QUICK LOGIC QL4036-2PF144C, QL4036-2PF144I, QL4036-2PF144M, QL4036-2PQ208C, QL4036-2PQ208I Datasheet
...
© 2002 QuickLogic Corporati on
www.quicklogic.com
1
•
•
•
•
•
•
• • • • • •
Device Highlights
High Performance & High Density
• 36,000 Usable PLD Gates with 204 I/Os
• 300 MHz 16-bit Counters, 400 MHz
Datapaths, 160+ MHz FIFOs
• 0.35 µm four-layer metal non-volatile
CMOS process for smallest die sizes
High Speed Embedded SRAM
• 14 dual-port RAM modules, organized in
user-configurable 1,152 bit blocks
• 5 ns access times, each port independently
accessible
• Fast and efficient for FIFO, RAM, and ROM
functions
Easy to Use / Fast Developm ent
Cycles
• 100% routable with 100% utilization and
complete pin-out stability
• Variable-grain logic cells provide high
performance and 100% utilization
• Comprehensive design tools include high
quality Verilog/VHDL synthesis
Advanced I/O Capabilities
• Interfaces with both 3.3 V and 5.0 V devices
• PCI compliant with 3.3 V and 5.0 V busses
for -1/-2/-3/-4 speed grades
• Full JTAG boundary scan
• I/O Cells with individually controlled
Registered Input Path and Output Enables
Figure 1: QuickRAM Block Diagram
14
RA M
Blocks
672
Hi gh Sp eed
Logic Cells
Interface
QL4036 QuickRAM Data Sheet
36,000 Usable PLD Gate QuickRAM ESP Combining Performance,
Density and Embedded RAM
2
www.quicklogic.com
© 2002 QuickLogic Corporation
•
•
•
•
•
•
QL4036 QuickRAM Data Sheet Rev G
Architecture Overview
The QuickRAM family of ESPs (Embedded Standard Products) offers FPGA logic in
combination with Dual-Port SRAM modules. The QL4036 is a 36,000 usable PLD gate
member of the QuickRAM family of ESPs. QuickRAM ESPs are fabricated on a 0.35 µm
four-layer metal process using QuickLogic's patented ViaLink
TM
technology to provide a
unique combination of high performance, high density, low cost, and extreme ease-of-use.
The QL4036 contains 672 logic cells and 14 Dual Port RAM modules (see Figure 1). Each
RAM module has 1,152 RAM bits, for a total of 16,128 bits. RAM Modules are Dual Port
(one read port, one write port) and can be configured into one of four modes:
64 (deep) × 18 (wide), 128 × 9, 256 × 4, or 512 × 2 (see
Figure 4). With a maximum of 82
I/Os, the QL4036 is available in 144-pin TQFP, 208-pin PQFP, 208-pin CQFP, and 256pin PBGA packages.
Designers can cascade multiple RAM modules to increase the depth or width allowed in
single modules by connecting corresponding address lines together and dividing the words
between modules (see
Figure 2). This approach allows up to 512-deep configurations as
large as 16 bits wide in the smallest QuickRAM device and 44 bits wide in the largest device.
Software support for the complete QuickRAM family, including the QL4036, is available
through two basic packages. The turnkey QuickWorks
TM
package provides the most
complete ESP software solution from design entry to logic synthesis, to place and route, to
simulation. The QuickTools packages provides a solution for designers who use Cadence,
Exemplar, Mentor, Synopsys, Synplicity, Viewlogic, Aldec, or other third-party tools for
design entry, synthesis, or simulation.
The QuickLogic
TM
variable grain logic cell features up to 16 simultaneous inputs and five
outputs within a cell that can be fragmented into five independent cells. Each cell has a fanin of 29 including register and control lines (see
Figure 3).
