Caution: To reduce the risk of electric shock, do not remove cover (or back). No user serviceable parts
inside. Refer servicing to qualifi ed service personnel.
This symbol indicates "dangerous
voltage" inside the product that
presents a risk of electric shock or
personal injury.
WARNING
To reduce the risk of fi re or electric shock, do not
expose this product to rain or moisture. The apparatus
shall not be exposed to dripping or splashing. No objects fi lled with liquids, such as vases, shall be placed
on the apparatus.
This symbol indicates that this product incorporates
double insulation between hazardous mains voltage and
user accessible parts. When servicing use only identical
replacement parts.
This symbol indicates important
instructions accompanying the product.
CAUTION: THIS PRODUCT UTILIZES A LASER. USE
OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE
OF PROCEDURES OTHER THAN THOSE SPECIFIED
HEREIN MAY RESULT IN HAZARDOUS RADIATION
EXPOSURE. DO NOT OPEN COVERS AND DO NOT
REPAIR YOURSELF. REFER SERVICING TO QUALIFIED
PERSONNEL.
WARNING
The TV is unstable if it is not properly attached to the
base or mounted to the wall. Please follow the base
or wall mounting instructions provided in the User’s
Guide to ensure your safety.
CLASS 1
LASER
PRODUCT
This symbol indicates that this product contains mercury. Special disposal of this product for environmental
reasons may be required under the laws applicable to your jurisdiction. For disposal or recycling
information, please contact your local authorities or the Electronic Industries Alliance: www.eiae.org.
Refer to the identifi cation/rating label located on the back panel of your product for its proper operating voltage.
FCC Regulations state that unauthorized changes or modifi cations to this equipment may void the user’s authority to
operate it.
Cable TV Installer: This reminder is provided to call your attention to Article 820-40 of the National Electrical Code
(Section 54 of the Canadian Electrical Code, Part 1) which provides guidelines for proper grounding and, in par tic u lar,
specifi es that the cable ground shall be connected to the grounding system of the building as close to the point of
cable entry as practical.
Important: This television is a table model and is designed to sit on a fi rm, fl at, surface. Don't place the TV on soft
carpeting or similar surface because the ventilation slots on the bottom of the unit will be blocked resulting in reduced
lifetime from overheating. To assure adequate ventilation for this product, maintain a spacing of 4 inches from the top
and sides of the TV receiver and 2 inches from the rear of the TV receiver and other surfaces.
Also, make sure the stand or base you use is of adequate size and strength to prevent the TV from being accidentally
tipped over, pushed off, or pulled off. This could cause personal injury and/or damage the TV. Refer to the Important
Safety Instructions on the next page.
Product Registration
Please fi ll out the product registration card (packed separately) and return it immediately. For US customers: Your RCA
Consumer Electronics product may also be registered at www.rca.com/television. Registering this product allows us to
contact you if needed.
Product Information
Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the
serial and model numbers in case you need them. These num bers are located on the product.
Model No. _____________________ Serial No.____________________ Purchase Date __________________
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifi ers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or
the third prong is provided for your safety. If the provided plug does not fi t into your outlet, consult an electrician
for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11. Only use attachments/accessories specifi ed by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specifi ed by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualifi ed service personnel.
Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain
or moisture, does not operate normally, or has been dropped.
15. If an outside antenna or cable system is connected to the product, be sure the antenna or cable system is grounded
so as to provide some protection against voltage surges and built-up static charges. Section 810 of the National
Electrical Code, ANSI/NFPA No. 70-1984 (Section 54 of Canadian Electrical Code, Part 1) provides information
with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an
antenna-discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode. See following example.
ANTENNA
LEAD IN
WIRE
GROUND CLAMP
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
ELECTRIC SERVICE
EQUIPMENT
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
Important Information i
Table of Contents
Important Safety Instructions ....................................... i
Chapter 1: Connections & Setup
Things to Consider Before You Connect ..................... 5
Protect Against Power Surges ................................ 5
Protect Components from Overheating ................ 5
• Connect all components before you plug any of their power cords into the wall outlet.
• Turn off the TV/DVD and/or component before you connect or disconnect any cables.
