RCA L26HD35D, L32HD35D User Manual

OWNER’S MANUAL

26/32” TFT LCD DIGITAL TV WITH DVD PLAYER

L26HD35D L32HD35D

If you purchase a universal remote control from your local retailer, please contact the remote manufacturer for the required programming code.

AIR/CABLE MODE SELECTION

When shipped from the factory, the Signal Type option is set to the “Cable” (Cable Television) mode. If not using Cable TV, set this menu option to the “Air” position.

Before operating the unit, please read this manual thoroughly.

52K0101A_eng.indd 152K0101A_eng.indd 1 3/12/09 3:10:38 PM3/12/09 3:10:38 PM

ATTENTION

The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock.

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN

TO PREVENT THE SPREAD OF FIRE, KEEP CANDLES OR OPEN FLAMES AWAY

OR MOISTURE.

FROM THIS PRODUCT AT TIMES.

CAUTION: TO PREVENT ELECTRIC SHOCK DO NOT USE THIS POLARIZED PLUG WITH AN EX-

TENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.

WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

CAUTION: Changes or modifications not expressly approved by the partly responsible for compliance with the FCC Rules

CAUTION:

THIS DIGITAL VIDEO PLAYER EMPLOYS A LASER SYSTEM. TO ENSURE PROPER USE OF THIS PRODUCT, PLEASE

READ THIS OWNER'S MANUAL CAREFULLY AND RETAIN FOR FUTURE REFERENCE. SHOULD THE UNIT REQUIRE MAINTENANCE, CONTACT AN AUTHORIZED SERVICE LOCATION-SEE SERVICE PROCEDURE.

USE OF CONTROLS, ADJUSTMENTS OR THE PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

TO PREVENT DIRECT EXPOSURE TO THE LASER BEAM, DO NOT TRY TO OPEN THE ENCLOSURE. RADIATION MAY BE PRESENT WHEN THE ENCLOSURE IS OPENED. DO NOT STARE INTO THE BEAM.

The lamp(s) within this product contain mercury. Disposal should be in compliance with local, state or federal laws.

Product Registration

Please fill out the product registration card (packed separately) and return it immediately. For US customers: Your RCA Consumer Electronics product may also be registered at www.rca.com/television. Registering this product allows us to contact you if needed.

Product Information

Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the serial and model numbers in case you need them. These num bers are located on the product.

Model No._____________________ Serial No. __________________________Purchase Date: __________________________

Dealer / Address / Phone: __________________________________________________________________________________

to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

could void the user’s authority to operate this equipment.

CLASS 1 LASER PRODUCT

Location of the required Marking

The rating sheet and the safety caution are on the rear of the unit.

CERTIFICATION: COMPLIES WITH FDA RADIATION PERFORMANCE STANDARDS, 21 CFR SUBCHAPTER J.

Complies with FDA performance standards for laser products except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007.

52K0101A_eng.indd 252K0101A_eng.indd 2 3/12/09 3:10:41 PM3/12/09 3:10:41 PM

15) Apparatus should not be exposed to dripping or splashing, and objects filled with liquids, such

NEC-NATIONAL

as vases, should not be placed on the apparatus.

16) An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits, as contact with them might be fatal.

17) Do not overload wall outlets and extension cords, as this can result in a risk of fire or electric shock.

18) Do not push objects through any openings in this unit, as they may touch dangerous voltage points or short out parts that could result in fire or electric shock. Never spill or spray any type of liquid into the unit.

19) If an outside antenna or cable system is connected to the unit, be sure the antenna or cable system is grounded to provide some protection against voltage surges and built-up static charges, Section 810 of the National Electrical Code, ANSI/NFPA 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to

ELECTRICAL CODE S2898A

EXAMPLE OF ANTENNA GROUNDING AS PER THE

NATIONAL ELECTRICAL CODE

GROUND

CLAMP

ELECTRIC SERVICE

EQUIPMENT

ANTENNA LEAD IN WIRE

ANTENNA DISCHARGE UNIT (NEC SECTION 810-20) GROUNDING CONDUCTORS (NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250, PART H)

grounding electrodes, and requirements for the grounding electrode.

