RCA DRC8040N User Manual

Download

DVD Recorder

User’s Guide

DRC8040N

Changing Entertainment. Again.

Important Information

CAUTION

RISK OF ELECTRIC

SHOCK DO NOT OPEN

This symbol indicates “dangerous voltage” inside the product that presents a risk of electric shock or personal injury.

FCC INFORMATION

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures.

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect this equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

This class B digital apparatus meets all requirements of the Canadian Interference – Causing Equipment Regulations. This class B digital apparatus complies with Canadian CES-003.

Cet appareil numérique de la class B est conforme á la norme du NMB-003 du Canada.

This symbol indicates that this product incorporates double insulation between hazardous mains voltage and user accessible parts.

This symbol indicates important instructions accompanying the product.

WARNING

To reduce the risk of ﬁ re or shock hazard, do not expose this DVD recorder to rain or moisture.

CAUTION

THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL.

CAUTION

FCC Regulations state that unauthorized changes or modiﬁ cations to this equipment may void the user’s authority to operate it.

Note:

This DVD recorder is designed and manufactured to respond to the Region Management Information. If the Region number of a DVD disc does not correspond to the Region number of this DVD recorder this DVD recorder cannot play the disc. The Region number for this DVD recorder is Region No 1.

Note:

Refer to the identiﬁ cation/rating label located on the back panel of your product for its proper operating voltage.

Product Registration

Please ﬁ ll out the product registration card and return it immediately. Returning the product registration card allows us to contact you if needed.

Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the serial and model numbers in case you need them. The numbers are located on the back of the DVD recorder.

Model No. __________________________ Serial No. __________________________

Purchase Date: ___________________________________________________________

Dealer/Address/Phone: ____________________________________________________

This device is protected by U.S. patent numbers 4,631,603 and 4,577,216 and 4,819,098 and other intellectual property rights. The use of Macrovision’s copy protection technology in the device must be authorized by Macrovision and is intended for home and other limited pay-per-view uses only, unless otherwise authorized in writing by Macrovision. Reverse engineering or disassembly is prohibited.

The apparatus should not be exposed to dripping or splashing and no objects ﬁ lled with liquids, such as vases, shoul be placed on the apparatus.

Ventilation:

You must adequately ventilate the product. Make sure there is adequate space around the DVD recorder to provide proper air ﬂ ow for ventilation. See diagram.

CLASS 1

LASER

PRODUCT

The AC power cord is polarized (one blade is wider than the other) and only ﬁ ts into AC outlets one way. If the plug won’t go into the outlet completely, turn the plug over and try to insert it the other way. If it still won’t ﬁ t, contact a qualiﬁ ed electrician to change the outlet or use a different one. Do not attempt to bypass this safety feature.

Table of Contents

Chapter 1: Connections and Setup

Types of Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Things to consider before you connect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Unpack the Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Choose your connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Explanation of Jacks and Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Back of the DVD recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Front of the DVD recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Connection: DVD recorder + TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Connection: DVD recorder + TV + Cable Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Connection: DVD recorder + TV + Satellite Receiver . . . . . . . . . . . . . . . . . . . . . . . . . 12

Advanced Audio Connection Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Install batteries in the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Turn on the TV and the DVD recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Complete Interactive Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

What to Expect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

How to ﬁ nd your TV’s Video Input Channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Next Steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Chapter 2: The Remote Control

Explanation of buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Find out if the remote can be programmed to operate your TV . . . . . . . . . . . . . . . .21

Programming the remote to operate your TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Programming the remote to operate other components . . . . . . . . . . . . . . . . . . . . . . 22

Using the remote to operate other components . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Code list for programming the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Chapter 3: Using the Recorder’s Features

Watching TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

The Channel Banner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

DVD Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Express recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Watching one channel while you record another channel . . . . . . . . . . . . . . . . . . 26

Timer Recordings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Disc Library . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Editing the Genre of a Title . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Finding a title (movie, program, etc.) by using the Sort Feature . . . . . . . . . . . . .28

Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Editing DVD+RW discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Using the Split Title Feature to Copy Camcorder Videocassette Tapes to Disc .31

Editing tiles using the Hide Chapter Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

Chapter 4: Playing Discs

Regional Coding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

Types of discs you can play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

How to Load and Play Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Using Different Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Search Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Playback Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Using the On-Screen Info Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Time Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Selecting a Title on DVDs or a Track on Audio CDs or VCDs . . . . . . . . . . . . . . . 36

Chapter Icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Subtitle Icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Repeat Icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

Audio Icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Camera Angle Icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Play Mode Icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

IntroScan (Audio CD only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

PlayBack Control (PBC), Video CD only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Playing mp3 and/or JPEG ﬁ les . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

Musical Slide Show: Playing JPEG and mp3 ﬁ les at the same time . . . . . . . . . . . . . . .40

Chapter 5: The Menu System

Overview of the Menu System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

The Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

Watch TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Play Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Disc Title Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Player Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Playlist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Disc Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Autoplay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Screen Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Angle Icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Disc Library . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Timers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Parental Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Lock/Unlock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Rating Limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Unrated Titles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46

System Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46

Digital Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

SRS/TruSurround . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46

Black Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Display Dimmer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46

Audio Broadcast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

AutoClock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46

Recording Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Recording Quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

Smart Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

Disc Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Languages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

Subtitles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

Disc Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Interactive Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Channel Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Clock Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Channel List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

Chapter 6: Additional Information

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50

Handling Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53

Maintenance of Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53

Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

Copying content from a DVD+R or DVD+RW disc to a VCR videocassette . . . . . . . . 56

Copying content from a VCR videocassette to a DVD+R or DVD+RW disc . . . . . . . . 57

Chapter 1: Connections and Setup

Types of Discs

DVD+Rewritable

DVD+R

RECORDING: TYPES OF DISCS YOU CAN USE FOR RECORDING

DVD+R 2.4x, 4x, or 8x ONLY; DVD+RW 2.4x and 4x ONLY.

NOTES:

It is NOT possible to record on CD-R or CD-RW discs.

IMPORTANT: It is NOT possible to record content that is copy-protected. This is usually true for most pre-recorded DVD discs and most pre-recorded VHS tapes.

PLAYBACK: TYPES OF DISCS YOU CAN PLAY

• DVD discs – DVD movie discs (DVD-ROM); DVD+R; DVD+RW; DVD-RW (must be recorded using video mode or VM); DVD-R

(must be recorded using video mode or VM and must be ﬁ nalized).

Some discs may not be compatible due to laser pickup and disc design.

• CDs (Audio CDs, CD-R, CD-RW) – Audio CDs contain musical or sound content only. mp3 discs are CDs (CD-R or CD-RW)

that contain mp3 ﬁ les. This product also plays CDs that contain JPEG ﬁ les and Multisession CDs.

• Video CD (VCD) and Super Video CD (S-VCD) discs – Like DVD video discs, VCDs contain picture and sound content. The

difference is the amount of information that can be stored on the disc.VCDs typically have lower picture and sound quality than DVD discs. Super Video CDs (S-VCDs) can be used to record up to 70 minutes of digital sound and video, with MPEG-2 standard video and MPEG-1 standard audio—but you must use DVD+R or DVD+RW discs to record on your unit not S-VCD disc compatibility is dependent on which MPEG coding software, disc design software, and disc writer software are used; and the discs themselves.

Things to consider before you connect

Protect components from overheating

• Don’t block ventilation holes on any of the components. Arrange the components so that air can circulate freely.

• Don’t stack components.

• When you place components in a stand, make sure you allow adequate ventilation.

• If you connect an audio receiver or ampliﬁ er, place it on the top shelf.

S-VCDs. Additionally,

Position cables properly to avoid audio interference

• Insert each cable ﬁ rmly into the designated jack.

• If you place components above the TV, route all cables down the side of the back of the TV instead of straight down the middle of the back of the TV.

• If your TV has an antenna that uses 300-ohm twin lead cables, do not coil the cables. Also, keep the twin lead cables away from audio/video cables.

Connection Pictures

Audio/video cables are usually bundled together. For better visibility, the connection pictures in this book show each cable separately (audio left, audio right, and video). Graphics contained within this publication are for representation only.

Unpack the Box

Your DVD recorder came with the following items:

DVD recorder Remote control and

batteries (part number

261387)

DVD

SAT•CABLE TV

VOL

MUTE

CLEAR

OPEN•CLOSE

ZOOM

123

456

7809

INPUT

REVERSE PLAY FORWARD

AGAIN ADVANCELIVE

ON•OFF

RETURN

GO•BACK

ANGLE

TIMER GUIDE

INFO

ANTENNA

PAUSESTOPRECORD

1 set of audio video cables (part number 233086)

S-Video cable (part number 257982) RF Coaxial cable (part

Power cord (part number 218104)

number 221396)

Graphics contained within this publication are for representation only.

Chapter 1: Connections and Setup

Choose Your Connection

There are several ways to connect your DVD recorder. Please use the following chart to determine which connection is best for you. Turn to the appropriate page for speciﬁ c instructions.

Components Cables Needed Connection Go to

SE U A P /

AY L

D W F

VP E R

P TO S

D R

O C E R

E S O L

C /

N E P O

+ P

I SK /

+ H C

P I K S /

H C

T U P N I

DVD Recorder

S U A P /

Y LA

D W F

VP E R

P O ST

D R

O C E R

E S O L

C /

N E P O

+ P

I K S /

+ H C

IP K S

-/ H C

T U NP I

DVD Recorder

S U A P /

Y A L P

D W F

V E R

P O T S

D R

O C E R

E S O L

C /

N E P O

+ P

I K S /

+ H C

IP K S /

H C

T U P IN

DVD Recorder

• Coaxial

• Audio/video

• S-Video

• Coaxial

• Audio/video

TV + cable box

• S-Video

Cable Box

• Coaxial

• Audio/video

• S-Video

TV + satellite receiver

Satellite Receiver

To achieve enhanced picture quality, use the S-Video Cable (supplied) to connect your DVD recorder to your TV if your TV has an S-Video jack available.

Connecting an optional audio receiver:

page 8

page 10

page 12

After you connect the DVD recorder to your TV (choose an option above), go to page 14 for general information about connecting an audio/video receiver.

VCR Connection go to pages 56 and 57

If you want to copy content from a DVD to a videotape or vice versa, go to page 56 and 57 for general information.

Note: You can’t transfer copy protected content.

Graphics contained within this publication are for representation only.

Chapter 1: Connections and Setup

Explanation of Input Jacks and Cables

This section describes the jacks and cables you can use to make connections (only a coaxial cable, an S-Video cable, and a set of audio/video cables are packed with your DVD recorder—you can purchase other cables by calling 1-800-338-0376, order online at www.rca.com, or go to your local electronics store). There are several ways to connect your unit to your TV depending upon the cables you have and the jacks that are on the back of your TV.

Different jacks and cables provide a different level of performance. It’s important to remember, we’re talking about degrees of picture improvement for comparison. If your TV has Component jacks (Y, Pb, Pr), S-VIDEO, and composite video (often color-coded yellow and grouped with Audio Left and Right jacks that are white and red); Component (Y, Pb, Pr), would be considered excellent, S-Video would be very good, and the composite video jack (yellow) would be considered good.

Component Video (Y, Pb, Pr) Jacks and Cables

S-VIDEO

The Y, Pb, Pr jacks provide optimum picture quality because the video is separated into three signals (two signals are dedicated to the color portion of the image, and the other signal is dedicated to the black and white part of the image).

To ensure maximum picture quality, use three video-grade cables (not supplied) for the connection. You can purchase bundled component video cables (not supplied) that are color-coded to match the Y, Pb, Pr jacks (red, green, and blue). Component Video Input jacks are usually found on high-end TVs, such as HDTVs; multimedia monitors; and some of the “ﬂ at” LCD and Plasma TVs or monitors.

Notes:

Also, remember to connect the left and right audio cables because the Y, Pb, Pr jacks and cables carry only the picture signal, not the sound.

S-Video Jacks and Cables

The S-Video (separate video) jack provides better picture quality than a composite video jack (sometimes labeled VIDEO and color-coded yellow on TVs) because S-Video keeps the color part of the picture separate from the black and white part of the picture. If your TV has an S-VIDEO jack, connect the DVD recorder to the TV with an S-Video cable for a better quality picture. One S-Video cable is supplied with your unit.

Note: Remember to connect the left and right audio cables because the S-Video cable carries only the picture signal, not the sound.

INPUT

VIDEO

AUDIO

Audio/Video Jacks and Cables (RCA-type)

Video

The basic Video jack (usually color-coded yellow) is also referred to as composite video. Composite video doesn’t keep color information separated (like S-Video), but it’s better than the video quality you get from an RF coaxial cable (the type used to connect a cable signal or off-air antenna).

Audio

These jacks are used to send the audio from the disc you’re playing in the DVD recorder to the TV. The audio jacks and cables (supplied) are often color-coded (red for right audio, and white for left audio). You must connect audio cables to the AUDIO L and R jacks on the unit and the corresponding Audio Input Jacks on the TV no matter which Video jack you connect (VIDEO; S-VIDEO; Y, Pb, Pr).

Note: If your TV has only one input for audio (mono), connect it to the left (white L/Mono) audio jack on the DVD recorder and don’t connect the right audio part of the cable.

Graphics contained within this publication are for representation only.

Chapter 1: Connections and Setup

S-VIDEO

COMPONENT VIDEO OUT

INPUT

VIDEO

AC IN

AUDIO PROG. SCAN

OFF

Back of the DVD Recorder

The back of your recorder might look a little overwhelming at ﬁ rst. This section explains what goes where and why. There are two sets of jacks on the back of your unit— INPUT jacks and OUTPUT jacks.

Each jack is explained individually below, but the basic idea is about sending and receiving information to be played on or through your DVD recorder and displaying that information on your TV screen.

INPUT The cables connected to INPUT jacks bring the signal INTO the DVD recorder, such as the cable signal (programming) from the cable company or satellite programming from a satellite receiver.

OUTPUT The cables connected to the OUTPUT jacks are sending the signal from the DVD recorder OUT TO your TV so you can see it on the screen. The correct cables must be connected to the DVD recorder’s Output jacks and the corresponding Input Jacks on the TV so you can see the program on the TV. You must also tune the TV to the correct channel, called a Video Input Channel (for details, go to page 18).

OUTPUT

DIGITAL

VIDEO

AUDIO OUT

OUT

AUDIO

COAXIAL

OPTICAL

CH3

INPUT

CABLE/ANTENNA

OUTPUT

CH4

Explanation of Jacks (from left to right)

AC-IN – This is where you attach the power cord.

PROG. SCAN switch – If you’ve connected your DVD recorder to a TV that uses progressive scanning to display the image via the Y, Pb, Pr jacks, turn the switch to

the “on” position for progressive scan playback of DVD discs. Typically, only some High Deﬁ nition Televisions and high-end multimedia monitors use progressive scanning. Leave the switch in the OFF position for S-VIDEO or regular VIDEO (yellow) connections.

Note: If you turn the PROG SCAN switch on, and your TV isn’t capable of progressive scanning you won’t see a clear picture on the TV screen. Additionally, when playing DVDs you won’t see any picture—press STOP (the main menu appears) and turn the PROG SCAN switch to the OFF position. Try playing the disc again.

INPUT: These jacks receive audio and video from a compatible component, such as a satellite receiver. Another set of Input Jacks (INPUT 2) are on the front of the DVD recorder for temporarily connecting components such as a camcorder or a video game unit.

VIDEO: Color coded yellow, the video cable you use with this jack provides better quality than an RF Coaxial cable but isn’t as good as S-Video. Connect corresponding video cable to a compatible component such as a satellite receiver or cable box.

AUDIO L (left): Color coded white, connect corresponding audio cable to a compatible component such as a satellite receiver or cable box.

AUDIO R (right): Color coded red, connect corresponding audio cable to a compatible component such as a satellite receiver or cable box.

COMPONENT VIDEO OUTPUT (Y, Pb, Pr): Some high-end TVs and monitors have Component Video Input jacks. The cables that send the video signal through

these Output Jacks provide the highest resolution because the video signal is divided into 3 separate parts (cables not supplied with DVD recorder). As with VIDEO and S-VIDEO, COMPONENT VIDEO (Y, Pb, Pr) only carries the picture signal so you need to connect the audio cables so you’ll hear the sound. If your TV has COMPONENT INPUT jacks, use three video grade cables to connect the DVD recorder to these jacks on the TV to get the best picture quality. However, make sure you also connect another video cable (either a RF coaxial cable to the CABLE/ANTENNA OUTPUT jack; the yellow cable to the VIDEO Output jack; or an S-Video cable to the S-VIDEO OUT jack) because you can only use Component Video for DVD Playback.

S-VIDEO

IN: If your satellite receiver or cable box has an S-VIDEO output jack, connect the S-Video cable to this jack because it provides better picture quality than standard

video (the yellow jack).

OUT: If your TV has an S-Video jack, connect an S-Video cable to the TV’s S-VIDEO jack and to this S-VIDEO OUT jack on the DVD recorder to achieve better picture quality than standard video (the yellow jack).

Graphics contained within this publication are for representation only.

continues on next page…

Chapter 1: Connections and Setup

S-VIDEO

COMPONENT VIDEO OUT

INPUT

AC IN

VIDEO

AUDIO PROG. SCAN

OFF

OUTPUT: These jacks send the content (audio and video) from your DVD recorder OUT to the TV so you can see it on the TV screen and hear it through the TV’s speakers.

VIDEO: Color coded yellow, the video cable you use with this jack provides better quality than an RF Coaxial cable but isn’t as good as S-Video.

AUDIO L (left): Color coded white, connect corresponding audio cable to TV’s Audio Left Input Jack.

AUDIO R (right): Color coded red, connect corresponding audio cable to TV’s Audio Right Input Jack.

DIGITAL AUDIO COAXIAL OUT: If you have a Dolby Digital or DTS receiver or decoder with a Digital Audio Coaxial Input jack, you can achieve enhanced sound quality by connecting a digital coaxial cable (not supplied). This is an RCA-type cable, not a black coaxial cable.

OUTPUT

DIGITAL

VIDEO

AUDIO OUT

OUT

AUDIO

COAXIAL

OPTICAL

CH3

INPUT

CABLE/ANTENNA

OUTPUT

CH4

DIGITAL AUDIO OPTICAL OUT: If you have a Dolby Digital or DTS receiver or decoder with a Digital Audio Optical Input jack, you can achieve enhanced sound quality by connecting a digital optical cable (not supplied).

CH3/Ch4 Switch This switch is also found on VCRs—it corresponds to the TV channel you would use to watch a DVD if you only have your TV connected to the DVD recorder with an RF Coaxial Cable via the CABLE/ANTENNA OUTPUT jack (if the switch is set to CH3, you would tune the TV to channel 3). However, the connections illustrated in the User’s Guide show a preferred connection using audio/video cables or an S-Video cable.

CABLE/ANTENNA INPUT: Connect an RF Coaxial cable from an off-air antenna, cable box, or cable outlet to this jack. The cable is sending the programming from the source to the DVD recorder.

CABLE/ANTENNA OUTPUT: Connect an RF Coaxial cable (provided) to this jack and to the Cable/Antenna Input jack on your TV.

Note: Make sure you connect regular audio cables in addition to connecting a Digital Audio cable because you can only use the DIGITAL AUDIO connection for DVD Playback.

Graphics contained within this publication are for representation only.

