RCA L26WD14, L37WD14, L32WD14 User Manual
Find Inside:
• Connections ........... page 6
LCD User’s Guide
• Remote ................... page 19
• Features ................. page 27
• Menus .................... page 36
• FAQs .......................page 45
• Troubleshooting ..... page 46
rc a.com/television
1668591B.indb 11668591B.indb 1 6/5/06 3:27:28 PM6/5/06 3:27:28 PM
Important Information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates "dangerous
voltage" inside the product that
presents a risk of electric shock or
personal injury.
WARNING
To reduce the risk of fi re or electric shock, do not
expose this product to rain or moisture. The apparatus
shall not be exposed to dripping or splashing. No objects fi lled with liquids, such as vases, shall be placed
on the apparatus.
This symbol indicates that this product contains mercury. Special disposal of this product for environmental
reasons may be required under the laws applicable to your jurisdiction. For disposal or recycling
information, please contact your local authorities or the Electronic Industries Alliance: www.eiae.org.
Refer to the identifi cation/rating label located on the back panel of your product for its proper operating voltage.
FCC Regulations state that unauthorized changes or modifi cations to this equipment may void the user’s authority to
operate it.
Caution: To reduce the risk of electric shock, do not remove cover (or
back). No user serviceable parts inside. Refer servicing to qualifi ed service
personnel.
This symbol indicates important
instructions accompanying the product.
WARNING
The TV is unstable if it is not properly attached to the
base or mounted to the wall. Please follow the base
or wall mounting instructions provided in the User’s
Guide to ensure your safety.
Cable TV Installer: This reminder is provided to call your attention to Article 820-40 of the National Electrical Code
(Section 54 of the Canadian Electrical Code, Part 1) which provides guidelines for proper grounding and, in par tic u lar,
specifi es that the cable ground shall be connected to the grounding system of the building as close to the point of cable
entry as practical.
Important: This television is a table model and is designed to sit on a fi rm, fl at, surface. Don't place the TV on soft
carpeting or similar surface because the ventilation slots on the bottom of the unit will be blocked resulting in reduced
lifetime from overheating. To assure adequate ventilation for this product, maintain a spacing of 4 inches from the top
and sides of the TV receiver and 2 inches from the rear of the TV receiver and other surfaces.
Also, make sure the stand or base you use is of adequate size and strength to prevent the TV from being accidentally
tipped over, pushed off, or pulled off. This could cause personal injury and/or damage the TV. Refer to the Important
Safety Instructions on the next page.
Product Registration
Please fi ll out the product registration card (packed separately) and return it immediately. For US customers: Your RCA
Consumer Electronics product may also be registered at www.rca.com/television. Registering this product allows us to
contact you if needed.
Product Information
Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the
serial and model numbers in case you need them. These num bers are located on the product.
Model No. _____________________ Serial No.____________________ Purchase Date __________________
Dealer/Address/Phone _________________________________________________________________________
1668591B.indb 21668591B.indb 2 6/5/06 3:27:59 PM6/5/06 3:27:59 PM
Important In for ma tion
Important Safety Instructions
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifi ers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or
the third prong is provided for your safety. If the provided plug does not fi t into your outlet, consult an electrician
for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11. Only use attachments/accessories specifi ed by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specifi ed by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualifi ed service personnel.
Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain
or moisture, does not operate normally, or has been dropped.
15. If an outside antenna or cable system is connected to the product, be sure the antenna or cable system is grounded
so as to provide some protection against voltage surges and built-up static charges. Section 810 of the National
Electrical Code, ANSI/NFPA No. 70-1984 (Section 54 of Canadian Electrical Code, Part 1) provides information
with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an
antenna-discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode. See following example.
