RRNL-C
Parts List
08-February-2017
This parts list is current as of the above revision date.
See http://www.rheempartslists.net/92-42800-RRNL-C.pdf for the current revision.
Package Gas-Electric
Table of Contents
Model Explanation. ... .. ..... .. ... .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ..... ..... Page 3
Parts Numbers
Panels - Miscellaneous (1). ... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ... .. ..... .. ... .. ..... ..... .. ... .. ..... . Page 4
Panels - Miscellaneous (2). ... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ... .. ..... .. ... .. ..... ..... .. ... .. ..... . Page 5
Electrical Group . .. ... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... .. .. Page 6
Fan Group. .. ... .. ..... .. ... .. ..... ..... .. ... .. ..... .. ... .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... .. ..... ... Page 7
Blower Group. .. ... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... .. ..... Page 8
Coil Parts ... .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ... .. ..... .. ... .. ..... ..... .. ... .. ..... . Page 9
Compressor Group .. ... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ... .. ..... .. ... . Page 10
Heat Exchanger-Burner Group... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ..... .. Page 11
Gas Controls .. ... .. ..... .. ... .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... .. ..... Page 12
Accessories . .. ... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... .. ..... Page 12
Orifice Selection Chart... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... Page 13
Drawings/Photographs
Exploded View .. .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ... .. . Page 14
Control Access Panel Detail .... ... .. ..... .. ... .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ..... Page 15
Electrical Control Box... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... . Page 16
Blower Assembly . .. ... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ... .. ..... .. ... .. ..... ..... .. ... .. ..... ..... .. Page 17
EvaporatorCoil Assembly . .. ... .. ..... ..... .. ... .. ..... .. ... .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... .. .... Page 18
Condenser Coil. ... .. ..... .. ... .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... .. .... Page 19
Compressor Assembly... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ... .. ..... .. ... .. ..... ..... .. ... .. ..... ..... Page 20
Heat Exchanger Assembly... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ..... ..... . Page 21
Burner Assembly .. ... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... .. . Page 22
Notes/Disclaimer .. ... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ..... ..... .. ... .. ..... ..... .. ... .. ..... .. ... .. ..... ..... .. ... .. .... Page 23
Page 2 of 23
08-February-2017
92-42800-RRNL-C
R R N L - C 0 6 0 J K 10 E A J A
(1) (2) (3) (4) (5) (6) (7) (8) (9) (10) (11)
(1) TRADENAME IDENTIFICATION (8) DRIVE PACKAGE
K = DIRECT DRIVE
(2) PRODUCT CLASSIFICATION
R = ROOFTOP (9) HEATING CAPACITY - (MBH)
04 = 40,000
(3) EFFICIENCY DESIGNATION 06 = 60,000
N = 13 SEER P = 14 SEER 08 = 80,000
10 = 100,000
(4) DESIGN SERIES
