Explorer® Balances
Instruction Manual
EXPLORER BALANCES EN-1
TABLE OF CONTENTS
1. INTRODUCTION ....................................................................................................................5
1.1 Description ...................................................................................................................................................5
1.2 Features ....................................................................................................................................................... 5
1.3 Safety Precautions ....................................................................................................................................... 5
2. INSTALLATION .....................................................................................................................6
2.1 Unpacking ....................................................................................................................................................6
2.2 Installing Components.................................................................................................................................. 7
2.2.1 Terminal Setup ......................................................................................................................................... 7
2.2.2 Installing the Wind Ring, Weighing Platform on Models EX124, EX224, and EX324 ............................. 7
2.2.4 Installing the Draft Shield Glass and Doors on Draft Shield Models........................................................ 8
2.2.5 Installing the Weighing Pan & Wind Shield – Non-Draft Shield Models .................................................. 9
2.3 Selecting the Location.................................................................................................................................. 9
2.4 Leveling the Equipment................................................................................................................................ 9
2.5 Connecting Power...................................................................................................................................... 10
2.5.1 AC Adapter.............................................................................................................................................10
2.6 Connecting the Interface ............................................................................................................................ 10
2.7 Adjusting the View Angle of the Terminal .................................................................................................. 10
2.8 Remote Terminal Operation................................................................................................................... 11
2.8.1 Separating the Terminal from the Weighing Base ................................................................................. 11
2.8.2 Terminal Mounting.................................................................................................................................. 11
2.9 Initial Calibration......................................................................................................................................... 11
3. OPERATION ........................................................................................................................12
3.1 Overview of Display, Home Screen ........................................................................................................... 12
3.2 Principal Functions and Main Menu.......................................................................................................... 12
3.3 Overview of Parts and Features –Draft Shield Models.............................................................................. 13
3.4 Overview of Parts and Features – Non-Draft Shield Models ..................................................................... 14
3.5 Overview of Parts and Features – Terminal .............................................................................................. 15
3.6 Functions and Their Icons..........................................................................................................................16
3.6.1 Standby .................................................................................................................................................. 16
3.6.2 Printing Data........................................................................................................................................... 16
3.6.3 Applications ............................................................................................................................................ 16
3.6.4 TouchLess Sensor Status ...................................................................................................................... 16
3.6.5 AutoCal™................................................................................................................................................16
3.6.6 Menu ...................................................................................................................................................... 16
3.6.7 More….................................................................................................................................................... 16
3.6.8 Level Assist ............................................................................................................................................ 16
3.6.9 Zero Operation ....................................................................................................................................... 16
3.6.10 Taring a Container.................................................................................................................................. 16
3.6.11 Weighing Units ....................................................................................................................................... 17
3.6.12 Preset Tare............................................................................................................................................. 17
3.6.13 Calibration Test ...................................................................................................................................... 17
3.6.14 Calculator ...............................................................................................................................................17
3.6.15 Stopwatch............................................................................................................................................... 17
3.6.16 Logout .................................................................................................................................................... 17
4. APPLICATIONS ...................................................................................................................18
4.1 Weighing ....................................................................................................................................................19
4.1.1 Edit Settings ........................................................................................................................................... 19
4.1.2 Application Setup ...................................................................................................................................20
4.1.3 Statistics for Weighing............................................................................................................................ 21
4.2 Parts Counting ........................................................................................................................................... 22
4.2.1 Standard Parts Counting (default).......................................................................................................... 22
4.2.2 Application Setup ...................................................................................................................................25
4.2.3 Parts Counting – Check ......................................................................................................................... 26
4.2.4 Parts Counting – Fill............................................................................................................................... 27
4.2.5 Statistics for Parts Counting...................................................................................................................28
4.3 Percent Weighing....................................................................................................................................... 30
4.3.1 Edit Settings ........................................................................................................................................... 30
4.3.2 Application Setup ...................................................................................................................................33
4.4 Check Weighing ......................................................................................................................................... 34
EN-2 EXPLORER BALANCES
4.4.1 Standard Check Weighing (default) ....................................................................................................... 34
4.4.2 Edit Settings ........................................................................................................................................... 34
4.4.3 Application Setup ...................................................................................................................................35
4.4.4 Check Weighing – Nominal/Weight Mode ............................................................................................. 36
4.4.5 Check Weighing – Nominal/Percent Tolerance Mode ........................................................................... 37
4.4.6 Display Settings...................................................................................................................................... 38
4.4.7 Statistics for Check Weighing ................................................................................................................ 39
4.5 Dynamic/Animal Weighing ......................................................................................................................... 40
4.5.1 Edit Settings ........................................................................................................................................... 41
4.5.2 Application Setup ...................................................................................................................................41
4.5.3 Dynamic Weighing – Semi-Auto ............................................................................................................ 42
4.5.4 Dynamic Weighing – Automatic ............................................................................................................. 43
4.5.5 Statistics for Dynamic Weighing............................................................................................................. 44
4.6 Filling .......................................................................................................................................................... 45
4.6.1 Edit Settings ........................................................................................................................................... 45
4.6.2 Application Setup ...................................................................................................................................46
4.6.3 Statistics for Filling .................................................................................................................................47
4.7 Totalization................................................................................................................................................. 49
4.7.1 Totalization – Manual (Default) .............................................................................................................. 49
4.7.2 Application Setup ...................................................................................................................................50
4.7.3 Totalization – Automatic......................................................................................................................... 51
4.8 Formulation ................................................................................................................................................52
4.8.1 Free Formulation (default)...................................................................................................................... 52
4.8.2 Application Setup ...................................................................................................................................53
4.8.3 Recipe Formulation ................................................................................................................................ 54
4.9 Differential Weighing .................................................................................................................................. 57
4.9.1 Item Settings ..........................................................................................................................................57
4.9.2 Application Setup ...................................................................................................................................59
4.9.3 Differential Weighing with Auto-Process On .......................................................................................... 60
4.10 Density Determination ................................................................................................................................ 61
4.10.1 Measuring the Density of a Solid Using Water (default) ........................................................................61
4.10.2 Application Setup ...................................................................................................................................63
4.10.3 Measuring the Density of a Buoyant Material Using Water ................................................................... 64
4.10.4 Measuring the Density of a Solid Using an Auxiliary Liquid................................................................... 64
4.10.5 Measuring the Density of a liquid using a Calibrated Sinker (not supplied)........................................... 65
4.10.6 Measuring the Density of Porous Material Using Oil ............................................................................. 67
4.11 Peak Hold................................................................................................................................................... 69
4.11.1 Peak Hold – Semi-Automatic (default) ................................................................................................... 69
4.11.2 Application Setup ...................................................................................................................................70
4.11.3 Peak Hold – Manual............................................................................................................................... 71
4.11.4 Peak Hold – Automatic...........................................................................................................................72
4.12 Ingredient Costing ...................................................................................................................................... 73
4.12.1 Item Settings .......................................................................................................................................... 73
4.12.2 Application Setup ...................................................................................................................................76
4.13 Pipette Adjustment ..................................................................................................................................... 77
4.13.1 Pipette Adjustment – Manual (default) ................................................................................................... 77
4.13.2 Begin Pipette Adjustment Process......................................................................................................... 79
4.13.3 Application Setup ...................................................................................................................................80
4.14 Statistical Quality Control (SQC)................................................................................................................ 81
4.14.1 Edit Settings ........................................................................................................................................... 81
4.14.2 Begin the SQC Process .........................................................................................................................82
4.14.3 Application Setup ...................................................................................................................................84
4.15 Statistics ..................................................................................................................................................... 85
4.16 Library ........................................................................................................................................................ 85
4.16.1 Creating a Library Record ...................................................................................................................... 85
4.16.2 Retrieving a Library Record ................................................................................................................... 86
4.16.3 Deleting a Stored Library Record........................................................................................................... 86
4.17 Additional Features .................................................................................................................................... 87
4.17.1 Weigh Below .......................................................................................................................................... 87
5. MENU SETTINGS ................................................................................................................88
5.1 Menu Navigation ........................................................................................................................................ 88
5.1.1 Changing Settings.................................................................................................................................. 88
5.2 Main Menu.................................................................................................................................................. 89
EXPLORER BALANCES EN-3
5.3 Calibration .................................................................................................................................................. 89
5.3.1 Calibration sub-menu ............................................................................................................................. 89
5.3.2 Internal Calibration (AutoCal™) ............................................................................................................. 89
5.3.3 Automatic Calibration ............................................................................................................................. 89
5.3.4 AutoCal™ Adjustment............................................................................................................................ 90
5.3.5 Span Calibration..................................................................................................................................... 90
5.3.6 User Calibration...................................................................................................................................... 91
5.3.7 Calibration Test ...................................................................................................................................... 91
5.4 User Settings.............................................................................................................................................. 92
5.4.1 User Settings Sub-menu ........................................................................................................................ 92
5.4.2 Language ............................................................................................................................................... 92
5.4.3 Volume ................................................................................................................................................... 92
5.4.4 Display Settings...................................................................................................................................... 92
5.4.5 User Manager......................................................................................................................................... 92
5.4.6 Functions Configuration ......................................................................................................................... 93
5.4.7 TouchLess Sensor Setup....................................................................................................................... 93
5.4.8 Draft Shield light ..................................................................................................................................... 93
5.5 Balance Setup............................................................................................................................................ 94
5.5.1 Balance Set-up sub-menu...................................................................................................................... 94
5.5.2 Stable Range.......................................................................................................................................... 94
5.5.3 Filter level ............................................................................................................................................... 94
5.5.4 Auto Zero Tracking.................................................................................................................................94
5.5.5 Auto Tare................................................................................................................................................ 95
5.5.6 Gross Indicator ....................................................................................................................................... 95
5.5.7 Legal For Trade......................................................................................................................................95
5.5.8 Graduations............................................................................................................................................95
5.5.9 Date & Time ........................................................................................................................................... 95
5.6 Applications................................................................................................................................................ 96
5.6.1 Turning an Application ON/OFF.............................................................................................................96
5.7 Weighing Units ........................................................................................................................................... 96
5.7.1 Units Sub-menu...................................................................................................................................... 96
5.7.2 Turning a Unit ON/OFF .......................................................................................................................... 97
5.7.3 Custom Units..........................................................................................................................................97
5.8 GLP and GMP Data ................................................................................................................................... 98
5.8.1 GLP Data Sub-menu.............................................................................................................................. 98
5.8.2 Header.................................................................................................................................................... 98
5.8.3 Balance Name........................................................................................................................................98
5.8.4 User Name ............................................................................................................................................. 98
5.8.5 Project Name.......................................................................................................................................... 98
5.9 Communication .......................................................................................................................................... 99
5.9.1 Communication Sub-menu..................................................................................................................... 99
5.9.2 Baud Rate ..............................................................................................................................................99
5.9.3 Transmission .......................................................................................................................................... 99
5.9.4 Handshake ........................................................................................................................................... 100
5.9.5 Alternate Command ............................................................................................................................. 100
5.9.6 Print Output .......................................................................................................................................... 100
5.9.7 Auto Print.............................................................................................................................................. 101
5.9.8 Print Calibration Data ........................................................................................................................... 101
5.9.9 Print Content ........................................................................................................................................101
5.9.10 Print Layout .......................................................................................................................................... 103
5.9.11 Data Transfer Function ........................................................................................................................ 103
Double click “Accessibility Options” in control panel.........................................................................................104
5.10 Library ...................................................................................................................................................... 105
5.11 I/O Settings............................................................................................................................................... 105
5.12 Diagnostics............................................................................................................................................... 105
5.12.1 Level Bubble Light................................................................................................................................105
5.12.2 Draft Shield Light (Analytical models) .................................................................................................. 105
5.12.3 Sensors ................................................................................................................................................105
5.12.4 Service Menu ....................................................................................................................................... 105
5.13 Factory Reset ........................................................................................................................................... 106
5.13.1 Factory Reset Sub-menu .....................................................................................................................106
5.13.2 Reset Calibration.................................................................................................................................. 106
5.13.3 Reset User Settings ............................................................................................................................. 106
EN-4 EXPLORER BALANCES
5.13.4 Reset Balance Setup............................................................................................................................ 106
5.13.5 Reset Application Modes ..................................................................................................................... 106
5.13.6 Reset Weighing Units...........................................................................................................................106
5.13.7 Reset GLP and GMP Data................................................................................................................... 106
5.13.8 Reset Communication .......................................................................................................................... 106
5.13.9 Reset I/O Settings ................................................................................................................................ 106
5.13.10 Reset All (Global Reset)....................................................................................................................... 106
5.14 Lockout..................................................................................................................................................... 107
5.14.1 Lockout Sub-menu ............................................................................................................................... 107
5.14.2 Lock Calibration.................................................................................................................................... 107
5.14.3 Lock User Settings ............................................................................................................................... 107
5.14.4 Lock Balance Setup .............................................................................................................................107
5.14.5 Lock Application Modes .......................................................................................................................107
5.14.6 Lock Weighing Units............................................................................................................................. 107
5.14.7 Lock GLP and GMP Data..................................................................................................................... 107
5.14.8 Lock Communication............................................................................................................................108
5.14.9 Lock Library.......................................................................................................................................... 108
5.14.10 Lock I/O Settings .................................................................................................................................. 108
5.14.11 Factory Reset ....................................................................................................................................... 108
5.15 Securing the Menu and Key Lock menu settings..................................................................................... 108
5.16 Information ............................................................................................................................................... 109
5.16.1 Using Information ................................................................................................................................. 109
6. LEGAL FOR TRADE..........................................................................................................110
6.1 Settings ....................................................................................................................................................110
6.2 Verification................................................................................................................................................ 110
6.3 Sealing .....................................................................................................................................................110
7. PRINTING ..........................................................................................................................111
7.1 Connecting, Configuring and Testing the Printer/Computer Interface..................................................... 111
7.2 Printout Examples .................................................................................................................................... 112
7.3 Output Format .......................................................................................................................................... 120
8. MAINTENANCE .................................................................................................................121
8.1 Calibration ................................................................................................................................................ 121
8.2 Cleaning ................................................................................................................................................... 121
8.3 Troubleshooting ....................................................................................................................................... 121
8.4 Service Information .................................................................................................................................. 121
9. TECHNICAL DATA ............................................................................................................122
9.1 Specifications ........................................................................................................................................... 122
9.2 Drawings and Dimensions ....................................................................................................................... 129
9.3 Parts and Accessories ............................................................................................................................. 130
9.4 Icons List .................................................................................................................................................. 131
9.5 Communication ........................................................................................................................................ 137
9.5.1 Interface Commands............................................................................................................................ 137
9.5.2 RS232 (DB9) Pin Connections............................................................................................................. 140
9.6 The USB Interface.................................................................................................................................... 140
10. SOFTWARE UPDATES.....................................................................................................144
11. COMPLIANCE....................................................................................................................145
EXPLORER BALANCES EN-5
1. INTRODUCTION
1.1 Description
The Explorer balance is a precision weighing instrument that will provide you with years of service if properly cared
for. The Ohaus Explorer balances are available in capacities from 120 grams to 10,200 grams.