20) When replacement parts are required, be sure the service technician uses replacement parts specified by the manufacturer or those that have the same characteristics as the original part.

Unauthorized substitutions may result in fire, electric shock or other hazards.

21) Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks to determine that the unit is in proper operating condition.

22) Keep your fingers clear of the disc slot as it is closing. It may cause injury.

52K0101A_eng.indd 352K0101A_eng.indd 3 3/12/09 3:10:42 PM3/12/09 3:10:42 PM

IMPORTANT SAFETY INSTRUCTIONS (continued)

23) When you connect the product to other equipment, turn off the power and unplug all of the equipment from the wall outlet. Failure to do so may cause an electric shock and serious personal injury. Read the owner's manual of the other equipment carefully and follow the instructions when making any connections.

24) Reduce the volume to the minimum level before you turn on the product. Otherwise, sudden high volume sound may cause hearing or speaker damage.

25) Do not allow the product to output distorted sound for an extended period of time. It may cause speaker overheating and fire.

26) When you use the headphones, keep the volume at a moderate level. If you use the headphones continuously with high volume sound, it may cause hearing damage.

27) Do not look into the opening of the disc slot or ventilation opening of the product to see the source of the laser beam. It may cause eye damage.

28) Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may cause serious personal injury and product malfunction.

29) This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

30) The socket-outlet must be installed near the unit and easily accessible.

CONDENSATION

Moisture will form in the operating section of the player if the player is brought from cool surroundings into a warm room or if the temperature of the room rises suddenly. When this happens, player's performance will be impaired. To prevent this, let the player stand in its new surroundings for about an hour before switching it on, or make sure that the room temperature rises gradually. Condensation may also form during the summer if the player is exposed to the breeze from an air conditioner. In such cases, change the location of the player.

HOW TO HANDLE THE LCD PANEL

Do not press hard or jolt the LCD panel. It may cause the LCD panel glass to break and injury may occur.

•

If the LCD panel is broken, make absolutely sure that you do not touch the liquid in the panel. This may cause skin inflammation. If the liquid gets in your mouth, immediately gargle and consult with your doctor. Also, if the liquid gets in your eyes or touches your skin, consult with your doctor after rinsing for at least 15 minutes or longer in clean water.

CHILD SAFETY: It Makes A Difference How and Where You Use Your Flat Panel Display

Congratulations on your purchase! As you enjoy your new product, please keep these safety tips in mind:

THE ISSUE

The home theater entertainment experience is a growing trend and larger flat panel displays are popular purchases. However, flat panel displays are not always supported on the proper stands or installed according to the manufacturer’s recommendations. Flat panel displays that are inappropriately situated on dressers, bookcases, shelves, desks, speakers, chests or carts may fall over and cause injury.

THIS MANUFACTURER CARES!

The consumer electronics industry is committed to making home entertainment enjoyable and safe.

TUNE INTO SAFETY

One size does NOT fit all. Follow the manufacturer’s recommendations for the safe installation and use of your flat panel display. Carefully read and understand all enclosed instructions for proper use of this product. Don’t allow children to climb on or play with furniture and television sets. Don’t place flat panel displays on furniture that can easily be used as steps, such as a chest of drawers. Remember that children can become excited while watching a program, especially on a “larger than life” flat panel display. Care should be taken to place or install the display where it cannot be pushed, pulled over, or knocked down. Care should be taken to route all cords and cables connected to the flat panel display so that they cannot be pulled or grabbed by curious children.

