A Guide to QuarkXPress
Server 9.0
CONTENTS
Contents
About this Guide...............................................................................5
What we're assuming about you............................................................................5
Where to go for help..............................................................................................5
Conventions............................................................................................................6
Getting started with QuarkXPress Server........................................7
QuarkXPress Server architecture...........................................................................7
Understanding QuarkXPress Server.......................................................................8
Server templates and static projects...............................................................................8
The document pool.........................................................................................................9
Projects and layouts........................................................................................................9
Job Jackets and resources..............................................................................................9
Caching.........................................................................................................................10
QuarkXPress Server preferences...................................................................................10
Quark License Administrator.........................................................................................11
Master-renderer environment.......................................................................................11
Changing logging levels in "log4j.xml"........................................................................11
Understanding QuarkXPress Server XTensions software.....................................12
The QuarkXPress Server XTensions API........................................................................12
Configuring QuarkXPress Server for launch.........................................................13
Launching QuarkXPress Server.............................................................................14
Quitting QuarkXPress Server...............................................................................14
The QuarkXPress Server user interface..........................................15
Navigation pane....................................................................................................15
Administration menu.............................................................................................17
General Preferences dialog box....................................................................................17
Renderer Preferences dialog box..................................................................................20
Job Jackets dialog box.................................................................................................28
Check Out License dialog box......................................................................................28
Creating URL requests....................................................................29
Understanding URL requests................................................................................29
Understanding QuarkXPress Server namespaces.................................................30
Looking up a namespace..............................................................................................30
ii | A GUIDE TO QUARKXPRESS SERVER 9.0
CONTENTS
Understanding QuarkXPress Server parameters..................................................31
Looking up a parameter................................................................................................31
QuarkXPress Server Web Integration Guide overview........................................31
Render types.................................................................................................................31
General parameters.......................................................................................................31
Specialized parameters.................................................................................................32
Server control parameters.............................................................................................32
Document providers......................................................................................................32
Modifying layouts with XML...........................................................33
Using SSL.........................................................................................34
Secure Sockets Layer (SSL) support......................................................................34
Enabling SSL..................................................................................................................34
Enabling HTTP and HTTPS............................................................................................35
Verifying and using SSL.................................................................................................35
Keystores and SSL certificates.......................................................................................35
QuarkXPress Server XTensions software.......................................37
CopyDeskArticle XTensions software...................................................................37
Rendering articles..........................................................................................................37
Exporting articles...........................................................................................................37
Adding articles to projects............................................................................................38
Creating and deleting components..............................................................................38
PDF Filter XTensions software.............................................................................39
Modifier XTensions software................................................................................39
Using Modifier XTensions software...............................................................................40
Creating XML for Modifier XTensions software............................................................41
Layer XTensions software.....................................................................................41
InteractiveDesignerSXT Server XTensions software............................................41
Telegraph XTensions software........................................................43
Setting Telegraph preferences.............................................................................43
Specifying a server for template upload.......................................................................44
Using Telegraph XTensions software...................................................................46
Identifying QuarkXPress items and groups...................................................................46
Naming items and groups.............................................................................................46
Uploading templates.....................................................................................................47
Uploading missing or modified pictures.......................................................................49
QuarkXPress Server Manager.........................................................50
A GUIDE TO QUARKXPRESS SERVER 9.0 | iii
CONTENTS
Understanding QuarkXPress Server Manager......................................................50
Load balancing..............................................................................................................50
Request timeout interval...............................................................................................51
Determining QuarkXPress Server instance availability..................................................52
Logging.........................................................................................................................52
Caching.........................................................................................................................53
Web services.................................................................................................................53
Working with QuarkXPress Server Manager........................................................53
Starting QuarkXPress Server Manager..........................................................................54
Request handler binding...............................................................................................56
Configuring QuarkXPress Server instances...................................................................56
Managing the cache......................................................................................................61
Managing logs...............................................................................................................63
Controlling load balancing............................................................................................66
Using a proxy server......................................................................................................67
Generating automatic e-mail messages........................................................................68
Using other global settings...........................................................................................69
Saving a server configuration........................................................................................71
Exporting a server configuration...................................................................................71
Using custom error messages.......................................................................................71
Sending requests from a browser.................................................................................73
Glossary..........................................................................................75
Legal notices...................................................................................76
iv | A GUIDE TO QUARKXPRESS SERVER 9.0
About this Guide
You do not need to read this guide from cover to cover. Instead, use this guide to quickly
look up information, find out what you need to know, and proceed with your work. Use
the detailed table of contents at the beginning of the guide to find information quickly.
What we're assuming about you
In writing this guide, we assume that you are familiar with your computer and know how
to:
ABOUT THIS GUIDE
• Launch an application
• Open, save, and close files
• Use menus, dialog boxes, and palettes
• Work within a networked computing environment
• Use the mouse, keyboard commands, and modifier keys
Consult the documentation provided with your computer or other resources if you need
more information in any of these areas.
Where to go for help
If you're new to QuarkXPress® Server, or if you want to explore one of its other longstanding
features, consult the following resources:
• A Guide to QuarkXPress Server
• The QuarkXPress Server Web Integration Guide
• Third-party books
• General books about desktop publishing
If your issues are at the system level — saving files, moving files, activating fonts, for
example — consult the documentation resources provided with your computer.
A GUIDE TO QUARKXPRESS SERVER 9.0 | 5
ABOUT THIS GUIDE
Conventions
Formatting conventions highlight information to help you quickly find what you need.
• Bold type style: The names of all dialog boxes, fields, and other controls are set in bold
type. For example: "Click OK."
• References: In descriptions of features, parenthetical references guide you in accessing
those features. For example: "The Find/Change dialog box (Edit menu) lets you find and
replace text."
• Arrows: You will often see arrows (>), which map out the menu path to a feature. For
example: "Choose Edit > Style Sheets to display the Style Sheets dialog box."
• Icons: Although many tools and buttons are referenced by name, which you can see by
displaying ToolTips, in some cases icons are shown for easy identification. For example,
"Click the button on the Measurements palette to center text."
• Cross-platform issues: This application is quite consistent across operating systems. However,
some labels, buttons, key combinations, and other aspects of the application must differ
between Mac OS® and Windows® because of user interface conventions or other factors.
In such cases, both the Mac OS and Windows versions are presented, separated by a slash,
with the Mac OS version presented first. For example, if the Mac OS version of a button
is labeled Select, and the Windows version is labeled Browse, you are directed to "Click
Select/Browse." More complex cross-platform differences are mentioned in notes or
parenthetical statements.
6 | A GUIDE TO QUARKXPRESS SERVER 9.0
Getting started with QuarkXPress Server
QuarkXPress Server lets you render QuarkXPress projects in a variety of formats.
QuarkXPress Server architecture
GETTING STARTED WITH QUARKXPRESS SERVER
The QuarkXPress Server architecture is shown in the following diagram.
QuarkXPress Server architecture diagram
A GUIDE TO QUARKXPRESS SERVER 9.0 | 7
GETTING STARTED WITH QUARKXPRESS SERVER
Understanding QuarkXPress Server
QuarkXPress Server lets you output customized QuarkXPress layouts in a variety of formats
— including JPEG, Portable Document Format (PDF), and PostScript® — from a centralized
QuarkXPress Server application. To send a request to a QuarkXPress Server application, all
you need to do is enter a URL into your Web browser's address field. For example, the
following URL instructs the QuarkXPress Server application named "QXPServer" to return
the file "MyProject.qxp" as a PDF file:
http://QXPServer:8080/pdf/MyProject.qxp
The QuarkXPress Server application receives these requests, renders (creates) the requested
projects in the requested formats, and then returns the rendered file to the client application
(in this case, the Web browser).
The format of QuarkXPress Server URL requests is described in detail in "Creating URL
requests" and in the QuarkXPress Server Web Integration Guide.
You can also create custom applications that communicate with a QuarkXPress Server
application using HTTP, Simple Object Access Protocol (SOAP), or another protocol. For
more information, see the QuarkXPress Server Web Integration Guide.
You can think of QuarkXPress Server as a special version of QuarkXPress that runs on a
server with the following main differences:
• Instead of accepting input from a keyboard and mouse, QuarkXPress Server accepts input
in the form of URLs and other types of requests.