1.2 Features
Modular Design: Ohaus Explorer balances are composed of two interconnected modules: a Terminal and a Base.
Depending on the user’s needs, the unit can be operated with the Terminal either attached to, or remote from, the
Base, with a single interconnect cord 1 meter long.
Touch Controls: Quick, graphical access to all control
functions, over a dozen applications and many features.
Touchless Sensors: can be assigned functions when
activated: Zero, Print, Tare, etc.
Statistics: available in Weighing, Counting, Percent
Weighing, Check Weighing, Dynamic Weighing, Filling,
Density Determination, Pipette Adjustment and
Statistical Quality Control applications.
1.3 Safety Precautions
Caution: Read all safety warnings before installing, making connections, or servicing this
equipment. Failure to comply with these warnings could result in personal injury and/or
property damage. Retain all instructions for future reference.
• Verify that the input voltage range printed on the data label and the plug type matches the local AC power
to be used.
• Make sure that the power cord does not pose a potential obstacle or tripping hazard.
• Use the balance only in dry locations.
• Do not drop loads on the pan.
• Use only approved accessories and peripherals.
• Operate the equipment only under ambient conditions specified in these instructions.
• Disconnect the equipment from the power supply when cleaning.
• Do not operate the equipment in hazardous or unstable environments.
• Service should only be performed by authorized personnel.
EN-6 EXPLORER BALANCES
2. INSTALLATION
2.1 Unpacking
Carefully remove your Explorer balance and each of its components from the package. The included components
vary depending on the balance model (see table below). Save the packaging to ensure safe storage and transport.
EX2202
EX223
EX423
EX623
EX1103
Included Component Photo
EX124
EX224
EX324
Terminal X X X
Weighing Base X X X
EX4202
EX6201
EX6202
EX10201
EX10202
Weighing Platform 90 mm Diameter
X
130 mm Diameter
X
180 x 210 mm
X
Sub-Platform 130mm Diameter
X
Support Caps
(4 Pcs)
X
Wind Ring
X
Wind Shield
X
Draft Shield
Assembly
X X
Power Adapter X X X
Power Cord (Country specific) X X X
Use Cover Terminal X X X
Compact Disk: USB Software X X X
Instruction Manual X X X
Quick Start Guide X X X
Warranty Card X X X
EXPLORER BALANCES EN-7
2.2 Installing Components
Refer to the illustrations and instructions below to identify and assemble your Explorer balance with its
components. All components must be assembled before using the balance.
2.2.1 Terminal Setup
When the Explorer is delivered, the Terminal is already attached (docked) to the Base. No additional setup is
necessary. However, for Draft Shield models, the Terminal needs to be detached temporarily in order to assemble
parts of the Draft Shield. Refer to the illustrations and instructions below to identify and assemble your Explorer
Balance.
Note: The Terminal is identical for all Explorer Balance models.
2.2.2 Installing the Wind Ring, Weighing Platform on Models EX124, EX224, and EX324
Note: Assembly instructions also apply to models with the suffix M or N.
1. Place the Wind Ring in position.
2. Insert the Platform Assembly
onto the Mounting Cone located
in the center of the Balance.
2.2.3 Installing the Sub-Platform and Weighing Pan on Models EX223, EX423, EX623 and EX1103
1. Place the Sub-platform in
position.
2. Position the Platform on the
Sub-platform.
EN-8 EXPLORER BALANCES
2.2.4 Installing the Draft Shield Glass and Doors on Draft Shield Models
1. Carefully remove each of the four glass Draft Shield sections from the packaging.
NOTE: Before installing side doors, be sure to set the lock tabs in the proper position, as shown here.
UNLOCK:
2. Follow the steps below to install side, front and top doors of the Draft Shield.
LOCK:
Side Door Installation
1. Unlock
3. Clear
Position glass door to slide. Open lock tab (top); insert in top groove and slide inside bottom groove. Close lock tab.
2. Align
4. Lock
Front Panel Installation
1. Release
terminal
2. Align
3. Push to
rear
4. Reconnect
terminal
Press button to separate Terminal from Base. Seat panel’s hooked ends in base. Swing panel to vertical position.
Top Door Installation
1. Align
2. Press Down
Insert Top Door’s hooked ends in grooved pegs. Press gently to seat. Check for smooth movement. Close door.
EXPLORER BALANCES EN-9
2.2.5 Installing the Weighing Pan & Wind Shield – Non-Draft Shield Models
Note: Assembly instructions also apply to models with the suffix M or N.
1. Place the four Support Caps onto the Balance as shown.
2. Place the Weighing Pan on the Support Caps
3. Place the Wind Shield onto the Balance as shown.
Note: The balance can be operated without the Wind Shield. However, depending on ambient conditions the
displayed results may be slightly less stable.
2.3 Selecting the Location
Avoid excessive vibrations, heat sources, air current, or rapid temperature changes. Allow sufficient space.
Note: Interface cables connect to the terminal. The terminal can be detached and mounted on a wall or
positioned on a table separate from the balance.
2.4 Leveling the Equipment
The Explorer has an illuminated level indicator as a reminder that the balance should
be leveled for accurate weighing. There is a level bubble in a small round window on
the front of the Base. To level the balance, adjust the Leveling Thumbwheels at each
corner until the bubble is centered in the circle.
Be sure the equipment is level each time its location is changed.
Note: The feet cannot rotate. The Thumbwheels must be used for leveling.
See the Level Assist screen in the Information Menu.
To see the Level Assist menu, touch
More on the bottom-right corner of the
main screen. Then touch Level Assist.
The Level Assist screen shows which
direction to turn the thumbwheels to
center the level bubble.
EN-10 EXPLORER BALANCES
2.5 Connecting Power
2.5.1 AC Adapter
Connect the power cord of the AC Adapter (supplied) to the power receptacle on the rear of the Base.
Then connect the AC adapter plug to a suitable electrical outlet.
Caution: For use with CSA certified (or equivalent approved) power source,
which must have a limited current output.
Note: Allow equipment to warm up for 60 minutes for optimal weighing performance.
Standby: When unit is plugged in, it starts in Standby mode. Press the Standby icon to start.
2.6 Connecting the Interface
Use the built-in RS-232 (10101) Port to connect either to a
computer or a printer with a standard (straight-through) serial
cable. Or connect using the scale’s USB port.
Note: For configuration and interface commands, see the
Communication Menu Settings section.
For Connecting, Configuring and Testing the Printer/Computer
Interface, and for sample Print Output Formats, see the Printing
section.
Interface connections on back of Terminal.
Thread printer cable along cable coils on bottom of balance. Or pass cable through groove near release button.
2.7 Adjusting the View Angle of the Terminal
To adjust the Terminal display’s viewing angle, press in the Terminal Adjust buttons on both sides of the Terminal.
EXPLORER BALANCES EN-11
2.8 Remote Terminal Operation
The Terminal communicates with the weighing base via the Terminal cable. This cable must be plugged into the
Terminal for the Explorer to display properly. If desired, the Explorer balance may be operated either with the
Terminal attached (as-shipped), or remotely (up to 1 meter away).
2.8.1 Separating the Terminal from the Weighing Base
1. To detach, press both the Release buttons inward (both at the same time) and gently pull the Terminal
towards you (outward) until the Terminal is detached. These Release buttons disengage the two hooks
holding the Terminal to the Base. A cable is attached to the Terminal. Take care to not damage or
disconnect this cable.
2. To reattach the Terminal, press in the two Release buttons and slide the Terminal into the Base until the
Terminal hooks click and engage to hold the Terminal in place.
Release Button Base and Terminal Terminal Cable
Note: If a longer operation distance is required, a Terminal Extension cable is available as an accessory.
2.8.2 Terminal Mounting
If desired, the Terminal may be mounted to a wall or table using fasteners (not supplied) that are appropriate for the
type of mounting surface The Terminal bracket will accommodate 4mm (#8) screws. Locate the mounting holes as
shown in Figure 2-1.
56.5 mm
2.2 in
48.5 mm
1.9 in
112 mm / 4.4 in
Figure 2-1. Terminal Mounting Dimensions.
2.9 Initial Calibration
When the Balance is first installed, and when it is moved to another location, it must be calibrated to ensure
accurate weighing results. The Explorer Balances have built in AutoCal which can calibrate the balance
automatically and does not require calibration masses. If preferred, the balance can be manually calibrated with
external masses. Have the appropriate calibration masses available before beginning calibration. Refer to the
Calibration Section for masses and calibration procedure.
EN-12 EXPLORER BALANCES
3. OPERATION
3.1 Overview of Display, Home Screen
This equipment utilizes a touch-sensitive display. Touch areas and Buttons to control the equipment’s functions.
CONTROLS
Touch for information menu
Instructional Messages
Stability (*), Net (NET),
Gross (G) and/or center
of zero (>0<) indicators
Result Fields:
Information varies by
application
Touch icons to perform
specific functions or
access other functions
3.2 Principal Functions and Main Menu
Weighing: Press Tare to set the display to zero. Place an item on the pan. Display indicates gross weight.
Taring: With no load on the pan, press Tare to set the display to zero. Place an empty container on the pan
and press Tare. Add material to the container and its net weight is displayed. Remove container and
container’s weight appears as a negative number. Press Tare to clear.
Touch to access application setup menu
Touch to change
applications
Touch to access
available libraries
Touch unit indicator to
change weighing unit
Capacity or Status Guides:
Vary by application
Application Buttons:
Functions vary by
application
MENU & SCREEN NAVIGATION
Touch Menu to open the menu list.
Touch and drag the Scroll bar to view additional items.
Calibration:
Touch to view calibration options.
User Settings:
Touch to view user preferences.
Balance Setup:
Touch to view balance settings.
Application Modes:
Touch to view application modes.
Weighing Units:
Touch to view weighing units.
GLP and GMP Data:
Insert user data for traceability.
Communication:
Touch to view COM Device Settings and Print
Settings.
Library:
Touch to delete all Library records.
I/O Settings:
Touch to view remote I/O Settings.
Diagnostics:
Touch to view Diagnostics items.
Factory Reset:
Touch to do a Factory reset.
Lockout:
Touch to access the Lockout menu list.
Information:
Touch to view list of topics.
EXPLORER BALANCES EN-13
3.3 Overview of Parts and Features –Draft Shield Models
Terminal cable
storage clips
Data label
Touchless
Sensors
Top View
Illuminated
Level
Indicator
(hidden)
Lock switch
Weigh
Below
Access
Foot; NonAdjustable
Bottom View
Draft Shield
Light
Leveling
Thumbwheels
Figure 3-1. Explorer Balance (models EX124, EX224, EX324, EX223, EX423, EX623, EX1103)
Rear View
Power
Connection
Type label
(M, N models only)
Side View
Touchless
Sensors with
Indicator Lights
EN-14 EXPLORER BALANCES
g
3.4 Overview of Parts and Features – Non-Draft Shield Models
Data label
Terminal cable
storage clips
Touchless
Sensors
Leveling
Thumbwheels
Top View
Lock switch
Illuminated
Level
Indicator
Power
Connection
Bottom View
Weigh
Below
Access
Foot; NonAdjustable
Touchless
Sensors with
Indicator Li
hts
Rear View
Figure 3-2. Explorer Base (models EX2202, EX4202, EX6202, EX10202, EX6201, EX10201)
Type label
(M, N models only)
Side View
EXPLORER BALANCES EN-15
3.5 Overview of Parts and Features – Terminal
Hooks
(to attach
Capacity sticker
(Approved models
only)
Touchless
Sensors with
Indicator Lights
Terminal
Release
Buttons
Terminal
Bracket
Angular
Adjust
Buttons
Foot
USB Device
Connection
Terminal
Cable
(from Base)
Top View
Terminal
Cable Clamp
RS232
Connection
Back View
Figure 3-3. Explorer Terminal
Option
Port
Side View
EN-16 EXPLORER BALANCES
3.6 Functions and Their Icons
Seven Icons are initially available to operate the Balance and access the Menu. These Icons can be customized
based on user preference. For setup information, see User Settings.
3.6.1 Standby
Touch Standby to shut down the display.
Note: After initial start-up (Section 2), in Standby your balance needs no warm-up time and is
immediately available for weighing by touching the Start-up icon.
3.6.2 Printing Data
Touch Print to send the displayed value to a printer or computer via the active COM port.
Note: Ensure proper setup of connections, printing and interface parameters.
Note: Data may also be printed using the Touchless Sensors by configuring these for Printing.
Data may also be printed using the P command from a computer connected to the COM port.
3.6.3 Applications
The balance can be configured to operate in various Application modes.
Touch Applications to choose – or the top button in the Application area.
3.6.4 TouchLess Sensor Status
Explorer balances have four TouchLess sensors that can be assigned a unique function when
activated (e.g., zero, print, tare, etc).
To assign a task for each TouchLess sensor, press Sensors.
Note: To activate a sensor, move an object over it (from a distance of 1-2 inches or 3 cm). The sensor
shows a green light and beeps when activated. If the sensor cannot be activated (sensor is disabled
during certain instances, like when the Menu is displayed) the sensor shows a red light.
3.6.5 AutoCal™
When AutoCal is ON, the balance performs a self calibration. AutoCal will automatically calibrate the
Balance (using the internal mass) each time a change in temperature significant enough to affect
accuracy, or after every 11 hours.
