Rice Lake SCT-4X-AN, SCT-4X-ETHIP, SCT-4X-MODTCP, SCT-4X-PRONET Manual

SCT-4X Series
Firmware version 01.21.01
Operation Manual
January 4, 2024
PN 221634 Rev A
© Rice Lake Weighing Systems. All rights reserved.
Rice Lake Weighing Systems® is a registered trademark of
Rice Lake Weighing Systems.
registered trademarks of their respective companies.
All information contained within this publication is, to the best of our knowledge, complete and accurate at the
time of publication. Rice Lake Weighing Systems reserves the right to make changes to the technology, features,
specications and design of the equipment without notice.
The most current version of this publication, software, rmware and all other product
updates can be found on our website:
www.ricelake.com
Revision History
This section tracks and describes manual revisions for awareness of major updates.
Revision Date Description
A
January 4, 2024
Initial release
© Rice Lake Weighing Systems • All Rights Reserved 3
Contents
Introduction   7
Transmitter Installation   8
Installation Requirements   8 Electrical Precautions   9 Grounding the System   11 Technical Features   15 Load Cell Installation   16
Wiring Diagrams   17
SCT-4X-AN   17 SCT-4X-ETHIP, SCT-4X-PRONET, SCT-4X-MODTCP   18
Display and Key Functions   19
Quick menu   19
Advanced Programming Menu   20
Advanced Menu and Saving Changes   20 Menu Key Functions   20 Menu Block Diagram   21
SCT-4X Operation Mode   23
Mode 1 “DEP.CH”   23 Mode 2 “IND.CH”   23
ADC Pre-calibration   23
Theoretical Calibration   24
Dependent channels   24 Independent Channels   25
Calibration with Sample Weights   26
Dependent Channels (with Digital Equalization)   26 Independent Channels   28
Equalization   30
Manual Calibration   31
4 Visit our website www.RiceLake.com
Quick Zero Calibration (Pre-Tare Reset)   31
Filter and Stability   32
Filter Adjustment   32 Anti-Peak Filter   33 Stability Detection Sensitivity   33 Stability Detection Time   34 Additional Filter for Stability Detection   34
Gravity   35
Zero Functions and Parameters   36
Auto-Zeroing on Start-Up   36 Maximum Percentage of Manual Zeroing   36 Zero Tracking   36 Zero Tracking Speed   37 Restoring Zero   37 Semi-Automatic Zeroing   37
Tare Functions and Parameters   38
Tare Mode   38 Semi-Automatic Tare   38 Predetermined Tare   38 Clearing a Tare   38 Restoring a Tare   38
Alibi Memory   39
Enabling the Alibi Memory   39 Saving a Weighing Operation in Alibi Memory   39 Reading Alibi Memory   40 Initializing Alibi Memory   40
User Functions   41
High Resolution   41 Peak Detection   41 Converting Units of Measure   41 Alibi Memory   41 No Function   41
Input Configuration   42
Output Configuration   43
© Rice Lake Weighing Systems • All Rights Reserved 5
Analog Output Configuration   44
Serial Communication Configuration   46
Selection of the PC serial port   46
Printer Port (COM.PRN) Configuration   47
Transmission mode   47 Baud Rate, Parity, Data Bits, Stop Bits   48 Printer power on mode   48 CTS signal   48 Print Language   49 Printing Reactivation   49
PC Port (COM.PC) Configuration   50
Transmission Mode   50 Baud Rate, Parity, Data Bits, Stop Bits   51
USB Port Configuration   51
Communication Protocols   52
Standard String   52 Extended String   52 Multi-Scale String   53 Serial Commands   54 Modbus Protocol   57
Diagnostics   60
Unbalancing   61
Programming the Setpoints   62
Restoring Factory Settings   63
Alarms   64
6 Visit our website www.RiceLake.com

Introduction

Thank you for purchasing this product.
This manual contains instructions for correct installation and commissioning of the SCT-4X four channel digital weight transmitter, including the following models:
SCT-4X-AN
SCT-4X-ETHIP
SCT-4X-MODTCP
SCT-4X-PRONET
This manual contains the instructions for a correct installation and commissioning of the SCT-4X four channel digital weight transmitter.
Also, this manual provides information on the correct operation and maintenance of the weigh transmitter. It is essential to pay the close attention to operation procedures.
It is recommended that you carefully follow the instructions for programming the weight transmitter; performing actions not indicated in this manual could compromise the functionality of the scale.
Manuals are available from Rice Lake Weighing Systems at www.ricelake.com/manuals
i
Warranty information is available at www.ricelake.com/warranties
Any problem with the product must be reported to the manufacturer or to the retailer where it was purchased. Always TURN OFF THE POWER SUPPLY prior to installation or repair action.
© Rice Lake Weighing Systems • All Rights Reserved 7

Transmitter Installation

Installation Requirements

Observe the following conditions for correct installation of the transmitter and of the load receiver:
Flat, level support surface.
Stability and absence of vibrations.
Absence of aggressive dusts and vapours.
Absence of draughts.
Make sure that the platform is levelled or that the load cells are evenly supported.
Moderate temperature and humidity 59°F 86°F (15°C - 30°C and 40% - 70%).
Do not install in an environment where there is a risk of explosion.
All transmitter connections must be made in accordance with applicable regulations in the area and environment of installation. Observe the electrical precautions listed in the section “Electrical precautions”.
Ensure that it is correctly earthed, see the relevant section “Grounding the system”.
Do not perform welding when the load cells have already been installed.
If necessary, use watertight sheaths and fittings to protect the load cell cables.
Any junction boxes must be watertight.
Anything not expressly described in this manual constitutes improper use of the equipment.
8 Visit our website www.RiceLake.com

Electrical Precautions

Use a regulated mains supply within ± 10% of the rated voltage.
The electrical protections (fuses, etc.) are the responsibility of the installer.
Observe the recommended minimum distances between cables of dierent categories (see table on page 10).
The following cables must comply with the maximum permissible lengths (see table on page 10), they must be shielded and must beinserted alone in metal conduits or pipes:
- the load cell extension cables;
- the signal amplifier cables;
- the cables for connecting the serial ports;
- the analog output cables.
The cell or amplifier cables must have an independent input in the electrical panel. They must be connected (if possible) directly to the terminal block of the transmitter without passing through the conduit with other cables.
Fit “RC” filters:
- on the contactor coils;
- on the solenoid valve coils;
- on all devices that produce electrical interference.
If condensation can occur inside the weight transmitter, it is advisable to keep the equipment powered at all times.
Connections to load cells and any external device must be as short as possible.
The cable ends (connectors, leads, terminals, etc.) must be installed correctly; the cable shielding must be kept intact until close to the connection point.
If the transmitter is placed inside an electrical panel, a shielded cable must also be used for the power supply.
© Rice Lake Weighing Systems • All Rights Reserved 9
RECOMMENDED DISTANCES AND CABLE CLASSIFICATION
Category I Category II Category III Category IV
≥ 3.94 in (100 mm)
≥ 7.87 in (200 mm)
≥ 19.66 (500 mm)
Distance
Fieldbus, LAN network (PROFIBUS or Ethernet).
Shielded data cables
DC supply cables with voltage > 60 V and < 400 V.
AC supply cables with voltage > 25 V and < 400 V.
Classification
(RS232...).
Shielded cables for analog digital signals < 25 V (sensors, load cells...).
≥ 3.94 in (100 mm)
≥ 19.66 (500 mm)
Power supply cables with voltage > 400 V.
Telephone cables.
≥ 19.66 (500 mm)
Any cable subject to lightning danger.
Low voltage power sup­ply cables (< 60 V).
Coaxial cables.
MAXIMUM ALLOWED LENGTHS
Load cell RS232 RS485 Analog output
164 ft (50 m) with 6 x 24 AWG (0.25 mm2) cable;
328 ft (100 m) with 6 x 22 AWG (0.5 mm2) cable.
49 ft (15 m) with baud rate up to 19200.
3937 ft (1200 m) with shielded 2 x 24 AWG twisted pair with outer braid + aluminium strip.
CURRENT:
328 ft (100 m) with 2 x 24 AWG (0.25 mm2) cable;
492 ft (150 m) with 2 x 22 AWG (0.5 mm2) cable;
984 ft (300 m) with 2 x 17 AWG (1 mm2) cable.
VOLTAGE:
164 ft (50 m) with 2 x 24 AWG (0.25 mm2) cable;
246 ft (75 m) with 2 x 22 AWG (0.5 mm2) cable;
150 meters with 2 x 17 AWG (1 mm2) cable.
10 Visit our website www.RiceLake.com
DGT1SP / XDGT1S
DGT1SP / X - wrong

Grounding the System

For correct earthing and optimal system operation, the transmitter, load cells, junction box, if any, and weighing structure must be earthed.
TRANSMITTER
The earth connection must be made via the appropriate terminal. The cable cross-section must be less than 14 AWG (2.5 mm2). The transmitter must be powered by a dedicated power supply with ground. Do not connect EARTH and GND terminals together!
SCT-4X Correct earth connection
1 2
GND Vdc
+-
SCT-4X Incorrect earth connection
1 2
GND Vdc
+-
LOAD CELLS AND JUNCTION BOX
The connection must be made by connecting the earth cables to the earth bar (cables that must have a cross-section of at least 6 AWG (16 mm2); finally, connect the earth bar to the earth post with a cable having a cross-section of at least 1-1/0 AWG (50 mm2).
EXAMPLES:
If the load cells are connected to the transmitter through a junction box, the cable shield from the transmitter and the cell cable shields must be connected to the earth socket of the junction box (refer to the junction box manual) and the junction box must be earthed using a copper cable with a cross-section of not less than
6 AWG (16 mm2)
.
If the load cells are connected directly to the transmitter (without using the junction box), the cell cable shields must be connected to theearthing point (or earth bar).
If the weighing system involves large and/or outdoor structures (weighbridges, silos, etc.) and the distance between the junction box and the weight transmitter is greater than 33 ft (10 m), connect the cell cable shields to the earth socket in the junction box.
WEIGHING STRUCTURE
Earth the weighing structure and/or any unconnected structures (e.g. silos that release material onto the weighing structure) using cables with a cross-section of not less than 6 AWG (16 mm2). Also connect the upper part with the lower part of each cell by means of a copper braid with a cross-section not less than 6 AWG (16 mm2) (refer to the earthing examples on page 12 and page 13).
SERIAL CABLES AND CONNECTED INSTRUMENTS
Connect the serial cable shield to the earthing point (or earth bar) inside the panel. To avoid any undesired eects, the earth reference ofthe connection cable, power supply and transmitter must be at the same potential.
© Rice Lake Weighing Systems • All Rights Reserved 11
i
GENERAL NOTES:
All earth cables must be of suitable length, so as to obtain an overall resistance of the earthing system of less than 1 .
If the weighing system involves large and/or outdoor structures (weighbridges, silos, etc.):
- the earth connection must be made by connecting the earth cables to an earth bar and the earth bar to the earth post with a cable having a cross-section of not less than 1-1/0 AWG (50 mm2);
- the earth post must be placed at a distance of at least 33  (10 m) from the structure.
If the load receiver is more than 33  (10 m) from the transmitter, we recommend using the SENSE line and load cells equipped with a (SENSE) compensation circuit.
12 Visit our website www.RiceLake.com
EXAMPLE OF EARTHING OF A WEIGHBRIDGE
Junction box
placed on the side wall of the pit
Weight transmitter
Load cell
Weighbridge
Weighbridge
Drilled copper plate positioned
on the side wall
Load cell bypass jumper
Earth cables Ø 8 - sec. 1-1/0 AWG (50 mm2) Ø 11.3 - sec. 95 AWG (100 mm2)
Earth post positioned under or near the weighbridge
© Rice Lake Weighing Systems • All Rights Reserved 13
EXAMPLE OF EARTHING OF A SILO
Protective earth by­pass for the load cell
Load cell
14 Visit our website www.RiceLake.com