• Instead of sending a project to a printer, QuarkXPress Server renders (creates) output in a
particular format and sends the rendered file to a client.
Server templates and static projects
QuarkXPress Server can open, render, and serve two types of projects:
• Static projects are QuarkXPress projects that can be rendered and served as-is in a variety
of formats by the QuarkXPress Server application. For example, you might make a product
manual available as a static project and allow customers to download that manual in a
variety of formats.
• Server templates are QuarkXPress projects that can be manipulated by the QuarkXPress Server
application before being rendered and served. For example, you might make a sales piece
available as a server template so that each person who downloads it receives a personalized
copy.
QuarkXPress Server can open QuarkXPress documents, projects, and templates created in
any language edition of QuarkXPress 5.0 or later. QuarkXPress Server can save and export
projects in QuarkXPress 8.x and QuarkXPress 9.x format.
8 | A GUIDE TO QUARKXPRESS SERVER 9.0
GETTING STARTED WITH QUARKXPRESS SERVER
The document pool
QuarkXPress Server reads server templates and static projects from a directory called the
document pool. The document pool can be any directory that is available to
QuarkXPress Server through a file system or an FTP server. You can use any of the following
methods to place files in the document pool:
• Drag the files to the document pool directory.
• Use the Add Files command in the Document Pool screen of the QuarkXPress Server Web
interface.
• Upload the files using FTP to the document pool directory.
• Use Telegraph XTensions® software to upload the files to the document pool from within
QuarkXPress. (For more information about Telegraph XTensions software, see "Telegraph
XTensions software.")
For more information about the document pool, see "The QuarkXPress Server user interface."
QuarkXPress Server can also serve documents from a database, a content management
system, or other sources. Collectively, the document pool and any other source of files to
be served are referred to as document providers.
Projects and layouts
QuarkXPress projects can contain one or more layouts, and only one layout can be rendered
at any given time. If you do not specify a layout when you send a rendering request,
QuarkXPress Server renders the first layout in the project.
Job Jackets and resources
In QuarkXPress, resources are things such as style sheets, colors, H&Js, output styles, and
item styles. Resources are stored in a Job Jackets structure, which can be either embedded
in a project or stored in a separate Job Jackets file.
QuarkXPress Server uses a default Job Jackets file to make a default set of resources available
to all projects handled by QuarkXPress Server, regardless of whether they are included in
the projects and articles you render. You can update this file in two ways:
• Using the QuarkXPress Server Web interface. For more information, see "Job Jackets dialog
box."
•
Using request handlers. For more information, see jobjacket and updateprefsfromjj
the QuarkXPress Server Web Integration Guide.
Once you've downloaded the default Job Jackets file, you can update its resources using
QuarkXPress. For more information, see "Job Jackets" in A Guide to QuarkXPress.
The location of the default Job Jackets file is stored in the QuarkXPress Server preferences
folder. For more information, see "QuarkXPress Server preferences."
A GUIDE TO QUARKXPRESS SERVER 9.0 | 9
GETTING STARTED WITH QUARKXPRESS SERVER
Caching
To maximize efficiency, QuarkXPress Server uses cached versions of all rendered projects
whenever possible. You can configure projects so that they are never cached, so that they
are cached for a particular amount of time, or so that they are rendered every time they
are served.
QuarkXPress Server preferences
When you launch QuarkXPress Server, the application creates preferences files that are
functionally and structurally equivalent to the preferences files created by QuarkXPress.
These preferences files reside in the QuarkXPress Server "Preferences" folder.
QuarkXPress Server also creates a "QuarkXPress Server.prf" file in the "Preferences" folder.
This file contains preference settings that are specific to QuarkXPress Server.
QuarkXPress Server uses these preferences the same way QuarkXPress uses them. If an
XTensions module creates a project in QuarkXPress Server, that project draws its settings
from the QuarkXPress Server preferences just as a new QuarkXPress project draws its settings
from the QuarkXPress preferences.
Preferences files are stored in the following locations:
•
Mac OS: [User]/Library/Preferences/Quark/QuarkXPress Server Renderer
9/
• Windows 2003 and Windows XP when running normally or under a domain user:
C:\Documents and Settings\[user name]\Application Data\Quark\QuarkXPress
Server Renderer 9
• Windows 2003 and Windows XP when running as a service under a local user:
C:\Documents and Settings\Default User\Application
Data\Quark\QuarkXPress Server Renderer 9\
• Windows 2008, when QuarkXPress Server is running as a service under the "local system
user" account: C:\ProgramData\Quark\QuarkXPress Server Renderer 9\
• Windows Vista, when QuarkXPress Server is running as a service under the "local system
user" account: C:\Windows\System32\config\systemprofile\AppData\Roaming\
• Windows 2008 and Windows Vista, when QuarkXPress Server is running normally under
the "Domain user" account: C:\Users\[user
name]\AppData\Roaming\Quark\QuarkXPress Server Renderer 9\
• Windows 2008 and Windows Vista, when QuarkXPress Server is running as a service under
the "Domain user" account:
C:\Windows\System32\config\systemprofile\AppData\Roaming\Quark\QuarkXPress
Server Renderer 9\
For more information about preferences, see "Administration menu."
10 | A GUIDE TO QUARKXPRESS SERVER 9.0
GETTING STARTED WITH QUARKXPRESS SERVER
Quark License Administrator
To prevent unauthorized use, QuarkXPress Server requires the presence of a Quark® License
Administrator (QLA) server to launch. QuarkXPress Server follows the configuration and
control rules that are enforced by QLA. For more information about QLA, see the QLA
documentation included with QuarkXPress Server.
Master-renderer environment
Requests for project renders are stored in a connection queue. The requests in the rendering
queue can be processed by a single QuarkXPress Server application, or by a master
QuarkXPress Server application and several renderers (additional instances of
QuarkXPress Server). The master QuarkXPress Server application launches the available
number of renderers and then passes the requests in the connection queue to those
renderers as they become available. The number of renderers available for launch is
determined by the number of licenses available from the QLA server.
The master QuarkXPress Server process and all of the renderers it launches share the
following elements:
• The same application preferences (each renderer has its own preferences files, but
QuarkXPress Server keeps them synchronized)
• The same document cache in memory
• The same memory cache
• The same server XTensions modules (a separate instance of each XTensions module runs
with each renderer)
• The same server document pool (if defined in the QuarkXPress Server preferences or if a
document provider is used in place of the document pool)
If a renderer unexpectedly quits, the master QuarkXPress Server restarts the renderer
without requiring any action from you.
Changing logging levels in "log4j.xml"
You can change the logging levels for QuarkXPress Server. Options include ERROR, INFO,
WARN, DEBUG, and TRACE.
•
ERROR = includes messages that indicate disrupted and failed requests.
•
INFO = includes messages that indicate the state of services.
•
WARN = includes non-critical service error messages
•
DEBUG = includes messages that indicate server resource usage.
•
TRACE = includes messages according to activity related to requests.
Refer to Java documentation for more information about logging levels.
To change logging levels:
A GUIDE TO QUARKXPRESS SERVER 9.0 | 11
GETTING STARTED WITH QUARKXPRESS SERVER
Open the "conf" folder in your QuarkXPress Server folder.
1
Open "log4j.xml" in a text-editing application.
2
To define the logging level for QuarkXPerss Server errors, scroll to <logger
3
name=com.quark.qxps. The structure is as follows:
<logger name="com.quark.qxps">
<level value="ERROR" />
</logger>
To define the logging level for QuarkXPress Server transactions, scroll to <logger
4
name=QXPSTransactionLogger. The structure is as follows:
<logger name="com.quark.qxps" additivity="false">
<level value="INFO" />
<appender-ref ref="QxpsTransactionFileAppender" />
</logger>
To define the logging level for other activity, scroll to the <root>. The structure is as
5
follows:
<root>
<priority value="ERROR" />
<appender-ref ref="QxpsServerAsyncAppender" />
</root>
Save and close "log4j.xml."
6
Understanding QuarkXPress Server XTensions software
QuarkXPress Server ships with a collection of XTensions software that adds capabilities to
QuarkXPress Server. For example, PDF Export XTensions software lets QuarkXPress Server
serve content in PDF format; Modifier XTensions software lets you retrieve, manipulate,
and reconstruct XML representations of projects; and QuarkCopyDesk® Renderer XTensions
software lets you create QuarkCopyDesk articles. Telegraph XTensions software works with
QuarkXPress to allow designers to name boxes in template files so that those boxes can
be addressed by URLs.