Chapter 1: Connections and Setup

Front of the DVD Recorder

ON/STANDBY – Turns the DVD recorder on and off.

STOP – Stops playback and/or recording.

PLAY/PAUSE – Starts playback of a disc. Pauses recording or playback.

REV (reverse) – Searches backwards through the disc.

FWD (forward) – Searches forwards through a disc.

REC (record) – Records content to a DVD disc (DVD+R or DVD+RW discs only).

OPEN/CLOSE – Opens and closes the disc tray.

INPUT – Just like a TV has Video Input Channels (page 18), the DVD recorder has one Video Input Channel for each set of INPUT jacks. The Video Input Channel is the

“channel” to which you tune the unit so you can see the picture and hear the sound that’s coming from the component that is connected to the DVD recorder’s INPUT jacks. For example, if you connected your camcorder to the Audio and Video Input jacks on the front of the DVD recorder, you would press the INPUT button until INPUT 2-Front appears to see what the camcorder is playing on the TV.

CH-/SKIP- (channel down/skip reverse) – Goes to the previous channel in the channel list when you’re watching TV. When playing a disc, goes to the beginning of the current chapter or track unless you’re within the ﬁ rst minute of a chapter or the ﬁ rst 15 seconds of a track—then, you’ll skip to the beginning of the preceding chapter or track.

CH+/SKIP+ (channel up/skip forward) – Goes to the next channel in the channel list when you’re watching TV. When playing a disc, goes to the beginning of the next title, chapter, or track on a disc (in effect,“skipping” the title, chapter, or track).

Front Input Jacks:

INPUT 2: Audio/Video jacks – These Input Jacks are provided for convenience when you are connecting a temporary component, such as a camcorder.

S-VIDEO – If a component you’re connecting, such as a camcorder, has an S-Video Output jack connect it to this jack for picture quality that is better than regular

video (yellow). Remember, you still have to connect audio cables to hear sound.

Graphics contained within this publication are for representation only.

Chapter 1: Connections and Setup

COMPONENT VIDEO OUT

INPUT

VIDEO

AC IN

DVD Recorder

AUDIO PROG. SCAN

OFF

S-VIDEO

OUTPUT

DIGITAL

VIDEO

AUDIO OUT

OUT

AUDIO

COAXIAL

OPTICAL

CH3

CH4

INPUT

CABLE/ANTENNA

OUTPUT

In from cable or antenna

S-VIDEO

VIDEO L

INPUT1

S-VIDEO

INPUT2

The back of your TV might look different than the one pictured here.

Details about the different kinds of cables used to connect your DVD recorder are on page 4.

CABLE/ANTENNA

To watch one program while you record another:

Tune the TV to its Input 1 channel or Vid 1 channel

Tune the DVD recorder to the channel you want to record, and press RECORD.

Use the buttons on the TV (or the TV’s remote control*) to tune the TV to the channel you want to watch.

To play a disc:

Tune the TV to its Input 1 channel or Vid 1 channel.

If you need help ﬁ nding your TV’s various Video Input Channels, go to page 18.

* The remote control packed with your DVD recorder is capable of being programmed to operate many brands and models of TVs and VCRs. For instructions, go to page 21. If the remote operates your TV, press TV and INPUT to access the Video Input Channel.

Graphics contained within this publication are for representation only.

RF Coaxial cable

Red

Yellow

White

Audio video cables are usually colorcoded red, white, and yellow.

If your TV has an S-Video jack, connect the S-Video cable (supplied). S-Video provides better video quality than composite video (the yellow jack).

Chapter 1: Connections and Setup

Connection: DVD recorder + TV

1. Connect the signal (cable or antenna):

Note: Depending upon how you currently have your TV connected, you’ll have to disconnect the cable from your TV’s Antenna Input jack (sometimes labeled CABLE/ANTENNA) or your VCR’s Input jack before you connect the cable as explained below.

Cable service: If you have cable service via a cable that comes out of the wall, connect the end

of that cable to the CABLE/ANTENNA INPUT jack on the DVD recorder.

Note: If you have a cable box, go to page 10 for connection instructions.

Off-air antenna: If you use an off-air antenna to get TV programming, connect the antenna’s RF

coaxial cable to the CABLE/ANTENNA INPUT jack on the DVD recorder.

2. Connect the DVD recorder to the TV

You need to connect cables from the DVD recorder’s OUTPUT jacks to the TV’s INPUT jacks in order to see the content from the DVD recorder.

Use the RF Coaxial cable that was packed with your unit, and connect one end to the CABLE/

ANTENNA OUTPUT jack on the DVD recorder. Connect the other end to the Cable/Antenna

Input jack on the back of your TV (sometimes labeled CABLE/ANTENNA).

3. If you want to be able to record one TV program while you watch a different program, you need

to connect the audio/video cables in addition to connecting the RF Coaxial cable described in

Step 2.

3a. Connect the audio cables.

A set of audio/video cables was packed with your DVD recorder. Connect the audio cables

to the OUTPUT AUDIO L (left – white) and R (right – red) jacks on the back of your DVD recorder, and to the corresponding Audio Input jacks on your TV (sometimes labeled AUDIO IN L and R).

3b. Connect the video cable. The cables you use for the video determine the quality of the

picture you’ll see on your TV when you’re playing DVDs. For more information about cables and signal quality, go to page 4. Connect the video cable (yellow) to the OUTPUT VIDEO jack on the back of your DVD recorder, and to the Video Input jack on your TV (sometimes labeled VIDEO IN).

3c. If your TV has an S-Video jack, use the S-Video cable (supplied). Connect one end of the

S-Video cable (supplied) to the S-VIDEO IN jack on the back of the TV and the other end to the S-VIDEO OUT jack on the back of the DVD recorder.

COMPONENT OUT

Y, Pb, Pr (not shown) If your TV has Component Input Jacks (Y,

Pb, Pr), you can achieve even greater picture quality by connecting the DVD recorder to the TV using these jacks (COMPONENT VIDEO OUTPUT, Y, Pb, Pr on the DVD recorder). For more explanation, go to page 4. Component Video cables not supplied with the unit.

Notes:

If your TV is capable of progressive scan, connect the DVD recorder to the TV using the COMPONENT VIDEO OUTPUT jacks, and slide the PROG SCAN switch to the ON position to see DVD titles (movies) in progressive scan format. If you need more explanation, go to page 5.

4. Attach the AC power cord to the unit.

5. Insert the other end of the AC power cord into an AC outlet (or power strip).

Go to page 15

Graphics contained within this publication are for representation only.

Chapter 1: Connections and Setup

S-VIDEO

COMPONENT VIDEO OUT

INPUT

VIDEO

AC IN

DVD Recorder

AUDIO PROG. SCAN

OFF

OUT

AUDIO

OUTPUT

VIDEO

DIGITAL

AUDIO OUT

COAXIAL

OPTICAL

The back of your TV and/or Cable Box might look different than the ones pictured here.

INPUT

CABLE/ANTENNA

OUTPUT

CH4

CH3

CABLE INCABLE OUT

S-VIDEO

VIDEO L

INPUT1

S-VIDEO

INPUT2

Notes about cable boxes:

If you have questions about using a cable box with the DVD recorder, consult your cable company. RCA can only provide general instructions because cable services and cable boxes differ in various areas. This connection only shows a basic RF Coaxial Cable connection, your cable box may have Audio Video or S-Video jacks.

CABLE/ANTENNA

Cable Box

If you connect your components as described, you must access different Video Input Channels on your TV to see programming. If you don’t know how to access Video Input Channels on your TV, go to page 18 for help. A general explanation, based on the connection shown above, follows:

To watch one program while you record another:

Tune the TV to its Input 1 channel or Vid 1 channel.

Tune the DVD recorder to the cable box channel (usually channel 2, 3, or 4).

Use the channel buttons on the cable box to tune to the channel you want to record. Press the RECORD button on the DVD recorder.

Use the buttons on the TV (or the TV’s remote control*) to tune the TV to the channel you want to watch.

To play a disc Tune the TV to its Input 1 channel or Vid 1 channel.

If you need help ﬁ nding your TV’s various Video Input Channels, go to page 18.

* The remote control packed with your DVD recorder is capable of being programmed to operate many brands and models of TVs. For instructions, go to page 21. If the remote operates your TV, press TV and INPUT to access the Video Input Channel.

Graphics contained within this publication are for representation only.

RF Coaxial cable

Red

Yellow

White

Audio video cables are usually color-coded red, white, and yellow. Red= right audio; White = left audio; Yellow = video.

If your TV has an S-Video jack, connect the S-Video cable (supplied). S-Video provides better video quality than composite video (the yellow jack).

Chapter 1: Connections and Setup

Connection: DVD recorder + TV + Basic Cable Box

1. Connect the cable box signal.

Note: Before you connect the DVD recorder, you’ll need to disconnect some of the cables ﬁ rst in order to reconnect them.

1b. Connect the RF Coaxial cable that is connected to the cable box’s Output jack (sometimes labeled CABLE OUT) to the

CABLE/ANTENNA INPUT jack on the back of the DVD recorder.

2. Connect the DVD recorder to the TV

You need to connect cables from the DVD recorder’s OUTPUT jacks to the TV’s INPUT jacks in order to see the content from the

DVD recorder (whether it’s a TV program or a disc you’re playing).

Use the RF Coaxial cable that was packed with your unit, and connect one end to the CABLE/ANTENNA OUTPUT jack on the

DVD recorder. Connect the other end to the Cable/Antenna Input jack on the back of your TV (sometimes labeled CABLE/ ANTENNA).

3. If you want to be able to record one TV program while you watch a different program, you need to connect the audio/video cables

(provided) in addition to connecting the RF Coaxial cable described in Step 2a.

3a. Connect the audio cables.

A set of audio/video cables was packed with your unit. Connect the audio cables to the OUTPUT AUDIO L (left – white) and

R (right – red) jacks on the back of your DVD recorder, and to the corresponding Audio Input jacks on your TV (sometimes labeled AUDIO IN L and R).

3b. Connect the video cable. The cables you use for the video determine the quality of the picture you’ll see on your TV when

you’re playing DVDs. For more information about cables and signal quality, go to page 4.

Connect the video cable (yellow) to the OUTPUT VIDEO jack on the back of your DVD recorder, and to the Video Input jack

on your TV (sometimes labeled VIDEO IN).

3c. S-VIDEO If your TV has an S-VIDEO jack, connect one end of the S-Video cable (supplied) to the S-VIDEO IN jack on the

back of the TV and the other end to the S-VIDEO OUT jack on the back of the DVD recorder.

COMPONENT OUT

greater picture quality by connecting the unit to the TV using these jacks (COMPONENT VIDEO OUTPUT, Y, Pb, Pr on the DVD recorder). For more explanation, go to page 4. Component Video cables not supplied with the unit.

Notes:

Y, Pb, Pr (not shown) If your TV has Component Input Jacks (Y, Pb, Pr), you can achieve even

4. Attach the AC power cord to the unit. Insert the other end of the AC power cord into an AC outlet (or power strip).

Go to page 15

Graphics contained within this publication are for representation only.

Chapter 1: Connections and Setup

AUDIO OUT

PHONE JACK

VIDEO

S-VIDEO

OUT TO TVIN FROM ANT

LOW SPEED DATA

SATELLITE DISH ANTENNA

SATELLITE IN

AC IN

DVD Recorder

Satellite Receiver

OFF

PROG. SCAN

S-VIDEO

OUT

AUDIO

OUTPUT

VIDEO

AUDIO OUT

DIGITAL

COAXIAL

OPTICAL

INPUT

CABLE/ANTENNA

OUTPUT

CH4

CH3

COMPONENT VIDEO OUT

INPUT

VIDEO

AUDIO

The back of your satellite receiver might look different than the one pictured here.

S-VIDEO

VIDEO L

INPUT1

S-VIDEO

INPUT2

Details about the different kinds of cables used to connect your DVD recorder are on page 4.

To watch TV (satellite programming) with the DVD recorder turned on:

To watch TV (satellite programming) with the DVD recorder turned off:

CABLE/ANTENNA

The back of your TV might look different than the one pictured here.

Tune the TV to its Input 1 channel or Vid 1 channel

Tune the DVD recorder to the INPUT 1 channel (press the INPUT button on the remote).

Tune the satellite receiver to the channel you want to watch.

Tune the TV to its CABLE/ANTENNA INPUT channel (usually channel 2, 3, or 4).

Tune the satellite receiver to the channel you want to watch.

To play a disc: Tune the TV to Input 1 channel or Vid 1 channel.

Graphics contained within this publication are for representation only.

RF Coaxial cable

Red

Yello

White

Audio video cables are usually color-coded red, white, and yellow. Red= right audio; White = left audio; Yellow = video.

Chapter 1: Connections and Setup

Connection: DVD recorder + TV + Satellite Receiver

The following instructions enable you to record the programs from your satellite receiver. Because the jack conﬁ guration and labels

on different satellite receivers and televisions, the steps provided are general guidelines. Consult your Satellite Receiver and/or

vary Television User’s Guides for additional information. If you have cable TV service AND satellite TV, you can connect the cable signal to the DVD recorder’s CABLE/ANTENNA INPUT jack.

1. Satellite signal: Leave the cable in place that comes from the satellite dish and goes to the satellite receiver.

2. Connect the satellite receiver to the DVD recorder

2a. Connect a coaxial cable to the satellite receiver’s OUT TO TV jack, and to the CABLE/ANTENNA INPUT jack on the

DVD recorder.

2b. Connect audio cables (red and white) to the satellite receiver’s output jacks [sometimes labeled Audio Left (white) and Audio

Right (red)]. Connect the other ends of these cables to the corresponding INPUT AUDIO L and AUDIO R jacks on the back of the DVD recorder.

2c. Connect the video cable (yellow) to the Video Output jack on the satellite receiver (sometimes labeled VIDEO) to the INPUT

VIDEO jack on the back of the DVD recorder.

If your satellite receiver, has an S-VIDEO OUT jack, connect an S-Video cable to that jack and to the S-VIDEO IN jack on the

DVD recorder for increased picture quality (not shown in connection diagram).

3. Connect the DVD recorder to the TV

You need to connect cables from the DVD recorder’s OUTPUT jacks to the TV’s INPUT jacks in order to see the content from the

DVD recorder (whether it’s a satellite program or a disc you’re playing).

Connect an RF coaxial cable to the DVD recorder’s CABLE/ANTENNA OUTPUT jack and to the TV’s Antenna Input jack

(sometimes labeled CABLE/ANTENNA).

3a. Connect the audio cables.

A set of audio/video cables was packed with your DVD recorder. Connect the audio cables to the OUTPUT AUDIO L (left

– white) and R (right – red) jacks on the back of your DVD recorder, and to the corresponding Audio Input jacks on your TV (sometimes labeled AUDIO IN L and R).

3b. Connect the video cable. The cables you use for the video determine the quality of the picture you’ll see on your TV when

you’re playing DVDs. For more information about cables and signal quality, go to page 4.

Connect the video cable (yellow) to the OUTPUT VIDEO jack on the back of your DVD recorder, and to the Video Input jack

on your TV (sometimes labeled VIDEO IN).

3c. S-VIDEO If your TV has an S-VIDEO input jack, connect one end of the S-Video cable (provided) to the

S-VIDEO input jack on the back of the TV and the other end to the S-VIDEO OUT jack on the back of the DVD recorder.

COMPONENT OUT Y, Pb, Pr (not shown) If your TV has Component Input Jacks (Y, Pb, Pr), you can achieve even

greater picture quality by connecting the DVD recorder to the TV using these jacks (COMPONENT VIDEO OUTPUT, Y, Pb, Pr on the DVD recorder). For more explanation, go to page 4. Component Video cables not supplied with the DVD recorder.

Notes:

4. Attach the AC power cord to the unit. Insert the other end of the AC power cord into an AC outlet (or power strip).

Go to page 15

Important

You can’t watch one satellite program and record another satellite program at the same time.

This connection scenario illustrates a basic connection—you can achieve better video quality by connecting the components with S-Video or Component Video options, depending upon the cables you have and the jacks available on your components. See page 4 for more information about jacks and cables.

Graphics contained within this publication are for representation only.

Chapter 1: Connections and Setup

COMPONENT VIDEO OUT

INPUT

VIDEO

AC IN

AUDIO PROG. SCAN

OFF

S-VIDEO

OUTPUT

DIGITAL

VIDEO

AUDIO OUT

OUT

AUDIO

COAXIAL

OPTICAL

CH3

INPUT

CABLE/ANTENNA

OUTPUT

CH4

DVD Recorder

OUTPUT AUDIO L (left) and R (right)

DIGITAL AUDIO OUT

Consult the manual that came with your receiver to connect it properly.

Advanced Audio Connection Information

Both Dolby Digital® and DTS® are audio formats used to record 5.1-channel audio signals onto the digital track of ﬁ lm (while the ﬁ lm is being made). Both of these formats provide up to six separate channels: left, right, center, left rear, right rear, and common subwoofer. The disc will play 5.1-channel sound only if you’ve connected a DTS or Dolby Digital receiver or decoder, and if the disc is encoded in the Dolby Digital or DTS format.

Please Read This Before Using the DIGITAL AUDIO Jack!

This unit’s digital audio output jack is designed for a connection to a Dolby Digital or DTS receiver or decoder. Older digital equipment may not be compatible with the Dolby Digital bitstream. Such a connection can create a high level of noise that may be harmful to your ears, and could damage headphones or speakers. It is important to choose the correct Digital Output setting in the System Options menu. For more information, go to page 46.

Connecting your DVD Recorder to an audio/video receiver

You’ll need to consult instructions that came with your audio video receiver in order to connect it properly. The information below provides general

guidelines for the DVD recorder’s Audio Output Jacks.

For a basic connection, connect the left and right audio cables to your audio/video receiver and to the OUTPUT AUDIO L (left – white) and R (right – red) jacks on the back of your DVD recorder.

If you have a Dolby Digital or DTS receiver, connect an optical cable (SPDIF) to the DIGITAL AUDIO OUT jack on the DVD recorder and the Digital Audio Input jack on the receiver (cables not supplied with DVD recorder). You must also adjust the Digital Output setting (go to page 46 for information).

Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

DTS is a registered trademark of Digital Home Theater Systems, Inc.

Graphics contained within this publication are for representation only.

Chapter 1: Connections and Setup

Install Batteries in the Remote

1. Remove the battery compartment cover on the back of the remote.

2. Insert new batteries. Match the polarities (+ and –) on the batteries with the diagram on the remote.

3. Put the battery compartment cover back on the remote.

Important Battery Information

• If you’re not going to use the remote for a month or more, be sure to remove the batteries because they can leak and cause damage.

• Dispose of batteries in the proper manner, according to federal, state, and local regulations.

• Any battery may leak electrolyte if mixed with a different battery type, if inserted incorrectly, if all batteries are not replaced at the same time, if disposed of in ﬁ re, or if an attempt is made to charge a battery not intended to be recharged.

• Discard leaky batteries immediately. Leaking batteries can cause skin burns or other personal injury.

Point the Remote in the Right Direction and Put it in DVD Recorder Mode

When you want the remote to operate the DVD recorder, point the remote at the DVD recorder, not the TV. The remote has to be pointed in the correct direction and toward the correct component in order for the remote control’s signal to communicate with the sensor on the component. Make sure there is a clear path between the remote control and the component you want to operate, so the signal isn’t blocked.

Make sure the remote is in DVD mode—press the DVD button.