Touch AutoCal™ to initiate. (Default status is ON.)
3.6.6 Menu
Touch Menu to enter the balance’s menu list.
3.6.7 More…
Touch More to access Level Assist, Zero, Tare, Units, Pretare, Cal Test, Calculator, and Stopwatch.
3.6.8 Level Assist
For assistance with Leveling the Balance; the Level Assist screen shows which direction to turn the
thumbwheels to center the level bubble.
3.6.9 Zero Operation
Remove the load from the pan and touch Zero to set the display to zero. When weighing pan is
empty, the >0< indicator turns on when the measurement is within +
Note: The balance also features Auto Zero Tracking (AZT) that automatically maintains a Center of
Zero within the tolerances set in the AZT menu (see Balance Settings).
¼ division (d) of the zero setting.
or
3.6.10 Taring a Container
Taring sets the weight of a container as zero, so only the weight of objects held in the container
(net weight) is displayed.
Manual Tare – Place the empty container on the pan and touch Tare when stable.
Add material to the container. The net weight of the material is displayed.
To clear the Tare value, remove the container from the pan and touch Tare.
EXPLORER BALANCES EN-17
3.6.11 Weighing Units
The balance can be configured to measure in a variety of weighing units, including three (3) custom
units. Touch Units to choose from the displayed list. (Scroll down to see all options.)
Note: The active weighing Unit can also be accessed by touching the unit area of the Main Display
line; If a unit is not displayed in the list, it must first be turned on via the User Menu.
3.6.12 Preset Tare
To enter a Preset Tare, press the Icon and then enter a value;
enter 0 to clear the Preset Tare. The display will show the PT symbol and the tare value as a negative
number.
3.6.13 Calibration Test
is used to compare a known calibration weight against the last stored span calibration data.
3.6.14 Calculator
To use the built-in calculator application, touch Calculator. A four function calculator with addition,
subtraction, multiplication and division mathematical operations is available
• Perform a numeric operation using the keypad.
• Press = to view the result.
• To Clear the display: Press CE to clear the entry, C to clear
all
• Touch
x to close and return to the current Application.
3.6.15 Stopwatch
To use the built-in stopwatch application, touch Stopwatch. A countdown timer with interval (lap)
timer is available.
• Press Start to begin using the Stopwatch timer.
• Press Reset to reset the timer to Zero.
• Touch Close to close and return to the current Application.
3.6.16 Logout
Used for User logout and return to User Login screen. This feature is only active if a user profile has
been created and a User has logged in.
EN-18 EXPLORER BALANCES
4. APPLICATIONS
The balance can be configured to operate in various Application modes.
Touch Applications to choose – or the top button in the Application area:
If an application mode does not appear in the list of available Applications it must be enabled in the User
Note:
Menu: touch Menu, then select Application Modes. The full list of modes appears. Touch the one you want to
enable. Then touch Enabled in the setup menu for that application mode – Percent Weighing in the example
below. Each enabled mode appears in the Applications menu.
The Explorer Balance incorporates the following Applications.
Weighing Parts Counting Percent
Totalization Formulation Differential
Weighing
Weighing
Determination
Check
Weighing
Density
Dynamic
(Animal)
Weighing
Peak Hold
(High Point)
Filling
Ingredient
Costing
Pipette
Adjustment
Statistical
Quality Control
(SQC)
Library
(complements most Applications)
EXPLORER BALANCES EN-19
4.1 Weighing
Note: Before using any application, be sure the balance has been leveled and calibrated.
Use this application to determine the weight of items in the selected unit of measure.
Note: The Explorer is shipped with all units enabled.
Weighing
1. In the upper left portion of the home screen, select Weighing (this application is the default).
2. Press Tare or Zero if necessary to begin.
3. Place objects on the pan to display the weight. When stable, the * appears.
4. The resulting value is displayed in the main Weighing Line in the active unit of measure.
The WEIGHING Home screen
Main Display Line
Second Display Line (not shown)
Reference Fields
Application Buttons
Functions
Application Icon
4.1.1 Edit Settings
To view or adjust the current settings
Touch the
Edit Settings
button. The Settings screen appears.
Minimum Weight: establish a minimum weight value to
be used to verify a reading. If an actual weight is below
the established Minimum Weight value, it is flagged by a
color change: yellow.
To adjust the Minimum Weight value, touch the
Minimum Weight
button.
A numeric input window appears.
Use the keys to enter the desired Minimum Weight,
then press 9.
The display reverts to the previous screen with the
new Minimum Weight value highlighted: orange.
To return to the Weighing home screen, touch
Return to Application at
bottom-right of that screen.
EN-20 EXPLORER BALANCES
4.1.2 Application Setup
The Application can be customized for various user preferences.
Touch the
Setup Icon
(wrench) to enter
Application Setup
.
The Application Setup Menu is now displayed.
Select the list item to view or change the setting as
desired.
To return to the Application home screen, touch Done.
The Weighing Application Setups are below (defaults in Bold)
Item Available Settings Comments
Enabled On, Off Turns Application on/off
Secondary Unit On, Off To show the Second Display line
Minimum Weight On, Off To enable Min Weight
Statistics Off, Manual, Auto
Lock Settings On, Off
Reference fields
Min Weight On, Off Min Weight is displayed
Gross On, Off Gross weight is displayed
Net On, Off Net weight is displayed
Tare On, Off Tare weight is displayed
Print Options
See Printing Section.
Min Weight On, Off
Press to lock the current setting(s)
so they cannot be changed.
EXPLORER BALANCES EN-21
4.1.3 Statistics for Weighing
The Statistics function allows you to compare a number of samples and examine the relative deviation of each
sample from the mean, along with other statistical data. A minimum of three samples is required.
Statistics can be determined manually (requires key press after each step) or automatically (weights are
automatically recorded when stable). To use the Statistics function, enable it in the Application Setup menu.
This feature is available in Weighing, Counting, Check Weighing, Dynamic/Animal Weighing and Filling
applications.
Application Setup: First, enable Statistics
Touch the Setup Icon (wrench) to
enter Setup menu to enable
Statistics.
The Statistics options screen
appears.
Enable the desired mode (Manual, Auto)
Press Close to return to the Setup menu.
To return to the Application home screen, press Done.
Accumulating displayed values & viewing data – Manual
Once Statistics-Manual is enabled, two buttons appear on
the Application screen; Statistics and Accumulate.
Application – Auto
Statistics Auto mode is similar to Manual mode, except the
first stable weight is automatically captured, so the
Accumulate button is not shown.
To add the sample to the data set, place the item on the pan
and press Accumulate.
When stable, the
item is added to the set, and the data set quantity increments
by one.
Continue to add items and press Accumulate to build the data
set.
Press the
Press Print to send results to the enabled COM port.
Press
clearing the current statistics set.
Press
Statistics
Close
Clear Data
Statistics
button to view the results, as shown here.
to return to the Application home screen without
to clear results and return to the home screen.
button lights briefly to show the
EN-22 EXPLORER BALANCES
4.2 Parts Counting
Use this application to count samples of uniform weight. Three different modes can be selected:
Standard Counting, Check Counting, or Fill Counting.
4.2.1 Standard Parts Counting (default)
In the upper left portion of the home screen, select Counting.
The default (or last) Average Piece Weight (APW) is displayed.
Place objects on the pan to display the number of pieces.
The PARTS COUNTINGStandard Home screen
Main Display Line
Second Display Line
Reference Fields
Application Buttons
Functions
Application Icon
The Auto Optimization feature improves counting accuracy:
it automatically re-calculates the piece weight as parts are
added. By default APW Optimization is Off.
When a new APW is established, APW Optimization occurs
when the number of pieces added to the pan is between one
and three times the number already on the pan. The screen
momentarily indicates Auto Optimization in the information
line.
4.2.1.1 Edit Settings: To view or adjust the current settings, touch the Edit Settings button:
The Settings screen is now displayed.
Settings available: APW, Sample Size,
Functions available:
Return to Application
Recalculate APW,
Establish an Average Piece Weight (APW)
Each time a new type of part is counted, the nominal weight of
one piece (Average Piece Weight or APW) must be established
using a small quantity of pieces. This APW is stored until
replaced by another APW.
There are two methods to establish the APW value:
1. The actual APW is known; or
2. The APW must be derived by weight. For this case the
current sample size will be used
To choose a different value, establish it beforehand, using the Sample Size button. (See below.)
EXPLORER BALANCES EN-23
Set a known Average Piece Weight (APW)
To adjust the APW value directly, touch the
A numeric input window appears.
Key in the desired APW Weight, then press 9.
The display returns to the previous screen with the
new APW value highlighted.
APW
button
.
To return to the Counting home screen,
touch Return to Application.
Set a new Average Piece Weight (APW) – Derived
To establish a new APW, touch the Recalculate APW button
The APW Screen is displayed.
NOTE: The sample size that is displayed will be used.
To use a different sample size, change that first. (See below.)
Follow the screen instructions to establish a new APW
Actions available: Tare, Cancel, or Accept
Press
Accept
to capture the value and return to the Settings
screen.
The Settings screen returns with the new APW value
highlighted.
To return to the Counting home screen,
touch
Return to Application.
The home screen shows 10 pieces at the new APW
EN-24 EXPLORER BALANCES
4.2.1.2 Sample Size
The sample size can be 1 to 100 pieces. The default sample
size is 10. Once a sample size is changed, the balance will
immediately open the Recalculate APW screen, expecting to
establish a new APW.
The current sample size is shown on the
To adjust the sample size, touch the
A numeric input window appears.
Key in the desired Sample Size, then press 9.
The next screen appears, with the message to place the number
of pieces entered in the numeric input window.
Place the indicated number of pieces on the platform.
Then touch either Tare, Cancel, or Accept.
Press
Accept
the Settings screen.
to capture the value and return to
Settings
Samples
screen.
button.
The Settings screen appears with the new APW value
highlighted.
To begin counting pieces, touch
Return to Application
.
EXPLORER BALANCES EN-25
4.2.2 Application Setup
The Application can be customized for various user preferences.
Touch the
Setup Icon
(wrench) to enter
Application Setup
.
The Application Setup Menu appears.
Select the list item to view or change the setting as
desired.
To return to the Application home screen, touch
Done
.
The Counting Application Setups are below (defaults in Bold).
Item Available Settings Comments
Enabled On, Off Turns Application on/off
Auto Optimization On, Off
Counting Mode Standard Counting,
Check Counting,
Fill Counting
Secondary Unit On, Off To show the Second Display line
Statistics Off, Manual, Auto
Lock Settings On, Off
Reference fields
APW On, Off The APW is displayed
Gross On, Off Gross weight is displayed
Net On, Off Net weight is displayed
Tare On, Off Tare weight is displayed
Target On, Off Used for Check-Fill only
Difference On, Off Used for Check-Fill only
Over Limit On, Off Used for Check-Counting only
Under Limit On, Off Used for Check-Counting only
Print Options
See Printing Section.
APW On, Off
Sample Size On, Off
Target On, Off Used for Check-Fill only
Difference On, Off Used for Check-Fill only
Over Limit On, Off Used for Check-Counting only
Under Limit On, Off Used for Check-Counting only
Select the Mode
Press to lock the current setting(s)
so they cannot be changed.
EN-26 EXPLORER BALANCES
4.2.3 Parts Counting – Check
This feature permits establishing a set quantity of pieces as criteria for similar items that can be quickly checked
against a sample.
Press the
Setup
(wrench)
button to enter
the Counting
Setup menu.
Change
Counting
Mode to
Check
Counting.
The PARTS COUNTING – Check Home screen
Main Display Line
Second Display Line
Reference Fields
Application Buttons
Functions
The default (or last) Average Piece Weight (APW) is
displayed. Place objects on the pan to display the
Check Status (number of pieces).
4.2.2.1 Edit Settings: To use the Parts Counting-Check mode,
the Over Limit and Under Limit values must be set.
The Average Piece Weight and standard sample size can also
be set. Follow these steps:
Touch the
Edit Settings
The buttons for
APW, Samples, Over Limit
button. The Settings screen appears.
and
Under Limit
show default (or previously set) values. To change any value,
touch the button. A keyboard screen appears.
(See keyboard screens, next page.)
To set a new average piece weight, press the
Recalculate APW button.
A new screen appears with the message:
Place 30 pieces. Press Accept
(Default is 10 pieces, but message matches
number of pieces in Samples button.)
After following these instructions, press Return to Application
on the main Edit Settings screen.
EXPLORER BALANCES EN-27
4.2.4 Parts Counting – Fill
This feature permits establishing a set quantity of pieces as a reference, so when pieces are added, their
percentage of the reference amount appears. A Progress bar indicates the percentage.
In the upper left portion of the home screen, select Parts Counting.
(The option will appear if it has been enabled in the Application Modes menu.)
Press the Setup
(wrench) button
to enter the
Counting Setup
menu.
Change
Counting Mode
to Fill
Counting.
The PARTS COUNTING – Fill Home screen
Main Display Line
Second Display Line
Reference Fields
Application Buttons
Functions
The default (or last) Average Piece Weight (APW) is displayed.
Place objects on the pan to display the Fill Status.
4.2.3.1 Edit Settings: To use the Parts Counting-Fill mode, the Target (in pieces) and Difference values (in
percent) must be set up in the Settings Menu.
Touch the Edit Settings button. The Settings screen appears.
EN-28 EXPLORER BALANCES
The buttons for APW, Samples and Target show default
(or previously set) values. To change values, touch the button.
A keyboard screen appears.
Key in the new value, and press Done.
To set a new average piece weight, press Recalculate APW.
A new screen appears saying:
Place 10 pieces. Press Accept
After following these instructions, and setting all values as
desired, press Return to Application.
4.2.5 Statistics for Parts Counting
Use the Statistics function to compare a number of samples and examine the relative deviation of the samples
along with other statistical data. A minimum of three samples is required.
Statistics can be determined manually (Manual mode, with key press after each step) or automatically (Auto
Mode: weights are automatically recorded when stable). To use the statistics function, enable it first in the
Application Setup menu.
Application Setup
First, Enable Statistics
Touch the Setup
Icon wrench (as
above) to enter
Setup menu.
Press Statistics and choose either Manual or Automatic, then press Close.
Press Done on the main options menu to return to the home screen.
