RCA L32HD32D, L26HD32D User Manual

ATTENTION

If you purchase a universal remote control from your local retailer, please contact the remote manufacturer for the required programming code.

AIR/CABLE MODE SELECTION

When shipped from the factory, the Signal Type option is set to the “Cable” (Cable Television) mode. If not using Cable TV, set this menu option to the “Air” position.

Before operating the unit, please read this manual thoroughly.

26/32” TFT LCD DIGITAL TV WITH DVD PLAYER

OWNER’S MANUAL

L26HD32D L32HD32D

Digital Television Transition Notice

This device contains a digital television tuner, so it should receive digital over the air TV programming, with a suitable antenna, after the end of full-power analog TV broadcasting in the United States on Februar y 17, 2009. Some older television receivers, if they rely on a TV antenna, will need a TV Converter to receive over the air digital programming, but should continue to work as before for other purposes (e.g., for watching low-power TV stations still broadcasting in analog, watching pre-recorded movies, or playing video games). When a Converter is used with an older television receiver, a signal splitter might be necessary to continue to receive low-power analog broadcasts via an antenna. For more information, please see www.DTV.gov. For information on the TV Converter program, and on government subsidized coupons that may be used toward the purchase of one, see www. dtv2009.gov, or call the NTIA at 1-888-DTV-2009.

51F0101B_eng.indd 1 4/4/08 10:04:02 AM

ANT

AC INPUT

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

WARNING:SHOCK HAZARD-DO NOT OPEN. AVIS:RISQUE DE CHOC ELECTRIQUE-NE PAS OUVRIR

CAUTION:

THIS DIGITAL VIDEO PLAYER EMPLOYS A LASER SYSTEM. TO ENSURE PROPER USE OF THIS PRODUCT, PLEASE

READ THIS OWNER'S MANUAL CAREFULLY AND RETAIN FOR FUTURE REFERENCE. SHOULD THE UNIT REQUIRE MAINTENANCE, CONTACT AN AUTHORIZED SERVICE LOCATION-SEE SERVICE PROCEDURE.

USE OF CONTROLS, ADJUSTMENTS OR THE PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

TO PREVENT DIRECT EXPOSURE TO THE LASER BEAM, DO NOT TRY TO OPEN THE ENCLOSURE. RADIATION MAY BE PRESENT WHEN THE ENCLOSURE IS OPENED. DO NOT STARE INTO THE BEAM.

Location of the required Marking

The rating sheet and the safety caution are on the rear of the unit.

The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN

OR MOISTURE.

CAUTION: TO PREVENT ELECTRIC SHOCK DO NOT USE THIS POLARIZED PLUG WITH AN EX-

TENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.

CERTIFICATION: COMPLIES WITH FDA RADIATION PERFORMANCE STANDARDS, 21 CFR SUBCHAPTER J.

The lamp(s) within this product contain mercury. Disposal should be in compliance with local, state or federal laws.

Product Registration

Please fill out the product registration card (packed separately) and return it immediately. For US customers: Your RCA Consumer Electronics product may also be registered at www.rca.com/television. Registering this product allows us to contact you if needed.

Product Information

Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the serial and model numbers in case you need them. These num bers are located on the product.

Model No._____________________ Serial No. __________________________Purchase Date: __________________________

Dealer / Address / Phone: __________________________________________________________________________________

WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant

to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help. CAUTION: Changes or modifications not expressly approved by the partly responsible for compliance with the FCC Rules

could void the user’s authority to operate this equipment.

51F0101A_eng.indd 2 3/10/08 10:56:09 AM

IMPORTANT SAFETY INSTRUCTIONS

-NATIONAL ELECTRICAL CODE S2898A

EXAMPLE OF ANTENNA GROUNDING AS PER THE

NATIONAL ELECTRICAL CODE

51F0101A_eng.indd 3 3/5/08 5:05:45 PM

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with a clean dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade and the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician to replace the obsolete receptacle.

10) Protect the power cord from being walked on or pinched particularly at plug, and the point where it exits from the apparatus.

11) Only use attachments/accessories specified by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug damage, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15) Apparatus should not be exposed to dripping or splashing, and objects filled with liquids, such as vases, should not be placed on the apparatus.

16) An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits, as contact with them might be fatal.

17) Do not overload wall outlets and extension cords, as this can result in a risk of fire or electric shock.

18) Do not push objects through any openings in this unit, as they may touch dangerous voltage points or short out parts that could result in fire or electric shock. Never spill or spray any type of liquid into the unit.

19) If an outside antenna or cable system is connected to the unit, be sure the antenna or cable system is grounded to provide some protection against voltage surges and built-up static charges, Section 810 of the National Electrical Code, ANSI/NFPA 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

GROUND

ELECTRIC SERVICE

EQUIPMENT

CLAMP

PORTABLE CART WARNING

(symbol provided by RETAC)

S3126A

ANTENNA LEAD IN WIRE

ANTENNA DISCHARGE UNIT (NEC SECTION 810-20) GROUNDING CONDUCTORS (NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250, PART H)

IMPORTANT SAFETY INSTRUCTIONS (continued)

20) When replacement parts are required, be sure the service technician uses replacement parts specified by the manufacturer or those that have the same characteristics as the original part.

Unauthorized substitutions may result in fire, electric shock or other hazards.

21) Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks to determine that the unit is in proper operating condition.

22) Keep your fingers clear of the disc slot as it is closing. It may cause injury.

23) When you connect the product to other equipment, turn off the power and unplug all of the equipment from the wall outlet. Failure to do so may cause an electric shock and serious personal injury. Read the owner's manual of the other equipment carefully and follow the instructions when making any connections.

24) Reduce the volume to the minimum level before you turn on the product. Otherwise, sudden high volume sound may cause hearing or speaker damage.

25) Do not allow the product to output distorted sound for an extended period of time. It may cause speaker overheating and fire.

26) When you use the headphones, keep the volume at a moderate level. If you use the headphones continuously with high volume sound, it may cause hearing damage.

27) Do not look into the opening of the disc slot or ventilation opening of the product to see the source of the laser beam. It may cause eye damage.

28) Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may cause serious personal injury and product malfunction.

29) This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

CONDENSATION

Moisture will form in the operating section of the player if the player is brought from cool surroundings into a warm room or if the temperature of the room rises suddenly. When this happens, player's performance will be impaired. To prevent this, let the player stand in its new surroundings for about an hour before switching it on, or make sure that the room temperature rises gradually. Condensation may also form during the summer if the player is exposed to the breeze from an air conditioner. In such cases, change the location of the player.

HOW TO HANDLE THE LCD PANEL

•

Do not press hard or jolt the LCD panel. It may cause the LCD panel glass to break and injury may occur.

•

If the LCD panel is broken, make absolutely sure that you do not touch the liquid in the panel. This may cause skin inflammation. If the liquid gets in your mouth, immediately gargle and consult with your doctor. Also, if the liquid gets in your eyes or touches your skin, consult with your doctor after rinsing for at least 15 minutes or longer in clean water.

51F0101A_eng.indd 4 3/5/08 5:05:46 PM

10cm

Notes when mounting the LCD TV/DVD on a wall

If the unit is to be mounted on the wall, contact the retailer where you purchased the LCD TV/DVD for advice, and have the equipment professionally installed. Incomplete or improper installation may cause injury to you, and/or damage to the LCD TV/DVD.

IMPORTANT NOTICE

Possible Adverse Effects on LCD Panel: If a fixed (non-moving) pattern remains on the LCD Panel for

long periods of time, the image can become permanently engrained in the LCD Panel and cause subtle but permanent ghost images. This type of damage is NOT COVERED BY YOUR WARRANTY. Never leave your LCD Panel on for long periods of time while it is displaying the following formats or images:

Fixed Images, such as stock tickers, video game patterns, TV station logos, and websites. Special Formats that do not use the entire screen. For example, viewing letterbox style (16:9) media on a normal (4:3) display (black bars at top and bottom of screen); or viewing normal style (4:3) media on a widescreen (16:9) display (black bars on left and right sides of screen).

The following symptoms are not signs of malfunction but technical limitation. Therefore we disclaim any responsibility for these symptoms.

LCD Panels are manufactured using an extremely high level of precision technology, however sometimes parts of the screen may be missing picture elements or have luminous spots.

This is not a sign of a malfunction.

Do not install the LCD Panel near electronic equipment that is susceptible to electromagnetic waves. Some equipment placed too near this unit may cause interference. Effect on infrared devices – There may be interference while using infrared devices such as infrared cordless headphones.

•

SAFETY PRECAUTIONS

51F0101A_eng.indd 5 3/5/08 5:05:46 PM

The unit emits heat when in operation. Do not place any covers or blankets on the unit, this may cause overheating. Do not block ventilation holes, or set up near radiators. Do not place in direct sunshine. When placing on a shelf leave 10 cm (4 inches) free space around the entire unit.

Features

LCD color TV With DVD/CD player

Unique space saving design combines a 26/32” LCD color TV and a DVD/CD player. A DVD disc has much more capacity, but is the same size as an audio CD disc. The Picture/Audio quality of a DVD exceeds other software. The picture quality is higher than Super VHS video cassettes. The audio quality is higher than an audio CD. The DVD also has special options; audio language selection, subtitle language selection, or multi-angle, etc. The DVD PLAYER can play back both audio CDs and MP3/WMA/JPEG CDs.

Compatible with a wide range of DVD audio outputs

Digital Audio Jack (Coaxial)

•

When a component with a built-in Dolby Digital decoder is connected, Dolby Digital sound can produce the effect of being in a movie theater or a concert hall.

•

Surround standard is different from Dolby Digital. This format is already in use in many theaters. By connecting this unit to a DTS decoder or an AV amplifier with a built-in DTS decoder, the DTS audio of DVD discs recorded in this format can be enjoyed. However, audio will not be output from the analog audio output jacks.

•

By connecting this unit to an AV amplifier with a built-in MPEG decoder, the MPEG audio of DVD discs recorded in this format can be enjoyed.

•

The Linear PCM sound of a 48 kHz/24 bit through 96 kHz/24 bit exceeds audio CD sound.

Convenience Features

Direct selection of your desired scenes using Title/Chapter/Time/Track - You can play back from the

desired scene.

Recalling Up to 3 Scenes Frame Advance - The PAUSE/STILL moves one frame at a time. Slow Motion - The SLOW moves you back and forth through the program by 4 steps of 1/7-1/2 times. Repeat Playback - You can repeat chapter, track, title, sides or material between two selected points. Program Playback (Audio CD/MP3/WMA CD) - You can play back tracks in programmed sequences. Zoom - You can zoom in the selected subject on the screen during playback.

Note: Make sure that discs are suitable for the following functions. Multi-Language - Maximum 32 language subtitles and maximum 8 language soundtracks can be played back

for movies or programs. Multi-Angle - Pictures of Sports or a Live Concert are recorded with many cameras. When you play such a disc, you can change the angles during playback. Parental Control - You can limit the play back of scenes or sounds of DVD discs that have a rating level encoded on the disc.

Video Aspect Ratio - You can change the aspect ratio of the screen for your monitor.

TV Features

Integrated Digital Tuner - You can view digital broadcasts without using a Digital TV Set-Top Box. Closed Caption Decoder With Full Text Mode - Displays text captions or full screen text on the screen for

hearing impaired viewers. Picture Adjustments Using The Remote Control - The On-Screen display allows precise remote control adjustment of BRIGHTNESS, CONTRAST, COLOR, TINT and SHARPNESS. Programmable TV Sleep Timer - Operable from the remote control, the TV can be programmed for up to 120 minutes to turn off automatically. On-Screen 3 Language Display - You can select one of 3 languages, English, Spanish or French for onscreen programming. V-Chip - The V-Chip function can read the rating of a TV program or movie content if the program is encoded with this information. V-chip will allow you to set a restriction level.

* This product incorporates copyright protection technology that is protected by U.S. patents and other

intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

is a trademark of DVD Format/Logo Licensing Corporation.

* Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of

Dolby Laboratories. Manufactured under license under U.S. Patent #: 5,451,942 & other U.S. and worldwide patents issued &

* HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of

HDMI Licensing LLC.

You can program up to 3 scenes in memory and recall the marked scenes.

51F0101A_eng.indd 6 3/5/08 5:05:46 PM

Contents

Before using your unit

IMPORTANT SAFETY INSTRUCTIONS ...........3

SAFETY PRECAUTIONS .................................5

IMPORTANT NOTICE .......................................5

Features ............................................................6

Contents ...........................................................7

Disc...................................................................8

Location of controls ........................................... 9

Remote control ...............................................11

Power source ..................................................12

Antenna connections ......................................13

Cable TV connections ..................................... 14

TV operation

Setting the on-screen language ...................... 15

Memorizing channels ......................................15

TV operation ...................................................16

Labeling channels ...........................................17

Labeling video inputs ...................................... 18

Setting the V-Chip ...........................................18

Closed Caption ............................................... 20

CC advanced ..................................................20

Adjusting the picture preference .....................21

Picture control adjustment ..............................21

Selecting the color temperature ...................... 21

Setting the picture size .................................... 22

Film Mode .......................................................22

Picture control adjustment in the PC mode .....23

DNR ................................................................23

Sound control adjustment ............................... 23

Selecting Stereo/Second Audio Program

(SAP) .............................................................. 23

Selecting the audio language .......................... 24

Selecting the HDMI audio input source ...........24

Turning off the built-in speakers ......................24

Adjusting the back lighting ..............................24

Setting the Auto Shut Off ................................25

Resetting your settings ...................................25

DVD operation

Preparation .....................................................25

Status display of disc ...................................... 25

Playback procedure ........................................26

Special playback ............................................. 26

MP3/WMA/JPEG and Audio CD playback ......27

Setting the JPEG interval ................................ 28

Program playback (CD) ..................................28

Repeat playback (CD).....................................29

Random playback (CD) ..................................29

Zooming .......................................................... 29

Locating desired scene ...................................29

Repeat playback .............................................30

Marking desired scenes ..................................30

Changing soundtrack language ......................30

Subtitles ..........................................................31

Changing angles .............................................31

Title selection ..................................................31

DVD menu ......................................................31

Setting the language ....................................... 32

Setting the aspect ratio of TV screen ..............32

Setting on screen display ................................32

Setting the picture mode ................................. 32

Night Mode .....................................................33

Digital Out ....................................................... 33

Parental control ............................................... 33

Temporary disabling of rating level

by DVD disc .................................................... 34

Additional information

Language code list .......................................... 35

Connections to other equipment ..................... 36

Reception disturbances .................................. 39

Problems and troubleshooting ........................40

Specifications .................................................42

Limited Warranty ............................................. 43

51F0101A_eng.indd 7 3/5/08 5:05:47 PM

Disc

ALL

CHAPTER 1

TITLE 1 TITLE 2

DVD DISC

CHAPTER 2 CHAPTER 2 CHAPTER 3CHAPTER 1

TRACK 1 TRACK 2 TRACK 3 TRACK 4 TRACK 5

Audio - CD

51F0101A_eng.indd 8 3/5/08 5:05:47 PM

Playable discs

Disc type and logo mark content

Audio

DVD Video

CD-DA

The following discs are also available.

