Service part catalogue
SelfCookingCenter® whitefficiency®
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
2/15/2012
3 AC208V (240V) 60Hz UL
CD-Ges_101207
©Copyright by RATIONAL Technical Service
All Rights reserved
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
SelfCookingCenter® whitefficiency®
2
3 AC208V (240V) 60Hz UL
2/15/2012
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
SelfCookingCenter® whitefficiency®
Pos. Part No. Description Qty.
1 Control panel 1
2 Electrical installation 1
3 ClimaPlus 1
4 Steam generator 1
5 Hot air heating 1
6 Motor and fan wheel 1
7 Interior cabinet 1
8 Door 1
9 Exterior cabinet 1
10 Water 1
11 CleanJet + Care 1
13 Standard accessory 1
2/15/2012
3 AC208V (240V) 60Hz UL
3
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Control panel
4
3 AC208V (240V) 60Hz UL
2/15/2012
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Control panel
Pos. Part No. Description Qty.
1 87.01.006 Control panel insert with overlay *RAT* 1
2 42.00.090 Control pcb *Sicotronic* 1
7 16.00.282 Dial 3
8 5110.1027 Distance plate for front panel 2
10 40.00.464 Potentiometer CT 1
11 5110.1029 Gasket mode switch 2
13 16.01.908 Sealing f. panel insert 1
2/15/2012
3 AC208V (240V) 60Hz UL
5
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Electrical installation
6
3 AC208V (240V) 60Hz UL
2/15/2012
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Electrical installation
Pos. Part No. Description Qty.
1 40.00.453 Solid state relais 3
2 10.00.061 Pan head screw Torx T20 M4x12 6
3 10.00.061 Pan head screw Torx T20 M4x12 2
4 1204.0120 Tooth lock washer A4,3 2
5 40.03.932 Heat sink big 2 SSR 2
6 40.03.371 Mounting device heat sink SSR 1
7 10.00.507 Pan head screw Torx 5/16" T20 9
8 40.03.373 Fan housing *UL* 1
9 40.03.428 Cooling fan 1
10 40.03.257 Converter 230VAC 24VDC 1
24 40.03.996 Bus cable 1.15m 1
35 40.04.048 Buzzer 1
A Electrical installation 1
2/15/2012
3 AC208V (240V) 60Hz UL
7
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Electrical installation
8
3 AC208V (240V) 60Hz UL
2/15/2012
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Electrical installation
Pos. Part No. Description Qty.
1 40.03.322 Contactor assembly 1
2 40.03.981 Cable clock switch USA 1
6 40.03.812 Cable control harness 1
8 40.01.329 Dry up protector 183° 1
9 3014.0302 Hex nut M10 for dry-up protector 1
10 40.01.482 Safety temperature limiter 365°C 1
11 3014.0327 Hex nut M10x1,0 1
12 40.03.669 Contactor B&J K3-40B00 190 R 1
13 40.02.641 Auxilliary contact B&J HN10 N/O 1
17 40.03.348 Control transformer T1 1
18 10.01.065 Hex nut M5 1
19 40.03.404 Mounting support transformer 1
20 10.01.065 Hex nut M5 1
21 40.02.425 Varistor 1
25 4001.0224 Fuse 6.35x32mm 2
25 40.01.588 Fuse SC-8A 10x38 2
26 40.02.512 Fuse holder 2x6.3A 1
26 40.01.487 Fuse holder 2pol 1
29 10.00.365 Pan head screw Torx M3x20 2
37 40.03.729 Terminal block grey WKN 35/U 3
39 40.03.731 Earth terminal WKN 35SL/U 1
47 40.03.282 Drip protection for air inlet filter 1 UL 1
48 10.00.709 Hex nut M6 w. locking 1
49 10.01.218 Edge protection profile 1
50 40.03.755 Cover behind 2 UL 1
51 10.00.365 Pan head screw Torx M3x20 2
54 40.04.122 Cover for Fuse *UL* 2
2/15/2012
3 AC208V (240V) 60Hz UL
9
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
ClimaPlus
10
2/15/2012
3 AC208V (240V) 60Hz UL
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
ClimaPlus
Pos. Part No. Description Qty.
1 22.00.882 Mounting device f. pressure sensor 1
2 3017.1011 Pressure sensor for humidity control Huba 401 1
4 22.00.850 Outer humidity meas. Piece 1
5 22.00.881 Gasket f. hum. meas. Pipe 1
6 1104.0122 Hex combination nut M4 galv 3
7 22.00.525 Hose set f. humidity control 1
8 22.00.725 Humidity control cpl. 1
9 22.00.915 Air inlet pipe 1
10 22.00.960 Drain hose for humidity control 1
11 2066.0527 Hose clamp ø14mm 2
12 22.00.767 Vent cover 1
13 22.00.837 O-ring for humidity control 2
15 10.00.111 Cable clip long 2
2/15/2012
3 AC208V (240V) 60Hz UL
11
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Steam generator
12
2/15/2012
3 AC208V (240V) 60Hz UL
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Steam generator
Pos. Part No. Description Qty.
