Renesas RX62N User guide

User’s Manual
RX62N Group
32
Renesas Starter Kit+ User’s Manual
RENESAS MCU RX Family / RX600 Series
All information contained in these materials, including products and product specifications, represents information on the product at the time of publication and is subject to change by Renesas Electronics Corporation without notice. Please review the latest information published by Renesas Electronics Corporation through various means, including the Renesas Electronics Corporation website (http://www.renesas.com).
www.renesas.com
Rev.2.01 Nov 2011
Notice
1. All information included in this document is current as of the date this document is issued. Such information, however, is subject to change without any prior notice. Before purchasing or using any Renesas Electronics products listed herein, please confirm the latest product information with a Renesas Electronics sales office. Also, please pay regular and careful attention to additional and different information to be disclosed by Renesas Electronics such as that disclosed through our website.
2. Renesas Electronics does not assume any liability for infringement of patents, copyrights, or other intellectual property rights of third parties by or arising from the use of Renesas Electronics products or technical information described in this document. No license, express, implied or otherwise, is granted hereby under any patents, copyrights or other intellectual property rights of Renesas Electronics or others.
3. You should not alter, modify, copy, or otherwise misappropriate any Renesas Electronics product, whether in whole or in part.
4. Descriptions of circuits, software and other related information in this document are provided only to illustrate the operation of semiconductor products and application examples. You are fully responsible for the incorporation of these circuits, software, and information in the design of your equipment. Renesas Electronics assumes no responsibility for any losses incurred by you or third parties arising from the use of these circuits, software, or information.
5. When exporting the products or technology described in this document, you should comply with the applicable export control laws and regulations and follow the procedures required by such laws and regulations. You should not use Renesas Electronics products or the technology described in this document for any purpose relating to military applications or use by the military, including but not limited to the development of weapons of mass destruction. Renesas Electronics products and technology may not be used for or incorporated into any products or systems whose manufacture, use, or sale is prohibited under any applicable domestic or foreign laws or regulations.
6. Renesas Electronics has used reasonable care in preparing the information included in this document, but Renesas Electronics does not warrant that such information is error free. Renesas Electronics assumes no liability whatsoever for any damages incurred by you resulting from errors in or omissions from the information included herein.
7. Renesas Electronics products are classified according to the following three quality grades: “Standard”, “High Quality”, and “Specific”. The recommended applications for each Renesas Electronics product depends on the product’s quality grade, as indicated below. You must check the quality grade of each Renesas Electronics product before using it in a particular application. You may not use any Renesas Electronics product for any application categorized as “Specific” without the prior written consent of Renesas Electronics. Further, you may not use any Renesas Electronics product for any application for which it is not intended without the prior written consent of Renesas Electronics. Renesas Electronics shall not be in any way liable for any damages or losses incurred by you or third parties arising from the use of any Renesas Electronics product for an application categorized as “Specific” or for which the product is not intended where you have failed to obtain the prior written consent of Renesas Electronics. The quality grade of each Renesas Electronics product is “Standard” unless otherwise expressly specified in a Renesas Electronics data sheets or data books, etc.
“Standard”: Computers; office equipment; communications equipment; test and measurement equipment; audio and visual
equipment; home electronic appliances; machine tools; personal electronic equipment; and industrial robots.
“High Quality”: Transportation equipment (automobiles, trains, ships, etc.); traffic control systems; anti-disaster systems; anti-
crime systems; safety equipment; and medical equipment not specifically designed for life support.
“Specific”: Aircraft; aerospace equipment; submersible repeaters; nuclear reactor control systems; medical equipment or
systems for life support (e.g. artificial life support devices or systems), surgical implantations, or healthcare intervention (e.g. excision, etc.), and any other applications or purposes that pose a direct threat to human life.
8. You should use the Renesas Electronics products described in this document within the range specified by Renesas Electronics, especially with respect to the maximum rating, operating supply voltage range, movement power voltage range, heat radiation characteristics, installation and other product characteristics. Renesas Electronics shall have no liability for malfunctions or damages arising out of the use of Renesas Electronics products beyond such specified ranges.
9. Although Renesas Electronics endeavors to improve the quality and reliability of its products, semiconductor products have specific characteristics such as the occurrence of failure at a certain rate and malfunctions under certain use conditions. Further, Renesas Electronics products are not subject to radiation resistance design. Please be sure to implement safety measures to guard them against the possibility of physical injury, and injury or damage caused by fire in the event of the failure of a Renesas Electronics product, such as safety design for hardware and software including but not limited to redundancy, fire control and malfunction prevention, appropriate treatment for aging degradation or any other appropriate measures. Because the evaluation of microcomputer software alone is very difficult, please evaluate the safety of the final products or system manufactured by you.
10. Please contact a Renesas Electronics sales office for details as to environmental matters such as the environmental compatibility of each Renesas Electronics product. Please use Renesas Electronics products in compliance with all applicable laws and regulations that regulate the inclusion or use of controlled substances, including without limitation, the EU RoHS Directive. Renesas Electronics assumes no liability for damages or losses occurring as a result of your noncompliance with applicable laws and regulations.
11. This document may not be reproduced or duplicated, in any form, in whole or in part, without prior written consent of Renesas Electronics.
12. Please contact a Renesas Electronics sales office if you have any questions regarding the information contained in this document or Renesas Electronics products, or if you have any other inquiries.
(Note 1) “Renesas Electronics” as used in this document means Renesas Electronics Corporation and also includes its majority-
owned subsidiaries.
(Note 2) “Renesas Electronics product(s)” means any product developed or manufactured by or for Renesas Electronics.
Disclaimer
By using this Renesas Starter Kit (RSK), the user accepts the following terms:
The RSK is not guaranteed to be error free, and the entire risk as to the results and performance of the RSK is assumed by the User. The RSK is provided by Renesas on an “as is” basis without warranty of any kind whether express or implied, including but not limited to the implied warranties of satisfactory qualit y, fitness for a particular purpose, title and non-infringement of intellectual property rights with regard to the RSK. Renesas expressly disclaims all such warranties. Renesas or its affiliates shall in no event be liable for any loss of profit, loss of data, loss of contract, loss of business, damage to reputation or goodwill, any economic loss, any reprogramming or recall costs (whether the foregoing losses are direct or indirect) nor shall Renesas or its affiliates be liable for any other direct or indirect special, incidental or consequential damages arising out of or in relation to the use of this RSK, even if Renesas or its affiliates have been advised of the possibility of such damages.
Precautions
The following precautions should be observed when operating any RSK product:
This Renesas Starter Kit is only intended for use in a laboratory environment under ambient temperature and humidity conditions. A safe separation distance should be used between this and any sensitive equipment. Its use outside the laboratory, classroom, study area or similar such area invalidates conformity with the protection requirements of the Electromagnetic Compatibility Directive and could lead to prosecution.
The product generates, uses, and can radiate radio frequency energy and may cause harmful interference to radi o communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment causes harmful interference to radio or television reception, which can be determined by turning the equipment off or on, you are encouraged to try to correct the interference by one or more of the following measures;
ensure attached cables do not lie across the equipment
reorient the receiving antenna
increase the distance between the equipment and the receiver
connect the equipment into an outlet on a circuit different from that which the receiver is connected
power down the equipment when not in use
consult the dealer or an experienced radio/TV technician for help NOTE: It is recommended that wherever
possible shielded interface cables are used.
The product is potentially susceptible to certain EMC phenomena. To mitigate against them it is recommended that the following measures be undertaken;
The user is advised that mobile phones should not be used within 10m of the product when in use.
The user is advised to take ESD precautions when handling the equipment.
The Renesas Starter Kit does not represent an ideal reference design for an end product and does not fulfil the regulatory standards for an end product.
How to Use This Manual
1. Purpose and Target Readers
This manual is designed to provide the user with an understanding of the RSK hardware functionality, and electrical characteristics. It is intended for users designing sample code on the RSK platform, using the many different incorporated peripheral devices.
The manual comprises of an overview of the capabilities of the RSK product, but does not intend to be a guide to embedded programming or hardware design. Further details regarding setting up the RSK and development environment can found in the tutorial manual.
Particular attention should be paid to the precautionary notes when using the manual. These notes occur within the body of the text, at the end of each section, and in the Usage Notes section.
The revision history summarizes the locations of revisions and additions. It does not list all revisions. Refer to the text of the manual for details.
The following documents apply to the RX62N Group. Make sure to refer to the latest versions of these documents. The newest versions of the documents listed may be obtained from the Renesas Electronics Web site.
Document Type Description Document Title Document No.
User’s Manual Describes the technical details of the RSK hardware. RSK+RX62N User’s
Manual
Software Manual Describes the functionalit y of the sample code, and
its interaction with the Renesas Peripheral Driver Library (RPDL)
Tutorial Provides a guide to setting up RSK environment,
running sample code and debugging programs.
Quick Start Guide Provides simple instructions to setup the RSK and
run the first sample, on a single A4 sheet.
Schematics Full detail circuit schematics of the RSK. RSK+RX62N
Hardware Manual Provides technical details of the RX62N
microcontroller.
RSK+RX62N Software Manual
RSK+RX62N Tutorial Manual
RSK+RX62N Quick Start Guide
Schematics RSK+RX62N
Hardware Manual
REJ10J2198
REJ10J2201
REJ10J2199
REJ10J2200
RJJ99J0073
R01UH0033EJ
2. List of Abbreviations and Acronyms
Abbreviation Full Form
ADC Analogue-to-Digital Converter bps bits per second CAN Controller-Area Network CPU Central Processing Unit CRC Cyclic Redundancy Check DIP Dual In-line Package DMA Direct Memory Access DMAC Direct Memory Access Controller E1 On-chip Debugger EEPROM Electronically Erasable Programmable Read Only Memory EMC Electromagnetic Compatibility ESD Electrostatic Discharge HEW High-performance Embedded Workshop I2C Phillips™ Inter-Integrated Circuit Connection Bus IRQ Interrupt Request LCD Liquid Crystal Display LED Light Emitting Diode MCU Micro-controller Unit MTU Multifunction Timer Unit OTG On The Go™ PC Program Counter PLL Phase Locked Loop PWM Pulse Width Modulation RSK+ Renesas Starter Kit+ RSPI Renesas Serial Peripheral Interface SDRAM Synchronous Dynamic Random Access Memory SFR Special Function Register SPI Serial Peripheral Interface SRAM Static Random Access Memory TFT Thin Film Transistor UART Universal Asynchronous Receiver/Transmitter USB Universal Serial Bus
Table of Contents
1. Overview............................................................................................................................................8
1.1 Purpose...................................................................................................................................................................... 8
1.2 Features..................................................................................................................................................................... 8
2. Power Supply.....................................................................................................................................9
2.1 Requirements ............................................................................................................................................................ 9
2.2 Power-Up Behaviour................................................................................................................................................. 9
3. Board Layout ...................................................................................................................................10
3.1 Component Layout.................................................................................................................................................. 10
3.2 Board Dimensions....................................................................................................................................................11
3.3 Component Placement ............................................................................................................................................ 12
4. Connectivity..................................................................................................................................... 14
4.1 Internal RSK Connections ...................................................................................................................................... 14
4.2 Debugger Connections............................................................................................................................................ 15
5. User Circuitry...................................................................................................................................16
5.1 Reset Circuit ........................................................................................................................................................... 16
5.2 Clock Circuit........................................................................................................................................................... 16
5.3 Switches.................................................................................................................................................................. 16
5.4 LEDs....................................................................................................................................................................... 17
5.5 Potentiometer.......................................................................................................................................................... 17
5.6 Debug LCD Module ............................................................................................................................................... 17
5.7 RS232 Serial Port.................................................................................................................................................... 18
5.8 Controller-Area Network (CAN) ............................................................................................................................ 18
5.9 Ethernet................................................................................................................................................................... 19
5.10 Universal Serial Bus (USB) .................................................................................................................................... 20
5.11 Generic LCD Header .............................................................................................................................................. 21
5.12 External Bus............................................................................................................................................................ 22
5.13 Renesas Serial Peripheral Interface (RSPI)............................................................................................................. 22
5.14 I2C Bus (Inter-IC Bus) ............................................................................................................................................ 22
6. Configuration ...................................................................................................................................23
6.1 Modifying the RSK................................................................................................................................................. 23
6.2 MCU Configuration................................................................................................................................................ 23
6.3 ADC Configuration................................................................................................................................................. 24
6.4 RS232 Serial Port Configuration ............................................................................................................................ 25
6.5 CAN Configuration................................................................................................................................................. 27
6.6 External Bus Configuration .................................................................................................................................... 28
6.7 USB Configuration ................................................................................................................................................. 30
6.8 Ethernet Configuration............................................................................................................................................ 33
6.9 Multi-Function Timer Pulse Unit (MTU) Configuration ........................................................................................ 35
6.10 IRQ & General I/O Pin Configuration .................................................................................................................... 39
6.11 Power Supply Configuration................................................................................................................................... 41
6.12 Clock Configuration................................................................................................................................................ 42
6.13 External Memory Configuration ............................................................................................................................. 42
7. Headers ............................................................................................................................................44
7.1 Application Headers................................................................................................................................................ 44
7.2 Generic Headers...................................................................................................................................................... 47
8. Code Development...........................................................................................................................48
8.1 Overview................................................................................................................................................................. 48
8.2 Compiler Restrictions ............................................................................................................................................. 48
8.3 Mode Support.......................................................................................................................................................... 48
8.4 Debugging Support................................................................................................................................................. 48
8.5 Address Space......................................................................................................................................................... 49
9. Additional Information.....................................................................................................................50
RSK+RX62N REJ10J2198-0201
Rev.2.01 RENESAS STARTER KIT+
Nov 30, 2011

1. Overview

1.1 Purpose

This RSK is an evaluation tool for Renesas microcontrollers. This manual describes the technical details of the RSK hardware. The Quick Start Guide and Tutorial Manual provide details of the software installation and debugging environment.