Figure 2: QuickRAM Module Bits
RDATAWDATA
RADDR
RDATA
WADDR
WDATA
RAM
Module
(1,152 bits)
RAM
Module
(1,152 bits)
© 2002 QuickLogic Corporati on
www.quicklogic.com
3
•
•
•
•
•
•
QL4036 QuickRAM Data Sheet Rev G
Product Summary
Total of 204 I/O Pins
• 196 bi-directional input/output pins, PCI-compliant for 5.0 V and 3.3 V buses for
-1/-2/-3/-4 speed grades
• 8 high-drive input/distributed network pins
Eight Low-Skew Distributed Networks
• Two array clock/control networks available to the logic cell flip-flop clock, set and reset
inputs—each driven by an input-only pin
• Six global clock/control networks available to the logic cell F1, clock, set and reset inputs
and the input and I/O register clock, reset and enable inputs as well as the output enable
control—each driven by an input-only or I/O pin, or any logic cell output or I/O cell
feedback
High Performance Silicon
• Input + logic cell + output total delays = under 6 ns
• Data path speeds over 400 MHz
• Counter speeds over 300 MHz
• FIFO speeds over 160+ MHz
4
www.quicklogic.com
© 2002 QuickLogic Corporation
•
•
•
•
•
•
QL4036 QuickRAM Data Sheet Rev G
Electrical Specifications
AC Characteristic s a t VCC = 3.3 V, TA = 25°C (K = 1.00)
To calculate delays, multiply the appropriate K factor from Table 10: Operating Range by the
following numbers in the tables provided.
Figure 3: QuickRAM Logic Cell
Table 1: Logic Cell
Symbol Parameter
Propagation Delays (ns)
Fanout (5)
1 2 3 4 5
t
PD
Combinatorial Delay
a
a. These limits are derived from a representative selection of the slowest paths through the Quick-
RAM logic cell including typical net delays. Worst case delay values for specific paths should be
determined from timing analysis of your particular design.
1.4 1.7 1.9 2.2 3.2
t
SU
Setup Time
a
1.7 1.7 1.7 1.7 1.7
t
H
Hold Time 0.0 0.0 0.0 0.0 0.0
t
CLK
Clock to Q Delay 0.7 1.0 1.2 1.5 2.5
t
CWHI
Clock High Time 1.2 1.2 1.2 1.2 1.2
t
CWLO
Clock Low Time 1.2 1.2 1.2 1.2 1.2
t
SET
Set Delay 1.0 1.3 1.5 1.8 2.8
t
RESET
Reset Delay 0.8 1.1 1.3 1.6 2.6
t
SW
Set Width 1.9 1.9 1.9 1.9 1.9
t
RW
Reset Width 1.8 1.8 1.8 1.8 1.8
QS
A1
A2
A3
A4
A5
A6
F1
F2
F3
F4
F5
F6
QS
OP
B1
B2
C1
C2
MP
MS
D1
D2
E1
E2
NP
NS
QC
QR
OZ
AZ
QZ
NZ
FZ
© 2002 QuickLogic Corporati on
www.quicklogic.com
5
•
•
•
•
•
•
QL4036 QuickRAM Data Sheet Rev G
Figure 4: QuickRAM Module
Table 2: RAM Cell Synchronous Write Timing
Symbol Parameter
Propagation Delays (ns)
Fanout
1 2 3 4 5
t
SWA
WA Setup Time to WCLK 1.0 1.0 1.0 1.0 1.0
t
HWA
WA Hold Time to WCLK 0.0 0.0 0.0 0.0 0.0
t
SWD
WD Setup Time to WCLK 1.0 1.0 1.0 1.0 1.0
t
HWD
WD Hold Time to WCLK 0.0 0.0 0.0 0.0 0.0
t
SWE
WE Setup Time to WCLK 1.0 1.0 1.0 1.0 1.0
t
HWE
WE Hold Time to WCLK 0.0 0.0 0.0 0.0 0.0
t
WCRD
WCLK to RD (WA=RA)
a
a. Stated timing for worst case Propagation Delay over process variation at VCC = 3.3 V and
TA = 25
°C. Multiply by the appropriate Delay Factor, K, for speed gra de, voltage and tempe ratur e
settings as specified in the Operating Range.
5.0 5.3 5.6 5.9 7.1
Table 3: RAM Cell Synchronous Read Timing
Symbol Parameter
Propagation Delays (ns)
Fanout
Logic Cells 1 2 3 4 5
t
SRA
RA Setup Time to RCLK 1.0 1.0 1.0 1.0 1.0
t
HRA
RA Hold Time to RCLK 0.0 0.0 0.0 0.0 0.0
t
SRE
RE Setup Time to RCLK 1.0 1.0 1.0 1.0 1.0
t
HRE
RE Hold Time to RCLK 0.0 0.0 0.0 0.0 0.0
t
RCRD
RCLK to RD
a
a. Stated timing for worst case Propagation Delay over process variation at VCC = 3.3 V and
TA = 25
°C. Multiply by the appropriate Delay Factor, K, for speed gra de, voltage and tempe ratur e
settings as specified in the Operating Range.