For more information about XTensions software included with QuarkXPress Server, see
"QuarkXPress Server XTensions software" and "Telegraph XTensions software."
The QuarkXPress Server XTensions API
In addition to the XTensions modules included with QuarkXPress Server, developers can
create custom XTensions software that add features. The complete server XTensions
Application Programming Interface (API) documentation is available in the
QuarkXPress Server XTensions Developer's Kit (XDK).
As of version 8.0, the QuarkXPress Server XDK is Unicode-compliant.
The QuarkXPress Server XDK lets you create XTensions modules that provide the following
abilities:
• The ability to register request handlers
12 | A GUIDE TO QUARKXPRESS SERVER 9.0
GETTING STARTED WITH QUARKXPRESS SERVER
• The ability to register project providers
• The ability to register new render formats
• The ability to add items to the list of response properties, cookies, and HTTP header items
• The ability to log messages in log files
• The ability to initiate a new transaction to be processed by the server
• The ability to completely control how projects are processed by the server
In addition, QuarkXPress Server XTensions software can register for the following basic
callbacks:
• Pre-processing
• Content loading
• Layout modification
• Post-processing
• Removing slugs while running the QuarkXPress project renderer
• Analyzing the server after a transaction is complete
• Pre- and post-transaction callback
Configuring QuarkXPress Server for launch
To configure QuarkXPress Server prior to launch, open the file [QuarkXPress Server
application folder]/conf/ServerApp.properties folder) and modify it as follows:
•
To make the server run without loading any network interface, use the -nonetwork option
with the qxpservercore.serverRendererParameters. In this mode, the only
transactions a server can run are those passed to it by another process.
• To control whether renderers are monitored, set
qxpservercore.monitorrenderers.value to true or false.
• To specify the query interval for monitoring renderers, set
qxpservercore.monitorrenderers.queryinterval.value to a value in seconds.
• To specify the number of retries for monitoring renderers, set
qqxpservercore.monitorrenderers.noofretries.value to an integer. If a renderer
process has been attempting to fulfill a request for the specified number of retries (with
the specified query interval in seconds between retries), the renderer monitor recyles that
process.
• To control how many renderers the master process launches, specify a number for
qxpserver.subrenders. Note that the number of renderers you can launch depends on
your license.
A GUIDE TO QUARKXPRESS SERVER 9.0 | 13
GETTING STARTED WITH QUARKXPRESS SERVER
Launching QuarkXPress Server
On Windows, you can install QuarkXPress Server as an application or as a service (Quark
recommends that you always run it as a service). On Mac OS, QuarkXPress Server always
runs as an application.
If you install QuarkXPress Server on Windows as an application, you can launch it using
the Start menu or by double-clicking the "ServerStartup.bat" in the QuarkXPress Server
application folder.
If you want to launch QuarkXPress Server as an application on Windows Server 2008,
Windows Vista, and Windows 7, Quark recommends executing "ServerStartup.bat" as an
administrator.
For information on launching QuarkXPress Server in a separate Tomcat installation, see
"Deploying QuarkXPress Server externally" in the QuarkXPress Server ReadMe.
QuarkXPress Server offers a browser-based user interface instead of a conventional user
interface.
Quitting QuarkXPress Server
To quit QuarkXPress Server on Mac OS, press Control+C.
To quit QuarkXPress Server on Windows, press Control+C or double-click the
"shutdown.bat" file in the QuarkXPress Server application folder.
14 | A GUIDE TO QUARKXPRESS SERVER 9.0
THE QUARKXPRESS SERVER USER INTERFACE
The QuarkXPress Server user interface
QuarkXPress Server offers a browser-based user interface instead of a conventional user
interface. This chapter describes that interface and explains how you can use it to configure
and customize your QuarkXPress Server application and manage your server XTensions
modules.
To view the QuarkXPress Server User Interface, launch a Web browser and enter the URL
http://[server]:[port]/qxpsadmin (where [server] is the IP address or domain
name of the server and [port] is the TCP/IP port on which the server is running). If the
server has realm verification enabled, you will be asked to enter your user name and
password.
Navigation pane
The navigation pane on the left side of the has two areas. The Server Information area
lets you view server information and the transaction log, and the Document Pool area
lets you view the contents of the document pool. You can collapse and expand this pane
with the button at the right end of the Navigation Pane header.
If you click Server Information, the Status Monitor screen displays. The fields in the top
area provide information about the server. The icons in the area below represent the
renderers that are currently running and show which requests are being processed by each
renderer in real time. This screen also shows how many active and idle renderers there
are.
A GUIDE TO QUARKXPRESS SERVER 9.0 | 15
THE QUARKXPRESS SERVER USER INTERFACE
Status Monitor screen
If you click Transaction Log, the Logs screen displays the current transaction log. To
download the active log, including recent crash reports, click Download Logs at the top
of the Logs header.
If you click Show XTensions Information, the XTensions Information screen displays,
allowing yout o view the status of all installed XTensions modules.
If you click Document Pool, the document pool screen displays.
Document Pool screen
To add a file, click Add Files in the header. If you add multiple files at one time, you can
create a folder to put them all into by entering the folder name in the Folder film.
16 | A GUIDE TO QUARKXPRESS SERVER 9.0
THE QUARKXPRESS SERVER USER INTERFACE
Document Pool screen
To delete a file, check its box and then click Delete Files.
To search for a file or folder, use the search field in the header.
To preview a file, Control+click/right-click the file and choose Preview.
To get a file's relative path, double-click the file name.
Administration menu
The administration menu lets you manage QuarkXPress Server.
You do not have to restart the server in GUI mode to set preferences.
General Preferences dialog box
The General Preferences dialog box (Administration > Preferences > General) lets you
set preferences that are not related to rendering. It includes the tabs described in the
following topics.
You can also set general preferences using the setprefs request handler. For more
information, see the QuarkXPress Server Web Integration Guide.
General Preferences — Server
The Server tab (Administration > Preferences > General > Server) includes the following
controls.
Use the Document Root Folder field to specify the location of the document pool.
Putting the document pool on a network connected drive is not recommended, because
this negatively impacts the performance of QuarkXPress Server.
Use the Allow Memory Caching check box to control whether memory is cached.
A GUIDE TO QUARKXPRESS SERVER 9.0 | 17
THE QUARKXPRESS SERVER USER INTERFACE
Use the Max Memory Cache Size field to specify the maximum memory size allocated
to the cache memory. Valid values are from 10MB to 1024MB.
Use the Force Served Documents Closed check box to control whether QuarkXPress Server
closes projects from the document pool after it renders them, regardless of the Telegraph
XTensions software setting. Uncheck this box to keep such projects open on the server.
Use the Default Renderer Type drop-down menu to specify the default rendering format
for the server.
• EPS Document: Returns an Encapsulated PostScript (EPS) file.
• JPEG: Returns a JPEG file.
• PDF: Returns a PDF file.
• PNG: Returns a Portable Network Graphics (PNG) file.
• PostScript: Returns a PostScript file.
• QCDDOC: Returns a QuarkCopyDesk article.
• QuarkXPress Document: Returns a QuarkXPress project.
• Raw Custom: Returns a file in internal QuarkXPress format for use by server XTensions
software developers.
• RLE Raw Custom: Returns a file in internal QuarkXPress format (compressed using Run
Length Encoding) for use by server XTensions software developers.
• SWF: Returns a SWF (Flash) file.
Use the Scale field to specify the default scale percentage at which QuarkXPress Server
should render projects.
Use the Disable QXD Return check box to specify whether QuarkXPress Server can return
QuarkXPress projects to clients.
General Preferences — Log
The Log tab (Administration > Preferences > General > Log) includes the following
controls.
Use the Log Document Problems check box to specify whether to include problem
descriptions in transaction log files. The "Log" folder inside the QuarkXPress Server
application folder contains three log files:
• QuarkXPress Server Fatal Log.log: This log lists all fatal errors.
• QuarkXPress Server Log.log: The log for the Java process. This log contains source
code-level logging information that can be useful in troubleshooting.
