RAM 1500 (2021) Owner's Manual

Page 1

RAM 1500

2021 OWNER’S MANUAL

Page 2

This Owner’s Manual illustrates and describes the operation of features and equipment that are either standard or optional on this vehicle. This manual may

also include a description of features and equipment that are no longer available or were not ordered on this vehicle. Please disregard any features and

equipment that are no longer available or were not ordered on this vehicle. FCA US LLC reserves the right to make changes in design and specifications, and/or

make additions to or improvements to its products without imposing any obligation upon itself to install them on products previously manufactured.

With respect to vehicles sold in Canada, the name FCA US LLC shall be deemed to be deleted and the name FCA Canada Inc. used in substitution therefore.

If you are the first registered retail owner of your vehicle, you may obtain a complimentary printed copy of the Warranty Booklet by calling

1-866-726-4636 (U.S.) or 1-800-387-1143 (Canada), or by contacting your dealer.

This Owner’s Manual is intended to familiarize you with the important features of your vehicle. Your most up-to-date Owner’s Manual, Navigation/Uconnect

manuals and Warranty Booklet can be found by visiting the website on the back cover. U.S. residents can purchase replacement kits by visiting

www.techauthority.com and Canadian residents can purchase replacement kits by calling 1-800-387-1143.

WARNING: Operating, servicing and maintaining a passenger vehicle or off-highway

motor vehicle can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. To minimize exposure, avoid breathing exhaust, do not idle the engine except as necessary, service your vehicle in a well-ventilated area and wear gloves or wash your hands frequently when servicing your vehicle. For more information go to www.P65Warnings.ca.gov/passenger-vehicle.

Page 3

TABLE OF CONTENTS

1 INTRODUCTION............................................................................................................................ 10

2 GETTING TO KNOW YOUR VEHICLE ..................................................................................17

3 GETTING TO KNOW YOUR INSTRUMENT PANEL ..................................................... 104

4 STARTING AND OPERATING .............................................................................................. 140

5 MULTIMEDIA .............................................................................................................................. 236

6 SAFETY .........................................................................................................................................310

7 IN CASE OF EMERGENCY .................................................................................................... 373

8 SERVICING AND MAINTENANCE ......................................................................................395

9 TECHNICAL SPECIFICATIONS ............................................................................................467

10 CUSTOMER ASSISTANCE .....................................................................................................479

11 INDEX .............................................................................................................................................483

Page 4

INTRODUCTION

Symbols Key..........................................................11

WARNINGS AND CAUTIONS ...............................11

VAN CONVERSIONS/CAMPERS..........................11

VEHICLE MODIFICATIONS/ALTERATIONS.........11

Symbol Glossary...................................................12

GETTING TO KNOW YOUR VEHICLE

KEYS ......................................................................17

Key Fob......................................................... 17

SENTRY KEY ..........................................................20

IGNITION SWITCH .................................................21

Keyless Enter-N-Go — Ignition..................... 21

REMOTE START — IF EQUIPPED (GASOLINE) ...22

How To Use Remote Start ...........................22

To Exit Remote Start Mode .........................23

Remote Start Front Defrost Activation — If

Equipped ...................................................... 24

Remote Start Comfort Systems —

If Equipped ...................................................24

Remote Start Windshield Wiper De-Icer

Activation — If Equipped.............................. 25

Remote Start Abort Message...................... 25

REMOTE START — IF EQUIPPED (DIESEL) ........25

How To Use Remote Start ...........................25

VEHICLE SECURITY SYSTEM — IF EQUIPPED .. 26

To Arm The System...................................... 26

To Disarm The System ................................26

Rearming Of The System............................. 27

Security System Manual Override .............. 27

DOORS .................................................................. 27

Manual Door Locks...................................... 27

Power Door Locks — If Equipped ...............28

Power Side Steps — If Equipped................. 28

Keyless Enter-N-Go — Passive Entry .......... 28

Automatic Unlock Doors On Exit —

If Equipped................................................... 30

Automatic Door Locks — If Equipped .........30

Child-Protection Door Lock System —

Rear Doors ................................................... 31

STEERING WHEEL ................................................31

Tilt/Telescoping Steering Column ..............31

Heated Steering Wheel — If Equipped ...... 32

DRIVER MEMORY SETTINGS — IF EQUIPPED... 32

Programming The Memory Feature............ 33

Linking And Unlinking The Key Fob To

Memory ........................................................33

Memory Position Recall............................... 34

SEATS ...................................................................34

Manual Adjustment (Front Seats) — If

Equipped ...................................................... 34

Manual Adjustment (Rear Seats) ............... 36

Power Adjustment (Front Seats) —

If Equipped................................................... 36

Heated Seats — If Equipped ...................... 38

Ventilated Seats — If Equipped................... 39

Plastic Grocery Bag Retainers ................... 39

Head Restraints........................................... 40

UCONNECT VOICE RECOGNITION ......................41

Introducing Voice Recognition.................... 41

Basic Voice Commands .............................. 42

Get Started................................................... 43

Additional Information................................. 43

DRIVER ADJUSTABLE PEDALS —

IF EQUIPPED..........................................................43

MIRRORS ..............................................................44

Inside Rearview Mirror ................................ 44

Outside Mirrors ........................................... 46

Outside Automatic Dimming Mirrors — If

Equipped ...................................................... 47

Power Mirrors............................................... 47

Power Folding Outside Mirrors For

Standard And Trailer Tow — If Equipped.... 47

Trailer Towing Mirrors — If Equipped ......... 48

Heated Mirrors — If Equipped..................... 48

Tilt Side Mirrors In Reverse —

If Equipped................................................... 48

Page 5

UNIVERSAL GARAGE DOOR OPENER

(HOMELINK®) — IF EQUIPPED ...........................49

Before You Begin Programming

HomeLink® ..................................................49

Erasing All The HomeLink® Channels........49

Identifying Whether You Have A Rolling

Code Or Non-Rolling Code Device ..............49

Programming HomeLink® To A Garage

Door Opener................................................. 50

Programming HomeLink® To A

Miscellaneous Device.................................. 51

Reprogramming A Single HomeLink®

Button........................................................... 51

Canadian/Gate Operator Programming..... 51

EXTERIOR LIGHTS.................................................52

Headlight Switch..........................................52

Multifunction Lever ..................................... 53

Daytime Running Lights (DRLs) .................53

High/Low Beam Switch ...............................53

Automatic High Beam Headlamp

Control — If Equipped .................................53

Flash-To-Pass ...............................................54

Automatic Headlights — If Equipped .........54

Parking Lights And Panel Lights ................. 54

Automatic Headlights With Wipers .............54

Headlight Delay............................................ 55

Lights-On Reminder..................................... 55

Fog Lights — If Equipped ............................ 55

Turn Signals ................................................55

Lane Change Assist — If Equipped .............55

Cargo Lights/Trailer Spotter Lights With

Bed Lights — If Equipped............................. 56

Battery Saver ...............................................57

INTERIOR LIGHTS ................................................ 57

Courtesy Lights ............................................ 57

Illuminated Entry ......................................... 58

WINDSHIELD WIPERS AND WASHERS............. 58

Windshield Wiper Operation ...................... 58

Rain Sensing Wipers — If Equipped............ 59

CLIMATE CONTROLS ........................................... 60

Automatic Climate Control Descriptions

And Functions .............................................. 60

Manual Climate Control Descriptions And

Functions...................................................... 63

Automatic Temperature Control (ATC) —

If Equipped................................................... 65

Climate Voice Recognition .......................... 66

Operating Tips ............................................. 66

INTERIOR STORAGE AND EQUIPMENT ............. 68

Storage ......................................................... 68

USB/AUX Control .........................................72

Electrical Power Outlets .............................. 74

Power Inverter — If Equipped ..................... 75

Wireless Charging Pad — If Equipped ........ 77

WINDOWS ............................................................ 77

Power Windows............................................ 77

Automatic Window Features....................... 78

Reset Auto-Up ............................................. 78

Window Lockout Switch ..............................79

Power Sliding Rear Window —

If Equipped .................................................. 79

Manual Sliding Rear Window —

If Equipped................................................... 79

Wind Buffeting ............................................ 80

POWER SUNROOF — IF EQUIPPED ....................80

Single Pane Power Sunroof —

If Equipped................................................... 80

Dual Pane Power Sunroof —

If Equipped................................................... 82

HOOD .....................................................................84

To Open The Hood....................................... 84

To Close The Hood....................................... 85

TAILGATE ...............................................................85

Opening ........................................................85

Closing.......................................................... 85

Locking Tailgate........................................... 85

Multifunction Tailgate — If Equipped.......... 85

Tailgate Removal ........................................86

Bed Step — If Equipped............................... 89

PICKUP BOX .........................................................90

Bed Rail Tie-Down System —

If Equipped .................................................. 91

RAMBOX — IF EQUIPPED ....................................92

Locking And Unlocking RamBox................. 93

RamBox Cargo Storage Bins....................... 93

RamBox Safety Warning ............................. 94

Bed Divider — If Equipped........................... 95

Page 6

SLIDE-IN CAMPERS .............................................97

Camper Applications ...................................97

TRI-FOLD TONNEAU COVER — IF EQUIPPED.....97

Tonneau Cover Components.......................97

Tri-Fold Tonneau Cover Folding For

Driving Or Removal...................................... 98

Tri-Fold Tonneau Cover Installation..........101

Tri-Fold Tonneau Cover Cleaning..............103

GETTING TO KNOW YOUR INSTRUMENT PANEL

BASE / MIDLINE INSTRUMENT CLUSTER —

GASOLINE ...........................................................104

Base / Midline Instrument Cluster

Descriptions — Gasoline............................105

PREMIUM INSTRUMENT CLUSTER —

GASOLINE ...........................................................107

Premium Instrument Cluster

Descriptions — Gasoline............................108

BASE / MIDLINE INSTRUMENT CLUSTER —

DIESEL................................................................. 109

Base / Midline Instrument Cluster

Descriptions — Diesel ................................110

PREMIUM INSTRUMENT CLUSTER —

DIESEL................................................................. 112

Premium Instrument Cluster

Descriptions — Diesel ...............................113

INSTRUMENT CLUSTER DISPLAY.....................114

Instrument Cluster Display Controls.........114

Oil Life Reset..............................................115

Display Menu Items...................................116

Diesel Particulate Filter (DPF)

Messages ..................................................121

Displays ......................................................123

Diesel Exhaust Fluid (DEF) Warning

Messages ...................................................123

Diesel Exhaust Fluid (DEF) Fault

Warning Messages ....................................124

Battery Saver On/Battery Saver Mode Message — Electrical Load Reduction

Actions — If Equipped ................................125

WARNING LIGHTS AND MESSAGES................126

Red Warning Lights ...................................126

Yellow Warning Lights ...............................129

Yellow Indicator Lights ..............................133

Green Indicator Lights...............................135

White Indicator Lights ...............................136

Blue Indicator Lights..................................137

ONBOARD DIAGNOSTIC SYSTEM — OBD II.....137

Onboard Diagnostic System (OBD II)

