XL-400 High Power 4/3/2-Channel Bridgeable Amplifier
Owner’s Manual
Please read before using this equipment.
12-2018.fm Page 2 Friday, May 12, 2000 12:46 PM
ˆ
Features .................................................................................................................................. 3
Preparation ............................................................................................................................. 4
Supplied Hardware ............................................................................................................ 4
Choosing a Mounting Location .................................................................................. 4
Preparing the Mounting Area ..................................................................................... 5
Routing Cables and Wires ......................................................................................... 5
Installation Order ........................................................... ..................................... ............... 5
Before You Make the Connections .................................................................................... 5
Connecting Ground and Switched/Primary Power ............................................................ 6
Connecting Inputs ................................................ .................................................................. 8
Low-Level Inputs ............................................................................................................... 8
High-Level (Speaker Wire) Inputs ..................................................................................... 9
Four Speaker Outputs ............................................................................................. 10
Two Speaker Outputs .............................................................................................. 11
Connecting Speakers ...................................................................................................... 12
Preparing the Speaker Wires ................................................................................... 12
Connecting Four Speakers ...................................................................................... 13
Connecting Two Speakers (Unbridged Connection) ................................................ 13
Connecting Two Speakers (Bridged Connection) .................................................... 14
Connecting Two Speakers and One Subwoofer (Unbridged Connection) ............... 14
Connecting Two Unbridged Speakers and One Bridged Subwoofer ....................... 15
Completing the Installation ................................................................................................. 16
Testing the Connections .................................................................................................. 16
Mounting the Amplifier .................................................................................................... 16
Operation .............................................................................................................................. 18
Turning On the Amplifier ................................................................................................. 18
Adjusting the Audio Level ................................................................................................ 18
Adjusting Frequency Crossover ...................................................................................... 19
Troubleshooting ................................................................................................................... 20
Care ................................................................................................................................ 21
Replacing a Fuse ..................................................... .. ... .................................................. 21
Replacing the SFE-Type Fuse ................................................................................. 21
Replacing the Blade-Type Fuses ............................................................................. 21
Specifications ....................................................................................................................... 23
©
2000 Tandy Corporation.
RadioShack and RadioShack.com are trademarks used by Tandy Corporation.
2
All Rights Reserved.
12-2018.fm Page 3 Friday, May 12, 2000 12:46 PM
ˆ
Features
Your RadioShack High Power 4/3/2-Chan­nel Bridgeable Amplifier produces a total of 400 watts to give added punch and power to your vehicle’s existing auto sound system.
The amplifier produces up to 200 watts per channel (if bridged) of clean, powerful sound at all audio frequencies with minimum distor­tion. You can connect your auto sound sys­tem’s low-level or speaker-level outputs to this amplifier.
Its features include:
14K Gold-Plated Noise-Isolated Low-Lev­el Input Jacks
(preamplifier) signal inputs to match your auto sound system’s output for the best high­fidelity performance.
14K Gold-Plated Speaker Terminals
signed for low impedance, high conductivity, and minimum corrosion, to provide the high­est signal transfer and lowest sound distor­tion.
Input Level Controls
level of the audio signals that enter the am­plifier.
Automatic Power Switching
matically turn the amplifier on or off when you turn your auto sound system on or off (depending on how you hook up the amplifi­er).
Bridging Capability
amplifier’s four 100-watt channels so you can use the amplifier with only two channels that produce a total of 200 watts from each chan­nel.
Mute Turn On Circuit
thump you hear when you turn on some am­plifiers.
— let you connect low-level
— de-
— let you adjust the
— can auto-
— lets you combine the
— eliminates the
Power Indicator
supplied to the amplifier.
Protection Indicator
shuts itself down.
Crossover Frequency Circuit
adjust the crossover frequency from 45–400 Hz. This lets you set up the amplifier so you can connect a subwoofer.
Short Circuit Protection
plifier’s sound if any output channel shorts, alerting you to turn off the auto sound sys­tem.
Auto-Off
plifier to protect the amplifier from overheat­ing or input overloads. The amplifier restarts automatically when it cools or the problem is corrected.