(10) IGNITION SYSTEM
(5) TECHNICAL VARIATIONS E = ELECTRIC
X = ELECTRIC NOX
(6) COOLING CAPACITY (BTU/HR)
024 = 24,000 042 = 42,000 (11) OPTION CODES
030 = 30,000 048 = 48,000 AJA = STAINLESS STEEL HEATEXCHANGER
036 = 36,000 060 = 60,000 AKA = SIDEFLOW OPTION
BVA= SIDEFLOW w/SS HEAT EXCAHNGER
(7) ELECTRICAL DESIGNATION
J = 208/230V - 1 PH - 60 Hz
C = 208/230V - 3 PH - 60 Hz
D = 460V - 3 PH - 60 Hz
2 G A 1 2 3 4 A D A A F 2 6 0 9 0 0 0 1
(1) (2) (3) (4) (5) (6) (7) (8) (9) (10) (11)
(1) GAS CODE (7) TECHNOLOGYVARIATIONS
(2) BLOWER CONTROL BOARD (8) PLANT
(3) COMPRESSOR IDENTIFICATION NUMBER (9) WEEK
(4) IGNITION DEVICE (10) YEAR
(5) INDUCER BLOWER (11) PRODUCTION NUMBER
(6) HEAT EXCHANGER
F 0 8 1 3 9 9 9 9
(1) (2) (3) (4)
(1) PLANT CODE
(2) WEEK (DATE CODE)
(3) YEAR
(4) PRODUCTION NUMBER
Note: For Compressor Identification Number, see Compressor Code on Rating Plate
For Gas Code, see Control System Gas Code on Rating Plate
SERIAL NUMBER EXPLANATION (Units Produced before Nov. 2013)
SERIAL NUMBER EXPLANATION (Units Produced after Nov.2013)
MODEL NUMBER EXPLANATION
Page 3 of 23
08-February-2017
92-42800-RRNL-C
No. Notes
1 Front Base Pan AS-58628-07
2 Base Rail (2) AE-58562-03
3 Base Rail (2) AE-58562-04
4 Back Base Pan AS-58607-64
5 Blower Shelf AS-58630-01
6 Blower Shelf Transition AS-58607-19
7 Divider Panel AS-58607-03
8 Bulkhead Assembly AS-58607-57
9 Exhaust Hood AS-58629-01
10 Combustion Air Inlet Hood AE-58599-01
11 Corner Post AS-58607-46H
12 Blower Access Panel AS-58607-47H
13 End Panel AS-58607-48H
14 Supply Cover - Downflow AS-58607-06H
14 Supply Cover - Side Option "AKA" AS-58607-35H
15 Return Cover - Downflow AS-58607-05H
15 Return Civer - Side Option "AKA" AS-58607-34H
16 Top Panel AS-58607-54H
17 Grille 95-100906-08
18 Filter Access Panel AS-58607-49H
19 Condenser Louver Panel AS-58607-56H
20 Center Post AE-58569-07
21 Control Access Panel AS-58607-50H
22 Control Box - (w/o components) AE-58597-01
23 Control Box Cover AE-58598-01
24 Furnace Shelf AS-58607-11
25 Burner Floor AE-58594-01
26 Exhaust Transition AS-58607-36
27 Bulkhead Valve (2) 61-22369-04
28 Bulkhead Valve Locknut (2) 63-22368-01
Bulkhead ValveCap (2) 83-100635-01
Heat Exchanger Tube Support AE-58590-01
Grommet - Gas Supply Piping 56-22114-01
MODEL
TECHNICALVARIATION
COOLING CAPACITY
SHEET METAL PARTS, MISCELLANEOUS (Granite/Steel Gray, After Date Code 4411)
RRNL
C
060
Page 4 of 23
08-February-2017
92-42800-RRNL-C
No. Notes
1 Front Base Pan AS-58628-07
2 Base Rail (2) AE-58562-03
3 Base Rail (2) AE-58562-04
4 Back Base Pan AS-58607-64
5 Blower Shelf AS-58630-01
6 Blower Shelf Transition AS-58607-19
7 Divider Panel AS-58607-03
8 Bulkhead Assembly AS-58607-57
9 Exhaust Hood AS-58629-01
10 Combustion Air Inlet Hood AE-58599-01
11 Corner Post AS-58607-46A
12 Blower Access Panel AS-58607-47A
13 End Panel AS-58607-48A
14 Supply Cover - Downflow AS-58607-06A
14 Supply Cover - Side Option "AKA" AS-58607-35A
15 Return Cover - Downflow AS-58607-05A
15 Return Civer - Side Option "AKA" AS-58607-34A
16 Top Panel AS-58607-54A
17 Grille 95-100906-08
18 Filter Access Panel AS-58607-49A
19 Condenser Louver Panel AS-58607-56A
20 Center Post AE-58569-07
21 Control Access Panel AS-58607-50A