Cybersecurity .............................................138

EMISSIONS INSPECTION AND

MAINTENANCE PROGRAMS .............................138

STARTING AND OPERATING

STARTING THE ENGINE..................................... 140

Automatic Transmission............................141

AutoPark.....................................................141

Tip Start Feature ....................................... 143

Keyless Enter-N-Go — Ignition...................143

Normal Starting Using ENGINE START/

STOP Button — Gasoline Engine .............. 143

Normal Starting Using ENGINE START/

STOP Button — Diesel Engine ..................144

Cold Weather Operation (Below –22°F

Or −30°C) ................................................. 146

After Starting.............................................. 146

Starting Fluids — Diesel Engine Only........ 146

NORMAL OPERATION — DIESEL ENGINE ....... 146

Cold Weather Precautions ........................146

Engine Idling ..............................................148

Stopping The Engine .................................148

ENGINE BLOCK HEATER — IF EQUIPPED ....... 150

ENGINE BREAK-IN RECOMMENDATIONS —

GASOLINE ENGINE ........................................... 150

ENGINE BREAK-IN RECOMMENDATIONS —

DIESEL ENGINE.................................................. 151

PARKING BRAKE ............................................... 151

Electric Park Brake (EPB).......................... 151

Page 7

AUTOMATIC TRANSMISSION ..........................154

Ignition Park Interlock ...............................155

Brake/Transmission Shift Interlock

System .......................................................155

Eight-Speed Automatic Transmission.......156

FOUR-WHEEL DRIVE OPERATION —

IF EQUIPPED ...................................................... 161

Four-Position Electronically Shifted

Transfer Case — If Equipped ....................161

Five-Position Electronically Shifted

Transfer Case — If Equipped ....................163

ACTIVE-LEVEL FOUR CORNER AIR

SUSPENSION SYSTEM — IF EQUIPPED........... 165

Description .................................................165

Air Suspension Modes...............................167

Instrument Cluster Display Messages......168

Operation....................................................168

ACTIVE-LEVEL FOUR CORNER AIR SUSPENSION SYSTEM (REBEL MODELS

ONLY) — IF EQUIPPED....................................... 169

Description .................................................169

Air Suspension Modes...............................171

Instrument Cluster Display Messages......171

Operation....................................................172

AXLE LOCK SYSTEM — IF EQUIPPED ..............173

LIMITED-SLIP DIFFERENTIAL —

IF EQUIPPED....................................................... 174

POWER STEERING............................................. 174

Electric Power Steering ............................174

FUEL SAVER TECHNOLOGY 5.7L ENGINES

ONLY — IF EQUIPPED.........................................175

STOP/START SYSTEM — IF EQUIPPED............175

Autostop Mode...........................................175

Possible Reasons The Engine Does Not

Autostop .....................................................175

To Start The Engine While In Autostop

Mode...........................................................176

To Manually Turn Off The Stop Start

System........................................................176

To Manually Turn On The Stop Start

System........................................................177

System Malfunction...................................177

CRUISE CONTROL SYSTEMS —

IF EQUIPPED ......................................................177

Cruise Control — If Equipped.....................177

Adaptive Cruise Control (ACC) —

If Equipped.................................................179

PARKSENSE FRONT/REAR PARK ASSIST

SYSTEM — IF EQUIPPED....................................189

ParkSense Sensors ...................................190

ParkSense Warning Display...................... 190

ParkSense Display.....................................190

Enabling And Disabling Front And/Or

Rear ParkSense.........................................193

Service The ParkSense Park Assist

System........................................................193

Cleaning The ParkSense System..............194

ParkSense System Usage Precautions ....194

PARKSENSE ACTIVE PARK ASSIST

SYSTEM — IF EQUIPPED ................................... 195

Enabling And Disabling The ParkSense

Active Park Assist System .........................196

Parallel/Perpendicular Parking Space

Assistance Operation ................................197

LANESENSE — IF EQUIPPED ........................... 199

LaneSense Operation................................199

Turning LaneSense On Or Off ...................200

LaneSense Warning Message..................200

Changing LaneSense Status.....................202

PARKVIEW REAR BACK UP CAMERA ............. 202

AUX Camera — If Equipped ...................... 204

SURROUND VIEW CAMERA SYSTEM — IF

EQUIPPED........................................................... 204

AUX Camera — If Equipped ...................... 208

REFUELING THE VEHICLE — GASOLINE

ENGINE................................................................ 208

REFUELING THE VEHICLE — DIESEL

ENGINE ............................................................... 210

Avoid Using Contaminated Fuel ...............210

Bulk Fuel Storage — Diesel Fuel............... 210

Diesel Exhaust Fluid.................................. 211

Diesel Exhaust Fluid Storage....................211

Adding Diesel Exhaust Fluid .....................211

Page 8

VEHICLE LOADING............................................. 213

Gross Vehicle Weight Rating (GVWR) ......213

Payload.......................................................213

Gross Axle Weight Rating (GAWR) ............213

Tire Size......................................................213

Rim Size......................................................214

Inflation Pressure ......................................214

Curb Weight................................................214

Loading.......................................................214

TRAILER TOWING .............................................. 214

Common Towing Definitions .....................214

Trailer Hitch Type and Maximum Trailer

Weight.........................................................218

Trailer Towing Weights (Maximum Trailer

Weight Ratings)..........................................218

Trailer And Tongue Weight ........................219

Trailer Reverse Steering Control...............219

Towing Requirements ...............................221

Towing Tips ................................................227

SNOWPLOW ......................................................227

Before Plowing ...........................................228

Snowplow Prep Package Model

Availability ..................................................228

Over The Road Operation With Snowplow

Attached .....................................................229

Operating Tips............................................229

General Maintenance................................229

RECREATIONAL TOWING (BEHIND

MOTORHOME) ...................................................230

Towing This Vehicle Behind Another

Vehicle........................................................230

Recreational Towing — Two-Wheel Drive

Models........................................................230

Recreational Towing — Four-Wheel Drive

Models........................................................231

DRIVING TIPS......................................................234

Driving On Slippery Surfaces ...................234

Driving Through Water ..............................234

Off-Road Driving Tips.................................235

MULTIMEDIA

UCONNECT SYSTEMS .......................................236

CYBERSECURITY ...............................................236

UCONNECT SETTINGS........................................237

Customer Programmable Features ..........237

HEAD-UP DISPLAY (HUD)..................................254

UCONNECT INTRODUCTION ..............................256

System Overview .......................................256

Safety And General Information ...............258

UCONNECT MODES............................................259

Steering Wheel Audio Controls ................259

Radio Mode ...............................................259

Media Mode ..............................................268

Phone Mode ..............................................271

CONNECTED VEHICLE SERVICES —

IF EQUIPPED ...................................................... 282

Is My Vehicle Connected?.........................282

Introduction To Connected Vehicle

Services ..................................................... 282

Getting Started With Connected Vehicle

Services ..................................................... 284

Using SiriusXM Guardian™ ......................286

Manage My SiriusXM Guardian™

Account ......................................................301

CONNECTED SERVICES FAQs .........................301

Connected Services SOS FAQs ................ 301

Connected Services Remote Door Lock/

Unlock FAQs ..............................................302

Connected Services Roadside

Assistance FAQs .......................................302

Connected Services Send & Go FAQs .....302

Connected Services Vehicle Finder

FAQs ..........................................................303

Connected Services Stolen Vehicle

Assistance FAQs .......................................303

Connected Services Remote Vehicle

Start FAQs ................................................. 303

Connected Services Remote Horn &

Lights FAQs ................................................304

Connected Services Account FAQs...........304

Data Collection & Privacy.......................... 306

Page 9

OFF-ROAD PAGES — IF EQUIPPED .................. 307

Off-Road Pages Status Bar .......................307

Vehicle Dynamics.......................................308

Accessory Gauge........................................308

Pitch & Roll.................................................308

Suspension ................................................309

RADIO OPERATION AND MOBILE PHONES.... 309

Regulatory And Safety Information...........309

SAFETY

SAFETY FEATURES ............................................310

Anti-Lock Brake System (ABS) .................310

Electronic Brake Control (EBC) System ...311

AUXILIARY DRIVING SYSTEMS ........................ 318

Blind Spot Monitoring (BSM) —

If Equipped ................................................318

Forward Collision Warning (FCW) With

Mitigation — If Equipped............................324

Tire Pressure Monitoring System

(TPMS) ........................................................327

OCCUPANT RESTRAINT SYSTEMS .................. 334

Occupant Restraint Systems Features ....334

Important Safety Precautions ...................334

Seat Belt Systems .....................................335

Supplemental Restraint Systems (SRS)...342

Child Restraints..........................................355

SAFETY TIPS .......................................................369

Transporting Passengers ..........................369

Transporting Pets ......................................369

Safety Checks You Should Make Inside

The Vehicle ................................................369

Periodic Safety Checks You Should

Make Outside The Vehicle ........................371

Exhaust Gas ..............................................371

Carbon Monoxide Warnings......................372

IN CASE OF EMERGENCY

HAZARD WARNING FLASHERS........................373

ASSIST AND SOS SYSTEM — IF EQUIPPED ....373

JACKING AND TIRE CHANGING .......................377

Preparations For Jacking...........................377

Jack Location .............................................378

Removal Of Jack And Tools....................... 378

Removing The Spare Tire..........................380

Jacking Instructions...................................381

To Stow The Flat Or Spare ........................384

Reinstalling The Jack And Tools ...............385

JUMP STARTING ................................................386

Preparations For Jump Start..................... 386

Jump Starting Procedure ..........................387

REFUELING IN EMERGENCY –

IF EQUIPPED ......................................................389

IF YOUR ENGINE OVERHEATS .........................389

MANUAL PARK RELEASE..................................390

FREEING A STUCK VEHICLE .............................391

TOWING A DISABLED VEHICLE........................ 392

Two-Wheel Drive Models........................... 393

Four-Wheel Drive Models.......................... 393

Emergency Tow Hooks — If Equipped ......394

ENHANCED ACCIDENT RESPONSE SYSTEM

(EARS) ................................................................ 394

EVENT DATA RECORDER (EDR)....................... 394

SERVICING AND MAINTENANCE

SCHEDULED SERVICING — GASOLINE

ENGINE ............................................................... 395

Maintenance Plan .....................................395

SCHEDULED SERVICING — DIESEL ENGINE .. 399

Maintenance Plan — Diesel Fuel Up To

B5 Biodiesel ..............................................400

Additional Maintenance — B6 To B20

Biodiesel.....................................................403

ENGINE COMPARTMENT .................................. 404

3.6L Engine With Stop/Start ....................404

5.7L Engine Without Stop/Start...............405

5.7L Engine With Stop/Start.....................406

3.0L Diesel Engine ....................................407

Checking Oil Level ..................................... 408

Adding Washer Fluid .................................408

Maintenance-Free Battery .......................409

Pressure Washing......................................409

Page 10

VEHICLE MAINTENANCE .................................. 409

Engine Oil — Gas Engine ...........................410

Engine Oil Filter..........................................410

Engine Air Cleaner Filter............................411

Draining Fuel/Water Separator Filter —

Diesel Engine ............................................412

Underbody Mounted Fuel Filter

Replacement — Diesel Engine ..................413

Priming If The Engine Has Run Out Of

Fuel — Diesel Engine .................................414

Intervention Regeneration Strategy —

Message Process Flow (Diesel Engine)....414

Diesel Exhaust Fluid ..................................415

Air Conditioner Maintenance ....................415

Accessory Drive Belt Inspection................417

Body Lubrication........................................418

Windshield Wiper Blades ..........................418

Exhaust System ........................................420

Cooling System .........................................421

Charge Air Cooler — Inter-Cooler (Diesel

Engine)........................................................424

Brake System ............................................425

Automatic Transmission ...........................426

Rear Axle And 4x4 Front Driving Axle

Fluid Level .................................................426

Transfer Case ............................................427

FUSES .........................................................427

BULB REPLACEMENT ................................437

TIRES....................................................................443

Tire Safety Information..............................443

Tires — General Information .....................449

Tire Types ...................................................454

Spare Tires — If Equipped .........................455

Wheel And Wheel Trim Care .....................456

Snow Traction Devices ..............................458

Tire Rotation Recommendations .............460

DEPARTMENT OF TRANSPORTATION

UNIFORM TIRE QUALITY GRADES ..................460

Treadwear ..................................................460

Traction Grades .........................................461

Temperature Grades .................................461

STORING THE VEHICLE......................................461

BODYWORK ........................................................461

Protection From Atmospheric Agents.......461

Body And Underbody Maintenance..........462

Preserving The Bodywork..........................462

INTERIORS .........................................................464

Seats And Fabric Parts..............................464

Plastic And Coated Parts...........................465

Leather Surfaces .......................................465

Glass Surfaces ..........................................466

TECHNICAL SPECIFICATIONS

VEHICLE IDENTIFICATION NUMBER................ 467

BRAKE SYSTEM ................................................ 467

WHEEL AND TIRE TORQUE

SPECIFICATIONS................................................ 467

Torque Specifications ...............................467

FUEL REQUIREMENTS — GASOLINE

ENGINE ............................................................... 468

3.6L Engine ...............................................468

5.7L Engine................................................ 469

Reformulated Gasoline .............................469

Materials Added To Fuel ........................... 469

Gasoline/Oxygenate Blends ..................... 469

Do Not Use E-85 In Non-Flex Fuel

Vehicles...................................................... 470

CNG And LP Fuel System Modifications ..470 Methylcyclopentadienyl Manganese

Tricarbonyl (MMT) In Gasoline.................. 470

Fuel System Cautions................................470

FUEL REQUIREMENTS – DIESEL ENGINE....... 471

Diesel Fuel Specifications.........................471

Biodiesel Fuel Requirements....................472

FLUID CAPACITIES ............................................ 474

ENGINE FLUIDS AND LUBRICANTS ................475

CHASSIS FLUIDS AND LUBRICANTS............... 478

Page 11

CUSTOMER ASSISTANCE

SUGGESTIONS FOR OBTAINING SERVICE FOR

YOUR VEHICLE ..................................................479

Prepare For The Appointment...................479

Prepare A List.............................................479

Be Reasonable With Requests .................479

IF YOU NEED ASSISTANCE .............................. 479

FCA US LLC Customer Center ...................479

FCA Canada Inc. Customer Center ...........480

Mexico ........................................................480

Puerto Rico And US Virgin Islands ............480

Customer Assistance For The Hearing Or

Speech Impaired (TDD/TTY) .....................480

Service Contract ........................................480

WARRANTY INFORMATION ..............................481

MOPAR® PARTS................................................481

REPORTING SAFETY DEFECTS ........................481

In The 50 United States And

Washington, D.C. .......................................481

In Canada...................................................481

PUBLICATION ORDER FORMS .........................482

General Information ..........................................482

Page 12

INTRODUCTION

Dear Customer, congratulations on the purchase of your new Ram vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality.

This is a specialized utility vehicle. It can go places and perform tasks that are not intended for conventional passenger vehicles. It handles and maneuvers differently from many passenger vehicles both on-road and off-road, so take time to become familiar with your vehicle. If equipped, the two-wheel drive version of this vehicle was designed for on-road use only. It is not intended for off-road driving or use in other severe conditions suited for a four-wheel drive vehicle. Before you start to drive this vehicle, read the Owner’s Manual. Be sure you are familiar with all vehicle controls, particularly those used for braking, steering, transmission, and transfer case shifting. Learn how your vehicle handles on different road surfaces. Your driving skills will improve with experience. When driving off-road, or working the vehicle, don’t overload the vehicle or expect the vehicle to overcome the natural laws of physics. Always observe federal, state, provincial and local laws wherever you drive. As with other vehicles of this type, failure to operate this vehicle correctly may result in loss of control or a collision Ú page 234.

This Owner's Manual has been prepared with the assistance of service and engineering specialists to acquaint you with the operation and maintenance of your vehicle. It is supplemented by customer-oriented documents. Within this information, you will find a description of the services that FCA US LLC offers to its customers as well as the details of the terms and conditions for maintaining its validity. Please take the time to read all of these publications carefully before driving your vehicle for the first time. Following the instructions, recommendations, tips, and important warnings in this manual will help ensure safe and enjoyable operation of your vehicle.

This Owner's Manual describes all versions of this vehicle. Options and equipment dedicated to specific markets or versions are not expressly indicated in the text. Therefore, you should only consider the information that is related to the trim level, engine, and version that you have purchased. Any content introduced throughout the Owner's Information, which may or may not be applicable to your vehicle, will be identified with the wording “If Equipped”. All data contained in this publication are intended to help you use your vehicle in the best possible way. FCA US LLC aims at a constant improvement of the vehicles produced. For this reason, it reserves the right to make changes to the model described for technical and/or commercial reasons. For further information, contact an authorized dealer.

When it comes to service, remember that authorized dealers know your Ram best, have factory-trained technicians and genuine MOPAR® parts, and care about your satisfaction.

Page 13

SYMBOLS KEY

Indicates a potentially hazardous situation,

WARNING!

CAUTION!

NOTE:

TIP:

PAGE REFERENCE ARROW

FOOTNOTE

which if not avoided, could result in death or serious injury.

An unsafe practice which may result in personal injury or damage to the vehicle.

A suggestion which will improve installation, operation, and reliability. If not followed, may result in damage.

General ideas/solutions/suggestions on easier use of the product or functionality.

Follow this reference for additional information on a particular feature.

Supplementary and relevant information pertaining to the topic.

WARNINGS AND CAUTIONS

This Owner’s Manual contains WARNINGS against operating procedures that could result in a collision, bodily injury and/or death. It also contains CAUTIONS against procedures that could result in damage to your vehicle. If you do not read this entire Owner’s Manual, you may miss important information. Observe all Warnings and Cautions.

VAN CONVERSIONS/CAMPERS

The New Vehicle Limited Warranty does not apply to body modifications or special equipment installed by van conversion/camper manufacturers/ body builders. US residents refer to the Warranty Information, Section

2.1.C. Canadian residents refer to the “What Is Not Covered” section of the Warranty Information. Such equipment includes video monitors, DVD/ Blu-Ray™, heaters, stoves, refrigerators, etc. For warranty coverage and service on these items, contact the applicable manufacturer.

Operating instructions for the special equipment installed by the conversion/camper manufacturer should also be supplied with your vehicle. For any additional instructions, please contact your conversion/ camper manufacturer.

To obtain dimensional and technical specifications for your vehicle, refer to the Body Builder’s Guide at https://www.ramtrucks.com/ ram-commercial/body-builders-guide.html.

VEHICLE MODIFICATIONS/ALTERATIONS

WARNING!

Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a collision resulting in serious injury or death.

Page 14

SYMBOL GLOSSARY

Some car components have colored labels with symbols indicating precautions to be observed when using this component. It is important to follow all warnings when operating your vehicle. See below for the definition of each symbol Ú page 104.

Red Warning Lights

Seat Belt Reminder Warning Light

Ú page 126

Air Bag Warning Light

Ú page 126

Brake Warning Light

Ú page 126

Hood Open Warning Light

Ú page 127

Vehicle Security Warning Light — If Equipped

Ú page 127

Engine Coolant Temperature Warning Light

Ú page 128

Red Warning Lights

Battery Charge Warning Light

Ú page 128

Oil Pressure Warning Light

Ú page 128

Oil Temperature Warning Light

Ú page 128

Electronic Throttle Control (ETC) Warning Light

Ú page 128

Electric Power Steering Fault Warning Light

Ú page 129

Tailgate Open Warning Light

Ú page 129

Trailer Brake Disconnected Warning Light

Ú page 129

Page 15

Red Warning Lights

Transmission Temperature Warning Light — If

Equipped

Ú page 129

Door Open Warning Light

Ú page 129

Yellow Warning Lights

Adaptive Cruise Control (ACC) Fault Warning

Light — If Equipped

Ú page 129

Air Suspension Fault Warning Light — If

Equipped

Ú page 129

Engine Check/Malfunction Indicator Warning

Light (MIL)

Ú page 130

Electronic Park Brake Warning Light

Ú page 130

Electronic Stability Control (ESC) Active Warning

Light — If Equipped

Ú page 130

Yellow Warning Lights

Electronic Stability Control (ESC) OFF Warning

Light — If Equipped

Ú page 131

Service LaneSense Warning Light — If Equipped

Ú page 131

Low Washer Fluid Warning Light — If Equipped

Ú page 131

Low Fuel Warning Light

Ú page 131

Tire Pressure Monitoring System (TPMS)

Warning Light

Ú page 131

Anti-Lock Brake System (ABS) Warning Light

Ú page 132

Rear Axle Locker Fault Indicator Light — If

Equipped

Ú page 132

Service Forward Collision Warning (FCW) Light

— If Equipped

Ú page 132

Page 16

Yellow Warning Lights

Service Stop/Start System Warning Light

Ú page 133

Service 4WD Warning Light — If Equipped

Ú page 133

Cruise Control Fault Warning Light

Ú page 133

Yellow Indicator Lights

Forward Collision Warning Off Indicator Light —

If Equipped

Ú page 133

Air Suspension Payload Protection Indicator

Light — If Equipped

Ú page 133

Trailer Merge Assist Indicator Light — If

Equipped

Ú page 133

TOW/HAUL Indicator Light

Ú page 133

Yellow Indicator Lights

Cargo Light On Indicator Light

Ú page 133

Air Suspension Off-Road 1 Indicator Light — If

Equipped

Ú page 133

Air Suspension Off-Road 2 Indicator Light — If

Equipped

Ú page 133

Air Suspension Normal Height Indicator Light —

If Equipped

Ú page 134

Air Suspension Aerodynamic Height Indicator

Light — If Equipped

Ú page 134

Entry/Exit Indicator Light — If Equipped

Ú page 134

Air Suspension Ride Height Raising Indicator

Light — If Equipped

Ú page 134

Page 17

Yellow Indicator Lights

Air Suspension Ride Height Lowering Indicator

Light — If Equipped

Ú page 134

Rear Axle Lock Indicator Light

Ú page 134

4WD Indicator Light — If Equipped

Ú page 134

4WD Low Indicator Light — If Equipped

Ú page 134

4WD High Indicator Light — If Equipped

Ú page 134

NEUTRAL Indicator Light — If Equipped

Ú page 134

Low Diesel Exhaust Fluid (DEF) Indicator Light —

If Equipped

Ú page 134

Wait To Start Light — If Equipped

Ú page 135

Yellow Indicator Lights

Water In Fuel Indicator Light — If Equipped

Ú page 135

Green Indicator Lights

Adaptive Cruise Control (ACC) Set With Target

Light — If Equipped

Ú page 135

Adaptive Cruise Control (ACC) Set With No

Target Detected Indicator Light — If Equipped

Ú page 135

ECO Mode Indicator Light

Ú page 135

Park/Headlight On Indicator Light

Ú page 135

LaneSense Indicator Light — If Equipped

Ú page 137

Front Fog Indicator Light — If Equipped

Ú page 136

Page 18

Green Indicator Lights

Turn Signal Indicator Lights

Ú page 136

Cruise Control SET Indicator Light — If Equipped

With A Premium Instrument Cluster

Ú page 136

Stop/Start Active Indicator Light

Ú page 136

4WD AUTO Indicator Light — If Equipped

Ú page 136

White Indicator Lights

Adaptive Cruise Control (ACC) Ready Light — If

Equipped

Ú page 136

Cruise Control Ready Indicator

Ú page 136

Speed Control SET Indicator Light — If Equipped

With Base/Midline Instrument Cluster Display

Ú page 136

White Indicator Lights

Hill Descent Control (HDC) Indicator Light — If

Equipped

Ú page 137

LaneSense Indicator Light — If Equipped

Ú page 137

Blue Indicator Lights

High Beam Indicator Light

Ú page 137

Page 19

GETTING TO KNOW YOUR VEHICLE

KEYS

KEY FOB

Your vehicle is equipped with a key fob which supports Passive Entry, Remote Keyless Entry (RKE), Keyless Enter-N-Go (if equipped), and Remote Start (if equipped). The key fob allows you to lock or unlock all doors, tailgate, and the RamBox (if equipped) as well as activate the Panic Alarm from distances up to approximately 66 ft (20 m). The key fob does not need to be pointed at the vehicle to activate the system. The key fob also contains an emergency key, which is stored in the rear of the key fob.

NOTE:

 The key fob’s wireless signal may be blocked if

the key fob is located next to a mobile phone, laptop, or other electronic device. This may result in poor performance.

 If your vehicle is equipped with a Wireless

Charging Pad, the key fob may not be found if it is placed within 15 cm (150 mm) of the pad Ú page 77.

 With the ignition in the ON position and the

vehicle moving at 2 mph (4 km/h), all RKE commands are disabled.

Key Fob

1 — Unlock 2 — LED Light 3 — Lock 4 — Tailgate Lowering 5 — Remote Start 6 — PANIC 7 — Emergency Key 8 — Air Suspension

In case the ignition switch does not change with the push of a button, the key fob may have a low or fully depleted battery. A low key fob battery can be verified by referring to the instrument cluster, which will display directions to follow.

NOTE: A low key fob battery condition may be indicated by a message in the instrument cluster display, or by the LED light on the key fob. If the LED key fob light no longer illuminates from key fob button pushes, then the key fob battery requires replacement.

Page 20

18 GETTING TO KNOW YOUR VEHICLE

To Lock/Unlock The Doors And Tailgate

Push and release the unlock button on the key fob once to unlock the driver’s door, or, twice within five seconds to unlock all doors, the tailgate and the RamBox (if equipped). To lock all the doors and the tailgate, push the lock button once.

When the doors are unlocked, the turn signals will flash and the illuminated entry system will be activated. When the doors are locked, the turn signals will flash and the horn will chirp.

All doors can be programmed to unlock on the first push of the unlock button. The horn chirp when the lock button is pushed can be programmed on/off within Uconnect Settings Ú page 237.

Air Suspension (Remote Lowering Of The Vehicle) — If Equipped

For easy entry and loading, your vehicle can be lowered by pushing the key fob air suspension lowering button

two times. When air suspension lowering is requested using the key fob, the vehicle will send a series of chirps and flashes to alert the customer that the operation has begun and will continue these alerts until it successfully lowers.

The following conditions must be met for the vehicle to lower remotely:

 The vehicle must not already be in Entry/Exit

(Park) ride height.

 The vehicle battery must be fully charged.

 All doors must be closed.

 The key fob must be out of the vehicle.

NOTE: Ensure the vehicle is clear of all objects, pets, and people prior to remote lowering.

Canceling Remote Lowering

Vehicle lowering can be cancelled at anytime. When vehicle lowering is cancelled, the vehicle will raise up to the next defined level and lock out the remote lowering feature until the ignition has been cycled ON/OFF.

To cancel vehicle lowering, push the key fob air suspension lowering button one time during the lowering process. When vehicle lowering is cancelled, the horn will chirp two times and the turn signal lamps will flash four times. Once raising is completed, the horn will chirp one time.

NOTE: More information on air suspension is provided later in this manual Ú page 165.

Replacing The Battery In The Key Fob

The replacement battery model is one CR2450 battery.

NOTE:

 Customers are recommended to use a

battery obtained from Mopar. Aftermarket coin battery dimensions may not meet the original OEM coin battery dimensions.

 Perchlorate Material — special handling may

apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate for further information.

 Do not touch the battery terminals that are

on the back housing or the printed circuit board.

 Do not replace the coin battery if the LED on

the key fob above the top row buttons blinks when a button is pressed. The coin battery should last a minimum of three years with normal vehicle usage.

Page 21

GETTING TO KNOW YOUR VEHICLE 19

1. Remove the emergency key (1) by pushing

the emergency key release button (2) on the side of the key fob, and pulling the emergency key out with your other hand.

Emergency Key Removal

1 — Emergency Key 2 — Emergency Key Release Button

2. Hold the key fob with the button side facing

down, and locate the small rectangular gap on the left side between the housing and the back cover of the key fob. Use a small screw driver (or similar tool) to pry open the left side of the fob cover while applying pressure until the cover snaps open.

3. Next, locate the gap on the right side of the

key fob, which is positioned further to the

edge than the left side gap. Pry open the right side, and remove the back cover.

4. Remove the battery by using your thumb to slide the battery downward and back toward the key ring.

Key Fob Battery Location

NOTE: When replacing the battery, ensure the (+) sign on the battery is facing upward. Avoid touching the new battery with your fingers. Skin oils may cause battery deterioration. If you touch a battery, clean it with rubbing alcohol.

5. Replace the battery by using your thumb to push down and slide the battery under the small lip on the top edge of the opening.

Key Fob Battery Replacement

6. To assemble the key fob case, line up the top edge of the back cover with the top of the fob, and press the edges into the interlocking hinges until all edges snap together with no large visual gaps.

7. Reinsert the emergency key until it locks into place.

NOTE: The key fob battery should only be replaced by qualified technicians. If the battery requires replacement, see an authorized dealer.

Page 22

20 GETTING TO KNOW YOUR VEHICLE

Programming And Requesting Additional Key Fobs

Programming the key fob may be performed by an authorized dealer.

NOTE:

 Once a key fob is programmed to a vehicle, it

cannot be re-purposed and reprogrammed to another vehicle.

 Only key fobs that are programmed to the

vehicle electronics can be used to start and operate the vehicle. Once a key fob is programmed to a vehicle, it cannot be programmed to any other vehicle.

WARNING!

 Always remove the key fobs from the

vehicle and lock all doors when leaving the vehicle unattended.

 For vehicles equipped with Keyless

Enter-N-Go — Ignition, always remember to place the ignition in the OFF mode.

Duplication of key fobs may be performed at an authorized dealer. This procedure consists of programming a blank key fob to the vehicle

electronics. A blank key fob is one that has never been programmed.

NOTE: When having the Sentry Key Immobilizer system serviced, bring all vehicle keys with you to an authorized dealer Ú page 482.

SENTRY KEY

The Sentry Key Immobilizer system prevents unauthorized vehicle operation by disabling the engine. The system does not need to be armed or activated. Operation is automatic, regardless of whether the vehicle is locked or unlocked.

The system uses a key fob, keyless push button ignition and a Radio Frequency (RF) receiver to prevent unauthorized vehicle operation. Therefore, only key fobs that are programmed to the vehicle can be used to start and operate the vehicle. The system cannot reprogram a key fob obtained from another vehicle.

After placing the ignition switch in the ON/RUN position, the vehicle security light will turn on for three seconds for a bulb check. If the light remains on after the bulb check, it indicates that there is a problem with the electronics. In addition, if the light begins to flash after the bulb check, it indicates that someone

attempted to start the engine with an invalid key fob. In the event that a valid key fob is used to start the engine but there is an issue with the vehicle electronics, the engine will start and shut off after two seconds.

If the vehicle security light turns on during normal vehicle operation (vehicle running for longer than 10 seconds), it indicates that there is a fault in the electronics. Should this occur, have the vehicle serviced as soon as possible by an authorized dealer.

CAUTION!

The Sentry Key Immobilizer system is not compatible with some aftermarket remote starting systems. Use of these systems may result in vehicle starting problems and loss of security protection.

All of the key fobs provided with your new vehicle have been programmed to the vehicle electronics Ú page 482.

Page 23

GETTING TO KNOW YOUR VEHICLE 21

IGNITION SWITCH

KEYLESS ENTER -N-GO — IGNITION

This feature allows the driver to operate the ignition switch with the push of a button as long as the key fob is in the passenger compartment.