4.0 4.3 4.6 4.9 6.1
WA
WD
WE
WCLK
RE
RCLK
RA
RD
[8:0]
[17:0]
[8:0]
[17:0 ]
MODE ASYNCRD
[1:0]
6
www.quicklogic.com
© 2002 QuickLogic Corporation
•
•
•
•
•
•
QL4036 QuickRAM Data Sheet Rev G
Table 4: RAM Cell Asynchronous Read Timing
Symbol Parameter
Propagation Delays (ns)
Fanout
1 2 3 4 5
RPDRD RA to RD
a
a. Stated timing for worst case Propagation Delay over process variation at VCC = 3.3 V and
TA = 25
°C. Multiply by the appropriate Delay Factor, K, for speed gra de, voltage and tempe ratur e
settings as specified in the Operating Range.
3.0 3.3 3.6 3.9 5.1
Table 5: Input-Only / Clock Cells
Symbol Parameter
Propagation Delays (ns)
Fanout
1 2 3 4 8 12 24
t
IN
High Drive Input Delay 1.5 1.6 1.8 1.9 2.4 2.9 4.4
t
INI
High Drive Input, Inverting Delay 1.6 1.7 .19 2.0 2.5 3.0 4.5
t
ISU
Input Register Set-Up Time 3.1 3.1 3.1 3.1 3.1 3.1 3.1
t
IH
Input Register Hold Time 0.0 0.0 0.0 0.0 0.0 0.0 0.0
t
ICLK
Input Register Clock To Q 0.7 0.8 1.0 1.1 1.6 2.1 3.6
t
IRST
Input Register Reset Delay 0.6 0.7 0.9 1.0 1.5 2.0 3.5
t
IESU
Input Register Clock Enable Setup Time 2.3 2.3 2.3 2.3 2.3 2.3 2.3
t
IEH
Input Register Clock Enable Hold Time 0.0 0.0 0.0 0.0 0.0 0.0 0.0
Table 6: Clock Cells
Symbol Parameter
Propagation Delays (ns)
Fanout
a
a. The array dist ribu ted ne tw ork s co nsi st of 40 ha lf columns and the glo bal d is tribu ted networks con-
sist of 44 half columns, each driven by an independent buffer. The number of half columns used
does not affect clo ck buffer delay . The array c lock has up to eight loads per half column. The global
clock has up to 11 loads per half column.
1 2 3 4 8 10 11
t
ACK
Array Clock Delay 1.2 1.2 1.3 1.3 1.5 1.6 1.7
t
GCKP
Global Clock Pin Delay 0.7 0.7 0.7 0.7 0.7 0.7 0.7
t
GCKB
Global Clock Buffer Delay 0.8 0.8 0.9 0.9 1.1 1.2 1.3
© 2002 QuickLogic Corporati on
www.quicklogic.com
7
•
•
•
•
•
•
QL4036 QuickRAM Data Sheet Rev G
Figure 5: Loads used for t
PXZ
Table 7: I/O Cell Input Delays
Symbol Parameter
Propagation Delays (ns)
Fanout
a
a. Stated timing for worst case Propagation Delay over process variation at V
CC
= 3.3 V and
TA = 25
°C. Multiply by the appropriate Delay Factor, K, for speed gra de, voltage and tempe ratur e
settings as specified in the Operating Range.
1 2 3 4 8 10
t
I/O
Input Delay (bidirectional pad) 1.3 1.6 1.8 2.1 3.1 3.6
t
ISU
Input Register Set-Up Time 3.1 3.1 3.1 3.1 3.1 3.1
t
IH
Input Register Hold Time 0.0 0.0 0.0 0.0 0.0 0.0
t
IOCLK
Input Register Clock to Q 0.7 1.0 1.2 1.5 2.5 3.0
t
IORST
Input Register Reset Delay 0.6 0.9 1.1 1.4 2.4 2.9
t
IESU
Input Register Clock Enable Set-Up Time 2.3 2.3 2.3 2.3 2.3 2.3
t
IEH
Input Register Clock Enable Hold Time 0.0 0.0 0.0 0.0 0.0 0.0
Table 8: I/O Cell Output Delays
Symbol Parameter
Propagation Delays (ns)
Output Load Capacitance (pF)
3 50 75 100 150
t
OUTLH
Output Delay Low to High 2.1 2.5 3.1 3.6 4.7
t
OUTHL
Output Delay High to Low 2.2 2.6 3.2 3.7 4.8
t
PZH
Output Delay Tri-state to High 1.2 1.7 2.2 2.8 3.9
t
PZL
Output Delay Tri-state to Low 1.6 2.0 2.6 3.1 4.2
t
PHZ
Output Delay High to Tri-state
a
a. These loads are used for t
PXZ
(see Figure 5)
2.0 - - - -
t
PLZ
Output Delay High to Tri-state
a
1.2 - - - -
1ΚΩ
1ΚΩ
tPHZ
tPLZ
5 pF
5 pF
8
www.quicklogic.com
© 2002 QuickLogic Corporation
•
•
•
•
•
•
QL4036 QuickRAM Data Sheet Rev G
DC Characteristics
The DC specifications are provided in the tables below.