WALL MOUNTING: IF YOU DECIDE TO WALL MOUNT YOUR FLAT PANEL DISPLAY, ALWAYS:

Use a mount that has been recommended by the display manufacturer and/or listed by an independent laboratory (such as UL, CSA, ETL). Follow all instructions supplied by the display and wall mount manufacturers. If you have any doubts about your ability to safely install your flat panel display, contact your retailer about professional installation. Make sure that the wall where you are mounting the display is appropriate to support the weight of the unit/ product and wall mount. If you are unsure, contact a professional installer. A minimum of two people are required for installation. Flat panel displays can be heavy.

52K0101A_eng.indd 452K0101A_eng.indd 4 3/12/09 3:10:42 PM3/12/09 3:10:42 PM

SAFETY PRECAUTIONS

The unit emits heat when in operation. Do not place any covers or blankets on the unit, this may cause overheating. Do not block ventilation holes, or set up near radiators. Do not place in direct sunshine. When placing on a shelf leave 10 cm (4 inches) free space around the entire unit.

10cm

Notes when mounting the LCD TV/DVD on a wall

If the unit is to be mounted on the wall, contact the retailer where you purchased the LCD TV/DVD for advice, and have the equipment professionally installed. Incomplete or improper installation may cause injury to you, and/or damage to the LCD TV/DVD.

IMPORTANT NOTICE

Possible Adverse Effects on LCD Panel: If a fixed (non-moving) pattern remains on the LCD Panel for

long periods of time, the image can become permanently engrained in the LCD Panel and cause subtle but permanent ghost images. This type of damage is NOT COVERED BY YOUR WARRANTY. Never leave your LCD Panel on for long periods of time while it is displaying the following formats or images:

•

Fixed Images, such as stock tickers, video game patterns, TV station logos, and websites.

•

Special Formats that do not use the entire screen. For example, viewing letterbox style (16:9) media on a normal (4:3) display (black bars at top and bottom of screen); or viewing normal style (4:3) media on a widescreen (16:9) display (black bars on left and right sides of screen).

The following symptoms are not signs of malfunction but technical limitation. Therefore we disclaim any responsibility for these symptoms.

•

LCD Panels are manufactured using an extremely high level of precision technology, however sometimes parts of the screen may be missing picture elements or have luminous spots.

This is not a sign of a malfunction.

•

Do not install the LCD Panel near electronic equipment that is susceptible to electromagnetic waves. Some equipment placed too near this unit may cause interference.

•

Effect on infrared devices – There may be interference while using infrared devices such as infrared cordless headphones.

52K0101A_eng.indd 552K0101A_eng.indd 5 3/12/09 3:10:42 PM3/12/09 3:10:42 PM

Features

LCD color TV With DVD/CD player

Unique space saving design combines a 26/32” LCD color TV and a DVD/CD player. A DVD disc has much more capacity, but is the same size as an audio CD disc. The Picture/Audio quality of a DVD exceeds other software. The picture quality is higher than Super VHS video cassettes. The audio quality is higher than an audio CD. The DVD also has special options; audio language selection, subtitle language selection, or multi-angle, etc. The DVD PLAYER can play back both audio CDs and MP3/WMA/JPEG CDs.

Compatible with a wide range of DVD audio outputs

Digital Audio Jack (Coaxial)

•

When a component with a built-in Dolby Digital decoder is connected, Dolby Digital sound can produce the effect of being in a movie theater or a concert hall.

•

Surround standard is different from Dolby Digital. This format is already in use in many theaters. By connecting this unit to a DTS decoder or an AV amplifier with a built-in DTS decoder, the DTS audio of DVD discs recorded in this format can be enjoyed. However, audio will not be output from the analog audio output jacks.

•

By connecting this unit to an AV amplifier with a built-in MPEG decoder, the MPEG audio of DVD discs recorded in this format can be enjoyed.

•

The Linear PCM sound of a 48 kHz/24 bit through 96 kHz/24 bit exceeds audio CD sound.

Convenience Features

Direct selection of your desired scenes using Title/Chapter/Time/Track - You can play back from the

desired scene.

