Service part catalogue
SelfCookingCenter® whitefficiency®
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
16.02.2012
1NAC120 V 60Hz UL
CD-Ges_101207
©Copyright by RATIONAL Technical Service
All Rights reserved
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
SelfCookingCenter® whitefficiency®
2
1NAC120 V 60Hz UL
16.02.2012
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
SelfCookingCenter® whitefficiency®
Pos. Part No. Description Qty.
1 Control panel 1
2 Electrical installation 1
3 ClimaPlus 1
4 Steam generator 1
5 Hot air heating 1
6 Motor and fan wheel 1
7 Interior cabinet 1
8 Door 1
9 Exterior cabinet 1
10 Water 1
11 CleanJet + Care 1
12 Gas parts 1
13 Standard accessory 1
16.02.2012
1NAC120 V 60Hz UL
3
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Control panel
4
1NAC120 V 60Hz UL
16.02.2012
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Control panel
Pos. Part No. Description Qty.
1 87.01.006 Control panel insert with overlay *RAT* 1
2 42.00.161 Control pcb 1
7 16.00.282 Dial 3
8 5110.1027 Distance plate for front panel 2
10 40.00.464 Potentiometer CT 1
11 5110.1029 Gasket mode switch 2
13 16.01.908 Sealing f. panel insert 1
16.02.2012
1NAC120 V 60Hz UL
5
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Electrical installation
6
1NAC120 V 60Hz UL
16.02.2012
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Electrical installation
Pos. Part No. Description Qty.
8 40.03.660 Fan housing 1
9 40.03.428 Cooling fan 1
10 40.03.257 Converter 230VAC 24VDC 1
24 40.03.995 Bus cable 0.85m 1
25 40.03.995 Bus cable 0.85m 1
27 40.00.279 Power transformer 1
28 40.03.480 Mounting support power transformer 1
29 1008.0766 Hex screw M8x30 1
31 40.00.320 Cable connection M20x1.5 1
35 40.04.048 Buzzer 1
36 40.01.597 Power supply cable 3xAWG14 1
37 40.03.391 Mounting device converter 1
A Electrical installation 1
16.02.2012
1NAC120 V 60Hz UL
7
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Electrical installation
8
1NAC120 V 60Hz UL
16.02.2012
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Electrical installation
Pos. Part No. Description Qty.
1 40.03.322 Contactor assembly 1
6 40.03.817 Cable control harness 1
7 40.04.181 Cable harness isolating transformer 1
8 40.02.515 Dry up protector 315°F/157°C 1
9 3014.0302 Hex nut M10 for dry-up protector 1
10 40.01.482 Safety temperature limiter 365°C 1
11 3014.0327 Hex nut M10x1,0 1
12 40.03.761 Contactor 3TG1010-3AK2 1
17 40.03.348 Control transformer T1 1
18 10.01.065 Hex nut M5 1
19 40.03.404 Mounting support transformer 1
20 10.01.065 Hex nut M5 1
21 40.01.483 Electronic noise filter 1
22 40.01.579 Fixing clip f. pcb 4
25 40.01.873 Fuse SC-15A 10x38 2
26 40.02.512 Fuse holder 2x6.3A 1
26 40.01.487 Fuse holder 2pol 1
29 10.00.365 Pan head screw Torx M3x20 2
16.02.2012
1NAC120 V 60Hz UL
9
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
ClimaPlus
10
16.02.2012
1NAC120 V 60Hz UL
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
ClimaPlus
Pos. Part No. Description Qty.
1 22.00.882 Mounting device f. pressure sensor 1
2 3017.1011 Pressure sensor for humidity control Huba 401 1
4 22.00.850 Outer humidity meas. Piece 1
5 22.00.881 Gasket f. hum. meas. Pipe 1
6 1104.0122 Hex combination nut M4 galv 3
7 22.00.525 Hose set f. humidity control 1
8 22.00.725 Humidity control cpl. 1
9 22.00.914 Air inlet pipe 1
10 22.00.960 Drain hose for humidity control 1
11 2066.0527 Hose clamp ø14mm 2
12 22.00.767 Vent cover 1
13 22.00.837 O-ring for humidity control 2
15 10.00.111 Cable clip long 2
16.02.2012
1NAC120 V 60Hz UL
11
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Steam generator
12
16.02.2012
1NAC120 V 60Hz UL
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Steam generator
Pos. Part No. Description Qty.
1 44.00.938 Steam generator insolated 1
2 10.00.709 Hex nut M6 w. locking 1
3 72.00.078 Burner steam gen. 1
4 72.00.077 Insulation f. burner steam gen. 2
5 1104.0122 Hex combination nut M4 galv 4
6 70.00.573 Burner pipe 1
7 72.00.067 Gasket f. burner carrier 1
8 1105.0121 Hex combination nut M5 galv 3
9 1105.0120 Hex nut M5 2
10 1205.0120 Tooth lock washer A5,3 2
11 44.01.218 Ignition electrode steam generator 1
12 1104.0120 Hex nut M4 2
13 44.00.250 Gasket f. ignition electrode 1
19 2066.0519 Hose clamp 35,6mm 1
20 2066.0526 Hose clamp ø46mm 1
21 44.00.207 Emptying pump 1
22 1006.0762 Hex screw M6x10 2
23 1306.0222 Washer A6,4x15x1,5 2
24 44.01.248 Fixing device f. pump steam generator 1
25 10.00.709 Hex nut M6 w. locking 2
26 44.00.234 Drain hose steam generator 1
27 40.04.108 Thermocouple steam generator *B5* 1
28 44.00.516 Fixing plate steam generator thermostat 1
31 2112.1006 Steam hose 50x7mm 2
32 2066.0504 Hose clamp 40-60mm 4
33 44.01.135 Steam pipe 1
37 44.00.253 Filling level electrode 85mm 1
38 44.01.168 Fixing angle steam generator 2
40 44.01.031 Closing cap for steam generator 1
41 10.00.982 Hose clamp D=18.2 1
43 2066.0518 Hose clamp 30mm 2
A 8354.1320 Pump connection spout cpl. 1
16.02.2012
1NAC120 V 60Hz UL
13
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Pump connection spout
14
16.02.2012
1NAC120 V 60Hz UL
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Pump connection spout
Pos. Part No. Description Qty.