Table 9: Absolute Maximum Ratings
Parameter Value Parameter Value
VCC Voltage -0.5 V to 4.6 V DC Input Current ±20 mA
V
CCIO
Voltage -0.5 V to 7.0 V ESD Pad Protection ±2000 V
Input Voltage -0.5 V to V
CCIO
+0.5 V Storage Temperature -65°C to +150°C
Latch-up Immunity ±200 mA Lead Temperature 300°C
Table 10: Operating Range
Symbol Parameter Military Industrial Commercial Unit
Min Max Min Max Min Max
V
CC
Supply Voltage 3.0 3.6 3.0 3.6 3.0 3.6 V
V
CCIO
I/O Input Tolerance Voltage 3.0 5.5 3.0 5.5 3.0 5.25 V
TA Ambient Temperature -55 - -40 85 0 70 °C
TC Case Temperature - 125 - - - - °C
K Delay Factor
-0 Speed Grade 0.42 2.03 0.43 1.90 0.46 1.85 n/a
-1 Speed Grade 0.42 1.64 0.43 1.54 0.46 1.50 n/a
-2 Speed Grade 0.42 1.37 0.43 1.28 0.46 1.25 n/a
-3 Speed Grade 0.43 0.90 0.46 0.88 n/a
-4 Speed Grade 0.43 0.82 0.46 0.80 n/a
© 2002 QuickLogic Corporati on
www.quicklogic.com
9
•
•
•
•
•
•
QL4036 QuickRAM Data Sheet Rev G
Table 11: DC Characteristics
Symbol Parameter Conditions Min Max Units
VIH Input HIGH Voltage 0.5 VCCV
CCI
O + 0.5 V
VIL Input LOW Voltage -0.5 0.3 V
CC
V
VOH Output HIGH Voltage
IOH = -12 mA 2.4 V
IOH = -500 µA 0.9 V
CC
V
VOL Output LOW Voltage
IOL = 16 mA
a
a. Applies only to -1/-2/-3/-4 com mercial grade dev ices . These spee d gra des are also PCI-com plia nt. All
other devices have 8 mA IOL specifications.
0.45 V
IOL = 1.5 mA 0.1 V
CC
V
II I or I/O Input Leakage Current VI = V
CCIO
or GND -10 10 µA
IOZ 3-State Output Leakage Current VI = V
CCIO
or GND -10 10 µA
CI Input Capacitance
b
b. Capacitance is sample tested only. Clock pins are 12 pF maximum.
10 pF
IOS Output Short Circuit Current
c
c. Only one output at a time. Duration should not exceed 30 seconds.
VO = GND -15 -180 mA
VO = VCC 40 210 mA
ICC D.C. Supply Current
d
d. For -1/-2/-3/-4 commerc ial gra de d ev ic es onl y. Ma ximum ICC is 3 mA fo r -0 c om m erci al gra de a nd all
industrial grade device a nd 5 mA for all mili tary grad e devi ces. Fo r AC conditi ons, co ntact Q uickLog ic
customer applications group (see ).
VI, VIO = V
CCIO
or GND 0.50 (typ) 2 mA
ICCIO D.C. Supply Current on VCCIO 0 100 µA
10
www.quicklogic.com
© 2002 QuickLogic Corporation
•
•
•
•
•
•
QL4036 QuickRAM Data Sheet Rev G
Kv and Kt Graphs
Figure 6: Voltage Factor vs. Supply Voltage
Figure 7: Temperature Factor vs. Operating Temperature
0.9200
0.9400
0.9600
0.9800
1.0000
1.0200
1.0400
1.0600
1.0800
1.1000
3 3.1 3.2 3.3 3.4 3.5 3 .6
Voltage Factor vs. Supply Voltage
Supply Voltage (V)
Kv
0.85
0.90
0.95
1.00
1.05
1.10
1.15
-60 -40 -20 0 20 40 60 80
Temper ature Factor vs. Ope ra ting Te mpe ra tur e
Junction Tem per ature C
Kt
© 2002 QuickLogic Corporati on
www.quicklogic.com
11
•
•
•
•
•
•
QL4036 QuickRAM Data Sheet Rev G
Power-up Sequencing
Figure 8: Power-up Requirements
The following requirements must be met when powering up the device (refer to Figure 8):
• When ramping up the power supplies keep (VCCIO -VCC)
MAX
≤ 500 mV. Deviation
from this recommendation can cause permanent damage to the device.