• QuarkXPress Server Transaction Log.log: This log lists all transactions and all errors.
Detailed application logging is enabled for these log files only if it is enabled in the
"log4j.xml" file.
18 | A GUIDE TO QUARKXPRESS SERVER 9.0
THE QUARKXPRESS SERVER USER INTERFACE
To log detailed transaction timing data, check Log Timing Data.
Logged problems include the following:
• Missing Fonts: If fonts are missing from a project that has been requested for rendering,
a one-line description of each missing font is added to the error log. If QuarkXPress Server
receives a request to render a project and does not have access to the fonts required by the
project, it uses the fonts specified in the Fonts tab of the Preferences dialog box
(Administration > Preferences > General). If these fonts are also unavailable,
QuarkXPress Server substitutes Helvetica (Mac OS) or Arial (Windows). This behavior is
the same as it is in QuarkXPress.
• Missing Pictures
• Missing SXTs: If a required server XTensions module is missing when a rendering request
is received, a one-line description of each missing module is added to the error log. If the
name of the missing module is not returnable, the XTensions module ID number is
returned.
• Text Encoding/Character Set Problems: If text is sent to a text box in the template and
the system does not have access to the correct font glyph, the issue is logged. The log data
indicates the character set that the system attempted to convert. For example, the log
entry might show that a request for Japanese characters was sent to an English project.
Information about missing fonts and missing pictures is also recorded in the
"QuarkXPressServerRenderer.log" file. This file also contains detailed timing information,
including the transaction UID for each transaction. This log file can be found here:
•
Mac OS: [drive]/Users/[user name]/Library/Logs/Quark
•
Windows: C:\Users\talyn\AppData\Quark\Log
To download all logs to a non-server computer, click Show Transaction Log in the
QuarkXPress Server Web interface, then click Download Logs on the upper right.
General Preferences — Email
QuarkXPress Server can automatically notify someone by e-mail when the checked-out
QLA license is about to expire. The Email tab (Administration > Preferences > General
> Email) lets you specify where such e-mail messages should be sent.
Use the Server field to specify the domain name or IP address of the e-mail server that
QuarkXPress Server should use to send messages (for example, mail.quark.com).
Use the Port field to specify the port number of the e-mail server that QuarkXPress Server
should use to send messages. Valid values are from 0 to 255.
Use the From to specify the source e-mail address the QuarkXPress Server application
should use to send messages (for example, QXPSserver1@quark.com).
Use the To to specify the e-mail address to which the QuarkXPress Server application
should send messages (for example, QXPServerAdmin@quark.com).
A GUIDE TO QUARKXPRESS SERVER 9.0 | 19
THE QUARKXPRESS SERVER USER INTERFACE
General Preferences — Authentication
The Authentication tab (Administration > Preferences > General > Authentication)
includes the following controls.
Check Authenticate For Admin Requests to enable the Username and Password fields.
These fields let you control access to administrative parameters and features. You can enter
up to 32 characters.
Renderer Preferences dialog box
Use the renderer Preferences dialog box (Administration > Preferences > Renderer) to
set up default preferences for use when projects are created in QuarkXPress Server. It
includes the tabs described in the following topics.
Many of these preferences come into play only when you create a project in QuarkXPress
Server, either using a construct request or through a request handled by a custom
QuarkXPress Server XTensions module.
You can also set renderer preferences using the setrendererprefs request handler. For
more information, see the QuarkXPress Server Web Integration Guide.
In versions of QuarkXPress Server prior to 9.0, these resources were accessed through the
Document Controls submenu.
Preferences — Display
The Display pane (Administration > Preferences > Renderer > Display) includes the
following controls.
Use the Color TIFFs drop-down list to specify the color depth of screen previews created
for color TIFFs when they are imported.
Use the Gray TIFFs drop-down list to specify the resolution of screen previews created for
grayscale TIFFs when they are imported.
Choose a profile that corresponds to your monitor from the Monitor Profile drop-down
menu, or choose Automatic. Profiles can be placed in the "Profiles" folder in the
QuarkXPress Server application folder.
Preferences — Input Settings
The Input Settings tab (Administration > Preferences > Renderer > Input Settings)
includes the following controls.
Check Smart Quotes to force QuarkXPress to replace feet (')and inches (") marks
automatically with the specified quotation marks.
Use the Format drop-down menu to specify the default characters to be used with the
Smart Quotes feature and Convert Quotes option in the Get Text dialog box (File > Get
Text).
20 | A GUIDE TO QUARKXPRESS SERVER 9.0
THE QUARKXPRESS SERVER USER INTERFACE
To change the separators used for indicating sequential ranges for output, enter a value
in the Sequential Page Range Separator. This value override the preferences set for a
project.
To change the separators used for indicating nonsequential ranges for output, enter a value
in the Non Sequential Page Range Separator. This value override the preferences set for
a project.
Preferences — Font Fallback
The Font Fallback pane (Administration > Preferences > Renderer > Font Fallback)
includes the following controls.
Check Font Fallback to activate the Font Fallback feature. When this feature is active, if
the application encounters a character it cannot display in the current font, it attempts
to find a font that can display the character.
If the application encounters a missing font when opening a project, it uses the preferences
in this pane to determine which substitute fonts to use.
If you add characters to an exising project and the font cannot support those characters,
the application will search the system for a font that can display the characters.
Check Search to have the application search for a suitable font that is used in the active
project. To restrict the search to a particular range, choose an option from the Search Type
drop-down menu. To search the entire story where a missing font occurs, choose Active
Story. To search a particular number of paragraphs in both directions, choose Paragraph
and enter a number in the Search Limit field.
To indicate which fallback fonts should be used when no other font can be found (taking
the Search settings into account), choose options from each of the drop-down menus in
the Font List area.
To indicate which font should be used for the slug line when a layout is printed with
registration marks turned on, choose an option from the Slug Line Font drop-down menu.
Preferences — Open and Save
The Open and Save pane (Administration > Preferences > Renderer > Open and Save)
includes the following controls.
Choose an option from the Encoding drop-down menu to indicate how the applications
should display characters in non-Unicode text.
Preferences — Fonts
The Fonts pane (Administration > Preferences > Renderer > Fonts) includes the following
controls.
To specify default replacement fonts, check Specify Default Replacement Font and choose
options from the Roman and East Asian drop-down menu.
A GUIDE TO QUARKXPRESS SERVER 9.0 | 21
THE QUARKXPRESS SERVER USER INTERFACE
To highlight characters that are in a Traditional Chinese encoding's UDA/VDA (User
Defined Area/Vendor Defined Area) range so that these characters can be visually verified,
check Highlight character ranges defined by Traditional Chinese font vendors.
Preferences — EPS
The EPS pane (Administration > Preferences > Renderer > EPS) includes the following
controls.
To control whether the application should generate a preview of an EPS file or use the
preview (if any) embedded in the file, choose an option from the Preview drop-down list.
The option specified in this pane is used only when the EPS preview is being created. If
you change the preference, you need to reimport the EPS file.
Preferences — PDF
Use the PDF pane of the Preferences dialog box (Administration > Preferences > Renderer
> PDF) to set preferences for rendering in PDF format.
The PDF pane displays only if PDF Filter XTensions software is loaded. For more
information, see "PDF Filter XTensions software"
Use this pane to specify a PDF workflow:
• Click DirectPDF to generate PDF output in the browser. This is the default option.
• Click PDFtoFolder to generate and save PDF files to a folder. Click Select/Browse to specify
a location for the folder in the Watched Folder field.
• Click PS4D (PostScript File for Later Distilling) to generate a PostScript file. Click
Select/Browse to specify a location for the folder in the Watched Folder field.
Preferences — Project General Settings
The Project General Settings pane (Administration > Preferences > Renderer > Project
General Settings) includes the following controls.
Check Use OpenType Kerning to activate the default kerning values for OpenType fonts.
When OpenType kerning is active, it overrides any kerning specified through Kerning
Table Edit (Utilities menu) for OpenType fonts.
To disable OpenType kerning for full-width characters, check Do Not Kern Full Width
Characters.
Preferences — Print Layout Settings
The Print Layout Settings pane (Administration > Preferences > Renderer > Print Layout
Settings) includes the following controls.
Use the Master Page Items drop-down menu to control what happens to master items
when master pages are applied.