Technical Features

POWER SUPPLY 12 - 24 VDC LPS or with class 2 power supply.
MAXIMUM ABSORPTION
(without load cells)
OPERATING TEMPERATURE From 14°F to 104°F (-10°C to +40°C) DISPLAY DIVISIONS 10000e, 2 x 3000e for legal weighing, expandable up to 800,000 for internal use (with a
CONVERSION SPEED Up to 2600 conversions / sec with single channel
MINIMUM VOLTAGE PER DIVISION 0.3 V (restricted transmitter); 0.03 V (non-restricted transmitter). COUNTING RESOLUTION 1,500,000 points (with input signal 3 mV/V) DISPLAY 6 digits, 0.56 in (14.2 mm) height SIGNALS 9 status indicator LED lights KEYPAD Mechanical with 5 keys. TARE FUNCTION Subtraction possible over the entire range LOAD CELL POWER SUPPLY 5 VDC, 230 mA LOAD CELL CONNECTION 6 wires (CELL1) with sense, 4 wires (CELLS 2, 3, 4) CONNECTABLE CELLS Up to 16 350  cells CASE Made of plastic (self-extinguishing PPO), suitable for DIN rail mounting (EN 60715 - DIN43880)
SERIAL OUTPUTS 1 half duplex RS485 bidirectional port on terminal (SCT-4X-AN).
SCT-4X-AN: 4.5 W
SCT-4X-ETHIP, SCT-4X-PRONET, SCT-4X-MODTCP: 7.5 W
minimum cell signal of 1.6 mV/V)
Up to 100 conversions / sec with 4 channels
or wall mounting
1 RS232 bidirectional port on terminal
2 ETHERNET ports (versions
1 USB port (micro USB type B) on front panel → Virtual COM (Device)
SCT-
4X-ETHIP*,
SCT-
4X-MODTCP*,
SCT-
4X-PRONET*)
* Fieldbus models are not equipped with port 232
OUTPUTS / INPUTS 2 photomosfet NO or NC outputs: max 60 VDC 0.5 A max / 48 VAC 0.5A;
2 configurable inputs (bidirectional optocouplers): 12 - 48 VDC; Input reading and output update time: 1 millisecond
16-bit analog output (SCT-4X-AN version)
Current: 0 - 20 mA / 4 - 20 mA. Voltage: 0 - 5 VDC, 0 - 10 VDC. The maximum applica­ble resistance on the current output is 300  while the minimum applicable resist­ance on the voltage output is 1 k.
LOAD CELL SENSITIVITY Maximum sensitivity of the connectible load cells: 6 mV/V FIELDBUS UPDATE RATES Up to 120 Hz
© Rice Lake Weighing Systems • All Rights Reserved 15

Load Cell Installation

After carrying out the instructions for the platform or load receiver, the shielded cable from the cell(s) must be properly connected to the terminal block(s) of the transmitter (from CELL1 to CELL4; see page 17).
The transmitter has one channel (CELL1) for 6-wire connection to load cells (using the REFERENCE), while for the remaining channels (CELL2, CELL3, CELL4) only 4-wire connection is allowed. The REFERENCE allows you to compensate for any voltage drop on the section of cable connecting the transmitter to the load receiver. It is especially useful when the distance between the transmitter and the load receiver is more than 33 ft (10 meters), or in high-resolution applications.
i
The SCT-4X has a DIP switch (EXC-SEN) located under the cover for Cell 1 and 2 connections. Set the DIP switch to correspond with the type of load cells connected to the transmitter:
ON for a 4-wire connection
OFF for a 6-wire connection
4-Wire Connection
CELL2 / CELL3 / CELL4
6-Wire Connection
CELL2 / CELL3 / CELL4 CELL1
CELL1
16 Visit our website www.RiceLake.com

Wiring Diagrams

SCT-4X-AN

REF +
E +
E +
-
EXC -
+
EXC +
S+ S-
REF -
-
+
REF +
SIG -
E -
LOAD CELL 1
SIG +
+
-
-
E -
+
S+ S-
SIG -
EXC +
EXC -
33 3235 34 29 2831 30 25 2427 26 21 2023 22 19 18
SIG +
REF -
LOAD CELL 2, 3, 4
JUMPER J1
Internal use
LOAD CELL 4 LOAD CELL 3 LOAD CELL 2 LOAD CELL 1
J1
1 2
ANALOG
11 129 10
RS232
13 14 156 7 83 4 5
+-
I-
I+
IN 2
IN 1
COM
12 / 24 Vdc
RL1
RL2
COM
V+
TX
V-
RX
RS485 TERM
ON
RS485
16 17
GND
A(+)
B(-)
© Rice Lake Weighing Systems • All Rights Reserved 17
LOAD CELL 1

SCT-4X-ETHIP, SCT-4X-PRONET, SCT-4X-MODTCP

REF +
E +
E +
+
-
-
E -
+
S+ S-
+
-
-
E -
+
S+ S-
REF -
LOAD CELL 2, 3, 4
SIG +
SIG -
EXC +
EXC -
33 3235 34 29 2831 30 25 2427 26 21 2023 22 19 18
EXC -
EXC +
REF -
SIG -
REF +
SIG +
JUMPER J1
Internal use
LOAD CELL 4 LOAD CELL 3 LOAD CELL 2 LOAD CELL 1
ETHERNET I/O PORT 1
ETHERNET I/O PORT 2
J1
1 2
6 7 83 4 5
+-
IN 2
IN 1
COM
12 / 24 Vdc
RL1
RL2
COM
RS485 TERM
ON
RS485
16 17
B(-)
A(+)
18 Visit our website www.RiceLake.com

Display and Key Functions

Symbol Description

Quick menu

Semi-automatic zeroing. Decreases the selected digit.
Semi-automatic tare. Increases the selected digit.
Activates the function. Selects the digit to be changed. Prolonged pressure allows you to select the active scale (only in MODE 2 “IND.CH”).
Confirms a value. Prints / Transmits data.
Reboots the transmitter.
Symbol Description
>0<
~
NET
F
W1
SP1
W2
SP2
Gross weight on zero.
Unstable weight.
A tare is active.
A special function is active.
Output 1 is active.
Output 2 is active.
The transmitter is equipped with a quick menu, through which you can program the main parameters of the scale. To enter the quick menu, follow the procedure below:
1. Reboot the transmitter.
2. Press the key when the display shows 8 8 8 8 8 8 .
© Rice Lake Weighing Systems • All Rights Reserved 19

Advanced Programming Menu

The advanced menu contains all the transmitter configuration parameters for the most advanced adjustments.

Advanced Menu and Saving Changes

1. Reboot the transmitter.
2. Press the key when the display shows 8 8 8 8 8 8 .
i
HOW TO EXIT THE SETUP AND SAVE CHANGES
1. Press several times, until the display shows “ s a v e ?”.
2. Press to save or to exit without saving.

Menu Key Functions

Previous parameter.
Next parameter.
Access the parameter / confirm setting.
Exit a parameter (without saving).
FUNCTION OF THE KEYS WHEN ENTERING NUMBERS
Increases the selected digit.
Decreases the selected digit.
Selects the next digit.
Confirms the value.
Resets the value. If pressed again, exits entering.
i
In the menu description on the following pages the symbol indicates repeated pressing of the key until the parameter indicated is reached.
Complete menu on pages 21 - 22
MENU ACCESS:
888888
20 Visit our website www.RiceLake.com
Press the key during the start­up procedure.
SAVING THE PARAMETERS:
Press the key several times, until the display shows
S A V E ? . Press the key to confirm.
1
...
p r e . C a l

Menu Block Diagram

8 8 8 8 8 8 T Y P E
A
B
f . m o d e
C
s e t u p
Mode of use (page 23).
1
f u n c t
2
R e a c t
3
C l o C k
4
t a r e
5
r s . z e r o
6
r s . t a r e
7
u n b a l
1
C o n f i G
2
d s p . r f
Functions (page 41).
Reactivating printing (page 49).
Date and time
Tare (page 38).
Zero restore (page 37).
Tare restore (page 38).
Unbalancing (page 61).
Display updating frequency.
Calibration, filtering and metrological parameters
Continued on page 22.
3
s e r i a l
4
f l d . b u s
5
i n i . a l
5
i n p u t s
6
o u t p u t
7
a n . o u t
1
p C . s e l
2
C o m . p r n
3
C o m . p C
4
u s b
Selection of the PC serial port (page 46).
Printer port configuration (page 47).
PC port configuration (page 50).
USB configuration (page 51).
Fieldbus communication protocol ( refer to Fieldbus manual).
Alibi memory initialisation (page 40).
1
i n p . 0 1
Digital inputs (page 42).
2
i n p . 0 2
1
o u t . 0 1
Digital outputs (page 43).
2
o u t . 0 2
Analog output (page 44).
Visible only on SCT-4X-AN models.
LEGEND:
D
d i a G
Indicates repeated pressing of the key.
8
d e f a u
Restore factory settings (page 63).
Diagnostics (page 60).
Parameter visible only under certain conditions.
Parameter or menu subject to approval.
Default value of the parameter.
© Rice Lake Weighing Systems • All Rights Reserved 21
Full C o n f i G s e t u p menu is displayed.
1
C o n f i G
1C
p r e . C a l S e t u p
2
n C h a n
3
C h a n
4
p a r a m
ADC converter pre-calibration (page 23).
Number of channels used. Calibration (page 24 / 25 / 26 / 29).
Channel to be configured. Calibration (page 25 / 29).
1
s t a b i l
2
a u t o - 0
3
0 - p e r C
Filter (page 32).
Zero parameters (page 36).
4
0 . t r a C k
5
0 . t r k . s p
6
d i v . s t b
7
t i m . t b
8
S t b . f l t
Stability parameters (pages 33 / 34).
5
G r a v
6
C a l i b
7
0 . C a l i b
9
p e a k . f l
1
x . x x x x x
1
d e C i
2
u . m .
3
d i v
4
r a n G e 1
5
r a n G e 2
6
C a l i b . p
7
t h e o . C a
8
m a n . C a l
Anti-peak filter (page 33).
Gravity of calibration zone / zone of use (page 35).
Calibration parameters
Real calibration with sample weights (page 26).
Theoretical calibration (page 24 / 25).
Manual calibration (page 31).
Zero calibration (page 31).
Complete menu on pages 21 - 22
MENU ACCESS:
888888
22 Visit our website www.RiceLake.com
Press the key during the start­up procedure.
SAVING THE PARAMETERS:
Press the key several times, until the display shows
S A V E ? . Press the key to confirm.

