READ THIS FIRST
We have designed your telephone to conform to federal
regulations and you can connect it to most telephone
lines. However, each device you connect to the phone
line draws power from it. This power draw is the device’s
ringer equivalence number
, or REN. The REN is on the
bottom of your phone.
If you are using more than one phone or other device on
the line, add up all the RENs. If the tot al is more than five
(or three in rural areas) your phones might not ring. If
ringer operation is impaired, remove one of the devices
from the line.
If your phone causes problems on the phone line, the
telephone company can disconnect your service. The
phone company tries to notify you i n advance . If advanc e
notice is not practical, the telephone company notifies
you as soon as possible and advises you of your right to
file a com p laint wi th the FCC.
The phone company can also make changes to its lines,
equipment, operations, or procedures that could affect
the phone’s operation. The phone company notifies you
in advance, so you can take the necessary steps to prevent interruption of your phone servi ce.
FCC STATEMENT
Your telephone complies with Part 68 of
must, upon request , provide the FCC registration number and the REN to your telephone company. Both numbers are on the bottom of your phone.
Note:
You must not connect you r tel ephone to:
• coin-operated systems
• party-line systems
• most electroni c key phone systems
FCC Rules
. You
CARE
• Keep the phone dry.
• Handle the phone carefu lly . Do not drop it.
• Do not use or store the phone in temperature
extremes.
• Keep the phone away from dust and di rt.
• Do not modify or tamper with the pho ne’s interna l components. Doing so might invalidate the phone’s warranty and void your FCC authorization to operate it. If
the phone is not operating as i t should, take it to your
local RadioShack store for assistance. If the trouble is
harming the phone lines, the phone company might
ask you to disconnect the telephone until you fix the
problem.
Limited One-Year Warranty
This product is warranted by RadioSha ck agains t manufa cturi ng defects
in material and workmanship under normal use for one (1) year from the
date of purch ase from RadioS hack company-ow ned stores and autho rized RadioSh ack franchisees and dealers. EXCEPT AS PROVIDED
HEREIN, RadioShack MAKES NO EXPRESS WARRANTIES AND ANY
IMPLIED WARRANTIES, INCLUDING THOSE OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE DURATION O F THE WRITTEN LIMITED WARRANTIES CONTAINED HEREIN. EXCEPT AS PROVIDED HEREIN,
RadioShack SHALL HAVE NO LIABILITY OR RESPONSIBILITY TO
CUSTOMER OR ANY OTHER PERSON OR ENTITY WITH RESPECT
TO ANY LIABILITY, LOSS OR DAMAGE CAUSED DIRECTLY OR INDIRECTLY BY USE OR PERFORMANCE OF THE PRODUCT OR ARISING OUT OF ANY BREACH OF T HIS WARRANTY, INCLUDING, BUT
NOT LIMITED TO, ANY DAMAGES RESULTING FROM INCONVENIENCE, LOSS OF TIME, DATA, PROPERTY, RE VENUE, OR PRO FIT
OR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES , EVE N I F Radi o Sh ack H AS BE EN AD V ISE D OF TH E POS SIBILITY OF SUCH DAMAGES.
Some states do not allow the limitations on how long an implied warranty
lasts or the exclu sion of incidental or conseque ntial damages, so the
above limitations or exclusions may not apply to you.
In the event of a product defect during t he warranty period, take the
product and the Rad ioShack sale s receipt as pr oof of purch ase date to
any RadioShac k store. RadioShack wil l, at its option, unless other wise
provided by law: (a) cor rect the defec t by product repai r without charge
for parts and labor; (b) replace the product with one of the same or similar design; or (c) refun d the purch ase pri ce. All repl aced par ts and prod ucts, and prod ucts o n which a refund is made, become the proper ty of
RadioShack. New or r econditioned part s and products may be used in
the performance of warranty service. Repaired or replaced parts and
products are warranted for the remainder of the original warranty period.
You will be charged for repair or replacement of the product made afte r
the expiration of the warranty period.