— temporarily shuts down the am-
— lights when power is
— lights if the amplifier
— lets you
— distorts the am-
THE FCC WANTS YOU TO KNOW
Your amplifier might cause TV or radio inter­ference even when it is operating properly. To determine whether your amplifier is caus­ing the interference, turn off your amplifier. If the interference goes away, your amplifier is causing it. Try to eliminate the interference by:
• moving your amplifier away from the receiver
• contacting your local RadioShack store for help
If you cannot eliminate the interference, the FCC requires that you stop using your ampli­fier.
Features
3
12-2018.fm Page 4 Friday, May 12, 2000 12:46 PM
ˆ
Preparation
SUPPLIED HARDWARE
Your amplifier comes with the following items. Be sure you locate everything shown before you store or dispose of the packing materials.
Power Wire (Red) (1)
Ground Wire (Black) (1)
Remote Wire (Blue/White) (1)
4-Pin Connector with Wire (2)
Sheet Metal Screws (4)
BEFORE YOU BEGIN THE INSTALLATION
Before you install your amplifier, read all the instructions in this owner’s manual. You should be able to answer all of the se ques­tions about your vehicle’s electrical and auto sound systems.
• Does my vehicle have an auto sound system, such as a car stereo or CD player, already installed? (You must have an existing auto sound system to use this amplifier.)
• How do I connect a wire to the fuse box?
• Which of the auto sound system’s wires is the power wire?
• Which of the auto sound system’s termi­nals are low-level outputs and which are high-level (speaker) outputs?
Flat Washers (4)
Lock Washers (4)
Also, be aware that installation in your vehi­cle might require cutting or modifying your vehicle.
Twist-On Terminal Connectors (9)
Choosing a Mounting Location
A good location for mounting the amplifier is in your vehicle’s trunk. Wherever you decide to mount it, choose a mounting location that:
• Does not interfere with the vehicle’s operation
• Lets you drill mounting holes without damaging other vehicle component s
• Allows enough space around the cooling fins for proper airflow and cooling
• Lets you easily see the amplifier’s POWER and PROTECTION indicators
4
Preparation
12-2018.fm Page 5 Friday, May 12, 2000 12:46 PM
Warning:
is on. Do not touch the amplifier or place flammable objects near it.
The amplifier gets very hot while it
Preparing the Mounting Area
Before you mount the amplifier, make sure you have these materials.
• an adapter harness
• additional wire
• shielded audio cables
• 16- or 18-gauge marked or color-coded wires
Then confirm that the amplifier fits in your ve­hicle’s available mounting area. This amp lifi­er requires a 5 wide by 171/2-inch deep (13.9 × 34.3 × 43.1 cm) mounting area with adequate ventilation space.
1
/2-inch high by 131/2-inch
Routing Cables and Wires
Avoid routing the connection cables and any speaker wires near moving parts or sharp edges. You can usually route wires and ca­bles along the wiring channel beneath the vehicle’s door facings by carefully removing the molding that holds the carpet in place. Af­ter routing the cables and wires, replace the molding.
INSTALLATION ORDER
For trouble-free installation, simply follow the sections in this owner’s manual in order. First make all the connections by temporarily con­necting the amplifier to:
1
Ground and power
Then test the connections. When you verify that everything works as expected, discon­nect the amplifier, mount it in your vehicle, and reconnect it.
Caution:
in the order shown, damage to the amplifier and your auto sound system is possible if any wire connections are made incorrectly.
Note:
you plan to connect with the name of the ter­minal you will connect it to.
If you do not make the connections
For easier installation, mark each wire
BEFORE YOU MAKE THE CONNECTIONS
The supplied connection cables include all the lead wires you need to connect the am­plifier to ground, power, and your existing auto sound system.
Important:
• Do not cut these wires. If you cut any wire, you cannot obtain a refund or exchange on this product. However,
will
RadioShack vice if you cut a wire and find the prod­uct is defective.
• If the connectors on your vehicle’s auto sound system are not compatible with the amplifier’s connectors, you might need an adapter harness to complete the connections. RadioShack stores sell adapter harnesses for most vehicles.
You might need additional wire, depending on your individual auto sound system, to complete the connections. Your local Ra­dioShack store carries a full line of wire and wire management accessories.
provide warranty ser-
2
Your auto sound system’s outputs
3
Your speakers
Preparation
5
12-2018.fm Page 6 Friday, May 12, 2000 12:46 PM
Cautions:
100 watts per channel if you connect your auto sound system to two pairs of
• For added safety and to protect your amplifier and auto sound system, dis­connect the cable from your vehicle’s
negative (
) battery terminal before you
begin.