DVD-R/RW discs of DVD video format.

• CD-R/RW discs of MP3/WMA/JPEG.

•

Region Number

Region number (Regional restriction code) is built-in to the unit and DVD video discs. Region number “1” or “ALL” of DVD video discs can be used on this unit.

Title

When two or more movies are recorded on a disc, the disc is divided into two or more sections. Each section is called a “TITLE”.

Chapter

The titles can be subdivided into many sections. Each section is called a “CHAPTER”.

Track

An Audio CD can contain several items. These are assigned to the tracks.

Removing Disc from Case

Be sure to hold the edge of disc. Do not touch the surface of the disc. Pick up the disc gently from the case.

•

Do not scratch the disc.

•

Do not get dirt on the surface of the disc.

•

Do not stick a label or adhesive tape on the disc.

•

Do not drop or bend the disc.

Storing Disc

•

Store the disc in the case to avoid risk of scratches, dirt or damage.

•

Do not leave disc exposed to direct sunlight or in hot or humid places.

Cleaning Disc

Wipe the disc with a clean, dry cloth from center to edge.

•

Do not wipe the disc in a circular motion.

•

Do not use liquid or aerosol cleaners.

Video (moving pictures)

Audio

CAUTION:

•

Only the left types of discs can be played on this unit. DVD-ROM, CD-ROM, SVCD, CVD, VCD, etc. cannot be played.

•

8cm discs can be played directly. If an 8cm disc adapter is used it will cause errors.

•

If you insert an irregular shaped disc, it may get stuck and cause a malfunction.

•

The use of a ring protector or other disc accessories will cause errors.

•

This unit is to be used exclusively with the NTSC color system. PAL and SECAM system discs cannot be used with this unit.

•

Some CD-R/RWs and DVD-R/RW can not be played back depending on the recording conditions.

Location of controls

Front

To display the menu screen. Press MENU button to display the menu screen. CHANNEL / buttons, VOLUME +/– buttons and INPUT/ENTER button can be used to select the desired setting during the menu screen operations.

POWER button

INPUT/ENTER button

VOLUME +/– buttons

CHANNEL /1 (PLAY) button

MENU button

Remote sensor

POWER indicator

EJECT button

Left side

CHANNEL /3 (STOP) button

DISC slot

51F0101A_eng.indd 9 3/5/08 5:05:48 PM

Location of controls (continued)

ANT

AC INPUT

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

WARNING:SHOCK HAZARD-DO NOT OPEN. AVIS:RISQUE DE CHOC ELECTRIQUE-NE PAS OUVRIR

ANT

AC INPUT

HDMI 1/DVI IN jack

HDMI 2 IN jack

PC MONITOR IN jack

VAR (VARIABLE) AUDIO OUT jacks

COAXIAL DIGITAL AUDIO OUT jack

51F0101A_eng.indd 10 3/10/08 10:56:10 AM

Rear side

PC/DVI AUDIO IN jack RF (ANT) IN jack

AC INPUT jack

(VIDEO/S-VIDEO/AUDIO(L/R))

LINE 1 IN jacks

(for COMPONENT IN and LINE 2 VIDEO IN)

LINE 2 VIDEO

IN jack

AUDIO (L/R) jacks

COMPONENT IN jacks

Remote control

POWER Power On/Off

DISPLAY/– Call TV information

Call DVD information Input “–” for digital channels

TV/DVD Switch between TV/AV and DVD

(EJECT) Eject a disc

0-9 Direct channel selection of TV

Input setting Enter a password

VOL +/– Adjust volume of TV

MUTE Switch off the sound

SLEEP Sleep timer

SETUP TV MENU

TV mode - Display menu of TV DVD mode - Call up initial setup mode

DVD MENU Display DVD menu

Select channel of TV

ϳϴϵ϶Cursor buttons

ENTER Enter information in the menu

EXIT CANCEL

Exit from On-Screen menu Reset information in the menu

TOP MENU Select title

SEARCH Fast Forward/Review playback

PLAY Playback

SKIP Skip chapter to forward or reverse direction

SUBTITLE Set subtitle

STOP Stop

SLOW Forward/Reverse- slow motion

PAUSE/STILL Pause CD sound

Still picture of DVD

PLAY MODE Select playback mode

AUDIO Change sound track language

RETURN Remove DVD setup menu

REPEAT A-B Repeat playback between A and B

ANGLE Change playback angle

SCREEN SIZE Display PICTURE SIZE menu

MARKER Index

JUMP Locating desired scene

QUICK VIEW ZOOM

Switch between present/last channel Zoom

INPUT SELECT Display source selection menu

ATTENTION

If you purchase a universal remote from a local retailer, please contact the remote manufacturer for the correct programming code.

51F0101A_eng.indd 11 3/5/08 5:05:49 PM

Operation

Aim the remote control at the remote sensor and press control buttons to operate. Operate the remote control within a 30° angle on either side of the remote sensor, up to a distance of approximately 15 feet.

•

Remote control (continued)

NOTE:

Do not leave the remote control unit exposed to direct sunlight or in hot or humid places. The remote control unit uses infrared beams to transmit signals, so sunlight or fluorescent light on the remote sensor may shorten operating distance. Incorrect use of batteries may cause them to leak or burst. Read the battery warnings and use the batteries properly. Do not mix old and new batteries. Remove batteries if the remote control will not be operated for an extended period of time.

•

Power source

TO USE AC POWER

Connect the AC cord plug into this unit’s AC IN jack. Connect the AC cord into an AC outlet.

NOTE:

Please make sure to insert the cord securely at both the LCD TV/DVD and the wall outlet. The AC Cord has a grounding-type AC line plug. If the supplied AC cord does not match your AC outlet, contact a qualified electrician, do not defeat the purpose of a grounding plug.

WARNING:

DO NOT CONNECT THIS UNIT TO THE POWER USING ANY DEVICE OTHER THAN THE SUPPLIED AC CORD. THIS COULD CAUSE FIRE, ELECTRICAL SHOCK, OR DAMAGE. DO NOT USE WITH A VOLTAGE OTHER THAN THE POWER VOLTAGE DISPLAYED. THIS COULD CAUSE FIRE, ELECTRICAL SHOCK, OR DAMAGE.

CAUTION:

WHEN THIS UNIT IS NOT USED FOR A LONG TIME, (E.G., AWAY ON A TRIP) IN THE INTEREST OF SAFETY, BE SURE TO UNPLUG IT FROM THE AC OUTLET. DO NOT PLUG/UNPLUG THE PLUG WHEN YOUR HANDS ARE WET. THIS MAY CAUSE ELECTRICAL SHOCK. IF YOU NEED TO REPLACE THE SUPPLIED AC ADAPTER OR AC CORD, THE SPECIFIED ONE IS RECOMMENDED. CONTACT THE DEALER THAT YOU PURCHASED THE UNIT FROM.

•

ANT

AC INPUT

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

WARNING:SHOCK HAZARD-DO NOT OPEN. AVIS:RISQUE DE CHOC ELECTRIQUE-NE PAS OUVRIR

AC cord (supplied)

AC 120V, 60Hz

Wider Hole and Blade

AC Outlet

51F0101A_eng.indd 12 3/10/08 10:56:11 AM

Inserting Batteries

Open the battery compartment

cover in the direction of the arrow.

Install two “AAA” batteries,

paying attention to the polarity diagram in the battery compartment.

Replace the compartment cover.

Approximately 15 feet

300-75 ohm Matching Transformer

Antenna connections

If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your antenna system. If you are using a Cable TV service, see page 14 for Cable TV connections.

Combination VHF/UHF Antenna (Single 75 ohm cable or 300 ohm twin-lead wire)

Combination VHF/UHF Antenna (Separate VHF and UHF 300 ohm twin-lead wires)

Separate VHF/UHF Antennas (75 ohm VHF cable and 300 ohm UHF twin-lead wires)

Connect the 75 ohm cable from the combination VHF/UHF antenna to the antenna jack.

If your combination VHF/UHF antenna has a 300 ohm twin-lead wire, the use of the 300-75 ohm matching transformer may be necessary.

Connect the UHF 300 ohm twin-lead wire to the Combiner (not supplied). Connect the VHF 300 ohm twin-lead wire to the 300-75 ohm Matching Transformer. Attach the Transformer to the Combiner, then attach the Combiner to the Antenna Jack.

Connect the VHF 75 ohm cable and UHF 300 ohm twin-lead wire to the Combiner (not supplied). Attach the Combiner to the Antenna Jack.

300-75 ohm Matching Transformer

UHF 300 ohm

VHF 300 ohm

Antenna

Jack

Combiner

VHF 75 ohm

Antenna

Jack

Antenna

Jack

75 ohm Coaxial Cable

Antenna

Jack

Combiner

UHF 300 ohm

IMPORTANT: Go to page 15 to choose the signal and search for channels.

51F0101A_eng.indd 13 3/5/08 5:05:50 PM

Cable TV connections

For basic Cable TV service not requiring a Converter/ Descrambler box, connect the 75 ohm Coaxial Cable directly to the Antenna Jack on the back of the TV.

For subscribers to scrambled Cable TV service

If you subscribe to a Cable TV service which requires the use of a Converter/Descrambler box, connect the incoming 75 ohm Coaxial Cable to the Converter/Descrambler box. Using another 75 ohm Coaxial Cable, connect the output jack of the Converter/Descrambler box to the Antenna Jack on the TV. Follow the connections shown below. Set the TV to the output channel of the Converter/Descrambler box (usually channel 3 or 4) and use the Converter/Descrambler box to select channels.

For subscribers to unscrambled Cable TV service with scrambled premium channels

If you subscribe to a Cable TV service in which basic channels are unscrambled and premium channels require the use of a Converter/Descrambler box, you may wish to use a signal Splitter and an A/B Switch box (available from the Cable TV company or an electronics supply store). Follow the connections shown below. With the switch in the “B” position, you can directly tune any nonscrambled channels on your TV. With the switch in the “A” position, tune your TV to the output of the Converter/Descrambler box (usually channel 3 or 4) and use the Converter/Descrambler box to tune scrambled channels.

Splitter

Incoming 75 ohm Cable TV Cable

A/B Switch

75 ohm Cable to TV

Incoming 75 ohm Cable TV Cable

75 ohm Cable to TV

Converter/

Descrambler

Antenna

Jack

Antenna

Jack

Converter/

Descrambler

This TV has an extended tuning range and can tune most cable channels without using a Cable TV Converter box. Some cable companies offer “premium pay channels” where the signal is scrambled. Descrambling these signals for normal viewing requires the use of a descrambler device which is generally provided by the Cable TV company.

For subscribers to basic Cable TV service

Antenna

Jack

75 ohm Coaxial Cable

IMPORTANT: Go to page 15 to choose the signal and search for channels.

51F0101A_eng.indd 14 3/5/08 5:05:51 PM

Setting the on-screen

NOTE:

It may take a few seconds for a digital channel picture to appear on screen after being selected.

Automatic search

Press SETUP/TV MENU in the TV mode. The TV menu screen will appear.

Press ϳ or ϴ to select “Channel”, then press ϶ or

ENTER.

Press ϳ or ϴ to select “Auto Ch Memory”, then

press ϶ or ENTER.

Press ϳ or ϴ to select “Automatic Search”, then

press ϶ or ENTER.

Auto Ch Memory

Signal Type Cable

Digital Channel Found : 0

Analog Channel Found : 0

: Select

ENTER:Cancel

Automatic Search Stop

The TV will begin memorizing all the channels available in your area.

It may take from 15 minutes to 30 minutes to complete memorizing digital cable channels.

Depending on the reception condition, a bar

display may not advance for several minutes, please be patient.

•

51F0101A_eng.indd 15 3/5/08 5:05:52 PM

language

You can choose from three different languages (English, French and Spanish) for the on-screen displays. Select the language you prefer first, then proceed with the other menu options.

To turn on the TV, press POWER.

(POWER indicator on the front of the unit changes green. It may take approx. 10 seconds for a picture to appear on screen.)

Press TV/DVD to select TV mode.

Press SETUP/TV MENU. The TV menu screen

will appear.

Press ϳ or ϴ to select “Setup”, then press ϶ or

ENTER.

Press ϳ or ϴ to select “Language”.

Setup

Closed Caption >>

Language English

Video Label >>

Backlight

Auto Shut Off Off

Reset >>

: Adjust

: Select

NOTE:

•

When you press SETUP/TV MENU first time after purchase this LCD TV, above screen will appear automatically.

Press ϵ or ϶ to select the desired language:

English, French (Français) or Spanish (Español).

Press EXIT/CANCEL to return to the normal

screen.

NOTE:

If no buttons are pressed for more than about 60

• seconds, the menu screen will return to normal operation automatically.

Memorizing channels

This TV is equipped with a channel memory feature which allows channels to skip up or down to the next channel set into memory, skipping over unwanted channels. Before selecting channels, they must be programmed into the TV’s memory. To use this TV with an antenna, set the Signal Type option to the Air mode. When shipped from the factory, this menu option is in the Cable mode.

