Rheem Prestige Series
™
Heat Pumps Equipped with The Comfort Control
2
System
™
FORM NO. P11-798
Efficiencies Ranging to 17 SEER/13 EER/9.5 HSPF Nominal Sizes 2 to 5 Ton [7.03 to 17.6 kW]
• Industry’s lowest profile design: 33" maximum height
• The Comfort Control
2
System™provides over 37+ on-board
diagnostics and fault history codes for condensing units with single-phase compressors by detecting system and electrical problems. The integrated diagnostics with Active Protection™ prevents compressor operation when potentially harmful con­ditions are detected. Sends “Call for Service” alert notification to the thermostat to alert the homeowner of required service.
• Serial Communication Enhanced – When installed with a Serial Communicating Air Handler (RHPL-HM****JC) or Communi cating Gas Furnace and user interface control (RHC-TST501CMMS or RHC-TST550CMMS) Series 500 thermostat this unit offers 4 or 2 wire installation, auto­configuration, and diagnostic messaging with full communi­cating capability.
• Legacy Enabled – Unit can be conventionally wired using 24VAC with non-communicating Rheem air-handlers or furnaces with non-communicating thermostat.
• Features a 10-year conditional unit replacement warranty and 10-year parts warranty when properly installed with a new Rheem air handler or Rheem indoor coil with a Rheem gas furnace. See product warranty card for additional information.
• Reliable Two-Stage operation for precise temperature control and On-Demand dehumidification. When matched with ECM gas furnace or air-handler, the system adjusts airflow to help control humidity for unsurpassed comfort in the cooling mode.
• All controls are accessible by removing one service panel. Removable top grille provides access to the condenser fan motor and condenser coil.
• Attractive, louvered wrap-around jacket protects the coil from yard hazards and weather extremes. Top grille is steel rein­forced for extra strength. Cabinet is powder painted for all­weather protection.
• For quiet operation and improved efficiency, models feature an ECM two-speed condenser fan motor with a 3-blade out­door fan.
• All models meet or exceed a 1000-hour salt spray test per ASTM B117 Standard Practice for Operating Salt Spray Testing Apparatus.
• Dual Fuel capable with select thermostats.
Air
Heat Pumps
RPRL Series
“Proper sizing and installation of equipment is critical to achieve
optimal performance. Ask your Contractor for details or visit www.energystar.gov.”
16.0
Air
Table of Contents
RPRL Series
2
TABLE OF CONTENTS
Model Features ..............................................................................................3
Model Number Identification ............................................................................4
Accessories....................................................................................................4
Scroll Compressor ..........................................................................................4
Performance Data ......................................................................................5-15
Electrical & Physical Data ..............................................................................16
Unit Dimensions............................................................................................17
Refrigerant Line Size Information ....................................................................18
Limited Warranty ..........................................................................................19
Air
Model Features
RPRL Series
3
The
Comfort Control2System
™
Features:
Two-Stage Scroll
®
Compressor
The scroll compressor is the key to efficiency for this Rheem model. It’s the latest in high-efficiency compressor technology. The advanced scroll compressor offers low noise and vibration characteristics and features tolerance to liquid refrigerant and system contamination. The scroll also has low start torque, eliminating start problems in the field. And its unique design enables the RPRL- JEC Heat Pump to perform efficiently, quietly and reliably. All models have a 10-year compressor warranty as standard.
Standard Features:
RPRL- JEC Heat Pumps
1. 2-stage operation in both cooling and heating mode.
2. Scroll compressor is hermetically sealed and incorporates
internal high temperature motor overload protection, and durable insulation on the motor windings. It is externally mounted on rubber grommets to reduce vibration and noise.
3. Compressors have an internal pressure relief assembly to protect against excessive pressure differential.
4. All refrigerant connections are on the exterior of the unit, located close to the ground for neat appearing installations.
5. Cabinet is constructed of powder painted galvanized steel. The full wraparound louvered grille protects the coil from damage.
6. Copper Tube—Aluminum Fin coils are used on all models.
7. The control box is located in the top corner of the cabinet
providing for easy access through a service panel.
8. Service valves are standard on all models.
9. Field connections for power and control wiring are kept
separate.
10. Every unit is factory charged and run-tested.
11. Separate compressor compartment for easy service access.
12. Drawn, painted base pan for extra corrosion resistance and
sound reduction.
13. The RPRL- JEC has a 10 year limited parts warranty, plus a 10 year conditional unit replacement warranty. See the General Terms of Limited Warranty for more details.
14. Hard Start Kits—Standard on all JEC models.
15. Enhanced compressor sound wrap is standard.
16. Control Box Cover.
17. The RPRL- JEC is shipped with a liquid line filter drier,
(not-installed).
18. The RPRL- JEC features factory-installed auto-reset low and high pressure controls.
■
The Rheem Exclusive Dual 7 Segment LED Display easily shows system status codes and conditions.
■
A Sealed Switch replaces the standard contactor and features optical control
and latching mechanism. The
sealed switch prevents infiltra­tion of insects and dust. A mini­mal switching arc, by the optical control, offers greater reliability. The latching mechanism consumes less power while reducing chatter.
■
The Status Indication and System Diagnostics feature ther­mostat communication capability, built-in diagnostics, cur­rent sensing and high & low switch monitoring. The thermo-
stat communication capability alerts the homeowner of any necessary service requirements. Faster, more accurate service is pro­vided with the built-in diagnostics, by providing the HVAC professional with dependable information. In addition, high and low pressure-switch moni­toring prevents the system from operating when damage could occur.
■
The Fault Recall feature will allow for the last six fault-codes to be displayed, and will retain these codes even if power failure occurs.
■
Built-in short-cycle protection allows the compressor to restart easily without removing the oil from the compressor.
■
A 30-second minimum run-time for every compressor call allows the oil to return to the compressor.
■
Active Protection prevents the compressor from operating if damage could occur.
■
The compressor and fan are controlled independently, which reduces the starting load and light dimming.
■
A manual push-button is offered to operate the com­pressor and fan for 5 seconds to allow for an operation check.
■
In order to save time and money, replacement automotive fuses can be utilized instead of replacing the entire control board.
All controls and compressor
are accessible for servicing by
removal of the service panel.
Air
Model I.D./Accessories/Compressor
RPRL Series
4
Model Number Identification
Accessories
• Outdoor Thermostats— RXPT-A01—One outdoor thermostat in box.
RXPT-A02—One outdoor thermostat for mounting in box for
use with RXPT-A01 or A03.
RXPT-A03—One outdoor thermostat with emergency Heat
Relay wired and mounted in box.
RXPT-A04—Two outdoor thermostats with emergency Heat
Relay wired and mounted in box.
• Blower Time Delay Control—RXMD-C06.
• Fossil Fuel Kits—Not required. See Rheem Thermostats Specification Sheet (T11-001).
• Low Ambient Control—Cycles outdoor fan to maintain ade- quate condensing pressures assuring liquid refrigerant flow to the coil. Allows low temperature operation in the cooling cycle down to 0°F [-17.8°C] outdoor temperature. It is recom ­mended that this control be installed in units to be operated at outdoor ambient temperatures under 70°F [21°C] (Model No. RXAD-A08)
[ ] Designates Metric Conversions
• Dual Fuel High Pressure Control—RXME-A01. This kit is required if this heat pump is installed in a dual fuel application.
• Communicating 2 Wire Kit —RXME-A02. This kit will allow the outdoor unit to communicate to the system with only 2 wires.
* Photos are representative. Actual models may vary.
For detailed thermostat match-up information, see specification sheet form number T11-001.
300-Series *
Deluxe Programmable
400-Series *
Special Applications/ Programmable
500-Series *
Communicating/ Programmable
200-Series *
Programmable
Thermostats
R P R L 024 J EC
RHEEM REMOTE
HEAT PUMP
EFFICIENCY
16 SEER
DESIGN SERIES R-410A
ELECTRICAL
DESIGNATION
J = 208/230V-1-6
Ø
VARIATIONS
EC = EQUIPPED WITH THE
COMFORT
CONTROL
2
SYSTEM
™
COOLING
CAPACITY
025 = 24,000 BTU/HR [7.03 kW] 037 = 36,000 BTU/HR [10.55 kW] 049 = 48,000 BTU/HR [14.07 kW] 061 = 60,000 BTU/HR [17.58 kW]
—
Air
Performance Data
RPRL Series
5
Performance Data AHRI Standard Conditions
Note: Only these combinations of indoor/outdoor units are approved and any other combinations should not be used.
Outdoor
Unit
RPRL-
Model Numbers
Stage
AHRI Cooling Performance
80°F [26.5°C] / 67°F [19.5°C] WB Indoor Air
95°F [35°C] DB Outdoor Air
AHRI Heating Performance (70°F [21°C] Indoor)
Outdoor Air
47°F [8.5°C] DB/
43°F [6°C] WB
Outdoor Air
17°F [-8.5°C] DB/
15°F [-9.5°C] WB
AHRI Rating
DOE
Region IV
HSPF
Net Sensible
BTU/H [kW]
Net Latent
BTU/H [kW]
AHRI Ratings
Indoor Airflow
CFM [L/s]
Sound
Rating
dB
47°F [8.5°C] DB/
43°F [6°C] WB
17°F [-8.5°C] DB/
15°F [-9.5°C] WB
ID Coil ID Air Mover
Tot al
Capacity
SEER EER BTU/H [kW] COP BTU/H [kW] COP BTU/H [kW] BTU/H [kW]
025JEC
RCSL-H*2621 ➀
RHPL-HM2421
1 14700 [4.3] 6300 [1.8]
25400 [7.4] 17 13
600 [283] 67 0 [0.0]
3.94
0 [0.0]
2.6 22600 [6.6] 14000 [4.1] 9
2 18500 [5.4] 6900 [2.0] 775 [366] 70 22600 [6.6] 14000 [4.1]
1 - dehumid 12500 [3.7] 5100 [1.5] 525 [248]
2 - dehumid 16800 [4.9] 7400 [2.2] 650 [307]
RCFL-H*2617
RGFE-07?MCK?
1 14600 [4.3] 6300 [1.8]
25400 [7.4] 17 13
600 [283] 67 16600 [4.9]
3.86
9300 [2.7]
2.16 22800 [6.7] 14100 [4.1] 8.5
2 18800 [5.5] 6700 [2.0] 825 [389] 70 22800 [6.7] 14100 [4.1]
RGFG-06?MCK?
1 14600 [4.3] 6300 [1.8]
25200 [7.4] 17 13
575 [271] 67 16600 [4.9]
3.86
9300 [2.7]
2.16 22800 [6.7] 14100 [4.1] 8.5
2 18300 [5.4] 6900 [2.0] 800 [378] 70 22800 [6.7] 14100 [4.1]
RGFG-07?MCK?
1 14500 [4.2] 6300 [1.8]
25600 [7.5] 17 13
600 [283] 67 16600 [4.9]
3.84
9300 [2.7]
2.16 22800 [6.7] 14200 [4.2] 8.5
2 18900 [5.5] 6600 [1.9] 850 [401] 70 22800 [6.7] 14200 [4.2]
RGGE-06?MCK?
1 14600 [4.3] 6300 [1.8]
25600 [7.5] 17 13
625 [295] 67 16600 [4.9]
3.88
9200 [2.7]
2.16 22800 [6.7] 14100 [4.1] 8.5
2 18800 [5.5] 6700 [2.0] 825 [389] 70 22800 [6.7] 14100 [4.1]
RGGE-07?MCK?
1 14600 [4.3] 6300 [1.8]
25200 [7.4] 17 13
575 [271] 67 16600 [4.9]
3.88
9200 [2.7]
2.16 22800 [6.7] 14100 [4.1] 8.5
2 18400 [5.4] 6900 [2.0] 800 [378] 70 22800 [6.7] 14100 [4.1]
RGJF-06?MCK?
1 14600 [4.3] 6300 [1.8]
25600 [7.5] 17 13
625 [295] 67 16600 [4.9]
3.88
9200 [2.7]
2.16 22800 [6.7] 14100 [4.1] 8.5
2 18800 [5.5] 6700 [2.0] 825 [389] 70 22800 [6.7] 14100 [4.1]
RGJF-07?MCK?