1 2118.1000 Pump connection spout 1
2 2120.1259 Stop plug 10mm 1
3 2110.1008 Silicon hose ø10x2mm 1
4 2066.0527 Hose clamp ø14mm 2
5 2066.0530 Hose clamp ø16.4mm 1
6 2062.0331 Junction pressure hose GS 10 1
7 4005.0101 Tie rap 145 mm 1
16.02.2012
1NAC120 V 60Hz UL
15
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Hot air heating
16
16.02.2012
1NAC120 V 60Hz UL
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Hot air heating
Pos. Part No. Description Qty.
8 74.00.758 Hot air heat exchanger 1
10 74.00.814 Gasket hot air heat exchanger/interior cabinet 2
11 74.00.813 Mating flange heat exchanger 2
12 74.00.296 Gasket f. heat exchanger below 2
13 10.01.065 Hex nut M5 10
14 10.01.065 Hex nut M5 8
A 74.00.821 Burner hot air 1
16.02.2012
1NAC120 V 60Hz UL
17
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Burner hot air
18
16.02.2012
1NAC120 V 60Hz UL
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Burner hot air
Pos. Part No. Description Qty.
1 74.00.034 Ignitionelectrode, hot air 1
2 74.00.873 Earth electrode, hot air 1
3 74.00.290 Gasket electrode hot air 1
4 10.00.696 Allen screw M4x6 w. Precoat 85 4
16.02.2012
1NAC120 V 60Hz UL
19
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Motor and fan wheel
20
16.02.2012
1NAC120 V 60Hz UL
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Motor and fan wheel
Pos. Part No. Description Qty.
1 40.03.378 Fan motor 1
3 10.01.049 Square necked mushroom head bolt 6x30 4
4 10.00.709 Hex nut M6 w. locking 2
5 22.00.721 Flange f. motor shaft gasket 1
6 22.00.722 Mounting support f. gasket flange 1
7 22.00.083 Motor shaft gasket 1
8 20.01.755 Isolation for mounting plate for motor 1
9 10.01.065 Hex nut M5 3
10 22.00.828 Fan wheel 1
11 10.00.565 Hex screw M8x20 1
12 1308.0162 Washer A8,4 1
13 10.00.112 Cable clip short 1
14 20.01.411 Bushing for motor mounting bar 4
16.02.2012
1NAC120 V 60Hz UL
21
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Interior cabinet
22
16.02.2012
1NAC120 V 60Hz UL
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Interior cabinet
Pos. Part No. Description Qty.
1 40.00.290 Thermocouple humidity 1
2 10.00.087 Clamp strap f. sensor 1
3 10.00.100 Hex nut M4, self-locking 1
7 40.03.531 Wiring interior light 1
8 40.00.098 Reflector f. interior light 1
9 40.00.091 Gasket frame w. glass a. gaskets 1
10 3024.0201 Halogen bulb 300°C 1
11 20.01.800 Door gasket 1
12 40.04.037 Meat probe sensor 1
13 10.00.612 Hex nut M16 flat 1
14 1315.0104 Copper washer 16x20x1,5 1
16 40.01.317 Screen core temperature sensor 1
17 10.01.076 Cap nut M5*A2 2
20 40.04.085 Thermocouple interior cabinet B1 1
21 40.03.782 Screen interior cabinet sensor 1
22 10.01.076 Cap nut M5*A2 2
23 54.01.117 Outlet sieve 1
24 40.01.482 Safety temperature limiter 365°C 1
25 3014.0327 Hex nut M10x1,0 1
A 22.00.941 Air baffle 1
16.02.2012
1NAC120 V 60Hz UL
23
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Air baffle
24
16.02.2012
1NAC120 V 60Hz UL
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Air baffle
Pos. Part No. Description Qty.
1 22.00.835 Air sucking ring f. air baffle 1
3 10.00.515 Rivet 3,2x5 A4 6
7 40.03.780 Fixing clip core temp. cable 1
8 22.00.491 Surge guard for Meat probe sensor 1
9 2760.1370 Latch hook for air baffle 2
10 1604.0167 Rivet 4x10 3
13 10.00.744 Washer A4,3 *A4 1
16.02.2012
1NAC120 V 60Hz UL
25
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Door
26
16.02.2012
1NAC120 V 60Hz UL
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Door
Pos. Part No. Description Qty.
1 24.00.152 Door handle 1
2 24.00.176 Door lock 1
6 24.00.504 Lock cover 1
8 24.00.133 Door mounting support top 1
9 1008.0768 Ornamental screw M8x16 3
11 24.00.223 Door mounting support bottom 1
12 1006.1962 Countersunk screw Torx M6x16 2
14 24.00.137 Door bolt 1
15 10.00.099 Hex screw M8x12 1
16 1308.0160 Washer A8,4 1
17 24.00.048 Door bolt 1
18 1008.0769 Ornamental screw M8x30 1
20 2001.0109 Compression spring 1
21 24.00.141 Holding bracket f. door catch 1
22 1006.0760 Hex screw M6x16 2
24 24.00.142 Door catch 1
25 1005.2000 Interlocking tooth screw M5x8 1
27 24.01.100 Spring clip f. door lock 1
A 24.00.088 Door 1
16.02.2012
1NAC120 V 60Hz UL
27
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Door
28
16.02.2012
1NAC120 V 60Hz UL
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Door
Pos. Part No. Description Qty.