Air/Cable selection

Press SETUP/TV MENU in the TV mode. The TV

menu screen will appear.

Press ϳ or ϴ to select “Channel”, then press ϶

or ENTER.

Press ϳ or ϴ to select “Auto Ch Memory”, then

press ϶ or ENTER.

Press ϳ or ϴ to select “Signal Type”.

Press ϵ or ϶ to select “Air” or “Cable”.

Air - VHF/UHF channels Cable - CABLE TV channels

Auto Ch Memory

Signal Type Cable

Automatic Search Start

: Adjust

: Select

Press EXIT/CANCEL to return to the normal

screen.

CABLE CHART

The chart below is typical of many cable system channel allocations.

NOTE:

Memorizing channels is best accomplished during

• evening “PRIMETIME” hours, as more stations are broadcasting digital signals. Memorizing channels can only be accomplished while a station is broadcasting a digital signal to set that channel into memory.

•

If you are unsure of the digital channels available in your area, you may visit www.antennaweb.org to receive a list based on your address or zip code.

•

New digital channels may be added to your area periodically, it is recommended to perform the “Automatic Search” procedure regularly.

Adding Channel

If you find a new channel unregistered, you can add the new channel into the channel memory.

Tune in the new channel.

Press SETUP/TV MENU in the TV mode. The TV

menu screen will appear.

Press ϳ or ϴ to select “Channel”, then press ϶ or

ENTER.

Press ϳ or ϴ to select “Add/Delete”, then press ϶

or ENTER.

Add/Delete

Adding Channel >>

Add/Delete >>

Clear All >>

: Select ENTER:Set

Press ϳ or ϴ to select “Adding Channel”, then

press ϶ or ENTER. The new channel will be

added into the channel memory.

Press EXIT/CANCEL to return to the normal

screen.

Add/Delete channel

You can select the channel that you want to skip.

Press SETUP/TV MENU in the TV mode. The TV

menu screen will appear.

Press ϳ or ϴ to select “Channel”, then press ϶ or

ENTER.

Press ϳ or ϴ to select “Add/Delete”, then press

϶ or ENTER.

Press ϳ or ϴ to select “Add/Delete”, then press

϶ or ENTER.

Press ϳ or ϴ to select the channel that you want

to skip.

Add/Delete

CH Signal

2 Analog

3 Analog Add

3-001 Digital Delete

3-002 Digital Add

4 Analog Delete

: Select

Press ϵ or ϶ to select “Add” or “Delete”,

whichever function you want to perform.

Repeat steps 5 - 6 for other channels you want to

add or delete.

Add

: Adjust

Press EXIT/CANCEL to return to the normal

screen.

Clear All

All channels are deleted from the channel memory.

Press SETUP/TV MENU in the TV mode. The TV

menu screen will appear.

Press ϳ or ϴ to select “Channel”, then press ϶ or

ENTER.

Press ϳ or ϴ to select “Add/Delete”, then press ϶

or ENTER.

Press ϳ or ϴ to select “Clear All”, then press ϶ or

ENTER.

Add/Delete

Adding Channel >>

Add/Delete >>

Clear All >>

: Select ENTER:Set

Press EXIT/CANCEL to return to the normal

screen.

TV operation

To turn on the TV, press POWER.

(POWER indicator on the front of the unit changes green. It may take approx. 10 seconds for a picture to appear on screen.)

Adjust the volume level by pressing VOL + or – .

The volume level will be indicated on the screen by blue bars. As the volume level increases, so do the number of bars. If the volume decreases, the number of blue bars also decreases.

Set the Signal Type option to the appropriate

position (see “Air/Cable selection” on page 15).

Press the Direct Channel Selection (0-9, –)

buttons to select the channel. (If you press only channel number, channel selection will be delayed for a few seconds.)

TO SELECT ANALOG CHANNELS

1-9: Press 1-9 as needed. Example, to

10-99: Press the 2 digits in order. Example, to

100-125: Press the 3 digits in order. Example, to

TO SELECT DIGITAL CHANNELS

Press the first 3 digits, then press the – button, followed by the remaining number. Example, to select channel 015-001, press 0, 1, 5, –, 0, 0, 1.

•

The same program may be available on either

•

select channel 2, press 2.

select channel 12, press 1, 2.

select channel 120, press 1, 2, 0.

If a channel is selected with only audio content, “Audio only” will be displayed on the screen. If a channel is selected with a weak digital signal, “Digital channel signal strength is low” will be displayed on the screen.

an analog channel or a digital channel. You may choose to watch either format. If a channel is selected to which you have not subscribed, be displayed on the screen.

“Digital channel is encrypted” will

51F0101A_eng.indd 16 3/5/08 5:05:53 PM

VHF/UHF/CABLE CHANNELS

Press and release CH / . The channel automatically stops at the next channel set into memory. For proper operation, before selecting channels, they should be set into the memory. See “Memorizing channels” on pages 15 and 16.

DISPLAY

Press DISPLAY to display the current information on the screen.

When the TV receives a digital signal, the digital information will appear.

62-001 HDTV Moving Picture1

CH-1

Digital Air

No Program Information is available

Sleep Timer

Off

English

Full

1080i

Channel number• Station name• Channel label (if preset)•

Broadcast program name

• V-Chip rating• Signal type• Sleep timer• Audio language• Program guide• Picture size• Resolution•

When the TV receives a analog signal, the analog information will appear.

•

Analog Cable

Sleep Timer

Off

Full 480i

Channel number• Channel label (if preset)• V-Chip rating• Signal type• Sleep timer• Picture size• Audio information (Stereo or SAP)

• Resolution•

Press DISPLAY again to clear the call display.

NOTE:

After a few seconds, DISPLAY screen will return to normal TV-operation automatically.

QUICK VIEW

This button allows you to go back to the last channel selected by pressing QUICK VIEW. Press QUICK VIEW again to return to the last channel you were watching.

MUTE

Press MUTE to switch off the sound. The TV’s sound will be silenced and “Mute” will appear on the screen. The sound can be switched back on by pressing this button again or the VOL + or –.

SLEEP

To set the TV to turn off after a preset amount of time, press SLEEP on the remote control. The clock will count up 10 minutes for each press of the SLEEP button (Off, 0h 10m, 0h 20m, ..., 2h 0m). After the sleep time is programmed, the display will appear briefly every ten minutes to remind you that the sleep timer is operating. To confirm the sleep timer setting, press SLEEP and the remaining time will be displayed for a few seconds. To cancel the sleep timer, press SLEEP repeatedly until the display turns to Off.

Sle ep Tim er

0h 10m

Labeling channels

Channel label appear with the channel number display each time you turn on the TV, select a channel, or press DISPLAY. You can choose any four characters to identify a channel.

To create channel labels

Press SETUP/TV MENU in the TV mode. The TV menu screen will appear.

Press ϳ or ϴ to select “Channel”, then press ϶ or

ENTER.

•

51F0101A_eng.indd 17 3/5/08 5:05:53 PM

Air Cable

VHF 2-13

UHF

14-69

NOTE:

If a channel with no broadcast is selected, the sound will automatically be muted. It may take a few seconds for a digital channel picture to appear on screen after being selected.

To select the video input source

To view a signal from another device connected to your LCD TV, such as a VCR player, press INPUT

SELECT, then press ϳ/ϴ or corresponding Number

buttons (0-7), then press ENTER. You can select

TV, Video1, Video2, Component, HDMI1, HDMI2, PC or DVD depending on which input jacks you used to connect your devices.

Source Selection

0.TV

1.Video1

2.Video2

3.Component

4.HDMI1

5.HDMI2

6.PC

7.DVD

[0-7]:Select

VHF 2-13

STD/HRC/IRC 14-36 (A) (W) 37-59 (AA) (WW) 60-85 (AAA) (ZZZ) 86-94 (86) (94) 95-99 (A-5) (A-1) 100-125 (100) (125) 01 (5A)

Press ϳ or ϴ to select “Ch Label”, then press ϶

, () @ / + =

If the character which you desire appears, press ENTER. Repeat this step to enter the rest of the characters. If you would like a blank space in the label name, you must choose the empty space from the list of characters.

When you finish inputting the label name, press EXIT/CANCEL to return to the normal screen.

Repeat steps 4-5 for other channel. You can assign a label to each channel.

To clear a Ch Label

After step 4 above, press ϳ or ϴ to select “Label

Clear”, then press ϶ or ENTER.

NOTE:

The channel labels will be reset after “Automatic Search” on page 15.

Labeling video inputs

The Video Label feature allows you to label each input source for your TV.

Press SETUP/TV MENU in the TV mode. The TV menu screen will appear.

Press ϳ or ϴ to select “Setup”, then press ϶ or

ENTER.

Press ϳ or ϴ to select “Video Label”, then press

϶ or ENTER.

Press ϳ or ϴ to select an input which you want to

label.

Press ϵ or ϶ to select the desired label for that

input source.

•

Video2 -

Component -

HDMI1 -

HDMI2 -

Video Label

: Adjust

: Select

Video1 -

– : Uses the default label name

VCR : Video cassette recorder DVD : DVD video DTV : Digital TV set-top box SAT : Satellite box CBL : Cable box HD : HDMI device (only for HDMI inputs)

Press EXIT/CANCEL to return to the normal screen.

Setting the V-Chip

An age limitation can be set to restrict children from viewing or hearing violent scenes or pictures that you may choose to exclude. The restriction applies to “TV Rating” and “Movie Rating” if this data is transmitted. You may set this restriction separately. To use the V-Chip function, you must register a password.

To register a password

Press SETUP/TV MENU in the TV mode. The TV menu screen will appear.

Press ϳ or ϴ to select “Lock”, then press ϶ or

ENTER.

Select and enter your password (4 digits) using Number buttons (0-9), then press ENTER.

[0-9]

Lock

New Password

* * *

: Select ENTER:Set

“ ” appears instead of the number.

Enter the same password again to confirm, then press ENTER. The password is now registered.

NOTE:

If you forget your password, you can reset it. Turn the volume all the way down using VOLUME – on the TV. Continue holding the button and press 0 on the remote control at the same time for about 5 seconds. Enter a new password. To avoid forgetting the password, write it down and keep in a safe place.

To set the V-Chip

Press SETUP/TV MENU in the TV mode. The TV menu screen will appear.

Press ϳ or ϴ to select “Lock” menu, then press

϶ or ENTER.

Use Number buttons (0-9) to enter your password, then press ENTER. Then Lock menu will appear.

•

51F0101A_eng.indd 18 3/5/08 5:05:54 PM

or ENTER. The “Ch Label” menu will appear.

Press ϵ or ϶ to select a channel you want to

label, then press ϴ.

Ch Label

Channel Number 15-1

Ch Label

Label Clear >>

: Adjust

: Select

Press ϵ or ϶ repeatedly until the character you

want appears in the first space.

Ch Label

Channel Number 15-1

Ch Label A

Label Clear >>

: Adjust

: Select

The characters rotation as follows:

ENTER:Set

SPACE

Press ϳ or ϴ to select “V-Chip”, then press

ϵ or ϶ to select “On” .

Press ϳ or ϴ to select “V-Chip Set”, then press

϶ or ENTER.

The V-Chip Set Menu appears.

Press ϳ or ϴ to select which rating will be used,

then press ϶ or ENTER. Each rating below will

appear.

TV Rating

ALL D L S V FV

TV-Y

TV-Y7

TV-G

TV-PG

TV-14

TV-MA

You can set the rating using age level and genre.

Age: TV-Y : All children TV-Y7 : 7 years old and above TV-G : General audience TV-PG : Parental guidance TV-14 : 14 years old and above TV-MA : 17 years old and above

Genre: ALL : All D : Dialogue L : Language S : Sex V : Violence FV : Fantasy Violence

Movie Rating

PG-13

NC-17

: Select

G : All ages PG : Parental guidance PG-13 : Parental guidance

R : Under 17 years old parental guidance

NC-17 : 17 years old and above X : Adult only

Press ϳ/ϴ/ϵ/϶ to select the desired rating, then

press ENTER.

Press EXIT/CANCEL to return to the normal screen.

V-Chip function is activated now.

To use the TV after the TV is protected.

When a program is received that is blocked by the VChip, press MUTE, then enter your password. The protection will be temporarily overridden. If the TV is turned off or the channel is changed, the V-Chip restriction will be reactivated.

NOTE:

The V-Chip function is activated only on programs

• and input sources that include a rating signal.

: Select

suggested

ENTER:Set

less than 13 years old

To change the password

Press SETUP/TV MENU in the TV mode. The TV

menu screen will appear.

Press ϳ or ϴ to select “Lock”, then press ϶ or

ENTER.

Use Number buttons (0-9) to enter your

password, then press ENTER. The Lock menu will appear.

Press ϳ or ϴ to select “Change Password”, then

press ϶ or ENTER.

The Change Password screen will appear.

Enter a new password using Number buttons

(0-9), then press ENTER.

Enter the same password again to confirm, then

press ENTER. The password is now registered.

Downloading the additional V-Chip rating system

As a supplement to the standard V-Chip rating system, your television will be able to download an additional rating system, if such a system becomes available in the future.

To download the additional V-Chip rating system (when available)

Press SETUP/TV MENU in the digital channel.

Press ϳ or ϴ to select “Lock”, then press ϶ or

ENTER.

Use Number buttons (0-9) to enter your password,

then press ENTER. The Lock menu will apper.

Press ϳ or ϴ to select “V-Chip Set (DTV)”, then

press ϶ or ENTER.

If the TV is not storing the additional rating

system, the TV will begin downloading it, which may take some time to be completed.

Set your preferred content rating limits for the

additional rating system.

You also need “Update” procedure to update

rating information.

NOTE:

You can only download the additional V-Chip rating

• system when your TV is receiving a digital signal. When you download the additional rating system, it

• may take some time for the download to occur. The V-Chip rating information and system are not

• determined or controlled by the TV. The standard V-Chip rating system is available

• whether your TV is receiving a digital signal or not, and will block both analog and digital programs. To set the restriction level using the standard V-Chip rating system, select V-Chip Set in step 4.

