Please read this manual before
operating this product for the first time.
Model H5450
Important Information
Important Information
Equipment Approval Information
Your telephone equipment is approved for connection to the Public Switched Telephone Network and is in compliance with parts 15 and 68, FCC Rules and Regulations and the Technical Requirements for Telephone Terminal Equipment published by ACTA.
1 Notification to the Local Telephone Company
On the bottom of this equipment is a label indicating, among other information, the US number and Ringer Equivalence Number (REN) for the equipment. You
must, upon request, provide this information to your telephone company.
The REN is useful in determining the number of devices you may connect to your telephone line and still have all of these devices ring when your telephone
number is called. In most (but not all) areas, the sum of the RENs of all devices connected to one line should not exceed 5. To be certain of the number of
devices you may connect to your line as determined by the REN, you should contact your local telephone company.
A plug and jack used to connect this equipment to the premises wiring and telephone network must comply with the applicable FCC Part 68 rules and requirements adopted by the ACTA. A compliant telephone cord and modular plug is provided with this product. It is designed to be connected to a compatible
modular jack that is also compliant. See installation instructions for details.
Notes
• This equipment may not be used on coin service provided by the telephone company.
• Party lines are subject to state tariffs, and therefore, you may not be able to use your own telephone equipment if you are on a party line. Check with your
local telephone company.
• Notice must be given to the telephone company upon permanent disconnection of your telephone from your line.
• If your home has specially wired alarm equipment connected to the telephone line, ensure the installation of this product does not disable your alarm
equipment. If you have questions about what will disable alarm equipment, consult your telephone company or a qualified installer.
2 Rights of the Telephone Company
Should your equipment cause trouble on your line which may harm the telephone network, the telephone company shall, where practicable, notify you that
temporary discontinuance of service may be required. Where prior notice is not practicable and the circumstances warrant such action, the telephone company
may temporarily discontinue service immediately. In case of such temporary discontinuance, the telephone company must: (1) promptly notify you of such
temporary discontinuance; (2) afford you the opportunity to correct the situation; and (3) inform you of your right to bring a complaint to the Commission
pursuant to procedures set forth in Subpart E of Part 68, FCC Rules and Regulations.
The telephone company may make changes in its communications facilities, equipment, operations or procedures where such action is required in the operation of its business and not inconsistent with FCC Rules and Regulations. If these changes are expected to affect the use or performance of your telephone
equipment, the telephone company must give you adequate notice, in writing, to allow you to maintain uninterrupted service.
2
Important Information
Interference Information
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference;
and (2) This device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna (that is, the antenna for radio or television that is “receiving” the interference).
• Reorient or relocate and increase the separation between the telecommunications equipment and receiving antenna.
• Connect the telecommunications equipment into an outlet on a circuit different from that to which the receiving antenna is connected.
If these measures do not eliminate the interference, please consult your dealer or an experienced radio/television technician for additional suggestions. Also,
the Federal Communications Commission has prepared a helpful booklet, “How To Identify and Resolve Radio/TV Interference Problems.” This booklet is available from the U.S. Government Printing Office, Washington, D.C. 20402. Please specify stock number 004-000-00345-4 when ordering copies.
Hearing Aid Compatibility
This telephone system meets FCC standards for Hearing Aid Compatibility.
US NUMBER IS LOCATED ON THE CABINET BOTTOM
REN NUMBER IS LOCATED ON THE CABINET BOTTOM
Licensing
Licensed under US Patent 6,427,009.
3
SE E M ARK ING ON BO TTO M / BA CK OF PRO DUC T
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO
PREVENT FIRE OR
ELECTRICAL SHOCK
HAZARD, DO NOT
EXPOSE THIS
PRODUCT TO RAIN
OR MOISTURE.
THE LIGHTNING
FLASH AND ARROW
HEAD WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
“DANGEROUS
VOLTAGE” INSIDE
THE PRODUCT.
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR
BACK). NO USER
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL.
THE EXC LAMATION
POINT WITHIN THE
TRIANG LE IS A
WARNING SIGN
ALERTI NG YOU OF
IMPORTANT
INSTRU CTIONS
ACCOMPANY ING
THE PR ODUCT.