• V
CCIO
must lead VCC when ramping the device.
• The power supply must take greater than or equal to 400 µs to reach VCC. Ramping
to V
CC/VCCIO
earlier than 400 µs can cause the device to behave improperly.
An internal diode is present in-between VCC and V
CCIO
, as shown in Figure 9.
Figure 9: Internal Diode Between VCC and VCCIO
Voltage
V
CCIO
V
CC
(V
CCIO
-VCC)
MAX
Time
400 us
V
CC
V
CC
V
CCIO
Internal Logic
Cells, RAM
blocks, etc
IO Cells
12
www.quicklogic.com
© 2002 QuickLogic Corporation
•
•
•
•
•
•
QL4036 QuickRAM Data Sheet Rev G
JTAG
Figure 10: JTAG Block Diagram
Microprocessors and Application Specific Integrated Circuits (ASICs) pose many design
challenges. One of these challenges concerns the accessibility of test points. The Joint Test
Access Group (JTAG) formed in response to this challenge, resulting in IEEE standard
1149.1, the Standard Test Access Port and Boundary Scan Architecture.
The JTAG boundary scan test methodology allows complete observation and control of the
boundary pins of a JTAG-compatible device through JTAG software. A Test Access Port
(TAP) controller works in concert with the Instruction Register (IR); these allow users to run
three required tests, along with several user-defined tests.
JTAG tests allow users to reduce system debug time, reuse test platforms and tools, and reuse
subsystem tests for fuller verification of higher level system elements.
TCK
TMS
TRSTB
RDI
TDO
Instruction Decode
&
Control Logic
TAp Controller
State Machine
(16 States)
Instruction Register
Boundary-Scan Register
(Data Register)
Mux
Bypass
Register
Mux
Internal
Register
I/O Registers
User Defined Data Register
© 2002 QuickLogic Corporati on
www.quicklogic.com
13
•
•
•
•
•
•
QL4036 QuickRAM Data Sheet Rev G
The JTAG 1149.1 standard requires the following three tests:
• Extest Instruction. The Extest instruction performs a PCB interconnect test. This test
places a device into an external boundary test mode, selecting the boundary scan
register to be connected between the TAP's Test Data In (TDI) and Test Data Out (TDO)
pins. Boundary scan cells are preloaded with test patterns (via the Sample/Preload
Instruction), and input boundary cells capture the input data for analysis.
• Sample/Preload Instruction. This instruction allows a device to remain in its
functional mode, while selecting the boundary scan register to be connected between
the TDI and TDO pins. For this test, the boundary scan register can be accessed via a
data scan operation, allowing users to sample the functional data entering and leaving
the device.
• Bypass Instruction. The Bypass instruction allows data to skip a device's boundary
scan entirely, so the data passes through the bypass register. The Bypass instruction
allows users to test a device without passing through other devices. The bypass register
connects the TDI and TDO pins, allowing serial data to be transferred through a device
without affecting the operation of the device.
14
www.quicklogic.com
© 2002 QuickLogic Corporation
•
•
•
•
•
•
QL4036 QuickRAM Data Sheet Rev G
Pin Descriptions
Ordering Information
Table 12: Pin Descriptions
Pin Function Description
TDI/RSI
Test Data In for JTAG /RAM init.
Serial Data In
Hold HIGH during normal operation. Connects to serial
PROM data in for RAM initialization. Connect to VCC if
unused.
TRSTB/RRO
Active low Reset for JTAG /RAM
init. reset out
Hold LOW during normal operation. Connects to serial
PROM reset for RAM initialization. Connect to GND if
unused.
TMS Test Mode Select for JTAG
Hold HIGH during normal operation. Connect to VCC if
not used for JTAG.
TCK Test Clock for JTAG
Hold HIGH or LOW during normal operation. Connect
to VCC or ground if not used for JTAG.
TDO/RCO
Test data out for JTAG /RAM init.
clock out
Connect to serial PROM clock for RAM initialization.
Must be left unconnected if not used for JTAG or RAM
initialization.
STM Special Test Mode Must be grounded during normal operation.
