RCA J26CE820, J32CE720, J42CE820 User Manual

LED Television

User’s Guide

Commercial Television

J22CE820 J26CE820

J32CE720 J42CE820

Made for Today

Important Information

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK

DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE.

REFER TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CC AA UU TT IIOO NN

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

WARNING

Please fill out the product registration card (packed separately) and return it immediately. For US customers: Your RCA Consumer Electronics product may also be registered at http://www.rcacommercialtv.com. Registering this product allows us to contact you if needed.

Product Registration

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the National Electric Code (U.S.A.). The code provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of the cable entry as practical.

NOTE TO CABLE TV INSTALLER

Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the serial and model numbers in case you need them. These numbers are located on the product.

Model No.

Serial No.

Purchase Date:

Dealer/Address/Phone:

Product Information

Important Information

Do not attempt to modify this product in any way without written authorization from RCA. Unauthorized modification could void the user’s authority to operate this product.

CAUTION

THESE SERVICING INSTRUCTIONS ARE FOR USE BY QUALIFIED SERVICE PERSONNEL ONLY. TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT PERFORM ANY SERVICING OTHER THAN THAT CONTAINED IN THE OPERATING INSTRUCTIONS UNLESS YOU ARE QUALIFIED TO DO SO.

CAUTION

Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, should be placed on the apparatus.

WARNING

When used outside of U.S., other power-supply cords may be used if the cord is approved by the local regulating agency.

CAUTION

Clean the exterior of this television by removing dust with a lint-free cloth. CAUTION: To avoid damage to the surface of the television, do not use abrasive or chemical cleaning agents.

CLEANING AND DISINFECTION

This apparatus with class I construction shall be connected to a main socket outlet with a protective earthing connection.

Important Information

Main plug is the disconnecting device. The plug must remain readily operable.

DISCONNECTING DEVICE FROM MAINS

YOUR PRODUCT HAS BEEN MANUFACTURED AND TESTED WITH YOUR SAFETY IN MIND. HOWEVER, IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARDS. TO AVOID DEFEATING THE SAFEGUARDS THAT HAVE BEEN BUILT INTO YOUR NEW PRODUCT, PLEASE READ AND OBSERVE THE FOLLOWING SAFETY POINTS WHEN INSTALLING AND USING YOUR NEW PRODUCT, AND SAVE THEM FOR FUTURE REFERENCE. OBSERVING THE SIMPLE PRECAUTIONS DISCUSSED IN THIS MANUAL CAN HELP YOU GET MANY YEARS OF ENJOYMENT AND SAFE OPERATION THAT ARE BUILT INTO YOUR NEW PRODUCT.

IMPORTANT SAFEGUARDS FOR YOU AND YOUR NEW PRODUCT

Note

-If the TV feels cold to the touch, there may be a small “flicker” when it is turned on. This is normal, there is nothing wrong with the TV.

- Some minute dot defects may be visible on the screen, appearing as tiny red, green, or blue spots. However, they have no adverse effect on the TVs performance.

-Avoid touching the LED screen or holding your finger(s) against it for long periods of time. Doing so may produce some temporary distortion effects on the screen.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

REGULATORY INFORMATION

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

THE PARTY RESPONSIBLE FOR PRODUCT COMPLIANCE

(RCA Commercial Electronics)

(TELEPHONE NO : 1-800-RCA-2161)

CAUTION

IMPORTANT SAFETY INSTRUCTIONS

Read before operating equipment

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15. If an outside antenna or cable system is connected to the product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Section 810 of the National Electrical Code, ANSI/NFPA No. 70-1984 (Section 54 of Canadian Electrical Code, Part 1) provides information with respect to proper grounding of the mast and supporting structure, grounding of the leadin wire to an antenna-discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. See following example.

