Page 1
USER’S GUIDE
HIGH EFFICIENT COMBINATION BOILER
It is the law that all gas appliances are installed by
a competent person, in accordance with the gas
safety installation and use current regulations.
To the current Gas Safety (Installation and Use)
Regulations 1994 (as amended).
All CORGI registered installers carry a CORGI I.D.
card and have a registration number. Both should be
recorded in your boiler log book. You can check your
installer by calling CORGI direct on: 01256 732300.
Escape of gas
Should a gas
supplier without delay.
Do NOT search for gas leaks with a naked flame.
WARNING: This appliance must be earthed.
Do not touch or tamper with this sealed unit or
its components
1.
1.1
1.1.1
leak be
INTRODUCTION
Please carefully read information given in
the booklet to help you gain maximum
control from your appliance with minimum
trouble and cost.
Your Ravenheat Combination Boiler has
been designed to supply your Central
Heating and Domestic Hot Water directly
from one unit.
When central Heating is operating, the
circulation will be interrupted when
domestic hot water is being drawn off. This
will normally not affect the level of heating.
suspected,
contact your gas
1.2.1
1.4
1.4.1
1.4.2
1.4.3
CLEARANCES AROUNDTHE BOILER
Above 125 mm
Below 100 mm
Front 450 mm
Sides 5 mm
5 mm in front when installed in a cupboard.
Minimum clearances are required for safety
and maintenance. Do not obstruct any
purpose made ventilation opening if boiler
has been fitted in a compartment.
Never hang clothes, etc., over the appliance.
USER CONTROLS
See Fig. 1
This appliance is designed to operate with
the minimum of attention by the user.
All controls are to be found on the control
panel.
OPERATING SAFETY CHECKS TO
PROTECTYOUR APPLIANCE
Before lighting the appliance check central
heating system pressure (7) is not less
than 1 bar gauge. If it is below this do not
light but consult your installer about refilling
your system as you may have a leak in the
system.
An ORANGE warning light on the control
panel warns of a flame failure of the main
burner. This can be reset manually by
pressing flame failure switch (1B).
Overheat thermostat lockout could occur due
to air or poor circulation in the boiler/heating
circuit. This can be reset manually by removing
grey cover (3) on control panel and pressing
red reset button. Replace cap. If lockout
should persist leave the appliance shut down
and consult your installer/service engineer
immediately.
Page 2
Fig. 1
2.
2.0
2.1
OPERATING DOMESTIC HOT WATER
Select only summer/winter switch position (1A).
Open hot water tap. After about 3 seconds
main burner will always operate.
2.2 Temperature of domestic hot water can be
varied by adjusting the water flow rate at the
tap. Domestic thermostat (5) will control
maximum temperature leaving the appliance.
The knob can be set between minimum and
maximum approximately 35
o
C to 65 oC.
For maximum temperature of domestic
hot water leave in maximum position.
3.
OPERATING HEATING & HOT WATER
TO SET AND ADJUST BUILT-IN TIMER
MODEL SEE OPPOSITE PAGE 3.
3.0
3.1
Select summer/winter switch 1IA) position.
Switch on time clock, adjust room stat and/or
thermostatic radiator valves to high settings.
3.2 Main burner will operate. Temperature output of
central heating can be adjusted by central
heating thermostat (4). The knob can be set
between minimum and maximum
approximately 40
o
C to 85oC.
While the appliance is being used to provide
domestic hot water, the central heating will not
operate. When hot water is no longer required
the appliance will automatically revert to
central heating and should not noticeably
affect the level of central heating. Adjust
external controls to required settings.
NOTE: An anti-cycling device is fitted to the
heating function. When the boiler reaches
its set maximum temperature it will not
operate on heating for about 3 minutes but
the domestic hot water function will always
operate on demand.
TO SHUT DOWN THE APPLIANCE
For short periods, switch to (summer) only
and turn off all hot taps. For long periods
switch of the on/off switch (1). If the appliance
is to be shut down for long periods when
there is a risk of freezing, then appliance
should be drained. Similar refilling must be
done by a competent person following
approved procedures.
CLEANING OF APPLIANCE OUTER CASING
Use a clean damp cloth. Do not use any
abrasive cleaners and with a dry cloth lightly
polish to protect painted surfaces.
