PROGRAMMING GUIDE V1.31
1. Unpacking
This package contains following items.
Programming Lead (See illustrated.)
•
Compact Disc (Programming software or installing wizards).
•
Programming Guide (this book).
•
1.1. System Requirements
Windows 7 32/64 bits /Vista/XP/Me/2000/98SE/95.
•
32MB of RAM.
•
2MB of available hard disk space.
•
CD –ROM Drive or internet access.
•
1.2. Installing Programming Software
Insert the compact disc into CD –ROM drive, installing wizards will
automatically guide you to install the software. If installation does not
work properly, to run setup.exe from CD –ROM drive.
1.3. Arrangement To Program
Connect the RHP530 as illustrated.
(1) Hold the power on/off button to turn the RHP530 off.
(2) Pull external spk/mic rubber out.
(3) Plug programming lead into 3.5mm earpiece.
(4) Connect end of the serial cable to PC’s serial port with 25 –9
adaptor or used USB type.
(5) Hold PTT (Push-to-talk) button and hold the power on button until
LCD shown chars.
INTERFACE CABLE AND USB –232 ARE NOT SUPPLIED AS PART OF THE
PROGRAMMING LEAD BUT ARE ADDITIONAL ACCESSORIES.
Page 1
PROGRAMMING GUIDE V1.31
2. Getting Started
2.1. Launch Programming
From the windows system, on the menu “Start” select
“Programs”, from Menu “RHP530” select “Launch Program”.
2.2. Open Saved File
On the menu “File”, select “Open”, the open window will
appear.
Select existed default setting in the appropriate box (file name
usually), then click on “Open”
2.3. Port Setting
On the “port” menu, click on “port”, tick sign show
on default Com 1. Select appropriate serial port
and click on “OK” .
2.4. Programming
Serial Number – set serial number to manage all RHP530 you
•
had. Type serial number on field as well as set auto number
increase if desired.
Program the RHP530 – click on “Programming” parameters
•
you set will write to RHP530.
Read the RHP530 – click on “Reading” to get parameters
•
from RHP530, serial number appears on filed after reading.
Page 2
PROGRAMMING GUIDE V1.31
2.5. Save As Setting
On the menu “File” click “Save as”, the Save RHP530 setting as
window will appear.
To type the filename in the appropriate box (file name
usually)., then press “Save”
IT’S RECOMMENDED TO SAVE ALL THE PROGRAMMED DATA
IN THE HARD DISK OF YOUR PC OR DISKETTE(S) IN ORDER TO
OBTAIN A PROGRAMMING ARCHIVE CONTAINING THE
DATA OF ALL THE RHP530 YOU HAVE PROGRAMMED. THIS
WILL BE USEFUL IN CASE YOUR CUSTOMER WOULD LIKE TO
ADD NEW RHP530 TO THE EXISTING NETWORK OR IF YOU
HAVE TO CREATE NEW NETWORKS WHICH HAVE SIMILAR
PROGRAMMING.
Page 3
PROGRAMMING GUIDE V1.31
3. Setting
There are many general parameters of RHP530 whereby user
can change parameter to obtain convenient operation.
Start programming software and click Setting –>General.
following dialog box appear
3.1. General Setting
3.1.1. Welcome Greetings
This option sets show defined characters after the RHP530 turns
on. To type word on field (up to 8–digit characters).
3.1.2. Power Save
This option enables power saving scale ( from 1:1/ 1:2 or 1:3).
3.1.3. Battery Low Warning
This option set battery low warning, when battery volt is below
6.5VDC, the option sounds warning tone in 30 seconds steps.
3.1.4. Tx Release Delay Time
This specifies the delay time after VOX.
3.1.5. Power ON LCD Timing Setting
This is period of time to show full patterns after power on.
3.1.6. PTT Rekey Inhibit Setting
If Tx time out timer expires, this option specifies the time,
RHP530 don’t allow to transmit during the time.
Page 4
PROGRAMMING GUIDE V1.31
Light on/off – toggles backlight on or off
4. Keys Define
Side keys (A,B,C & D), allows user to assign a function is
activated immediately.
•
VOX on/off – toggles VOX option on or off.
•
Function key – assigns this key as function key.
•
Second function – assigns this key as second function.
•
Monitor on/off – toggles monitor squelch on or off
•
Previous channel – assign this key to go back previous
•
channel
Intercom on/off – toggles intercom option on or off.