The START/STOP ignition button has several operating modes that are labeled and will illuminate when in position. These modes are OFF, ACC, ON/RUN, and START.

Keyless Push Button Ignition

1 — OFF 2 — ACC (Accessory) 3 — ON/RUN

The push button ignition can be placed in the following modes:

OFF

 The engine is stopped

 Some electrical devices (e.g. central locking,

alarm, etc.) are still available

ACC

 Engine is not started

 Some electrical devices are available (e.g.

power sunroof, power windows etc.)

ON/RUN

 Driving position

 All the electrical devices are available (e.g.

climate controls, heated seats, etc.)

START

 The engine will start (when foot is on the

brake)

NOTE: If the ignition switch does not change the mode by pushing the button, the key fob may have a low or depleted battery. In this situation, a back up method can be used to operate the ignition switch. Put the nose side (side opposite of the emergency key) of the key fob against the

START/STOP ignition button and push to operate the ignition switch.

Back Up Starting Method

WARNING!

 When exiting the vehicle, always remove

the key fob from the vehicle and lock your vehicle.

 Never leave children alone in a vehicle, or

with access to an unlocked vehicle.

 Allowing children to be in a vehicle unat-

tended is dangerous for a number of reasons. A child or others could be seriously or fatally injured. Children should be warned not to touch the parking brake, brake pedal or the gear selector.

(Continued)

Page 24

22 GETTING TO KNOW YOUR VEHICLE

WARNING! (Continued)

 Do not leave the key fob in or near the

vehicle, or in a location accessible to children, and do not leave the ignition of a vehicle equipped with Keyless Enter-N-Go in the ON/RUN mode. A child could operate power windows, other controls, or move the vehicle.

 Do not leave children or animals inside

parked vehicles in hot weather. Interior heat build-up may cause serious injury or death.

CAUTION!

An unlocked vehicle is an invitation for thieves. Always remove key fob from the vehicle and lock all doors when leaving the vehicle unattended.

NOTE:

 The key fob may not be detected by the

vehicle Keyless Enter-N-Go system if it is located next to a mobile phone, laptop or other electronic device; these devices may block the key fob’s wireless signal and

prevent the Keyless Enter-N-Go system from starting the vehicle.

 Engine starting procedure Ú page 140.

 When opening the driver's door and the igni-

tion is in the ON/RUN position (engine not running), a chime will sound to remind you to place the ignition in the OFF position. In addition to the chime, the message “Ignition or Accessory ON” will display in the cluster.

REMOTE START — IF EQUIPPED (GASOLINE)

This system uses the key fob to start the engine conveniently from outside the vehicle while still maintaining security. The system has a range of

approximately 300 ft (91 m).

Remote start is used to defrost windows in cold weather and to reach a comfortable climate in all ambient conditions before the customer enters the vehicle.

NOTE: Obstructions between the vehicle and key fob may reduce this range.

WARNING!

 Do not start or run an engine in a closed

garage or confined area. Exhaust gas contains Carbon Monoxide (CO) which is odorless and colorless. Carbon Monoxide is poisonous and can cause serious injury or death when inhaled.

 Keep key fobs away from children. Opera-

tion of the Remote Start System, windows, door locks or other controls could cause serious injury or death.

HOW TO USE REMOTE START

Push and release the Remote Start button on the key fob twice within five seconds. The vehicle doors will lock, the parking lights will flash, and the horn will chirp twice (if programmed). Then, the engine will start, and the vehicle will remain in the Remote Start mode for a 15 minute cycle.

Pushing the remote start button a third time shuts the engine off.

Page 25

GETTING TO KNOW YOUR VEHICLE 23

To drive the vehicle, push the unlock button, insert the key into the ignition, and turn to the ON/RUN position.

NOTE:

 With Remote Start, the engine will only run

for 15 minutes.

 Remote Start can only be used twice.

 If an engine fault is present or fuel level is

low, the vehicle will start and then shut down in 10 seconds.

 The parking lights will turn on and remain on

during Remote Start mode.

 For security, power window and power

sunroof operation (if equipped) are disabled when the vehicle is in the Remote Start mode.

 The ignition must be placed in the ON/RUN

position before the Remote Start sequence can be repeated for a third cycle.

All of the following conditions must be met before the engine will remote start:

 Gear selector in PARK

 Doors closed

 Hood closed

 Hazard switch off

 Brake switch inactive (brake pedal not

pushed)

 Battery at an acceptable charge level

 PANIC button not pushed

 Fuel meets minimum requirement

 System not disabled from previous remote

start event

 Vehicle Security system not active

 Malfunction Indicator Light is not illuminated

WARNING!

 Do not start or run an engine in a closed

garage or confined area. Exhaust gas contains Carbon Monoxide (CO) which is odorless and colorless. Carbon Monoxide is poisonous and can cause serious injury or death when inhaled.

 Keep key fobs away from children. Opera-

tion of the Remote Start System, windows, door locks or other controls could cause serious injury or death.

TO EXIT REMOTE START MODE

To drive the vehicle after starting the Remote Start system, either push and release the unlock button on the key fob to unlock the doors, or unlock the vehicle using Keyless Enter-N-Go — Passive Entry via the door handles, and disarm the vehicle security system (if equipped). Then, prior to the end of the 15 minute cycle, press the brake pedal and push and release the START/STOP ignition button.

Page 26

24 GETTING TO KNOW YOUR VEHICLE

The Remote Start system will turn the engine off with another push and release of the Remote Start button on the key fob, or if the engine is allowed to run for the entire 15 minute cycle. Once the ignition is placed in the ON/RUN position, the climate controls will resume the previously set operations (temperature, blower control, etc.).

NOTE:

 To avoid unintentional shutdowns, the

system will disable for two seconds after receiving a valid Remote Start request.

 For vehicles equipped with the Keyless

Enter-N-Go — Passive Entry feature, the message “Remote Start Active — Push Start Button” will display in the instrument cluster display until you push the START/STOP ignition button.

REMOTE START FRONT DEFROST

CTIVATION — IF EQUIPPED

When remote start is active, and the outside ambient temperature is 40°F (4.5°C) or below, the system will automatically activate front defrost for 15 minutes or less. The time is dependent on the ambient temperature. Once the timer expires, the system will automatically

adjust the settings depending on ambient conditions. See “Remote Start Comfort Systems — If Equipped” in the next section for detailed operation.

REMOTE START COMFORT SYSTEMS —

F EQUIPPED

When remote start is activated, the front and rear defrost will automatically turn on in cold weather. The heated steering wheel and driver heated seat feature will turn on if programmed in the comfort menu screen within Uconnect Settings Ú page 237. In warm weather, the driver vented seat feature will automatically turn on when the remote start is activated and is programmed in the comfort menu screen. The vehicle will adjust the climate control settings depending on the outside ambient temperature.

Automatic Temperature Control (ATC) — If Equipped

The climate controls automatically adjust to an optimal temperature and mode, dependent on the outside ambient temperature. When the ignition is placed in the ON/RUN position, the climate controls will resume their previous settings.

Manual Temperature Control (MTC) — If Equipped

 In ambient temperatures of 40°F (4.5°C) or

below, the climate settings will default to maximum heat, with fresh air entering the cabin. If the front defrost timer expires, the vehicle will enter Mix Mode.

 In ambient temperatures from 40°F (4.5°C)

to 78°F (26°C), the climate settings will be based on the last settings selected by the driver.

 In ambient temperatures of 78°F (26°C) or

above, the climate settings will default to MAX A/C, Bi-Level mode, with Recirculation on.

For more information on ATC, MTC, and climate control settings, see Ú page 60.

NOTE: These features will stay on through the duration of remote start, or until the ignition is placed in the ON/RUN position. The climate control settings will change, and exit the automatic defaults, if manually adjusted by the driver while the vehicle is in remote start mode. This includes turning the climate controls off using the OFF button.

Page 27

GETTING TO KNOW YOUR VEHICLE 25

REMOTE START WINDSHIELD WIPER

E-ICER ACTIVATION — IF EQUIPPED

When the Remote Start system is active and the outside ambient temperature is less than 33°F (0.6°C), the Windshield Wiper De-Icer will activate. Exiting remote start will its resume previous operation. If the Windshield Wiper De-Icer was active, the timer and operation will continue.

REMOTE START ABORT MESSAGE

The following messages will display in the instrument cluster display if the vehicle fails to remote start, or exits remote start prematurely:

 Remote Start Cancelled — Door Open

 Remote Start Cancelled — Hood Open

 Remote Start Cancelled — Fuel Low

 Remote Start Cancelled — Too Cold

 Remote Start Cancelled — Time Expired

 Remote Start Disabled — Start Vehicle to

Reset

The message will stay active until the ignition is placed in the ON/RUN position Ú page 482.

REMOTE START — IF EQUIPPED (DIESEL)

This system uses the key fob to start the engine conveniently from outside the vehicle while still maintaining security. The system has a range of approximately 300 ft (91 m).

NOTE:

 Obstructions between the vehicle and the

key fob may reduce this range.

 The Remote Start system will wait for the

Wait To Start indicator light Ú page 135 to extinguish before cranking the engine. This allows time for the engine pre-heat cycle to pre-heat the cylinder air, and is normal in cold weather. For further information on the Wait To Start indicator light and the pre-heat cycle see .

HOW TO USE REMOTE START

All of the following conditions must be met before the engine will remote start:

 Gear selector in PARK

 Doors closed

 Hood closed

 Hazard switch off

 Brake switch inactive (brake pedal not

pressed)

 Battery at an acceptable charge level

 PANIC button not pushed

 Fuel meets minimum requirement

 System not disabled from previous remote

start event

 Vehicle Security system not active

 Water In Fuel indicator light is not illuminated

 Wait To Start indicator light is not illuminated

 Malfunction Indicator Light (MIL) is not illumi-

nated

Page 28

26 GETTING TO KNOW YOUR VEHICLE

WARNING!

 Do not start or run an engine in a closed

garage or confined area. Exhaust gas contains Carbon Monoxide (CO) which is odorless and colorless. Carbon Monoxide is poisonous and can cause serious injury or death when inhaled.

 Keep key fobs away from children. Opera-

tion of the Remote Start System, windows, door locks or other controls could cause serious injury or death.

VEHICLE SECURITY SYSTEM — IF EQUIPPED

The Vehicle Security system monitors the vehicle doors, hood, tailgate, and the Keyless Enter-N-Go — Ignition for unauthorized operation. While the Vehicle Security system is armed, interior switches for door locks and tailgate release are disabled. If something triggers the alarm, the Vehicle Security system will provide the following audible and visible signals:

 The horn will pulse

 The turn signals will flash

 The vehicle security light in the instrument

cluster will flash

TO ARM THE SYSTEM

Follow these steps to arm the Vehicle Security system:

1. Make sure the vehicle’s ignition is placed in the OFF position.

 For vehicles equipped with Keyless Entry,

make sure the vehicle’s keyless ignition system is OFF.

2. Perform one of the following methods to lock the vehicle:

 Push the lock button on the interior

power door lock switch with the driver and/or passenger door open.

 Push the lock button on the exterior

Passive Entry door handle with a valid key fob available in the same exterior zone Ú page 28.

 Push the lock button on the key fob.

3. If any doors are open, close them.

TO DISARM THE SYSTEM

The Vehicle Security system can be disarmed using any of the following methods:

 Push the unlock button on the key fob.

 Grab the Passive Entry door handle to unlock

the door Ú page 28.

 Cycle the ignition out of the OFF position to

disarm the system.

NOTE:

 The driver's door key cylinder cannot arm or

disarm the Vehicle Security system. Use of the door key cylinder when the system is armed will sound the alarm when the door is opened.

 The Vehicle Security system remains armed

when the power tailgate (if equipped) is opened using the tailgate button on the key fob.

 If Passive Entry (if equipped) is used to

unlock the tailgate, the Vehicle Security system is disarmed and the rest of the vehicle doors will remain locked unless “Unlock All Doors 1st Press” is selected in the Passive Entry settings.

 When the Vehicle Security system is armed,

the interior power door lock switches will not unlock the doors.

Page 29

GETTING TO KNOW YOUR VEHICLE 27

The Vehicle Security system is designed to protect your vehicle. However, you can create conditions where the system will give you a false alarm. If one of the previously described arming sequences has occurred, the Vehicle Security system will arm regardless of whether you are in the vehicle or not. If you remain in the vehicle and open a door, the alarm will sound. If this occurs, disarm the Vehicle Security system.

If the Vehicle Security system is armed and the battery becomes disconnected, the Vehicle Security system will remain armed when the battery is reconnected; the exterior lights will flash, and the horn will sound. If this occurs, disarm the Vehicle Security system.

REARMING OF T HE SYSTEM

If something triggers the alarm, and no action is taken to disarm it, the Vehicle Security system will turn the horn off after 29 seconds, five seconds between cycles, and up to eight cycles if the trigger remains active. The Vehicle Security system will then rearm itself.

SECURITY SYSTEM MANUAL OVERRIDE

The Vehicle Security system will not arm if you lock the doors using the manual door lock.

DOORS

MANUAL DOOR LOCKS

The power door locks can be manually locked from inside the vehicle by using the door lock knob. To lock each door, push the door lock knob on each door trim panel downward. To unlock the front doors, pull the inside door handle to the first detent. To unlock the rear doors, pull the door lock knob on the door trim panel upward. If the lock knob is down when the door is closed, the door will lock. Therefore, make sure the key fob is not inside the vehicle before closing the door.

NOTE: Manually locking the vehicle will not arm the Vehicle Security system.

Door Lock Knob

WARNING!

 For personal security and safety in the

event of a collision, lock the vehicle doors before you drive as well as when you park and leave the vehicle.

 When exiting the vehicle, always make sure

the keyless ignition is in the OFF mode, remove the key fob from the vehicle and lock your vehicle.

 Never leave children alone in a vehicle, or

with access to an unlocked vehicle. Allowing children to be in a vehicle unattended is dangerous for a number of reasons. A child or others could be seriously or fatally injured. Children should be warned not to touch the parking brake, brake pedal or the gear selector.

 Do not leave the key fob in or near the

vehicle, or in a location accessible to children, and do not leave the ignition of a vehicle equipped with Keyless Enter-N-Go in the ACC or ON/RUN mode. A child could operate power windows, other controls, or move the vehicle.

Page 30

28 GETTING TO KNOW YOUR VEHICLE

POWER DOOR LOCKS — IF EQUIPPED

The power door lock switches are located on each front door panel. Push the switch to lock or unlock the doors.

Power Door Lock Switches

The driver’s door will unlock automatically if the keys are found inside the vehicle when the door lock button on the front door panel is used to lock the door. This will occur for two attempts. Upon the third attempt, the doors will lock even if the key is inside.

NOTE: If the key fob is located next to a mobile phone, laptop, or other electronic device, the wireless signal may get blocked, and the driver’s door may not unlock automatically.

If the door lock switch is pushed while the ignition is in ACC or ON/RUN and the driver's door is open, the doors will not lock.

If a rear door is locked, it cannot be opened from inside the vehicle without first unlocking the door. The door may be unlocked manually by raising the lock knob.

POWER SIDE STEPS — I F EQUIPPED

The Power Side Steps will extend a step for easier entry and exit of the vehicle.

When configured for “Auto” mode, the Power Side Steps will deploy when any of the doors are opened, or when the deploy setting is activated through the touchscreen. When configured for “Store” mode, the steps will not deploy unless the setting is selected manually through the “Controls” menu within the touchscreen.

If the vehicle speed exceeds 5 mph (8 km/h), or if the retract setting is selected within Uconnect Settings Ú page 237, the steps will retract.

KEYLESS ENTER -N-GO — PASSIVE

NTRY

The Passive Entry system is an enhancement to the vehicle’s key fob and a feature of Keyless Enter-N-Go — Passive Entry. This feature allows

you to lock and unlock the vehicle’s door(s) without having to push the key fob lock or unlock buttons.

NOTE:

 Passive Entry may be programmed on or off

within Uconnect Settings Ú page 237.

 The key fob may not be detected by the

vehicle Passive Entry system if it is located next to a mobile phone, laptop, or other electronic device; these devices may block the key fob’s wireless signal and prevent the Passive Entry system from locking/unlocking the vehicle.

 Passive Entry Unlock initiates illuminated

approach (low beams, license plate lamp, position lamps) for whichever time duration is set between 0, 30, 60 or 90 seconds. Passive Entry Unlock also initiates two flashes of the turn signal lamps.

 If wearing gloves, or if it has been raining/

snowing on the Passive Entry door handle, the unlock sensitivity can be affected, resulting in a slower response time.

 If the vehicle is unlocked by Passive Entry

and no door is opened within 60 seconds, the vehicle will re-lock and (if equipped) will arm the Vehicle Security system.

Page 31

GETTING TO KNOW YOUR VEHICLE 29

To Unlock From The Driver Or Passenger Side

With a valid Passive Entry key fob within 5 ft (1.5 m) of the door handle, grab the handle to unlock the vehicle. Grabbing the driver’s door handle will unlock the driver door automatically. Grabbing the passenger door handle will unlock all doors and the tailgate automatically.

Grab The Door Handle To Unlock

NOTE:

 If “Unlock All Doors 1st Press” is

programmed all doors will unlock when you grab hold of the front driver’s door handle. You can select between “Unlock Driver Door 1st Press” and “Unlock All Doors 1st Press” within the Uconnect Settings Ú page 237.

 All doors will unlock when the front

passenger door handle is grabbed regardless of the driver’s door unlock preference setting.

Frequency Operated Button Integrated Key (FOBIK-Safe)

To minimize the possibility of unintentionally locking a Passive Entry key fob inside your vehicle, the Passive Entry system is equipped with an automatic door unlock feature which will function if the ignition switch is in the OFF position.

There are five situations that trigger a FOBIK-Safe search in any passive entry vehicle:

 A lock request is made by a valid Passive

Entry key fob while a door is open.

 A lock request is made by the Passive Entry

door handle while a door is open.

 A lock request is made by the door panel

switch while the door is open.

 When the Vehicle Security system is in

pre-arm or armed status and the tailgate transitions from opened to closed.

 When the tailgate transitions from open to

closed and remote start is active.

When any of these situations occur, after all open doors are shut, the FOBIK-Safe search will be executed. If it finds a Passive Entry key fob inside the vehicle, the vehicle will unlock and alert the customer.

NOTE: The vehicle will only unlock the doors when a valid Passive Entry key fob is detected inside the vehicle. The vehicle will not unlock the doors when any of the following conditions are true:

 The doors are manually locked using the door

lock knobs.

 Three attempts are made to lock the doors

using the door panel switch and then the doors are closed.

 There is a valid Passive Entry key fob outside

the vehicle within 5 ft (1.5 m) of a Passive Entry door handle.

To Lock The Vehicle’s Doors And Tailgate

With one of the vehicle’s Passive Entry key fobs within 5 ft (1.5 m) of either front door handles, pushing the Passive Entry lock button will lock the vehicle.

Page 32

30 GETTING TO KNOW YOUR VEHICLE

Push The Door Handle Button To Lock

NOTE: DO NOT grab the door handle when pushing the door handle lock button. This could unlock the door(s).

Do NOT Grab The Door Handle When Locking

NOTE:

 After pushing the door handle button, you

must wait two seconds before you can lock or unlock the doors, using either Passive Entry door handle. This is done to allow you to check if the vehicle is locked by pulling the door handle without the vehicle unlocking.

 If Passive Entry is disabled using the

Uconnect settings, the key protection described in "Frequency Operated Button Integrated Key (FOBIK-Safe)" remains active/ functional.

 The Passive Entry system will not operate if

the key fob battery is depleted.

 The LED light on the key fob will not blink

if the key fob battery is low or fully depleted, but a low key fob battery condition will still support the Passive Entry system functionality. When the key fob battery is low, the instrument cluster will display a message indicating that the key fob battery is low Ú page 17 Ú page 482.

AUTOMATIC UNLOCK DOORS ON EXIT —

F EQUIPPED

The doors will unlock automatically on vehicles with power door locks after the following sequence of actions:

1. The Automatic Unlock Doors On Exit feature is enabled.

2. All doors are closed.

3. The transmission gear selector was not in PARK, then is placed in PARK.

4. Any door is opened.

AUTOMATIC DOOR LOCKS — IF

QUIPPED

The auto door lock feature default condition is enabled. When enabled, the door locks will lock automatically when the vehicle's speed exceeds 15 mph (24 km/h). The auto door lock feature is enabled/disabled in the Uconnect Settings Ú page 237.

Page 33

GETTING TO KNOW YOUR VEHICLE 31

CHILD-PROTECTION DOOR LOCK

YSTEM — REAR DOORS

To provide a safer environment for small children riding in the rear seats, the rear doors are equipped with a Child-Protection Door Lock system.

To use the system, open each rear door, use a flat blade screwdriver, and rotate the dial to the lock or unlock position. When the system on a door is engaged, that door can only be opened by using the outside door handle even if the inside door lock is in the unlocked position.

Child Lock Control

NOTE:

 When the Child-Protection Door Lock system

is engaged, the door can be opened only by

using the outside door handle even though the inside door lock is in the unlocked position.