I/ACLK
High-drive input and/or array
network driver
Can be configured as either or both.
I/GCLK
High-drive input and/or global
network driver
Can be configured as either or both.
I High-drive input Use for input signals with high fanout.
I/O Input/Output pin Can be configured as an input and/or output.
V
CC
Power supply pin Connect to 3.3 V supply.
V
CCIO
Input voltage tolerance pin
Connect to 5.0 V supply if 5 V input tolerance is required,
otherwise connect to 3.3 V supply.
GND Ground pin Connect to ground.
GND/THERM Ground/Thermal pin
Available on 456-PBGA only. Connect to ground plane
on PCB if heat sinking desired. Otherwise may be left
unconnected.
QL 4036 - 1 PQ208 C
QuickLogic device
QuickRAM device
part number
Speed Grade
0 = Quick
1 = Fast
2 = Faster
3 = Faster
*4 = Wow
Operating Range
C = Commercial
I = Industrial
M = Military
Package Code
PF144 = 144-pin TQFP
CF208 = 208-pin CQFP
PQ208 = 208-pin PQFP
PB256 = 256-pin PBGA
* Contact QuickLogic regarding availabliity
© 2002 QuickLogic Corporati on
www.quicklogic.com
15
•
•
•
•
•
•
QL4036 QuickRAM Data Sheet Rev G
144 TQFP and 208 PQFP/CQFP Pinout Diagrams
Figure 11: Top View of 144 Pin TQFP
Figure 12: Top View of 208 Pin PQFP/CQFP
Pin 1
Pin 37 Pin 73
Pin 109
QL4036-1PF144C
QuickRAM
Pin 1
Pin 53
Pin 105
Pin 157
QL4036-1PQ208C
QuickRAM
16
www.quicklogic.com
© 2002 QuickLogic Corporation
•
•
•
•
•
•
QL4036 QuickRAM Data Sheet Rev G
144 TQFP and 208 PQFP/CQFP Pinout Table
Table 13: 144 TQFP and 208 PQFP/CQFP Pinout Table
208
PQFP
144
TQFP
Function
208
PQFP
144
TQFP
Function
208
PQFP
144
TQFP
Function
208
PQFP
144
TQFP
Function
208
PQFP
144
TQFP
Function
1NC
I/O
43 30
GND
85 60
I/O
127 87
GND
169 117
I/O
2 1
I/O
44 31
I/O
86 61
I/O
128 88
I/O
170 118
I/O
32
I/O
45 NC
I/O
87 NC
I/O
129 89
GCLK / I
171 119
I/O
4 3
I/O
46 32
I/O
88 62
I/O
130 90
ACLK / I
172 120
I/O
5NC
I/O
47 NC
I/O
89 63
I/O
131 91
VCC
173 NC
I/O
6 4
I/O
48 33
I/O
90 NC
I/O
132 92
GCLK / I
174 NC
I/O
75
I/O
49 NC
I/O
91 NC
I/O
133 93
GCLK / I
175 121
I/O
8 NC
I/O
50 34
I/O
92 64
I/O
134 94
VCC
176 NC
I/O
96
I/O
51 35
I/O
93 NC
I/O
135 95
I/O
177 122
GND
10 7
VCC
52 36
I/O
94 65
I/O
136 NC
I/O
178 123
I/O
11 NC
I/O
53 37
I/O
95 66
GND
137 96
I/O
179 124
I/O
12 NC
GND
54 38
TDI
96 67
I/O
138 NC
I/O
180 NC
I/O
13 8
I/O
55 39
I/O
97 NC
VCC
139 97
I/O
181 125
I/O
14 NC
I/O
56 NC
I/O
98 NC
I/O
140 98
I/O
182 126
GND
15 9
I/O
57 40
I/O
99 68
I/O
141 NC
I/O
183 127
I/O
16 NC
I/O
58 NC
I/O
100 69
I/O
142 99
I/O
184 128
I/O
17 10
I/O
59 NC
GND
101 NC
I/O
143 NC
I/O
185 129
I/O
18 11
I/O
60 41
I/O
102 70
I/O
144 100
I/O
186 NC
I/O
19 12
I/O
61 42