1 14600 [4.3] 6300 [1.8]
25200 [7.4] 17 13
575 [271] 67 16600 [4.9]
3.88
9200 [2.7]
2.16 22800 [6.7] 14100 [4.1] 8.5
2 18400 [5.4] 6900 [2.0] 800 [378] 70 22800 [6.7] 14100 [4.1]
RGLE-07?AMK?
1 14600 [4.3] 6300 [1.8]
25200 [7.4] 17 13
600 [283] 67 16600 [4.9]
3.9
9200 [2.7]
2.16 22600 [6.6] 14000 [4.1] 8.5
2 18400 [5.4] 6900 [2.0] 800 [378] 70 22600 [6.6] 14000 [4.1]
RGPE-05?BMK?
1 14600 [4.3] 6300 [1.8]
25200 [7.4] 17 13
575 [271] 67 16600 [4.9]
3.88
9300 [2.7]
2.16 22600 [6.6] 14100 [4.1] 8.5
2 18400 [5.4] 6900 [2.0] 800 [378] 70 22600 [6.6] 14100 [4.1]
RGPE-07?AMK?
1 14600 [4.3] 6300 [1.8]
25600 [7.5] 17 13
625 [295] 67 16600 [4.9]
3.9
9200 [2.7]
2.16 22600 [6.6] 14000 [4.1] 8.5
2 18800 [5.5] 6700 [2.0] 825 [389] 70 22600 [6.6] 14000 [4.1]
RGRM-04?MAE?
1 14600 [4.3] 6300 [1.8]
25200 [7.4] 17 13
575 [271] 67 16600 [4.9]
3.82
9300 [2.7]
2.14 22800 [6.7] 14200 [4.2] 8.5
2 18300 [5.4] 6900 [2.0] 800 [378] 70 22800 [6.7] 14200 [4.2]
RGRM-06?MAE?
1 14600 [4.3] 6300 [1.8]
25400 [7.4] 17 13
600 [283] 67 16600 [4.9]
3.84
9300 [2.7]
2.16 22800 [6.7] 14200 [4.2] 8.5
2 18700 [5.5] 6700 [2.0] 825 [389] 70 22800 [6.7] 14200 [4.2]
RGRM-07?MAE?
1 14500 [4.2] 6300 [1.8]
25400 [7.4] 17 13
625 [295] 67 16700 [4.9]
3.78
9300 [2.7]
2.14 23000 [6.7] 14300 [4.2] 8.5
2 18800 [5.5] 6600 [1.9] 850 [401] 70 23000 [6.7] 14300 [4.2]
RGTM-06?MAE?
1 15600 [4.6] 6100 [1.8]
25400 [7.4] 17 13
750 [354] 67 16700 [4.9]
3.86
9400 [2.8]
2.12 22800 [6.7] 14100 [4.1] 8.5
2 18800 [5.5] 6700 [2.0] 825 [389] 70 22800 [6.7] 14100 [4.1]
ROCA-070E03
1 14600 [4.3] 6300 [1.8]
25200 [7.4] 17 13
600 [283] 67 16600 [4.9]
3.9
9200 [2.7]
2.16 22600 [6.6] 14000 [4.1] 8.5
2 18400 [5.4] 6900 [2.0] 800 [378] 70 22600 [6.6] 14000 [4.1]
Rev.
4/25/2012
➀ Highest sales volume tested combination required by DOE test procedures.
[ ] Designates Metric Conversions
Air
Performance Data
RPRL Series
6
Performance Data AHRI Standard Conditions
Note: Only these combinations of indoor/outdoor units are approved and any other combinations should not be used.
Outdoor
Unit
RPRL-
Model Numbers
Stage
AHRI Cooling Performance
80°F [26.5°C] / 67°F [19.5°C] WB Indoor Air
95°F [35°C] DB Outdoor Air
AHRI Heating Performance (70°F [21°C] Indoor)
Outdoor Air
47°F [8.5°C] DB/
43°F [6°C] WB
Outdoor Air
17°F [-8.5°C] DB/
15°F [-9.5°C] WB
AHRI Rating
DOE
Region IV
HSPF
Net Sensible
BTU/H [kW]
Net Latent
BTU/H [kW]
AHRI Ratings
Indoor Airflow
CFM [L/s]
Sound
Rating
dB
47°F [8.5°C] DB/
43°F [6°C] WB
17°F [-8.5°C] DB/
15°F [-9.5°C] WB
ID Coil ID Air Mover
Tot al
Capacity
SEER EER BTU/H [kW] COP BTU/H [kW] COP BTU/H [kW] BTU/H [kW]
025JEC
RCFL-H*2617 ROLA-070E03
1 14500 [4.2] 6300 [1.8]
25200 [7.4] 17 13
600 [283] 67 16600 [4.9]
3.9
9300 [2.7]
2.14 22600 [6.6] 14000 [4.1] 8.5
2 18400 [5.4] 6900 [2.0] 800 [378] 70 22600 [6.6] 14000 [4.1]
RCFL-H*2617+RXMD-C06 Coil Only
1 14000 [4.1] 6300 [1.8]
24800 [7.3] 15 12
600 [283] 67 16400 [4.8]
3.9
9000 [2.6]
2.14 22200 [6.5] 13600 [4.0] 8.2
2 17900 [5.2] 6900 [2.0] 775 [366] 70 22200 [6.5] 13600 [4.0]
RCFL-H*2621
RGFE-07?MCK?
1 14600 [4.3] 6300 [1.8]
25600 [7.5] 17 13
600 [283] 67 16600 [4.9]
3.88
9200 [2.7]
2.16 22800 [6.7] 14100 [4.1] 8.5
2 18800 [5.5] 6700 [2.0] 825 [389] 70 22800 [6.7] 14100 [4.1]
RGFG-06?MCK?
1 14600 [4.3] 6300 [1.8]
25200 [7.4] 17 13
575 [271] 67 16600 [4.9]
3.88
9200 [2.7]
2.16 22800 [6.7] 14100 [4.1] 8.5
2 18400 [5.4] 6900 [2.0] 800 [378] 70 22800 [6.7] 14100 [4.1]
RGFG-07?MCK?
1 14500 [4.2] 6300 [1.8]
25600 [7.5] 17 13
600 [283] 67 16600 [4.9]
3.86
9200 [2.7]
2.16 22800 [6.7] 14100 [4.1] 8.5
2 19000 [5.6] 6600 [1.9] 850 [401] 70 22800 [6.7] 14100 [4.1]
RGGE-06?MCK?
1 14600 [4.3] 6300 [1.8]
25600 [7.5] 17 13
625 [295] 67 16600 [4.9]
3.9
9200 [2.7]
2.16 22600 [6.6] 14000 [4.1] 8.5
2 18800 [5.5] 6700 [2.0] 825 [389] 70 22600 [6.6] 14000 [4.1]
RGGE-07?MCK?
1 14600 [4.3] 6300 [1.8]
25200 [7.4] 17 13
575 [271] 67 16600 [4.9]
3.88
9200 [2.7]
2.16 22600 [6.6] 14100 [4.1] 8.5
2 18400 [5.4] 6900 [2.0] 800 [378] 70 22600 [6.6] 14100 [4.1]
RGJF-06?MCK?
1 14600 [4.3] 6300 [1.8]
25600 [7.5] 17 13
625 [295] 67 16600 [4.9]
3.9
9200 [2.7]
2.16 22600 [6.6] 14000 [4.1] 8.5
2 18800 [5.5] 6700 [2.0] 825 [389] 70 22600 [6.6] 14000 [4.1]
RGJF-07?MCK?
1 14600 [4.3] 6300 [1.8]
25200 [7.4] 17 13
575 [271] 67 16600 [4.9]
3.88
9200 [2.7]
2.16 22600 [6.6] 14100 [4.1] 8.5
2 18400 [5.4] 6900 [2.0] 800 [378] 70 22600 [6.6] 14100 [4.1]
RGLE-07?AMK?
1 14600 [4.3] 6300 [1.8]
25400 [7.4] 17 13
600 [283] 67 16500 [4.8]
3.92
9200 [2.7]
2.16 22600 [6.6] 14000 [4.1] 8.5
2 18400 [5.4] 6900 [2.0] 800 [378] 70 22600 [6.6] 14000 [4.1]
RGPE-05?BMK?
1 14600 [4.3] 6300 [1.8]
25200 [7.4] 17 13
575 [271] 67 16600 [4.9]
3.9
9200 [2.7]
2.16 22600 [6.6] 14000 [4.1] 8.5
2 18400 [5.4] 6900 [2.0] 800 [378] 70 22600 [6.6] 14000 [4.1]
RGPE-07?AMK?
1 14600 [4.3] 6300 [1.8]
25600 [7.5] 17 13
625 [295] 67 16500 [4.8]
3.92
9200 [2.7]
2.16 22600 [6.6] 14000 [4.1] 8.5
2 18900 [5.5] 6700 [2.0] 825 [389] 70 22600 [6.6] 14000 [4.1]
RGRM-04?MAE?
1 14500 [4.2] 6300 [1.8]
25200 [7.4] 17 13
575 [271] 67 16600 [4.9]
3.86
9200 [2.7]
2.16 22800 [6.7] 14100 [4.1] 8.5
2 18300 [5.4] 6900 [2.0] 800 [378] 70 22800 [6.7] 14100 [4.1]
RGRM-06?MAE?
1 14600 [4.3] 6300 [1.8]
25400 [7.4] 17 13
600 [283] 67 16600 [4.9]
3.86
9200 [2.7]
2.16 22800 [6.7] 14100 [4.1] 8.5
2 18700 [5.5] 6700 [2.0] 825 [389] 70 22800 [6.7] 14100 [4.1]
RGRM-07?MAE?
1 14500 [4.2] 6300 [1.8]
25400 [7.4] 17 13
625 [295] 67 16600 [4.9]
3.8
9300 [2.7]
2.14 22800 [6.7] 14200 [4.2] 8.5
2 18800 [5.5] 6600 [1.9] 850 [401] 70 22800 [6.7] 14200 [4.2]
RGTM-06?MAE?
1 15600 [4.6] 6100 [1.8]
25400 [7.4] 17 13
750 [354] 67 16700 [4.9]
3.86
9300 [2.7]
2.14 22800 [6.7] 14100 [4.1] 8.5
2 18800 [5.5] 6700 [2.0] 825 [389] 70 22800 [6.7] 14100 [4.1]
ROCA-070E03
1 14600 [4.3] 6300 [1.8]
25400 [7.4] 17 13
600 [283] 67 16400 [4.8]
3.92
9200 [2.7]
2.16 22600 [6.6] 14000 [4.1] 8.5
2 18400 [5.4] 6900 [2.0] 800 [378] 70 22600 [6.6] 14000 [4.1]
Rev.
4/25/2012
➀ Highest sales volume tested combination required by DOE test procedures.
[ ] Designates Metric Conversions
7
Air
Performance Data
RPRL Series
Performance Data AHRI Standard Conditions
Note: Only these combinations of indoor/outdoor units are approved and any other combinations should not be used.
Outdoor
Unit
RPRL-
Model Numbers
Stage
AHRI Cooling Performance
80°F [26.5°C] / 67°F [19.5°C] WB Indoor Air
95°F [35°C] DB Outdoor Air
AHRI Heating Performance (70°F [21°C] Indoor)
Outdoor Air
47°F [8.5°C] DB/
43°F [6°C] WB
Outdoor Air
17°F [-8.5°C] DB/
15°F [-9.5°C] WB
AHRI Rating
DOE
Region IV
HSPF
Net Sensible
BTU/H [kW]
Net Latent
BTU/H [kW]
AHRI Ratings
Indoor Airflow
CFM [L/s]
Sound
Rating
dB
47°F [8.5°C] DB/
43°F [6°C] WB
17°F [-8.5°C] DB/
15°F [-9.5°C] WB
ID Coil ID Air Mover
Tot al
Capacity
SEER EER BTU/H [kW] COP BTU/H [kW] COP BTU/H [kW] BTU/H [kW]
025JEC
RCFL-H*2621 ROLA-070E03
1 14500 [4.2] 6300 [1.8]
25200 [7.4] 17 13
600 [283] 67 16600 [4.9]
3.92
9200 [2.7]
2.16 22600 [6.6] 14000 [4.1] 8.5
2 18400 [5.4] 6900 [2.0] 800 [378] 70 22600 [6.6] 14000 [4.1]
RCFL-H*2621+RXMD-C06 Coil Only
1 14000 [4.1] 6300 [1.8]
24800 [7.3] 15 12
600 [283] 67 16400 [4.8]
3.9
9000 [2.6]
2.14 22200 [6.5] 13600 [4.0] 8.2
2 17900 [5.2] 6900 [2.0] 775 [366] 70 22200 [6.5] 13600 [4.0]
037JEC
RCSL-H*3821
➀
RHPL-HM3821
1 20800 [6.1] 8600 [2.5]
36600 [10.7] 16.5 13
900 [425] 69 23800 [7.0]
3.8
12600 [3.7]
2.58 34400 [10.1] 21400 [6.3] 9
2 27300 [8.0] 9300 [2.7] 1200 [566] 73 34400 [10.1] 21400 [6.3]
1 - dehumid 18000 [5.3] 7200 [2.1] 750 [354]
2 - dehumid 18600 [5.4] 6600 [1.9] 900 [425]
RCFL-H*3821
RGFE-06?MCK?