• Make sure all antennas and cables are properly grounded. Refer to the Important Safety Instructions.
Protect Components from Overheating
• Don’t block ventilation holes on any of the components. Arrange the components so that air can circulate freely.
• Don’t stack components.
• If you place components in a stand, make sure you allow adequate ventilation.
• If you connect an audio receiver or amplifi er, place it on the top shelf so the heated air from it won’t fl ow around other
components.
Position Cables Properly to Avoid Audio Interference
• Insert each cable fi rmly into the designated jack.
• If you place components above the TV/DVD, route all cables down the side of the back of the TV/DVD instead of straight
down the middle of the TV/DVD.
• If your antenna uses 300-ohm twin lead cables, do not coil the cables. Also, keep the twin lead cables away from audio/
video cables.
Important Stand and Base Safety Information
Choose the location for your TV/DVD carefully. Place the TV/DVD on a stand or base that is of adequate size and strength to
prevent the TV/DVD from being accidentally tipped over, pushed off, or pulled off. This could cause personal injury and/or
damage the TV/DVD. Refer to the Important Safety Instructions packed separately.
Use Indirect Light
Don’t place the TV/DVD where sunlight or room lighting will be directed toward the screen. Use soft or indirect lighting.
Types of Discs Your TV/DVD will Play (only 12cm sizes)
• DVD discs and DVD-R/RW (video format only) - DVD discs contain high quality picture and sound content.
• Audio discs (Audio CDs, CD-DA, and CD-R/RW) - Audio CDs contain musical or sound content only. This player is also
capable of playing CDs that contain JPEG fi les.
• mp3 discs – A disc that contains audio fi les (for example, a CD-R with downloaded mp3 fi les).
Check Supplied Parts
Check that the following parts were packed with your product.
POWER
TV/DVD
DISPLAY
VOL
1
2
3
6
4
5
MUTE
89
7
SLEEP
SETUP/
0
SUBTITLE
RETURN
DVD
MENU
CH
ENTER
TOP MENU
CH
SEARCH
PLAY
SKIP
STOP
ANGLE
REPEAT A-B
QUICK VIEW/
JUMP
MARKER
ZOOM
INPUT
SELECT
2 AA batteries
Power cord
TV MENU
EXIT/
CANCEL
SEARCH
SKIP
SLOWSLOWPAUSE/STILL PLAY MODE
AUDIO
SCREEN SIZE
Note: If you need to replace your remote, call 1-800-338-0376. A shipping and handling
Remote control
Part # 076R0PF010
Chapter 1 5
fee, and the appropriate sales tax, will be charged upon ordering. Have your Visa,
MasterCard, or Discover Card ready.
Graphics contained within this publication are for representation only.
Connections & Setup
ANT
Coaxial cable
or
Outdoor or Indoor
antenna
Get the Picture
The fi rst part of connecting your TV is to get the picture, also known
as the signal. The back panel of your TV allows you to receive analog
and/or digital channels by using the ANT Input. See the graphic to the
left for the location of the jack.
Getting Channels
What You Need
• Antenna ("rabbit ears") or outdoor antenna with coaxial cable
OR
• Coaxial cable with cable service
A. Do you have an indoor or outdoor antenna? If not, go to step B. If
so, plug the antenna or coaxial cable from the wall outlet into the
ANT Input to receive free off-air local digital and analog channels
where available.
B. Do you have cable? If so, plug the coaxial cable from the wall
outlet into the ANT Input to receive your cable channels.
C. Do you have a set-top box? If so, you may need to call your cable
company or satellite service provider. They may use special cables
to allow you to view digital channels.
What You Need To Know
• Visit www.antennaweb.org to get help deciding what type of
antenna to use to receive the local digital channels available to
you. By entering where you live, this mapping program tells you
what local analog and digital stations are available using a certain
antenna.
• When you are ready to watch channels, the channel banner
displays the type of channel you're viewing. Look for DIGITAL at
the bottom of the screen for digital channels; look for ANALOG for
analog channels. Go to page 14 for more information.
6 Chapter 1
Connections & Setup
Choose Your Connection
For additional assistance while using your RCA product, please visit www.rca.com/customersupport.
