Response LA9015 User Manual

Quick Guide

App name:

ResponseGPS

1

1.Insert a SIM card(not included) into the SIM card slot located under the rubber
cover beside the case of the tracker (Press the yellow button to release).

2.Charging the tracker first with AC charger or connect to other USB (Refer the

following description).

3.Turn the unit on by pressing any of the button until the green LED remains
turned on.

4.Contact your mobile service provider to obtain the APN "name" in order to view

,,

the location on the tracking website. APNs vary depending on your SIM cards
plan (i.e. pre-paid or contract)

5.Enter the following command via SMS on your the tracker to set the APN"name":
Send SMS "APN*123456*apnname" (123456 refers to the default password)

For example:
Plan: Vodafone Pre Paid
APN Name : live.vodafone.com
Send SMS: APN*123456*live.vodafone.com

If the APN Name has been entered correctly, you will receive a SMS
stating APN:live.vodafone.com (example)

6.Login to the tracking website (www.responsegps.com) using the last 7 digits
of the serial number for the username and password which is located in the
battery compartment of the tracker.

For example:
Serial number: CC2014012345678
Username: 2345678
Password: 2345678

7.Free Response GPS app is available on iTunes
and www.responsegps.com tracking platform to
easily view the current tracking location on your iOS
or Android smart phone or tablet.

Note: 4G SIM cards are acceptable to use with this device however the unit only
operates on a 2G band.
This unit requires data to be activated on your pre-paid or contract SIM card.
(Recommend order 20-30M/Month data package)

Note: The APN name needs to be entered correctly otherwise the location
may show up in China, Africa, etc.

Product Picture

Specification

2

Portable design, no installation charge
Solar panel can extend battery using time
Extra big rechargeable battery (4000 mAH)
Extra power magnetic pin & water-proof design
Auto download & configuration setting for APN & GPRS
Upload & working mode can be start / stop / controlled by SMS
App (Android? & iPhone?) / WeChat / Web / SMS / Wap locate
Built in Shock Sensor to detect car movements with shock alarm
Cell ID locate when GPS is not available (Indoor or underground)
Universal 4 GSM Band & high sensitive GPS module

Before Using

SOS Button

LED Indicator

Solar Panel

Charging Point

1.Power ON / OFF

If the tracker is powered OFF, press and hold the Button A or B or C and
release after the GREEN LED is ON, then the tracker is powered ON.
If the tracker is powered ON, press and hold the button A or B or C until
the GREEN LED flash quickly,release the button,and press the same button 3
times quickly,then the GREEN LED will turn off and the tracker will power OFF.

A B CLEDs

3

2.Install SIM card

Pulling out the long narrow rubber stopple beside the tracker, you can see
the SIM card socket, beside which, press the yellow switch button with a tool
and then the holder will come out. Pull it out and put the SIM card in the holder
and then push the holder into the tracker (Pay attention to that the SIM card
metal contact pin cannot face down to the holder), and push the long narrow
rubber stopple into the tracker to cover the SIM card socket.

SIM Room Cover

SIM Room Cover

SIM Room Cover

Note:

1) This tracker use 2G GSM network, and it upload tracking only through GPRS,
it cannot work in CDMA network or 3G(WCDMA or CDMA2000) network.
(Many 3G SIM card can use 2G GSM network, this 3G SIM card can be used
in this tracker).

2) Enable the SIM card GPRS data service, order a GPRS data package
(20-30M/month) can save data charge (Normally the tracker will use about
20M GPRS data every month)

3) Please confirm the PIN code of the SIM card is disabled.

4) Before installing or uninstalling the SIM card, please power off the tracker.

4

3.LED flash indicator

GREEN LED Flash once: GSM & GPS working well
GREEN LED Flash twice: GSM working well and no GPS signal
GREEN LED Flash three times: GSM & GPS working well but battery low
GREEN LED Flash four times: GSM working well,battery low and no GPS signal
GREEN LED ON continuously: GSM searching network
GREEN LED OFF continuously: Power off
GREEN LED Flash fast: incoming a call or sending SMS
RED LED Flash once: uploading current tracking
RED LED Flash twice: cannot upload tracking now
RED LED Flash slowly: the tracker is being charged

4.Recharge and power supply

The tracker only uses the 5V DC voltage to recharge, too high voltage or
AC voltage may damage the tracker or even cause accidents,so please check
and confirm the adapter model is suitable for this tracker.We recommend using
our OEM charger to recharge the tracker.

1)Use battery charging stand, put the CCTR-808S in the battery charging
stand,confirm the CCTR-808S charging pin is well connected to the battery
charging stand charging output pin(please refer the following diagram),and
put the battery charging stand into the AC socket(110-220V AC),the LED on
the battery charging stand will turn on to RED,it is means the it is charging,
if the LED change to Green, it means the charging is finished. The fully
charging need about 5-10 hours.

2) Use Solar Charging, Place the tracker in the sunlight, the solar battery will
recharge the tracker automatically, in the long distance transport or longtime
tracking please install the tracker in the place with sunlight, this can extend
the battery working time, but it is impossible to finished fully charging only
by solar power when working.

Note:The voltage of the charger must not be higher than 5.5V. High voltage
will damage the tracker. Please use the OEM adapter, it needs 5-10 hours to
charge the tracker fully. Place the tracker in the sunlight as far as possible
and it will extend the battery working time observably.

5

5.Low Battery Alarm:

When the tracker battery voltage is low,the GREEN LED of the tracker will
flash 3 or 4 times,and then the tracker will send battery low information SMS to
the preset phone.
Low power
Battery: 8%

6.Back to default set (Factory configuration)

Send the SMS command to the tracker can reset to the factory configuration.
The SMS command is FACTROY*123456. Please see the detail in following
description.

7.ANTENNA

The Antenna of GSM and GPS are built in the tracker. So please leave the
tracker away from big metal that will reduce the GSM and GPS signal.

8.Waterproof

The design of the tracker is IP56 level waterproof, it means the raining or
sprinkling cannot damage the tracker,but you cannot drop the tracker into water.

9.Using Condition

O

The working temperature is -20 C to 60 C, over this range the
specification cannot reach the standard level. The storage temperature can
reach to -40 C to 80 C.