1 24.00.163 Inner door pane 1
2 24.00.147 Sleeve for door bolt top 1
3 24.00.146 Door setting bolt 1
4 24.00.502 Fixing device f. magnet with magnet 1
5 24.01.188 Drain door drip collector 1
6 24.01.800 Door drip collector 1
9 24.00.171 Silicone buffer 7mm for door 1
10 1005.1966 Countersunk screw Torx M5x16 2
11 10.00.041 Rivet nut M5 hexagon closed 2
16.02.2012
1NAC120 V 60Hz UL
29
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Exterior cabinet
30
16.02.2012
1NAC120 V 60Hz UL
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Exterior cabinet
Pos. Part No. Description Qty.
1 1104.0820 Snap nut 4,2mm 2
3 12.00.205 Upper part of pedestal 4
4 12.01.133 Lower part of pedestal 4
6 10.00.975 Hex screw M10x35 4
7 12.00.516 Turning lock f. lower part of pedestal 4
8 10.00.745 Cap nut M6*A2 1
9 1206.0120 Tooth lock washer A6,4 1
10 16.01.146 Bracket for door contact switch 1
11 1105.0123 Hex combination nut M4 1
13 22.00.767 Vent cover 1
14 16.01.965 Opening mechanism for panel insert 1
18 40.00.335 Door switch 1
A Exterior cabinet 1
16.02.2012
1NAC120 V 60Hz UL
31
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Exterior cabinet
32
16.02.2012
1NAC120 V 60Hz UL
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Exterior cabinet
Pos. Part No. Description Qty.
1 16.02.158 Top cover 1
2 1003.2265 Countersunk self tapping screw 4,2x16 9
3 1104.0820 Snap nut 4,2mm 9
4 1004.2160 Hex self tapping screw 4,2x16 2
5 16.00.135 Side panel right 1
6 1603.0166 Rivet 3,2x7,9 CNS closed 4
7 16.00.136 Side panel left 1
8 10.00.992 Hex self tapping screw B4,2x32 2
9 1104.0820 Snap nut 4,2mm 2
10 16.01.924 Back panel 1
11 16.01.855 Front panel 1
12 1603.0166 Rivet 3,2x7,9 CNS closed 4
15 16.02.098 Crossbar below 1
16 1004.2160 Hex self tapping screw 4,2x16 2
17 1107.0100 Star lock ø4 5
18 50.00.751 Tulip for handshower with tape 1
19 16.00.180 Crossbar top 1
20 1603.0166 Rivet 3,2x7,9 CNS closed 4
22 16.01.748 Gasket f. breather tube d=63mm 1
24 40.02.684 Air inlet filter cpl. 1
25 16.00.329 Cover f. USB interface 1
26 10.00.103 EJOT PT-screw KA 3.5x10 1
27 40.04.046 Interface cable USB 1.0m 1
28 10.00.460 EJOT PT-Screw Torx 3,5x14 2
29 50.00.286 Drip collector 1
30 50.00.303 Bushing drip collector 2
31 50.01.613 Drain pipe with bushing 1
32 50.00.296 Clip f. drip collector 3
16.02.2012
1NAC120 V 60Hz UL
33
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Water
34
16.02.2012
1NAC120 V 60Hz UL
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Water
Pos. Part No. Description Qty.
1 54.01.108 Ventilation pipe 1
2 54.01.141 Rubber form piece venting pipe 1
3 2066.0516 Hose clamp 60-80 mm 2
4 50.00.086 Locking plate f. water distribution 1
5 1900.0202 Water filter 1
6 2066.0205 Hose clamp 8-16x9 mm SW 7mm 1
8 50.00.313 T-fitting water connection 1
9 50.01.607 Hand shower roll guide *lead free* 1
10 50.01.213 Connect. pipe f. hand shower roll guide 1
11 50.00.085 Plug-in spring f. hand shower roll guide 1
12 50.00.130 Hand shower 1
13 50.00.156 Clamp f. hand shower roll guide 1
15 1105.0121 Hex combination nut M5 galv 1
30 54.01.148 Inspection lid, quenching nozzle, B2 1
31 54.01.168 Gasket f. inspection lid quenching 1
32 54.01.191 Collecting pan 1
33 10.00.745 Cap nut M6*A2 1
34 50.01.147 Single solenoid valve 1
35 50.00.071 Water distribution hor. w/o roll guide con. 1
38 2067.0050 Pressure hose d10mm 1.03
39 2067.0050 Pressure hose d10mm .42
47 50.01.146 Single solenoid valve 1
48 50.00.070 Water distribution hor roll guide con. 1
49 2067.0050 Pressure hose d10mm .31
50 50.00.078 Non return valve DW16/DN12 2
51 8354.1304 Venting valve for steam generator 1
52 1900.0202 Water filter 2
55 2022.0101 Grommet d8mm 1
16.02.2012
1NAC120 V 60Hz UL
35
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
CleanJet + Care
36
16.02.2012
1NAC120 V 60Hz UL
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
CleanJet + Care
Pos. Part No. Description Qty.
16.02.2012
1NAC120 V 60Hz UL
37
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Gas parts
38
16.02.2012
1NAC120 V 60Hz UL
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Gas parts
Pos. Part No. Description Qty.
