REX CI2591NFA User Manual

CI2591N

................................................ .............................................

EN UPRIGHT FREEZER USER MANUAL 2
FR CONGÉLATEUR ARMOIRE NOTICE D'UTILISATION 19
DE STAND-GEFRIERGERÄT BENUTZERINFORMATION 37
ES CONGELADOR VERTICAL MANUAL DE

INSTRUCCIONES

55

www.electrolux.com

2

CONTENTS

1. SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2. CONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

3. DAILY USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

4. HELPFUL HINTS AND TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

5. CARE AND CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

6. WHAT TO DO IF… . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

7. INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

8.

NOISES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

9. TECHNICAL DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

WE’RE THINKING OF YOU

Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it
decades of professional experience and innovation. Ingenious and stylish, it has been designed
with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great
results every time.

Welcome to Electrolux.

Visit our website for:

Get usage advice, brochures, trouble shooter, service information:

www.electrolux.com

Register your product for better service:

www.electrolux.com/productregistration

Buy Accessories, Consumables and Original spare parts for your appliance:

www.electrolux.com/shop

CUSTOMER CARE AND SERVICE

We recommend the use of original spare parts.
When contacting Service, ensure that you have the following data available.
The information can be found on the rating plate. Model, PNC, Serial Number.

Warning / Caution-Safety information
General information and tips
Environmental information

Subject to change without notice.

ENGLISH 3

1.

SAFETY INSTRUCTIONS

In the interest of your safety and to ensure
the correct use, before installing and first
using the appliance, read this user manual
carefully, including its hints and warnings.
To avoid unnecessary mistakes and acci­dents, it is important to ensure that all
people using the appliance are thoroughly
familiar with its operation and safety fea­tures. Save these instructions and make
sure that they remain with the appliance if
it is moved or sold, so that everyone using
it through its life will be properly informed
on appliance use and safety.
For the safety of life and property keep
the precautions of these user's instruc­tions as the manufacturer is not responsi­ble for damages caused by omission.

1.1 Children and vulnerable
people safety

• This appliance is not intended for use
by persons (including children) with re­duced physical, sensory or mental ca­pabilities, or lack of experience and
knowledge, unless they have been giv­en supervision or instruction concerning
use of the appliance by a person re­sponsible for their safety.

Children should be supervised to en­sure that they do not play with the ap­pliance.

• Keep all packaging well away from chil­dren. There is risk of suffocation.

• If you are discarding the appliance pull
the plug out of the socket, cut the con­nection cable (as close to the appliance
as you can) and remove the door to
prevent playing children to suffer elec­tric shock or to close themselves into it.

• If this appliance featuring magnetic
door seals is to replace an older appli­ance having a spring lock (latch) on the
door or lid, be sure to make that spring
lock unusable before you discard the
old appliance. This will prevent it from
becoming a death trap for a child.

1.2 General safety

WARNING!

Keep ventilation openings, in the appli­ance enclosure or in the built-in structure,
clear of obstruction.

• The appliance is intended for keeping
foodstuff and/or beverages in a normal
household and similar applications such
as:

– staff kitchen areas in shops, offices

and other working environments;

– farm houses and by clients in hotels,

motels and other residential type en­vironments;

– bed and breakfast type environ-

ments;

– catering and similar non-retail appli-

cations.

• Do not use a mechanical device or any
artificial means to speed up the thawing
process.

• Do not use other electrical appliances
(such as ice cream makers) inside of re­frigerating appliances, unless they are
approved for this purpose by the manu­facturer.

• Do not damage the refrigerant circuit.

• The refrigerant isobutane (R600a) is
contained within the refrigerant circuit of
the appliance, a natural gas with a high
level of environmental compatibility,
which is nevertheless flammable.

During transportation and installation of
the appliance, be certain that none of
the components of the refrigerant cir­cuit become damaged.

If the refrigerant circuit should become
damaged:

– avoid open flames and sources of ig-

nition

– thoroughly ventilate the room in

which the appliance is situated

• It is dangerous to alter the specifica­tions or modify this product in any way.
Any damage to the cord may cause a
short-circuit, fire and/or electric shock.

WARNING!

Any electrical component (power
cord, plug, compressor) must be
replaced by a certified service
agent or qualified service person­nel to avoid hazard.

www.electrolux.com

4

• This appliance is heavy. Care should be

• Do not remove nor touch items from

• Avoid prolonged exposure of the appli-

• Bulb lamps (if foreseen) used in this ap-

1.3 Daily Use

• Do not put hot pot on the plastic parts

• Do not store flammable gas and liquid

• Do not place food products directly

• Frozen food must not be re-frozen once

• Store pre-packed frozen food in ac-

• Appliance's manufacturers storage rec-

• Do not place carbonated or fizzy drinks

1.

Power cord must not be length­ened.