22 Control Box - (w/o components) AE-58597-01
23 Control Box Cover AE-58598-01
24 Furnace Shelf AS-58607-11
25 Burner Floor AE-58594-01
26 Exhaust Transition AS-58607-36
27 Bulkhead Valve (2) 61-22369-04
28 Bulkhead Valve Locknut (2) 63-22368-01
Bulkhead ValveCap (2) 83-100635-01
Heat Exchanger Tube Support AE-58590-01
Grommet - Gas Supply Piping 56-22114-01
MODEL
TECHNICALVARIATION
COOLING CAPACITY
SHEET METAL PARTS, MISCELLANEOUS (Neutra Green, Before Date Code 4411)
RRNL
C
060
Page 5 of 23
08-February-2017
92-42800-RRNL-C
MODEL
No. Notes
31 Stk Induced Draft Blower w/Gasket 70-23641-01
Gasket - Induced Draft Blower 68-23643-01
32 Stk Comfort Alert Module N/A
33 Stk Contactor 42-102851-02
34 Stk Pressure Switch 42-24335-20
35 Stk Transformer 46-18788-05
36 Ground Lug 45-19000-01
39 Integrated Furnace Control Board (IFC) See Gas Controls
57 Stk Blower Relay 42-101208-02
73 Capacitor - Compressor/Fan See Compressor Group
Capacitor - Blower Motor See Blower Group
84 Limit Control - Blower Shelf See Heat Exchanger-Burner Group
88 Limit - Manual Reset (Burner Compartment) See Heat Exchanger-Burner Group
Compressor Wiring Harness (Molded Plug) See Compressor Group
Wiring Harness - 9 pin to 9 insulated terminals AS-102393-02
Leadwire - from Flame Sensor to 9 pin Wiring Harness Plug 45-25323-02
Capacitor Adaptor Plate (2 in. round capacitor) AE-54609-01
Capacitor Adaptor Plate (2 in. X 1-1/4 in. oval capacitor) AE-54609-02
No. Notes
31 Stk Induced Draft Blower w/Gasket 70-23641-01 70-23641-02
Gasket - Induced Draft Blower 68-23643-01 68-23643-01
32 Stk Comfort Alert Module N/A N/A
33 Stk Contactor 42-22464-01 42-22464-01
34 Stk Pressure Switch 42-24335-20 42-24335-20
35 Stk Transformer 46-18788-05 46-102027-01
36 Ground Lug 45-19000-01 45-19000-01
39 Integrated Furnace Control Board (IFC) See Gas Controls
57 Stk Blower Relay 42-101208-02 42-21571-08
73 Capacitor - Fan Motor See Fan Group
Capacitor - Blower Motor See Blower Group
84 Limit Control - Blower Shelf See Heat Exchanger-Burner Group
88 Limit Control - Roll Out SeeHeat Exchanger-Burner Group
Compressor Wiring Harness (Molded Plug) See Compressor Group
Wiring Harness - 9 pin to 9 insulated terminals AS-102393-02 AS-102393-02
Leadwire - from Flame Sensor to 9 pin Wiring Harness Plug 45-25323-02 45-25323-02
Capacitor Adaptor Plate (2 in. round capacitor) AE-54609-01 AE-54609-01
Capacitor Adaptor Plate (2 in. X 1-1/4 in. oval capacitor) AE-54609-02 AE-54609-02
TECHNICALVARIATION
COOLING CAPACITY
ELECTRICAL DESIGNATION
ELECTRICAL GROUP
MODEL
TECHNICALVARIATION
COOLING CAPACITY
ELECTRICAL DESIGNATION
ELECTRICAL GROUP
RRNL
C
060
J
RRNL
C
060
C
RRNL
C
060
D
Page 6 of 23
08-February-2017
92-42800-RRNL-C
MODEL
No. Notes
37 Stk Fan Motor 51-100998-29
38 Stk Fan Blade 70-23594-03
73 Capacitor - Compressor/Fan
No. Notes
37 Stk Fan Motor 51-100998-29 51-100998-20
38 Stk Fan Blade 70-23594-03 70-23594-03
73 Stk Capacitor - Fan Motor 43-100496-12 43-100496-39
TECHNICALVARIATION
COOLING CAPACITY
ELECTRICAL DESIGNATION
FANGROUP
MODEL
TECHNICALVARIATION
COOLING CAPACITY
ELECTRICAL DESIGNATION
FANGROUP
RRNL
C
060
J
See Compressor
Group
RRNL
C
060
C
RRNL
C
060
D
Page 7 of 23
08-February-2017
92-42800-RRNL-C