EXPLORER BALANCES EN-29
Accumulating displayed values & Viewing data – Manual
Once Statistics is enabled, two buttons appear on the Application screen; Statistics and Accumulate.
To add the sample to the data set, place the item on the pan and
press Accumulate.
When stable, the Statistics button lights briefly to show the item
is added to the set and the data set quantity increments by one.
Continue to add items and press Accumulate to build the
statistical data set
At any time, press the
Statistics
button to view the results.
The Statistics Results screen
Press Print to send to the enabled COM port
Press Close to return to the Application home screen
with the current statistics set or
Press
Clear Data
Application home screen.
to clear the results and return to the
Statistics – Automatic
Statistics Automatic mode is similar to manual mode (above) except the first stable weight is automatically
captured. Thus the Accumulate button is not used.
EN-30 EXPLORER BALANCES
4.3 Percent Weighing
Use Percent Weighing to measure the weight of a sample displayed as a percentage of a pre-established
Reference Weight.
The default (or last) Reference Weight is displayed.
Place an object on the pan. The difference between the sample and the Reference Weight is displayed as both a
weight and a percentage.
To Access Percent Weighing:
Press the upper left portion of the home screen,
so the available Application Modes are visible.
Select Percent Weighing.
The Percent Weighing Home Screen appears.
4.3.1 Edit Settings
To view or adjust the current settings
To adjust the Application settings
button. (See above.)
The Settings screen is now displayed.
Settings available: Reference, Reference Adjust
Functions Available:
Recalculate Reference,
Return to Application
touch the
,
The PERCENT WEIGHING Home screen
Main Display Line
Second Display Line
Reference Fields
Application Buttons
Functions Application Icon
Edit Settings
EXPLORER BALANCES EN-31
Establishing a Reference Weight
There are two methods to establish the Reference Weight value:
1. Direct: If the actual Reference Weight is known, it can be entered directly;
Establishing a Known Reference Weight
Using a Sample to Establish a Derived Reference Weight
2. Derived: The sample’s weight can be used to establish the reference weight.
The current
Reference
weight value is
shown on the
Settings screen.
To adjust the
Reference
weight directly,
touch the
Reference
button.
A numeric input
window appears.
Key in the desired Reference Weight, then press 9.
The display returns to the previous screen with the new value highlighted.
To return to the Percent Weighing home screen, touch
Return to Application
.
To establish a
new Reference
weight value,
touch the
Recalculate
Reference
button.
The New
Reference
screen appears.
Follow the
screen
instructions to
establish a new
Reference
Weight.
Actions available: Tare, Cancel, or Accept.
Press
Accept
to capture the value and return to the Settings screen.
The display returns to the Settings screen with the new Reference weight value highlighted momentarily.
To return to the Percent weighing home screen, touch Return to Application.
EN-32 EXPLORER BALANCES
Reference Weight Adjustment (Reference Adjust)
The Reference Weight adjustment can be 1 to 1000 percent.
Examples: 100% means the sample is displayed as compared to 100% of the Reference Weight.
25% means the sample is displayed as compared to 400% of the Reference Weight.
The Edit Settings screen shows current Reference Adjust value. To change it, touch Reference Adjust button.
A numeric input
window appears.
Key in the
desired
Reference
Weight
Adjustment, then
press
The display returns to the previous screen with the new value highlighted momentarily.
To return to the Percent weighing home screen, touch
Done.
Return to Application
.
EXPLORER BALANCES EN-33
4.3.2 Application Setup
The Application can be customized for various user preferences. Press Setup (wrench) from the home screen.
The
Setup
appears.
Menu
Select the item
to view or
change.
To return to the
Application
home screen,
press
Percent Weighing Application Setups (defaults in Bold)
Item Available Settings Comments
Enabled On, Off Turns Application on/off
Secondary Unit On, Off To show the Second Display line
Lock Settings On, Off
Reference fields
Reference Weight On, Off The Reference is displayed
Difference (weight) On, Off
Difference (percent) On, Off
Gross On, Off Gross weight is displayed
Net On, Off Net weight is displayed
Tare On, Off Tare weight is displayed
Print Options
See Printing Section.
Reference Weight On, Off
Reference Adjust On, Off
Difference (weight) On, Off
Difference (percent) On, Off
Done
.
Press to lock the current setting(s)
so they cannot be changed.
Displays the Difference to the
reference weight.
Displays the Difference to the
reference weight as percentage.
EN-34 EXPLORER BALANCES
4.4 Check Weighing
Check Weighing is used to compare the weight of a sample against target limits. Three different modes can be
selected: Over and Under, Nominal Weight Tolerance, or Nominal Percent Tolerance.
4.4.1 Standard Check Weighing (default)
In the upper left portion of the home screen, select Check Weighing.
The default (or last) Check weigh limits are displayed. Place objects on the pan. The Under/Accept/Over status
is shown in the progress bar area while the actual weight of the item is shown on the main Display Line.
The CHECK WEIGHING Home screen
Main Display Line
Second Display Line
Reference Fields
Application Buttons
Application Icon
Functions
4.4.2 Edit Settings
To view or adjust the current settings
Touch the
The Application Settings Screen.
The check limit values are displayed in the settings screen.
A numeric input window appears.
Enter the desired Limit Weight, then press OK.
The display returns to the previous screen with the new value
highlighted momentarily.
To return to the CHECK WEIGHING home screen,
touch
Edit Settings
Settings available: Over Limit, Under Limit
Functions Available:
To set the Over Limit value, touch the Over Limit button
To set the Under Limit value, touch the
Return to Application
button. The Settings screen appears.
Return to Application
Under Limit
.
button
EXPLORER BALANCES EN-35
4.4.3 Application Setup
The Application can be customized for various user preferences.
Touch the Setup Icon (wrench) to enter the Application Setup
from the home screen:
The
Menu is now displayed.
Setup
Select the list item to view or change the setting as
desired.
To return to the Application home screen, touch
Check Weighing Application Setups (defaults in Bold)
Item Available Settings Comments
Enabled On, Off Turns Application on/off
Limits Setting Mode Over and Under,
Nominal/Weight Tol,
Nominal/Percent Tol.
Secondary Unit On, Off To show the Second Display line
Audible Signal On, Off Beeps if reading is under or over.
Statistics Off, Manual, Auto
Display Setting Weight,
Check Status
Lock Settings On, Off Press to lock the current setting(s)
Reference fields
Over Limit On, Off Over weight limit
Under Limit On, Off Over weight limit
Gross On, Off Gross weight is displayed
Net On, Off Net weight is displayed
Tare On, Off Tare weight is displayed
Target On, Off Used for Nominal Checkweigh
Positive Tolerance On, Off Used for Nominal Checkweigh
Negative Tolerance On, Off Used for Nominal Checkweigh
Print Options
See Printing Section.
Over Limit On, Off
Under Limit On, Off
Target On, Off Used for Nominal Checkweigh
Positive Tolerance On, Off Used for Nominal Checkweigh
Negative Tolerance On, Off Used for Nominal Checkweigh
.
Done
To select the Mode
To show Weight or Check Status
on Main Display Line
so they cannot be changed.
EN-36 EXPLORER BALANCES
4.4.4 Check Weighing – Nominal/Weight Mode
With this feature you can establish a Target or Nominal weight
value and pre-set tolerance in weight.
To enable this feature, enter the Setup menu.
Change the mode to Nominal/Wt Tolerance.
The Check Weighing options screen returns.
Press Done to begin Check Weighing.
CHECK WEIGHING – Nominal/Wt Tolerance home screen
Main Display Line
Second Display Line (not shown)
Reference Fields
Application Buttons
Functions Application Icon
To use this mode, touch Edit Settings to set the Nominal, and
Upper and Lower Tolerance values (in weight).
(See keyboards below.)
Press Return to Application when settings are complete.
EXPLORER BALANCES EN-37
4.4.5 Check Weighing – Nominal/Percent Tolerance Mode
With this feature you can establish a Target or Nominal weight value and pre-set tolerance in percent.
To enable this feature, enter the Setup menu.
Change the mode to Nominal, % Tolerance. The Check Weighing options screen returns.
Press Done to begin Check Weighing.
The CHECK WEIGHING – Nominal/Percent Tolerance
home screen
Main Display Line
Second Display Line (not shown)
Reference Fields
Application Buttons
Application Icon
Functions
To use this mode, touch Edit Settings to set the Target
Weight, and Upper and Lower Tolerance values (in percent).
(See keyboards below.)
Press Return to Application when settings are complete.
EN-38 EXPLORER BALANCES
4.4.6 Display Settings
The results can be displayed with the check status (Under, Accept, or Over) either in the Progress bar
(Weighing) or in the main Weighing Line (Check Status).
To display the results in the main Weighing Line, set the Display Setting to
Check Status, using the Application Setup screen.
(The default value is Weight.)
The CHECK WEIGHING home screen with
Display set to Check Status
Main Display Line
Second Display Line
Reference Fields
Application Buttons
Application Icon
Functions
To enable audible signals for Under, Accept, and Over,
Touch Audible Signal-On in the Application Setup screen.
EXPLORER BALANCES EN-39
4.4.7 Statistics for Check Weighing
Use the Statistics function to compare a number of samples and examine the relative deviation of the samples
along with other statistical data. A minimum of three samples is required.
Statistics can be determined manually (with key press after each step) or automatically (weights recorded
automatically when stable). To use the statistics function, enable it first in the Application Setup menu.
Application Setup
First, Enable Statistics.
Touch the
Icon wrench to
enter Setup
menu.
Touch
Statistics
Choose either
Manual
Automatic
press
Accumulating Displayed Values & Viewing Data – Manual
Once Statistics is enabled, two buttons appear on the Application screen: Statistics and Accumulate.
To add the sample to the data set, place the item on the pan and
press Accumulate.
When stable, the
the item is added to the set and the data set quantity increments
by one.
Continue adding items and pressing Accumulate to build the
statistical data set
At any time, press the
Statistics
button momentarily lights to show
Statistics
button to view the results.
.
or
Done
Setup
, then
.
The Statistics Results screen
Press Print to send to the enabled COM port
Press Close to return to the Application home screen
with the current statistics set.
Press
Clear Data
the Application home screen.
to clear the results and return to
Statistics – Automatic
Statistics Automatic mode is similar to manual mode (above) except the first stable weight is automatically
captured. Thus the Accumulate button is not used.
EN-40 EXPLORER BALANCES
4.5 Dynamic/Animal Weighing
Use this application to weigh an unstable load, such as a moving animal. Three different start/reset modes can be
selected: Manual (start and stop via key press), Semi-Automatic (auto-start with manual reset), and Automatic
(start and stop automatically).
Dynamic Weighing – Manual (default)
To set the mode, touch the Setup wrench:
When you make a selection, the Setup options
screen re-appears.
Press Done.
On the Dynamic Weighing home screen, the
default (or last) Averaging Time is displayed.
Follow the screen instructions.
The DYNAMIC WEIGHING Home screen
Main Display Line
Second Display Line
Reference Fields
Application Buttons
Functions Application Icon
Place objects on the pan.
Press the Begin Dynamic button.
The balance begins a countdown (averaging process).
During the countdown, the information line displays the time
remaining.
If necessary, press Cancel to quit and return to the Home
screen.
When the countdown ends, the result is displayed and held.
Press Reset to clear the held weight and return to the Initial
screen.
Clear the pan before beginning a new Dynamic Weighing
Note:
cycle.
EXPLORER BALANCES EN-41
4.5.1 Edit Settings
To view or adjust the current settings:
Press the
Edit Settings
button.
(See Home Screen, previous page.)
The Settings screen appears.
The Application Settings Screen.
Settings available: Averaging Time
Functions Available:
Return to Application
The Averaging Time can be set from 1 to 99 seconds.
The default value is 10. To change it, press the button.
A numeric input window is displayed.
Key in the desired Averaging Time, then press Done.
The display returns to the previous screen with the new value
highlighted.
To return to the Dynamic Weighing home screen,
touch
Return to Application
.
4.5.2 Application Setup
The Application can be customized for various user
preferences.
Touch the Setup wrench to enter the Application Setup
from the home screen.
The
Menu appears.
Setup
Select the list item to view or change the setting as desired.
To return to the Application home screen, press Done.
EN-42 EXPLORER BALANCES
Dynamic Weighing Application Setups (defaults in Bold)
Item Available Settings Comments
Enabled On, Off Turns Application on/off
Auto Sample Mode Manual,
Semi Automatic
Automatic
Statistics Off, Manual, Auto
Lock Settings On, Off Press to lock the current setting(s)
Reference fields
Averaging Time On, Off Time in Seconds
Gross On, Off Gross weight is displayed
Net On, Off Net weight is displayed
Tare On, Off Tare weight is displayed
Print Options
Averaging Time On, Off
4.5.3 Dynamic Weighing – Semi-Auto
The cycle begins when an object (animal) is placed on the pan, but the held value must be reset manually.
To enable this feature, touch the Setup Icon (wrench) in the
top-center of the main screen to enter the
Dynamic Weighing Setup menu.
See Printing Section.
To select the Mode
so they cannot be changed.
Change the mode to Semi Automatic.
The Dynamic – Semi-Automatic screen appears with the
default (or last) Averaging Time displayed.
Place specimen
on the Pan. The
cycle starts
automatically.
After the cycle
ends, the weight
reading is held.
Press the
button to clear the
reading and return
to zero.
Reset
EXPLORER BALANCES EN-43
4.5.4 Dynamic Weighing – Automatic
The cycle begins when an object (animal) is placed on the pan, and the held value is automatically reset
when the object is removed from the pan (10-second delay).
To enable this feature, enter the Dynamic Weighing Setup menu.
Press Auto Sample, and change the mode to Automatic.
The Dynamic – Automatic screen appears with the default
(or last) Averaging Time displayed.
Place objects on the pan to begin.
The cycle starts automatically.
After the cycle ends, remove the specimen and the balance returns
to the Home screen automatically (after a 10-second delay).
EN-44 EXPLORER BALANCES
4.5.5 Statistics for Dynamic Weighing
Use the Statistics function to compare a number of samples and examine the relative deviation of the samples
along with other statistical data. A minimum of three samples is required.