SCT-4X Operation Mode

8 8 8 8 8 8
A
T Y P E
1
d e p . C h
2
i n d . C h
Smart junction box mode.
Multi-scale mode.

Mode 1 “DEP.CH”

Allows you to connect the load cells (from 2 to 4) directly and to equalise them.

Mode 2 “IND.CH”

Allows you to manage up to 4 independent scales.
Scale 1 Scale 2
Scale 3
Scale 4
i
Change displayed scale by pressing Mode for 2 seconds, use Zero and Tare to select, and then press Print to confirm.

ADC Pre-calibration

8 8 8 8 8 8
A
T Y P E
C 1 1
S e t u p
C o n f i G p r e . C a l
For manufacturer use only
LEGEND:
Indicates repeated pressing of the key.
Parameter visible only under certain conditions.
Parameter or menu subject to approval.
Default value of the parameter.
© Rice Lake Weighing Systems • All Rights Reserved 23

Theoretical Calibration

Dependent channels

8 8 8 8 8 8
CALIBRATION PROCEDURE:
A 1
T Y P E d e p . C h
C
S e t u p
1 1
C o n f i G
p r e . C a l
2
n C h a n
6
C a l i b
1
d e C i
2
u . m .
3
d i v
4
r a n G e 1
7
t h e o . C a
1
C e l . s e n
2
C e l . C A p
3
d e a d . l d
4
k n o . w G t
1. Select mode of use d e p . C h.
2. Set the number of channels used (from 1 to 4 ).
3. Set the calibration parameters:
d e C i = Number of decimals. u . m . = Unit of measurement ( k G, G, t, l b). d i v = Minimum division. r a n G e 1 = Maximum range.
4. Set the cell data:
s e n . C e l = Cell sensitivity (given by the sum of the mV/V value of each cell). C e l . C a p = Total capacity of the cells (given by the sum of the capacities of each cell).
5. Enter the weight value of the structure in the d e a d . l d parameter. If you do not know this value, enter “0”.
6. If the structure contains a quantity of material whose weight value is known (e.g. full silo), enter this value in the K N o . W G T parameter.
7. Application of theoretical calibration:
Press the key to exit the calibration menu. The display shows t h . C a l ?. Press the key to confirm the use of the theoretical
calibration, or the key to cancel.
Complete menu on pages 21 - 22
MENU ACCESS:
888888
24 Visit our website www.RiceLake.com
Press the key during the start­up procedure.
SAVING THE PARAMETERS:
Press the key several times, until the display shows
S A V E ? . Press the key to confirm.

Independent Channels

8 8 8 8 8 8
A 2
T Y P E i n d . C h
C
S e t u p
1
1 1
C o n f i G p r e . C a l
2
n C h a n
3
C h a n
6
C a l i b
1
d e C i
2
u . m .
3
d i v
4
r a n G e 1
7
t h e o . C a
1
C e l . s e n
2
C e l . C A p
3
d e a d . l d
4
k n o . w G t
CALIBRATION PROCEDURE:
1. Select mode of use i n d . C h.
2. Set the number of connected scales (from 1 to 4 ).
3. Select the scale to be calibrated (from 1 to 4 ).
4. Set the calibration parameters:
d e C i = Number of decimals. u . m . = Unit of measurement ( k G, G, t, l b). d i v = Minimum division. r a n G e 1 = Maximum range.
5. Set the cell data:
s e n . C e l = Cell sensitivity (given by the sum of the value of each cell). C e l . C a p = Total capacity of the cells (given by the sum of the value of each cell).
6. Enter the weight value of the structure in the d e a d . l d parameter. If you do not know this value, enter “0”.
7. If the structure contains a quantity of material whose weight value is known (e.g. full silo), enter this value in the K N o . W G T parameter.
8. Application of theoretical calibration:
Press the key to exit the calibration menu. The display shows t h . C a l ?. Press the key to confirm the use of the theoretical calibration,
or the key to cancel.
9. Repeat the procedure from point 3 for each scale to be calibrated.
LEGEND:
Indicates repeated pressing of the key.
Parameter visible only under certain conditions.
Parameter or menu subject to approval.
Default value of the parameter.
© Rice Lake Weighing Systems • All Rights Reserved 25

Calibration with Sample Weights

Dependent Channels (with Digital Equalization)

8 8 8 8 8 8
A 1
T Y P E d e p . C h
C
S e t u p
1 1
C o n f i G p r e . C a l
2
n C h a n
6
C a l i b
1
d e C i
2
u . m .
3
d i v
4
r a n G e 1
6
C a l i b . p
1
e q u a l
2
n t p
3
T p 0
4
d d t 1
5
t p 1
2
d d t 2
3
T p 2
4
d d t 3
CALIBRATION PROCEDURE:
5
t p 3
1. Select mode of use d e p . C h.
2. Set the number of connected scales (from 1 to 4 ).
3. Set the calibration parameters:
d e C i = Number of decimals. u . m . = Unit of measurement ( k G, G, t, l b). d i v = Minimum division. r a n G e 1 = Maximum range.
4. Equalise the cells.
Attention: The equalisation procedure is not compulsory. However, for a good accuracy of the system, it is recommended to perform it. To perform equalisation follow the instructions on page 30.
5. Acquire the calibration points (continued on next page)
Complete menu on pages 21 - 22
MENU ACCESS:
888888
26 Visit our website www.RiceLake.com
Press the key during the start­up procedure.
SAVING THE PARAMETERS:
Press the key several times, until the display shows
S A V E ? . Press the key to confirm.
5. Acquire the calibration points:
A
Display View:
n t P
press
D
Display View:
d d t 1
Press and enter the value of the first
sample weight using the , and keys.
To confirm press
B
Display View:
n 3
Press and select the number of calibration
points using the and keys
(from 1 to 3). To confirm press
E
Display View:
t p 1
Load the scale with the first sample weight
and press
C
Display View:
t p 0
Unload the scale.
To acquire the zero point press
F
Display View:
d d t 2
Press and enter the value of the second
sample weight using the , and keys.
To confirm press
G
Display View:
t p 2
Load the scale with the second sample
weight and press
H
Press and enter the value of the third
sample weight using the , and keys.
Display View:
d d t 3
Load the scale with the third sample weight
To confirm press
i
For successful calibration, the value of the largest sample weight must be at least 50% of the capacity.
I
Display View:
t p 3
and press
LEGEND:
Indicates repeated pressing of the key.
Parameter visible only under certain conditions.
Parameter or menu subject to approval.
Default value of the parameter.
© Rice Lake Weighing Systems • All Rights Reserved 27

Independent Channels

A 2
8 8 8 8 8 8
T Y P E i n d . C h
C
S e t u p
1 1
C o n f i G P r e . C a l
2
n C h a n
3
C h a n
6
C a l i b
1
d e C i
2
u . m .
3
d i v
4
r a n G e 1
6
C a l i b . p
1
2
3
4
n t p
T p 0
d d t 1
t p 1
CALIBRATION PROCEDURE:
1. Select mode of use i n d . C h.
2. Set the number of connected scales (from 1 to 4 ).
3. Select the scale to be calibrated (from 1 to 4 ).
4. Set the calibration parameters:
d e C i = Number of decimals. u . m . = Unit of measurement ( k G, G, t, l b). d i v = Minimum division. r a n G e 1 = Maximum range.
5. Acquire the calibration points (continued on next page)
5
6
7
8
d d t 2
t p 2
d d t 3
t p 3
Complete menu on pages 21 - 22
MENU ACCESS:
888888
28 Visit our website www.RiceLake.com
Press the key during the start­up procedure.
SAVING THE PARAMETERS:
Press the key several times, until the display shows
S A V E ? . Press the key to confirm.
5. Acquire the calibration points:
A
Display View:
n t P
press
D
Display View:
d d t 1
Press and enter the value of the first
sample weight using the , and keys.
To confirm press
B
Display View:
n 3
Press and select the number of calibration
points using the and keys
(from 1 to 3). To confirm press
E
Display View:
t p 1
Load the scale with the first sample weight
and press
C
Display View:
t p 0
Unload the scale.
To acquire the zero point press
F
Display View:
d d t 2
Press and enter the value of the second
sample weight using the , and keys.
To confirm press
G
Display View:
t p 2
Load the scale with the second sample
weight and press
H
Press and enter the value of the third
sample weight using the , and keys.
Display View:
d d t 3
Load the scale with the third sample weight
To confirm press
i
For successful calibration, the value of the largest sample weight must be at least 50% of the capacity.
I
Display View:
t p 3
and press
LEGEND:
Indicates repeated pressing of the key.
Parameter visible only under certain conditions.
Parameter or menu subject to approval.
Default value of the parameter.
© Rice Lake Weighing Systems • All Rights Reserved 29

Equalization

If the dependent channel mode has been set, you can improve the accuracy of the system by digitally equalising the connected cells.
8 8 8 8 8 8
A
A
C
Display View:
e q 0
Completely unload the scale
Press
T Y P E
S e t u p
1
d e p . C h
1
C o n f i G
1
p r e . C a l
p r e . C a l
6 1
C a l i b d e C i
C a l i b
6
C a l i b . p
B
Display View:
e q 1
Load the equalisation weight * so that it
rests as much as possible only on cell 1
2
4
3
Press
1
e q u a l r e s e t ?
e q u a l r e s e t ?
C
Load the equalisation weight * so that it rests as much as possible only on cell 2
Visible only if
t y p e = D e p . C h
Display View:
e q 2
1
4 3
Press
D
Display View:
e q 3
Load the equalisation weight * so that it rests as much as possible only on cell 3
1
4
2
Press
(visible only
if C H A N = 3 )
E
Load the equalisation weight * so that it rests as much as possible only on cell 4
Display View:
e q 4
1 2
Press
3
(visible only
if C H A N = 4 )
F
Display View:
e q o k
When equalisation is complete the display
shows the message E Q O K and automatically
exits the equalisation menu.
n t p
i
Equalisation can only be performed if the system is configured with dependent channels and calibration with sample weights is active.
For successful equalisation, it is advisable to use a compact weight with as small a supporting surface as possible, so that it rests as much as possible on only one cell. The weight value must be at least 20% of the capacity.
Complete menu on pages 21 - 22
MENU ACCESS:
888888
30 Visit our website www.RiceLake.com
Press the key during the start­up procedure.
SAVING THE PARAMETERS:
Press the key several times, until the display shows
S A V E ? . Press the key to confirm.