CAUTION:
Important Information
FCC RF Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be
installed and operated with a minimum distance of 20 centimeters between the radiator and your body. This transmitter must not be
co-located or operated in conjunction with any other antenna or transmitter.”
For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines when used with the belt clip supplied
with this product. Use of other accessories may not ensure compliance with FCC RF exposure guidelines.
4
Introduction
Introduction
CAUTION: When using telephone equipment, there are basic safety instructions that
should always be followed. Refer to the IMPORTANT SAFETY INSTRUCTIONS provided
with this product and save them for future reference.
Congratulations on your purchase of the RCA H5450 Cordless Handset which is
designed to be used only with the RCA 25450 Telephone System. The RCA 25450
Telephone System was built to satisfy a variety of business and residential needs. A
prominent feature of the RCA 25450 is the two-way radio which gives you the flexibility to add remote handset phones anywhere there is an A/C electrical outlet.
The RCA 25450 Telephone System functions like a PBX office system. Calls are
handled in a way that offer similar privacy.
This user’s guide will cover the basics to get you started, explain the advanced
features of the Cordless Handset, and show you how to tailor the RCA H5450 to your
specific needs.
To get the most from your new phone, we suggest that you take a few minutes right
now to read through this user’s guide.
NOTE: The ringer timing in this system may ring in a different sequence than other types of
phone systems connected to the same line(s).
IMPORTANT: In order to use all of the features of this unit, you must subscribe to either the
standard Name/Number Caller ID Service or Call Waiting Caller ID Service. To know who is
calling while you are on the phone, you must subscribe to Call Waiting Caller ID Service.
IMPORTANT: Because cordless phones operate on electricity, you should have at least one
phone in your business or home that isn’t cordless, in case the power goes out.
5
Table of Contents
Important InformatIon .............................................................................2
EquIpmEnt approval InformatIon ..............................................................2
IntErfErEncE InformatIon ..........................................................................3
HEarIng aId compatIbIlIty ........................................................................3
• Never install telephone wiring during a lightning storm.
• Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations.
• Never touch non-insulated telephone wires or terminals, unless the telephone line is disconnected from the network.
• Use caution when installing or modifying telephone lines.
• Temporarily disconnect any equipment connected to the phone such as faxes, other phones, or modems.
Installation Guidelines
• Avoid sources of noise, such as a window by a busy street, and electrical noise, such as motors, microwave ovens, and fluorescent lighting.
• Avoid heat sources, such as heating air ducts, heating appliances, radiators, and direct sunlight.
• Avoid areas of excessive moisture or extremely low temperature.
• Avoid dusty locations.
• Avoid other cordless telephones or personal computers.
INSTALLATION NOTE: Some cordless telephones operate at frequencies that may cause or receive interference with TVs, microwave ovens, and VCRs. To
minimize or prevent such interference, the base of the cordless telephone should not be placed near or on top of a TV, microwave ovens, or VCR. If such
interference continues, move the cordless telephone farther away from appliances. Certain other communications devices may also use the 900 MHz frequency
for communication, and, if not properly set, these devices may interfere with each other and/or your new telephone. If you are concerned with interference,
please refer to the owner’s manual for these devices on how to properly set channels to avoid interference. Typical devices that may use the 900 MHz frequency
for communication include wireless audio/video senders, wireless computer networks, multi-handset cordless telephone systems, and some long-range cordless
telephone systems.
8
Parts Checklist
REDIAL MENU
Cordless
Handset
Belt Clip
Base
Charging
Cradle
Charging
Cradle Bracke
t
Battery Pack
Battery Compartment Cover
Charger/AC Adapter
Make sure your package includes the following items:
Connections and Setup
9
Connections and Setup
Battery
Back Cover
Handset
Cradle
Black
Wire
Cordless Handset Installation
Installing the Charging Cradle and AC Adaptor
Plug the transformer end of the AC Adaptor into a standard AC electric power outlet, plug the other end into the “Power 5.5VDC In” jack on the back of the Charging
Cradle.
Installing the Cordless Handset Battery
1. Locate the back cover and battery pack packaged separately from the Handset.
2. Insert the battery pack and connect the plug on the battery pack to the jack
inside the compartment. Use only the supplied RCA Nickel Metal Hydride
(Ni-MH) battery.