•

The downloadable V-Chip rating system is an evolving technology, and availability, content, and format may vary.

•

You cannot select this feature if the TV is not receiving a digital signal for the current station.

51F0101A_eng.indd 19 3/5/08 5:05:55 PM

Closed Caption

WHAT IS CLOSED CAPTIONING?

This television has the capability to decode and display Closed Captioned television programs. Closed Captioning will display text on the screen for hearing impaired viewers or it will translate and display text in another language.

Captions: This Closed Caption Mode will display text on the screen in English or another language. Generally, Closed Captions in English are transmitted on C1 and Closed Captions in other languages are transmitted on C2. Text: The Text Closed Caption Mode will usually fill 1/2 of the screen with a programming schedule or other information.

Press SETUP/TV MENU in the TV mode. The TV

menu screen will appear.

Press ϳ or ϴ to select “Setup”, then press ϶ or

ENTER.

Press ϳ or ϴ to select “Closed Caption”, then

press ϶ or ENTER.

The Closed Caption menu will appear.

Press ϵ or ϶ to select “On”.

On: Captions will be displayed on the screen. Off: Captions will not be displayed on the screen.

Press ϳ or ϴ to select “Analog Caption” or “Digital

Caption”.

When you select “Analog Caption”, you can choose C1, C2, C3, C4, T1, T2, T3 and T4.

When you select “Digital Caption”, you can choose from CS1, CS2, CS3, CS4, CS5 and CS6.

Press ϵ or ϶ to select the desired Closed

Caption mode for both Digital and Analog Caption.

Press ϳ or ϴ to select “CC Priority”, then press

ϵ or ϶ to select “Digital CC” or “Analog CC”.

NOTE:

•

Depending on the broadcast signal, some Analog Captions will function with a Digital broadcast signal. This step prevent that two kind of captions are overlapping.

Press EXIT/CANCEL to return to the normal

screen.

NOTE:

•

If the program or video you selected is not closedcaptioned, no captions will display on-screen.

•

If text is not available in your viewing area, a black rectangle may appear on-screen. If this happens, set the CC Setting to “Off”.

•

When selecting Closed Captions, the captioning will be delayed approx. 10 seconds.

•

If no caption signal is received, no captions will appear, but the television will remain in the Caption Mode. Misspellings or unusual characters may

• occasionally appear during Closed Captioning. This is normal with Closed Captioning, especially with

live programs. This is because during live programs, captions are also entered live. These transmissions do not allow time for editing. When Captions are being displayed, on-screen

• displays, such as volume and mute may be seen but may interfere with Closed Captions. Some cable systems and copy protection systems

• may interfere with the Closed Captioned signal.

•

If using an indoor antenna or if TV reception is very poor, the Closed Caption Decoder may not appear or may appear with strange characters or misspelled words. In this case, adjust the antenna for better reception or use an outdoor antenna.

CC advanced

When you have selected Custom as the display method, you can adjust the various setting listed below as follows:

This feature is designed to customize Digital Captions only.

Press SETUP/TV MENU in the digital channel.

The TV menu screen will appear.

Press ϳ or ϴ to select “Setup”, then press ϶ or

ENTER.

Press ϳ or ϴ to select “Closed Caption”, then

press ϶ or ENTER.

The Closed Caption menu will appear.

Press ϳ or ϴ to select “Digital CC Preset”, then

press ϵ or ϶ to select “Custom”.

Press ϳ or ϴ to select “CC Advanced”, then

press ϶ or ENTER.

The CC Advanced menu will appear.

Press ϳ or ϴ to select the desired item, then

press ϵ or ϶ to change the setting.

CC Advanced

Text Size Auto

Text Type Auto

Text Edge Auto

Text Color Auto

Text Opacity Auto

Background Color Auto

Background Opacity Auto

: Adjust

: Select

You can select from among the following items and parameters.

Text Size: Auto, Small, Standard, Large Text Type: Auto, Style1, Style2, Style3, Style4,

Text Edge: Auto, None, Raised, Depressed,

Text Color: Auto, Black, White, Red, Green,

Text Opacity: Auto, Solid, Transparent,

Background Color:

Background Opacity:

Style5, Style6, Style7

Uniform, Left Shadow, Right Shadow

Blue, Yellow, Magenta, Cyan

Translucent, Flashing Auto, Black, White, Red, Green,

Blue, Yellow, Magenta, Cyan Auto, Solid, Transparent,

Translucent, Flashing

51F0101A_eng.indd 20 3/5/08 5:05:56 PM

Press EXIT/CANCEL to return to the normal

After adjusting, press ENTER to return to the Picture Setting menu. Then continue to adjust the other items.

ϵ϶

Brightness

decrease brightness

increase brightness

Contrast decrease

contrast

increase contrast

Sharpness makes picture

softer

makes picture clearer

Color be pale color be brilliant color Tint be reddish color be greenish

color

After your desired setting, press EXIT/CANCEL to return to the normal screen.

NOTE:

The Contrast default setting is set to maximum at the factory.

Selecting the color temperature

Press SETUP/TV MENU in the TV mode. The TV menu screen will appear.

Press ϳ or ϴ to select “Picture”, then press ϶ or

ENTER.

Press ϳ or ϴ to select “Picture Setting”, then

press ϶ or ENTER.

The Picture Setting menu will appear.

Press ϳ or ϴ to select “Color Temperature”, then

press ϵ or ϶ to change the setting.

Brightness Contrast Sharpness Color Tint

Picture Setting

25 50 25 25

: Adjust

: Select

Color Temperature Cool

Setting Picture Quality

Cool Bluish Standard Neutral Warm Reddish

•

51F0101A_eng.indd 21 3/5/08 5:05:56 PM

screen.

NOTE:

•

You cannot set both “Text Color” and “Background Color” as a same color. You cannot set both “Text Opacity” and “Background

• Opacity” to “Transparent”.

Adjusting the picture preference

You can select four picture modes—Sports, Standard, Movie and Memory—as described in the following table:

Press SETUP/TV MENU in the TV mode. The TV

menu screen will appear.

Press ϳ or ϴ to select “Picture”, then press ϶ or

ENTER.

Press ϳ or ϴ to select “Picture Preference”.

Press ϵ or ϶ to select a mode you want to adjust.


Picture Setting >> Picture Preference Sports Picture Size >> Film Mode PC Setting >> DNR On

: Select

: Adjust

Mode Picture Quality

Sports

Bright and dynamic picture (factory-set)

Standard Standard picture quality (factory-set) Movie Movie-like picture setting (factory-set) Memory Your personal preferences (set by

After your desired setting, press EXIT/CANCEL

to return to the normal screen.

you; see “Picture control adjustment” below).

Picture control adjustment

Press SETUP/TV MENU in the TV mode. The TV

menu screen will appear.

Press ϳ or ϴ to select “Picture”, then press ϶ or

ENTER.

Press ϳ or ϴ to select “Picture Setting”, then

press ϶ or ENTER.

The Picture Setting menu will appear.

Press ϳ or ϴ to select the item you want to

adjust.

Press ϵ or ϶ to adjust the setting.

Picture Setting

Brightness

Contrast

Sharpness Color

Tint

Color Temperature Cool

: Select ENTER:Set

: Adjust

Brightness:25

Press EXIT/CANCEL to return to the normal

Cinema Wide1 picture size (for 4:3 format programs)

To fill the screen, the right and left edges are extended, however; the center of the picture remains near its former ratio. The top and bottom edges of the picture may be hidden.

Cinema Wide2 picture size (for letter box programs)

The entire picture is uniformly enlarged—it is stretched the same amount both wider and taller (retains its original proportion).

The top and bottom edges of the picture may be hidden.

A B C D E F G - - - - - - - - - - - - - - - -

Cinema Wide3 picture size (for letter box programs with subtitles)

To fill the width of the screen, it is extended horizontally. However; it is only slightly extended at the top and the bottom.

The top and bottom edges of the picture may be hidden.

A B C D E F G - - - - - - - - - - - - - - - -

A B C D E F G - - - - - - - - - - - - - - - - - - - - - - - - - -

Full picture size (for 16:9 source programs)

Full will display the picture at the maximum size.

NOTE:

Some High Definition and/or Digital broadcasts may not allow you to change the picture size. In HDMI or COMPONENT mode with a scanning rate of 720p or 1080i, only the Cinema Wide2 and Full picture size features are available. In PC Mode, only the Natural and Full picture size features are available. Additionally this feature will not work when display mode is WXGA. In Cinema Wide2 picture size, some of the on screen display items may be positioned off the visible portion of the screen.

Film Mode

A smoother motion may be obtained by setting the Film Mode to “On” when you view a DVD.

Press SETUP/TV MENU in the TV mode. The TV menu screen will appear.

Press ϳ or ϴ to select “Picture”, then press ϶ or

ENTER.

Press ϳ or ϴ to select “Film Mode”.

Press ϵ or ϶ to select “On” or “Off”.

•

51F0101A_eng.indd 22 3/5/08 5:05:57 PM

screen.

Setting the picture size

You can view 480i and 480p format programs in a variety of picture sizes— Natural, Cinema Wide1, Cinema Wide2, Cinema Wide3 and Full.

Selecting the picture size

Press SETUP/TV MENU in the TV mode. The TV

menu screen will appear.

Press ϳ or ϴ to select “Picture”, then press ϶ or

ENTER.

Press ϳ or ϴ to select “Picture Size”, then press

϶ or ENTER to display Picture Size menu. Press

ϳ/ϴ or corresponding Number buttons (0-4)

to select the desired picture size, as described below.

Picture Size

0.Natural

1.Cinema Wide1

2.Cinema Wide2

3.Cinema Wide3

4.Full

[0-4]:Select

NOTE:

•

Selectable picture sizes may vary depending on the input source or broadcast signal. Picture Size menu also can be displayed by

• pressing SCREEN SIZE on the remote control.

Press EXIT/CANCEL to return to the normal

screen.

Natural picture size

In some cases, this image will display the size of standard 4:3 with a black side bar.


Picture Setting >> Picture Preference Sports Picture Size >> Film Mode On PC Setting >> DNR On

: Adjust

: Select

Press EXIT/CANCEL to return to the normal

screen.

Picture control adjustment in the PC mode

You can adjust to optimize the performance of the TV in the PC mode.

Press INPUT SELECT, then press ϳ/ϴ or

Number button (6) to select the PC mode.

Press SETUP/TV MENU. The TV menu screen

will appear.

Press ϳ or ϴ to select “Picture”, then press ϶ or

ENTER.

Press ϳ or ϴ to select “PC Setting”, then press ϶

or ENTER. The PC Setting menu will appear.

PC Setting

Hor Position

Ver Position

Clock

Phase

: Select ENTER:Set

: Adjust

Press ϳ or ϴ to select the desired item you want

to adjust.

Press ϵ or ϶ to adjust the setting.

Hor Position:

Ver Position:

Clock: To minimize any vertical bars

Phase: This must be adjusted after the

After adjusting, press ENTER to return to the PC

Setting menu. Then continue to adjust the other items.

Press EXIT/CANCEL to return to the normal

screen.

NOTE:

•

If no buttons are pressed for more than approx. 60 seconds, the Menu-screen will return to normal Monitor-screen automatically. The PC settings are not effective for other input

•

modes.

To adjust the horizontal position of the image on the PC mode.

To adjust the vertical position of the image on the PC mode.

or stripes visible on the screen background.

frequency of the PC mode has been set to 60Hz to optimize picture quality (page 38).

DNR

DNR (Digital Noise Reduction) can reduce the roughness of the picture. (This function is available only for analog broadcast.)

Press SETUP/TV MENU in the TV mode. The TV

menu screen will appear.

Press ϳ or ϴ to select “Picture”, then press ϶ or

ENTER.

Press ϳ or ϴ to select “DNR”. Press ϵ or ϶ to

select “On” or “Off”.


Picture Setting >> Picture Preference Spor ts Picture Size >> Film Mode On PC Setting >> DNR On

: Adjust

: Select

Press EXIT/CANCEL to return to the normal

screen.

Sound control adjustment

Press SETUP/TV MENU in the TV mode. The TV

menu screen will appear.

Press ϳ or ϴ to select “Audio” , then press ϶ or

ENTER.

Press ϳ or ϴ to select the item you want to

adjust.

Audio

Bass

Treble

Balance

MTS Stereo

Audio Language No Info.

HDMI1 Audio HDMI

Speakers On

: Select

: Adjust

Bass: Press ϵ or ϶ to adjust the bass sound.

Treble: Press ϵ or ϶ to adjust the treble sound.

Balance: Press ϵ or ϶ to obtain an equal sound

After you desired setting, press EXIT/CANCEL to

return to the normal screen.

level from both speakers.

Press ϳ or ϴ to change the adjusting item.•

Selecting Stereo/Second Audio Program (SAP)

The multi-channel TV sound (MTS) feature provides high-fidelity stereo sound. MTS also can transmit a second audio program (SAP) containing a second language or other audio information. When the TV receives a stereo or SAP broadcast, the word “Stereo” or “SAP” displays on-screen every time you press DISPLAY.

51F0101A_eng.indd 23 3/5/08 5:05:57 PM

Press SETUP/TV MENU in the TV mode. The TV

menu screen will appear.

Press ϳ or ϴ to select “Audio”, then press ϶ or

ENTER.

Press ϳ or ϴ to select “MTS”, then press ϵ or ϶

to select “Stereo”.

Audio

Bass

Treble

Balance

MTS Stereo

Audio Language No Info.

HDMI1 Audio HDMI

Speakers On

: Select

: Adjust

Press EXIT/CANCEL to return to the normal

screen.

NOTE:

•

Generally you can leave your TV in stereo mode because the TV automatically outputs the type of sound being broadcast (stereo or mono). If the stereo sound is noisy, select “Mono” to

• reduce the noise.

To listen to a second audio program (SAP)

Press ϵ or ϶ to select “SAP” in step 3 above. The

TV speakers will output the second audio program instead of normal audio.