 After disengaging the Child-Protection Door

Lock system, always test the door from the inside to make certain it is in the unlocked position.

 After engaging the Child-Protection Door Lock

system, always test the door from the inside to make certain it is in the locked position.

 For emergency exit with the system engaged,

pull up on the door lock knob (unlocked position), roll down the window, and open the door with the outside door handle.

WARNING!

Avoid trapping anyone in the vehicle in a collision. Remember that the rear doors cannot be opened from the inside door handle when the Child Protection Door Locks are engaged.

NOTE: Always use this device when carrying children. After engaging the child lock on both rear doors, check for effective engagement by trying to

open a door with the internal handle. Once the Child-Protection Door Lock system is engaged, it is impossible to open the doors from inside the vehicle. Before getting out of the vehicle, be sure to check that there is no one left inside.

STEERING WHEEL

TILT/TELESCOPING STEERING COLUMN

This feature allows you to tilt the steering column upward or downward. It also allows you to lengthen or shorten the steering column. The tilt/telescoping lever is located on the steering column, below the multifunction lever.

Tilt/Telescoping Lever

To unlock the steering column, push the control downward (toward the floor). To tilt the steering column, move the steering wheel upward or

Page 34

32 GETTING TO KNOW YOUR VEHICLE

downward as desired. To lengthen or shorten the steering column, pull the steering wheel outward or push it inward as desired. To lock the steering column in position, push the control upward until fully engaged.

WARNING!

Do not adjust the steering column while driving. Adjusting the steering column while driving or driving with the steering column unlocked, could cause the driver to lose control of the vehicle. Failure to follow this warning may result in serious injury or death.

HEATED STEERING WHEEL — IF

QUIPPED

The steering wheel contains a heating element that helps warm your hands in cold weather. The heated steering wheel has only one temperature setting. Once the heated steering wheel has been turned on, it will stay on until

the operator turns it off. The heated steering wheel may not turn on when it is already warm.

The heated steering wheel control button is located within the climate or controls screen of the touchscreen.

 Press the heated steering wheel button

once to turn the heating element on.

 Press the heated steering wheel button a

second time to turn the heating element off.

NOTE: The engine must be running for the heated steering wheel to operate.

For information on use with the Remote Start system, see Ú page 24.

WARNING!

 Persons who are unable to feel pain to the

skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion, or other physical conditions must exercise care when using the steering wheel heater. It may cause burns even at low temperatures, especially if used for long periods.

(Continued)

WARNING! (Continued)

 Do not place anything on the steering wheel

that insulates against heat, such as a blanket or steering wheel covers of any type and material. This may cause the steering wheel heater to overheat.

DRIVER MEMORY SETTINGS — IF EQUIPPED

This feature allows the driver to save up to two different memory profiles for easy recall through a memory switch. Each memory profile saves desired position settings for the following features:

 Driver’s seat

 Easy Entry/Exit seat operation (on/off) (if

equipped)

 Adjustable pedals (if equipped)

 Side mirrors

NOTE: Your vehicle is equipped with two key fobs, each can be linked to either memory position 1 or 2.

Page 35

GETTING TO KNOW YOUR VEHICLE 33

The driver memory settings switch is located on the driver door, next to the door handle, and consists of three buttons:

 The set (S) button, which is used to activate

the memory save function.

 The (1) and (2) buttons which are used to

recall either of two pre-programmed memory profiles.

Memory Switch

PROGRAMMING THE MEMORY FEATURE

To create a new memory profile, perform the following:

NOTE: Saving a new memory profile will erase the selected profile from memory.

1. Place the vehicle’s ignition in the ON/RUN position (do not start the engine).

2. Adjust all memory profile settings to desired preferences (i.e., driver’s seat, outside mirrors, adjustable pedals (if equipped), and radio station presets).

3. Push the set (S) button on the memory switch, and then push the desired memory button (1 or 2) within five seconds. The instrument cluster display will display which memory position has been set.

NOTE: Memory profiles can be set without the vehicle in PARK, but the vehicle must be in PARK to recall a memory profile.

LINKING AND UNLINKING THE KEY FOB

O MEMORY

Your key fob can be programmed to recall one of two saved memory profiles by pushing the unlock button on the key fob.

NOTE: Before programming your key fob you must select the “Personal Settings Linked to Key Fob” feature through the Uconnect system Ú page 237.

To program your key fob, perform the following:

1. Place the vehicle’s ignition in the OFF position.

2. Select a desired memory profile 1 or 2.

3. Once the profile has been recalled, push and release the set (S) button on the memory switch.

4. Push and release button (1) or (2) accordingly. “Memory Profile Set” (1 or 2) will display in the instrument cluster.

5. Push and release the lock button on the key fob within 10 seconds.

NOTE: Your key fob can be unlinked to your memory settings by pushing the set (S) button, followed by pushing the unlock button on the key fob within 10 seconds.

Page 36

34 GETTING TO KNOW YOUR VEHICLE

MEMORY POSITION RECALL

NOTE: If a recall is attempted when the vehicle is not in PARK, a message will display in the instrument cluster display.

To recall the memory settings for driver one or two, push the desired memory button number (1 or 2) or the unlock button on the key fob linked to the desired memory position.

A recall can be canceled by pushing any of the memory buttons (S, 1, or 2) during a recall. When a recall is canceled, the driver seat will stop moving. A delay of one second will occur before another recall can be selected.

SEATS

Seats are a part of the Occupant Restraint System of the vehicle.

WARNING!

 It is dangerous to ride in a cargo area,

inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed.

(Continued)

WARNING! (Continued)

 Do not allow people to ride in any area of

your vehicle that is not equipped with seats and seat belts. In a collision, people riding in these areas are more likely to be seriously injured or killed.

 Be sure everyone in your vehicle is in a seat

and using a seat belt properly.

MANUAL ADJUSTMENT (FRONT SEATS )

F EQUIPPED

— I

WARNING!

 Adjusting a seat while the vehicle is moving

is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be adjusted properly and you could be injured. Adjust the seat only while the vehicle is parked.

 Do not ride with the seatback reclined so

that the shoulder belt is no longer resting against your chest. In a collision you could slide under the seat belt and be seriously or even fatally injured. Use the recliner only when the vehicle is parked.

Manual Front Seat Forward/Rearward Adjustment

Both front seats are adjustable forward or rearward. The manual seat adjustment handle is located under the seat cushion at the front edge of each seat.

Manual Seat Adjustment Bar

While sitting in the seat, pull up on the handle and slide the seat forward or rearward. Release the bar once you have reached the desired position. Then, using body pressure, move forward and rearward on the seat to be sure that the seat adjusters have latched.

Page 37

WARNING!

 Adjusting a seat while driving may be

dangerous. Moving a seat while driving could result in loss of control which could cause a collision and serious injury or death.

 Seats should be adjusted before fastening

the seat belts and while the vehicle is parked. Serious injury or death could result from a poorly adjusted seat belt.

Manual Front Seat Recline Adjustment

The recline lever is located on the outboard side of the seat. To recline the seat, lean forward slightly, lift the lever, lean back to the desired position and release the lever. To return the seatback to its normal upright position, lean forward and lift the lever. Release the lever once the seat back is in the upright position.

Manual Recline Lever

WARNING!

 Do not stand or lean in front of the seat

while actuating the handle. The seatback may swing forward and hit you causing injury.

 To avoid injury, place your hand on the seat-

back and actuate the handle, then position the seatback in the desired position.

Front Bench Seat — If Equipped

The seat is divided into three segments. The outboard seat portions are each 40% of the total width of the seat. If equipped, the back of the center portion (20%) easily folds down to provide an armrest/center storage compartment.

GETTING TO KNOW YOUR VEHICLE 35

Center Portion Of Front Bench Seat

Center Portion Folded Forward

Page 38

36 GETTING TO KNOW YOUR VEHICLE

MANUAL ADJUSTMENT (REAR SEATS)

WARNING!

Do not pile luggage or cargo higher than the top of the seatback. This could impair visibility or become a dangerous projectile in a sudden stop or collision.

Reclining Rear Seats — If Equipped

The recliner handle is located on the front of the rear outboard seat cushions. To adjust the seat back, lift upward on the handle, and slide the seat bottom forward. The lower portion of the seat back will tilt rearward. When you reach the desired position, release the handle.

Rear Seat Recliner Handle Locations

NOTE: This feature is not available if vehicle is equipped with rear bench seat.

WARNING!

Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest. In a collision you could slide under the seat belt, which could result in serious injury or death.

POWER ADJUSTMENT (FRONT SEATS) —

F EQUIPPED

Some models may be equipped with eight-way power driver and passenger seats. The power seat switches are located on the outboard side of the driver and passenger seat cushions. There are two power seat switches that are used to control the movement of the seat cushion and the seatback.

Power Seat Switches

1 — Power Seat Switch 2 — Power Seatback Switch

Adjusting The Seat Forward Or Rearward

The seat can be adjusted both forward and rearward by using the power seat switch. The seat will move in the direction of the switch. Release the switch when the desired position has been reached.

Adjusting The Seat Up Or Down

The height of the seats can be adjusted up or down by using the power seat switch. The seat will move in the direction of the switch. Release the switch when the desired position has been reached.

Page 39

GETTING TO KNOW YOUR VEHICLE 37

Tilting The Seat Up Or Down

The angle of the seat cushion can be adjusted up or down using the power seat switch. The front of the seat cushion will move in the direction of the switch. Release the switch when the desired position has been reached.

Reclining The Seatback

The angle of the seatback can be adjusted forward or rearward by using the power seat switch. The seat will move in the direction of the switch. Release the switch when the desired position is reached.

WARNING!

 Adjusting a seat while driving may be

dangerous. Moving a seat while driving could result in loss of control which could cause a collision and serious injury or death.

 Seats should be adjusted before fastening

the seat belts and while the vehicle is parked. Serious injury or death could result from a poorly adjusted seat belt.

(Continued)

WARNING! (Continued)

 Do not ride with the seatback reclined so

that the shoulder belt is no longer resting against your chest. In a collision you could slide under the seat belt, which could result in serious injury or death.

CAUTION!

Do not place any article under a power seat or impede its ability to move as it may cause damage to the seat controls. Seat travel may become limited if movement is stopped by an obstruction in the seat’s path.

Power Lumbar — If Equipped

Vehicles equipped with power driver or passenger seats may also be equipped with power lumbar. The power lumbar switch is located on the outboard side of the power seat. Push the switch forward to increase the lumbar support. Push the switch rearward to decrease the lumbar support. Pushing upward or downward on the switch will raise and lower the position of the support.

Power Lumbar Switch

Easy Entry/Exit Seat — If Equipped

This feature provides automatic driver’s seat positioning to enhance driver mobility when entering and exiting the vehicle.

The distance the driver’s seat moves depends on where you have the driver’s seat positioned when you place the vehicle’s ignition in the OFF position.

 When you place the vehicle’s ignition in the

OFF position, the driver’s seat will move about 2.4 inches (60 mm) rearward if the driver’s seat position is greater than or equal to 2.7 inches (67.7 mm) forward of the rear stop. The seat will return to its previously set position when you place the ignition into the ACC or ON/RUN position.

Page 40

38 GETTING TO KNOW YOUR VEHICLE

 When you remove the key fob from the igni-

tion, the driver’s seat will move to a position

0.3 inches (7.7 mm) forward of the rear stop if the driver’s seat position is between

0.9 inches and 2.7 inches (22.7 mm and

67.7 mm) forward of the rear stop. The seat will return to its previously set position when you place the ignition to the ACC or ON/RUN position.

 The Easy Entry/Easy Exit feature is disabled

when the driver’s seat position is less than

0.9 inches (22.7 mm) forward of the rear stop. At this position, there is no benefit to the driver by moving the seat for Easy Exit or Easy Entry.

When enabled in Uconnect Settings, Easy Entry and Easy Exit positions are stored in each memory setting profile Ú page 32.

NOTE: The Easy Entry/Exit feature is enabled or disabled through the programmable features in the Uconnect system Ú page 237.

HEATED SEATS — IF EQUIPPED

WARNING!

 Persons who are unable to feel pain to the

skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion or other physical condition must exercise care when using the seat heater. It may cause burns even at low temperatures, especially if used for long periods of time.

 Do not place anything on the seat or seat-

back that insulates against heat, such as a blanket or cushion. This may cause the seat heater to overheat. Sitting in a seat that has been overheated could cause serious burns due to the increased surface temperature of the seat.

For information on use with the Remote Start system, see Ú page 24.

Front Heated Seats — If Equipped

The front heated seats control buttons are located within the Uconnect system. You can gain access to the control buttons through the climate screen and the controls screen.

 Push the heated seat button once to turn

the HI setting on.

 Push the heated seat button a second

time to turn the MED setting on.

 Push the heated seat button a third time

to turn the LO setting on.

 Push the heated seat button a fourth time

to turn the heating elements off.

NOTE:

 Once a heat setting is selected, heat will be

felt within two to five minutes.

 The engine must be running for the heated

seats to operate.

 The level of heat selected will stay on until

the operator changes it.

Page 41

GETTING TO KNOW YOUR VEHICLE 39

Rear Heated Seats — If Equipped

On some models, the two rear outboard seats may be equipped with heated seats. There are two heated seat switches that allow the rear passengers to operate the seats independently. The heated seat switches for each heater are located on the rear of the center console.

There are two heated seat switches that allow the rear passengers to operate the seats independently. You can choose from HI, MED, LO, or OFF heat settings. Amber indicator lights in each switch indicate the level of heat in use.

 Push the heated seat button once to turn

the HI setting on.

 Push the heated seat button a second

time to turn the MED setting on.

 Push the heated seat button a third time

to turn the LO setting on.

 Push the heated seat button a fourth time

to turn the heating elements off.

NOTE: The level of heat selected will stay on until the operator changes it.

VENTILATED SEATS — IF EQUIPPED

Front Ventilated Seats

The ventilated seats are equipped with fans that can be controlled through the climate and control screen in the Uconnect system. The fans operate at three speeds, HI, MED and LO.

 Press the ventilated seat button once to

choose HI.

 Press the ventilated seat button a second

time to choose MED.

 Press the ventilated seat button a third

time to choose LO.

 Press the ventilated seat button a fourth

time to turn the ventilation off.

NOTE: The engine must be running for the ventilated seats to operate.

Rear Ventilated Seats — If Equipped

If equipped, the two outboard rear seats will have ventilated seats. The rear ventilated seat control switches are located on the rear of the center console.

There are two ventilated seat switches that allow the rear passengers to operate the seats independently. The fans operate at three speeds: HI, MED, and LO. Push the ventilated seat buttons to toggle through the speeds, or to turn the feature off.

NOTE: The engine must be running for the ventilated seats to operate.

PLASTIC GROCERY BAG RETAINERS

Retainer hooks which will hold plastic grocery bag handles are attached to the underside of the rear seat cushion. To access these hooks, lift the rear seat cushion upward.

Page 42

40 GETTING TO KNOW YOUR VEHICLE

HEAD RESTRAINTS

Head restraints are designed to reduce the risk of injury by restricting head movement in the event of a rear impact. Head restraints should be adjusted so that the top of the head restraint is located above the top of your ear.

WARNING!

 All occupants, including the driver, should

not operate a vehicle or sit in a vehicle’s seat until the head restraints are placed in their proper positions in order to minimize the risk of neck injury in the event of a crash.

 Head restraints should never be adjusted

while the vehicle is in motion. Driving a vehicle with the head restraints improperly adjusted or removed could cause serious injury or death in the event of a collision.

NOTE: Do not reverse the head restraints (making the rear of the head restraint face forward) in an attempt to gain additional clearance to the back of your head.

Front Head Restraints

Your vehicle is equipped with front four-way driver and passenger head restraints.

To raise the head restraint, pull upward on the head restraint. To lower the head restraint, push the adjustment button, located at the base of the head restraint, and push downward on the head restraint.

NOTE: The head restraints should only be removed by qualified technicians, for service purposes only. If either of the head restraints require removal, see an authorized dealer.

Head Restraint Adjustment Button Location

To adjust the head restraint forward, pull the top of the head restraint toward the front of the vehicle as desired and release. To adjust the head restraint rearward, pull the top of the head restraint to the forward most position and release. The head restraint will return to the rear most position.

Forward Adjustment

NOTE: If your vehicle is equipped with a front bench seat, the center head restraint is not adjustable or removable.

Page 43

GETTING TO KNOW YOUR VEHICLE 41

WARNING!

 All occupants, including the driver, should

not operate a vehicle or sit in a vehicle’s seat until the head restraints are placed in their proper positions in order to minimize the risk of neck injury in the event of a crash.

 Head restraints should never be adjusted

while the vehicle is in motion. Driving a vehicle with the head restraints improperly adjusted or removed could cause serious injury or death in the event of a collision.

Rear Head Restraints

The outboard head restraints are non-adjustable, but can be folded down for improved rearward visibility. Push the button on the outboard side of the head restraint to release. To return the head restraint to its upright position, push up on the head restraint until it locks back into place.

Release Button

WARNING!

Sitting in a seat with the head restraint in its lowered position could result in serious injury or death in a collision. Always make sure the outboard head restraints are in their upright positions when the seat is to be occupied.

The center head restraint is not adjustable or removable.

NOTE: The head restraints should only be removed by qualified technicians, for service purposes only. If any of the head restraints require removal, see an authorized dealer.

For child restraint tethering Ú page 334.

UCONNECT VOICE RECOGNITION

INTRODUCING VOICE RECOGNITION

Start using Uconnect Voice Recognition with these helpful quick tips. It provides the key Voice Commands and tips you need to know to control your vehicle’s Voice Recognition (VR) system.

Uconnect 3 With 5-inch Display

Page 44

42 GETTING TO KNOW YOUR VEHICLE

Uconnect 4C/4C NAV With 8.4-inch Display

If you see the NAV icon on the bottom bar or in the Apps menus of your 8.4-inch touchscreen, you have the Uconnect 4C NAV system. If not, you have a Uconnect 4C with 8.4-inch display system.

BASIC VOICE COMMANDS

The basic Voice Commands below can be given at any point while using your Uconnect system.

Push the VR button . After the beep, say:

 “Cancel” to stop a current voice session.

 “Help” to hear a list of suggested Voice

Commands.

 “Repeat” to listen to the system prompts

again.

Notice the visual cues that inform you of your Voice Recognition system’s status.

Uconnect 4C NAV With 12-inch Display

Page 45

GETTING TO KNOW YOUR VEHICLE 43

GET STARTED

The VR button is used to activate /deactivate your Voice Recognition system.

Helpful hints for using Voice Recognition:

 Reduce background noise. Wind noise and

passenger conversations are examples of noise that may impact recognition.

 Speak clearly at a normal pace and volume

while facing straight ahead.

 Each time you give a Voice Command, first

push the VR button, wait until after the beep, then say your Voice Command.

 You can interrupt the help message or

system prompts by pushing the VR button and saying a Voice Command from the current category.

Uconnect Voice Command Buttons

1 — Push To Start Or Answer A Phone Call And Send Or Receive A Text

2 — Push The Voice Recognition Button To Begin Radio, Media, Navigation, And Climate Functions

3 — Push The Hang-up Button To End A Call

ADDITIONAL INFORMATION

© 2020 FCA US LLC. All rights reserved. Mopar and Uconnect are registered trademarks and Mopar Owner Connect is a trademark of FCA US LLC. Android™ is a trademark of Google Inc. SiriusXM® and all related marks and logos are trademarks of SiriusXM® Radio Inc Ú page 482.

For Uconnect system support, call 1-877-855-8400 (24 hours a day 7 days a week) or visit DriveUconnect.com (US) or DriveUconnect.ca (Canada).

DRIVER ADJUSTABLE PEDALS — IF EQUIPPED

The adjustable pedals system is designed to allow a greater range of driver comfort for steering wheel tilt and seat position. This feature allows the brake and accelerator pedals to move toward or away from the driver to provide improved position with the steering wheel.

The adjustable pedal switch is located on the instrument panel, below the headlight switch.

Page 46

44 GETTING TO KNOW YOUR VEHICLE

Adjustable Pedals Switch

 The pedals can be adjusted with the ignition

placed in the OFF position.

 The pedals cannot be adjusted when the

vehicle is in REVERSE or when the Cruise Control system or Adaptive Cruise Control system is on. The following messages will appear in the instrument cluster display if the pedals are attempted to be adjusted when the system is locked out: “Adjustable Pedal Disabled — Cruise Control Engaged” or “Adjustable Pedal Disabled — Vehicle In Reverse”.

NOTE:

 Always adjust the pedals to a position that

allows full movement of the pedal.

 Further small adjustments may be necessary

to find the best possible seat/pedal position.

 For vehicles equipped with Driver Memory

Settings Ú page 32, you can use your key fob or the memory switch on the driver’s door trim panel to return the adjustable pedals to pre-programmed positions.

WARNING!

Do not adjust the pedals while the vehicle is moving. You could lose control and have an accident. Always adjust the pedals while the vehicle is parked.

CAUTION!

Do not place any article under the adjustable pedals or impede its ability to move, as it may cause damage to the pedal controls. Pedal travel may become limited if movement is stopped by an obstruction in the adjustable pedal's path.

