RCA RTB1016 Owner's Manual
User Manual
Manuel de l’utilisateur
Manual del usuario
RTB1016
It's important to read this instruction prior to using your new product for the fi rst time.
Il est important de lire ce manuel d’instructions avant d’utiliser votre nouveau produit
pour la première foi.
Es importante que lea este libro de instrucciones antes de usar su nuevo producto por
primera vez.
Important Information
THE LIGHTNING FLASH AND ARROWHEAD
WITHIN THE TRIANGLE IS A WARNING SIGN
ALERTING YOU OF “DANGEROUS VOLTAGE”
INSIDE THE PRODUCT.
THE EXCLAMATION POINT WITHIN THE TRIANGLE IS A WARNING SIGN ALERTING YOU OF
IMPORTANT INSTRUCTIONS ACCOMPANYING
THE PRODUCT.
SEE MARKING ON BACK OF PRODUCT
WARNING: TO PREVENT FIRE OR ELECTRICAL SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO
RAIN OR MOISTURE.
CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH
THE SAME OR EQUIVALENT TYPE.
WARNING: TO BE COMPLETELY DISCONNECT THE POWER INPUT , THE MAINS PLUG OF APPARATUS
SHALL BE DISCONNECTED FROM THE MAINS. THE MAINS PLUG OF APPARATUS SHOULD NOT BE
OBSTRUCTED OR SHOULD BE EASILY ACCESSED DURING INTENDED USE.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK). NO
USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Service Information
This product should be serviced only by those
specially trained in appropriate servicing techniques.
Main plug is used as the disconnect device, it shall
remain operable and should not be obstructed
during intended use. To be completely disconnected
the apparatus from supply mains, the main plug of
the apparatus shall be disconnected from the mains
socket outlet completely.
Caution
Invisible laser radiation when open and interlocks
defeated. Avoid exposure to beam. Class 1 laser
product.
This system must be opened only by qualifi ed
technicians to prevent accidents caused by the
aser beam.
Copyrights
This product incorporates copyright protection
technology that is protected by methods claims in
certain U. S. Patents and other intellectual property
rights owned by Macrovision Corporation and other
rights owners. Use of this copyright protection
technology must be authorized by Macrovision
Corporation, and is intended for home and
other limited viewing uses only unless otherwise
authorized by Macrovision Corporation. Reverse
engineering or disassembly is prohibited.
EN-1
Important Information
Important Battery Information
• Do not mix diff erent types of batteries or new and
old batteries. Do not use rechargeable batteries.
• In order to avoid any risk of explosion, observe the
polarities indicated inside the battery compartment.
Replace only with the type of batteries specifi ed. Do
not dispose of them in a fi re or recharge them.
• If you are not using the remote control for a long
period of time, remove the batteries.
Please respect the environment and
prevailing regulations. Before you dispose of batteries or accumulators, ask
your dealer whether they are subject
to special recycling and if they will accept them for disposal.
Illustrations contained in this document are for representation only.
CAUTION:
This product utilizes a laser. Use of controls or
adjustments or performance of procedures other
than those specified may result in hazardous
radiation exposure. Do not open covers and do
not repair yourself. Refer servicing to qualified
personnel.
This Class B digital apparatus complies with
Canadian ICES-003.
Cet appareil numérique de la classe B est
conforme à la norme du NMB-003 du Canada.
WARNING
To reduce the risk of fi re or electric shock,
do not expose this product to rain or moisture. No objects fi lled with liquids, such as
vases, should be placed on the apparatus.
CLA SS 1 LA SER PRO DUCT
APPAREIL À LASER DE CLASSE 1
PROD UCTO LASER DE CLASE 1
Double insulation when servicing use
only identical replacement parts.
This product contains a low
power laser device.
EN-2
Important Safety Instructions
Please Read and Save for Future Reference.
Some of the following information may not apply
to your particular product; however, as with any
electronic product, precautions should be observed
during handling and use.
Read these instructions.
•
Keep these instructions.
•
Heed all warnings.
•
Follow all instructions.
•
Do not use this apparatus near water.
•
Clean only with a dry cloth.
