RCA LCDX3022W User Manual
LCD Television
User’s Guide
Important Information
CAUTION
RISK OF ELECTRIC
SHOCK DO NOT OPEN
Caution: To reduce the risk of electric shock, do not
remove cover (or back). No user serviceable parts
inside. Refer servicing to qualified service personnel.
WARNING
To reduce the risk of fire or electric
shock, do not expose this product
to rain or moisture.
The apparatus shall not be exposed
to dripping or splashing and that
no objects filled with liquids, such
as vases, shall be placed on the
apparatus.
Refer to the identification/rating label located on the back panel of your
product for its proper operating voltage.
FCC Regulations state that unauthorized changes or modifications to this
equipment may void the user’s authority to operate it.
Cable TV Installer: This reminder is provided to call your attention to Article
820-40 of the National Electrical Code (Section 54 of the Canadian Electrical
Code, Part 1) which provides guidelines for proper grounding and, in
particular, specifies that the cable ground shall be connected to the grounding
system of the building as close to the point of cable entry as practical.
This symbol indicates important instructions
accompanying the product.
This symbol indicates "dangerous voltage"
inside the product that presents a risk of
electric shock or personal injury.
Product Registration
Please fill out the product registration card (packed separately) and return it immediately. For U.S. customers: Your RCA
Scenium Consumer Electronics product may also be registered at www.rcascenium.com/productregistration. Registering
this product allows us to contact you if needed.
Product Information
Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the
serial and model numbers. These numbers are located on the product.
Model No. ____________________ Serial No. ________________________ Purchase Date: ______________
Dealer/Address/Phone: _________________________________________________________________________
Important Information
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and a
third grounding prong. The wide blade or the third prong is provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving
the cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
15. If an outside antenna or cable system is connected to the product, be sure the antenna or
cable system is grounded so as to provide some protection against voltage surges and builtup static charges. Section 810 of the National Electrical Code, ANSI/NFPA No. 70-1984
(Section 54 of Canadian Electrical Code, Part 1) provides information with respect to proper
grounding of the mast and supporting structure, grounding of the lead-in wire to an
antenna-discharge unit, size of grounding conductors, location of antenna-discharge unit,
connection to grounding electrodes, and requirements for the grounding electrode. See
following example.
ELECTRIC SERVICE
EQUIPMENT
ANTENNA
LEAD IN
WIRE
GROUND CLAMP
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
i
This page left intentionally blank.
Table of Contents
Chapter 1: Connections & Setup
Things to Consider Before You Connect ........................................................................................ 3
Protect Against Power Surges.................................................................................................. 3
Protect Components from Overheating.................................................................................. 3
Important Stand and Base Safety Information ....................................................................... 3
Position Cables Properly to Avoid Audio Interference........................................................... 3
Use Indirect Light...................................................................................................................... 3
Connection Illustrations ........................................................................................................... 3
Check Supplied Parts ................................................................................................................ 3
Explanation of Jacks ........................................................................................................................ 4
Connect Your Cable ......................................................................................................................... 6
Choose Your Connection ................................................................................................................. 6
Connection to AV Components ............................................................................................... 6
Connection to a Personal Computer ....................................................................................... 8
Plug in the TV................................................................................................................................... 8
Put batteries in the remote............................................................................................................. 8
Turn on the TV ................................................................................................................................. 8
Adjust the Viewing Angle of the TV ..............................................................................................8
Set Up Your TV ................................................................................................................................. 8
Choose the Menu Language .................................................................................................... 9
Choose the Signal Type ............................................................................................................ 9
Complete Channel Search ........................................................................................................ 9
Chapter 2: Using the Remote Control
Button Descriptions for TV Mode.................................................................................................10
Button Descriptions for Other Modes.......................................................................................... 11
Using the INPUT Button ......................................................................................................... 11
Programming the Remote to Operate Other Components ........................................................ 12
Find Out If You Need to Program the Remote ..................................................................... 12
Programming the Remote ..................................................................................................... 12
How to Use the Remote After You’ve Programmed It ......................................................... 13
The Learning Feature .................................................................................................................... 13
Adding a Learned Function ................................................................................................... 14
Clearing a Learned Function .................................................................................................. 14
Deleting ALL Learned Functions ............................................................................................ 15
Volume Punchthrough Feature .....................................................................................................15
Deleting ALL Volume Punchthrough Commands ................................................................. 16
Remote Code List ........................................................................................................................... 16
Chapter 3: Using the TV’s Features