1 44.00.941 Steam generator insolated 1
2 10.00.709 Hex nut M6 w. locking 2
14 44.01.347 Heating element 1
15 44.01.374 Heating element w/o pipe 1
17 44.00.280 Gasket f. heating element+Level elektrode insert 2
18 10.00.709 Hex nut M6 w. locking 10
19 2066.0519 Hose clamp 35,6mm 1
20 2066.0526 Hose clamp ø46mm 1
21 44.00.207 Emptying pump 1
22 1006.0762 Hex screw M6x10 2
23 1306.0222 Washer A6,4x15x1,5 2
24 44.00.232 Fixing device f. pump steam generator 1
25 10.00.709 Hex nut M6 w. locking 2
26 44.01.221 Drain hose steam generator 1
27 40.04.106 Thermocouple steam generator *B5* 1
29 10.00.414 Cable strap black 120° 1
30 1104.0122 Hex combination nut M4 galv 1
31 2112.1006 Steam hose 50x7mm 1
32 2066.0504 Hose clamp 40-60mm 2
34 44.00.280 Gasket f. heating element+Level elektrode insert 1
35 2920.1300 Level elektrode insert 1
36 10.00.709 Hex nut M6 w. locking 4
37 44.01.407 Filling level electrode 90mm 1
38 44.01.168 Fixing angle steam generator 1
39 44.01.181 Fixing angle steam generator 1
40 44.01.031 Closing cap for steam generator 1
41 10.00.982 Hose clamp D=18.2 1
43 2066.0518 Hose clamp 30mm 2
A 8354.1320 Pump connection spout cpl. 1
2/15/2012
3 AC208V (240V) 60Hz UL
13
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Pump connection spout
14
2/15/2012
3 AC208V (240V) 60Hz UL
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Pump connection spout
Pos. Part No. Description Qty.
1 2118.1000 Pump connection spout 1
2 2120.1259 Stop plug 10mm 1
3 2110.1008 Silicon hose ø10x2mm 1
4 2066.0527 Hose clamp ø14mm 2
5 2066.0530 Hose clamp ø16.4mm 1
6 2062.0331 Junction pressure hose GS 10 1
7 4005.0101 Tie rap 145 mm 1
2/15/2012
3 AC208V (240V) 60Hz UL
15
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Hot air heating
16
2/15/2012
3 AC208V (240V) 60Hz UL
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Hot air heating
Pos. Part No. Description Qty.
1 40.03.410 Mating flange f. heating assembly 1
2 40.03.639 Heating assembly 1
4 10.00.109 Hex screw M5x23 6
5 10.01.076 Cap nut M5*A2 1
6 40.03.415 Gasket f. heating assembly 1
7 1107.0103 Star lock ø3 2
2/15/2012
3 AC208V (240V) 60Hz UL
17
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Motor and fan wheel
18
2/15/2012
3 AC208V (240V) 60Hz UL
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Motor and fan wheel
Pos. Part No. Description Qty.
1 40.03.378 Fan motor 1
3 10.01.049 Square necked mushroom head bolt 6x30 4
4 10.00.709 Hex nut M6 w. locking 2
5 22.00.721 Flange f. motor shaft gasket 1
6 22.00.722 Mounting support f. gasket flange 1
7 22.00.083 Motor shaft gasket 1
8 20.01.755 Isolation for mounting plate for motor 1
9 10.01.065 Hex nut M5 3
10 22.00.828 Fan wheel 1
11 10.00.565 Hex screw M8x20 1
12 1308.0162 Washer A8,4 1
13 10.00.111 Cable clip long 3
14 20.01.411 Bushing for motor mounting bar 4
2/15/2012
3 AC208V (240V) 60Hz UL
19
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Interior cabinet
20
2/15/2012
3 AC208V (240V) 60Hz UL
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Interior cabinet
Pos. Part No. Description Qty.
1 40.00.290 Thermocouple humidity 1
2 10.00.087 Clamp strap f. sensor 1
3 10.00.100 Hex nut M4, self-locking 1
7 40.03.531 Wiring interior light 1
8 40.00.098 Reflector f. interior light 1
9 40.00.091 Gasket frame w. glass a. gaskets 1
10 3024.0201 Halogen bulb 300°C 1
11 20.01.802 Door gasket 1
12 40.04.039 Meat probe sensor 1
13 10.00.612 Hex nut M16 flat 1
14 1315.0104 Copper washer 16x20x1,5 1
16 40.01.317 Screen core temperature sensor 1
17 10.01.076 Cap nut M5*A2 2
20 40.03.488 Thermocouple interior cabinet B1 1
21 40.03.782 Screen interior cabinet sensor 1
22 10.01.076 Cap nut M5*A2 2
23 54.01.117 Outlet sieve 1
24 40.01.482 Safety temperature limiter 365°C 1
25 3014.0327 Hex nut M10x1,0 1
A 22.00.924 Air baffle 1
2/15/2012
3 AC208V (240V) 60Hz UL
21
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Air baffle
22
2/15/2012
3 AC208V (240V) 60Hz UL
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Air baffle
Pos. Part No. Description Qty.
4 22.00.734 Hand protection 1
6 10.00.515 Rivet 3,2x5 A4 4
7 40.03.780 Fixing clip core temp. cable 1
8 22.00.491 Surge guard for Meat probe sensor 1
9 2760.1370 Latch hook for air baffle 2
10 1604.0167 Rivet 4x10 3
13 10.00.744 Washer A4,3 *A4 1
2/15/2012
3 AC208V (240V) 60Hz UL
23
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Door
24
2/15/2012
3 AC208V (240V) 60Hz UL
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Door
Pos. Part No. Description Qty.