•
Do not block any ventilation openings. Install in
•
accordance with the manufacturer’s instructions.
Do not install near any heat sources such
•
as radiators, heat registers, stoves, or other
apparatus (Including amplifiers) that produce
heat.
Only use attachments / accessories specifi ed by
•
the manufacturer.
Do not defeat the safety purpose of the polarized
•
or grounding-type plug. A polarized plug has
two blades with one wider than the other. A
grounding type plug has two blades and a third
grounding prong. The wide blade or the third
prong is provided for your safety. If the provided
plug does not fi t into your wall outlet, consult an
electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on
•
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
Unplug this apparatus during lightning storms or
•
when unused for long periods of time.
Use only with a cart, stand, tripod,
•
bracket, or table specified by the
manufacturer, or sold with the
apparatus. When a cart is used, use
caution when moving the cart/
apparatus combination to avoid
injury from tip-over.
Refer all servicing to qualified service personnel.
•
Servicing is required when the apparatus has been
damaged in any way, such as the power cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
]
Portable Cart
Warning
Additional Safety Information
• The apparatus shall not be exposed to dripping or
splashing and that no objects fi lled with liquids,
such as vases, shall be placed on the apparatus.
• Always leave suffi cient space around the product
for ventilation. Do not place product in or on a bed,
rug, in a bookcase or cabinet that may prevent air
fl ow through vent openings.
• Do not place lighted candles, cigarettes, cigars, etc.
on the product.
• Connect power cord only to AC power source as
marked on the product.
• Care should be taken so that objects do not fall
into the product.
• Do not attempt to disassemble the cabinet. This
product does not contain customer serviceable
components.
If your product operates on batteries, adhere to the
following precautions:
A. Any battery may leak electrolyte if mixed with a
diff erent battery type, if inserted incorrectly, or if
all batteries are not replaced at the same time.
B. Any battery may leak electrolyte or explode if
disposed of in fi re or an attempt is made to charge
a battery not intended to be recharged.
C. Discard leaky batteries immediately. Leaking
batteries can cause skin burns or other personal
injury. When discarding batteries, be sure to dispose
of them in the proper manner, according to your
state/provincial and local regulations.
D. Battery shall not be exposed to excessive heat such
as sunshine, fi re or the like.
EN-3
FCC Information
This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses
and can radiate radio frequency energy and, if
not installed and used in accordance with the
instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment
•
and receiver.
Connect the equipment into an outlet on a
•
circuit diff erent from that to which the receiver
is connected.
Consult the dealer or an experienced radio / TV
•
technician for help.
WARNING: Changes or modifications to this unit
not expressly approved by the party responsible
for compliance could void the user's authority to
operate the equipment.
Ventilation
You must adequately ventilate the product. Make
sure there is adequate space around the unit to
provide proper air fl ow for ventilation. See diagram.
This product complies with DHHS Rules 21 CFR Sub-
7 cm
10 cm
10 cm
chapter J. Applicable at the date of manufacture.
10 cm
7 cm
For your Safety
The AC power plug is polarized
(one blade is wider than the other)
and only fi ts into AC power outlets
one way. If the plug won’t go into
the outlet completely, turn the
plug over and try to insert it the
other way.
If it still won’t fi t, contact a qualifi ed electrician to
change the outlet, or use a diff erent one. Do not attempt to bypass this safety feature.
Removing the power plug is the only way to completely remove power from your product. Make
sure the power plug remains easily accessible.
Note:
This unit has been designed to play back BD-video
with region “A” and DVD-video with region “1”. You
cannot play back BD-video or DVD-video that are
labeled for other regions. Look for the symbols on
the right on your BD-video or DVD-video. If these
region symbols do not appear on your BD-video or
DVD-video, you cannot play back the disc in this unit.
The letter or number inside the globe refers to region
of the world. A BD-video or DVD-video labeled for a
specifi c region can only be played back in the unit
with the same region code.
EN-4
Features
• Full high-defi nition video playback at up to 1080p resolution for an amazing viewing experience.
Upconversion of standard defi nition DVDs for enhanced picture quality at up to 1080p over an HDMI
connection.