Manual Calibration

8 8 8 8 8 8
If you know the number of ADC converter points for a known weight (for example if you want to copy the calibration from one transmitter to another) the calibration points can be entered manually:
1. The display shows m o d . p n t, proceed by pressing the ke y.
2. Using the and keys, select the calibration point you want to enter / change (from 0 to 3 ).
Press the key to confirm.
3. The display shows w e i G h t, use the , and keys to enter the weight value.
Press the key to confirm.
4. The display shows p o i n t s, use the , and keys to enter the converter points value.
Press the key to confirm.
A
C
S e t u p
T Y P E
1 1
C o n f i G p r e . C a l
6
C a l i b
1
d e C i
8
m a n . C a l
i
Repeat the procedure for each calibration point.
If i n d . C H mode has been selected, the procedure must be repeated for each scale ( C H A N 2 , 3 , 4 ).

Quick Zero Calibration (Pre-Tare Reset)

8 8 8 8 8 8
ADC
A
T Y P E
C
S e t u p
1
C o n f i G
7
0 . C a l i b
i
If i n d . C H mode has been selected, it is first necessary to
select the channel on which the zero calibration is to be
performed ( C H A N 1 2 , 3 , 4 ).
ADC

Tp 0 Tp n
LEGEND:
Indicates repeated pressing of the key.
Parameter visible only under certain conditions.
Kg
Tp 0 Tp n
Parameter or menu subject to approval.
Default value of the parameter.
© Rice Lake Weighing Systems • All Rights Reserved 31
Kg

Filter and Stability

Filter Adjustment

8 8 8 8 8 8
A
T Y P E
C
S e t u p
Filter Updating frequency (Hz) * Response time (ms) Use
1 channel 4 channels 1 channel 4 channels
F 1 f 2 f 3 f 4 f 5 f 6 f 7 f 8 f 9 f 1 0
5 3 5000 8000 High resolution or
10 5 2500 5000
20 10 1000 2000 Simple weighing
40 17 450 1000
80 30 300 800
160 50 150 500
325 100 50 150
650 * 35 *
1300 * 20 *
2600 * 10 *
1 1
C o n f i G p r e . C a l
14
S t a b i l P a r a m
Oscillating loads
Dosing
High-speed weight transmission
i
In the case of a restricted transmitter, it is possible to select only filter F 3 .
Filters f 8 , f 9 and f 1 0 can be used only for applications with a single channel.
(*) The filter aects the speed of the PC port only if A L L . M A X mode has been selected.
Complete menu on pages 21 - 22
MENU ACCESS:
888888
Press the key during the start­up procedure.
SAVING THE PARAMETERS:
Press the key several times, until the display shows
S A V E ? . Press the key to confirm.
32 Visit our website www.RiceLake.com

Anti-Peak Filter

The transmitter has an additional filter for the elimination of sudden weight peaks (e.g. shocks or falling material). The following parameters, opportunely configured, allow you to eliminate the peak by blocking the weight for its entire duration.
The weight is blocked if it remains within the number of divisions set in P K . L K . D V for the time set in P K . L K . T M and is subsequently unblocked if the weight deviates from the blocking value for a number of divisions greater than P K . D I V (o P K . b n . d v ) or if the time set in
P K . T I M E has elapsed.
8 8 8 8 8 8
A
T Y P E
C
S e t u p
1 1
C o n f i G P r e . C a l
4
p a r a m
1
s t a b i l
9 1
P e a k . f l P k . l k . d v
2
3
4
5
P k . l k . t m
P k . d i v
p k . b n . d v
P k . t i m e

Stability Detection Sensitivity

It is possible to decide that tare, zero and print functions (from keypad or serial command / PLC) are performed only if the weight is stable.
8 8 8 8 8 8
A
C
S e t u p
T Y P E
1 1
C o n f i G p r e , C a l
3
P a r a m
1
S t a b i l
6
d i v . s t b
The value 0 disables the stability control. By entering a value other than 0, you enable stability control. Enter the number of deviation divisions beyond which the transmitter detects instability.
LEGEND:
Indicates repeated pressing of the key.
Parameter visible only under certain conditions.
Parameter or menu subject to approval.
From 0 to 99.
= 02.
= 02.
Default value of the parameter.
© Rice Lake Weighing Systems • All Rights Reserved 33

Stability Detection Time

8 8 8 8 8 8
If the weight remains within the number of divisions set in D I V . S T B for the time set in this parameter, the weight is
stable. Enter the value in ms. In case of a restricted transmitter, the value is fixed at 500 ms.
A
F . m o d e
B
S e t u p
1
C o n f i G
1
p r e . C a l
2
p a r a m
1
s t a b i l
7
t i m . s t b

Additional Filter for Stability Detection

from 10 to 10000.
500. = 500.
8 8 8 8 8 8
Additional filter that locks the weight if it oscillates around a value for a maximum of 10 divisions. The weight is unlocked if the value increases/decreases for the number of divsions set in the parameter S.T.DIVS for a time value greater than the time set in the parameter S.T.TIME. The value 0 disables the filter.
A
F . m o d e
B
S e t u p
1
C o n f i G
1
p r e . C a l
2
p a r a m
1
s t a b i l
8 1
s t b . f l t
s . f . t i n e
2
s . f . d i v s
from 0 to 2000.
0. = 0.
from 0 to 100.
0. = 0.
Complete menu on pages 21 - 22
MENU ACCESS:
888888
34 Visit our website www.RiceLake.com
Press the key during the start­up procedure.
SAVING THE PARAMETERS:
Press the key several times, until the display shows
S A V E ? . Press the key to confirm.

Gravity

8 8 8 8 8 8
A
T Y P E
C
S e t u p
1 1
C o n f i G p r e . C a l
5
G r a v
This parameter allows you to correct the gravity acceleration value. Before calibration, set the value of the calibration zone. Next, set this value to the value of the zone of use. Any dierence between the two values will be automatically compensated.
i
In the case of a restricted transmitter, the value is read-only.
EXAMPLE:
1. Before calibration, in the G R A V parameter enter the value
9.80543.
From 9 . 7 5 0 0 1 to 9 . 8 4 9 9 9 .
= 9 . 8 0 5 4 3 .
Calibration zone
Italy
g = 9.80543
2. Calibrate the transmitter.
3. Before using the transmitter, in the G R A V parameter enter the
value 9.80549.
Zone of use
Wisconsin
g = 9.80549
LEGEND:
Indicates repeated pressing of the key.
Parameter visible only under certain conditions.
Parameter or menu subject to approval.
Default value of the parameter.
© Rice Lake Weighing Systems • All Rights Reserved 35

Zero Functions and Parameters

8 8 8 8 8 8
A
T Y P E
C
S e t u p
1 1
C o n f i G p r e . C a l

Auto-Zeroing on Start-Up

2
a u t o . 0
1
d i s a b
2
3
C y C l e
e n a b
1
C . p e r C
1
C . p e r C
4 1
p a r a m s t a b i l
2
a u t o . 0
3
0 - p e r C
4
0 . t r a C k
5
0 . t r k . s p
Disabled.
Enabled, enter in C . P E R C the % value of the capacity. In I n d . C h mode, it is possible to perform an auto-zeroing
cycle of all connected scales. Enter in C . p e r C the % value
of the capacity.
% auto-zeroing on start-up.
% manual zeroing.
Zero tracking.
Zero tracking speed.
from 0 to 50%. from 0 to 10%.
Visible only if
t y p e i n d . C h

Maximum Percentage of Manual Zeroing

3
0 - p e r c
Indicates the weight value that can be zeroed by key or command. The value is expressed as % of the full scale. For example: if the scale has a full scale (RANGE1) of 1000 kg, by setting 3% it is possible to zero up to 30 kg. The value 0 disables the ZERO key and the zeroing commands.
from 0 to 50%. from 0 to 2%.
= 2%.

Zero Tracking

This menu allows to set zero tracking, i.e. the compensation parameter of the thermal drift of the scale; the set value corresponds to
the number of divisions that is reset to zero in the time set in the parameter 0 . t r k . s p .
4
0 . t r a C k
1
t r 1 0
2
t r 8
3
t r 6
4
t r 4
5
t r 2
6
t r 1
7
t r 1 / 2
8
t r 1 / 4
10 divisions.
8 divisions.
6 divisions.
4 divisions.
2 divisions.
1 division.
1/2 division.
1/4 division.
i
In the case of a restricted transmitter, it is
possible to select the values t r 1 / 2 , t r 1 / 4 , t r n o.
9
T R n o
Complete menu on pages 21 - 22
Tracking disabled.
MENU ACCESS:
888888
36 Visit our website www.RiceLake.com
Press the key during the start­up procedure.
SAVING THE PARAMETERS:
Press the key several times, until the display shows
S A V E ? . Press the key to confirm.

Zero Tracking Speed

5
0 . t r k . s p
It indicates the value of time that elapses from when the instrument detects stability to when zero tracking takes eect. The value is expressed in ms.

Restoring Zero

8 8 8 8 8 8
A
C
F . m o d e
T y p e
1
f u n C t
5
r s . z e r o
D I S A B
E N A B
from 100 to 5000. from 1000.
= 1000.
Zero restoring disabled.
Zero restoring enabled.
 If a u t o . 0 = d i s a b:
The last zero in the memory before turning o the power is always restored.
 If a u t o . 0 = e n a b / C y C l e:
The last zero in the memory before turning o the power is restored only if the auto-zeroing fails.

