Raypak S-R410 User Manual

Page 1
X94 Professional
High Efficiency Pool and Spa Heater
Page 2
NO ONE PUTS MORE INTO THEIR POOL HEATERS
Introducing the Raypak X94 Professional series pool heater, designed specifically for commercial properties such as apartments, condos, hotels, motels, schools, parks, community and high-end private pools. It’s also the perfect heater for tough coastal weather conditions where salt air challenges durability. When your reputation is on the line every day, you’ve got to work smart and come prepared with strength, experience, and the guts to lead the way. In a word, it demands a Raypak Professional series pool heater.
BLOWER
GAS VALVE
GAS INLET
FLUE OUTLET
PRV
AUTO
BYPASS
DIGITAL CONTROL
STAINLESS STEEL HEAT ENGINE
BURNER
PROFESSIONAL HERITAGE
Built by a company dedicated to water heating, and refined through more than six decades of year-round demanding use in commercial boiler rooms, Raypak heaters embody the durability, longevity and flexibility that the true pool professional expects. Many of the X94 Professional pool heater features come directly from our years of commercial boiler experience. This knowledge and experience is unmatched in the pool heating industry.
WATER CONNECTIONS
FLUE COLLECTOR AND CONDENSATE COLLECTOR
2” SLIP CPVC
DRAIN VALVE
CON
DEN
SATE
TR
A
P
Page 3
X94 PROFESSIONAL - IN A CATEGORY ALL ITS OWN
MICROPROCESSOR
control is more precise than mechanical systems. It controls temperatures for pool and spa settings and stores diagnostic information for service technicians.
HEAT EXCHANGER
The first gas-fired pool heater to use a stainless steel heat exchanger designed specifically for pool heating. Excellent for salt chlorine generated pools.
CONDENSATE TRAP
This allows for the combustion condensate to gather safely without any of the flue gasses leaking out. We provide a 3/4” CPVC stub out to route your condensate to a neutralizer (not supplied).
STAINLESS STEEL
is used liberally throughout the X94 Professional pool heater.
aypak spared no expense to
R ensure that any area that could be compromised by harsh environments would stand the test of time.
PLUMBING CONNECTIONS
Multi-port plumbing options are simple with 2” CPVC slip connections. Raypak supplies two 2” CPVC plugs so you can tailor the installation to your specific needs.
DIRECT SPARK IGNITION
High-voltage spark provides a quick and smooth burner light o≠. Flame sensing and rectification are provided by the spark electrode and built-in sensing probe.
DIRECT VENT CAPABLE
Flue exhaust can be vented up to 65 equivalent feet without the use of an extractor. Inlet combustion air can be ducted through 4” PVC, ABS, CPVC, or galvanized steel duct.
FLOW SWITCH, T&P and PRV
50 state ASME compliant right out of the box. Flow switch eliminates possible “false” water flow issues from above/below grade pools. No additional parts to buy to make your heater commercial code compliant.
WIRING SHEATH
is standard construction on all exposed wiring. This helps prevent rodent damage and other associated issues that can damage the wiring. Not to mention it looks great!
94% EFFICIENCY
Certified and listed at 94% thermal e∞ciency. In addition to this high e∞ciency, the X94 Professional is also low NO compliant in all 50 states. This is the greenest Raypak pool heater we have ever built!
x
METAL FIBER MESH BURNER
Our unique flat burner design is a 3D knitted structure made from FeCrAlloy®yarn. This design is made for high temperature and low oxidation operation. Designed to operate at low and high inputs without flashback.
WARRANTY
The Raypak Professional is unmatched in warranty for commercial applications: Three years parts and labor. We stand behind what we believe in.