Statistics can be determined manually (Manual mode, with key press after each step) or automatically
(Automatic Mode: weights are automatically recorded when stable). To use the statistics function, enable it first
in the Application Setup menu.
Application Setup
First, Enable Statistics
Touch the
Setup
Icon wrench to
enter Setup
menu.
Press
Statistics
.
Choose either
Manual
Automatic
or
mode, then
press
Done
.
Accumulating Displayed Values & Viewing Data – Manual
Once Statistics is enabled, two buttons appear on the Application screen: Statistics and Accumulate.
To add the sample to the data set, place the item on the pan
and press Accumulate.
When stable, the
Statistics
button momentarily lights to show
the item is added to the set and the data set quantity increments
by one.
Continue adding items and pressing Accumulate to build the
statistical data set
At any time, press the
Statistics
button to view the results.
The Statistics Results screen
Press Print to send to the enabled COM port
Press Close to return to the Application home screen
with the current statistics.
Press
Clear Data
Application home screen.
to clear the results and return to the
Statistics – Automatic
Statistics Automatic mode is similar to manual mode (above) except the first stable weight is automatically
captured. Thus the Accumulate button is not used.
EXPLORER BALANCES EN-45
4.6 Filling
This application allows the user to slowly fill a container to a pre-determined target weight. The progress bar
displays the filling status, and within 10 percent of the target value the progress bar converts to fine resolution
(+/– 10%) for accurate results.
In the upper left portion of the home screen, select Filling.
The default (or last) Target weight is displayed. Place objects on the pan to begin.
The FILLING Home screen
Main Display Line
Second Display Line
Reference Fields
Application Buttons
Functions Application Icon
The progress bar displays the filling status, and within 10 percent of the target value, the progress bar converts
to fine resolution display.
4.6.1 Edit Settings
To view or adjust the current settings:
Touch the
Edit Settings
The Settings screen appears:
Settings available: Target Weight
Functions Available:
Establish a Target Weight
Each time a new item is used for filling, the Target Weight
(fill-to weight) must be established.
There are two (2) methods to establish the Target Weight:
1. The actual Target Weight is known; or
2. The Target Weight can be derived from a sample.
button.
Recalculate Target Weight
Return to Application
,
Establish using a Known Target Weight
The current Target Weight appears on the
the
Target Weight
button. (See above.)
Settings
screen, on
To adjust the Target weight value directly,
touch the
Target Weight
button.
A numeric input window appears.
Enter the desired Target Weight, then press Done.
The display returns to the previous screen with the new value
highlighted.
Press
Return to Application
to go to the
Filling
home screen.
EN-46 EXPLORER BALANCES
Using a Sample to establish new Target Weight - Derived
To establish a new Target Weight value,
press the Recalculate Target Weight button.
The New Target Screen appears, with a message:
Place the target weight on the pan. Press Accept to
continue
Place the weight on the pan (or in a tared container).
Press
The display returns to the Settings screen with the new
Target Weight value highlighted momentarily.
To return to the Filling home screen,
touch
4.6.2 Application Setup
The Application can be customized for various user
preferences.
Touch the
menu from the home screen.
.
Accept
Return to Application
to return to the Settings screen.
Icon (wrench) to enter the Application Setup
Setup
.
The Setup Menu appears.
Select the list item to view or change the setting as
desired.
To return to the Application home screen, touch
.
Done
EXPLORER BALANCES EN-47
The Filling Application Setups (defaults in Bold)
Item Available Settings Comments
Enabled On, Off Turns Application on/off
Secondary Unit On, Off To show the Second Display line
Statistics Off, Manual, Auto
Lock Settings On, Off Press to lock the current setting(s) so they
cannot be changed.
Reference fields
Target Weight On, Off The Target weight is displayed
Difference (Weight) On, Off Displays the Difference to the Target weight
Difference (Percent) On, Off Displays the Difference to the Target weight
Gross On, Off Gross weight is displayed
Net On, Off Net weight is displayed
Tare On, Off Tare weight is displayed
Print Options
Target Weight On, Off
Difference (Weight) On, Off
Difference (Percent) On, Off
4.6.3 Statistics for Filling
Use the Statistics function to compare a number of samples and examine the relative deviation of the samples
along with other statistical data. A minimum of three samples is required.
Statistics can be determined manually (Manual mode, with key press after each step) or automatically
(Automatic Mode: weights are automatically recorded when stable). To use the statistics function, enable it first
in the Application Setup menu.
See Printing Section.
Application Setup
First, Enable Statistics
Touch the Setup
Icon wrench (see
below) to enter
Setup menu.
Touch
or
Done
.
.
Statistics
Choose either
Manual
Automatic
mode, then
press
EN-48 EXPLORER BALANCES
Accumulating Displayed Values & Viewing Data – Manual
Once Statistics is enabled, two buttons appear on the Application screen: Statistics and Accumulate.
To add the sample to the data set, place the item on the pan
and press Accumulate.
When stable, the
the item is added to the set and the data set quantity increments
by one.
Continue adding items and pressing Accumulate to build the
statistical data set
At any time, press the
Statistics
button momentarily lights to show
Statistics
button to view the results.
The Statistics Results screen
Press Print to send to the enabled COM port
Press Close to return to the Application home screen
with the current statistics set.
Press
Clear Data
Application home screen.
to clear the results and return to the
Statistics – Automatic
Statistics Automatic mode is similar to manual mode (above) except the first stable weight is automatically
captured. Thus the Accumulate button is not used.
EXPLORER BALANCES EN-49
4.7 Totalization
Totalization measures the cumulative weight of a sequence of items. Two different Totalization accumulation
modes can be selected: Manual accumulation (requires key press) and Automatic accumulation.
The cumulative total may exceed the capacity of the Balance.
4.7.1 Totalization – Manual (Default)
Touch the upper left portion of the home screen.
A drop-down menu appears. Select Totalization if it is present.
(If not, touch the Menu icon in the bottom-left corner, then
choose Application Modes, scroll down to find Totalization,
press it, then press Enabled to turn it On. It will now appear in
the Application Modes menu on the home screen.
Place objects on the pan to begin.
The TOTALIZATION Home screen
Main Display Line
Second Display Line
Reference Fields
Application Buttons
Functions Application Icon
The sample weight is shown on the Main Display Line.
Press Accumulate to add the weight of the item to the total.
When stable, the new total is shown on the secondary Display Line.
Remove the item from the weighing pan, then add the next item
and continue as above.
When finished, press the
Second Display Line to zero
Clear Total
.
button to reset the
EN-50 EXPLORER BALANCES
4.7.2 Application Setup
The Application can be customized for various user preferences.
Touch the Setup Icon (wrench) to enter the Application Setup
from the home screen.
The Setup Menu appears.
Select the list item to view or change the setting as
desired.
To return to the Application home screen, touch Done.
The Totalization Application Setups (defaults in Bold)
Item Available Settings Comments
Enabled On, Off Turns Application on/off
Auto Sample Mode On, Off To select the mode
Reference fields
Samples On, Off
Average (weight) On, Off Displays the Average
Standard deviation On, Off Displays the standard deviation
Minimum (weight) On, Off Displays the Minimum value
Maximum (weight) On, Off Displays the Maximum value
Range On, Off Displays the Range
Gross On, Off Gross weight is displayed
Net On, Off Net weight is displayed
Tare On, Off Tare weight is displayed
Print Options
See Printing Section.
Samples On, Off
Average (weight) On, Off
Standard Deviation On, Off
Minimum (weight) On, Off
Maximum (weight) On, Off
Range On, Off
To display the number of
samples weighed
EXPLORER BALANCES EN-51
4.7.3 Totalization – Automatic
The weight of the item is added automatically (when stable).
To enable this feature:
1. Touch the Setup Icon (wrench) to enter Application Setup.
2. Press Auto Sample to turn this feature On.
Clear the pan (if necessary). Add a new sample.
The item weight is shown on the Main Display Line.
The weight of the item is automatically added (when stable) to the
total. The new total is shown on the Second Display Line.
Remove the item from the weighing pan, then add the next item
and continue the same as in manual mode.
When finished, press the
Second Display line to zero.
Clear Total
button to reset the
EN-52 EXPLORER BALANCES
4.8 Formulation
Use this application for compounding and recipe making. The number of components can be 2 to 99.
Formulation has two available modes of operation: Free Formulation and Recipe Formulation.
4.8.1 Free Formulation (default)
This mode of Formulation allows the user to freely add components. A filler material is asked for at the end.
In the upper left portion of the home screen, select Formulation.
The FREE FORMULATION Home screen
Main Display Line
Second Display Line
Reference Fields
Application Buttons
Functions Application Icon
To start the compounding process, press
Begin Formulation
A prompt says Place component 1 then press Accept.
The item weight is displayed on the main display Line.
Place the first ingredient on the pan (or in a tared container).
Press Accept to store the first component.
A prompt says Place item 2. Press Accept.
Continue adding components and pressing Accept to store the
weight of the individual components until the formula is
complete.
The Total line shows the total weight of all the components.
Press
at any time in the process to print the recipe.
Print
Then press End Formula.
The display may prompt for a Filler material.
If the formula calls for a filler material, press OK.
A popup message window appears, prompting for the
Filler Material to be added.
Add the filler if needed, then press Accept.
(If no filler is needed, press Accept without adding filler.)
The results are then displayed in a pop-up window.
Free - Formulation Results
Press Print to send data to the enabled COM port
Press Close to close the Results window and return to the
Application home screen
.
EXPLORER BALANCES EN-53
4.8.2 Application Setup
The Application can be customized for various user preferences.
Touch the
icon (wrench) to enter
Setup
Application Setup
from the home screen.
The
Setup Menu
appears.
Select the list item to view or change the setting as
desired.
To return to the Application home screen, touch
Done
.
The Formulation Application Setups (defaults in Bold)
Item Available Settings Comments
Enabled On, Off Turns Application on/off
Mode
Free Formulate,
Recipe Based
Filler On, Off To prompt for a filler material
Secondary Unit On, Off To show the Second Display line
Reference fields
Total On, Off Total is displayed
Gross On, Off Gross weight is displayed
Net On, Off Net weight is displayed
Tare On, Off Tare weight is displayed
Target On, Off For Recipe Based mode
Difference (weight) On, Off For Recipe Based mode
Difference (percent) On, Off For Recipe Based mode
Print Options
See Printing Section.
Total On, Off
Target On, Off
Difference (weight) On, Off
Difference (percent) On, Off
To select the mode
For Recipe Based mode
For Recipe Based mode
For Recipe Based mode
EN-54 EXPLORER BALANCES
4.8.3 Recipe Formulation
Recipe Formulation requires the formula to be entered first,
followed component by component.
To enable this feature, press the Setup icon (wrench) to
enter the Formulation Setup menu.
Change the mode to Recipe Based.
Press Done in the main setup options screen.
The RECIPE FORMULATION Home screen
Main Display Line
Second Display Line
Reference Fields
Application Buttons
Functions Application Icon
Press Begin Formulation.
If no items have been previously set up, the Settings screen
appears.
If items already exist in memory, Formulation begins.
Press the Add New button.
A new default component is added to the end of the Formula
(default Name, Weight).
To change the default component Name, Press Edit Name.
The alpha-numeric entry screen appears.
EXPLORER BALANCES EN-55
Enter the new name, then press 9.
The display returns to the previous screen with the new value
highlighted momentarily.
To change the
default
component
weight, press
Edit Weight.
The numeric
entry screen
appears.
Enter the new
weight, then
press 9.
The display returns to the previous screen with the new value highlighted momentarily.
Continue adding components as required for your formula.
To change the order of a component in the formula, touch the
item to highlight it, then press Move Up or Move Down.
To delete a component, touch the item to highlight it, and
press Delete Item.
To clear all components, press Clear All.
A confirmation is required.
When finished, press
Press Begin Formulation. Follow the screen instructions:
Add the required component in the formula.
The component weight is shown on the Main Display Line.
The progress bar displays the fill status. Within 10 percent of the
target value the progress bar converts to fine resolution display.
Press Accept to add the weight of the component to the total.
The new total appears on the Second Display Line.
The Difference to the target is displayed for each component
(in weight and percent).
Follow the screen instructions to continue adding components
and pressing Accept to complete the Formula.
When finished, the Formulation Results screen is displayed.
Return to Application
.
EN-56 EXPLORER BALANCES
Formulation Results
Press Print to send the results to the enabled COM port.
To close the Results window and return to the Application home
screen, press
Close
.
EXPLORER BALANCES EN-57
4.9 Differential Weighing
Differential weighing stores weight values so samples can be dried or processed and the difference in weight
calculated. Up to 99 samples can be stored.
Differential weighing has two operating modes:
• Auto-Process On, where the initial and final weights are
sequentially gathered for a one item; and
• Auto-Process Off, where initial weights are gathered for
a set of items, then all the final weights for each item are
gathered afterwards.
Touch the
the home screen.
icon (wrench) to enter
Setup
Application Setup
The DIFFERENTIAL WEIGHING Home screen
Main Display Line
Second Display Line
Reference Fields
Application Buttons
Functions Application Icon
from
4.9.1 Item Settings
Press
Item Settings
to set up items in memory.
To set up the item, Press Add New.
EN-58 EXPLORER BALANCES
New items are added with default name and weight
information
(no initial or final weights).
To change the default Item Name, press Edit Name.
The alpha-numeric entry screen appears.
Enter the new name, then press 9.
The display returns to the previous screen with the new value
highlighted momentarily.
Continue adding items as required using Add New.
New items can be added at any time.
To delete an item, touch the item to highlight it,
then press Delete Item.
To Clear the item initial weight press Clear Initial Weight.
(This feature is disabled if no initial weight is stored.)
To Clear the item’s final weight, press Clear Final Weight.
(This feature is disabled if no final weight is stored.)
To clear all items, press Clear All, then confirm.
When finished, press
Return to Application
.
On the main Application screen, follow the screen instructions:
Add the first item, then press Accept to store the value.
The initial weights of the defined item are recorded first, then
the final weights of the items are collected next.
Once the items initial weight and a final weight are stored, the
values are displayed along with the Difference in weight and
percent.
The items are stored in memory. To begin a new Differential
weighing session, delete the initial and/or final weights.