2.

Make sure that the power plug is
not squashed or damaged by the
back of the appliance. A squashed
or damaged power plug may over­heat and cause a fire.

3.

Make sure that you can come to
the mains plug of the appliance.

4.

Do not pull the mains cable.

5.

If the power plug socket is loose,
do not insert the power plug. There
is a risk of electric shock or fire.

6.

You must not operate the appli­ance without the lamp cover (if
foreseen) of interior lighting.

taken when moving it.

the freezer compartment if your hands
are damp/wet, as this could cause skin
abrasions or frost/freezer burns.

ance to direct sunlight.

pliance are special purpose lamps se­lected for household appliances use
only. They are not suitable for house­hold room illumination.

in the appliance.

in the appliance, because they may ex­plode.

against the air outlet on the rear wall. (If
the appliance is Frost Free)

it has been thawed out.

cordance with the frozen food manu­facturer's instructions.

ommendations should be strictly ad­hered to. Refer to relevant instructions.

in the freezer compartment as it creates
pressure on the container, which may
cause it to explode, resulting in damage
to the appliance.

• Ice lollies can cause frost burns if con­sumed straight from the appliance.

1.4 Care and cleaning

• Before maintenance, switch off the ap­pliance and disconnect the mains plug
from the mains socket.

• Do not clean the appliance with metal
objects.

• Do not use sharp objects to remove
frost from the appliance. Use a plastic
scraper.

1.5 Installation

For electrical connection carefully
follow the instructions given in
specific paragraphs.

• Unpack the appliance and check if
there are damages on it. Do not con­nect the appliance if it is damaged. Re­port possible damages immediately to
the place you bought it. In that case re­tain packing.

• It is advisable to wait at least four hours
before connecting the appliance to al­low the oil to flow back in the compres­sor.

• Adequate air circulation should be
around the appliance, lacking this leads
to overheating. To achieve sufficient
ventilation follow the instructions rele­vant to installation.

• Wherever possible the back of the
product should be against a wall to
avoid touching or catching warm parts
(compressor, condenser) to prevent
possible burn.

• The appliance must not be located
close to radiators or cookers.

• Make sure that the mains plug is acces­sible after the installation of the appli­ance.

• Connect to potable water supply only (If
a water connection is foreseen).

1.6 Service

• Any electrical work required to do the
servicing of the appliance should be
carried out by a qualified electrician or
competent person.

• This product must be serviced by an
authorized Service Centre, and only
genuine spare parts must be used.

1.7 Environment Protection

This appliance does not contain
gasses which could damage the
ozone layer, in either its refrigerant
circuit or insulation materials. The
appliance shall not be discarded

2. CONTROL PANEL

1 2 3 4 5 6

ENGLISH 5

together with the urban refuse and
rubbish. The insulation foam con­tains flammable gases: the appli­ance shall be disposed according
to the applicable regulations to
obtain from your local authorities.
Avoid damaging the cooling unit,
especially at the rear near the heat
exchanger. The materials used on
this appliance marked by the sym-

are recyclable.

bol

ON/OFF button

1

Mode button

2

Display

3

Temperature colder button

4

Temperature warmer button

5

2.1 Display

A)

Alarm indicator

B)

EcoMode

C)

FastFreeze mode

D)

DrinksChill and Temperature indicator

E)

DrinksChil mode

Drink Chill button

6

It is possible to change predefined sound
of buttons to a loudly one by pressing to­gether Mode button and Temperature
colder button for some seconds. Change
is reversible.

ABCD

E

After selection of the Mode or the
Temperature button the anima-

tions
After selection of the temperature
the animation flashes for a few mi­nutes.

starts.

2.2 Switching on

To switch on the appliance do these
steps:

www.electrolux.com

6

1.

2.

3.

4.

5.

To select a different set temperature refer
to "Temperature regulation".

2.3 Switching off

To switch off the appliance do these
steps:

1.

2.

3.

2.4 Temperature regulation

The set temperature of the freezer may be
adjusted by pressing the temperature but­ton.
Set default temperature:

• -18°C for the freezer

The temperature indicator shows the set
temperature.
The set temperature will be reached with­in 24 hours.

2.5 EcoMode

For optimal food storage select the Eco­Mode .
To switch on the function:

1.

To switch off the function:

Connect the mains plug to the power
socket.

Press the ON/OFF button if the dis­play is off.

The alarm buzzer could operate after
few seconds.

To reset the alarm refer to "High tem­perature alarm".

If DEMO appears on the display, the
appliance is in demonstration mode.
Refer to "What to do if..." paragraph.

The temperature indicators show the
set default temperature.

Press the ON/OFF button for 3 sec­onds.

The display switches off.
To disconnect the appliance from the

power disconnect the mains plug
from the power socket.

After a power failure the set tem­perature remains stored.