Turn on the TV and DVD Recorder

1. Turn on the DVD recorder—press the DVD button on the remote.

2. Turn on the TV and tune it to the correct Video Input Channel—if you have an RCA, GE, or Proscan TV, press the TV button on the remote (if the TV doesn’t turn

on, press the ON•OFF button) and then press the INPUT button on the remote until you get to the Video Input Channel that matches how the DVD recorder is connected to the TV.

If you have another brand of TV, turn on the TV and tune the TV to the correct Video Input Channel (if you don’t know how to access the Video Input Channel on

your TV, go to page 18 for help).

Note: You can program your remote to operate most brands of remote controllable TVs. Instructions are on page 21.

DVD

SAT•CABLE TV

VOL

Left

CLEAR

arrow button

Down arrow button

Use the arrow buttons on the remote to move through on-screen menus and highlight different options. Press the OK button to select a menu item that is highlighted.

OPEN•CLOSE

ZOOM

123

7809

INPUT

ON•OFF

RETURN

MUTE

GO•BACK

Up arrow button

Right arrow

ANGLE

TIMER GUIDE

INFO

button

OK button

ANTENNA

English

Francois Espanol

Complete the Interactive Setup

The next few pages step you through the series of screens that will appear the ﬁ rst time you turn on your DVD recorder.

Use the remote control to follow the on-screen instructions. The arrow buttons move the on-screen highlight in the corresponding directions on the screen (up, down, left, right).

Press the OK button to select a highlighted item.

Notes:

You can access the setup screens from the main menu. If you move, get a different program provider for TV shows, or change your connections, you’ll need to complete the Interactive Setup again.

If you don’t see the Language selection screen (below) the ﬁ rst time you turn on the DVD recorder, make sure you’ve tuned your TV to the Video Input Channel that corresponds to the way you’ve connected the TV to the DVD recorder. If you need help, go to page 18.

1) Select on-screen menu language

Make sure the remote is in DVD mode (press the DVD button). If you want the on-screen menus

to appear in English, press the OK button on the remote control. If you prefer another language, press the arrow down button until that language is highlighted. Press OK to select the language. Next, the connection screen appears.

Note: If you don’t see the Language selection screen the ﬁ rst time you turn on the DVD recorder, make sure you’ve tuned your TV to the Video Input Channel that corresponds to the way you’ve connected the TV to the DVD recorder. If you need help, go to page 18.

Graphics contained within this publication are for representation only.

Chapter 1: Connections and Setup

Antenna-Cable

Done

Searching channels. 35% complete 2 channels found Please wait…

Antenna-Cable

2) Select the Signal that’s connected to the CABLE/ANTENNA INPUT jack

Completing this information lets the DVD recorder know what program signals are being sent to

it. Choose the type of signal that is connected to the CABLE/ANTENNA INPUT jack. Press the right arrow button to access the choices:

Note: If you’ve connected a cable box or satellite receiver to the CABLE/ANTENNA INPUT jack, turn on the cable box or satellite receiver and tune to the channel you want to record before completing this step.

Cable-Antenna (cable service)

Antenna Only (no cable service, just off-air antenna)

Note: If the DVD recorder doesn’t start searching for channels after you’ve selected the type of signal connected to the CABLE/ANTENNA INPUT jack, press the down arrow button to highlight Done and press OK.

3) Channel Search

The DVD recorder automatically scans the signal coming through the cable connected to the

CABLE/ANTENNA INPUT jack and prepares the channel list. The channel list determines what channels appear when you press the CH+ and CH- buttons.

A progress indicator appears on the TV screen. When the Channel Search reaches 100%, press

OK (the Channel List appears). If the Channel List doesn’t appear, check the CABLE/ANTENNA INPUT jack to make sure the cable is connected properly.

Note: If you are using only a cable box or satellite receiver, there will be few, if any, channels in the channel list.

Edit the list of channels found



Ch 02

Ch 03

Ch 04



Select your local time zone:

Eastern

Central Mountain

Should the clock be automatically adjusted for daylight savings time?

4) Channel List

The Channel List contains the channels you tune to when you press the CH+ and CH- (channel

up and channel down) buttons on the remote control. From the Channel List screen, you can delete channels you rarely watch. You’ll still be able to tune to the “deleted” channels directly by using the number buttons on the remote control, but the DVD recorder won’t tune to a channel you delete when you press the CH+/CH- buttons on the remote control.

Press the down arrow button to scroll through the channels. A checkmark in the box next to the

channel means it has been stored in the channel list. Highlight the channel and press OK to check or uncheck the box. You can also label channels by pressing the INFO button.

To skip editing the channel list, press the right arrow button.

5) Time Zone

Use the down arrow button to highlight your time zone, and press OK (the Daylight Savings

Time screen appears).

6) Daylight Savings Time

If you live an area that recognizes Daylight Savings Time, press OK (the DVD recorder’s internal

clock will automatically advance the time by 1 hour in the spring and set the clock back by 1 hour in the fall).

If you live in an area that doesn’t use Daylight Savings Time, press the right arrow button to

highlight No, and press OK.

Ye s

Graphics contained within this publication are for representation only.

Year 2004

Date 04/29 Tue 29-April

Time 01:47 PM

Done

Chapter 1: Connections and Setup

7) Time and Date

Your DVD recorder has an automatic clock, but it may take awhile for the DVD recorder to ﬁ nd

the correct channel for the clock. Therefore, you might want to set up the clock manually here.

Use the number buttons on the remote to enter Year, Date, and Time. To change the AM/PM

setting when you’re entering the Time, press the right arrow button.

Notes: If this screen doesn’t appear, you can set the time later from the main menu—with the remote in DVD mode, press MENU, select Setup, select Installation, select Clock Setup and follow the on-screen instructions.

The DVD recorder is equipped with a clock that automatically keeps the time accurate. If you have any problem with the time being accurate, simply turn off the AutoClock option (page 46). Access the main menu, choose System Options, and then AutoClock. Follow the instructions to disable it, and set the time manually using the Clock Setup menu option that you access via the Setup/Installation menu.

Watch TV

Disc Disc Library

Live - Ch 2

No Disc

1 Library Disc(s)

Watch TV

When the set-up procedure is complete, the main menu appears with the Watch TV menu highlighted. To watch TV, just press the OK button on the remote.

Timers Setup

To watch channels, or video inputs, press OK

10:49 am Thu 17-Mar 2004

What to Expect

Turn on the DVD Recorder to Watch TV

In order to use the features of the DVD recorder, you’ll have to get used to turning on your DVD recorder to watch TV.

You also need to tune the TV to the Video Input Channel—instead of changing channels with the TV’s channel up and channel down buttons, you change channels via the DVD recorder’s channel up and down buttons (or number buttons). The TV stays on the Video Input Channel that corresponds to the Input Jacks on the TV you used to connect the TV to the DVD recorder. If you need help ﬁ nding the TV’s Video Input Channel, go to page 18.

The Main Menu Appears

The main menu appears whenever you turn on the DVD recorder. To watch TV, press the OK button when the Watch TV menu is highlighted. When you change channels, the channel banner appears to give you programming information that is available (for more information, go to page 26).

Changing Channels

You might notice a slight delay when you’re changing channels because the signal goes to the DVD recorder and is then sent out to the TV.

Discs for Recording

Recording to DVD discs is new to many people. There are several different formats of DVD discs. For your DVD recorder, only DVD+R 2.4x, 4x, or 8x and DVD+RW

2.4x and 4x type discs can be used for recording. A DVD+RW disc is “rewritable” which means you can use the disc over and over again (similar to how you use VCR tapes to record). Additionally, DVD+RW discs have many “digital features” for editing the disc’s content. DVD+R discs can only be used one time—you can’t record over existing programs and you must get used to “ﬁ nalizing the disc” in order for other DVD players to be able to play DVD+R discs. Throughout this User’s Guide, you’ll notice that some features and menu options are only available for a speciﬁ c type of disc.

Make sure you use discs from a reputable manufacturer. Many problems encountered when recording (or playing) discs are related to the wide variation in disc quality due to the large number of brands and manufacturers. If you encounter problems with one brand of disc, please try another brand.

Graphics contained within this publication are for representation only.

Chapter 1: Connections and Setup

How to ﬁ nd your TV’s Video Input Channel

In order to see what’s playing on your DVD recorder, you need to tune the TV to the Video Input Channel that corresponds to the Input Jacks on your TV that you used to connect the DVD recorder to the TV. The Video Input Channel(s) varies for different brands and different models of TVs.

RCA, GE, and Proscan TVs

If your brand of TV is RCA, GE, or Proscan, the remote control packed with your DVD recorder will most likely access the TV’s Video Input Channel—with the DVD recorder turned on, press the TV button, and then press INPUT until you see the DVD recorder’s menu on your TV screen.

Other Brands of TVs

Since access to a TV’s Video Input Channel varies from one manufacturer to the next, it’s difﬁ cult to provide speciﬁ c instructions for your particular brand. However, a list of suggestions is provided below.

• Consult the Instruction Manual that came with your TV.

• If you can’t ﬁ nd the information in the manual, or can’t ﬁ nd the manual, review the following list.

• There might be a button on the TV’s remote control that accesses the Video Input Channel (see table below for examples).

• You might select the Video Input Channel from the TV’s menu system.

• You might tune to it by pressing a speciﬁ c channel number (see table below).

• Press the Channel up and/or down buttons on the TV’s remote control (sometimes the Video Input Channel is stored in your TV’s channel list).

Video Input Channel Variations

Button/Switch Button on the Channel on the TV

VIDEO VID1 S-VID 00 93

TV remote Number

SIGNAL LINE INPUT 90 VID 1

VID 1 VID SOURCE 91 VID 2

VID 2 VIDEO AUX 92 INPUT

Next Steps

This chapter is dedicated to connecting your DVD recorder. Choose what you want to do next, and go to the appropriate chapter for instructions.

Chapter 2: The Remote Control (page 19)

A description of each button is in Chapter 2. Additionally, the universal remote control can be programmed to operate many brands and types of components. Go to page 19 for instructions.

Chapter 3: Recording, Playback & Features (page 25)

This chapter tells you how to record and playback programs and how to use the Disc Library.

Chapter 4: Playing Discs (page 32)

If you’re ready to pop in a DVD (or a CD), this chapter explains how different discs function in the DVD recorder and describes the features you can use with different types of discs.

Chapter 5: The Menu System (page 41)

Since this product is multi-functional, there are many on-screen menus to control settings and access features. Chapter 5 describes the menus and why you would want to use them.

Chapter 6: Additional Information (page 49)

If you’re having trouble, go to Chapter 6. It includes troubleshooting information, the product’s warranty, and accessories you might want to purchase.

Graphics contained within this publication are for representation only.

Chapter 2

The Remote Control

• Explanation of the buttons

• Find out if the remote can operate your TV

• Programming the remote to operate your TV

• Programming the remote to operate other components

Graphics contained within this User’s Guide are for representation only. Some of the menu screens, buttons, and display messages might be different in your product than they appear in this book. The on-screen help text provides the most current operational information.

page 19

Chapter 2: The Remote Control

ON•OFF

MUTE

RETURN

GO•BACK

INPUT

ANTENNA

123

7809

VOL

SAT•CABLE TV

DVD

CLEAR

INFO

ANGLE

GUIDE

OPEN•CLOSE

ZOOM

REVERSE PLAY FORWARD

PAUSESTOPRECORD

AGAIN ADVANCELIVE

TIMER

Explanation of Buttons

You can use this remote to operate the DVD recorder, and to access the features available. The remote is also designed to operate most RCA, GE, and Proscan components (TVs and satellite receivers). If you have another brand, you can program the remote control to operate those components (go to page 22 for instructions).

Indicator light

The Universal Remote Control that came with your DVD recorder operates most RCA, GE, and Proscan branded components.

Additionally, the remote is capable of being programmed to operate many other brands and models of TVs, satellite receivers, or cable boxes.

INPUT In DVD recorder mode, accesses the Input Jacks on the recorder (RF ANTENNA/CABLE INPUT, INPUT 1, and INPUT 2 on the front of the

DVD recorder).

LIVE When main menu is on the screen, provides quick access to watch TV.

MENU When you’re not playing a disc, accesses the DVD recorder’s menu. When you’re playing a disc, accesses the disc’s menu, if one is available.

MUTE Lowers the volume to its minimum level. Press again to restore volume.

OPEN•CLOSE Opens and closes the disc tray.

OK When a menu is on the screen, selects the highlighted item.

ON•OFF Turns the DVD recorder on and off. Also turns off compatible components.

PAUSE Pauses disc play or recording.

PLAY Begins disc play.

RECORD Records programming.

REVERSE Searches backward through the disc.

SAT•CABLE Puts the remote in Satellite or Cable mode in order for the remote to operate a satellite receiver or cable box. This remote is capable

of being programmed to operate most brands of satellite receivers and cable boxes. This remote is already programmed to operate RCA, GE, and Proscan brand satellite receivers.

STOP Stops playback or recording.

TIMER/GUIDE Accesses the list of Timer Recordings (the Timer List screen).

TV Puts the remote in TV mode in order for it to operate your TV. This remote is already programmed to operate RCA, GE, and Proscan brand TVs.

This remote is capable of being programmed to operate many brands of TVs.

VOL +/- If your remote is capable of operating your TV, increases and decreases the volume level.

ZOOM Enlarges the image on the screen so you can zoom in on details. To pan and scan after you’ve zoomed in on an image, use the arrow buttons.

The Zoom feature isn’t available on all discs. Typically, it works with DVD discs and CDs with JPEG files.

The descriptions that follow describe how each button works when operating the DVD recorder. Many buttons will perform different functions depending upon the type of disc and menu functions of the disc.

Indicator light Used to indicate status of remote control when programming it to operate other components. Also, indicates when batteries are low by flickering when you press a button on the remote.

0-9 (Number buttons) Use the number buttons to input information such as chapter numbers, track numbers, to make selections on some menu screens, and/or to change channels.

Arrow buttons (up, down, left, right) Use the arrow buttons to highlight options that appear on the screen (the arrow buttons move the highlight in the corresponding directions — up arrow moves the highlight up; left arrow moves the highlight left, etc.).

ADVANCE When playing a disc, moves forward approximately 30 seconds. Not applicable for VCDs or mp3 files.

AGAIN Accesses the Scene Again™ feature—replays the last several seconds (approximately 10) of the DVD disc you’re playing. Not applicable for VCDs or mp3 files.

ANGLE Accesses various camera angles that might have been added to a pre-recorded disc when it was created. Not available on all discs.

ANTENNA In DVD recorder mode, switches between displaying the picture from the DVD recorder or the TV. Allows you to watch pne program while you record another. In SAT•CABLE mode, functions as a Satellite/Receiver button for RCA satellite receivers.

CH + Advances to the next chapter or track when you’re playing discs. Goes to the next channel in the channel list when watching TV.

CH – When playing a disc, goes to the beginning of the current chapter or track, unless you’re within the first minute of a chapter or the first 15 seconds of a track—then you’ll skip to the beginning of the preceding chapter or track. When watching TV, goes to the previous channel in the channels list.

CLEAR Removes on-screen menus and displays.

DVD Turns on the DVD recorder and puts the remote in DVD mode so it operates the DVD

recorder.

FORWARD Searches forward through the disc.

GO BACK Returns you to the previous menu. When watching TV, goes back to the previous

channel.

INFO Displays the on-screen Info Display (for details about the Info Display, go to page 35.)

Graphics contained within this publication are for representation only.

ON•OFF

MUTE

RETURN

GO•BACK

INPUT

ANTENNA

123

7809

VOL

SAT•CABLE TV

DVD

CLEAR

INFO

ANGLE

GUIDE

OPEN•CLOSE

ZOOM

REVERSE PLAY FORWARD

PAUSESTOPRECORD

AGAIN ADVANCELIVE

TIMER

ON•OFF

MUTE

RETURN

GO•BACK

INPUT

ANTENNA

123

7809

VOL

SAT•CABLE TV

DVD

CLEAR

INFO

ANGLE

GUIDE

OPEN•CLOSE

ZOOM

REVERSE PLAY FORWARD

PAUSESTOPRECORD

AGAIN ADVANCELIVE

TIMER

ON•OFF button

TV button

Chapter 2: The Remote Control

Find out if the remote can operate your TV

This remote control is designed to operate most RCA, GE, and Proscan TVs.

1. Press the TV button.

2. Press the ON•OFF button (if the TV turns on or off, this remote will operate the TV).

3. If that doesn’t work, you can try programming the remote by following the instructions below.

Programming the remote to operate your TV

There are two ways to program this remote control to operate other brands of TVs: Direct Entry and Automatic Code Search (both methods are described below).

Direct Entry

1. Turn on the TV.

2. Look up the brand and code number(s) from the list on page 23.

3. Press and hold the TV button on the remote.

4. Keep holding down the TV button, and enter the ﬁ rst code from the code list for your brand (page 23).

5. Release the TV button.

6. Point the remote toward the TV and press the ON•OFF button to see if the TV turns off. If it doesn’t, press the TV button and then press ON•OFF. If you get no response, follow steps 1-5 again, but enter the next code from the code list for your brand of television.

• If you try all the codes for your TV brand and none work, try the Automatic Code Search method. If Automatic Code Search doesn’t work, the remote is not compatible with your TV.

Note: This remote may not be compatible with all brands and models of televisions. It may also not operate all the functions of your TV.

ON•OFF button

TV button

Indicator light

Automatic Code Search

The Automatic Code Search method tests all of the codes for a specific component button. If you want to stop the automatic code search without programming any of your components, press CLEAR until the indicator on the remote turns off.

1. Turn on the TV.

2. Press and hold the TV button. While you continue pressing the TV button, press and hold the ON•OFF button until the indicator light on the remote turns on— then release both buttons.

3. Point the remote at the TV. Press and release PLAY, then wait 5 seconds or until the indicator on the remote stops ﬂ ashing.

At this point the remote is searching for the correct code to program (you’ll know it’s found the

correct code when the TV turns off, go to step 4). If, after 5 seconds, the TV doesn’t turn off, press PLAY again to tell the remote to search the next set of codes.

Continue pressing PLAY until the TV turns off or you have searched through all of the codes.

The component buttons ﬂ ash when all the codes have been searched, the TV button turns off, and the remote exits Automatic Code Search. If the TV does not turn off after trying all the codes, the remote can’t be programmed to operate your brand of TV— you’ll have to use the remote that came with your TV.

4. When the TV turns off, the remote has found the proper code. Press and release REVERSE, then

PLAY button

wait 2 seconds. Repeat this step until the TV turns back ON.

5. To ﬁ nish, press and hold STOP until the indicator on the remote turns off.

REVERSE button

STOP button

Graphics contained within this publication are for representation only.

Chapter 2: The Remote Control

Programming the remote to operate a satellite receiver or cable box

This remote is already programmed to operate most RCA, GE, and Proscan satellite receivers — just press the SAT•CABLE button. If you have another brand or you need to program the SAT•CABLE button to operate a cable box, you need to program the remote.

There are two ways to program this remote control to operate other brands of satellite receivers or cable boxes: Direct Entry and Automatic Code Search (both methods are described below).