• Rich multi-channel surround sound.
• Easy and simple HDTV connection using a single HDMI cable (cable not included).
• Multiple outputs for connecting your home theater system or amplifi er.
• PIP functionality that lets you display primary and secondary video at the same time (if available on the
Blu-ray Disc).
• Pop-up menu display without interrupting playback (if available on the Blu-ray Disc).
• HDMI 1080p/60fps output (Blu-ray Disc only) that provides smooth playback of video with a frame rate
of 60 frames per second (TV must be connected with an HDMI cable and be compatible with 1080p 60
frame).
Connections and Setup
What’s Included
Remote control and 2
AAA batteries
One Pig-Tail
antenna wire
Left and right front
speakers
Composite
video cable
Subwoofer
Main unit (receiver)
Left and right Surround speakers
Center speaker
Things to Consider before You Connect
• Ensure that the mains (AC power) supply in your house complies with that indicated on the identifi cation
sticker located on the back of your unit.
• Install your unit horizontally, away from any source of heat (fi replace) or appliances creating strong magnetic
or electric fi elds. The components of this unit are sensitive to heat. The maximum ambient temperature
should not exceed 35°C / 95°F.
• Leave enough space around the unit to allow adequate ventilation: 10 cm/4 inches on either side and above
the top, and 5 cm/2 inches at the rear.
• The humidity of the room should not exceed 75%. If you have to use the unit outdoors, do not expose it
to rain or splashing water. The apparatus should not be exposed to dripping or splashing and no objects
fi lled with liquids, such as vases, should be placed on the apparatus.
• Moving the unit from a cold place to a warm one can cause condensation on some components inside
the unit. Let the condensation disappear on its own before turning the unit on again.
• Before moving the unit, make sure the disc tray is empty.
• Where the mains plug or an appliance coupler is used as a disconnect device, the disconnect device shall
remain readily operable.
• Other important use and cleaning information at the end of the booklet.
EN-5
Connections and Setup
Connecting the Antenna
FM antenna
The FM antenna connects to the FM terminal on the
system’s back panel. It must be hooked up in order
to receive clear reception.
Connecting to your TV
Method 1 (best)
HDMI
• Connect the HDMI OUT jack on the rear of the unit
to the HDMI IN jack on your TV using a HDMI cable
(not included).
• You can select the resolution of the player’s HDMI
output signals (HDMI Auto, 1080p, 1080i, 720p,
480p and 480i) to match your TV’s resolution
capabilities, please see instructions on page 21 for
details.
Method 1
To HDMI
output
TV
HDMI cable
(not supplied)
HDHDMI
To HDMI
input
Method 2 (good)
Component video jacks (Pr, Pb, Y)
• The component video jacks are color-coded
green, blue and red.
• Additional component video cables (not supplied)
are required. They are usually color-coded green,
blue and red.
• Connect the component video OUT jacks on the
unit to the component video IN jacks on your TV.
Method 3 (basic)
Composite video jack (yellow)
• This video jack is color-coded yellow.
• Use the video cable with yellow plugs (supplied)
for good picture quality.
• Connect the video OUT jack on the unit to the IN
jack on your TV.
Method 2
Component
Video Cable
(not supplied)
Green Blue Red
VIDEO
Y
P
B
P
R
Method 3
IN
VIDEO IN
TV
Video Cable
included
Notes
• Refer to the owner’s manual of the connected TV
as well.
• HDMI, the HDMI logo and High-Defi nition
Multimedia Interface are trademarks or registered
trademarks of HDMI licensing LLC.
• If your television is a high defi nition television
with an HDMI input, we highly recommend you
use the unit’s HDMI output to get the highest
possible video resolution.
Notes
• If one of the devices is not working, check that all
the cables have been inserted properly into the
jacks.
• If your component has only one input for audio
(mono), connect it to the left (white L/Mono)
audio jack on the TV and don’t connect the right
audio part of the cable.
EN-6
Connections and Setup
Connecting AUDIO IN from External
Sources such as TV
Method 1 (best)
Using Digital Optical Input
Connect components capable of outputting
Dolby digital surround sound (e.g. TV or SAT/Cable
Box) or standard PCM (stereo) format digital signals.