Recalling Up to 3 Scenes Frame Advance - The PAUSE/STILL moves one frame at a time. Slow Motion - The SLOW moves you back and forth through the program by 4 steps of 1/7-1/2 times. Repeat Playback - You can repeat chapter, track, title, sides or material between two selected points. Program Playback (Audio CD/MP3/WMA CD) - You can play back tracks in programmed sequences. Zoom - You can zoom in the selected subject on the screen during playback.

Note: Make sure that discs are suitable for the following functions. Multi-Language - Maximum 32 language subtitles and maximum 8 language soundtracks can be played back

for movies or programs. Multi-Angle - Pictures of Sports or a Live Concert are recorded with many cameras. When you play such a disc, you can change the angles during playback. Parental Control - You can limit the play back of scenes or sounds of DVD discs that have a rating level encoded on the disc. Video Aspect Ratio - You can change the aspect ratio of the screen for your monitor.

You can program up to 3 scenes in memory and recall the marked scenes.

TV Features

Integrated Digital Tuner - You can view digital broadcasts without using a Digital TV Set-Top Box. Closed Caption Decoder With Full Text Mode - Displays text captions or full screen text on the screen for

hearing impaired viewers. Picture Adjustments Using The Remote Control - The On-Screen display allows precise remote control adjustment of BRIGHTNESS, CONTRAST, COLOR, TINT and SHARPNESS. Programmable TV Sleep Timer - Operable from the remote control, the TV can be programmed for up to 120 minutes to turn off automatically. On-Screen 3 Language Display - You can select one of 3 languages, English, Spanish or French for onscreen programming. V-Chip - The V-Chip function can read the rating of a TV program or movie content if the program is encoded with this information. V-chip will allow you to set a restriction level.

* is a trademark of DVD Format/Logo Licensing Corporation. * Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of

Dolby Laboratories. Manufactured under license under U.S. Patent #: 5,451,942 & other U.S. and worldwide patents issued &

* HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of

HDMI Licensing LLC.

52K0101A_eng.indd 652K0101A_eng.indd 6 3/12/09 3:10:43 PM3/12/09 3:10:43 PM

Contents

Before using your unit

IMPORTANT SAFETY INSTRUCTIONS ...........3

SAFETY PRECAUTIONS .................................5

IMPORTANT NOTICE .......................................5

Features ............................................................6

Contents ...........................................................7

Disc...................................................................8

Location of controls ........................................... 9

Remote control ...............................................11

Power source ..................................................12

Antenna connections ......................................13

Cable TV connections .....................................14

TV operation

Starting setup .................................................15

Setting the on-screen language ......................15

Memorizing channels ......................................15

TV operation ...................................................17

Labeling channels ...........................................18

Labeling video inputs ...................................... 18

Setting the V-Chip ...........................................18

Closed Caption ............................................... 20

CC advanced ..................................................21

Adjusting the picture preference .....................21

Picture control adjustment ..............................21

Selecting the color temperature ...................... 22

Setting the picture size .................................... 22

Film mode ....................................................... 23

Picture control

DNR ................................................................ 23

Sound control adjustment ............................... 24

Selecting Stereo/

Second Audio Program (SAP) ........................24

Selecting the audio language .......................... 24

Selecting the HDMI audio input source ...........25

Turning off the built-in speakers ......................25

Adjusting the back lighting ..............................25

Checking the digital-signal strength ................ 25

Setting the auto shut off ..................................25

Resetting your settings ...................................26

adjustment in the PC mode...........

