RCA pp18l, RCU450 User Manual

Download

universal

UNIVERSAL

Multi-Brand Use RCU450

See back for most popular brands.

Compatible with today’s most popular brands.

Consolidates up to 4 remotes

Lighted component keys indicate operating mode

Dedicated MENU key for DVD navigation

remote

Remote

Component keys. (

TV, VCR, DBS• CABLE, DVD•AUX)

(Lighted component key indicates operating mode).

CHANand VOL

keys have dual functions. They act as navigation keys (up, down, left, and right) in menu systems.

Dedicated MENU key for DVD disc menus, some TVs and satellite receivers.

Table of Contents

Product Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Battery Information and Installation . . . . . . . . . . . . . . . . . . .3

Key Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Program for TV—Direct Entry Method . . . . . . . . . . . . . . . . .5

Program for VCR—Direct Entry Method . . . . . . . . . . . . . . .6

Program for Satellite or Cable Box—Direct Entry Method . . .7

Program for DVD or AUX—Direct Entry Method . . . . . . . . .8

Code Search Methods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Manual Code Search . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Auto Code Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Code Retrieval . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Sleep Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

On-screen Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Accessing a Menu System . . . . . . . . . . . . . . . . . . . . . . .12

Highlighting and Selecting Menu Items . . . . . . . . . . . .12

Exiting a Menu System . . . . . . . . . . . . . . . . . . . . . . . . .13

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Limited 90-Day Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . .15

BACKLIGHT key—

Turns backlighting on/off. (Select models only).

Actual model may vary from picture shown

Battery Installation and Information

Your universal remote requires two AAAAlkaline batteries (batteries may or may not be included, depending on model). To install the batteries:

1. Remove the battery compartment cover.

2. Insert the batteries, matching the batteries to the (+) and (–) marks inside the battery compartment.

3. Press and push the battery cover back into place.

Note: Reprogramming may be

required after batteries are replaced.

Congratulations on your purchase of the 4 component universal remote by RCA. This universal remote controls up to four electronic components and makes juggling remote controls a thing of the past. You can program this RCA universal remote to operate most models of most brands of infrared, remote-controlled components manufactured after

1990. (See the enclosed Code List for a complete list of brands.) The 4 component universal remote is easy to use, easy to program and gives you control at the touch of your fingertips.

Note: The 4 component universal remote is already

programmed to operate most RCA, GE and PROSCAN branded TVs, VCRs, DVD players and satellite receivers (DBS). Just press the corresponding component key—VCR for a VCR; DVD•AUX for a DVD player; TV for a television; DBS•CABLE for a satellite receiver or a cable box.

4 Component Universal Remote

Key Descriptions

Component keys (DVD•AUX, DBS•CABLE, VCR, TV): select the component you

want the remote to operate. (Lighted component key indicates operating mode).

For example, after you’ve programmed the remote to operate your TV, you must press the TV key first to put the remote in TV Mode. While in TV Mode, the CHAN keys change the channel on the TV, the VOL keys adjust the TV’s volume, etc.

ransport keys–REW (Rewind), PLAY, FF

(Fast Forward), P AUSE, STOP: operate the same as your original VCR or DVD remote control, although key labels may vary (REVERSE, FORWARD).

Backlight Key (select models only)

–turns backlighting on/off. Backlighting will remain on for approximately 6 seconds after last keypress to conserve battery life.

Other Keys (listed alphabetically)

0-9 (Number Keys): operate the same as number keys on your

original remote and are used to enter component codes when programming the remote control with Direct Entry method.

ANTENNA: in TV mode, switches between the signal coming from a satellite receiver or cable box and an off-air antenna. In VCR mode, switches between the signal coming from a VCR and a TV.

CHAN (Channel) UP AND DOWN: goes to the next highest or lowest channel number in the component channel list, respectively, except for DVDs. In DVDs, the CHAN UP/DOWN goes to the NEXT/PREVIOUS chapter. Additionally, when you’re using the remote with On-screen Menus, the CHAN keys act as UP ARROW and DOWN ARROW keys (moving the cursor or highlight up or down).

CODE SEARCH: use to program the remote. ENTER: use with Manual or Auto Code Search method to

accept code (See Code Search on page 9). Also, some brands require you to press the ENTERkey after you enter a channel number. In some menu systems, you must press

ENTER to select a highlighted item. MENU: accesses DVD disc menus when DVD•AUX key

is programmed to operate a DVD player. Accesses menu systems of some TVs, a few RCA brand VCRs and satellite receivers. (For more information, refer to Using On-screen Menus section on page 11).