Direct Entry

1. Turn on the satellite receiver or cable box.

2. Look up the brand and code number(s) from the list on page 23.

3. Press and hold the SAT•CABLE button on the remote.

4. Keep holding down the SAT•CABLE button, and enter the ﬁ rst code from the code list for your brand.

5. Release the SAT•CABLE button.

6. Point the remote toward the satellite receiver or cable box and press the ON•OFF button to see if it turns off. If it doesn’t, press the SAT•CABLE button and then press ON•OFF. If you get no response, follow steps 1-5 again, but enter the next code from the code list for your brand of satellite receiver or cable box.

• If you try all the codes for your TV brand and none work, try the Automatic Code Search method. If Automatic Code Search doesn’t work, the remote is not compatible with your TV.

Note: This remote may not be compatible with all brands and models of components. It may also not operate all the functions of your component.

Automatic Code Search

The Automatic Code Search method searches all of the codes for a specific component button. If you want to stop the automatic code search without programming the remote, press CLEAR until the indicator on the remote turns off.

1. Turn on the satellite receiver or cable box.

2. Press and hold the SAT•CABLE button. While you continue pressing the SAT•CABLE button, press and hold the ON•OFF until the indicator light on the remote turns on— then release both buttons.

3. Point the remote at the satellite receiver or cable box. Press and release PLAY, then wait 5 seconds or until the indicator on the remote stops ﬂ ashing.

At this point the remote is searching for the correct code (you’ll know it’s found the correct code when the satellite receiver or

cable box turns off, go to step 4). If, after 5 seconds, the the satellite receiver or cable box doesn’t turn off, press PLAY again to tell the remote to search the next set of codes.

Continue pressing PLAY until the satellite receiver or cable box turns off or you have searched through all of the codes. The

component buttons ﬂ ash when all the codes have been searched, the compnent button turns off, and the remote exits Automatic Code Search. If the component does not turn off after trying all the codes, the remote can’t be programmed to operate your brand —you’ll have to use the remote that came with your component.

4. When the satellite receiver or cable turns off, the remote has found the proper code. Press and release REVERSE, then wait 2 seconds. Repeat this step until the satellite receiver or cable box turns back ON.

5. To ﬁ nish, press and hold STOP until the indicator on the remote turns off.

Using the remote to operate other components

Know the mode

Once you’ve programmed the remote to operate other components, you need a basic understanding of how the remote control works. The codes in the remote control that make a component act a specific way are mode dependent— if you want to change settings in your TV’s menu, you must press the TV button before you press the MENU button so the remote control knows that you want to access the TV’s menu system.

To summarize, to operate the DVD recorder you must press the DVD button; to operate the TV, you must press the TV button; to operate a satellite receiver or cable box, you must press the SAT•CABLE button.

Understanding the INPUT button

Another important button is the INPUT button. The INPUT button access the programming from a specific component. We call these channels, Video Input Channels, because you are telling the component to send the video (and audio) that corresponds to the Video Input jack you used to connect the component to the DVD recorder. For example, if you connected a satellite receiver to your DVD recorder by using the S-VIDEO IN jack, you would need to press DVD (to put the remote in DVD mode) and then press INPUT until the S-Video Input Channel appears (if the satellite receiver is on, you’ll see the program it is tuned to, and S-VID appears in the DVD recorder’s channel banner to let you know which “channel” the DVD recorder has accessed.

Graphics contained within this publication are for representation only.

Code List:TVs for TV button

Chapter 2: The Remote Control

Abex

1172

Admiral

1001 1173 1211

Adventura

1174

Aiko

1016

Akai

1002

Alleron

1046

Amtron

1038

Anam National

1003 1038 1192 1193 1194

AOC

1004 1005 1006 1007 1175 1176 1195

Audiovox

1038

Belcor

1004

Bell & Howell

1001 1083 1162

Bradford

1038

Brokwood

1004

Candle

1004 1006 1008 1174

Celebrity

1002

Centurion

1009

Citizen

1004 1006 1008 1016 1038 1105 1171 1174

1177

Colortyme

1004 1006 1010

Concerto

1004 1006

Contec/Cony

1012 1013 1014 1038

Craig

1038

Crown

1038 1171

Curtis Mathes

1000 1004 1006 1015 1105 1162 1171 1212

CXC

1038

Daewoo

1004 1005 1006 1016 1017 1018 1127 1171 1196

Daytron

1004 1006 1171

Dimensia

1000

Dumont

1004 1151

Electroband

1002

Electrohome

1003 1004 1006 1019 1020 1022

Emerson

1004, 1006 1012 1023

1024 1025 1026 1027 1028 1029 1030 1031 1032 1033 1034 1035 1036 1037 1038 1039 1041 1042 1043 1044 1046 1047 1123 1124 1162 1171 1177 1179 1191 1208

Envision

1004 1006

Fisher

1048 1049 1051 1162 1180

Fujitso

1046

Funai

1038 1046

Futuretec

1038

1000 1003 1004 1006 1022 1052 1054 1055 1087 1164 1165 1166 1167 1168 1181 1213

Gibralter

1004 1151

Goldstar

1004 1005 1006 1012 1019 1056 1057 1058 1155 1156 1171 1172

Grundy

1038 1046 1171

Hallmark

1004 1006

Harvard

1038

Hitachi

1004 1006 1012 1013 1014 1059 1060 1061 1135 1136 1137 1138 1139 1140 1141 1142 1143 1144 1145 1146 1148 1150 117 1198 1199

IMA

1038

Infinity

1062

JCPenney

1000 1004 1005 1006 1008 1022 1052 1054 1058 1063 1064 1072 1087

Graphics contained within this publication are for representation only.

1105 1128 1171 1172 1181 1201

Janeil

1174

JBL

1062

JCB

1002

Jensen

1004 1006

JVC

1012 1013 1014 1054 1060 1065 1066 1067 1157 1158 1159 1182

Kawasho

1002 1004 1006

Kenwood

1004 1006 1019

Kloss Novabeam

1068 1069 1174 1183

KTV

1038 1070 1171 1177

Loewe

1062

Logik

1083

Luxman

1004 1006

LXI

1000 1006 1049 1062 1071 1072 1073 1162

1181 1207

Magnavox

1004 1006 1008 1019 1062 1068 1069 1075 1076 1077 1088 1130 1131 1132 1133 1134 1183 1219 1235

Majestic

1083

Marants

1062

Marantz

1004 1006 1062 1078

Megatron

1006 1059

Memorex

1001 1006 1082 1083 1162

MGA

1004 1005 1006 1019 1022 1051 1079 1080 1082

Midland

1054 1151 1171 1172 1181

Minutz

1052

Mitsubishi

1004 1005 1006 1019 1022

1051 1079 1080 1081 1082 1125

Montgomery Ward

1083

Motorola

1003 1173

MTC

1004 1005 1006 1105

Multitech

1038

Multivision

1084

NAD

1006 1071 1072 1185

NEC

1003 1004 1005 1006 1200

Nikko

1006 1016

NTC

1016

Onwa

1038

Optimus

1185

Optonica

1095 1173

Orion

1035 1191

Panasonic

1003 1054 1062 1170 1214

Philco

1003 1004 1005 1006 1008 1012 1019 1062

1068 1069 1075 1077

1183

Philips

1003 1004 1008 1012 1019 1062 1068 1069 1075 1076 1086 1087 1088 1089

Pilot

1004 1171

Pioneer

1004 1006 1090 1091 1092 1179 1185

Portland

1004 1005 1006 1016 1171

Price Club

1105

Prism

1054

Proscan

1000 1181

Proton

1004 1006 1012 1093

Pulsar

1004 1151

Quasar

1003 1054 1070 1094

Radio Shack Realistic

1000 1004 1006 1012 1038

1049 1095 1162 1171 1172

RCA

1000 1003 1004 1005 1006 1007 1019 1096 1098 1099 1100 1101 1102 1103 1129 1179 1181 1187 1188 1190 1202 1203 1215 1233

Runco

1151

Sampo

1004 1006 1171 1172

Samsung

1004 1005 1006 1012 1015 1019 1104 1105 1106 1171 1172 1204

Samsux

1171

Sansui

1191 1180

Chapter 2: The Remote Control

Code List

(cont.)

Sanyo

1004 1048 1049 1080 1107 1108 1162 1169 1180

Scotch

1006

Scott

1004 1006 1012 1024 1035 1038 1046

Sears

1000 1004 1006 1013 1014 1019 1046 1048 1049 1051 1066 1071 1072 1109 1110 1162 1180 1181 1189

Sharp

1004 1006 1012 1029 1095 1111 1112 1113 1122 1171 1173

Shogun

1004

Signature

1001 1083 1115

Simpson

1008

Sony

1002 1205 1216 1218

Soundesign

1004 1006 1008 1038 1046

Squareview

1189

SSS

1004 1038

Starlite

1038

Supre-Macy

1174

Supreme

1002

Sylvania

1004 1006 1008 1019 1062 1068 1069 1075 1076 1077 1088 1116 1161 1183

Symphonic

1033 1038 1189

Tandy

1173

Tatung

1003

Technics

1054

Techwood

1004 1006 1054

Teknika

1004 1005 1006 1008 1012 1013 1014 1016

1038 1046 1076 1082 1083 1105 1170 1171

Telecaption

1117

TMK

1004 1006

Toshiba

1049 1071 1072 1105 1109 1117 1118 1160 1162

Totevision

1171

Universal

1052 1087

Victor

1066 1182

Vidtech

1004 1005 1006

Viking

1174

Wards

1000 1001 1004 1005 1006 1019 1024 1033 1046 1052 1062 1068 1069 1075 1076 1083 1087 1088 1095 1119 1120

Yamaha

1004

1005 1006 1019

Zenith

1004 1083 1151 1152 1153 1154 1210 1217

Cable Box

SAT•CABLE button

ABC

5002 5003 5004 5006 5053

Antronix

5008 5009

Archer

5008 5009 5010

Cabletenna

5008

Cableview

5008

Colour Voice

5012 5013

Comtronic

5014

Contec

5016

Eastern

5017

GC Electronics

5009

5000 5001

Gemini

5018 5019

General Instrument

5003

Hamlin

5020 5021 5022 5028

5035 5045

Hitachi

5003

Jerrold

5003 5018 5023 5024 5046 5053

Magnavox

5025

Memorex

5026

Movie Time

5027

NEC

5005

NSC

5027

Oak

5016 5029

Panasonic

5048 5052

Philips

5011 5012 5013 5015 5019 5025 5030 5031 5032

Pioneer

5033 5034

Proscan

5000 5001

RCA

5007 5047 5049 5052

Realistic

5009

Regal

5022 5035

Regency

5017

Rembrandt

5003

Samsung

5034

Scientific Atlanta

5006 5036 5037 5038

Signal

5018

Signature

5003

Sprucer

5052

Standard Components

5039 5044

Starcom

5018 5053

Stargate

5018

Starquest

5018

Tocom

5004 5023

Tusa

5018

TV86

5027

Unika

5008 5009

United Cable

5053

Universal

5008 5009 5010

Viewstar

5025 5027

Zenith

5050 5051

Satellite

SAT•CABLE button

Alphastar

5079

Chapparal

5056 5057

Dishnet

5078

Drake

5058 5059

Echostar

5089

5000 (SAT1) 5001 (SAT2)

General Instruments

5060 5061 5062

Hitachi

5083 5084

Hughes Network

5077 5090

JVC

5082

Panasonic

5075

Philips

5085

Primestar

5076

Proscan

5000 (SAT1), 5001 (SAT2)

RCA

5000 (SAT1), 5001 (SAT2) 5071 5080 5081

Realistic

5063

Sony

5072

STS1

5064

STS2

5065

STS3

5066

STS4

5067

Toshiba

5068 5073

Uniden

5069 5086

Graphics contained within this publication are for representation only.

Chapter 3

Recording, Playback & Features

• Watching TV

• Recording (DVD+R and DVD + RW)

• Disc Library

• Playback

page 25

Chapter 3: Recording, Playback & Features

Watching TV

Turn on the DVD Recorder to Watch TV

1. Turn on the TV, and tune the TV to the correct Video Input Channel (this channel corresponds to the input jacks on your TV that you used to connect the DVD

recorder to the TV).

2. Turn on the DVD recorder (the DVD recorder’s main menu appears).

3. Since the Watch TV menu is already highlighted, just press the OK button on the remote (the DVD recorder tunes to the last station you watched and a channel banner

appears). To see the channel banner after it disappears from the screen, press INFO on the remote control.

02:15 pm

Ch 9

Audio: Stereo. (>)

Favorite Show 3:00

The Channel Banner

While watching TV, press INFO on the remote control to see the channel banner. The information that appears in the channel banner depends upon the information sent from the broadcaster. For example, the rating, the program name, and the time the program ends are not always sent by the broadcaster.

TV-PG

Channel Banner

00:01:08

REC

•

Ch 9

• 0h 30min

00h:54min available

Audio: Stereo. (>) TV-PG

Recording Banner

Note: When you stop recording, the DVD recorder takes several seconds to save information to the disc. A still frame of the recording may appear on the screen before you are returned to TV viewing.

IMPORTANT:

When you record to a DVD+R disc, you must ﬁ nalize it before you can play it in another DVD player.

To ﬁ nalize the disc (select the Disc menu from main menu, then select the Disc Title Menu. With the disc name highlighted, press OK. Select Finalize Disc and press OK. Once the disc is ﬁ nalized, you won’t be able to record to it again, change the name of the disc, or the name of the titles on the disc.

Space available on disc

DVD Recording

After you load a DVD+R or DVD+RW disc into the DVD recorder’s disc tray, there are several ways to record programming. When you insert a blank DVD+R or DVD+RW disc, the DVD recorder will need to format the disc so you may need to wait several seconds. The quickest way to start recording is to press the RECORD button while you’re watching a show (the recording banner appears). You don’t even need to remember to press the stop button if you use the Express Recording feature in the recording banner (see next section).

Notes: The DVD recorder won’t record copy-protected material.

The ﬁ rst time you load a DVD+R or DVD+RW disc, the DVD recorder will format it.

Remember, if you’re using a DVD+R disc you must ﬁ nalize it if you want to play the disc in another DVD player (page 30).

Once a DVD+R is ﬁ nalized, you can’t record to it again.

Express Recording Feature

Each time you press the RECORD button on the remote the recording time increases by 30 minutes, up to the maximum limit (the status is listed on the far right side of the recording banner). The DVD recorder will record for the amount of time you speciﬁ ed and then stop automatically. If you press INFO, the amount of recording time left appears. At anytime during the recording, you can extend the recording time by pressing the RECORD button. If you only press RECORD once, the recording will not stop automatically—you will need to press the STOP button to stop recording.

Watching one channel while you record another channel

If you want to watch another channel while you’re recording, you need to make sure you’ve connected an RF coaxial cable to the CABLE/ANTENNA OUTPUT jack on DVD recorder and TV’s corresponding Cable/Antenna Input jack.

1. Make sure the DVD recorder and the TV are on. Tune the TV to the appropriate Video Input Channel (if you need help, go to page 18).

2. Using the DVD recorder’s channel buttons, tune to the program you want to record. Press the RECORD button.

3. If the remote that came with your DVD recorder operates your TV, just press the TV button and use the channel up and down buttons to change the channel on the

TV.

If the remote doesn’t operate your TV, use the TV’s remote control to change channels.

4. When you’re ﬁ nished recording, remember to turn the TV back to its Video Input Channel and watch TV through the DVD recorder.

Notes:

This feature might work differently if you receive programming via a cable box. If you receive programming via a satellite receiver, this feature isn’t available—you can’t record one satellite program and watch another satellite program.

The remote that came with your DVD recorder is a programmable Universal remote that can be programmed to operate many brands and models of TVs. Go to page 21 if you want to program the remote.

When you stop recording, a delay may occur while the DVD recorder generates information about the recording for the Disc Library.

Graphics contained within this publication are for representation only.

Chapter 3: Recording, Playback & Features

Watch TV Disc Disc Library

Timers

Setup

Add Timer

To set a timer for video recording, press OK. To exit, press GO BCK/RETURN

Name

Channel

Day(s)

Start Time

Stop Time

Recording Quality

Timers

Ch 002

05/19 19 Mon Once

03:00PM

04:00PM

*1 : Best

Timer Recordings

Setting up timer recordings to record programs automatically

1. From the DVD recorder’s main menu, use the remote’s arrow buttons to highlight Timers, and

press the OK button.

Tip: You can also access the Timers menu by pressing the TIMER•GUIDE button on the remote control.

2. Since Add Timer is highlighted, just press OK (the Timer Setup screen appears).

3. If you want to give the Timer a name, highlight Name and press the INFO button (the on-screen

keyboard appears—follow the on-screen instructions to name the timer). When ﬁ nished entering the name, make sure you press the right arrow button to highlight Done and press OK.

4. Press the down arrow button to highlight the Channel ﬁ eld and use the number buttons on the

remote to enter the channel number, and press OK (highlight moves to Day).

To enter a Video Input Channel, press the right arrow button.

5. Use the number buttons to enter month and day. To change the frequency (once, daily, weekly,

etc.), press the right arrow button. When ﬁ nished, press OK (highlight moves to Start Time).

6. Use the number buttons to enter the time you want to start recording. Press the right arrow

button to change the a.m./p.m. setting. When ﬁ nished, press OK (the highlight moves to Stop Time).

7. Use the number buttons to enter the time you want the DVD recorder to stop recording. Press

the right arrow button to change a.m./p.m. setting. When ﬁ nished, press OK (the highlight moves to Recording Quality).

8. You can change the quality of the recording by pressing the right arrow button. The better the

quality, the more space the recording takes up on the disc—(go to page 47 for more information). Press OK to conﬁ rm the quality recording setting.

9. When you’re ﬁ nished, make sure Keep Timer is highlighted and press OK.

Notes: The DVD recorder’s clock must be set in order for Timer Recordings to work properly.

Keep Timer Cancel Timer

Timer Setup Screen

Graphics contained within this publication are for representation only.

Chapter 3: Recording, Playback & Features

Watch TV

Disc

Disc Library

Timers

Setup

Live - Ch 6

Disc Name: Maggie

4 Library Disc(s)

None scheduled

5:44 pm Mon 7-Jan 2004

Shows you’ve recorded to a DVD+R or DVD+RW disc are called titles.

Disc Library

You can ﬁ nd a show you recorded to disc more quickly by using the DVD recorder’s Disc Library. Everytime you use your DVD recorder to record a program, the DVD recorder assigns the disc a number, and keeps track of what you’ve recorded and when you recorded it. The disc’s library stores the following information about each disc:

• Disc Name and Number

• The number of titles (recordings) on a disc

• Recording space available on a disc

• Name of the title (show, program, movie)

• Date the program was recorded

• Genre of the program (you may need to assign)

• Which disc is loaded (indicated by a round disc symbol next to the title or disc name)

Editing the Genre of a Title

Most of the Disc Library’s contents are automatically created if the information is available, but you can add or change the genre when the disc is loaded in the DVD recorder.

1. Insert the DVD+R or DVD+RW disc into the DVD recorder that has the recorded program with

the genre information you want to edit.

2. Highlight Disc Library, and press OK. If you want to edit the genre information for one of the

recorded programs, use up/down arrow buttons to highlight the program. The round disc should be next to the title, indicating that the disc is loaded in the DVD recorder.

3. Press right arrow (the Sort by Title option is highlighted).

4. Press down arrow until Assign Genre is highlighted, and press OK (a list of genres appears).

5. Use the up/down arrow buttons to highlight a Genre and press OK. It will take about 15 seconds

for the DVD recorder to save the information.

