RCA RCD3379 User Manual
ON CONDENSATION
When left in a heated room where it is warm and damp,
•
water droplets or condensation may form inside the CD
player. When there is condensation inside the unit, the
unit may not function normally. Let it stand for 1 to 2 hours
before turning the power on, or gradually heat the room and
allow the unit to dry before use.
User Manual
RCD3379
It's impor tant to read this instruction prior to using your new
product for the first time.
Safety Precautions
FCC Information
Battery Operation Instructions
Names of Controls
Technical Information
Important Safety Instructions
The following markings and symbols are located on the back of
the unit.
CLASS1LASER PRODUCT
APPAREILÀLASER DE CLASSE 1
PRODUCTO LASER DE CLASE 1
PRODUTO LASER CLASSE 1
This product contains a low laser device.
DO NOT TOUCH THE LENS.
CAUTION: INVISIBLE LASER RADIATION
WHEN OPEN AND INTERLOCKS DEFEATED.
AVOIDE EXPOSURE TO BEAM.
CAUTION: TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK). NO USERSERVICEABLE PARTS INSIDE. REFER TO QUALIFIED
SERVICE PERSONNEL.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO
NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
WARNING: THE APPARATUS SHOULD NOT BE EXPOSED
TO DRIPPING OR SPLASHING AND THAT NO OBJECTS
FILLED WITH LIQUIDS, SUCH AS VASES, SHOULD BE
PLACED ON THE APPARATUS.
CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED MAY RESULT IN HAZARDOUS RADIATION
EXPOSURE.
ON SAFETY
Before operating, make sure the voltage requirement of the
•
mains plug matches your local voltage.
Disconnect the mains plug immediately if liquid spills into
•
or onto the unit, or if an object falls into the unit. The unit
should not be used until service by a qualified service
personnel is completed.
Do not open the cabinet. Lasers used in rays employed by
•
the unit may damage your eyes. Any servicing should be
done by qualified service personnel.
When you are not going to use the unit for a long period of
•
time, disconnect the mains plug.
ON PLACEMENT
Do not leave, mount or use the unit in places which are
•
extremely hot, cold, dusty, or humid.
Allow adequate air circulation to prevent internal heat build-
•
up. Do not place the unit on a surface or near materials (a
curtain ex. rugs, blankets, cur tains, etc.) which might block
the ventilation holes.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) th is dev ic e m ust acc ep t a ny int erfer enc e r ece ived,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications.
Howeve r, th ere is no guarantee tha t interference wi ll not
occur in a par ticular installation. If this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit different
•
from that to which the receiver is connected.
Consult the dealer or an experienced radio / TV technician
•
for help.
This Class B digital apparatus complies with Canadian
ICES-003.
Cet appareil numérique de la classe B est conforme à la
norme du NMB-003 du Canada.
WARNING: Ch ang es or modi fic a ti o ns to this uni t not
expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Some of the following in format ion may not ap ply to you r
particular product; however, as with any electronic product,
precautions should be observed during handling and use.
Read these instructions.
•
Keep these instructions.
•
Heed all warnings.
•
Follow all instructions.
•
Do not use this apparatus near water.
•
Clean only with a dry cloth.
•
Do not block any ventilation openings. Install in accordance
•
with the manufacturer’s instructions.
Do not install near any heat sources such as radiators, heat
•
registers, stoves, or other apparatus (Including amplifiers)
that produce heat.
Do not d efec t the s afet y pur p os e of the p ol ari ze d or
•
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong is provided for your safety.
If the provided plug does not fit into your wall outlet, consult
•
an electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched
•
particularly.
at plugs, convenience receptacles, and the point where they
•
exit from the apparatus.
Only use attachments / accessories specified by the
•
manufacturer.
Use only with a cart, stand, tripod, bracket, or table
•
specified by the manufacturer, or sold with the apparatus.
When a car t is used, use caution when moving the cart /
apparatus combination to avoid injury from tip-over.
Unplug this apparatus during lightning storms or when
•
unused for long periods of time.