• Be sure your speakers can handle as much as 400 watts of power (200 watts per channel if you connect your auto sound system to one pair of speakers
speakers or one pair of speakers and a subwoofer). Each speaker must have an impedance of at least 4 ohms. Y our local RadioShack store carries a full line of speakers.
To make it easier to gauge wire length and connect the amplifier, temporarily place the amplifier as close as possible to the selected mounting location.
and bridge the amplifier’s outputs, or
CONNECTING GROUND AND SWITCHED/PRIMARY POWER
Fuse
Red
Black
Holder
Blue/White
Chassis Ground
Vehicle’s Battery
Auto Sound System
Follow these steps to connect the amplifier to ground, switched power, and primary power.
1. If you have not done so already, discon­nect the cable from your vehicle’s nega­tive (–) battery terminal.
2. Use a screwdriver to connect the spade end of the supplied black ground wire to
GND
the amplifier’s
(ground) terminal.
3. Connect the black ground wire’s other end to a chassis ground, such as a metal bolt attached to a metal part of the vehicle’s frame. Be sure the bolt is not
6
Preparation
Switched Power Lead
insulated from the chassis by a plastic part.
4. Use a screwdriver to connect the spade end of the supplied blue/white wire to
REM
the amplifier’s
(remote power) ter-
minal.
If your auto sound system has a
5.
switched power lead
, connect the blue/ white wire’s other end to your auto sound system’s switched power lead using one of the supplied twist-on termi­nal connectors.
12-2018.fm Page 7 Friday, May 12, 2000 12:46 PM
This connection turns on the amplifier
when you turn on the auto sound sys­tem, and turns off the amplifier when you turn off the auto sound system. This prevents your vehicle’s battery from being drained if you leave your amplifier on when you turn off your auto sound system.
If your auto sound system does not have
a switched power lead
, connect the blue/white wire’s other end to a point in your vehicle’s fuse block that has power only when you turn on the ignition or turn the key to ACC.
This connection turns on the amplifier
when you turn on the ignition or turn the key to ACC, and turns off the amplifier when you turn off the ignition. This pre­vents your vehicle’s battery from being drained if you leave your amplifier on when you turn off the ignition.
6. Use a screwdriver to connect the spade end of the supplied red power cable (with in-line fuse holder) to the ampli-
+ 12V
fier’s
terminal.
7. Connect the other end of the red power cable to your vehicle’s positive (+) bat­tery terminal. Then tighten the terminal.
Caution:
Due to the amplifier’s high cur­rent requirement, you must connect the red power cable’s fused end directly to the vehicle’s positive (+) battery terminal or damage to your vehicle’s wiring could result.
Do not reconnect your vehicle’s negative (–) battery cable yet.
Preparation
7
12-2018.fm Page 8 Friday, May 12, 2000 12:46 PM
ˆ
Connecting Inputs
LOW-LEVEL INPUTS
You can connect your auto sound system’s low-level line out jacks to the amplifier’s low­level line in jacks.
If your auto sound system does not have low-level line out jacks, see “High-Level
If your auto sound system has four separate line out jacks
2. to the amplifier.
(Speaker Wire) Inputs” on Page 9 to connect your amplifier.
Note:
dio cables (not supplied) available at your lo­cal RadioShack store.
1. Temporarily place the amplifier as close
CH 3
CH 4
For the best results, use shielded au-
as possible to the selected mounting location.
, connect the auto sound system
CH 2
CH 1
Right Rear
Auto Sound System
Left Rear
8
Connecting Inputs
Right Front
Left Front
12-2018.fm Page 9 Friday, May 12, 2000 12:46 PM
If your auto sound system has two line out jacks (left and right)
, connect the auto sound
system to the amplifier.
CH 3
CH 4
Left
Auto Sound System
Note:
For the best results, use shielded audio Y-adapters (not supplied) available at your local
CH 2
CH 1
Right
RadioShack store.
HIGH-LEVEL (SPEAKER WIRE) INPUTS
If your auto sound system does not have low-level line out jacks but has only speaker outputs, connect your auto sound system’s speaker outputs to the amplifier’s
PUT
jacks.