Selecting the audio language

When two or more audio languages are included in a digital signal, you can select one of the audio language. (This function is available only for digital broadcast.)

Press SETUP/TV MENU in the digital channel.

The TV menu screen will appear.

Press ϳ or ϴ to select “Audio” , then press ϶ or

ENTER.

Press ϳ or ϴ to select “Audio Language”, then

press ϶ or ENTER to display the Audio Language

menu.

Press ϳ/ϴ or Number buttons (0-6) to select

your desired language.

Audio Language

0. English

1. Language 1

2. Language 2

3. French

4. Language 3

5. Spanish

6. No Info.

[0-6]: Select

Press EXIT/CANCEL to return to the normal

screen.

Selecting the HDMI audio input source

When you use PC/DVI AUDIO IN jack with HDMI

or DVI device, you must select HDMI audio input source from “HDMI” or “DVI”.

Press SETUP/TV MENU in the TV mode. The TV

menu screen will appear.

Press ϳ or ϴ to select “Audio”, then press ϶ or

ENTER.

Press ϳ or ϴ to select “HDMI1 Audio”.

Press ϵ or ϶ to select “HDMI” or “DVI”.

Audio

Bass

Treble

Balance

MTS Stereo

Audio Language No Info.

HDMI1 Audio HDMI

Speakers On

: Select

: Adjust

HDMI: When you connect the HDMI device to

the TV, select this setting.

DVI: When you connect the DVI device to the

TV with analog audio cords, select this setting.

Press EXIT/CANCEL to return to the normal

screen.

Turning off the built-in speakers

Use this feature to turn the TV/DVD speakers off when you connect an audio system (see pages 38).

Press SETUP/TV MENU in the TV mode. The TV

menu screen will appear.

Press ϳ or ϴ to select “Audio”, then press ϶ or

ENTER.

Press ϳ or ϴ to select “Speakers”.

Press ϵ or ϶ to select “Off”.

Audio

Bass

Treble

Balance

MTS Stereo

Audio Language No Info.

HDMI1 Audio HDMI

Speakers On

: Select

: Adjust

Press EXIT/CANCEL to return to the normal

screen.

To turn on the built-in speakers:

Select “On” in step 3 above.

Adjusting the back lighting

The Backlight feature adjusts the screen brightness for improved picture clarity.

Press SETUP/TV MENU in the TV mode. The TV

menu screen will appear.

Press ϳ or ϴ to select “Setup”, then press ϶ or

ENTER.

Press ϳ or ϴ to select “Backlight”.

51F0101A_eng.indd 24 3/5/08 5:05:58 PM

Setup

DVD 00 :15:25 01:4 1:39

Title 1 /3 Chapte r2/2 4

1/1 Eng Dolby Digit al 1 /2 Eng

1/1

DISC OPERATION

ELAPSED TIME

TOTAL TIME

CHAPTER NO.

SUBTITLE LANGUAGE

A KIND OF AUDIOAUDIO LANGUAGE

ANGLE NO.

TITLE NO.

To make the status display screen disappear, press

DISPLAY again.

•

51F0101A_eng.indd 25 3/7/08 4:29:20 PM

Closed Caption >>

Language English

Video Label >>

Backlight

Auto Shut Off Off

Reset >>

: Adjust

: Select

Press ϵ or ϶ to adjust the setting.

Press EXIT/CANCEL to return to the normal

screen.

Setting the Auto Shut Off

If the Auto Shut Off feature is On, a station being viewed stops broadcasting and the TV is not operated, the TV will automatically shut itself off after 15 minutes.

Press SETUP/TV MENU in the TV mode. The TV

menu screen will appear.

Press ϳ or ϴ to select “Setup”, then press ϶ or

ENTER.

Press ϳ or ϴ to select “Auto Shut Off ”.

Press ϵ or ϶ to select “On” or “Off”.

Setup

Closed Caption >>

Language English

Video Label >>

Backlight

Auto Shut Off Off

Reset >>

: Adjust

: Select

Press EXIT/CANCEL to return to the normal

screen.

Resetting your settings

The Reset function returns your settings to the factory settings.

Press SETUP/TV MENU in the TV mode. The TV

menu screen will appear.

Press ϳ or ϴ to select “Setup” , then press ϶ or

ENTER.

Press ϳ or ϴ to select “Reset”.

Setup

Closed Caption >>

Language English

Video Label >>

Backlight

Auto Shut Off Off

Reset >>

: Select ENTER:Set

Press ϶ or ENTER to return your settings to the

factory settings. “Reset” will appear on the screen approx. 3

seconds, then it returns to the normal screen.


Picture Setting >> Picture Preference Sports Picture Size >> Film Mode On PC Setting >> DNR On

: Select ENTER:Set

NOTE:

•

“Picture Size” in Picture menu cannot be reset by this function.

•

“MTS”, “Audio Language”, “HDMI1 Audio” and “Speakers” in Audio menu cannot be reset by this function.

Audio

Bass

Treble

Balance

MTS Stereo

Audio Language No Info.

HDMI1 Audio HDMI

Speakers On

: Select

: Adjust

Preparation

The following pages describe the setup/ operation in DVD mode.

Preparation

Before DVD/CD operation, please make the following preparations.

Insert the AC cord plug into a standard 120V

60Hz polarized AC outlet.

If the AC cord plug is plugged in for the first

• time, wait for about 5 seconds before pressing

POWER.

NOTE:

When connecting to other equipment, unplug

• the unit from the AC outlet.

Press POWER on the unit or on the remote

control to turn on the unit. The POWER indicator will change to green.

Each time you turn the unit ON, the TV/DVD

• starts from the TV mode. When using an amplifier, switch on the

• amplifier.

Press TV/DVD to select DVD mode.

The DVD startup screen will appear on the screen.

NOTE:

If the unit does not operate properly:

Static electricity, etc., may affect the player’s operation. Disconnect the AC power cord once, then connect it again.

Status display of disc

Press DISPLAY. The status display of the disc will appear on the screen.

Playback procedure

On the screen, “

” changes to “Reading” and

then playback will commence.

A menu screen may appear on the TV screen, if the disc has a menu feature. In this case,

press ϳ, ϴ, ϵ, ϶ or ENTER to operate a menu

feature.

•

Reading

Press STOP to end playback.

The unit memorizes the stopped point, depending on the disc. “

” appears on the screen. Press PLAY to resume playback (from the scene point). If you press STOP again (“ ” appears on the screen) or unload the disc, the unit will clear the stopped point.

•

Press (EJECT). Remove the disc and then press POWER. The unit turns off. When you eject the disc, you may hear mechanism noise, but it is not malfunction.

NOTE:

If a non-compatible disc is loaded, “Incorrect Disc”, “Region Code Error” or “Parental Error” will appear on the TV screen according to the type of loaded disc. If these appear, check your disc again (see pages 8 and 33~34). Some discs may take a minute or so to start playback. If an 8 cm disc is placed into the disc slot and picture playback or menu display does not begin automatically, press PLAY. A “Prohibition” symbol “

” may appear at the upper right of the screen. This symbol means either the feature you tried is not available on the disc, or the unit cannot access the feature at this time. This does not indicate a problem with the unit. If you place a single-faced disc label backwards (i.e. the wrong way) “Reading” will appear in the display and then “Incorrect Disc” will be displayed. Some playback operations of DVDs may be intentionally fixed by software producers. Since this unit plays DVDs according to the disc content recorded, some playback features may not be available. Also refer to the instructions supplied with the DVDs.

•

Special playback

Fast Forward Playback

Press SEARCH

during normal playback.

Each press of SEARCH

will increase the speed of

the search

(x 2), (x 4), (x 8), (x

15). (CD:

(x 2), (x 4), (x 8), (x 20))

To resume normal playback, press PLAY.

Review Playback

Press SEARCH

during normal playback.

Each press of SEARCH

will increase the speed

of the search

(x 2), (x 4), (x 8), (x 15). (CD:

(x 2), (x 4), (x 8), (x 20))

To resume normal playback, press PLAY.

Still Playback

Press PAUSE/STILL during normal playback to pause playback.

To resume normal playback, press PLAY.

Frame Advance

Press PAUSE/STILL during still playback. One frame is advanced each time you press PAUSE/ STILL.

To resume normal playback, press PLAY.

Slow-motion Playback

Press SLOW Reverse or SLOW Forward during

normal playback or still playback.

Each press of

SLOW

will change the speed of the

slow x1/2, x1/4, x1/6, x1/7.

To resume normal playback, press PLAY. To resume the still playback, press PAUSE/STILL.

Locating a chapter or track

Press SKIP Forward or SKIP Reverse during playback to locate a chapter that you want to watch. Each time you press the button, a chapter or track is skipped.

NOTE:

The unit is capable of holding a still video image or On screen display image on your television screen indefinitely. If you leave the still video image or On screen display image displayed on your TV for an extended period of time, you risk permanent damage to your television screen. There may be a slight delay between when you press the button and the function activating.

•

51F0101A_eng.indd 26 3/5/08 5:05:59 PM

Press TV/DVD to select DVD mode.

Place the disc in the

disc slot with the label side facing forward. (If the disc has a label.) Hold the disc without touching either of its surfaces, align it with the guides, and place it in position.

MP3/WMA/JPEG and

Selected file name

MP3- 5

MP3- 6

WMA- 11

WMA- 12

Pict ure-1

Pict ure-2

Musi c Pla ying

Sele ct Fi les

Repea t :Off

Mode :Off

/MP3 -5.MP 3

1/15 00: 00:00

Pict ure-3

Pict ure-4

File number

Operation status

Elapsed time

Tool kit window

Preview windowCursor

File list

: Indicates Music file (Audio CD/MP3/WMA) : Indicates Picture file (JPEG)

File type

In case the current directory includes 9 files or

more, press ϳ or ϴ to scroll in the file list.

To see contents in folder, select the folder and then press ENTER. To return to the parent directory, select “

Go Up ...” then press ENTER. In case of a CD containing a mixture of MP3, WMA and JPEG files, the files are played back by selecting them from the file browser.

•

Press ϳ or ϴ to select the desired file.

When PLAY is pressed after displaying file browser displayed, playback begins automatically starting from the first file. In this case, if the first file is an MP3/WMA file, only MP3/WMA files are played back in order. If the first file is a JPEG file, the first JPEG file is played back. If there is no file at a root directory, playback does not begin automatically.

Folde r-1

Folde r-2

MP3- 1

MP3- 2

MP3- 3

WMA- 1

WMA- 2

WMA- 3

/MP3- 2.MP3

JPEG Previ ew

Selec t Fil es

Repea t :Off

Mode :Off

Press ENTER. The selected file starts playing back.

Press STOP to end playback.

The unit records the stopped point. “

” appears on the screen. Press PLAY to resume playback (from the scene point). If you press STOP again or unload the disc, the unit will clear the stopped point.

NOTE:

During MP3/WMA/JPEG-Playback, you cannot use JUMP and A-B Repeat functions. You can use Program playback, Repeat (Track or All) and Random functions for MP3/WMA/ JPEG and Audio CD Playback (see pages 28 and 29).

•

51F0101A_eng.indd 27 3/5/08 5:06:00 PM

Audio CD playback

This player can play back MP3/WMA/JPEG-data which has been recorded on CD-R or CD-RW. To produce MP3/WMA/JPEG-data, you need a Windows-PC with CD-ROM drive and MP3/WMA/ JPEG-encoding software (not supplied). The Apple-HFS-System cannot be played.

MP3/WMA/JPEG CD information

Limitations on MP3/WMA/JPEG CD playback

•

MP3/WMA/JPEG CD is the disc that is standardized by ISO9660, its file name must include 3-digit extension letters, “mp3”, “wma”, “jpg”.

•

The directory and file names of MP3/WMA/JPEG CD must correspond to ISO standardized files.

•

This unit can read 2000 files per disc. If one directory has more than 2000 files, it reads up to 2000 files, the remaining files will be omitted.

•

MP3/WMA CDs cannot be used for playback for the purpose of recording.

•

If the CD has both audio tracks and MP3/WMA/ JPEG files, only audio tracks are played.

•

It may take more than one minute for this unit to read MP3/WMA/JPEG files depending on its structure.

•

Music recorded by “Joliet Recording Specification” can be played back.

•

The music files recorded by “Hierarchical File System” (HFS) cannot be played.

•

The unit can play back baseline and progressive JPEG files. MP3 or WMA files on the KODAK Picture CD are

• not recognized on this unit.

Limitations on display

The maximum number for display is 15 characters.

• Long file names will be condensed. Available letters for display are the following:

• capital or lowercase letters A through Z, numbers 0 through 9, and _ (under score). Other letters than those above are replaced by a

• hyphen.

Notes on MP3/WMA/JPEG files

To play back MP3/WMA/JPEG CD in the recorded order,

Use MP3/WMA/JPEG software that records data

1. alphabetically or numerically. Name each file including a two-digit or three-digit

2. number (e.g. “01” “02” or “001” “002”). Refrain from making too many sub-folders.

CAUTION:

Some MP3/WMA/JPEG CDs cannot be played

• back depending on the recording conditions. The CD-R/RW that has no music data or non-MP3/

• WMA/JPEG files can not be played back.

MP3/WMA CD and Audio CD playback:

Load a MP3/WMA/JPEG CD or an Audio CD in

the disc slot.

“Reading” will appear on the TV screen. Reading

time will depend on the number of files on the disc.

A file browser screen will appear on the TV

screen.

JPEG playback:

Pict ure-0 1

Pict ure-0 2

Pict ure-0 3

Pict ure-0 4

Pict ure-0 5

Pict ure-0 6

Pict ure-0 7

Pict ure-0 8

JPEG Previ ew

Selec t Fil es

Repea t :Off

Mode :Off

W: 2048 H: 1 536

/Pict ure-0 1.JPG

Press ENTER or PLAY. The selected picture appears on the TV screen.

Rotating an image

You can rotate an image by 90 degrees. Press ANGLE during playback of the image. “

”, “ ”, “ ” or “ ” appears on the screen.

Zooming an image

Zoom function also can be used in viewing JPEG files. Press ZOOM (See “Zooming” on page 29).

