Innovative functional elements
like the soft-touch button
control and ergonomic lighting
assist the barista in every phase
of use and cleaning.
Classe 9USB features advanced
electronics and an alphanumeric
display for managing the
machine’s main settings.
Stunning lights on the steel side
panels and the floating front panel
accentuate the design, lending the
machine a strikingly elegant yet
bold and trendy look.
Classe 9USB has an ergonomic
lighting system in the work area to
make the barista’s job easier plus
chrome group covers and all the
distinctive stylish accessories from
the Rancilio range.
The hot-water temperature
control system for tea and
infusions has two dierent
temperatures and programmable
dosing.
9USB
/
9USB TALL
Classe 9USB has an eye-catching, futuristic design and is made from tough materials, such as
stainless steel and aluminium, so it’s packed with character.
Shock-absorbing side panels guarantee a sturdy machine that’s practical to use.
Available with 2, 3 and 4 groups and also in a TALL version.
Technical Features
STANDARD FEATURES: 1 filter holder for 2 cups per group, 1 filter holder for 1 cup,
2 steam wands, 1 mixed hot water dispenser with two buttons for programmable timecontrolled dosing and/or temperature (4-TEA), coee tamper, measuring scoop and
cleaning discs, levelling feet
ACCESSORIES: DP automatic or manual water softener, MD dosing grinder
Standard features, accessories
aluminium and stainless steel body
Materials
Technical Data
Classe 9USB / 9USB TALL
independent heat exchangers
electric heating
built-in volumetric pump
pump pressure gauge
boiler pressure gauge
electronic water level control
electronic boiler pressure control
multifunctional onboard computer with display and USB port
low-voltage brew heads (24 V)
low-voltage dispensing controls (24 V)
version "TALL" - H max cups/glasses: 5.7 in (14.5 cm)
LED lights illuminate the work area, functional LED lights on the group button panels,
stylish lateral lighting
2 GROUPS
29.5×21.3×20.6 in (750×540×523 mm)
dimensions (W×D×H) boiler
boiler power
weight
voltage
120 V / 220-240 V / 380-415 V (3N)
11 l (2.4 galUK)
3,200 W (120 V) - 4,300 W
145.5 lb (66 kg)
frequency
frequency
frequency
50/60 Hz
50/60 Hz
50/60 Hz
3 GROUPS
4 GROUPS
39.0×21.3×20.6 in (990×540×523 mm)
48.3×21.3×20.6 in (1230×540×523 mm)
dimensions (W×D×H)
dimensions (W×D×H)
boiler
boiler
boiler power
boiler power
weight
weight
voltage
voltage
220-240 V / 380-415 V (3N)
220-240 V / 380-415 V (3N)
16 l (3.5 galUK)
22 l (4.8 ga lUK)
6,000 W
6,000 W
174. 2 lb (79 kg)
211.6 lb (96 kg)
Standard
On demand
www.ranciliogroup.com
Classe 9USB - 3 groups - front view
Classe 9USB TALL - 3 groups - front view
Classe 9USB - 3 groups - rear view
Classe 9USB - 2 groups - side view
Temperature programming
Ergonomic steam control
Smart power management
Automatic washing programme
Rapid setting
Advanced diagnostics
Electric cup warmer
Ergonomic filter holder
Ergonomic work surface
ERGO-FILTER
HOLDER
Voltage stabilizer
Ergonomic control panel
Ergonomic lighting
Automatic steam wand
Pod and capsule adaptor