1 20400 [6.0] 8600 [2.5]
35800 [10.5] 15.5 11.5
875 [413] 69 24200 [7.1]
3.6
12900 [3.8]
2.45 35000 [10.3] 22200 [6.5] 8.5
2 26500 [7.8] 9300 [2.7] 1200 [566] 73 35000 [10.3] 22200 [6.5]
RGFE-07?MCK?
1 20400 [6.0] 8600 [2.5]
35600 [10.4] 15.5 11.5
875 [413] 69 24200 [7.1]
3.6
12900 [3.8]
2.45 35000 [10.3] 22200 [6.5] 8.5
2 26300 [7.7] 9300 [2.7] 1225 [578] 73 35000 [10.3] 22200 [6.5]
RGFE-09?ZCM?
1 20600 [6.0] 8600 [2.5]
36200 [10.6] 16 12
875 [413] 69 24000 [7.0]
3.7
12700 [3.7]
2.5 34600 [10.1] 21800 [6.4] 9
2 26900 [7.9] 9300 [2.7] 1200 [566] 73 34600 [10.1] 21800 [6.4]
RGFE-10?ZCM?
1 20600 [6.0] 8600 [2.5]
36000 [10.5] 16 12
900 [425] 69 24000 [7.0]
3.7
12700 [3.7]
2.5 34600 [10.1] 21800 [6.4] 9
2 26700 [7.8] 9300 [2.7] 1225 [578] 73 34600 [10.1] 21800 [6.4]
RGFG-06?MCK?
1 20400 [6.0] 8600 [2.5]
35800 [10.5] 15.5 11.5
875 [413] 69 24200 [7.1]
3.6
12900 [3.8]
2.45 35000 [10.3] 22200 [6.5] 8.5
2 26500 [7.8] 9300 [2.7] 1200 [566] 73 35000 [10.3] 22200 [6.5]
RGFG-07?MCK?
1 19700 [5.8] 8900 [2.6]
35200 [10.3] 16 12
800 [378] 69 24000 [7.0]
3.75
12700 [3.7]
2.55 34600 [10.1] 21600 [6.3] 9
2 24900 [7.3] 10300 [3.0] 1000 [472] 73 34600 [10.1] 21600 [6.3]
RGFG-09?ZCM?
1 20600 [6.0] 8600 [2.5]
36200 [10.6] 16 12
875 [413] 69 24000 [7.0]
3.7
12700 [3.7]
2.5 34600 [10.1] 21800 [6.4] 9
2 26900 [7.9] 9300 [2.7] 1200 [566] 73 34600 [10.1] 21800 [6.4]
RGFG-10?ZCM?
1 20600 [6.0] 8600 [2.5]
36200 [10.6] 16 12
900 [425] 69 24000 [7.0]
3.7
12800 [3.8]
2.5 34600 [10.1] 21800 [6.4] 9
2 26900 [7.9] 9300 [2.7] 1200 [566] 73 34600 [10.1] 21800 [6.4]
RGGE-06?MCK?
1 20400 [6.0] 8600 [2.5]
36000 [10.5] 15.5 12
925 [437] 69 24200 [7.1]
3.65
12900 [3.8]
2.5 34800 [10.2] 22000 [6.4] 8.5
2 26700 [7.8] 9300 [2.7] 1200 [566] 73 34800 [10.2] 22000 [6.4]
RGGE-07?MCK?
1 20400 [6.0] 8600 [2.5]
35800 [10.5] 15.5 12
875 [413] 69 24200 [7.1]
3.65
12900 [3.8]
2.5 34800 [10.2] 22000 [6.4] 8.5
2 26500 [7.8] 9300 [2.7] 1200 [566] 73 34800 [10.2] 22000 [6.4]
RGGE-09?ZCM?
1 21700 [6.4] 8100 [2.4]
36400 [10.7] 16 12
1025 [484] 69 24200 [7.1]
3.7
12900 [3.8]
2.5 34600 [10.1] 21800 [6.4] 9
2 27300 [8.0] 9100 [2.7] 1250 [590] 73 34600 [10.1] 21800 [6.4]
RGGE-10?ZCM?
1 20600 [6.0] 8600 [2.5]
36200 [10.6] 16 12
875 [413] 69 24000 [7.0]
3.7
12700 [3.7]
2.55 34600 [10.1] 21800 [6.4] 9
2 26900 [7.9] 9300 [2.7] 1200 [566] 73 34600 [10.1] 21800 [6.4]
RGJF-06?MCK?
1 20400 [6.0] 8600 [2.5]
36000 [10.5] 15.5 12
925 [437] 69 24200 [7.1]
3.65
12900 [3.8]
2.5 34800 [10.2] 22000 [6.4] 8.5
2 26700 [7.8] 9300 [2.7] 1200 [566] 73 34800 [10.2] 22000 [6.4]
Rev.
4/25/2012
➀ Highest sales volume tested combination required by DOE test procedures.
[ ] Designates Metric Conversions
8
Air
Performance Data
RPRL Series
Performance Data AHRI Standard Conditions
Note: Only these combinations of indoor/outdoor units are approved and any other combinations should not be used.
Outdoor
Unit
RPRL-
Model Numbers
Stage
AHRI Cooling Performance
80°F [26.5°C] / 67°F [19.5°C] WB Indoor Air
95°F [35°C] DB Outdoor Air
AHRI Heating Performance (70°F [21°C] Indoor)
Outdoor Air
47°F [8.5°C] DB/
43°F [6°C] WB
Outdoor Air
17°F [-8.5°C] DB/
15°F [-9.5°C] WB
AHRI Rating
DOE
Region IV
HSPF
Net Sensible
BTU/H [kW]
Net Latent
BTU/H [kW]
AHRI Ratings
Indoor Airflow
CFM [L/s]
Sound
Rating
dB
47°F [8.5°C] DB/
43°F [6°C] WB
17°F [-8.5°C] DB/
15°F [-9.5°C] WB
ID Coil ID Air Mover
Tot al
Capacity
SEER EER BTU/H [kW] COP BTU/H [kW] COP BTU/H [kW] BTU/H [kW]
037JEC
RCFL-H*3821
RGJF-07?MCK?
1 20400 [6.0] 8600 [2.5]
35800 [10.5] 15.5 12
875 [413] 69 24200 [7.1]
3.65
12900 [3.8]
2.5 34800 [10.2] 22000 [6.4] 8.5
2 26500 [7.8] 9300 [2.7] 1200 [566] 73 34800 [10.2] 22000 [6.4]
RGJF-09?ZCM?
1 21700 [6.4] 8100 [2.4]
36400 [10.7] 16 12
1025 [484] 69 24200 [7.1]
3.7
12900 [3.8]
2.5 34600 [10.1] 21800 [6.4] 9
2 27300 [8.0] 9100 [2.7] 1250 [590] 73 34600 [10.1] 21800 [6.4]
RGJF-10?ZCM?
1 20600 [6.0] 8600 [2.5]
36200 [10.6] 16 12
875 [413] 69 24000 [7.0]
3.75
12700 [3.7]
2.55 34600 [10.1] 21800 [6.4] 9
2 26900 [7.9] 9300 [2.7] 1200 [566] 73 34600 [10.1] 21800 [6.4]
RGLE-07?AMK?
1 20600 [6.0] 8600 [2.5]
36000 [10.5] 16 12
875 [413] 69 24000 [7.0]
3.7
12800 [3.8]
2.5 34600 [10.1] 21800 [6.4] 9
2 26700 [7.8] 9300 [2.7] 1200 [566] 73 34600 [10.1] 21800 [6.4]
RGLE-07?BRQ?
1 20600 [6.0] 8600 [2.5]
36400 [10.7] 16.5 12.5
925 [437] 69 24000 [7.0]
3.75
12700 [3.7]
2.55 34400 [10.1] 21600 [6.3] 9
2 27100 [7.9] 9300 [2.7] 1225 [578] 73 34400 [10.1] 21600 [6.3]
RGLE-10?BRM?
1 20800 [6.1] 8600 [2.5]
36400 [10.7] 16.5 12.5
875 [413] 69 23800 [7.0]
3.8
12600 [3.7]
2.55 34400 [10.1] 21400 [6.3] 9
2 27100 [7.9] 9300 [2.7] 1200 [566] 73 34400 [10.1] 21400 [6.3]
RGPE-05?BMK?
1 20400 [6.0] 8600 [2.5]
36000 [10.5] 16 12
900 [425] 69 24200 [7.1]
3.65
12800 [3.8]
2.5 34800 [10.2] 22000 [6.4] 9
2 26700 [7.8] 9300 [2.7] 1200 [566] 73 34800 [10.2] 22000 [6.4]
RGPE-07?AMK?
1 20600 [6.0] 8600 [2.5]
36000 [10.5] 16 12
900 [425] 69 24000 [7.0]
3.7
12800 [3.8]
2.5 34800 [10.2] 21800 [6.4] 9
2 26700 [7.8] 9300 [2.7] 1225 [578] 73 34800 [10.2] 21800 [6.4]
RGPE-07?BRQ?
1 20600 [6.0] 8600 [2.5]
36400 [10.7] 16.5 12.5
900 [425] 69 24000 [7.0]
3.8
12700 [3.7]
2.55 34400 [10.1] 21600 [6.3] 9
2 27100 [7.9] 9300 [2.7] 1225 [578] 73 34400 [10.1] 21600 [6.3]
RGPE-10?BRM?
1 20600 [6.0] 8600 [2.5]
36400 [10.7] 16.5 12.5
900 [425] 69 24000 [7.0]
3.8
12600 [3.7]
2.55 34400 [10.1] 21600 [6.3] 9
2 27100 [7.9] 9300 [2.7] 1225 [578] 73 34400 [10.1] 21600 [6.3]
RGPR-10?BRM?
1 20600 [6.0] 8600 [2.5]
36200 [10.6] 16 12.5
925 [437] 69 24000 [7.0]
3.75
12700 [3.7]
2.55 34400 [10.1] 21600 [6.3] 9
2 26900 [7.9] 9300 [2.7] 1225 [578] 73 34400 [10.1] 21600 [6.3]
RGRM-04?MAE?
1 20400 [6.0] 8600 [2.5]
35600 [10.4] 15 11.5
925 [437] 69 24200 [7.1]
3.55
13000 [3.8]
2.45 35200 [10.3] 22200 [6.5] 8.5
2 26300 [7.7] 9300 [2.7] 1200 [566] 73 35200 [10.3] 22200 [6.5]
RGRM-06?MAE?
1 20400 [6.0] 8600 [2.5]
35600 [10.4] 15.5 11.5
900 [425] 69 24200 [7.1]
3.6
12900 [3.8]
2.45 35000 [10.3] 22200 [6.5] 8.5
2 26300 [7.7] 9300 [2.7] 1175 [554] 73 35000 [10.3] 22200 [6.5]
RGRM-07?MAE?
1 19700 [5.8] 8900 [2.6]
35000 [10.3] 15.5 11.5
800 [378] 69 24000 [7.0]
3.7
12800 [3.8]
2.5 34800 [10.2] 21800 [6.4] 8.5
2 24900 [7.3] 10100 [3.0] 1025 [484] 73 34800 [10.2] 21800 [6.4]
RGRM-07?YBG?