1 70.00.566 Blower for burner NRG118 1
3 70.00.566 Blower for burner NRG118 1
4 10.00.990 Hex screw M5x16 Torx T20 4
5 70.00.495 Flange f. burner blower RG118 1
6 10.01.065 Hex nut M5 4
7 70.00.497 Gasket f. blower burner 2
8 70.00.451 Flange f. burner blower RG118 1
9 10.00.065 Countersunk screw Torx T20 M4x12 3
12 70.00.637 Spacer sleeve f. gas burner blower 1
13 70.00.262 O-ring 21.89x2.62 2
14 10.00.068 Countersunk screw Torx T20 M4x40 4
15 10.00.063 Pan head screw Torx T20 M4x25 3
16 10.00.063 Pan head screw Torx T20 M4x25 3
17 10.00.065 Countersunk screw Torx T20 M4x12 3
18 70.00.122 Corrugated hose 390mm 1
19 70.00.090 Corrugated hose 600mm 1
21 10.00.061 Pan head screw Torx T20 M4x12 8
22 10.00.063 Pan head screw Torx T20 M4x25 8
24 74.00.308 Gas connection manifold 2x3/4" 1
25 1006.0762 Hex screw M6x10 2
26 1306.0222 Washer A6,4x15x1,5 2
27 74.00.883 Automatic ignition controller 1
29 10.00.062 Pan head screw Torx T20 M4x20 1
32 70.00.631 Air hose D40x350mm 1
34 70.00.454 Air hose D40x600mm 1
37 70.00.624 Silicone hose ø8x1,6x141mm 1
38 70.00.623 Silicone hose ø8x1,6x115mm 1
40 70.00.188 Hose fitting 3/4"-3/4" 1
43 70.00.221 Air hose fixing device 40mm 2
A Gas valve RH 1
B Gas valve SEP 1
16.02.2012
1NAC120 V 60Hz UL
39
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Gas valve
40
16.02.2012
1NAC120 V 60Hz UL
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Gas valve
Pos. Part No. Description Qty.
1 70.00.577 Gas valve RH 1
2 70.00.255 Premix chamber cover gas f. RG130 1
3 70.00.030 Premix chamber gas f. RG130 1
4 70.00.580 Premix disc gas 1
5 70.00.256 Disc premix chamber-blower RG130 1
16.02.2012
1NAC120 V 60Hz UL
41
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Gas valve
42
16.02.2012
1NAC120 V 60Hz UL
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Gas valve
Pos. Part No. Description Qty.
1 70.00.576 Gas valve SEP 1
2 70.00.255 Premix chamber cover gas f. RG130 1
3 70.00.030 Premix chamber gas f. RG130 1
4 70.00.580 Premix disc gas 1
5 70.00.256 Disc premix chamber-blower RG130 1
6 70.00.108 Disc gas valve-premix chamber 1
7 70.00.261 O-ring 17x1.5 1
16.02.2012
1NAC120 V 60Hz UL
43
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Standard accessory
44
16.02.2012
1NAC120 V 60Hz UL
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Standard accessory
Pos. Part No. Description Qty.