• If your auto sound system has four
speaker outputs, see “Four Speaker Outputs” on Page 10 to connect your system’s speaker outputs to the ampli­fier using either a floating or common ground connection.
• If your auto sound system has two
speaker outputs, see “Two Speaker Out­puts” on Page 11 to connect your sys­tem’s speaker outputs to the amplifier
HIGH IN-
Connecting Inputs
using either a floating or common ground connection.
Note:
A floating ground connection lets the amplifier provide more power to each speak­er, but requires that you connect a separate wire to each speaker terminal. A common ground connection lets you use fewer wires to connect the speakers to the amplifier, but reduces the amount of power supplied to the speakers from the amplifier.
Use the supplied wire harnesses and the supplied twist-on terminal connectors to make the appropriate connections.
9
12-2018.fm Page 10 Friday, May 12, 2000 12:46 PM
Four Speaker Outputs
Floating Ground Connection
Violet/Black Green/Black
Violet
Right Rear +
Speaker
Right Rear–
Speaker
Left Rear –
Common Ground Connection
Violet/Black Green/Black
Green
Speaker
Left Rear +
Speaker
Auto Sound System
Gray/Black
Gray
Right Front +
Speaker
Gray/Black
Right Front–
Speaker
White/Black
White
Left Front +
Left Front –
Speaker
White/Black
Speaker
10
Violet
Right Rear +
Speaker
Common
Green
Left Rear +
Speaker
Auto Sound System
Gray
Right Front +
Speaker
Common
White
Left Front +
Speaker
Connecting Inputs
12-2018.fm Page 11 Friday, May 12, 2000 12:46 PM
Two Speaker Outputs
Floating Ground Connection
Violet/Black
Violet
Right +
Speaker
Right –
Speaker
Green/Black
Left –
Common Ground Connection
Violet/Black
Violet
Green/Black
Green
Speaker
Left +
Speaker
Auto Sound System
Green
y
a
r
G
Gray/
Black
White/
Black
White
y
a
r
G
Gray/
Black
White/
Black
White
Right +
Speaker
Common
Left +
Speaker
Auto Sound System
Connecting Inputs
11
12-2018.fm Page 12 Friday, May 12, 2000 12:46 PM
CONNECTING SPEAKERS
You can connect four speakers, two speak­ers and a subwoofer, or just two speakers to the amplifier and your auto sound system.
Important:
tions, make sure both the left and right sides of the amplifier) are set to ST.
Preparing the Speaker Wires
Caution:
to each speaker terminal as described in the following procedures. Only use a common ground wire or chassis ground if your auto sound system is wired for it.
Notes:
• Use 16- or 18-gauge marked or color­coded wires to help you correctly con­nect the speakers to your amplifier.
• Color-coded wires have a stripe running down one of the conductors or different colored insulation for each conductor. Your local RadioShack store has a wid e selection of speaker wire.
Before you make the connec-
BRG/ST
switches (on
You must connect a separate wire
3. Strip the insulation from the ends of
1
each conductor to expose
/4 inch of wire. Twist the ends to secure loose strands.
Conductors
1
/4 Inch
4 Inches
• For the maximum bass response and the best overall performance, keep your speakers properly phased (connect + to + and – to –).
1. With the speakers placed in their approximate locations, run one wire from each speaker to the amplifier.
If you are connecting a subwoofer, run
two wires from each of the subwoofer’s terminals to the amplifier.
2. Separate each wire’s two conductors at both ends for a length of about 4 inches.
12
Connecting Inputs
12-2018.fm Page 13 Friday, May 12, 2000 12:46 PM
Connecting Four Speakers
CH1 Front Left Speaker
1. Use a screwdriver to connect the front left speaker’s positive (+) wire to the amplifier’s
CH1 (+)
terminal.
CH2 Front Right Speaker
CH3 Rear Left Speaker
(–) wires to the amplifier’s
CH2 (–)
terminals.
4. Repeat Steps 1–3 to connect the rear
2. Use a screwdriver to connect the front left speaker’s negative (–) wire to the amplifier’s
CH1 (–)
terminal.
left and rear right speaker’s positive (+) and negative (–) wires to the amplifier ’s
CH3 (+), CH3 (–), CH4 (+),
minals.