22 | A GUIDE TO QUARKXPRESS SERVER 9.0
THE QUARKXPRESS SERVER USER INTERFACE
• Click Keep Changes if you intend modified master items on your layout pages to remain
when a new master page is applied. The items that are kept are no longer master items.
• Click Delete Changes if you want modified master items on your layout pages to be deleted
when a new master page is applied.
Use the Framing drop-down menu to specify whether frames are placed inside or outside
text and picture boxes.
• When you click Inside, the distance between the text and the frame is determined by the
box's Text Inset values (Item > Modify). When you place a frame inside a picture box,
the frame overlaps the picture.
• When you click Outside, the frame is placed outside the box, increasing the box's width
and height. The frame cannot extend beyond a constraining box or the pasteboard.
Use the Auto Page Insertion drop-down menu (Print layouts only) to determine whether
pages are inserted automatically to contain text overflow from an automatic text box or
a chain of text boxes (on a page associated with a master page that contains an automatic
text box). The drop-down menu also enables you to determine where any pages will be
inserted.
Preferences — Print Layout Measurements
The Print Layout Measurements pane (Administration > Preferences > Renderer >
Default Print Layout Measurements) includes the following controls.
Use the Horizontal and Vertical drop-down menus to specify the measurement system
for the rulers displayed along the top and left of the layout window. Horizontal corresponds
to the top ruler; Vertical corresponds to the left ruler.
Use the Points/Inch field to override the default value of 72 points per inch. The application
uses the value here as the basis for all point and pica measurements, as well as for all point-
and pica-to-inch conversions. The desktop publishing standard for points per inch is 72.
However, the traditional typographic standard used on most metal typographic rulers is
usually approximately 72.27 or 72.307 points per inch (range = 60 to 80 pt, measurement
system = points, smallest increment = .001).
Use the Ciceros/cm field to specify a ciceros-to-centimeter conversion value different from
the standard 2.1967 (range = 2 to 3 c, measurement system = ciceros, smallest
increment = .001).
Preferences — Paragraph
The Paragraph pane (Administration > Preferences > Renderer > Paragraph) includes
the following controls.
Use the Auto Leading feature to automatically set line spacing. Unlike paragraphs with
absolute leading (identical line spacing above every line), paragraphs with auto leading
may include lines with different leading when fonts and font sizes are mixed in the same
paragraph.
A GUIDE TO QUARKXPRESS SERVER 9.0 | 23
THE QUARKXPRESS SERVER USER INTERFACE
Auto leading starts with a base amount of leading, which the application calculates by
examining the ascent and descent values built into the fonts used in an auto-leaded line
and the line above it; however, the user-specified text size plays the largest part in
determining this base amount. Finally, a value specified by the user in the Auto Leading
field is added to the base amount to arrive at the total amount of leading.
To specify percentage-based auto leading, enter a value from 0% to 100% in 1% increments.
This value determines the amount of leading between two lines of text as follows: The
largest font size in the line above is multiplied by the percentage value. This outcome is
added to the base amount of auto leading between the two lines. Although the design of
certain fonts complicates the process, here is a simplified example: 10-point text styled
consistently in a "standard" font with Auto Leading set to 20% has 12 points of leading
(10 pts + [20% of 10] = 12 pts).
Use the Maintain Leading check box to control the placement of a line of text that falls
immediately below an obstruction in a column or box. If Maintain Leading is checked,
the line's baseline is placed according to its applied leading value. If Maintain Leading is
unchecked, the ascent of the line will abut the bottom of the obstruction or any applied
runaround value.
In the Lock to Grid Based On area:
• Click Ascent and Descent to lock text to grid based on the ascenders and descenders of
characters.
• Click Font Size (Em Box) to lock text to grid based on the size of the em boxes of the
characters.
Preferences — Character
The Character pane (Administration > Preferences > Renderer > Character) includes
the following controls.
Use the Superscript fields to control the placement and scale (size) of superscript characters.
The Superscript Offset value determines how far below the baseline the application places
a superscript character. The Superscript Offset value is measured as a percentage of font
size. The default value is 33%. The Superscript VScale value determines the vertical size
of the character and is a percentage of font size. The Superscript HScale value determines
width and is a percentage of the normal character width (as specified by the font designer).
The default value for both scales is 60% (range = 0 to 100%, measurement system =
percentage, smallest increment = .1).
Use the Subscript fields to control the placement and scale (size) of subscript characters.
The Subscript Offset value determines how far above the baseline the application places
a subscript character. The Subscript Offset value is measured as a percentage of font size.
The default value is 33%. The Subscript VScale value determines the vertical size of the
character and is a percentage of font size. The Subscript HScale value determines width
and is a percentage of the normal character width (as specified by the font designer). The
default value for both scales is 100% (range = 0 to 100%, measurement system = percentage,
smallest increment = .1).
24 | A GUIDE TO QUARKXPRESS SERVER 9.0
THE QUARKXPRESS SERVER USER INTERFACE
Use the Small Caps fields to control the scale of characters with the Small Caps type style
applied to them. The Small Caps VScale value determines the vertical size of the character
and is measured as a percentage of font size. The Small Caps HScale value determines
width and is measured as a percentage of the normal character width (as specified by the
font designer). The default value for both scales is 75% (range = 0 to 100%, measurement
system = percentage, smallest increment = .1).
Use the Superior fields to control the scale of superior characters. The Superior VScale
value determines the vertical size of the character and is measured as a percentage of font
size. The Superior HScale value determines width and is measured as a percentage of the
normal character width (as specified by the font designer). The default value for both scales
is 60% (range = 0 to 100%, measurement system = percentage, smallest increment = .1).
Use the Ligatures Break Above field to use ligatures built into a font. A ligature is a
typographic convention in which certain characters are combined into a single glyph.
Most fonts contain ligatures for the characters "f" followed by "i" and "f" followed by "l".
The Ligatures Break Above field enables you to specify the kerning or tracking value
(measured in 1/200 em space increments) above which characters will not be combined
into ligatures. For example, a headline with a large tracking value would probably not
contain ligatures. The default value is 1 (range = 0 to 10, measurement system = .005
[1/200] em space, smallest increment = .001). To prevent the second two letters in "ffi"
and "ffl" (as in office and waffle) from being combined into ligatures, check Not "ffi" or
"ffl". Three-character ligatures for these combinations, common in traditional typesetting
systems, are not standardized in fonts designed for Mac OS, so some typographers prefer
to keep all three letters separate rather than combine only two of them. Note that many
PostScript fonts do not have "ffi" and "ffl" ligatures, but most OpenType fonts do. This
option is unchecked by default.
Check Auto Kern to specify that the application should use kerning tables, which are built
into most fonts, to control intercharacter spacing. The Auto Kern Above field enables you
to specify the point size above which automatic kerning must be used. The Auto Kern
Above feature also implements custom tracking information specified in the Tracking
Values dialog box for a selected font (Utilities > Edit Tracking) in QuarkXPress. This
option is checked by default, with a 4-point threshold (range = 0 to 72 pt, measurement
system = various [", pt, cm, etc.], smallest increment = .001).
Check Standard Em Space to specify an em-space equivalent to the point size of the text
(for example, 24pt text has a 24pt em space). If Standard Em Space is unchecked, the
application uses the width of the two zeros in the current font as the em-space width. This
option is checked by default. You can insert an em space in text by pressing
Option+space/Ctrl+Shift+6.
Use the Flex Space Width field to change the 50% default width of a flexible space. To
create a breaking flexible space, press Option+Shift+space/Ctrl+Shift+5; to create a
nonbreaking flexible space, press Command+Option+Shift+space/Ctrl+Alt+Shift+5. The
Flex Space Width value is expressed as a percentage of the normal en space for a given
font and font size (range = 0 to 400%, measurement system = percentage, smallest
increment = .1).
A GUIDE TO QUARKXPRESS SERVER 9.0 | 25
THE QUARKXPRESS SERVER USER INTERFACE
Use the Accents for All Caps check box to specify whether to include accent marks on
accented characters with the All Caps type style applied. This option is checked by default.
Use the Space between CJK & R field to indicate how much space should be included by
default between a Chinese, Japanese, or Korean character and an adjacent Roman character.
Preferences — Trapping
The Trapping pane (Administration > Preferences > Renderer > Trapping) includes the
following controls.
