115V/15AMP DEDICATED CIRCUIT REQUIRED.
HARDWARE BY OTHERS -
BOTTOM LEFT-HAND JAMB.
POWER SUPPLY IS PULLED FROM
FINISHED FLOOR
33 1/2"
41"
4-1/2"
4-1/4"
NOTE: THIS DRAWING EMBODIES A CONFIDENTIAL PROPRIETARY DESIGN ORIGINATED AND OWNED BY QUIKSERV CORP., AND IS
SUBMITTED UNDER A CONFIDENTIAL RELATIONSHIP. ALL PATENT, MANUFACTURING, SALE RIGHTS REGARDING THE SAME ARE
RESERVED EXCEPT TO THE EXTENT RIGHTS ARE EXPRESSLY GRANTED TO OTHERS. THE RECIPIENT AGREES BY ACCEPTING THESE
DRAWINGS NOT TO SUPPLY OR DISCLOSE ANY INFORMATION REGARDING THEM TO ANY UNAUTHORIZED PERSON.
Quikserv Corp.
P.O. Box 40466
Houston, TX 77240-466
SS4035E-IP SIDE VIEW
Submitted By: Date: Sheet:
SS4035E-IP SIDE 1.23.2013
Actual Dimension:
48" (W) X 41" (H)
Rough Opening:
48-3/8" (W) X 41-3/8" (H)
Service Opening:
20"(W) X 27"(H)
BRIAN COBLE
1/23/2013
Scale:
N/A