There are several ways to connect your TV. Please use the following chart to determine which connection is best
for you. Proceed to the appropriate page and connect your TV.
Jacks Used Cables Needed Go to...
Audio/Video
VIDEO
L
(MONO)
AUDIO
Video
R
Audio R and L
pages 8-9
L
(MONO)
COMPONENT
Y
Pb
AUDIO
PC/HDMI
AUDIO
HDMI
R
Y Pb Pr
Component Video
pages 8-9
Audio R and L
Audio
Pr
HDMI
HDMI™
pages 10-11
OR
HDMI™
+
HDMI/DVI adapter
+
Audio
PC
MONITOR
PC Monitor
Audio
VGA
page 12
Audio
PC/HDMI
AUDIO
HDMI, the HDMI logo, and High-Defi nition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.
Chapter 1 7
Connections & Setup
Video (Basic) Connection
This is an example of a connection using the Video jack. Go to the top of page 9 for specifi c
instructions.
AUDIO
R
1
VIDEO
L
(MONO)
Don't forget: If necessary,
connect antenna or cable to
2
3
get a picture. Go to page 6 for
instructions.
INPUT
VIDEO
AUDIO
L
OUTPUT
S-VIDEO
R
AUDIO
LR
VIDEO
L
COMPONENT VIDEO
YPbPr
S-VIDEO
AUDIO
R
Component Video (Advanced) Connection
This is an example of a connection using the Component Video jacks. Go to the middle of
page 9 for specifi c instructions.
AUDIO
L
(MONO)
COMPONENT
R
3
Y
Pb
Pr
1
Don't forget: If necessary,
connect antenna or cable to
get a picture. Go to page 6 for
instructions.
8 Chapter 1
OUTPUT
2
COMPONENT VIDEO
YPbPr
VIDEO
AUDIO
R
L
AUDIO
LR
S-VIDEO
INPUT
VIDEO
AUDIO
S-VIDEO
R
L
Connections & Setup
Red
Yellow
White
Composite cables are color
coded- Yellow= video;
Red= right audio; white=
left audio
Green
Blue
Red
Component Video cables
(Y Pb Pr) are color codedGreen, Blue and Red
Red
White
Audio cables are color
coded- Red= right audio;
white= left audio
POWER button
POWER
TV/DVD
DISPLAY
VOL
1
2
3
6
4
5
MUTE
89
7
SLEEP
SETUP/
0
TV MENU
EXIT/
CANCEL
SEARCH
SLOWSLOWPAUSE/STILL PLAY MODE
AUDIO
SCREEN SIZE
DVD
MENU
CH
ENTER
TOP MENU
CH
SEARCH
PLAY
SKIP
SKIP
STOP
SUBTITLE
RETURN
ANGLE
REPEAT A-B
QUICK VIEW/
JUMP
MARKER
ZOOM
INPUT
SELECT
INPUT
SELECT
button
Use these buttons
to view the picture
of the device you’ve
connected to the TV.
Connecting the Device with Video (Basic)
This connection allows you to connect a device that has a Video Out jack, for example, a
satellite receiver.
Note: If the device you're connecting also has Component Video jacks and you have
component video cables, we recommend you use the Component Video (Advanced)
Connection instead. See instructions below.
Using the example of a satellite receiver:
1. If necessary, connect your cable and/or off-air antenna as described on
page 6.
2. Connect your yellow video cable.
Connect a video cable to the VIDEO INPUT 1 jack on the back of the TV/DVD and to
the Video Output jack on the satellite receiver.
3. Connect your red and white audio cables.
Connect the audio (red and white) cables to the AUDIO INPUT 1 R and L jacks on the
back of the TV/DVD and to the Audio Output jacks on the satellite receiver.
Connecting the Device with Component Video (Advanced)
This connection allows you to connect a device that has Y Pb Pr jacks, for example, a
satellite receiver.
Using the example of a satellite receiver:
1.If necessary, connect your cable and/or off-air antenna as described on
page 6.
2.Connect your Y Pb Pr component video cables.
Connect three video cables or special Y Pb Pr cables to the COMPONENT (INPUT 3)
Y Pb Pr jacks on the back of the TV/DVD and to the Y Pb Pr outputs on the satellite
receiver.