MUTE: lowers the TV’s volume to its minimum level. ON•OFF: turns component on and off.

Note: Some RCA, GE and PROSCAN models require that

you press the component key to turn ON the component and the ON•OFF key to turn OFF the component.

PREV CH (Previous Channel): switches back to previous channel—operates the same as LAST CHANNEL, GO BACK or RECALL key found on some brands of remote controls.

REC (Record): use with VCR to record programming. You must press the REC key twice to start recording.

SLEEP: allows you to set a time to turn off your TV automatically.

VOL (Volume) UP and DOWN: increases or decreases the TV’s volume level. Additionally, when you’re using the remote with On-screen Menus, the VOL keys act as RIGHT or LEFT ARROW keys (moving the highlight or cursor right or left).

123

456

789

ON•OFF

TV CODE

Program for TV— Direct Entry Method

1. Manually turn on the TV.

2. Locate the enclosed TV Code List.

Find your brand of TV.

Note: If your brand isn’t listed,

use one of the Code Search methods to program this remote control (See Code Search on page 9).

3. Press and hold the CODE SEARCH

key for approximately three seconds until all four component keys light up. Then release the CODE SEARCH key.

4. Press and release the TV key.

The TV key remains lit.

5. Use the number keys to enter

the first code listed for your brand.

After you enter a valid 3-digit code, the component key light turns off.

Note: If you enter an invalid code,

the lighted component key will flash rapidly. Start over at step 3.

6. Aim the remote at your TV and press

the ON•OFF key. If your TV turns off, you have found the correct code.

7. Enter the code in the box provided

on this page for future reference.

8. If your TV doesn’t turn off, repeat

steps 3-6 above, entering the next code for your brand.

If none of the codes work or your brand is not listed, use one of the Code Search methods to program this remote (See Code Search on page 9).

For a description of each key on the remote control, refer to the Key Descriptions section on page 3-4.

In order for the four component universal remote to control your TV, you must program it with the TV code that matches your TV. These instructions explain the preferred method of programming the remote—the Direct Entry method.

CODE

Program for VCR— Direct Entry Method

1. Manually turn on the VCR.

2. Locate the enclosed VCR Code List. Find your brand of VCR.

Note: If your brand isn’t listed, use one

of the Code Search methods to program this remote control

(See Code Search

on page 9).

3. Press and hold the CODE SEARCH key for approximately three seconds until all four component keys light up. Then release the CODE SEARCH key.

4. Press and release the VCRkey. The VCR key remains lit.

5. Use the number keys on the remote to enter the first code listed for your brand.

After you enter a valid 3-digit code, the component key light turns off.

Note: If you enter an invalid code,

the lighted component key will flash rapidly. Start over at step 3.

6. Aim the remote at the VCR. Press the ON•OFF key. If your VCR turns off, you have found the correct code.

7. Enter the code in the box provided on this page for future reference.

8. If your VCR doesn’t turn off, repeat steps 3-6 above, entering the next code for your brand.

If none of the codes work or your brand is not listed, use one of the Code Search methods to program this remote (See Code Search on page 9).

For a description of each key on the remote control, refer to the Key Descriptions section on page 3-4.

In order for the four component universal remote to control your VCR, you must program it with the code that matches your VCR. These instructions explain the preferred method of programming the remote—the Direct Entry method.

ON•OFF

123

456

789

VCR CODE

CODE

Program for Satellite or Cable Box— Direct Entry Method

1. Manually turn on the satellite receiver or cable box.

2. Locate the enclosed Satellite or Cable Box Code List. Find your brand in the Satellite Codes or Cable Box Codes section, respectively.

Note: If your brand isn’t listed,

use one of the Code Search methods to program this remote control (See Code Search on page 9).

3. Press and hold the CODE SEARCH key for approximately three seconds until all four component keys light up. Then release the CODE SEARCH key.

4. Press and release the DBS•CABLE key. The DBS•CABLE key remains lit.

5. Use the number keys on the remote to enter the first code listed for your brand.

After you enter a valid 3-digit code, the component key light turns off.