Semi-Automatic Zeroing

By pressing the key, or sending the zero command, the transmitter zeroes the gross weight on the scale. For a moment the display
shows “ z e r o” and then it shows 0 (gross weight).
The semi-automatic zeroing cannot be performed if:
The weight on the scale is greater than the zero capacity ( 0 . p e r C ).
The weight is unstable.
LEGEND:
Indicates repeated pressing of the key.
Parameter visible only under certain conditions.
Parameter or menu subject to approval.
Default value of the parameter.
© Rice Lake Weighing Systems • All Rights Reserved 37

Tare Functions and Parameters

Tare Mode

8 8 8 8 8 8
A
C
F . m o d e
T y p e
1
f u n C t
5
t a r e
l o C k
u n l o C K
D i s a b
Tare blocked. When the gross weight drops to 0, the tare remains engaged.
Tare unlocked. When the gross weight drops to 0, the tare is cleared.
Tare disabled.

Semi-Automatic Tare

By pressing the key, or sending the tare command, the transmitter sets as tare the weight on the scale. For a moment the display shows
t a r e” and then it shows 0 (net weight). The
The semi-automatic tare cannot be performed if:
The weight is less than one division.
The weight is overloaded.
NET
light indicates that the net weight is shown on the display.

Predetermined Tare

By holding down the key, or by means of the predetermined tare command, it is possible to enter a tare value manually.
For a moment the display shows “ - t m - ” and shows the tare present (or 0 if no tare is present).
Enter the tare value and press to confirm.

Clearing a Tare

The tare can be cleared in dierent ways:
By unloading the scale and performing a semi-automatic tare.
By entering a predetermined tare value of 0.
If the weight is negative, pressing the key.

Restoring a Tare

8 8 8 8 8 8
A
C
F . m o d e
T y p e
1
f u n C t
5
r s . t a r e
D I S A B
Restoring tare disabled.
Complete menu on pages 21 - 22
MENU ACCESS:
888888
38 Visit our website www.RiceLake.com
E N A B
Press the key during the start­up procedure.
Restoring tare enabled. When restarting, the last tare in the memory before turning o the power is restored.
SAVING THE PARAMETERS:
Press the key several times, until the display shows
S A V E ? . Press the key to confirm.

Alibi Memory

The alibi memory allows you to store the weight values transmitted to the computer for further processing and/or data integration. The stored values can then be retrieved from the PC port or directly on the display of the transmitter for later checking.

Enabling the Alibi Memory

8 8 8 8 8 8
A
C
F . m o d e
T y p e
1 1
f u n C t v i s s
4
a l i b i

Saving a Weighing Operation in Alibi Memory

A weighing operation is stored after receiving the PID serial command (see “Serial commands” page 54) or after pressing the key. The transmitter transmits on the PC port the gross weight, the tare and an ID code that uniquely identifies the weighing. The ID has the following format:
• rewrite number: 5-digit number (from 00000 to 00255) indicating the number of complete rewrites;
• weighing number: 6-digit number (from 000000 to 131072) indicating the weighing number in the current rewrite. Each time it is saved, the weighing number is increased by 1; when it reaches the value 131072, it starts again from 000000 and the rewrite number is increased by 1.
Example
If the weighing that has been saved is as follows:
PIDST,1, 1.000lb, 1.000lb,00126-131072
The next one will be:
PIDST,1, 1.000lb, 1.000lb,00127-000000
A weighing operation can only be saved if the weight ≥ 0, stable and valid (not underloaded or overloaded). To store the weighing operation by key, the function must be active (see “Reactivating printing” on page 50). In addition, if the transmitter is restricted, the weight must exceed 20 divisions.
If these conditions are not met:
• the response to the PID command will have “NO” instead of the ID (PIDST,1, 1.000kg, 1.000kg,NO);
• there is no transmission when the key is pressed.
LEGEND:
Indicates repeated pressing of the key.
Parameter visible only under certain conditions.
Parameter or menu subject to approval.
Default value of the parameter.
© Rice Lake Weighing Systems • All Rights Reserved 39

Reading Alibi Memory

FROM THE TRANSMITTER (MANUAL)
By pressing the key you can read a saved weight:
you will be asked to enter the rewrite number “ r e w . i d” (from 0 to 255) and the ID number “ i d” (from 0 to 131072).
The weighing data are shown. Use the and keys to scroll through the following information:
C h . X”, where X indicates the scale number.
U m YY”, where YY indicates the unit of measurement ( k G, G, t or l b).
G r o s s”, followed by the gross weight.
T a r e / t a r e p t”, followed by the tare value.
Press the key to return to weighing.
The weighing of an ID can only be verified if:
• it has a rewrite number equal to the current alibi memory number and a weighing number ≤ the last value received with the PID command;
• it has a rewrite number ≥ 0, but 1 less than the current alibi memory value, and a weighing number greater than the last value received with the PID command.
FROM PC
To read a weighing operation from a PC, see the serial command READING A WEIGHING OPERATION IN THE ALIBI MEMORY” on
page 54.
FROM PLC
To read a weighing operation from a PLC, refer to the Modbus and Fieldbus protocol manuals.
i
If the alibi memory is empty, when the key is pressed the display shows “ e m p t y” for one second and returns to weighing mode. If an invalid ID is entered, the display shows “ N o i d ” and returns to weighing mode.

Initializing Alibi Memory

8 8 8 8 8 8
A
T Y P E
C
S e t u p
1
C o n f i G
4
i n i . a l
Not visible if the transmitter is legal for trade.
i
This operation deletes all saved weighing operations; it is not possible to delete a weighing operation individually.
Complete menu on pages 21 - 22
MENU ACCESS:
888888
40 Visit our website www.RiceLake.com
Press the key during the start­up procedure.
SAVING THE PARAMETERS:
Press the key several times, until the display shows
S A V E ? . Press the key to confirm.

User Functions

8 8 8 8 8 8
A
C
F . m o d e
T y p e

High Resolution

v i s s
Weight display in high resolution (x10). Press the key to activate or deactivate the function. When the weight is displayed in high resolution, the F light is lit. In the case of a restricted transmitter, the high-resolution weight display is automatically deactivated after 5 seconds.
1 1
f u n C t v i s s
2
3
C o n v e r
4
a l i b i
5
Not visible if T Y P E = I N D . C H and N C H A N > 1 .
p e a k
n o n e

Peak Detection

p e a k
Detection of the maximum weight value during a time interval. Press the key to activate the function. The display shows
- p e a k - ” every 5 sec and the transmitter shows the maximum weight reached since the function was activated. To deactivate the function press the again, the display shows “ p e a k o f” for a moment and shows the instantaneous
weight again.

Converting Units of Measure

c o n v e r
Converting the scale unit of measurement using a free conversion factor. Press the key to convert the weight to pounds. By holding down the key, you can enter a free conversion factor, which will be multiplied by the weight. Example: to make the display show the cubic meters of water on the scale, enter the value 997 as the conversion factor. The key can be used to switch from the main unit of measurement to the secondary unit at any time. When the secondary unit of measurement is displayed, the F light is lit.

Alibi Memory

a l i b i
(See section “Alibi memory” page 40).

No Function

n o n e
LEGEND:
Indicates repeated pressing of the key.
No function when the key is pressed.
Parameter visible only under certain conditions.
Parameter or menu subject to approval.
Default value of the parameter.
© Rice Lake Weighing Systems • All Rights Reserved 41
Input Configuration
The indicator has 2 configurable inputs (bidirectional optocouplers).
8 8 8 8 8 8
A
T Y P E
C
S e t u p
1
C o n f i G
5
i n p u t s
1
2
i n p . 0 1
i n p . 0 2
Such as i n p . 0 2 ( = z e r o).
1
N o N E
2
z e r o
3
t a r e
4
m o d e
5
p r i n t
6
7
o f f
8
D i s . k e y
C
No function.
key.
key.
key.
key.
key.
Reboots the transmitter.
Disable keypad (and re-enable).
INPUT CONNECTION:
3 4 5
VdcGND
i
The input is activated when there is a potential dierence IN2) and terminal 3 (INCOM). The inputs are bidirectional, therefore it is possible to invert GND and Vdc.
between terminals 4 - 5 (IN1 and
Complete menu on pages 21 - 22
MENU ACCESS:
888888
42 Visit our website www.RiceLake.com
Press the key during the start­up procedure.
SAVING THE PARAMETERS:
Press the key several times, until the display shows
S A V E ? . Press the key to confirm.
Output Configuration
The indicator has 2 programmable outputs (photomosfet).
8 8 8 8 8 8
A
T Y P E
C
S e t u p
1
C o n f i G
6
o u t p u t
1
2
o u t . 0 1
o u t . 0 2
Such as o u t . 0 2 .
1
f u n C
1
0 n o n e
2
1 G r o s
3
2 n e t
4
4 G r o . 0
5
5 n e t . 0
6
6 m o t i
7
2 3 k . p r
8
2 5 . k . m o d
9
2 6 k . C
10
2 7 . k . z e r
11
2 8 . k . t a r
No function.
Setpoint on gross weight.
Setpoint on net weight.
Gross weight on zero.
Net weight on zero.
Unstable weight.
Pressing the key.
Pressing the key.
Pressing the key.
Pressing the key.
Pressing the key.
12
2 9 e r r
13
3 0 . n e t . t
14
3 1 . u n b
2 1
n o / n C n o
2
n C
3 1
o n . s t a t d r C t
2
s t b l
4 1
r l . i s t i s t . o f f
2
i s t . o n
5 1
e n a b . t m 0 . 0 0 0
6 1
d e l a y 0 . 0 0 0
7 1
s i G n p o s i t
2
n e G . p o s
Error.
Setpoint on net weight with tare.
Unbalancing.
Contact normally open.
Contact normally closed.
Direct activation / deactivation.
Activation / deactivation at stability.
Hysteresis disabled.
Hysteresis enabled.
Activation duration time (s).
Activation delay time (s).
Positive weight operation.
Absolute value operation.
LEGEND:
Indicates repeated pressing of the key.
Parameter visible only under certain conditions.
3
n e G a t
Parameter or menu subject to approval.
Negative weight operation.
Default value of the parameter.
© Rice Lake Weighing Systems • All Rights Reserved 43
Analog Output Configuration
The SCT-4X-AN model has an analog output in voltage (0 - 5 / 0 - 10 VDC) or current (4 - 20 / 0 - 20 mA ).
8 8 8 8 8 8
A
T Y P E
C
S e t u p
1
C o n f i G
Visible only on SCT-AX-AN models.
7
a n . o u t
1 1
m o d e a o . G r o
2
2
a o . t y p e
3
C a l i b
1
2
3
4
5
1
2
3
4
a o . n e t
0 5 V
0 1 0 V 0 2 0 m A 4 2 0 m a
m a n u a l
a o 0 v
a o 1 0 v a o 0 m a
a o . 2 0 m a
Analog output for gross weight.
Analog output for net weight. Operation 0 - 5 V. Operation 0 - 10 V. Operation 0 - 20 mA. Operation 4 - 20 mA.
Manual setting of D/A points.
Setting D/A points at 0 V.
Setting D/A points at 10 V.
Setting D/A points at 0 mA.
Setting D/A points at 20 mA.
4
C h a n
5
w e i G t . 1
6
o u t 1
7
w e i G t . 2
8
o u t 2
9
w e i G t . 3
10
o u t 3
Selection of the scale associated with the analog output.
Weight 1.
Value in V / mA / D/A points for w e i G t . 1 .
Weight 2.
Value in V / mA / D/A points for w e i G t . 2 .
Weight 3.
Value in V / mA / D/A points for w e i G t . 3 .
i
This menu allows an advanced configuration of the analog output.
For simple configurations, it is recommended to use the quick menu (Ref. Quick Start Guide).
Complete menu on pages 21 - 22
MENU ACCESS:
888888
44 Visit our website www.RiceLake.com
Press the key during the start­up procedure.
SAVING THE PARAMETERS:
Press the key several times, until the display shows
S A V E ? . Press the key to confirm.
9 . 9 4
9 . 9 8
1 0 . 0 0
Kg
mA / V