NOTE: It is important to maintain the polarity (black and red wires) to the jack inside the
compartment. To ensure proper battery installation, the connector is keyed and can be
inserted only one way.
3. Close the battery compartment by pushing the back cover up until it snaps into
place.
4. Place the handset in the charging cradle. Charge the battery for 12 hours before
the first use.
NOTE: Allow the handset battery to properly charge (for 12 hours) prior to first use or when
you install a new battery pack. If you do not properly charge the phone, battery performance
will be compromised.
NOTE: The Cordless Handset may feel warm to the touch after charging.
10
Mounting Surface
Cord Channel
Insert
tabs here
Leave 3"
from here
to plug
Loop inside
to prevent
pinching
3/16"
Connections and Setup
Installing the Charging Cradle Wall Mount
Choose a mounting location at least 10-1/2” clearance above the top screw hole.
1. Cut out the Charging Cradle Wall Mount Template. See page 71.
2. Hold the template against the wall and mark the mounting screw positions.
3. Drill holes in wall using appropriate size drill bit.
4. Insert anchor screws into the wall. We recommend #8 pan head screws. Allow
3/16” space between screw heads and wall.
5. Press the AC adapter cord in the cord channel of the wall bracket. Allow approximately 3” of cord past the end of the channel.
6. Insert the round connector on the AC adapter cord into the connection on the
bottom of the charging cradle.
7. Insert the front tabs of the bracket in the square holes of the charging cradle.
Swing the cradle down to snap it in place. Make sure the AC adapter cord is not
pinched between the cradle and the mount.
8. Mount the assembly to the wall.
9. Plug the AC Adapter into a power outlet.
10. Insert the Cordless Handset into the cradle. Charge the battery for 12 hours
before the first use.
11
Registering the Cordless Handset
Registering the Cordless Handset
Cordless handsets must be registered with the Base Unit before use. If the Cordless
Handset was purchased with the Base Unit as a system, the Cordless Handset has
already been registered. The ID will be displayed when the Cordless Handset is powered on. If the Cordless Handset has not been registered or the registration has been
deleted, the display shows “Please register”.
NOTE: You must program both the Base Unit and the Cordless Handset to register the
handset. Have both units ready to program as you must complete registration of the handset
within 30 seconds after programming the Base Unit.
1. On the Base Unit, press the soft button.
2. Press 5 or 6 on the Navigation button to scroll through the options until
“Registration” appears on the display.
3. Press the soft button.
4. “Register HS” appears on the display. Have the Cordless Handset ready to
program.
5. Press the soft button.
6. The display will show “Press REGISTER in HS menu options.” A 30 second timer
will begin at this point. If the registration process is not completed in this time,
the process will be canceled.
7. On the Cordless Handset, press the soft button.
8. Press 5 or 6 on the Navigation button to scroll through the options until
“Registration” appears on the display.
9. Press the soft button.
10. “Register HS” appears on the display.
12
Registering the Cordless Handset
11. Press the soft button.
12. The Cordless Handset will link to the Base Unit at this time.
13. When finished, the Cordless Handset display will show “Registration completed”.
The new ID number is shown on the first line of the Cordless Handset display.
14. Repeat the steps for each Cordless Handset to be registered.
Deregister Cordless Handset
You will program the Base Unit and the Cordless Handset to complete the procedure.
NOTE: Cordless Handsets must be deregistered from the Base Unit before the assigned ID can
be reused.
1. On the Base Unit, press the soft button.
2. Press 5 or 6 on the Navigation button to scroll through the options until
“Registration” appears on the display.
3. Press the soft button.
4. Press 5 or 6 on the Navigation button to scroll through the options until
“Deregister HS” appears on the display.
5. Press the soft button. Have the Cordless Handset ready to program.
6. The display on the Base Unit will show “Press DEREGISTER in HS menu options.”
A 30 second timer will begin at this point. If the deregistration process is not
completed in this time, the process will be canceled.
7. On the Cordless Handset, press the soft button.
8. Press 5 or 6 on the Navigation button to scroll through the options until
“Registration” appears on the display.
13
Registering the Cordless Handset
Deregister HSDeregister HS
9. Press the soft button.
10. Press 5 or 6 on the Navigation button to scroll through the options until
“Deregister HS” appears on the display.