1 24.00.152 Door handle 1
2 24.00.176 Door lock 1
6 24.00.504 Lock cover 1
8 24.00.133 Door mounting support top 1
9 1008.0768 Ornamental screw M8x16 3
11 24.00.223 Door mounting support bottom 1
12 1006.1962 Countersunk screw Torx M6x16 2
14 24.00.137 Door bolt 1
15 10.00.099 Hex screw M8x12 1
16 1308.0160 Washer A8,4 1
17 24.00.048 Door bolt 1
18 1008.0769 Ornamental screw M8x30 1
20 2001.0109 Compression spring 1
21 24.00.141 Holding bracket f. door catch 1
22 1006.0760 Hex screw M6x16 2
24 24.00.142 Door catch 1
25 1005.2000 Interlocking tooth screw M5x8 1
27 24.01.100 Spring clip f. door lock 1
A 24.00.093 Door 1
2/15/2012
3 AC208V (240V) 60Hz UL
25
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Door
26
2/15/2012
3 AC208V (240V) 60Hz UL
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Door
Pos. Part No. Description Qty.
1 24.00.164 Inner glass pane 1
2 24.00.147 Sleeve for door bolt top 1
3 24.00.146 Door setting bolt 1
4 24.00.502 Fixing device f. magnet with magnet 1
5 24.01.188 Drain door drip collector 1
6 24.01.800 Door drip collector 1
9 24.00.171 Silicone buffer 7mm for door 1
10 1005.1966 Countersunk screw Torx M5x16 2
11 10.00.041 Rivet nut M5 hexagon closed 2
2/15/2012
3 AC208V (240V) 60Hz UL
27
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Exterior cabinet
28
2/15/2012
3 AC208V (240V) 60Hz UL
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Exterior cabinet
Pos. Part No. Description Qty.
1 1104.0820 Snap nut 4,2mm 2
3 12.00.205 Upper part of pedestal 4
4 12.01.133 Lower part of pedestal 4
6 10.00.975 Hex screw M10x35 4
7 12.00.516 Turning lock f. lower part of pedestal 4
8 10.00.745 Cap nut M6*A2 1
9 1206.0120 Tooth lock washer A6,4 1
10 16.01.146 Bracket for door contact switch 1
11 1105.0123 Hex combination nut M4 1
13 22.00.767 Vent cover 1
14 16.01.965 Opening mechanism for panel insert 1
18 40.00.335 Door switch 1
A Exterior cabinet 1
2/15/2012
3 AC208V (240V) 60Hz UL
29
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Exterior cabinet
30
2/15/2012
3 AC208V (240V) 60Hz UL
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Exterior cabinet
Pos. Part No. Description Qty.
1 16.02.152 Top cover 1
2 1003.2265 Countersunk self tapping screw 4,2x16 9
3 1104.0820 Snap nut 4,2mm 9
5 16.00.127 Side panel right 1
6 1603.0166 Rivet 3,2x7,9 CNS closed 4
7 16.00.128 Side panel left 1
8 10.00.992 Hex self tapping screw B4,2x32 2
9 1104.0820 Snap nut 4,2mm 2
10 16.01.926 Back panel 1
11 16.01.857 Front panel 1
12 1603.0166 Rivet 3,2x7,9 CNS closed 4
15 16.02.098 Crossbar below 1
16 1004.2160 Hex self tapping screw 4,2x16 2
17 1107.0100 Star lock ø4 5
18 50.00.751 Tulip for handshower with tape 1
19 16.00.180 Crossbar top 1
20 1603.0166 Rivet 3,2x7,9 CNS closed 4
22 16.01.748 Gasket f. breather tube d=63mm 1
24 40.02.684 Air inlet filter cpl. 1
25 16.00.329 Cover f. USB interface 1
26 10.00.103 EJOT PT-screw KA 3.5x10 1
27 40.04.046 Interface cable USB 1.0m 1
28 10.00.460 EJOT PT-Screw Torx 3,5x14 2
29 50.00.286 Drip collector 1
30 50.00.303 Bushing drip collector 2
31 50.01.613 Drain pipe with bushing 1
32 50.00.296 Clip f. drip collector 3
2/15/2012
3 AC208V (240V) 60Hz UL
31
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Water
32
2/15/2012
3 AC208V (240V) 60Hz UL
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Water
Pos. Part No. Description Qty.
1 54.01.110 Ventilation pipe 1
2 54.01.141 Rubber form piece venting pipe 1
3 2066.0516 Hose clamp 60-80 mm 2
4 50.00.086 Locking plate f. water distribution 1
5 1900.0202 Water filter 1
6 2066.0205 Hose clamp 8-16x9 mm SW 7mm 1
8 50.00.313 T-fitting water connection 1
9 50.01.607 Hand shower roll guide *lead free* 1
10 50.01.213 Connect. pipe f. hand shower roll guide 1
11 50.00.085 Plug-in spring f. hand shower roll guide 1
12 50.00.130 Hand shower 1
13 50.00.156 Clamp f. hand shower roll guide 1
15 1105.0121 Hex combination nut M5 galv 1
30 54.01.148 Inspection lid, quenching nozzle, B2 1
31 54.01.168 Gasket f. inspection lid quenching 1
32 54.01.191 Collecting pan 1
33 10.00.745 Cap nut M6*A2 1
34 50.01.147 Single solenoid valve 1
35 50.00.071 Water distribution hor. w/o roll guide con. 1
38 2067.0050 Pressure hose d10mm 1.35
39 2067.0050 Pressure hose d10mm .65
47 50.01.146 Single solenoid valve 1
48 50.00.070 Water distribution hor roll guide con. 1
49 2067.0050 Pressure hose d10mm .31
50 50.00.078 Non return valve DW16/DN12 2
51 8354.1304 Venting valve for steam generator 1
52 1900.0202 Water filter 2
55 2022.0101 Grommet d8mm 1
2/15/2012
3 AC208V (240V) 60Hz UL
33
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
CleanJet + Care
34
2/15/2012
3 AC208V (240V) 60Hz UL
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
CleanJet + Care
Pos. Part No. Description Qty.