3.Connect your red and white audio cables.
Connect the audio (red and white) cables to the INPUT 3 AUDIO R and L jacks on the
back of the TV/DVD and to the Audio Output jacks on the satellite receiver.
Viewing the Picture from the Connected Device
1. Plug in the TV/DVD (see page 13 for details) and the device, if they aren't already
plugged in.
2. Turn on the TV and the device you want to view, for example a satellite receiver.
3. Press the INPUT SELECT button on the remote control and select VIDEO1 from the
input list (if connected to the VIDEO INPUT 1 jack) or COMPONENT (if connected to
the COMPONENT jacks). To go back to viewing TV channels, press the INPUT SELECT
button and select ANT from the input list.
• If you're done
connecting devices to
your TV, go to page 14
to complete the Initial
Setup.
• To continue
connecting devices, go
to the next page.
Chapter 1 9
Connections & Setup
HDMI Connection
This is an example of a connection using the HDMI jack.
*Don't forget: If necessary,
connect antenna or cable to
get a picture. Go to page 6 for
instructions.
PC/HDMI
AUDIO
HDMI
A
Device with HDMI
Y
Video Out
C
B
Device with DVI
L
Pb
R
Pr
Audio Out
HDMI Out
OR
DVI Out
L
Audio Out
R
10 Chapter 1
Connections & Setup
Connecting the Device
High-Defi nition Multimedia Interface (HDMI) technology is an uncompressed digital connection
that carries both video and audio data by way of an integrated mini-plug cable. Since HDMI
technology is based on Digital Visual Interface (DVI), the jack on the back of your TV/DVD is
also compatible with devices that have a DVI output jack.
Using the example of a set-top box:
• If your set-top box has an HDMI jack, connect an HDMI cable.
HDMI cable
HDMI cable
HDMI/DVI adapter
Connect an HDMI cable to the HDMI Input jack on the back of the TV/DVD and to
the HDMI Out jack on the back of the device.
–OR–
• If your set-top box has a DVI jack, connect an HDMI cable and an
HDMI/DVI adapter.
A. Connect an HDMI cable to the HDMI Input jack on the back of the TV/DVD.
B. Attach an HDMI/DVI adapter to the end of the HDMI cable, then connect the
adapter to the DVI Out jack on the set-top box.
C. Since you’re using an HDMI/DVI adapter, you need to connect a 3.5 mm stereo
mini-pin to audio left/right cable. Connect the mini-pin end to the PC/HDMI AUDIO
jack on the back of the TV/DVD and the other end to the R and L jacks on the back
of the device.
3.5 mm stereo mini pin
to Audio left/right
POWER button
POWER
TV/DVD
DISPLAY
VOL
1
2
3
6
4
5
MUTE
89
7
SLEEP
SETUP/
0
CH
ENTER
CH
PLAY
SKIP
SUBTITLE
SLOWSLOWPAUSE/STILL PLAY MODE
RETURN
REPEAT A-B
AUDIO
MARKER
DVD
MENU
TOP MENU
SEARCH
SKIP
STOP
ANGLE
QUICK VIEW/
JUMP
ZOOM
INPUT
SELECT
TV MENU
EXIT/
CANCEL
SEARCH
SCREEN SIZE
INPUT
SELECT
button
Use these buttons
to view the picture
of the device you’ve
connected to the TV.
Viewing the Picture from the Connected Device
The device in this connection is connected to the HDMI jack. To view this device:
1. Plug in the TV (see page 13 for details) and the device, if they aren't already plugged
in.
2. Turn on the TV and the device you want to view, for example a set-top box.
3. Press the INPUT SELECT button on the remote control and select HDMI for the input
list. To go back to viewing TV channels, press the INPUT SELECT button and select
ANT from the input list.
• If you're done connecting
devices to your TV, go to
page 14 to complete the
Initial Setup.
• If you experience HDMI
problems, go to the HDMI
Troubleshooting section on
page 39.
Chapter 1 11
Connections & Setup
PC Connection
This is an example of a connection using the PC jacks.
1
Don't forget: If necessary,
connect antenna or cable to
get a picture. Go to page 6
for instructions.