EXPLORER BALANCES EN-59
4.9.2 Application Setup
The Application can be customized for various user preferences.
Touch the
icon (wrench) to enter
Setup
Application Setup
the home screen.
from
The
Menu appears.
Setup
Select the list item to view or change the setting as desired.
To return to the Application home screen, touch
Done
.
The Differential Weighing Application Setups (defaults in Bold)
Item Available Settings Comments
Enabled On, Off Turns Application on/off
Auto-Process Mode On, Off To select the mode
Reference fields
Initial Weight On, Off The initial weight is displayed
Final Weight On, Off The final weight is displayed
Difference (Weight) On, Off Displays the Difference to initial
Difference (Percent) On, Off Displays the Difference to initial
Gross On, Off Gross weight is displayed
Net On, Off Net weight is displayed
Tare On, Off Tare weight is displayed
Print Options
See Printing Section.
Initial Weight On, Off
Final Weight On, Off
Difference (Weight) On, Off
Difference (Percent) On, Off
in weight
in percent
EN-60 EXPLORER BALANCES
4.9.3 Differential Weighing with Auto-Process On
Differential weighing with Auto Process On requires the initial and final weights to be sequentially gathered for a
single item.
To enable this feature, touch the Setup icon (wrench) from the
home screen to enter Application Setup.
Press Auto Process to turn it On.
Follow the screen instructions to begin.
The DIFFERENTIAL WEIGHING – Auto Home screen
Main Display Line
Second Display Line (not shown)
Reference Fields
Application Buttons
Functions Application Icon
Follow the screen instructions:
Press
Item Settings
to set up items in memory if necessary.
Use the buttons as necessary.
Follow the same steps as shown on page 57.
Press
Return to Application
when ready.
A message prompts for Item 1 to be placed on the pan again,
then to press
Accept to establish Final Weight
.
After
Accept
pressed, the difference between initial and
final weights
appears in the
Reference
Fields.
A message
prompts to start
the process
again, if
desired.
is
EXPLORER BALANCES EN-61
4.10 Density Determination
The Explorer can be used to determine an object’s density. Four types of density determination can be made:
1. Solids more dense than water
2. Solids less dense than water
3. Liquid density
A density determination kit is designed to be used with Ohaus Explorer balances. Illustrations in this procedure
refer to the density kit. However, you may use whatever lab apparatus that suits the requirements for density
measurements. The balance software includes a built-in reference density table for water at temperatures
between 10°C and 30°C. Review this entire section before attempting density measurements.
When making density measurements the material should weigh at least 10 mg on an analytical balance and 100
mg on a precision balance.
Density can be determined manually (with a key press after each step) or automatically (weights are
automatically recorded). Before making density measurements, establish the Application Settings.
4. Porous material (impregnated with oil)
The DENSITY DETERMINATION Home screen
Main Display Line
Second Display Line (not shown)
Reference Fields
Application Buttons
Functions Application Icon
4.10.1 Measuring the Density of a Solid Using Water (default)
Press the Setup button (the wrench) to open the Density
Determination Settings screen.
Confirm the following Setups are selected:
9 Density Type: Solid
9 Liquid Type: Water
9 Porous Material: Off
Press
to return to the Density Determination home screen.
Done
The Edit Settings Screen.
Settings available: Water Temp
Functions Available:
Return to Application
To adjust the water temperature value,
touch the Water Temp button.
The balance calculates water density based on the water
temperature value entered (internal lookup table).
Measure the actual water temperature using a precision
thermometer.
EN-62 EXPLORER BALANCES
A numeric input window appears.
Enter the actual water temperature, then press Done.
The display returns to the previous screen with the new value
highlighted.
To return to the Density Determination home screen,
touch Return to Application.
To begin the Density Determination process,
press
(See below.)
Once the necessary weights have been determined, the density of the sample is displayed in g/cc
(along with the weight in air, weight in water) on the Application screen.
Press
Begin Density Determination
Begin Density Determination
to reset all the weight values and restart the process.
.
Step 1 of 2 –
Weigh the
Sample in Air.
Press
Begin
Density
Calculation
Follow screen
instructions,
then press
Accept
to store the dry
sample weight
(“in air”).
Step 2 of 2 –
Weigh the
Sample
Submerged in
the Liquid.
Follow the
screen
instructions,
then press
Accept
to store the
sample weight
(submerged in
liquid).
.
EXPLORER BALANCES EN-63
4.10.2 Application Setup
The Application can be customized for various user preferences.
Touch the
Icon (wrench) to
enter Application
Setup from the
home screen.
Setup
The Density Application Setups (defaults in Bold)
Item Available Settings Comments
Enabled On, Off Turns Application on/off
Density Type Solid, Liquid To select either solid or liquid
Liquid Type Water, Other Liquid used during measurements
Porous Material On, Off To select Porous material
Auto Print Result On, Off To automatically print results
Auto Sample Mode On, Off To select the mode
Reference fields
Liquid Density On, Off Test liquid’s density is displayed
Water Temperature On, Off The water temp is displayed
Oil density On, Off The test oil’s density is displayed
Weight in Air On, Off The sample weight is displayed
Oiled Weight On, Off The sample weight is displayed
Weight in Liquid On, Off The sample weight is displayed
Sinker volume On, Off Displays volume of the Sinker
Print Options
See Printing Section.
Porous Material On, Off
Liquid Type On, Off
Liquid Density On, Off
Water Temperature On, Off
Weight in Air On, Off
Weight in Liquid On, Off
The
Setup Menu
appears.
Select the list item to view or change the setting as
desired.
To return to the Application home screen, touch
Done
.
EN-64 EXPLORER BALANCES
4.10.3 Measuring the Density of a Buoyant Material Using Water
Press the Setup button (the wrench) to open Settings screen.
Confirm the following Setups are selected:
9 Density Type: Solid
9 Liquid Type: Water
9 Porous Material: Off
Press
to return to the Density Determination home screen.
Done
Follow the same procedure as Solid Material above, except in
Density Determination step 2, push the sample down into the
liquid until it is fully submerged.
4.10.4 Measuring the Density of a Solid Using an Auxiliary Liquid
To enable this feature, enter the Density Setup menu and select the following:
Density Type: Solid; Liquid Type: Other; Porous Material: Off. See Application Setup.
The DENSITY DETERMINATION – SOLID Home screen
Main Display Line
Second Display Line
Reference Fields
Application Buttons
Functions Application Icon
Confirm the default values displayed (Liquid Density, etc) are
correct.
To edit the default values, touch
Edit Settings
and the
application Settings screen appears.
Settings available: Liquid Density
Functions Available:
Return to Application
To adjust the Liquid Density value, touch the Liquid Density
button.
Measure the actual liquid density of the Density setup and enter
it.
A numeric input window appears.
Key in the density in g/cc, then press Done.
The display returns to the previous screen with the
new value highlighted.
EXPLORER BALANCES EN-65
To return to the Density Determination home screen,
touch Return to Application.
Begin the Density determination process as per above.
4.10.5 Measuring the Density of a liquid using a Calibrated Sinker (not supplied)
Enable this feature, enter the Density Setup menu and select the following; Density Type: Liquid.
(See Application Setup.)
Note: when the Density Type is set to Liquid, the Liquid type and Porous material selections are disabled.
The DENSITY DETERMINATION – LIQUID Home screen
Main Display Line
Second Display Line
Reference Fields
Application Buttons
Functions Application Icon
Confirm that the default value displayed (sinker volume) is
correct. To edit the default values, touch
Settings screen is now displayed:
Settings available: Sinker Volume
Functions Available:
To adjust the Sinker volume value, touch the
button.
Return to Application
Edit Settings
Sinker Volume
and the
EN-66 EXPLORER BALANCES
A numeric input window is displayed.
Key in the desired value, then press 9.
The display returns to the previous screen with the new value
highlighted.
To return to the Density Determination home screen,
touch Return to Application.
Begin Density Determination
Press
Step 1 of 2 – Weigh the Sinker in Air.
Follow the screen instructions, then press
to store the sinker weight (“in air”).
to start the process.
Accept
Step 2 of 2 – Weigh the Sinker Submerged in the Test
Liquid.
Follow the screen instructions, then press Accept
to store the sinker weight (submerged in liquid).
Once the necessary weights have been determined,
the density of the Liquid sample is displayed in g/cc
(along with the weight in air, weight in water)
on the Application screen.
Press
Begin Density Determination
values and restart the process.
to reset all the weight
EXPLORER BALANCES EN-67
4.10.6 Measuring the Density of Porous Material Using Oil
To enable this feature, enter the Density Determination
Setup menu, and set the following:
9 Density Type: Solid
9 Liquid Type: Water
9 Porous Material: On
The DENSITY DETERMINATION – POROUS Home screen
Main Display Line
Second Display Line
Reference Fields
Application Buttons
Functions Application Icon
Confirm the default values displayed (Water Temp) are correct.
To edit the default values, touch
The Settings screen appears.
Settings available: Water Temp, Oil Density
Functions Available:
The balance calculates water density based on the water
temperature value entered (look-up table).
Measure the actual water temperature using a precision
thermometer.
To adjust the Water Temperature or Oil Density values,
touch the Water Temp or Oil Density button.
Numeric input windows appear.
Key in the desired value,
then press 9.
The display returns to the previous
screen with the new value highlighted.
To return to the Density Determination
home screen, touch
Return to Application.
Edit settings
Return to Application
.
EN-68 EXPLORER BALANCES
Press Begin Density Calculation.
Step 1 of 3 – Weigh the Un-Oiled Sample in Air.
Follow the screen instructions then press
dry sample weight (in air).
Accept
to store the
Step 2 of 3 – Weigh the Oiled Sample in Air.
Follow the screen instructions then press
to store the sample weight (oiled).
Accept
Step 3 of 3 – Weigh the Oiled Sample Submerged in Liquid.
Follow the screen instructions then press
to store the oiled sample weight (submerged in liquid).
Accept
Once the necessary weights have been determined, the density
of the sample is displayed in g/cc (along with the weight in air,
un-oiled and oiled, and weight in water) on the Application
screen
The value stays on the display until Begin Density
Determination is touched.
Press
Begin Density Determination
values and restart the process.
to reset all the weight
EXPLORER BALANCES EN-69
4.11 Peak Hold
The Peak Hold application allows the user to capture and store the highest stable weight in a series of weight
measurements.
Three different start/reset modes can be selected:
9 Manual (start and stop the capture via key press),
9 Semi-Automatic (start automatically/reset manually); and
9 Automatic (start and stop the capture automatically).
This application allows both stable and unstable weights to be captured.
4.11.1 Peak Hold – Semi-Automatic (default)
In the upper left portion of the home screen, select Peak Hold.
Follow the screen instructions to begin.
The PEAK HOLD Home screen
Main Display Line
Second Display Line
Reference Fields
Application Buttons
Functions Application Icon
Place item on the pan. The capture process starts automatically.
The highest reading is held on the display.
To release the reading, press
The following screen appears.
End Peak Hold
.
Clear the pan or press
process.
to reset the display and re-start the
Tare
EN-70 EXPLORER BALANCES
4.11.2 Application Setup
The Application can be customized for various user preferences.
Touch the
icon (wrench) to enter
Setup
Application Setup
the home screen.
The
Setup Menu
appears.
Select the list item to view or change the setting as
desired.
To return to the Application home screen, touch
from
Done
.
The Peak Hold Application Setups (defaults in Bold).
Item Available Settings Comments
Enabled On, Off Turns Application on/off
Auto Sample Mode Manual,
Semi Automatic
Automatic
Stable Weight Only On, Off To capture Stable values only
Secondary Unit On, Off To show the Second Display line
Reference fields
Gross On, Off Gross weight is displayed
Net On, Off Net weight is displayed
Tare On, Off Tare weight is displayed
Print Options
See Printing Section.
Stable Weight Only On, Off
To select the mode of operation
EXPLORER BALANCES EN-71
4.11.3 Peak Hold – Manual
For manual start and reset, choose Manual mode.
To enable this feature, enter the Peak Hold Setup menu:
Change the mode to Manual.
Follow the screen instructions: Place item on the pan.
Press
Begin Peak Hold
The following screen appears:
to begin the capture process.
The PEAK HOLD – Manual Home screen
Main Display Line
Second Display Line
Reference Fields
Application Buttons
Functions Application Icon
The highest stable weight reading is held indefinitely.
Press
End Peak Hold
and re-start the process.
then clear the pan to reset the display
EN-72 EXPLORER BALANCES
4.11.4 Peak Hold – Automatic
For automatic start and reset, choose Automatic mode.
To enable this feature, enter the Peak Hold Setup menu.
Change the mode to Automatic.
The HIGH POINT – Auto Home screen
Main Display Line
Second Display Line
Reference Fields
Application Buttons
Functions Application Icon
Place item on the pan. The capture process starts automatically.
The highest stable weight reading is held until the weight is
removed.
The process starts automatically once the weight is removed
from the pan (after 10 sec delay).
EXPLORER BALANCES EN-73
4.12 Ingredient Costing
This application allows the user to determine the cost of a formula or recipe based on the known cost and quantity
of the components or ingredients. Up to 99 components are allowed.
In the upper left portion of the home screen, select Ingredient Costing.
Follow the screen instructions to begin.
The INGREDIENT COSTING Home screen
Main Display Line
Second Display Line
Reference Fields
Application Buttons
Functions Application Icon
4.12.1 Item Settings
Press Item Settings to set up items in memory.
The Edit Settings Screen.
Settings available: Add New, Edit name, Edit Cost,
Edit Unit, Delete Item, Clear All
Functions Available:
Return to Application
To set up the item(s) in memory, Press Add New.
A new item is added (default Name) with default info
(cost per weight and weight unit).
EN-74 EXPLORER BALANCES
To change the default item name, Press Edit Name.
The alpha-numeric entry screen appears.
Enter the new name, then press 9.
The display returns to the previous screen with the new value
highlighted momentarily.
To change the default component cost per unit,
Press Edit Cost.
The numeric entry screen appears.
Enter the new weight, then press Done.
The display returns to the previous screen with the new value
highlighted momentarily.
To change the default component Unit, press Edit Unit.
The Weighing Units screen appears.
EXPLORER BALANCES EN-75
Continue adding items as required, using Add New.