Note: If you enter an invalid code,

the lighted component key will flash rapidly. Start over at step 3.

6. Aim the remote at the satellite receiver or cable box and press the ON•OFF key. If your Satellite receiver or cable box turns off, you have found the correct code.

7. Enter the code in the box provided on this page for future reference.

8. If your satellite receiver or cable box doesn’t turn off, repeat steps 3-6 above, entering the next code for your brand.

If none of the codes work or your brand is not listed, use one of the Code Search methods to program this remote (See Code Search on page 9).

For a description of each key on the remote control, refer to the Key Descriptions section page 3-4.

In order for the four component universal remote to control your satellite or cable box, you must program it with the code that matches your component. The DBS•CABLE key can be programmed to operate either

a satellite receiver or a cable box. These instructions explain the preferred method of programming the remote—the Direct Entry method.

ON•OFF

123

456

789

DBS (SATELLITE)

CABLE BOX CODE

CODE

DVD•AUX CODE

Program for DVD•AUX— Direct Entry Method

In order for the four component universal remote to control your DVD player or auxiliary component, you must program it with the code that matches your component. The DVD•AUX key can be programmed to operate a DVD player or a second TV, VCR, DBS or cable box. These instructions explain the preferred method of programming the remote—the Direct Entry method.

ON•OFF

123

456

789

1. Manually turn on the component you

wish to assign to the DVD•AUX key (TV, VCR, DVD, DBS System or Cable Box).

2. Locate the enclosed DVD code list, or the

corresponding code list for the auxiliary component (TV, VCR, DBS, or cable box).

Note: If your brand isn’t listed, use one of

the Code Search methods to program this remote control

(See Code Search on page 9).

3. Press and hold the CODE SEARCH

key approximately three seconds until all four component keys light up. Then release the CODE SEARCH key.

4. Press and release the DVD•AUX key. The DVD•AUX key remains lit.

5. To program for DVD, press the VCR key. For an auxiliary component, press the corresponding component key (TV, VCR, DBS•CABLE).

The DVD•AUX key will blink, then remain lit.

6. Use the number keys on the remote to enter the first code listed for your brand.

After you enter a valid 3-digit code, the component key light turns off.

Note: If you enter an invalid code,

the lighted component key will flash rapidly. Start over at step 3.

7. Aim the remote at your component and press the ON•OFF key. If your component turns off, you have found the correct code.

8. Enter the code in the box provided on this page for future reference.

9. If your component doesn’t turn off, repeat steps 3-7 above, entering the next code for your brand.

If none of the codes work or your brand is not listed, use one of the Code Search methods to program this remote (See Code Search on page 9).

For a description of each key on the remote control, refer to the Key Descriptions section page 3-4.

TV VCR CABLE DBS DVD

✓

CODE

Code Search Methods

Manual Code Search

1. Manually turn on the component you want the remote to operate.

2. Press and hold the CODESEARCH key for approximately three seconds until all four component keys light up. Then release the CODE SEARCH key.

3. Press and release the component key that corresponds to the component you want the remote to operate (TV, VCR or DBS•CABLE). The chosen component key remains lit.

Note: For DVD or AUX, press

DVD•AUX, then the component key

corresponding to the component to be stored under the AUX key. For DVD, press DVD•AUX, then the VCR key. For an auxiliary component, press DVD•AUX, then the corresponding component key (TV, VCR, DBS•CABLE).

4. Aim the remote at the component and press the ON•OFF key continuously until the component turns off. The component key remains lit during this process, blinking each time you press the

ON•OFF key.

Important: Because there are so many

codes, you may have to press the ON•OFF key many times—possibly up to 200 times.

5. When the component turns off, press the ENTER key immediately to store the code. The lighted component key then turns off.

6. Use Code Retrieval on the next page to identify the code for your component for future reference.

If your component’s brand isn’t listed in the Code List or you have tried all of the codes for your brand and the remote does not operate your component, use one of the Code Search methods below—Manual Code Search or Auto Code Search. Both Code Search methods search all of the codes because your component’s code may be listed under another brand in the code list.

Note: The Code Search method may take a long time because

the remote searches all of the codes in its memory for the code which operates your component. Therefore, if your brand is listed in the Code List, use the Direct Entry method described on pages 5-8.