1.2 Features

This RSK provides an evaluation of the following features:
Renesas microcontroller programming
User code debugging
User circuitry such as switches, LEDs and a potentiometer
Sample application
Sample peripheral device initialisation code
The RSK board contains all the circuitry required for microcontroller operation.
REJ10J2198-0201 Rev. 2.01 Page 8 of 54 Nov 30, 2011
RSK+RX62N 2. Power Supply

2. Power Supply

2.1 Requirements

This RSK+ is supplied with an E1 debugger. The debugger is able to power the RSK+ board with up to 200mA. When the RSK is connected to another system then that system should supply power to the RSK+. All RSK and RSK+ boards have an optional centre positive supply connector using a 2.0mm barrel power jack.
This RSK+ supports a wide range of voltage inputs, and requires specific configuration for different inputs. Details of the external power supply connections are shown in Table 2-1 below.
Connector Supply Voltages J10 Setting J11 Setting
Regulated, 5V DC Shorted Shorted PWR1
The main power supply connected to PWR1 should supply a minimum of 5W to ensure full functionality.
This RSK+ features an independent USB power supply, which allows a user to power the USB host/OTG modules from a second external power supply. Connections for the external USB power supply are detailed in Ta bl e 2- 2 below.
Connector Supply Voltages
PWR2 Regulated, 3.3V DC PWR3 Regulated, 5V DC
Unregulated, 7 to 15V DC Open Open
Table 2-1: Main Power Supply Requirements
Table 2-2: USB Power Supply Requirements
The USB power supplies connected to PWR2 and PWR3 should both supp ly a minimum of 600mA to ensure full USB host functionality. Note: The OTG module is limited to supply a maximum of 200mA when operating as host.
The RSK+ can also be powered directly from the USB VBUS, when a suitable host device is connected to the USB0 connector and the RSK+ is correctly configured (refer to §6). This will limit the current consumption of the RSK+ to 500mA (USB maximum), therefore full functionality can not be achieved whilst being powered from the USB VBUS.

2.2 Power-Up Behaviour

When the RSK+ is purchased, the RSK+ board has the ‘Release’ or stand-alone code from the example tutorial code pre-programmed into the Renesas microcontroller. On powering up the board the user LEDs will start to flash. After 200 flashes or after pressing any switch, the LEDs will flash at a rate controlled by the potentiometer.
REJ10J2198-0201 Rev. 2.01 Page 9 of 54 Nov 30, 2011
RSK+RX62N 3. Board Layout

3. Board Layout

3.1 Component Layout

Figure 3-1 below shows the top component layout of the board.
Ethernet Interface
Application HeadersEthernet Status LEDs
USB Host
USB OTG
RS232 Serial
Debug LCD Header
CAN Header
Power Jack
5V Rail LED
3.3V Rail LED DIP Switches
JA6 JA2
JA5 JA1
RX62N
Application Board Interface
SW4
User LEDsReset Switch
E1 InterfaceE20 Interface
TFT JA3
User Switches
TFT Display Header Application Board Interface
Analog Potentiometer
Figure 3-1: Board Layout
REJ10J2198-0201 Rev. 2.01 Page 10 of 54 Nov 30, 2011
RSK+RX62N 3. Board Layout

3.2 Board Dimensions

Figure 3-2 below gives the board dimensions and connector positions. All the through-hole connectors are on a common 0.1 inch grid for easy interfacing.
Ether-
net
Serial
CAN
PWR
12.0mm 3.2mm3.00mm 7.0mm 3.2mm
JA6 JA2
LCD
RES
E20
USB
USB
RX62N
J20
TFT JA3
E1 SW1 SW2 SW3
54.53mm
85.01mm
90.00mm
97.71mm
JA5 JA1
RV1
19.00mm
7.00mm
40.00mm
7.00mm
8.81mm
10.00mm
68.64mm
76.26mm
104.20mm
110.00mm
111.82mm
119.44mm
128.00mm
143.00mm
150.00mm
173.00mm
180.00mm
Figure 3-2: Board Dimensions
REJ10J2198-0201 Rev. 2.01 Page 11 of 54 Nov 30, 2011
RSK+RX62N 3. Board Layout

3.3 Component Placement

Figure 3-3 below shows placement of individual components on the top-side PCB – bottom-side component placement can be seen in Figure 3-4, overleaf. Component types and values can be looked up using the board schematics.
(3V3_PWR)
POWER1(5V_ PWR)
RES
LED0
LED1
LED2
LED3
GND4
SW1 SW2
SW3
R189
C59
E20
E1
R188
U10
R190
C58
GND3
T3
T5R20
R187
R203 R202 R199 R200 R201 R204
R193
R195 R196 R197 R198 R194
T18
R18
R17
R19
R21
R22
T4
C29
C30
C28
C27 C26
RV1
C49
R220R16
POWER2
U9
C50
L1
R323
R24
J1
R324
R25 R26 R27 R28
SW4
R219
JA3
R163
R160
R159
R162
R161
J9
R166
U7
R167
C42
R165
R164
PWR1
D1
C44
C43
D10
J10
J11
D2
C45
C46
D3
D5
C54
C55
J13
R175
R227 R226
R222
R221
R15
TFT
R139 R251 R252 R135
U2
C31
R29
R32
J2
R158
R172
R174
R173
C47
C48
U8
R176
R177
R223
U5
U3
J17
R33
RCAN
C67
R248
C96
R228
R229
JA2
R320 R321
R143
C32
R30
J3
JA1
R247
LCD
R253
R70
R69
R90
R89 R138 R112 R113 R238 R239
R97
R96
R240 R241 R235 R234 R170
J20
R87
R86
R73
R72
R75
R74
R79
R78
R254
R71
R246
U12
R93
R88 R137 R108 R109 R236 R237 R232 R233
R132 R133 R128 R129 R141
R140
R124 R125
R85 R47 R84 R81 R80 R83 R82 R77 R76
R136
T6
C65
R243
C66
R242
SERIAL
R212
R209
R210
C61
C62
C64
J14
C63
U11
R317 R316
R206
C95
GND2
Product Label
R211R205
C60
R207
R208
R217
R218
R36
R35
R37
R225 R42
R134R224
R43
R41
R91
R92
R231
R230
R95
R94
R110 R111 R106 R107
R39
R38
R40
R60
R59
R57
R58
R56
J5
J6
R213R215
JA6
R55
R54
J16
J15
R214R216
J4
C33
R34 R31
U4
R118
R116
R114
R115
R117
R119
R121R120
R64
R65
R53
R52
R51
R50
R49
J22
R310
C88
L6
C79
R290
L4
C80 C87
R306
C83
C86
X4
R122
R98
R123
R99
GND6
C76
ETHERNET
R307 R304 R305
C91 C92C93 C94
C89C90
C85
C84
U15
R301
R302
C77C78
R100
R102
R105
R101
R103
R104
T13
R274 R275
GND1
R312
LED5
(DUPLEX)
R311
R315
R314 R313
T14T16T15T17
LED4
C81
(SPEED)
C82
L5
PWR
C97
C98
3
PWR
C56
C57
2
U14
R327 C75 R328
R130 R131 R126 R127
R46 R45 R44
R12
R10
R9
C9
J23
X3
U1
C22
R11
R7R5C6
C10
R2
X1
C5R4R6
R8
X2
C8
C7
R3
JA5
T1
R191
T2
R154
R156
R155
R153
R157
GND5
R272 R273
D9
R270 R271
T12
T9
R192
T10
C70
J19
U13
C71
R257 R258
R259 R255 R256
T7
L3
/R276
R260
/R268
USB1
D7
R277
R322
T11
J12
C69
C72
J18
T8
D8
D6
L2
J21
USB0
R269
J7
J8
Figure 3-3: Top-Side Component Placement
REJ10J2198-0201 Rev. 2.01 Page 12 of 54 Nov 30, 2011
RSK+RX62N 3. Board Layout
Figure 3-4 below shows the component placement on the bottom-side of the RSK+ board.
R181
R182
C68
R250 R249
R244R245
R309
Serial Number
R303
R308
R279 R282 R280 R281
R297 R292
R296 R291
R284
R283
R300
R295
R288
R294
R287
R289 R278
R299
R298 R293
R286
R285
MAC Address
C51 C52 C53
D4
R183
R184
R185
R186
JA6 JA2
R62
R171
R169
C17
C19
C18
C16
C15
R144
C2
R23
C1
R326 R325
C74
C73
R265
R266
R267
R262 R261
R264
R263
C3 R1
C20 C21
C12
C13
C4
C25
C14
C24
C23
C11
R329
R330 R332
R14
R13
R168
R331
C40
R146 R147 R148 R149
C34
C35
C36 C37
R150 R151 R152
C38
C36
TFT
JA3
U6
R179R178
C41
R67
R180
R318
R319
R48
JA1JA5
Figure 3-4: Bottom-Side Component Placement
REJ10J2198-0201 Rev. 2.01 Page 13 of 54 Nov 30, 2011
RSK+RX62N 4. Connectivity

4. Connectivity

4.1 Internal RSK Connections

The diagram below shows the RSK+ board components and their connectivity to the MCU.
Power Jack
Application Board Headers
MCU Pin Headers
Debug LCD
E1/E20 Debug Interface
CAN
RS-232
TFT Driver
USB Function/Host/OTG
Ethernet
Optional Jacks
VCC
Mode Pins
RX62N
MCU
ADC I/O
Potentiometer
Figure 4-1: Internal RSK+ Block Diagram
Reset
IRQ
Boot Mode Switches
128Mbit SDRAM
16Kbit I2C EEPROM
16Mbit SPI Serial Flash
Reset Circuit
SW3
SW2 SW1
Switches
User LEDs
RRO R
Ethernet
GGG Y
LEDs
Power
G
RESET
G
REJ10J2198-0201 Rev. 2.01 Page 14 of 54 Nov 30, 2011
RSK+RX62N 4. Connectivity

4.2 Debugger Connections

The diagram below shows the connections between the RSK+, E1 debugger and the host PC.
User Interface
Cable
E1 Emulator
RSK+
USB Cable
Host PC
Figure 4-2: Debugger Connection Diagram
REJ10J2198-0201 Rev. 2.01 Page 15 of 54 Nov 30, 2011
RSK+RX62N 5. User Circuitry

5. User Circuitry

5.1 Reset Circuit

A reset control circuit is fitted to the RSK to generate the required reset signal, and is triggered from the RES switch. Refer to the RX62N hardware manual for details regarding the reset signal timing requirements, and the RSK+RX62N board schematics for information regarding the reset circuitry in use on the RSK.

5.2 Clock Circuit

A clock circuit is fitted to the RSK to generate the required clock signal to drive the MCU, and associated peripherals. Refer to the RX62N hardware manual for details regarding the clock signal requirements, and the RSK+RX62N board schematics for information regarding the clock circuitry in use on the RSK. Details of the oscillators fitted to the RSK are listed in Table 5-1 below.
Crystal Function Default Placement Frequency Device Package
X1 Main MCU oscillator. Fitted 12MHz HC49/4U X2 Internal RSK Testing Only Unfitted n/a n/a X3 Real time Clock Fitted 32.768kHz Encapsulated, SMT X4 Ethernet Clock Fitted 25MHz HC49/4U
Table 5-1: Oscillators

5.3 S witches

There are four switches located on the RSK+ board. The function of each switch and its connection is shown in Table 5-2. For further information regarding switch connectivity, refer to the RSK+RX62N board schematics.
Switch Function MCU Connection
RES When pressed, the microcontroller is reset. RES#, Pin H4 SW1 Connects to an IRQ input for user controls. IRQ8-A, Pin C1 SW2 Connects to an IRQ input for user controls. IRQ9-A, Pin D2 SW3/ADTRG Connects to an IRQ inp ut for user controls. The s witch is also connected
to an ATRG input, and is used to trigger AD conversions.
Table 5-2: Switch Connections
IRQ15-A/ADTRG0#, Pin C4
REJ10J2198-0201 Rev. 2.01 Page 16 of 54 Nov 30, 2011
RSK+RX62N 5. User Circuitry

5.4 LEDs

There are ten LEDs on the RSK board. The function of each LED, its colour, and its connections are shown in Table 5-3.
LED Colour Function MCU Connection
3V3_PWR Green Indicates the status of the 3.3V power rail. No connection 5V_PWR Green Indicates the status of the 5V power rail. No connection LED0 Green User operated LED. P02, Pin B1 LED1 Orange User operated LED. P03, Pin C2 LED2 Red User operated LED. P05, Pin C3 LED3 Red User operated LED. P34, Pin J4 LED4 Green Ethernet speed status LED. No connection LED5 Green Ethernet duplex status LED. No connection Built into
Ethernet con. Built into
Ethernet con.
Green Ethernet link status LED. No connection
Yellow Ethernet activity status LED. No connection
Table 5-3: LED Connections

5.5 Potentiometer

A single-turn potentiometer is connected as a potential divider to analogue input AN0, C5. The potentiometer can be used to create a voltage between AVCC and ground (by default, AVCC is connected to the board 5V supply).
The potentiometer is fitted to offer an easy method of supplying a variable analogue input to the micro controller. It does not necessarily reflect the accuracy of the controller’s ADC. Refer to the device hardware manual for further details.

5.6 Debug LCD Module

A debug LCD module is supplied with the RSK, and should be connected to the LCD header, LCD1.
Care should be taken when installing the LCD module to ensure pins are not bent or damaged. The LCD module is vulnerable to electrostatic discharge (ESD); therefore appropriate ESD protection should be used.
The debug LCD module uses a 4-bit interface to reduce pin allocation. No contrast control is provided, as this is set by a resistor supplied on the display module. Connection information for the debug LCD is provided in Ta ble 5 -4, overleaf. Connection information for the debug LCD module is provided in Table 5-4 below.
Debug LCD Header
Pin Circuit Net Name MCU Pin Pin Circuit Net Name MCU Pin
1 Ground - 2 Board_5V ­3 No Connection - 4 DLCDRS P84, Pin R9 5 R/W (Pulled to ground) - 6 DLCDE (pulled to ground) P85, Pin P9 7 No Connection - 8 No Connection ­9 No Connection - 10 No Connection ­11 DLCDD4 P94, Pin C8 12 DLCDD5 P95, Pin D8 13 DLCDD6 P96, Pin B8 14 DLCDD7 P97, Pin B9
Table 5-4: LCD Header Connections
REJ10J2198-0201 Rev. 2.01 Page 17 of 54 Nov 30, 2011
RSK+RX62N 5. User Circuitry

5.7 RS232 Serial Port

Serial port SCI2-A is connected to the standard RS232 header fitted to the RSK. Alternatively, serial port SCI1-B or SCI6-A can be connected to the RS232 transceiver by making changes to the configurations to the jumpers and option links (refer to §6). Connections between the RS232 header and the microcontroller are listed in the Table 5-5.
SCI Signal Function MCU Connection RS232 Connection
TxD2-A SCI2-A Transmit Signal. P13, Pin P5 Pin 2 RxD2-A SCI2-A Receive Signal. P12, Pin R3 Pin 3 TxD1-B SCI1-B Transmit Signal. PF0, Pin K3 Pin 8* RxD1-B SCI1-B Receive Signal. PF2, Pin L1 Pin 7* TxD6-A SCI6-A Transmit Signal. P00, Pin C1 Pin 2* RxD6-A SCI6-A Receive Signal. P01, Pin D2 Pin 3*
Table 5-5: Serial Port Connections
* This connection is a not available in the default RSK+ configuration - refer to §6 for the required modifications.