8 10.01.192 Sticker set 1
10 60.71.381 Water connection kit, table unit G/USA 1
16.02.2012
1NAC120 V 60Hz UL
45
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Index
Part-no. Description Page
22.00.941 Air baffle ............................................................... 23....................
70.00.631 Air hose D40x350mm ................................................. 39....................
70.00.454 Air hose D40x600mm ................................................. 39....................
70.00.221 Air hose fixing device 40mm .......................................... 39....................
40.02.684 Air inlet filter cpl. ....................................................... 33....................
22.00.914 Air inlet pipe ........................................................... 11....................
22.00.835 Air sucking ring f. air baffle ............................................ 25....................
10.00.696 Allen screw M4x6 w. Precoat 85 ...................................... 19....................
74.00.883 Automatic ignition controller ........................................... 39....................
16.01.924 Back panel ............................................................. 33....................
70.00.566 Blower for burner NRG118 ............................................ 39....................
16.01.146 Bracket for door contact switch ........................................ 31....................
74.00.821 Burner hot air .......................................................... 17....................
70.00.573 Burner pipe ............................................................ 13....................
72.00.078 Burner steam gen. ..................................................... 13....................
40.03.995 Bus cable 0.85m ....................................................... 7.....................
50.00.303 Bushing drip collector .................................................. 33....................
20.01.411 Bushing for motor mounting bar ....................................... 21....................
40.04.048 Buzzer ................................................................. 7.....................
10.00.111 Cable clip long ......................................................... 11....................
10.00.112 Cable clip short ........................................................ 21....................
40.00.320 Cable connection M20x1.5 ............................................ 7.....................
40.03.817 Cable control harness ................................................. 9.....................
40.04.181 Cable harness isolating transformer ................................... 9.....................
10.01.076 Cap nut M5*A2 ........................................................ 23....................
10.00.745 Cap nut M6*A2 ........................................................ 31, 35................
50.00.156 Clamp f. hand shower roll guide ....................................... 35....................
10.00.087 Clamp strap f. sensor .................................................. 23....................
50.00.296 Clip f. drip collector .................................................... 33....................
44.01.031 Closing cap for steam generator ...................................... 13....................
54.01.191 Collecting pan ......................................................... 35....................
2001.0109 Compression spring ................................................... 27....................
46
1NAC120 V 60Hz UL
16.02.2012
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Index
Part-no. Description Page
50.01.213 Connect. pipe f. hand shower roll guide ............................... 35....................
40.03.761 Contactor 3TG1010-3AK2 ............................................. 9......................
40.03.322 Contactor assembly ................................................... 9......................
87.01.006 Control panel insert with overlay *RAT* ............................... 5......................
42.00.161 Control pcb ............................................................ 5......................
40.03.348 Control transformer T1 ................................................ 9......................
40.03.257 Converter 230VAC 24VDC ............................................ 7......................
40.03.428 Cooling fan ............................................................ 7......................
1315.0104 Copper washer 16x20x1,5 ............................................ 23....................
70.00.122 Corrugated hose 390mm .............................................. 39....................
70.00.090 Corrugated hose 600mm .............................................. 39....................
1005.1966 Countersunk screw Torx M5x16....................................... 29....................
1006.1962 Countersunk screw Torx M6x16....................................... 27....................
10.00.065 Countersunk screw Torx T20 M4x12 .................................. 39....................
10.00.068 Countersunk screw Torx T20 M4x40 .................................. 39....................
1003.2265 Countersunk self tapping screw 4,2x16 ............................... 33....................
16.00.329 Cover f. USB interface................................................. 33....................
16.02.098 Crossbar below ........................................................ 33....................
16.00.180 Crossbar top ........................................................... 33....................
16.00.282 Dial .................................................................... 5......................
70.00.108 Disc gas valve-premix chamber ....................................... 43....................
70.00.256 Disc premix chamber-blower RG130 .................................. 41, 43................
5110.1027 Distance plate for front panel .......................................... 5......................
24.00.088 Door ................................................................... 27....................
24.00.137 Door bolt ............................................................... 27....................
24.00.048 Door bolt ............................................................... 27....................
24.00.142 Door catch ............................................................. 27....................
24.01.800 Door drip collector ..................................................... 29....................
20.01.800 Door gasket............................................................ 23....................
24.00.152 Door handle ........................................................... 27....................
24.00.176 Door lock .............................................................. 27....................
24.00.223 Door mounting support bottom ........................................ 27....................
16.02.2012
1NAC120 V 60Hz UL
47
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Index
Part-no. Description Page
24.00.133 Door mounting support top ............................................ 27....................
24.00.146 Door setting bolt ....................................................... 29....................
40.00.335 Door switch ............................................................ 31....................
24.01.188 Drain door drip collector ............................................... 29....................
22.00.960 Drain hose for humidity control ........................................ 11....................
44.00.234 Drain hose steam generator ........................................... 13....................
50.01.613 Drain pipe with bushing ................................................ 33....................
50.00.286 Drip collector .......................................................... 33....................
40.02.515 Dry up protector 315°F/157°C ......................................... 9.....................
74.00.873 Earth electrode, hot air ................................................ 19....................
10.00.103 EJOT PT-screw KA 3.5x10 ............................................ 33....................
10.00.460 EJOT PT-Screw Torx 3,5x14 .......................................... 33....................
40.01.483 Electronic noise filter .................................................. 9.....................
44.00.207 Emptying pump ........................................................ 13....................
40.03.660 Fan housing ........................................................... 7.....................
40.03.378 Fan motor .............................................................. 21....................
22.00.828 Fan wheel ............................................................. 21....................
44.00.253 Filling level electrode 85mm ........................................... 13....................
44.01.168 Fixing angle steam generator ......................................... 13....................
40.03.780 Fixing clip core temp. cable ........................................... 25....................
40.01.579 Fixing clip f. pcb ....................................................... 9.....................
24.00.502 Fixing device f. magnet with magnet .................................. 29....................
44.01.248 Fixing device f. pump steam generator ................................ 13....................