DVD operation

Preparation .....................................................26

Status display of disc ......................................26

Playback procedure ........................................26

Special playback ............................................. 27

MP3/WMA/JPEG and Audio CD playback ......27

Setting the JPEG interval ................................ 29

Program playback (CD) ..................................29

Repeat playback (CD).....................................30

Random playback (CD) ..................................30

Zooming ..........................................................30

Locating desired scene ...................................30

Repeat playback .............................................30

Marking desired scenes ..................................31

Changing soundtrack language ......................31

Subtitles .......................................................... 32

Changing angles .............................................32

Title selection ..................................................32

DVD menu ......................................................32

Setting the language ....................................... 32

Setting the aspect ratio of TV screen ..............33

Setting on screen display ................................33

Setting the picture mode ................................. 33

Night mode .....................................................34

Digital out ........................................................34

Parental control ...............................................34

Temporary disabling of rating level

by DVD disc .................................................... 35

Additional information

Language code list .......................................... 36

Connections to other equipment ..................... 37

Reception disturbances .................................. 40

Problems and troubleshooting ........................41

Specifications ................................................43

Limited Warranty ............................................44

52K0101A_eng.indd 752K0101A_eng.indd 7 3/12/09 3:10:43 PM3/12/09 3:10:43 PM

Disc

Playable discs

Disc type and logo mark content

DVD Video

CD-DA

The following discs are also available.

DVD-R/RW discs of DVD video format.

• CD-R/RW discs of MP3/WMA/JPEG.

•

Audio

Video

(moving

pictures)

Audio

CAUTION:

•

Only the left types of discs can be played on this unit. DVD-ROM, CD-ROM, SVCD, CVD, VCD, etc. cannot be played.

•

8cm discs can be played directly. If an 8cm disc adapter is used it will cause errors.

•

If you insert an irregular shaped disc, it may get stuck and cause a malfunction.

•

The use of a ring protector or other disc accessories will cause errors.

•

This unit is to be used exclusively with the NTSC color system. PAL and SECAM system discs cannot be used with this unit.

•

Some CD-R/RWs and DVD-R/RWs cannot be played back depending on the recording conditions.

Region Number

Region number (Regional restriction code) is built-in to the unit and DVD video discs. Region number “1” or “ALL” of DVD video discs can be used on this unit.

Title

When two or more movies are recorded on a disc, the disc is divided into two or more sections. Each section is called a “TITLE”.

TITLE 1 TITLE 2

CHAPTER 1

DVD DISC

CHAPTER 2 CHAPTER 2 CHAPTER 3CHAPTER 1

Chapter

The titles can be subdivided into many sections. Each section is called a “CHAPTER”.

Track

An Audio CD can contain several items. These are assigned to the tracks.

TRACK 1 TRACK 2 TRACK 3 TRACK 4 TRACK 5

Audio - CD

ALL

Removing Disc from Case

Be sure to hold the edge of disc. Do not touch the surface of the disc. Pick up the disc gently from the case.

•

Do not scratch the disc.

•

Do not get dirt on the surface of the disc.

•

Do not stick a label or adhesive tape on the disc.

•

Do not drop or bend the disc.

Storing Disc

•

Store the disc in the case to avoid risk of scratches, dirt or damage.

•

Do not leave disc exposed to direct sunlight or in hot or humid places.

Cleaning Disc

Wipe the disc with a clean, dry cloth from center to edge.

•

Do not wipe the disc in a circular motion. Do not use liquid or aerosol cleaners.

•

52K0101A_eng.indd 852K0101A_eng.indd 8 3/12/09 3:10:44 PM3/12/09 3:10:44 PM

Front

Location of controls

Left side

DISC slot

Remote sensor

POWER indicator

EJECT button

VOLUME +/– buttons

CHANNEL /1 (PLAY) button

CHANNEL /3 (STOP) button

MENU button

INPUT/ENTER button

POWER button

To display the menu screen. Press MENU button to display the menu screen.

CHANNEL

setting during the menu screen operations.