5.8 Controller-Area Network (CAN)

A CAN transceiver IC is fitted to the RSK+, and is connected to the CAN MCU peripheral. For further details regarding the CAN protocol and supported modes of operation, please refer to the RX62N hardware manual.
The connections for the CAN microcontroller signals are listed in Table 5-7 below.
CAN Signal Function MCU Connection
CTX0 CAN Data Transmission. P32, Pin J2 CRX0 CAN Data Reception. P33, Pin K1 CANEN CAN Transceiver Device Enable Control. P42, Pin A3 CANERRn CAN Error and Power Status. P43, Pin D5 CANSTBn CAN Standby Mode Control. P41, Pin D4
Table 5-6: CAN Connections
REJ10J2198-0201 Rev. 2.01 Page 18 of 54 Nov 30, 2011
RSK+RX62N 5. User Circuitry

5.9 Ethernet

When running any Ethernet software, a unique MAC address should be used. A unique Renesas allocated MAC address is attached to the RSK+RX62N PCB as a sticker, and should be always be used with this devic e ensured to ensure full compatibility when using other Renesas hardware on a common Ethernet connection.
An Ethernet controller IC is fitted to the RSK, and is connected to the Ethernet MCU peripheral. The RX62N MCU supports full duplex 10Mb/s and 100Mb/s transmission and reception. The Ethernet status LEDs (LED6 – 9) are detailed in §5.4. The connections for the Ethernet controller are listed in Table 5-7 below.
Ethernet Signal Function MCU Connection
MDIO Management data serial I/O P71, Pin K13 MDC Management serial clock P72, Pin K14 TX_CLK Transmit clock PC4, Pin P12 TX_EN Transmit enable. P80, Pin R13 TX_ER Transmit error. PC3, Pin N11 TXD0 Transmit data bit 0. P81, Pin M11 TXD1 Transmit data bit 1. P82, Pin P11 TXD2 Transmit data bit 2. PC5, Pin N10 TXD3 Transmit data bit 3. PC6, Pin M10 RX_DV Receive data valid. PC2, Pin N12 RX_ER Receive data error. P77, Pin R14 RXD0 Receive data bit 0. P75, Pin R15 RXD1 Receive data bit 1. P74, Pin N13 RXD2 Receive data bit 2. PC1, Pin P14 RXD3 Receive data bit 3. PC0, Pin M12 COL Collision detect. PC7, Pin R12 CRS Carrier sense P83, Pin R11
Table 5-7: Ethernet Connections
REJ10J2198-0201 Rev. 2.01 Page 19 of 54 Nov 30, 2011
RSK+RX62N 5. User Circuitry

5.10 Universal Serial Bus (USB)

This RSK+ device is fitted with a USB host socket (type B) and an OTG (On The Go™) socket (type AB). USB module USB0 is connected to the OTG socket, and can operate as either a host or function device. Module USB1 is connected to a dedicated host port. The connections for the USB0 module are shown in Table 5-8 below.
USB Signal Function MCU Connection
USB0_DP Positive differential data signal. USB0_DP, Pin R5* USB0_DM Negative differential data signal. USB0_DM, Pin R7* USB0_VBUS Cable monitor pin. P16, Pin P3 USB0_EXICEN OTG low-power control signal. P21, Pin R1 USB0_VBUSEN-A VBUS power supply enable P24, Pin P1 USB0_OVRCURA Over-current detection signal A. P14, Pin P4 USB0_OVRCURB Over-current detection signal B. P16, Pin P3 USB0_ID USB ID pin. P20, Pin N3 USB_DPUPE-A Positive differential data pull-up control signal. P23, Pin N2 USB_DPUPE-B Positive differential data pull-up control signal. P15, Pin N5 USB0_DPRPD Differential data pull-down control signal. P25, Pin M2 USB0_DRPD Differential data pull-down control signal. P22, Pin M3
Table 5-8: USB0 Module Connections
The connections for the USB1 module are shown in Figure 5-9 below.
USB Signal Function MCU Connection
USB1_DP Positive differential data signal. USB1_DP, Pin R8 USB1_DM Negative differential data signal. USB1_DM, Pin R7 USB1_VBUSEN-B VBUS power supply enable P17, Pin N4 USB1_OVRCURA Over-current detection signal A. P15, Pin N5
Table 5-9: USB1 Module Connections
REJ10J2198-0201 Rev. 2.01 Page 20 of 54 Nov 30, 2011
RSK+RX62N 5. User Circuitry

5.11 Generic LCD Header

This RSK+ device is fitted with a generic TFT LCD header, that allows connection to compatible Renesas LCD application boards.
The pin connections of this header are listed in Table 5-10 below.
Generic LCD Header
Pin Circuit Net Name MCU Pin Pin Circuit Net Name MCU Pin
1 5V - 2 5v ­3 3V3 - 4 3V3 ­5 No Connection - 6 No Connection ­7 B1 PD0, Pin A7 8 B2 PD1, Pin B7 9 B3 PD2, Pin A8 10 B4 PD3, Pin A9 11 B5 PD4, Pin A10 12 G0 PD5, Pin C10 13 G1 PD6, Pin B10 14 G2 PD7, Pin A12 15 G3 PE0, Pin C12 16 G4 PE1, Pin A15 17 G5 PE2, Pin B14 18 R1 PE3, Pin C13 19 R2 PE4, Pin D13 20 R3 PE5, Pin C14 21 R4 PE6, Pin C15 22 R5 PE7, Pin D14 23 EDACK P54, Pin M7 24 HSYNC P32, Pin J2 25 DOTCLK P56, Pin P7 26 LCDDEN P34, Pin J4 27 VSYNC P24, Pin P1 28 EDREQ P55, Pin M6 29 SSCK P27, Pin L2 30 SSI P30, Pin L4 31 SSO P26, Pin N1 32 SCS P50, Pin P10 33 RESET RES#, Pin H4 34 GND ­35 BACKLIGHT P93, Pin D7 36 SD_DOTCLK ­37 GND - 38 GND ­39 GND - 40 GND ­41 X_DRIVE P84, Pin P9 42 Y_DRIVE P85, Pin R9 43 X_INPUT1 P44, Pin B4 44 Y_INPUT1 P45, Pin A4 45 X_INPUT2 P46, Pin A5 46 Y_INPUT2 P47, Pin B5 47 No Connection - 48 No Connection ­49 No Connection - 50 No Connection -
Table 5-10: Generic LCD Header Connections
REJ10J2198-0201 Rev. 2.01 Page 21 of 54 Nov 30, 2011
RSK+RX62N 5. User Circuitry

5.12 External Bus

The RX62N features an external data bus, which is connected to various devices on the RSK+ board. Details of the devices connected to the external data bus are listed in Table 5-11 below. Further details of the devices connected to the external bus can be found in the board schematics.
Chip Select Device Name Device Description Address Space
CS0* JA3 Application Header FF000000h to FFFFFFFFh (16Mbytes) SDCS U5 128MBit SDRAM 08000000h to 0FFFFFFFh (128Mbytes) CS1 to CS2 - Unused 06000000h to 07FFFFFFh (16Mbytes) CS3 JA3 Application Header 05000000h to 05FFFFFFh (16Mbytes) CS4 to CS7 - Unused 01000000h to 04FFFFFFh (4 x 16Mbytes)
Table 5-11: External Bus Address Space

5.13 Renesas Serial Peripheral Interface (RSPI)

The RX62N features two Renesas Serial Peripheral Interface modules (Renesas SPI or RSPI). Ta bl e 5 -1 2 below details the connected devices, and their connections to the MCU.
RSPI Channel Slave Select Device Name Device Description
1 SSLB0 U6 Serial Flash, 16Mbits 1 SSLB1 TFT Generic LCD Header
Table 5-12: SPI Connections

5.14 I2C Bus (Inter-IC Bus)

The RX62N features two I (Electronically-Erasable Programmable Read Only Memory). Specific details of the EEPROM device and the connections can be found in the board schematics.
This device is configured to respond to the address 0x3. The first bit of the device address can be configured by modifying option links – refer to §6 for further details.
2
C (Inter-IC Bus) interface modules. I2C module 0 is connected to a 16Kbit EEPROM
REJ10J2198-0201 Rev. 2.01 Page 22 of 54 Nov 30, 2011
RSK+RX62N 6. Configuration

6. Configuration

6.1 Modifying the RSK

This section lists the option links that are used to modify the way RSK+ operates in order to access different configurations. Configurations are made by modifying link resistors or headers with movable jumpers or by configuration DIP switches
A link resistor is a 0 surface mount resistor, which is used to short or isolate parts of a circuit. Option links are listed in the following sections, detailing their function when fitted or removed. Bold, blue text indicates the default configuration that the RSK+ is supplied with. Refer to the component placement diagram (§3) to locate the option links, jumpers and DIP switches.
When removing soldered components, always ensure that the RSK is not exposed t o a soldering iron for intervals greater than 5 seconds. This is to avoid damage to nearby components mounted on the RSK.
When modifying a link resistor, always check the related option links to ensure there is no possible signal contention or short circuits. Because many of the MCU’s pins are multiplexed, some of the peripherals must be used exclusively. Refer to the RX62N hardware manual and RSK+RX62N board schematics for further information.

6.2 MCU Configuration

Table 6-1 below details the option links associated with configuring the MCU operating modes and emulator support.
Reference Link Fitted Configuration Link Removed Configuration Related Ref.
R190 Connects RESn (MCU, pin H4) to the
reset IC U10, pin 6.
R324 Connects EMLE (MCU, pin D1) to
GROUND (via R24), bypassing J1.
Table 6-1: MCU Option Links
Ta bl e 6 -2 below details the function of the jumpers associated with configuring the MCU operating modes, and
emulator support.
Reference Pin 1 Pin 2 Operating Mode Related Ref.
SW4
Reference Pin 3 Pin 4 Operating Mode Related Ref.
SW4
OFF OFF Single chip mode -
ON OFF Boot mode ­OFF ON USB boot mode ­ON ON DO NOT SET -
OFF X Big endian -
ON X Little endian -
X OFF USB boot mode bus-powered* J12, J21 X ON USB boot mode self-powered* J12, J21
Table 6-2: MCU Setting DIP Switches
x – Mode selection is irrespective of this pin changing (i.e. “Don’t care”). * To configure the device to power from the USB VBUS, see the USB configuration section (§6.7).
REJ10J2198-0201 Rev. 2.01 Page 23 of 54 Nov 30, 2011
Connects RESn (MCU, pin H4) to the reset IC U10, pin 6.
Disconnects EMLE (MCU, pin D1) from GROUND via R24. (Still connectable via J1),
-
J1
RSK+RX62N 6. Configuration
Table 6-3 below details the different configurations and functions of the MCU operating mode jumpers.
Reference Position One Position Two Position Three Related Ref.
J1* Pins 1 and 2 shorted.
Connects EMLE to Board_VCC (bypassed to GROUND via R324).
Pins 2 and 3 shorted. Connects EMLE to GROUND (bypassed by R324).
All pins open. EMLE is left to float – DO NOT SET.
R324
Table 6-3: MCU Operating Mode Jumpers
*By default, this jumper is not fitted to the RSK+. R324 is fitted by default, therefore EMLE is connected to GROUND.

6.3 ADC Configuration

Table 6-4 below details the function of the option links associated with the Analogue-to-Digital circuit.
Reference Link Fitted Configuration Link Removed Configuration Related Ref.
R16 Connects VREFL (MCU, pin B3) to
GROUND.
R17 Connects UC_VCC to VREFH (MCU,
pin B2).
R18 Connects CON_VREFH to VREFH
(MCU, pin B2)
R19 Connects AVSS (MCU, pin A1) to
GROUND.
R20 Connects AVSS (MCU, pin A1) to
CON_AVSS.
R21 Connects AVCC (MCU, pin A2) to
UC_VCC.
R22 Connects AVCC (MCU, pin A2) to
CON_AVCC.
R72 Connects AN0_ADPOT (MCU, pin C5)
to the potentiometer, RV1.
R73 Connects AN0_ADPOT (MCU, pin C5)
to header JA1, pin 9.
R74 Connects AN1_CANSTBn (MCU, pin
D4) to CAN transceiver (U12, pin 14).
R75 Connects AN1_CANSTBn (MCU, pin
D4) to header JA1, pin 10.
R76 Connects AN2_CANEN (MCU, pin A3)
to the CAN transceiver (U12, pin 6).
R77 Connects AN2_CANEN (MCU, pin A3)
to header JA1, pin 11.
R78 Connects AN3_CANERRn (MCU, pin
D5) to the CAN transceiver (U12, pin
8).
R79 Connects AN3_CANERRn (MCU, pin
D5) to the header JA1, pin 12.
Table 6-4: ADC Option Links (Continued Overleaf)
Disconnects VREFL (MCU, pin B3) from GROUND.
Disconnects UC_VCC from VREFH (MCU, pin B2).
Disconnects CON_VREFH from VREFH (MCU, pin B2)
Disconnects AVSS (MCU, pin A1) from GROUND.
Disconnects AVSS (MCU, pin A1) from CON_AVSS.
Disconnects AVCC (MCU, pin A2) from UC_VCC.
Disconnects AVCC (MCU, pin A2) from CON_AVCC.
Disconnects AN0_ADPOT (MCU, pin C5) from the potentiometer, RV1.
Disconnects AN0_ADPOT (MCU, pin C5) from header JA1, pin 9.
Disconnects AN1_CANSTBn (MCU, pin D4) from CAN transceiver (U12, pin 14).
Disconnects AN1_CANSTBn (MCU, pin D4) from header JA1, pin 10.
Disconnects AN2_CANEN (MCU, pin A3) from the CAN transceiver (U12, pin 6).
Disconnects AN2_CANEN (MCU, pin A3) from header JA1, pin 11.
Disconnects AN3_CANERRn (MCU, pin D5) from the CAN transceiver (U12, pin 8).
Disconnects AN3_CANERRn (MCU, pin D5) from the header JA1, pin
12.
R17, R18, R220
R16, R18, R220
R16, R17, R220
R20
R19, R220
R22
R21
R73
R72
R75
R74
R77
R76
R79
R78
REJ10J2198-0201 Rev. 2.01 Page 24 of 54 Nov 30, 2011
RSK+RX62N 6. Configuration
Reference Link Fitted Configuration Link Removed Configuration Related Ref.
R80 Connects AN4_XINPUT1 (MCU, pin
B4) to header TFT, pin 43.
R81 Connects AN4_XINPUT1 (MCU, pin B4)
to header JA5, pin 1.
R82 Connects AN5_YINPUT1 (MCU, pin
A4) to header TFT, pin 44).
R83 Connects AN5_YINPUT1 (MCU, pin A4)
to header JA5, pin 2.
R84 Connects AN6_XINPUT2 (MCU, pin
A5) to header TFT, pin 45.
R85 Connects AN6_XINPUT2 (MCU, pin A5)
to header JA5, pin 3.
R86 Connects AN7_YINPUT2 (MCU, pin
B5) to header TFT, pin 46.
R87 Connects AN7_YINPUT2 (MCU, pin B5)
to header JA5, pin 4.
R220 Connects VREFL (MCU, pin B3) to
CON_AVSS.
Disconnects AN4_XINPUT1 (MCU, pin B4) from header TFT, pin 43.
Disconnects AN4_XINPUT1 (MCU, pin B4) from header JA5, pin 1.
Disconnects AN5_YINPUT1 (MCU, pin A4) from header TFT, pin 44.
Disconnects AN5_YINPUT1 (MCU, pin A4) from header JA5, pin 2.
Disconnects AN6_XINPUT2 (MCU, pin A5) from header TFT, pin 45.
Disconnects AN6_XINPUT2 (MCU, pin A5) from header JA5, pin 3.
Disconnects AN7_YINPUT2 (MCU, pin B5) from header TFT, pin 46.
Disconnects AN7_YINPUT2 (MCU, pin B5) from header JA5, pin 4.
Disconnects VREFL (MCU, pin B3) from CON_AVSS.
R81
R80
R83
R82
R85
R84
R87
R86
R16, R17, R18, R20
Table 6-3: ADC Option Links (Continuation)