Page 4
R
e m o t e
W
a t e r
6 9 F
T
e m p
P
o o l
104F
S
p a
S
e t
S
e n s o r
1 0 4 F
F
a i l u r e
S
p a
S
e t
H
e a t i n g
1 0 4 F
S
p a
S
e t
N
o
1 0 4 F
D
e m a n d
S
p a
S
e t
H
i
1 0 4 F
L
i m i t
F
a u l t
1
S
u p p l y
V
o l t
a g e
2 8 . 2
F
l a m e
S
t r e n g t h
G
o o d
8
R
u nTi m e
C
y c l e s
134
1 0 0
h
S
p a
S
e t
L
o w
1 0 4 F
V
o l t a g e
A DIGITAL CONTROL SO SOPHISTICATED, YET SO SIMPLE TO USE
F
l u e
C
P
V
C
/
P
P
M
o n i t o r
M
a x
7 5
0 0
F
a n
RPM
F
r e e z e
E
n a b l e d
P
r o t e c t
Microprocessor-Controlled Thermostat
The Raypak X94 Professional gas
eater is equipped with a micro-
h
processor-based control. This control allows you to set your pool and spa temperature precisely at your preferred setting just by pressing an up or down temperature control button. The digital display tells you when the water is being heated and notifies you when your target temper­ature has been reached.
Self-Diagnostic
Troubleshooting a Raypak gas heater
has never been easier. The Raypak
Professional has on-board diagnostic controls that let the user and the service professional know what is going on with the heater at all times. The display uses real English, with no cryptic codes to decipher.
Remote-Compatible
The Raypak X94 Professional is com-
patible with most major pool controls
and remote systems on the market today. Any two- or three-wire remote can connect to the Raypak X94 Professional and be integrated into the pool control system of your choice. The display clearly shows the heater is under control of a remote system.
Run Time and Cycle Meter
Another industry first, the Raypak pool heater can report how long it
has run and how many times it has fired the main burner. This is valuable feedback for the serv­ice professional. Multi-unit installations can monitor the run time of each unit and balance out the duty load, thus avoid­ing overworking one individual heater.
Flame Strength Indicator
Raypak leads the way with the first control in the pool industry to monitor
and measure the flame signal. Known for our high quality, leading edge commercial boilers, it just made sense for Raypak to use this existing commercial technology on our pool heaters. This little tool is a service tech’s dream. Raypak also uses this function on the end-of­line test, making sure every heater leaves with a strong flame signal.
On Board Voltmeter
The Raypak digital control is so smart
it can monitor the low voltage electri-
cal supply from the transformer. This helps eliminate miswiring during installation. It lets the in­staller know if the unit is wired for 240V when 120V is sup­plied and vice-versa. The heater will also let you know if the voltage has dropped too low to function properly. No other pool heater takes care of you like a Raypak and no other pool heater has this function built in.
Flue Gas Temperature Monitoring
The X94 comes standard with a built-in flue gas high limit lo-
cated in the flue collector. This allows you to use PVC, CPVC or Polypro without hav­ing to buy any accessories to run the low temp flue pipe.
Fan Speed - High Altitude Adjustment
High altitude operation can be
dialed in at the job site to max-
imize the combustion flue gases. The blower fan can safely be fine-tuned through the digital control. This feature is also helpful with long intake air ducting or to help reduce fan noise. The user can adjust the fan speed between 7000rpm and 7500rpm.
Freeze Protection
When freeze protection is en­abled (when pump operation
is enabled) the control will monitor the water temperature. If it falls below 40°F the pump will turn on for 15 minutes. After 15 minutes the pump will shut off once the water exceeds 42°F.
Page 5
R
u
n
O
f f
2
:
0 6
P
W
e
d
S
c
h
e
d
u
l e
A
P
u
m p
2
S
O
p
e
r a
t i o
n
p
e
e
d
V
a l v e
E
n a b l e d
O
p e r a t i o n
P
o o l
T
u r b o -
R
a p i d
H
e a t
F
a n
M
o d e
MORE CONTROL - LESS HASSLE
The Raypak X94 Professional gas heater is equipped with an enhanced functionality board as seen in the photo below. This control works in conjunction with the standard ignition control board and offers expanded functionality required to operate the variable speed fan. In addition to the fan control, the board also allows for a pump time clock function, pump speed controller, 3-way valve controller, freeze protection and burner modulation control. All programming is
one through the standard control LCD display.
d
Time Clock
With the built-in time clock function you can program the pump for a 7 day
chedule. It can be set for up to 4 dif-
s ferent operating periods per day. There is also an option to set 2 different schedules, schedule A and schedule B. A manual override feature for service or operation outside the schedule is provided.
