Quinny CV059 User Manual
CV059
User Guide
Guide d’utilisation
TM
®
French Guide Included
Guide français inclus
Contents
TM
English User Guide:
Contenu:
Guide d’utilisation français:
Warnings 1
Parts List 2
Assembly 3-5
To Use 5-7
Install Infant Car Seat 7
Care and Maintenance 8
Replaceable Parts 8
Warranty 8
Mise en garde 9
Liste des pièces 10
Assemblage 11-13
Utilisation 13-15
Installation du siège d’auto pour enfant 15
Soin et entretien 16
Pièces de remplacement 16
Garantie 16
i
WARNING
FOR THE SAFETY OF YOUR CHILD, PLEASE READ THE FOLLOWING WARNINGS AND ASSEMBLY
INSTRUCTIONS AND KEEP FOR FUTURE REFERENCE.
• Adult assembly required.
• CAUTION: Keep small parts away from children during assembly.
• NEVER LEAVE CHILD UNATTENDED. ALWAYS keep child in view when in stroller.
• AVOID SERIOUS INJURY from falling or sliding out. ALWAYS use seat belt. Check frequently to make sure it is secure.
• ALWAYS keep fingers away from moving parts, when folding, unfolding or adjusting stroller to prevent
finger entrapment.
• ALWAYS make sure stroller is FULLY OPEN AND LOCKED before using.
• ALWAYS use the brakes when stroller is stopped.
• ALWAYS remove protective material and poly bags and dispose before assembly.
• NEVER use stroller on stairs or escalators.
• NEVER rollerblade with stroller.
• NEVER allow children to play with or hang onto the stroller.
• NEVER allow children to climb into the stroller unassisted. Stroller may tip over and injure child.
• NEVER place or hang parcels, bags or accessories on the handle or canopy. The stroller may tip over or the
canopy may collapse.
• This product will become unstable if a parcel bag or rack is used when there is no provision for one.
• This product may become unstable if a parcel bag, other than the one recommended by the manufacturer is used.
• This product will become unstable if the manufacturer’s recommended load is exceeded.
• DO NOT carry additional children, goods or accessories in or on this product except as recommended in the
manufacturer’s instructions.
• NEVER place more than 11-LBS. (5-kg) in the storage basket. If weight is exceeded, hazardous unstable
conditions may exist.
• STROLLER is only for use with children up to 50-LBS. (22.73-kg), and WHEN SEATED, the midpoint of the
child’s head is at or below the top of the stroller seat.
• ONLY use this stroller with ONE child at a time.
• STROLLER is for use with children who can sit up unassisted, and is NOT recommended for newborns.
• Maximum tire pressure is 35-psi.
1
Parts List Warnings
TM TM
D
A
Rear wheels (2)
B
Front wheel assembly
C
E
G
F
C
Adjustable height handle
D
Canopy
Shopping basket
E
F
Car seat adapters* (2)
G
Bumper bar
®
* Maxi-Cosi
TM
Dreami
TM
Mico
bassinet sold separately.
car seat and Quinny
• Keep these instructions for future use.
• Lay out and identify all parts.
• D o not return this product to the
A
place of purchase. If any parts are
missing, call Consumer Relations at
(800) 951-4113. Or visit our website at
B
www.quinny.com.
• Include the model number and
manufacture date (found on the
bottom rail of stroller).
2
Assembly
2
1
2
1
2
1
1 Install Rear Wheels
Press the button in while
sliding the rear wheel axle
into the frame until you hear
a “click” (Figure 1). Repeat
for other rear wheel. Pull
to confirm it is assembled
securely.
2 Attach Shopping
Basket
Slide tab into tube at the
front center (Figure 2).
Secure an adhesive strap
around frame above each
rear wheel (Figure 2a).
1
2
2a
4 Unfold Stroller
Unfasten the transport hook
and push the handlebar
upward (Figure 4).
The frame will unfold
itself. The handlebar will
lock into place with a
“click” (Figure 4a).
NOTE: The BuzzTM stroller frame
has a unique mechanism that
enables the automatic unfolding
of the frame. The temperature
can effect the functioning of this
mechanism. In cold or frosty
weather, the stroller may unfold
more slowly than usual (at room
temperature).
4
4a
5 Adjust Handlebar
Height
Squeeze the adjustment
button and slide the
handlebar to desired height
(Figure 5). The handlebar
will click into place.
5
3 Install Front Wheel
Assembly
Squeeze the front wheel
fork while inserting it into
the frame tube. Push front
wheel fork into frame tube
until you hear a “click”
(Figure 3).
is assembled securely.
Pull to confirm it
3
6 Parking Brake
Always use the parking
brake, even when
standing still for only a few
moments! Push down on
the red pedal (P) behind
the rear wheel to set the
parking brake (Figure 6).
Push the opposite pedal
to release the parking
brake.
3
6
Assembly To Use
NOTES: The seat can be positioned facing the handlebar or forward.
The Buzz
4 (maximum 50-LBS. / 22.73-kg).
7 Attach Seat Facing
Slide both sides of the
TM
stroller seat is suitable for children from 6 months to age
7
Handlebar or
Forward
seat into the frame until
you hear each side click
and the RED INDICATOR
IS NOT VISIBLE on the
seat release buttons
(Figure 7).
Red
Indicator
Seat Facing
Handlebar
The seat can be adjusted
to two positions; a sitting
position and a semi-reclining
position. Stand at the side
of or behind the stroller.
Push the buttons on both
sides downward and tilt
the seat to the desired
position (Figure 7a).
Seat Facing
7a
7b
Forward
The seat can be adjusted
to two positions when
facing forward; a sitting
position and a semireclining position. Push
the buttons on both sides
downward and tilt the seat
to the desired position
(Figure 7b).
WARNING
DO NOT use when red
indicator is visible (Figure 7). DO NOT use with seat
in the position labeled “WRONG”.
RECLINED
RECLINED
8 To Remove Seat
Push the buttons on both
sides downward and lift
the seat from the frame
(Figure 8).
SEMI-RECLINED WRONG
SEMI-RECLINED WRONG
8
9 Canopy
Clip each side of the
canopy onto the frame until
it clicks into place (Figure
9). NOTE: Height of canopy
may be adjusted by sliding
it up and down the frame
(Figure 9). The sunshade
may be pulled forward.
9
4