6.4 RS232 Serial Port Configuration

Table 6-5 below details the function of the option links associated with serial port configuration.
Reference Link Fitted Configuration Link Removed Configuration Related Ref.
R36 Connects TxD6-A_IRQ8-A (MCU, pin
C1) to the RS232 transceiver (U11, pin
12) via R217.
R39 Connects RxD6-A_IRQ9-A (MCU, pin
D2) to the RS232 transceiver (U11, pin
10) via R218.
R209 Connects T2OUT (U11, pin 8) to the
serial socket, pin 8.
R210 Connects R2IN (U11, pin 9) to the serial
socket, pin 7.
R213 Connects T1IN (U11, pin 13) to the
header JA6, pin 5.
R214 Connects R1OUT (U11, pin 15) to the
header JA6, pin 6.
R215 Connects TxD2-A (MCU, pin P5) to the
RS232 transceiver U11, pin 13 (bypassing J15).
R216 Connects RxD2-A (MCU, pin P5) to the
RS232 transceiver U11, pin 15 (bypassing J16).
Table 6-5: RS232 Serial Port Option Links (Continued Overleaf)
Disconnects TxD6-A_IRQ8-A (MCU, pin C1) from the RS232 transceiver (U11, pin 12) via R217.
Disconnects RxD6-A_IRQ9-A (MCU, pin D2) from the RS232 transceiver (U11, pin 10) via R218.
Disconnects T2OUT (U11, pin 8) from the serial socket, pin 8.
Connects R2IN (U11, pin 9) to the serial socket, pin 7.
Disconnects T1IN (U11, pin 13) from the header JA6, pin 5.
Disconnects R1OUT (U11, pin 15) from the header JA6, pin 6.
Disconnects TxD2-A (MCU, pin P5) from the RS232 transceiver U11, pin 13 (still connectable via J15).
Disconnects RxD2-A (MCU, pin P5) from the RS232 transceiver U11, pin 15 (still connectable via J16).
R35, R217
R38, R218
R217
R218
J15, R215
J16, R216
J15, R213
J16, R214
REJ10J2198-0201 Rev. 2.01 Page 25 of 54 Nov 30, 2011
RSK+RX62N 6. Configuration
Reference Link Fitted Configuration Link Removed Configuration Related Ref.
R217 Connects TxD6-A (MCU, pin C1) to the
RS232 transceiver (U11, pin 12) via R36.
R218 Connects RxD6-A (MCU, pin D2) to the
RS232 transceiver (U11, pin 12) via R39.
R221 Connects TDO_TxD1-B (MCU, pin K3)
to the header JA2, pin 6.
R222 Connects TDI_RxD1-B (MCU, pin L1)
to the header JA2, pin 8.
R223 Connects TCK_SCK1-B (MCU, pin
M1) to the header JA2, pin 10.
Disconnects TxD6-A (MCU, pin C1) from the RS232 transceiver (U11, pin 12) via R36.
Disconnects RxD6-A (MCU, pin D2) from the RS232 transceiver (U11, pin 12) via R39.
Disconnects TDO_TxD1-B (MCU, pin K3) from the header JA2, pin 6.
Disconnects TDI_RxD1-B (MCU, pin L1) from the header JA2, pin 8.
Disconnects TCK_SCK1-B (MCU, pin M1) from the header JA2, pin 10.
R36, R209
R39, R210
-
-
-
Table 6-5: RS232 Serial Port Option Links (Continuation)
Table 6-6 below details the different configurations and functions of the RS232 serial jumpers.
Reference Position One Position Two Position Three Related Ref.
J5 Pins 1 and 2 shorted.
Connects SCL0 _RxD2-A to the IIC EEPROM U7, pin 6.
J6 Pins 1 and 2 shorted.
Connects SDA0 _TxD2-A to the IIC EEPROM U7, pin 5.
J15 Pins 1 and 2 shorted.
Connects TDO _TxD1-B to the RS232 transceiver (U11, pin 13).
J16 Pins 1 and 2 shorted.
Connects TDI _RxD1-B to the RS232 transceiver (U11, pin 15).
Pins 2 and 3 shorted. Connects SCL0 _RXD2-A to the RS232 transceiver via J16.
Pins 2 and 3 shorted. Connects SDA0 _TxD2-A to the RS232 transceiver via J15.
Pins 2 and 3 shorted. Connects TxD2-A to the RS232 transceiver (U11, pin 13).
Pins 2 and 3 shorted. Connects RxD2-A to the RS232 transceiver (U11, pin 15).
All pins open. Discon­nects both lines.
All pins open. Discon­nects both lines.
All pins open. Discon­nects both lines to the RS232 transceiver (U11, pin 13).
All pins open. Discon­nects both lines to the RS232 transceiver (U11, pin 15).
J16
J15
R215
R216
Table 6-6: RS232 Serial Port Jumpers
REJ10J2198-0201 Rev. 2.01 Page 26 of 54 Nov 30, 2011
RSK+RX62N 6. Configuration

6.5 CAN Configuration

Table 6-7 below details the function of the option links associated with CAN configuration.
Reference Link Fitted Configuration Link Removed Configuration Related Ref.
R74 Connects AN1_CANSTBn (MCU, pin
D4) to CAN transceiver (U12, pin 14).
R75 Connects AN1_CANSTBn (MCU, pin
D4) to header JA1, pin 10.
R76 Connects AN2_CANEN (MCU, pin A3)
to the CAN transceiver (U12, pin 6).
R77 Connects AN2_CANEN (MCU, pin A3)
to header JA1, pin 11.
R78 Connects AN3_CANERRn (MCU, pin
D5) to the CAN transceiver (U12, pin 8).
R79 Connects AN3_CANERRn (MCU, pin
D5) to the header JA1, pin 12.
R242 Connects CTX0 (MCU, pin J2) to the
CAN transceiver U12, pin 1 (via J23).
R243 Connects CTR0 (MCU, pin K1) to the
CAN transceiver U12, pin 4.
R247 Connects WAKE (U12, pin 9) to
ground.
R248 Connects VBAT (U12, pin 10) to
Board_5V (bypassing J17).
Table 6-7: CAN Option Links
Table 6-8 below details the different configurations and functions of the CAN jumpers.
Reference Position One Position Two Position Three Related Ref.
J17* Pins 1 and 2 shorted.
Connects VBAT (U12, pin
10) to Board_5V (bypassed by R248).
J23 Pins 1 and 2 shorted.
Connects CT0X _IRQ2-A_MTIOC0C to the CAN transceiver (U12, pin 1) via R242.
Pins 2 and 3 shorted. Connects VBAT (U12, pin 10) to Unregulated_VCC.
Pins 2 and 3 shorted. Connects CT0X _IRQ2-A_MTIOC0C to header TFT, pin 24.
Table 6-8: CAN Jumpers
*By default, this jumper is not fitted to the RSK+. Therefore the default configuration is all pins open.
Disconnects AN1_CANSTBn (MCU, pin D4) from CAN transceiver (U12, pin 14).
Disconnects AN1_CANSTBn (MCU, pin D4) from header JA1, pin 10.
Disconnects AN2_CANEN (MCU, pin A3) from the CAN transceiver (U12, pin 6).
Disconnects AN2_CANEN (MCU, pin A3) from header JA1, pin 11.
Disconnects AN3_CANERRn (MCU, pin D5) from the CAN transceiver (U12, pin 8).
Disconnects AN3_CANERRn (MCU, pin D5) from the header JA1, pin
12.
Disconnects CTX0 (MCU, pin J2) from the CAN transceiver U12, pin 1 (via J23).
Disconnects CTR0 (MCU, pin K1) from the CAN transceiver U12, pin 4.
Disconnects WAKE (U12, pin 9) from ground.
Disconnects VBAT (U12, pin 10) from Board_5V (still connectable via J17).
All pins open. Discon­nects both lines.
All pins open. Discon­nects both lines.
R75
R74
R77
R76
R79
R78
J23
-
-
J17
R248
R67, R242
REJ10J2198-0201 Rev. 2.01 Page 27 of 54 Nov 30, 2011
RSK+RX62N 6. Configuration

6.6 External Bus Configuration

Table 6-9 below details the function of option links related to configuring the MCU’s external bus.
Reference Link Fitted Configuration Link Removed Configuration Related Ref.
R32 Connects OEn pin (U2, pin 19) to
GROUND, bypassing J2.
R33 Connects OEn pin (U3, pin 19) to
GROUND, bypassing J3.
R34 Connects OEn pin (U4, pin 19) to
GROUND, bypassing J4.
R88 Connects WRn_WR0n_SSLB1-A
(MCU, pin P10) to header JA3, pin 26 (via R232).
R89 Con nects WRn_WR0n_SSLB1-A (MCU,
pin 10) to header JA3, pin 48 (via R238).
R90 Connects WRn_WR0n_SSLB1-A
(MCU, pin 10) to header TFT, pin 32 (via R251).
R91 Connects EDACK0-C
_ETLINKSTA_MTIOC4B-B (MCU, pin M7) to the Ethernet transceiver U15, pin
10.
R92 Connects EDACK0-C
_ETLINKSTA_MTIOC4B-B (MCU, pin M7) to header JA2, pin 17.
R93 Connects EDACK0-C
_ETLINKSTA_MTIOC4B-B (MCU, pin M7) to headers JA6, pin 2; and TFT , pin 23.
R94 Connects EDREQ0-C
_MTIOC4D-B (MCU, pin M6) to header JA2, pin 18.
R95 Connects EDREQ0-C
_MTIOC4D-B (MCU, pin M6) to headers JA6, pin 1; and TFT, pin 28.
R96 Connects SDCSn (MCU, pin A13) to
the SDRAM module U5, pin 19 (chip select signal).
R97 Connects SDCSn (MCU, pin A13) to
header JA3, pin 28.
R106 Connects A0_MTIOC6A (MCU, pin
F14) to the external address bus.
R107 Connects A0_MTIOC6A (MCU, pin F14)
to header JA1, pin 23 (via R225).
R108 Connects A1_MTIOC6B (MCU, pin
G15) to the external address bus.
Table 6-9: External Bus Option Links (Continued Overleaf)
Disconnects OEn pin (U2, pin 19) from GROUND (still connectable via J2).
Disconnects OEn pin (U3, pin 19) from GROUND (still connectable via J3).
Disconnects OEn pin (U4, pin 19) from GROUND (still connectable via J4).
Disconnects WRn_WR0n _SSLB1-A (MCU, pin P10) from header JA3, pin 26 (via R232).
Disconnects WRn_WR0n _SSLB1-A (MCU, pin 10) from header JA3, pin 48 (via R238).
Disconnects WRn_WR0n _SSLB1-A (MCU, pin 10) from header TFT, pin 32 (via R251).
Disconnects EDACK0-C _ETLINKSTA_MTIOC4B-B (MCU, pin M7) from the Ethernet transceiver U15, pin 10.
Disconnects EDACK0-C _ETLINKSTA_MTIOC4B-B (MCU, pin M7) from header JA2, pin 17.
Disconnects EDACK0-C _ETLINKSTA_MTIOC4B-B (MCU, pin M7) from headers JA6, pin 2; and TFT , pin 23.
Disconnects EDREQ0-C _MTIOC4D-B (MCU, pin M6) from header JA2, pin 18.
Disconnects EDREQ0-C _MTIOC4D-B (MCU, pin M6) from headers JA6, pin 1; and TFT, pin
28.
Disconnects SDCSn (MCU, pin A13) from the SDRAM module U5, pin 19 (chip select signal).
Disconnects SDCSn (MCU, pin A13) from header JA3, pin 28.
Disconnects A0_MTIOC6A (MCU, pin F14) from the external address bus.
Disconnects A0_MTIOC6A (MCU, pin F14) from header JA1, pin 23 (via R225).
Disconnects A1_MTIOC6B (MCU, pin G15) from the external address bus.
J2
J3
J4
R89, R90, R232
R88, R90, R238
R88, R89, R251
R92, R93
R91, R93
R91, R93
R95
R94
R97
R96
R107
R106, R225
R109
REJ10J2198-0201 Rev. 2.01 Page 28 of 54 Nov 30, 2011
RSK+RX62N 6. Configuration
Reference Link Fitted Configuration Link Removed Configuration Related Ref.
R109 Connects A1_MTIOC6B (MCU, pin G15)
to header JA5, pin 9 (via R241).
R110 Connects A2_MTIOC6C (MCU, pin
H13) to the external address bus.
R111 Connects A2_MTIOC6C (MCU, pin H13)
to header JA5, pin 10.
R112 Connects A4_MTIOC7A (MCU, pin
H14) to the external address bus.
R113 Connects A4_MTIOC7A (MCU, pin H14)
to header JA5, pin 9 (via R240).
R124 Connects D0_POE7n (MCU, pin A7) to
external data bus.
R125 Connects D0_POE7n (MCU, pin A7) to
header JA5, pin 16.
R126 Connects D4_POE3n (MCU, pin A10)
to the external data bus.
R127 Con nects D4_POE3n (MCU, pin A10) to
header JA2, pin 24.
R128 Connects D5_MTIC5W-B (MCU, pin
C10) to the external data bus.
R129 Connects D5_MTIC5W-B (MCU, pin
C10) to header JA6, pin 16.
R130 Connects D6_MTIC5V-B (MCU, pin
B10) to the external data bus.
R131 Connects D6_MTIC5V-B (MCU, pin
B10) to header JA6, pin 15.
R132 Connects D7_MTIC5U-B (MCU, pin
A12) to the external data bus.
R133 Connects D7_MTIC5U-B (MCU, pin
A12) to header JA6, pin 14.
R143 Connects BCLK (MCU, pin R10) to the
header J20, pin 10.
R234 Connects CS0n-a (MCU, pin B11) to
header JA3, pin 45.
R235 Connects WAITn-A (MCU, pin N6) to
header JA3, pin 45.
R236 Connects WR1n (MCU, pin M8) to
header JA3, pin 47.
R237 Connects DQM1 (MCU, pin E15) to
header JA3, pin 47.
R238 Connects WR0n (MCU, pin P10) to
header TFT, pin 32 (via R89).
R239 Connects DQM1 (MCU, pin E15) to
header JA3, pin 48.
Disconnects A1_MTIOC6B (MCU, pin G15) from header JA5, pin 9 (via R241).
Disconnects A2_MTIOC6C (MCU, pin H13) from the external address bus.
Disconnects A2_MTIOC6C (MCU, pin H13) from header JA5, pin 10.
Disconnects A4_MTIOC7A (MCU, pin H14) from the external address bus.
Disconnects A4_MTIOC7A (MCU, pin H14) from header JA5, pin 9 (via R240).
Disconnects D0_POE7n (MCU, pin A7) from external data bus.
Disconnects D0_POE7n (MCU, pin A7) from header JA5, pin 16.
Disconnects D4_POE3n (MCU, pin A10) from the external data bus.
Disconnects D4_POE3n (MCU, pin A10) from header JA2, pin 24.
Disconnects D5_MTIC5W-B (MCU, pin C10) from the external data bus.
Disconnects D5_MTIC5W-B (MCU, pin C10) from header JA6, pin 16.
Disconnects D6_MTIC5V-B (MCU, pin B10) from the external data bus.
Disconnects D6_MTIC5V-B (MCU, pin B10) from header JA6, pin 15.
Disconnects D7_MTIC5U-B (MCU, pin A12) from the external data bus.
Disconnects D7_MTIC5U-B (MCU, pin A12) from header JA6, pin 14.
Disconnects BCLK (MCU, pin R10) from the header J20, pin 10.
Disconnects CS0n-a (MCU, pin B11) from header JA3, pin 45.
Disconnects WAITn-A (MCU, pin N6) from header JA3, pin 45.
Disconnects WR1n (MCU, pin M8) from header JA3, pin 47.
Disconnects DQM1 (MCU, pin E15) from header JA3, pin 47.
Disconnects WR0n (MCU, pin P10) from header TFT, pin 32 (via R89).
Disconnects DQM1 (MCU, pin E15) from header JA3, pin 48.
R108, R241
R111
R110
R113
R112, R240
R125
R124
R127
R126
R129
R128
R131
R130
R133
R132
R321
R235
R234
R237
R236
R89, R239
R238
Table 6-9: External Bus Option Links (Continuation)
REJ10J2198-0201 Rev. 2.01 Page 29 of 54 Nov 30, 2011
RSK+RX62N 6. Configuration
Table 6-10 below details the different configurations and functions of the external bus jumpers.
Reference Position One Position Two Position Three Related Ref.
J2* Pins 1 and 2 shorted.
Connects OEn (U2, pin
19) to GROUND (bypassed by R32).
J3* Pins 1 and 2 shorted.
Connects OEn (U3, pin
19) to GROUND (bypassed by R33).
J4* Pins 1 and 2 shorted.
Connects OEn (U4, pin
19) to GROUND (bypassed by R34).
All pins open. Disconnects OEn (U2, pin 19) from GROUND (still connectable via R32).
All pins open. Disconnects OEn (U3, pin 19) from GROUND (still connectable via R33).
All pins open. Disconnects OEn (U4, pin 19) from GROUND (still connectable via R34).
- R32
- R33
- R34
Table 6-10: External Bus Jumpers
*By default, this jumper is not fitted to the RSK+. Therefore the default configuration is all pins open.

