2 3 4 5 6 7
2000655
User’s Guide
Use Dynamo Power
Your radio comes with a 3.6V, 300 mA h, NiMH rechargeable batte ry pack that can be
recharged using the dy namo crank.
1. On the back panel of the r adio, switch
DYNAMO/
BATT ERY to
DYNAMO.
2. Lift the crank
and rotate it in
either direction.
The RECHARGE
Indicator light s
when charging.
Charge time
depends on
cranking rate and
duration.
For example, turning t he crank at about
2 turns per second for abo ut 90 seconds
should power the rad io for about 10
minutes. If playbac k time decreases to less
than 5 minutes at this cr anking rate, repla ce
the rechargeable bat tery pack.
AM/FM/Weather Band
Crank Radio
We hope you enjoy your AM/FM/ Weather
Band Crank Radio from Rad ioShack. This ra dio
receives AM, FM, and al l National Oceanic a nd
Atmospheric Administration (NOAA) Weather
Radio channels. Plea se read this user's gui de
before using your radio.
Package Contents
• Crank Radio
• Rechargeable Battery Pack
• User’s Guide
Specifications
AM .............................................................. 530 – 1710 kHz
FM ...................................................................88 – 108 MHz
Weather (WX) .................................162.4 – 162.55 MHz
Power Output (at 10% THD) ............................10 0 mW
Power ..........................................................3 .6V, 100mAh
..............Ni-Mh rechargeable battery pack (included)
......................................3 AA ba tteries (not incl uded) or
.....................5VDC Micro-USB adapter (not included)
Antenna ...........................................AM: built-in antenna
..........................................FM/WX: telescoping antenna
Speaker .........................................................3 in. (76 mm)
..............................................................I mpedance: 8 ohm
Specificat ions are subje ct to change a nd improveme nt
without notice . Actual produ ct may vary f rom the imag es
found in this docu ment.
Power Your Radio
IMPORTANT! Always insert the rechargeable
battery pack when yo u use your radio. Inser t the
battery pack plu g into the connector, then p lace
the battery pack i n the slot.
You can power your radio in three w ays:
• Dynamo power using the included
rechargeable battery pack
• Three AA batteries (not included)
• 5V DC Micro-USB adapter (not included)
Install Batteries (Optional)
Insert 3 AA
batteries (not
included) into
the battery
compartment
matching
the marked
polarity. Switch
DYNAMO/
BATT ERY to
BATT ERY.
Battery Notes:
• Dispose of batteries promptly and prope rly.
Do not burn or bury th em.
• Use only fresh batte ries of the required size
and type.
• Do not mix old and ne w batteries, die rent
types of batteries (alk aline or rechargeab le),
or rechargeable batte ries of dierent
capacities.
• If you do not plan to use th e radio for a long
time, remove the batter ies. Batteries ca n
leak chemicals tha t can damage elec tronic
parts.
Use a Micro USB Adapter (Optional)
You can listen to the radio and
charge the radio’s batter y pack at
the same time. Conn ect a 5V DC
Micro-USB adapter (not suppl ied)
to the DC IN jack. Using t his
method, the battery pack requires
about 12 hours to fully ch arge.
Notes:
• Your adapter must suppl y 5V DC and deliver
at least 500mA . Its plug must t your radio’s
5V jack. Using an adapte r that does not meet
these specicati ons could damage you r radio
or adapter.
• Batteries shou ld NEVER be lef t unattended
while charging. On ly adults sho uld charge
the batteries. Use ca ution when using t he
charger to avoid electr ic shock.
• Do not disassembl e the charger or batte ry
pack. Incorrect asse mbly can result in ri sk of
electric shock or re.
ALERT
indicator
RECHARGE
indicator
BAND
• Select AM/FM/WX band.
• Enter/Exit time setting mode.
SCAN
Scan for stations .
UP/DO WN
Tune stations.
VOL+/VOL–
• Adjust the volume.
• Set the clock time.
Dynamo
crank
POWER
ALERT
DC IN
DYNAMO/
BATTE RY
2000655_UG_EN_071114.indd 1-7 7/29/2014 4:19:21 PM
8 9 10 11 12 13 14
© 2014 RadioShack Corpor ation.
All rights reser ved. Radio Shack is
a registered trade mark used by
RadioShack Corporation.
