Radio Shack Handsfree User Manual
43-1701.fm Page 1 Wednesday, September 20, 2000 8:48 AM
2-Line 900 MHz Handsfree
Cordless Phone
Owner’s Manual
Please read before using this equipment.
43-1701.fm Page 2 Wednesday, September 20, 2000 8:48 AM
ˆ
Contents
Features ............................................................... ... ... 6
Preparation ................................................................ 7
Selecting a Location ............................................ 7
Connecting the Base ........................................... 8
Connecting and Charging the Battery Pack ........ 9
Recharging the Battery Pack ...................... 11
Connecting and Adjusting the Headset ............. 13
Setting Ring/Vibrate/Dual .................................. 14
Turning the Ringers On or Off ........................... 14
Setting the Dialing Mode ................................... 14
Operation ............................................................. .... 15
Adjusting the Headset’s Volume ........................ 16
Using Hold ......................................................... 17
Using Conference .............................................. 17
Changing Channels ........................................... 18
Using Redial ...................................................... 18
Using Mute ........................................................ 18
Using Flash ......................................... ... ... .. ....... 19
Using Tone Services on a Pulse Line ................ 19
Using Page ........................................................ 19
Memory Dialing .............................................. ... . 20
Storing a Number in Memory ..................... 20
Entering a Pause in Memory Number ........ 21
Dialing a Stored Number ............................ 21
Chain-Dialing Service Numbers ................. 21
Testing Stored Emergency Numbers .......... 22
Troubleshooting ...................................................... 22
©
RadioShack and RadioShack.com are trademarks used by RadioShack Corporation.
2
2000 RadioShack Corporation. All Rights Reserved.
Contents
!
43-1701.fm Page 3 Wednesday, September 20, 2000 8:48 AM
WARNING:
shock hazard, do not expose this product to rain
or moisture.
To reduce the risk of fire or
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
CAUTION:
ELECTRIC SHOCK, DO NOT REMOVE
COVER OR BACK. NO USER-SERVICEABLE PART S INSIDE. REFER SERVICING
TO QUALIFIED PERSONNEL.
!
TO REDUCE THE RISK OF
This symbol is intended to alert
you to the presence of uninsulated dangerous voltage within
the product’s enclosure that might
be of sufficient magnitude to constitute a risk of electric shock. Do
not open the product’s case.
This symbol is intended to inform
you that important operating and
maintenance instructions are
included in the literature accompanying this product.
Your phone is ETL listed to UL standards and meets all applicable FCC standards.
Contents
3
43-1701.fm Page 4 Wednesday, September 20, 2000 8:48 AM
READ THIS BEFORE INSTALLATION
Each device that you connect to the phone line draws power
from the phone line. We refer to this power draw as the device’s
ringer equivalence number, or REN. The REN is on the bottom
of the base.
If you are using more than one phone or other device on the
line, add up all the RENs. If the total is more than five (three in
rural areas), your phone might not ring. If ringer operation is impaired, remove a device from the line.
FCC STATEMENT
This telephone complies with Part 68 of
upon request, provide the FCC registration number and the
REN to your phone company. These numbers are on the bottom of the base.
Note:
You must not connect your phone to any of the following
coin-operated systems, party-line systems, or most electronic
key phone systems.
In the unlikely event that your phone causes problems on the
phone line, the phone company can temporarily discontinue
your service. If this happens, the phone compa ny attempts to
notify you in advance. If advance notice is not practical, the
phone company notifies you as soon as possible and advises
you of your right to file a complaint with the FCC.
Also, the phone company can make changes to its lines, equ ipment, operations, or procedures that could affect the operation
of this telephone. The telephone company notifies you of thes e
4
Contents
FCC Rules
. You must,
43-1701.fm Page 5 Wednesday, September 20, 2000 8:48 AM
changes in advances, so you can take the necessary steps to
prevent interruption of your telephone service.
This equipment complies with the limits for a Class B dig ital device as specified in Part 15 of
FCC Rules.
These limits provide
reasonable protection against radio and TV interference in a
residential area. However, your equipment might cause TV or
radio interference even when it is operating properly. To eliminate interference, you can try one or more of the following corrective measures.
• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment and the radio
or TV.
• Use outlets on different electrical circuits for the equipment
and the radio or TV.
Consult your local RadioShack store if the problem still exists.
Warning:
Changes or modifications to this unit not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
Contents
5
43-1701.fm Page 6 Wednesday, September 20, 2000 8:48 AM
ˆ
Features
Your RadioShack 2-Line 900 MHz Handsfree Cordless Phone
combines the clarity of 900 MHz communication with portability
and convenience. The phone’s cordless keypad clips to your
belt or clothing so you can make and answer calls away from
the unit’s base. The headset allows you to use your hands while
you talk.
10-Memory Speed Dial
phone numbers for easy dialing.
Ring/Vibrate Dual Mode Selection
ring, vibrate, or both.
Receiver Volume Control
hear during a call.
Ample Talk and Standby Time
12 hours), the supplied battery provides about 7 hours of talk
time or 7 days of standby time.
10-Channel Auto Scan
nel when you make or answer a call.
Conference
time.
Security Access-Protection Code
phone users from using your phone line.
Hearing-Aid Compatible —
ing-aids that have a T (telephone) switch.
6
— lets you talk to parties on both lines at the same
— stores up to 10 frequently-called
— lets you set the ringer to
— lets you adjust the volume you
— when fully charged (about
— automatically selects a clear chan-
— prevents other cordless
lets you use your phone with hear-
Features
43-1701.fm Page 7 Wednesday, September 20, 2000 8:48 AM
ˆ
A Quick Look at the Phone
LOW BATT
VOLUME
CHANNEL
ˆ
9
CONF
L1
MUTE
MEMORY
Preparation
RING VIB/
RING/VIB
VOLUME
HOLD
L2
FLASH
8
TEL LINE
1/2
REDIAL/
PAUSE
TEL LINE
2
DC
Jack
SELECTING A LOCATION
You can place the phone’s base on a flat surface such as a
desk, shelf, or table. Select a location that is:
• near an easily accessible AC outlet
Preparation
7
43-1701.fm Page 8 Wednesday, September 20, 2000 8:48 AM
• near a telephone line jack
• out of the way of normal activities
• away from electrical machinery, electrical appliances, metal
walls, filing cabinets, wireless intercoms, security alarms,
and room monitors
The base’s location affects the phone’s range. If you have a
choice of several locations, try each to see which provides the
best performance.
Notes:
• Your telephone is designed to be connected to the telephone network using a compatible modular jack that is Part
68 compliant.
• Your telephone connects directly to a modular telephone
line jack. If your phone line jack is not a modu lar jack, you
can update the wiring yourself, using jacks and adapters
available at your local RadioShack store. Or, you can let
the phone company update the wiring for you.
• The USOC number of the jack to be installed is RJ14C (for
TEL LINE 1/2
) or RJ11C (for both telephone line jacks).
CONNECTING THE BASE
You can power the base using the supplied 15V, 300-mA AC
adapter.
8
Preparation