Pump Speed Controller
The controller can handle any type of
pump from a single speed, dual speed,
4-speed or variable speed. Variable speed is handled through a direct PWM signal. The pump can also be programmed to boost the flow automatically when there is a call for heat in Pool or Spa mode.
3-Way Valve Controller
3-way water valve control is possible when pump operation is enabled. The
control allows you to program the suc­tion and return valves to the desired position. There is also an option to allow a “Valve Change Delay”. This turns the pump off for 30 seconds to allow the valves to rotate into position without the pump running.
Rheem EcoNet™Enabled
Introducing EcoNet, the first control that integrates your heating, cooling and water heating systems. Now you can enjoy total home comfort at your fin­gertips, with an advanced control that makes it sim­ple to adjust temperature, set schedules, check system status and more. It’s smart technology that makes it easier than ever to ensure all of your home comfort systems are working together at peak effi­ciency. For more detailed information go to
www.rheem.com/EcoNet/Home
Full Burner Control- Industry First Eco Mode Turbo Mode Comfort Mode
Another industry first, the Raypak X94 can adjust the amount of input to the
burner. Turbo mode is standard full­fire operation. Eco Mode is a reduced input rate which can be used for added energy savings or to reduce short cy­cling. Comfort Mode is for Spa mode and reduces the burner input as the water approaches the target tempera­ture. Once the water is within 1.5°F of the set point, the burner modulates the input rate down to match the heating load. This feature helps keep the water comfortable and re­duces short cycling.
Optional EcoNet Remote Control Center
Home control with intuitive LCD touchscreen navigation
Page 6
INSTALLATION FLEXIBILITY
PLUG
O
UTLET
INLET
OUTLET
INLET
PLUG
O
UTLET
INLET
PLUG
PLUG
OUTLET
INLET
OUTLET
INLET
PLUG
PLUG
INLET
PLUG
OUTLET
PLUG
OUTLET
PLUG
INLET
OUTLET
INLET
P
LUG
PLUG
INLET
PLUG
OUTLET
Easy Multiple Unit Nesting
Designed with multiple unit installations in mind, the X94 lends itself to space saving installations. All connections, except for combustion air, are located on the rear of the unit for clean installations and easy access to the heater. The unique angled front control panel allows unobstructed access to the controls when the units are installed side by side. Unit is serviceable from the top of the unit and the two front doors. With such a small footprint and close nest­ing capability, you can install 3 X94 heaters with just under
1.2 million BTU of input and take up less than 22 square feet!
Venting Options
The X94 Professional offers the most venting options of
ny gas pool heater on the market today. The unit can be
a installed with 4” PVC, CPVC, Polypro or stainless steel flue vent. The heater is equipped with a multiport vent adapter so no extra parts are required. The heater can also be in­stalled with 4” PVC or metal pipe duct to bring fresh com­bustion air from outside the equipment room. This is absolutely the perfect solution when chemicals are stored in the equipment room.
Optional Condensate Neutralizer
Raypak also offers a con­densate neutralizer that is performance matched to the X94. Inexpensive and easy to install and maintain. All PVC construction with limestone rock neutralizer. Raypak makes larger neutralizers that can be used on multiple unit installations. Consult the factory for sizing.
P/N 015199
Multiple Plumbing Options
Another industry first from Raypak - 4 possible water connection configura­tions. Not only do you have right­handed and left-handed options, but now you have pass-through options as well. You can place the heater in series with your equipment plumbing. The clean, straight piping eliminates or re­duces the number of elbows needed, offering you the lowest possible pres­sure drop. The X94 Professional comes with 2 CPVC plug fittings to allow you full flexibility when installing the unit.