Refer all servicing to qualified service personnel. Servicing
•
is required when the apparatus has been damaged in any
way, such as the power cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
Portable Cart Warning
IF YOUR PRODUCT OPERATES ON BATTERIES, adhere
to the following precautions:
A. Any battery may leak electrolyte if mixed with a different
battery type, if inserted incorrectly, or if all batteries are not
replaced at the same time.
B. Any battery may leak electrolyte or explode if disposed
of in fire or an attempt is made to charge a battery not
intended to be recharged.
C. Discard leaky batteries immediately. Leaking batteries can
cause skin burns or other personal injury. When discarding
batteries, be sure to dispose of them in the proper manner,
according to provincial and local regulations.
Important Battery Precautions
An y bat ter y may prese nt a ri sk of fir e, explo si on, o r
•
chemical burn if abused. Do not try to charge a battery that
is not intended to be recharged, do not incinerate, and do
not puncture.
Non-rechargeable batteries, such as alkaline batteries, may
•
leak if left in your product for a long period of time. Remove
the batteries from the product if you are not going to use it
for a month or more.
If your product uses more than one battery, do not mix types
•
and make sure they are inserted correctly. Mixing types or
inserting incorrectly may cause them to leak.
Discard any leaky or deformed battery immediately. They
•
may cause skin burns or other personal injury.
Batteries should not be exposed to excessive heat such as
•
sunshine, fire or the like.
Please help to prote ct the en vironment by recy cli ng or
•
disposing of batteries according to federal, state, and local
regulations.
Technical Information
Product: Portable CD Player with radio
Band: RCA
Model: RCD3379
Power Supply: DC 9V/500mA
1
2
3
4
5
6
7
8
9
10
11
12 13 14
1. Handle
2. CD Door
3.
SKIP Button
Press to skip to the previous track while in CD mode.
4. REPEAT Button
Press to repeat one track / all tracks.
5.
PLAY / PAUSE Button
Press to start / pause playing a disc while in CD mode.
6. STOP Button
Press to stop playing a disc while in CD mode.
7. CD Display
Track number
Repeat all: “ • ” lights up and remains on.
Repeat one: “ • ” blinks.
Play mode: “ • ” lights up and remains on.
Pause mode: “ • ” blinks.
8. SKIP Button
Press to skip to the next track while in CD mode.
9. TUNING Knob
Rotate this knob to tune in the desired station.
10. VOLUME (+ / - ) Control
Adjusts the volume.
11. Battery Compartment
Pre ss and hol d the k no b to ope n the b at te r y door,
according to the indicator marked on the compartment.
12. LINE IN Jack
13. DC IN 9V Power Jack
Connect the AC adaptor to this jack.
14. MODE Switch
Slide the switch to select the desired mode(AM, FM, CD,
LINE IN and STANDBY).
Note: LINE IN mode is combined to radio(AM/FM) and
CD mode.
Portable CD Player with radio
- 1 - - 2 - - 3 - - 4 -
CD1379(RCD3379) ENG IB.indd 1 2009-05-11 16:56:45
Packaging and Shipping Instruction
When you send the product to the AVC service facility you must
use the original carton box and packing material or an equivalent
as designated by AVC.
Your Responsibility
(1) You must retain your bill of sale to provide proof of purchase.
(2) Thes e war ran ti e s are effe ct i ve onl y if the pro d uc t i s
purchased and operated in the U.S.A. or Canada.
(3) Wa rr a n t ie s ex te n d on ly to d e f e c t s in ma t e r i a l or
workmanship, and do not extend to any product or parts
which have been lost or discarded, or damage to product
or parts caused by misuse, accident, improper operation or
maintenance, or use in violation of instructions provided with
the product, or to product which has been altered or modified
without authorization of AVC, or to products or parts thereof
which have had the serial number removed or changed.
Out of Warranty
In the event your product requires rep air after the limited
warranty period has expired, please contact our Customer
Support Center at 1-877-252-6873 or
www.RCAav.com.
Hours: Monday-Thursday: 9am-7pm, Friday: 9am-5pm,
Saturday: 9am-NOON Eastern time.
Important:
You are responsible for any transportation, shipping or
insurance relative to the return of the product to our Product
Returns Center.
