User’s Manual
R0E001000EXT00
External Trigger Cable for the E100 Emulator
1. Outline
The external trigger cable R0E001000EXT00 allows tracing of
external signals and output of events through the external trigger
connector of the E100 emulator (R0E001000EMU00).
Rev.2.00
Apr 16, 2010
2. Package Components (See Figure 1)
REJ10J1817-0200
Check to see if the R0E001000EXT00 package has all the
following contents before using this product.
(1) R0E001000EXTE0 board............................................ 1 pc.
(2) R0E001000EXTT0 board (with a cable)..................... 1 pc.
(3) R0E001000FLX10 flexible cable................................ 1 pc.
(4) R0E001000EXT00 User's Manual (this document)
3. Usage (See Figure 2)
The usage of the external trigger cable R0E001000EXT00 is
shown in Figure 2.
After checking that the power supplies for the E100 emulator and the user system are turned off, connect the external trigger cable
R0E001000EXT00 according to the following procedure.
(1) Connect R0E001000FLX10 to the R0E001000EXTE0 board.
(2) Open the lid (EXT) of the E100 emulator and connect the R0E001000EXTE0 board to the external trigger connector.
(3) Connect signals to the user-system connection sockets of R0E001000EXTT0.
(4) Connect R0E001000FLX10 to R0E001000EXTT0.
R0E001000EXTE0 board
(E100 emulator side)
R0E001000EXTT0 board with a cable
(user system side)
Figure 1 Package Components of the R0E001000EXT
R0E001000FLX10
flexible cable
REJ10J1817-0200 Rev.2.00 Page 1 of 4
Apr 16 2010
R0E001000EXT00 User’s Manual
R0E001000EXTE0
(1)
R0E001000FLX10
flexible cable
External trigger connector
5
E
0
R
(2)
0
0
U
C
M
0
5
6
0
3
1
H
I
0
G
H
P
E
R
0
F
E
O
M
R
U
M
L
A
A
N
T
C
O
R
E
S
Y
S
T
E
M
Figure 2 Usage of the R0E01000EXT00
4 Connection with a User System
(See Figure 3)
(1) GND connection
The black wire connected to the R0E001000EXTT0
board acts as a GND terminal. This wire must be
connected to GND of the user system.
(2) Trigger-signal correspondence table
Input and output attributes for trigger signals are
specifiable through settings in the emulator debugger.
Table 1 shows the correspondence between the [Trigger]
section ([External trigger cable]) on the [System] page of
the [Configuration Properties] dialog box of the emulator
debugger and identification numbers for the user-system
connection sockets.
R0E001000EXTT0
User-system connection sockets
(204351-1 made by AMP)
Size: 0.76 mm
R0E001000EXTT0
Identification number on the sticker
for each user-system connection socket
Figure 3 Connection with a User System
(4)
Wires:
Black (GND) and gray (signal)
(3)
REJ10J1817-0200 Rev.2.00 Page 2 of 4
Apr 16 2010