Optional Stainless Steel Vent Terminal
The Raypak X94 comes standard with a PVC vent terminal, required for all installa­tions. A stainless steel version is available as an option.
P/N 015361 P/N 015451
Page 7
THE HEART AND SOUL OF THE RAYPAK X94 PROFESSIONAL
®
AL-6XN
Alloy
Super-Austenitic Stainless Steel Heat Engine
The heat engine on the X94 is made from a high-end metal alloy blend that was developed over 40 years ago for use with seawater and brackish water conditions. Used primarily in condensers and heat ex­changers on offshore oil platforms and power plants. This special alloy blend is far superior in strength, pitting and corrosion resistance than other types of stainless. It is also preferred over titanium and other stainless steels when used in high salt-water applications. Raypak spent over three years developing the perfect heat engine for pool appli­cations. We tested several different types of stainless material and concluded that AL-6XN is far superior to any other material available. Every part of the heat engine is made from this material including the fire box, heat exchange tubes, headers and nipples.
AL-6XN®Alloy stainless steel
. This is
So What Does This Mean To You?
Believe it or not, pool water is one of the most corrosive water applications for a heater to operate and survive in. Es­pecially with the popularity of salt chlorine generators, the water continues to challenge the life span of pool heaters. The X94 is built specifically for this environment and uses all of the best materials available to provide the longest life for a premium product. No other high efficiency pool heater is built with the advanced alloys and heat engine design as the Raypak X94. There really isn’t any competition to the Raypak Professional Series.
THE MYSTERY OF ASME UNCOVERED
The Raypak X94 Professional heater comes standard as an ASME certified and stamped unit. Being in the boiler business for over 60 years truly makes Raypak the leader for your commercial needs. Why ASME? Most local codes require that public pools, pools that are in condominiums, apartments, or other commercial applications, be in compliance with ASME Section IV.
ASME
stands for dustrial and manufacturing standards. A pool heater that is made to ASME standards must conform to a set of specifications as determined by ASME, specifically in relation to the operating water pres­sure the appliance can handle. Each and every ASME heat exchanger that goes into a Raypak Pro­fessional heater is inspected to make sure it complies with the ASME Code for pool heaters.
That’s why Raypak is the only pool heater manufacturer to supply a flow switch, PRV and T&P gauge standard with every Professional Series gas heater under 400MBTU. We know what it takes to make a unit 50-state ASME compliant right out of the box. Does your heater company make sure all the little details are taken care of like Raypak does, or do you have to make another trip to your distributor to get everything you need?
American Society of Mechanical Engineers
, a non-profit group which sets many in-
Page 8
TM
Technical Data
X94 Professional Gas Pool Heaters
Amp Draw
120 volt 240 volt
5 N/A
Shipping
Weights (lbs)
Complete
Unit
Heater
Model
BTUH Input (000)
(B)
Flue
Diameter
(C)
Air Inlet
Gas
Connection
Water
Connection
Minimum
Flow (gpm)
Maximum
Flow (gpm)
S-R410 399.0 4” 4” 3/4” 2” 40 125 300
Designation for a Professional heater using propane gas is “EP”; a Professional heater using natural gas is “EN”. Prefix “S” is for stainless steel heat exchanger and headers. Example: S-R410-EN = Stainless steel heat exchanger, 410 model size, digital, natural gas Heaters are rated for natural and propane gas up to 4,500 feet. For elevations over 4,500 feet consult the factory. Heater can be installed directly on a combustible surface. Flue gases must be properly vented with 4” CAT IV venting, see I/O manual. Inlet air can be ducted with 4” metal or PVC pipe-See I/O manual for complete venting details
Raypak, Inc. 2151 Eastman Avenue, Oxnard, CA 93030, (805) 278-5300. Fax (800) 872-9725 www.raypak.com
Litho in U.S.A. ©2015 Raypak, Inc. Catalog No. 6200.30-A Effective: 11-01-15 Replaces: 04-01-15
The Pool and Spa Heating Experts
sm
