L46WD22
Product Size (H x W x D) with stand: 32.0 x 45.2 x 12.0 inches
w/o stand: 29.5 x 45.2 x 4.8 inches
46" diagonal LCD Flat Panel HDTV
Features and Benefits
EN-V Picture Processing Technology Designed to Provide Enhanced Color and Contrast So You Can Enjoy a Crisp
Picture with Magnificent Clarity
Built-in High Definition Digital (NTSC/ATSC/QAM) Tuner for Access to Off-Air Digital Programming or Unscrambled Digital Cable*
BBE® Digital Maximizes Simulated Sound Effects While Maintaining Clarity and Definition
2 Built-in HDMI™ Connections Provide High Definition Video and Audio to Connect to the Latest Digital Devices
2 HD Component Inputs and a PC Input
* Cable TV subscription required. Check with your
cable company for availability in your area.
46" diagonal LCD Flat Panel HDTV
REAR JACK PANEL
REAR JACK PANEL
SIDE JACK PANEL
ANTENNA CABLE INPUT
AUDIO\VIDEO INPUT 2
DIGITAL AUDIO
OUTPUT
(COAXIAL)
2 COMPONENT INPUT
(1080i/720p/480p/480i)
HDMI 1/DVI INPUT HDMI 2 INPUT
DVI AUDIO INPUT
L –– AUDIO –– R
AUDIO INPUT VGA INPUT
L –– AUDIO –– R
AUDIO\VIDEO INPUT 1
L –– AUDIO –– R
VIDEOVIDEO
FIXED/VARIABLE
AUDIO OUTPUT
L –– AUDIO –– R
PC INPUT
R –– AUDIO –– L
VIDEO
HEADPHONE
USE TV MENU
TO SET OPTIONS
S-VIDEO
(DIGITAL AND AN ALOG)
PRPBY
1 COMPONENT INPUT
(1080i/720p/480p/480i)
L –– AUDIO –– R
PRPBY
Specifications
BRAND RCA
TECHNOLOGY
Tuner NTSC/ATSC/QAM
Analog Video Formats (NTSC/480i) AV / S-Vid / Component
Video Formats (480p, 720p, 1080i) Component, HDMI
HDTV Capability Yes
Category LCD
Display Type TFT LCD
Screen Size 46"
Display Aspect Ratio 16:9
Display Resolution 1366x768
Brightness (cd/m2) 500
Contrast Ratio 2000:1
Viewing Angle Horizontal/Vertical 178/178
Response Time 8 ms
Enhanced Video Processing Yes
Adjustable Color Temperature Yes
Adjustable Picture Control
Format Control Yes
Comb Filter 3D/YC
Reverse 3:2 Pull Down (Film Mode) Yes
Noise Reduction Yes
SOUND
Audio Power (Watts) Front Speakers 8 W/CH x 2
Treble, Bass, Balance, Volume, Mute Control Yes
Broadcast Stereo MTS Stereo
Second Audio Program (SAP) Yes
Dolby * Processing Yes
Headphone Adjustments Yes
Premium Sound
CONVENIENCE
Side Panel Controls Power, CH +/–, Vol +/–, Menu
Auto Channel Search Yes
Autotune (1-button launch) Yes
Multilingual On–Screen–Display English, French, Spanish
Channel Labelling Yes
Closed Caption Qualified Yes
ENERGY STAR® Compliant Yes
Parental Control (V–Chip) USA & Canada
Picture Reset Yes
Picture Memory Presets Yes
Clock Yes
Sleep Timer Yes
Alarm (Wake Up Timer) Yes
PC Compatibility Yes (via RGB & DVI)
REAR CONNECTIONS — INPUTS
RF Input (ATSC/NTSC) 1
Composite Video Input 1
bright, cont, sharp, color, tint
BBE® Digital **
L46WD22
Audio Input for Composite Video/S-Video 1 L/R
PC Input 1 - RGB
Audio Input for PC 1 - 3/5mm PC Audio
Component Video Input (YCrCb/YPrPb) 2
Audio Input for Component Video 2 L/R
HDMI*** Inputs 2 (1 DVI Compatible Only)
Audio input for DVI 1 L/R for DVI
REAR CONNECTIONS — OUTPUTS
Audio Output 1 L/R (Fixed Variable)
Digital Audio Output 1 Coaxial
SIDE PANEL INPUTS/OUTPUTS
Composite Video Input 1
Audio Input for Composite/S-Video 1 L/R
S-Video Input 1
USB Input 1 - SW Upgrade Only
Headphone Jack Output Yes
REMOTE CONTROL
Model Number R301F1
Type 3-Device Universal Remote
Batteries Included Yes
SUPPLIED ACCESSORIES
Power Supply Built-in
Power Cord Yes
Quick Start Guide Yes
User’s Guide & Warranty (E/F/S) RCA.com website
GENERAL
TV Finish Black
Detachable Base Yes, Glossy B lack
VESA Wall Mount Compatible Yes (600 x 400 / M6)
Packaging Size (HxWxD) inches 36.0 X 51.2 X 16.6
Weight (lbs) (Product/Packaged) 70.0 / 85.8
ENERGY STAR and the ENERGY STAR
mark are registered U.S. marks.
* Dolby is a registered trademark of Dolby Laboratories.
** Manufactured under license from BBE Sound, Inc
*** HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.
Product features, definitions and physical specifications are subject to change without notice.
RCA and associated marks are trademarks of THOMSON S.A. used under license to TTE CORPORATION.
TTE Technology, Inc.
Indianapolis, IN USA 46290
