hsb
2
PLUS Series
LCD Display
Owner’s
Handbook
Document number: 81186_2
Date:14th December 2 001
iii
hsb
Series LCD Display
Owner’s Handbook
December 2001
INTENDED USE
The display units detailed in this handbook may form part of navigational
radar systems intended for light marine use. These displays and radar
systems are only an aid to navigation.
SAFETY NOTICES
This radar equipment must be installed and operated in accordance with the
instructions contained in this manual. Failure to do so can result in personal
injury and/or navigational inaccuracies. In particular:
1. HIGH VOLTAGE. The LCD display unit and scanner unit contain
high voltages. Adjustments require specialized service procedures and
tools only available to qualified service technicians – there are no user
serviceable parts or adjustments. The operator should never remove the
display unit cover or attempt to service the equipment.
2
2. ELECTROMAGNETIC ENERGY. The radar scanner transmits
electromagnetic energy. It is important that the radar is turned off whenever
personnel are required to come close to the scanner to perform work on the
scanner assembly or associated equipment.
It is recommended that the radar scanner is mounted out of range of personnel
(above head height).
Avoid looking directly at the antenna as your eyes are the most sensitive part of
the body to electromagnetic energy.
When properly installed and operated, the use of this radar will conform to the
requirements of ANSI/IEEE C95.1-1992 Standard for Safety Levels with
Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3Hz
to 300 GHz and NRPB, Board Statement on Restrictions on Human Exposure
to Static and Time Varying Electromagnetic Fields and Radiation. Doc NRPB,
N0. 5 (1993).
4. NAVIGATION AID. This unit is only an aid to navigation. Its accuracy can
be affected by many factors, including equipment failure or defects,
environmental conditions, and improper handling or use. It is the user’s
responsibility to exercise common prudence and navigational judgements.
This radar unit should not be relied upon as a substitute for such prudence and
judgement.
iv
2
hsb
PLUS Series LCD Display
Raymarine products are supported by a network of Authorized Service
Representatives. For information on our products and services, contact either
of the following:
UNITED STATES Raymarine Inc.
22 Cotton Road, Unit D
Nashua, NH 03063-4219
Telephone: +1 603 881 5200
+1 800 539 5539
Fax: +1 603 864 4756
EUROPE Raymarine Limited
Anchorage Park
Portsmouth
Hampshire PO3 5TD
England
Telephone: +44 (0) 23 9269 3611
Fax: +44 (0) 23 9269 4642
Copyright © Raymarine Ltd. 2001
The technical and graphical information contained in this handbook, to the
best of our knowledge, was correct as it went to press. However, our policy of
continuous improvement and updating may change product specifications
without prior notice. As a result, unavoidable differences between the product
and handbook may occur from time to time, for which liability cannot be
accepted by Raymarine.
Raymarine is a registered trademark of Raymarine Limited.
SeaTalk is a registered trademark of Raymarine Limited.
2
hsb
is a trademark of Raymarine Limited.
Pathfinder Plus is a trademark of Raymarine Limited.
This product contains technology provided under license by Acorn Group plc.
The copyright of this intellectual property is acknowledged by Raymarine
Ltd., as are Acorn’s trademarks and patents. Acorn’s world wide web address
is http://www.acorn.com.
Preface
v
This handbook covers the radar and chart aspects of the following
hsb
2
(PLUS) series display systems from Raymarine:
System Display Scanner Chartplotter
Pathfinder Radar RL70 PLUS Yes No
Raychart Chartplotter RC520PLUS No Yes
Combined Pathfinder Radar/Chartplotter RL70RC PLUS Yes Yes
This handbook also describes the use of multi-display systems.
Note: Radar systems are supplied with an appropriate Raymarine scanner
unit and inter-connecting cable. Details for installing the scanner are described in the Pathfinder Radar Scanner Owner’s Handbook.
The Raychart (RC) display units include a cartridge holder assembly which
contains two slots for C-MAP NT chart cards.
This handbook contains very important information on the installation and
operation of your new equipment. In order to obtain the best results in
operation and performance, please read this handbook thoroughly.
Raymarine’s Technical Services representatives or your local dealer will be
available to answer any questions you may have.
Warranty
To register your
to fill out the warranty registration card found at the end of this handbook. It is
very important that you complete the owner information and return the card to
the factory in order to receive full warranty benefits.
EMC Conformance
All Raymarine equipment and accessories are designed to the best industry
standards for use in the recreational marine environment.
The design and manufacture of Raymarine equipment and accessories
conform to the appropriate Electromagnetic Compatibility (EMC) standards,
but correct installation is required to ensure that performance is not
compromised.
2
hsb
series display unit ownership, please take a few minutes
vi
2
hsb
PLUS Series LCD Display
Contents