/ buttons, VOLUME +/– buttons and INPUT/ENTER button can be used to select the desired

52K0101A_eng.indd 952K0101A_eng.indd 9 3/12/09 3:10:45 PM3/12/09 3:10:45 PM

Location of controls (continued)

Rear side

PC MONITOR IN jack

VAR (VARIABLE) AUDIO OUT jack

COAXIAL DIGITAL AUDIO OUT jack

RF (ANT) IN jack

AC INPUT jack

HDMI 1/DVI IN jack

HDMI 2 IN jack

PC/DVI AUDIO IN jack

(for COMPONENT IN and LINE 2 VIDEO IN)

COMPONENT IN jacks

LINE 2 VIDEO IN jack

LINE 1 IN jacks (VIDEO/S-VIDEO/AUDIO (L/R))

AUDIO (L/R) jacks

52K0101A_eng.indd 1052K0101A_eng.indd 10 3/12/09 3:10:48 PM3/12/09 3:10:48 PM

Remote control

POWER Power On/Off

DISPLAY/– Call TV information

TV/DVD Switch between TV/AV and DVD

(EJECT) Eject a disc

0-9 Direct channel selection of TV

VOL +/– Adjust volume of TV

MUTE Switch off the sound

SLEEP Sleep timer

SETUP/ TV MENU

DVD MENU Display DVD menu

▲▼◀▶ Cursor buttons

ENTER Enter information in the menu

EXIT/ CANCEL

TOP MENU Select title

SEARCH Fast Forward/Review playback

PLAY Playback

SKIP Skip chapter to forward or reverse direction

SUBTITLE Set subtitle

STOP Stop

SLOW Forward/Reverse- slow motion

PAUSE/STILL Pause CD sound

PLAY MODE Select playback mode

AUDIO Change sound track language

RETURN Remove DVD setup menu

REPEAT A-B Repeat playback between A and B

ANGLE Change playback angle

SCREEN SIZE Display PICTURE SIZE menu

MARKER Index

CCD/ JUMP

RECALL/ ZOOM

INPUT SELECT Display source selection menu

Call DVD information Input “–” for digital channels

Input setting Enter a password

TV mode - Display menu of TV DVD mode - Call up initial setup mode

Select channel of TV

Exit from On-Screen menu Reset information in the menu

Still picture of DVD

Closed Caption Locating desired scene

Switch between present/last channel Zoom

ATTENTION

If you purchase a universal remote from a local retailer, please contact the remote manufacturer for the correct programming code.

52K0101A_eng.indd 1152K0101A_eng.indd 11 3/12/09 3:10:50 PM3/12/09 3:10:50 PM

Remote control (continued)

Inserting Batteries

Open the battery compartment

cover in the direction of the arrow.

Operation

Aim the remote control at the remote sensor and press control

• buttons to operate. Operate the remote control within a 30° angle on either side of

• the remote sensor, up to a distance of approximately 15 feet.

NOTE:

•

Do not leave the remote control unit exposed to direct sunlight or in hot or humid places.

•

The remote control unit uses infrared beams to transmit signals, so sunlight or fluorescent light on the remote sensor may shorten operating distance. Incorrect use of batteries may cause them to leak or burst. Read the battery warnings and use the batteries

• properly. Do not mix old and new batteries.

• Remove batteries if the remote control will not be operated for an extended period of time.

•

Install two “AAA” batteries,

paying attention to the polarity diagram in the battery compartment.

Replace the compartment cover.

Approximately 15 feet

Power source

TO USE AC POWER

Connect the AC cord plug into this unit’s AC IN jack.

1. Connect the AC cord into an AC outlet.

AC Outlet

Wider Hole and Blade

AC 120V, 60Hz

AC cord (supplied)

NOTE:

•

Please make sure to insert the cord securely at both the LCD TV/DVD and the wall outlet.

•

The AC Cord has a grounding-type AC line plug. If the supplied AC cord does not match your AC outlet, contact a qualified electrician, do not defeat the purpose of a grounding plug.

WARNING:

•

DO NOT CONNECT THIS UNIT TO THE POWER USING ANY DEVICE OTHER THAN THE SUPPLIED AC CORD. THIS COULD CAUSE FIRE, ELECTRICAL SHOCK, OR DAMAGE.