MODEL
No. Notes
Stk Blower Assembly (Includes items 51-56) AS-58662-49
51 Housing N/A
51 Housing w/Wheel 70-100840-02
51a Transition AE-102207-05
51b Transition - Back AE-102207-06
52 Stk Blower Wheel 703016
53 Cut-Off N/A
54 Stk Motor 51-101984-12
55 Motor Band 70-19927-03
56 Motor Arm Assembly (3) 70-19929-09
57 Blower Relay See Electrical Group
79 Stk Capacitor - Blower Motor N/A
No. Notes
Stk Blower Assembly (Includes items 51-56) AS-58662-49 AS-58662-51
51 Housing N/A N/A
51 Housing w/Wheel 70-100840-02 70-100840-02
51a Transition AE-102207-05 AE-102207-05
51b Transition - Back AE-102207-06 AE-102207-06
52 Stk Blower Wheel 703016 703016
53 Cut-Off N/A N/A
54 Stk Motor 51-101984-12 51-103624-06
Motor Mounting Bracket Assembly (Includes items 55, 56) 70-19927-03 70-19927-03
55 Motor Band 70-19929-09 70-19929-09
56 Motor Arm Assembly (3) 70-19929-09 70-19929-09
57 Blower Relay See Electrical Group
79 Stk Capacitor - Blower Motor N/A N/A
TECHNICALVARIATION
COOLING CAPACITY
ELECTRICAL DESIGNATION
BLOWER GROUP
MODEL
TECHNICALVARIATION
COOLING CAPACITY
ELECTRICAL DESIGNATION
BLOWER GROUP
RRNL
C
060
J
RRNL
C
060
C
RRNL
C
060
D
Page 8 of 23
08-February-2017
92-42800-RRNL-C
MODEL
No. Notes
CONDENSER COIL:
61 Stk Condenser Coil AS-103011-01
Access ValveBody (2) 61-18542-01
Access ValveCore (2) 61-18551-01
78 Stk Filter Drier - Liquid Line 83-22755-05
EVAPORATOR COIL:
62 Stk Evaporator Coil w/Drain Pan AS-102660-10
62 Stk Evaporator Coil w/Drain Pan (Tin Plated) AS-104668-10
63 Drain Pan Grommet 56-23601-01
64 Stk Drain Pan 68-23602-02
64a Drain Trap (Attached to Drain Pan) 68-23603-01
65 Auxiliary Drain Pipe AE-58611-01
66 Stk Distributor Assembly 83-102202-03
67 Stk TXV 61-102211-28
68 Condensate Shield AE-101751-02
68a Condensate Barrier AE-100544-02
No. Notes
CONDENSER COIL:
61 Stk Condenser Coil AS-103011-01 AS-103011-01
Access ValveBody (2) 61-18542-01 61-18542-01
Access ValveCore (2) 61-18551-01 61-18551-01
78 Stk Filter Drier - Liquid Line 83-22755-05 83-22755-05
EVAPORATOR COIL:
62 Stk Evaporator Coil w/Drain Pan AS-102660-10 AS-102660-10
62 Stk Evaporator Coil w/Drain Pan (Tin Plated) AS-104668-10 AS-104668-10
63 Drain Pan Grommet 56-23601-01 56-23601-01
64 Stk Drain Pan 68-23602-02 68-23602-02
64a Drain Trap (Attached to Drain Pan) 68-23603-01 68-23603-01
65 Auxiliary Drain Pipe AE-58611-01 AE-58611-01
66 Stk Distributor Assembly 83-102202-03 83-102202-03
67 Stk TXV 61-102211-28 61-102211-28
68 Condensate Shield AE-101751-02 AE-101751-02
68a Condensate Barrier AE-100544-02 AE-100544-02
TECHNICALVARIATION
COOLING CAPACITY
ELECTRICAL DESIGNATION
COIL GROUP
MODEL
TECHNICALVARIATION
COOLING CAPACITY
ELECTRICAL DESIGNATION
COIL GROUP
RRNL
C
060
J
RRNL
C
060
C
RRNL
C
060
D
Page 9 of 23
08-February-2017
92-42800-RRNL-C
MODEL
No. Notes
Compressor ID: 7989
71 Stk Compressor 55-102045-26S
72 Grommet (4) 56-18518-06
Stk CompressorWiring Harness (Molded Plug) 45-100834-80
73 Stk Capacitor - Compressor/Fan 43-26271-47
74 Capacitor - Start N/A
75 Relay - Start N/A
76 High Pressure Control N/A
77 Low Pressure Control N/A
No. Notes
Compressor ID: 7990 8361
71 Stk Compressor 55-102045-27S 55-102045-28S
72 Grommet (4) 56-18518-06 56-18518-06