Table of Contents

Important Information ..............................................2

IMPORTANT SAFETY INSTRUCTIONS ........................5

Chapter 1: Connections and Setup

Things to Consider Before You Connect ..................7

Protect Against Power Surges ........................7

Protect Devices from Overheating..................7

Position Cables Properly to Avoid Audio

Interference ......................................................7

Use Indirect Light ............................................7

Remote Control ................................................7

Check Supplied Parts........................................7

Controls And Connectors ..........................................8

Front Panel - J22CE820 ....................................8

Rear Panel - J22CE820 ....................................9

Front Panel - J26CE820 ..................................10

Rear Panel - J26CE820 ..................................11

Front Panel - J32CE720 ..................................12

Rear Panel - J32CE720 ..................................13

Front Panel - J42CE820 ..................................14

Rear Panel - J42CE820 ..................................15

Connections ..............................................................16

Wall mount Installation ................................16

Vesa Standard TV Mounts - 22/26 inches ....17

Vesa Standard TV Mounts - 32/42 inches ....18

Antenna Connection......................................19

VCR Connection..............................................20

DVD Connection ............................................22

HDSTB Connection ........................................24

External A/V Source........................................26

PC Connection ................................................27

Resolution ......................................................28

USB Port ..........................................................28

Chapter 2: Using the Remote Control

Basic(User) Remote ........................................29

Master(Installer) Remote ..............................30

Put Batteries in the Remote ..........................30

Chapter 3: How to clone TV

Learning: Copying your settings

out of the TV ..................................................33

Teaching: Placing settings into TV.................34

Chapter 4: Basic Operation

Plug in the TV ................................................35

Turn on the TV................................................35

Channel Scan ..................................................35

Channel Selection ..........................................35

Volume Adjustment ......................................35

Sound Mute ....................................................35

Source Selection ............................................36

Language Selection........................................36

Chapter 5: Commercial Interface Menus

Chapter 6: User Operations

Chapter 7: Using the TV's Features

On Screen Menus ....................................................41

Setting up the TV Channel List ..............................42

Auto Scan........................................................42

Add / Delete a Channel..................................43

Picture Controls ........................................................44

Adjusting The Picture Controls ....................44

Manual Picture Controls ................................45

Adaptive Back Light ......................................46

Reset Picture Mode ........................................46

Advanced Video ......................................................47

Dynamic Noise Reduction ..............................47

Adaptive Luma Control..................................48

Flesh Tone ......................................................48

Blue Stretch ....................................................49

Blue Mute ......................................................49

Gamma............................................................50

Color Temperature ........................................51

Screen Mode ..................................................52

Sound Controls ........................................................53

Adjusting The Sound Controls ......................53

Manual Sound Controls ................................54

Sound Surround ............................................55

Stereo/SAP Broadcast Setup ..........................55

Audio Language ............................................56

Built-In Speaker ..............................................56

Captions ....................................................................57

Closed Caption - Analog................................57

Closed Caption - Digital ................................58

Digital Closed Caption Options ....................59

Time Setting ............................................................60

Time Zone Settings ........................................60

Auto Time Settings ........................................61

Manual Time Settings ....................................62

Auto On /Off Time Settings ..........................63

Sleep Timer ....................................................64

Reset ........................................................................65

Reset Default ..................................................65

Parental Control ......................................................66

Entering your password ................................66

Set Password ..................................................66

Ratings - Enable / Disable ..............................67

TV Ratings for USA ........................................68

Movie Ratings ................................................70

English TV Ratings for Canada ......................71

French TV Ratings for Canada ......................72

Downloadable Rating ....................................73

Block Unrated ................................................74

Clean All..........................................................74

Setting the PC Mode................................................75

Automatic Screen Adjustment ......................75

Manual Screen Adjustment ..........................76

USB Functions ..........................................................77

USB Settings....................................................77

Specification ............................................................78

Chapter 8: Other Information

Troubleshooting ......................................................82

Limited Warranty ....................................................83

Care and Cleaning ....................................................84

CHILD SAFETY ..........................................................85

Graphics contained within this publication are for representation only.

Chapter 1 7

Chapter 1: Connections and Setup

Things to Consider Before You Connect

• Connect all devices before you plug any of their power cords into the wall outlet or power strip. Never plug your TV into an outlet that is controlled by a wall switch.