ANTENNA
LEAD IN
WIRE
GROUND CLAMP
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
ELECTRIC SERVICE
EQUIPMENT
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
Important Information i
1668591B.indb 31668591B.indb 3 6/5/06 3:28:00 PM6/5/06 3:28:00 PM
Table of Contents
Important Safety Instructions ....................................... i
Chapter 1: Connections and Setup
Things to Consider Before You Connect ..................... 5
Protect Against Power Surges ................................ 5
Protect Devices from Overheating ........................ 5
Position Cables Properly to Avoid Audio
Interference .......................................................... 5
Use Indirect Light .................................................... 5
Check Supplied Parts .............................................. 5
Get the Picture .............................................................. 6
Getting Channels .................................................... 6
Choose Your Connection ............................................. 7
Video (Basic) Connection ....................................... 8
Component Video (Advanced) Connection ..........8
HDMI/DVI Connection .......................................... 10
USB Connection .................................................... 12
VGA Connection ................................................... 13
Plug in the TV .............................................................. 14
Put Batteries in the Remote ....................................... 14
Turn on the TV ............................................................. 14
How to Use the Remote Control to Complete the
Initial Setup ............................................................... 14
Complete the Initial Setup ......................................... 15
Set the Menu Language ...................................... 15
Complete Channel Setup ..................................... 15
What To Expect ........................................................... 16
Watching TV ...............................................................16
Changing Channels ............................................... 16
Explanation of Jacks (in alphabetical order) ............. 17
Buttons and Other Jacks On Your TV ........................ 18
Side Input Jacks ..................................................... 18
Front Panel Buttons .............................................. 18
Chapter 2: Using the Remote Control
The Buttons on the Remote Control .......................... 19
Using the INPUT Button ....................................... 20
Programming the Remote to Operate Other
Devices ....................................................................... 20
Find Out If You Need to Program the Remote ... 20
Programming the Remote ................................... 21
How to Use the Remote After You’ve
Programmed It .......................................................... 22
Modes of Operation ............................................. 22
Volume Punchthrough Feature .................................. 22
Deleting ALL Volume Punchthrough
Commands .......................................................... 23
Remote Code List ........................................................ 24
Chapter 3: Using the TV's Features
Channel Banner ........................................................... 27
Autotuning .................................................................. 27
Parental Controls and V-Chip ..................................... 29
How V-Chip Works for USA and Canada ............. 29
Lock/Unlock Parental Controls ............................. 29
US V-Chip TV Ratings ............................................ 30
Blocking Canadian V-Chip Ratings ......................31
V-Chip Movie Rating Limit ................................... 32
Block Channels ...................................................... 32
Front Panel Block .................................................. 32
Blocking Unrated/Exempt Programs ................... 33
Future Rating Region ........................................... 33
Additional Features .................................................... 33
Screen Formats ...................................................... 33
PIP (Picture-in-Picture) Operation ........................ 34
Chapter 4: Using the TV's Menu System
Using the Menu System ............................................. 36
Channel List Menu ...................................................... 36
Sound Menu ................................................................ 36
Picture Menu ............................................................... 38
PIP Menu ...................................................................... 40
Setup Menu ................................................................. 40
Parental Control Menu ............................................... 42
Time Menu ................................................................... 43
USB Menu .................................................................... 43
Chapter 5: Other Information
Frequently Asked Questions (FAQs) .......................... 45
Troubleshooting .......................................................... 46
Mounting Your TV to the Wall ................................... 49
V-Chip Rating Explanations ........................................ 50
US V-Chip Rating System ...................................... 50
Canadian English V-Chip Rating System .............. 50
Canadian French V-Chip Rating System ..............51
Limited Warranty ........................................................ 52
Care and Cleaning ....................................................... 53
4
1668591B.indb 41668591B.indb 4 6/5/06 3:28:01 PM6/5/06 3:28:01 PM
Chapter 1: Connections and Setup
Things to Consider Before You Connect
Protect Against Power Surges
• Connect all devices before you plug any of their power cords into the wall outlet or power
strip. NEVER plug your TV into an outlet that is controlled by a wall switch.
• Turn off the TV and/or device(s) before you connect or disconnect any cables.
• Make sure all antennas and cables are properly grounded. Refer to the Important Safety
Instructions at the beginning of the User's Guide.
Protect Devices from Overheating
• Don’t block ventilation holes on any of the devices. Arrange the devices so that air can
circulate freely.
• Don’t stack devices.
• If you place devices in a stand, make sure you allow adequate ventilation.
• If you connect an audio receiver or amplifi er, place it on the top shelf so the heated air
from it won’t fl ow around other devices.
Position Cables Properly to Avoid Audio Interference
• Insert each cable fi rmly into the designated jack.
• If you place devices above the TV, route all cables down the side of the back of the TV
instead of straight down the middle.
• If your antenna uses 300-ohm twin lead cables, do not coil the cables. Also, keep the twin
lead cables away from audio/video cables.
Use Indirect Light
Don’t place the TV where sunlight or room lighting will be directed toward the screen. Use soft
or indirect lighting.
Check Supplied Parts
Check that the following parts were packed with your product.
Remote control
Part # R301C1
Chapter 1 5
Graphics contained within this publication are for representation only.