Press the Mode button until the cor­responding icon appears.

The temperature indicator shows the
set temperature:

– for the freezer: -18°C

1.

Press the Mode button to select an­other function or nothing.

The function switches off by se­lecting a different set temperature.

2.6 FastFreeze mode

To switch on the function:

1.

Press the Mode button until the cor-

responding icon appears.
This function stops automatically after 52
hours.
To switch off the function before its auto­matic end:

1.

Press the Mode button to select an-

other function or nothing.

The function switches off by se­lecting a different freezer set tem­perature.

2.7 DrinksChill mode

The DrinksChill mode is to be used to set
an acoustic alarm at the preferred time,
useful for example when a recipe requires
to cool down a mixture for a certain peri­od of time, or when a reminder is needed
in order not to forget the bottles placed in
the freezer for fast cooling.
To switch on the function:

1.

Press the DrinkChill button.

The DrinksChill indicator appears.

The Timer shows the set value (30 mi-

nutes).

2.

Press the Temperature colder button

and Temperature warmer button to

change the Timer set value from 1 to

90 minutes.

3.

The Timer start to flash (min).
At the end of the countdown the Drinks­Chill indicator flashes and an audible
alarm sounds:

1.

Remove any drinks contained in the

freezer compartment.

2.

Press the DrinkChill button to switch

off the sound and terminate the func-

tion.
It is possible to deactivate the function at
any time during the countdown:

1.

Press the DrinkChill button.

2.

The DrinksChill indicator goes off.
It is possible to change the time during
the countdown and at the end by press-

ing the Temperature colder button and
the Temperature warmer button.

2.8 High temperature alarm

An increase in the temperature in the
freezer compartment (for example due to
an earlier power failure) is indicated by:

• flashing the alarm and freezer tempera­ture indicators

• sounding of buzzer.

To reset the alarm:

1.

Press any button.

2.

The buzzer switches off.

3.

The freezer temperature indicator
shows the highest temperature
reached for a few seconds. Then
show again the set temperature.

3. DAILY USE

ENGLISH 7

4.

The alarm indicator appears until the

normal conditions are restored.
When the alarm has returned the alarm in­dicator goes off.

2.9 Door open alarm

An acoustic alarm will sound if the door is
left open for a few minutes. The door
open alarm conditions are indicated by:

• flashing Alarm indicator

• acoustic buzzer
When normal conditions are restored
(door closed), the alarm will stop.
During the alarm, the buzzer can be
switched off by pressing any button.

3.1 Cleaning the interior

Before using the appliance for the first
time, wash the interior and all internal ac­cessories with lukewarm water and some
neutral soap so as to remove the typical
smell of a brand-new product, then dry
thoroughly.

Do not use detergents or abrasive
powders, as these will damage
the finish.

If DEMO appears on the Display, the ap­pliance is in demonstration mode: refer to
“WHAT TO DO IF...” paragraph.

3.2 Freezing fresh food

The freezer compartment is suitable for
freezing fresh food and storing frozen and
deep-frozen food for a long time.
To freeze fresh food activate the Fast
Freeze function at least 24 hours before
placing the food to be frozen in the freezer
compartment.
Place the fresh food to be frozen in the
two top compartments.
The maximum amount of food that can be
frozen in 24 hours is specified on the rat-

ing plate, a label located on the inside of
the appliance.
The freezing process lasts 24 hours: dur­ing this period do not add other food to
be frozen.
After 24 hours, when the freezing process
is completed, return to the required tem­perature (see "Temperature regulation").

3.3 Storage of frozen food

When first starting-up or after a period out
of use, before putting the products in the
compartment let the appliance run at least
2 hours on the higher settings.

In the event of accidental defrost­ing, for example due to a power
failure, if the power has been off
for longer than the value shown in
the technical characteristics chart
under "rising time", the defrosted
food must be consumed quickly
or cooked immediately and then
re-frozen (after cooling).

3.4 Thawing

Deep-frozen or frozen food, prior to being
used, can be thawed in the refrigerator
compartment or at room temperature, de­pending on the time available for this op­eration.

www.electrolux.com

8

Small pieces may even be cooked still fro­zen, directly from the freezer: in this case,
cooking will take longer.

3.5 Ice-cube production

This appliance is equipped with one or
more trays for the production of ice­cubes. Fill these trays with water, then put
them in the freezer compartment.

4. HELPFUL HINTS AND TIPS

Do not use metallic instruments to
remove the trays from the freezer.

3.6 Cold accumulators

The freezer contains at least one cold ac­cumulator which increases storage time in
the event of a power cut or breakdown.