•Turn off the TV and/or device(s) before you connect or disconnect any cables.

• Make sure all antennas and cables are properly grounded. Refer to the Important Safety Instructions at the beginning of the User's Guide.

Protect Against Power Surges

• Don’t block ventilation holes on any of the devices. Arrange the devices so that air can circulate freely.

• Don’t stack devices.

• If you place devices in a stand, make sure you allow adequate ventilation.

• If you connect an audio receiver or amplifier, place it on the top shelf so the heated air from it won’t flow around other devices.

Protect Devices from Overheating

• Insert each cable firmly into the designated jack.

• If you place devices above the TV, route all cables down the side of the back of the TV instead of straight down the middle.

• If your antenna uses 300-ohm twin lead cables, do not coil the cables. Also, keep the twin lead cables away from audio/video cables.

•

Use shielded interface cables with ferrite cores to maintain compliance for this product.

Position Cables Properly to Avoid Audio Interference

Don’t place the TV where sunlight or room lighting will be directed toward the screen. Use soft or indirect lighting.

Use Indirect Light

You will need a master remote or USB Cloner to set up the TV. Contact your RCA Commercial Distributor to purchase these.

Remote Control

Check that the following parts were packed with your product.

Check Supplied Parts

Power Cord Owner’s Manual Composite

Gender Cable

Component

Gender Cable

Note

- If you need to replace your remote, call 1-800-RCA-2161. A shipping and handling fee, and the appropriate sales tax will be charged upon ordering. Have your Visa, MasterCard, or Discover Card ready.

- Stand Base, Stand Body images shown may differ from your TV.

Master and Guest

Remote (Optional)

Chapter 1: Connections and Setup

Front Panel - J22CE820

VOL SOURCE MENUCH

Note

- Image shown may differ from your TV.

1. VOL- / VOL+

Adjusts sound level and menu settings.

2. CH / CH

Select a channel and menu settings.

3. SOURCE Selects the TV, AV(AV1), Side AV(AV2), S-Video, YPBPR, VGA, HDMI1, HDMI2 or USB mode.

4. MENU

Display on screen menus.

5. POWER

Switches the set on or off.

6. Power Indicator

Illuminates to bright blue when the TV is on. When the TV is powered off, this LED is also off.

Remote control sensor

Accepts the IR signal of remote controller.

Chapter 1

Chapter 1: Connections and Setup

Rear Panel - J22CE820

54 11321 98

6 7

Note

- Image shown may differ from your TV.

1. AC IN

This TV operates on AC power.

2. HDMI/DVI IN1

Connect to the HDMI jack for device with HDMI output. This input can also be used as a DVI connection with separate analog audio inputs.

3. HDMI IN2

Connect to the HDMI jack for device with HDMI output.

4. AUDIO IN (RGB/DVI)

Connect to the audio output jack on your PC.

5. RGB IN (PC)

Connect to the video output jack on your PC.

6. COMPONENT IN (YPbPr)

Video/Audio inputs for Component.

7. AV IN 1

Connects to your Audio/Video devices using a composite (Yellow/Red/White) cable.

8. S-VIDEO IN

Connects to your video devices using an S-Video cable.

9. AUDIO OUT

Connect analog audio to various types of equipment.

10.SERVICE(RS232)

This port is used for service.

11.ANTENNA/CABLE IN

Connect to your antenna or cable box for TV signal.

12.AV IN 2

Connects to your Audio/Video devices using a composite (Yellow/Red/White) cable.

13.USB IN

USB device interface.

Chapter 1

Chapter 1: Connections and Setup

Front Panel - J26CE820

VOL SOURCE MENUCH

Note

- Image shown may differ from your TV.

1. VOL- / VOL+

Adjusts sound level and menu settings.

2. CH / CH

Select a channel and menu settings.

3. SOURCE

Selects the TV, AV(AV1), Side AV(AV2), S-Video, YPBPR, VGA, HDMI1, HDMI2 or USB mode.

4. MENU

Display on screen menus.

5. POWER

Switches the set on or off.

