Rancilio 10RE User Manual

10RE

CLASSE 10 RE

Pure
technology

Classe 10 RE incorporates a special
mechanical system that ensures an
espresso of an extremely high quality.
The combination of the RE group with
Classe 10 creates a product of outstanding
excellence for true connoisseurs.

RE GROUP

system conserves the traditional method
of making an espresso. The manual action
gives the operator great control over coee
brewing times. The ideal machine for expert
baristas with a passion for their art.

C-LEVER

am valve with a special control knob and er­gonomic design is complete with open-stay
and open-close functions. The valve has a
very short travel distance, and is operated
by rotating it just 25°. Turning it upwards, it
opens and remains in this position. Turned
downwards, it automatically closes when
released. Rapidity, precision and ergonomics:
maximum user comfort for daily tasks.

CUP WARMER

allows cups to be kept at optimal temperatu­re, a vital factor in the quality of an espresso
coee.

The special RE mechanical

(Rancilio Patent) The new ste-

The electric cup-warmer

www.rancilio.com

10RE . TECHNICAL FEATURES

10RE . FEATURES

Technical Features

independent heat exchangers

electr ic heating

incorporated volumetric pump

pump p ressure gauge

boiler pressure gauge

automatic water level control

boiler pressure control with pressure stat

200 V – 240 V dispensing controls

housing in aluminium and stainless steel

electric cup-warmer

Endowments, accessories

ENDOWMENTS: 1 filter holder for 2 cups per group, 1 filter holder for 1 cup,

2 steam wands, 2 hot water dispensers, with one mixed, coee tamper, measuring scoop
and washing disks, foot extensions.

ACCESSORISES: DP automatic or manual water softener, MD dosing grinder.

Colors

satin-finished metallic grey

Technical Data

2 GROUPS

dimensions

30.7 x 21.2 x 20.8 inch

boiler power

(wxdxh)

weight

200.6 Lb

voltage

120 / 220-240 / 380-415 3N6000 W

boiler

2.9 USgal

Hz

50/60

Standard

On demand

3 GROUPS

dimensions

40.1 x 21.2 x 20.8 inch

boiler power voltage

6000 W

4 GROUPS

dimensions

49.6 x 21.2 x 20.8 inch

boiler power

6000 W

(wxdxh)

(wxdxh)

weight

244.7 Lb

220-240 / 380-415 3N

weight

295.4 Lb

voltage

220-240 / 380-415 3N

boiler

4.2 USgal

boiler

5.8 USgal

Hz

50/60

Hz

50/60