Control panel and fixtures can be wiped with
damp cloth and dried. Spray polishes must
not be used on control panel surfaces or
switches. Care must be taken in preventing
any liquids entering the appliance.
CARE OF YOUR APPLIANCE AND SYSTEM
Annual servicing of your appliance is required
to maintain safety and efficiency of its
operation. Therefore it is recommended that
the appliance is serviced at least once a year
and that the whole of the heating system be
checked at the same time by a qualified
installer. If it is known or suspected that a fault
exists on the boiler then it MUST NOT be used
until the fault has been corrected by a
COMPETENT PERSON. It is essential that the
instructions in this booklet are strictly followed
for safe and economic operation of the boiler.
SERVICING SHOULD BE CARRIED OUT BY A
COMPETENT PERSON.
Ravenheat Manufacturing Ltd.,
Chartists Way, Morley, Leeds LS27 9ET.
Page 3
PROGRAMMABLE TIME CLOCK
INSTRUCTIONS FOR USE
Your Ravenheat boiler comes complete with (optional)
digital programmer. The timeclock is supplied with a
cover to prevent accidental loss of programme, or
children tampering with preset programmes.
5.
TO PROGRAMME TIMECLOCK
To access programming buttons remove clear cover,
Press reset key with a pencil before setting or
reprogramming times.
5.1.1
5.1.1.1
TO SET TIME AND DAY OF THE WEEK:
SET DAY OF WEEK:
- Press clock button and hold in.
Press day button to desired day.
- Release both buttons,
The day of the week will be set.
5.1.1.2 SET HOUR:
- Press clock button and hold in.
Press hour button to desired time,
- Release both buttons,
The hour will be set.
5.1.1.3 SET MINUTE:
- Press clock button and hold in.
Press minute button to desired time
- Release both buttons.
The minute will be set.
NOTE:
When, setting time holding in the hour/minute
button this will rapidly advance the display.
5.12
5.1.2.1
TO SET PROGRAMMES:
Press timer button and release to enter into
programme mode.
5.1.2.2
Programme “1 ON” will show in lower left
hand corner.
Press
DAY
5.1.2.3
key to select the programme period
There are 10 day settings for your choice.
(1) Mo to Su (2) Mo (3) Tu (4) We (5) Th
(6) Fr (7) Sa (8) Su (9) Mo+Tu+We+ThtFr
(10) Sa+Su.
For each programme days ‘off’ setting must be
input the same as the ‘on’ setting.
5.1.2.7 After setting programme 1 ON/OFF TIME
repeat step 2.1 to 2.7 to set programmes 2
through to 6 if required.
5.1.2.8
Your timer gives you up to 6 different ONE
and 6 different OFF settings per programme
period. Note you have a choice of 6 ON-6
OFF programmes max.
5.1.2.6.1 REVIEWYOUR PROGRAMMES:
- Press the TIMER key to advance display to
each subsequent ON or OFF setting.
- Check days and times displayed.
- To make a change, follow instructions
under ’TO SET PROGRAMMES”.
Note on completion of programming operations
press the clock button to show current time/day
and replace the clear tamper proof cover.
5.1.2.8.2 MANUAL KEY
- Press MANUAL key to select ON / AUTO /
OFF mode.
- ON mode is to turn on the timer, OFF
mode is to turn off the timer.
- AUTO mode is to set the timer to programme
mode. It will turn on or turn off according to
the programmes you set.
- From ON to AUTO mode it will turn on until
next OFF programme.
- From OFF to AUTO mode it will turn off
until next ON programme.
5.1.2.4
5.1.2.5
5.1.2.6
You now have a choice of 6 programmes.
5.1.2.8.3 LED INDICATOR
LED light is on when the boiler is operating in
Press hour button to set the required hour ‘on’.
Press minute button to set minute,
After setting the programme press
TIMER
key
again “1 OFF” will appear. Repeat procedure
5.123 through to 5.1.2.5 to set programme
5.1.3
NOTE:
Once the reset button is pressed, the stored time and
programme will be cleared to initial state.
heating mode.
TO RESET TIMER:
Press reset button to reset the timer unit.
“1 0FF”TIME.
N.B.: When the clock is either ‘programmed” on, or is on constant, the red indicator will illuminate
Page 4
Chartists Way, Morley, Leeds, LS27
Telephone: (0113) 252 7007
Tfax: (0113) 238 0229