6. Power Indicator

Illuminates to bright blue when the TV is on. When the TV is powered off, this LED is also off.

Remote control sensor

Accepts the IR signal of remote controller.

Chapter 1

Chapter 1: Connections and Setup

Rear Panel - J26CE820

54 1132 98

6 7

Note

- Image shown may differ from your TV.

1. AC IN

This TV operates on AC power.

2. HDMI/DVI IN1

Connect to the HDMI jack for device with HDMI output. This input can also be used as a DVI connection with separate analog audio inputs.

3. HDMI IN2

Connect to the HDMI jack for device with HDMI output.

4. AUDIO IN (RGB/DVI)

Connect to the audio output jack on your PC.

5. RGB IN (PC)

Connect to the video output jack on your PC.

6. COMPONENT IN (YPbPr)

Video/Audio inputs for Component.

7. AV IN 1

Connects to your Audio/Video devices using a composite (Yellow/Red/White) cable.

8. S-VIDEO IN

Connects to your video devices using an S-Video cable.

9. AUDIO OUT

Connect analog audio to various types of equipment.

10.SERVICE(RS232)

This port is used for service.

11.ANTENNA/CABLE IN

Connect to your antenna or cable box for TV signal.

12.AV IN 2

Connects to your Audio/Video devices using a composite (Yellow/Red/White) cable.

13.USB IN

USB device interface.

Chapter 1

Chapter 1: Connections and Setup

Front Panel - J32CE720

VOL SOURCE MENUCH

12345

VOL SOURCEMENUCH

Note

- Image shown may differ from your TV.

1. VOL- / VOL+

Adjusts sound level and menu settings.

2. CH / CH

Select a channel and menu settings.

3. SOURCE

Selects the TV, AV(AV1), Side AV(AV2), S-Video, YPBPR, VGA, HDMI1, HDMI2 or USB mode.

4. MENU

Display on screen menus.

5. POWER

Switches the set on or off.

6. Power Indicator

Illuminates to bright blue when the TV is on. When the TV is powered off, this LED is also off.

Remote control sensor

Accepts the IR signal of remote controller.

Chapter 1

Chapter 1: Connections and Setup

Rear Panel - J32CE720

54 1132 98

6 7

Note

- Image shown may differ from your TV.

1. AC IN

This TV operates on AC power.

2. HDMI/DVI IN1

Connect to the HDMI jack for device with HDMI output. This input can also be used as a DVI connection with separate analog audio inputs.

3. HDMI IN2

Connect to the HDMI jack for device with HDMI output.

4. AUDIO IN (RGB/DVI)

Connect to the audio output jack on your PC.

5. RGB IN (PC)

Connect to the video output jack on your PC.

6. COMPONENT IN (YPbPr)

Video/Audio inputs for Component.

7. AV IN 1

Connects to your Audio/Video devices using a composite (Yellow/Red/White) cable.

8. S-VIDEO IN

Connects to your video devices using an S-Video cable.

9. AUDIO OUT

Connect analog audio to various types of equipment.

10.SERVICE(RS232)

This port is used for service.

11.ANTENNA/CABLE IN

Connect to your antenna or cable box for TV signal.

12.AV IN 2

Connects to your Audio/Video devices using a composite (Yellow/Red/White) cable.

13.USB IN

USB device interface.

Chapter 1

Chapter 1: Connections and Setup

Front Panel - J42CE820

VOL SOURCE MENUCH

Note

- Image shown may differ from your TV.

1. VOL- / VOL+

Adjusts sound level and menu settings.

2. CH / CH

Select a channel and menu settings.

3. SOURCE

Selects the TV, AV(AV1), Side AV(AV2), S-Video, YPBPR, VGA, HDMI1, HDMI2 or USB mode.

4. MENU

Display on screen menus.

5. POWER

Switches the set on or off.

6. Power Indicator

Illuminates to bright blue when the TV is on. When the TV is powered off, this LED is also off.

Remote control sensor

Accepts the IR signal of remote controller.