3. Repeat Steps 1–2 to connect the front right speaker’s positive (+) and negative
Connecting Two Speakers (Unbridged Connection)
Left Speaker
CH4 Rear Right Speaker
Right Speaker
and
CH2 (+)
CH4 (–)
and
ter-
This connection produces 100 watts per channel. Use this connection if you do not have high-power speakers.
1. Use a screwdriver to connect the left speaker’s positive (+) wire to the ampli­fier’s
CH3 (+)
terminal.
Connecting Inputs
2. Use a screwdriver to connect the left speaker’s negative (–) wire to the ampli-
CH3 (–)
fier’s
terminal.
3. Repeat Steps 1–2 to connect the right speaker’s positive (+) and negative (–) wires to the amplifier’s
(–)
terminals.
CH4 (+)
and
CH4
13
12-2018.fm Page 14 Friday, May 12, 2000 12:46 PM
Connecting Two Speakers (Bridged Connection)
Left Speaker
Caution:
This connection produces 200 watts per channel. Use this connection only if you have high-power speakers that can han-
2. Use a screwdriver to connect the left speaker’s negative (–) wire to the ampli-
CH2 (+)
fier’s
Right Speaker
terminal.
dle a power output of 200 watts.
3. Repeat Steps 1–2 to connect the right
Note:
CH2 (+)
tive (–) terminals for a bridged connection.
and
CH4 (+)
are used as nega-
speaker’s positive (+) and negative (–) wires to the amplifier’s
(+)
terminals.
CH3 (+)
and
CH4
1. Use a screwdriver to connect the left speaker’s positive (+) wire to the ampli-
CH1 (+)
fier’s
terminal.
4. Set both
BRG/ST
and right sides of the amplifier) to
switches (on the left
BRG
Connecting Two Speakers and One Subwoofer (Unbridged Connection)
Or
CH1 Front Left Speaker
CH2 Front Right Speaker
CH3 Rear Subwoofer
CH4 Rear Subwoofer
.
1. Use a screwdriver to connect the front left speaker’s positive (+) wire to the amplifier’s
CH1 (+)
terminal.
2. Use a screwdriver to connect the front left speaker’s negative (–) wire to the
CH1 (–)
amplifier’s
14
terminal.
Connecting Inputs
3. Repeat Steps 1–2 to connect the front right speaker’s positive (+) and negative (–) wires to the amplifier’s
CH2 (–)
terminals.
CH2 (+)
and
12-2018.fm Page 15 Friday, May 12, 2000 12:46 PM
4. Use a screwdriver to connect the sub­woofer’s positive (+) wire to the ampli­fier’s
CH3 (+)
or
CH4 (+)
terminal.
5. Repeat Step 4 to connect the sub­woofer’s negative (–) wire to the ampli-
channel you connected in Step 4. For example, if you connected the sub­woofer’s positive (+) wire to the ampli­fier’s
CH3 (+)
terminal, connect the
subwoofer’s negative (–) wire to the
CH3 (–)
amplifier’s
terminal.
fier’s negative (–) terminal for the same
Connecting Two Unbridged Speakers and One Bridged Subwoofer
CH1 Front Left Speaker
Note:
CH4 (+)
is used as a negative (–) termi-
nal for a bridged connection.
1. Use a screwdriver to connect the left front speaker’s positive (+) wire to the amplifier’s
CH1 (+)
terminal.
CH2 Front Right Speaker
Subwoofer
6. Make sure the
right
side of the amplifier is set to ST,
then set the
BRG/ST
side of the amplifier to
BRG/ST
switch on the
switch on the
BRG
.
left
2. Use a screwdriver to connect the left front speaker’s negative (–) wire to the
CH1 (–)
amplifier’s
terminal.
3. Repeat Steps 1–2 to connect the right front speaker’s positive (+) and negative (–) wires to the amplifier’s
CH2 (–)
terminals.
CH2 (+)
and
4. Use a screwdriver to connect the sub­woofer’s positive (+) wire to the ampli­fier’s
CH3 (+)
terminal.
5. Repeat Step 4 to connect the sub­woofer’s negative (–) wire to the ampli­fier’s
CH4 (+)
terminal.