Press STOP to end playback. The file browser appears on the TV screen. If you want to watch the other file, repeat steps 1-2.

Select Files

The file type to make it display in the file browser can be chosen.

Press ϵ/϶ to select “Select Files” at right column

in the file browser.

Press ENTER, then press ϳ/ϴ to select file

type from the list (Music or Picture).

•

Press ENTER to add/remove check mark. Checked file type will be displayed in the file browser.

Press RETURN to save the setting.

Setting the JPEG interval

You can continuously play back all JPEG files automatically.

Press SETUP/TV MENU in the stop mode.

Press ϳ or ϴ to select

option, then press

ϵ/϶ or ENTER.

Press ϳ or ϴ to select “JPEG Interval”, then press

϶ or ENTER.

Press ϳ or ϴ to select your desired time, then

press ENTER.

TV Screen :

Display : On

Picture Mode : Auto

JPEG Interval

Off

5 Seconds 10 Seconds 15 Seconds

: 16:9

Off:

Plays back one file at a time.

5 Seconds:

Plays back images in the form of a slide show at 5 second intervals.

10 Seconds:

Plays back images in the form of a slide show at 10 second intervals.

15 Seconds:

Plays back images in the form of a slide show in 15 second intervals.

Press SETUP/TV MENU to remove the menu screen.

Program playback (CD)

You can arrange the order of tracks on the disc.

In the file browser, press ϳ/ϴ/ϵ/϶ to select “Edit

Mode”, then press ENTER.

When “Edit Mode” is black color, you can mark the files which you want to add into Program list.

Folde r-1

Folde r-2

MP3- 1

MP3- 2

MP3- 3

WMA- 1

WMA- 2

WMA- 3

JPEG Previ ew

Repeat :Of f

Mode :Off

Edit M ode

Press ϳ/ϴ/ϵ/϶ to select the file you want to add

into the program list.

Press ENTER. Selected file was marked. Repeat this procedure to select the other files.

Folde r-1

Folde r-2

MP3- 1

MP3- 2

MP3- 3

WMA- 1

WMA- 2

WMA- 3

JPEG Previ ew

Repeat :Of f

Mode :Off

Edit M ode

/MP3- 1.MP3

Press ϳ/ϴ/ϵ/϶ to select “Add To Program”.

Then press ENTER. All marked files are added into the program list.

When you finish storing the files you want into the Program list, select “Edit Mode” again and press ENTER to release edit mode.

51F0101A_eng.indd 28 3/5/08 5:06:01 PM

In the file browser, pressϳ/ϴ to select the desired

JPEG file. To display a thumbnail list, press DVD MENU.

Press ϳ/ϴ/ϵ/϶ to select the desired file.

(To return to the file browser, press TOP MENU.)

Folde r-1

Folde r-2

MP3- 1

MP3- 2

MP3- 3

WMA- 1

WMA- 2

WMA- 3

JPEG Previ ew

Edit M ode

Progra m V iew

Add To P rogra m

Press ϳ/ϴ to select “Program View”, then

press ENTER. Program View shows only the programmed files that you have added in Step 2.

Folder -1

Folder -2

MP3-1

MP3-2

MP3-3

WMA-1

WMA-2

WMA-3

JPEG Previe w

Edit Mo de

Program Vi ew

Add To Pr ogram

MP3-1

MP3-2

MP3-3

WMA-3

JPEG Previe w

Edit Mo de

Browser Vie w

Clear P rogra m

Browser View Program View

In the Program View, press PLAY. The files start to playback in programmed order that were added by you.

To remove file from program list in stop mode

In the Edit Mode, switch to Program View. Select the files you want to remove, then press ENTER. Select “Clear Program” and press ENTER. Marked file is removed from program list.

NOTE:

The program is cancelled when you eject the disc or turn the power off.

Repeat playback (CD)

In the file browser, press ϳ/ϴ/ϵ/϶ to select

“Repeat”.

Press ENTER repeatedly to select “Track” or “All”.

Folde r-1

Folde r-2

MP3- 1

MP3- 2

MP3- 3

WMA- 1

WMA- 2

WMA- 3

JPEG Previ ew

Selec t Fil es

Repea t :Trac k

Mode :Off

Press PLAY. The unit automatically starts repeat playback after finishing the current track.

To resume normal playback, select Repeat : “Off” in step 2.

NOTE:

The repeat or random function is canceled when you eject the disc or turn the power off. The track repeat function is canceled when SKIP

or is pressed. In case of Audio CD, the function of A-B Repeat also can be used (See “A-B Repeat playback” on page 30).

•

Random playback (CD)

In the file browser, press ϳ/ϴ/ϵ/϶ to select

“Mode”.

Press ENTER to select “Random”.

Folde r-1

Folde r-2

MP3- 1

MP3- 2

MP3- 3

WMA- 1

WMA- 2

WMA- 3

JPEG Previ ew

Selec t Fil es

Repea t :Off

Mode :Rando m

Press PLAY. The Random playback will start.

To resume normal playback, select Mode : “Off” in step 2.

Zooming

This unit will allow you to zoom in on the frame image. You can then make selections by switching the position of the frame.

Press ZOOM during playback. The center part of the image will be zoomed in. Each press of ZOOM will change the ZOOM magnification

1 (x 1.3), 2 (x 1.5) and 3

(x 2.0).

Press ϳ/ϴ/ϵ/϶ to view a different part of the

frame. You may move the frame from the center position UP, DOWN, LEFT or RIGHT.

In the zoom mode press ZOOM repeatedly to return to a 1:1 view (

Off).

NOTE:

You can select the Pause, Slow or Search playback in the zoom mode. Some discs may not respond to zoom feature.

Locating desired scene

Use the title, chapter and time recorded on the disc to locate the desired point to play back.

Press JUMP during playback or stop mode.

Time

Titl e Cha pter

Jum p

Press ϳ or ϴ to select the “Title”, “Chapter” or

“Time”.

Press Number buttons (0–9) to input the number.

If you input a wrong number, press EXIT/ CANCEL. Refer to the package supplied with the disc to check the numbers.

•

51F0101A_eng.indd 29 3/7/08 4:29:23 PM

Press ENTER.

Playback starts.

• When you change the title, playback starts from

• Chapter 1 of the selected title. Some discs may not work in the above

• operation.

Repeat playback

Title, Chapter Playback:

Press PLAY MODE during playback or stop

mode.

Press ENTER repeatedly to select “Chapter” or

“Title”. The unit automatically starts repeat playback after finishing the current title or chapter.

If you set the repeat mode during stop mode,

• press PLAY to start Repeat playback.

Play Mo de

Repeat : Off

Press PLAY MODE again to make the screen

disappear.

•

In stop mode, press PLAY to start Repeat playback. To resume normal playback, select Repeat

• “Off” in step 2.

A-B Repeat Playback:

A-B repeat playback allows you to repeat material between two selected points.

Press REPEAT A-B during playback.

The start point is selected.

Press REPEAT A-B again.

The end point is selected. Playback starts at the point that you selected. Playback stops at the end point, returns to Point A automatically, then starts again.

A B

During the A-B Repeat Playback the ANGLE

• feature will not operate. You may not be able to set A-B Repeat, depending

• on the scenes of the DVD.

•

A-B Repeat does not work with an interactive DVD, MP3/WMA/JPEG-CD.

Marking desired scenes

The TV/DVD stores the points that you want to watch again. You can resume playback from that scene.

Marking the scenes:

Press MARKER during playback.

Select the blank Marker using ϳ or ϴ, then press

ENTER at the desired scene.

Marker 1 Marker 2 Marker 3

•

Up to 3 scenes can be selected.

•

Repeat this procedure to set the other 2 scenes.

Press MARKER to remove this display.

Returning to the scenes:

Press MARKER during playback or stop mode.

Press ϳ or ϴ to select the Marker 1-3.

Marker 1 Marker 2 Marker 3

Press ENTER.

Playback starts from the marked scene.

To cancel the mark:

Press MARKER during playback or stop mode.

Press ϳ or ϴ to select the Marker 1-3.

Press EXIT/CANCEL.

Press MARKER to remove this display.

NOTE:

The marking is canceled when you eject the disc or

• turn the power off. Some subtitles recorded around the marker may fail

• to appear. [DVD]

00 2 7 5 4

00 2 7 5 4 01 1 6 2 5 02 0 8 3 1

To resume normal playback press REPEAT A-B

again.

” appears on the screen.

“

Off

NOTE:

•

Some discs may not work with the repeat operation. In A-B repeat mode, subtitles near point A or B may

• not appear.

51F0101A_eng.indd 30 3/7/08 4:29:24 PM

Changing soundtrack language

You can select the language when you play a multilingual disc.

Press AUDIO during playback.

1/2 Eng Dolby Digital

Press AUDIO repeatedly until the desired language is selected.

The on-screen display will disappear after a few seconds.

NOTE:

If the desired language is not heard after pressing AUDIO several times, the language is not recorded on the disc. Changing soundtrack language is cancelled when you eject the disc. The initial default language or available language will be heard if the disc is played back again.

Subtitles

Turning the subtitles on and off

When playing back a disc recorded with subtitles, you can turn the subtitles on or off.

Press SUBTITLE during playback until “Off” appears.

Off

Changing the subtitle language

You can select the language when playing back a disc recorded with multilingual subtitles.

Press SUBTITLE repeatedly during playback until your desired language appears.

1/5 Eng

The on-screen display will disappear after a few seconds.

NOTE:

Changing subtitle language is cancelled when you eject the disc. Some functions may not work on some DVDs. You may not be able to turn subtitles on or off or change subtitles. While playing the DVD, the subtitle may change when:

- you eject the disc.

- you change the title. In some cases, the subtitle language is not changed to the selected one immediately.

•

Changing angles

When playing back a disc recorded with multiangle facility, you can change the view angle.

Press ANGLE during playback.

The current angle will appear.

1/2

Press ANGLE repeatedly until the desired angle is selected.

NOTE:

Depending on the DVD, you may not be able to change the angles even if multi-angles are recorded on the DVD.

Title selection

Two or more titles are recorded on some discs. If the title menu is recorded on the disc, you can select the desired title.

Press TOP MENU during playback. Title menu appears on the screen.

Press ϳ/ϴ or ϵ/϶ to select the desired title.

Press ENTER or PLAY. The playback of the selected title will start.

NOTE:

Depending on the DVD, you may not be able to select the title. Depending on the DVD, a “title menu” may simply be called a “menu” or “title” in the instructions supplied with the disc.

DVD menu

Some DVDs allow you to select the disc contents using the menu. When you playback these DVDs, you can select the subtitle language and soundtrack language, etc. using the DVD menu.

Press DVD MENU during playback. The DVD menu appears on the screen.

Press DVD MENU again to resume playback at the scene when you pressed DVD MENU.

•

Press ϳ/ϴ or ϵ/϶ to select the desired item.

Press ENTER. The menu continues to another screen. Repeat steps 2 and 3 to set additional items if any.

•

51F0101A_eng.indd 31 3/5/08 5:06:05 PM

The current soundtrack language will appear.

Setting the language

Subtitle

Audio

English

Francais

Espanol

Other

English, Francais, Espanol :

The selected language will be heard or seen.

Other:

Other language can be selected (see the “Language code list” on page 35).

Original (Audio):

The unit will select the first priority language of each disc.

Off (Subtitle):

Subtitles do not appear.

Press SETUP/TV MENU to remove the menu screen.

NOTE:

If the selected language is not recorded on the disc, the first priority language is selected.

Setting the aspect ratio of TV screen

You can select the aspect ratio of the picture.

Press SETUP/TV MENU in the stop mode or No Disc.

Press ϳ or ϴ to select

option, then press

ϵ/϶ or ENTER.

Press ϳ or ϴ to select “TV Screen”, then press ϶

or ENTER.

Press ϳ or ϴ to select your desired screen type,

then press ENTER.

TV Screen 4:3

Display

4:3

Picture Mode

JPEG Interval : Off

16:9

•

You have the following screen sizes to choose from:

4:3

Letterbox

When playing back a wide screen DVD disc, it displays the wide picture with black bands at the top and bottom of screen.

4:3 Panscan

It displays the wide picture on the whole screen with left and right edges automatically cut off.

16:9

Wide

A wide screen picture is displayed full size.

Press SETUP/TV MENU to remove the menu screen.

NOTE:

It is not always possible for the DVD disc to display the picture as per your preferred picture setting - for example, if you select “4:3 Panscan”, the disc may not offer this option. In this case the picture would display the format the disc is capable of playing back.

Setting on screen display

On screen display can be switched on or off when you press the any button.

Press SETUP/TV MENU in the stop mode or No Disc.

Press ϳ or ϴ to select

option, then press

ϵ/϶ or ENTER.

Press ϳ or ϴ to select “Display”, then press ϶ or

ENTER.

Press ϳ or ϴ to select “On” or “Off”, then press

ENTER.

TV Screen :

: Off

Display

Picture Mode

JPEG Interval

Off

: 16:9

On: On screen displays appear when you press

the buttons (factory setting).

Off: On screen displays do not appear when you

press any buttons except SUBTITLE, PLAY

MODE, MARKER, DISPLAY, AUDIO and JUMP.

Press SETUP/TV MENU to remove the menu screen.

Setting the picture mode

There are two types of source content in pictures recorded in DVD video discs: film content (pictures recorded from films at 24 frames per second) and video content (video signals recorded at 30 frames per second). Make this selection according to the type of content being viewed.

•

51F0101A_eng.indd 32 3/5/08 5:06:05 PM

You can select the language of “Menu”, “Subtitle” and “Audio” if more than one languages are recorded onto the disc.

Press SETUP/TV MENU in the stop mode.

Press ϳ or ϴ to select

or ENTER.

Press ϳ or ϴ to select desired option, then press

϶ or ENTER.

Press ϳ or ϴ to select your desired language

(e.g. English), then press ENTER.

option, then press ϵ/϶

Press SETUP/TV MENU in the stop mode or No

option, then press

ϵ/϶ or ENTER.

Press ϳ or ϴ to select “Parental”, then press ϶ or

ENTER. “Enter Password” screen will appear.