1 20100 [5.9] 8700 [2.5]
35600 [10.4] 15.5 11.5
850 [401] 69 24200 [7.1]
3.55
12900 [3.8]
2.45 35200 [10.3] 22400 [6.6] 8.5
2 26300 [7.7] 9300 [2.7] 1200 [566] 73 35200 [10.3] 22400 [6.6]
RGRM-09?RAJ?
1 21700 [6.4] 8100 [2.4]
36800 [10.8] 16 12
1050 [495] 69 24200 [7.1]
3.7
12900 [3.8]
2.5 34800 [10.2] 21800 [6.4] 9
2 28100 [8.2] 8700 [2.5] 1325 [625] 73 34800 [10.2] 21800 [6.4]
RGRM-09?ZAJ?
1 21000 [6.2] 8400 [2.5]
36000 [10.5] 16 12
950 [448] 69 24200 [7.1]
3.7
12900 [3.8]
2.5 34800 [10.2] 21800 [6.4] 9
2 26700 [7.8] 9300 [2.7] 1225 [578] 73 34800 [10.2] 21800 [6.4]
Rev.
4/25/2012
➀ Highest sales volume tested combination required by DOE test procedures.
[ ] Designates Metric Conversions
9
Air
Performance Data
RPRL Series
Performance Data AHRI Standard Conditions
Note: Only these combinations of indoor/outdoor units are approved and any other combinations should not be used.
Outdoor
Unit
RPRL-
Model Numbers
Stage
AHRI Cooling Performance
80°F [26.5°C] / 67°F [19.5°C] WB Indoor Air
95°F [35°C] DB Outdoor Air
AHRI Heating Performance (70°F [21°C] Indoor)
Outdoor Air
47°F [8.5°C] DB/
43°F [6°C] WB
Outdoor Air
17°F [-8.5°C] DB/
15°F [-9.5°C] WB
AHRI Rating
DOE
Region IV
HSPF
Net Sensible
BTU/H [kW]
Net Latent
BTU/H [kW]
AHRI Ratings
Indoor Airflow
CFM [L/s]
Sound
Rating
dB
47°F [8.5°C] DB/
43°F [6°C] WB
17°F [-8.5°C] DB/
15°F [-9.5°C] WB
ID Coil ID Air Mover
Tot al
Capacity
SEER EER BTU/H [kW] COP BTU/H [kW] COP BTU/H [kW] BTU/H [kW]
037JEC
RCFL-H*3821
RGRM-10?RAJ?
1 20600 [6.0] 8600 [2.5]
36000 [10.5] 16 12
900 [425] 69 24000 [7.0]
3.7
12700 [3.7]
2.5 34600 [10.1] 21800 [6.4] 9
2 26700 [7.8] 9300 [2.7] 1225 [578] 73 34600 [10.1] 21800 [6.4]
RGRM-10?ZAJ?
1 20600 [6.0] 8600 [2.5]
35800 [10.5] 16 12
875 [413] 69 24000 [7.0]
3.7
12800 [3.8]
2.5 34600 [10.1] 21800 [6.4] 9
2 26200 [7.7] 9600 [2.8] 1150 [543] 73 34600 [10.1] 21800 [6.4]
RGTM-06?MAE?
1 20600 [6.0] 8600 [2.5]
35400 [10.4] 16 12
900 [425] 69 24000 [7.0]
3.75
12800 [3.8]
2.55 34400 [10.1] 21600 [6.3] 9
2 25300 [7.4] 10100 [3.0] 1025 [484] 73 34400 [10.1] 21600 [6.3]
RGTM-07?RBG?
1 21000 [6.2] 8400 [2.5]
36600 [10.7] 16 12.5
950 [448] 69 24000 [7.0]
3.7
12800 [3.8]
2.5 34600 [10.1] 21800 [6.4] 9
2 27600 [8.1] 9000 [2.6] 1275 [602] 73 34600 [10.1] 21800 [6.4]
RGTM-09?RAJ?
1 21700 [6.4] 8100 [2.4]
36600 [10.7] 16 12
1025 [484] 69 24200 [7.1]
3.7
12900 [3.8]
2.5 34600 [10.1] 21800 [6.4] 9
2 27600 [8.1] 9000 [2.6] 1275 [602] 73 34600 [10.1] 21800 [6.4]
RGTM-09?ZAJ?
1 21300 [6.2] 8300 [2.4]
36200 [10.6] 16 12.5
975 [460] 69 24000 [7.0]
3.75
12800 [3.8]
2.55 34600 [10.1] 21600 [6.3] 9
2 26900 [7.9] 9300 [2.7] 1225 [578] 73 34600 [10.1] 21600 [6.3]
ROCA-070E03
1 21400 [6.3] 8200 [2.4]
36200 [10.6] 16 12
1000 [472] 69 24200 [7.1]
3.7
12900 [3.8]
2.5 34600 [10.1] 21800 [6.4] 9
2 26900 [7.9] 9300 [2.7] 1200 [566] 73 34600 [10.1] 21800 [6.4]
ROCA-070E04
1 21400 [6.3] 8200 [2.4]
36200 [10.6] 16 12
1000 [472] 69 24200 [7.1]
3.7
12900 [3.8]
2.5 34600 [10.1] 21800 [6.4] 9
2 26900 [7.9] 9300 [2.7] 1200 [566] 73 34600 [10.1] 21800 [6.4]
ROLA-070E03
1 20600 [6.0] 8600 [2.5]
36400 [10.7] 16 12.5
900 [425] 69 24000 [7.0]
3.75
12700 [3.7]
2.55 34400 [10.1] 21600 [6.3] 9
2 27100 [7.9] 9300 [2.7] 1175 [554] 73 34400 [10.1] 21600 [6.3]
ROLA-070E04
1 20600 [6.0] 8600 [2.5]
36400 [10.7] 16 12.5
900 [425] 69 24000 [7.0]
3.75
12700 [3.7]
2.55 34400 [10.1] 21600 [6.3] 9
2 27100 [7.9] 9300 [2.7] 1175 [554] 73 34400 [10.1] 21600 [6.3]
ROLA-115E05
1 20600 [6.0] 8600 [2.5]
36400 [10.7] 16 12.5
900 [425] 69 24000 [7.0]
3.8
12700 [3.7]
2.55 34400 [10.1] 21600 [6.3] 9
2 27100 [7.9] 9300 [2.7] 1200 [566] 73 34400 [10.1] 21600 [6.3]
RCFL-H*3821+RXMD-C06 Coil Only
1 20000 [5.9] 8600 [2.5]
35800 [10.5] 14 11.5
900 [425] 69 23400 [6.9]
3.5
12000 [3.5]
2.35 34400 [10.1] 21600 [6.3] 8.2
2 26500 [7.8] 9300 [2.7] 1200 [566] 73 34400 [10.1] 21600 [6.3]
RCFL-H*3824
RGFE-09?ZCM?
1 20600 [6.0] 8600 [2.5]
36200 [10.6] 16 12
875 [413] 69 24000 [7.0]
3.7
12700 [3.7]
2.5 34600 [10.1] 21800 [6.4] 9
2 26900 [7.9] 9300 [2.7] 1200 [566] 73 34600 [10.1] 21800 [6.4]
RGFE-10?ZCM?
1 20600 [6.0] 8600 [2.5]
36000 [10.5] 16 12
900 [425] 69 24000 [7.0]
3.7
12700 [3.7]
2.5 34600 [10.1] 21800 [6.4] 9
2 26700 [7.8] 9300 [2.7] 1225 [578] 73 34600 [10.1] 21800 [6.4]
RGFE-12?RCM?
1 20600 [6.0] 8600 [2.5]
36200 [10.6] 16.5 12.5
875 [413] 69 24000 [7.0]
3.75
12700 [3.7]
2.55 34400 [10.1] 21600 [6.3] 9
2 26900 [7.9] 9300 [2.7] 1225 [578] 73 34400 [10.1] 21600 [6.3]
RGFG-09?ZCM?
1 20600 [6.0] 8600 [2.5]
36200 [10.6] 16 12
875 [413] 69 24000 [7.0]
3.7
12700 [3.7]
2.5 34600 [10.1] 21800 [6.4] 9
2 26900 [7.9] 9300 [2.7] 1200 [566] 73 34600 [10.1] 21800 [6.4]
RGFG-10?ZCM?
1 20600 [6.0] 8600 [2.5]
36200 [10.6] 16 12
900 [425] 69 24000 [7.0]
3.7
12800 [3.8]
2.5 34600 [10.1] 21800 [6.4] 9
2 26900 [7.9] 9300 [2.7] 1200 [566] 73 34600 [10.1] 21800 [6.4]
Rev.
4/25/2012
➀ Highest sales volume tested combination required by DOE test procedures.
[ ] Designates Metric Conversions
10
Air
Performance Data
RPRL Series
Performance Data AHRI Standard Conditions
Note: Only these combinations of indoor/outdoor units are approved and any other combinations should not be used.
Outdoor
Unit
RPRL-
Model Numbers
Stage
AHRI Cooling Performance
80°F [26.5°C] / 67°F [19.5°C] WB Indoor Air
95°F [35°C] DB Outdoor Air
AHRI Heating Performance (70°F [21°C] Indoor)
Outdoor Air
47°F [8.5°C] DB/
43°F [6°C] WB
Outdoor Air
17°F [-8.5°C] DB/
15°F [-9.5°C] WB
AHRI Rating
DOE
Region IV
HSPF
Net Sensible
BTU/H [kW]
Net Latent
BTU/H [kW]
AHRI Ratings
Indoor Airflow
CFM [L/s]
Sound
Rating
dB
47°F [8.5°C] DB/
43°F [6°C] WB
17°F [-8.5°C] DB/
15°F [-9.5°C] WB
ID Coil ID Air Mover
Tot al
Capacity
SEER EER BTU/H [kW] COP BTU/H [kW] COP BTU/H [kW] BTU/H [kW]
037JEC
RCFL-H*3824
RGFG-12?RCM?
1 20600 [6.0] 8600 [2.5]
36200 [10.6] 16.5 12.5
875 [413] 69 24000 [7.0]
3.75
12700 [3.7]
2.55 34400 [10.1] 21600 [6.3] 9
2 26900 [7.9] 9300 [2.7] 1225 [578] 73 34400 [10.1] 21600 [6.3]
RGGE-09?ZCM?
1 21700 [6.4] 8100 [2.4]
36400 [10.7] 16 12
1025 [484] 69 24200 [7.1]
3.7
12900 [3.8]
2.5 34600 [10.1] 21800 [6.4] 9
2 27300 [8.0] 9100 [2.7] 1250 [590] 73 34600 [10.1] 21800 [6.4]
RGGE-10?ZCM?
1 20600 [6.0] 8600 [2.5]
36200 [10.6] 16 12
875 [413] 69 24000 [7.0]
3.7
12700 [3.7]
2.55 34600 [10.1] 21800 [6.4] 9
2 26900 [7.9] 9300 [2.7] 1200 [566] 73 34600 [10.1] 21800 [6.4]
RGGE-12?RCM?
1 20600 [6.0] 8600 [2.5]
36400 [10.7] 16.5 12.5
875 [413] 69 24000 [7.0]
3.8
12600 [3.7]
2.55 34400 [10.1] 21600 [6.3] 9
2 27100 [7.9] 9300 [2.7] 1200 [566] 73 34400 [10.1] 21600 [6.3]
RGJF-09?ZCM?
1 21700 [6.4] 8100 [2.4]
36400 [10.7] 16 12
1025 [484] 69 24200 [7.1]
3.7
12900 [3.8]
2.5 34600 [10.1] 21800 [6.4] 9
2 27300 [8.0] 9100 [2.7] 1250 [590] 73 34600 [10.1] 21800 [6.4]
RGJF-10?ZCM?
1 20600 [6.0] 8600 [2.5]
36200 [10.6] 16 12
875 [413] 69 24000 [7.0]
3.75
12700 [3.7]
2.55 34600 [10.1] 21800 [6.4] 9
2 26900 [7.9] 9300 [2.7] 1200 [566] 73 34600 [10.1] 21800 [6.4]
RGJF-12?RCM?
1 20600 [6.0] 8600 [2.5]
36400 [10.7] 16.5 12.5
875 [413] 69 24000 [7.0]
3.8
12600 [3.7]
2.55 34400 [10.1] 21600 [6.3] 9
2 27100 [7.9] 9300 [2.7] 1200 [566] 73 34400 [10.1] 21600 [6.3]
RGLE-07?BRQ?