Select a Trapping Method:
• Click Absolute to trap using the values in the Auto Amount and Indeterminate fields
according to the object and background colors involved. If the object color is darker, the
object is choked by the background using the Auto Amount value. If the object color is
lighter, the object is spread into the background using the Auto Amount value.
• Click Proportional to trap using the value in the Auto Amount field multiplied by the
difference between the luminance (lightness or brightness) of the object color and the
background color.
• Click Knockout All to turn off trapping and print objects with a zero trap amount.
Check Process Trapping to trap each process separation plate individually when a page
contains overlapping process colors.
Check Ignore White to specify that an object color in front of multiple background colors
(including white) does not take white into account when trapping.
Enter a trapping value in the Auto Amount field or choose Overprint:
• Enter a value in the Auto Amount field to control the amount of trapping that QuarkXPress
applies to object and background colors that have an Auto Amount specified in the Trap
Specifications dialog box (Edit > Colors > Edit Trap), and to control the amount of
trapping applied to items with an Auto Amount (+) Trap Information or (–) specified
in the Trap Information palette (Window > Trap Information).
• Choose Overprint to cause overprinting for object and background colors with an Auto
Amount specified in the Trap Specifications dialog box (Edit > Colors > Edit Trap), as
well as for items with an Auto Amount (+) or (–) specified in the Trap Information palette
(Window > Trap Information).
Enter a trapping value in the Indeterminate field or choose Overprint:
• Enter a value in the Indeterminate field to control the amount of trapping that
QuarkXPress applies to object colors that are in front of indeterminate backgrounds
(multiple colors with conflicting trapping relationships).
• Choose Overprint to cause an object color to overprint an indeterminate background.
26 | A GUIDE TO QUARKXPRESS SERVER 9.0
THE QUARKXPRESS SERVER USER INTERFACE
Enter a Knockout Limit value. The knockout limit is the value (expressed as a percentage
of darkness of the object color) that enables you to control the point at which an object
color knocks out a background color.
Enter an Overprint Limit value. Overprint limit is a trapping setting that allows an object
set to overprint to trap according to the Auto Amount value if the object's shade is less
than a particular percentage.
Preferences — Color Manager
The Color Manager pane (Administration > Preferences > Renderer > Color Manager)
includes the following controls.
To specify an engine for color transformation, choose an option from the Color Engine
drop-down menu.
To achieve the darkest possible blacks in all output methods, check Black Point
Compensation.
Use the Source Setup drop-down menu to specify the source color space of pictures and
colors used in the application.
To enable the Profile Information command in the Window menu and the Color
Management tab in the Import Picture dialog box, check Enable Access to Picture
Profiles. This option allows you to view information about profiles.
To specify a default proof output setup, choose an option from the Proof Output drop-down
menu.
To specify a rendering intent for soft proofing, choose an option from the Rendering
Intent drop-down list. Perceptual scales all the colors in the source gamut so that they
all fit within the destination gamut. Relative Colorimetric retains colors that are in both
the source gamut and the destination gamut. The only source colors that are changed are
those that are not within the destination gamut. Saturation considers the saturation of
source colors and changes them to colors with the same relative saturation in the
destination gamut. Absolute Colorimetric retains colors that are in both the source gamut
and the destination gamut. Colors that are outside the destination gamut are adjusted in
relation to how they would look when printed on white paper. Defined by Sources uses
the rendering intents defined in source setup for all colors and images.
To color manage vector content in imported EPS and PDF files, check Color Manage
Vector EPS/PDF. Note that this preference applies only to EPS and PDF files imported
after this box is checked.
To color manage vector content in EPS and PDF files that have already been imported in
the active project, check Include Existing Vector EPS/PDF in Layout.
Preferences — Layers
The Layers pane (Administration > Preferences > Renderer > Layers) has the following
controls.
A GUIDE TO QUARKXPRESS SERVER 9.0 | 27
THE QUARKXPRESS SERVER USER INTERFACE
To make new layers visible by default, check Visible.
To suppress the printout of new layers by default, check Suppress Output.
To make new layers locked by default, check Locked.
To maintain runaround on new layers so that text on visible layers flows around items on
hidden layers, click Keep Runaround.
Preferences — Full Res Preview
Use the Full Res Preview pane (Administration > Preferences > Renderer > Full Res
Preview) to control how the Full Res Preview XTensions module works.
To turn off Full Resolution Preview when opening a project, check Disable Full Resolution
Previews on Open.
To specify a maximum cache folder size for full resolution previews, enter a value in the
Maximum Cache Folder Size field.
Job Jackets dialog box
The Job Jackets dialog box lets you edit the Job Jackets file used by QuarkXPress Server.
To edit the QuarkXPress Server Job Jackets file:
In the QuarkXPress Server Web interface, choose Administration > Job Jackets. The
1
Manage Job Jacket dialog box displays.
Click the Get Job Jacket for editing button and save the Job Jackets file to the desktop.
2
Open the downloaded Job Jackets file in QuarkXPress and make any necessary changes to
3
the QXPSJobTicket Job Ticket.
In the Job Jacket dialog box, click Choose File and select the modified Job Jackets file.
4
Click Submit. The QuarkXPress Server Job Jackets file is replaced with the modified version.
5
Check Out License dialog box
To check the QuarkXPress Server license out of Quark License Administrator, choose
Administration > Check Out License. To specify the number of days for checkout, enter
a value in days in the Check out for field. To be warned in advance of license expiration,
check Warn me and use the corresponding fields.
28 | A GUIDE TO QUARKXPRESS SERVER 9.0
Creating URL requests
You can use URL requests to make QuarkXPress Server render projects in a variety of
formats, to use the features of server XTensions modules, and to control the server. The
topics below provide an overview of how to construct server requests and use URL
parameters.
This chapter also lists functions that let you control the server. For detailed information
CREATING URL REQUESTS
about constructing other types of URL requests, see the QuarkXPress Server Web Integration
Guide.
Understanding URL requests
QuarkXPress Server URL requests should use the following format:
http://server:port/namespace/path/projectname?parameter=value
•
server: Indicates the name or IP address of the QuarkXPress Server computer.
•
port: Indicates the QuarkXPress Server application's port number. The default port number
is 8080.
•
namespace: Sets the render type (or indicates another server functionality to access). For
more information, see "Understanding QuarkXPress Server namespaces"
•
path: Indicates the path to the directory where the target project file is stored. Paths are
evaluated relative to the document pool directory.
•
projectname: Identifies the project to be rendered.
•
parameter=value: Optional parameters that provide more detailed control over how the
target project should be rendered. Multiple parameter/value pairs, separated by the "&"
character, can be included.
For example, the following URL asks the QuarkXPress Server application named "QXPServer"
to return the file "MyProject.qxp" as a PDF file with hyperlinks and all fonts embedded:
http://QXPServer:8080/PDF/MyProject.qxp?includehyperlinks=1&embedallfonts=1
A GUIDE TO QUARKXPRESS SERVER 9.0 | 29
CREATING URL REQUESTS
Some URL parameters require Boolean arguments. For such parameters, valid values include
1 or 0, true or false, y or n, and yes or no.
You can also send requests to QuarkXPress Server using the HTTP GET and POST protocols
and using XML with XSLT. For more information about these approaches, see the
QuarkXPress Server Web Integration Guide.
Understanding QuarkXPress Server namespaces
QuarkXPress Server namespaces differentiate among types of requests that are otherwise
identical. For example, consider the following three URLs:
http://QXPServer:8080/project1.qxp
http://QXPServer:8080/pdf/project1.qxp
http://QXPServer:8080/postscript/project1.qxp
These requests are identical, except each uses a different namespace (in italic). (The first
request does not specify a namespace, but this simply means the project is to be rendered
using the server's default render type.)
Namespaces can be used to determine the format in which a rendered project is returned,
as indicated above, but they can also be used to direct a request to XTensions software
that performs other functions. For example, if you use Modifier XTensions software's xml
namespace, Modifier XTensions software can return an XML representation of the project.
Looking up a namespace
The QuarkXPress Server Web Integration Guide lists the namespaces for every
QuarkXPress Server function. There is no single list of namespaces because some functions
do not require a particular namespace or are available in multiple namespaces. To determine
which namespace you want to use:
Open the QuarkXPress Server Web Integration Guide.