11. Press the soft button.
12. The Cordless Handset will link to the Base Unit at this time. The Cordless Handset
display will show “Deregistration completed,” and return to standby.
13. Repeat the steps for each Cordless Handset to be deregistered.
10. If an invalid ID was entered, the display will show “Invalid ID” and return to the
“Registration” submenu.
14
Speaker
Voice Mail
Microphone
Speakerphone
Intercom
Keypad
Exit
Soft Button
LCD display
Cordless Handset Receiver
Soft Button
Voice Mail
Indicator
Antenna
Flash
Navigation Button
(Volume + -/Directory/Caller ID)
Talk
End/Power
Features
Cordless Handset Layout
15
Features
Contacts
Cordless Handset Charging Cradle Layout
16
Smith John
1-315-555-1234
Caller ID
Information
Soft Buttons
Battery
Status
01
Handset ID
Number
RSSI
L1
Line
Indicator
Features
Features
LCD display
The LCD display has a LED (Light Emitting Diode) for backlighting. The LED dims after
10 seconds of inactivity.
The first line of the display can show the Caller ID, time and date, or can show the
following status icons from left to right:
RSSI (Receive Signal Strength Indicator) - During a call, the number of bars is
proportional to the radio signal strength received
Line Indicators - Indicate the line number(s) being accessed or held.
Handset ID - Displays a 2-digit Handset ID
Battery Strength Indicator - Number of bars is proportional to the amount of
battery time remaining. Indicates charging when in charger cradle
The second and third lines can show status, Caller ID information, message, menu
selections, or editable characters.
The last line shows various left and right Soft Button functions.
End/Power Button
Press to end a call. Press for 3 seconds to turn the handset power ON or OFF.
Talk Button
Press to place a phone call, answer an incoming phone call, or make an intercom call
through the receiver or headset. The receiver or headset remains in use unless the
Speaker button is pressed.
17
Features
Arrows on Display Indicate
Scrolling Available by Using
Navigation Button
VM box # 01
00 new 00 old
Play new
Left and Right Soft Buttons
The function of each Soft Button changes according to what is shown in the display
above it. Press to perform the function above the Soft Button.
MENU System (Adjust Settings and Registration)
Use the Menu system by pressing the soft button to adjust sound settings, phone settings, and to register Cordless Handsets.
NOTE: You must exit the Menu System before you can make a call.
Redial Soft Button
Allows you to dial the last ten (10) numbers called. You can use the Navigation Button 5 or 6 arrows to scroll through the last 10 numbers.
Pre-Dialing
Allows you to enter a phone number before accessing a telephone line by pressing
the Talk or Speaker button.
Navigation Button
Press 5 or 6 to scroll through records and menu selections on the display, adjust
ringer volume during Standby Mode, and adjust the Cordless Handset receiver,
Speakerphone or Headset voice volume during a call. Press 3 or 4 to move the
cursor on the display during number and name editing, and to access Caller ID or
Directory functions during Standby Mode.
Speaker Button
Press the Speaker button to activate the Speakerphone and make a call, answer an
incoming call, or make an intercom call. You can toggle between the speakerphone
mode and the receiver by pressing the Talk or Speaker buttons. To end a call, press
the End button.
18
Features
Headset Jack
Allows you to plug in a headset. The headset jack supports a standard 2.5 mm headset plug.
Mute
Available through the soft button. During a call, allows you to temporarily turn off the microphone on the Cordless Handset, headset, or speakerphone so
the person on the line cannot hear you.
Flash button
Press to send a signal to a phone line to retrieve a dial tone after you end a call, or
to perform the call waiting feature provided by local phone companies during a call.
Hold
Available through the soft button during a call. Allows you to temporarily suspend a call up to 30 minutes.
Exit Button
Returns to the Standby Mode display. Any unsaved changes will be discarded.
Voice Mail Button
Allows you to access the Voice Mail system to play new or old messages or to change
your voice mail options.
Voice Mail Indicator Light
Flashes when there are unheard voice mail messages.
19
Features
Intercom Button
Press to place an intercom call to an extension (Cordless Handset ID or Base Unit ID)
or a Group ID.
Call Forwarding
Allows you to forward future incoming calls from your extension to an external
phone number.
Call Transferring
Allows you to move a call from one extension to another.