Connecting Inputs
15
12-2018.fm Page 16 Friday, May 12, 2000 12:46 PM
ˆ
Completing the Installation
TESTING THE CONNECTIONS
Before you continue, make sure you have securely made all connections. Then recon­nect the cable to the vehicle’s negative ( battery terminal.
LEVEL (MIN/MAX)
Set sides of the amplifier to its mid position (see “Adjusting the Audio Level” on Page 18). Then turn on your vehicle’s ignition and auto sound system to confirm that the amplifier
on the left and right
MOUNTING THE AMPLIFIER
Sheet Metal Screw
Lock Washer
Flat Washer
and auto sound system operate properly. The amplifier turns on after a few seconds.
If you cannot quickly confirm whether the auto sound system and amplifier are working properly,
)
and disconnect the cable from your vehi­cle’s negative (–) battery terminal.
recheck your connections. After you test the auto sound system and
amplifier and verify that everything is proper­ly connected and working, follow the instruc­tions in “Mounting the Amplifier.”
turn off your vehicle’s ignition
Then
9
/64-Inch Mounting Hole
Once you verify that the amplifier is connect­ed properly, follow these steps to mount it.
1. Disconnect the cable from the vehicle’s negative (–) battery terminal.
2. To make mounting more convenient, temporarily disconnect the amplifier’s connections (ground, primary power, remote power, your auto sound system’s input, and speakers).
16
Completing the Installation
Chassis or Car Mat
Note:
If you have not already done so, be sure to mark each wire with the name of the terminal you will reconnect it to.
3. Using the mounting holes on the ampli­fier as a guide, mark the positions for the mounting holes.
9
4. Drill
/64-inch (3.57 mm) holes at the marked locations, being careful not to damage anything behind the mounting surface.
12-2018.fm Page 17 Friday, May 12, 2000 12:46 PM
5. Secure the amplifier to the mounting surface using the supplied sheet metal screws and washers.
6. Reconnect the wiring.
7. Reconnect the cable to the vehicle bat­tery’s negative (–) terminal.
8. Reset your vehicle’s clock, your auto sound system’s tuner memory, and other timer/memory devices.
Completing the Installation
17
12-2018.fm Page 18 Friday, May 12, 2000 12:46 PM
ˆ
Operation
TURNING ON THE AMPLIFIER
The amplifier automatically turns on a few seconds after you turn your vehicle’s ignition switch to ACC or ON or turn on your auto sound system, depending on how you wired the system. The POWER indicator on the side of the amplifier lights when the amplifier is on.
Important:
or more of power from your vehicle’s battery during operation. To protect your battery from discharging, do not operate the amplifi­er unless your vehicle is running.
Note:
if it gets too hot, then restarts automatically once it cools.
Your amplifier requires 60 amps
Your amplifier temporarily shuts down
ADJUSTING THE AUDIO LEVEL
For the best performance, you must set
EL (MIN/MAX)
amplifier to adjust the level of the audio sig­nals that enter the amplifier.
on the left and right sides of the
LEV-
1. Use a screwdriver to turn
MAX)
on the left and right sides of the
amplifier fully counterclockwise to
2. Turn the auto sound system’s volume control to about one-third of its full range.
3. On the left and right sides of the ampli­fier, adjust fortable listening level.
4. Turn up the auto sound system’s volume control until the sound begins to distort. Then immediately turn the volume down to a point just before where the distor­tion began.
Caution:
system’s volume control more than needed to adjust the audio level, or more than two-thirds of its maximum vol­ume.
5. On the left and right sides of the ampli­fier, adjust sound is at the maximum level you want the amplifier to produce.
6. Adjust the auto sound system’s volume control to a comfortable listening level.
LEVEL (MIN/MAX)
Never turn up the auto sound
LEVEL (MIN/MAX)
LEVEL (MIN/
MIN
.
to a com-
until the
18
Operation
12-2018.fm Page 19 Friday, May 12, 2000 12:46 PM
ADJUSTING FREQUENCY CROSSOVER
If you installed a subwoofer using the steps in “Connecting Two Speakers and One Sub­woofer (Unbridged Connection)” on Page 14 or “Connecting Two Unbridged Speakers and One Bridged Subwoofer” on Page 15,
X-OVER FREQ ON/OFF
set
X-OVER FREQ
The amplifier passes through all frequencies at or below that setting (45−400 Hz).
for your vehicle’s acoustics.
to ON, then adjust
Note:
X-OVER FREQ
the amplifier will pass frequencies (from 45 400 Hz). You should not use it to adjust the sound you hear through your main speakers.
selects the limit at which
Operation
19
12-2018.fm Page 20 Friday, May 12, 2000 12:46 PM
ˆ
Troubleshooting
We do not expect you to have any problems with your RadioShack High Power 4/3/2-Channel Bridgeable Amplifier, but if you do have a problem, this chart might help. If not, take th e a mpli­fier to your local RadioShack store for assistance.