Since the Disc Library is saved in the DVD recorder, you have a limited amount of space to keep disc contents. If the Disc Library becomes full, you’ll have to delete some of the discs from the Disc Library to make room.

My Show

Simon’s Show

Caroline Comics

Disk 1

Disk 2

Disk 3

My Show Recorded on: Genre: Disc Name: Disc Number: 1

Sort by Title

Disc Name Disc Number: Number of Titles Available Space 1* Quality Available Space 6* Quality Current Quality: 1* SmartRecord: Off

Sort by Space

Finding a title (movie, program, etc) by using the Sort Feature

1. Press MENU (the main menu appears).

2. Press the down arrow button until Disc Library is highlighted, and press OK (a list of titles appears).

3. Press the right arrow button. Each time you press the down arrow button, the next option

appears.

Sort by Title

When you press OK with Sort by Title highlighted, the on-screen keyboard appears. Enter the ﬁ rst character of the title you’re trying to ﬁ nd and select Done (the titles starting with that letter appear, with the ﬁ rst in the list highlighted).

Sort by Genre

Lists contents of the disc by the Genre (you may need to assign a genre to recordings). Use the arrow buttons to highlight a Genre, and press OK (all titles that you’ve assigned to that Genre appear).

Sort by Date

Lists contents of the disc by the date recorded.

Other Sorting Options—Show All Discs

When you choose Show All Discs, additional sorting options appear:

Sort by Space: Lists the discs by the amount of recording space left.

Sort by Disc No.: Lists the discs numerically.

Sort by Disc Title: Lists discs alphabetically by disc title.

Show All Titles: Lists all the titles recorded.

Delete Disc: Deletes the disc that is highlighted and the its contents from the Disc Library, but

doesn’t delete the contents from the disc—the titles are still on the disc.

Graphics contained within this publication are for representation only.

Chapter 3: Recording, Playback & Features

Watch TV

Disc

Disc Library Timers Setup

Watch TV

Disc

Disc Library Timers Setup

Live - Ch 2

Maggie’s Disc

1 Library Disc(s)

10:49 am Thu 17-Mar 2003

Play Disc

Disc Title Menu

Player Menu

Playlist

Disc Options

Playback

To play recordings, do the following:

1. Turn on the TV and the DVD recorder.

2. Make sure the TV is tuned to the correct Video Input Channel (for help, go to page 18).

3. Insert the DVD+R or DVD+RW disc you want to play.

4. Once the DVD recorder reads the disc’s contents, the main menu appears. If the main menu

doesn’t appear, press MENU (the main menu appears).

Notes:

If you selected Autoplay On in the Disc Options menu (page 44), the disc’s title menu appears automatically when you insert the disc.

If the screen is blank, you might not have your TV tuned to the correct Video Input Channel. For more information about Video Input Channels, go to page 18.

5. Use the up and down arrow buttons on the remote to highlight the Disc menu, and press OK (the

options appear).

6. There are two ways to access your recordings within these menu options:

Play Disc: If you want to play all of the recordings on the disc (or there is only one recording), just

press OK when this menu is highlighted (the ﬁ rst recording plays).

Disc Title Menu: Press OK when this menu option is highlighted (all of the recordings/titles on the

disc appear). Use the arrow buttons to highlight the title you want to select:

• To watch the program that you’ve highlighted, press PLAY.

• If you want to name the program, delete it, or change the play mode, press OK (the options appear).

Rename Title: For DVD+RW discs or DVD+R discs which have not been ﬁ nalized.

Play Title: Plays the movie, program or show.

Play Full Title: Can only be selected for DVD+RW discs that may have hidden chapters.

Delete Title: For DVD+RW discs only.

Note: You can delete a title from a DVD+R disc that hasn’t been ﬁ nalized but the program will still be on the disc. You will not be able to access the program once the title has been deleted.

Clear Chapters: For DVD+RW discs only.

1- Disc name

Maggie’s Disc

Caroline’s Bday

Simon at soccer

2- Titles on the disc (programs you recorded)

3- Information bar: shows how much space individual titles are taking up on the disc. For example: the ﬁ rst bar represents the title Caroline’s Bday; the longest recording (title) is the third one, entitled Anniversary.

Anniversary

Steve’s vacation

Steve & Maggie

Maggie’s Disc 6 Title(s) on Disc 0h 24min available *1 Best

5- Disc information: Name of disc, how many recordings are on the disc; how much recording time is left on the disc; the Recording Quality setting.

4- shows how much recording space is left on the disc

Disc Information

In addition to providing information about individual titles on the disc, the Disc Title Menu gives you helpful information about the disc itself. After you’ve inserted the DVD+RW disc or DVD+R disc, select Disc from main menu, highlight Disc Title Menu and press OK.

The picture above is an example of what you’ll see (details are on the next page).

Graphics contained within this publication are for representation only.

Chapter 3: Recording, Playback & Features

1- Disc name

Maggie’s Disc

Caroline’s Bday

Simon at soc-

Anniversary

Steve’s vacation

Steve & Maggie

Rename Disc

Erase Disc

Lock Disc

Make Compatible

Caroline’s Bday

Rename Title

Play Title

Play Full Title

Delete Title

Clear Chapters

Maggie’s Disc 6 Title(s) on Disc 0h 24min available *1 Best

The top menu bar is the name of the disc. With the disc name highlighted, press OK and the options described below appear:

Note: You cannot select the disc name for a ﬁ nalized DVD+R disc.

Rename Disc: press OK, on-screen keyboard appears so you can change the name of the disc (1 on illustration above left).

Erase Disc: DVD+RW discs only. Erases a DVD+RW disc so you can record new programming onto it (not available for DVD+R disc).

Lock Disc: DVD+RW discs only. Protects contents of the DVD so nobody can record new programming onto it. If the disc has been locked, the menu option changes to Unlock Disc (not available for DVD+R discs).

Finalize Disc: DVD+R only. Enables a DVD+R disc to be played in other DVD players. Not available if the disc has already been ﬁ nalized. After a disc is ﬁ nalized, you can’t record more programs to the disc.

Make Compatible: DVD+RW discs only. If you have made edits to the disc (described in the next section), such as adding or deleting chapter markers or hiding chapters, this option enables the edited version of the disc to be compatible with other DVD players.

If you press OK when a title is highlighted, the following options appear:

Rename Title: Press OK when highlighted, and the on-screen keyboard appears. Follow the onscreen instructions to give the disc a different name. Highlight Done when you’re ﬁ nished, and press OK.

Play Title: Press OK when highlighted to play the title.

Play Full Title: Press OK when highlighted to play a title which has been edited by hiding chapters if

you want to play the title in its entirety (even the hidden chapters). Not available for DVD+R discs.

Delete Title: Press OK when highlighted to delete the title. Follow the on-screen instructions on the conﬁ rmation screen to delete the title. (Not available for ﬁ nalized DVD+R discs.) If you delete a title from a non-ﬁ nalized DVD+R disc, the information will still be on the disc but the title will be erased so there won’t be any way to access the title.

Clear Chapters: The DVD recorder adds a chapter marker about every 5 minutes of recording. You can also add chapters manually. When you highlight this option and press OK, all chapter markers are erased. (Not available for DVD+R discs).

The Edit icon

Insert Chapter Marker

Delete Chapter Marker

Hide Chapter

New Title Frame

Split Title

Editing DVD+RW discs

While playing the disc, press the INFO button on the remote (the Info Display appears). Details about the different icons appear in Chapter 4: Playing Discs. However, the edit feature includes special options for DVD+RW discs.

1. While playing a disc, press the INFO button.

2. Press the right arrow button to highlight the Edit icon

appear (use the up/down arrow buttons to highlight a choice and press OK to select).

• Insert Chapter Marker (DVD+RW discs only). When you’re recording to a disc, the DVD recorder adds a chapter marker automatically every 5 minutes. Additionally, you can insert chapter markers manually to segment different parts of the title. To insert a chapter marker, simply highlight Insert Chapter Marker during playback at the point where you want the chapter to start.

• Delete Chapter Marker (DVD+RW discs only). Since the DVD recorder automatically adds chapter markers every 5 minutes, you may want to make each chapter longer by deleting a chapter marker during playback.

• Hide Chapter (DVD+RW discs only). During playback you can hide a speciﬁ c chapter so it is automatically skipped. For more information, go to page 31.

• New Title Frame You can change the thumbnail image that appears in the Player Menu (described in the next section). When the video appears that you want to use to visually represent the title, press OK (the next time you access the Player Menu a still image of this video will appear).

• Split Title (DVD+RW discs only). You can divide one recording into smaller segments so that each title appears separately in the Disc Title Menu. This is a helpful feature when you record a block of programming that contains several shows and/or when you copy camcorder videocassette tapes to a disc.

, and press OK. The following choices

Graphics contained within this publication are for representation only.

Chapter 3: Recording, Playback & Features

Rename Title

Play Title

Play Full Title

Delete Title

Clear Chapters

Insert Chapter Marker

Delete Chapter Marker

Hide Chapter

New Title Frame

Split Title

Simon’s 4th Birthday Fri, 6/20/2003 03:00 pm – 04:00 pm *1 Best

Using the Split Title Feature to Copy Camcorder Videocassette Tapes to Disc

The Split Title option lets you divide one recording into different titles. This is especially handy when you transfer videocassette tapes from camcorder recordings to disc—once you “Split the Title” you can jump from one special occasion to the next without the time consuming effort of fast forwarding through a tape.

1. Connect the VCR’s Output Jacks to the DVD recorder’s Input jacks (for easy access, you can

use the Front Input jacks). For a connection picture using the Input jacks on the back of the DVD recorder, go to page 56. Match the Video (yellow) and the Audio jacks (red and white) to the correct cables.

2. Turn on the VCR and the DVD recorder

3. Insert a blank DVD+RW disc into the DVD recorder (you must use DVD+RW disc to use the

Split Title feature, not a DVD+R disc).

4. Put the videocassette into the VCR (make sure it’s cued to the beginning of the tape, or the place

from which you want to start recording).

5. Press PLAY on the VCR and RECORD on the DVD recorder (most videocassettes contain 2

hours of programming so you can automatically set the DVD recorder to record for 2 hours by pressing RECORD 4 times). See Express Recording on page 26.

6. After you’ve ﬁ nished recording, name the disc—go to the DVD recorder main menu; highlight

Disc Title Menu and press OK (the options appear).

7. Since Rename Disc is highlighted, just press OK (the keyboard appears). Use the arrow

buttons and OK to rename the disc. Remember to highlight Done when you’re finished, and press OK.

8. The disc contains one title—the entire contents of the videocassette tape. Play the

disc from the beginning to determine what to name the first event you recorded (for example, Simon’s 4th birthday). Name the first title by going to the Disc Title Menu and selecting Rename Title. Use the keyboard to rename the title.

9. When you get to the end of the first event on the disc— in the example above,

Simon’s 4th birthday—press the PAUSE button. Press INFO (the Info Display appears).

10. Press the right arrow button to highlight the Edit icon

11. Press the down arrow button to highlight Split Title—the recorder cuts the recording

at that point (you’ll have to wait for a minute or so while the information is updated). Now you have two titles named Simon’s 4th birthday. Start playing the second title, and rename it to fit the description of the event. Continue this sequence until you’ve divided the disc into as many separate titles as you want.

12. Additionally, you can easily remove any unused part of the disc. Typically, the end of

videocassette tapes contain snowy, blank footage. If you copied the entire videocassette to disc, the end of the disc might have this unused content. To remove, just split this portion into a separate title, and then delete the title from the disc.

, and press OK.

Editing Titles with the Hide Chapter Feature

As with most editing features on recorded discs, Hide Chapter is only available with DVD+RWdiscs. Some people use it to hide commercials or introductions to programs. You have to Insert a Chapter Marker at the beginning and the end of the part of the recording you want to “hide.”

Note: Since the DVD recorder automatically adds a chapter marker every 5 minutes during recording, it might be a good idea to Clear All Chapter Markers before using the Hide Chapter feature. To ﬁ nd the Clear Chapters option, go to the Disc menu and select Disc Title Menu. Highlight the title you want to clear chapters from, and press OK. Highlight Clear Chapters, and press OK.

1. While playing the recording (called a title), press INFO (the Info Display appears).

2. Press right arrow until the Edit icon

3. When you’re at the beginning of the place you want to hide, press PAUSE. Then, highlight Insert

Chapter Marker and press OK(if the Info Display isn’t on the screen, press INFO and select the Edit icon

4. Use FAST FORWARD or ADVANCE to go to the end of the segment that you want to hide, and

select Insert Chapter Marker again and press OK.

5. To “hide the chapter” you must be playing it. Therefore, press REVERSE or AGAIN until playback

is between the two chapter markers you just inserted. If the Info Display isn’t on the screen, press INFO, select the Edit icon, and select Hide Chapter and press OK (each time the title plays this chapter will be automatically skipped).

6. To “undo” the Hide Chapter feature for normal playback, go to the Disc Title Menu and select Play

Full Title.

Graphics contained within this publication are for representation only.

is highlighted, and press OK.

Chapter 4

Playing Discs

• Regional Coding

• Types of Discs You Can Play

• How to Load and Play Discs

• Using the Different Menus

• Search Options

• Playback Options

• Using the On-Screen Info Display

page 32

Chapter 4: Playing Discs

Regional Coding

Both the DVD recorder and the discs are coded by region. These regional codes must match in order for a pre-recorded DVD to play. This player’s code is region 1. However, discs you use for recording (DVD+R and DVD+RW) aren’t assigned region numbers.

Types of discs you can play

DVD+Rewritable

Note: Some discs may not be compatible due to laser pickup and design.

This is an example of a onesided disc.

(

)

This is an example of a twosided disc—the title is usually in the center of the disc.

Tip

When you stop playing a disc, the player remembers where you stopped. When you start playing the disc again, the DVD recorder picks up where you left off unless the disc is removed or the player is unplugged, or you press the STOP button twice.

DVD+ R

• DVD+R and DVD+RW discs – used to record programming. Instructions about playing and recording these discs are in Chapter 3.

• DVD Video discs – contain picture and sound [DVD-R, DVD-RW (video mode only), DVD+R, DVD+RW, and DVD ROM are compatible with this player]. DVD-R discs must be ﬁ nalized.

• CDs (CD-R, CD-RW) – Audio CDs contain musical or sound content only. mp3 discs are CDs that contain mp3 ﬁ les. This player is also capable of playing CDs that contain JPEG ﬁ les, and Multisession CDs.

• Video CD discs – Like DVD video discs, VCDs contain picture and sound content. The difference is the amount of information that can be stored on the disc.VCDs typically have lower picture and sound quality than DVD discs.

Super Video CDs (S-VCDs) hold up to 70 minutes of digital sound and video, with MPEG-2

standard video and MPEG-1 standard audio (but you must use DVD+R or DVD+RW discs to record on your DVD recorder, NOT S-VCDs). Additionally, S-VCD disc compatibility is dependent on which MPEG coding software, disc design software, and/or disc writer software are used; and the discs themselves.

You can’t

play the following types of discs:, Laserdiscs, CD-I, CD-ROM (computer only discs), discs recorded using other broadcast standards (i.e. PAL or SECAM), or DVD-RAM discs.

Note: Some discs may not be compatible due to laser pickup and disc design.

How to Load and Play Discs

Turn on the TV and your DVD recorder (press ON•OFF on the remote or press the ON/STANDBY button on the DVD recorder).

1. Make sure the TV is tuned to its Video Input channel (if you need more information, go to

page 18).

2. Press the OPEN/CLOSE button (the disc tray opens).

3. Place a disc gently into the tray with the disc’s label facing up (double-sided discs have content on

both sides, so you can place either side up).

4. Press the OPEN/CLOSE or PLAY button. The disc tray closes. The DVD recorder reads the

disc’s table of contents, and then one of three things happens depending on how the disc was programmed:

• The disc starts playing.

• The disc menu appears on the screen. One of the options will start disc play. Highlight that option and press OK.

• The DVD recorder’s main menu appears on the screen. Highlight the Disc menu and press PLAY.

Note: If you don’t see a picture, press STOP (the main menu appears), and check the position of the PROG SCAN switch on the back of the unit. Make sure the PROG SCAN switch is in the OFF position. Try playing the disc again.

The only time the PROG SCAN switch should be in the ON position is if you connected this unit to a progressive scan TV via Y, Pb, Pr COMPONENT jacks.

Graphics contained within this publication are for representation only.

Chapter 4: Playing Discs

Watch TV

Disc Disc Library Timers Setup

Live - Ch 2

No Disc

1 Library Disc(s)

10:49 am Thu 17-Mar 2003

Using Different Menus

Each disc is programmed with different features. There are three separate types of menus that you can use to access features:

• The Disc menu – The Disc menu is part of each disc and is separate from the DVD recorder’s

menu. The contents of each Disc menu vary according to how the disc was authored and what features are included.

To make the Disc menu appear, press the MENU button while the disc is playing.

• The DVD recorder’s Info Display – The Info Display appears as icons across the top of the

screen when a disc is playing. It can only be accessed while you are playing a disc. It’s turned on and off with the INFO button on the remote. The Info Display icons change based on the type of disc you’re playing. Go to page 35 for more information.

• The DVD recorder menu – If you’re playing a disc, press STOP (the DVD recorder’s menu

appears automatically).

Remember: A feature will only work if the disc was programmed with that feature. For example, if you choose subtitles on the Info Display, the subtitles will only appear if the disc was created with subtitles. If a menu or icon is “grayed out” it means that item (or feature) isn’t available.

To watch TV, press OK.

ZOOM button

REVERSE button

AGAIN button

DVD

SAT•CABLE TV

VOL

CLEAR

OPEN•CLOSE

ZOOM

INPUT

REVERSE PLAY FORWARD

AGAIN ADVANCELIVE

RETURN

MUTE

GO•BACK

INFO

123

7809

Search Options

Picture Scan

To search a disc during playback, use the FORWARD or REVERSE button. Each time you press FORWARD or REVERSE, your DVD recorder scans the disc faster until you reach the fastest scan

ON•OFF

ANGLE

TIMER GUIDE

ANTENNA

FORWARD button

PAUSESTOPRECORD

PAUSE button

ADVANCE button

speed. To resume normal playback, press PLAY.

Note: Many DVD titles are programmed to prohibit skipping of warnings or credits so that you can’t fast forward through them.

Freeze Frame and Frame Advance

While a disc is playing, press PAUSE to freeze the picture. To advance one frame at a time, press PAUSE again (the on-screen icon changes from PAUSE to FRAME). Each time you press the FORWARD or REVERSE button, the picture goes to the next (or previous) frame. To resume normal playback, press PLAY.

Slow Motion (in Freeze Frame Mode) – DVD discs only

While a disc is playing, press PAUSE. Press REVERSE or FORWARD (each time you press REVERSE or FORWARD the slow motion will get a little faster until you reach the fastest slow motion speed). To resume normal playback, press PLAY.

Time Search – DVD and VCD discs only

Make sure the Time Display (top left side of the Info Display) is highlighted, and then use the number buttons to enter a speciﬁ c time on the disc that is playing. Go to page 36 for more information about the Time Display.

Quick Fast Forward and Quick Reverse – DVD and Audio CD only

While you’re playing a disc, press the AGAIN button on the remote (the disc automatically repeats the last 10 seconds of the movie).

Similarly, press the ADVANCE button to go forward approximately 30 seconds.