2/15/2012
3 AC208V (240V) 60Hz UL
35
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Standard accessory
36
2/15/2012
3 AC208V (240V) 60Hz UL
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Standard accessory
Pos. Part No. Description Qty.
8 10.01.191 Sticker set 1
10 60.71.379 Water connection kit, table unit E/USA 1
10 60.71.379 Water connection kit, table unit E/USA 1
2/15/2012
3 AC208V (240V) 60Hz UL
37
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Index
Part-no. Description Page
22.00.924 Air baffle ............................................................... 21....................
40.02.684 Air inlet filter cpl. ....................................................... 31....................
22.00.915 Air inlet pipe ........................................................... 11....................
40.02.641 Auxilliary contact B&J HN10 N/O ...................................... 9.....................
16.01.926 Back panel ............................................................. 31....................
16.01.146 Bracket for door contact switch ........................................ 29....................
40.03.996 Bus cable 1.15m ....................................................... 7.....................
50.00.303 Bushing drip collector .................................................. 31....................
20.01.411 Bushing for motor mounting bar ....................................... 19....................
40.04.048 Buzzer ................................................................. 7.....................
10.00.111 Cable clip long ......................................................... 11, 19................
40.03.981 Cable clock switch USA ............................................... 9.....................
40.03.812 Cable control harness ................................................. 9.....................
10.00.414 Cable strap black 120° ................................................ 13....................
10.01.076 Cap nut M5*A2 ........................................................ 17, 21................
10.00.745 Cap nut M6*A2 ........................................................ 29, 33................
50.00.156 Clamp f. hand shower roll guide ....................................... 33....................
10.00.087 Clamp strap f. sensor .................................................. 21....................
50.00.296 Clip f. drip collector .................................................... 31....................
44.01.031 Closing cap for steam generator ...................................... 13....................
54.01.191 Collecting pan ......................................................... 33....................
2001.0109 Compression spring ................................................... 25....................
50.01.213 Connect. pipe f. hand shower roll guide ............................... 33....................
40.03.322 Contactor assembly ................................................... 9.....................
40.03.669 Contactor B&J K3-40B00 190 R ....................................... 9.....................
87.01.006 Control panel insert with overlay *RAT* ............................... 5.....................
42.00.090 Control pcb *Sicotronic* ............................................... 5.....................
40.03.348 Control transformer T1 ................................................ 9.....................
40.03.257 Converter 230VAC 24VDC ............................................ 7.....................
40.03.428 Cooling fan ............................................................ 7.....................
1315.0104 Copper washer 16x20x1,5 ............................................ 21....................
1005.1966 Countersunk screw Torx M5x16 ....................................... 27....................
38
3 AC208V (240V) 60Hz UL
2/15/2012
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Index
Part-no. Description Page
1006.1962 Countersunk screw Torx M6x16....................................... 25....................
1003.2265 Countersunk self tapping screw 4,2x16 ............................... 31....................
40.03.755 Cover behind 2 UL .................................................... 9......................
16.00.329 Cover f. USB interface................................................. 31....................
40.04.122 Cover for Fuse *UL* ................................................... 9......................
16.02.098 Crossbar below ........................................................ 31....................
16.00.180 Crossbar top ........................................................... 31....................
16.00.282 Dial .................................................................... 5......................
5110.1027 Distance plate for front panel .......................................... 5......................
24.00.093 Door ................................................................... 25....................
24.00.137 Door bolt ............................................................... 25....................
24.00.048 Door bolt ............................................................... 25....................
24.00.142 Door catch ............................................................. 25....................
24.01.800 Door drip collector ..................................................... 27....................
20.01.802 Door gasket............................................................ 21....................
24.00.152 Door handle ........................................................... 25....................
24.00.176 Door lock .............................................................. 25....................
24.00.223 Door mounting support bottom ........................................ 25....................
24.00.133 Door mounting support top ............................................ 25....................
24.00.146 Door setting bolt ....................................................... 27....................
40.00.335 Door switch ............................................................ 29....................
24.01.188 Drain door drip collector ............................................... 27....................
22.00.960 Drain hose for humidity control ........................................ 11....................
44.01.221 Drain hose steam generator ........................................... 13....................
50.01.613 Drain pipe with bushing................................................ 31....................
50.00.286 Drip collector .......................................................... 31....................
40.03.282 Drip protection for air inlet filter 1 UL .................................. 9......................
40.01.329 Dry up protector 183°.................................................. 9......................
40.03.731 Earth terminal WKN 35SL/U........................................... 9......................
10.01.218 Edge protection profile ................................................ 9......................
10.00.103 EJOT PT-screw KA 3.5x10 ............................................ 31....................
10.00.460 EJOT PT-Screw Torx 3,5x14 .......................................... 31....................
2/15/2012
3 AC208V (240V) 60Hz UL
39
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Index
Part-no. Description Page
44.00.207 Emptying pump ........................................................ 13....................
40.03.373 Fan housing *UL* ...................................................... 7.....................
40.03.378 Fan motor .............................................................. 19....................
22.00.828 Fan wheel ............................................................. 19....................