This warranty do es n ot cove r: (a) da mage or fail ure c aused by or attrib utable to acts of God, ab use, accident, misuse, impr oper or abnormal
usage, failure to follow instructions, improper installation or maintenance, alter ation, li ghtning or other i ncidence of ex cess volta ge or c urrent; (b) any repairs other than those provided by a RadioShack
Authorized Servi ce F acility; (c) con sumable s suc h as fus es or batter ies;
(d) cosmetic dam age; ( e) tr anspor tati on, shi ppin g or in suranc e cos ts; o r
(f) costs of product removal, installation, set-up service adjustment or reinstallation.
This warranty gi ves you specific legal rights, and you may also have
other rights which vary from state to state.
RadioShack Customer Relations, Dept. W,
100 Throckmorton St., Suite 600, Fort Worth, TX 76102
We Se rvi ce Wh at We S e ll
3/97
RadioShack
A Division of Tandy Corporation
Fort Worth, Texas 76102
Blue Neon
Trim Phone
n Lighted Keypad
n Neon Blue Ring Indicator
n Handset Volume Control
n Flash
nMute
nRedial
n Adjus ta b le R i nger
n Tone or Pulse (Rotary) Dialing
n Hearing Aid Compatible
Owner’s Manual
Cat. No. 43-861
8A8 Printed in China
MOUNTING THE PHONE
w
w
T
USING THE PHONE
Desk Mounting
Wall Plate
Mounting
Note
: The adapter powers the phone’s neon light and is
not needed for phone operation.
Cautions
• Always unplug the adapter from the AC outlet before
• The supplied AC adapt er supplies 12 volts, delivers at
:
you unplug the other end from the phone.
least 400 milliamps, and has a plug which properly fits
the phone’s
not meet these specifications could damage the phone
or the adapter.
DC 12V
jack. Using an adapter that does
Wall Mounting Handset Holder
If you mount the
phone on a wall, pull
out the handset holder
and rotate it 180°.
Handset Holder
TONE
Set to
match the type of ser vice
you have.
If you have pulse (rotary)
service, yo u can set it to
TONE
(or press ) during a
call to use tone services,
such as bank-b y-phone.
Hold down
MUTE
to talk
ith someone
in the r oom
ithout being
heard by the
person on the
phone.
o resume y our
conversat ion,
release
MUTE
or
.
PULSE
to
FLASH
Press
switchhook sign al f or special services such as call wai ting.
Note
: If you do not subscribe to
any special services, pressing
FLASH
Press
number dialed (up to 31 digit s).
to produce a
might disc onnect the call.
REDIAL
to dial the last
Use a paper clip or other
pointed object to l if t the plastic
cover off the number plate.
Then write your phon e number
and up to ten other important
numbers on the number plate
and replace the cover.
Note:
Use a pencil so you can
change the numbers later.
Press the switchhook to disconnect a call.
Set the ringer to sound
a high- or low-volume
ring, or to not sound at
all. You can make calls
with the ringer off, and
you can receive calls if
you hear another phon e
on the same line ringing.
VOLUME
Set
HI
to adjust the volume you
hear through the hands et.
LO/MED/
to
Note:
The USOC number of the jack to be installed is
RJ11C (RJ11W for a wall jack).
CAUTION
RISK OF ELECTRIC SHOCK
This symbol is intended to inform you
that parts inside the telephone present
a risk of electric shock.
This symbol is intended to alert you to
important operating and servicing instructions included in the papers with
the telephone.
DO NOT OPEN
Plug the handset cor d int o the
jacks on the hand set and base, a s
shown by the arrows above.
RadioShack is a registered trademark used by Tandy Corporation.
Press to end a call without
returning the handset to
the cradle.
1998 Tandy Corporation.
All Rights Reserved.
NEON
Set
the neon light, or set to
OFF
With
neon light st ays on when
the phone is not in use,
turns off when you pick up
the handset, and f lashes
when the phone rings.
to ON to turn on
to turn it off.
NEON
set to ON, the