4.1 Hints for freezing

To help you make the most of the freezing
process, here are some important hints:

• the maximum quantity of food which
can be frozen in 24 hrs. is shown on
the rating plate;

• the freezing process takes 24 hours.
No further food to be frozen should be
added during this period;

• only freeze top quality, fresh and thor­oughly cleaned, foodstuffs;

• prepare food in small portions to enable
it to be rapidly and completely frozen
and to make it possible subsequently to
thaw only the quantity required;

• wrap up the food in aluminium foil or
polythene and make sure that the
packages are airtight;

• do not allow fresh, unfrozen food to
touch food which is already frozen, thus
avoiding a rise in temperature of the lat­ter;

• lean foods store better and longer than
fatty ones; salt reduces the storage life
of food;

• water ices, if consumed immediately af­ter removal from the freezer compart­ment, can possibly cause the skin to be
freeze burnt;

• it is advisable to show the freezing in
date on each individual pack to enable
you to keep tab of the storage time.

4.2 Hints for storage of frozen

food

To obtain the best performance from this
appliance, you should:

• make sure that the commercially frozen
foodstuffs were adequately stored by
the retailer;

• be sure that frozen foodstuffs are trans­ferred from the foodstore to the freezer
in the shortest possible time;

• not open the door frequently or leave it
open longer than absolutely necessary;

• once defrosted, food deteriorates rap­idly and cannot be refrozen;

• do not exceed the storage period indi­cated by the food manufacturer.

5. CARE AND CLEANING

CAUTION!

Unplug the appliance before car­rying out any maintenance opera­tion.

This appliance contains hydrocar­bons in its cooling unit; mainte­nance and recharging must there-

fore only be carried out by author­ized technicians.

5.1 Periodic cleaning

The equipment has to be cleaned regular­ly:

• clean the inside and accessories with
lukewarm water and some neutral
soap.

• regularly check the door seals and wipe
clean to ensure they are clean and free
from debris.

• rinse and dry thoroughly.

Do not pull, move or damage any
pipes and/or cables inside the
cabinet.
Never use detergents, abrasive
powders, highly perfumed clean­ing products or wax polishes to
clean the interior as this will dam­age the surface and leave a
strong odour.

Clean the condenser (black grill) and the
compressor at the back of the appliance
with a brush. This operation will improve
the performance of the appliance and
save electricity consumption.

Take care of not to damage the
cooling system.

Many proprietary kitchen surface cleaners
contain chemicals that can attack/dam­age the plastics used in this appliance.
For this reason it is recommended that
the outer casing of this appliance is only
cleaned with warm water with a little
washing-up liquid added.

ENGLISH 9

After cleaning, reconnect the equipment
to the mains supply.

5.2 Defrosting of the freezer

The freezer compartment of this model,
on the other hand, is a "no frost" type.
This means that there is no buildup of
frost when it is in operation, neither on the
internal walls nor on the foods.
The absence of frost is due to the contin­uous circulation of cold air inside the
compartment, driven by an automatically
controlled fan.

5.3 Periods of non-operation

When the appliance is not in use for long
periods, take the following precautions:

disconnect the appliance from elec-

•

tricity supply

• remove all food

• defrost (if foreseen) and clean the appli­ance and all accessories

• leave the door/doors ajar to prevent un­pleasant smells.

If the cabinet will be kept on, ask some­body to check it once in a while to pre­vent the food inside from spoiling in case
of a power failure.

6. WHAT TO DO IF…

WARNING!

Before troubleshooting, discon­nect the mains plug from the
mains socket.
Only a qualified electrician or com­petent person must do the trou­bleshooting that is not in this man­ual.

Problem Possible cause Solution
The appliance does

not operate.

The mains plug is not con-

The appliance is switched
off.

nected to the mains sock­et correctly.

Switch on the appliance.

Connect the mains plug to
the mains socket correctly.

www.electrolux.com

10

Problem Possible cause Solution

The appliance has no

The buzzer sounds.
The Alarm light
flashing.

The door is not closed

The compressor op­erates continually.

The door is not closed

The door has been

The product temperature

The room temperature is

The FastFreeze mode is

The temperature in
the freezer is too
low.

The FastFreeze mode is

The temperature in
the freezer is too
high.

Many products are stored

Products are too near to

Upper or lower
square is shown in
the temperature dis­play.

power. There is no voltage
in the mains socket.

The temperature in the
freezer is too high.

correctly.
The temperature is not set

correctly.

correctly.

opened too frequently.

is too high.

too high.

switched on.
The temperature regulator

is not set correctly.

switched on.
The temperature regulator

is not set correctly.

at the same time.

each other.
An error has occurred in

measuring the tempera­ture

Connect a different electri­cal appliance to the mains
socket.
Contact a qualified electri­cian.

Refer to "Excessive Tem­perature Alarm".

Refer to "Door open alarm".

Set a higher temperature.

Refer to "Closing the door".

Do not keep the door open
longer than necessary.

Let the product tempera­ture decrease to room tem­perature before storage.

