RICCAR Moonlight Operating Instruction

Owner’s Manual

IMPORTANT SAFETY INSTRUCTIONS

When using an electrical appliance, basic precautions should always be followed, including the following:

READ ALL INSTRUCTIONS BEFORE

USING THIS APPLIANCE

The manufacturer cannot accept responsibility for damage WARNING:

To reduce the risk of fire, electric shock or injury:

caused when the appliance is not used according to the instructions, or for uses other than those for which it was intended.

• Do not leave appliance when plugged in.

Unplug from outlet when not in use and

before servicing.

• WARNING: ELECTRIC SHOCK COULD OCCUR IF USED OUTDOORS OR ON WET SURFACES.

• Do not allow to be used as a toy. Close

attention is necessary when used by or near children.

• Use only as described in this manual.

Use only manufacturer’s recommended attachments.

• Do not use with damaged cord or plug. If

appliance is not working as it should, has been dropped, damaged, left outdoors, or dropped into water, return it to your

Authorized Retailer for service.

• Do not pull or carry by cord, use cord as

a handle, close a door on the cord, or pull cord around sharp edges or corners. Do

not run appliance over cord. Keep cord

away from heated surfaces.

• Do not unplug by pulling on cord. To

unplug, grasp the plug, not the cord.

• Hold plug when rewinding the power cord to prevent the cord from whipping.

• Do not handle plug or appliance with

wet hands.

• Do not put any object into openings. Do

not use with any opening blocked; keep free of dust, lint, hair and anything that

may reduce air ow.

• Keep hair, loose clothing, ngers and all

parts of body away from openings and

moving parts.

• Do not pick up anything that is burning or

smoking, such as cigarettes, matches or hot ashes.

• Do not use without vacuum bag in place.

• Turn off all controls before unplugging.

• Use extra care when cleaning on stairs.

• Do not use to pick up ammable or

combustible liquids such as gasoline or use in areas where they may be present.

• Do not attempt to service the unit while

appliance is plugged in.

• Do not use vacuum to pick up water or

any wet materials.

Contents

Safety Precautions 4

Replacing Vacuum Bag and Filters 5

Description and Operation 6-7

Troubleshooting Guide 8

Owner’s Information 9

SAVE THESE INSTRUCTIONS.

Warranty 10

Safety Precautions Replacing Vacuum Bag and Filters

This vacuum cleaner should be used for normal, dry household dust and dirt. The manufacturer cannot be held responsible for any damage caused by use or operation of the vacuum contrary to these instructions. If the vacuum is wrongly operated for a purpose other than that for which

it is intended, no liability can be accepted for any possible damage.

• Do not vacuum areas which contain moisture or water, flammable matter, needles, pins,

razor blades, matches, cigarettes, etc., since they may damage the vacuum or vacuum bag.

Replacing the vacuum bag

Change the vacuum bag when the indicator is RED or suction power is weak. The dust cover will not close without

a bag in the unit or if the bag is not properly installed.

• When rewinding the power cord, hold the plug before pressing the cord rewind button to

prevent the cord from whipping.

• Make sure a vacuum bag and filters are always in place.

• This product is equipped with a polarized alternating current line plug (a plug having one

blade wider than the other). This plug fits into the power outlet only one way. This is a safety

feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the

plug should still fail to fit, contact an electrician to replace the obsolete outlet. Do not defeat

the safety purpose of the polarized plug.

1. Pull the bag holder straight out to access the bag.

2. Push the latch on the underside of the holder to release the bag collar.

3. Remove and discard the used bag. NOTE: The Performance HEPA™ bag cannot be reused.

4. Secure the new bag with the bag collar holder latch. Slide the tab on the bag holder into the slot on the front of the bag compartment.

Replacing the secondary filter

1. Open the bag compartment and locate the

filter behind the vacuum bag. For better access to the secondary filter, remove the

bag holder and bag.

2. Slide filter holder up and out.

3. Remove the used filter and replace it with

a new filter.

4. Slide the filter holder back in place and replace the bag holder and bag.

Replacing the HEPA filter

1. Locate the HEPA filter inside the bag

compartment near the door hinge.

2. Press the black tab to remove the used filter and snap in a new filter. NOTE: The HEPA filter cannot be washed and reused.