•

DO NOT USE WITH A VOLTAGE OTHER THAN THE POWER VOLTAGE DISPLAYED. THIS COULD CAUSE FIRE, ELECTRICAL SHOCK, OR DAMAGE.

CAUTION:

•

WHEN THIS UNIT IS NOT USED FOR A LONG TIME, (E.G., AWAY ON A TRIP) IN THE INTEREST OF SAFETY, BE SURE TO UNPLUG IT FROM THE AC OUTLET.

•

DO NOT PLUG/UNPLUG THE PLUG WHEN YOUR HANDS ARE WET. THIS MAY CAUSE ELECTRICAL SHOCK.

•

IF YOU NEED TO REPLACE THE SUPPLIED AC ADAPTER OR AC CORD, THE SPECIFIED ONE IS RECOMMENDED. CONTACT THE DEALER THAT YOU PURCHASED THE UNIT FROM.

52K0101A_eng.indd 1252K0101A_eng.indd 12 3/12/09 3:10:50 PM3/12/09 3:10:50 PM

Antenna connections

If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your antenna system. If you are using a Cable TV service, see page 14 for Cable TV connections.

Combination VHF/UHF Antenna (Single 75 ohm cable or 300 ohm twin-lead wire)

Connect the 75 ohm cable from the combination VHF/UHF antenna to the antenna jack.

If your combination VHF/UHF antenna has a 300 ohm twin-lead wire, the use of the 300-75 ohm matching transformer may be necessary.

75 ohm Coaxial Cable

Antenna

Jack

300-75 ohm Matching Transformer

Antenna

Jack

Combination VHF/UHF Antenna (Separate VHF and UHF 300 ohm twin-lead wires)

Connect the UHF 300 ohm twin-lead wire to

Antenna

Jack

Combiner

UHF 300 ohm

VHF 300 ohm

the Combiner (not supplied). Connect the VHF 300 ohm twin-lead wire to the 300-75 ohm Matching Transformer. Attach the Transformer to the Combiner, then attach the Combiner to the Antenna Jack.

300-75 ohm Matching Transformer

Separate VHF/UHF Antennas (75 ohm VHF cable and 300 ohm UHF twin-lead wires)

Antenna

Jack

Combiner

UHF 300 ohm

VHF 75 ohm

Connect the VHF 75 ohm cable and UHF 300 ohm twin-lead wire to the Combiner (not supplied). Attach the Combiner to the Antenna Jack.

IMPORTANT: Go to page 15 to choose the signal and search for channels.

52K0101A_eng.indd 1352K0101A_eng.indd 13 3/12/09 5:55:14 PM3/12/09 5:55:14 PM

Cable TV connections

This TV has an extended tuning range and can tune most cable channels without using a Cable TV Converter box. Some cable companies offer “premium pay channels” where the signal is scrambled. Descrambling these signals for normal viewing requires the use of a descrambler device which is generally provided by the Cable TV company.

For subscribers to basic Cable TV service

For basic Cable TV service not requiring a Converter/

Antenna

Jack

75 ohm Coaxial Cable

For subscribers to scrambled Cable TV service

If you subscribe to a Cable TV service which requires the use of a Converter/Descrambler box, connect the incoming 75 ohm Coaxial Cable to the Converter/Descrambler box. Using another 75 ohm Coaxial Cable, connect the output jack of the Converter/Descrambler box to the Antenna Jack on the TV. Follow the connections shown below. Set the TV to the output channel of the Converter/Descrambler box (usually channel 3 or 4) and use the Converter/Descrambler box to select channels.

Incoming 75 ohm Cable TV Cable

Descrambler box, connect the 75 ohm Coaxial Cable directly to the Antenna Jack on the back of the TV.