Printed
in China
07A14
2000655
Complies with t he European Un ion’s
“Restricti on of Hazardous Su bstances
Directive,” whic h protects th e
environment by rest ricting s pecic
hazardous materials and products.
Notes:
• When charging you r device, you must
rst install and f ully charge the ra dio's
rechargeable batter y pack.
• If the power of recharge able battery pa ck
is exhausted, the rad io cannot charge your
device properly.
• The radio will b e muted when chargin g other
devices.
Connect Headphones
Connect headphones with a 1/8-in. (3.5 mm)
plug (not supplied) to the headphone jack s.
The speaker will automatically mute.
Listening Safely
Do not wear headphones, earphones, or
earbuds while ope rating a motor vehicl e or riding
a bicycle. This can create a t rac hazard and
could be illegal in s ome areas.
To protect your hearing, follow these guidelines:
• Do not listen at high vo lume levels. Ex tended
high-volume listeni ng can lead to perma nent
hearing loss.
Weather Alerts
To hear weather alerts, se lect the WX band and
press ALERT. The ALERT indicator lig hts. When
an alert is received, t he ALERT indicator a shes,
and the radio beeps . Press ALERT to listen to
the weather band broadcasts.
Charge Other Devices
Using power from the rad io's rechargeable
battery pack, you c an charge a device with U SBcharging capabilities (USB cable not included).
1. Connect your
device (not
included) to the
USB port on the
side panel using
a USB cable (not
included) with a
tip that matches
your device (maximum charging voltage
and current 5V/500mA). Refer to your
device to check the chargi ng status.
2. Slide the USB ON/USB OFF switch on
the back panel of the ra dio to ON when
charging, and switch to OFF when nished.
• Set the volume to th e lowest setting. T hen
turn on your audio devi ce and adjust the
volume to a comfortab le level.
• Avoid increasing the volume. Your ears will
adapt to the volume level , so a level that does
not cause discomfort cou ld still damage yo ur
hearing.
FCC Information
This equipment h as been teste d and found to com ply with
the limits for a Cl ass B digita l device, purs uant to Part 15
of the FCC Rules. Thes e limits are d esigned to prov ide
reasonable protec tion again st harmful i nterferen ce in a
residential installation. This equipment generates, uses,
and can radiate ra dio frequen cy energy an d, if not insta lled
and used in accordan ce with the in structi ons, may cause
harmful inter ference to radi o communica tions. Howe ver,
there is no guarant ee that inter ference wil l not occur in
a particular i nstallat ion. If this e quipment d oes cause
harmful inter ference to radi o or televisio n reception,
which can be determined by turning the equipment
o and on, the user is e ncouraged t o try to correc t the
interference by on e or more of the fol lowing meas ures:
• Reorient or relocate th e receiving a ntenna.
• Increase the separat ion between t he equipm ent and
receiver.
• Connect the equip ment into an out let on a circui t
dierent from that t o which the rece iver is connec ted.
• Consult your local Rad ioShack store o r an experie nced
radio/TV technician for help.
If you cannot eliminate the interference, the FCC
requires that you sto p using your eq uipment. C hanges
or modicatio ns not expressl y approved by the p arty
responsible for com pliance cou ld void the use r’s author ity
to operate the equipment.
This device compl ies with Par t 15 of the FCC Rules .
Operation is sub ject to the fol lowing two c onditions :
(1) this device may not cause h armful int erference, a nd
(2) this device must ac cept any inter ference receive d,
including interference that may cause undesired operation.
Limited Warranty
RadioShack warrants this product against defects in
materials and wor kmanship u nder norma l use by the
original purchaser for ninety (90) days after the dat e of
purchase from a Radio Shack-owned sto re or an author ized
RadioShack fran chisee or dea ler. RADIOSH ACK MAKES
NO OTHER EXPRESS WARRANTIES.
This warranty d oes not cover: (a) dam age or failu re
caused by or attri butable to a buse, misuse , failure to
follow instructions, improper installation or maintenance,
alteration, ac cident, Act s of God (such as o ods or
lightning), or exce ss voltage o r current; (b) imp roper or
incorrectly pe rformed re pairs by perso ns who are not a
RadioShack Auth orized Serv ice Facility ; (c) consumable s
such as fuses or batte ries; (d) ordina ry wear and te ar
or cosmetic damag e; (e) transpor tation, sh ipping or
insurance costs; (f ) costs of prod uct removal , install ation,
set-up service, adju stment or rein stallat ion; and (g) clai ms
by persons other th an the origi nal purchase r.