44.01.407 Filling level electrode 90mm ........................................... 13....................
44.01.168 Fixing angle steam generator ......................................... 13....................
44.01.181 Fixing angle steam generator ......................................... 13....................
40.03.780 Fixing clip core temp. cable ........................................... 23....................
24.00.502 Fixing device f. magnet with magnet .................................. 27....................
44.00.232 Fixing device f. pump steam generator ................................ 13....................
22.00.721 Flange f. motor shaft gasket ........................................... 19....................
16.01.857 Front panel ............................................................ 31....................
4001.0224 Fuse 6.35x32mm ...................................................... 9.....................
40.01.487 Fuse holder 2pol ....................................................... 9.....................
40.02.512 Fuse holder 2x6.3A .................................................... 9.....................
40.01.588 Fuse SC-8A 10x38 .................................................... 9.....................
16.01.748 Gasket f. breather tube d=63mm ...................................... 31....................
40.03.415 Gasket f. heating assembly ............................................ 17....................
44.00.280 Gasket f. heating element+Level elektrode insert ..................... 13....................
22.00.881 Gasket f. hum. meas. Pipe ............................................ 11....................
54.01.168 Gasket f. inspection lid quenching ..................................... 33....................
40.00.091 Gasket frame w. glass a. gaskets ..................................... 21....................
5110.1029 Gasket mode switch ................................................... 5.....................
2022.0101 Grommet d8mm ....................................................... 33....................
3024.0201 Halogen bulb 300°C ................................................... 21....................
22.00.734 Hand protection ........................................................ 23....................
50.00.130 Hand shower .......................................................... 33....................
50.01.607 Hand shower roll guide *lead free* .................................... 33....................
40.03.932 Heat sink big 2 SSR ................................................... 7.....................
40.03.639 Heating assembly ..................................................... 17....................
44.01.347 Heating element ....................................................... 13....................
44.01.374 Heating element w/o pipe ............................................. 13....................
40
3 AC208V (240V) 60Hz UL
2/15/2012
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Index
Part-no. Description Page
1105.0123 Hex combination nut M4............................................... 29....................
1104.0122 Hex combination nut M4 galv.......................................... 11, 13................
1105.0121 Hex combination nut M5 galv.......................................... 33....................
10.00.100 Hex nut M4, self-locking ............................................... 21....................
10.01.065 Hex nut M5 ............................................................ 9, 19..................
10.00.709 Hex nut M6 w. locking ................................................. 9, 13, 19..............
3014.0302 Hex nut M10 for dry-up protector ...................................... 9......................
3014.0327 Hex nut M10x1,0 ...................................................... 9, 21..................
10.00.612 Hex nut M16 flat ....................................................... 21....................
10.00.109 Hex screw M5x23 ..................................................... 17....................
1006.0762 Hex screw M6x10 ..................................................... 13....................
1006.0760 Hex screw M6x16 ..................................................... 25....................
10.00.099 Hex screw M8x12 ..................................................... 25....................
10.00.565 Hex screw M8x20 ..................................................... 19....................
10.00.975 Hex screw M10x35 .................................................... 29....................
1004.2160 Hex self tapping screw 4,2x16 ........................................ 31....................
10.00.992 Hex self tapping screw B4,2x32 ....................................... 31....................
24.00.141 Holding bracket f. door catch .......................................... 25....................
2066.0205 Hose clamp 8-16x9 mm SW 7mm..................................... 33....................
2066.0518 Hose clamp 30mm .................................................... 13....................
2066.0519 Hose clamp 35,6mm .................................................. 13....................
2066.0504 Hose clamp 40-60mm ................................................. 13....................
2066.0516 Hose clamp 60-80 mm ................................................ 33....................
10.00.982 Hose clamp D=18.2 ................................................... 13....................
2066.0527 Hose clamp ø14mm ................................................... 11, 15................
2066.0530 Hose clamp ø16.4mm ................................................. 15....................
2066.0526 Hose clamp ø46mm ................................................... 13....................
22.00.525 Hose set f. humidity control............................................ 11....................
22.00.725 Humidity control cpl. ................................................... 11....................
24.00.164 Inner glass pane ....................................................... 27....................
54.01.148 Inspection lid, quenching nozzle, B2 .................................. 33....................
40.04.046 Interface cable USB 1.0m ............................................. 31....................
2/15/2012
3 AC208V (240V) 60Hz UL
41
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Index
Part-no. Description Page
1005.2000 Interlocking tooth screw M5x8 ......................................... 25....................
20.01.755 Isolation for mounting plate for motor ................................. 19....................
2062.0331 Junction pressure hose GS 10 ........................................ 15....................
2760.1370 Latch hook for air baffle ............................................... 23....................
2920.1300 Level elektrode insert .................................................. 13....................
24.00.504 Lock cover ............................................................. 25....................
50.00.086 Locking plate f. water distribution ...................................... 33....................
12.01.133 Lower part of pedestal ................................................. 29....................
40.03.410 Mating flange f. heating assembly ..................................... 17....................
40.04.039 Meat probe sensor .................................................... 21....................
22.00.083 Motor shaft gasket ..................................................... 19....................
22.00.882 Mounting device f. pressure sensor ................................... 11....................
40.03.371 Mounting device heat sink SSR ....................................... 7.....................
22.00.722 Mounting support f. gasket flange ..................................... 19....................