Playback options

Many of your DVD recorder’s playback features are accessed through the Info Display (described on pages 35 through 39). Additionally, with some discs you can use the Zoom Feature to see details of an image.

Zoom

1. While you’re playing a disc, press ZOOM (the player zooms in on the image). Each time you press

ZOOM, the picture is magniﬁ ed even more (until you get to the maximum zoom level).

2. To see other parts of the picture when you’ve zoomed in on the image, press the up, down, left,

and/or right arrow buttons to go in corresponding directions.

Graphics contained within this publication are for representation only.

Chapter 4: Playing Discs

Using the On-Screen Info Display

The on-screen Info Display contains many playback features. To see the Info Display, press the INFO button on the remote while a disc is playing (the Info Display appears across the top of the screen). Each feature is illustrated with an icon. Use the left and right arrow buttons to move through the different icons in the Info Display. When an icon is highlighted, use the up and down arrow buttons on the remote to scroll through the choices.

Remember, you can only access the Info Display when you’re playing a disc. Also, the Info Display features are only available if the disc was created with that particular feature (i.e., if you select the Angle icon, you won’t be able to change the camera angle unless the disc was created with different camera angles). If one of the icons is “grayed out,” the Info Display feature isn’t available for the disc you’re playing.

The invalid symbol appears on the screen when you press a button that doesn’t have any function. To make the Info Display disappear from the screen, press INFO on the remote control.

Time display (page 36)

Title (page 36)

Chapter (page 36)

Audio (page 37)

Subtitles (page 36) Repeat (page 37)

Angle (page 38)

Text will appear here as you highlight different icons to help you use the Info Display.

This is the Info Display you’ll see when you’re playing a pre-recorded DVD disc

. To make the Info Display appear, press the INFO button on the remote control. Use the left and right arrow buttons to highlight different icons. Use the up and down arrow buttons to scroll through the choices available.

DVD+Rewritable

Time display

(page 36)

Track

(page 36)

Play Mode

(page 38)

Repeat

(page 37)

IntroScan

(page 39)

This is the Info Display you’ll see when you’re playing an audio CD

Time display

(page 36)

Track

(page 36)

PlayBack Control

(page 39)

Audio

(page 37)

This is the Info Display you’ll see when you’re playing a Video CD

Repeat

(page 37)

, also called a

VCD.

DVD+R and DVD+RW Info

DVD+ R

Display… go to page 29.

Graphics contained within this publication are for representation only.

Chapter 4: Playing Discs

Time Display (DVD, Video CD, and Audio CD)

This feature displays the time that has elapsed during playback. For DVD discs, the time displayed refers to the current title and acts as a Time Search feature. For example, if you like a particular scene in a movie, you can enter the elapsed time the scene plays and skip right

Hour Seconds

Minutes

to it.

1. Highlight the Time Display and use the number buttons on the remote to enter the elapsed time you want to go to in that title. You

must use two digits for each ﬁ eld. For example, if you enter 01:35:12, playback will start one hour, 35 minutes, and 12 seconds into the title.

Notes:

For Audio CDs, the time displayed refers to the track that’s playing.

Some portions of a disc might prohibit searching or scanning, such as warnings or opening credits.

Selecting a Title on DVDs or a Track on Audio CDs or Video CDs

Some discs contain more than one title. For example, there might be four movies on one disc (each movie might be considered a title). Each title is divided into chapters.

To select a title via the Info Display, highlight the Title icon with the right arrow button on the remote control. Press the up or down arrow button to go to the next title: When you’re playing a VCD or an Audio CD, use these instructions to go to a different Track.

Notes:

You can also use the number buttons on the remote to enter the title/track number.

Many disks only have one title.

Shortcut

While you’re playing a disc, you can use the CH +/ CH– buttons to go to the next chapter or previous chapter.

Chapter Icon (DVD)

Because DVD discs use digital technology, a title can be divided into individual chapters (similar to tracks on a CD). You can skip to a speciﬁ c chapter by using the Chapter feature in the Info Display.

1. While a disc is playing, press INFO on the remote (the Info Display appears).

2. Press the right arrow button until the chapter icon is highlighted.

3. Press the up and/or down arrow buttons to go to different chapters.

Notes:

You can also use the number button(s) on the remote to enter the chapter you want to play—you may need to enter 2 digits, depending on the number of chapter there are on the disc (for example, if there are 14 chapters, to go to chapter 4, press 0 and then press 4). The movie starts playing at the beginning of the chapter you entered.

The Chapter feature won’t work if the disc isn’t formatted with separate chapters.

When you’re recording onto DVD+R and DVD+RW discs, a chapter mark is added automatically every 5 minutes of recording.

Subtitle Icon (DVD)

To change the subtitle language, highlight the subtitle icon and press the up or down arrow buttons to scroll through the choices (the subtitle language options appear in the box at the bottom of the Info Display).

Notes:

Changing the subtitle language with the Info Display will only affect the disc you are currently playing. When the disc is removed or the player is turned off, the subtitle language will revert to the language setting speciﬁ ed through the DVD recorder’s Language menu.

If the disc doesn’t contain the language you want to use, the disc’s default language is automatically selected.

Some discs are programmed to only allow you to access the subtitle feature through the disc’s menu. If changing subtitle language via the Info Display doesn’t work (as described above), press MENU and change the subtitle language via the disc’s menu.

Graphics contained within this publication are for representation only.

Chapter 4: Playing Discs

Repeat Icon (DVD, Video CD, and Audio CD)

By default, the Repeat feature is Off. There are three Repeat options:

• Title – repeats the title that is playing

• Disc – repeats the disc that is playing

• A-B – repeats a segment of the disc that you select.

For DVD discs and VCDs, play modes are also available from the Repeat Icon:

DVD and VCDs: Play mode standard plays the discs chapters in the order they were placed on the disc.

DVD: Play mode playlist plays a playlist you create in the menu system (page 43).

Repeating Titles, Chapters, or Tracks

1. While a disc is playing, press INFO (the Info Display appears).

2. Press the right arrow button until the Repeat icon is highlighted.

3. Press the up or down arrow button to scroll through the different Repeat options—Repeat title, Repeat disc, Repeat AB, and Repeat

Standard (the modes appear at the bottom of the Info Display).

4. To turn off the Repeat feature, press the up or down arrow button repeatedly until Play Mode: Standard appears.

AB Repeat

AB Repeat lets you deﬁ ne a speciﬁ c segment on the disc that you want to repeat. For example, you might want to watch a speciﬁ c scene from a movie repeatedly:

1. Follow steps 1 and 2 above.

2. Press the up (or down) arrow button until “Repeat Mode:

OK when the disc gets to the beginning point of the segment (the A point) that you want to repeat.

3. Go to the end of the segment you want to repeat. Press OK to set the B point (if the info banner is not displayed on the TV, press

INFO and then OK to set the B point). The segment you marked will play repeatedly until you turn off the Repeat feature).

4. To turn off the Repeat feature, highlight the Repeat icon, and press the up arrow button on the remote until Play Mode: Standard

appears at the bottom of the Info Display.

AB. Press OK to set A point” appears at the bottom of the Info Display. Press

Audio Icon (DVD and Video CD)

If the disc was created with different language tracks (recorded in different languages) or different audio formats (Dolby, DTS, stereo, etc.), you can change the audio option while you’re playing the disc.

1. While a disc is playing, press INFO (the info display appears).

2. Press the right arrow button until the Audio icon is highlighted.

3. Press the down arrow button on the remote to scroll through the available audio options.

4. When the option you want to use is highlighted, press the OK button.

Notes:

The language feature only works if the disc was created with multiple language tracks. If the disc doesn’t contain the language you selected, the disc will play in the default language.

When you choose an audio language during disc playback, you only override the audio language setting in the DVD recorder’s Language menu temporarily.

Some discs are programmed to only allow the audio setting to be changed via the disc’s menu. If changing audio option via the Info Display doesn’t work (as described above), press MENU and change the audio setting via the disc’s menu.

Graphics contained within this publication are for representation only.

Chapter 4: Playing Discs

Camera Angle Icon (DVD)

Some discs contain multiple angles of a particular scene or sequence. If the disc only has one angle, this feature won’t work. Currently, very few discs have this feature.

1. While a disc is playing, press ANGLE on the remote. If the disc wasn’t created with multiple angles, the invalid symbol appears. If the

disc contains multiple angles, the Angle icon appears with the current angle number and the number of angles available. For example, 1 of 4 indicates that Angle 1 is displayed and there are 4 different angles available.

2. Press the up arrow button to go to the second camera angle. Press the arrow button again to go to the third angle, etc.

3. To resume normal playback, scroll through the camera angles until you get to the original angle.

Play Mode Icon (Audio CD)

When you play audio CDs, the various Play Modes are available from the Info Display. The Play Mode feature lets you set up the order in which you want the tracks on the CD to play. There are three Play Modes:

Standard: the tracks play in the same order as listed on the CD (starting with track 1). This is the default play mode.

Random: the tracks on the CD play in a random order.

Program: the tracks play in the order you designate. To use the Program play mode, you must set up the order in which you want the

tracks to play in the DVD recorder’s main menu system (go to page 43 for instructions).

Random

The Random option plays the tracks in a random order.

1. While you’re playing a disc, press INFO (the Info Display appears).

2. Press the left or right arrow button to highlight the Play Mode icon.

3. Press the down arrow button until Play Mode: Random appears in the text at the bottom of the Info Display (the tracks start playing in

random order).

To switch back to Standard Playback, follow steps 1 through 3 above until Play Mode: Standard appears underneath the Info Display icons.

Note: The player defaults to Standard Playback whenever you put a new CD into the DVD recorder.

Program

The Program Play Mode is only available after you set up a playlist via the DVD recorder’s Disc menu (page 43).

Graphics contained within this publication are for representation only.

IntroScan Icon (Audio CD)

Use the IntroScan feature to preview each track on the CD.

1. While the CD is playing, press INFO (the Info Display appears).

2. Use the arrow buttons to highlight the IntroScan icon.

3. Press OK (the ﬁ rst 20 seconds of each track starts playing).

Playback Control (PBC) Icon (Video CD)

Use the arrow buttons to highlight the Playback Control icon. Press the up or down arrow button to go back and forth between On and Off. How Playback Control (PBC) works varies for different Video CDs. With most Video CDs, turning on Playback Control enables you to access the Video CD’s menu if it has one and requires that you navigate through the Video CD’s contents by using the Video CD menu instead of the DVD recorder’s Info Display. When PBC is on, you won’t be able to use any repeat modes or skip titles in the DVD recorder’s Info Display.

Playing Discs You Recorded (DVD+R and DVD+RW)

Playback of DVD+R and DVD+RW discs that you used to record programs is explained in Chapter 3 (go to page 29).

Playing mp3 or JPEG ﬁ les

Chapter 4: Playing Discs

Your DVD recorder can play mp3 ﬁ les and JPEG ﬁ les. You can also create a musical slide show by putting both mp3 (MPEG-1, layer 3) and JPEG ﬁ les on the same disc.

mp3 is an audio ﬁ le format which compresses recorded music. It was developed by Fraunhofer Gesellschaft in collaboration with Thomson Inc. The main advantage of the mp3 format is the ability to store CD-quality music tracks that are user-friendly and compressed on a personal computer. mp3 (MPEG-3, which stands for Motion Picture Experts Group-Layer 3, meaning the third layer of information) is a format used to compress digital audio. Since the audio is compressed, it takes up less space.

Note: You can only play true mp3 ﬁ les in the DVD recorder—some products use software to compress mp3 ﬁ les and convert them to other formats such as MPX. Your DVD recorder won’t recognize or play MPX ﬁ les or other types of converted mp3 ﬁ les.

JPEG ﬁ les are image ﬁ les. Make sure that they have a resolution of less than 5 megapixels (approximately 2MB).

Note: The time taken for the contents of the disc to be displayed varies according to the size and number of JPEG ﬁ les actually on the disc. If nothing is displayed after a few minutes, it is likely that certain ﬁ les are too large. In this case, reduce the ﬁ les’ resolution to less than 5 megapixels (approximately 2MB) and write another disc.

Creating an mp3 Disc on Your Computer

Your DVD recorder handles MPEG-1, layer 3 audio. If you encode your own mp3 ﬁ les from an audio CD, avoid using the features of MPEG-2, such as the 22kHz sampling frequency.

Be sure to make a data CD rather than an audio CD. If you make an audio CD, you will lose the extra features and compression of the mp3 format.

Notes:

Some transport modes (reverse and fast forward) are not available for mp3 CDs.

When burning multisession CDs, make sure you close the last session.

Winamp 2.7ful

cjjb2000a

_ _ _ AL)_ _ TEG _ _

-3.jA- - LET _S_

1. Place the disc in the disc tray with the printed side facing up.

2. If the AutoPlay option in the Disc Options menu is enabled (see page 44), the disc’s contents are

displayed, otherwise press the PLAY button to display them.

3. Select a folder using the

list of ﬁ les or press PLAY to start playing all the ﬁ les contained in the folder.

and buttons on the remote control, then press OK to display the

-3.jA- - C _ _ _ I

Example of folder list.

Graphics contained within this publication are for representation only.

Chapter 4: Playing Discs

01.THE REASON

02.IMMORTALI

03.TREAT HER

04.WHY ON WH

05.LOVE IS IN



PLAY

-3.jA- - LET_S_

04. WHY ON WHY



Example of mp3 ﬁ les.

Example of JPEG ﬁ les.

Watch TV

Disc

Disc Library Timers Setup

To start playback from the beginning, press OK.

Play Disc

Disc Title Menu Player Menu Playlist Disc Options

To start playback from the beginning, press OK.

Play Disc

Disc Title Menu

Player Menu

Playlist

Disc Options

Music

Pictures

Both

4. Select a ﬁ le using the and buttons, press OK (the playback options appear). Use the and

buttons to scroll through the options and press OK when desired option appears.

• mp3 ﬁ le: if you press play when a ﬁ le is highlighted (and you selected Play All), the player begins by playing the selected ﬁ le, then all the ﬁ les and subfolders contained in the same folder. The player then plays the contents of the folders at the same level as the folder containing the ﬁ le selected at the start. If you chose Standard Play, playback will stop after all of the ﬁ les in the current folder (and its subfolders) have played.

Notes:

While listening you can use the

or button to go back to the previous track or go to

the next one, and press the MENU button to display the disc’s contents.

Some ﬁ le names are too long to be completely displayed.

• JPEG ﬁ le: the player starts the slide show with the JPEG ﬁ le you have selected and proceeds to display all the JPEG ﬁ les in the same folder, then all the JPEG ﬁ les in the subfolders located in the same folder.

Note: During the slide show you can use the ANGLE button to rotate the picture 90°, the

ZOOM button to magnify the picture, the

or buttons to go back to the previous picture or go on to the next one, the FORWARD and REVERSE buttons to change the speed of the slide show (the speed selection varies depending upon the size of the JPEG ﬁ les), and the MENU button to interrupt the slide show and display the disc’s contents.

5. When the player has played all the ﬁ les, the disc’s contents appear.

6. Press STOP to end playback.

Musical Slide Show: Playing JPEG and mp3 ﬁ les at the same time

The way the JPEG ﬁ les and mp3 ﬁ les are displayed when you put the CD-R disc in the DVD recorder, varies depending upon how you set up the ﬁ les and folders when you created the CD. The musical slide show enables you to display JPEG ﬁ les while listening to mp3 music ﬁ les that are on the same disc.

If you want to control the order in which the mp3 music ﬁ les play, you need to set up a playlist by going to the Disc menu and choosing Playlist and enter the individual mp3 ﬁ les in the order you want to play them. Then, you choose Play Disc and choose Both from the submenu. When the JPEG list appears, select the picture you want to use as the ﬁ rst slideshow picture. When playback starts, the mp3 playlist will start playing automatically in the order you designated as the JPEG ﬁ les are displayed.

The order the mp3 ﬁ les and JPEG ﬁ les play in the Musical Slide Show as described in the instructions that follow are designated by the order the ﬁ les were placed on the disc.

1. Insert the disc that has the mp3 and jpeg ﬁ les on it into the DVD recorder disc tray.

2. Close the disc tray (press OPEN/CLOSE).

3. After the DVD recorder reads the disc, highlight the Disc menu and press OK.

4. Since Play Disc is highlighted, just press OK.

5. Press the arrow down button on the remote to highlight Both, and press OK.

6. Select the mp3 folder and the JPEG folder.

7. To try different options, press the right arrow button to highlight Standard Play. Use the up/down

arrow buttons to scroll through the choices available.

fldr pic mp3+jpeg

Standard Play

Graphics contained within this publication are for representation only.

Chapter 5

Menu System

• Overview of the Menu System

• Watch TV Menu

• Disc Menu

• Disc Library Menu

• Timer Menu

• Setup Menu

page 41

Chapter 5: Menu System

Overview of the Menu System

Since this product has many features, it has a wealth of menus and options. To access the main menu during playback, press the STOP button on the remote. To access the main menu when you’re not playing a disc, press the MENU button.

How to navigate through on-screen menus

Throughout the DVD recorder’s menu system, you’ll see arrows on the on-screen menu bars. These arrows indicate you can use the correlating arrow buttons on the remote control to navigate to different menus and access choices. When a menu item is highlighted, press OK to select the menu.

If you see the left arrow button, you can press the left arrow button on the remote control to return to the previous menu. Throughout the menu system, the GO BACK button takes you to the previous menu.

Watch TV

Disc

Disc Library Timers Setup

To start playback from the beginning, press OK.

Press the left arrow button on the remote to go to the previous menu.

Watch TV

Disc Disc Library

Live - Ch 2

No Disc

1 Library Disc(s)

Timers Setup

To watch TV, press OK.

10:49 am Thu 17-Mar 2003

Play Disc

Disc Title Menu

Player Menu

Playlist

Disc Options

Press the right arrow button or the OK button on the remote to access the Disc Options.

My Show

Simon’s Show

Caroline Comics

Press the up or down arrow button on the remote control to see more options.

My Show Recorded on: Genre: Disc Name: Disc Number: 1

Sort by Title

The Main Menu

The main menu is divided into the following submenus:

Watch TV – shows current channel number or input.

Disc – plays a disc, accesses the disc title menu, enables you to create a customized playlist (audio

CDs and DVDs), selects the screen format for DVDs, and accesses title menus and disc menus for DVDs. Go to page 43 for details.

Disc Library – contains information about all programs you’ve recorded using this DVD recorder. You can use the Disc Library as a search tool by sorting recorded programs. As much information as possible is stored automatically. The information is stored in the DVD recorder’s memory and has storage limits. You may need to delete some library contents in the future to make room for new recordings. For detailed information about the Disc Library, go to page 45.

Timers – set up timer recordings and view the list of existing timer recordings. Go to page 45 for general information about this menu. For instructions to set up a timer, go to Chapter 3 (page 27).

Setup – accesses all of the menus from the Interactive Setup (the menus you went through the ﬁ rst time you turned on the product); parental controls (rating limits); record quality settings; language options for on-screen menus and discs; and advanced settings for audio and component video. Go to page 45 for more information.

Graphics contained within this publication are for representation only.

Chapter 5: Menu System

Watch TV

Disc Disc Library

Live - Ch 2

No Disc

1 Library Disc(s)

Timers Setup

To watch TV, press OK.

Watch TV

Disc

Disc Library Timers Setup

To start playback from the beginning, press OK.