Stk Compressor Wiring Harness (Molded Plug) 45-100834-80 45-100834-80
76 High Pressure Control N/A N/A
77 Low Pressure Control N/A N/A
TECHNICALVARIATION
COOLING CAPACITY
ELECTRICAL DESIGNATION
COMPRESSOR GROUP
MODEL
TECHNICALVARIATION
COOLING CAPACITY
ELECTRICAL DESIGNATION
COMPRESSOR GROUP
RRNL
C
060
J
RRNL
C
060
C
RRNL
C
060
D
Page 10 of 23
08-February-2017
92-42800-RRNL-C
No. Notes
81 Stk Heat Exchanger (Includes Center Panel and Turbulators) AS-58632-04
82 Turbulators
Collector Box Gasket 68-23644-01
83 Collector Box AE-58588-01
84 Stk Limit Control - Blower Shelf 47-102436-01
85 NOX Insert Assembly (5) 75-23684-01
86 Lower Burner Shield (NOX) AE-59148-01
87 Radiation Shield AE-58595-01
88 Stk Limit - Manual Reset (Burner Compartment) 47-22861-02
89 Stk Burner Assembly AS-60993-05
90 Burner Support Bracket (2) AE-61588-02
91 Burner Support - (Holds Burners between Burner Support Brackets) AE-102438-01
92 Stk Manifold Assembly 81-101154-01
94 Square Head Plug (Used on Manifold to plug extra holes) N/A
93 Burner Orifice - Natural Gas
93 Burner Orifice - LP
93 Number of Orifices (5)
95 Stk Flame Sensor 62-23543-02
96 Stk Ignition Electrode/Cable Assembly 62-23556-01
97 3 Bushing 45-42519-01
MODEL
TECHNICALVARIATION
HEATING CAPACITY
HEAT EXCHANGER, BURNER / MANIFOLD
RRNL
C
10
AE-58591-02
(5)
See Orifice
Selection Chart
See Orifice
Selection Chart
Page 11 of 23
08-February-2017
92-42800-RRNL-C
No. Notes
39 Stk Integrated Furnace Control Board (IFC) 62-23599-04 62-23599-04 62-23599-04
Stk Gas Valve - Natural Gas 60-105055-01 60-105055-01 60-106207-01
Stk,1 Gas Valve- LP See Note 1 See Note 1 See Note 1
Stk LP Conversion Kit EP-85H EP-85H EP-84W
No. Notes
Economizer - Downflow, 3 Position RXRE-CAA30
Economizer - Downflow, Fully Modulating RXRD-CAM10
Economizer - Horizontal Application, 3 position RXRE-CCA30
Economizer - Horizontal Application, Fully Modulating RXRD-CCM10
FreshAir Damper - Fixed, 35% RXRF-FAA1
FreshAir Damper - Motorized, 35% RXRF-FAB1
Filter Kit RXRY-B01
Low Ambient Control RXRZ-B01
High Pressure Control RXAB-E01
Low Pressure Control RXAC-C01
MODEL
TECHNICALVARIATION
GAS CODE
GAS CONTROLS
MODEL
SIZE
OPTIONS AND ACCESSORIES
RRNL
C
2G
RRNL
C
2U
RRNL
C
2W
RRNL
ALL
Page 12 of 23
08-February-2017
92-42800-RRNL-C
CAUTION: Selection of the correct Natural Gas Orifice requires the following information for the specific installation:
1) Furnace Input Rating (BTU/HR)
2) Number of Burners
2) Altitude (ft.)
For detailed information and instructions for Orifice selection, see the Gas Furnace LP Conversion Kit Index 92-21519-47 and the latest edition of the
National Fuel Gas Code Handbook, or the National Standard of Canada, Natural Gas and Propane Installation Code, CAN B149.1.
CAUTION:This information is provided for replacement purposes only. Conversion for operation at High Altitude must be done using the kit specified
on the product specification sheet for the unit.
NOTE:This Orifice sizing chart is based on a Natural Gas heating value of 1075 BTU/cu. ft and a pressure setting of 3.5 in. water column.
NOTE: Factory installed orifices are calculated and sized based on a Natural Gas heating value of 1075 BTU/cu. ft. and an elevation of 0 - 2000 ft.