Connections and Setup
ANT/CABLE INPUT
Coaxial cable
Get the Picture
The fi rst part of connecting your TV is to get the picture, also known
as the signal. The back panel of your TV allows you to receive analog
and/or digital channels by using the ANT/CABLE INPUT. See the
graphic to the left for the location of the jack.
6 Chapter 1
Connections and Setup
Choose Your Connection
For additional assistance while using your RCA product, please visit www.rca.com/customersupport.
There are several ways to connect your TV. Please use the following chart to determine which connection is best
for you. Proceed to the appropriate page and connect your TV.
Jacks Used Cables Needed Go to...
Audio/Video
VIDEO1
AUDIO1
COMPONENT
INPUT
(CMP1)
Video1
L
R
Audio1 R and L
page 8-9
AUDIO
R
HDMI/DVI
HDMI™
page 10-11
OR
HDMI™
+
HDMI/DVI adapter
+
Audio
VGA
AUDIO
VGA
VGA
page 13
Audio
VGA
VIDEO
HDMI, the HDMI logo, and High-Defi nition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.
Audio
Chapter 1 7
Connections and Setup
OUTPUT
VIDEO
COMPONENT VIDEO
YPbPr
AUDIO
R
L
S-VIDEO
INPUT
VIDEO
AUDIO
L
S-VIDEO
R
8 Chapter 1
Connections and Setup
Red
Yellow
White
Composite cables are color
coded- Yellow= video;
Red= right audio; white=
left audio
Connecting the Device with Video (Basic)
This connection allows you to connect a device that has a Video Out jack, for example, a
DVD player.
Note: If the device you're connecting also has Component Video jacks and you have
component video cables, we recommend you use the Component Video (Advanced)
Connection instead. See instructions below.
Using the example of a DVD player:
1. If necessary, connect your cable and/or off-air antenna as described on page 6.
2. Connect your yellow video cable.
Connect a video cable to the VIDEO1 Input jack on the back of the TV and to the Video
Output jack on the DVD player.
3. Connect your red and white audio cables.
Connect the audio (red and white) cables to the AUDIO1 R and L/MONO jacks on the
back of the TV and to the Audio Output jacks on the DVD player.
Connecting the Device with Component Video (Advanced)
This connection allows you to connect a device that has Y Pb Pr or Y Cb Cr jacks, for
example, a DVD player.
Using the example of a DVD player:
1. If necessary, connect your cable and/or off-air antenna as described on page 6.
Component Video cables
(Y Pb Pr) are color codedGreen, Blue and Red
Red
White
Audio cables are color
coded- Red= right audio;
white= left audio
ON•OFF button
ON•OFF
SAT•AUX
GO BACK
MUTE
INFO
PRESETS
PIP
DVD
CH
+
CH CTRL
ZOOM+
GUIDE
SUB CH
INPUT
TV
VOL
MENU
ZOOM-
CLEAR
INPUT
button
Use these buttons
to view the picture
of the device you’ve
connected to the TV.
2. Connect your Y Pb Pr component video cables.
Connect three video cables or special Y Pb Pr cables to the COMPONENT INPUT
(CMP1) Y Pb/Cb Pr/Cr jacks on the back of the TV and to the Y Pb Pr or Y Cb Cr
outputs on the DVD player.
3. Connect your red and white audio cables.
Connect the audio (red and white) cables to the CMP1 AUDIO R and L jacks on the
back of the TV and to the Audio Output jacks on the DVD player.
• If you're done
connecting devices to
your TV, go to page 14
to complete the Initial
Setup.
• To continue
connecting devices, go
to the next page.
Chapter 1 9
Connections and Setup
Device with HDMI
Y
Video Out
Device with DVI
L
Pb
R
Pr
Audio Out
HDMI Out
OR
DVI Out
R
Audio Out
L
10 Chapter 1
Connections and Setup
Chapter 1 11
Connections and Setup
USB Connection
This is an example of a connection using the USB jack.
Connecting the Device
This connection allows you to connect to a compatible mass storage device with USB, such as
a digital camera, JumpDrive (FlashDrive), or mp3 player.
• Connect one end of the USB cable to the USB device and the other end to the USB jack on
the TV.
12 Chapter 1
VGA Connection
This is an example of a connection using the VGA jacks.
1
VGA
AUDIO
Connections and Setup
Don't forget: If necessary,
connect antenna or cable to
get a picture. Go to page 6 for
instructions.
VGA
VIDEO
Connecting the Device
This connection allows you to connect to a personal computer.