Conference Calling
The conference call function allows a caller from the Base Unit or a Cordless Handset
to add a third person to a call. The call must include at least one outside line.
Second Incoming Call
Alerts you of a new call from a different line by a tone when you are on the phone.
Allows you to toggle between calls.
Caller ID
Contact your local phone company to subscribe to this feature. The phone system
receives and displays Caller ID information transmitted by your local phone company.
This information may include the phone number, date and time. The unit can store
up to 50 calls.
20
Features
Call Waiting
Contact your local phone company to subscribe to this feature. This feature allows you
to see on the display who is calling when you hear a call waiting tone.
NOTE: The call waiting tone is audible only to the extension that is on the line. No other extension
will hear the tone or can answer the call.
Extension Groups
This feature allows several Cordless Handset users to be called or paged at the same time
as one group. The first Handset user to answer receives the call. There are four group ID
numbers (91-94) available for Cordless Handset users.
NOTE: The Base Unit always belongs to all groups
For example, if several Cordless Handset users in a sales department decide to be called
as a group, each Cordless Handset subscribes to the same group ID number. Outside and
Intercom calls can be directed to that “sales” group ID number.
Auto Attendant recordings can also direct calls to Extension Groups. For example, you
could record an Auto Attendant message to say; “To speak with someone in sales, press 91”.
21
Using Your RCA 25450 Phone System
Using Your RCA 25450 Phone System
Your RCA 25450 Cordless Handset comes ready to use unless it was purchased separately from the Base Unit. If purchased separately, it must be registered before use.
See “Registering Handsets” in this manual. This section details the basic operation
of the Cordless Handset, including instructions on making, receiving and ending a
call, call waiting, switching between audio modes, putting a call on hold, muting,
transferring a call, and using the intercom.
Making a Call
Press and hold the End button to turn on the Cordless Handset. You will hear a
confirmation tone and see the display when the Handset is on. Calls can be made by
pressing the Talk or Speaker buttons or plugging in a headset.
Refer to Auto or Manual Line Selection in this User’s Guide for instructions on setting your Cordless Handset to the Auto or Manual Line Selection Mode.
Auto Line-Selection Dial
The Auto Line-Selection Dial function allows the user to dial a phone number without first choosing a line. An available line is automatically selected.
1. Press the Talk or Speaker button.
NOTE: To cancel dialing at any time, press the End button.
2. The display will show “Press REDIAL or dial number” or the dialing prefix if it is
enabled via the phone setting menu.
3. Press the soft button to redial the last number called, or enter the
phone number using the keypad (0–9, *, #).
4. If the Cordless Handset can not establish a connection to the Base Unit after 15
seconds, it will show “No connection”. If all usable phone lines are not available,
it will show “No line is available”. If there are usable phone lines available but all
system resources are in use, the display will show “System busy”.
22
Using Your RCA 25450 Phone System
5. Otherwise, it will enter talk mode. The corresponding receiver, headset, or speakerphone will be turned on.
6. If the Cordless Handset loses the connection with the Base Unit due to interference, it will try to re-establish the connection for 10 seconds and the display will
show “Re-establishing connection …”
7. If the connection is re-established, it will enter talk mode. Otherwise, the display
will show “Connection lost” for 5 seconds and return to the standby screen.
Manual Line-Selection Dial
The manual line-selection dial function allows the user to choose a phone line to
make a call.
1. Press the Talk or Speaker button. It will show “Connecting …”
NOTE: To cancel dialing at any time, press the End button.
2. If the Cordless Handset can not establish a connection to the Base Unit after 15
seconds, the display will show “No connection”. If all usable phone lines are not
available, it will show “No line is available”. If there are usable phone lines avail-
able but system resources are busy, the display will show “System busy”.
3. Otherwise, the display will show phone lines that are available at the time. Use
the keypad (1–4) to select a line.
4. If the phone line selected is unavailable, it will show “Line (1-4) is in use”.
5. Otherwise, it will enter talk mode and the display will show “Press REDIAL or dial number” or the dialing prefix if it is enabled via phone setting menu and the corresponding receiver, headset, or speakerphone will be turned on.
6. Press the Redial button to redial the last number called, or enter the phone
number using the keypad (0–9, *, #).
23
Loading...
+ 53 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