2
3
PC
MONITOR
PC/HDMI
AUDIO
Connecting the Device
This connection allows you to connect to a personal computer.
1. If necessary, connect your cable and/or off-air antenna as described on page 6.
2. Connect your monitor cable.
Connect one end of a 15-pin monitor cable to the PC MONITOR jack on the TV/DVD and the
other end to the PC's video output jack. Note, if your PC's video output isn't 15-pin, you'll need
an adapter that can connect to a 15-pin monitor cable.
3. Connect your audio cable.
Connect a 3.5 mm stereo mini pin cable (sometimes referred to as 1/8" stereo mini pin) to the
HDMI/PC AUDIO jack on the back of the TV and the other end to the Audio Output jack on
the PC.
Note: The maximum resolution is 1360 x 768. Be sure to set your PC to the correct monitor
output setting.
Viewing the PC
1. Plug in the TV and the PC, if they aren't already plugged in.
2. Turn on the TV and the PC.
3. Press the INPUT SELECT button on the remote control and select PC from the input list. To go
back to viewing TV channels, press the INPUT SELECT button and select ANT from the input list.
12 Chapter 1
Connections & Setup
Plug in the TV/DVD
Plug the end of the power cord into the back of the TV/DVD. Plug the other end into a
grounded wall outlet. Insert the plug completely into the outlet. Do not plug into an outlet
controlled by a light switch.
Put Batteries in the Remote
• Remove the battery compartment cover from the back of the remote by pushing the tab
and lifting off the cover.
• Insert two fresh batteries. Make sure the polarities (+ and -) are aligned correctly.
• Replace the cover.
Turn on the TV/DVD
Turn on your TV/DVD by pressing the Power button on the TV or on the remote control.
POWER
DISPLAY
1
2
4
5
89
7
SETUP/
0
TV MENU
EXIT/
CANCEL
SEARCH
SLOWSLOWPAUSE/STILL PLAY MODE
AUDIO
SCREEN SIZE
SKIP
SUBTITLE
RETURN
MARKER
CH
ENTER
CH
PLAY
REPEAT A-B
TV/DVD
3
6
SLEEP
STOP
JUMP
VOL
MUTE
DVD
MENU
TOP MENU
SEARCH
SKIP
ANGLE
QUICK VIEW/
ZOOM
INPUT
SELECT
ENTER
button
Arrows
How to Use the Remote Control to
Complete the Initial Setup
The technical term is “Navigation” – how you move through the onscreen menus. The theory is the same throughout the menu screens:
highlight your choice and select it.
To highlight a menu item, press the arrow buttons on the remote to
highlight one of the items listed on the screen. Use the up or down
arrow button to move up or down. Use the right or left arrow button
to view other selections for a menu choice or to display a sub-menu.
Note: Highlighted means that the menu item stands out from
other menu items on the list (appears darker, brighter, or a
different color).
Chapter 1 13
Connections & Setup
SETUP
LANGUAGE ENGLISH
ENGLISH/FRANÇAIS/ESPAÑOL
TV/CABLE CABLE
AUTO CH MEMORY
ADD/DELETE
:SELECT
:ADJUST
Complete the Initial Setup
The menu system in your TV allows the TV’s features to work
properly. You need to set up a few things fi rst before using your
TV/DVD.
Set the Menu Language
Press the SETUP/TV MENU button on the remote. With the SETUP
icon (
If English is your preferred language, press the down arrow button to
continue to the next step. To choose another language, press the right
arrow button until that language is highlighted, and press the down
arrow button to continue.
Set the Signal Type
If you connected Cable to your ANT jack, the option is chosen for you
and you can press the down arrow button to continue.
If you connected an antenna to your ANT jack, press the right arrow
button to choose TV and then press the down arrow button to
continue.
) highlighted, press the down arrow button.
SETUP
LANGUAGE ENGLISH
TV/CABLE CABLE
AUTO CH MEMORY
ADD/DELETE
:SELECT
:ADJUST
Complete the Channel Search
With Auto Ch Memory highlighted, press the right arrow button to
begin the channel search. The search takes some time as it is looking
for analog and digital channels, and digital sub channels. Once the
search is complete, the TV tunes to a channel.
14 Chapter 1
Loading...
+ 30 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