40.03.404 Mounting support transformer ......................................... 9.....................
50.00.078 Non return valve DW16/DN12 ......................................... 33....................
22.00.837 O-ring for humidity control ............................................. 11....................
16.01.965 Opening mechanism for panel insert .................................. 29....................
1008.0768 Ornamental screw M8x16 ............................................. 25....................
1008.0769 Ornamental screw M8x30 ............................................. 25....................
22.00.850 Outer humidity meas. Piece ........................................... 11....................
54.01.117 Outlet sieve ............................................................ 21....................
10.00.507 Pan head screw Torx 5/16" T20 ....................................... 7.....................
10.00.365 Pan head screw Torx M3x20 .......................................... 9.....................
10.00.061 Pan head screw Torx T20 M4x12 ..................................... 7.....................
50.00.085 Plug-in spring f. hand shower roll guide ............................... 33....................
40.00.464 Potentiometer CT ...................................................... 5.....................
2067.0050 Pressure hose d10mm ................................................ 33....................
3017.1011 Pressure sensor for humidity control Huba 401 ....................... 11....................
2118.1000 Pump connection spout ............................................... 15....................
8354.1320 Pump connection spout cpl. ........................................... 13....................
40.00.098 Reflector f. interior light ................................................ 21....................
42
3 AC208V (240V) 60Hz UL
2/15/2012
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Index
Part-no. Description Page
10.00.515 Rivet 3,2x5 A4 ......................................................... 23....................
1603.0166 Rivet 3,2x7,9 CNS closed ............................................. 31....................
1604.0167 Rivet 4x10 ............................................................. 23....................
10.00.041 Rivet nut M5 hexagon closed.......................................... 27....................
54.01.141 Rubber form piece venting pipe ....................................... 33....................
40.01.482 Safety temperature limiter 365°C...................................... 9, 21..................
40.01.317 Screen core temperature sensor ...................................... 21....................
40.03.782 Screen interior cabinet sensor......................................... 21....................
16.01.908 Sealing f. panel insert ................................................. 5......................
16.00.128 Side panel left ......................................................... 31....................
16.00.127 Side panel right ........................................................ 31....................
2110.1008 Silicon hose ø10x2mm ................................................ 15....................
24.00.171 Silicone buffer 7mm for door .......................................... 27....................
50.01.147 Single solenoid valve .................................................. 33....................
50.01.146 Single solenoid valve .................................................. 33....................
24.00.147 Sleeve for door bolt top ................................................ 27....................
1104.0820 Snap nut 4,2mm ....................................................... 29, 31................
40.00.453 Solid state relais ....................................................... 7......................
24.01.100 Spring clip f. door lock ................................................. 25....................
10.01.049 Square necked mushroom head bolt 6x30 ............................ 19....................
1107.0103 Star lock ø3 ............................................................ 17....................
1107.0100 Star lock ø4 ............................................................ 31....................
44.00.941 Steam generator insolated ............................................ 13....................
2112.1006 Steam hose 50x7mm .................................................. 13....................
10.01.191 Sticker set ............................................................. 37....................
2120.1259 Stop plug 10mm ....................................................... 15....................
22.00.491 Surge guard for Meat probe sensor ................................... 23....................
50.00.313 T-fitting water connection .............................................. 33....................
40.03.729 Terminal block grey WKN 35/U........................................ 9......................
40.00.290 Thermocouple humidity................................................ 21....................
40.03.488 Thermocouple interior cabinet B1 ..................................... 21....................
40.04.106 Thermocouple steam generator *B5*.................................. 13....................
2/15/2012
3 AC208V (240V) 60Hz UL
43
Combi Master 101 - 10 x 1/1 GastronormE
E11MH1112
Index
Part-no. Description Page
4005.0101 Tie rap 145 mm ........................................................ 15....................
1204.0120 Tooth lock washer A4,3 ............................................... 7.....................
1206.0120 Tooth lock washer A6,4 ............................................... 29....................
16.02.152 Top cover .............................................................. 31....................
50.00.751 Tulip for handshower with tape ........................................ 31....................
12.00.516 Turning lock f. lower part of pedestal .................................. 29....................
12.00.205 Upper part of pedestal ................................................. 29....................
40.02.425 Varistor ................................................................ 9.....................
22.00.767 Vent cover ............................................................. 11, 29................
54.01.110 Ventilation pipe ........................................................ 33....................
8354.1304 Venting valve for steam generator .................................... 33....................
10.00.744 Washer A4,3 *A4 ...................................................... 23....................
1306.0222 Washer A6,4x15x1,5 .................................................. 13....................
1308.0162 Washer A8,4 ........................................................... 19....................
1308.0160 Washer A8,4 ........................................................... 25....................
60.71.379 Water connection kit, table unit E/USA ................................ 37....................
50.00.070 Water distribution hor roll guide con. .................................. 33....................
50.00.071 Water distribution hor. w/o roll guide con. ............................. 33....................
1900.0202 Water filter ............................................................. 33....................
40.03.531 Wiring interior light ..................................................... 21....................
44
2/15/2012
3 AC208V (240V) 60Hz UL
Deckblatt Elektrische Dokumentation, Cover sheet electrical Documentation
Die Elektrische Dokumentation besteht aus: 1. diesem Deckblatt, 2. dem Schaltplan und 3. der Legende der elektrischen Bauteile
The electric documentation contains: 1. this cover sheet, 2. the wiring diagram and 3. the bill of material (BOM)
Deckblatt-Nr.