Al l wa rr ant ie s i mp lie d by s ta te law , i nc lud ing the i mp lie d
warranties of merchantability and fitness for a particular purpose,
are expressly limited to the duration of the limited warranties set
forth above. With the exception of any warranties implied by state
law as hereby limited, the foregoing warranty is exclusive and in
lieu of all other warranties, guarantees, agreements and similar
obligations of manufacturer or seller with respect to the repair
or replacement of any parts. In no event shall AVC be liable for
consequential or incidental damages.
No person, age nt, distributor, dealer or com pany is authorized
to change, modify or extend the terms of these warranties in any
manner whatsoever. The time within action must be commenced
to enforce any obligation of AVC arising under the warranty or
under any statute, or law of the United States or any state thereof,
is hereby limited to one year from the date of purchase. This
limitation does not apply to implied warranties arising under state
law.
This warranty gives you specific legal rights and you may also
have other rights, which may vary from state to state. Some states
do not allow limitation on how long an implied warranty lasts,
when an action may be brought, or the exclusion or limitation of
incidental or consequential damages, so the above provisions
may not apply to you.
For more informatio n on other products and service s, please
contact our web site at www.RCAav.com.
Important:
Also keep your “Bill of Sale” as proof of purchase.
Model no. ........................ Product name ...............................
Type of set ...................... Serial no. ......................................
Invoice no. ...................... Date purchased ............................
Dealer name ...............................................................................
FOR SUPPORT, SERVICE AND REPAIR, PLEASE VISIT
www.RCAav.com.
Specifications and exter nal appearanc e are subject to change
without notice.
AVC MULTIMEDIA ("AVC") m ak es the fo ll owi ng l i mi t ed
warranties. These limited warranties extend to the original
consumer purchaser and is limited to non-commercial user of the
product.
One Year Parts & Labor Warranty
AVC products purchased in the United States are warranted to be
free from defects in materials or workmanship for a period of one
year from the date of their original retail purchase. If the unit fails
to conform to this warranty, we will service the product using new
or refurbished parts and products, at AVC's sole discretion.
During a period of one year from the effective warranty date, AVC
will provide, when needed, service labor to repair a manufacturing
defect at its designated Service Center. To obtain warranty service
in the United States, you must first call our Customer Support
Center at 1- 877- 252 - 6873, during the hours listed in the
box below. The deternination of service will be made by AVC
customer support.
PLEASE DO NOT RETURN YOUR UNI T TO AVC WITHOUT
PRIOR AUTHORIZATION. New or remanufactured replacements
for defective parts or products will be used for repairs by AVC
at its designated Service Center for one year from the defective
warranty date. Such replacement parts or products are warranted
for an additional one year from the date of repair or replacement.
The Customer will be requir ed to s hip the unit to the Service
Center indicated at the time Customer Support is contacted to
make the necessary repairs. The customer is responsible for all
transportation charges to the service facility.
Power Supply
Volume Adjustment
Listening to the Radio
Maintenance
Limited Warranty
Troubleshooting Guide
LINE IN Connection
CD Playback
Repeat Playback
You can power your portable stereo system by plugging the
detachable AC power cord into the AC inlet on the back of
the unit and into a wall AC power outlet. Check that the rated
voltage of your unit matches your local voltage. Make sure
that the AC power cord is fully inserted into the unit.
CAUTIONS: (for North America) To prevent electrical shock,
match wide blade of plug to wide slot, fully insert.
USING THE BATTERIES
Insert 6 “C-Size” batteries in the battery compartment. Be
sure that the batteries are inserted correctly to avoid damage
to the unit.
• Always remove the batteries when
unit will not be used for a long
period of time, as this will cause
leakage of the batteries and
subsequently damage to your unit.
• Playback would automatically
come to a stop when the batteries
have no more power. Replace all
the batteries with new ones.
• Do not mix old and new batteries.
Do not mix ALKALINE, standard (CARBONZINC) or
rechargeable (NICKELCADMIUM) batteries.
Warning: Do not dispose of batteries in a fire. Batteries may
explode or leak.
Caution: Danger of explosion if batteries are incorrectly
replaced. Replace only with the same or equivalent type.
TO ADJUST THE VOLUME
Adjust the VOLUME control to obtain the
desired volume.
1. Slide the MODE switch to AM or FM.
2. Use the TUNING Knob to tune to the desired station.
3. Adjust the volume level.
AM(MW)/FM
• Reposition the unit to get better AM(MW)/FM reception.