About the Channel Banner ........................................................................................................... 18
Why You Should Use the Autotuning Feature ............................................................................ 18
How to Set Up the Autotuning Feature................................................................................ 18
PIP (Picture-in-PC) Operation ........................................................................................................ 19
Parental Controls ........................................................................................................................... 20
How V-Chip Works .................................................................................................................. 20
US V-Chip Rating System ........................................................................................................ 21
Canadian English V-Chip Rating System ............................................................................... 21
Canadian French V-Chip Rating System ................................................................................ 22
V-Chip TV Ratings ................................................................................................................... 22
Blocking Specific Content Themes......................................................................................... 24
Viewing Specific Content Themes ......................................................................................... 24
V-Chip Movie Rating Limit ..................................................................................................... 24
Blocking Canadian V-Chip Ratings ........................................................................................ 25
V-Chip Unrated/Exempt Block ............................................................................................... 26
Front Panel Block .................................................................................................................... 26
Channel Block ......................................................................................................................... 26
Lock/Unlock Parental Controls ............................................................................................... 27
Additional Features ....................................................................................................................... 27
1
Table of Contents
Chapter 4: Using the Menu System
Menus, On-screen Help, and Control Panels ............................................................................... 28
Exiting a menu ........................................................................................................................ 28
Controls ................................................................................................................................... 28
Picture Menu .................................................................................................................................. 29
Sound Menu................................................................................................................................... 30
Parental Control Menu .................................................................................................................. 31
Preferences Menu .......................................................................................................................... 31
Setup Menu.................................................................................................................................... 32
PC Picture Quality Menu ............................................................................................................... 33
PC Picture Size Menu ..................................................................................................................... 33
PC Sound Menu ............................................................................................................................. 33
PC Preferences Menu..................................................................................................................... 34
PC Information Center................................................................................................................... 34
Chapter 5: Other Information
Troubleshooting ............................................................................................................................. 35
Care and Cleaning ......................................................................................................................... 36
Limited Warranty........................................................................................................................... 37
Accessory Information .................................................................................................................. 39
2
Chapter 1: Connections & Setup
Things to Consider Before You Connect
Protect Against Power Surges
• Connect all components before you plug any of their power cords into the wall outlet or power strip. NEVER plug
your TV into an outlet that is controlled by a wall switch.
•Turn off the TV and/or component(s) before you connect or disconnect any cables.
• Make sure all antennas and cables are properly grounded. Refer to the Important Safeguards Instructions at the
beginning of the manual.
Protect Components from Overheating
• Don’t block ventilation holes on any of the components. Arrange the components so that air can circulate freely.
• Don’t stack components.
• If you place components in a stand, make sure you allow adequate ventilation.
• If you connect an audio receiver or amplifier, place it on the top shelf so the heated air from it won’t flow around
other components.
Important Stand and Base Safety Information
If a stand or base is used ensure that is of adequate size and strength to prevent the TV from being accidentally tipped
over, pushed off, or pulled off. This could cause personal injury and/or damage the TV. Refer to the Important Safety
Instructions at the beginning of the manual.
Position Cables Properly to Avoid Audio Interference
Insert each cable firmly into the designated jack.
Use Indirect Light
Don’t place the TV where sunlight or room lighting will be directed toward the screen. Use soft or indirect lighting.
Connection Illustrations
The components used in the connection illustrations are for representation only. The input jacks and the output jacks
on the back of your components (VCR, DVD player, etc.,) might look different than those illustrated.
Check Supplied Parts
Check that the following parts were packed with your product.
ON-OFF
learning
TV
DVD VCR
AUX
SAT
//
AUDIO
CAB
HD
PIP
SWAP
PIP+
SLEEP
Z
Z
ZOOM
FREEZE
PIP-
DISC MENU INFO
i
CLEAR
c
ZOOM- ZOOM+
K
O
PRESETS
GUIDE
VOLVOL
MUTEMUTE GO
BACKGOBACK
225511
44
77 88
INPUTINPUT ANTENNAANTENNA
00
PLAYPLAY FORWARDFORWARDREVERSEREVERSE
STOPSTOP
Z
LIGHT
MENU
M
SKIP
CH
33
66
99
PAUSEPAUSERECORDRECORD
2 AA batteries
3.5mm mini phone
to audio cable adapter
(use with the RGB Audio
In jack, not the
headphone jack)
Power cord
Remote Control
Chapter 1 3
Graphics contained within this publication are for representation only.
Connections & Setup
Explanation of Jacks
This section describes the jacks and cables you might use to make connections. There are
several ways to connect components to your TV.
Different jacks and cables provide a different level of performance. It’s important to remember
the different degrees of picture improvement for comparison. The YPbPr (component) jack is
considered an excellent improvement; S-Video and Video (composite) jacks are considered
very good; while the Antenna/Cable connection is good.