Kg
mA / V






Kg
mA / V





CALIBRATION PROCEDURE:
A
Connect a multimeter to the Enter the parameter to be changed:
a o 0 v / a o 1 0 v / a o 0 m a / a o . 2 0 m a and set an approximate value.
Voltage output 63300 ~ 10 V 0 ~ 0 V
transmitter
Current output 58200 ~ 20 mA 0 ~ 0 mA
D
Press to update the output value on the multimeter.
B
.
Press to update the output value on the multimeter.
E
Repeat the procedure from point “CC”
until the desired value is reached, then press to save.
C
Increase or decrease the D/A points value to reach the desired output.
100 D/A points ~ 0.015 V - 0.035 mA 1000 D/A points ~ 0.15 V - 0.35 mA
Example: Increase to 63550.
a o 1 0 v
from 63300
F
Save the changes (press the key several times until you reach the message key to confirm).
s a v e ?
, then press the
ANALOG OUTPUT GRAPHS:
Positive weight operation
i
Voltage or current operation is determined by the connection to the transmitter terminals:
Current: 9 (+) and 10 (-). Voltage: 11 (+) and 12 (-).
Negative weight operation
LEGEND:
Indicates repeated pressing of the key.
Parameter visible only under certain conditions.
Parameter or menu subject to approval.
Default value of the parameter.
© Rice Lake Weighing Systems • All Rights Reserved 45
Serial Communication Configuration
The transmitter has 3 serial ports (COM1 / 232, COM2 / 485, USB) that can be used indiscriminately to communicate:  In bidirectional mode with the PC / PLC (“PC” port);  In one-directional mode with the PC, thermal printer, repeater (“PRN” port);
The USB port always allows quick connection to the PC to change / save / restore the transmitter settings at any time.
It is necessary to choose which port to use as PC and, consequently, which one to use as PRN.

Selection of the PC serial port

8 8 8 8 8 8
A
T Y P E
C
S e t u p
1
C o n f i G
3
s e r i a l
1 1
P C . s e l 4 8 5
2
2 3 2
i
Port 232 is not available on models SCT-4X-MODTCP, SCT-4X-PRONET and SCT-4X-ETHIP.
Use of serial port 485 as PC port (Pin 16 and 17).
Use of serial port 232 as PC port (Pin 13, 14 and 15).
Complete menu on pages 21 - 22
MENU ACCESS:
888888
46 Visit our website www.RiceLake.com
Press the key during the start­up procedure.
SAVING THE PARAMETERS:
Press the key several times, until the display shows
S A V E ? . Press the key to confirm.
Printer Port (COM.PRN) Configuration
8 8 8 8 8 8
A
T Y P E
C
S e t u p
1
C o n f i G
3
s e r i a l
1
P C . s e l
2 1
C o m . p r n P r . m o d e
2
b a u d . p r
3
p r t y . p r
4
b i t . p r
5
s t o p . p r
6
p w r . p r n
7
P r n . C t s
Transmission mode.
Baud rate.
Parity.
Data bits.
Stop bits.
Printer power on mode.
CTS signal.
8
p r . C o n f
Print language.

Transmission mode

1
p r . m o d e
i
For the specifications of transmission modes, strings and protocols see the section “TRANSMISSION PROTOCOLS”.
Setting p r . m o d e = r e p e . 6 automatically sets the serial port to 4800, N-8-1. It is however possible to set it dierently.
1
p r - n o
2
p r p C . h k
3
r e p e . 6
4
p r P C . e x
5
p r p C . s t
6
a l l . e x t
7
a l l . s t d
8
t p r
Transmission not enabled.
Transmission of the weight value when the key is pressed.
Transmission of the 6-digit weight.
Extended string transmission when the key is pressed.
Standard string transmission when the key is pressed.
Continuous transmission of the extended string.
Continuous transmission of the standard string.
Enables printing on a printer.
When selecting one of these protocols, you are asked if you want to display the 485 address at the beginning of the string:
D E V . I D Y E S / N o.
LEGEND:
Indicates repeated pressing of the key.
Parameter visible only under certain conditions.
Parameter or menu subject to approval.
Default value of the parameter.
© Rice Lake Weighing Systems • All Rights Reserved 47

Baud Rate, Parity, Data Bits, Stop Bits

2
b a u d . p r
3
p r t y . p r
4
b i t . p r
5
s t o p . p r
1
2
3
4
5
6
7
8
1
2
3
1
2
1
9 6 0 0 4 8 0 0 2 4 0 0 1 2 0 0
1 1 5 2 0 0
5 7 6 0 0 3 8 4 0 0 1 9 2 0 0
n o n e e v e n
o d d
8 7
1
No parity, 8 data bits, 1 stop bit.
Even.
Odd.
8 bits.
7 bits.
1 stop bit.
2
2
2 stop bits.

Printer power on mode

It is possible to set the way the printer is turned on:
6
p W R . P R N
1
p w r . e x t
2
e x t . o f f
Printer always on.
Printer turned on at the time of printing.

CTS signal

On serial port 232 there is the CTS (Clear to send) signal in pin 16.
7
p r n . C t s
1
n o C t s
2
E m u C t s
CTS signal not managed.
Emulation of the CTS signal.
visible only if p r . m o d e = t p r
Complete menu on pages 21 - 22
MENU ACCESS:
888888
48 Visit our website www.RiceLake.com
Press the key during the start­up procedure.
SAVING THE PARAMETERS:
Press the key several times, until the display shows
S A V E ? . Press the key to confirm.

Print Language

8
p r . C o n f
1 1
l a n G i t a l
2
s e t . t i c

Printing Reactivation

8 8 8 8 8 8
A
C
F . m o d e
T y p e
1
2 1
Italian.
2
3
4
5
e s p a f r a n d e u t e n G l
Spanish.
French.
German.
English.
Ticket number setting.
f u n C t
r e a c t z e r o
2
a l w a y s
visible only if p r . m o d e = t p r
i
Using the Rice Lake Tools software you can configure additional printing parameters.
Reactivation of printing after the weight has changed from zero.
Printing always active.
3
i n s t
Reactivation of printing after the weight has changed from instability.
LEGEND:
Indicates repeated pressing of the key.
Parameter visible only under certain conditions.
Parameter or menu subject to approval.
Default value of the parameter.
© Rice Lake Weighing Systems • All Rights Reserved 49
PC Port (COM.PC) Configuration
8 8 8 8 8 8
A
C
S e t u p
T Y P E

Transmission Mode

1
p C m o d e
1
2
r e p e . 6
o n d e
1
C o n f i G
3
s e r i a l
1
P C . s e l
C o m . P C P C m o d e
Transmission on demand.
Transmission of the 6-digit weight.
1
2
b a u d
3
p a r i t y
4
b i t
5
s t o p
Transmission mode.
Baud rate.
Parity.
Data bits.
Stop bits.
3
P r i n . s t
4
p r i n . e x
5
4 8 5
6
m o d b u s
7
a l l . m a x
8
a l l . s t d
9
a l l . e x t
10
s t a b . s t
11
s t a b . e x
Standard string transmission when the key is pressed.
Extended string transmission when the key is pressed.
Transmission with 485 protocol (enter the 485 address of the transmitter).
Transmission with Modbus protocol (refer to the Modbus protocol manual).
Continuous high speed weight transmission for conversion applications.
Continuous transmission of the standard string.
Continuous transmission of the extended string.
Stable transmission of the standard string.
Stable transmission of the extended string.
When selecting one of these protocols, you are asked if you want to display the 485 address at the beginning of the string:
D E V . I D Y E S / N o.
Complete menu on pages 21 - 22
MENU ACCESS:
888888
50 Visit our website www.RiceLake.com
Press the key during the start­up procedure.
SAVING THE PARAMETERS:
Press the key several times, until the display shows
S A V E ? . Press the key to confirm.

Baud Rate, Parity, Data Bits, Stop Bits

2
b a u d
1
9 6 0 0
2
4 8 0 0
3
2 4 0 0
4
1 2 0 0
5
1 1 5 2 0 0
6
5 7 6 0 0
7
3 8 4 0 0
8
1 9 2 0 0
3
p a r i t y
4
b i t
5
s t o p
1
2
3
1
2
1
2
n o n e e v e n
o d d
8 7
1 2
No parity, 8 data bits, 1 stop bit.
Even.
Odd.
8 bits.
7 bits.
1 stop bit.
2 stop bits.
USB Port Configuration
8 8 8 8 8 8
A
T Y P E
C
S e t u p
1
C o n f i G
3
s e r i a l
1
P C . s e l
4
U s b
Useful for the configuration of the instrument from PC with Rice Lake Tools.
LEGEND:
Indicates repeated pressing of the key.
Parameter visible only under certain conditions.
Parameter or menu subject to approval.
Default value of the parameter.
© Rice Lake Weighing Systems • All Rights Reserved 51

Communication Protocols

Standard String

[01]ST,GS, 0.0,kg<CR LF>
Where:
01 Transmitter code 485 (2 characters), only if communication mode 485 is enabled
ST Scale status (2 characters):
US - Unstable weight ST - Stable weight OL - Weight overload (out of range) UL - Weight underload (out of range)
, Character ASCII 044
GS Type of weight data (2 characters)
GS - Gross NT - Net VL - Microvolts RZ - Converter points
, Character ASCII 044
0.0 Weight (8 characters including the decimal point)
, Character ASCII 044
kg Unit of measurement (2 characters)
<CR LF> Transmission terminator, characters ASCII 013 and ASCII 010