1. If necessary, connect your cable and/or off-air antenna as described on page 6.
2. Connect your monitor cable.
Connect one end of a 15-pin monitor cable to the VGA VIDEO jack on the TV and the
other end to the PC's video output jack. Note, if your PC's video output isn't 15-pin, you'll
need an adapter that can connect to a 15-pin monitor cable.
3. Connect your audio cable.
Connect a 3.5 mm stereo mini pin cable (sometimes referred to as 1/8" stereo mini pin) to
the VGA AUDIO jack on the back of the TV and the other end to the Audio Output jack on
the PC.
Notes: The maximum resolution is 1024 x 768. Be sure to set your PC to the correct
monitor output setting.
To hear sound from the TV while using the PC, press the PRESETS button. Highlight
PC Sound source and press the right arrow to choose TV tuner. Go to page 35 for more
information about how to use PIP with this connection.
Viewing the PC
1. Plug in the TV and the PC, if they aren't already plugged in.
2. Turn on the TV and the PC.
3. Repeatedly press the INPUT button on the remote control until you see VGA displayed at
the bottom of the TV's screen. To go back to viewing TV channels, use the number buttons
to enter the channel or press CH+ or CH- buttons.
Chapter 1 13
Connections and Setup
Plug in the TV
Plug the end of the power cord into the back of the TV. Plug the other end into a grounded
wall outlet. Insert the plug completely into the outlet. Do not plug into an outlet controlled by
a light switch.
Put Batteries in the Remote
• Remove the battery compartment cover from the back of the remote by pushing the tab
and lifting off the cover.
• Insert two fresh batteries. Make sure the polarities (+ and -) are aligned correctly.
• Replace the cover.
Turn on the TV
Turn on your TV by pressing the Power button on the front of the TV or ON•OFF on the
remote control.
VOL
MENU
ZOOM-
CLEAR
TV
INPUT
ON•OFF
SAT•AUX
GO BACK
PRESETS
MUTE
INFO
DVD
+
SUB CH
PIP
CH
CH CTRL
ZOOM+
GUIDE
OK
button
Arrows
How to Use the Remote Control to
Complete the Initial Setup
The technical term is “Navigation” – how you move through the onscreen menus. The theory is the same throughout the menu screens:
highlight your choice and select it.
To highlight a menu item, press the arrow buttons on the remote to
highlight one of the items listed on the screen. Use the up or down
arrow button to move up or down. Use the right or left arrow button
to view other selections for a menu choice or to display a sub-menu.
More than one selection displays, for example, On...; a menu choice
with a sub-menu displays dots (...).
Note: Highlighted means that the menu item stands out from
other menu items on the list (appears darker, brighter, or a
different color).
Tip
To access the setup menus manually, press MENU and
choose Setup.
14 Chapter 1
1668591B.indb 141668591B.indb 14 6/5/06 3:28:10 PM6/5/06 3:28:10 PM
Connections and Setup
Complete the Initial Setup
The menu system in your TV allows the TV’s features to work properly. The fi rst time you turn
on your TV, the language screen appears.
Set the Menu Language
The fi rst part of the setup allows you to select your preferred language
English
Français
Español
for the menu system.
If English is your preferred language, press OK. To choose another
language, press the down arrow button until that language is
highlighted, and press OK.
Complete Channel Setup
Make sure you've connected the TV to cable and/or an off-air signal
before you start the next part of the setup.
Channel setup
Go back
Signal type Cable...
Auto Channel search ...
Channel setup
Go back
Signal type Cable...
Auto Channel search Running...
Progress
Analog Channels found 10
Digital Channels found 05
Ch. search in progress. Press CLEAR to cancel
Any channels already found will be stored.
If you have analog and digital channels,
the TV's search might take longer since it is
looking for both.
Set the Signal Type
If you connected Cable to your ANT/CABLE jack, the option is chosen
for you and you can press the down arrow button to continue. To
choose Antenna, press the right arrow button and then press the down
arrow button to continue.
Complete the Channel Search
Even though the initial channel search can take several minutes, you
must complete it in order for your TV to display channels and programming. Press OK to begin the channel search. The menu shows the
TV is running a channel search. When it's complete, the Channel setup
menu remains on-screen. To exit the menu system, press CLEAR.
Some channels might have been found during the channel search that
are unavailable to view and you might want to get rid of these so they
don't appear as you change channels. To do this press OK (the List
and Labels menu appears). Note that removing channels from your
channel list may be time consuming, so you might want to do it later.
Go to page 40 for details on editing your channel list.