44.00.516 Fixing plate steam generator thermostat .............................. 13....................
70.00.495 Flange f. burner blower RG118 ........................................ 39....................
70.00.451 Flange f. burner blower RG118 ........................................ 39....................
22.00.721 Flange f. motor shaft gasket ........................................... 21....................
16.01.855 Front panel ............................................................ 33....................
40.01.487 Fuse holder 2pol ....................................................... 9.....................
40.02.512 Fuse holder 2x6.3A .................................................... 9.....................
40.01.873 Fuse SC-15A 10x38 ................................................... 9.....................
74.00.308 Gas connection manifold 2x3/4" ....................................... 39....................
48
1NAC120 V 60Hz UL
16.02.2012
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Index
Part-no. Description Page
70.00.577 Gas valve RH .......................................................... 41....................
70.00.576 Gas valve SEP ........................................................ 43....................
74.00.290 Gasket electrode hot air ............................................... 19....................
70.00.497 Gasket f. blower burner................................................ 39....................
16.01.748 Gasket f. breather tube d=63mm ...................................... 33....................
72.00.067 Gasket f. burner carrier ................................................ 13....................
74.00.296 Gasket f. heat exchanger below ....................................... 17....................
22.00.881 Gasket f. hum. meas. Pipe ............................................ 11....................
44.00.250 Gasket f. ignition electrode ............................................ 13....................
54.01.168 Gasket f. inspection lid quenching..................................... 35....................
40.00.091 Gasket frame w. glass a. gaskets ..................................... 23....................
74.00.814 Gasket hot air heat exchanger/interior cabinet ........................ 17....................
5110.1029 Gasket mode switch ................................................... 5......................
2022.0101 Grommet d8mm ....................................................... 35....................
3024.0201 Halogen bulb 300°C ................................................... 23....................
50.00.130 Hand shower .......................................................... 35....................
50.01.607 Hand shower roll guide *lead free* .................................... 35....................
1105.0123 Hex combination nut M4............................................... 31....................
1104.0122 Hex combination nut M4 galv.......................................... 11, 13................
1105.0121 Hex combination nut M5 galv.......................................... 13, 35................
1104.0120 Hex nut M4 ............................................................ 13....................
10.00.100 Hex nut M4, self-locking ............................................... 23....................
10.01.065 Hex nut M5 ............................................................ 9, 17, 21, 39..........
1105.0120 Hex nut M5 ............................................................ 13....................
10.00.709 Hex nut M6 w. locking ................................................. 13, 21................
3014.0302 Hex nut M10 for dry-up protector ...................................... 9......................
3014.0327 Hex nut M10x1,0 ...................................................... 9, 23..................
10.00.612 Hex nut M16 flat ....................................................... 23....................
10.00.990 Hex screw M5x16 Torx T20 ........................................... 39....................
1006.0762 Hex screw M6x10 ..................................................... 13, 39................
1006.0760 Hex screw M6x16 ..................................................... 27....................
10.00.099 Hex screw M8x12 ..................................................... 27....................
16.02.2012
1NAC120 V 60Hz UL
49
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Index
Part-no. Description Page
10.00.565 Hex screw M8x20 ..................................................... 21....................
1008.0766 Hex screw M8x30 ..................................................... 7.....................
10.00.975 Hex screw M10x35 .................................................... 31....................
1004.2160 Hex self tapping screw 4,2x16 ........................................ 33....................
10.00.992 Hex self tapping screw B4,2x32 ....................................... 33....................
24.00.141 Holding bracket f. door catch .......................................... 27....................
2066.0205 Hose clamp 8-16x9 mm SW 7mm ..................................... 35....................
2066.0518 Hose clamp 30mm .................................................... 13....................
2066.0519 Hose clamp 35,6mm .................................................. 13....................
2066.0504 Hose clamp 40-60mm ................................................. 13....................
2066.0516 Hose clamp 60-80 mm ................................................ 35....................
10.00.982 Hose clamp D=18.2 ................................................... 13....................
2066.0527 Hose clamp ø14mm ................................................... 11, 15................
2066.0530 Hose clamp ø16.4mm ................................................. 15....................
2066.0526 Hose clamp ø46mm ................................................... 13....................
70.00.188 Hose fitting 3/4"-3/4" ................................................... 39....................
22.00.525 Hose set f. humidity control ............................................ 11....................
74.00.758 Hot air heat exchanger ................................................ 17....................
22.00.725 Humidity control cpl. ................................................... 11....................
44.01.218 Ignition electrode steam generator .................................... 13....................
74.00.034 Ignitionelectrode, hot air ............................................... 19....................
24.00.163 Inner door pane ........................................................ 29....................
54.01.148 Inspection lid, quenching nozzle, B2 .................................. 35....................
72.00.077 Insulation f. burner steam gen. ........................................ 13....................
40.04.046 Interface cable USB 1.0m ............................................. 33....................
1005.2000 Interlocking tooth screw M5x8 ......................................... 27....................
20.01.755 Isolation for mounting plate for motor ................................. 21....................
2062.0331 Junction pressure hose GS 10 ........................................ 15....................
2760.1370 Latch hook for air baffle ............................................... 25....................
24.00.504 Lock cover ............................................................. 27....................
50.00.086 Locking plate f. water distribution ...................................... 35....................
12.01.133 Lower part of pedestal ................................................. 31....................
50
1NAC120 V 60Hz UL
16.02.2012
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Index
Part-no. Description Page
74.00.813 Mating flange heat exchanger ......................................... 17....................
40.04.037 Meat probe sensor .................................................... 23....................
22.00.083 Motor shaft gasket ..................................................... 21....................
40.03.391 Mounting device converter ............................................ 7......................
22.00.882 Mounting device f. pressure sensor ................................... 11....................
22.00.722 Mounting support f. gasket flange ..................................... 21....................
40.03.480 Mounting support power transformer .................................. 7......................
40.03.404 Mounting support transformer ......................................... 9......................
50.00.078 Non return valve DW16/DN12 ......................................... 35....................
70.00.261 O-ring 17x1.5 .......................................................... 43....................
70.00.262 O-ring 21.89x2.62 ..................................................... 39....................
22.00.837 O-ring for humidity control ............................................. 11....................
16.01.965 Opening mechanism for panel insert .................................. 31....................
1008.0768 Ornamental screw M8x16 ............................................. 27....................
1008.0769 Ornamental screw M8x30 ............................................. 27....................