6.7 USB Configuration

Table 6-11 below details the function of option links related to configuring the USB ports.
Reference Link Fitted Configuration Link Removed Configuration Related Ref.
R49 Connects USB1OVRCURA
_P15_MTIOC0B (MCU, pin N5) to USB IC U14, pin 2.
R50 Connects USB1OVRCURA_P15
_MTIOC0B (MCU, pin N5) to header TFT, pin 32.
R51 Connects USB1OVRCURA_P15
_MTIOC0B (MCU, pin N5) to header JA2, pin 9 (via R229).
R52 Connects USB1BUSEN-B
_MTIOC0B (MCU, pin N4) to USB IC U14, pin 1.
R53 Connects USB1BUSEN-B
_MTIOC0B (MCU, pin N4) to header JA6, pin 13.
R54 Connects USB0ID_TMRIO-
B_MTIOC1A (MCU, pin N3) to USB IC U13, pin 3.
R55 Connects USB0ID_TMRIO-B_MTIOC1A
(MCU, pin N3) to header JA2, pin 22.
R56 Connects USB0ID_TMRIO-B_MTIOC1A
(MCU, pin N3) to header JA2, pin 23 (via R231).
Table 6-11: USB Option Links (Continued Overleaf)
Disconnects USB1OVRCURA _P15_MTIOC0B (MCU, pin N5) from USB IC U14, pin 2.
Connects USB1OVRCURA _P15_MTIOC0B (MCU, pin N5) to header TFT, pin 32.
Connects USB1OVRCURA _P15_MTIOC0B (MCU, pin N5) to header JA2, pin 9 (via R229).
Disconnects USB1BUSEN-B _MTIOC0B (MCU, pin N4) from USB IC U14, pin 1.
Disconnects USB1BUSEN-B _MTIOC0B (MCU, pin N4) from header JA6, pin 13.
Disconnects USB0ID_TMRIO­B_MTIOC1A (MCU, pin N3) to USB IC U13, pin 3.
Disconnects USB0ID_TMRIO­B_MTIOC1A (MCU, pin N3) from header JA2, pin 22.
Disconnects USB0ID_TMRIO­B_MTIOC1A (MCU, pin N3) from header JA2, pin 23 (via R231).
R50, R51
R49, R51, R252
R49, R50, R229
R53
R52
R55, R56
R54, R55
R55, R56, R231
REJ10J2198-0201 Rev. 2.01 Page 30 of 54 Nov 30, 2011
RSK+RX62N 6. Configuration
Reference Link Fitted Configuration Link Removed Configuration Related Ref.
R57 Connects USB0EXICEN
_TMCI0-B (MCU, pin R1) to USB IC U13, pin 11.
R58 Connects USB0EXICEN
_TMCI0-B (MCU, pin R1) to JA2, pin 21.
R59 Connects USB0DRPD_TMO0 (MCU,
pin M3) to USB0_D-.
R60 Connects USB0DRPD_TMO0 (MCU, pin
M3) to header JA2, pin 19.
R62 Connects USB0VBUSEN-A
_MTIOC4A-A_MTCLKA-A (MCU, pin P1) to header JA2, pin 25.
R64 Connects USB0DPRPD
_MTCLKB-A (MCU, pin M3) to USBD0_D-.
R65 Connects USB0DPRPD
_MTCLKB-A (MCU, pin M3) to header JA2, pin 26.
R144 Connects VSS_USB (MCU, pin R6) to
GROUND.
R191 Connects VCC_USB (MCU, pin P6) to
UC_VCC.
R192 Connects VCC_USB (MCU, pin P6) to
CON_VCCUSB.
R261 Connects VCC (U13, pin 2) to
Board_VCC.
R268 Bypasses the inductor L2 on the VBUS
line from USB0.
R269 Connects GND (USB0 Connector, pin
5) to GROUND.
R276 Bypasses the inductor L3 on the
VBUS line from USB1.
R277 Connects GND (USB1 Connector, pin
4) to GROUND.
R274 Connects FLG (U14, pin 2) to
Board_VCC.
R322 Connects USB0VBUS (MCU, pin P3)
to the VBUS line from USB0, via J18 (bypasses J12).
R325 Connects 3V3USB to CON_3V3USB. Disconnects 3V3USB from
R326 Connects 3V3USB to Board_VCC. Disconnects 3V3USB from
R327 Connects 5VUSB to CON_5VUSB. Disconnects 5VUSB from
R328 Connects 5VUSB to Board_5V. Disconnects 5VUSB from Board_5V. R325, R326,
Disconnects USB0EXICEN _TMCI0-B (MCU, pin R1) to USB IC U13, pin 11.
Disconnects USB0EXICEN _TMCI0-B (MCU, pin R1) from JA2, pin 21.
Disconnects USB0DRPD _TMO0 (MCU, pin M3) from USB0_D-.
Disconnects USB0DRPD _TMO0 (MCU, pin M3) from header JA2, pin 19.
Disconnects USB0VBUSEN
-A_MTIOC4A-A_MTCLKA-A (MCU, pin P1) from header JA2, pin 25.
Disconnects USB0DPRPD _MTCLKB-A (MCU, pin M3) from USBD0_D-.
Disconnects USB0DPRPD _MTCLKB-A (MCU, pin M3) from header JA2, pin 26.
Disconnects VSS_USB (MCU, pin R6) from GROUND.
Disconnects VCC_USB (MCU, pin P6) from UC_VCC
Disconnects VCC_USB (MCU, pin P6) from CON_VCCUSB.
Disconnects VCC (U13, pin 2) to Board_VCC.
Leaves the inductor L2 on the VBUS line from USB0.
Disconnects GND (USB0 Connector, pin 5) from GROUND.
Leaves the inductor L3 on the VBUS line from USB1.
Disconnects GND (USB1 Connector, pin 4) from GROUND.
Disconnects FLG (U14, pin 2) from Board_VCC.
Disconnects USB0VBUS (MCU, pin P3) from the VBUS line from USB0, via J18 (still connectable via J12).
CON_3V3USB.
Board_VCC.
CON_5VUSB.
R58
R57
R60
R59
J22
R65
R64
R191, R192
R144, R192
R144, R191
-
L2
-
L3
-
-
J12
R326, R327, R328
R325, R327, R328
R325, R326, R327
R327
Table 6-11: USB Option Links (Continuation)
REJ10J2198-0201 Rev. 2.01 Page 31 of 54 Nov 30, 2011
RSK+RX62N 6. Configuration
Table 6-12 below details the different configurations and functions of the USB jumpers.
Reference Position One Position Two Position Three Related Ref.
J7 Pins 1 and 2 shorted.
Connects USB0OVRCURA _USB0DPUPE-B to USB0_D+.
J8 Pins 1 and 2 shorted.
Connects USB0VBUS_USB0 OVRCURB to the USB0 VBUS (via J12).
J12* Pins 1 and 2 shorted.
Connects USB0VBUS to Board VCC.
J18 Pins 1 and 2 shorted.
Connects VBUS (Connector USB0, pin 1) to USB IC U13, pin 1. [OTG Mode]
J19* Pins 1 and 2 shorted.
Connects SHDNn (U13, pin 11) to GROUND.
J21* Pins 1 and 2 shorted.
Connects VBUS (connector USB0, pin 1) to the main power supply.
J22 Pins 1 and 2 shorted.
Connects USB0VBUS EN-A_MTIOC4A-A _MTCLKA-A to USB IC U13, pin 4.
Pins 2 and 3 shorted. Connects USB0OVR CURA_USB0DPUPE-B to USB IC U13, pin 5.
Pins 2 and 3 shorted. Connects USB0VBUS _USB0OVRCURB to USB IC U13, pin 6.
Pins 2 and 3 shorted. Connects USB0VBUS to VBUS from USB0 via J18 (can be bypassed by R322)
Pins 2 and 3 shorted. Connects VBUS (Connector USB0, pin
1) to USB0VBUS (MCU, pin P3) via J8 & J12. [FUNC Mode]
All pins open. Disconnects SHDNn (U13, pin 11) from GROUND.
All pins open. Disconnects VBUS (connector USB0, pin 1) from the main power supply.
Pins 2 and 3 shorted. Connects USB0VBUS EN-A_MTIOC4A-A _MTCLKA-A to header TFT, pin 27.
All pins open. Discon­nects both lines.
All pins open. Discon­nects both lines.
All pins open. Discon­nects both lines.
All pins open. Discon­nects both lines.
- -
- J12
All pins open. Discon­nects both lines.
-
J12
J18, R322
J8, J12
R62
Table 6-12: USB Jumpers (Continued Overleaf)
*By default, this jumper is not fitted to the RSK+. Therefore the default configuration is all pins open.
REJ10J2198-0201 Rev. 2.01 Page 32 of 54 Nov 30, 2011
RSK+RX62N 6. Configuration