ON•OFF

ENTER

CODE

1. Press and hold the CODE SEARCH key for approximately three seconds until all four component keys light up. Then release the CODE SEARCH key.

2. Press and release the component key that matches the component’s code you are retrieving (TV, VCR, or DBS•CABLE). The chosen component key remains lit.

If you used one of the Code Search methods to program your remote, follow the steps below to find out which code is compatible with your component. Finding the actual code and writing it down will save you time if you ever need to program the remote again (e.g., if programming is lost when you change the batteries).

Code Retrieval

ENTER

ON•OFF

Auto Code Search

1. Manually turn on the component you want the remote to operate.

2. Press and hold the CODESEARCH key for approximately three seconds until all four component keys light up. Then release the CODE SEARCH key.

3. Press and release the component key that corresponds to the component you want the remote to operate (TV, VCR, or DBS•CABLE). The chosen component key remains lit.

Note: For DVD or AUX, press

DVD•AUX, then the component key

4. Aim the remote at the component and press the ON•OFF key once. The remote automatically sends every code for the specified component one at a time, with a three second delay between each code. The lighted component key blinks each time a new code is sent. Keep the remote aimed at the component throughout the process.

5. As soon as the component turns off, you must press the ENTER key immediately so the remote stores the correct code. The lighted component key then turns off. If you don’t press ENTER within three seconds, the remote will send the next code in the list, and you will have to start over from step 2.

6. Use Code Retrieval to identify the code for your component for future reference.

CODE

DVD•AUX

DBS•

CABLE

VCR TV

PROGRAMMING SLEEP FEATURE

1. Press and hold the SLEEP key

until the TV component key lights. Release the SLEEP key.

2. Enter time in minutes using the

numerical key pad. The TV component key light turns off. (Minute 1 thru 9: press 0 before the actual number. Maximum: 99 minutes).

3. Leave remote aimed at television. (Sleep Feature will not work unless remote is left aimed at television.)

CANCELING THE SLEEP TIMER

The Sleep Timer program will be canceled and reset to zero by either of the following.

1. Press and hold the SLEEP key until the TV component key blinks.

2. Press the ON•OFF key, turning the TV off.

This feature will automatically turn off your TV at a duration you choose from 1 to 99 minutes.

Sleep Feature

ON•OFF

123

456

789

123

456

789

SLEEP

CODE

Note: For DVD or AUX, press

DVD•AUX, then the component

key corresponding to the component stored under the AUX key. For DVD, press DVD•AUX, then the VCR key. For an auxiliary component, press DVD•AUX, then the corresponding component key (TV, VCR, DBS•CABLE).

3. Press and release the CODESEARCH key. The component key light turns off.

4. Starting with 0 on the keypad, press the number keys in order (0-9) until the component key light blinks.

Note: For DVD or AUX, press

DVD•AUX, then the component key

5. The number that causes the component key light to blink is the first digit of your code.

6. Repeat step 4 until you have retrieved all three numbers of the code.

7. Refer to the code box to write down the code for your component within the Direct Entry Section (pages 5-8) for the component just programmed.

Highlighting and Selecting Menu Items

To navigate On-screen Menus, use the VOL UP/DOWN and/or CHAN UP/DOWN keys. VOL UP/DOWN keys move the cursor (or the highlight) right/left. CHAN UP/DOWN keys move the cursor (or the highlight) up/down. For RCA, GE or PROSCAN products, press the MENU or ENTER key to select the highlighted item. If menu items have numbers next to them, you can use the number keys to select an item. Additionally, the ENTER key can be used to select menu choices.

For Sony products, pressing the ENTER key while in Menu Mode returns you to the previous menu.

1. Make sure your components

are turned on and your TV is set to the component's input.

2. Press the component key on

the remote (TV, VCR, DVD•AUX, or DBS•CABLE) The chosen component key will blink once.

3. Press the MENU key. The chosen

component key blinks continuously to indicate the remote is in Menu Mode and the component’s menu should appear on the TV screen.

This is an example of a DVD disc On-screen Menu. English is the menu choice highlighted. Using this remote control, you would press the ENTER key to select English.

To highlight another language, you would press the CHAN DOWN key (In the example above, the highlight would move to Español).

Accessing a Menu System

This remote cannot access every menu system of all models and brands of consumer electronics components. However, if you’ve successfully programmed the DVD•AUX key to operate a DVD player, you can access DVD disc menus with the MENU key.