Furnace
Input
Rating (BTU/HR)
40,000 36,000 2 62-22175-45 62-22175-47 62-22175-48 62-22175-49 62-22175-45 62-22175-15
60,000 54,000 3 62-22175-45 62-22175-47 62-22175-48 62-22175-49 62-22175-45 62-22175-15
72,000 N/A 4 62-22175-15 62-22175-49 62-22175-50 62-22175-51 62-22175-15 N/A
80,000 72,000 4 62-22175-45 62-22175-47 62-22175-48 62-22175-49 62-22175-45 62-22175-15
90,000 N/A 5 62-22175-15 62-22175-49 62-22175-50 62-22175-51 62-22175-15 N/A
100,000 90,000 5 62-22175-45 62-22175-47 62-22175-48 62-22175-49 62-22175-45 62-22175-15
120,000 108,000 6 62-22175-45 62-22175-47 62-22175-48 62-22175-49 62-22175-45 62-22175-15
135,000 121,500 6 62-22175-44 62-22175-45 62-22175-47 62-22175-48 62-22175-44 62-22175-45
150,000 135,000 6 62-22175-42 62-22175-43 62-22175-44 62-22175-45 62-22175-42 62-22175-44
180,000 N/A 9 62-22175-45 62-22175-47 62-22175-48 62-22175-49 62-22175-45 N/A
210,000 N/A 9 62-22175-43 62-22175-44 62-22175-45 62-22175-47 62-22175-43 N/A
210,000 N/A 10 62-22175-45 62-22175-47 62-22175-48 62-22175-49 62-22175-45 N/A
225,000 202,500 9 62-22175-42 62-22175-43 62-22175-44 62-22175-45 62-22175-42 62-22175-44
250,000 225,000 10 62-22175-42 62-22175-43 62-22175-44 62-22175-45 62-22175-42 62-22175-44
252,000 225,000 9 62-22175-40 62-22175-42 62-22175-43 62-22175-44 62-22175-40 62-22175-42
252,000 N/A 12 62-22175-45 62-22175-47 62-22175-48 62-22175-49 62-22175-45 N/A
290,000 N/A 14 62-22175-45 62-22175-47 62-22175-48 62-22175-49 62-22175-45 N/A
300,000 270,000 12 62-22175-42 62-22175-43 62-22175-44 62-22175-45 62-22175-42 62-22175-44
330,000 N/A 14 62-22175-43 62-22175-44 62-22175-45 62-22175-47 62-22175-43 N/A
350,000 315,000 14 62-22175-42 62-22175-43 62-22175-44 62-22175-45 62-22175-42 62-22175-44
400,000 360,000 14 62-22175-40 62-22175-42 62-22175-43 62-22175-44 62-22175-40 62-22175-42
CAUTION: Selection of the correct LP Orifice requires the following information for the specific installation:
1) Furnace Input Rating (BTU/HR)
2) Number of Burners
2) Altitude (ft.)
For detailed information and instructions for Orifice selection, see the Gas Furnace LP Conversion Kit Index 92-21519-47 and the latest edition of the
National Fuel Gas Code Handbook, or the National Standard of Canada, Natural Gas and Propane Installation Code, CAN B149.1.
CAUTION:This information is provided for replacement purposes only. Conversion to LP or for operation at High Altitude should be done using the
kit(s) specified on the product specification sheet for the unit.
NOTE:This Orifice sizing chart is developedusing the specified pressure setting of 10 in. water column instead of the 11.0 in water column used by the NFG and
CANB149.1.
NOTE: Orifices supplied in the LP Conversion Kit are calculated and sized based on a heating value of 2500 BTU/cu. ft. and an elevation of 0 - 2000 ft.