Watch TV

Disc

Disc Library Timers Setup

To start playback from the beginning, press OK.

Caroline Paige

The DVD recorder’s Player Menu shows how a DVD+R or DVD+RW disc menu will appear in another DVD player.

Note: not all DVD players support DVD+R and DVD+RW discs.

10:49 am Thu 17-Mar 2003

Play Disc

Disc Title Menu

Player Menu

Playlist

Disc Options

Play Disc

Disc Title Menu

Player Menu

Playlist

Disc Options

Fri, 6/20/2003

Go to page 1

Watch TV

The Watch TV menu shows the current channel or input. To watch TV, press OK when the Watch TV menu is highlighted (the channel banner appears to show you available program information, such as channel, name, and time). For more information, go to page 26.

Disc

You can only access the disc menu when you’ve inserted a compatible disc into the DVD recorder. The submenus follow:

Play Disc: starts playing the disc.

Disc Title Menu: available only when you’ve inserted a DVD+R or DVD+RW disc that you’ve

recorded in this DVD recorder. With Disc Title Menu highlighted, press OK to access the disc’s title menu (the disc name appears on the top and each recording is listed below the disc name). For

details about the Disc Title Menu, go to Chapter 3 (page 29).

If you press OK when the disc name is highlighted, the following choices appear:

Rename Disc: Press OK when highlighted (the on-screen keyboard appears). Follow the onscreen instructions to give the disc a different name. Highlight Done when you’re ﬁ nished, and press OK. You cannot select the disc name for a ﬁ nalized DVD+R disc.

Erase Disc: Erases a DVD+RW disc so you can record new programming onto it. Not available for DVD+R disc.

Lock Disc: Protects contents of the DVD so nobody can record new programming onto it. If the disc is locked, this option changes to unlock. This option isn’t available for DVD+R discs.

Finalize Disc: Only appears if you have a DVD+R disc in the DVD recorder. In order for a DVD+R disc to be played in other DVD player, you must ﬁ nalize it.

Make Compatible: DVD+RW discs only. If you have made edits to the disc, such as adding or deleting chapter markers or hiding chapters, this option enables the edited version of the disc to be compatible with other DVD players.

If you press OK when one of the recordings (titles) is highlighted, the following choices appear: Rename title; Play title; Play full title; Delete title; and Clear chapters.

Player Menu: shows you how a DVD+R or DVD+RW disc’s menu will appear in other A small still-frame from each title you record (program, show, movie) appears as a thumbnail image. Use the DVD player’s left and right arrow buttons to highlight a thumbnail so you can play the recording. If you have multiple recordings and want to get back to the beginning quickly, highlight Go to page 1 (if available on the screen) and press OK.

Note: Not all DVD players are able to play DVD+R and DVD+RW discs. Check the DVD player’s owner’s manual.

Playlist: (available for Audio CDs and DVDs): You can create a customized playlist just like you can with many CD players where you rearrange the order in which the songs play. The playlist is played via the Program Play option in the Info Display (page 38). To set up a playlist, follow the onscreen instructions.

DVD Players.

Graphics contained within this publication are for representation only.

Chapter 5: Menu System

Watch TV

Disc

Disc Library Timers Setup

To start playback from the beginning, press OK.

4 x 3 Letterbox

Play Disc

Disc Title Menu

Player Menu

Playlist

Disc Options

AutoPlay: When you select On, a pre-recorded DVD disc immediately starts playing after

you insert it into the player (there’s no need to press the PLAY button). With AutoPlay On, recordable discs (DVD+R or DVD+RW) with content recorded on them will automatically display contents.

Note: For CDs with mp3 or JPEG ﬁ les on them, instead of playing automatically, the

contents of the CD (the ﬁ les and/or folders) appear automatically.

Screen format: the setting you choose adjusts the way a movie appears on your TV (DVD discs only). Standard TVs are 4 x 3 format. Depending on the type of television you have, you may want to adjust the screen setting (also called the aspect ratio). The choices follow:

4 x 3 Letterbox – Choose this setting if you want to see movies in their original aspect

ratio (height-to-width ratio). You’ll see the entire frame of the movie, but it will take up a smaller portion of the screen vertically. The movie might appear with black bars at the top and bottom of the screen.

4 x 3 Standard – Choose this setting if you want the movie to ﬁ ll the entire screen of

your TV. This might mean that parts of the picture (the left and right edges) won’t be seen. Most discs that are produced in a widescreenonly format can’t be cropped in this fashion.

4 x 3 Standard

16 x 9

16 x 9 – Choose this setting if your DVD recorder is connected to a widescreen TV. If

you choose this setting and you don’t have a widescreen TV, the images on the screen might appear distorted due to vertical compression. If you play a disc recorded in 4 x 3 format on a widescreen TV, the left and right sides of the screen will appear black.

Angle Icon: Some DVDs are produced with multiple camera angles. However, it is difﬁ cult to know when the angle feature is available throughout a movie. If you turn on the Angle Display, an icon will appear on the screen whenever multiple angles are available for a particular scene in a movie.

Graphics contained within this publication are for representation only.

Chapter 5: Menu System

Disc Library

The disc library accesses information about what you’ve recorded onto discs. Details of this feature and the submenus are described on page 28.

Timers

Timer: You can add timers and view or edit existing timers from this menu for automatic recording. Timer recordings are especially useful when you have a favorite program that you want to record every week and/or every day. If you use a cable box, the cable box must be On and tuned to the channel you want to record, during the timer recording; if you’re recording from satellite, the satellite set-top box, also called a receiver, must be On and tuned to the channel you want to record. For details about setting up a timer, go to page 27.

Setup

The Setup menu contains many submenus that are explained on the following pages. Follow the instructions at the bottom of the screen.

Note: To return to a previous menu, press the left arrow button or GO BACK.

Parental Controls

You can set up ratings limits and turn on the Parental Control feature in order to control the type of discs people can play in the DVD recorder. The padlock icon on the Lock menu indicates whether the player is locked or unlocked.

Locked: You need to enter the password in order to play discs that have a higher rating than what you’ve allowed. When the player is locked, nobody can access the Lock menu without entering the password.

Unlocked: No password required to play discs. Even if you’ve set ratings limits, they won’t be enforced when the player is unlocked.

Notes:

The player is shipped unlocked without any rating limits set. If you want to use the Parental Control feature, set Ratings Limits and then lock the player.

Don’t confuse the DVD recorder’s Parental Control feature with a parental control feature that may be in your TV, often referred to as V-Chip. The ratings described here refer to discs that you play in the recorder, not TV programs.

Parental Control

System Options

Recording Options

Disc Options

Languages

Installation

Lock

Rating Limits

Unrated Titles

Lock

Rating Limits

Unrated Titles

Enter Password

Conﬁ rm Password

Lock (and Unlock)

1. From the DVD recorder’s main menu, select Setup and press OK (the Setup menu items

appear).

2. Since Parental Control is highlighted, just press the OK button (the Parental Control menu items

appear).

3. Since Lock is highlighted, just press the OK button on the remote.

4. If prompted to enter a password, use the number buttons on the remote control and press OK

(Conﬁ rm Password appears). Enter the same numbers you entered before and press OK.

5. To return to the previous menu, press the left arrow button.

Once the player is locked, you’ll need to enter the password everytime you access the Parental Controls menu.

Note: The player is shipped without any rating limits set. You need to set Ratings Limits in order for the player to prevent people from playing discs with certain ratings.

Rating Limits

The Rating Limits menu lets you determine what types of discs can be played in the player, and what types of discs will require a password to override the rating limit that you’ve set. In the U.S., the ratings feature is based on the ratings set up by the MPAA (Motion Pictures Association of America) such as R, PG, G, etc.

The system ranks the ratings from 1 to 8 in order to accommodate ratings systems used in other countries (1 is considered material that is least offensive and 8 is considered the most offensive).

Note: In order for the Ratings to be enforced, the DVD recorder must be locked and the disc you’re playing must contain a movie (or a title) that is rated.

Graphics contained within this publication are for representation only.

Chapter 5: Menu System

Parental Control

System Options

Recording Options

Disc Options

Languages

Installation

Lock

Rating Limits

Unrated Titles

Apply DVD+R, +RW

To set Ratings:

1. From the DVD recorder’s main menu, select Setup and press OK (the Setup menu items appear).

2. Since Parental Control is already highlighted, just press OK (the Parental Control menu items appear).

3. Highlight Rating Limits and press OK (the 8-level rating list appears).

4. Use the up and down arrow buttons to move the bar to the rating level you ﬁ nd acceptable.

Ratings that don’t require a password (free access) appear under the bar.

Ratings that require a password appear above the bar.

5. Press OK.

Note: You must lock the player (page 45) in order for the ratings to be enforced.

Unrated Titles

Some discs contain titles (or movies) that don’t have a rating assigned to them. Sometimes, movies you might ﬁ nd the most explicit are unrated. However, much of the new programming on discs, such as interviews with actors and directors, is also unrated. Additionally, the discs you use to record (DVD+R and DVD+RW) are considered unrated.

In order to prevent unrated titles from being played, you need to choose Password Required from the Unrated Titles menu, and lock the player.

If you want this setting to apply to discs you recorded (DVD+R and DVD+RW discs), simply highlight the check box next to Apply DVD+R, +RW and press OK.

System Options:

Contains settings and menus for audio features, as well as black level settings and dimmer options for the front display of your DVD recorder.

Digital Output: If you connected your DVD recorder to a receiver via the DIGITAL AUDIO OUT jack on the back of the player, choose the type of receiver (or decoder) you have: Dolby Digital or DTS.

Note: If you select DTS, and you don’t have a DTS receiver connected to the DVD recorder you won’t hear any audio or the audio will be distorted.

SRS/TruSurround: The TruSurround turn on the Virtual Surround

Black Level: Adjusts how bright the picture appears. Choose between Dark and Light. Use the arrow buttons to highlight a choice and press the OK button to select the choice that’s highlighted.

Display Dimmer: Adjusts the brightness of the display on the front of the DVD recorder. Use the arrow buttons to highlight a setting, and the OK button to select the option that’s highlighted. The choices follow: Automatic (the display automatically dims during playback); Bright; Dim.

Audio Broadcast: Default setting for type of audio recorded and played. Choices are Stereo, Mono, SAP (Second Audio Program).

AutoClock: Keeps the DVD recorder’s time current by downloading time from broadcast signal. If the DVD recorder’s clock is out of sync and

AutoClock is on, try turning off AutoClock and set the time manually via the Clock Setup menu (page 48).

TruSurround TruSurround technology is incorporated under license agreement from SRS Labs, Inc.

is a trademark of SRS Labs, Inc.

feature simulates a six-speaker listening experience through just two speakers. The default setting is Off. To

feature highlight SRS/TruSurround, and press OK. Highlight On and press the OK button.

Graphics contained within this publication are for representation only.

Chapter 5: Menu System

Parental Control

System Options

Recording Options

Disc Options

Languages

Installation

Parental Control

System Options

Recording Options

Disc Options

Languages

Installation

Recording Quality

SmartRecord

Display

Audio

Subtitles

Disc Menu

Recording Options:

Recording Quality: The better the quality, the more memory (space) the recording will use

on the DVD+R or DVD+RW disc. The choices for a disc are:

1 Best 1 hour recording time on an empty 4.7 GB disc

2 High 2 hours recording time on an empty 4.7 GB disc

3 Good 3 hours recording time on an empty 4.7 GB disc

4 Normal 4 hours recording time on an empty 4.7 GB disc

5 Basic 6 hours recording time on an empty 4.7 GB disc

6 Low 8 hours recording time on an empty 4.7 GB disc

SmartRecord: Used with Timer Recordings to ensure you have enough space on a DVD+R

or DVD+RW disc to record the program. When SmartRecord is on, the DVD recorder automatically detects how much recording time is left on the disc and adjusts the Recording Quality automatically if necessary.

Disc Options:

Takes you to Disc Menu options—Autoplay, Screen Format, and Angle Icon. Go to page 44 for more information.

Languages:

Display: the language that appears when you access this menu the ﬁ rst time reﬂ ects the

option you chose during the interactive setup. To change the language of the onscreen displays (menus), use the arrow buttons to highlight a language and press OK to select it.

Audio: the language that appears when you access this menu the ﬁ rst time reﬂ ects the option you chose during the interactive setup. You can change the audio language by highlighting an option and pressing the OK button. The language selected will only apply when it is available on the disc.

Subtitles: Some movies on DVD discs have subtitles. Set up your default settings in this menu. You can quickly override these settings while playing a disc by using the Info Display (go to page 35 for information).

Automatic: If the language you selected in the interactive setup isn’t available for the title

you’re playing, but subtitles are available in that language—the subtitles for that language will appear automatically during playback.

Off: subtitles won’t appear on the screen.

On: if the title (movie) has subtitles available, they will appear automatically.

Original: subtitle language will match the original audio (dialogue) language of the title

(movie).

Disc Menu: Many discs have their own menu that appears on the screen. You can select the language in which you want the disc menu displayed. In order for your setting to take effect, the disc’s menu must have been created with the corresponding language option.

Graphics contained within this publication are for representation only.

Chapter 5: Menu System

Parental Control

System Options

Recording Options

Disc Options

Languages

Installation

Interactive Setup

Channel Search

Clock Setup

Channel List

Searching channels... 35% complete 2 channels found

Please wait....

Edit the list of channels found

Installation:

The submenus contained in the Installation menu pertain to the type of signal that is connected to your DVD recorder (cable or off-air antenna). If you move, or change any of the information you entered when you ﬁ rst set up your DVD recorder, you need to change the information in the following menus.

Interactive Setup: The ﬁ rst time you turned on your DVD recorder, you had to complete an interactive setup so your DVD recorder could have the information it needs to function properly. For details about the Interactive Setup, go to page 15. To go through this procedure again to change settings, highlight Interactive Setup and press the OK button.

Channel Search: If you’ve changed program providers (cable and/or satellite), the Channel Search will automatically search the signal and put the latest channels in the DVD recorder’s channel list. Use the arrow buttons to highlight Channel Search, and press OK to begin (a progress indicator appears to let you know how quickly the search is being completed).

Clock Setup: If the clock is incorrectly set or you skipped this step during the interactive setup, you can set the DVD recorder’s clock using the number buttons on the remote and the arrow buttons to navigate. Follow the on-screen instructions.

Note: In order for Timer Recordings to work, you must set the clock to the correct time and date.

Channel List: Enables you to change what channels are accessed when you press the DVD recorder’s channel up and down buttons (if you delete a channel from the channel list, you can still access it by using the number buttons on the remote). For more explanation, go to page 16.

Graphics contained within this publication are for representation only.

Chapter 6

Additional Information

• Troubleshooting

• Handling Cautions

• Maintenance of Cabinet

• Limited Warranty

• Accessory Information

• Copying content from DVD+R or DVD+RW disc to VCR videocassette

• Copying VCR videocassette to a DVD+R or DVD+RW disc

page 49

Chapter 6: Additional Information

Troubleshooting

General Problems

Player won’t work (locks up)

• Try unplugging the AC power cord and plugging it back in.

• Reset the DVD recorder: on the front of the unit, press and hold the STANDBY/ON button while you press and hold the STOP button—wait at least 3 seconds before you release both of the buttons. You’ll need to set up your menu preferences because this Reset Procedure returns the DVD recorder’s menus to the factory default settings and also erases the contents of the Disc Library.

No power

• Plug in the DVD recorder. Make sure both ends of the AC power cord are securely plugged into the recorder and into an AC outlet.

• Make sure you’ve plugged it into a working outlet and/or a power strip that is turned on.

• Don’t plug the unit into an outlet that is operated by a wall switch.

No picture

• Turn on the TV.

• Tune your TV to the Video Input Channel that corresponds to the jacks you used to connect the TV to the DVD recorder (go to page 18 for more help).

• Check the PROG SCAN switch on the back of the unit to make sure it is in the OFF position. Try playing the disc again.

• Make sure your DVD recorder is connected properly.

• If you connected a satellite receiver or a cable box, make sure it is turned on.

• Press the ANTENNA button on the remote control.

A screen saver appears on the TV

• Your player is equipped with a screen saver that appears on the TV after your player has been idle for several minutes. To make it disappear, press STOP or CLEAR on the remote.

The menu is displayed in a foreign language

• The Language menu (Display menu) is set to that language. Go to the Setup menu and choose Languages (in Spanish, shown as Idiomas; in French, as Langues), choose the Display option. Highlight the language you prefer, and press OK.

I forgot my password

• Press the STOP button on the front of the unit while you press the STOP button on the remote control—keep pressing both buttons for approximately 3 seconds (until the DVD recorder (instructions are listed below).

The time (clock) is wrong

Go to the System Options menu and select AutoClock. Set it to off and then set the time manually via the Clock Setup menu, which is found in the Installation menu.

icon disappears from the front panel display). Release both buttons (the player should be unlocked). If that doesn’t work, try resetting the

DVD Problems

Disc won’t eject

• When you put a disc into the player, the player may take up to 15 seconds to read the disc. You won’t be able to eject the disc during this time. Wait 15 seconds and try again.

• Maybe the Tray Lock feature has been activated. To unlock the disc tray, press and hold the STOP button on the front of the unit and then press and hold the OPEN/CLOSE button on the front of the unit at the same time—wait 3 seconds before releasing both buttons.

Disc tray won’t open

Disc won’t play

• Many problems encountered when playing (or recording) a disc are related to the wide variation in disc quality due to the large number of brands and manufacturers. We highly recommend using discs from a reputable manufacturer. If you encounter problems with one brand, please try another brand.

• Insert a disc with the label side facing up.

• Check the type of disc you put into the player. This player only plays DVD video discs, Video CDs, audio CDs, and CDs with true mp3 ﬁ les and/or JPEG ﬁ les. mp3 ﬁ les that have been converted to MPX ﬁ les (or similar types of ﬁ les) won’t be recognized by your DVD recorder.

• Both the DVD recorder and the disc are coded by region. If the regional codes don’t match, the disc cannot be played. This player is Region No. 1. Region coding isn’t applicable to discs you use to record (DVD+R and DVD+RW).

• Press STOP (the main menu appears). Check the PROG SCAN switch on the back of the unit to make sure it is in the OFF position. Try playing the disc again.

• If you’re playing a Multisession CD, you might not have closed the session before ejecting it from your computer. Close the session and try the disc again.

• If you’re trying to play a DVD+R or DVD+RW disc you recorded in this DVD recorder in another DVD+RW discs. Also, if it is a DVD+R disc make sure you ﬁ nalize it (page 43).

• If you’re trying to play a DVD-R or DVD-RW disc, it must have been recorded using the video mode (VM) and DVD-R discs must have been ﬁ nalized.

• If it’s a DVD+R or DVD+RW disc, check the setting in the Parental Controls menu. Go to Unrated Titles, and see if the box is checked next to Apply to DVD+R and DVD+RW discs. If there is a check in the box and you set Unrated Titles to Password Required, simply highlight the checkbox and press OK. Try to play the disc again.

DVD player, the DVD player may not support DVD+R or

Graphics contained within this publication are for representation only.

Chapter 6: Additional Information

Play starts, but then stops immediately

• The disc is dirty. Clean it.

• Condensation has formed in the DVD recorder. Allow it to dry out.

The picture is distorted and/or fuzzy; or “jumps” during disc playback

• The disc might be damaged. Try another disc.

• It is normal for some distortion to appear during forward or reverse scan.