MIRRORS

INSIDE REARVIEW MIRROR

Manual Mirror — If Equipped

The mirror head can be adjusted up, down, left, and right. The mirror should be adjusted to center on the view through the rear window.

Headlight glare from vehicles behind you can be reduced by moving the small control under the mirror to the night position (toward the rear of the vehicle). The mirror should be adjusted while set in the day position (toward the windshield).

Adjusting Rearview Mirror

Page 47

GETTING TO KNOW YOUR VEHICLE 45

Automatic Dimming Mirror — If Equipped

The rearview mirror can be adjusted up, down, left, and right. The mirror should be adjusted to center on the view through the rear window.

This mirror automatically adjusts for headlight glare from vehicles behind you.

NOTE: The Automatic Dimming Mirror feature is disabled when the vehicle is in REVERSE to improve the driver’s rear view.

The Automatic Dimming feature can be turned on or off through the touchscreen.

Automatic Dimming Mirror

CAUTION!

To avoid damage to the mirror during cleaning, never spray any cleaning solution directly onto the mirror. Apply the solution onto a clean cloth and wipe the mirror clean.

Digital Rearview Mirror — If Equipped

The Digital Rearview Mirror provides a high definition, wide and unobstructed view of the road behind while driving.

To activate the Digital Rearview Mirror, push the on/off control lever on the bottom of the mirror forward.

Digital Rearview Mirror

1 — On/Off Control 2 — Menu Button

3 — Left Scroll Button 4 — Right Scroll Button

Push the menu button next to the on/off control to access the following mirror options:

 Brightness

 Tilt

 Pan (if equipped)

Use the left and right buttons to scroll through menu options.

When not in use, pull the on/off control back toward the steering wheel to return the mirror to the regular Automatic Dimming Mirror.

NOTE: The Digital Rearview Mirror is not as effective during night time driving in low light applications.

Page 48

46 GETTING TO KNOW YOUR VEHICLE

Illuminated Vanity Mirror

To access an illuminated vanity mirror, flip down one of the visors and lift the cover.

Lift Cover For Illuminated Mirror

“Slide-On-Rod” Features Of Sun Visor — If Equipped

The sun visor “Slide-On-Rod” feature allows for additional flexibility in positioning the sun visor to block out the sun.

1. Fold down the sun visor.

2. Unclip the visor from the corner clip.

3. Pivot the sun visor toward the side window.

4. Extend the sun visor for additional sun blockage.

“Slide-On-Rod” Extender

NOTE: The sun visor can also be extended while the sun visor is against the windshield for additional sun blockage through the front of the vehicle.

OUTSIDE MIRRORS

The outside mirror(s) can be adjusted to the center of the adjacent lane of traffic to achieve the optimal view.

NOTE: If your vehicle is equipped with puddle lamps under the outside mirrors, they can be turned off through the Uconnect system Ú page 237.

WARNING!

Vehicles and other objects seen in an outside convex mirror will look smaller and farther away than they really are. Relying too much on side convex mirrors could cause you to collide with another vehicle or other object. Use your inside mirror when judging the size or distance of a vehicle seen in a side convex mirror.

Outside Mirrors Folding Feature

All outside mirrors are hinged and may be moved either forward or rearward to resist damage. The hinges have three detent positions:

 Full forward position

 Full rearward position

 Normal position

CAUTION!

It is recommended to fold the mirrors into the full rearward position to resist damage when entering a car wash or a narrow location.

Page 49

GETTING TO KNOW YOUR VEHICLE 47

OUTSIDE AUTOMATIC DIMMING

IRRORS — IF EQUIPPED

The driver’s outside mirror and if equipped, the passenger’s outside mirror, will automatically dim for glare from vehicles behind you. This feature is controlled by the inside automatic dimming mirror. The mirrors will automatically adjust for headlight glare when the inside mirror adjusts.

POWER MIRRORS

The power mirror switch is located on the driver's side door trim panel.

Power Mirror Controls

1 — Mirror Direction Control 2 — Right Mirror Selection 3 — Left Mirror Selection

The power mirror controls consist of mirror select buttons and a four-way mirror control switch. To adjust a mirror, push the mirror select button for the mirror that you want to adjust. Using the mirror control switch, push on any of the four arrows for the direction that you want the mirror to move.

Power Mirror Movement

Power mirror preselected positions can be controlled by the optional Driver Memory Settings feature Ú page 32.

POWER FOLDING OUTSIDE MIRRORS

OR STANDARD AND TRAILER TOW — IF

QUIPPED

The power folding mirrors can be folded rearward and unfolded into the normal driving position.

The switch for the power folding mirrors is located between the power mirror switches L (left) and R (right). Push the switch once and the mirrors will fold in, push the switch a second time and the mirrors will return to the normal driving position.

If the mirror is manually folded after a powered cycle, a potential extra button push is required to get the mirrors back to the normal driving position. If the mirror does not fold automatically, check for ice or dirt build up at the pivot area, which can cause excessive drag.

Power Folding Mirror Switch

Page 50

48 GETTING TO KNOW YOUR VEHICLE

Resetting The Power Folding Outside Mirrors

You may need to reset the power folding mirrors if the following occurs:

 The mirrors are accidentally blocked while

folding.

 The mirrors are accidentally manually

folded/unfolded (by hand or by pushing the power folding mirror switch).

 The mirrors come out of the unfolded posi-

tion.

 The mirrors shake and vibrate at normal

driving speeds.

To reset the power folding mirrors: Fold and unfold them by pushing the button (this may require multiple attempts). This resets them to their normal driving position.

TRAILER TOWING MIRRORS — IF

QUIPPED

These mirrors are designed with an adjustable mirror head to provide a greater vision range when towing extra-wide loads. To change position inboard or outboard, the mirror head should be rotated (flipped in or out).

Trailer Towing Position

NOTE: Fold the trailer towing mirrors prior to entering an automated car wash.

A small blindspot mirror is located next to the main mirror and can be adjusted manually.

Blindspot Mirror

HEATED MIRRORS — IF EQUIPPED

These mirrors are heated to melt frost or ice. This feature will be activated whenever you turn on the rear window defroster (if equipped) Ú page 60.

TILT SIDE MIRRORS IN REVERSE — IF

QUIPPED

This feature provides automatic outside mirror positioning which will assist with the driver’s ground visibility. The outside mirrors will move slightly downward from the present position when the vehicle is shifted into REVERSE. The outside mirrors will then return to the original position when the vehicle is shifted out of REVERSE. If the vehicle is equipped with Driver Memory Settings, this feature will be linked to the programmable settings.

NOTE: The Tilt Side Mirrors In Reverse feature can be turned on and off using the Uconnect system Ú page 237.

Page 51

GETTING TO KNOW YOUR VEHICLE 49

UNIVERSAL GARAGE DOOR OPENER (HOMELINK®) — IF EQUIPPED

HomeLink® Buttons

 HomeLink® replaces up to three hand-held

transmitters that operate devices such as garage door openers, motorized gates, lighting, or home security systems. The HomeLink® unit is powered by your vehicles 12 Volt battery.

 The HomeLink® buttons that are located in

the overhead console or sunvisor designate the three different HomeLink® channels.

 To operate HomeLink®, push and release

any of the programmed HomeLink® buttons. These buttons will activate the devices they are programmed to with each press of the corresponding HomeLink® button.

 The HomeLink® indicator light is located

above the center button.

BEFORE YOU BEGIN PROGRAMMING

OME LINK®

For efficient programming and accurate transmission of the radio frequency signal, it is recommended that a new battery be placed in the hand-held transmitter of the device that is being programmed to the HomeLink® system. Make sure your hand-held transmitter is programmed to activate the device you are trying to program your HomeLink® button to.

Ensure that your vehicle is parked outside of the garage before you begin programming.

It is recommended that you erase all the channels of your HomeLink® before you use it for the first time.

ERASING ALL THE HOMELINK®

HANNELS

To erase the channels, follow this procedure:

1. Place the ignition switch into the ON/RUN position.

2. Push and hold the two outside HomeLink® buttons (I and III) for up to 20 seconds, or until the HomeLink® indicator light flashes.

NOTE: Erasing all channels should only be performed when programming HomeLink® for the first time. Do not erase channels when programming additional buttons.

IDENTIFYING WHETHER YOU HAVE A

OLLING CODE OR NON-ROLLING CODE

EVICE

Before programming a device to one of your HomeLink® buttons, you must determine whether the device has a rolling code or non-rolling code.

Page 52

50 GETTING TO KNOW YOUR VEHICLE

Rolling Code Devices

To determine if your device has a rolling code, a good indicator is its manufacturing date. Typically, devices manufactured after 1995 have rolling codes. A device with a rolling code will also have a “LEARN” or “TRAIN” button located where the antenna is attached to the device. The button may not be immediately visible when looking at the device. The name and color of the button may vary slightly by manufacturer.

NOTE: The “LEARN” or “TRAIN” button is not the button you normally use to operate the device.

Non-rolling Code Devices

Most devices manufactured before 1995 will not have a rolling code. These devices will also not have a “LEARN” or “TRAIN” button.

PROGRAMMING HOMELINK® TO A

ARAGE DOOR OPENER

To program any of the HomeLink® buttons to activate your garage door opener motor, follow the steps below:

NOTE: All HomeLink® buttons are programmed using this procedure. You do not need to erase all channels when programming additional buttons.

1. Place the ignition switch into the ON/RUN position.

2. Place the garage door opener transmitter 1 to 3 inches (3 to 8 cm) away from the HomeLink® button you wish to program, while keeping the HomeLink® indicator light in view.

3. Push and hold the HomeLink® button you want to program while you push and hold the garage door opener transmitter button you are trying to replicate.

4. Continue to hold both buttons and observe the HomeLink® indicator light. The HomeLink® indicator light will flash slowly and then rapidly. Once this happens, release both buttons.

NOTE: Make sure the garage door opener motor is plugged in before moving on to the rolling code/ non-rolling code final steps.

Rolling Code Garage Door Opener Final Steps

NOTE: You have 30 seconds in which to initiate rolling code final step 2, after completing rolling code final step 1.

1. At the garage door opener motor (in the garage), locate the “LEARN” or “TRAIN” button. This can usually be found where the hanging antenna wire is attached to the garage door opener motor. Firmly push and release the “LEARN” or “TRAIN” button.

2. Return to the vehicle and push the programmed HomeLink® button three times (holding the button for two seconds each time). If the garage door opener motor operates, programming is complete.

3. Push the programmed HomeLink® button to confirm that the garage door opener motor operates. If the garage door opener motor does not operate, repeat the final steps for the rolling code procedure.

Page 53

GETTING TO KNOW YOUR VEHICLE 51

Non-Rolling Code Garage Door Opener Final Steps

1. Push and hold the programmed HomeLink® button and observe the HomeLink® indicator light. If the HomeLink® indicator light stays on constantly, programming is complete.

2. Push the programmed HomeLink® button to confirm that the garage door opener motor operates. If the garage door opener motor does not operate, repeat the steps from the beginning.

WARNING!

 Your motorized door or gate will open and

close while you are programming the universal transceiver. Do not program the transceiver if people or pets are in the path of the door or gate.

 Do not run your vehicle in a closed garage

or confined area while programming the transceiver. Exhaust gas from your vehicle contains Carbon Monoxide (CO) which is odorless and colorless. Carbon Monoxide is poisonous when inhaled and can cause you and others to be severely injured or killed.

PROGRAMMING HOMELINK® TO A

ISCELLANEOUS DEVICE

The procedure on how to program HomeLink® to a miscellaneous device follows the same procedure as programming to a garage door opener Ú page 50. Be sure to determine if the device has a rolling code, or non-rolling code before beginning the programming process.

NOTE: Canadian radio frequency laws require transmitter signals to time-out (or quit) after several seconds of transmission, which may not be long enough for HomeLink® to pick up the signal during programming. Similar to this Canadian law, some U.S. gate operators are designed to time-out in the same manner. The procedure may need to be performed multiple times to successfully pair the device to your HomeLink® buttons.

REPROGRAMMING A S INGLE

OME LINK® B UTTON

To reprogram a single HomeLink® button that has been previously trained, without erasing all the channels, follow the procedure below. Be sure to determine whether the new device you

want to program the HomeLink® button to has a Rolling Code, or Non-rolling Code.

1. Place the ignition in the ON/RUN position, without starting the engine.

2. Push and hold the desired HomeLink® button until the HomeLink® Indicator light begins to flash after 20 seconds. Do not release the button.

3. Without releasing the button, proceed with Step 2 in “Programming HomeLink® To A Garage Door Opener” Ú page 50, and follow all remaining steps.

CANADIAN/GATE OPERATOR

ROGRAMMING

For programming transmitters in Canada/ United States that require the transmitter signals to “time-out” after several seconds of transmission.

Canadian radio frequency laws require transmitter signals to time-out (or quit) after several seconds of transmission – which may not be long enough for HomeLink to pick up the signal during programming. Similar to this Canadian law, some U.S. gate operators are designed to time-out in the same manner.

Page 54

52 GETTING TO KNOW YOUR VEHICLE

It may be helpful to unplug the device during the cycling process to prevent possible overheating of the garage door or gate motor.

1. Cycle the ignition to the ON/RUN position.

2. Place the hand-held transmitter 1 to 3 inches (3 to 8 cm) away from the HomeLink button you wish to program while keeping the HomeLink indicator light in view.

3. Continue to press and hold the HomeLink button, while you press and release (“cycle”) your hand-held transmitter every two seconds until HomeLink has successfully accepted the frequency signal. The indicator light will flash slowly and then rapidly when fully trained.

4. Watch for the HomeLink indicator to change flash rates. When it changes, it is programmed. It may take up to 30 seconds or longer in rare cases. The garage door may open and close while you are programming.

5. Press and hold the programmed HomeLink button and observe the indicator light.

NOTE:

 If the indicator light stays on constantly,

programming is complete and the garage door/device should activate when the HomeLink button is pressed.

 To program the two remaining HomeLink

buttons, repeat each step for each remaining button. DO NOT erase the channels.

If you unplugged the garage door opener/ device for programming, plug it back in at this time.

Reprogramming A Single HomeLink Button (Canadian/Gate Operator)

To reprogram a channel that has been previously trained, follow these steps:

1. Cycle the ignition to the ON/RUN position.

2. Press and hold the desired HomeLink button until the indicator light begins to flash after 20 seconds. Do not release the button.

3. Without releasing the button, proceed with “Canadian/Gate Operator Programming” step 2 and follow all remaining steps Ú page 482.

EXTERIOR LIGHTS

HEADLIGHT SWITCH

The headlight switch is located on the left side of the instrument panel. This switch controls the operation of the headlights, parking lights, automatic headlights (if equipped), instrument panel light dimming, cargo light/trailer spotter lights (if equipped), and fog lights (if equipped).

Headlight Switch

1 — Rotate Headlight Control 2 — Ambient Light Dimmer Control 3 — Instrument Panel Dimmer Control 4 — Push Cargo Light Switch 5 — Push Fog Light Switch

Page 55

GETTING TO KNOW YOUR VEHICLE 53

To turn on the headlights, rotate the headlight switch clockwise. When the headlight switch is on, the parking lights, taillights, license plate light and instrument panel lights are also turned on. To turn off the headlights, rotate the headlight switch back to the O (off) position.

CAUTION!

Do not use abrasive cleaning components, solvents, steel wool or other abrasive materials to clean the lenses.

NOTE:

 Your vehicle is equipped with plastic head-

light and fog light (if equipped) lenses that are lighter and less susceptible to stone breakage than glass lights. Plastic is not as scratch resistant as glass and therefore different lens cleaning procedures must be followed.

 To minimize the possibility of scratching the

lenses and reducing light output, avoid wiping with a dry cloth. To remove road dirt, wash with a mild soap solution followed by rinsing.

MULTIFUNCTION LEVER

The multifunction lever is located on the left side of the steering column.

Multifunction Lever

DAYTIME RUNNING LIGHTS (DRLS)

The Daytime Running Lights (DRLs) come on whenever the engine is running, and the low beams are not on. The lights will remain on until the ignition is placed in the OFF or ACC position, or the parking brake is engaged.

NOTE:

 For vehicles sold in Canada, the Daytime

Running Lights will automatically deactivate when the front fog lights are turned on.

 If a turn signal is activated, the DRL lamp on

the same side of the vehicle will turn off for the duration of the turn signal activation. Once the turn signal is no longer active, the DRL lamp will illuminate.

 If allowed by law in the country in which the

vehicle was purchased, the Daytime Running Lights can be turned on and off using the Uconnect system Ú page 237.

HIGH/LOW BEAM SWITCH

Push the multifunction lever toward the instrument panel to switch the headlights to high beams. Pulling the multifunction lever back will turn the low beams on.

AUTOMATIC HIGH BEAM HEADLAMP

ONTROL — I F EQUIPPED

The Automatic High Beam Headlamp Control system provides increased forward lighting at night by automating high beam control through the use of a camera mounted on the inside rearview mirror or a windshield mounted camera. These cameras detect vehicle specific light and automatically switch from high beams to low beams until the approaching vehicle is out of view.

Page 56

54 GETTING TO KNOW YOUR VEHICLE

NOTE:

 The Automatic High Beam Headlamp Control

can be turned on or off by selecting “ON” under “Auto Dim High Beams” within your Uconnect Settings Ú page 237, as well as turning the headlight switch to the AUTO position.

 Broken, muddy, or obstructed headlights and

taillights of vehicles in the field of view will cause headlights to remain on longer (closer to the vehicle). Also, dirt, film, and other obstructions on the windshield or camera lens will cause the system to function improperly.

 If the windshield or Automatic High Beam

Headlamp Control mirror is replaced, the mirror must be re-aimed to ensure proper performance. See a local authorized dealer.

 To opt out of the Advanced Auto High Beam

Sensitivity Control (default) and enter Reduced High Beam Sensitivity Control (not recommended), toggle the high beam lever 6 full on/off cycles within 10 seconds of placing the ignition in the ON position. The system will return to the default setting upon placing the ignition in the OFF position.

FLASH-TO-PASS

You can signal another vehicle with your headlights by lightly pulling the multifunction lever toward you. This will cause the high beam headlights to turn on, and remain on, until the lever is released.

AUTOMATIC HEADLIGHTS — IF EQUIPPED

This system automatically turns the headlights on or off according to ambient light levels. To turn the system on, rotate the headlight switch to the AUTO position.

When the system is on, the Headlight Delay feature is also on. This means the headlights will stay on for up to 90 seconds after you place the ignition into the OFF position. To turn the automatic headlights off, turn the headlight switch out of the AUTO position.

NOTE: The engine must be running before the headlights will turn on in the Automatic Mode.

PARKING LIGHTS AND PANEL LIGHTS

To turn on the parking lights and instrument panel lights, rotate the headlight switch clockwise. To turn off the parking lights, rotate the headlight switch back to the O (off) position.

AUTOMATIC HEADLIGHTS WITH W IPERS

If your vehicle is equipped with Automatic Headlights, it also has this customer-programmable feature. When your headlights are in the automatic mode and the engine is running, they will automatically turn on when the wiper system is on. This feature is programmable through the Uconnect system Ú page 237.

If your vehicle is equipped with the Rain Sensing Wiper system Ú page 59, and it is activated, the headlights will automatically turn on after the wipers complete five wipe cycles within approximately one minute, and they will turn off approximately four minutes after the wipers completely stop.

NOTE: When your headlights come on during the daytime, the instrument panel lights will automatically dim to the lower nighttime intensity.

Page 57

GETTING TO KNOW YOUR VEHICLE 55

HEADLIGHT DELAY

To assist when exiting the vehicle, the headlight delay feature will leave the headlights on for up to 90 seconds. This delay is initiated when the ignition is placed in the OFF position while the headlight switch is on, and then the headlight switch is cycled off. Headlight delay can be cancelled by either turning the headlight switch on then off, or by placing the ignition in the ON position.

NOTE:

 This feature can be programmed through the

Uconnect system Ú page 237.

 The headlight delay feature is automatically

activated if the headlight switch is left in the AUTO position when the ignition is placed in the OFF position.

LIGHTS-ON REMINDER

If the headlights, parking lights, or cargo lights are left on after the ignition is placed in the OFF position, the vehicle will chime when the driver’s door is opened.

FOG LIGHTS — IF EQUIPPED

The fog lights are turned on by rotating the headlight switch to the parking light or headlight position and pushing in the fog light button on the headlight switch.

Fog Light Button

The fog lights will operate only when the parking lights are on or when the vehicle headlights are on low beam. An indicator light located in the instrument cluster will illuminate when the fog lights are on. The fog lights will turn off when the button is pushed a second time, when the headlight switch is rotated to the off position, or the high beam is selected.

If the fog lights are off, one of the fog lights will illuminate depending on the direction in which the vehicle is turning. This will provide increased visibility while turning, depending on the angle of the steering wheel.

TURN SIGNALS

Move the multifunction lever up or down to activate the turn signals. The arrows on each side of the instrument cluster flash to show proper operation.

NOTE: If either light remains on and does not flash, or there is a very fast flash rate, check for a defective outside light bulb.

LANE CHANGE ASSIST — IF EQUIPPED

Lightly push the multifunction lever up or down, without moving beyond the detent, and the turn signal will flash three times then automatically turn off.