1 20600 [6.0] 8600 [2.5]
36400 [10.7] 16.5 12.5
925 [437] 69 24000 [7.0]
3.75
12700 [3.7]
2.55 34400 [10.1] 21600 [6.3] 9
2 27100 [7.9] 9300 [2.7] 1225 [578] 73 34400 [10.1] 21600 [6.3]
RGLE-10?BRM?
1 20800 [6.1] 8600 [2.5]
36400 [10.7] 16.5 12.5
875 [413] 69 23800 [7.0]
3.8
12600 [3.7]
2.55 34400 [10.1] 21400 [6.3] 9
2 27100 [7.9] 9300 [2.7] 1200 [566] 73 34400 [10.1] 21400 [6.3]
RGLE-12?ARM?
1 20600 [6.0] 8600 [2.5]
36400 [10.7] 16.5 12.5
925 [437] 69 24000 [7.0]
3.8
12600 [3.7]
2.55 34400 [10.1] 21400 [6.3] 9
2 27100 [7.9] 9300 [2.7] 1225 [578] 73 34400 [10.1] 21400 [6.3]
RGLR-12?ARM?
1 21600 [6.3] 8200 [2.4]
36400 [10.7] 16.5 12.5
1000 [472] 69 24000 [7.0]
3.8
12700 [3.7]
2.55 34400 [10.1] 21600 [6.3] 9
2 27100 [7.9] 9300 [2.7] 1225 [578] 73 34400 [10.1] 21600 [6.3]
RGPE-07?BRQ?
1 20600 [6.0] 8600 [2.5]
36400 [10.7] 16.5 12.5
900 [425] 69 24000 [7.0]
3.75
12700 [3.7]
2.55 34400 [10.1] 21600 [6.3] 9
2 27100 [7.9] 9300 [2.7] 1225 [578] 73 34400 [10.1] 21600 [6.3]
RGPE-10?BRM?
1 20600 [6.0] 8600 [2.5]
36400 [10.7] 16.5 12.5
900 [425] 69 24000 [7.0]
3.8
12700 [3.7]
2.55 34400 [10.1] 21600 [6.3] 9
2 27100 [7.9] 9300 [2.7] 1225 [578] 73 34400 [10.1] 21600 [6.3]
RGPE-12?ARM?
1 20600 [6.0] 8600 [2.5]
36400 [10.7] 16.5 12.5
875 [413] 69 24000 [7.0]
3.8
12700 [3.7]
2.55 34400 [10.1] 21400 [6.3] 9
2 27100 [7.9] 9300 [2.7] 1200 [566] 73 34400 [10.1] 21400 [6.3]
RGPR-12?ARM?
1 21600 [6.3] 8200 [2.4]
36600 [10.7] 16.5 12.5
1000 [472] 69 24000 [7.0]
3.75
12800 [3.8]
2.55 34400 [10.1] 21600 [6.3] 9
2 27500 [8.1] 9100 [2.7] 1250 [590] 73 34400 [10.1] 21600 [6.3]
RGRM-07?YBG?
1 20100 [5.9] 8700 [2.5]
35600 [10.4] 15.5 11.5
850 [401] 69 24200 [7.1]
3.55
12900 [3.8]
2.4 35200 [10.3] 22400 [6.6] 8.5
2 26300 [7.7] 9300 [2.7] 1200 [566] 73 35200 [10.3] 22400 [6.6]
RGRM-09?RAJ?
1 21700 [6.4] 8100 [2.4]
36600 [10.7] 16 12
1050 [495] 69 24200 [7.1]
3.7
12900 [3.8]
2.5 34800 [10.2] 21800 [6.4] 9
2 27900 [8.2] 8700 [2.5] 1325 [625] 73 34800 [10.2] 21800 [6.4]
Rev.
4/25/2012
➀ Highest sales volume tested combination required by DOE test procedures.
[ ] Designates Metric Conversions
11
Air
Performance Data
RPRL Series
Performance Data AHRI Standard Conditions
Note: Only these combinations of indoor/outdoor units are approved and any other combinations should not be used.
Outdoor
Unit
RPRL-
Model Numbers
Stage
AHRI Cooling Performance
80°F [26.5°C] / 67°F [19.5°C] WB Indoor Air
95°F [35°C] DB Outdoor Air
AHRI Heating Performance (70°F [21°C] Indoor)
Outdoor Air
47°F [8.5°C] DB/
43°F [6°C] WB
Outdoor Air
17°F [-8.5°C] DB/
15°F [-9.5°C] WB
AHRI Rating
DOE
Region IV
HSPF
Net Sensible
BTU/H [kW]
Net Latent
BTU/H [kW]
AHRI Ratings
Indoor Airflow
CFM [L/s]
Sound
Rating
dB
47°F [8.5°C] DB/
43°F [6°C] WB
17°F [-8.5°C] DB/
15°F [-9.5°C] WB
ID Coil ID Air Mover
Tot al
Capacity
SEER EER BTU/H [kW] COP BTU/H [kW] COP BTU/H [kW] BTU/H [kW]
037JEC
RCFL-H*3824
RGRM-09?ZAJ?
1 21000 [6.2] 8400 [2.5]
36000 [10.5] 15.5 12
950 [448] 69 24200 [7.1]
3.65
12900 [3.8]
2.5 34800 [10.2] 22000 [6.4] 8.5
2 26700 [7.8] 9300 [2.7] 1225 [578] 73 34800 [10.2] 22000 [6.4]
RGRM-10?RAJ?
1 20600 [6.0] 8600 [2.5]
36000 [10.5] 16 12
900 [425] 69 24000 [7.0]
3.7
12700 [3.7]
2.5 34600 [10.1] 21800 [6.4] 9
2 26700 [7.8] 9300 [2.7] 1225 [578] 73 34600 [10.1] 21800 [6.4]
RGRM-10?ZAJ?
1 20600 [6.0] 8600 [2.5]
35800 [10.5] 16 12
875 [413] 69 24000 [7.0]
3.7
12800 [3.8]
2.5 34600 [10.1] 21800 [6.4] 9
2 26200 [7.7] 9600 [2.8] 1150 [543] 73 34600 [10.1] 21800 [6.4]
RGRM-12?RAJ?
1 20600 [6.0] 8600 [2.5]
36200 [10.6] 16 12
925 [437] 69 24000 [7.0]
3.7
12700 [3.7]
2.5 34600 [10.1] 21800 [6.4] 9
2 26900 [7.9] 9300 [2.7] 1225 [578] 73 34600 [10.1] 21800 [6.4]
RGTM-07?RBG?
1 21000 [6.2] 8400 [2.5]
36600 [10.7] 16 12.5
950 [448] 69 24000 [7.0]
3.7
12800 [3.8]
2.5 34600 [10.1] 21800 [6.4] 9
2 27600 [8.1] 9000 [2.6] 1275 [602] 73 34600 [10.1] 21800 [6.4]
RGTM-09?RAJ?
1 21700 [6.4] 8100 [2.4]
36600 [10.7] 16 12
1025 [484] 69 24200 [7.1]
3.7
12900 [3.8]
2.5 34600 [10.1] 21800 [6.4] 9
2 27600 [8.1] 9000 [2.6] 1275 [602] 73 34600 [10.1] 21800 [6.4]
RGTM-09?ZAJ?
1 21300 [6.2] 8300 [2.4]
36200 [10.6] 16 12.5
975 [460] 69 24000 [7.0]
3.75
12800 [3.8]
2.55 34600 [10.1] 21600 [6.3] 9
2 26900 [7.9] 9300 [2.7] 1225 [578] 73 34600 [10.1] 21600 [6.3]
RGTM-10?RBJ?
1 21300 [6.2] 8300 [2.4]
36400 [10.7] 16 12.5
975 [460] 69 24000 [7.0]
3.75
12800 [3.8]
2.55 34400 [10.1] 21600 [6.3] 9
2 27100 [7.9] 9300 [2.7] 1225 [578] 73 34400 [10.1] 21600 [6.3]
ROCA-070E03
1 19700 [5.8] 8900 [2.6]
35400 [10.4] 16 12.5
800 [378] 69 24000 [7.0]
3.8
12700 [3.7]
2.6 34200 [10.0] 21400 [6.3] 9
2 25100 [7.4] 10300 [3.0] 1000 [472] 73 34200 [10.0] 21400 [6.3]
ROCA-070E04
1 19700 [5.8] 8900 [2.6]
35400 [10.4] 16 12.5
800 [378] 69 24000 [7.0]
3.8
12700 [3.7]
2.6 34200 [10.0] 21400 [6.3] 9
2 25100 [7.4] 10300 [3.0] 1000 [472] 73 34200 [10.0] 21400 [6.3]
ROLA-070E03
1 20600 [6.0] 8600 [2.5]
36200 [10.6] 16 12.5
900 [425] 69 24000 [7.0]
3.75
12700 [3.7]
2.55 34400 [10.1] 21600 [6.3] 9
2 26900 [7.9] 9300 [2.7] 1175 [554] 73 34400 [10.1] 21600 [6.3]
ROLA-070E04
1 20600 [6.0] 8600 [2.5]
36200 [10.6] 16 12.5
900 [425] 69 24000 [7.0]
3.75
12700 [3.7]
2.55 34400 [10.1] 21600 [6.3] 9
2 26900 [7.9] 9300 [2.7] 1175 [554] 73 34400 [10.1] 21600 [6.3]
ROLA-115E05
1 20600 [6.0] 8600 [2.5]
36400 [10.7] 16 12.5
900 [425] 69 24000 [7.0]
3.8
12700 [3.7]
2.55 34400 [10.1] 21600 [6.3] 9
2 27100 [7.9] 9300 [2.7] 1200 [566] 73 34400 [10.1] 21600 [6.3]
RCFL-H*3824+RXMD-C06 Coil Only
1 20000 [5.9] 8600 [2.5]
35800 [10.5] 14 11.5
900 [425] 69 23400 [6.9]
3.5
12000 [3.5]
2.35 34400 [10.1] 21600 [6.3] 8.2
2 26500 [7.8] 9300 [2.7] 1200 [566] 73 34400 [10.1] 21600 [6.3]
Rev.
4/25/2012
➀ Highest sales volume tested combination required by DOE test procedures.
[ ] Designates Metric Conversions
12
Air
Performance Data
RPRL Series
Performance Data AHRI Standard Conditions
Note: Only these combinations of indoor/outdoor units are approved and any other combinations should not be used.
Outdoor
Unit
RPRL-
Model Numbers
Stage
AHRI Cooling Performance
80°F [26.5°C] / 67°F [19.5°C] WB Indoor Air
95°F [35°C] DB Outdoor Air
AHRI Heating Performance (70°F [21°C] Indoor)
Outdoor Air
47°F [8.5°C] DB/
43°F [6°C] WB
Outdoor Air
17°F [-8.5°C] DB/
15°F [-9.5°C] WB
AHRI Rating
DOE
Region IV
HSPF
Net Sensible
BTU/H [kW]
Net Latent
BTU/H [kW]
AHRI Ratings
Indoor Airflow
CFM [L/s]
Sound
Rating
dB
47°F [8.5°C] DB/
43°F [6°C] WB
17°F [-8.5°C] DB/
15°F [-9.5°C] WB
ID Coil ID Air Mover
Tot al
Capacity
SEER EER BTU/H [kW] COP BTU/H [kW] COP BTU/H [kW] BTU/H [kW]
049JEC
RCSL-H*4824 ➀
RHPL-HM4824
1 27500 [8.1] 12000 [3.5]
47000 [13.8] 16 12.5
1175 [554] 69 0 [0.0]
3.78
0 [0.0]
2.68 45000 [13.2] 29200 [8.6] 9
2 34000 [10.0] 13000 [3.8] 1575 [743] 73 45000 [13.2] 29200 [8.6]
1 - dehumid 24800 [7.3] 9600 [2.8] 1025 [484]
2 - dehumid 25400 [7.4] 8900 [2.6] 1175 [554]
RCFL-H*4821
RGFE-09?ZCM?