Decrease the room temper­ature.

Refer to "FastFreeze
mode".

Set a higher temperature.

Refer to "FastFreeze
mode".

Set a lower temperature.

Store less products at the
same time.

Store products so that
there is cold air circulation.

Call your service represen­tative (the cooling system
will continue to keep food
products cold, but temper­ature adjustment will not be
possible).

Problem Possible cause Solution
DEMO appears on

the Display.

6.1 Closing the door

1.

Clean the door gaskets.

2.

If necessary, adjust the door. Refer to
"Installation".

7. INSTALLATION

The appliance is in dem­onstration mode (DEMO).

3.

If necessary, replace the defective
door gaskets. Contact the Service
Center.

ENGLISH 11

Keep pressed approximate­ly 10sec the Mode button
since a long sound of buz­zer is heard and the Display
shut off for a short while:
appliance start works regu­larly.

7.1 Positioning

WARNING!

If you are discarding an old appli­ance that has a lock or catch on
the door, you must ensure that it
is made unusable to prevent
young children being trapped in­side.

The appliance shall have the plug
accessible after installation.

Install this appliance at a location where
the ambient temperature corresponds to
the climate class indicated on the rating
plate of the appliance:

Cli­mate
class

SN +10°C to + 32°C
N +16°C to + 32°C
ST +16°C to + 38°C

Ambient temperature

Cli-

Ambient temperature
mate
class

T +16°C to + 43°C

7.2 Electrical connection

Before plugging in, ensure that the volt­age and frequency shown on the rating
plate correspond to your domestic power
supply.
The appliance must be earthed. The pow­er supply cable plug is provided with a
contact for this purpose. If the domestic
power supply socket is not earthed, con­nect the appliance to a separate earth in
compliance with current regulations, con­sulting a qualified electrician.
The manufacturer declines all responsibili­ty if the above safety precautions are not
observed.
This appliance complies with the E.E.C.
Directives.

www.electrolux.com

12

7.3 Ventilation requirements

5 cm

min.
200 cm

2

7.4 Door reversibility

min.
200 cm

The airflow behind the appliance must be
sufficient.

2

The door of the appliance opens to the
right. If you want to open the door to the
left, follow these steps before you install
the appliance:

1.

Loosen and remove the upper pin.

2.

Remove the door.

3.

Remove the spacer.

4.

With a key, loosen the lower pin.

On the opposite side:

1.

Tighten the lower pin.

2.

Install the spacer.

3.

Install the door.

4.

Tighten the upper pin.

7.5 Installing the appliance

CAUTION!

Make sure that the mains cable
can move freely.

Do the following steps:

ENGLISH 13

If necessary cut the adhesive sealing strip
and apply it to the appliance as shown in

x

figure.

x

Install the appliance in the niche.
Push the appliance in the direction of the
arrow (1) until the upper gap cover stops
against the kitchen furniture.
Push the appliance in the direction of the
arrow (2) against the cupboard on the op-

2

posite side of the hinge.

1

4mm

44mm

Adjust the appliance in the niche.
Make sure that the distance between the
appliance and the cupboard front-edge is
44 mm.
The lower hinge cover (in the accessories
bag) makes sure that the distance be­tween the appliance and the kitchen furni­ture is correct.
Make sure that the clearance between the
appliance and the cupboard is 4 mm.
Open the door. Put the lower hinge cover
in position.

www.electrolux.com

14

Attach the appliance to the niche with 4
screws.

I

I

Remove the correct part from the hinge
cover (E). Make sure to remove the part
DX, in the case of right hinge, SX in oppo­site case.

Attach the covers (C, D) to the lugs and
the hinge holes.
Attach the hinge covers (E) to the hinge.

C

D

E

E

ENGLISH 15

Disconnect the parts (Ha), (Hb), (Hc) and
(Hd).

ca. 50 mm

ca. 50 mm

Hc

Ha

8 mm

Install the part (Ha) on the inner side of the
kitchen furniture door.

90°

21 mm

90°

21 mm

Push the part (Hc) on the part (Ha).

Open the appliance door and the kitchen
furniture door at an angle of 90°.
Insert the small square (Hb) into guide
(Ha).
Put together the appliance door and the
furniture door and mark the holes.

Hb

Ha

www.electrolux.com

16

8 mm

K

Hb

Remove the brackets and mark a dis­tance of 8 mm from the outer edge of the
door where the nail must be fitted (K).

Ha

Place the small square on the guide again
and fix it with the screws supplied.
Align the kitchen furniture door and the
appliance door by adjusting the part (Hb).

8. NOISES

There are some sounds during normal
running (compressor, refrigerant circula­tion).

Press the part (Hd) on the part (Hb).
Do a final check to make sure that:

• All screws are tightened.

• The sealing strip is attached tightly to
the cabinet.