Chapter 1

Chapter 1: Connections and Setup

Rear Panel - J42CE820

54 1132 98

6 7

Note

- Image shown may differ from your TV.

1. AC IN

This TV operates on AC power.

2. HDMI/DVI IN1

Connect to the HDMI jack for device with HDMI output. This input can also be used as a DVI connection with separate analog audio inputs.

3. HDMI IN2

Connect to the HDMI jack for device with HDMI output.

4. AUDIO IN (RGB/DVI)

Connect to the audio output jack on your PC.

5. RGB IN (PC)

Connect to the video output jack on your PC.

6. COMPONENT IN (YPbPr)

Video/Audio inputs for Component.

7. AV IN 1

Connects to your Audio/Video devices using a composite (Yellow/Red/White) cable.

8. S-VIDEO IN

Connects to your video devices using an S-Video cable.

9. AUDIO OUT

Connect analog audio to various types of equipment.

10.SERVICE(RS232)

This port is used for service.

11.ANTENNA/CABLE IN

Connect to your antenna or cable box for TV signal.

12.AV IN 2

Connects to your Audio/Video devices using a composite (Yellow/Red/White) cable.

13.USB IN

USB device interface.

Chapter 1

Chapter 1: Connections and Setup

Chapter 1

Wall mount Installation

4 inches

The set can be installed on a wall as shown above. For proper ventilation, allow a clearance of 4 inches on all four sides from the wall. Detailed instructions are available from your dealer, refer to the optional Wall Mounting Bracket Installation and Setup Guide. (Wall Mount Sold Separately)

Note

- This Television should be installed by a Qualified Service Personnel.

Chapter 1: Connections and Setup

Note

- Screw length needed depends on the wall mount used. For further information, refer to the VESA Wall Mounting Instruction Guide.

Vesa Standard TV Mounts - 22/26 inches

To the right are some examples of VESA standard mounts. Since there are numerous types of stands and mounts available, only a few are shown here. Refer to the instructions provided with the TV stand that will be used to mount the TV. Be sure the style of stand selected is capable of supporting the weight of the TV and is appropriate for the application.

General Guidelines: Choosing a Location for installing a VESA Standard Mount

If the mount will be on a wall, a typical wooden stud behind the wall board would be the preferred choice for a location to attach the wall mount. The wall mount location chosen should be appropriate for drilling holes and have available the required power source as well as antenna/cable and any other equipment leads as necessary.

Wall Mounts

A sturdy surface on a desk or other similar flat table-like furniture would be the appropriate location for mounting a pedestal-style TV stand. Most stands are designed so that the wiring is threaded through the stand itself or a loopthrough style clamp so that the wiring is neatly bunched and not strung in such a way as to create a potential hazard to the user. (Some stands are portable and can be moved from one location to another.) Be sure all safety considerations are followed.

Pedestal Mounts and Stands

Typical Wall Standard Type Mount

with Swivel Bracket

Typical Pedestal Type Mount with

Swivel Bracket

Caution: Tightening wall mount screws that are too long could cause damage to the internal components of

this television. Use M4 X “L” bolts to mount LED. (“L” = Wall Mount bracket thickness + 0.3 inch or below for J22CE820) Use M5 X “L” bolts to mount LED. (“L” = Wall Mount bracket thickness + 0.3 inch or below for J26CE820)

You must use a UL listed wall mount or the DTI Services, LLC DTI-006 Wall Mount Bracket whenever Wall Mounting this television. A skilled person should be contacted to perform the installation of the television and wall mount. Specification of a generic "UL Listed wall mount" should additionally include : minimum weight that the mount must be able to support, minimum screen size that the mount must be able to support, instructions furnished as part of the wall mount must be closely followed, the wall mount must be suitable to support the type of television under consideration.

Chapter 1

Chapter 1: Connections and Setup

Vesa Standard TV Mounts - 32/42 inches

General Guidelines: Choosing a location for installing a VESA Standard Mount

Typical Wall Standard Type Mount with Swivel Bracket

Be sure the style of stand selected is capable of supporting the weight of the TV.