VCC
103 71
TRSTB
145 NC
VCC
187 130
VCCIO
20 13
I/O
62 43
I/O
104 72
TMS
146 101
I/O
188 131
I/O
21 NC
I/O
63 NC
I/O
105 NC
I/O
147 102
GND
189 132
I/O
22 14
I/O
64 44
I/O
106 73
I/O
148 103
I/O
190 NC
I/O
23 15
GND
65 45
I/O
107 NC
I/O
149 104
I/O
191 133
I/O
24 16
I/O
66 NC
I/O
108 74
I/O
150 NC
I/O
192 134
I/O
25 17
GCLK / I
67 46
I/O
109 75
I/O
151 105
I/O
193 NC
I/O
26 18
ACLK / I
68 47
I/O
110 76
I/O
152 106
I/O
194 135
I/O
27 19
VCC
69 48
I/O
111 77
I/O
153 NC
I/O
195 136
I/O
28 20
GCLK / I
70 NC
I/O
112 NC
I/O
154 107
I/O
196 NC
I/O
29 21
GCLK / I
71 49
I/O
113 78
I/O
155 NC
I/O
197 137
I/O
30 22
VCC
72 NC
I/O
114 79
VCC
156 108
I/O
198 NC
I/O
31 23
I/O
73 50
GND
115 80
I/O
157 109
TCK
199 138
GND
32 NC
I/O
74 51
I/O
116 NC
GND
158 110
STM
200 139
I/O
33 24
I/O
75 52
I/O
117 81
I/O
159 111
I/O
201 NC
VCC
34 NC
I/O
76 NC
I/O
118 82
I/O
160 NC
I/O
202 140
I/O
35 25
I/O
77 53
I/O
119 NC
I/O
161 112
I/O
203 NC
I/O
36 NC
I/O
78 54
GND
120 83
I/O
162 113
I/O
204 141
I/O
37 26
I/O
79 55
I/O
121 NC
I/O
163 NC
GND
205 142
I/O
38 27
I/O
80 56
I/O
122 84
I/O
164 NC
I/O
206 NC
I/O
39 28
I/O
81 NC
I/O
123 85
I/O
165 114
VCC
207 143
TDO
40 NC
I/O
82 57
I/O
124 NC
I/O
166 115
I/O
208 144
I/O
41 NC
VCC
83 58
VCCIO
125 86
I/O
167 116
I/O
42 29
I/O
84 59
I/O
126 NC
I/O
168 NC
I/O
© 2002 QuickLogic Corporati on
www.quicklogic.com
17
•
•
•
•
•
•
QL4036 QuickRAM Data Sheet Rev G
256 PBGA Pinout Diagram
Figure 13: 256 PBGA Pinout Diagram
QL4036-1PB256C
QuickRAM
BOTTOM View
TOP View
PIN A1
CORNER
19 17 15 13 11 9 7 5 3 1
20 18 16 14 12 10 8 6 4 2
18
www.quicklogic.com
© 2002 QuickLogic Corporation
•
•
•
•
•
•
QL4036 QuickRAM Data Sheet Rev G
256 PBGA Pinout Table
Table 14: 256 PBGA Pinout Table
256
PBGA
Function
256
PBGA
Function
256
PBGA
Function
256
PBGA
Function
256
PBGA
Function
256
PBGA
Function
A1
VSS
C4
I/O
E19
I/O
L2
ACLK / I
T17
I/O
V20
I/O
A2
I/O
C5
I/O
E20
I/O
L3
GCLK / I
T18
I/O
W1
I/O
A3
I/O
C6
I/O
F1
I/O
L4
GCLK / I
T19
NC
W2
I/O
A4
I/O
C7
I/O
F2
I/O
L17
VCC
T20
I/O
W3
TDI
A5
I/O
C8
I/O
F3
I/O
L18
I/O
U1
I/O
W4
I/O
A6
I/O
C9
VCCIO
F4
VCC
L19
I/O
U2
I/O
W5
I/O
A7
I/O
C10
I/O
F17
VCC
L20
I/O
U3
I/O
W6
I/O
A8
I/O
C11
I/O
F18
NC
M1
I/O
U4
VSS
W7
I/O
A9
I/O
C12
I/O
F19
I/O
M2
I/O
U5
I/O
W8
I/O
A10
I/O
C13
I/O
F20
I/O
M3
I/O
U6
VCC
W9
I/O
A11
I/O
C14
I/O
G1
I/O
M4
NC
U7
I/O
W10
I/O
A12
I/O
C15
I/O
G2
NC
M17
NC
U8
VSS
W11
I/O
A13
I/O
C16
I/O
G3
I/O
M18
I/O
U9
I/O
W12
I/O
A14
I/O
C17
I/O
G4
I/O
M19
I/O
U10
VCC
W13
I/O
A15
I/O
C18
I/O
G17
I/O
M20
I/O
U11
I/O
W14
I/O
A16
I/O
C19
I/O
G18
I/O
N1
I/O
U12
I/O
W15
I/O
A17
I/O
C20
I/O
G19
NC
N2
I/O
U13
VSS
W16
I/O
A18
