
Advantages and benefits
• Low starting effort, rolls easily; tread does not flat-
spot.
• Soft and cushioned non-marking ride.
• Protective metal thread guards.
• Grease seal to hold in lubricant.
• Corrosion-resistant zinc finish.
• ‘’Full LOCK’’ breaking system locks both the wheel
and the swivel.
Non-marking tread:
Conditions :
• Water: Optimal
• Solvents: Efficient
• Detergents: Efficient
Recommanded surfaces:
• Acids: Not recommended
• Extreme cold: Optimal
• Extreme heat : Optimal
• Petroleum products : Efficient
Product
number
F08335 100mm Swiveling caster 100mm (4’’) 70 kg (154 lbs) 35mm (1-3/8’’) 130mm (5-1/8’’)
F08336 100mm, Swiveling caster w/ “FULL
F08334 100mm Rigid caster 100mm (4’’) 70 kg (154 lbs) 35mm (1-3/8’’) 130mm (5-1/8’’)
F08338 125mm Swiveling caster 125mm (5’’) 100 kg (220lbs) 35mm (1-3/8’’) 155mm (6-1/8’’)
F08339 125mm Swiveling caster w/ “FULL
F08337 125mm Rigid caster 125mm (5’’) 100 kg (220lbs) 35mm (1-3/8’’) 155mm (6-1/8’’)
F24789 160mm Swiveling caster 160mm (6-5/16’’) 140 kg (309lbs) 50mm (1-15/16’’) 195mm (7-11/16’’)
F24800 160mm, Swiveling caster w/ “FULL
F24795 160mm Rigid caster 160mm (6-5/16’’) 140 kg (309lbs) 50mm (1-15/16’’) 195mm (7-11/16’’)
Description Wheel Diameter Load Capacity Tread Width Overall Height
LOCK” break
LOCK” break
LOCK” break
100mm (4’’) 70 kg (154 lbs) 35mm (1-3/8’’) 130mm (5-1/8’’)
125mm (5’’) 100 kg (220lbs) 35mm (1-3/8’’) 155mm (6-1/8’’)
160mm (6-5/16’’) 140 kg (309lbs) 50mm (1-15/16’’)
195mm (7-11/16’’)
www.richelieu.com
