Revo REHXT0550-1 Quick Installation Guide

Quick Installation Guide

REVO Elite HD

NETWORK BOX

CAMERA

Please read this manual thoroughly before use, and keep it handy for future reference.

REHXT0550-1, Quick Installation Guide

1. Description

This manual applies to the REHXT0550-1 network camera.

The Network Camera provides a network service for a progressive-scan image sensor that can be
monitored on a real-time screen regardless of distance or location. By using its dedicated program,
many users are able to access the Network Camer a at once, or a single user can monitor various
network cameras at the same time. It also enables users to play, store and retrieve a monitored image
by using a PC. All the settings and real-time monitoring screens are also provided through web access.

The Network Camera is fully featured f or security surveillance and remote monitoring needs. It is
based on a DSP compression chip, and makes it available on the network as rea l -time, full frame rate
Motion JPEG and H.264 (or MPEG-4) video streams.

The alarm input and alarm output can be used to connect various third party devices, such as door
sensors and alarm bells.

• Installation Steps
Follow these steps to install the network camera on your local network (LAN):

1. Check the package contents against the list below.

2. Connect the Network Camera. See page 3.

3. Set an IP address. See page 4.

4. Set the password. See page 5.

• Package Component

The system comes with the following components:

Network Camera unit Installation CD Installation Guide Accessory Kit

• Contents in the installation CD

1. The REHXT0550-1

2. The SmartManager User’s Manual

3. The Revo Remote Pro HD User’s Manual

4. The SmartManager Installation software

5. The Revo Remote Pro HD Installation software

Note: Check your package to make sure that you received the complete system, including all
components shown above.

User’s Manual

2

REHXT0550-1, Quick Installation Guide

3

REHXT0550-1, Quick Installation Guide

• Front View

• Rear View

NO Function Description

1 Power Adaptor Terminal Main Power, 2pin terminal, DC12V/AC24V 330mA(4.0W)

Power Indicator(Green) Indicates power input.

2

Status Indicator(Red) Indicates camera status.
Audio Input Audio Input Stereo Jack

3

Audio Output Audio Output Stereo Jack

4 Network Connector(PoE) RJ-45 port compatible with 10/100Mbps having PoE functionality.
5 Video Switch Selects Video On/Off. Set to On to output a video signal.

6 Video Output
7 Micro SD Card Slot

3pin Terminal IO Connects alarm In/Out.

8

2pin RS485 Terminal Connects PTZ device.

Connects the video output. This BNC connector provides a

1.0Vp-p/75 ohms composite video signal.
Card Slot for Micro SD. Open the protection cover with a
supported tool to insert Micro SD card.

9 Reset Button Returns the camera to factory default conditions.

NO Function

1 Focus adjustment fixing screw
2 Auto Iris lens connector

4