Page 58

56 GETTING TO KNOW YOUR VEHICLE

CARGO LIGHTS/TRAILER SPOTTER

IGHTS WITH BED LIGHTS — IF

QUIPPED

The cargo light, bed lights, and trailer spotter lights are turned on by pushing the cargo light button located on the lower half of the headlight switch.

Cargo/Bed Lights Button On Headlight Switch

Cargo Lights

When the vehicle is stationary, these lights can also be turned on using the switch located just inside the pickup box, on the lower part of the bed light lens. A telltale will illuminate in the instrument cluster display when these lights are on. Pushing the switch a second time will turn the lights off.

Bed Light Switch (Without RamBox)

The cargo light and bed lights (if equipped) will turn on for approximately 30 seconds when a key fob unlock button is pushed, as part of the Illuminated Entry feature.

When these lights are activated using the button on the headlight switch, the trailer spotter lights will remain illuminated when the vehicle transmission is in PARK, NEUTRAL, or REVERSE. The trailer spotter lights will turn off when the vehicle transmission is placed in DRIVE.

NOTE: The cargo light will automatically turn off if the vehicle is shifted into NEUTRAL or DRIVE, and will turn back on when the vehicle is shifted into PARK or REVERSE. The bed lights are not affected by gear selection.

NOTE: For vehicles shipped to or sold in the states of California or Mississippi, the cargo, bed, and mirror spotter lights will not work while the vehicle is in motion. In every other state, the cargo and mirror spotter lights will turn off when the vehicle is in motion, but the bed light will remain on. In all states, including California and Mississippi, if a bed camera is deactivated, the bed lights will turn back on.

Page 59

GETTING TO KNOW YOUR VEHICLE 57

BATTERY SAVER

Timers are set to both the interior and exterior lights to protect the life of your vehicle’s battery.

After 10 minutes, if the ignition is OFF and any door is left open or the dimmer control is rotated all the way up to the dome light on position, the interior lights will automatically turn off.

NOTE: Battery saver mode is canceled if the ignition is ON.

If the headlights remain on while the ignition is placed in the OFF position, the exterior lights will automatically turn off after eight minutes. If the headlights are turned on and left on for eight minutes while the ignition is OFF, the exterior lights will automatically turn off.

INTERIOR LIGHTS

COURTESY LIGHTS

Courtesy and dome lights are turned on when the doors are opened or the Dome ON button is pushed on the overhead console. If your vehicle is equipped with Remote Keyless Entry and the unlock button is pushed on the key fob, the

courtesy and dome lights will turn on. When a door is open and the interior lights are on, and the Dome Defeat button on the overhead console is pressed, the interior lights will turn off.

Front Map/Reading Lights

The overhead console lights can also be operated individually as reading lights by pushing the corresponding buttons.

Front Courtesy/Reading Lights

1 — Reading Light On/Off Buttons 2 — Dome Defeat Button 3 — Dome ON Button

Three types of rear courtesy/reading lights are available for your vehicle.

 Push button on/off

 Push lens on/off

 Push round puck lens on/off (if equipped

with Dual Pane Sunroof)

NOTE: The courtesy/reading lights will remain on until the switch is pushed a second time, so be sure they have been turned off before exiting the vehicle. If the interior lights are left on after the ignition is turned off, they will automatically turn off after 10 minutes.

Dimmer Control

The dimmer controls are inboard and adjacent to the headlight switch located on the left side of the instrument panel.

Dimmer Controls

1 — Ambient Light Control 2 — Instrument Panel Dimmer Control

Page 60

58 GETTING TO KNOW YOUR VEHICLE

With the parking lights or headlights on, rotating the right dimmer control upward will increase the brightness of the instrument panel lights. Rotating the left dimmer control will adjust the interior and ambient light levels when the headlights are on.

NOTE: The dimming of the touchscreen is programmable through the Uconnect system Ú page 237.

ILLUMINATED ENTRY

The courtesy lights will turn on when you use the key fob to unlock the doors or open any door.

This feature also turns on the approach lamps located beneath the outside mirrors (if equipped).

The lights will fade to off after approximately 30 seconds, or they will immediately fade to off once the ignition switch is placed in the ON/ RUN position from the OFF position.

The front courtesy overhead console and door courtesy lights will not turn off if the Dome ON button on the overhead console is pushed. The overhead and door courtesy lights will turn off after 10 minutes to protect the battery.

The illuminated entry system will not operate if the Dome Defeat button on the overhead console is pushed.

NOTE: If your vehicle is equipped with Illuminated Approach lights under the outside mirrors, they will also be turned off by pushing the Dome Defeat button.

WINDSHIELD WIPERS AND WASHERS

The windshield wiper/washer controls are located on the multifunction lever on the left side of the steering column. The front wipers are operated by rotating a switch, located on the end of the lever.

Windshield Wiper/Washer Lever

WINDSHIELD WIPER OPERATION

Intermittent Wipers

The intermittent feature of this system was designed for use when weather conditions make a single wiping cycle, with a variable pause between cycles, desirable. For maximum delay between cycles, rotate the control knob upward to the first detent.

The delay interval decreases as you rotate the knob until it enters the low continual speed position. The delay can be regulated from a maximum of about 18 seconds between cycles, to a cycle every one second. The delay intervals will double in duration when the vehicle speed is 10 mph (16 km/h) or less.

Windshield Washers

To use the windshield washer, push the washer knob, located on the end of the multifunction lever, inward and hold. Washer fluid will be sprayed and the wiper will operate for two to three cycles after the washer knob is released.

If the washer knob pushed while in the delay range, the wiper will operate for several seconds after the washer knob is released. It will then resume the intermittent interval previously selected. If the washer knob is

Page 61

GETTING TO KNOW YOUR VEHICLE 59

pushed while in the off position, the wiper will turn on and cycle approximately three times after the wash knob is released.

To prevent freeze-up of your windshield washer system in cold weather, select a solution or mixture that meets or exceeds the temperature range of your climate. This rating information can be found on most washer fluid containers.

WARNING!

Sudden loss of visibility through the windshield could lead to a collision. You might not see other vehicles or other obstacles. To avoid sudden icing of the windshield during freezing weather, warm the windshield with the defroster before and during windshield washer use.

Mist

When a single wipe to clear off road mist or spray from a passing vehicle is needed, push the washer knob, located on the end of the multifunction lever, inward briefly and release. The wipers will cycle one time and automatically shut off.

NOTE: The mist feature does not activate the washer pump; therefore, no washer fluid will be sprayed on the windshield. The wash function must be used in order to spray the windshield with washer fluid.

For information on wiper care and replacement, see Ú page 418.

RAIN SENSING WIPERS — IF EQUIPPED

This feature senses rain or snowfall on the windshield and automatically activates the wipers. Rotate the end of the multifunction lever to one of four detent positions to activate this feature.

The sensitivity of the system can be adjusted with the multifunction lever. Wiper delay position one is the least sensitive, and wiper delay detent position four is the most sensitive.

Wiper delay position three should be used for normal rain conditions.

Positions one and two can be used if the driver desires less wiper sensitivity. Position four can be used if the driver desires more sensitivity. Place the wiper switch in the O (off) position when not using the system.

NOTE:

 The Rain Sensing feature will not operate

when the wiper switch is in the low or high-speed position.

 The Rain Sensing feature may not function

properly when ice, or dried salt water is present on the windshield.

 Use of Rain-X or products containing wax or

silicone may reduce Rain Sensing performance.

 The Rain Sensing feature can be turned on

and off using the Uconnect system Ú page 237.

The Rain Sensing system has protection features for the wiper blades and arms, and will not operate under the following conditions:

 Low Ambient Temperature — When the igni-

tion is first placed in the ON position, the Rain Sensing system will not operate until the wiper switch is moved, vehicle speed is greater than 3 mph (5 km/h), or the outside temperature is greater than 32°F (0°C).

Page 62

60 GETTING TO KNOW YOUR VEHICLE

 Transmission In NEUTRAL Position — When

the ignition is ON, and the automatic transmission is in the NEUTRAL position, the Rain Sensing system will not operate until the wiper switch is moved, vehicle speed is greater than 3 mph (5 km/h), or the gear selector is moved out of the NEUTRAL position.

 Remote Start Mode Inhibit — On vehicles

equipped with Remote Start system, Rain Sensing wipers are not operational when the vehicle is in the remote start mode.

CLIMATE CONTROLS

The Climate Control system allows you to regulate the temperature, air flow, and direction of air circulating throughout the vehicle. The controls are located on the touchscreen (if equipped), on the sides of the touchscreen or on the instrument panel below the radio.

AUTOMATIC CLIMATE CONTROL

ESCRIPTIONS AND F UNCTIONS

Uconnect 4/4C/4C NAV With 8.4-inch Display Auto-

matic Temperature Controls

Uconnect 4C NAV With 12-inch Display Automatic Tem-

perature Controls

NOTE: Icons and descriptions can vary based upon vehicle equipment.

MAX A/C Button

Press and release the MAX A/C button on the touchscreen to change the current setting to the coldest output

of air. The MAX A/C indicator illuminates when MAX A/C is on. Pressing the button again will cause the MAX A/C operation to exit.

NOTE: The MAX A/C button is only available on the touchscreen.

A/C Button

Press and release this button on the

touchscreen, or push the button on

the faceplate to change the current

setting. The A/C indicator illuminates

when A/C is on.

Page 63

GETTING TO KNOW YOUR VEHICLE 61

Recirculation Button

Press and release this button on the touchscreen, or push the button on the faceplate, to change the system

between Recirculation mode and outside air mode. The Recirculation indicator and the A/C indicator illuminate when the Recirculation button is pressed. Recirculation can be used when outside conditions, such as smoke, odors, dust, or high humidity are present. Recirculation can be used in all modes. Recirculation may be unavailable (button on the touchscreen greyed out) if conditions exist that could create fogging on the inside of the windshield. The A/C can be deselected manually without disturbing the mode control selection. Continuous use of the Recirculation mode may make the inside air stuffy and window fogging may occur. Extended use of this mode is not recommended.

Auto Button

Set your desired temperature and

press AUTO. AUTO will achieve and

maintain your desired temperature by

automatically adjusting the blower

speed and air distribution. AUTO mode is highly recommended for efficiency.

You can turn AUTO on in one of two ways:

 Press and release this button on the touch-

screen.

 Push the button on the faceplate.

Toggling this function will cause the system to switch between manual mode and automatic mode Ú page 65.

Front Defrost Button

Press and release the Front Defrost button on the touchscreen, or push and release the button on the

faceplate, to change the current airflow setting to Defrost mode. The Front Defrost indicator illuminates when Front Defrost is on. Air comes from the windshield and side window demist outlets. When the defrost button is selected, the blower level may increase. Use Defrost mode with maximum temperature settings for best windshield and side window defrosting and defogging. When toggling the front defrost mode button, the climate system will return to the previous setting.

Rear Defrost Button

Press and release the Rear Defrost button on the touchscreen, or push and release the button on the

faceplate, to turn on the rear window defroster and the heated outside mirrors (if equipped). The Rear Defrost indicator illuminates when the rear window defroster is on. The rear window defroster automatically turns off after 15 minutes.

CAUTION!

Failure to follow these cautions can cause damage to the heating elements:

 Use care when washing the inside of the

rear window. Do not use abrasive window cleaners on the interior surface of the window. Use a soft cloth and a mild washing solution, wiping parallel to the heating elements. Labels can be peeled off after soaking with warm water.

 Do not use scrapers, sharp instruments, or

abrasive window cleaners on the interior surface of the window.

 Keep all objects a safe distance from the

window.

Page 64

62 GETTING TO KNOW YOUR VEHICLE

Driver And Passenger Temperature Up And Down Buttons

These buttons provide the driver and passenger with independent temperature control.

Push the red button (or rotate knob if equipped) on the faceplate or touchscreen, or press and slide the

temperature bar towards the red arrow button on the touchscreen for warmer temperature settings.

Push the blue button (or rotate knob if

equipped) on the faceplate or

touchscreen, or press and slide the

temperature bar towards the blue arrow button on the touchscreen for cooler temperature settings.

NOTE:

 The numbers within the temperature display

will only appear if the system is equipped with an automatic climate control system.

 Up and down buttons are only available on

vehicles equipped with a 12-inch display.

SYNC Button

Press the SYNC button on the touchscreen to toggle the SYNC feature on/off. The SYNC indicator

illuminates when SYNC is on. SYNC synchronizes the passenger temperature setting with the driver temperature setting. Changing the passenger’s temperature setting while in SYNC will automatically exit this feature.

NOTE: The SYNC button is only available on the touchscreen.

Blower Control

Blower Control regulates the amount

of air forced through the climate

control system. There are seven

blower speeds available. Adjusting the blower will cause automatic mode to switch to manual operation. The speeds can be selected using either the blower control knob on the faceplate or the buttons on the touchscreen.

Faceplate

The blower speed increases as you turn the blower control knob clockwise from the lowest blower setting. The blower speed decreases as you turn the blower control knob counterclockwise.

Touchscreen

Use the small blower icon to reduce the blower setting and the large blower icon to increase the blower setting. Blower can also be selected by pressing the blower bar area between the icons.

Mode Control

Select Mode by pressing one of the Mode buttons on the touchscreen, or pushing the Mode button on the

faceplate, to change the airflow distribution mode. The airflow distribution mode can be adjusted so air comes from the instrument panel outlets, floor outlets, defrost outlets, and demist outlets.

Page 65

GETTING TO KNOW YOUR VEHICLE 63

Panel Mode

Air comes from the outlets in the instrument panel. Each of these outlets can be individually adjusted to

direct the flow of air. The air vanes of the center outlets and outboard outlets can be moved up and down or side to side to regulate airflow direction. There is a shut off wheel located below the air vanes to shut off or adjust the amount of airflow from these outlets.

Bi-Level Mode

Air comes from the instrument panel

outlets and floor outlets. A slight

amount of air is directed through the

defrost and side window demister

outlets.

NOTE: Bi-Level mode is designed under comfort conditions to provide cooler air out of the panel outlets and warmer air from the floor outlets.

Floor Mode

Air comes from the floor outlets. A slight amount of air is directed through the defrost and side window demister outlets.

Mix Mode

Air is directed through the floor, defrost, and side window demister outlets. This setting works best in cold

or snowy conditions that require extra heat to the windshield. This setting is good for maintaining comfort while reducing moisture on the windshield.

Climate Control OFF Button

Press and release the OFF button on

the touchscreen, or push the OFF

button on the faceplate (if equipped)

to turn the Climate Control on/off.

MANUAL CLIMATE CONTROL

ESCRIPTIONS AND F UNCTIONS

Uconnect 3 With 5-inch Display Manual Temperature

Controls

MAX A/C Setting

Set the temperature control knob to the MAX A/C setting to change the current setting to the coldest output

of air. Moving the temperature control knob away from the MAX A/C setting causes the MAX A/C operation to exit.

Page 66

64 GETTING TO KNOW YOUR VEHICLE

A/C Button

Push the A/C button to engage the Air Conditioning (A/C). The A/C indicator illuminates when A/C is on.

NOTE:

 For Manual Climate Controls, if the system is

in Mix, Floor or Defrost Mode, the A/C can be turned off, but the A/C system shall remain active to prevent fogging of the windows.

 If fog or mist appears on the windshield or

side glass, select Defrost mode, and increase blower speed if needed.

 If your air conditioning performance seems

lower than expected, check the front of the A/C condenser (located in front of the radiator), for an accumulation of dirt or insects. Clean with a gentle water spray from the front of the radiator and through the condenser.

Recirculation Button

Push the Recirculation button to change the system between recirculation mode and outside air

mode. The Recirculation indicator and the A/C indicator illuminate when the Recirculation button is pressed. Recirculation

can be used when outside conditions, such as smoke, odors, dust, or humidity are present. Recirculation can be used in all modes except for Defrost. Recirculation may be unavailable if conditions exist that could create fogging on the inside of the windshield. The A/C can be deselected manually without disturbing the mode control selection. Continuous use of the Recirculation mode may make the inside air stuffy and window fogging may occur. Extended use of this mode is not recommended.

On systems with Manual Climate Controls, the Recirculation mode is not allowed in Defrost mode to improve window cleaning operation. Recirculation is disabled automatically if this mode is selected. Attempting to use Recirculation while in this mode causes the LED in the control button to blink and then turn off.

Front Defrost Setting

Turn the mode control knob to the Front Defrost mode setting. Air comes from the windshield and side window

demist outlets. When the defrost button is selected, the blower level may increase. Use Defrost mode with maximum temperature settings for best windshield and side window defrosting and defogging.

Rear Defrost Button

Push and release the Rear Defrost Control button to turn on the rear window defroster and the heated

outside mirrors (if equipped). The Rear Defrost indicator illuminates when the rear window defroster is on. The rear window defroster automatically turns off after 15 minutes.

CAUTION!

Failure to follow these cautions can cause damage to the heating elements:

 Use care when washing the inside of the

 Do not use scrapers, sharp instruments, or

abrasive window cleaners on the interior surface of the window.

 Keep all objects a safe distance from the

window.

Page 67

GETTING TO KNOW YOUR VEHICLE 65

Temperature Control

Temperature Control regulates the temperature of the air forced through the climate system.

The temperature increases as you turn the temperature control knob clockwise.

The temperature decreases as you turn the temperature control knob counterclockwise.

Blower Control

Blower Control regulates the amount of air forced through the climate control system. There are seven

blower speeds available. The blower speed increases as you turn the blower control knob clockwise from the lowest blower setting. The blower speed decreases as you turn the blower control knob counterclockwise.

Mode Control

Turn the mode control knob to adjust

airflow distribution. The airflow

distribution mode can be adjusted so

air comes from the instrument panel outlets, floor outlets, defrost outlets and demist outlets.

Panel Mode

Air comes from the outlets in the instrument panel. Each of these outlets can be individually adjusted to

Bi-Level Mode

Air comes from the instrument panel

outlets and floor outlets. A slight

amount of air is directed through the

defrost and side window demister outlets.

NOTE: Bi-Level mode is designed under comfort conditions to provide cooler air out of the panel outlets and warmer air from the floor outlets.

Floor Mode

Air comes from the floor outlets. A

slight amount of air is directed

through the defrost and side window

demister outlets.

Mix Mode

Air is directed through the floor, defrost, and side window demister outlets. This setting works best in cold

or snowy conditions that require extra heat to the windshield. This setting is good for maintaining comfort while reducing moisture on the windshield.

AUTOMATIC TEMPERATURE CONTROL (ATC) — I

Automatic Operation

1. Push the AUTO button on the faceplate, or

2. Next, adjust the temperature that you would

3. When the system is set up for your comfort

F EQUIPPED

the AUTO button on the touchscreen on the Automatic Temperature Control (ATC) Panel.

like the system to maintain by adjusting the driver and passenger temperature control buttons. Once the desired temperature is displayed, the system will achieve and automatically maintain that comfort level.

level, it is not necessary to change the settings. You will experience the greatest efficiency by simply allowing the system to function automatically.

Page 68

66 GETTING TO KNOW YOUR VEHICLE

NOTE:

 It is not necessary to move the temperature

settings for cold or hot vehicles. The system automatically adjusts the temperature, mode, and blower speed to provide comfort as quickly as possible.

 The temperature can be displayed in US or

Metric units by selecting the US/Metric customer-programmable feature within Uconnect Settings Ú page 237.

To provide you with maximum comfort in the Automatic mode during cold start-ups, the blower fan will remain on low until the engine warms up. The blower will increase in speed and transition into Auto mode.

Manual Operation Override

This system offers a full complement of manual override features. The AUTO symbol in the front ATC display will be turned off when the system is being used in the manual mode.

CLIMATE VOICE RECOGNITION

Adjust vehicle temperatures hands-free and keep everyone comfortable while you keep moving ahead.

Push the VR button on the steering wheel. After the beep, say one of the following commands:

 “Set driver temperature to 70 degrees”

 “Set passenger temperature to 70 degrees”

Did you know: Voice Command for Climate may only be used to adjust the interior temperature of your vehicle. Voice Command will not work to adjust the heated seats or steering wheel if equipped.

OPERATING TIPS

NOTE: Refer to the chart at the end of this section for suggested control settings for various weather conditions.

Summer Operation

The engine cooling system must be protected with a high-quality antifreeze coolant to provide proper corrosion protection and to protect against engine overheating. OAT coolant (conforming to MS.90032) is recommended.

Winter Operation

To ensure the best possible heater and defroster performance, make sure the engine cooling system is functioning properly and the

proper amount, type, and concentration of coolant is used. Use of the Air Recirculation mode during Winter months is not recommended, because it may cause window fogging.

Vacation/Storage

For information on maintaining the Climate Control system when the vehicle is being stored for an extended period of time, see Ú page 461.

Window Fogging

Vehicle windows tend to fog on the inside in mild, rainy, and/or humid weather. To clear the windows, select Defrost or Mix mode and increase the front blower speed. Do not use the Recirculation mode without A/C for long periods, as fogging may occur.