1
Choose Complete API List from the QuarkXPress Server Functions menu at the top of
2
the page.
Click the link for the render type you want or the function you want to use. (The link
3
might be a dynamic publishing process, a renderer, or a request handler.) The page
corresponding to that render type or function displays.
Locate the Namespace row. If the render type or function has an associated namespace,
4
that namespace is listed here.
Third-party XTensions can add their own namespaces. For information about a third-party
namespace, see the documentation for the XTensions module that adds that namespace.
30 | A GUIDE TO QUARKXPRESS SERVER 9.0
Understanding QuarkXPress Server parameters
Parameters let you control the details of how a request is executed. For example, you can
use the page parameter to create a request that returns only the third page of a project:
http://QXPServer:8080/jpeg/project1.qxp?page=3
You can include multiple parameters in the same request; simply separate them with an
ampersand (&). For example, here's a new version of the above URL that returns page three
at a scale of 50%:
http://QXPServer:8080/jpeg/project1.qxp?page=3&scale=.5
Looking up a parameter
The QuarkXPress Server Web Integration Guide lists the parameters that are available for
every QuarkXPress Server function. To determine which parameters you can use with a
request:
Open the QuarkXPress Server Web Integration Guide.
1
Choose Complete API List from the QuarkXPress Server Functions menu at the top of
2
the page.
CREATING URL REQUESTS
Click the link for the render type you want or the function you want to use. (The link
3
might be a dynamic publishing process, a renderer, or a request handler.) The page
corresponding to that render type or function displays.
Locate the Parameters row. This row lists all available parameters, and includes a description
4
and a list of valid values for each parameter.
QuarkXPress Server Web Integration Guide overview
The topics below provide an overview of the contents of the QuarkXPress Server Web
Integration Guide.
Render types
QuarkXPress Server render types let you render content in a variety of formats, including
EPS, JPEG, PNG, PDF, PostScript, QuarkXPress, QuarkCopyDesk, and SWF (Flash). You can
also return documents in two different "raw" formats. Developers can implement additional
rendering formats through server XTensions software.
For more information, see the QuarkXPress Server Web Integration Guide.
General parameters
General parameters are parameters that are applicable to most render types. These
parameters allow you to render an individual box, component, layout, page, or spread.
You can also render a particular selection of layers, pages, and spreads. In addition, you
can control whether the pasteboard is included and how the output should be scaled.
A GUIDE TO QUARKXPRESS SERVER 9.0 | 31
CREATING URL REQUESTS
For more information, see the QuarkXPress Server Web Integration Guide.
Specialized parameters
Specialized parameters are parameters that serve special purposes. Some of these parameters
work by asking the server to read the contents of XML files.
For more information, see the QuarkXPress Server Web Integration Guide.
Server control parameters
Server control parameters let you perform a variety of server administration tasks, including
adding and deleting files from the document pool, retrieving information about files, and
flushing caches.
For more information, see the QuarkXPress Server Web Integration Guide.
Document providers
Document providers allow QuarkXPress to render the following types of documents:
•
copydesk: Allows QuarkXPress Server to render article files created by QuarkCopyDesk.
•
qcddoc: Allows QuarkXPress Server to render and export QuarkCopyDesk articles.
For more information, see the QuarkXPress Server Web Integration Guide.
32 | A GUIDE TO QUARKXPRESS SERVER 9.0
Modifying layouts with XML
The xml namespace deconstructs a project according to the Modifier DTD. The construct
namespace lets the server turn an XML representation of a QuarkXPress project back into
an actual project. With these namespaces, you can deconstruct a project into an XML
representation, change the XML in accordance with the Modifier DTD, and then have the
server generate an updated version of the QuarkXPress project. You can even create new
MODIFYING LAYOUTS WITH XML
QuarkXPress projects from scratch using XML.
In addition, you can use the construct namespace to:
• Create a page based on master page
• Create a project from XML, using a Job Jackets™ file as the basis for the project
• Modify text font and style, including OpenType® styles
• Apply style sheets and local formatting to text
• Create and populate tables
• Import pictures into picture boxes and specify picture attributes
The DTD used for XML construction and deconstruction is completely Unicode®-compliant,
making it ideal for use in international publishing. Furthermore, the use of this DTD
ensures that the schema of XML output created by Constructor does not change when
server preferences change. This DTD is provided in the QuarkXPress Server application
folder and fully documented in the QuarkXPress Server Web Integration Guide.
Deconstructor XTensions software and the deconstruct namespace are no longer
supported.
A GUIDE TO QUARKXPRESS SERVER 9.0 | 33
USING SSL
Using SSL
You can configure QuarkXPress Server with different security options. In addition to your
own network security specifications, you can specify Secure Sockets Layer (SSL) protocol
for client applications.
Secure Sockets Layer (SSL) support
You can configure Tomcat (and therefore all QuarkXPress Server clients) to run in secure
mode with Secure Sockets Layer (SSL) technology. This section explains the configuration
process.
It is also possible to run QuarkXPress Server without embedding Tomcat in the JVM. For
more information, see the QuarkXPress Server ReadMe file.
To manage Web applications in the QuarkXPress Server environment, QuarkXPress Server
embeds an instance of Apache Tomcat 6.18 in its JVM.
When you enable SSL, it applies to all QuarkXPress Server client applications.
Enabling SSL
The instructions below address two scenarios. The "server.xml" file you edit contains XML
tags for both scenarios, which you need to enable or disable by "commenting" and
"uncommenting" specific tags.
To enable SSL for secure HTTP for all QuarkXPress Server applications:
Open the "conf" folder in your QuarkXPress Server folder.
1
Open "server.xml" in a text-editing application.
2
Locate the following tag (preceded by the comment <!-- Define a non-SSL HTTP/1.1
3
Connector on port 8080 -->) and comment it out.
<Connector port="8080" maxHttpHeaderSize="8192" maxThreads="150"
minSpareThreads="25" maxSpareThreads="75" enableLookups="false"
redirectPort="61399" acceptCount="100" connectionTimeout="20000"
disableUploadTimeout="true" URIEncoding="UTF-8"/>
34 | A GUIDE TO QUARKXPRESS SERVER 9.0
Locate the following tag (preceded by the comment <!-- Define a SSL HTTP/1.1
4
Connector on port 61399 -->) and uncomment it.
<Connector port="61399" maxHttpHeaderSize="8192"MaxThreads="150"
minSpareThreads="25" maxSpareThreads="75"enableLookups="false"
disableUploadTimeout="true"acceptCount="100" scheme="https"
secure="true"clientAuth="false" sslProtocol="TLS" />
Replace 61399 with 61400 (or any port on which Tomcat will be listening for secure
5
connections).
Save and close "server.xml."
6
Open the "ServerApp.properties" file (in the "conf" folder) and enter the port number from
7
step 5 for qxpswebserver.port.
This change means QuarkXPress Server client applications can use HTTPS. For example,
the URL for a QuarkXPress Server user would be as follows: https://[server
name]:[port]/.
Enabling HTTP and HTTPS
To enable HTTP and HTTPS:
USING SSL
Open the "conf" folder in your QuarkXPress Server folder.
1
Open "server.xml" in a text-editing application.
2
Uncomment the following tag:
3
<Connector port="61399" maxHttpHeaderSize="8192"MaxThreads="150"
minSpareThreads="25" maxSpareThreads="75"enableLookups="false"
disableUploadTimeout="true"acceptCount="100" scheme="https"
secure="true"clientAuth="false" sslProtocol="TLS" />
Save and close "server.xml."
4
This feature allows QuarkXPress Server application users to access QuarkXPress Server with
HTTPS or HTTP.
Verifying and using SSL
To verify and use SSL:
Start the QuarkXPress Server
1
Test QuarkXPress Server access by navigating to the QuarkXPress Server Web interface
2
HTTPS. For example: https://[server]:[port]/qxpsadmin
Keystores and SSL certificates
A certificate is a file on a Web server that is used in encryption and confirmation between
two endpoints to establish a secure connection. A keystore is essentially a database of digital
certificates on the Web server.
A GUIDE TO QUARKXPRESS SERVER 9.0 | 35
USING SSL
You can obtain an SSL certificate from a trusted Certificate Authority (CA). Import the
certificate into the keystore used by QuarkXPress Server's JVM.