For pedestal-type mounts, a sturdy surface on a desk or other similar flat table-like surface would be the appropriate location for mounting a pedestal-style TV stand. (Some stands are portable and can be moved from one location to another.) Be sure all safety considerations are followed.

Most stands are designed so that the wiring would be threaded through the stand itself or a loopthrough style clamp so that the wiring is neatly bunched and not strung in such a way as to create a potential hazard to the user.

The following examples are VESA Standard wall mounts. Since there are numerous types of stands and mounts available, only a few are shown here. Refer to the instructions provided with the TV stand that will be used to mount the TV.

Note

- Image shown may differ from your TV.

- Screw length needed depends on the wall mount used. For further information, refer to the VESA Wall Mounting Instruction Guide.

Caution: Tightening wall mount screws that are too long could cause damage to the internal components of

this television. Use M5 X “L” bolts to mount LED. (“L” = Wall Mount bracket thickness + 0.5 inch or below for J32CE720) Use M6 X “L” bolts to mount LED. (“L” = Wall Mount bracket thickness + 0.3 inch or below for J42CE820)

Model

J32CE720

J42CE820

VESA (A*B)

200 X 100mm

400 X 400mm

Chapter 1

Chapter 1: Connections and Setup

Chapter 1

Rear panel of the set

Antenna Connection

Note

-To improve the picture quality in a poor signal area, please purchase a signal amplifier and install properly.

- If the antenna is not installed properly, contact your dealer for assistance.

Rear panel of the set

Multi-family Dwellings/ Apartments (Connect to wall antenna socket)

Single-family Dwellings /Houses (Connect to wall jack for outdoor antenna)

Wall Antenna Socket

Outdoor Antenna

RF Coaxial Wire (75 ohm)

Turn clockwise to tighten.

Be careful not to bend the bronze wire when connecting to an antenna port.

* Separately purchase a RF Coaxial Wire(75 ohm)

Signal

Amplifier

VHF UHF

VHF

UHF

Chapter 1: Connections and Setup

VCR Connection

AA When connecting with an antenna

ANT IN

ANT OUT S-VIDEO

OUT

(R) AUDIO (L) VIDEO

1. Connect the Antenna out socket of the VCR to the Antenna input socket on the TV.

2. Power up the VCR and Television.

3. Tune the TV to the channel output by the VCR. (typically ch.3 or 4.)

4. Refer to the VCR manual for operating instructions.

VCR

Rear panel of the set

- To avoid picture noise (interference), leave an adequate distance between the TV and the VCR.

Chapter 1

AA When connecting with an RCA cable

ANT IN

ANT OUT S-VIDEO

OUT

(L) AUDIO (R)VIDEO

OUTPUT SWITCH

1. Connect the AUDIO/VIDEO jacks between TV and VCR. Match the jack colors (Video = yellow, Audio Left = white, and Audio Right = red)

2. Insert a video tape into the VCR and press PLAY on the VCR.

3. Select the AV1 or AV2 input source using the INPUT button on the remote control.

4. Refer to the VCR manual for operating instructions.

VCR

Rear panel of the set

Side panel of the set

Chapter 1: Connections and Setup

AA When connecting with a S-Video cable

ANT IN

ANT OUT S-VIDEO

OUT

(L) AUDIO (R)VIDEO

OUTPUT SWITCH

1. Connect the S-VIDEO output of the VCR to the S- VIDEO input on the set.

2. Connect the audio outputs of the VCR to the AV AUDIO input jacks on the set.

3. Insert a video tape into the VCR and press PLAY on the VCR.

4. Select the S-VIDEO input source using the INPUT button on the remote control.

5. Refer to the VCR manual for operating instructions.

VCR

Rear panel of the set

Chapter 1

Chapter 1: Connections and Setup

AA When connecting with a Component cable

(L) AUDIO (R)