22.00.850 Outer humidity meas. Piece ........................................... 11....................
54.01.117 Outlet sieve ............................................................ 23....................
10.00.365 Pan head screw Torx M3x20 .......................................... 9......................
10.00.061 Pan head screw Torx T20 M4x12 ..................................... 39....................
10.00.062 Pan head screw Torx T20 M4x20 ..................................... 39....................
10.00.063 Pan head screw Torx T20 M4x25 ..................................... 39....................
50.00.085 Plug-in spring f. hand shower roll guide ............................... 35....................
40.00.464 Potentiometer CT ...................................................... 5......................
40.01.597 Power supply cable 3xAWG14 ........................................ 7......................
40.00.279 Power transformer ..................................................... 7......................
70.00.255 Premix chamber cover gas f. RG130 .................................. 41, 43................
70.00.030 Premix chamber gas f. RG130 ........................................ 41, 43................
70.00.580 Premix disc gas........................................................ 41, 43................
2067.0050 Pressure hose d10mm ................................................ 35....................
3017.1011 Pressure sensor for humidity control Huba 401 ....................... 11....................
2118.1000 Pump connection spout ............................................... 15....................
8354.1320 Pump connection spout cpl. ........................................... 13....................
16.02.2012
1NAC120 V 60Hz UL
51
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Index
Part-no. Description Page
40.00.098 Reflector f. interior light ................................................ 23....................
10.00.515 Rivet 3,2x5 A4 ......................................................... 25....................
1603.0166 Rivet 3,2x7,9 CNS closed ............................................. 33....................
1604.0167 Rivet 4x10 ............................................................. 25....................
10.00.041 Rivet nut M5 hexagon closed .......................................... 29....................
54.01.141 Rubber form piece venting pipe ....................................... 35....................
40.01.482 Safety temperature limiter 365°C ...................................... 9, 23.................
40.01.317 Screen core temperature sensor ...................................... 23....................
40.03.782 Screen interior cabinet sensor ......................................... 23....................
16.01.908 Sealing f. panel insert ................................................. 5.....................
16.00.136 Side panel left ......................................................... 33....................
16.00.135 Side panel right ........................................................ 33....................
2110.1008 Silicon hose ø10x2mm ................................................ 15....................
24.00.171 Silicone buffer 7mm for door .......................................... 29....................
70.00.623 Silicone hose ø8x1,6x115mm ......................................... 39....................
70.00.624 Silicone hose ø8x1,6x141mm ......................................... 39....................
50.01.147 Single solenoid valve .................................................. 35....................
50.01.146 Single solenoid valve .................................................. 35....................
24.00.147 Sleeve for door bolt top ................................................ 29....................
1104.0820 Snap nut 4,2mm ....................................................... 31, 33................
70.00.637 Spacer sleeve f. gas burner blower ................................... 39....................
24.01.100 Spring clip f. door lock ................................................. 27....................
10.01.049 Square necked mushroom head bolt 6x30 ............................ 21....................
1107.0100 Star lock ø4 ............................................................ 33....................
44.00.938 Steam generator insolated ............................................ 13....................
2112.1006 Steam hose 50x7mm .................................................. 13....................
44.01.135 Steam pipe ............................................................ 13....................
10.01.192 Sticker set ............................................................. 45....................
2120.1259 Stop plug 10mm ....................................................... 15....................
22.00.491 Surge guard for Meat probe sensor ................................... 25....................
50.00.313 T-fitting water connection .............................................. 35....................
40.00.290 Thermocouple humidity ................................................ 23....................
52
1NAC120 V 60Hz UL
16.02.2012
Combi Master 61 - 6 x 1/1 GastronormG
G61MH1111
Index
Part-no. Description Page
40.04.085 Thermocouple interior cabinet B1 ..................................... 23....................
40.04.108 Thermocouple steam generator *B5*.................................. 13....................
4005.0101 Tie rap 145 mm ........................................................ 15....................
1205.0120 Tooth lock washer A5,3 ............................................... 13....................
1206.0120 Tooth lock washer A6,4 ............................................... 31....................
16.02.158 Top cover .............................................................. 33....................
50.00.751 Tulip for handshower with tape ........................................ 33....................
12.00.516 Turning lock f. lower part of pedestal .................................. 31....................
12.00.205 Upper part of pedestal ................................................. 31....................
22.00.767 Vent cover ............................................................. 11, 31................
54.01.108 Ventilation pipe ........................................................ 35....................
8354.1304 Venting valve for steam generator .................................... 35....................
10.00.744 Washer A4,3 *A4 ...................................................... 25....................
1306.0222 Washer A6,4x15x1,5 .................................................. 13, 39................
1308.0162 Washer A8,4........................................................... 21....................
1308.0160 Washer A8,4........................................................... 27....................
60.71.381 Water connection kit, table unit G/USA................................ 45....................
50.00.070 Water distribution hor roll guide con. .................................. 35....................
50.00.071 Water distribution hor. w/o roll guide con. ............................. 35....................
1900.0202 Water filter ............................................................. 35....................
40.03.531 Wiring interior light..................................................... 23....................
16.02.2012
1NAC120 V 60Hz UL
53
Deckblatt Elektrische Dokumentation, Cover sheet electrical Documentation
Die Elektrische Dokumentation besteht aus: 1. diesem Deckblatt, 2. dem Schaltplan und 3. der Legende der elektrischen Bauteile
The electric documentation contains: 1. this cover sheet, 2. the wiring diagram and 3. the bill of material (BOM)
Deckblatt-Nr.
Front Page No.
75-21243 Version 0
Typ / Type CMP 61G
Schaltplan
Wiring diagram
76-00558 Version 0
Spannung (SPL)
Voltage
1NAC120 V 60 Hz
Legende
Legend electr. components
78-00830 Version 0
Geräteserialnr.
Serial number
G61MH1102 Version 1102
Erstellt am
Created at
Aug 31, 2011 10:30 AM Ersteller
Creator
SCHD
Gültig ab
Valid from
Aug 30, 2011 3:38 PM Änderung
Modification
0123456789
PE / 2.00
M1-F1
M1-F2
XM1
33
22
11
M
~
Y1
X19
WH
M1:BUS / 2.00
A1:BUS / 2.00
X18
44
11
55
22
33 66
BU
XY1
11
22
Y2
A1
A2
WH
XY2
11
A1
A2
BN
BU
BU
BU
22
K1:13 / 2.00
K1:A2 / 3.00
GY
G1
BU
2
XM5
M5
N
+
XG1
33
11
GY
22 11
L1
-
22
M
M4
11
22
44 33
BU
WH
XM4
11
22
M
~
M1
6,3A
6,3A
BN
BU
SXT3
22
T3-F1
0,8A
230V
230V
240V
PXT3
1010
0
BKBKBK
BUBUBU
YE/GNYE/GN
1
3
K1
N/O
2
4
99 88 77 66 55
220V
208V
T3
200V
127V
W19
100V
110V
120V
44 33 221111
0V
0V
F3
F4
A4
S1
X21
11
33
BU
GYRDBN
1
2
1
2
A4-F1
1,6AT
22
RD
BUS
BUS
W17
F1 15A
F2 15A
X0
BK
BU
1
BU
2
K1
12
34
13 14
A1
A2
.00
.00
.05
K1
N/O
BN
1314
W0
Z1
Erstellt von
76-00558
MODUL 1
CMP 61/101G-UL
Leistung/Power
0Version
1NAC120 V 60 Hz
Created by
Datum
Date
Blatt
Page
SCHD
12.10.2011
1
3.00 / K1:13
/ K1:A2
1.08 / PE
1.07 / K1:13
1.08 / A1:BUS
1.08 / M1:BUS
0123456789
BN
BU
YE/GN
BU
YE/GN
0
XM8
11BN22
L1 PE N
M
1
~
33
GND
U/min
PWM
XA5
5pol.XM8
33
3
22
2
44
14
1WH2BU3
HL 1
YE/GN
XM9
4
A5
RJ 45
RJ 45
BUSBUSPENL1
5pol.XM9
33
6
22
5
D
44
GND
U/min
PWM
M8
B12
Y12
76-00558
MODUL 2
CMP 61/101G-UL
Heizung/Heating
0Version
1NAC120 V 60 Hz
B11
Y11
Erstellt von
Created by
Datum
Date
Blatt
Page
BU
YE/GN
11BN22
L1 PE N
M
1
~
M9
33
SCHD
12.10.2011
2
0123456789
P1
P
Signal
IN GND
XP1
11
22
33
A4
X1
X14
11
22
33
44
0
T1
T1-F1
2AT
PXT1
GY
GY
WH
WH
T1-F2
11,5V
SXT1
250V
7
5AT
18V
4
3
2
1
.