Outside Air Intake

Make sure the air intake, located directly in front of the windshield, is free of obstructions, such as leaves. Leaves collected in the air intake may reduce airflow, and if they enter the air distribution box, they could plug the water drains. In Winter months, make sure the air intake is clear of ice, slush, and snow.

Page 69

GETTING TO KNOW YOUR VEHICLE 67

Cabin Air Filter

The Climate Control system filters out dust and pollen from the air. Contact an authorized dealer to service your cabin air filter, and to have it replaced when needed.

Stop/Start System — If Equipped

While in an Autostop, the Climate Control system may automatically adjust airflow to maintain cabin comfort. Customer settings will be maintained upon return to an engine running condition.

Windshield Wiper De-Icer — If Equipped

The windshield wiper de-icer is a heating element located at the base of the windshield.

It operates automatically once the following conditions are met:

 Activation By Front Defrost

The wiper de-icer activates automatically during a cold weather manual start with full defrost, and when the ambient temperature is below 33°F (0.6°C).

 Activation By Rear Defrost

The wiper de-icer activates automatically when the Rear Defrost is operating and the ambient temperature is below 33°F (0.6°C).

 Activation By Remote Start Operation

When the Remote Start is activated and the outside ambient temperature is less than 33°F (0.6°C) the windshield wiper de-icer is activated. Upon exiting Remote Start, the climate control functions will resume their previous operation except, if the de-icer is active, the de-icer timer and operation will continue.

Operating Tips Chart

WEATHER

Hot Weather And

Vehicle Interior Is Very

Hot

Warm Weather

CONTROL SETTINGS

Set the mode control

to (Panel Mode),

(A/C) on, and

blower on high. Roll

down the windows for

a minute to flush out the hot air. Adjust the controls as needed to

achieve comfort.

Turn (A/C) on and

set the mode control

to the (Panel

Mode)position.

WEATHER

Cool Sunny

Cool & Humid

Conditions

Cold Weather

CONTROL SETTINGS

Operate in

(Bi-Level Mode)

position.

Set the mode control

to (Floor Mode)

position and turn on

(A/C) to keep

windows clear.

Set the mode control

to the (Floor

Mode) position. If

windshield fogging

starts to occur, move

the control to the (Mix Mode) position.

Page 70

68 GETTING TO KNOW YOUR VEHICLE

INTERIOR STORAGE AND EQUIPMENT

STORAGE

Glove Compartment

The glove compartment is located on the passenger side of the instrument panel and features both an upper and lower storage area.

Glove Compartment

1 — Upper Glove Compartment Release Button (If Equipped)

2 — Upper Glove Compartment 3 — Lower Glove Compartment

If equipped with a covered upper glove compartment, push the release button to open.

To open the lower glove compartment, pull the release handle.

WARNING!

Do not operate this vehicle with a glove compartment in the open position. Driving with the glove compartment open may result in injury in a collision.

Door Storage

Front Door Storage — If Equipped

Storage areas are located in the door trim panels.

Rear Door Storage — If Equipped

Storage compartments are located in both the driver and passenger rear door trim panels.

Center Storage Compartment — If Equipped

The center storage compartment is located between the driver and passenger seats. The storage compartment provides an armrest and contains both an upper and lower storage area.

Center Storage Compartment

WARNING!

 This armrest is not a seat. Anyone seated

on the armrest could be seriously injured during vehicle operation, or a collision. Only use the center seating position when the armrest is fully upright.

 In a collision, the latch may open if the total

weight of the items stored exceeds about 10 lbs (4.5 kg). These items could be thrown about endangering occupants of the vehicle. Items stored should not exceed a total of 10 lbs (4.5 kg).

Page 71

GETTING TO KNOW YOUR VEHICLE 69

Pull on the upper handle on the front of the armrest to raise the cover. The upper storage area contains a USB power outlet that can be used to power small electrical devices.

Center Storage Compartment

1 — Upper Console Handle 2 — Lower Console Handle

Upper Storage USB Outlet

With the upper lid closed, pull on the lower handle to open the lower storage bin. The lower bin contains a power inverter. There is also a “fill line” located along the rear inside wall of the lower bin. Contents above the “fill line” may interfere with cupholder placement if equipped with a premium center console.

Forward Portion Of Lower Storage Bin

1 — Wireless Charging Pad 2 — Power Inverter 3 — Storage Area

WARNING!

Do not operate this vehicle with a console compartment lid in the open position. Driving with the console compartment lid open may result in injury in a collision.

Premium Center Console — If Equipped

The premium center console is equipped with two front storage bins located in front of the center storage compartment. These storage bins may be equipped with tandem doors. Push the front bin to access the cupholders, or push the rear bin to access the coin holder/small storage bin.

Center Console Tandem Doors— If Equipped

1 — Push Front Bin Access 2 — Push Rear Bin Access

Page 72

70 GETTING TO KNOW YOUR VEHICLE

Overhead Sunglass Storage

At the front of the overhead console, a compartment is provided for the storage of one pair of sunglasses.

From the closed position, push the door latch to open the compartment.

Tandem Doors Open Position

1 — Front Bin Open 2 — Rear Bin Open

Push the release button at the front of the cupholder bin to slide tray rearward to access the front lower storage bin, or forward to access the rear lower storage bin.

Push Release Button To Slide Tray

Front Bench Seat Storage

With the seatback in the upright position, lift the center seat bottom to access additional storage underneath the seat.

Overhead Sunglass Door

Front Bench Seat Storage — If Equipped

If your vehicle is equipped with a front bench seat, storage can be found by folding down the center seat back. A console storage area and cupholders are available.

Below Seat Bottom Storage

Page 73

GETTING TO KNOW YOUR VEHICLE 71

There is a storage drawer located in the lower center of the instrument panel. It can be released by pushing the access button above it. Pull drawer outward to the fully open position.

Storage Drawer Access Button

Rear Console Storage — If Equipped

The center portion of the 40/20/40 rear seat will fold forward for rear seat cupholders and a storage compartment. Lift up on the console latch to access the storage compartment.

Rear Console Latch Location

Seatback Storage

Located in the back of both the driver and passenger front seats are pockets that can be used for storage.

Driver’s Side Seatback Storage

Second Row In-Floor Storage Bin — If Equipped

In-floor storage bins are located in front of the second row seats and can be used for extra storage. The storage bins have removable liners that can be easily removed for cleaning.

To open the in-floor storage bin, lift upward on the handle of the latch and open the lid.

In-Floor Storage Bin Latch

Page 74

72 GETTING TO KNOW YOUR VEHICLE

NOTE: The front seat may have to be moved forward to fully open the lid.

Opened Storage Bin

Each storage bin also contains two hooks for securing cargo. These hooks should be used to secure loads safely when the vehicle is moving.

In-Floor Storage Bin Hooks

NOTE: The maximum load limit for each hook is 250 lbs (113 kg).

Storage Under Rear Seat — If Equipped

To access the storage under the rear seats, unlatch the lock mechanism in the center of the seat base by rotating it to either side, and fold the front of the seat base forward.

Folding Down Front Of Seat Base

1 — Lock Mechanism 2 — Front Of Seat Base

Flip the inside of the base upward into the upright position, locking into place, creating and extended storage area.

Fully Extended Storage Area

NOTE: The rear seats do not need to be folded up to access this feature.

USB/AUX C ONTROL

Located on the center stack, just below the instrument panel, is the main media hub. There are four total USB ports: Two Mini-USBs (Type C) and two Standard USBs (Type A). There is also an AUX port located in the middle of the USB Ports.

Plugging in a smartphone device to a USB Port may activate Android Auto™ or Apple CarPlay® features, if equipped. For further information, refer to “Android Auto™” or “Apple CarPlay®” in the Owner’s Manual Supplement.

Page 75

GETTING TO KNOW YOUR VEHICLE 73

NOTE: Two devices can be plugged in at the same time, and both ports will provide charging capabilities. Only one port can transfer data to the system at a time. A pop-up will appear and allow you to select the device transferring data.

For example, if a device is plugged into the Type A USB port and another device is plugged into the Type C USB port, a message will appear and allow you to select which device to use.

Center Stack USB/AUX Media Hub

1 — USB Port #1 2 — AUX Port 3 — USB Port #2

Rear USB Ports

1 — Rear Media USB Ports 2 — Rear Charge Only USB Ports

The third and fourth USB ports are located behind the center console, above the power inverter. One of these USBs ports are charge only.

Applicable to only Uconnect 4C/4C NAV With

8.4-inch Display, and Uconnect 4C NAV With 12-inch Display radios, different scenarios are listed below when a non-phone device is plugged into the smaller and larger USB ports,

and when a phone device is plugged into the smaller and larger USB ports:

 “A new device is now connected. Previous

connection was lost”.

 “(Phone Name) now connected. Previous

connection was lost”.

 “Another device is in use through the same

USB port. Please disconnect the first device to use the second device”.

Plugging in a phone or another USB device may cause the connection to a previous device to be lost.

If equipped, your vehicle may also contain a USB port located on the top tray of the vehicles center console.

If equipped, two Mini-USB ports (Type C), two Standard USB ports (Type A), and one AUX port may be located to the left of the center stack, just below the climate controls.

Page 76

74 GETTING TO KNOW YOUR VEHICLE

Center Console USB/AUX Media Hub

1 — Standard USB Type A Ports 2 — Mini-USB Type C Ports 3 — AUX Port

Some USB ports support media and charging. You can use features, such as Apple CarPlay®, Android Auto™, Pandora®, and others while charging your phone.

NOTE: Plugging in a phone or another USB device may cause the connection to a previous device to be lost.

For further information, refer to the Uconnect Owner’s Manual Supplement or visit UconnectPhone.com.

ELECTRICAL POWER OUTLETS

The auxiliary 12 Volt (13 Amp) power outlet can provide power for in-cab accessories designed for use with the standard “cigarette lighter” style plug. The 12 Volt power outlets and 5 Volt (2.5 Amp) USB Port (Charge Only) have a cap attached to the outlet indicating “12V DC”, together with either a key symbol, battery symbol, or USB symbol.

A key symbol indicates that the ignition must be in the ON/RUN or ACC positions for the outlet to provide power. The battery symbol indicates that the outlet is connected to the battery, and can provide power at all times.

CAUTION!

 Do not exceed the maximum power of 160

Watts (13 Amps) at 12 Volts. If the 160 Watts (13 Amps) power rating is exceeded, the fuse protecting the system will need to be replaced.

(Continued)

CAUTION! (Continued)

 Power outlets are designed for accessory

plugs only. Do not insert any other object in the power outlets as this will damage the outlet and blow the fuse. Improper use of the power outlet can cause damage not covered by your New Vehicle Limited Warranty.

An auxiliary power outlet can be found in the tray on top of the center stack. This power outlet only works when the ignition is in the ON/RUN or ACC position.

Power Outlet — Top Of Center Stack

Page 77

GETTING TO KNOW YOUR VEHICLE 75

Power Outlet Fuse Locations

1 — F54 Fuse 20 A Yellow Power Outlet Battery Fed Position

2 — F54 Fuse 20 A Yellow Power Outlet Ignition Fed Position

3 — F48 Fuse 10 A Red Port Power or Rear USB (Charge Only)

When the vehicle is turned off, be sure to unplug any equipment as to not drain the battery of the vehicle. All accessories connected to the outlet(s) should be removed or turned off when the vehicle is not in use to protect the battery against discharge.

WARNING!

To avoid serious injury or death:

 Only devices designed for use in this type of

outlet should be inserted into any 12 Volt outlet.

 Do not touch with wet hands.

 Close the lid when not in use and while

driving the vehicle.

 If this outlet is mishandled, it may cause an

electric shock and failure.

CAUTION!

 Many accessories that can be plugged in

draw power from the vehicle's battery, even when not in use (i.e., cellular phones, etc.). Eventually, if plugged in long enough, the vehicle's battery will discharge sufficiently to degrade battery life and/or prevent the engine from starting.

 Accessories that draw higher power (i.e.,

coolers, vacuum cleaners, lights, etc.), will discharge the battery even more quickly. Only use these intermittently and with greater caution.

(Continued)

CAUTION! (Continued)

 After the use of high power draw accesso-

ries, or long periods of the vehicle not being started (with accessories still plugged in), the vehicle must be driven a sufficient length of time to allow the generator to recharge the vehicle's battery.

POWER INVERTER — IF EQUIPPED

A 115 Volt (400 Watts Maximum) inverter may be located inside the center console towards the right hand side. This inverter can power cellular phones, electronics and other low power devices requiring power up to 400 Watts. Certain high-end video game consoles exceed this power limit, as will most power tools.

Center Console Power Inverter Outlet

Page 78

76 GETTING TO KNOW YOUR VEHICLE

There is also a second 115 Volt (400 Watts Maximum) power inverter located on the rear of the center console. This inverter can power cellular phones, electronics and other low power devices requiring power up to 400 Watts. Certain high-end video game consoles exceed this power limit, as will most power tools.

All power inverters are designed with built-in overload protection. If the power rating of 400 Watts is exceeded, the power inverter shuts down. Once the electrical device has been removed from the outlet the inverter should reset.

Rear Center Console Power Inverter Outlet

NOTE: 400 Watts is the maximum for the inverter, not each outlet. If three outlets are in use, 400 Watts is shared amongst the devices plugged in.

If equipped with a front bench seat, there may be a 115 Volt (400 Watts Maximum) inverter located to the right of the center stack, just below the climate controls. This inverter can power cellular phones, electronics and other low power devices requiring power up to 400 Watts. Certain high-end video game consoles exceed this power limit, as will most power tools.

Center Stack Power Inverter

To turn on the power outlet, simply plug in the device. The outlet turns off when the device is unplugged.

NOTE:

 The Center Stack Power Inverter is only avail-

able on vehicles equipped with a front bench seat.

 The power inverter only turns on if the ignition

is in the ACC or ON/RUN position.

 Due to built-in overload protection, the power

inverter shuts down if the power rating is exceeded.

WARNING!

To avoid serious injury or death:

 Do not insert any objects into the recepta-

cles.

 Do not touch with wet hands.

 Close the lid when not in use.

 If this outlet is mishandled, it may cause an

electric shock and failure.

Page 79

GETTING TO KNOW YOUR VEHICLE 77

WIRELESS C HARGING PAD — IF

QUIPPED

Wireless Charging Pad

Your vehicle may be equipped with a 15W 3A Qi wireless charging pad located inside of the center console. This charging pad is designed to wirelessly charge your Qi enabled mobile phone. Qi is a standard that allows wireless charging of your mobile phone.

Your mobile phone must be designed for Qi wireless charging. If the phone is not equipped with Qi wireless charging functionality, an aftermarket sleeve or a specialized back plate can be purchased from your mobile phone provider or a local electronics retailer. Please see your phone’s owner’s manual for further information.

The wireless charging pad is equipped with an anti-slip mat, an adjustable cradle to hold your mobile phone in place, and an LED indicator light.

NOTE: Using a phone case may interfere with wireless charging.

CAUTION!

The key fob should not be placed on the charging pad or within 15 cm (150 mm) of it. Doing so can cause excessive heat buildup and damage to the fob. Placing the fob in close proximity of the charging pad blocks the fob from being detected by the vehicle and prevents the vehicle from starting.

WINDOWS

POWER WINDOWS

The window controls on the driver's door control all the door windows.

Power Window Switches

The passenger door windows can also be operated by using the single window controls on the passenger door trim panel. The window controls will operate only when the ignition is in the ACC or ON/RUN position.

To open the window part way (manually), push the window switch down briefly and release.

NOTE: The power window switches will remain active for up to 10 minutes after the ignition is placed in the OFF position. Opening either front door will cancel this feature. The time is programmable within Uconnect Settings Ú page 237.

Page 80

78 GETTING TO KNOW YOUR VEHICLE

WARNING!

Never leave children unattended in a vehicle. Do not leave the key fob in or near the vehicle or in a location accessible to children, and do not leave the ignition of a vehicle equipped with Keyless Enter-N-Go in the ACC or ON/ RUN mode. Occupants, particularly unattended children, can become entrapped by the windows while operating the power window switches. Such entrapment may result in serious injury or death.

AUTOMATIC WINDOW FEATURES

Auto-Down Feature

The driver and front passenger door power window switches have an Auto-Down feature. Push the window switch down for a short period of time, then release, and the window will go down automatically.

To stop the window from going all the way down during the Auto-Down operation, pull up or push down on the switch briefly.

Auto-Up Feature With Anti-Pinch Protection

Lift the window switch up for a short period of time and release; the window will go up automatically.

To stop the window from going all the way up during the Auto-Up operation, push down on the switch briefly.

To close the window part way, lift the window switch briefly and release it when you want the window to stop.

If the window runs into any obstacle during auto-closure, it will reverse direction and then go back down. Remove the obstacle and use the window switch again to close the window.

NOTE: Any impact due to rough road conditions may trigger the auto-reverse function unexpectedly during auto-closure. If this happens, pull the switch lightly and hold to close the window manually.

WARNING!

There is no anti-pinch protection when the window is almost closed. To avoid personal injury be sure to clear your arms, hands, fingers and all objects from the window path before closing.

RESET AUTO-UP

Should the Auto-Up feature stop working, the window probably needs to be reset. To reset Auto-Up:

1. Pull the window switch up to close the window completely and continue to hold the switch up for an additional two seconds after the window is closed.

2. Push the window switch down firmly to open the window completely and continue to hold the switch down for an additional two seconds after the window is fully open.

Page 81

GETTING TO KNOW YOUR VEHICLE 79

WINDOW LOCKOUT SWITCH

The window lockout switch on the driver's door trim panel allows you to disable the window controls on the rear passenger doors. To disable the window controls, push and release the window lockout button (the indicator light on the button will turn on). To enable the window controls, push and release the window lockout button again (the indicator light on the button will turn off).

Window Lockout Switch

POWER SLIDING REAR WINDOW — IF

QUIPPED

The switch for the power sliding rear window is located on the overhead console. Push the switch rearward to open the glass. Pull the switch forward to close the glass.

Rear Window Switch

MANUAL SLIDING REAR WINDOW — I F

QUIPPED

A locking device in the center of the window helps to prevent entry from the rear of the vehicle. Squeeze the lock to release the window.

Manual Rear Window Lock

Page 82

80 GETTING TO KNOW YOUR VEHICLE

WIND BUFFETING

Wind buffeting can be described as the perception of pressure on the ears or a helicopter-type sound in the ears. Your vehicle may exhibit wind buffeting with the windows down, or the sunroof (if equipped) in certain open or partially open positions. This is a normal occurrence and can be minimized. If the buffeting occurs with the rear windows open, open the front and rear windows together to minimize the buffeting. If the buffeting occurs with the sunroof open, adjust the sunroof opening to minimize the buffeting or open any window.

POWER SUNROOF — IF EQUIPPED

SINGLE PANE POWER SUNROOF — IF

QUIPPED

The power sunroof switches are located on the overhead console between the courtesy/ reading lights.

Power Sunroof Switches

1 — Opening/Closing Sunroof 2 — Venting Sunroof

WARNING!

 Never leave children unattended in a

vehicle, or with access to an unlocked vehicle. Never leave the key fob in or near the vehicle, or in a location accessible to children. Do not leave the ignition of a vehicle equipped with Keyless Enter-N-Go in the ACC or ON/RUN mode. Occupants, particularly unattended children, can become entrapped by the power sunroof while operating the power sunroof switch. Such entrapment may result in serious injury or death.

 In a collision, there is a greater risk of being

thrown from a vehicle with an open sunroof. You could also be seriously injured or killed. Always fasten your seat belt properly and make sure all passengers are also properly secured.

 Do not allow small children to operate the

sunroof. Never allow your fingers, other body parts, or any object, to project through the sunroof opening. Injury may result.

Page 83

GETTING TO KNOW YOUR VEHICLE 81

Opening And Closing The Sunroof

Express Open/Close

Push the switch rearward and release it within one-half second and the sunroof will open automatically from any position. The sunroof will open fully and stop automatically.

Push the switch forward and release it within one-half second and the sunroof will close automatically from any position. The sunroof will close fully and stop automatically.

During Express Open or Express Close operation, any other movement of the sunroof switch will stop the sunroof.

Manual Open/Close

To open the sunroof, push and hold the switch rearward to full open.

To close the sunroof, push and hold the switch in the forward position.

Any release of the switch during open or close operation will stop the sunroof movement. The sunroof will remain in a partially opened position until the switch is operated and held again.

NOTE: If the sunshade is in the closed position when Express or Manual Open operation is initiated the sunshade will automatically open to the half open position prior to the sunroof opening.

Pinch Protect Feature

This feature will detect an obstruction in the opening of the sunroof during Express Close operation. If an obstruction in the path of the sunroof is detected, the sunroof will automatically retract. Remove the obstruction if this occurs.

NOTE: If three consecutive sunroof close attempts result in Pinch Protect reversals, Pinch Protect will disable and the sunroof must be closed in Manual Mode.

Venting Sunroof — Express

Push and release the Vent button within one half second and the sunroof will open to the vent position. This is called “Express Vent”, and it will occur regardless of sunroof position. During Express Vent operation, any other actuation of the switch will stop the sunroof.

Sunshade Operation

The sunshade can be opened manually. However, the sunshade will open automatically as the sunroof opens.

NOTE: The sunshade cannot be closed if the sunroof is open.