•
4.1.1. A,B,C,D Keys
4.1.2. Key Features
Bluetooth on/off – toggles Blue-Tooth option on or off
•
Bluetooth pair – execute Blue-Tooth pairing mode
•
Page 5
PROGRAMMING GUIDE V1.31
NAV Channel Step Select – the option sets frequency step on
4.2. Menu Definitions
Menu define allowed user to operate specific options in menu
list. Click on desired option in available items and select a
desired option. click on “ >> “ to add the feature for user.
Squelch Level – The option change squelch level (from 0 to 9
•
in 1 step).
VOX Level – The option is allowed to change VOX Level
•
(from 0 to 9).
TOT on/off – enable/disable the TOT(time out timer).
•
Beep On/Off– Beep sound is allowed to turn On/Off.
•
Intercom Setting on/off – enable/disable the intercom
•
feature.
Intercom Monitor on/off – enable/disable the intercom
•
monitor.
Blue-Tooth on/off – enable/disable the blue-tooth power.
•
Power Level Trim – this option trim the power level
•
DOES NOT CHANGE THIS PARAMETER WITHOUT TECHNICAL
SUPPORT.
•
NAV channel.
COM Channel Step Select – the option sets frequency step
•
on COM channel.
Hi/Low Power Setting – toggles the RF power level (High/Low)
•
Backlight Timing Setting – set backlight timing, the backlight
•
keep lighting during the time setting from 0-15 seconds in 1s
step.
Battery Save Setting – enable/disable the power saving.
•
Pause Scan Setting – select the scan type (busy/pause).
•
Side Tone Level Select – set side tone level (from 0-15 in 1
•
step).
NOAA Alert on/off – enable/disable the alert while base
•
station announce the alert.
Page 6
PROGRAMMING GUIDE V1.31
4.2.1. Power On Initialization
4.3. Scan Define
Side Tone Level– sets initial side tone level (from 1 –6 in 1
•
step).
Intercom level– sets initial intercom level (from 1 –6 in 1 step).
•
Nav frequency Step – sets frequency step in navigation
•
band, the step is from 5K,8.33K,10K,20K,25K,50K and 100KHz.
Com frequency Step –sets frequency step in communication
•
band, the step is from 5K,8.33K,10K,20K,25K,50K and 100KHz.
TOT Active – enable the Time Out Timer.
•
RHP530 will be initialized to enable when power on.
Key Beep– enables the beep sound while pressing the
•
button.
Keylocked– keypad is locked.
•
Power on frequency – sets initial frequency
•
Squelch level– sets initial squelch level (from 0 –9 in 1 step).
•
VOX level– sets initial VOX level (from 0 –5 in 1 step).
•
Beep level– sets initial beep level (from 0 –6 in 1 step).
•
Alert Output level– sets initial alert (from 1 –6 in 1 step).
•
4.3.1. Time
Scan Time– the time set a period of normal channel scan for
•
per channel
4.3.2. Scan Type
Busy Scan– the RHP530 always land on busy channel unless
•
channel free. When the channel is free, RHP530 resumes
scan after the timer expired.
Pauses Scan– the RHP530 landed on busy channel. RHP530
•
resume scan after the timer expired.
Page 7
PROGRAMMING GUIDE V1.31
4.4. Bluetooth Initialize Setting
Some parameters of blue-tooth is initialized when RHP530
power on.
Power On Blue-Tooth is On– the blue-tooth is initialized to on.
•
Pin Code– set 4 digts pair pin for pairing Blue-Tooth headset.
•
Key Define – PTT: this option switched RHP530 to transmit
•
when power on/off button of Blue-Tooth headset is pressed
once.
Save Power– enables power saving
•
WHEN SAVE POWER IS ACTIVATED, THE RECEIVING ATTACK
TIME NEED MORE TIME TO TRANSMIT.
Output level– this option sets Blue-Tooth microphone
•
sensitivity to met other Blue-Tooth headset.
Input level– this option sets Blue-Tooth speaker volume.
•
Page 8
PROGRAMMING GUIDE V1.31
Weather Channel – sets weather channel on this memory
5. Memory Setting
On the menu “Setting”, select “Memory”, Memory numbers
shown as following.
When click on desired memory number, the row is highlight
then double click in this row, the Memory initialize window
appears
•
number
THE WEATHER CHANNEL IS OPTIONAL ON MEMORY NUMBER.
PLEASE CONTACT WITH YOUR DEALER IF THE OPTION IS NOT
APPEARED.
Name – names this channel.
•
Tag – sets the channel including Tag feature.
•
Memory number – up to 99 numbers,
•
Enable – enables this memory number.
•
Frequency – sets the desired Nav/Com frequency.
•
Page 9