• The disc might be dirty. Clean it.

• Some discs have defects that cause them to jump from one scene to the next.

• Turn the PROG SCAN switch on the back of the DVD recorder to the “off” position. This switch should only be turned on if you’ve connected the DVD recorder to a television that uses progressive scanning to display the image. Some, but not all High Deﬁ nition Televisions (HDTVs) and multimedia monitors use progressive scan.

• If you have a progressive scan TV connected, a slight jumping of the signal is normal when you ﬁ rst play a DVD disc. A more detailed explanation follows:

If you have a progressive scan TV connected to the DVD recorder via the COMPONENT jacks (Y, Pb, Pr) and turned on the PROG SCAN switch, the DVD

recorder automatically switches between progressive scan and regular interlace because progressive scan is only available when you play DVD discs. As the signal is converted from interlace to progressive (and vice versa), the recorder resynchronizes the signal. Depending upon your TV, this resynchronization process might cause a slight “jump” in the picture when you start playing a DVD disc and again when you return to watching TV.

No sound or distorted sound

• Make sure your player is connected properly. Make sure all cables are securely inserted into the appropriate jacks.

• You may need to readjust the Digital Output setting (from the System Options menu). Go to page 46. If you select DTS, and your DVD recorder isn’t connected to a DTS-capable receiver, you won’t hear any sound, or the sound will be distorted.

• Turn your TV to its Video Input Channel (go to page 18).

• Sound is muted when you’re using search features (fast forward, reverse, frame advance, etc.).

• If you connected an audio receiver to your DVD recorder, make sure you chose the correct input setting on the receiver.

Can’t advance through a movie

• You can’t advance through the opening credits and warning information that appear at the beginning of movies because the disc is programmed to prohibit that action.

Subtitle and/or audio language is not the one selected from the initial setting

• If the subtitle and/or audio language does not exist on the disc, the disc’s priority language will be selected instead. Set the subtitle and/or audio language manually through the Info Display or the DVD recorder’s menu system.

Play doesn’t begin

• The rating of the title on the disc exceeds the rating limit set in the Ratings Limits menu. Unlock the player and/or change the rating limit in those menus. Go to page 45 for more information.

No forward or reverse scan

• Some discs have sections that prohibit rapid scanning, or title and chapter skip.

• If you’re trying to skip through the warning information and credits at the beginning of a movie, you won’t be able to. This part of the movie is often programmed to prohibit skipping through it.

Desired angle cannot be changed

• Most discs don’t have the multi-camera angle system, and some discs only have multiple angles during certain parts of the movie.

Picture is too tall and thin

• Change the Screen Format in the menu system. Go to page 44 for more information.

Picture is too short and wide

• Change the Screen Format in the menu system. Go to page 44 for more information.

Disc I recorded won’t play in another DVD player

• If it’s a DVD+R disc, make sure you ﬁ nalize the disc (page 43).

• Some DVD players won’t play DVD+R and/or DVD+RW discs. Check the DVD player’s manual.

Recording/Copying Problems

Not enough space on the DVD+R or DVD+RW disc

• To get more recording time, you can change the Recording Quality setting (page 47). If it is a DVD+RW disc, you can delete some titles to create more space.

Won’t record

• You can’t record content that is copy-protected. If a message appears notifying you that you can’t record the material, press CLEAR on the remote to remove the message from the screen.

• Make sure you’ve inserted a DVD+R or DVD+RW disc.

• Make sure the disc isn’t locked, which protects contents of disc but prevents recording. Go to page 43 for more information.

• Many problems encountered when recording (or playing) disc are related to the wide variation in disc quality due to the large number of brands and manufacturers. We highly recommend using discs from a reputable manufacturer. If you encounter problems with one brand of disc, please try another brand.

Graphics contained within this publication are for representation only.

Chapter 6: Additional Information

mp3 ﬁ les

The following recommendations can’t be taken as a guarantee that the DVD recorder will play mp3 recordings, or as an assurance of sound quality. Certain technologies and methods for mp3 ﬁ le recording on CD-R discs prevent optimal playback of these ﬁ les on your product.

• Make sure the ﬁ le is a true mp3 ﬁ le. You can only play true MP3 ﬁ les in the DVD recorder—some products use software to compress mp3 ﬁ les and convert them to other formats such as MPX. Your DVD recorder won’t recognize or play MPX ﬁ les or other types of converted mp3 ﬁ les.

• When naming mp3 ﬁ les, don’t exceed 12 characters, and enter .mp3 as the ﬁ le extension. When using a general name format of: Title.mp3, make sure the title is 8 characters or less, don’t use spaces, and don’t use special characters (such as, =. +, /, %, &, etc.).

• Whatever the real recording capacity of the CD-R, don’t use more than 630MB of recording space on the disc.

• Use a decompression transfer rate of at least 128 kb/sec (kilobits/second) when recording mp3 ﬁ les. Sound quality with mp3 ﬁ les basically depends on the rate of compression you choose. Getting audio CD quality sound requires an analog/digital sampling rate, that is conversion to mp3 format, of at least 128 kb/sec and up to 160 kb/sec. However, choosing higher rates like 192 kb/sec or more, only rarely give even better sound quality. Conversely, ﬁ les with sampling rates below 128 kb/sec won’t be played.

Can’t get to DVD recorder’s main menu

• Press the STOP button until the main menu appears or press the left arrow button to return to the previous menu. If that doesn’t work, remove the mp3 disc from the disc tray.

Can’t make the Info Display appear

• The Info Display is only available when playing DVD discs, Audio CDs, Video CDs, and watching TV.

Timer Recordings

• Make sure the time is correct. Your DVD recorder is equipped with an automatic clock, but the feature might not work properly in some areas. If the time is inaccurate, set it manually by selecting the Setup menu; then Installation; and then Clock Setup.

• Make sure you set up the timer recording correctly.

• If you’re recording from a satellite receiver or cable box, make sure they are turned on and tuned to the channel you want to record before it is time for the recording to start. Also, if you used audio/video or S-Video cables to connect your satellite receiver or cable box to the DVD recorder, tune the DVD recorder to the corresponding Video Input Channel by pressing the INPUT button on the remote control. If you used a coaxial cable to connect your satellite receiver or cable box to the DVD recorder, tune the DVD recorder to the corresponding satellite / cable box channel (usually channel 2, 3, or 4). Remember, the DVD recorder must be tuned to the appropriate input that matches how the satellite receiver or cable box is connected before you turn off the DVD recorder.

Graphics contained within this publication are for representation only.

Chapter 6: Additional Information

Remote Control

Remote won’t work

• You might be in the wrong mode. To operate your DVD recorder, press the DVD button on the remote before you press any other buttons. If you’re operating the TV, press the TV button ﬁ rst, etc. (this remote operates most RCA, GE, and Proscan TVs and satellite receivers, and you can program it to operate other brands of televisions).

• Insert new batteries in the remote.

• Operate the remote control at a distance of no more than 20 feet.

• Remove any obstacles between the remote and the DVD recorder or other component. If your DVD recorder is in an entertainment cabinet, the glass doors might obstruct the remote control from operating the DVD recorder. Open the doors.

• You might need to reset the remote: remove the batteries and press the number 1 button for at least 60 seconds. Release the 1 button, replace the batteries, and program the remote again (if necessary).

Can’t program the remote

• The universal remote control that came with your DVD recorder is already programmed to operate most RCA, GE, and Proscan components. You can program it to operate many other brands and models of TVs, cable boxes, digital satellite receivers, etc. However, the remote doesn’t support all brands and all models so there is a possibility the remote can’t be programmed to operate your component. Instructions for programming the remote control are on page

21.

Lost the remote control

• To order a new remote control, go to page 55. The buttons on the front of the DVD recorder operate the DVD recorder’s basic functions, but you won’t be able to use the menu system without the remote control. The buttons on the front of the unit are described on page 7. Also, if you have another RCA, GE, or Proscan brand product with a remote control that has a DVD button, some of the buttons will probably operate this product if you press the DVD button ﬁ rst.

Handling Cautions

• Before connecting other components to this unit, be sure to turn all components off.

• Don’t move the player while a disc is being played. The disc may get scratched or broken, and the player’s internal parts may be damaged.

• Don’t put any container ﬁ lled with liquid or any small metal objects on the unit.

• Don’t put your hand into the disc tray.

• Don’t place anything other than the disc in the disc tray.

• Exterior inﬂ uences such as lightning and static electricity can affect normal operation. If this occurs, turn the unit off and on again with the ON/STANDBY button, or disconnect and then reconnect the AC power cord to the AC power outlet. The unit should operate normally.

• Be sure to remove the disc and turn off the player after use.

Maintenance of Cabinet

For safety reasons, when cleaning the cabinet be sure to disconnect the AC power cord from the AC outlet.

• Do not use benzene, thinner, or other solvents for cleaning.

• Wipe the cabinet with a soft cloth.

Formation of Condensation

• Due to sharp changes in temperature and humidity, condensation may form if warm air comes in contact with any cold parts inside the player.

• When condensation forms inside the player, the player may not operate correctly. If this occurs, leave the player at room temperature until the inside of the player becomes dry and operational.

• If condensation forms on a disc, wipe the disc with a soft, dry cloth by moving the cloth from the center hole toward the outer edge.

Handling Discs

• Don’t touch the disc’s signal surfaces. Hold by the edges or by one edge and the hole in the center.

• Don’t afﬁ x labels or adhesive tape to label surfaces. Don’t scratch or damage the label.

• Do not use damaged (cracked or warped) discs.

Cleaning Discs

• Dirty discs can cause reduced video and audio performance.Always keep discs clean by wiping them gently with a soft cloth from the inner edge toward the outer

perimeter.

• If a disc becomes very dirty, wet a soft cloth in water, wring it out well.Wipe the dirt away gently, and remove any water drops with a dry cloth.

• Do not use record-cleaning sprays or anti-static agents on discs.Also, never clean the discs with benzene, thinner, or other volatile solvents which may cause damage to

the disc surface.

Graphics contained within this publication are for representation only.

Chapter 6: Additional Information

Limited Warranty

What your warranty covers:

• Defects in materials or workmanship.

For how long after your purchase:

• One year from date of purchase for parts and labor.

The warranty period for rental units begins with the ﬁ rst rental or 45 days from date of shipment to the rental ﬁ rm, whichever comes ﬁ rst.

What we will do:

• Pay any Authorized RCA Service Center the labor charges to repair your DVD recorder.

• Pay any Authorized RCA Service Center for the new or, at our option, refurbished replacement parts required to repair your DVD recorder.

How you get service:

• Take your DVD recorder to any Authorized RCA Service Center. To identify your nearest Authorized RCA Service Center, ask your dealer, look in the Yellow Pages, or call 1-800-336-1900.

• Proof of purchase in the form of a bill of sale or receipted invoice which is evidence that the product is within the warranty period must be presented to obtain warranty service. For rental ﬁ rms, proof of ﬁ rst rental is also required.

• Pick up your DVD recorder when repairs are completed.

What your warranty does not cover:

• Acts of nature, such as but not limited to lightning damage.

• Adjustment of customer controls.

• Damage from misuse or neglect.

• A unit that has been modiﬁ ed or incorporated into other products or is used for institutional or other commercial purposes.

• Batteries.

• Units purchased or serviced outside the U.S. A.

Product Registration:

• Please complete the online Product Registration on RCA.com or complete and mail the Product Registration Card packed with your unit. It will make it easier to contact you should it ever be necessary. The return of the card is not required for warranty coverage.

Limitation of Warranty:

• THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT. ALL OTHER WARRANTIES, EXPRESS OR IMPLIED (INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE) ARE HEREBY DISCLAIMED. NO VERBAL OR WRITTEN INFORMATION GIVEN BY THOMSON INC., ITS AGENTS OR EMPLOYEES SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS WARRANTY.

• REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER. THOMSON INC. SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT OR ARISING OUT OF ANY BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. THIS DISCLAIMER OF WARRANTIES AND LIMITED WARRANTY ARE GOVERNED BY THE LAWS OF THE STATE OF INDIANA. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED TO THE APPLICABLE WARRANTY PERIOD SET FORTH ABOVE.

How state law relates to warranty:

• Some states do not allow the exclusion nor limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you.

• This warranty gives you speciﬁ c legal rights, and you also may have other rights that vary from state to state.

If you purchased your product outside the United States:

• This warranty does not apply. See your dealer for warranty information.

Graphics contained within this publication are for representation only.

Chapter 6: Additional Information

Accessory Information

There are various accessories available to complement your product. Prices are subject to change without notice. All accessories

subject to availability.

are

A shipping and handling fee will be charged upon ordering, and we are required by law to collect the appropriate sales tax for each individual state, country, and locality to which the merchandise is being sent.

For more information about accessories, go on-line to www.rca.com

off

reset

busy

protected

wiring

Optical Plug to Optical Plug for Optical Audio connection to a compatible receiver. 3 feet (part number DV3); price $15.95 6 feet (part number DV6); price $19.95

Optical Plug to Mini Plug 3 feet (part number DV3M); price $15.95 6 feet (part number DV6M); price $19.95

Surge Protector (part number SCTV4000C); price $49.95

DVD

SAT•CABLE TV

VOL

CLEAR

OPEN•CLOSE

INPUT

REVERSE PLAY FORWARD

AGAIN ADVANCELIVE

ON•OFF

RETURN

MUTE

ZOOM

123

7809

GO•BACK

ANGLE

TIMER GUIDE

INFO

ANTENNA

PAUSESTOPRECORD

Remote Control part number 261387; $23.10

Component Video Cables 6 feet (part number DT6DC); price $24.95 12 feet (part number DT12DC); price $34.95

How to Order

On-Line

Accessories may also be purchases at www.rca.com/accessories (subject to availability).

By Phone

To place an order by phone, have your Visa, MasterCard, or Discover Card ready and call the toll-free number listed below.

Use this number only to place an order for accessory items.

1-800-338-0376

Graphics contained within this publication are for representation only.

Chapter 6: Additional Information

S-VIDEO

OUT

AC IN

DVD Recorder

COMPONENT VIDEO OUT

INPUT

VIDEO

AUDIO PROG. SCAN

OFF

AUDIO

OUTPUT

VIDEO

DIGITAL

AUDIO OUT

COAXIAL

OPTICAL

INPUT

CABLE/ANTENNA

OUTPUT

CH4

CH3

OUT TO TV

IN FROM ANTENNA

INPUT

OUTPUT

VIDEOL

VCR

Note: Copy-protected content,

S-VIDEO

VIDEO L

INPUT1

CABLE/ANTENNA

S-VIDEO

INPUT2

Copying content from a DVD+R or DVD+RW disc to a VCR videocassette

The following instructions are provided for a general connection in case you might want to copy content from a disc you recorded to a VCR videocassette.The back of your TV and VCR probably don’t exactly match the ones shown here. In general, you just need to connect the DVD recorder’s Output jacks to the VCR’s Input Jacks. Also, you need to be able to see what your copying, so the TV needs to be connected.

1. Connect the DVD recorder to the VCR. Connect a set of audio/video cables to the DVD recorder’s OUTPUT VIDEO (yellow),AUDIO L (white), and AUDIO R (red) jacks, to the VCR’s Input Jacks (sometimes labeled VIDEO and AUDIO L and R).

2. Connect the VCR to the TV. Connect an RF coaxial cable to the OUT TO TV jack on the VCR and to the IN FROM CABLE/ANTENNA jack on the TV. Also, connect the cable or antenna signal to the In From Antenna jack on the VCR.

3. Make sure all of the components (TV,VCR, and DVD recorder) are plugged into working power outlets.

4. Turn on all of the components.

5. Tune the TV to channel 3 or 4 (depending on the whether the VCR’s 3/4 switch is set to 3 or 4) because the VCR is connected to the TV with an RF Coaxial Cable.

6. Change the channel on the VCR to its Video Input Channel (sometimes called LINE or LINE INPUT) because the DVD recorder is connected to the VCR’s INPUT jacks.

7. Insert the DVD+R or DVD+RW disc you want to copy to a videocassette into the DVD recorder.

8. Insert a working videocassette tape into the VCR.

9. Press the RECORD button on the VCR.

10. Start playback on DVD recorder.

such as pre-recorded DVD titles, cannot be recorded, copied, or duplicated.

Graphics contained within this publication are for representation only.

Chapter 6: Additional Information

AC IN

DVD Recorder

VCR

INPUT

OUTPUT

VIDEOL

OUT TO TV

IN FROM ANTENNA

S-VIDEO

COMPONENT VIDEO OUT

INPUT

VIDEO

AUDIO PROG. SCAN

OFF

OUTPUT

DIGITAL

VIDEO

AUDIO OUT

AUDIO

OUT

COAXIAL

OPTICAL

CH3

INPUT

CABLE/ANTENNA

OUTPUT

CH4

S-VIDEO

VIDEO L

INPUT1

S-VIDEO

INPUT2

Copying content from a VCR videocassette to a DVD+R or DVD+RW disc

The following instructions are provided for a general connection in case you want to copy your VCR videocassettes to disc. The back of your TV and VCR probably don’t exactly match the ones shown here. In general, you just need to connect the VCR’s Output Jacks to the DVD recorder’s Input Jacks. Also, you need to be able to see what your copying, so the TV needs to be connected.

1. Connect the DVD recorder to the VCR. Connect a set of audio/video cables to the DVD recorder’s INPUT VIDEO (yellow),AUDIO L (white), and AUDIO R (red) jacks, to the VCR’s OUTPUT Jacks (sometimes labeled OUTPUT VIDEO and AUDIO L and R).

2. Connect the DVD recorder to the TV. Connect a set of audio/video cables to the DVD recorder’s OUTPUT VIDEO (yellow),AUDIO L (white), and AUDIO R (red) jacks, to the TV’s INPUT Jacks (sometimes labeled INPUT VIDEO, L and R).

3. Use the RF coaxial cable that was packed with your unit, and connect one end to the CABLE/ANTENNA OUTPUT jack on the DVD recorder. Connect the other end to the Cable/Antenna Input jack on your TV (sometimes labeled CABLE/ANTENNA).

4. Make sure all of the components (TV,VCR, and DVD recorder) are plugged into working power outlets.

5. Turn on all of the components.

6. Tune the TV to the Video Input Channel that corresponds with the Audio/Video Input jacks you used to connect it to the DVD recorder.

7. Insert the videocassette you want to record onto disc into the VCR, and cue it up.

8. Tune the DVD recorder to its Video Input Channel (press the DVD button and then the INPUT button on the DVD recorder’s remote control).

9. Put a DVD+R or DVD+RW disc into the DVD recorder, and press RECORD.

10. Press PLAY on the VCR.

11. When you’re ﬁ nished recording, press STOP on the DVD recorder and tune the TV to its Video Input Channel so it displays content playing in the DVD recorder.

12. Make sure the content copied by playing the disc.

CABLE/ANTENNA

Note: Copy-protected content, such as pre-recorded VHS movies, cannot be duplicated.

Graphics contained within this publication are for representation only.

This page intentionally left blank.

Visit our website at www.rca.com

Please do not send any products to the Indianapolis address listed in this manual or on the carton. This will only add delays in service for your product.

Thomson Inc.

10330 North Meridian Street Indianapolis, IN 46290

Trademark(s) ® Registered Marca(s) Registrada(s) Printed in China TOCOM 16421400

THOMSON

RCA DRC8040N User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