The MENU key will also access TV menu systems for most RCA, GE and PROSCAN TVs, as well as some other popular brands. Also, some RCA VCR menus are supported by this remote’s menu key. This remote also supports select satellite receiver menus.

If this remote’s MENU key doesn’t access the menu system for your component, you’ll need to use the original remote to change menu settings.

Note: This remote’s MENU key doesn’t support cable box

menu systems and some VCR menu systems.

Using On-screen Menus

Troubleshooting

Problem: The remote can’t be programmed to operate your component.

• You may be too far away from the component or at a wrong angle. This remote uses IR (infrared) technology to communicate with components. The remote sends the code and the component’s IR sensor reads the code.

Therefore, there must be an unobstructed path between the remote and the IR sensor on the component. Move closer and make sure you point the remote at the component (VCR when programming the VCR key; TV when programming the TV key; cable box or satellite receiver when you’re programming the DBS•CABLEkey; DVD Player when programming the DVD•AUX key).

• If you’ve entered all of the codes for your brand that are in the accompanying Code List and followed the instructions, try one of the Code Search methods (See Code Search on page 9).

• You must put the remote in the correct mode by pressing the corresponding component key (TV, VCR, DVD•AUX, or DBS•CABLE) so the remote knows which component you want to operate.

• To program the 4 component universal remote to operate a combination unit (TV/VCR or TV/DVD), first try the VCR or DVD codes for your brand. Some units, however, require that you program both the TV key (using the TV codes) and the VCR or DVD•AUX key (using the VCR or DVD codes) for full operation.

• To program the 4 component universal remote to operate a combination unit (VCR/DVD), program the VCR key using the VCR codes and then program the DVD•AUX key using the DVD codes.

Notes:

All functions in competitive models and brands of products may not be fully supported.

The remote will automatically time out in Menu Mode and the lighted component key will stop blinking after approximately 10 seconds of inactivity (no keys being pressed). For DVD menus, the Menu Mode will time out after approximately 15 seconds.

Because of the wide variety of menu formats, some experimenting may be required.

Exiting a Menu System

To exit Menu Mode, press the corresponding component key on the remote (TV, VCR, DVD•AUX, or DBS•CABLE). The lighted component key turns off and the remote reverts to its normal mode of operation.

Problem: The remote does not operate your component.

• You may have pressed an invalid key for the mode the

remote is in (for example, REC only works in VCR Mode).

• You must put the remote in the correct mode by pressing

the corresponding component key (TV, VCR, DVD•AUX, or DBS•CABLE) so the remote knows which component you want to operate.

• Remove any obstacles between the remote and the component. Make sure to aim the remote at the IR sensor on the component.

• Make sure the batteries are properly installed (See Battery Installation on page 3).

• Replace the batteries with two new AAA batteries. Reprogramming may be required.

• Reset the remote. Remove the batteries, then press and hold the number 1 key on the remote for several seconds to reset the microprocessor inside the remote. Release the number 1 key, reinstall the batteries, and try the remote again. Reprogramming will be required.

Problem: The remote is not performing commands properly.

• You must put the remote in the correct mode by pressing the corresponding component key (TV, VCR, DVD•AUX, or DBS•CABLE) so the remote knows which component you want to operate.

• Make sure component is “ready” (e.g., DVD player has disc loaded; VCR has tape loaded, etc.).

• You may have pressed an invalid key for the mode the remote is in (for example, REC only works in VCR mode).

• If you’re trying to turn on an RCA, GE or PROSCAN component, press the component key (TV, VCR, DVD•AUX, or DBS•CABLE) instead of the ON•OFF key.

• If operating a VCR to record, you must press the REC key two times.

• If you’re trying to change channels, try pressing the ENTER key after entering the channel number as this is a requirement of certain models and brands.

• There is a possibility that a programmed code may only be able to control some of your component features (e.g., only turns a component on and off). Follow the steps provided for programming the remote (See Programming Sections on pages 5-7). If the component can be turned on and off, make sure you press the CHAN UP/DOWN key to see if the component responds. If not, try the next code from the list.

Problem: The VCR won’t record.

• As a safety feature, you must press the REC key twice to begin recording.

• Make sure the tape is properly loaded in the VCR.

• Make sure the tape is not write-protected. If the safety tab is removed, the tape is write-protected and you cannot record onto that tape.

