Model
RLN16-410
GUI 16-Bit True Color
Operating System Embedded Linux OS
Max. User Access 20 Users (1 admin account & 19 user accounts); Support up to 12 simultaneous video streams (10 substreams & 2 mainstreams).
Video Input PoE IP Camera x 16
Audio Input Cameras with Built-in Mic
Decoding Resolution 5MP/4MP/3MP/1080p/720p
VGA Output 1024*768,1280*720,1280*800,1280*1024,1440*900,1920*1080p (1080p)
HDMI Output 1024*768,1280*720,1280*800,1280*1024,1440*900,1920*1080p (1080p)
Audio Output 1CH RCA (Linear, 1kΩ)
Playback Resolution 5MP/4MP/3MP/1080p/720p
Synchronous Playback 4CH
SATA Devices 1 x 3TB (2 SATA Slots)
Maximum Capacity 12TB (Maximum 4TB HDD/Port)
External HDD 1 x e-Sata
USB Connector 2 x USB 2.0
Serial Interface No
2-Way Audio (Voice Talk) No
Alarm Input/Output No
Network Interface RJ45, 10M/100M Ethernet, 16 Network Ports for IP Cameras, 1 Giga Network Port for LAN/WAN
Network Protocol HTTP, HTTPS, TCP/IP, UDP, DHCP, P2P, UPNP, RTSP, SMTP, SSL/TLS, DNS, DDNS, NTP, FTP
Mobile Device iPhone, Android Smartphones
System Upgrade USB Local Update + Client Update
Remote Software Reolink App, IE Browser, Reolink Client (Windows/Mac)
Power Supply Input 100~240V, 48V 2.5A
Consumption <10W Without HDD & PoE
Working Temperature -10°C~ + 55°C (14°F~131°F)
Working Humidity 10%~90%
Dimension (mm) 330(W) x 45(H) x 260(D)
Weight (w/o HDD/DVD±RW) 3.0 kg
General
RLK16-410B8-NVR-Kit-NVR-Specifications
System
A/V Input
A/V Output
HDD
External Interface
Network