MENU
POWER
VOL
CH
R
L
AUDIO
IN
DVI
AUDIOINPr Pb Y RL/
RGB
VIDEO IN
CMPT
AUDIO
S-VIDEO
RL/
IN
AUDIOINVIDEO
VID1
Mono
IN
Mono
ANTENNA/
IN
CABLE
SUBWOOFER
OUT
AUDIO OUTPUT
RLAUDIO
OUT
Side Panel
Bottom Panel (lift the panel as shown above to view the jacks)
Bottom Panel
DVI Input Lets you connect an HD receiver, HD cable box, or a computer with a DVI output.
•R AUDIO IN Provides right audio connection when using the DVI jack. The right audio
connector is usually red.
•L AUDIO IN Provides left audio connection when using the DVI jack. The left audio
connector is usually white.
• DVI (Digital Visual Interface) For connection of components that have a DVI jack, such
as an HD receiver. The DVI jack provides an uncompressed, digital video interface
developed for high-bandwidth digital connection. It supports the overlay of high-resolution
graphics used by some program guides and interactive components.
RGB Input
• RGB For connection of components that have an RGB output jack, such as a personal
computer, HD receiver, or DVD player.
• AUDIO IN (Stereo mini jack) Use to obtain sound when a component is connected to
the RGB jack. Use the supplied 3.5mm mini phone to audio cable adapter. Connect audio
cables to the end of the adapter.
4 Chapter 1Graphics contained within this publication are for representation only.
Connections & Setup
CMPT (Component) Input
•Y Pb Pr VIDEO IN For connection of components that have component output jacks (Y, Pb, Pr), such as a
personal computer, HD receiver, DVD player, or other device with component outputs.
The Y Pb Pr jacks provide excellent picture quality because the video is separated into three signals.
•R AUDIO IN Provides right audio connection when using the Y Pb Pr jacks. The right audio connector is
usually red.
• L/Mono AUDIO IN Provides left audio connection when using the Y Pb Pr jacks. The left audio connector is
usually white.
Note: If your component has only one output for audio (mono), connect it to the L/Mono AUDIO jack on the
TV and don’t connect the R AUDIO part of the cable. In this case, you need to change a setting to hear sound
from both speakers. Go to the Sound menu, highlight Sound Type and then choose Mono.
VID1 Input
• S-VIDEO IN The S-Video (super video) jack provides better picture quality than the regular video jack
because the color (chrominance, also called chroma) part of the signal is separated from the black and white
(luminance) part of the picture.
Note: Remember to connect the left and right audio cables to the AUDIO IN jacks because the
S-VIDEO cable carries only the picture signal, not the sound.
•R AUDIO IN Provides right audio connection when using the VIDEO or S-VIDEO jack. The right audio
connector is usually red.
• L/Mono AUDIO IN Provides left audio connection when using the VIDEO or S-VIDEO jack. The left audio
connector is usually white.
Note: If your component has only one output for audio (mono), connect it to the L/Mono AUDIO jack on the
TV and don’t connect the R AUDIO part of the cable. In this case, you need to change a setting to hear sound
from both speakers. Go to the Sound menu, highlight Sound Type and then choose Mono.
• VIDEO IN Provides composite video connection. The video connector is usually yellow.
ANTENNA/CABLE Lets you connect a coaxial cable to receive the signal from the antenna, cable, or cable box.
AUDIO OUTPUT
• SUBWOOFER OUT Provides lower bass frequencies out from the TV and to a powered subwoofer.
•R AUDIO OUT Use to output the right audio of the selected source component connected to this unit to an
AV amplifier or similar component.
•L AUDIO OUT Use to output the left audio of the selected source component connected to this unit to an AV
amplifier or similar component.
Note: Set the Audio output to Fixed or Variable in the Sound menu. Go to page 31 for more information.
Power In Connect the power cord to this jack to give the TV power.
Side Panel
• Headphone Allows you to connect headphones to listen to the sound coming from the TV.
Note: When you plug in headphones, the TV’s internal speakers are automatically turned off.
If you can’t locate your remote, you can use the side panel of your TV to operate many of the TV’s features.
MENU Brings up the Main menu. When the menu system is displayed, pressing MENU selects highlighted items.
VOL
Increases the volume. In the menu system, it points right to items and adjusts menu controls.
VOL
Decreases the volume. In the menu system, it points left to items and adjusts menu controls.
CH
Scans up through the current channel list. In the menu system, it points up to items and adjusts menu
controls.