Front Page No.
75-21344 Version 0
Typ / Type CMP 101E
Schaltplan
Wiring diagram
76-00519 Version 0
Spannung (SPL)
Voltage
3AC208 V 60 Hz
Legende
Legend electr. components
78-00889 Version 0
Geräteserialnr.
Serial number
E11MH1102 Version 1102
Erstellt am
Created at
Sep 1, 2011 1:27 PM Ersteller
Creator
SCHD
Gültig ab
Valid from
Aug 30, 2011 3:38 PM Änderung
Modification
0123456789
K1:1 / 2.00
K1:3 / 2.00
K1:5 / 2.00
Option
Sicotronic system
X0:PE
X0:N
X0:1 Eingang Sicotronic
M1
6,3A
M1-F2
6,3A
L1
Z1
L2
L3
VTVT
BKBK
OGOG
0
K1
N/O
YE/GNYE/GN
1
3
5
2
4
6
A4
F3
F4
S1
X21
11
GYRDBN
1
2
1
2
A4-F1
1,6AT
22
33
BU
RD
Option Pot.-freier Kontakt
Option pot.-free contact
K1
N/O
.
W17
BUS
PE
33
22
11
M
~
X19
44
11
55
22
33 66
Y1
WH
XY1
A1
A2
BU
11
22
Y2
WH
XY2
A1
A2
BU
BU
GY
11
22
XM1
M1-F1
X0:2 Gerät EIN
X0:3 Heizungsanforderung
X20:1 Nullleiter
X20:2 Eingang Sicotronic
X20:3 Gerät EIN
X20:4 Heizungsanforderung
ohne Option
Brücke 2-4
w/o option
Link 2-4
G1
XM5
X.0
.
W32
1
2
X20
N
BU
11
22 11
3
1
2
3
22
33
44
L1
-
22
PE
XG1
33
N
2
+
11
Attention
After carrying out a voltage conversion,
change the connection on the control
transformer to the desired voltage input
208V
240V
X18
M4
M
(208 or 240V)
W20
11
BU
WH
XM4
11
~
208V
240V
1b
1a
S13
1
BK
WH
3
22
X26
22
44 33
22
GY
1
M
M5
F1 8A
BN
F2 8A
BU
L1
L2
L3
PE X0
76-00519
A1
K1
A2
12
.00
34
.00
56
.00
13 14
.04
.04
MODUL 1
Leistung/Power
0Version
K1
N/O
BN
1314
K1:13 / 3.00
K1:A2 / 3.00
CMP 101E-UL
3AC208 V 60 Hz
Erstellt von
Created by
Datum
Date
Blatt
Page
SCHD
05.10.2011
1
1.07 / K1:1
1.07 / K1:3
1.07 / K1:5
0123456789
BK
OG
VT
A4
X24
HL1-
HL1+
D2-
D2+
88
77
66
55
X24
HL2-
HL2+
D1-
D1+
44
33
22
11
BNBN
RDRD
BKBN
BNVT
(HL1)
XV1
44
B- B+
RDGY
V1
A1/B1
BK
BK
B2
0
33
OGBK
22
A- A+
(D2)
GYBN
11
A2
OGGY
V2
XV2
A1/B1
OG
OG
B2
44
B- B+
(HL1)
33
OGOG
22
A- A+
(D2)
GYGYGY
V3
11
VT
VT
A2
VTWH
A1/B1
B2
(HL2)
BNBN
XV3
44
B- B+
RDRD
OGOG
WHWHWH
33
22
11
A- A+
A2
(D1)
Therm oelement Dampfgenerator
Therm ocouple steam generator
76-00519
R1
0Version
OG
WH
1
3
2
4
9kW(3x3kW)
D1/D2
BK
GY
5
6
R2
BN
1
3
5
2
4
6
9kW(3x3kW)
D1/D2
R4
BK
BN
8
6
7
5
18kW(6x3kW)
OG
HL1/HL2
MODUL 2
CMP 101E-UL
Heizung/Heating
3AC208 V 60 Hz
VT
GY
12
11
WH
10
4
2
9
3
1
Erstellt von
Created by
Datum
Date
Blatt
Page
SCHD
05.10.2011
2
0123456789
P1
P
Signal
IN GND
XP1
11
22
33
A4
X1
X14
11
22
33
44
0
T1
T1-F1
2AT
PXT1
GY
GY
WH
WH
T1-F2
11,5V
SXT1
250V
7
5AT
18V
4
3
2
1
.
.
.
.
.
.
.
.