• The door opens and closes correctly.

Hb

Hd

SSSRR

HISSS!

R!

ENGLISH 17

CLICK!

BRRR!

OK

SSSRRR!

HISSS!

SSSRRR!

HISSS!

BLUBB!

CLICK!

BRRR!

CRACK!

CLICK!

BRRR!

BLUBB!

BLUBB!

CRACK!CRACK!

www.electrolux.com

18

9. TECHNICAL DATA

Dimension of the recess
Height 1225 mm
Width 560 mm
Depth 550 mm
Rising Time 24 h
Voltage 230-240 V
Frequency 50 Hz

The technical information are situated in
the rating plate on the internal left side of
the appliance and in the energy label.

10. ENVIRONMENT CONCERNS

Recycle the materials with the symbol

. Put the packaging in applicable

containers to recycle it.
Help protect the environment and human
health and to recycle waste of electrical

and electronic appliances. Do not dispose
appliances marked with the symbol

with the household waste. Return the
product to your local recycling facility or
contact your municipal office.

FRANÇAIS 19

SOMMAIRE

1. INSTRUCTIONS DE SÉCURITÉ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

2. BANDEAU DE COMMANDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

3. UTILISATION QUOTIDIENNE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

4. CONSEILS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

5. ENTRETIEN ET NETTOYAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

6. EN CAS D'ANOMALIE DE FONCTIONNEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

7. INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

8.

BRUITS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

9. CARACTÉRISTIQUES TECHNIQUES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

NOUS PENSONS À VOUS

Merci d'avoir choisi ce produit Electrolux. Avec ce produit, vous bénéficiez de dizaines d'années
d'expérience professionnelle et d'innovation. Ingénieux et élégant, il a été conçu sur mesure pour
vous. Grâce à cet appareil, vous savez que chaque utilisation vous apportera satisfaction.

Bienvenue chez Electrolux.

Visitez notre site Internet pour :

Obtenir des conseils d'utilisation, des brochures, de l'aide, des informations :

www.electrolux.com

Enregistrer votre produit pour obtenir un meilleur service :

www.electrolux.com/productregistration

Acheter des accessoires, consommables et pièces de rechange d'origine pour votre
appareil :

www.electrolux.com/shop

SERVICE APRÈS-VENTE

N'utilisez que des pièces de rechange d'origine.
Avant de contacter le service, assurez-vous de disposer des informations suivantes :
Vous trouverez ces informations sur la plaque signalétique. Modèle, PNC, numéro de série.

Avertissement/Attention : consignes de sécurité.
Informations générales et conseils
Informations écologiques

Sous réserve de modifications.

www.electrolux.com

20

1.

INSTRUCTIONS DE SÉCURITÉ

Pour votre sécurité et garantir une utilisa­tion correcte de l'appareil, lisez attentive­ment cette notice, y compris les conseils
et avertissements, avant d'installer et
d'utiliser l'appareil pour la première fois.
Pour éviter toute erreur ou accident, veil­lez à ce que toute personne qui utilise
l'appareil connaisse bien son fonctionne­ment et ses fonctions de sécurité. Con­servez cette notice avec l'appareil. Si l'ap­pareil doit être vendu ou cédé à une autre
personne, veillez à remettre cette notice
au nouveau propriétaire, afin qu'il puisse
se familiariser avec son fonctionnement et
sa sécurité.
Pour la sécurité des personnes et des
biens, conservez et respectez les consi­gnes de sécurité figurant dans cette noti­ce. Le fabricant décline toute responsabi­lité en cas de dommages dus au non-res­pect de ces instructions.

1.1 Sécurité des enfants et des
personnes vulnérables

• Cet appareil n'est pas destiné à être
utilisé par des enfants ou des person­nes dont les capacités physiques, sen­sorielles ou mentales, ou le manque
d'expérience et de connaissance les
empêchent d'utiliser l'appareil sans ris­que lorsqu'ils sont sans surveillance ou
en l'absence d'instruction d'une per­sonne responsable qui puisse leur as­surer une utilisation de l'appareil sans
danger.

Empêchez les enfants de jouer avec
l'appareil.

• Ne laissez pas les différents emballages
à portée des enfants. Ils pourraient
s'asphyxier.

• Si l'appareil doit être mis au rebut, veil­lez à couper le câble d'alimentation
électrique au ras de l'appareil pour évi­ter les risques d'électrocution. Démon­tez la porte pour éviter que des enfants
ne restent enfermés à l'intérieur.

• Cet appareil est muni de fermetures
magnétiques. S'il remplace un appareil
équipé d'une fermeture à ressort, nous
vous conseillons de rendre celle-ci inuti­lisable avant de vous en débarrasser.
Ceci afin d'éviter aux enfants de s'en-

fermer dans l'appareil et de mettre ainsi
leur vie en danger.