CH
Scans down through the channel list. In the menu system, it points down to items and adjusts menu
controls.
POWER Turns the TV on and off.
Note: If you use the Front Panel Block feature, the front panel buttons no longer provide access to the menus.
Go to Chapter 3 for more information.
Chapter 1 5
Graphics contained within this publication are for representation only.
Connections & Setup
A
Connect Your Cable
Connect your cable or antenna to the ANTENNA/CABLE jack on the bottom panel of the TV
using a coaxial cable.
CABLE
OR
OFF-AIR ANTENNA
NTENNA/
CABLE
SUBWOOFER
OUT
AUDIO OUTPUT
RLAUDIO
OUT
Choose Your Connection
There are several ways to connect your television, depending on the components you want to
connect and the quality of the signal you want to achieve. The following are examples of some
ways to connect your TV. Choose the connection which is best for you.
Connection to AV Components
Using the DVI Jack
Connect a component, such as an HD receiver, to the TV using the DVI jack. Connect one end
of a DVI cable (not supplied) to the DVI jack on the bottom of the TV and the other end to the
DVI Out jack on the back on the component. Then connect the audio cables to the DVI AUDIO
IN jacks (R and L) next to the DVI jack on the TV and to the Audio Out jacks on the
component.
Note: When using the DVI jack to receive your signal, all necessary information is
transferred from the receiver to the TV. Therefore, there is no need to make adjustments
in the Main Menu.
R
L
AUDIO
IN
DVI
ˇ˝ˇ˝ˇ˝ˇ˝ˇ˝ˇ˝
ˇ˝ˇ˝ˇ˝ˇ˝ˇ˝ ˇ˝ˇ˝ˇ˝ˇ˝ ˇ˝ˇ˝ˇ˝ˇ˝ˇ˝ ˇ˝ˇ˝ˇ˝ˇ˝ˇ˝
HD receiver (RCA Scenium ATSC21, for example)
6 Chapter 1Graphics contained within this publication are for representation only.
Connections & Setup
Using the CMPT Jack
Connect a component, such as a VCR, DVD player or Satellite Receiver, to the TV using the
CMPT jacks. Connect Component cables to the Y Pb Pr VIDEO IN jacks on the bottom panel of
the TV and to the Component Out jacks on the component. Then connect audio cables to the
CMPT AUDIO IN jacks (R and L) on the bottom panel of the TV and to the Audio Output jacks
on the component.
Note: The CMPT input also accepts Y Cr Cb signals. Your TV will automatically adjust to
that type of signal.
Pr Pb Y RL/
VIDEO IN
AV component
CMPT
AUDIO
Mono
IN
Using the RGB Jack
Connect a component, such as a DVD player or digital cable box, to the TV using the RGB
jack. Connect one end of a 15 pin D-sub cable to the RGB jack on the bottom of the TV and
the other end to the RGB out jack on the component. Then connect the supplied 3.5mm mini
phone to audio cable adapter to the RGB AUDIO IN jack on the bottom of the TV. Connect
audio cables to the adapter and connect the other end to the Audio Output jacks on the
component.
AUDIO
IN
RGB
AV component
Chapter 1 7
Graphics contained within this publication are for representation only.
Connections & Setup
Connection to a Personal Computer
Using RGB
Connect a personal computer to the TV using the RGB jack. Connect a 15-pin monitor cable to the
computer and the other end to the bottom of the TV.
Note: Your computer will most likely output the signal in a 4:3 aspect ratio. Be sure to
change the monitor setting for the best picture quality.
AUDIO
IN
RGB
SUBWOOFER
OUT
AUDIO OUTPUT
RLAUDIO
OUT
Plug in the TV
Plug the flat end of the cable into the power jack on the bottom panel
of the TV. Plug the end of the power cord into an appropriate wall
outlet. Be sure to insert the plug completely. Do not plug into an outlet
controlled by a light switch.
Put batteries in the remote
• Remove the battery compartment cover from the back of the remote by pushing down on the
tab and lifting the cover.
• Insert 2 fresh “AA” batteries. Make sure the polarities (+ and -) are aligned correctly.
• Replace the cover.
Turn on the TV
Press TV on the remote, or press POWER on the TV’s side panel.
Note: Pressing the TV button turns on the TV and puts the remote into TV mode. “TV mode”
means that the buttons on the remote control operate the TV’s functions.
Adjust the Viewing Angle of the TV
The TV’s screen is adjustable simply by pushing on the top, front part of the screen, while your
other hand holds the base of the TV.
Set Up Your TV
There are several options you might need to set up in order for your TV to work properly. Turn on
your TV, then press the MENU button on your remote control. Read the instructions that follow.