6.8 Ethernet Configuration

Table 6-13 below details the function of option links related to configuring the MCU’s Ethernet peripheral.
Reference Link Fitted Configuration Link Removed Configuration Related Ref.
R91 Connects EDACK0-C
_ETLINKSTA_MTIOC4B-B (MCU, pin M7) to the Ethernet transceiver U15, pin
10.
R92 Connects EDACK0-C
_ETLINKSTA_MTIOC4B-B (MCU, pin M7) to header JA2, pin 17.
R93 Connects EDACK0-C
_ETLINKSTA_MTIOC4B-B (MCU, pin M7) to headers JA6, pin 2; and TFT , pin 23.
R114 Connects ETRXDV_MTCLKE-A (MCU,
pin N12) to the Ethernet transceiver U15, pin 19 (via line buffer U4).
R115 Connects ETRXDV_MTCLKE-A (MCU,
pin N12) to header JA5, pin 17 (via line buffer U4).
R116 Connects ETTXER_MTCLKF-A (MCU,
pin N11) to the Ethernet transceiver U15, pin 1 (via line buffer U4).
R117 Connects ETTXER_MTCLKF-A (MCU,
pin N11) to header JA5, pin 18 (via line buffer U4).
R118 Connects ETTXD2_MTIC11W-A (MCU,
pin N10) to the Ethernet transceiver U15, pin 26 (via line buffer U4).
R119 Connects ETTXD2_MTIC11W-A (MCU,
pin N10) to JA5, pin 14 (via line buffer U4).
R120 Connects ETTXD3_MTIC11V-A (MCU,
pin M10) to the Ethernet transceiver U15, pin 27 (via line buffer U4).
R121 Connects ETTXD3_MTIC11V-A (MCU,
pin M10) to header JA5, pin 13 (via line buffer U4).
R122 Connects ETCOL_MTIC11U-A (MCU,
pin R12) to the Ethernet transceiver U15, pin 36.
R123 Connects ETCOL_MTIC11U-A (MCU,
pin R12) to header JA5, pin 12.
R301 Connects XTAL2 (U15, pin 13) to the
crystal X4.
R312 Connects SPEED100/PHYAD0 (U15,
pin 9) to ground.
Table 6-13: Ethernet Option Links (Continued Overleaf)
Disconnects EDACK0-C _ETLINKSTA_MTIOC4B-B (MCU, pin M7) from the Ethernet transceiver U15, pin 10.
Disconnects EDACK0-C _ETLINKSTA_MTIOC4B-B (MCU, pin M7) from header JA2, pin 17.
Disconnects EDACK0-C _ETLINKSTA_MTIOC4B-B (MCU, pin M7) from headers JA6, pin 2; and TFT , pin 23.
Disconnects ETRXDV _MTCLKE-A (MCU, pin N12) from the Ethernet transceiver U15, pin 19.
Disconnects ETRXDV _MTCLKE-A (MCU, pin N12) to header JA5, pin 17.
Disconnects ETTXER _MTCLKF-A (MCU, pin N11) from the Ethernet transceiver U15, pin 1.
Disconnects ETTXER _MTCLKF-A (MCU, pin N11) from header JA5, pin 18.
Disconnects ETTXD2 _MTIC11W-A (MCU, pin N10) from the Ethernet transceiver U15, pin 26.
Connects ETTXD2_MTIC11W-A (MCU, pin N10) to JA5, pin 14.
Disconnects ETTXD3 _MTIC11V-A (MCU, pin M10) to the Ethernet transceiver U15, pin 27.
Disconnects ETTXD3 _MTIC11V-A (MCU, pin M10) to header JA5, pin 13.
Disconnects ETCOL _MTIC11U-A (MCU, pin R12) from the Ethernet transceiver U15, pin 36.
Disconnects ETCOL _MTIC11U-A (MCU, pin R12) from header JA5, pin 12.
Disconnects XTAL2 (U15, pin 13) from the crystal X4.
Disconnects SPEED100 /PHYAD0 (U15, pin 9) from ground.
R92, R93
R91, R93
R91, R93
R115
R114
R117
R116
R119
R118
R121
R120
R123
R122
X4
-
REJ10J2198-0201 Rev. 2.01 Page 33 of 54 Nov 30, 2011
RSK+RX62N 6. Configuration
Reference Link Fitted Configuration Link Removed Configuration Related Ref.
R313 Connects LINK/PHYAD1 (U15, pin 10)
to ground.
R314 Connects ACTIVITY/PHYAD2 (U15, pin
11) to ground.
R315 Connects FDUPLEX/PHYAD3 (MCU,
pin 12) to ground.
R317 Connects CAP (connector
ETHERNET, pin 10) to GROUND.
Disconnects LINK/PHYAD1 (U15, pin 10) from ground.
Disconnects ACTIVITY /PHYAD2 (U15, pin 11) from ground.
Disconnects FDUPLEX /PHYAD3 (MCU, pin 12) FROM ground.
Disconnects CAP (connector ETHERNET, pin 10) from GROUND.
-
-
-
-
Table 6-13: Ethernet Option Links (Continuation)
REJ10J2198-0201 Rev. 2.01 Page 34 of 54 Nov 30, 2011
RSK+RX62N 6. Configuration

6.9 Multi-Function Timer Pulse Unit (MTU) Configuration

Table 6-14 to Tabl e 6 -17 on the following pages detail the function of option links related to configuring the MCU’s MTU pins.
Reference Link Fitted Configuration Link Removed Configuration Related Ref.
R33 Connects OEn pin (U3, pin 19) to
GROUND, bypassing J3.
R34 Connects OEn pin (U4, pin 19) to
GROUND, bypassing J4.
R49 Connects USB1OVRCURA
_P15_MTIOC0B (MCU, pin N5) to USB IC U14, pin 2.
R50 Connects USB1OVRCURA_P15
_MTIOC0B (MCU, pin N5) to header TFT, pin 32.
R51 Connects USB1OVRCURA_P15
_MTIOC0B (MCU, pin N5) to header JA2, pin 9 (via R229).
R52 Connects USB1BUSEN-B
_MTIOC0B (MCU, pin N4) to USB IC U14, pin 1.
R53 Connects USB1BUSEN-B
_MTIOC0B (MCU, pin N4) to header JA6, pin 13.
R54 Connects USB0ID_TMRIO-
B_MTIOC1A (MCU, pin N3) to USB IC U13, pin 3.
R55 Connects USB0ID_TMRIO-B_MTIOC1A
(MCU, pin N3) to header JA2, pin 22.
R56 Connects USB0ID_TMRIO-B_MTIOC1A
(MCU, pin N3) to header JA2, pin 23 (via R231).
R62 Connects USB0VBUSEN-A
_MTIOC4A-A_MTCLKA-A (MCU, pin P1) to header JA2, pin 25.
R64 Connects USB0DPRPD
_MTCLKB-A (MCU, pin M3) to USBD0_D-.
R65 Connects USB0DPRPD
_MTCLKB-A (MCU, pin M3) to header JA2, pin 26.
R69 Connects LED3_PO12
_LCDDEN_MTIOC0A (MCU, pin J4) to LED3 and header TFT, pin 26.
R70 Connects LED3_PO12
_LCDDEN_MTIOC0A (MCU, pin J4) to header JA2, pin 20.
Table 6-14: MTU Option Links – Part 1
Disconnects OEn pin (U3, pin 19) from GROUND (still connectable via J3).
Disconnects OEn pin (U4, pin 19) from GROUND (still connectable via J4).
Disconnects USB1OVRCURA _P15_MTIOC0B (MCU, pin N5) from USB IC U14, pin 2.
Connects USB1OVRCURA _P15_MTIOC0B (MCU, pin N5) to header TFT, pin 32.
Connects USB1OVRCURA _P15_MTIOC0B (MCU, pin N5) to header JA2, pin 9 (via R229).
Disconnects USB1BUSEN-B _MTIOC0B (MCU, pin N4) from USB IC U14, pin 1.
Disconnects USB1BUSEN-B _MTIOC0B (MCU, pin N4) from header JA6, pin 13.
Disconnects USB0ID_TMRIO­B_MTIOC1A (MCU, pin N3) to USB IC U13, pin 3.
Disconnects USB0ID_TMRIO­B_MTIOC1A (MCU, pin N3) from header JA2, pin 22.
Disconnects USB0ID_TMRIO­B_MTIOC1A (MCU, pin N3) from header JA2, pin 23 (via R231).
Disconnects USB0VBUSEN
-A_MTIOC4A-A_MTCLKA-A (MCU, pin P1) from header JA2, pin 25.
Disconnects USB0DPRPD _MTCLKB-A (MCU, pin M3) from USBD0_D-.
Disconnects USB0DPRPD _MTCLKB-A (MCU, pin M3) from header JA2, pin 26.
Disconnects LED3_PO12 _LCDDEN_MTIOC0A (MCU, pin J4) from LED3 and header TFT, pin 26.
Disconnects LED3_PO12 _LCDDEN_MTIOC0A (MCU, pin J4) from header JA2, pin 20.
J3
J4
R50, R51
R49, R51, R252
R49, R50, R229
R53
R52
R55, R56
R54, R55
R55, R56, R231
J22
R65
R64
R70. R71
R69, R71
REJ10J2198-0201 Rev. 2.01 Page 35 of 54 Nov 30, 2011
RSK+RX62N 6. Configuration
Reference Link Fitted Configuration Link Removed Configuration Related Ref.
R71 Connects LED3_PO12
_LCDDEN_MTIOC0A (MCU, pin J4) to header JA2, pin 7 (via R227).
R91 Connects EDACK0-C
_ETLINKSTA_MTIOC4B-B (MCU, pin M7) to the Ethernet transceiver U15, pin
10.
R93 Connects EDACK0-C
_ETLINKSTA_MTIOC4B-B (MCU, pin M7) to headers JA6, pin 2; and TFT , pin 23.
R98 Connects ETTXEN_MTIOC3B-B (MCU,
pin R13) to the Ethernet transceiver U15, pin 6.
R99 Connects ETTXEN_MTIOC3B-B (MCU,
pin R13) to header JA2, pin 13.
R100 Connects ETTXD0_MTIOC3D-B (MCU,
pin M11) to the Ethernet transceiver U15, pin 23.
R101 Connects ETTXD0_MTIOC3D-B (MCU,
pin M11) to header JA2, pin 14.
R102 Connects ETTXD1_MTIOC4A-B (MCU,
pin P11) to the Ethernet transceiver U15, pin 24.
R103 Connects ETTXD1_MTIOC4A-B (MCU,
pin P11) to header JA2, pin 15.
R104 Connects ETCRS_MTIOC4C-B (MCU,
pin R11) to the Ethernet transceiver U15, pin 3.
R105 Connects ETCRS_MTIOC4C-B (MCU,
pin R11) to header JA2, pin 16.
R106 Connects A0_MTIOC6A (MCU, pin
F14) to the external address bus.
R107 Connects A0_MTIOC6A (MCU, pin F14)
to header JA1, pin 23 (via R225).
R108 Connects A1_MTIOC6B (MCU, pin
G15) to the external address bus.
R109 Connects A1_MTIOC6B (MCU, pin G15)
to header JA5, pin 9 (via R241).
R110 Connects A2_MTIOC6C (MCU, pin
H13) to the external address bus.
R111 Connects A2_MTIOC6C (MCU, pin H13)
to header JA5, pin 10.
R112 Connects A4_MTIOC7A (MCU, pin
H14) to the external address bus.
Disconnects LED3_PO12 _LCDDEN_MTIOC0A (MCU, pin J4) from header JA2, pin 7 (via R227).
Disconnects EDACK0-C _ETLINKSTA_MTIOC4B-B (MCU, pin M7) from the Ethernet transceiver U15, pin 10.
Disconnects EDACK0-C _ETLINKSTA_MTIOC4B-B (MCU, pin M7) from headers JA6, pin 2; and TFT , pin 23.
Disconnects ETTXEN _MTIOC3B-B (MCU, pin R13) from the Ethernet transceiver U15, pin 6.
Disconnects ETTXEN _MTIOC3B-B (MCU, pin R13) from header JA2, pin 13.
Disconnects ETTXD0 _MTIOC3D-B (MCU, pin M11) from the Ethernet transceiver U15, pin 23.
Disconnects ETTXD0 _MTIOC3D-B (MCU, pin M11) from header JA2, pin 14.
Connects ETTXD1_MTIOC4A-B (MCU, pin P11) to the Ethernet transceiver U15, pin 24.
Connects ETTXD1 _MTIOC4A-B (MCU, pin P11) to header JA2, pin 15.
Disconnects ETCRS _MTIOC4C-B (MCU, pin R11) from the Ethernet transceiver U15, pin 3.
Disconnects ETCRS _MTIOC4C-B (MCU, pin R11) from header JA2, pin 16.
Disconnects A0_MTIOC6A (MCU, pin F14) from the external address bus.
Disconnects A0_MTIOC6A (MCU, pin F14) from header JA1, pin 23 (via R225).
Disconnects A1_MTIOC6B (MCU, pin G15) from the external address bus.
Disconnects A1_MTIOC6B (MCU, pin G15) from header JA5, pin 9 (via R241).
Disconnects A2_MTIOC6C (MCU, pin H13) from the external address bus.
Disconnects A2_MTIOC6C (MCU, pin H13) from header JA5, pin 10.
Disconnects A4_MTIOC7A (MCU, pin H14) from the external address bus.
R69, R70, R227
R92, R93
R91, R93
R99
R98
R101
R100
R103
R102
R105
R104
R107
R106, R225
R109
R108, R241
R111
R110
R113
Table 6-15: MTU Option Links – Part 2
REJ10J2198-0201 Rev. 2.01 Page 36 of 54 Nov 30, 2011
RSK+RX62N 6. Configuration
Reference Link Fitted Configuration Link Removed Configuration Related Ref.
R113 Connects A4_MTIOC7A (MCU, pin H14)
to header JA5, pin 9 (via R240).
R114 Connects ETRXDV_MTCLKE-A (MCU,
pin N12) to the Ethernet transceiver U15, pin 19 (via line buffer U4).
R115 Connects ETRXDV_MTCLKE-A (MCU,
pin N12) to header JA5, pin 17 (via line buffer U4).
R92 Connects EDACK0-C
_ETLINKSTA_MTIOC4B-B (MCU, pin M7) to header JA2, pin 17.
R116 Connects ETTXER_MTCLKF-A (MCU,
pin N11) to the Ethernet transceiver U15, pin 1 (via line buffer U4).
R117 Connects ETTXER_MTCLKF-A (MCU,
pin N11) to header JA5, pin 18 (via line buffer U4).
R118 Connects ETTXD2_MTIC11W-A (MCU,
pin N10) to the Ethernet transceiver U15, pin 26 (via line buffer U4).
R119 Connects ETTXD2_MTIC11W-A (MCU,
pin N10) to JA5, pin 14 (via line buffer U4).
R120 Connects ETTXD3_MTIC11V-A (MCU,
pin M10) to the Ethernet transceiver U15, pin 27 (via line buffer U4).
R121 Connects ETTXD3_MTIC11V-A (MCU,
pin M10) to header JA5, pin 13 (via line buffer U4).
R122 Connects ETCOL_MTIC11U-A (MCU,
pin R12) to the Ethernet transceiver U15, pin 36.
R123 Connects ETCOL_MTIC11U-A (MCU,
pin R12) to header JA5, pin 12.
R128 Connects D5_MTIC5W-B (MCU, pin
C10) to the external data bus.
R129 Connects D5_MTIC5W-B (MCU, pin
C10) to header JA6, pin 16.
R130 Connects D6_MTIC5V-B (MCU, pin
B10) to the external data bus.
R131 Connects D6_MTIC5V-B (MCU, pin
B10) to header JA6, pin 15.
R132 Connects D7_MTIC5U-B (MCU, pin
A12) to the external data bus.
R133 Connects D7_MTIC5U-B (MCU, pin
A12) to header JA6, pin 14.
R224 Connects IRQ10-A (MCU, pin B1) to
header JA1, pin 23 (via R42).
Disconnects A4_MTIOC7A (MCU, pin H14) from header JA5, pin 9 (via R240).
Disconnects ETRXDV _MTCLKE-A (MCU, pin N12) from the Ethernet transceiver U15, pin 19.
Disconnects ETRXDV _MTCLKE-A (MCU, pin N12) to header JA5, pin 17.
Disconnects EDACK0-C _ETLINKSTA_MTIOC4B-B (MCU, pin M7) from header JA2, pin 17.
Disconnects ETTXER _MTCLKF-A (MCU, pin N11) from the Ethernet transceiver U15, pin 1.
Disconnects ETTXER _MTCLKF-A (MCU, pin N11) from header JA5, pin 18.
Disconnects ETTXD2 _MTIC11W-A (MCU, pin N10) from the Ethernet transceiver U15, pin 26.
Connects ETTXD2_MTIC11W-A (MCU, pin N10) to JA5, pin 14.
Disconnects ETTXD3 _MTIC11V-A (MCU, pin M10) to the Ethernet transceiver U15, pin 27.
Disconnects ETTXD3 _MTIC11V-A (MCU, pin M10) to header JA5, pin 13.
Disconnects ETCOL _MTIC11U-A (MCU, pin R12) from the Ethernet transceiver U15, pin 36.
Disconnects ETCOL _MTIC11U-A (MCU, pin R12) from header JA5, pin 12.
Disconnects D5_MTIC5W-B (MCU, pin C10) from the external data bus.
Disconnects D5_MTIC5W-B (MCU, pin C10) from header JA6, pin 16.
Disconnects D6_MTIC5V-B (MCU, pin B10) from the external data bus.
Disconnects D6_MTIC5V-B (MCU, pin B10) from header JA6, pin 15.
Disconnects D7_MTIC5U-B (MCU, pin A12) from the external data bus.
Disconnects D7_MTIC5U-B (MCU, pin A12) from header JA6, pin 14.
Disconnects IRQ10-A (MCU, pin B1) from header JA1, pin 23 (via R42).
R112, R240
R115
R114
R91, R93
R117
R116
R119
R118
R121
R120
R123
R122
R129
R128
R131
R130
R133
R132
R42, R225
Table 6-16: MTU Option Links – Part 3
REJ10J2198-0201 Rev. 2.01 Page 37 of 54 Nov 30, 2011
RSK+RX62N 6. Configuration
Reference Link Fitted Configuration Link Removed Configuration Related Ref.
R225 Connects MTIOC6A (MCU, pin F14)
to header JA1, pin 23 (via R107).
R226 Connects IRQ8-A (MCU, pin C1) to
header JA2, pin 7 (via R35).
R227 Connects MTIOC0A (MCU, pin J4) to
header JA2, pin 7 (via R71).
R228 Connects IRQ9-A (MCU, pin D2) to
header JA2, pin 9 (via R38).
R229 Connects MTIOC0B (MCU, pin N5) to
header JA2, pin 9 (via R51).
R230 Connects IRQ2-A (MCU, pin J2) to
header JA2, pin 23 (via R67).
R231 Connects MTIOC1A (MCU, pin N3) to
header JA2, pin 23 (via R56).
R240 Connects MTIOC7A (MCU, pin H14)
to header JA5, pin 9 (via R113).
R241 Connects MTIOC6B (MCU, pin G15)
to header JA5, pin 9 (via R109).
Disconnects MTIOC6A (MCU, pin F14) from header JA1, pin 23 (via R107).
Disconnects IRQ8-A (MCU, pin C1) from header JA2, pin 7 (via R35).
Disconnects MTIOC0A (MCU, pin J4) from header JA2, pin 7 (via R71).
Disconnects IRQ9-A (MCU, pin D2) from header JA2, pin 9 (via R38).
Disconnects MTIOC0B (MCU, pin N5) from header JA2, pin 9 (via R51).
Disconnects IRQ2-A (MCU, pin J2) to header JA2, pin 23 (via R67).
Disconnects MTIOC1A (MCU, pin N3) from header JA2, pin 23 (via R56).
Disconnects MTIOC7A (MCU, pin H14) from header JA5, pin 9 (via R113).
Disconnects MTIOC6B (MCU, pin G15) from header JA5, pin 9 (via R109).
R107, R224
R35, R227
R71, R226
R38, R229
R51, R228
R67, R231
R56, R230
R113, R241
R109, R240
Table 6-17: MTU Option Links – Part 4
Table 6-18 below details the different configurations and functions of the MTU jumpers.
Reference Position One Position Two Position Three Related Ref.
J3* Pins 1 and 2 shorted.
Connects OEn (U3, pin
19) to GROUND (bypassed by R33).
J4* Pins 1 and 2 shorted.
Connects OEn (U4, pin
19) to GROUND (bypassed by R34).
J22 Pins 1 and 2 shorted.
Connects USB0VBUS EN-A_MTIOC4A-A _MTCLKA-A to USB IC U13, pin 4.
J23 Pins 1 and 2 shorted.
Connects CT0X_IRQ2-A _MTIOC0C to the CAN transceiver (U12, pin 1) via R242.
All pins open. Disconnects OEn (U3, pin 19) from GROUND (still connectable via R33).
All pins open. Disconnects OEn (U4, pin 19) from GROUND (still connectable via R34).
Pins 2 and 3 shorted. Connects USB0VBUS EN-A_MTIOC4A-A _MTCLKA-A to header TFT, pin 27.
Pins 2 and 3 shorted. Connects CT0X _IRQ2-A_MTIOC0C to header TFT, pin 24.
- R33
- R34
All pins open. Discon­nects both lines.
All pins open. Discon­nects both lines.
R62
R67, R242
Table 6-18: MTU Jumpers
*By default, this jumper is not fitted to the RSK+. Therefore the default configuration is all pins open.
REJ10J2198-0201 Rev. 2.01 Page 38 of 54 Nov 30, 2011
RSK+RX62N 6. Configuration