To Wall
Outlet
TO USE THE AC ADAPTOR
ATTENTION: You must disconnect any device from the LINE-
IN jack. This product has a “smart-sense” feature, where it
picks LINE-IN as the audio source if a device is connected to
the LINE-IN jack.
1. Slide the MODE switch to CD. After a short time, the “- -”
icon will blink on the display.
2. Open the CD door. Place a disc in the center with the label
side facing up and then close the CD door gently.
3. Then the total track no. is shown on the display.
4. Press the
PLAY/PAUSE button to start
playback. The PLAY “ • ” indicator will light
up and remain on.
• Adjust the VOLUME.
TO PAUSE PLAYBACK
• Press the PLAY/PAUSE button while a
CD is playing to pause play. The PAUSE “ • ”
indicator will blink.
• To resume playback, press the
PLAY/PAUSE button
again.
TO STOP PLAYBACK
• Press the STOP button.
TO SKIP TO A DIFFERENT TRACK
• Press the button to skip to the start of the current track or
previous tracks. Press the
button to skip to the next track.
TO LOCATE A PARTICULAR POINT ON A TRACK
• P ress and hold the or button during playback,
accor di ng to th e desire d d irection, an d releas e a t the
desired point.
TO CLEAN THE UNIT
Do not use volatile chemicals on this unit. Clean by lightly
wiping with a soft cloth.
TO CLEAN THE CD
If the CD skips or will not play, the disc may
need to be cleaned. Before playing, wipe
the disc from the center outwards with a
cleaning cloth. After playing, store the disc
in its case.
TO HANDLE THE DISC
On ly tou ch the CD on the edg e t o avo id
finger prints on its surface. Do not stick paper
or tape nor write anything on the surface.
PROBLEMS SOLUTIONS
CD
System does
not turn on
• Make sure AC power plug is secure in the
outlet and inlet has power.
• Batteries may be dead. Install new batteries.
Disc in place
but unit won’t
play
• Make sure the MODE switch is set to CD
position.
• Make sure LINE IN jack is disconnected.
• Make sure disc is clean and undamaged.
• Make sure printed side of disc is facing up.
• Make sure PAUSE mode is not activated.
• Make sure the unit is on a secure spot.
Vibration or jarring can cause the disc to
skip.
RADIO
Poor FM reception
• Electrical interference in your home can
cause poor reception. Move the unit away
from them (especially those with motors and
transformers).
Poor AM(MW)
reception
• Reposition or turn the unit for better
reception.
TO CONNECT TO LINE IN FOR OTHER SOUND
SOURCES
You can connect audio devices such as your iPod, CD players
or MP3 players to the unit through the LINE IN jack. Use a
Line-in cable (not supplied), connect the LINE IN jack on the
side panel to the Line Out or Earphone jack of the other audio
devices.
TO LISTEN TO THE CONNECTED DEVICE
1. Slide the MODE switch to Radio (AM/FM) or CD mode. This
product has a “smart-sense” feature, where, if the LINE-
IN jack has a connection, it will select LINE-IN instead of
Radio or CD.
2. Turn on the audio device you have attached to the LINE IN
jack.
ATTENTION: You must disconnect any device from the LINE-
IN jack. This product has a “smart-sense” feature, where it
picks LINE-IN as the audio source if a device is connected to
the LINE-IN jack.
Note: After listening to the radio, slide the MODE switch to
STANDBY.
TO REPEAT CURRENT TRACK
• Press the REPEAT button once during
playback, the REPEAT ONE “ • ” indicator
will blink.
TO REPEAT THE ENTIRE CD
• Press the REPEAT button a second time
to repeat all tracks, the REPEAT ALL “ • ”
indicator will light up and remain on.
TO CANCEL PLAYBACK MODE
• Press the REPEAT button until the REPEAT indicator is
turned off.
Note: Repeat play can only be done when the unit is in the
play mode.
Printed in China 811-137991W010
Need More Help?
Please visit online help at http://www.1800customersupport.com/RCA
- 5 - - 6 - - 7 -
CD1379(RCD3379) ENG IB.indd 2 2009-05-11 16:56:47
Loading...