Press “0000” using Number buttons (0-9). (This is pre-setting password of this unit). Then press ENTER.

If you input a wrong number, press EXIT/ CANCEL.

•

51F0101A_eng.indd 33 3/5/08 5:06:06 PM

Disc.

Press ϳ or ϴ to select

or ENTER.

Press ϳ or ϴ to select “Picture Mode”, then press

϶ or ENTER.

Press ϳ or ϴ to select your desired picture mode,

then press ENTER.

TV Screen :

Picture Mode

JPEG Interval

Auto:

Select this position normally. The DVD player automatically detects source content, film or video, of playback source.

Film:

Suitable for playback of film content pictures.

Video:

Suitable for playback of video content pictures.

Press SETUP/TV MENU to remove the menu

screen.

NOTE:

•

Depending on the disc, pictures may be cut off or doubled. In this case, select “Video”.

Night Mode

Night Mode enables you to control the dynamic range so as to achieve a suitable sound for your equipment.

Press SETUP/TV MENU in the stop mode or No

Disc.

Press ϳ or ϴ to select

ϵ/϶ or ENTER.

Press ϳ or ϴ to select “Night Mode”, then press

϶ or ENTER.

Press ϳ or ϴ to select “On” or “Off”, then press

ENTER. On : Loud sounds such as explosions are toned

down slightly when played.

Off : The unit will play the disc as recorded.

Night Mode

Digital Out

option, then press ϵ/϶

: 16:9

: OnDisplay

Auto

Film

Video

option, then press

Off

Press SETUP/TV MENU to remove the menu

screen.

Digital Out

You can select the digital output sound format corresponding to your system connection.

Press SETUP/TV MENU in the stop mode or No

Disc.

Press ϳ or ϴ to select

ϵ/϶ or ENTER.

Press ϳ or ϴ to select “Digital Out”, then press ϶

or ENTER.

Press ϳ or ϴ to select “Off”, “PCM” or “Bitstream”,

then press ENTER.

Digital Out

Off: There is no sound output from

PCM: Change Dolby Digital to PCM for the

Bitstream: Disc audio bitstream data will be

Press SETUP/TV MENU to remove the menu

screen.

NOTE:

This function works only during playback of Dolby Digital recorded discs. The level of Dynamic Range Reduction may differ depending on DVD video disc. Even if you select “Bitstream”, MPEG audio will be output in PCM format.

DIGITAL AUDIO OUT jack.

output. Select when connected to a 2 channel digital stereo amplifier.

output.

: OffNight Mode

Off

PCM

Bitstream

option, then press

Parental control

Some discs are specified not suitable for children. Such discs can be limited not to play back with the unit.

Password and setting:

Press SETUP/TV MENU in the stop mode or No

Disc.

Press ϳ or ϴ to select

Parental : Off

option, then press

ϵ/϶ or ENTER.

Press ϳ or ϴ to select “Password”, then press ϶

or ENTER. “Enter Current Password” screen will appear.

Press Number buttons (0-9) to enter the password you have stored.

If you input a wrong number, press EXIT/ CANCEL.

•

Then press ENTER. “Enter New Password” screen will appear. Press Number buttons (0–9) to input the new password.

•

Parental : Off

Password : Change

Enter New Pas sword

Press ENTER. Now your new password has been set. Be sure to remember this number!

NOTE:

If you forget your password it can be reset. With no disc in the player and in DVD mode, press STOP on the unit. Continue holding the button and press 7 on the remote control at the same time. “Password Clear” appears on the screen. Now the password has been return to the initial value (0000).

Temporary disabling of rating level by DVD disc

Some pre-recorded DVD discs may attempt to temporarily cancel the rating level that you have set. You will be given the option to allow or not allow the override.

Load a DVD disc (see page 26).

If the DVD disc has been designed to temporarily cancel the Rating level, the screen which follows the “Reading” screen will change, depending on which disc is played. If you select “YES” with ENTER key, password input screen will then appear.

Enter the password with Number buttons (0-9). Then press ENTER.

If you interrupt the entering, press RETURN.•

Enter Password

Playback will commence if the entered password was correct.

NOTE:

This temporary cancellation of the rating level will be kept until the disc is ejected. When the disc is ejected, the original rating level will be set again automatically.

•

51F0101A_eng.indd 34 3/7/08 4:29:25 PM

Password : Change

Enter Password

The parental level list will appear. Press ϳ or ϴ to

select the level 1 to level 8. The limitation will be more severe as the level number is lowered. Then press ENTER.

Parental

Password

Level Off : The parental control setting does

•

Level 8 : Virtually all DVD software can be

•

Level 1 : DVD software for adults cannot be

•

Select from level 1 to level 8. The limitation will

• be more severe as the level number decreases.

Press SETUP/TV MENU to remove the menu

screen.

NOTE:

If each setup (P.32~34) has been completed, the unit will use these settings during DVD playback. Each setup will be retained in memory.

Depending on the discs, the unit may not be able to limit playback. Some discs may not be encoded with specific rating level information though its disc jacket says “adult”. For those discs, the age restriction will not work. After the rating is locked, the setting cannot be changed unless you enter the correct password.

1 2 3 4 5 6 7 8 Off

not function.

played back.

Setting the new password:

Press SETUP/TV MENU in the stop mode or No

Disc.

Press ϳ or ϴ to select

Language code list

Enter the appropriate code number for the initial settings “Menu”, “Subtitle” and/or “Audio” (see page 32).

Language Name Code Language Name Code Language Name Code Language Name Code

Abkhazian 1112 Fiji 1620 Lingala 2224 Singhalese 2919

Afar 1111 Finnish 1619 Lithuanian 2230 Slovak 2921

Afrikaans 1116 French 1628 Macedonian 2321 Slovenian 2922

Albanian 2927 Frisian 1635 Malagasy 2317 Somali 2925

Amharic 1123 Galician 1722 Malay 2329 Spanish 1529

Arabic 1128 Georgian 2111 Malayalam 2322 Sundanese 2931

Armenian 1835 German 1415 Maltese 2330 Swahili 2933

Assamese 1129 Greek 1522 Maori 2319 Swedish 2932

Aymara 1135 Greenlandic 2122 Marathi 2328 Tagalog 3022

Azerbaijani 1136 Guarani 1724 Moldavian 2325 Tajik 3017

Bashkir 1211 Gujarati 1731 Mongolian 2324 Tamil 3011

Basque 1531 Hausa 1811 Nauru 2411 Tatar 3030

Bengali; Bangla 1224 Hebrew 1933 Nepali 2415 Telugu 3015

Bhutani 1436 Hindi 1819 Norwegian 2425 Thai 3018

Bihari 1218 Hungarian 1831 Oriya 2528 Tibetan 1225

Breton 1228 Icelandic 1929 Panjabi 2611 Tigrinya 3019

Bulgarian 1217 Indonesian 1924 Pashto, Pushto 2629 Tonga 3025

Burmese 2335 Interlingua 1911 Persian 1611 Turkish 3028

Byelorussian 1215 Irish 1711 Polish 2622 Turkmen 3021

Cambodian 2123 Italian 1930 Portuguese 2630 Twi 3033

Catalan 1311 Japanese 2011 Quechua 2731 Ukrainian 3121

Chinese 3618 Javanese 2033

Corsican 1325 Kannada 2124 Romanian 2825 Uzbek 3136

Croatian 1828 Kashmiri 2129 Russian 2831 Vietnamese 3219

Czech 1329 Kazakh 2121 Samoan 2923 Volapük 3225

Danish 1411 Kirghiz 2135 Sanskrit 2911 Welsh 1335

Dutch 2422 Korean 2125 Scots Gaelic 1714 Wolof 3325

English 1524 Kurdish 2131 Serbian 2928 Xhosa 3418

Esperanto 1525 Laothian 2225 Serbo-Croatian 2918 Yiddish 2019

Estonian 1530 Latin 2211 Shona 2924 Yoruba 3525

Faroese 1625 Latvian, Lettish 2232 Sindhi 2914 Zulu 3631

Rhaeto-Romance

2823 Urdu 3128

51F0101A_eng.indd 35 3/5/08 5:06:08 PM

To connect the LCD TV/DVD to a VCR with an S-Video cord

If you connect a VCR with a S-Video cable to the S-VIDEO IN jack on the rear side of the unit, you must also connect the audio cables to the LINE 1 AUDIO IN jacks on the rear side of the unit. The S-Video cable only carries the video signal. The audio signal is separate.

NOTE:

When the S-Video cable and the standard video cable are connected at the same time, the S-Video cable takes precedence.

•

The exact arrangement you use to interconnect various video and audio components to this unit is dependent on the model and features of each component. Check the Owner’s Manual provided with each component for the location of video and audio inputs and outputs.

To connect the LCD TV/DVD to a VCR

Connections to other equipment

To connect to a DVD player with Component Video Input

You can enjoy a high quality picture by connecting the unit’s COMPONENT VIDEO OUT jacks of your DVD player with the COMPONENT video cables (not supplied).

Rear of the unit

To Audio/Video OUT

Audio/Video cord

(not supplied)

To LINE 2 VIDEO/AUDIO IN

To S-Video OUT

To Audio OUT

Audio cord (not supplied)

S-Video cord (not supplied)

To S-VIDEO IN

To LINE 1 AUDIO IN

Rear of the unit

To Component OUT

Audio cord (not supplied)

Component video cord

(not supplied)

To LINE 2 AUDIO IN

Rear of the unit

To COMPONENT IN

To Audio OUT

NOTE:

Component Video input of the unit are for use with a device which output 480i/1080i interlaced signals and 480p/720p progressive signals.

•

VCR

DVD

To LINE 1 VIDEO/AUDIO IN

51F0101A_eng.indd 36 3/10/08 10:56:11 AM

Connections to other equipment (continued)

Coaxial digital cable

(not supplied)

AV Amplifier with built-in digital surround decoder as listed above

Center Speaker

Coaxial Digital Audio Output

To Coaxial

Digital Audio Input

Rear of the unit

Front

Speaker

(Left)

Front Speaker (Right)

Subwoofer

Surround Speaker (Left)

Surround Speaker (Right)

TV/DVD

NOTE:

When you are viewing digital broadcast, this unit will not work in conjunction with DTS audio or MPEG audio. There will be no sound output if connected to an AV amplifier with a built-in DTS decoder or MPEG decoder. Coaxial digital audio output is active only when receiving digital broadcasting, not when receiving analog broadcasting.

•

HDMI - to - DVI adapter cable

(HDMI type A connector)

(not supplied)

Audio cord (not supplied)

HDMI cable (type A connector)

(not supplied)

To DVI output

To HDMI out

HDMI device

DVI device

To HDMI 1/DVI IN

To HDMI 2 (or HDMI 1/DVI) IN

To PC/DVI AUDIO IN

NOTE:

When you connect a DVI device, you must connect only with HDMI 1/DVI. When using HDMI 1 to connect your HDMI or DVI devices, you must select the corresponding audio input source (HDMI or DVI) on the menu screen (see ”Selecting the HDMI audio input source” on page 24). Otherwise you will only see the image with no sound.

If you connect an external component (cable box, satellite receiver, etc.) to this LCD TV using an HDMI cable or a DVI to HDMI cable, the image will not display if the output resolution of the component is set to 480i. To receive the picture you must change the output resolution on the external component.

Should you require further instruction, please contact the manufacturer of the external component.

•

51F0101A_eng.indd 37 3/10/08 10:56:11 AM

To connect a HDMI or a DVI device to the unit

The HDMI input receives digital audio and uncompressed video from a HDMI device or uncompressed digital video from a DVI device. When you connect to a DVI device with a HDMI-to-DVI adapter cable, it transfers only video signal. Separate analog audio cords required.

Rear of the unit

Using an AV Amplifier with built-in digital surround

If you are using an Amplifier with built-in digital surround sound, you can enjoy various audio systems including Dolby Digital Surround audio that sounds just like the movie.

Connect an AV amplifier with built-in Dolby Digital decoder, DTS decoder, or MPEG decoder etc. as shown below.

Connections to other equipment (continued)

To connect the TV/DVD to a camcorder, or a TV Game

To playback from a camcorder, connect the camcorder to the unit as shown. This unit can also be used as a display device for many video games. However, due to the wide variety of signals generated by these devices and subsequent hook-up variations required, they have not all been included in the suggested connection diagrams. You’ll need to consult each component’s Owner’s Manual for additional information.

Rear of the unit

Audio/Video cord

(not supplied)

To LINE 1 or LINE 2 VIDEO/AUDIO IN

To Audio/Video OUT

VGA cable (not supplied)

To connect the TV/DVD to a PC (Personal Computer)

Before you connect this TV/DVD to your PC, change the adjustment of your PC’s Resolution and Refresh rate (60 Hz). Connect one end of a (male to male) VGA cable to the video card of the computer and the other end to the

VGA

connector PC MONITOR on the rear of the

TV/DVD

. Attach the connectors firmly with the screws on the plug.

In case of a Multimedia computer, connect the audio cord to the audio output of your Multimedia computer and to the AUDIO connector of the PC/DVI AUDIO IN jack of the TV/DVD. Press INPUT SELECT on the remote control to select PC mode. Switch on the computer. The TV/DVD can operate as the computer monitor.

Monitor Display modes

MODE Resolution Refresh rate

VGA 640x480 60Hz VGA 720x400 70Hz SVGA 800x600 60Hz XGA 1024x768 60Hz WXGA 1280x768 60Hz WXGA 1280x720 60Hz WXGA 1360x768 60Hz

To return to normal mode

Press INPUT SELECT again.

PC/DVI AUDIO IN jack

To PC IN

NOTE:

The on-screen displays will have a different appearance in PC mode than in TV mode. If there is no video signal from the PC when the unit is in PC mode, “No signal” will appear on the TV-screen.

•

Audio cord (not supplied)

Rear of the unit

To connect an audio system

This connection allows you to use an audio amplifier and external speakers, and adjust the audio level using the TV’s remote control. To control the audio, turn on the unit and the stereo amplifier, and turn off the unit’s built-in speakers (see “Turning off the built-in speakers” on page 24).