Symptom Possible Cause Suggestion
No power
POWER
after the vehicle’s auto sound system is turned on
No sound Auto sound system not turned
Distorted sound The amplifier might be receiving
the amplifier’s
indicator does not light
Power problem. Check the amplifier’s and auto
Vehicle’s ignition not turned on. Start the vehicle. Amplifier not connected to auto
sound system/vehicle correctly.
on or volume set to minimum.
LEVEL (MIN/MAX)
Amplifier’s controls set to minimum.
Amplifier not connected to auto sound system/vehicle correctly.
The amplifier might have shut down.
Power problem. Check the amplifier’s and auto
too much input power from your auto sound system.
An output channel might have shorted.
sound system’s fuses and replace them if necessary (see “Replacing a Fuse” “Replacing a Fuse” on Page 21).
Check all connections.
Turn the auto sound system on or adjust its volume.
LEVEL (MIN/MAX)
Adjust
Check all connections.
Turn your auto sound system off and let the amplifier cool. Make sure the amplifier is properly ventilated. Then turn your auto sound system back on. The amplifier turns itself back on when it is cooled.
The amplifier detected an input overload. Reduce the auto sound system’s volume.
sound system’s fuses and replace them if necessary (see “Replacing a Fuse” on Page 21).
Reduce your auto sound sys­tem’s output power (if possi­ble), or reduce the auto sound system’s volume.
Take the amplifier to your local RadioShack store.
.
20
Troubleshooting
12-2018.fm Page 21 Friday, May 12, 2000 12:46 PM
Symptom Possible Cause Suggestion
Distorted sound (continued) The amplifier might have shut
down.
Turn your auto sound system off and let the amplifier cool. Make sure the amplifier is properly ventilated. Then turn your auto sound system back on. The amplifier turns itself back on when it is cooled.
CARE
To enjoy your amplifier for a long time:
• Keep the amplifier dry. If it gets wet, wipe it dry immediately.
• Use and store the amplifier only in nor­mal temperature environments.
• Handle the amplifier gently and care­fully. Do not drop it.
• Keep the amplifier away from dust and dirt.
• Wipe the amplifier with a damp cloth occasionally to keep it looking new.
Modifying or tampering with the amplifier’s internal components can cause a malfunc­tion and might invalidate its warranty and void your FCC authorization to operate it. If your amplifier is not performing as it should, take it to your local RadioShack store for as­sistance.
REPLACING A FUSE
If the amplifier does not operate, you might need to replace the red power cable’s 60­amp SFE-type fuse or one or both of the 30­amp blade-type fuses on the amplifier’s back panel. Check all fuses.
Caution:
Do not use a fuse with ratings other than those specified. Doing so might damage your amplifier.
Replacing the SFE-Type Fuse
1. Disconnect the cable from the vehicle’s negative (–) battery terminal.
2. Push together and twist the fuse holder’s parts on the red power cable until they spring apart. Then remove the fuse.
Fuse
3. If the fuse is blown, replace it. Use only an SFE-type fuse with the proper rating (available at many automotive supply stores). The fuse must be 60 amps.
4. Reassemble the fuse holder by inserting the fuse into the longer of the fuse holder’s ends, and pushing together and twisting the two parts until they latch together.
5. Reconnect the cable to the vehicle’s negative (–) battery terminal.
Important:
Let the amplifier cool down and see if it starts again before you assume a fuse needs to be replaced.