New items can be added at any time.
To delete an item, touch the item to highlight it,
then press Delete Item.
To clear all items, press Clear All. A confirmation is required.
When finished, press
Return to Application
.
Once setup is complete and the application screen is displayed,
follow the screen instructions:
Add the first item then press Accept to store the value in
memory.
The weight of the item is recorded,
then the screen prompts for the next component.
Unit Cost, Total Weight
and
Total Cost
are also displayed.
Continue follow the screen instructions to add the items to the
pan and touch the Accept button until each item has been
weighed.
Press the View Data button at any time to show the current
results: (Item, Item Cost and Item Weight).
After the last item has been weighed, press View Data to see
the results.
(Cancel the current data set by pressing
Clear Data
.)
Ingredient Costing Results.
Press Print to send the data to the enabled COM port.
Press Close to close the results window and return to the
Application home screen.
EN-76 EXPLORER BALANCES
4.12.2 Application Setup
The Application can be customized for various user preferences.
Touch the
Icon (wrench) to enter Application Setup from
Setup
the home screen.
The
Setup Menu
is now displayed.
Select the list item to view or change the setting as
desired.
To return to the Application home screen, touch
Done
.
The Ingredient Costing Application Setups (defaults in Bold)
Item Available Settings Comments
Enabled On, Off Turns Application on/off
Currency label None, various To select the Currency label
Reference fields
Unit Cost On, Off To display the Item cost
Total Weight On, Off To display the Total weight
Total Cost On, Off To display the Total cost
Gross On, Off Gross weight is displayed
Net On, Off Net weight is displayed
Tare On, Off Tare weight is displayed
Print Options
See Printing Section.
Total Weight On, Off
Total Cost On, Off
EXPLORER BALANCES EN-77
4.13 Pipette Adjustment
Pipette adjustment checks the accuracy and precision values of pipettes by weight analysis. The balance has a
built-in density reference table for water at temperatures between 10°C and 30°C. If other liquids are used for
pipette calibration, enter the liquid’s density at current room temperature in g/cc. Since all calculations are made
within the balance, the atmospheric pressure is also required.
Pipette adjustment can be accomplished manually (with a key press after each step) or automatically (weights
are automatically recorded when stable). Calculations made within the balance provide results of inaccuracy and
imprecision. Up to 30 samples can be used.
The PIPETTE ADJUSTMENT Home screen
Main Display Line
Second Display Line
Reference Fields
Application Buttons
Functions Application Icon
4.13.1 Pipette Adjustment – Manual (default)
Confirm the default values displayed are correct:
Nominal, Inaccuracy, Imprecision, Density, Atmospheric
Pressure, Water Temperature, etc.
To edit the default values, touch the
The Edit Settings Screen.
Settings available: Nominal Capacity, Water Temp,
Inaccuracy, Atmospheric Press,
Imprecision, Pipette Name,
Pipette Number
Functions Available:
To adjust the pipette Nominal Capacity value,
touch the Nominal button.
Enter the Nominal Capacity in the keyboard screen that
appears, and press 9.
The display returns to the previous screen with the new value
highlighted.
Note:
Application Setup.
Capacity can be measured in mL or uL, depending on the
Return to Application
Edit Settings
button.
EN-78 EXPLORER BALANCES
To adjust the water temperature, touch the Water Temp button.
The balance calculates water density based on the water
temperature value entered. Measure the actual water
temperature using a precision thermometer.
A numeric input window is displayed.
Key in the desired temperature, then press Done.
The display returns to the previous screen with the new value
highlighted.
Continue to enter the required information
following the above procedure:
Pipette Inaccuracy, via the Inaccuracy button
Barometric Pressure, via the Barometric Pressure button
Pipette Imprecision, via the Imprecision button
Pipette Name, via the Pipette Name button
Pipette Number
When finished, press Return to Application.
The Application home screen appears, and you can begin the
Pipette Adjustment process.
, via the
Pipette number
button
EXPLORER BALANCES EN-79
4.13.2 Begin Pipette Adjustment Process
Step 1 – Dispense the First Sample
Follow the screen instructions, then press
first sample weight (liquid).
Accept
Touch
Begin Pipette
Adjustment.
Follow the
screen
instructions, to
Place
container on
the pan. Then
Press Tare.
to store the
Continue to follow the screen instructions by dispensing
samples and pressing Accept to store each sample weight
(liquid).
The default number of samples is 10.
It can be changed in Setup, from 2 to 30 samples.
Once all the sample
weights have been
dispensed,
the Results screen is
automatically
displayed.
Press
results plotted. Press
Result
result screen. Press
to return to the
Close
Pipette Adjustment
home screen.
Note: To view either the results or graph screens again from the home screen, press the View Result button.
To start a new Pipette Adjustment process, press Begin Pipette Adjustment.
to see
Graph
to return to the
EN-80 EXPLORER BALANCES
4.13.3 Application Setup
The Application can be customized for various user preferences.
Touch the
Icon (wrench) to enter the
Setup
Application Setup
from the home screen.
The
Setup Menu
Select the list item to view or change the setting as
desired.
To return to the Application home screen, touch
The Pipette Adjustment Application Setups (defaults in Bold)
Item Available Settings Comments
Enabled On, Off Turns Application on/off
Auto Sample Mode On, Off o To select the mode of operation
Number of Samples 2 – 30 (default 10) To select the number of samples
Liquid Type Water, Other Liquid used during measurements
Unit of Pressure
Volume Unit (Pipette
capacity unit)
Secondary Unit On, Off To show the Second Display line
Lock Settings On, Off Press to lock the current setting(s) so
Reference fields
Print Options
appears.
Done
ATM, inHg, KPa,
mbar, mmHg, PSIA
mL, uL Nominal capacity unit
Nominal Volume On, Off Nominal capacity displayed
Inaccuracy On, Off Inaccuracy value displayed
Imprecision On, Off Imprecision value displayed
Liquid Density On, Off Liquid density value displayed
Barometric Unit On, Off Barometric Pressure value displayed
Water Temperature On, Off Water temperature is displayed
See Printing Section.
Nominal Volume On, Off
Inaccuracy On, Off
Imprecision On, Off
Liquid Density On, Off
Barometric Unit On, Off
Water Temperature On, Off
.
To select Atmospheric Pressure unit
they cannot be changed.
EXPLORER BALANCES EN-81
4.14 Statistical Quality Control (SQC)
The Statistical Quality control (SQC) feature is useful during various types of process filling operations, to monitor
and/or control the process to eliminate under- and over-filling.
As samples are weighed and stored in the balance, a Trend Analysis is developed and can be displayed.
Up to 10 batches with up to 80 samples in a batch are visible for quality control purposes. Each batch of samples
is shown, with the maximum, minimum, standard deviation and mean values for each batch. An on-going
examination of the relative deviation of the samples along with other statistical data can be viewed.
The filling process operation can be effectively monitored by observing the results on the View Trace screen.
SQC collection can be done manually (Manual mode, requires key press after each step) or
automatically (Auto Mode, the weights are automatically recorded when stable).
In the upper left portion of the home screen, select SQC.
The SQC Home screen
Main Display Line
Second Display Line
Reference Fields
Application Buttons
Functions Application Icon
4.14.1 Edit Settings
Confirm the default values (
Nominal, Inaccuracy, Imprecision
Density, Atmospheric Pressure, Water Temperature
are correct.
To view/edit the default values, touch the
Edit Settings
The Settings screen appears.
Settings available: Nominal Target weight,
+Tolerance 1, –Tolerance 1,
+Tolerance 2, –Tolerance 2
Functions Available:
Return to Application
To adjust the Nominal Target weight value,
touch the Nominal button.
A numeric input window appears.
Key in the desired Nominal Weight, then press 9.
The display returns to the previous screen with the new value
highlighted.
,
, etc.)
button.
EN-82 EXPLORER BALANCES
Continue to enter the required information following the above
procedure:
Positive Tolerance 1, via the +Tolerance 1 button.
Negative Tolerance 1, via the –Tolerance 1 button.
Positive Tolerance 2, via the +Tolerance 2 button.
Negative Tolerance 2, via the –Tolerance 2 button.
Tolerances can be in either weight (default) or percent –
See
Application Setup
When finished, press Return to Application and the SQC home
screen appears.
4.14.2 Begin the SQC Process
, Section 4.14.3.
Touch the
New Batch
button.
First Batch: the
screen prompts
for the Batch
name.
Enter the Batch
name, then
press 9.
Begin
The Process screen is then displayed.
Follow the screen instructions, then press Accept
to store the sample weight.
The current number of
Minimum
Continue to follow the screen instructions by weighing samples
and pressing Accept to store each sample’s weight.
The sample size is 10 (default).
It can be changed in Setup from 2 to 80 pieces.
At any time, press
screen, showing results for the current Batch.
Once all the samples have been weighed,
the
If the COM interface is enabled, press
either to a computer or a printer.
Press
A message offers the chance to save the batch, if desired.
value,
Results
Close
screen appears automatically.
to return to the current Batch process.
Samples
Maximum
End Batch
value, and
to see the Individual results
, along with the
are displayed.
Range
to send the results
Print
Average, Sum
,
EXPLORER BALANCES EN-83
To view the process results of this batch (and any other saved
batch), press the
View Batch History
button.
The Batch History screen shows the basic information –
Maximum, Minimum, Average (mean), and Standard
Deviation – for all currently saved batches.
Press Select to see (and print) the Batch Information screen for
any saved batch.
Press Clear Batches to reset SQC results and
return to the SQC home screen
Press
begin another batch or to view process results.
to return to the SQC home screen to
Close
To view the
Process results
graphically
(batch
comparison),
press the View
Trace button.
Press Print or
Close as
above.
EN-84 EXPLORER BALANCES
4.14.3 Application Setup
The Application can be customized for various user preferences.
Touch the
Icon (wrench) to enter
Setup
Application Setup
the home screen.
from
The
Setup Menu
is now displayed.
Select the list item to view or change the setting as
desired.
To return to the Application home screen, touch
The SQC Application Setups (defaults in Bold)
Item Available Settings Comments
Enabled On, Off Turns Application on/off
Number of Samples 2 – 80 (default 10) To select the number of samples in a Batch
Tolerance Mode Weight,
Percent
Auto Sample Mode Manual,
Semi Automatic,
Automatic
Lock Settings On, Off Press to lock the current setting(s) so they
Reference fields
Number of Batches On, Off The total batches
Number of Samples On, Off The total samples
Average On, Off The Average value is displayed
Total On, Off The Sum value is displayed
Maximum On, Off The Maximum value is displayed
Minimum On, Off The Minimum value is displayed
Range On, Off The Range is displayed
Print Options
See Printing Section.
Number of Batches On, Off
Number of Samples On, Off
Average On, Off
Total On, Off
Maximum On, Off
Minimum On, Off
Range On, Off
Done.
Tolerance used during measurements
To select the mode of operation
cannot be changed.
EXPLORER BALANCES EN-85
4.15 Statistics
Statistics are used to compare a number of samples and examine the relative deviation of the samples along with
other statistical data. A minimum of three samples is required.
Statistics can operate manually (key press after each step) or automatically (weights automatically recorded
when stable). To use the statistics feature, enable it in the Application Setup menu.
This feature is available in Weighing, Counting, Check Weighing, Dynamic Weighing and Filling applications.
4.16 Library
When an item is processed on a regular basis, the item’s data may be stored in memory for future use. This
memory is referred to as the Balance’s Library.
The following data is stored for the Application used:
Parameters
Application
Weighing
Counting
Percent Weighing
Check Weighing
Dynamic Weighing
Filling
Totalization
Formulation
Differential Weighing
Density Determination
Peak Hold
Ingredient Costing
Pipette Adjustment
SQC
and setups
Name
x x x
x x x x x x x x
x x x x
x x x x x x
x x x x
x x x x
N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
x x x
N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
x x x
x x x
4.16.1 Creating a Library Record
To create a Library record, the Settings screen is used. From the home screen, touch the Edit Settings button.
The Settings screen is now displayed.
Preset
Tare
APW
Touch the
Settings
button.
Ref Wt.
or Target
Edit
Sample
size
Under
Limit
Over
Limit
Level Mode
The
Settings
screen appears.
Confirm the
application settings;
then touch Save
(the diskette,
top-right).
An alphanumeric
entry screen
appears, to enter
the Library Record
name.
EN-86 EXPLORER BALANCES
Enter the Record name,
then press 9.
Note: Library Record names
can be 8 characters or less.
A
Record is saved
appears. Press OK, then…
Press
4.16.2 Retrieving a Library Record
Load a Library record from the home screen.
Press the
Library
bar in the upper right area of the screen.
(It shows the name of the most recently used library file.)
The Library manager popup is now displayed.
Touch the Library Record to highlight it, then touch Recall
to load the record’s settings into the Application.
message
Return to Application
.
Then press
to return to the home screen with the Library
Close
name displayed and the stored parameters active.
4.16.3 Deleting a Stored Library Record
To delete a stored record, follow “Retrieving a Library Record” above, but press Delete instead of Recall.
EXPLORER BALANCES EN-87
4.17 Additional Features
4.17.1 Weigh Below
The Explorer Balance is equipped with a weigh below hook for weighing below the balance.
Note: before turning the balance over, remove the Pan, Pan Support, Wind Ring/Shield and Draft Shield
elements (if present) to prevent damage.
CAUTION: Do not place the balance on the pan support cone or Load cell Pins
To use this feature, remove power from the balance, then remove the protective cover for the weigh below
opening (2 screws). The protective cover is reversible for easy storage.
The balance can be supported using lab jacks or any other convenient method. Ensure the balance is level and
secure. Power on the Balance, then use a string or wire to attach items to be weighed.
EN-88 EXPLORER BALANCES
5. MENU SETTINGS
5.1 Menu Navigation
All menu navigation is performed by touching the display. To enter the Menu, touch Menu from any Application
Home screen. The Main menu appears, with buttons for Main, Back and Done. Continue touching the
appropriate list item to navigate to the Menu items or touch a button to change location.
5.1.1 Changing Settings
To change a menu setting, navigate to that setting using the following steps:
Enter the Menu
From any Application screen, Touch Menu.
The Main Menu List appears on the display.