Rear of the unit

Amplifier

To Audio (L) Input

To Audio (R) Input

Audio cord (not supplied)

NOTE:

To hear sound when using an external audio amplifier, the volume of both the unit and the amplifier must be set above 0 (zero).

For example, if the volume of the

unit is set to 0, you will not be able to hear any sound, even if the volume of the amplifier is at its highest level.

•

51F0101A_eng.indd 38 3/10/08 10:56:12 AM

GHOSTS

Ghosts are caused by the television signal following two paths. One is the direct path and the other is reflected by tall buildings, hills or other large objects. Changing the direction or position of the antenna may improve the reception.

SNOW

If the TV is located far from the TV station, in a fringe reception area where the signal is weak, small dots may appear in the picture. If the signal is extremely weak, the installation of a larger external antenna may be necessary.

RADIO FREQUENCY INTERFERENCE (RFI)

Caused by two-way radios, this type of interference produces moving ripples or diagonal streaks in the picture. Some cases may cause a loss of contrast in the picture. Changing the direction and position of the antenna or installing an RFI filter may improve the picture.

PICTURE SIZE VARIATION

A slight picture size variation is normal when you adjust the CONTRAST or BRIGHTNESS settings.

Most types of television interference can be remedied by adjusting the height and position of the VHF/ UHF antenna. Outdoor antennas are recommended for best results. The most common types of television interference are shown below. If one of these symptoms appear when the TV is connected to a Cable TV system, the disturbance may be caused by the local Cable TV company broadcast.

CARE AND MAINTENANCE

To prevent fire or shock hazard, disconnect the TV from the power source before cleaning. The finish on the cabinet may be cleaned with mild soap and a soft, damp cloth and cared for as other furniture. Use caution when cleaning or wiping the plastic parts.

Reception disturbances

IGNITION

Black spots or horizontal streaks may appear, the picture may flutter or drift. Usually caused by interference from automobile ignition systems, neon lamps or AC powered tools and appliances such as drills or hair dryers.

51F0101A_eng.indd 39 3/5/08 5:06:09 PM

Problems and troubleshooting

Use the following check list for troubleshooting when you have problems with your TV/DVD. Consult your local dealer or service outlet if problems persist. Be sure all connections are properly made when using with other units.

SYMPTOMS POSSIBLE SOLUTIONS PAGE

POWER

•

TV/DVD does not operate.

TV BROADCAST RECEPTION

Poor sound or no sound.

Poor picture or no picture.

Poor reception on some channels.

Poor color or no color.

Picture wobbles or drifts.

No Cable TV reception.

Horizontal or diagonal bars on screen.

No reception above channel 13.

TV shuts off.

Closed - Caption is not activated.

Display is not shown in your language.

•

Make sure the power cord is plugged in. Power is off, check fuse or circuit breaker. Unplug unit, then plug it back in.

Station or Cable TV experiencing problems, tune to another station. Check Volume adjustments or muting. Check for sources of possible interference. Check “Speakers” setting in the menu.

Station or Check antenna or Cable TV connections, reorient antenna. Check for sources of possible interference. Check picture control adjustments.

Station or Cable TV experiencing problems, tune to another station. Station signal is weak, reorient antenna to receive stronger station. Check for sources of possible interference.

Station or Make sure channels are set into memory. Check picture control adjustments. Check antenna or Cable TV connections, reorient antenna. Check for sources of possible interference.

Station or Cable TV experiencing problems, tune to another station. Make sure channels are set into memory. Cable TV company is scrambling signal. Check antenna orientation.

Check all Cable TV connections. Set Signal Type option to the “Cable” mode. Station or Cable TV system problems, try another station.

Check antenna connections, reorient antenna. Check for sources of possible interference.

Make sure Signal Type option is in the appropriate mode. If using antenna, check UHF antenna connections.

No broadcast on station tuned. Sleep Timer is set. Power interrupted.

TV station experiencing problems or program tuned is not closed captioned. Try another channel. Check Cable TV connection or VHF/UHF antenna, reposition or rotate antenna. Set Closed caption in the menu.

Select proper language in the menu options.• 15

Cable TV

experiencing problems, tune to another station.

Cable TV

experiencing problems, tune to another station.

16, 17 16, 17

39 24

16, 17 13, 14

39 21

16, 17

13 39

16, 17

15 21

13, 14

16, 17

–

14 15

16, 17

13 39

15 13

16, 17

–

16, 17

13, 14

The LCD panel is a very high technology product, giving you fine picture details. Occasionally, a few non-

• active pixels may appear on the screen as a fixed point of blue, green or red. Please note that this does not affect the performance of your product.

51F0101A_eng.indd 40 3/5/08 5:06:10 PM

” appears on the

screen.

The function is prohibited with the unit or the disc.• 26

REMOTE CONTROL

The remote control does not function.

Aim at the remote control at the remote sensor. Operate within Approx. 15 feet or reduce the light in the room. Clear the path of the beam. The batteries are weak. Replace the batteries. Check the batteries are inserted correctly.

•

Problems and troubleshooting (continued)

51F0101A_eng.indd 41 3/5/08 5:06:10 PM

SYMPTOMS POSSIBLE SOLUTIONS PAGE

DVD

•

No disc is inserted.

Playback doesn’t start.

No picture. TV/DVD selector is not set correctly.• 25

No sound.

Picture is distorted during CUE or REVIEW.

Stopping playback, search, slow-motion play, repeat play, or program play, etc. cannot be performed.

No on-screen display. Select Display On.• 32

No surround sound. The setup does not match your stereo system.• 37

The unit or remote operation key is not functioning.

Playback does not start when the title is selected.

Audio soundtrack and/or subtitle language is not changed when you play back a DVD.

No subtitle.

Angle cannot be changed. Multi-angles are not recorded on the DVD disc.• 31

“

•

The disc may be dirty. Clean up the disc.

•

The unit cannot play CD-ROMs, etc.

•

Check the input selector of the amplifier is set properly.

•

The unit is in the Special playback mode.

•

Select the correct Audio Output position on AV amplifier.

The picture will be distorted occasionally.• –

Some discs may not allow some functions.• –

Turn off the unit and unplug the AC power cord for several minutes,

• then replug it.

Check the Parental setup.• 33

Multilingual language is not recorded on the DVD disc.• 31

•

Some discs have no subtitles.

•

Subtitles are cleared. Press SUBTITLE.

8 8

– 26 37

Specifications

MODEL L26HD32D L32HD32D GENERAL

Power supply AC 120V 60Hz Power consumption Operation: 120W

Weight 8.8 kg (19.4 lbs) 12.0 kg (26.5 lbs) Dimensions Width: 663 mm (26-1/8 inches)

Operating temperature 5˚C - 40˚C Operating humidity Less than 80%

TELEVISION

Type 26.01 inches (660.5 mm diagonal) 31.5 inches (800.4 mm diagonal) Display method Transmission TFT color LCD panel Number of Pixels 1366 (H) x 768 (V) Tuner type NTSC standard

Receiving channels VHF 2-13

Inputs S-Video: Y-Input:1.0 V (p-p), 75 ohms

Outputs Digital audio out: 0.5 Vp-p 75 ohms terminated

Speaker 41 mm x 122 mm (1-5/8 inches x 4-13/16 inches), 8 ohms x 2 Audio output power 5.0W + 5.0W

DVD/CD player

Signal system NTSC Applicable disc 1.DVD (12 cm, 8 cm)

Pickup CD: Wavelength: 790 nm

ACCESSORIES Remote control

Stand by: 1W

Height: 495 mm (19-1/2 inches) Depth: 211 mm (8-5/16 inches)

ATSC standard (8VSB), QAM

UHF 14-69 CATV 14-36 (A)-(W) 37-59 (AA)-(WW) 60-85 (AAA)-(ZZZ) 86-94 (86)-(94) 95-99 (A-5)-(A-1) 100-125 (100)-(125) 01 (5A)

C-Input:0.3 V (p-p), 75 ohms Video: (RCA) 1 V p-p/75 ohms Audio: (RCA) –8 dBm/50K ohms Component video: (Y) 1 V (p-p), 75 ohms (PB)/(PR) 0.7 V (p-p), 75 ohms HDMI: HDMI compliant (type A connector) HDCP compliant E-EDID compliant Suggested scan rates: 1080i, 480p, 480i, 720p HDMI Audio: 2-channel PCM 32/44.1/48 kHz sampling frequency 16/20/24 bits per sample PC Monitor: Mini-Dsub 15pin x 1 Antenna: VHF/UHF In 75 ohms coaxial

Variable audio out: 0-600mV/1k ohms

2.CD (12 cm, 8 cm)

Maximum output power: 7 mW DVD: Wavelength: 655 nm Maximum output power: 5 mW

Batteries (UM-4) x 2 AC Cord

Operation: 160W Stand by: 1W

Width: 796.5 mm (31-3/8 inches) Height: 581 mm (22-7/8 inches) Depth: 214 mm (8-7/16 inches)

Designs and specifications are subject to change without notice.

51F0101B_eng.indd 42 4/4/08 10:04:04 AM

TTE Technology, Inc. (“TTE”) Limited Warranty

All LCD Models

EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, THIS WARRANTY DOES NOT COVER, AND AS DESCRIBED BELOW TTE EXPRESSLY DISCLAIMS, ALL ACTUAL AND IMPLIED WARRANTIES WITH RESPECT TO ANY PRODUCT USED FOR INSTITUTIONAL OR OTHER COMMERCIAL PURPOSES (INCLUDING BUT NOT LIMITED TO RENTAL PURPOSES).

What your warranty covers: Defects in materials or workmanship to the original owner

New LCD Televisions - Screen Sizes 32” and smaller:

•

For how long after your purchase:

•

Ninety (90) days from date of purchase for labor charges. After ninety (90) days, labor charges will be at owner expense.

•

One (1) year from date of purchase for parts.

•

What we will do:

•

At TTE’s discretion, pay an Authorized RCA Service Center for both labor charges and parts to repair your television, or replace your television with a new or refurbished/remanufactured unit.

•

See “How to get service”

New LCD Televisions - screen sizes 33” through 47”:

•

For how long after your purchase:

•

One (1) year from the date of purchase for labor charges.

•

One (1) year from the date of purchase for parts.

•

What we will do:

•

At TTE’s discretion, pay an Authorized RCA Service Center for labor charges and parts to repair your television, or replace your television with a new or refurbished/remanufactured unit.

•

See “How to get service”

All Remanufactured/Refurbished LCD Televisions:

•

For how long after your purchase:

•

Ninety (90) days from date of purchase for labor charges.

•

Ninety (90) days from date of purchase for parts.

•

What we will do:

•

At TTE’s discretion, pay an Authorized RCA Service Center for both labor charges and parts to repair your television, or replace your television with a refurbished/remanufactured unit.

•

See “How to get service”

How to get service:

•

Call 1-800-951-9582. Please have your unit’s date of purchase and model/serial number ready. The model/ serial number information can be found on the back of your unit.

•

A representative will troubleshoot your problem over the phone.

•

If it is determined that your unit requires service, the service location will be at the sole discretion of TTE based upon the TTE Limited Warranty statement.

•

At the sole discretion of TTE, television screen sizes 32” and smaller is either consumer carry-in to an Authorized RCA Service Center or directly exchanged for a new or refurbished/remanufactured unit.

•

At the sole discretion of TTE, television screen sizes 33” through 47” is either consumer carry-in to an Authorized RCA Service Center or directly exchanged for a new or refurbished/remanufacture unit.

•

Proof of purchase in the form of a bill of sale or receipted invoice from an Authorized Dealer which is evidence that the product is within the warranty period must be presented to obtain warranty service.

What your warranty does not cover:

•

Customer instruction. (Your Owner’s Manual describes how to install, adjust, and operate your unit. Any additional information should be obtained from your dealer.)

•

Installation and related adjustments.

•

Damage resulting from non-approved installation methods.

51F0101A_eng.indd 43 3/5/08 5:06:11 PM

•

51F0101B_eng.indd 44 4/4/08 10:04:05 AM

Signal reception problems not caused by your unit.

•

Damage from misuse or neglect.

•

Batteries.

•

A television that has been modified or incorporated into other products or is used for institutional or other commercial purposes (including but not limited to rental purposes).

•

A unit purchased or serviced outside the U.S.A.

•

Acts of nature, such as but not limited to lightning damage.

•

Special, incidental or consequential damages.

Product Registration:

•

Please complete and mail the Product Registration Card packed with your unit or register on-line at www.rca. com/television. It will make it easier to contact you should it ever be necessary. The return of the card is not required for warranty coverage.

Limitation of Warranty:

•

THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT. NO VERBAL OR WRITTEN INFORMATION GIVEN BY TTE TECHNOLOGY, INC., ITS AGENTS OR EMPLOYEES SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE OR MODIFY THE SCOPE OF THIS WARRANTY.

•

REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER. TTE TECHNOLOGY, INC. SHALL NOT BE LIABLE FOR SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT OR ARISING OUT OF ANY BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. THIS DISCLAIMER OF WARRANTIES AND LIMITED WARRANTY ARE GOVERNED BY THE LAWS OF THE STATE OF INDIANA. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED TO THE APPLICABLE WARRANTY AND WARRANTY PERIOD SET FORTH ABOVE.

How State Law relates to this warranty:

•

Some states do not allow the exclusion nor limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you.

•

This warranty gives you specific legal rights, and you also may have other rights that vary from state to state.

If you purchased your unit outside the United States or seek warranty coverage outside the United States:

•

This warranty does not apply. Contact your dealer for warranty information.

Service calls which do not involve defective materials or workmanship are not covered by this warranty. Costs of such service calls are the sole responsibility of the purchaser.

Visit the RCA website at www.rca.com/television

Please do not send any products to the Indianapolis address listed in this manual or on the carton. This will only add delays in service for your product.

TTE Technology, Inc.

101 West 103rd Street Indianapolis, IN 46290

J51F0101B SH 08/05

RCA L32HD32D, L26HD32D User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