Should a problem o ccur that is cover ed by this warr anty,
take the product a nd the RadioS hack sales re ceipt as
proof of purchase date to a ny RadioShack s tore in the U.S .
RadioShack will , at its opti on, unless ot herwise p rovided by
law (a) replace the prod uct with th e same or a compa rable
product, or (b) refun d the purchas e price. All rep laced
products, and p roducts o n which a refund i s made,
become the proper ty of RadioS hack.
RADIOSHACK EX PRESSLY DISCL AIMS ALL
WARRANTIES AN D CONDITIO NS NOT STATED IN
THIS LIMITED WAR RANTY. ANY I MPLIED WARRA NTIES
THAT MAY BE IMPOSED BY LAW, INCLUD ING THE
IMPLIED WARRAN TY OF MERCH ANTABILITY A ND, IF
APPLICABLE, TH E IMPLIED WAR RANTY OF F ITNESS
FOR A PARTICULAR PUR POSE, SHALL E XPIRE ON TH E
EXPIRATION OF TH E STATED WARRANTY PERI OD.
EXCEPT AS DESCRI BED ABOVE, R ADIOSHACK SH ALL
HAVE NO LIABILIT Y OR RESPON SIBILIT Y TO THE
PURCHASER OF THE P RODUCT OR AN Y OTHER
PERSON OR ENTIT Y WITH RESPECT TO ANY L IABILIT Y,
LOSS OR DAMAGE CAUSED DI RECTLY OR INDIRECT LY
BY USE OR PERFORMANC E OF THE PRODU CT OR
ARISING OUT OF A NY BREACH OF T HIS WARRANT Y,
INCLUDING, BU T NOT LIMITED TO, AN Y DAMAGES
RESULTING FROM INCON VENIENCE A ND ANY LOSS OF
TIME, DATA, PROPERTY, REVENU E, OR PROFIT A ND ANY
INDIRECT, SPECIAL, IN CIDENTAL, OR CONS EQUENTIAL
Use the Radio
Set the Time
1. Press and hold BAND for 3 second s until
the time display ash es.
2. Press VOL + to set the hour. Press VOL - to
set the minute, Press and ho ld VOL + or
VOL - to set quickly . Press BAND to exit .
Note: The radio will exit the time-setting mode
if you do not press any buttons fo r 10 seconds.
Listen to Your Radio
1. Extend the antenn a (for FM and WX). Press
1POWER to turn on the radio.
3. Press VOL + and VOL - to adjust the
volume.
3. Press BAND to select a radio band.
4. Press UP and DOWN to tune to a station.
5. Press SCAN to automatically tune to a
station.
Notes:
• For best FM/WX rece ption, fully ex tend the
telescopic antenna.
• The radio has a bui lt-in AM antenna. Rotate
your radio to improve recepti on.
Recycle Rechargeable Batteries
Recycle used recha rgeable bat teries at one of
the many collect ion sites in t he U.S. and
Canada. To nd the site n earest you, vis it
www.call2recycle.org or call 1-800-822-8837.
DAMAGES, EVEN IF R ADIOSHAC K HAS BEEN ADVI SED
OF THE POSSIBIL ITY OF SUCH DA MAGES.
Some states do not al low limit ations on how l ong an
implied warra nty lasts o r the exclusion o r limitat ion of
incidental or co nsequenti al damages , so the above
limitations o r exclusions may n ot apply to you . This
warranty gives yo u specic l egal right s, and you may al so
have other right s which vary f rom state to st ate.
You may contact RadioSh ack at:
RadioShack Customer Relations,
300 RadioShack C ircle
Fort Worth, TX 76102 02/14
www.radioshack.com
Product
AM/FM/Weather Band
Crank Radio
Model 2000655
Responsible
Party
RadioShack
300 RadioShack C ircle, Fort
Worth, TX 76102
Phone 817-415-320 0
USB output
port
2000655_UG_EN_071114.indd 8-14 7/29/2014 4:19:26 PM
Loading...