Problem: The remote will not change channels.

• You must put the remote in the correct mode by pressing the corresponding component key (TV, VCR, DVD•AUX, or DBS•CABLE) so the remote knows which component you want to operate.

• Press the ENTER key after you enter a channel number.

THOMSON INC. warrants that, for 90 days from date of purchase, it will replace this product if found to be defective in materials or workmanship. Return it postage prepaid to the Product Exchange Center address for a prompt, no-charge replacement with a current equivalent. This replacement is THOMSON INC.’s sole obligation under this warranty. THOMSON INC. will not be responsible for any incidental or consequential damages or for any loss arising in connection with the use or in ability to use this product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This warranty excludes defects or damage due to misuse, abuse or neglect. This warranty gives you specific legal rights, and you may also have other rights, which vary from state to state.

Product Exchange Center 11721 Alameda Avenue Socorro TX 79927

Limited 90-Day Warranty

Problem: The component’s menu doesn’t appear on the TV screen.

• The TV must be tuned to the Video Input that matches the manner in which you connected the component to the TV.

For example, if you connected your DVD player to your TV by connecting audio/video cables (usually color-coded yellow, red, and white) to the TV’s Input 1 jack, you must tune the TV to its Video Input 1 channel. Remember, different manufacturers label these jacks differently. Consult the instruction manual that came with the TV for more information.

• You must put the remote in the correct mode by pressing the corresponding component key (TV, VCR, DVD•AUX, or DBS•CABLE) so the remote knows which component you want to operate.

• Menu access isn’t supported for all brands. If that’s the case, you’ll need to use your original remote control to access menu functions for these components.

If you have further questions, please visit www.rca.com.

Consolidate four remote controls into one!

Compatible with today’s most popular brands!

Your RCA universal remote control is compatible with most brands of infrared remote-controlled components manufactured after 1990. Some well-known brands are shown below. The complete list of brands is found on the code list inside this package. The remote already operates most RCA, GE and

PROSCAN products without any programming!

Requires two AAA batteries

(sold separately).

10330 North Meridian Street

Indianapolis IN 46290

Made in Indonesia.

RCU450 US IB REV A

Trademark(s) ®Registered.

Marca(s) Registrada(s).

www.rca.com

Operates up to four components, including:

• TV • VCR

• Satellite receiver or Cable box • DVD or AUX

Dedicated MENU key

Operates menu system of major TV brands (most RCA, GE, and PROSCAN), and some other popular brands. Operates DVD disc menus!

Apex Audiovox Broksonic Citizen Curtis Mathes Daewoo Emerson

Hisense Hitachi JC Penney JVC Kenwood LG (Goldstar) LXI Magnavox Mitsubishi Montgomery Ward NEC Orion Panasonic Philco Philips Pioneer Prima

PROSCAN

Quasar RadioShack/ Realistic

RCA

Samsung Sanyo Sears Sharp Sony Sylvania Tandy Teknika Toshiba Victor Wards Yamaha Zenith

DVD

Aiwa Apex Broksonic Daewoo Emerson Funai Go-Video Hitachi JVC Kenwood Konka Magnavox Memorex Mintek Mitsubishi NAD Onkyo Orition Panasonic Philips Pioneer

PROSCAN

Qwestar

RCA

Samsung Sansui Sanyo Sharp Sony Sylvania Toshiba Zenith

VCR

Canon Curtis Mathes Daewoo Emerson

Go-Video Hitachi JC Penney JVC Kenwood LG (Goldstar) LXI Magnavox Matsushita Mitsubishi Montgomery Ward NEC Panasonic Philco Philips Pioneer

PROSCAN

Quasar RadioShack/ Realistic

RCA

Samsung Sanyo Sears Sharp Sony Sylvania Tandy Teknika Toshiba Victor Wards Yamaha Zenith

SAT

Alphastar Dish Network Echostar Express Vu

Hitachi Hughes JVC Magnavox Motorola Panasonic Philips Primestar

PROSCAN RCA

Sony Star Choice Toshiba Uniden

Cable

ABC Archer Cableview Citizen Garrard GC Electronics GE General Instruments Jerrold Motorola Philips Pioneer RCA Scientific Atlanta United Cable Universal View Star Zenith

Date Code

RCA pp18l, RCU450 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