Ignition Off Operation

The power sunroof switch will remain active for up to approximately 10 minutes after the ignition switch is placed in the OFF position. Opening either front door will cancel this feature.

NOTE: Ignition Off time is programmable through the Uconnect system Ú page 237.

Sunroof Maintenance

Use only a non-abrasive cleaner and a soft cloth to clean the glass panel. Periodically check for and clear out any debris that may have collected in the tracks.

Page 84

82 GETTING TO KNOW YOUR VEHICLE

DUAL PANE POWER SUNROOF — IF

QUIPPED

The power sunroof switches are located on the overhead console between the courtesy/ reading lights.

Power Sunroof Switches

1 — Opening/Closing Sunroof 2 — Venting Sunroof 3 — Opening/Closing Sunshade

WARNING!

 Never leave children unattended in a

 In a collision, there is a greater risk of being

thrown from a vehicle with an open sunroof. You could also be seriously injured or killed. Always fasten your seat belt properly and make sure all passengers are also properly secured.

 Do not allow small children to operate the

sunroof. Never allow your fingers, other body parts, or any object, to project through the sunroof opening. Injury may result.

Opening And Closing The Sunroof

The sunroof has two programmed automatic stops for the sunroof open position; a comfort stop position and a full open position. The comfort stop position has been optimized to minimize wind buffeting.

Express Open/Close

Push the switch rearward and release it within one-half second and the sunroof will open automatically from any position. The sunroof will open fully and stop automatically.

Push the switch forward and release it within one-half second and the sunroof will close automatically from any position. The sunroof will close fully and stop automatically.

During Express Open or Express Close operation, any other movement of the sunroof switch will stop the sunroof.

Page 85

GETTING TO KNOW YOUR VEHICLE 83

Manual Open/Close

To open the sunroof, push and hold the switch rearward to full open.

To close the sunroof, push and hold the switch in the forward position.

Any release of the switch during open or close operation will stop the sunroof movement. The sunroof will remain in a partially opened position until the switch is operated and held again.

NOTE: If the sunshade is in the closed position when Express or Manual Open operation is initiated the sunshade will automatically open to the half open position prior to the sunroof opening.

Opening And Closing The Power Sunshade

The sunshade has two programmed positions: half open and full open positions. When operating the sunshade from the closed position, the sunshade will always stop at the half open position regardless of express or manual open operation. The switch must be actuated again to continue on to full open position.

If the sunroof is open or vented, the sunshade cannot be closed beyond the half open position. Pushing the sunshade close switch when the sunroof is open/vented and the sunshade is at half open position will first automatically close the sunroof prior to the sunshade closing.

Express Open/Close

Push the sunshade switch rearward and release it within one-half second, the sunshade will open to the half open position and stop automatically. Push and release the switch again from the half open position and the sunshade will open to the full open position and stop automatically.

Push the sunshade switch forward and release it within one-half second and the sunshade will close automatically.

During Express Open or Express Close operation, any other actuation of the sunroof switches will stop the sunshade in a partially open position.

Manual Open/Close

Push and hold the sunshade switch rearward, the sunshade will open to the half open position and stop automatically. Push and hold the sunshade switch again and the sunshade will open to the full open position.

Push and hold the switch forward and the sunshade will close and stop at full closed position.

Releasing the switch while the sunshade is in motion will stop the sunshade in a partially open position.

Pinch Protect Feature

NOTE: If three consecutive sunroof close attempts result in Pinch Protect reversals, Pinch Protect will disable and the sunroof must be closed in Manual Mode.

Page 86

84 GETTING TO KNOW YOUR VEHICLE

Venting Sunroof — Express

Push and release the Vent button within one half second and the sunroof will open to the vent position. This is called “Express Vent” and it will occur regardless of sunroof position. During Express Vent operation, any movement of the switch will stop the sunroof.

NOTE: If the sunshade was not already open, it will automatically open prior to the roof opening to the vent position.

Ignition Off Operation

The power sunroof switch will remain active for up to approximately 10 minutes after the ignition switch is placed in the OFF position. Opening either front door will cancel this feature.

NOTE: Ignition Off time is programmable through the Uconnect system Ú page 237.

Sunroof Maintenance

Use only a non-abrasive cleaner and a soft cloth to clean the glass panel. Periodically check for and clear out any debris that may have collected in the tracks.

HOOD

TO OPEN THE HOOD

To open the hood, two latches must be released.

1. Pull the hood release lever located below the steering wheel at the base of the instrument panel.

Hood Release Lever Location

2. Reach into the opening beneath the center of the hood and push the safety latch lever to the left to release it, before raising the hood.

Safety Latch Location

Page 87

GETTING TO KNOW YOUR VEHICLE 85

TO CLOSE THE HOOD

Hoods equipped with gas props are closed from the point where the props no longer hold the hood open.

WARNING!

Be sure the hood is fully latched before driving your vehicle. If the hood is not fully latched, it could open when the vehicle is in motion and block your vision. Failure to follow this warning could result in serious injury or death.

CAUTION!

To prevent possible damage, do not slam the hood to close it. Use a firm downward push at the front center of the hood to ensure that both latches engage.

TAILGATE

OPENING

The tailgate may be opened by pushing the tailgate release pad located on the tailgate door.

The tailgate damper strut will lower the tailgate to the open position (if equipped).

Electronic Tailgate Release — If Equipped

The key fob may be equipped with an electronic release feature for the tailgate, allowing hands-free tailgate

opening. To activate, push and release the Tailgate Release button on the key fob twice within five seconds. The tailgate door will unlatch, and slowly lower into the open position.

If equipped, a button on the center overhead console inside the vehicle can be used to release the tailgate. An indicator light may also signal when the tailgate is open.

For the tailgate to lower, the vehicle must be stationary and in PARK or NEUTRAL.

NOTE: The optional Tri-Fold Tonneau Cover Ú page 97 may prevent electronic tailgate release. The Tonneau Cover must be removed or folded up before releasing the tailgate.

CLOSING

To close the tailgate, push it upward until both sides are securely latched.

LOCKING TAILGATE

The tailgate can be locked using the key fob lock button.

MULTIFUNCTION TAILGATE — IF

QUIPPED

The 60/40 multifunction tailgate has two swing doors to allow for closer access to the pickup box with the doors open.

Opening

The tailgate must be latched closed to open the swing doors. Push the paddle down, then pull the release handle beneath the tailgate lowering handle. This opens the 60 split door.

Page 88

86 GETTING TO KNOW YOUR VEHICLE

60 Split Door Release Handle

Once the 60 split swing door is opened, pull the release handle on the inboard side of the 40 split door to open.

40 Split Door Release Handle

Closing

Always close the 40 split door first, then close the 60 split door. The swing doors must be securely latched before the tailgate can be lowered.

NOTE:

 When the swing doors are open, the

maximum load placed on a door cannot exceed 180 lbs (82 kg).

 Pull back on the swing doors firmly after

closing to ensure they are securely latched.

WARNING!

To prevent serious injury or death:

 Always keep hands away from the hinge

sides of the swing doors and where the doors meet when opening and closing the doors. Your hand or someone else’s hand could be pinched.

 Never operate the vehicle with the swing

doors open.

 Never hang from or sit on the swing doors.

CAUTION!

 Always check both swing doors are latched

before starting vehicle.

 Vehicle damage may occur if doors are not

securely latched.

TAILGATE REMOVAL

To remove the tailgate, follow the instructions below:

1. Open the tailgate to a 45° angle.

2. Lift up on the right side of the tailgate, lifting it off of the pivot.

Lift Right Side Off Of Pivot

Page 89

GETTING TO KNOW YOUR VEHICLE 87

3. Without latching, rotate the tailgate to nearly closed. Then, while providing support to the tailgate, slide it slowly to the right, removing the tailgate from the left pivot.

NOTE: Rest the tailgate on the bumper so that the entire tailgate is secure and supported.

WARNING!

For vehicles equipped with a multifunction tailgate, the tailgate weighs 115 lbs (52 kg) and should be removed by at least two people. Injury to the customer or damage to the tailgate may occur if one person tries to remove the multifunction tailgate.

Slide Tailgate To The Right

4. Let the tailgate rest on the support cables while having the tailgate naturally slide forward on the bumper.

Connector Bracket Location

Tailgate Only Supported By Cables

5. Remove the connector bracket from the sill by pushing inward in the locking tab.

Locking Tab

Page 90

88 GETTING TO KNOW YOUR VEHICLE

6. Disconnect the wiring harness by pushing on the two release tabs, ensuring the connector bracket does not fall into the sill.

Connected Wiring Harness

1 — First Release Tab 2 — Second Release Tab

Disconnected Body Side Harness

7. Connect the body side plug (provided in the glove compartment) to the body side wiring harness and insert the bracket back into the sill.

Body Side Plug (One Piece)

8. Connect the tailgate plugs (provided in the glove compartment) to the tailgate wiring harness to ensure that the terminals do not corrode.

Tailgate Plugs (Two Pieces)

1 — Large Plug 2 — Small Plug

9. Tape the tailgate harness and bracket against the forward-facing surface of the tailgate. This will prevent damaging the connector and bracket when storing or reinstalling the tailgate.

Page 91

GETTING TO KNOW YOUR VEHICLE 89

10. Raise the tailgate slightly, and remove the support cables by releasing the lock tang from the pivot.

NOTE: Make sure tailgate is supported by you and/or a second person when removing support cables.

Locking Tang

11. Remove the tailgate from the vehicle.

NOTE:

 Do not carry the tailgate loose in the truck

pickup box.

 If the tailgate is closed with the wire harness

disconnected, the tailgate can only be opened by removing the inside panel and unlatching the locking mechanism manually.

WARNING!

To avoid inhaling carbon monoxide, which is deadly, the exhaust system on vehicles equipped with “Cap or Slide-In Campers” should extend beyond the overhanging camper compartment and be free of leaks.

BED STEP — IF EQUIPPED

Your vehicle may be equipped with an extendable bed step on the driver’s side of the tailgate to provide easier entry and exit into the truck bed.

Bed Step Location

Bed Step Components

1 — Bed Step 2 — Foot Tab

To extend the bed step, place your foot on the protruding foot tab located on the left edge of the bed step, and push rearward. A small amount of force will release the spring load, and extend the bed step out and away from the tailgate.

NOTE: Once the spring load is overcome, the bed step will extend out quickly, so be sure to stand in a position that will avoid coming into contact with the step as it extends.

Page 92

90 GETTING TO KNOW YOUR VEHICLE

Bed Step (Extended)

To stow the bed step back under the tailgate, push the bed step forward with your foot until the bed step is retracted by the spring load.

WARNING!

Do not attempt to stow the bed step with your hands. The low clearance space between the bed step and the rear bumper as the bed step returns to the stowed position could result in injury to your hands or fingers.

PICKUP BOX

The pickup box has many features designed for utility and convenience.

Pick Up Box Features

1 — Upper Load Floor Indents 2 — Bulk Head Dividers 3 — Cleats

NOTE: If you are installing a Toolbox, Ladder Rack or Headache Rack at the front of the Pickup Box, you must use Mopar Box Reinforcement Brackets that are available from an authorized dealer.

You can carry wide building materials (sheets of plywood, etc.) by building a raised load floor. Place lumber across the box in the indentations provided above the wheel housings and in the bulkhead dividers to form the floor.

WARNING!

 The pickup box is intended for load carrying

purposes only, not for passengers, who should sit in seats and use seat belts.

 Care should always be exercised when

operating a vehicle with unrestrained cargo. Vehicle speeds may need to be reduced. Severe turns or rough roads may cause shifting or bouncing of the cargo that may result in vehicle damage. If wide building materials are to be frequently carried, the installation of a support is recommended. This will restrain the cargo and transfer the load to the pickup box floor.

(Continued)

Page 93

GETTING TO KNOW YOUR VEHICLE 91

WARNING! (Continued)

 If you wish to carry more than 600 lbs

(272 kg) of material suspended above the wheelhouse, supports must be installed to transfer the weight of the load to the pickup box floor or vehicle damage may result. The use of proper supports will permit loading up to the rated payload.

 Unrestrained cargo may be thrown forward

in an accident causing serious or fatal injury.

There are stampings in the sheet metal on the inner side bulkheads of the box in front of and behind both wheel housings. Place wooden boards across the box from side to side to create separate load compartments in the pickup box.

There are four tie-down cleats bolted to the lower sides of the pickup box that can sustain loads up to 1,000 lbs (450 kg) total.

BED RAIL TIE-DOWN SYSTEM — IF

QUIPPED

CAUTION!

The maximum load per cleat should not exceed 250 lbs (113 kg), or 500 lbs (227 kg) total per rail, and the angle of the load on each cleat should not exceed 45 degrees above horizontal, or damage to the cleat or cleat rail may occur.

There are two adjustable cleats on each side of the bed that can be used to assist in securing cargo.

Adjustable Cleats

Each cleat must be located and tightened down in one of the detents, along either rail, in order to keep cargo properly secure.

To move the cleat to any position on the rail, turn the nut counterclockwise, approximately three turns. Then pull out on the cleat and slide it to the detent nearest the desired location. Make sure the cleat is seated in the detent and tighten the nut.

Adjustable Cleat Assembly

1 — Utility Rail Detent 2 — Cleat Retainer Nut 3 — Utility Rail Cleat

Page 94

92 GETTING TO KNOW YOUR VEHICLE

Cleat Removal (Standard Box Rail)

To remove the cleats from the utility rail, slide the cleat forward to access the cut out at the end of the box rail, then remove the cleat.

Slide Cleat Forward To Remove

Cleat Removal (With Tonneau Cover)

To remove the cleats from the utility rail, remove the end cap screw located in the center of the end cap, using a #T30 Torx head driver. Remove the end cap and slide the cleat off the end of the rail.

End Cap Screw Location With Tonneau Cover

Cleat Removal (Without Tonneau Cover)

Remove the end cap by pushing upward on the release button located beneath the end cap while pulling the cap away from the rail. The cleat can now be removed by sliding it off the end of the rail.

End Cap Release Button Without Tonneau Cover

Pull End Cap Away From Rail

RAMBOX — IF EQUIPPED

The RamBox system is an integrated pickup box storage and cargo management system consisting of three features:

 Cargo storage bins

 Cargo divider

 Bed rail tie-down system Ú page 91

NOTE: Bed rail tie-down system is also available for vehicles not equipped with a RamBox.

Page 95

GETTING TO KNOW YOUR VEHICLE 93

LOCKING AND UNLOCKING RAM BOX

Push and release the lock or unlock button on the key fob to lock and unlock all doors, the tailgate and the RamBox Ú page 17. To unlatch the storage bin manually, insert the emergency key into the keyhole and turn clockwise. Always return the key to the upright (vertical) position before removing it from the keyhole.

CAUTION!

 Ensure cargo bin lids are closed and

latched before moving or driving vehicle.

 Loads applied to the top of the bin lid

should be minimized to prevent damage to the lid and latching/hinging mechanisms.

 Damage to the RamBox bin may occur due

to heavy/sharp objects placed in bin that shift due to vehicle motion. In order to minimize potential for damage, secure all cargo to prevent movement and protect inside surfaces of bin from heavy/sharp objects with appropriate padding.

RAMBOX CARGO STORAGE BINS

Cargo storage bins are located on both sides of the pickup box. The cargo storage bins provide watertight, lockable, illuminated storage for up to 150 lbs (68 kg) of evenly distributed cargo.

RamBox Cargo Storage Bins

CAUTION!

Failure to follow the following items could cause damage to the vehicle:

 Assure that all cargo inside the storage bins

is properly secured.

 Do not exceed cargo weight rating of 150 lbs

(68 kg) per bin.

To open a storage bin with the RamBox unlocked, push and release the button located on the lid. The RamBox lid will open upward to allow hand access. Lift the lid to fully open.

NOTE: RamBox will not open when the button is pushed if the RamBox is locked.

RamBox Button And Keyhole Lock

1 — Keyhole Lock 2 — Button

Page 96

94 GETTING TO KNOW YOUR VEHICLE

CAUTION!

Leaving the lid open for extended periods of time could cause the vehicle battery to discharge. If the lid is required to stay open for extended periods of time, it is recommended that the bin lights be turned off manually using the on/off switch.

The interior of the RamBox will automatically illuminate when the lid is opened. The timing can be adjusted within Uconnect Settings Ú page 237.

Cargo bins feature two removable drain plugs (to allow water to drain from bins). To remove plug, pull up on the edge. To install, push plug downward into drain hole.

RamBox Drain Plug Removal

NOTE: Provisions are provided in the bins for cargo dividers. These accessories (in addition to other RamBox accessories) are available from Mopar.

If equipped, a 115 Volt (400 Watts Maximum) inverter may be located inside the RamBox of your vehicle. The inverter can be turned on by the Instrument Panel Power Inverter switch located to the left of the steering wheel. The RamBox inverter can power cellular phones, electronics and other low power devices requiring power up to 400 Watts. Certain high-end video game consoles exceed this power limit, as will most power tools.

RamBox Power Inverter

The Instrument Panel Power Inverter switch is only found on vehicles equipped with a RamBox. The switch only controls on/off operation of the power outlet in the RamBox; it does not control on/off operation of the power outlets located inside the cabin of the vehicle.

Instrument Panel Power Inverter Switch

RAMBOX SAFETY WARNING

Carefully follow these warnings to help prevent personal injury or damage to your vehicle:

WARNING!

 Always close the storage bin covers when

your vehicle is unattended.

(Continued)

Page 97

GETTING TO KNOW YOUR VEHICLE 95

WARNING! (Continued)

 Do not allow children to have access to the

storage bins. Once in the storage bin, young children may not be able to escape. If trapped in the storage bin, children can die from suffocation or heat stroke.

 In an accident, serious injury could result if

the storage bin covers are not properly latched.

 Do not drive the vehicle with the storage bin

covers open.

 Keep the storage bin covers closed and

latched while the vehicle is in motion.

 Do not use a storage bin latch as a

tie-down.

RamBox Emergency Release Lever

As a security measure, an Emergency Release Lever is built into the storage bin cover latching mechanism.

In the event of an individual being locked inside the storage bin, the storage bin cover can be opened from inside of the bin by pulling on the glow-in-the-dark lever attached to the storage bin cover latching mechanism.

Emergency Release Lever

BED DIVIDER — IF EQUIPPED

The bed divider has two functional positions:

 Divider Position

 Storage Position

Divider Position

The divider position is intended for managing your cargo and assisting in keeping cargo from moving around the bed. There are 11 divider slots along the bed inner panels which allow for various positions to assist in managing your cargo.

To install the bed divider into a divider position, perform the following:

1. Make sure the center handle is unlocked using the vehicle key and rotate the center handle vertically to release the divider side gates.

Center Handle And Lock

1 — Center Handle Lock 2 — Handle 3 — Unlocked Position 4 — Locked Position

Page 98

96 GETTING TO KNOW YOUR VEHICLE

2. With the side gates open, position the divider so the outboard ends align with the intended slots in the sides of the bed.

Aligning Gate To Slots

3. Rotate the side gates closed so that the outboard ends are secured into the intended slots of the bed.

4. Rotate the center handle horizontally to secure the side gates in the closed position.

Side Gates Closed

5. Lock the center handle to secure the panel into place.

Storage Position

The storage position for the bed divider is at the front of the truck bed which maximizes the bed cargo area when not in use.

To install the bed divider into the storage position, perform the same steps as you would for the divider position, except position the divider fully forward in the bed against the front panel.

Storage Position

The outboard ends should be positioned in front of the cargo tie-down loops.

Cargo Tie-Down Loop

Page 99

GETTING TO KNOW YOUR VEHICLE 97

SLIDE-IN CAMPERS

CAMPER APPLICATIONS

Certain truck models are not recommended for slide-in campers. To determine if your vehicle is excluded, please refer to the “Consumer Information Truck-Camper Loading” document available online at ramtrucks.com. For safety reasons, follow all instructions in this document.

WARNING!

NOTE: When a cap or pickup camper is installed on a vehicle, an alternate Center High Mounted Stop Light (CHMSL) must be provided.

TRI-FOLD TONNEAU COVER — IF EQUIPPED

The Tri-Fold Tonneau Cover can be installed on the truck bed to protect your gear and cargo.

TONNEAU COVER COMPONENTS

Folded Tonneau Components

1 – Stowage Strap 2 – Tonneau Bumper Folded

Tonneau Cover Latch Components

1 — Handle 2 — Slide Locking Lever 3 — Locating Bumper 4 — Truck Flange Bead 5 — Latch Bumper 6 — J Hook

Page 100

98 GETTING TO KNOW YOUR VEHICLE

TRI-FOLD TONNEAU COVER FOLDING

OR DRIVING OR REMOVAL

To remove the Tonneau Cover use the following steps:

1. Open the tailgate to access the rear pair of Tonneau Cover latches located on the underside of the Cover.

Position One (Front Latches Latched And Stowage

Straps Secured)

Position Two (Front And Rear Latches Latched)

1 — Panel 1 2 — Panel 2 3 — Panel 3

Slide Locking Lever Inward

2. Slide the locking lever toward the inside of the truck bed to release the J Hook and pull the handle downward into the released position.

Location Of Rear Latches

Unlatching Latch