I/O
D1
I/O
G20
I/O
N3
I/O
U14
I/O
W17
I/O
A19
TCK
D2
I/O
H1
I/O
N4
VSS
U15
VCC
W18
I/O
A20
I/O
D3
I/O
H2
I/O
N17
VSS
U16
I/O
W19
I/O
B1
TDO
D4
VSS
H3
I/O
N18
I/O
U17
VSS
W20
TRSTB
B2
I/O
D5
I/O
H4
VSS
N19
I/O
U18
I/O
Y1
I/O
B3
I/O
D6
VCC
H17
VSS
N20
I/O
U19
I/O
Y2
NC
B4
I/O
D7
I/O
H18
I/O
P1
I/O
U20
I/O
Y3
I/O
B5
I/O
D8
VSS
H19
I/O
P2
I/O
V1
I/O
Y4
I/O
B6
I/O
D9
I/O
H20
I/O
P3
I/O
V2
NC
Y5
I/O
B7
I/O
D10
I/O
J1
I/O
P4
I/O
V3
I/O
Y6
I/O
B8
I/O
D11
VCC
J2
I/O
P17
I/O
V4
I/O
Y7
I/O
B9
I/O
D12
I/O
J3
NC
P18
I/O
V5
I/O
Y8
I/O
B10
I/O
D13
VSS
J4
I/O
P19
NC
V6
I/O
Y9
I/O
B11
I/O
D14
I/O
J17
NC
P20
I/O
V7
I/O
Y10
I/O
B12
I/O
D15
VCC
J18
I/O
R1
NC
V8
I/O
Y11
I/O
B13
I/O
D16
I/O
J19
I/O
R2
I/O
V9
I/O
Y12
I/O
B14
I/O
D17
VSS
J20
GCLK / I
R3
I/O
V10
I/O
Y13
I/O
B15
I/O
D18
I/O
K1
I/O
R4
VCC
V11
I/O
Y14
I/O
B16
I/O
D19
I/O
K2
I/O
R17
VCC
V12
VCCIO
Y15
I/O
B17
NC
D20
I/O
K3
I/O
R18
I/O
V13
I/O
Y16
I/O
B18
STM
E1
NC
K4
VCC
R19
I/O
V14
I/O
Y17
I/O
B19
NC
E2
I/O
K17
GCLK / I
R20
I/O
V15
I/O
Y18
I/O
B20
I/O
E3
I/O
K18
ACLK / I
T1
NC
V16
I/O
Y19
I/O
C1
I/O
E4
I/O
K19
GCLK / I
T2
I/O
V17
I/O
Y20
NC
C2
I/O
E17
I/O
K20
NC
T3
I/O
V18
I/O
C3
I/O
E18
I/O
L1
GCLK / I
T4
NC
V19
TMS
© 2002 QuickLogic Corporati on
www.quicklogic.com
19
•
•
•
•
•
•
QL4036 QuickRAM Data Sheet Rev G
Contact Information
Telephone:408 990 4000 (US)
416 497 8884 (Canada)
44 1932 57 9011 (Europe)
49 89 930 86 170 (Germany)
852 8106 9091 (Asia)
81 45 470 5525 (Japan)
E-mail: info@quicklogic.com
Support:support@quicklogic.com
Web site:http://www.quicklogic.com/
Revision History
Copyright Information
Copyright © 2002 QuickLogic Corporation. All Rights Reserved.
The information contained in this product brief, and the accompanying software programs are protected by copyright. All rights are reserved by QuickLogic Corporation. QuickLogic Corporation
reserves the right to make periodic modifications of this product without obligation to notify any person or entity of such revision. Copying, duplicating, selling, or otherwise distributing any part of this
product without the prior written consent of an authorized representative of QuickLogic is prohibited.
QuickLogic, pASIC, and ViaLink are registered trademarks, and SpDE and QuickWork s are trademarks of QuickLogic Corporation.
Verilog is a registered trademark of Cadence Design Systems, Inc.
Table 15: Revision History
Revision Date Comments
A not avail. First release.
B not avail.
C not avail.
D not avail.
E not avail.
F May 2000 Update of AC/DC Specs and reformat
G May 2002
Added Kfactor, Power-up, JTAG and mechanical
drawing information. Reformatted.
Loading...