1 27400 [8.0] 12000 [3.5]
46000 [13.5] 15 11
1200 [566] 69 33400 [9.8]
3.6
20200 [5.9]
2.26 46500 [13.6] 31200 [9.1] 9
2 32800 [9.6] 13000 [3.8] 1600 [755] 73 46500 [13.6] 31200 [9.1]
RGFE-10?ZCM?
1 27800 [8.1] 11700 [3.4]
45500 [13.3] 15 11
1225 [578] 69 33400 [9.8]
3.58
20200 [5.9]
2.26 47000 [13.8] 31200 [9.1] 9
2 32600 [9.6] 13000 [3.8] 1600 [755] 73 47000 [13.8] 31200 [9.1]
RGFG-09?ZCM?
1 27400 [8.0] 12000 [3.5]
46000 [13.5] 15 11
1200 [566] 69 33400 [9.8]
3.6
20200 [5.9]
2.26 46500 [13.6] 31200 [9.1] 9
2 32800 [9.6] 13000 [3.8] 1600 [755] 73 46500 [13.6] 31200 [9.1]
RGFG-10?ZCM?
1 27400 [8.0] 12000 [3.5]
46000 [13.5] 15 11
1200 [566] 69 33400 [9.8]
3.6
20200 [5.9]
2.26 47000 [13.8] 31200 [9.1] 9
2 33600 [9.8] 12500 [3.7] 1650 [779] 73 47000 [13.8] 31200 [9.1]
RGGE-09?ZCM?
1 28000 [8.2] 11700 [3.4]
46000 [13.5] 15.5 11
1225 [578] 69 33600 [9.8]
3.64
20200 [5.9]
2.3 46500 [13.6] 31000 [9.1] 9
2 33000 [9.7] 13000 [3.8] 1600 [755] 73 46500 [13.6] 31000 [9.1]
RGGE-10?ZCM?
1 27400 [8.0] 12000 [3.5]
46000 [13.5] 15 11
1200 [566] 69 33400 [9.8]
3.62
20200 [5.9]
2.28 46500 [13.6] 31200 [9.1] 9
2 32800 [9.6] 13000 [3.8] 1600 [755] 73 46500 [13.6] 31200 [9.1]
RGJF-09?ZCM?
1 28000 [8.2] 11700 [3.4]
46000 [13.5] 15.5 11
1225 [578] 69 33600 [9.8]
3.64
20400 [6.0]
2.3 46500 [13.6] 31000 [9.1] 9
2 33000 [9.7] 13000 [3.8] 1600 [755] 73 46500 [13.6] 31000 [9.1]
RGJF-10?ZCM?
1 27400 [8.0] 12000 [3.5]
46000 [13.5] 15 11
1200 [566] 69 33400 [9.8]
3.62
20200 [5.9]
2.28 46500 [13.6] 31200 [9.1] 9
2 32800 [9.6] 13000 [3.8] 1600 [755] 73 46500 [13.6] 31200 [9.1]
RGLE-07?BRQ?
1 28000 [8.2] 11700 [3.4]
46000 [13.5] 15.5 11.5
1225 [578] 69 33600 [9.8]
3.56
20400 [6.0]
2.32 44500 [13.0] 29200 [8.6] 9
2 33200 [9.7] 13000 [3.8] 1600 [755] 73 44500 [13.0] 29200 [8.6]
RGLE-10?BRM?
1 27600 [8.1] 12000 [3.5]
46500 [13.6] 16 12
1200 [566] 69 33800 [9.9]
3.66
20400 [6.0]
2.38 45000 [13.2] 29400 [8.6] 9
2 33400 [9.8] 13000 [3.8] 1600 [755] 73 45000 [13.2] 29400 [8.6]
RGPE-07?BRQ?
1 28000 [8.2] 11700 [3.4]
46500 [13.6] 15.5 11.5
1225 [578] 69 33600 [9.8]
3.6
20400 [6.0]
2.34 45000 [13.2] 29200 [8.6] 9
2 33200 [9.7] 13000 [3.8] 1600 [755] 73 45000 [13.2] 29200 [8.6]
RGPE-10?BRM?
1 28000 [8.2] 11700 [3.4]
46500 [13.6] 16 11.5
1225 [578] 69 33600 [9.8]
3.6
20400 [6.0]
2.34 45000 [13.2] 29200 [8.6] 9
2 33800 [9.9] 12700 [3.7] 1625 [767] 73 45000 [13.2] 29200 [8.6]
RGRM-09?ZAJ?
1 27800 [8.1] 11700 [3.4]
46000 [13.5] 15 11
1225 [578] 69 33400 [9.8]
3.54
20000 [5.9]
2.22 47000 [13.8] 31600 [9.3] 9
2 33200 [9.7] 12700 [3.7] 1625 [767] 73 47000 [13.8] 31600 [9.3]
RGRM-10?ZAJ?
1 27400 [8.0] 12000 [3.5]
45500 [13.3] 15 11
1150 [543] 69 33400 [9.8]
3.56
20200 [5.9]
2.28 47000 [13.8] 31400 [9.2] 9
2 32600 [9.6] 13000 [3.8] 1600 [755] 73 47000 [13.8] 31400 [9.2]
RGTM-07?RBG?
1 28800 [8.4] 11200 [3.3]
46500 [13.6] 15 11
1325 [625] 69 33400 [9.8]
3.62
20000 [5.9]
2.22 46500 [13.6] 31200 [9.1] 9
2 34000 [10.0] 12400 [3.6] 1675 [790] 73 46500 [13.6] 31200 [9.1]
Rev.
4/25/2012
➀ Highest sales volume tested combination required by DOE test procedures.
[ ] Designates Metric Conversions
13
Air
Performance Data
RPRL Series
Performance Data AHRI Standard Conditions
Note: Only these combinations of indoor/outdoor units are approved and any other combinations should not be used.
Outdoor
Unit
RPRL-
Model Numbers
Stage
AHRI Cooling Performance
80°F [26.5°C] / 67°F [19.5°C] WB Indoor Air
95°F [35°C] DB Outdoor Air
AHRI Heating Performance (70°F [21°C] Indoor)
Outdoor Air
47°F [8.5°C] DB/
43°F [6°C] WB
Outdoor Air
17°F [-8.5°C] DB/
15°F [-9.5°C] WB
AHRI Rating
DOE
Region IV
HSPF
Net Sensible
BTU/H [kW]
Net Latent
BTU/H [kW]
AHRI Ratings
Indoor Airflow
CFM [L/s]
Sound
Rating
dB
47°F [8.5°C] DB/
43°F [6°C] WB
17°F [-8.5°C] DB/
15°F [-9.5°C] WB
ID Coil ID Air Mover
Tot al
Capacity
SEER EER BTU/H [kW] COP BTU/H [kW] COP BTU/H [kW] BTU/H [kW]
049JEC
RCFL-H*4821
RGTM-09?ZAJ?
1 28200 [8.3] 11600 [3.4]
46000 [13.5] 15.5 11
1250 [590] 69 33400 [9.8]
3.64
20200 [5.9]
2.28 46500 [13.6] 31000 [9.1] 9
2 33000 [9.7] 13000 [3.8] 1600 [755] 73 46500 [13.6] 31000 [9.1]
ROLA-070E04
1 27400 [8.0] 12000 [3.5]
46000 [13.5] 15.5 11
1175 [554] 69 33600 [9.8]
3.64
20400 [6.0]
2.32 46500 [13.6] 31000 [9.1] 9
2 33000 [9.7] 13000 [3.8] 1600 [755] 73 46500 [13.6] 31000 [9.1]
ROLA-115E05
1 27600 [8.1] 12000 [3.5]
46000 [13.5] 15.5 11.5
1200 [566] 69 33600 [9.8]
3.54
20400 [6.0]
2.34 44500 [13.0] 29200 [8.6] 9
2 33200 [9.7] 13000 [3.8] 1600 [755] 73 44500 [13.0] 29200 [8.6]
RCFL-H*4821+RXMD-C06 Coil Only
1 26800 [7.9] 12000 [3.5]
45500 [13.3] 14.5 11.5
1175 [554] 69 32000 [9.4]
3.68
18700 [5.5]
2.2 43500 [12.7] 28000 [8.2] 8.2
2 31600 [9.3] 14000 [4.1] 1425 [672] 73 43500 [12.7] 28000 [8.2]
RCFL-H*4824
RGFE-09?ZCM?
1 27400 [8.0] 12000 [3.5]
46000 [13.5] 15 11
1200 [566] 69 33400 [9.8]
3.6
20200 [5.9]
2.26 47000 [13.8] 31200 [9.1] 9
2 32800 [9.6] 13000 [3.8] 1600 [755] 73 47000 [13.8] 31200 [9.1]
RGFE-10?ZCM?
1 27800 [8.1] 11700 [3.4]
45500 [13.3] 15 11
1225 [578] 69 33400 [9.8]
3.58
20200 [5.9]
2.24 47000 [13.8] 31400 [9.2] 9
2 32600 [9.6] 13000 [3.8] 1600 [755] 73 47000 [13.8] 31400 [9.2]
RGFE-12?RCM?
1 28000 [8.2] 11700 [3.4]
46000 [13.5] 15.5 11.5
1225 [578] 69 33600 [9.8]
3.64
20400 [6.0]
2.3 46500 [13.6] 31000 [9.1] 9
2 33600 [9.8] 12700 [3.7] 1625 [767] 73 46500 [13.6] 31000 [9.1]
RGFG-09?ZCM?
1 27400 [8.0] 12000 [3.5]
46000 [13.5] 15 11
1200 [566] 69 33400 [9.8]
3.6
20200 [5.9]
2.26 47000 [13.8] 31200 [9.1] 9
2 32800 [9.6] 13000 [3.8] 1600 [755] 73 47000 [13.8] 31200 [9.1]
RGFG-10?ZCM?
1 27400 [8.0] 12000 [3.5]
46000 [13.5] 15 11
1200 [566] 69 33400 [9.8]
3.58
20200 [5.9]
2.26 47000 [13.8] 31200 [9.1] 9
2 33600 [9.8] 12500 [3.7] 1650 [779] 73 47000 [13.8] 31200 [9.1]
RGFG-12?RCM?
1 28000 [8.2] 11700 [3.4]
46000 [13.5] 15.5 11.5
1225 [578] 69 33600 [9.8]
3.64
20400 [6.0]
2.3 46500 [13.6] 31000 [9.1] 9
2 33600 [9.8] 12700 [3.7] 1625 [767] 73 46500 [13.6] 31000 [9.1]
RGGE-09?ZCM?
1 28000 [8.2] 11700 [3.4]
46000 [13.5] 15.5 11
1225 [578] 69 33600 [9.8]
3.64
20200 [5.9]
2.3 46500 [13.6] 31000 [9.1] 9
2 33000 [9.7] 13000 [3.8] 1600 [755] 73 46500 [13.6] 31000 [9.1]
RGGE-10?ZCM?
1 27400 [8.0] 12000 [3.5]
46000 [13.5] 15 11
1200 [566] 69 33400 [9.8]
3.62
20200 [5.9]
2.28 46500 [13.6] 31200 [9.1] 9
2 32800 [9.6] 13000 [3.8] 1600 [755] 73 46500 [13.6] 31200 [9.1]
RGGE-12?RCM?
1 27600 [8.1] 12000 [3.5]
46500 [13.6] 15.5 11.5
1200 [566] 69 33600 [9.8]
3.6
20400 [6.0]
2.34 45000 [13.2] 29200 [8.6] 9
2 33400 [9.8] 13000 [3.8] 1575 [743] 73 45000 [13.2] 29200 [8.6]
RGJF-09?ZCM?
1 28000 [8.2] 11700 [3.4]
46000 [13.5] 15.5 11
1225 [578] 69 33600 [9.8]
3.64
20400 [6.0]
2.3 46500 [13.6] 31000 [9.1] 9
2 33000 [9.7] 13000 [3.8] 1600 [755] 73 46500 [13.6] 31000 [9.1]
RGJF-10?ZCM?
1 27400 [8.0] 12000 [3.5]
46000 [13.5] 15 11
1200 [566] 69 33400 [9.8]
3.62
20200 [5.9]
2.28 46500 [13.6] 31200 [9.1] 9
2 32800 [9.6] 13000 [3.8] 1600 [755] 73 46500 [13.6] 31200 [9.1]
RGJF-12?RCM?
