Page 1
Air outlet for connecting the air tubing
Dial for navigating and changing options
Home button for returning to the
Home screen at any time
Start/Stop button for starting therapy
Quick start guide
English
Page 2
Read your entire Lumis™ User Guide before use.
Setup
1
2
a
b
With the device on a stable level surface,
grip the retention clip on the back of the
device and pull up to open.
Note: The retention clip is shown in the open
position.
(a) Plug the power connector into the device
power inlet then (b) push down the retention
clip to secure in place.
Connect one end of the power cord into the
power supply unit and the other end into the
power outlet.
3 4
Connect the air tubing firmly to the air outlet
located on the rear of the device.
Connect the free end of the air tubing firmly
onto the assembled mask. Press Start/Stop
to begin therapy.
Lumis with HumidAir
If you have a Lumis device with HumidAir™, fill the humidifier as follows:
1
2
Open the humidifier and fill with water up to
the maximum water level mark.
Close the humidifier and insert it into the
side of the device.
Heated humidification offers relief from dryness and congestion and is designed to make therapy
more comfortable.
Page 3
Adjusting to therapy
If you are a first time user, you might need some time to get used to therapy. This is not unusual as
it takes most patients between one and two weeks to adjust to the air pressure.
Overcoming symptoms by changing comfort settings
If you are having difficulties getting used to therapy, you can use the Lumis comfort features.
• Trouble falling asleep—If you are having trouble falling asleep with high pressure, turn on Ramp
or increase Ramp Time.
• Bloated feeling—If you are experiencing a slightly bloated feeling from swallowing air, turn on
Ramp or increase Ramp Time.
• Feeling of not getting enough air—If you feel like you are not getting enough air, turn Ramp
Time to Off.
To change the Ramp Time:
3. Turn the dial
to adjust to your
preferred setting.
1. Press the dial to
enter My Options.
2. Turn the dial to
highlight Ramp
Time and then
press to select it.
4. Press the dial to
save the change.
If you have a Lumis device with HumidAir, you have more comfort features available which help
make your therapy more comfortable.
• Dry or runny nose—If you are getting a dry or runny nose, adjust the Humidity Level by turning
it up.
• Droplets of water (condensation)—If you are getting droplets of water on your nose, mask or air
tubing, adjust the Humidity Level by turning it down.
Page 4
ResMed.com
288300
Cleaning
1. Wash the air tubing in warm water using mild detergent.
Do not wash in a dishwasher or washing machine.
2. Rinse the air tubing thoroughly and allow to dry out of direct sunlight and/or heat.
3. Wipe the exterior of the device with a dry cloth.
If you have an Lumis device with HumidAir, clean the humidifier as per steps1 and 2.
Refer to your mask User Guide for detailed instructions on cleaning your mask.
Checking and replacing your parts regularly
It is important for your comfort and health that you check and replace your parts and supplies
regularly. Replacing your parts and supplies on a regular basis helps ensure you are receiving optimal
therapy and continued comfort.
Refer to your Lumis User Guide for detailed instructions on checking your device. Contact your care
provider for information on your replacement schedule.
Serial number Device number
Mask type and size Date of setup
Notes
ResMed Ltd
1 Elizabeth Macarthur Drive
Bella Vista NSW 2153 Australia
DISTRIBUTED BY
ResMed Corp 9001 Spectrum Center Boulevard San Diego CA 92123 USA
ResMed (UK) Ltd 96 Jubilee Ave Milton Park Abingdon Oxfordshire OX14 4RW UK
See www.resmed.com for other ResMed locations worldwide. For patent information, see www.resmed.com/ip.
Lumis, ClimateLine and HumidAir are trademarks of ResMed Ltd. ClimateLine is registered in U.S. Patent and Trademark Office.
© 2015 ResMed Ltd. 288300/1 2015-03