Extended String

[01]1ST, 0.0,PT 20.8, 0,vv,01/02/19 11:12:13<CR LF>
Where:
01 Transmitter code 485 (2 characters), only if communication mode 485 is enabled
1 Number of the active scale
ST Scale status (2 characters):
US - Unstable weight ST - Stable weight OL - Weight overload (out of range) UL - Weight underload (out of range)
, Character ASCII 044
0.0 Weight (8 characters including the decimal point)
, Character ASCII 044
PT Preset tare indication
20.8 Tare (8 characters including the decimal point)
, Character ASCII 044
0 Character ASCII 048
, Character ASCII 044
kg Unit of measurement (2 characters)
, Character ASCII 044
01/02/19 11:12:13 dd/mm/yy hh:mm:ss (only with REXD command and optional clock card)
<CR LF> Transmission terminator, characters ASCII 013 and ASCII 010
52 Visit our website www.RiceLake.com

Multi-Scale String

[01]ST, 612,kg,ST, 61.4, t,ST, 6.17, g,ST, 0.617,lb<CR LF>
Where:
01 Transmitter code 485 (2 characters), only if communication mode 485 is enabled
ST Scale 1 status (2 characters):
US - Unstable weight ST - Stable weight VL - Microvolts RZ - Converter points
, Character ASCII 044
612 Scale 1 weight (8 characters including the decimal point)
, Character ASCII 044
kg Scale 1 unit of measurement (2 characters)
, Character ASCII 044
ST Scale 2 status (2 characters):
US - Unstable weight ST - Stable weight VL - Microvolts RZ - Converter points
, Character ASCII 044
61.4 Scale 2 weight (8 characters including the decimal point)
, Character ASCII 044
t Scale 2 unit of measurement (2 characters)
, Character ASCII 044
ST Scale 3 status (2 characters):
US - Unstable weight ST - Stable weight VL - Microvolts RZ - Converter points
, Character ASCII 044
6.17 Scale 3 weight (8 characters including the decimal point)
, Character ASCII 044
g Scale 3 unit of measurement (2 characters)
, Character ASCII 044
ST Scale 4 status (2 characters):
US - Unstable weight ST - Stable weight VL - Microvolts RZ - Converter points
, Character ASCII 044
0.617 Scale 4 weight (8 characters including the decimal point)
, Character ASCII 044
lb Scale 4 unit of measurement (2 characters)
<CR LF> Transmission terminator, characters ASCII 013 and ASCII 010
If t y p e = i n d . C h and n C h a n ≥ 2
© Rice Lake Weighing Systems • All Rights Reserved 53

Serial Commands

By selecting the PC port on demand mode ( o n d e), you can communicate with the transmitter via serial commands.
For each command received, the transmitter emits a string containing the response (refer to the command description) or one of the following signals:
OK<CR LF> Command sent when sending a correct command. This response does not imply that the command is executed.
ERR01<CR LF> Command sent correctly but followed by letters entered unintentionally (e.g. READF, TARES).
ERR02<CR LF> Incorrect command data.
ERR03<CR LF> Command sent not allowed (transmitter busy, or not used in the selected operating mode).
ERR04<CR LF> Command sent non-existent.
i
If the 485 protocol has been selected, you must precede the command with the transmitter address (e.g. 01READ).
WEIGHT READING (standard string)
Format Response
WEIGHT READING IN HIGH RESOLUTION (X10) AUTOMATIC TARE
Format Response
MANUAL TARE
Format
Where Response
R E A D <CR LF>
Standard string<CR LF>.
G R 1 0 <CR LF>
Standard string with weight in resolution x10 <CR LF>.
T M A N t t t t t t
<CR LF>
tttttt tare value
OK<CR LF> (or ERRxx).
EXTENDED OR MULTI-SCALE WEIGHT READING
Format Response
Format Response
ZEROING (of active channel)
Format Response
R E X T <CR LF>
Extended string<CR LF>.
T A R E <CR LF>
OK<CR LF> (or ERRxx).
Z E R O <CR LF>
OK<CR LF> (or ERRxx).
By entering a manual tare value of 0, the tare on the scale is cleared.
DISABLING KEYPAD ENABLING KEYPAD
Format Response
READING INPUTS READING OUTPUTS
Format Where
Response
Where
K E Y E D <CR LF>
OK<CR LF> (or ERRxx).
I N P U n <CR LF>
n Input (1 / 2).
I N P U n v v v v
<CR LF>
n Input number.
Input status:
vvvv
0000 = Not active. 0001 = Active. FFFF = Input reading error.
Format Response
Format Where
Response
Where
K E Y E E <CR LF>
OK<CR LF> (or ERRxx).
O U T S n <CR LF>
n Output (1 / 2).
O U T S n v v v v
<CR LF>
vvvv
54 Visit our website www.RiceLake.com
n Output number.
Output status:
0000 = Not active. 0001 = Active. FFFF = Output reading error.
PRESSING A KEY
Format
Where
Response
RELEASING A KEY BRIDGE BETWEEN THE SERIAL PORTS
Format Response
SCALE INFORMATION
Format
Response
K E Y P x x <CR LF>
xx Key code.
00
01
02
03
04
OK<CR LF> (or ERRxx).
K E Y R <CR LF>
OK<CR LF> (or ERRxx).
R A L L <CR LF>
s s , b , N N N N N N u u , L L L L L L u u ,
Y Y T T T T T T u u , S S S , A A A , C C C C
, , R R R R R - I I I I I I <CR LF>
i
To simulate pressing a key, you must send the KEYP and KEYR commands in succession. If more than 1.5 s pass after the KEYP command is sent, the transmitter will execute the function associated with prolonged pressing of the key.
Format Response
B R I D G E 1 <CR LF>
OK<CR LF> (or ERRxx).
Where
UL = Underload.
ss
b Number of the active scale.
NNNNNNuu Net weight with unit of measurement.
LLLLLLuu Gross weight with unit of measurement.
YY PT if a manual tare is present or “ ”.
TTTTTTuu Tare with unit of measurement.
SSS
AAA
CCCC Code of last key pressed.
RRRRR Last rewrite number saved to Alibi memory.
IIIIII Last ID number saved to Alibi memory.
OL = Overload. ST = Stable weight. US = Unstable weight.
Scale status: 000 = scale weighing. 001 = entering a numerical value. 002 = scale in technical menu.
Counter keys pressed:
0001 =
0002 =
0003 =
0004 =
0170 =
© Rice Lake Weighing Systems • All Rights Reserved 55
READING OF MICROVOLTS READING OF CONVERTER POINTS
Format Response
INITIALISING ALIBI MEMORY
Format Response
READING A WEIGHING OPERATION IN THE ALIBI MEMORY
Format
Response
Where
SAVING A WEIGHING OPERATION IN THE ALIBI MEMORY
M V O L
Standard string<CR LF>.
A L D L
ALDLOK / ALDLNO <CR LF>
A L R D X X X X X - Y Y Y Y Y Y <CR LF>
b , L L L L L L L L L L u u ,
Y Y T T T T T T T T T T u u <CR LF>
b Scale number.
LLLLLLLLLLuu Gross weight with unit of measurement.
YY “PT if a manual tare is present or “ ”.
TTTTTTTTTTuu Tare with unit of measurement.
Format Response
WEIGHT READING WITH DATE AND TIME
Format Response
R A Z F
Standard string<CR LF>.
R E X D
Extended string<CR LF>.
Format
Response
Where
P I D <CR LF>
P I D S T , b , L L L L L L L L L L u u , Y Y
T T T T T T T T T T u u , X X X X X - Y Y Y Y
Y Y <CR LF>
b Scale number.
LLLLLLLLLLuu Gross weight with unit of measurement.
YY “PT if a manual tare is present or “ ”.
TTTTTTTTTTuu Tare with unit of measurement.
XXXXX Rewrite number.
YYYYYY ID number.
i
The alibi memory commands are executed only if f u n C t = a l i b i.
In IND.CH mode, if the commands “ZERO”, “TARE” and “TMAN” are followed by “,X”, the command is executed only on the indicated scale. For example:
Format Where
T A R E , X <CR LF>
Scale:
Format Where
Z E R O , X <CR LF>
Scale:
X
Response
The fieldbus protocol is described in the respective manual.
OK<CR LF> (or ERRxx).
0 = scale 1
1 = scale 2 2 = scale 3 3 = scale 4
56 Visit our website www.RiceLake.com
Response
X
OK<CR LF> (or ERRxx).
0 = scale 1
1 = scale 2 2 = scale 3 3 = scale 4