Pb Pr

1. Connect the video outputs (Y, PB, PR) of the DVD to the COMPONENT VIDEO(Y/Pb/Pr) jacks on the set.

2. Connect the audio outputs of the DVD to the COMPONENT AUDIO jacks on the set.

3. Turn on the DVD player, insert a DVD.

4. Select YPbPr source using the INPUT button on the remote control.

5. Refer to the DVD player's manual for operating instructions.

DVD

Rear panel of the set

DVD Connection

AA When connecting with a HDMI cable

HDMI-DVD OUTPUT

1. Connect the HDMI output of the DVD to the HDMI/DVI IN 1 or HDMI IN 2 jack on the set.

2. Select HDMI1 or HDMI2 input source using the INPUT button on the remote control.

3. Refer to the DVD player's manual for operating instructions.

DVD

Rear panel of the set

Chapter 1

Chapter 1: Connections and Setup

Chapter 1

AA When connecting with a S-Video cable

(L) AUDIO (R)

Pb Pr

S-VIDEO

1. Connect the S-VIDEO output of the DVD to the S-VIDEO input on the set.

2. Connect the audio outputs of the DVD to the AV AUDIO input jacks on the set.

3. Turn on the DVD player, insert a DVD.

4. Select the S-VIDEO input source using the INPUT button on the remote control.

5. Refer to the DVD player's manual for operating instructions.

DVD

Rear panel of the set

Chapter 1: Connections and Setup

- This TV can receive Digital Over-the-air/Cable signals without an external digital set-top box. However, if you do receive Digital signals from a digital set-top box or other digital external device, refer to the figure as shown below.

HDSTB Connection

AA When connecting with a D-Sub 15 pin cable

(R) AUDIO (L) RGB-DTV OUTPUT

1. Connect the RGB output of the digital set-top box to the RGB IN (PC) jack on the set.

2. Connect the audio outputs of the set-top box to the AUDIO IN (RGB/DVI) jack on the set.

3. Turn on the digital set-top box.

4. Select VGA input source using the INPUT button on the remote control.

5. Refer to the digital set-top box manual for operating instructions.

Digital Set-top Box

Rear panel of the set

AA When connecting with a HDMI to DVI cable

DVI-DTV OUTPUT

(R) AUDIO (L)

1. Connect the DVI output of the digital set-top box to the HDMI/DVI IN 1 jack on the set.

2. Connect the audio outputs of the set-top box to the AUDIO IN (RGB/DVI) jack on the set.

3. Turn on the digital set-top box.

4. Select HDMI1 input source using the INPUT button on the remote control.

5. Refer to the digital set-top box manual for operating instructions.

Digital Set-top Box

Rear panel of the set

Chapter 1

Chapter 1: Connections and Setup

Chapter 1

AA When connecting with a Component cable

(L) AUDIO (R)

Pb Pr

1. Connect the video outputs (Y, PB, PR) of the digital set-top box to the COMPONENT VIDEO(Y/Pb/Pr) jacks on the set.

2. Connect the audio outputs of the digital set-top box to the COMPONENT AUDIO jacks on the set.

3. Turn on the digital set-top box.

4. Select YPbPr source using the INPUT button on the remote control.

5. Refer to the digital set-top box manual for operating instructions.

Digital Set-top Box

Rear panel of the set

AA When connecting with a HDMI cable

HDMI-DTV OUTPUT

1. Connect the HDMI output of the digital set-top box to the HDMI/DVI IN 1 or HDMI IN 2 jack on the set.

2. Turn on the digital set-top box.

3. Select HDMI1 or HDMI2 input source using the INPUT button on the remote control.

4. Refer to the digital set-top box manual for operating instructions.

Digital Set-top Box

Rear panel of the set

Chapter 1: Connections and Setup

L-AUDIO-RVIDEO

OUT

1. Connect the AUDIO/VIDEO jacks between TV and external equipment. Match the jack colors (Video = yellow, Audio Left = white, and Audio Right = red)

2. Select the AV1 or AV2 input source using the INPUT button on the remote control.

3. Operate the corresponding external equipment.

4. Refer to the external equipment manual for operating instructions.

Camcorder

Video game set

Rear panel of the set

External A/V Source

Side panel of the set

Chapter 1

Chapter 1: Connections and Setup

Chapter 1

AA When connecting with a D-Sub 15 pin cable

AUDIO OUT PC OUTPUT

1. Connect the RGB output of the PC to the RGB IN (PC) jack on the set.

2. Connect the PC Audio Output to the AUDIO IN (RGB/DVI) jack on the TV using a male-to-male

3.5mm mini jack.