Select the Sub-Menu
Scroll down to the selected item of the Main Menu List
and touch it. The Sub-Menu appears.
Select the Menu Item
Continue until the desired setting is chosen in the
Menu list. Touch the setting to change it.
The changed setting will be displayed as highlighted
for 2 seconds to confirm the changed value.
Exit the Menu and Return to the Current Application
After the setting is confirmed, touch Done to return to the Application.
Note: at any time the Main, Back & Done buttons can be touched to navigate to the desired area of the menu or
return to the current Application.
EXPLORER BALANCES EN-89
5.2 Main Menu
The Explorer balance Main menu structure is illustrated below.
Calibration User
Settings
Library I/O
Settings
Balance
Setup
Diagnostics
Application
Modes
Factory
Reset
Weighing
Units
Lockout Information
GLP and
GMP Data
Communication
5.3 Calibration
Explorer Balances offer a choice of six calibration methods: Internal Calibration, AutoCal Calibration,
Calibration Adjust, Span Calibration, linearity Calibration, and User Calibration.
Note: Do not disturb the balance during any calibration.
5.3.1 Calibration sub-menu
AutoCal™
Internal
Calibration
5.3.2 Internal Calibration (AutoCal™)
Calibration is accomplished with the internal calibration mass. Internal calibration can be performed at
any time, provided the balance has warmed up to operating temperature and is level.
With the Balance turned ON and no load on the pan, touch AutoCal™ Internal Calibration.
The Balance begins to calibrate.
Alternately, touch the shortcut Calibration Icon from any Application home screen
to initiate an Internal Calibration.
The display shows the status, then returns to the current application.
Automatic
Calibration
AutoCal™
Adjustment
Span
Calibration
User
Calibration
Calibration
Test
To cancel at any time, press Cancel.
5.3.3 Automatic Calibration
When Automatic Calibration is set ON, the balance performs a self calibration when a measured
predefined change occurs (in temperature or time). AutoCal will automatically calibrate the Balance (using
the internal mass) each time a change in temperature significant enough to affect accuracy, or after every
11 hours.
EN-90 EXPLORER BALANCES
5.3.4 AutoCal™ Adjustment
Use this calibration method to adjust the zero calibration point, without affecting the span or linearity
calibration.
Calibration Adjust may be used to adjust the result of the Internal calibration by +
100 divisions.
Note: Before making a calibration adjustment, perform an Internal Calibration. To verify whether an
adjustment is needed, place a test mass equal to the span calibration value* on the pan and note the
difference (in divisions) between the nominal mass value and the actual Balance reading. If the difference
is within +
1 division, calibration adjustment is not required. If the difference exceeds +1 division,
calibration adjustment is recommended. (*See Table 5-1, below.)
Example:
Actual weight reading: 200.014
Expected weight reading: 200.000 (Test mass value)
Difference Weight (d): 0.014
Difference weight in digits: –14 (Adjust value)
To perform a Calibration Adjustment, touch AutoCal Adjustment from the Calibration Menu; Enter the
value (positive or negative divisions) to match the difference noted earlier in the procedure and press 9.
Recalibrate using Internal Calibration. After calibration, place the test mass on the pan and verify that the
mass value now matches the displayed value. If not, repeat the procedure until Internal Calibration
reading agrees with the test mass.
Once completed, the balance stores the Adjustment value and the display returns to the current
application.
5.3.5 Span Calibration
Span calibration uses two calibration points, one at zero load and the other at specified full load (span).
Refer to Table 5.1 for Span values.
Note: Factory default settings are shown in bold.
TABLE 5-1 Calibration Masses
Model Span Calibration Points Weight Class
EX124 50g, 100g ASTM Class 1 OIML E2
EX224 100g, 150g, 200g ASTM Class 1 OIML E2
EX324, M, N 150g, 200g, 300g ASTM Class 1 OIML E2
EX223 100g, 150g, 200g ASTM Class 1 OIML E2
EX423 200g, 300g, 400g ASTM Class 1 OIML E2
EX623 300g, 400g, 500g, 600g ASTM Class 1 OIML E2
EX1103, M, N 500g, 1000g ASTM Class 1 OIML E2
EX2202 1000g, 2000g ASTM Class 1 OIML E2
EX4202 2000g, 3000g, 4000g ASTM Class 1 OIML E2
EX6202 3000g, 4000g, 5000g, 6000g ASTM Class 1 OIML E2
EX10202, M, N 5000g, 10,000g ASTM Class 1 OIML E2
EX6201 3000g, 4000g, 5000g, 6000g ASTM Class 2 OIML F1
EX10201 5000g, 10,000g ASTM Class 1 OIML E2
With the balance turned ON and no load on the pan, touch Span Calibration to initiate the procedure.
Additional calibration values to be used are shown on the display. The best accuracy is achieved using
the mass closest to the full span value.
Note: To change the span calibration point, touch the alternate weight shown on the display.
Follow the screen instructions and place the specified calibration weight on the scale when prompted to
do so. When complete, the display shows the Span calibration status and returns to the current
application.
EXPLORER BALANCES EN-91
5.3.6 User Calibration
User Calibration is used to calibrate the balance using a user defined mass.
With no load on the scale, press User Calibration from the calibration sub-menu.
The display shows the current full load (span) calibration point and calibration unit of measure.
To change the value to a user-defined weight, touch ENTER VALUE.
Enter the weight via the popup screen. The balance then prompts for the User-defined weight.
Place the specified calibration weight on the balance and the calibration process completes.
The display shows status, then returns to the current application.
5.3.7 Calibration Test
Use Calibration Test to compare a known calibration weight against the stored span calibration data.
With no load on the scale, press Cal Test to begin the process.
The balance captures the zero point, then prompts for the span value.
The display shows status, followed by the difference between the current calibration weight and the
stored calibration data.
After 3 seconds, the display returns to the current application.
EN-92 EXPLORER BALANCES
5.4 User Settings
When using the Balance for the first time, enter this sub-menu to set User-defined values like Language,
Display Settings, Volume, Functions Configuration and the Touchless Sensor setup.
5.4.1 User Settings Sub-menu
Language Volume Display
Settings
User
Manager
Functions
Configuration
Factory default settings are shown below in bold.
5.4.2 Language
Set the language displayed for menus and displayed messages.
English (default)
German
French
Spanish
Italian
5.4.3 Volume
Controls the built-in Speaker loudness.
Default value= 5 (mid-level)
0= disabled (Off)
Range is 0 to 10
5.4.4 Display Settings
Use this sub-menu to change the setting for:
Screen Brightness: Default value= 50 (mid-level)
Range is 20 to 100
Touch Calibrate
“Touch the screen at the center of the ring. O Press here.”
(First top-left, then bottom-right.)
Auto Dim (Dims the display if no Screen Activity for x minutes)
Default value = OFF (disabled). Range is 1 to 240 minutes
5.4.5 User Manager
Enter this sub-menu to create user profiles if desired.
User Level: Default is Standard User; Administrator is available.
Change PIN: Set password if desired.
Lockout: Can be used by Administrator to lockout the Menu items of a
named User.
Sensor
Setup
Draft Shield
Light
(Analytical
models)
EXPLORER BALANCES EN-93
5.4.6 Functions Configuration
Touch Functions Configuration to see a table of Selected and
Available functions. Press > to move a function from Available to
Selected, and press < to move them back.
To move all functions to the right, Press >> and press <<
to move them back.
5.4.7 TouchLess Sensor Setup
If desired, assign Print, Zero, Tare, or Calibrate
to the Touchless Sensors Terminal Right, Terminal Left,
Base Right, and Base Left.
5.4.8 Draft Shield light
Set the status of the lighted Draft Shield feature.
OFF = disabled.
ON = enabled.
EN-94 EXPLORER BALANCES
5.5 Balance Setup
Enter this sub-menu to customize Balance display functionality.
5.5.1 Balance Set-up sub-menu
Stability
Filter Level Auto Zero
Indicator Range
Gross Indicator Legal For Trade Graduations Date & Time
Factory default settings are shown below in bold.
5.5.2 Stable Range
Set the amount the reading can vary while the stability symbol remains on.
0.5 D = 0.5 graduations
1 D = 1 graduation
2 D = 2 graduations
3 D = 3 graduations
5 D = 5 graduations
Note: When LEGAL FOR TRADE (below) is set to ON, the setting is forced to 1 D.
The setting is locked when the Security Switch is set to the ON position.
5.5.3 Filter level
Set the amount of signal filtering.
LOW = faster stabilization time with less stability.
MEDIUM = normal stabilization time with normal stability.
HIGH = slower stabilization time with more stability.
5.5.4 Auto Zero Tracking
Set the automatic zero tracking functionality.
OFF = disabled.
0.5 D = display maintains zero up to a drift of 0.5 graduation
1 D = display maintains zero up to a drift of 1 graduation per
3 D = display maintains zero up to a drift of 3 graduations per
Note: When Legal for Trade is set to ON, the AZT setting is forced to 0.5 D.
The OFF setting is still available. The setting is locked at the current setting when the
security switch is set to the ON position
per second
second.
second.
Tracking
Auto Tare
EXPLORER BALANCES EN-95
5.5.5 Auto Tare
Set the automatic Tare.
OFF = disabled.
5.5.6 Gross Indicator
Set the symbol displayed for gross weights.
5.5.7 Legal For Trade
Use this menu to set the Legal for Trade status.
Note: When Legal for Trade is set to ON, the menu settings are affected as follows:
Calibration Menu:
Balance Setup Menu:
Communication Menu:
Note: The security switch under the Base must be in the locked position to set Legal
for Trade to ON. The security switch must be in the unlocked position to set Legal for
Trade to OFF. See Section 6.
5.5.8 Graduations
Set the displayed readability of the balance.
For example, if the standard readability is 0.01g, selecting 10 Divisions will result in a
displayed reading of 0.1g.
5.5.9 Date & Time
Set the current Date and Time.
Change the format (if desired),
then enter the current value.
Select 9 to return to the sub-menu.
ON = enabled.
OFF = no symbol is displayed.
GROSS = the G symbol is displayed.
BRUTTO = the B symbol is displayed.
OFF = standard operation.
ON = operation complies with Weights and Measures regulations.
AutoCal internal Calibration is forced to ON and hidden. Automatic Calibration, and
Calibration Test functions are available. All other functions are hidden.
Stability Indicator Range is locked at 1 Division.
Auto Zero Tracking is limited to 0.5 Division and OFF.
Auto Tare and Gross Indicator are locked at their current setting.
Graduations is forced to 1 Division and the menu item is hidden.
Weighing Units menu: all units are locked at their current settings.
Stable Weight Only is locked ON.
Numeric Value Only is locked OFF.
Auto print mode selections are limited to OFF, On Stability, and Interval.
Continuous is not available.
1 Division = standard readability.
10 Divisions = readability is increased by a factor of 10.
EN-96 EXPLORER BALANCES
5.6 Applications
Enter this sub-menu to activate the desired Balance Applications. Only one application can be running at
a time.
(The use of each Application is described in detail in Section 4.)
5.6.1 Turning an Application ON/OFF
Touch line of the desired
application. In the Item
option screen, touch the
Enabled line to toggle it
on or off.
Once an Application is
enabled (turned on) it
may be chosen from the
Applications shortcut
(top-left of all home
screens).
The current menu item status is shown: OFF = disabled, ON = enabled
5.7 Weighing Units
Enter this sub-menu to activate the desired units of measure.
Note: Due to national laws, the indicator may not include some of the units of measure listed.
5.7.1 Units Sub-menu
milligram gram kilogram carat ounce ounce troy
pound pennyweight grain Newton momme mesgal
Tael (HK) Tael (SG) Tael (TW) tical tola baht
Custom Unit 1 Custom Unit 2 Custom Unit 3
Note: If LEGAL FOR TRADE is set to ON, the Unit menu is locked.
EXPLORER BALANCES EN-97
5.7.2 Turning a Unit ON/OFF
Select the desired unit, then touch the item to
toggle it either on or off.
The current menu item status is shown.
OFF = disabled
ON = enabled
5.7.3 Custom Units
Use each Custom Unit to display weight in an alternative unit of measure. The custom unit is defined using a
conversion factor, where the conversion factor is the number of custom units per kilogram expressed in scientific
notation (Factor x 10^Exponent).
For example: To display weight in troy ounces (32.15075 troy ounces per kilogram)
enter a Factor of 0.321508 and an Exponent of 2.
Set the status.
OFF = disabled
ON = enabled
When Custom Unit is set to ON, the Factor, Exponent and Least Significant Digit must be set.
Factor
Set the conversion factor using the numeric keypad.
Settings of 0.00001 to 1.9999999 are available. The default setting is 1.000000
Exponent
Set the factor multiplier.
0 = multiply the Factor by 1 (1x10
1 = multiply the Factor by 10 (1x10
2 = multiply the Factor by 100 (1x10
0
)
1
)
2
3 = multiply the Factor by 1000 (1x10
–3 = divide the Factor by 1000 (1x10
–2 = divide the Factor by 100 (1x10
–1 = divide the Factor by 10 (1x10
-3
-2
)
-1
)
Least Significant Digit
Set the graduation.
Settings of 0.00001, 0.00002, 0.00005, 0.0001, 0.0002, 0.0005, 0.001, 0.002,
0.005, 0.01, 0.02, 0.05, 0.1, 0.2, 0.5, 1, 2, 5, 10, 20, 50, 100, 200, 500 and 1000
are available.
Note: Least Significant Digit setting selections are dependent on the Factor and Exponent settings.
Selections are limited.
)
3
)
)
EN-98 EXPLORER BALANCES
5.8 GLP and GMP Data
Enter this menu to set the Good laboratory Practices (GLP) data.
5.8.1 GLP Data Sub-menu
5.8.2 Header
Enables the printing of GLP headings. There are up to 5 headings available.
Alphanumeric settings up to 25 characters are available for
5.8.3 Balance Name
Set the balance identification.
5.8.4 User Name
Set the user identification.
5.8.5 Project Name
Enter this menu to set the Project identification.
Alphanumeric settings up to 25 characters are available. The default setting is blank.
each Header setting. .
Alphanumeric settings up to 25 characters are available. The default setting is
blank.
Alphanumeric settings up to 25 characters are available. The default setting is
blank.