Troubleshooting
Replacing the Blade-Type Fuses
1. Disconnect the cable from the vehicle’s negative (–) battery terminal.
21
12-2018.fm Page 22 Friday, May 12, 2000 12:46 PM
2. For each fuse, grasp its plastic end and pull it out of the back of the amplifier.
3. If the fuse is blown, replace it. Use only a blade-type fuse with the proper rating. The fuse must be 30 amps.
4. Grasp the fuse’s plastic end and push it in.
5. Reconnect the cable to the vehicle’s negative (–) battery terminal.
22
Troubleshooting
12-2018.fm Page 23 Friday, May 12, 2000 12:46 PM
ˆ
Specifications
Output Power:
Stereo ....................................................................... 65 Watts × 4 @ 4 Ohms, 20–20 kHz, 0.5% THD
100 Watts × 4 @ 4 Ohms, 20–20 kHz, 10% THD
75 Watts × 4 @ 2 Ohms, 20–20 kHz, 0.5% THD
80 Watts × 4 @ 2 Ohms, 20–20 kHz, 1% THD
Bridged .................................................................................. 200 Watts @ 4 Ohms, 1 kHz, 10% THD
Frequency Response ................................................................................................ 20–20,000 Hz (±3 dB)
Power Supply Voltage ......................................................................................... 12V DC Negative Ground
Maximum Current Draw ........................................................................................................................ 60 A
Dimensions (HWD) ...................................................................................................... 2
Net Weight ........................................................................................................................................... 12 lbs
Specifications are typical; individual units might vary. Specifications are subject to change and improve­ment without notice.
5
/8 × 13 × 17 Inches
(6.6 × 33 × 43.2 cm)
(5.4 kg)
Specifications
23
12-2018.fm Page 24 Friday, May 12, 2000 12:46 PM
Limited One-Year Warranty
This product is warranted by RadioShack against manufacturing defects in material and workman­ship under normal use for one (1) year from the date of purchase from Radi oSha ck company- owned stores and authorized RadioShack franchisees and dealers. EXCEPT AS PROVIDED HEREIN, Ra­dioShack MAKES NO EXPRESS WARRANTIES AND ANY IMPLIED WARRANTIES, INCLUDING THOSE OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE DURATION OF THE WRITTEN LIMITED WARRANTIES CONTAINED HEREIN. EXCEPT AS PROVIDED HEREIN, RadioShack SHALL HAVE NO LIABILITY OR RE­SPONSIBILITY TO CUSTOMER OR ANY OTHER PERSON OR ENTITY WITH RESPECT T O ANY LIABILITY, LOSS OR DAMAGE CAUSED DIRECTLY OR INDIRECTLY BY USE OR PERFOR­MANCE OF THE PRODUCT OR ARISING OUT OF ANY BREACH OF THIS WARRANTY, IN­CLUDING, BUT NOT LIMITED TO, ANY DAMAGES RESULTING FROM INCONVENIENCE, LOSS OF TIME, DATA, PROPERTY, REVENUE, OR PROFIT OR ANY INDIRECT, SPECIAL, INCIDEN­TAL, OR CONSEQUENTIAL DAMAGES, EVEN IF RadioShack HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limit a­tion of incidental or consequential damages, so the above limitations or exclusions may not apply to you. In the event of a product defect during the warranty period, take the product and the RadioShack sales receipt as proof of purchase date to any RadioShack store. RadioShack will, at its option, un­less otherwise provided by law: (a) correct the defect by product repair without charge for parts and labor; (b) replace the product with one of the same or similar design; or (c) refund the purchase price. All replaced parts and products, and products on which a refund is made, become the prop­erty of RadioShack. New or reconditioned parts and products may be used in the performance of warranty service. Repaired or replaced parts and products are warranted for the remainder of the original warranty period. You will be charged for repair or replacement of the product made after the expiration of the warranty period. This warranty does not cover: (a) damage or failure caused by or attributable to acts of God, abuse, accident, misuse, improper or abnormal usage, failure to follow instructions, improper installation or maintenance, alteration, lightning or other incidence of excess voltage or current; (b) any repairs other than those provided by a RadioShack Authorized Service Facility; (c) consumables such as fuses or batteries; (d) cosmetic damage; (e) transportation, shipping or insurance costs; or (f) costs of product removal, installation, set-up service adjustment or reinstallat i on. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
RadioShack Customer Relations, 200 Taylor Street, 6th Floor, Fort Worth, TX 76102
We Service What We Sell
12/99
RadioShack A Division of Tandy Corporation Fort Worth, Texas 76102
12-2018
05A00
Printed in China
Loading...