6.10 IRQ & General I/O Pin Configuration

Table 6-19 below details the function of the option links associated with IRQ and general I/O pin configuration.
Reference Link Fitted Configuration Link Removed Configuration Related Ref.
R32 Connects OEn pin (U2, pin 19) to
GROUND, bypassing J2.
R35 Connects TxD6-A_IRQ8-A (MCU, pin
C1) to switch SW1 (via R37).
R36 Connects TxD6-A_IRQ8-A (MCU, pin
C1) to the RS232 transceiver (U11, pin
12) via R217.
R37 Connects IRQ8-A (MCU, pin C1) to the
switch SW1 (via R35).
R38 Connects RxD6-A_IRQ9-A (MCU, pin
D2) to switch SW2 (via R40).
R39 Connects RxD6-A_IRQ9-A (MCU, pin
D2) to the RS232 transceiver (U11, pin
10) via R218.
R40 Connects IRQ9-A (MCU, pin D2) to
switch SW2 (via R38).
R41 Connects LED0_SCK6-A
_IRQ10-A (MCU, pin B1) to LED0.
R42 Connects LED0_SCK6-A
_IRQ10-A (MCU, pin B1) to header JA1, pin 23 (via R224).
R43 Connects LED0_SCK6-A
_IRQ10-A (MCU, pin B1) to header JA6, pin 11.
R44 Connects DA1_LED2 (MCU, pin C3) to
LED2.
R45 Connects DA1_LED2 (MCU, pin C3) to
header JA1, pin 14.
R46 Connects DA0_LED1 (MCU, pin C2) to
LED1.
R47 Connects DA0_LED1 (MCU, pin C2) to
header JA1, pin 13.
R48 Connects ADTRG0n_A (MCU, pin C4)
to switch SW3.
R49 Connects USB1OVRCURA
_P15_MTIOC0B (MCU, pin N5) to USB IC U14, pin 2.
R50 Connects USB1OVRCURA_P15
_MTIOC0B (MCU, pin N5) to header TFT, pin 32.
R51 Connects USB1OVRCURA_P15
_MTIOC0B (MCU, pin N5) to header JA2, pin 9 (via R229).
R67 Connects CTX0_IRQ2-A
_MTIOC0C (MCU, pin J2) to the header JA2, pin 23 (via R230).
Table 6-19: IRQ & General I/O Option Links (Continued Overleaf)
Disconnects OEn pin (U2, pin 19) from GROUND (still connectable via J2).
Disconnects TXD6-A_IRQ8-A (MCU, pin C1) from switch SW1 (via R37).
Disconnects TxD6-A_IRQ8-A (MCU, pin C1) from the RS232 transceiver (U11, pin 12) via R217.
Disconnects IRQ8-A (MCU, pin C1) from the switch SW1.
Disconnects RxD6-A_IRQ9-A (MCU, pin D2) from switch SW2 (via R40).
Disconnects RxD6-A_IRQ9-A (MCU, pin D2) from the RS232 transceiver (U11, pin 10) via R218.
Disconnects IRQ9-A (MCU, pin D2) from switch SW2 (via R38).
Disconnects LED0_SCK6-A_IRQ10-A (MCU, pin B1) from LED0.
Disconnects LED0_SCK6-A _IRQ10-A (MCU, pin B1) from header JA1, pin 23 (via R224).
Disconnects LED0_SCK6-A _IRQ10-A (MCU, pin B1) to header JA6, pin 11.
Disconnects DA1_LED2 (MCU, pin C3) from LED2.
Disconnects DA1_LED2 (MCU, pin C3) from header JA1, pin 14.
Connects DA0_LED1 (MCU, pin C2) to LED1.
Connects DA0_LED1 (MCU, pin C2) to header JA1, pin 13.
Disconnects ADTRG0n_A (MCU, pin C4) to switch SW3.
Disconnects USB1OVRCURA _P15_MTIOC0B (MCU, pin N5) from USB IC U14, pin 2.
Connects USB1OVRCURA _P15_MTIOC0B (MCU, pin N5) to header TFT, pin 32.
Connects USB1OVRCURA _P15_MTIOC0B (MCU, pin N5) to header JA2, pin 9 (via R229).
Disconnects CTX0_IRQ2-A _MTIOC0C (MCU, pin J2) from the header JA2, pin 23 (via R230).
J2
R36, R37, R226
R35, R217
R35
R39, R40
R38, R218
R38
R42, R43
R41, R43, R224
R42, R43
R45
R44
R47
R46
-
R50, R51
R49, R51, R252
R49, R50, R229
R230
REJ10J2198-0201 Rev. 2.01 Page 39 of 54 Nov 30, 2011
RSK+RX62N 6. Configuration
Reference Link Fitted Configuration Link Removed Configuration Related Ref.
R224 Connects IRQ10-A (MCU, pin B1) to
header JA1, pin 23 (via R42).
R225 Connects MTIOC6A (MCU, pin F14) to
header JA1, pin 23 (via R107).
R226 Connects IRQ8-A (MCU, pin C1) to
header JA2, pin 7 (via R35).
R227 Connects MTIOC0A (MCU, pin J4) to
header JA2, pin 7 (via R71).
R228 Connects IRQ9-A (MCU, pin D2) to
header JA2, pin 9 (via R38).
R229 Connects MTIOC0B (MCU, pin N5) to
header JA2, pin 9 (via R51).
R230 Connects IRQ2-A (MCU, pin J2) to
header JA2, pin 23 (via R67).
R231 Connects MTIOC1A (MCU, pin N3) to
header JA2, pin 23 (via R56).
R251 Connects SSLB1-A (MCU, pin P10) to
the header TFT, pin 32 (via R90).
R252 Connects P15 (MCU, pin N5) to the
header TFT, pin 32.
Disconnects IRQ10-A (MCU, pin B1) from header JA1, pin 23 (via R42).
Disconnects MTIOC6A (MCU, pin F14) from header JA1, pin 23 (via R107).
Disconnects IRQ8-A (MCU, pin C1) from header JA2, pin 7 (via R35).
Disconnects MTIOC0A (MCU, pin J4) from header JA2, pin 7 (via R71).
Disconnects IRQ9-A (MCU, pin D2) from header JA2, pin 9 (via R38).
Disconnects MTIOC0B (MCU, pin N5) from header JA2, pin 9 (via R51).
Disconnects IRQ2-A (MCU, pin J2) to header JA2, pin 23 (via R67).
Disconnects MTIOC1A (MCU, pin N3) from header JA2, pin 23 (via R56).
Disconnects SSLB1-A (MCU, pin P10) from the header TFT, pin 32 (via R90).
Disconnects P15 (MCU, pin N5) from the header TFT, pin 32.
R42, R225
R107, R224
R35, R227
R71, R226
R38, R229
R51, R228
R67, R231
R56, R230
R252, R90
R251, R50
Table 6-19: IRQ & General I/O Option Links (Continuation)
Table 6-20 below details the function of the jumpers associated with IRQ and general I/O pin configuration.
Reference Position One Position Two Position Three Related Ref.
J3* Pins 1 and 2 shorted.
Connects OEn (U3, pin 19) to GROUND (bypassed by R33).
J4* Pins 1 and 2 shorted.
Connects OEn (U4, pin 19) to GROUND (bypassed by R34).
All pins open. Disconnects OEn (U3, pin 19) from GROUND (still connectable via R33).
All pins open. Disconnects OEn (U4, pin 19) from GROUND (still connectable via R34).
- R33
- R34
Table 6-20: IRQ & General I/O Jumpers
*By default, this jumper is not fitted to the RSK+. Therefore the default configuration is all pins open.
REJ10J2198-0201 Rev. 2.01 Page 40 of 54 Nov 30, 2011
RSK+RX62N 6. Configuration

6.11 Power Supply Configuration

Table 6-21 below details the function of the option links associated with power supply configuration.
Reference Link Fitted Configuration Link Removed Configuration Related Ref.
R172 Connects Unregulated_VCC to the
PWR1 connector, pin 3.
R173 Connects CON_5V to the main power
supply.
R174 Connects Board_5V to the main 5V
power supply.
R175 Connects the 3.3V regulator to the
main 3.3V connections.
R176 Connects CON_3V3 to the main 3.3V
power supply (via R175).
R177 Connects UC_VCC to the main 3.3V
power supply, bypassing J13 (via R175).
R325 Connects 3V3USB to CON_3V3USB. Disconnects 3V3USB from
R326 Connects 3V3USB to Board_VCC. Disconnects 3V3USB from
R327 Connects 5VUSB to CON_5VUSB. Disconnects 5VUSB from
R328 Connects 5VUSB to Board_5V. Disconnects 5VUSB from Board_5V. R325, R326,
Table 6-21: Power Supply Option Links
Table 6-22 below details the function of the jumpers associated with power supply configuration.
Reference Position One Position Two Position Three Related Ref.
J10 & J11 Pins 1 and 2 shorted on
both jumpers. Power supply regulated is bypassed, to allow a regulated 5V supply to be used.
J12* Pins 1 and 2 shorted.
Connects USB0VBUS to Board VCC.
J13* Pins 1 and 2 shorted.
Connects UC_VCC to the output of the 3.3V regulator, via R175 (bypassed by R177).
J21* Pins 1 and 2 shorted.
Connects VBUS (connector USB0, pin 1) to the main power supply.
All pins open on both jumpers. Power supply is used, allowing an unregulated 7-15V supply to be used.
Pins 2 and 3 shorted. Connects USB0VBUS to VBUS from USB0 via J18 (can be bypassed by R322)
All pins open. Disconnects UC_VCC from the output of the 3.3V regulator (still connectable via R177).
All pins open. Disconnects VBUS (connector USB0, pin 1) from the main power supply.
Table 6-22: Power Supply Jumpers (Continued Overleaf)
*By default, this jumper is not fitted to the RSK. The default position is therefore all pins open.
Disconnects Unregulated _VCC from the PWR1 connector, pin
3. Disconnects CON_5V from the main
power supply. Disconnects Board_5V from the main
5V power supply. Disconnects the 3.3V regulator from
the main 3.3V connections. Disconnects CON_3V3 from the main
3.3V power supply (via R175). Connects UC_VCC to the main 3.3V
power supply, bypassing J13 (via R175).
CON_3V3USB.
Board_VCC.
CON_5VUSB.
All other combinations are unsupported, and may cause damage to the RSK+.
All pins open. Discon­nects both lines.
- R177
- J12
-
-
-
R176, R177
R175
R175
R326, R327, R328
R325, R327, R328
R325, R326, R327
R327
-
J18, J21, R322
REJ10J2198-0201 Rev. 2.01 Page 41 of 54 Nov 30, 2011
RSK+RX62N 6. Configuration