1 27600 [8.1] 12000 [3.5]
46500 [13.6] 15.5 11.5
1200 [566] 69 33600 [9.8]
3.62
20400 [6.0]
2.36 45000 [13.2] 29200 [8.6] 9
2 33400 [9.8] 13000 [3.8] 1575 [743] 73 45000 [13.2] 29200 [8.6]
RGLE-07?BRQ?
1 28000 [8.2] 11700 [3.4]
46000 [13.5] 15.5 11.5
1225 [578] 69 33600 [9.8]
3.56
20400 [6.0]
2.32 44500 [13.0] 29200 [8.6] 9
2 33200 [9.7] 13000 [3.8] 1600 [755] 73 44500 [13.0] 29200 [8.6]
Rev.
4/25/2012
➀ Highest sales volume tested combination required by DOE test procedures.
[ ] Designates Metric Conversions
14
Air
Performance Data
RPRL Series
Performance Data AHRI Standard Conditions
Note: Only these combinations of indoor/outdoor units are approved and any other combinations should not be used.
Outdoor
Unit
RPRL-
Model Numbers
Stage
AHRI Cooling Performance
80°F [26.5°C] / 67°F [19.5°C] WB Indoor Air
95°F [35°C] DB Outdoor Air
AHRI Heating Performance (70°F [21°C] Indoor)
Outdoor Air
47°F [8.5°C] DB/
43°F [6°C] WB
Outdoor Air
17°F [-8.5°C] DB/
15°F [-9.5°C] WB
AHRI Rating
DOE
Region IV
HSPF
Net Sensible
BTU/H [kW]
Net Latent
BTU/H [kW]
AHRI Ratings
Indoor Airflow
CFM [L/s]
Sound
Rating
dB
47°F [8.5°C] DB/
43°F [6°C] WB
17°F [-8.5°C] DB/
15°F [-9.5°C] WB
ID Coil ID Air Mover
Tot al
Capacity
SEER EER BTU/H [kW] COP BTU/H [kW] COP BTU/H [kW] BTU/H [kW]
049JEC
RCFL-H*4824
RGLE-10?BRM?
1 27600 [8.1] 12000 [3.5]
46500 [13.6] 16 12
1200 [566] 69 33800 [9.9]
3.66
20400 [6.0]
2.38 45000 [13.2] 29400 [8.6] 9
2 33400 [9.8] 13000 [3.8] 1600 [755] 73 45000 [13.2] 29400 [8.6]
RGLE-12?ARM?
1 28200 [8.3] 11700 [3.4]
46500 [13.6] 16 11.5
1225 [578] 69 33800 [9.9]
3.64
20400 [6.0]
2.36 45000 [13.2] 29400 [8.6] 9
2 33400 [9.8] 13000 [3.8] 1600 [755] 73 45000 [13.2] 29400 [8.6]
RGPE-07?BRQ?
1 28000 [8.2] 11700 [3.4]
46500 [13.6] 15.5 11.5
1225 [578] 69 33600 [9.8]
3.6
20400 [6.0]
2.34 45000 [13.2] 29200 [8.6] 9
2 33200 [9.7] 13000 [3.8] 1600 [755] 73 45000 [13.2] 29200 [8.6]
RGPE-10?BRM?
1 28000 [8.2] 11700 [3.4]
46500 [13.6] 15.5 11.5
1225 [578] 69 33600 [9.8]
3.58
20400 [6.0]
2.34 44500 [13.0] 29200 [8.6] 9
2 33800 [9.9] 12700 [3.7] 1625 [767] 73 44500 [13.0] 29200 [8.6]
RGPE-12?ARM?
1 27600 [8.1] 12000 [3.5]
46500 [13.6] 16 12
1200 [566] 69 33800 [9.9]
3.64
20400 [6.0]
2.38 45000 [13.2] 29400 [8.6] 9
2 34000 [10.0] 12700 [3.7] 1625 [767] 73 45000 [13.2] 29400 [8.6]
RGRM-09?ZAJ?
1 27800 [8.1] 11700 [3.4]
46000 [13.5] 15 11
1225 [578] 69 33400 [9.8]
3.54
20000 [5.9]
2.22 47000 [13.8] 31600 [9.3] 9
2 33200 [9.7] 12700 [3.7] 1625 [767] 73 47000 [13.8] 31600 [9.3]
RGRM-10?ZAJ?
1 27400 [8.0] 12000 [3.5]
45500 [13.3] 15 11
1150 [543] 69 33400 [9.8]
3.54
20200 [5.9]
2.26 47000 [13.8] 31400 [9.2] 9
2 32600 [9.6] 13000 [3.8] 1600 [755] 73 47000 [13.8] 31400 [9.2]
RGRM-12?RAJ?
1 27800 [8.1] 11700 [3.4]
46500 [13.6] 15.5 11.5
1225 [578] 69 33400 [9.8]
3.64
20200 [5.9]
2.28 46500 [13.6] 31000 [9.1] 9
2 33600 [9.8] 12700 [3.7] 1625 [767] 73 46500 [13.6] 31000 [9.1]
RGTM-07?RBG?
1 28800 [8.4] 11200 [3.3]
46500 [13.6] 15 11
1325 [625] 69 33400 [9.8]
3.62
20000 [5.9]
2.22 46500 [13.6] 31200 [9.1] 9
2 34000 [10.0] 12400 [3.6] 1675 [790] 73 46500 [13.6] 31200 [9.1]
RGTM-09?ZAJ?
1 28200 [8.3] 11600 [3.4]
46000 [13.5] 15.5 11
1250 [590] 69 33400 [9.8]
3.62
20200 [5.9]
2.28 46500 [13.6] 31000 [9.1] 9
2 32800 [9.6] 13000 [3.8] 1600 [755] 73 46500 [13.6] 31000 [9.1]
RGTM-10?RBJ?
1 28400 [8.3] 11500 [3.4]
46500 [13.6] 15.5 11.5
1275 [602] 69 33400 [9.8]
3.5
20200 [5.9]
2.28 44500 [13.0] 29000 [8.5] 9
2 34200 [10.0] 12400 [3.6] 1675 [790] 73 44500 [13.0] 29000 [8.5]
ROCA-070E04
1 27200 [8.0] 12000 [3.5]
45500 [13.3] 15 11.5
1200 [566] 69 33400 [9.8]
3.58
20200 [5.9]
2.24 45000 [13.2] 29200 [8.6] 9
2 31200 [9.1] 14100 [4.1] 1400 [661] 73 45000 [13.2] 29200 [8.6]
ROLA-070E04
1 27400 [8.0] 12000 [3.5]
46000 [13.5] 15.5 11
1175 [554] 69 33600 [9.8]
3.64
20400 [6.0]
2.32 46500 [13.6] 31000 [9.1] 9
2 33000 [9.7] 13000 [3.8] 1600 [755] 73 46500 [13.6] 31000 [9.1]
ROLA-115E05
1 27600 [8.1] 12000 [3.5]
46000 [13.5] 15.5 11.5
1200 [566] 69 33600 [9.8]
3.54
20400 [6.0]
2.34 44500 [13.0] 29000 [8.5] 9
2 33200 [9.7] 13000 [3.8] 1600 [755] 73 44500 [13.0] 29000 [8.5]
RCFL-H*4824+RXMD-C06 Coil Only
1 26800 [7.9] 12000 [3.5]
45500 [13.3] 14.5 11.5
1175 [554] 69 32000 [9.4]
3.68
18700 [5.5]
2.2 43500 [12.7] 28000 [8.2] 8.2
2 31600 [9.3] 14000 [4.1] 1425 [672] 73 43500 [12.7] 28000 [8.2]
Rev.
4/25/2012
➀ Highest sales volume tested combination required by DOE test procedures.
[ ] Designates Metric Conversions
Air
Performance Data
RPRL Series
15
Performance Data AHRI Standard Conditions
Note: Only these combinations of indoor/outdoor units are approved and any other combinations should not be used.
Outdoor
Unit
RPRL-
Model Numbers
Stage
AHRI Cooling Performance
80°F [26.5°C] / 67°F [19.5°C] WB Indoor Air
95°F [35°C] DB Outdoor Air
AHRI Heating Performance (70°F [21°C] Indoor)
Outdoor Air
47°F [8.5°C] DB/
43°F [6°C] WB
Outdoor Air
17°F [-8.5°C] DB/
15°F [-9.5°C] WB
AHRI Rating
DOE
Region IV
HSPF
Net Sensible
BTU/H [kW]
Net Latent
BTU/H [kW]
AHRI Ratings
Indoor Airflow
CFM [L/s]
Sound
Rating
dB
47°F [8.5°C] DB/
43°F [6°C] WB
17°F [-8.5°C] DB/
15°F [-9.5°C] WB
ID Coil ID Air Mover
Tot al
Capacity
SEER EER BTU/H [kW] COP BTU/H [kW] COP BTU/H [kW] BTU/H [kW]
061JEC
RCSL-H*6024
➀
RHPL-HM6024
1 33700 [9.9] 14300 [4.2]
57500 [16.8] 16 12.5
1325 [625] 76 39000 [11.4]
3.8
21400 [6.3]
2.62 55500 [16.3] 34200 [10.0] 9
2 41500 [12.2] 16000 [4.7] 1725 [814] 76 55500 [16.3] 34200 [10.0]
1 - dehumid 29300 [8.6] 11700 [3.4] 1100 [519]
2 - dehumid 37800 [11.1] 17200 [5.0] 1375 [649]
RCFL-H*6024
RGFE-09?ZCM?
1 33600 [9.8] 13800 [4.0]
56000 [16.4] 14.5 11
1400 [661] 76 39000 [11.4]
3.6
21600 [6.3]
2.5 57500 [16.8] 36400 [10.7] 8.2
2 40500 [11.9] 15600 [4.6] 1775 [838] 76 57500 [16.8] 36400 [10.7]
RGFE-12?RCM?
1 34400 [10.1] 13500 [4.0]
56500 [16.6] 14.5 11
1450 [684] 76 39000 [11.4]
3.65
21400 [6.3]
2.55 57500 [16.8] 36200 [10.6] 8.2
2 41000 [12.0] 15400 [4.5] 1800 [849] 76 57500 [16.8] 36200 [10.6]
RGFG-09?ZCM?
1 33700 [9.9] 13800 [4.0]
56000 [16.4] 14.5 11
1400 [661] 76 39000 [11.4]
3.6
21600 [6.3]
2.5 57500 [16.8] 36400 [10.7] 8.2
2 40400 [11.8] 15600 [4.6] 1775 [838] 76 57500 [16.8] 36400 [10.7]
RGFG-10?ZCM?
1 33600 [9.8] 13800 [4.0]
56500 [16.6] 14.5 11
1400 [661] 76 39000 [11.4]
3.6
21600 [6.3]
2.5 58000 [17.0] 36600 [10.7] 8.2
2 41000 [12.0] 15200 [4.5] 1825 [861] 76 58000 [17.0] 36600 [10.7]
RGFG-12?RCM?
1 34400 [10.1] 13500 [4.0]
56500 [16.6] 14.5 11
1450 [684] 76 39000 [11.4]
3.65
21400 [6.3]
2.55 57500 [16.8] 36200 [10.6] 8.2
2 41000 [12.0] 15400 [4.5] 1800 [849] 76 57500 [16.8] 36200 [10.6]
RGGE-09?ZCM?
1 33700 [9.9] 13800 [4.0]
56500 [16.6] 14.5 11
1400 [661] 76 39000 [11.4]
3.65
21400 [6.3]
2.55 57500 [16.8] 36200 [10.6] 8.2
2 40900 [12.0] 15600 [4.6] 1775 [838] 76 57500 [16.8] 36200 [10.6]
RGGE-10?ZCM?
1 33700 [9.9] 13800 [4.0]
56000 [16.4] 14.5 11
1400 [661] 76 39000 [11.4]
3.6
21400 [6.3]
2.5 57500 [16.8] 36400 [10.7] 8.2
2 40400 [11.8] 15600 [4.6] 1775 [838] 76 57500 [16.8] 36400 [10.7]
RGGE-12?RCM?
1 33500 [9.8] 14000 [4.1]
56500 [16.6] 15 11.5
1375 [649] 76 39000 [11.4]
3.75
21200 [6.2]
2.6 57000 [16.7] 35800 [10.5] 8.5
2 40500 [11.9] 16000 [4.7] 1750 [826] 76 57000 [16.7] 35800 [10.5]
RGJF-09?ZCM?