Chapter 1 15
1668591B.indb 151668591B.indb 15 6/5/06 3:28:10 PM6/5/06 3:28:10 PM
Connections and Setup
What To Expect
Watching TV
• Remember: Look for an A at the bottom of the screen to see if
Analog video is sent in a 4/3 format, which your TV displays these
you're watching an analog channel.
channels in a 16/9 format. Press the ZOOM+/- button to view the
different formats available. Go to page 33 for more explanation of
screen formats.
10 CBS
A
Look for the A at the bottom of the screen to
see if you're watching an analog channel.
10-1 CBS
D
Look for the D at the bottom of the screen to
see if you're watching a digital channel.
• Remember: Look for a D at the bottom of the screen to see if
you're watching a digital channel.
Most digital video is sent in a 16/9 format which does fi ll your
screen, but sometimes is sent in 4/3 which does not fi ll your
screen. It depends on how the station or source device is
formatting the video. If there are bars on-screen, press the
ZOOM+/- button to try a different format that may eliminate
the bars. Go to page 33 for more explanation of screen formats.
Changing Channels
• Digital channels can have both primary channels (like the analog
channel number) and sub-channels. To tune to a digital channel
with a sub-channel, enter the primary channel number, then press
either the right arrow or the SUB CH button. Enter the sub-channel
number and press OK.
• Depending upon the type of signals you have connected to your
HDTV, you might notice that the channels change slower than
you’re used to. This is perfectly normal. Digital cable channels
sometimes take longer to tune.
16 Chapter 1
1668591B.indb 161668591B.indb 16 6/5/06 3:28:10 PM6/5/06 3:28:10 PM
Connections and Setup
Explanation of Jacks (in alphabetical order)
This section describes the jacks on the back panel of your TV. There are several ways to
connect devices.
ANT/CABLE Input Lets you connect a coaxial cable to receive the signal from your antenna,
cable, or cable box.
COMPONENT INPUTS Lets you connect a device that has component video jacks, such as a
DVD player.
• CMP1 Y Pb/Cb Pr/Cr (Component Video) Provides optimum picture quality because the
video is separated into three signals. Use three video-grade or component video cables for
the connection. When using CMP1 Y Pb/Cb Pr/Cr, make sure you connect left and right
audio cables to the CMP1 L and R AUDIO jacks.
• CMP1 L AUDIO Provides left audio connection when using the CMP1 video inputs. The left
audio connector is usually white.
• CMP1 R AUDIO Provides right audio connection when using the CMP1 video inputs. The
right audio connector is usually red.
• CMP2 Y Pb/Cb Pr/Cr (Component Video) Same as described for CMP1 Y Pb/Cb Pr/Cr and
CMP1 Audio above. Make sure you connect the left and right audio cables to the CMP2 L
and R AUDIO jacks.
HDMI1/DVI Input Lets you connect a device, such as a digital cable box, with an HDMI or a
DVI output.
• HDMI1/DVI INPUT (High-Defi nition Multimedia Interface/Digital Visual
Interface) Provides an uncompressed digital connection that carries both video and
audio data by way of an integrated mini-plug cable. Since HDMI technology is based on
Digital Visual Interface (DVI), the jack on the back of your TV is also compatible with DVI
devices.
• L AUDIO (used for DVI only) Provides left audio connection when using the DVI jack.
The left audio connector is usually white.
• R AUDIO (used for DVI only) Provides right audio connection when using the DVI jack.
The right audio connector is usually red.
Note: Remember to connect the left and right audio cables because the DVI cable carries
only the picture signal, not the sound.
HDMI2 Input Lets you connect a device, such as a digital cable box, with an HDMI output.
SPDIF OUT Use a digital coaxial cable to connect your TV to a compatible audio receiver.
VGA Connect your computer, or other device with a VGA output, to this jack using a 15 pin
D-sub cable. Go to page 34 for more information about how to use PIP with this connection.
VGA AUDIO (Stereo mini jack) Use to obtain sound when a PC is connected to the VGA jack.
Use a 3.5 mm stereo mini pin cable (sometimes referred to as 1/8” stereo mini pin) to connect
a PC to your TV.
VIDEO1 Input Lets you connect a device that has composite video jacks, such as a VCR or
DVD player.
• L AUDIO Provides left audio connection when using the VIDEO1 jack. The left audio
connector is usually white.
• R AUDIO Provides right audio connection when using the VIDEO1 jack. The right audio
connector is usually red.
Chapter 1 17
1668591B.indb 171668591B.indb 17 6/5/06 3:28:11 PM6/5/06 3:28:11 PM
Loading...
