Renkforce RF-3174190 Operating Instructions

EZCast Wire

User’s Manual

Rev. 1.11!

Introduction

Thanks for choosing EZCast! The EZCast Wire contains the
cutting-edge EZCast technology, and firmware upgrade will be
provided accordingly in order to compatible with latest devices.
The EZCast Wire cooperates with the EZCast app, which support
iOS, Android, Mac, and Microsoft Windows. Please read the
installation guide below to setup your EZCast Wire. Happy Casting!
[e-mail]

Hardware Installation

Please follow below steps to setup EZCast Wire:

Step 1: Connect EZCast Wire to TV, Monitor, or Projector

Connect EZCast Wire into any HDMI input port on your TV, Monitor, or
Projector. If your EZCast Wire contains an VGA port, you may also use it for
VGA display.

Note: In general, the audio and video quality of HDMI port should be better than VGA port.

Step 2: Connect EZCast Wire to your device.

(a) Connect with Mac or Microsoft Windows:
Plug one end (smaller one, micro USB) of the USB cable into your EZCast
Wire and the other end of the USB cable (bigger one, USB Type-A) into your
Mac or Microsoft Windows.
(b) Connect with iOS or Android:
Plug one end (smaller one, micro USB) of the USB power cable into your

HDMI

output

VGA

output

EZCast Wire and the other end of the USB power cable (bigger one, USB
Type-A) into an external 5V1A power adapter.
Use the cable of your device (lightening for iOS, micro USB for Android) to
connect iOS/Android device and your EZCast Wire (bigger one, USB Type­A)

Step 3: Switch to the correct HDMI (VGA) source

If the HDMI (VGA) source is set correctly, you should see the EZCast Wire
setup screen as shown below.

If your TV (Monitor, Projector) does not show this screen, it usually means
you do not choose the source correctly. In your TV remote control, find the
source button, press to select the correct source.

Software Installation

Please follow below steps to download software for your devices:

(a) Mac or Microsoft Windows:

Please download software from EZCast website below
http://www.iezvu.com
Note: Supports from Windows 7/8.1, and Mac OS 10.10 and after.

(b) iOS and Android:

Please download “EZCast” from App Store(iOS) or Google play (Android).
You may also scan the QR code on TV screen for download.
Note: Supports iOS8 and above
Note: Supports Android 4.4 and above
*Note: Not all Android 4.4 devices support USB Mirror.
**Not all smartphone supports USB audio, and consequently the sound may