.
.
.
.
.
.
.
240V
230V
6
5
0
220V
208V
200V
4
3
2
1 N
GY
GY
GY
11
22
33
X3
22WH11
S2
Y5
S3
H1
W11
WH
YE/GN
44
X12
X4
GN
GY
WH
33
22
11
33
22
11
GN
WH
WH
WH
114422
33
44
X11
X5
55
33
22
11
GN
WH
X6
44 33B522
WH
X27
WH
WH
11
11
GN
BN
22
11
22
X13
X2
77
66BU55T244
WH
YE/GN
X8
11
33WH22 11
WH
22
Option Thermoelement Sousvide
X50
44 33
22 11
YE
Option Thermocouple Sousvide
X2
77
W23
YE/GN
7
X2.0
7
X2.1
66
55
44
33
22
11
6
5
4
3
2
1
6
5
4
3
2
1
EEPROM
2.00 / K1:13
1.07 / K1:A2
BN
BU
76-00558
B1
MODUL 3
Sensoren/Sensors
0Version
B2
B4
B3
CMP 61/101G-UL
1NAC120 V 60 Hz
Erstellt von
Created by
Datum
Date
Blatt
Page
B7
SCHD
12.10.2011
3
Positionsliste
Bill of material
Änderungsdatum 30.08.2011 Name CMP 61G-UL Dokument-Nr. 78-00830
Erzeuger SCHD Spannung 1NAC120 V 60 Hz Version 0
Seite 1 von
2
Name
Name
Artikelnr.
Item number
Artikelbezeichnung
Item description
Module
Modul
-A4 42.00.161 Bedienplatine CMP Operator PCB CMP Modul 1
-A4-F1 3019.0125 Sicherung 1,6AT Fuse 1,6AT Modul 1
-A5 74.00.883 Feuerungsautomat Brenner 61-202 Ignition box Modul 2
-B1 40.04.085 Thermoelement Garraum Thermocouple interior cabinet Modul 3
-B2 54.01.148 Thermoelement Ablöschung Thermocouple quenching Modul 3
-B3 40.04.037 Thermoelement Kerntemperatur Thermocouple core sensor Modul 3
-B4 40.00.290 Thermoelement Feuchte Thermocouple humidity Modul 3
-B5 40.04.108 Thermoelement Dampfgenerator Thermocouple steam generator Modul 3
-F1/F2 40.01.873 Steuersicherung Control fuse Modul 1
-F3 40.02.515 Sicherheitstemperaturbegrenzer Gas:157°C/314°
F Elek.:183°C/360°F
Safety thermostat steam generator Gas: 157°C/
314°F Elec.: 183°C/360°F
Modul 1
-F4 40.01.482 Sicherheitstemperaturbegrenzer 360°C/680°F Safety thermostat interior cabinet 360°C/680°F Modul 1
-G1 40.03.257 Gleichrichter Kühllüfter DC converter cooling fan Modul 1
-H1 3024.0201 Garraumbeleuchtung Interior cabinet light Modul 3
-K1 40.03.761 Hauptschütz Main contactor Modul 1
-M1 40.03.378 Lüftermotor Fan motor Modul 1
-M4 44.00.207 SC-Pumpe SC-pump Modul 1
-M5 40.03.428 Kühllüfter Cooling fan Modul 1
-M8 70.00.566 Gasgebläse HL Gas blower hot air Modul 2
-M9 70.00.566 Gasgebläse DG Gas blower steam Modul 2
-P1 3017.1011 Differenzdrucksensor Differential pressure sensor Modul 3
-S2 44.00.253 Niveauelektrode Water level electrode Modul 3
-S3 40.00.335 Türkontaktschalter Door contact switch Modul 3
Positionsliste
Bill of material
Änderungsdatum 30.08.2011 Name CMP 61G-UL Dokument-Nr. 78-00830
Erzeuger SCHD Spannung 1NAC120 V 60 Hz Version 0
Seite 2 von
2
Name
Name
Artikelnr.
Item number
Artikelbezeichnung
Item description
Module
Modul
-S7 40.00.464 Potentiometer Zeit / Kerntemperatur Time / Core potentiometer Modul 3
-T1 40.03.348 Steuertrafo Control transformer Modul 3
-T1-F1 3019.0120 Sicherung Steuertrafo T1 2AT Fuse control transformer T1 2AT Modul 3
-T1-F2 3019.0126 Sicherung Steuertrafo T1 5AT Fuse control transformer T1 5AT Modul 3
-T2 40.04.048 SCC WE: Lautsprecher / CMP: Alarmsummer SCC WE: Speaker / CMP: Buzzer Modul 3
-T3 40.00.279 Sondertrafo Special transformer Modul 1
-T3-F1 3019.0124 Sicherung Sondertrafo T3 Fuse special transformer Modul 1
-W0 40.01.597 Anschlusskabel Cable: power supply Modul 1
-W11 40.03.531 Kabel: Garraumbeleuchtung Cable: interior cabinet light Modul 3
-W17 40.03.817 Kabel: Steuerstamm Cable: control harness Modul 1
-W19 40.04.181 Kabel: Zusatzstamm Gas Cable: power supply gas Modul 1
-Y1 50.01.147 Magnetventil Füllen Solenoid valve filling Modul 1
-Y11 70.00.576 Gasventil D Gas valve steam Modul 2
-Y12/Y13 70.00.577 Y12: Gasventil HL1 / Y13: Gasventil HL2 201/
202G
Y12: Gas valve hot air / Y13: Gas valve hot air
(bottom)
Modul 2
-Y2 50.01.146 Magnetventil Ablöschung Solenoid valve quenching Modul 1
-Y5 22.00.725 Klimaventil Clima valve Modul 3
-Z1 40.01.483 Entstörfilter/Varistor Electronic noise filter Modul 1
Loading...