3. Turn on both the PC and TV.

4. Select the VGA input source on your TV by pressing either the INPUT buttons on the remote control.

Rear panel of the set

PC Connection

AA When connecting with a HDMI to DVI cable

DVI OUTPUT

AUDIO OUT

1. Connect the DVI Output on the PC to the HDMI / DVI IN 1 Input jack on the TV.

2. Connect the PC Audio Output to the AUDIO IN (RGB/DVI) jack on the TV using a male-to-male

3.5mm mini jack.

3. Turn on both the PC and TV.

4. Select the HDMI1 input source on your TV by pressing either the INPUT buttons on the remote control.

Rear panel of the set

31.47

35.16

37.88

48.36

59.94

56.25

60.32

60.00

Horizontal

Frequency (kHz)

Vertical

Frequency (Hz)

640 x 480

800 x 600

1024 x 768

Resolution

AA PC

60.000

Vertical

Frequency (Hz)

480/60P

720/60P

1080/60I

1080/60P

Resolution

AA HDMI

Resolution

Note

a. The synchronization input form is separate. b. If the resolution is not supported, ‘Not Support!’ message will be displayed.

1. Connect the USB device to the USB IN jack on the set.

2. Select the USB input source using the INPUT button on the remote control.

3. Follow the on screen display to access the USB functions.

USB Memory

Side panel of the set

USB Port

Chapter 1: Connections and Setup

Chapter 1

29Chapter 2

Chapter 2: Using the Remote Control

The basic remote control (KM38R02) is used by the viewer for basic operating functions. It is designed so that the viewer cannot alter certain master remote-specified features. The Sleep, Closed Captioning, and Channel Guide features can be accessed directly with remote buttons.

1. POWER

Switches the set on or off.

2. PICTURE

Changes picture settings to a pre-defined mode.

3. SOUND

Changes sound settings to a pre-defined mode.

4. SLEEP

Sets the sleep timer.

5. SYSTEM

Configures the remote preamble (Bed 1/Bed 2/Bed 3) for use with multi TVs in 1 room. Press and hold <SYSTEM> and <1> key to set the remote for “Bed1”(TV1). Press and hold <SYSTEM> and <2> key to set the remote for “Bed2”(TV2). Press and hold <SYSTEM> and <3> key to set the remote for “Bed3”(TV3). Refer to “Key Management”,”RCU type” in Chapter 4.

6. RATIO

Selects your desired picture aspect ratio.

7. SAP

Selects MTS sound / audio language.

8. INFO

Displays the current channel information.

9. RESET

Not Used.

10. NUMBER BUTTONS

Selects channel numbers.

11. Hyphen( - )

Used when entering a digital channel (ex : 10 - )

2 3 6

1 5 4

9 8

Basic(User) Remote

Chapter 2: Using the Remote Control

Chapter 2

12. GO BACK

Returns to the previous channel.

13. VOL + / VOL -

Adjusts sound level.

14. CH + / CH -

Selects a channel.

15. MENU

Displays “Basic” on screen menu. There are 2 remotes for this TV; KM38R02 - user Remote. This remote displays a basic user menu when the menu key is pressed. KM38R01 - installer Remote. This remote displays an installer menu when the menu key is pressed.

16. GUIDE

Displays ”Channel List“ menu.

17. CC

Selects the Caption menu directly.

18. INPUT Selects the TV, AV(AV1), Side AV(AV2), S-Video, YPBPR, VGA, HDMI1, HDMI2 or USB mode.

19. Navigational Controls

Navigates menu items.

20. MUTE

Switches the sound on or off.

21. CLEAR

Exit from any OSD.

+ 142 hidden pages