Modbus Protocol

MODBUS REGISTERS FOR DATA READING (SINGLE SCALE)
Data Register DESCRIPTION
30001
Gross Weight
Net Weight
Input status
register
Command status
register
Output status
register
V Channel 1
Gross weight value.
30002
30003
Net weight value.
30004
30005
Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Active channel.
(msb)
Active channel. No function. No function. No function. No function. Input no. 2 status. Input no. 1 status.
(lsb)
Gross zero zone (0 = “outside zone 0”; 1 = “in zone 0”).
(msb)
Tare PT (1 = a preset tare is active). Tare (1 = a tare is active). Overload condition (0 = No; 1 = Overload). Underload condition (0 = No; 1 = Underload). Stability (0 = Unstable; 1 = Stable). Gross weight sign (0 = “+”; 1 = “-”). Net weight sign (0 = “+”; 1 = “-”).
(lsb)
Last command received.
30006
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Last command result.
(msb)
Last command result. Last command result. Last command result. Processed command count. Processed command count. Processed command count. Processed command count.
(lsb)
No function.
Bit 7
No function.
(msb)
30007
... Bit 2 Bit 1 Bit 0
... No function. Digital output 1 status (0 = OFF; 1 = ON). Digital output 2 status (0 = OFF; 1 = ON).
(lsb)
30111 V of channel 1.
V Channel 2
V Channel 3
V Channel 4
30112 V of channel 2.
30113 V of channel 3.
30114 V of channel 4.
This manual contains the main registers for reading data / sending commands. Refer to the Modbus protocol manual for a complete list of available registers.
© Rice Lake Weighing Systems • All Rights Reserved 57
MODBUS REGISTERS FOR DATA READING (MULTI-SCALE)
Data Register DESCRIPTION
Status register
scale 1
Gross weight
scale 1
Status register
scale 2
Gross weight
scale 2
Bit 15 Bit 14 Bit 13 Bit 12 Bit 11
Not used.
(msb)
Not used. Not used. Scale active (0 = “no”; 1 = “yes”). Decimals (00 = 0; 01 = 1; 10 = 2; 11 = 3)
Bit 10
40202
Bit 9 Bit 8
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Unit of Measure (00 = "g"; 01 = "kg"; 10 = "t"; 11 = "lb").
(lsb)
Preset tare (0 = “no”; 1 = “yes”).
(msb)
Active tare (0 = “no”; 1 = “yes”). Net weight polarity (0 = “+”; 1 = “-”). Gross zero zone (0 = “outside zone 0”; 1 = “in zone 0”). Overload condition (0 = No; 1 = overload). Underload condition (0 = No; 1 = underload). Stability (0 = “unstable”; 1 = “stable”). Gross weight sign (0 = “+”; 1 = “-”).
(lsb)
40203
Gross weight of scale 1.
40204
40205 As Status register scale 1.
40206
Gross weight of scale 2.
40207
Status register
scale 3
Gross weight
scale 3
Status register
scale 4
Gross weight
scale 4
Net weight
scale 1
Net weight
scale 2
Net weight
scale 3
Net weight
scale 4
40208 As Status register scale 1.
40209
Gross weight of scale 3.
40210
40211 As Status register scale 1.
40212
Gross weight of scale 4.
40213
40214
Net weight of scale 1.
40215
40216
Net weight of scale 2.
40217
40218
Net weight of scale 3.
40219
40220
Net weight of scale 4.
40221
This manual contains the main registers for reading data / sending commands. Refer to the Modbus protocol manual for a complete list of available registers.
58 Visit our website www.RiceLake.com
MODBUS REGISTERS FOR SENDING COMMANDS
Data Register DESCRIPTION
Main commands available:
Command
Parameter 1
Parameter 2
40001
40002
40003
40004
40005
Value
00 Hex
01 Hex
02 Hex
03 Hex
0A Hex
0B Hex
19 Hex
22 Hex
Command
No command
Zero
Tare
Predetermined tare
Setting setpoint 1
Setting setpoint 2
Setting digital outputs
Rebooting the transmitter
First command parameter. The parameter is always expressed as an absolute value (no decimal / sign).
Second command parameter. The parameter is always expressed as an absolute value (no decimal / sign).
EXAMPLE 1
To reset the weight on the scale:
2. Set the command in byte 2
EXAMPLE 2
To set a predetermined tare of 1000kg:
1. Set the value in parameter 1 (byte 3, 4, 5, 6)
2. Set the command in byte 2
Byte
Value
1 00 Hex 2 01 Hex
Byte
1 00 Hex 2 03 Hex 3 4 00 Hex
5 03 Hex 6
This manual contains the main registers for reading data / sending commands. Refer to the Modbus protocol manual for a complete list of available registers.
(MSB)
(LSB)
Value
00 Hex
E8 Hex
© Rice Lake Weighing Systems • All Rights Reserved 59

Diagnostics

8 8 8 8 8 8
1
p r G . v e r
2
m a n u f . d
3
d i v . i n t
4
a d C . u v
For correct operation, the value of the V of each channel must be less than 30000 with a weight equal to the maximum capacity. This value must be stable, and increase if a load is applied to the cell.
5
A D C . p n t
A
T Y P E
D
d i a G
Display of firmware release (e.g. 0 1 . 0 6 . 0 0 ).
Display of firmware libraries (for use by the manufacturer).
Display of calibration internal divisions.
Display of the V related to the weight on the scale. Use the and keys to display the dierent channels
Display of the A/D points of the converter related to the weight on the scale. Use the and keys to display the dierent channels
(in d e p . C h mode the sum is also visible).
(in d e p . C h mode the sum is also visible).
For correct operation, the value of A/D points must be stable, and increase if a load is applied to the cell.
6
w e i G h t
7
C a l . p t s
8
d i s p l a
9
k e y b
Display of the weight on the scale. Use the and keys to display the dierent channels.
Display of calibration points with corresponding A/D point values. Use the and keys to display the dierent calibration points. Press the key to display the dierent channels.
Activation of all display segments and indicators.
The code of last key pressed is shown on the display:
8001
8002
8003
8004
80AA
C
Press the same key 3 consecutive times to exit.
10
s e r
Complete menu on pages 21 - 22
Bridge between serial ports (for manufacturer’s use).
MENU ACCESS:
888888
60 Visit our website www.RiceLake.com
Press the key during the start­up procedure.
SAVING THE PARAMETERS:
Press the key several times, until the display shows
S A V E ? . Press the key to confirm.
11
o u t p u t
Activation of the output shown on the display ( r e l . 1 / r e l . 2 ).
Use the and keys to activate the two outputs.
12
i n p u t s
13
a n . o u t
14
s e r . n u m
15
s . r a d i o
Checking the status of the inputs: value 0 indicates that the input is disabled, value 1 indicates that the input is enabled. Use the and keys to display the two inputs.
Analog output test. Use the , , keys to enter the D/A point value of the analog output. Press the key to confirm and update the V / mA value of the analog output.
Display of transmitter serial number.
Radio channel display and setting.

Unbalancing

The instrument has an active unbalance function as standard that signals if the load is unevenly distributed, compared to the stored condition.
Imbalance occurs when the load distribution percentage value on a cell deviates by at least 10% for more than 3 seconds. It is possible to change these value with the following parameters:
8 8 8 8 8 8
A
C
F . m o d e
T y p e
1
f u n C t
6
u n b a l
1
m a x . u n b
2
u n b . s t r
3
m a x . 0 . u n
4
u n b . t i m
Visible only in D E P . C h mode.
Maximum percentage of variation allowed compared to the stored values ( = 10).
Storage of the current percentage values.
Maximum percentage of variation at zero allowed compared to the stored values ( = 10).
Minimum time for unbalancing signaling ( = 3).
LEGEND:
Indicates repeated pressing of the key.
Parameter visible only under certain conditions.
Parameter or menu subject to approval.
Default value of the parameter.
© Rice Lake Weighing Systems • All Rights Reserved 61
Example:
25% 25%
34% 23%
45% 20%
65% 15%
25%
Condition stored
The unbalance condition is signalled via Modbus / Fieldbus or a digital output ( f u n c = 3 1 . u n b ).
25%
23% 20%
20% 15%
i
This function is only available if E X C L . C H = N o N E.
Use this function only in systems where the load is evenly distributed.

Programming the Setpoints

15%
5%
In weighing mode, if the output functions ( 1 G r o s s / 2 n e t ) have been set correctly, pressing for 3 seconds will enter the setpoint
programming menu:
s . 1 o n 0 . 0 0 0
s . 1 o f f
s . 2 o n
s . 2 o f f
Once you have entered the desired values, press . The display shows “ s t o r e” and returns to weighing mode.
Output 1 activation value.
Output 1 deactivation value.
Output 2 activation value.
Output 2 deactivation value.
visible only if r l . i s t = i s t . o n
visible only if r l . i s t = i s t . o n
Complete menu on pages 21 - 22
MENU ACCESS:
888888
62 Visit our website www.RiceLake.com
Press the key during the start­up procedure.
SAVING THE PARAMETERS:
Press the key several times, until the display shows
S A V E ? . Press the key to confirm.

Restoring Factory Settings

8 8 8 8 8 8
A
T Y P E
C
S e t u p
1
C o n f i G
8
d e f a u
The transmitter is initialized and the default parameters (indicated by the symbol) are activated. Pressing
the display shows “ d f l t ?” confirm further with or exit by pressing another key.
The actual activation of the default parameters is performed by saving the settings ( s a v e ?) while exiting the menu.
LEGEND:
Indicates repeated pressing of the key.
Parameter visible only under certain conditions.
Parameter or menu subject to approval.
Default value of the parameter.
© Rice Lake Weighing Systems • All Rights Reserved 63

Alarms

Alarm Description
p r e C e r . m o t e r p n t
e r r . x . 1
o v e r x
e r 1 1
e r 1 2
e r 3 7
e r 3 9
C . e r . - 3 6
C . e r . - 3 7
Displayed if you try to calibrate a point without first confirming the number of calibration points ( n t p).
Calibration error: unstable weight during point acquisition.
Calibration error: during the acquisition of a calibration point a NULL value was read from the converter.
Error that occurs if the capacity of channel X is not set, or there is an error in the calibration parameters of channel X , where X indicates the number of the channel to which the error refers.
Error that occurs if the capacity of channel X is not set, or there is an error in the calibration parameters of channel X , where X indicates the number of the channel to which the error refers.
Calibration error: a sample weight that is too low was used; it is recommended to use a weight of at least half the scale’s capacity.
Calibration error: The acquired calibration point ( t p 1 / t p 2 / t p 3 ) is equal to the zero point ( t p 0). Scale to be calibrated (we recommend resetting the transmitter to the factory default “ d e f a u” settings before
proceeding).
Scale to be calibrated (we recommend resetting the transmitter to the factory default “ d e f a u” settings before
proceeding).
Negative internal points were calculated during calibration:
the calibration point is below the zero point;
the signal is negative (check the connections).
Internal points below the minimum value were calculated during calibration:
the calibration point is equal to the zero point;
too high a capacity has been set with respect to the division.
h w , e r r
a l . e r r
b u s y u n s t a b u n . o v e r
- - - - - -
- - - - - ­ G r o s . e r
n e r . e r r n o . 0 . u n s C o n v e r r , C L k C e l . e r r
E r . C e l . 1
...
E r . C e l . 4 E X C L . C H
Hardware error: software not compatible with the installed hardware.
Displayed when the alibi memory is enabled and the transmitter does not detect the presence of the card
when the power is turned on. The C o n v function is set automatically, but not saved in the setup environment.
Printing in progress (printer serial port busy) or transmitter waiting to transmit a print to PC.
You are trying to print with an unstable weight.
You are trying to print with the weight in underload / overload.
The weight is overloaded (9 divisions over the maximum capacity).
The weight is underloaded.
Restricted transmitter: -9 divisions.
Non-restricted transmitter: -100 divisions.
You are trying to print with a non-positive gross weight (less than or equal to zero).
You are trying to print with a non-positive net weight (less than or equal to zero).
Weight not passed by net 0 or instability.
You are trying to print while the transmitter is converting the unit of measurement.
Communication problems with the clock card of the transmitter.
Signal anomaly: check the connection of the cells.
Signal anomaly: check the connection of the cell indicated.
You are trying to perform a calibration/point acquisition with an excluded channel. Check the E X C L . C H
parameter in the quick menu (ref. Quick start guide).
Complete menu on pages 21 - 22
MENU ACCESS:
888888
64 Visit our website www.RiceLake.com
Press the key during the start­up procedure.
SAVING THE PARAMETERS:
Press the key several times, until the display shows
S A V E ? . Press the key to confirm.
Notes
Notes
© Rice Lake Weighing Systems Content subject to change without notice.
www.ricelake.com
230 W. Coleman St. • Rice Lake, WI 54868 • USA USA: 800-472-6703 • International: +1-715-234-9171
PN 221634 Rev AJanuary 4, 2024
Loading...