240V
230V
6
5
0
220V
208V
200V
4
3
2
1 N
GY
GY
GY
11
22
33
X3
22WH11
S2
Y5
S3
H1
W11
WH
YE/GN
44
X12
X4
GN
GY
WH
33
22
11
33
22
11
GN
WH
WH
WH
114422
33
44
X11
X5
55
33
22
11
GN
WH
X6
44 33B522
WH
X27
WH
WH
11
11
GN
BN
22
11
22
X13
X2
77
66BU55T244
WH
YE/GN
X8
11
33WH22 11
WH
22
Option Thermoelement Sousvide
X50
44 33
22 11
YE
Option Thermocouple Sousvide
X2
77
W23
YE/GN
7
X2.0
7
X2.1
66
55
44
33
22
11
6
5
4
3
2
1
6
5
4
3
2
1
EEPROM
1.06 / K1:13
1.06 / K1:A2
BN
BU
76-00519
B1
MODUL 3
Sensoren/Sensors
0Version
B2
B4
B3
CMP 101E-UL
3AC208 V 60 Hz
Erstellt von
Created by
Datum
Date
Blatt
Page
B7
SCHD
05.10.2011
3
Positionsliste
Bill of material
Änderungsdatum 30.08.2011 Name CMP 101E-UL Dokument-Nr. 78-00889
Erzeuger SCHD Spannung 3AC208 V 60 Hz Version 0
Seite 1 von
2
Name
Name
Artikelnr.
Item number
Artikelbezeichnung
Item description
Module
Modul
-A4 42.00.090 Bedienplatine CMP Operator PCB CMP Modul 1
-A4-F1 3019.0125 Sicherung 1,6AT Fuse 1,6AT Modul 1
-B1 40.03.488 Thermoelement Garraum Thermocouple interior cabinet Modul 3
-B2 54.01.148 Thermoelement Ablöschung Thermocouple quenching Modul 3
-B3 40.04.039 Thermoelement Kerntemperatur Thermocouple core sensor Modul 3
-B4 40.00.290 Thermoelement Feuchte Thermocouple humidity Modul 3
-B5 40.04.106 Thermoelement Dampfgenerator Thermocouple steam generator Modul 3
-F1/F2 40.01.588 Steuersicherung Control fuse Modul 1
-F3 40.01.329 Sicherheitstemperaturbegrenzer Gas:157°C/314°
F Elek.:183°C/360°F
Safety thermostat steam generator Gas: 157°C/
314°F Elec.: 183°C/360°F
Modul 1
-F4 40.01.482 Sicherheitstemperaturbegrenzer 360°C/680°F Safety thermostat interior cabinet 360°C/680°F Modul 1
-G1 40.03.257 Gleichrichter Kühllüfter DC converter cooling fan Modul 1
-H1 3024.0201 Garraumbeleuchtung Interior cabinet light Modul 3
-K1 40.03.669 Hauptschütz Main contactor Modul 1
-M1 40.03.378 Lüftermotor Fan motor Modul 1
-M4 44.00.207 SC-Pumpe SC-pump Modul 1
-M5 40.03.428 Kühllüfter Cooling fan Modul 1
-P1 3017.1011 Differenzdrucksensor Differential pressure sensor Modul 3
-R1 44.01.347 Dampfheizkörper Heating element steam Modul 2
-R2 44.01.374 Dampfheizkörper Heating element steam Modul 2
-R4 40.03.639 Heißluftheizkörper Heating element hot air Modul 2
-S2 44.01.407 Niveauelektrode Water level electrode Modul 3
-S3 40.00.335 Türkontaktschalter Door contact switch Modul 3
Positionsliste
Bill of material
Änderungsdatum 30.08.2011 Name CMP 101E-UL Dokument-Nr. 78-00889
Erzeuger SCHD Spannung 3AC208 V 60 Hz Version 0
Seite 2 von
2
Name
Name
Artikelnr.
Item number
Artikelbezeichnung
Item description
Module
Modul
-S7 40.00.464 Potentiometer Zeit / Kerntemperatur Time / Core potentiometer Modul 3
-T1 40.03.348 Steuertrafo Control transformer Modul 3
-T1-F1 3019.0120 Sicherung Steuertrafo T1 2AT Fuse control transformer T1 2AT Modul 3
-T1-F2 3019.0126 Sicherung Steuertrafo T1 5AT Fuse control transformer T1 5AT Modul 3
-T2 40.04.048 SCC WE: Lautsprecher / CMP: Alarmsummer SCC WE: Speaker / CMP: Buzzer Modul 3
-V1-V12 40.00.453 Leistungshalbleiter Solid state relais Modul 2
-W11 40.03.531 Kabel: Garraumbeleuchtung Cable: interior cabinet light Modul 3
-W17 40.03.812 Kabel: Steuerstamm Cable: control harness Modul 1
-W20 40.03.981 Kabel: Spannungswahlschalter UL Cable: selector switch UL Modul 1
-X20 40.04.180 Sicotronic-Klemme Sicotronic link Modul 1
-Y1 50.01.147 Magnetventil Füllen Solenoid valve filling Modul 1
-Y2 50.01.146 Magnetventil Ablöschung Solenoid valve quenching Modul 1
-Y5 22.00.725 Klimaventil Clima valve Modul 3
-Z1 40.02.425 Entstörfilter/Varistor Electronic noise filter Modul 1
Loading...