Use a fi ber optical cable for this digital audio connection. (Cable not included).
Press OPTICAL button on remote control or
SOURCE button on main unit to select OPTICAL
input.
Method 2 (good)
Using AUDIO IN Jacks
Connect the AUDIO IN jacks from the unit to the
AUDIO OUT jacks on TV, SAT/Cable Box, VCR or
other component. Press either SOURCE button on
the main unit or AUX button on the remote control
to select AUX mode.
TV
OR
OR
SAT/
White
Red
AUDIO OUT
Audio cable
(not included)
Cable BoxVCR
Connecting your player to a wired network router (optional)
Connect an Ethernet cable (CAT5 or better with
RJ45 connector) to the ETHERNET jack on the back
of your player and to an Ethernet jack on a network
hub or broadband router.
Hub or broadband router
LAN
LAN cable
(not included)
Notes:
• Do not connect a modular phone cable to the
ETHERNET jack.
• When plugging or unplugging the cable, hold
the connector on the end of the cable. When
unplugging, do not pull on the cable. Press
down the lock tab and pull the connector out
of the jack.
• Because there are various connection
confi gurations, follow the instructions from
your Internet service provider.
Connecting AUDIO OUT to an auxilliary
Audio System (optional connection)
This system has AUDIO OUT jacks allowing you to
connect to auxiliar y audio systems such as a second
audio amplifi er or perhaps a wi reless audio tr ansmitter.
Audio System
AUDIO IN
Audio cable
(not included)
EN-7
Red White
Connections and Setup
Connecting the Speakers
Speaker wires are color-coded to match the terminals. Connect the speaker wire from the back of each
speaker to the corresponding color terminal at the back of the unit. Press down the tab to open the terminal
and insert the wire. Release the tab to lock wire in the terminal.
Center Speaker
Front Speakers
Subwoofer
Green and Black
Purple and Black
Right
Red and
Black
Left
White and Black
Insert
Press
Gray and Black
Blue and Black
Release
Right
To adjust each speaker volume level for optimum listening experience.
(1) Press LEVEL button / or on the remote control to select FL (front Left speaker).
(2) Press or buttons to adjust the value up or down (between -10dB and +10dB).
(3) Repeat step (1) and (2) for the other speakers FR, CT, SW, SL, SR.
Speaker gains may be set to levels of up to +10dB, actual max levels may also depend on your Volume
Setting.
Left
Rear Speakers
(Surround Sound)
Note:
When connecting the speakers, make sure the polarities (“+” speaker wire to “+” on the receiver)
of speaker wires and terminals match. For example, red wire to red terminal on the receiver. If the
cords are reversed, the sound will be distorted. Do not let the speaker wires touch each other, it
will damage the system’s amplifi er.
EN-8
Connections and Setup
Positioning Speakers
3
1
2
3
Courtesy Dolby Laboratories
1. Left, Right (Front Speakers)
Front speakers carry primarily music and sound effects.
2. Center
In surround mode, the center speaker carries most
of the dialog as well as music and eff ects.
It should be set between the left and right speakers.
3. Surround (Rear Speakers)
The surround speakers’ overall sound balance
should be as close as possible to the front speakers.
Proper placement is vital to establish an evenly distributed sound fi eld.
4. Subwoofer
A subwoofer is designed to reproduce powerful low
bass eff ects (explosions, the rumble of spaceships,
etc.).
4
1
Front Speaker Placement
For best results, follow the speaker placement
below.
Alignment
Align the center speaker evenly with (A) or slightly
behind (B) (the left and right speakers), but not
ahead of them.
Angle
Place the left and right speakers to form a 45-degree
angle with your favorite viewing position to duplicate the soundtrack mixer’s perspective.
Height
The three front speakers should be as close as possible to the same height. This often requires placing
the center speaker directly on top (A) or beneath (B)
the TV set.
Note:
Center speaker provided with this unit is
magnetically shielded to protect your TV
set. It is not recommended to place speakers without magnetic shield near the TV
set.
A
B
EN-9
Loading...