1.2 Consignes générales de
sécurité

AVERTISSEMENT

Veillez à ce que les orifices de ventilation,
situés dans l'enceinte de l'appareil ou la
structure intégrée, ne soient pas obstrués.

• Les appareils sont destinés uniquement
à la conservation des aliments et/ou
des boissons dans le cadre d’un usage
domestique normal, tel que celui décrit
dans la présente notice.

– dans des cuisines réservées aux em-

ployés dans des magasins, bureaux
et autres lieux de travail ;

– dans les fermes et par les clients

dans des hôtels, motels et autres
lieux de séjour ;

– dans des hébergements de type

chambre d'hôte ;

– pour la restauration et autres utilisa-

tions non commerciales.

• N'utilisez pas d'appareils électriques,
d'agents chimiques ou tout autre systè­me artificiel pour accélérer le processus
de dégivrage.

• Ne faites pas fonctionner d'appareils
électriques (comme des sorbetières
électriques, ...) à l'intérieur des appa­reils de réfrigération à moins que cette
utilisation n'ait reçu l'agrément du fabri­cant.

• N'endommagez pas le circuit frigorifi­que.

• Le circuit frigorifique de l’appareil con­tient de l’isobutane (R600a), un gaz na­turel offrant un haut niveau de compati­bilité avec l’environnement mais qui est
néanmoins inflammable.

Pendant le transport et l'installation de
votre appareil, assurez-vous qu'aucune
partie du circuit frigorifique n'est en­dommagée.

Si le circuit frigorifique est endomma­gé :

– évitez les flammes vives et toute au-

tre source d'allumage

– aérez soigneusement la pièce où se

trouve l'appareil

• Ne modifiez pas les spécifications de
l'appareil. Si le câble d'alimentation est
endommagé, il peut causer un court
circuit, un incendie et/ou une électrocu­tion.

AVERTISSEMENT

Les éventuelles réparations ou in­terventions sur votre appareil, ain­si que le remplacement du câble
d'alimentation, ne doivent être ef­fectuées que par un professionnel
qualifié.

1.

Ne branchez pas le cordon d'ali­mentation à une rallonge.

2.

Assurez-vous que la prise n'est pas
écrasée ou endommagée par l'ar­rière de l'appareil. Une prise de
courant écrasée ou endommagée
peut s'échauffer et causer un in­cendie.

3.

Vérifiez que la prise murale de l'ap­pareil est accessible.

4.

Ne débranchez pas l'appareil en ti­rant sur le câble.

5.

Si la prise murale n'est pas bien fi­xée, n'introduisez pas de prise de­dans. Risque d'électrocution ou
d'incendie.

6.

N'utilisez pas l'appareil sans le dif­fuseur de l'ampoule (si présent) de
l'éclairage intérieur.

• Cet appareil est lourd. Faite attention
lors de son déplacement.

• Ne touchez pas avec les mains humi­des les surfaces givrées et les produits
congelés (risque de brûlure et d'arra­chement de la peau).

• Évitez une exposition prolongée de
l'appareil aux rayons solaires.

• Les ampoules (si présentes) utilisées
dans cet appareil sont des ampoules
spécifiques uniquement destinées à
être utilisées sur des appareils ména­gers. Elles ne sont pas du tout adap­tées à un éclairage quelconque d'une
habitation.

FRANÇAIS 21

1.3 Utilisation quotidienne

• Ne posez pas d'éléments chauds sur
les parties en plastique de l'appareil.

• Ne stockez pas de gaz ou de liquides
inflammables dans l'appareil (risque
d'explosion).

• Ne placez pas d'aliments directement
contre la sortie d'air sur la paroi arrière
de l'appareil. (Si l'appareil est sans gi­vre.)

• Un produit décongelé ne doit jamais
être recongelé.

• Conservez les aliments emballés con­formément aux instructions de leur fa­bricant.

• Respectez scrupuleusement les con­seils de conservation donnés par le fa­bricant de l'appareil. Consultez les ins­tructions respectives.

• Ne mettez pas de bouteilles ni de boî­tes de boissons gazeuses dans le com­partiment congélateur, car la pression
se formant à l'intérieur du contenant
pourrait le faire éclater et endommager
ainsi l'appareil.

• Ne consommez pas certains produits
tels que les bâtonnets glacés dès leur
sortie de l'appareil, car ils peuvent pro­voquer des brûlures.

1.4 Entretien et nettoyage

• Avant toute opération d'entretien, met­tez l'appareil à l'arrêt et débranchez-le.

• N'utilisez pas d'objets métalliques pour
nettoyer l'appareil.

• N'utilisez pas d'objet tranchant pour
gratter la couche de givre. N'employez
pour cela qu'une spatule en plastique.

1.5 Installation

Avant de procéder au branche­ment électrique, respectez scru­puleusement les instructions four­nies dans cette notice.