6.12 Clock Configuration

Table 6-23 below details the function of the option links associated with clock configuration.
Reference Link Fitted Configuration Link Removed Configuration Related Ref.
R4 Connects EXTAL (MCU, pin J1) to the
crystal X1.
R5 Connects XTAL (MCU, pin H1) to the
crystal X1.
R6 Connects EXTAL (MCU, pin J1) to the
crystal X2.
R7 Connects XTAL (MCU, pin H1) to the
crystal X2.
R8 Connects EXTAL (MCU, pin J1) to
CON_EXTAL.
R10 Connects OSC2 (MCU, pin E1) to the
crystal X3.
R11 Connects OSC1 (MCU, pin F1) to the
crystal X3.
R12 Connects OSC2 (MCU, pin E1) to
ground.
R301 Connects XTAL2 (U15, pin 13) to the
crystal X4.
Table 6-23: Clock Option Links
Disconnects EXTAL (MCU, pin J1) from the crystal X1.
Disconnects XTAL (MCU, pin H1) from the crystal X1.
Disconnects EXTAL (MCU, pin J1) from the crystal X2.
Disconnects XTAL (MCU, pin H1) from the crystal X2.
Disconnects EXTAL (MCU, pin J1) from CON_EXTAL.
Disconnects OSC2 (MCU, pin E1) from the crystal X3.
Disconnects OSC1 (MCU, pin F1) from the crystal X3.
Disconnects OSC2 (MCU, pin E1) from ground.
Disconnects XTAL2 (U15, pin 13) from the crystal X4.
R4, R6, R7, R8
R5, R6, R7, R8
R4, R5, R6, R8
R4, R5, R7, R8
R4, R5, R6, R7
R11, R12
R10, R12
R10, R11
X4

6.13 External Memory Configuration

Table 6-24 below details the function of the option links associated with external memory configuration.
Reference Link Fitted Configuration Link Removed Configuration Related Ref.
R152 Connects SDCLK (MCU, pin B15) to
SDRAM module U5, pin 38.
R156 Connects WP# (U6, pin 3) to ground,
enabling write protection on the SPI flash IC.
R157 Connects HOLD# (U6, pin 7) to ground,
enabling serial flash IC operation suspension.
R161 Connects SDA0 (MCU, pin P5) to the
R162 Connects SCL0 (MCU, pin R3) to the
R163 Connects WP (U7, pin 7) to ground
R164 Connects A0 (U7, pin 1) to
2
C EEPROM (U7, pin 5).
I
I2C EEPROM (U7, pin 6).
(bypassing J9), disabling write protection on the I2C EEPROM IC.
Board_VCC or Board_5V, via R166 and R167 respectively.
Table 6-24: External Memory Configuration (Continued Overleaf)
Disconnects SDCLK (MCU, pin B15) from SDRAM module U5, pin 38.
Disconnects WP# (U6, pin 3) from ground, disabling write protection on the SPI flash IC.
Disconnects HOLD# (U6, pin 7) from ground, disabling serial flash IC operation suspension.
Disconnects SDA0 (MCU, pin P5) from the I2C EEPROM (U7, pin 5).
Disconnects SCL0 (MCU, pin R3) from the I2C EEPROM (U7, pin 6).
Disconnects WP (U7, pin 7) from ground (still connectable via J9), enabling write protection on the I2C EEPROM IC.
Disconnects A0 (U7, pin 1) from Board_VCC and Board_5V, via R166 and R167 respectively.
-
-
-
-
-
J9
R165, R166, R167
REJ10J2198-0201 Rev. 2.01 Page 42 of 54 Nov 30, 2011
RSK+RX62N 6. Configuration
Reference Link Fitted Configuration Link Removed Configuration Related Ref.
R165 Connects A0 (U7, pin 1) to GROUND. Disconnects A0 (U7, pin 1) from
GROUND.
R166 Powers the I2C EEPROM IC (U7) from
Board_VCC.
R167 Powers the I2C EEPROM IC (U7) from
Board_5V.
Disconnects the I2C EEPROM IC (U7) from Board_VCC.
Disconnects the I2C EEPROM IC (U7) from Board_5V.
R164
R167
R166
Table 6-24: External Memory Configuration (Continuation)
Table 6-25 below details the function of the jumpers associated with external memory configuration.
Reference Position One Position Two Position Three Related Ref.
J9 Pins 1 and 2 shorted.
Connects WP (U7, pin 7) to GROUND, disabling write protection on the
2
C EEPROM IC
I (bypassed by R163).
All pins open. WP (U7, pin
7) is disconnected form GROUND, enabling write protection on the I EEPROM IC (still connectable by R163).
- R163
2
C
Table 6-25: External Memory Configuration
REJ10J2198-0201 Rev. 2.01 Page 43 of 54 Nov 30, 2011
RSK+RX62N 8. Code Development

7. Headers

7.1 Application Headers

This RSK is fitted with application headers, which can be used to connect compatible Renesas application devices or as easy access to MCU pins.
Table 7-1 below lists the connections of the application header, JA1.
Application Header JA1
Pin Circuit Net Name MCU Pin Pin Circuit Net Name MCU Pin
1 5V - 2 0V ­3 3V3 - 4 0V ­5 AVCC - 6 AVSS ­7 AVREF - 8 ADTRG ­9 AD0 C5 10 AD1 D4 11 AD2 A3 12 AD3 D5 13 DAC0 C2 14 DAC1 C3 15 IO_0 C12 16 IO_1 A15 17 IO_2 B14 18 IO_3 C13 19 IO_4 D13 20 IO_5 C14 21 IO_6 C15 22 IO_7 D14 23 IRQ3/IRQAEC/M2_HSIN0 B1 24 IIC_EX NC 25 IIC_SDA - 26 IIC_SCL -
Table 7-1: Application Header JA1 Connections
Table 7-2 below lists the connections of the application header, JA2.
Application Header JA2
Pin Circuit Net Name MCU Pin Pin Circuit Net Name MCU Pin
1 RESET H4 2 EXTAL ­3 NMI H2 4 Vss1 ­5 WDT_OVF F2 6 SCIaTX K3 7 IRQ0/WKUP/M1_HSIN0 C1 8 SCIaRX L1 9 IRQ1/M1_HSIN1 D2 10 SCIaCK M1 11 M1_UD P7 12 No Connection NC 13 M1_Up R13 14 M1_Un M11 15 M1_Vp P11 16 M1_Vn R11 17 M1_Wp M6 18 M1_Wn M6 19 TimerOut M3 20 TimerOut M3 21 TimerIn R1 22 TimerIn R1 23 IRQ2/M1_EncZ/M1_HSIN2 J2 24 M1_POE A10 25 M1_TRCCLK P1 26 M1_TRDCLK M2
Table 7-2: Application Header JA2 Connections
REJ10J2198-0201 Rev. 2.01 Page 44 of 54 Nov 30, 2011
RSK+RX62N 8. Code Development
Table 7-3 below lists the connections of the BUS application header, JA3
Bus Application Header JA2
Pin Circuit Net Name MCU Pin Pin Circuit Net Name MCU Pin
1 A0 F14 A1 A1 G15 3 A2 H13 4 A3 H15 97 A4 H14 6 A5 J13 7 A6 J15 8 A7 J14 9 A8 K15 10 A9 K12 11 A10 M15 12 A11 L14 13 A12 L13 14 A13 N15 15 A14 M14 16 A15 P15 17 D0 A7 18 D1 B7 19 D2 A8 20 D3 A9 21 D4 A10 22 D5 C10 23 D6 C10 24 D7 A12 25 RDn N8 26 WR/SDWE P10 27 LED5_CS3n-B N14 28 CSb A13 29 D8 C12 30 D9 A15 31 D10 B14 32 D11 C13 33 D12 D13 34 D13 C14 35 D14 C15 36 D15 D14 37 A16 M12 38 A17 P14 39 A18 N12 40 A19 N11 41 A20 P12 42 A21 N10 43 A22 M10 44 SDCLK B15 45 CSc/Wait B11 46 ALE/SDCKE D15 Q HWRn/DQM1 M8 48 LWRn/DQM0 P10 49 CAS A14 50 RAS B12
Table 7-3: Bus Application Header JA 3 Connections
REJ10J2198-0201 Rev. 2.01 Page 45 of 54 Nov 30, 2011
RSK+RX62N 8. Code Development
Table 7-4 below lists the connections of the application header, JA5.
Application Header JA5
Pin Circuit Net Name MCU Pin Pin Circuit Net Name MCU Pin
1 AD4 B4 2 AD5 A4 3 AD6 A5 4 AD7 B5 5 CAN1TX J2 6 CAN1RX K1 7 CAN2TX NC 8 CAN2RX NC 9 IRQ4/M2_EncZ/M2HSIN1 H14 10 IRQ5/M2_HSIN2 H13 11 M2_UD K12 12 M2_Uin R12 13 M2_Vin M10 14 M2_Win N10 15 M2_Toggle K15 16 M2_POE NC 17 M2_TRCCLK N12 18 M2_TRDCLK N11 19 M2_Up M15 20 M2_Un L14 21 M2_Vp L13 22 M2_Vn N15 23 M2_W M14 24 M2_Wn P15
Table 7-4: Application Header JA5 Connections
Table 7-5 below lists the connections of the application header, JA6.
Application Header JA6
Pin Circuit Net Name MCU Pin Pin Circuit Net Name MCU Pin
1 DREQ NC 2 DACK NC 3 TEND NC 4 GROUND NC 5 RS32TX - 6 RS232RX ­7 SCIbRX R3 8 SCIbTX P5 9 SCIcTX C1 10 SCIbCK M5 11 SCIcCK B1 12 SCIcRX D2 13 M1_Toggle NC 14 M1_Uin NC 15 M1_Vin NC 16 M1_Win NC 17 Reserved NC 18 Reserved NC 19 Reserved NC 20 Reserved NC 21 Reserved NC 22 Reserved NC 23 Unregulated_VCC NC 24 GROUND NC
Table 7-5: Application Header JA6 Connections
REJ10J2198-0201 Rev. 2.01 Page 46 of 54 Nov 30, 2011
RSK+RX62N 8. Code Development

7.2 Generic Headers

Generic headers, used to provide easy connections to various pins from devices fitted to the RSK+.
Table 7-6 below lists the connections of the pin header, J20.
Pin Header J20
Pin Circuit Net Name MCU Pin Pin Circuit Net Name MCU Pin
1 CNVSS E2 2 BSCANP E3 3 P10 N7 4 P90 A6 5 P91 B6 6 P92 B6 7 PG0 A11 8 PG1 D10 9 GROUND - 10 P53_BCLK R10
Table 7-6: Pin Header J20 Connections
REJ10J2198-0201 Rev. 2.01 Page 47 of 54 Nov 30, 2011
RSK+RX62N 8. Code Development

8. Code Development

8.1 Overview

For all code debugging using Renesas software tools, the RSK+ board must be connected to a PC via an E1/E20 debugger. An E1 debugger is supplied with this RSK+ product.
For further information regarding the debugging capabilities of the E1/E20 debuggers, refer to the RX Family E1/E20 Emulator User’s Manual (REJ10J2089).

8.2 Compiler Restrictio ns

The compiler supplied with this RSK is fully functional for a period of 60 days from first use. After the first 60 days of use have expired, the compiler will default to a maximum of 128k code and data. To use the compiler with programs greater than this size you need to purchase the full tools from your distributor.
The protection software for the compiler will detect changes to the system clock. Changes to the system clock back in time may cause the trial period to expire prematurely.

8.3 Mode Support

The MCU supports Single Chip, Boot and USB Boot modes, which are configured on the RSK+ board. Details of the modifications required can be found in §6. All other MCU operating modes are configured within the MCU’s registers, which are listed in the RX62N group hardware manual.
Only ever change the MCU operating mode whilst the RSK is in reset, or turned off; otherwise the MCU may become damaged as a result.

8.4 Debugging Support

The E1 emulator (as supplied with this RSK+) supports break points, event points (including mid-execution insertion) and basic trace functionality. It is limited to a maximum of 8 on-chip event points, 256 software breaks and 256 branch/cycle trace. For further details, refer RX Family E1/E20 Emulator User’s Manual (REJ10J2089-
0100).
REJ10J2198-0201 Rev. 2.01 Page 48 of 54 Nov 30, 2011
RSK+RX62N 8. Code Development

8.5 Address Space

Figure 8-1 below details the address space of MCU in its different operating modes. For further details, refer to the RX62N group hardware manual.
Figure 8-1: MCU Address Space Diagram
REJ10J2198-0201 Rev. 2.01 Page 49 of 54 Nov 30, 2011
RSK+RX62N 9. Additional Information

9. Additional Information

Technical Support
For details on how to use High-performance Embedded Workshop (HEW), refer to the HEW manual available on the CD or from the web site.
For information about the RX62N series microcontrollers refer to the RX62N Group hardware manual.
For information about the RX62N assembly language, refer to the RX600 Series Software Manual.
Online technical support and information is available at: http://www.renesas.com/rskrx62n
Technical Contact Details
America: techsupport.america@renesas.com Europe: tools.support.eu@renesas.com Japan: csc@renesas.com
General information on Renesas Microcontrollers can be found on the Renesas website at:
http://www.renesas.com/
Trademarks
All brand or product names used in this manual are trademarks or registered trademarks of their respective companies or organisations.
Copyright
This document may be, wholly or partially, subject to change without notice. All rights reserved. Duplication of this document, either in whole or part is prohibited without the written permission of Renesas Electronics Europe Limited.
© 2010 (2011) Renesas Electronics Europe Limited. All rights reserved. © 2010 (2011) Renesas Electronics Corporation. All rights reserved. © 2010 (2011) Renesas Solutions Corp. All rights reserved.
REJ10J2198-0201 Rev. 2.01 Page 50 of 54 Nov 30, 2011
Loading...