8 Chapter 1Graphics contained within this publication are for representation only.
MAIN MENU
Sound
Parental Control
Preferences
Setup
Preferences
Language English. . .
Press MENU or CLEAR to exit.
Closed Caption. . .
Menu Time-out 10 Seconds
Menu Position
Menu Background Opaque. . .
Timers. . .
Press </> or OK to select.
Press MENU to go to Main Menu.
Connections & Setup
Choose the Menu Language
Select your preferred language for the menu system.
1. From the Main menu, press the down arrow button to highlight
Preferences, then press OK (the Preferences menu appears with
Language highlighted).
2. The default language is English. To select French or Spanish,
press the right arrow button.
MAIN MENU
Sound
Parental Control
Preferences
Setup
Setup
Press MENU or CLEAR to exit.
Signal Type Cable. . .
Auto Channel Search Start. . .
Autotuning. . .
Channel List. . .
Press </> to select.
Press MENU to go to Main Menu.
Setup
Signal Type Cable. . .
Auto Channel Search Start. . .
Autotuning. . .
Channel List. . .
Choose the Signal Type
In order for your TV to search for channels, you need to make sure
your signal type is set correctly.
1. Press the MENU button (the MAIN MENU appears).
2. Press the down arrow button to highlight Setup, then press OK
(the Setup menu appears with Signal Type highlighted).
3. The Signal Type option is set to Cable. To change the option to
Antenna, press the right arrow button.
Complete Channel Search
To search for all channels viewable through your antenna or cable TV
system:
1. From the Setup menu, press the down arrow button to highlight
Auto Channel Search.
2. Press the right arrow button to begin the channel search.
Note: Depending on the number of channels you receive, it may
take several minutes for the channel search to finish.
Press </> to start. Press MENU to go to Main Menu.
Press OK to stop search.
Chapter 1 9
Graphics contained within this publication are for representation only.
Chapter 2: Using the Remote Control
ON-OFF
learning
TV
DVD VCR
AUX
SAT
//
CAB
PIP
SWAP
ZOOM
FREEZE
DISC MENU INFO
CLEAR
c
ZOOM- ZOOM+
PRESETS
VOLVOL
MUTEMUTE GO
11
44
77 88
INPUTINPUT ANTENNAANTENNA
OK
GUIDE
22
55
00
PLAYPLAY FORWARDFORWARDREVERSEREVERSE
STOPSTOP
HD
PIP+
PIP-
BACKGOBACK
i
AUDIO
SLEEP
Z
LIGHT
MENU
SKIP
33
66
99
PAU SEPAUSERECORDRECORD
Button Descriptions for TV Mode
Arrows Used to highlight different items in the TV menu and to
adjust the menu controls. When not in the menu system, the left arrow
(ZOOM-) zooms out on the picture. The right arrow (ZOOM+) zooms
in on the picture.
(0-9) Number Buttons Enter channel numbers and password
ZZ
M
CH
settings directly through the remote control.
CH + or CH - Scans up or down through the current channel list.
Press once to change the channel up or down; press and hold to
continue changing channels.
CLEAR Removes any menu or display from the screen and returns
you to normal viewing. Cancels the commercial skip timer.
FREEZE Freezes entire picture, but audio continues.
GO BACK Returns you to the previous channel.
INFO Brings up the channel banner; press again to clear the screen.
INPUT Toggles through the available input sources (VID1, CMPT,
RGB, DVI and current channel).
LIGHT Press to illuminate some of the remote control’s buttons. To
conserve battery power, the light turns off after several seconds.
Backlight won’t activate if batteries are low, but blinks on and off
quickly.
MENU Brings up the Main menu.
MUTE Reduces the TV’s volume to its minimum level. Press again to
restore the volume.
OK When in the menu system, selects highlighted items.
ON•OFF When in TV mode, turns the TV on or off. If in another
mode (VCR, DVD, SAT/CABLE, AUX/HD, AUDIO) and programmed,
will turn the component on or off.
Tip
The VCR, DVD, SAT/CAB, AUX/HD, and AUDIO
buttons turn on most RCA, GE, and Proscan
components.
PRESETS Resets the picture settings to factory default for the video
input channel you’re currently tuned to.
SKIP Press once before changing channels and the TV will wait 30
seconds before returning to the original channel. Press repeatedly to
add more time.
SLEEP Displays the Sleep Timer option.
TV Turns on the TV and puts the remote in TV mode. Also displays
current status.
VOL – or VOL + Decreases or increases the TV’s volume.
10 Chapter 2
Graphics contained within this publication are for representation only.
Loading...