Furnace
Input
Rating (BTU/HR)
40,000 36,000 2 62-22175-55 62-22175-55 62-22175-56 62-22175-56 62-22175-55 62-22175-13
60,000 54,000 3 62-22175-55 62-22175-55 62-22175-56 62-22175-56 62-22175-55 62-22175-13
72,000 N/A 4 62-22175-13 62-22175-57 62-22175-57 62-22175-59 62-22175-13 N/A
80,000 72,000 4 62-22175-55 62-22175-55 62-22175-56 62-22175-56 62-22175-55 62-22175-13
90,000 N/A 5 62-22175-13 62-22175-57 62-22175-57 62-22175-59 62-22175-13 N/A
100,000 90,000 5 62-22175-55 62-22175-55 62-22175-56 62-22175-56 62-22175-55 62-22175-13
120,000 108,000 6 62-22175-55 62-22175-55 62-22175-56 62-22175-56 62-22175-55 62-22175-13
135,000 121,500 6 62-22175-54 62-22175-55 62-22175-55 62-22175-56 62-22175-54 62-22175-55
150,000 135,000 6 62-22175-54 62-22175-55 62-22175-55 62-22175-56 62-22175-54 62-22175-54
180,000 N/A 9 62-22175-55 62-22175-55 62-22175-56 62-22175-56 62-22175-55 N/A
210,000 N/A 9 62-22175-54 62-22175-55 62-22175-55 62-22175-56 62-22175-54 N/A
210,000 N/A 10 62-22175-55 62-22175-55 62-22175-56 62-22175-56 62-22175-55 N/A
225,000 202,500 9 62-22175-54 62-22175-55 62-22175-55 62-22175-56 62-22175-54 62-22175-54
250,000 225,000 10 62-22175-54 62-22175-55 62-22175-55 62-22175-56 62-22175-54 62-22175-54
252,000 225,000 9 62-22175-53 62-22175-54 62-22175-54 62-22175-55 62-22175-53 62-22175-54
252,000 N/A 12 62-22175-55 62-22175-55 62-22175-56 62-22175-56 62-22175-55 N/A
290,000 N/A 14 62-22175-55 62-22175-55 62-22175-56 62-22175-56 62-22175-55 N/A
300,000 270,000 12 62-22175-54 62-22175-55 62-22175-55 62-22175-56 62-22175-54 62-22175-54
330,000 N/A 14 62-22175-54 62-22175-55 62-22175-55 62-22175-56 62-22175-54 N/A
350,000 315,000 14 62-22175-54 62-22175-55 62-22175-55 62-22175-56 62-22175-54 62-22175-54
400,000 360,000 14 62-22175-53 62-22175-54 62-22175-54 62-22175-55 62-22175-53 62-22175-54
Canadian High
Altitude Derated
Input
(BTU/HR)
Canadian High
Altitude Derated
Input
(BTU/HR)
PACKAGE EQUIPMENT - ORIFICE SELECTION CHART - NATURALGAS
Number
of
Burners
PACKAGE EQUIPMENT - ORIFICE SELECTION CHART - LP
Number
of
Burners
0 - 2000
U.S.
0 - 2000
U.S.
2001 - 4000
U.S.
2001 - 4000
U.S.
Elevation (ft.)
4001 - 6000
U.S.
Elevation (ft.)
4001 - 6000
U.S.
Country
8000+
U.S.
Country
8000+
U.S.
0 - 2000
Canada
0 - 2000
Canada
2001 - 4500
Canada
2001 - 4500
Canada
08-February-2017
92-42800-RRNL-C
Page 13 of 23
Exploded View
Page 14 of 23
08-February-2017
92-42800-RRNL-C
Control Access Panel Detail
Page 15 of 23
08-February-2017
92-42800-RRNL-C
Electrical Control Box
Page 16 of 23
08-February-2017
92-42800-RRNL-C
Blower Assembly
Page 17 of 23
08-February-2017
92-42800-RRNL-C
EvaporatorCoil Assembly
Page 18 of 23
08-February-2017
92-42800-RRNL-C
Condenser Coil
Page 19 of 23
08-February-2017
92-42800-RRNL-C
Compressor Assembly
Page 20 of 23
08-February-2017
92-42800-RRNL-C
Heat Exchanger Assembly
Page 21 of 23
08-February-2017
92-42800-RRNL-C
Burner Assembly
Page 22 of 23
08-February-2017
92-42800-RRNL-C
NOTES
Stk It is recommended that stock be maintained for this part.
N/A Not Applicable
1 Order Gas Valve for Natural Gas along with LP Conversion Kit.
DISCLAIMER: This document is intended to provide general replacement parts information to aid qualified
service personnel in the repair of these models. The complete Model and Serial Number of the unit under repair
should be specified when selecting and ordering replacement parts. Specifications and illustrations are subject
to change without notice. Document 92-42800-RRNL-C supersedes all previous parts lists for these models. See
http://www.rheempartslists.net/92-42800-RRNL-C for the latest revision of this document. The manufacturer
assumes no obligation for errors or omissions. Service personnel must verify the proper and safe operation of
equipment after the replacement of any original components.
P.O. Box 17010
Fort Smith, AR 72917-7010
Loading...