• Déballez l'appareil et vérifiez qu'il n'est
pas endommagé. Ne branchez pas
l'appareil s'il est endommagé. Signalez
immédiatement au revendeur de l'ap­pareil les dommages constatés. Dans
ce cas, gardez l'emballage.

www.electrolux.com

22

• Il est conseillé d'attendre au moins qua-

• Veillez à ce que l'air circule librement

• Placez l'appareil dos au mur pour éviter

• Placez de préférence votre appareil loin

• Assurez-vous que la prise murale reste

• Branchez à l'alimentation en eau pota-

1.6 Maintenance

• Les branchements électriques néces-

tre heures avant de brancher l'appareil
pour que le circuit frigorifique soit stabi­lisé.

autour de l'appareil pour éviter qu'il ne
surchauffe. Pour assurer une ventilation
suffisante, respectez les instructions de
la notice (chapitre Installation).

tout contact avec le compresseur et le
condenseur (risque de brûlure).

d'une source de chaleur (chauffage,
cuisson ou rayons solaires trop inten­ses).

accessible après l'installation de l'appa­reil.

ble uniquement. (Si un branchement
sur le réseau d'eau est prévu.)

saires à l'entretien de l'appareil doivent
être réalisés par un électricien qualifié
ou une personne compétente.

• Cet appareil ne doit être entretenu et
réparé que par un Service après-vente
autorisé, exclusivement avec des piè­ces d'origine.

1.7 Protection de

l'environnement

Le système frigorifique et l'isola­tion de votre appareil ne contien­nent pas de C.F.C. contribuant
ainsi à préserver l'environnement.
L'appareil ne doit pas être mis au
rebut avec les ordures ménagères
et les déchets urbains. La mousse
d'isolation contient des gaz in­flammables : l'appareil sera mis au
rebut conformément aux règle­ments applicables disponibles au­près des autorités locales. Veillez
à ne pas détériorer les circuits fri­gorifiques, notamment au niveau
du condenseur. Les matériaux uti­lisés dans cet appareil identifiés

par le symbole
bles.

sont recycla-

2. BANDEAU DE COMMANDE

1 2 3 4 5 6

Touche ON/OFF

1

Touche Mode

2

Affichage

3

Touche de diminution de la tempéra-

4

ture
Touche d'augmentation de la tempé-

5

rature

Touche Drink Chill

6

Pour augmenter le volume défini lors de
l'appui sur les touches, appuyez simulta­nément sur la touche Mode et la touche
de diminution de la température pendant
plusieurs secondes. Ce changement est
réversible.

2.1 Affichage

A)

Voyant d'alarme

B)

EcoMode

C)

Mode FastFreeze

D)

DrinksChill et indicateur de températu­re

E)

Mode DrinksChil

Après avoir sélectionné la touche
Mode ou celle de température,

l'animation
Après avoir sélectionné la tempé­rature, l'animation clignote pen­dant quelques minutes.

démarre.

2.2 Mise en marche

Pour mettre l'appareil marche, procédez
comme suit :

1.

Branchez la fiche électrique de l'ap­pareil à la prise de courant.

2.

Appuyez sur la touche ON/OFF si l'af­fichage est éteint.

3.

L'alarme sonore peut se déclencher
au bout de quelques secondes.

Pour réinitialiser l'alarme, reportez­vous au paragraphe « Alarme haute
température ».

4.

Si DEMO s'affiche, l'appareil est en
mode démonstration. Reportez-vous
au paragraphe « En cas d'anomalie
de fonctionnement ».

5.

Les indicateurs de température indi­quent la température programmée

par défaut.
Pour sélectionner une température diffé­rente, reportez-vous au paragraphe « Ré­glage de la température ».

FRANÇAIS 23

ABCD

E

2.3 Mise à l'arrêt

Pour éteindre l'appareil, procédez comme
suit :

1.

Appuyez sur la touche ON/OFF pen­dant 3 secondes.

2.

L'affichage s'éteint.

3.

Pour mettre l'appareil hors tension,
débranchez-le électriquement.

2.4 Réglage de la température

La température de consigne du congéla­teur peut être réglée en appuyant sur la
touche de température.
Réglage de la température par défaut :

• -18 °C dans le compartiment congéla­teur

L'indicateur de température indique la
température programmée.
La température programmée sera atteinte
en 24 heures.

Après une coupure de courant, la
température programmée reste
activée.

2.5 EcoMode

Pour une conservation optimale des ali­ments, sélectionnez la fonction EcoMode.
Pour activer cette fonction :

1.

Appuyez sur la touche Mode jusqu'à
ce que le symbole correspondant
s'affiche.

L'indicateur de température indique la
température programmée :

– pour le congélateur : - 18 °C

Pour désactiver cette fonction :