Antenna

Converter/

Descrambler

75 ohm Cable to TV

Jack

For subscribers to unscrambled Cable TV service with scrambled premium channels

If you subscribe to a Cable TV service in which basic channels are unscrambled and premium channels require the use of a Converter/Descrambler box, you may wish to use a signal Splitter and an A/B Switch box (available from the Cable TV company or an electronics supply store). Follow the connections shown below. With the switch in the “B” position, you can directly tune any nonscrambled channels on your TV. With the switch in the “A” position, tune your TV to the output of the Converter/Descrambler box (usually channel 3 or 4) and use the Converter/Descrambler box to tune scrambled channels.

Incoming 75 ohm Cable TV Cable

Splitter

Converter/

Descrambler

A/B Switch

75 ohm Cable to TV

Antenna

Jack

IMPORTANT: Go to page 15 to choose the signal and search for channels.

52K0101A_eng.indd 1452K0101A_eng.indd 14 3/12/09 3:10:51 PM3/12/09 3:10:51 PM

Starting setup

The Starting Setup menu appears the first time you turn on the TV, and assists you to select the menu language, specify the Air/Cable setting, and program your channels automatically.

IMPORTANT: Make sure that the antenna or cable TV system connection is made!

To turn on the TV, press POWER (POWER

indicator on the front of the unit changes green. It may take approx. 10 seconds for a picture to appear on screen.). The starting setup function begins. Press ◀ or ▶ to select your desired language.

Auto Setup

Language English

Signal Type Cable

Automatic Search Start

: Adjust

: Select

Press ▲ or ▼ to select “Signal Type”, then press

◀ or ▶ to select “Cable” or “Air”.

Press ▲ or ▼ to select “Automatic Search”, then

press ▶ or ENTER.

Now the “Auto Setup” starts. After the starting

setup is completed, the TV channel appears on the screen.

•

Depending on the reception condition, it may

take from 15 minutes to 30 minutes to complete memorizing digital cable channels. Please be patient.

NOTE:

If you press EXIT/CANCEL in the process of “Auto

•

Setup”, the Starting Setup stops and changes to the normal screen. When you make a menu selection, your changes

•

occur immediately. You do not have to press EXIT/ CANCEL to see your changes. When you are finished programming the menus,

•

press EXIT/CANCEL.

Setting the on-screen language

You can choose from three different languages (English, French and Spanish) for the on-screen displays. Select the language you prefer first, then proceed with the other menu options.

Press POWER.

Press TV/DVD to select TV mode.

Press SETUP/TV MENU. The TV menu screen

will appear.

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Press ▲ or ▼ to select “Setup”, then press ▶ or

ENTER.

Press ▲ or ▼ to select “Language”.

Setup

Closed Caption >>

Language English

Video Label >>

Auto Shut Off Off

Reset >>

: Select

Press ◀ or ▶ to select the desired language:

English, French (Français) or Spanish (Español).

Press EXIT/CANCEL to return to the normal

screen.

NOTE:

•

If no buttons are pressed for more than about 60 seconds, the menu screen will return to normal operation automatically.

: Adjust

Memorizing channels

This TV is equipped with a channel memory feature which allows channels to skip up or down to the next channel set into memory, skipping over unwanted channels. Before selecting channels, they must be programmed into the TV’s memory. To use this TV with an antenna, set the Signal Type option to the Air mode. When shipped from the factory, this menu option is in the Cable mode.

Air/Cable selection

Press SETUP/TV MENU in the TV mode. The TV

menu screen will appear.

Press ▲ or ▼ to select “Channel”, then press ▶

or ENTER.

Press ▲ or ▼ to select “Auto Ch Memory”, then

press ▶ or ENTER.

Press ▲ or ▼ to select “Signal Type”.

Press ◀ or ▶ to select “Air” or “Cable”.

Air - VHF/UHF channels Cable - CABLE TV channels

Auto Ch Memory

Signal Type Cable

Automatic Search Start

: Adjust

: Select

Press EXIT/CANCEL to return to the normal

screen.

52K0101A_eng.indd 1552K0101A_eng.indd 15 3/12/09 3:10:52 PM3/12/09 3:10:52 PM

+ 33 hidden pages