1 33800 [9.9] 13800 [4.0]
56500 [16.6] 14.5 11
1400 [661] 76 39000 [11.4]
3.65
21400 [6.3]
2.55 57500 [16.8] 36200 [10.6] 8.2
2 40500 [11.9] 15600 [4.6] 1775 [838] 76 57500 [16.8] 36200 [10.6]
RGJF-10?ZCM?
1 33600 [9.8] 13800 [4.0]
56000 [16.4] 14.5 11
1400 [661] 76 39000 [11.4]
3.6
21400 [6.3]
2.5 57500 [16.8] 36400 [10.7] 8.2
2 40500 [11.9] 15600 [4.6] 1775 [838] 76 57500 [16.8] 36400 [10.7]
RGJF-12?RCM?
1 33800 [9.9] 14000 [4.1]
56500 [16.6] 15 11.5
1375 [649] 76 39000 [11.4]
3.75
21200 [6.2]
2.6 57000 [16.7] 35800 [10.5] 8.5
2 40500 [11.9] 16000 [4.7] 1750 [826] 76 57000 [16.7] 35800 [10.5]
RGLE-10?BRM?
1 32000 [9.4] 15000 [4.4]
56500 [16.6] 15.5 12
1200 [566] 76 38500 [11.3]
3.85
20800 [6.1]
2.65 56500 [16.6] 35000 [10.3] 8.5
2 39500 [11.6] 17000 [5.0] 1600 [755] 76 56500 [16.6] 35000 [10.3]
RGLE-12?ARM?
1 32100 [9.4] 14900 [4.4]
56500 [16.6] 15.5 12
1225 [578] 76 38500 [11.3]
3.85
20800 [6.1]
2.65 56500 [16.6] 35000 [10.3] 8.5
2 39500 [11.6] 17000 [5.0] 1600 [755] 76 56500 [16.6] 35000 [10.3]
RGTM-07?RBG?
1 33000 [9.7] 14300 [4.2]
56500 [16.6] 15 11.5
1325 [625] 76 39000 [11.4]
3.75
21200 [6.2]
2.6 57000 [16.7] 35600 [10.4] 8.5
2 40000 [11.7] 16400 [4.8] 1675 [790] 76 57000 [16.7] 35600 [10.4]
RGTM-09?RAJ?
1 32000 [9.4] 15000 [4.4]
56000 [16.4] 15 11.5
1200 [566] 76 38500 [11.3]
3.8
21000 [6.2]
2.6 56500 [16.6] 35400 [10.4] 8.5
2 39000 [11.4] 17000 [5.0] 1600 [755] 76 56500 [16.6] 35400 [10.4]
ROCA-070E04
1 33400 [9.8] 13800 [4.0]
55500 [16.3] 14 11.5
1400 [661] 76 39500 [11.6]
3.7
21800 [6.4]
2.55 57000 [16.7] 35800 [10.5] 8.2
2 38500 [11.3] 17000 [5.0] 1600 [755] 76 57000 [16.7] 35800 [10.5]
RCFL-H*6024+RXMD-C06 Coil Only
1 32600 [9.6] 14300 [4.2]
56500 [16.6] 14 11.5
1325 [625] 76 37800 [11.1]
3.6
20200 [5.9]
2.45 54500 [16.0] 33400 [9.8] 8.2
2 40000 [11.7] 16400 [4.8] 1675 [790] 76 54500 [16.0] 33400 [9.8]
Rev.
4/25/2012
➀ Highest sales volume tested combination required by DOE test procedures. [ ] Designates Metric Conversions
Air
Electrical and Physical Data
RPRL Series
16
Model
Number
RPRL
ELECTRICAL PHYSICAL
Phase Frequency (Hz) Voltage (Volts)
Compressor
Fan Motor
Full Load
Amperes
(FLA)
Minimum
Circuit Ampacity Amperes
Fuse or HACR
Circuit Breaker
Outdoor Coil
Refrig.
Per Circuit Oz. [g]
Weight
Rated Load
Amperes
(RLA)
Locked Rotor
Amperes
(LRA)
Minimum
Amperes
Maximum
Amperes
Face Area
Sq. Ft. [m
2
]
No.
Rows
CFM [L/s]
Net
Lbs. [kg]
Shipping Lbs. [kg]
Rev. 4/25/2012 025JEC 1-60-208/230 11.7/11.7 46 1 14/14 20/20 25/25 23 [2.14] 1 2800[1321] 160 [4536] 234 [106.1] 241 [106.1] 037JEC 1-60-208/230 15.3/15.3 83 2.8 22/22 30/30 35/35 23 [2.14] 1 3500[1652] 151 [4281] 231 [104.8] 244 [104.8] 049JEC 1-60-208/230 21.2/21.2 104 2.2 29/29 35/35 45/45 22.22 [2.06] 2 3500[1652] 260 [7371] 296 [134.3] 303 [134.3] 061JEC 1-60-208/230 28.8/28.8 153 2.5 39/39 50/50 60/60 22.22 [2.06] 2 3800[1793] 270 [7654] 316 [143.3] 323 [143.3]
NOTE: Factory Refrigerant Charge includes refrigerant for 15 feet of standard line set.
[ ] Designates Metric Conversions
Electrical and Physical Data
Air
Unit Dimensions
RPRL Series
17
Model Number
RPRL-
Height “H”
(Inches) [mm]
Length “L”
(Inches) [mm]
Width “W”
(Inches) [mm]
025JEC/037JEC 049JEC/061JEC
33 [838] 443/8 [1127] 311/2 [800]
AIR DISCHARGE
[ ] Designates Metric Conversions
ALLOW 60⬙ [1524 mm] CLEARANCE
H
AIR INLETS (LOUVERS) ALLOW 12⬙ [305 mm] MIN. CLEARANCE 3 SIDES
W
L
ACCESS PANEL
ALLOW 24⬙ [610 mm] ACCESS CLEARANCE
LOW VOLTAGE CONNECTION
7
/80 [22 mm]
SERVICE FITTINGS
HIGH VOLTAGE CONNECTION
11
/320 [34 mm]
1
VAPOR LINE
A-00003
CONNECTION
HIGH PRESSURE CONTROL MANUAL RESET (FIELD INSTALLED ACCESSORY)
7
/80 [73 mm] DIA.
2 ACCESSORY KNOCKOUTS
LIQUID LINE CONNECTION
SERVICE ACCESS TO ELECTRICAL & VALVES ALLOW 240 [610 mm] CLEARANCE ONE SIDE
Air
Refrigerant Line Size Information
RPRL Series
18
(-)PRL
Standard Line
Connection
Size
(Inch I.D.) [mm]
Line Size
(Inch O.D.)
[mm]
Liquid Line Size
Outdoor Unit Above or Below Indoor Coil
Total Equivalent Length—Feet [m]
25 [7.62] 50 [15.24] 75 [22.86] 100 [30.48] 125 [38.10] 150 [45.72]
Maximum Vertical Separation—Feet [m]
-025 3/8 [9.53]
1/4" [6.35] 25 [7.62] N/A N/A N/A N/A N/A
5/16" [7.93] 25 [7.62] 36 [10.97] 33 [10.06] 28 [8.53] 22 [6.71] 16 [4.88]
3/8" [9.52] 25 [7.62] 41 [12.50] 40 [12.19] 39 [11.89] 37 [11.28] 36 [10.97]
-037 3/8 [9.53]
5/16" [7.93] 25 [7.62] 22 [6.71] 9 [2.74] N/A N/A N/A
3/8" [9.52] 25 [7.62] 39 [11.89] 34 [10.36] 30 [9.14] 25 [7.62] 21 [6.40] 1/2" [12.70] 25 [7.62] 46 [14.02] 45 [13.72] 44 [13.41] 43 [13.11] 42 [12.80]
-049 3/8 [9.53]
5/16" [7.93] 25 [7.62] 17 [5.18] N/A N/A N/A N/A
3/8" [9.52] 25 [7.62] 47 [14.33] 39 [11.89] 31 [9.45] 23 [7.01] 16 [4.88] 1/2" [12.70] 25 [7.62] 50 [15.24] 58 [17.68] 56 [17.07] 54 [16.46] 53 [16.15]
-061 3/8 [9.53]
3/8" [9.52] 25 [7.62] 18 [5.49] 11 [3.35] N/A N/A N/A 1/2" [12.70] 25 [7.62] 29 [8.84] 27 [8.23] 26 [7.93] 7.62 23 [7.01]
Heat Pump Refrigerant Line Size Information
R-410A System
Capacity
Model
Line Size Connection Size (Inch I.D.) [mm]
Line Size
(Inch O.D.)
[mm]
Suction Line Size
Outdoor Unit ABOVE Indoor Coil
Total Line Length—Feet [m]
25 [7.62] 50 [15.24] 75 [22.86] 100 [30.48] 125 [38.10] 150 [45.72]
-025 3/4 [19.05]
5/8" [15.88] Refer to Liquid Line Table for vertical Separation 3/4" [19.05] Not allowed for any length 7/8" [22.23] Not allowed for any length
-037 3/4 [19.05]
5/8" [15.88] Refer to Liquid Line Table for vertical Separation 3/4" [19.05] Not allowed for any length 7/8" [22.23] Not allowed for any length
-049 7/8 [22.22]
5/8" [15.88] Refer to Liquid Line Table for vertical Separation 3/4" [19.05] Refer to Liquid Line Table for vertical Separation 7/8" [22.23] Refer to Liquid Line Table for vertical Separation
-061 7/8 [22.22]
3/4" [19.05] Refer to Liquid Line Table for vertical Separation 7/8" [22.23] Refer to Liquid Line Table for vertical Separation
1-1/8" [28.58] Not allowed for any length
NOTES: Using suction line larger than shown in chart will result in poor oil return and is not recommended. N/A = Application not recommended.
*Standard line size.
R-410A System
Capacity
Model
Line Size
Connection Size
(Inch I.D.) [mm]
Line Size
(Inch O.D.)
[mm]
Suction Line Size
Outdoor Unit BELOW Indoor Coil
Total Line Length—Feet [m]
25 [7.62] 50 [15.24] 75 [22.86] 100 [30.48] 125 [38.10] 150 [45.72]
-025 3/4 [19.05]
5/8" [15.88] Refer to Liquid Line Table for vertical Separation 3/4" [19.05] Refer to L.L table Not allowed for any length 7/8" [22.23] Not allowed for any length
-037 3/4 [19.05]
5/8" [15.88] Refer to Liquid Line Table for vertical Separation 3/4" [19.05] Not allowed for any length 7/8" [22.23] Not allowed for any length
-049 7/8 [22.22]
5/8" [15.88] Refer to Liquid Line Table for vertical Separation 3/4" [19.05] Refer to Liquid Line Table for vertical Separation 7/8" [22.23] Refer to Liquid Line Table for vertical Separation
-061 7/8 [22.22]
3/4" [19.05] Refer to Liquid Line Table for vertical Separation 7/8" [22.23] Refer to Liquid Line Table for vertical Separation
1-1/8" [28.58] Not allowed for any length
NOTES: Using suction line larger than shown in chart will result in poor oil return and is not recommended. N/A = Application not recommended.
*Standard line size. [ ] Designates Metric Conversions
NOTES: N/A = Application not recommended.
*Standard line size.
Air
Limited Warranty
RPRL Series
19
GENERAL TERMS OF LIMITED WARRANTY*
Rheem will furnish a replacement for any part of this product which fails in normal use and service within the applicable period stated, in accordance with the terms of the limited warranty.
*For complete details of the Limited and Conditional Warranties, including
applicable terms and conditions, contact your local contractor or the Manufacturer for a copy of the product warranty certificate.
Conditional Unit Replacement
(Registration Required)...............................Ten (10) Years
The new degree of comfort.
™
Rheem Heating, Cooling & Water Heating • P.O. Box 17010
Fort Smith, Arkansas 72917 • www.rheem.com
In keeping with its policy of continuous progress and product improvement, Rheem reserves the right to make changes without notice.
PRINTED IN U.S.A 06/12 QG FORM NO. P11-798
Rheem Canada Ltd./Ltée • 125 Edgeware Road, Unit 1
Brampton, Ontario • L6Y 0P5
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