For more information about the importance of keystores, use the following URL:
http://tomcat.apache.org/tomcat-6.0-doc/ssl-howto.html.
36 | A GUIDE TO QUARKXPRESS SERVER 9.0
QUARKXPRESS SERVER XTENSIONS SOFTWARE
QuarkXPress Server XTensions software
Just as XTensions software provides additional functionality to QuarkXPress, XTensions
software enables QuarkXPress Server to do things it can't do by default. The XTensions
modules included with QuarkXPress Server allow clients to render projects as PDF files,
apply QuarkVista picture effects to pictures, dynamically update pictures in picture boxes
and text in text boxes (as well as boxes themselves), import data on the fly, manipulate
layers in projects, and more.
CopyDeskArticle XTensions software
CopyDeskArticle XTensions software allows QuarkXPress Server to do the following things:
• Render QuarkCopyDesk articles
• Export QuarkCopyDesk articles from a QuarkXPress project
• Add a QuarkCopyDesk article to an existing QuarkXPress project
• Create and delete components in a QuarkCopyDesk article within a QuarkXPress project
Rendering articles
To render QuarkCopyDesk articles, use the copydesk namespace, as follows:
http://[server]:[port]/[render type]/copydesk/[articlename]
For example, to render "Article.qcd" as a PDF file, you could use a URL like the following:
http://QXPServer.8080/pdf/copydesk/Article.qcd
Exporting articles
To export an article from a QuarkXPress project, use the QCDDOC namespace, as follows:
http://[server]:[port]/qcddoc/[project name]?article=[article name or
ID]
A GUIDE TO QUARKXPRESS SERVER 9.0 | 37
QUARKXPRESS SERVER XTENSIONS SOFTWARE
For example, to export the article named "Article1" from the project named "Project1.qxp,"
you could use a URL like the following:
http://QXPServer.8080/qcddoc/Project1.qxp?article=Article1
You cannot export an article from a QuarkXPress project unless the article has been created
and named in QuarkXPress using CopyDeskArticleXT XTensions software.
To export an article in a particular format, use the format parameter.
•
To export a standard article, use format=fullfeatured.
•
To export an article in lightweight mode, use format=lightweight.This format can be
useful in situations where file size is an issue. The lightweight file format includes only
those items that a QuarkCopyDesk user is supposed to work on.
For example:
http://QXPServer.8080/qcddoc/Project1.qxp?article=Article1?format=lightweight
You cannot export page pictures in lightweight mode.
Adding articles to projects
You can use Modifier XTensions software to create a QuarkCopyDesk article within an
existing QuarkXPress project. For example, to add an article named "New Article" to the
project named "Project1.qxp," you could use XML like the following:
<PROJECT PROJECTNAME="Project1.qxp" XMLVERSION="8.0">
<LAYOUT POINTSPERINCH="72">
<ID NAME="Layout 1" UID="1"/>
<ARTICLE OPERATION="CREATE" DOCFORMAT="FULLFEATURED">
<ID NAME="New Article" UID="4"/>
<RGBCOLOR BLUE="98" GREEN="254" RED="0"/>
<COMPONENT BOXNAME="Box1" BOXUID="1" COMPONENTCLASS="CT_TEXT"
NAME="Component 1" UID="1"/>
</ARTICLE>
</LAYOUT>
</PROJECT>
For more information, see the QuarkXPress Server Web Integration Guide.
Creating and deleting components
You can use Modifier XTensions software to create and delete components in
QuarkCopyDesk articles. For example, to add a component named "New Component" to
the article named "Article 1" in the project named "Project1.qxp," you could use XML like
the following:
<PROJECT JOBJACKET="Project1 Job Jacket" JOBTICKET="Default Job Ticket
1:Project1"
PROJECTNAME="Project1.qxp" XMLVERSION="8.0">
<LAYOUT POINTSPERINCH="72">
<ID NAME="Layout 1" UID="1"/>
<ARTICLE DOCFORMAT="FULLFEATURED">
<ID NAME="Article 1" UID="1"/>
<COMPONENT OPERATION="CREATE" BOXUID="9" COMPONENTCLASS="CT_TEXT"
NAME="New Component"/>
</ARTICLE>
38 | A GUIDE TO QUARKXPRESS SERVER 9.0
</LAYOUT>
</PROJECT>
To delete the component named "New Component" from the article named "Article1.qcd,"
you could use XML like the following:
<PROJECT JOBJACKET="Project1 Job Jacket" JOBTICKET="Default Job Ticket
1:Project1"
PROJECTNAME="Project1.qxp" XMLVERSION="8.0">
<LAYOUT POINTSPERINCH="72">
<ID NAME="Layout 1" UID="1"/>
<ARTICLE DOCFORMAT="FULLFEATURED">
<ID NAME="Article 1" UID="1"/>
<COMPONENT OPERATION="DELETE" NAME="New Component"/>
</ARTICLE>
</LAYOUT>
</PROJECT>
For more information, see the QuarkXPress Server Web Integration Guide.
PDF Filter XTensions software
PDF Filter XTensions software allows QuarkXPress Server to render a QuarkXPress project
as a PDF file. To render QuarkXPress projects as PDF files when PDF is not the
QuarkXPress Server default render type, use the PDF namespace, as follows:
QUARKXPRESS SERVER XTENSIONS SOFTWARE
http://[server]:[port]/pdf/[projectname]
For information about PDF preferences, see "Preferences — PDF." To take advantage of more
detailed preferences, create a PDF output style and use that output style when rendering
projects as PDF files.
For information about the parameters for exporting in this format, see the
QuarkXPress Server Web Integration Guide.
Modifier XTensions software
Modifier XTensions software lets clients perform all of the following tasks using XML:
• Modify the properties of pictures in a QuarkXPress project
• Modify the text in text boxes within a QuarkXPress project
• Modify the properties of text boxes and picture boxes in a QuarkXPress project
• Create and delete picture boxes and text boxes in a QuarkXPress project
• Import text or text strings into text boxes within a QuarkXPress project
• Import pictures into picture boxes within a QuarkXPress project
• Save modified QuarkXPress projects in any supported format to any location on the network
(and also in the QuarkXPress Server document pool)
• Create and delete pages
• Create and delete layers
A GUIDE TO QUARKXPRESS SERVER 9.0 | 39
QUARKXPRESS SERVER XTENSIONS SOFTWARE
• Move items within layers
• Create and delete tables
• Modify tables and their contents
• Create QuarkCopyDesk articles and components
• Create lines, anchored boxes, and Bézier boxes
• Create lists
• Group and ungroup boxes
• Divide layouts into sections
To use Modifier XTensions software, a client creates an XML file indicating the actions to
be taken and sends that XML file to the QuarkXPress Server application, where Modifier
XTensions software reads the XML and makes the requested changes. Clients can use a
single XML file or string to manipulate multiple documents and boxes.
For more specific information about Modifier XTensions software, and for the Modifier
DTD, see the QuarkXPress Server Web Integration Guide.
Modifier XTensions software supports both GET and POST functionality.
Modifier XTensions software supports XML containing code that uses Unicode UTF-8 and
UTF-16 encodings. Use the encoding attribute of the XML declaration to specify an
encoding, as you would with any other XML file.
Using Modifier XTensions software
To use Modifier XTensions software:
Create a QuarkXPress project. Note the IDs or names of any text and picture boxes you
1
want to manipulate.
Upload the project to the QuarkXPress Server document pool.
2
Create XML that describes the changes you want, as described in "Creating XML for Modifier
3
XTensions software."
Send the XML to the server in one of the following ways:
4
• Put the XML in a file on the server and then use a URL to point to the file, as follows:
http://server:port/namespace/path/projectname?modify=file:[absolute
path to XML file on server or relative path to XML file on server
relative to the document pool]
• Put the XML in the URL, as follows:
http://[server]:[port]/[namespace]/path/projectname?modify=[XML string]
40 | A GUIDE TO QUARKXPRESS SERVER 9.0
Clients can also send XML in the form of a POST request.
Creating XML for Modifier XTensions software
All XML used with Modifier XTensions software uses the Modifier DTD. This DTD is
documented in full in the QuarkXPress Server Web Integration Guide.
In general, the structure for addressing items in a particular layout is as follows:
<PROJECT>
<LAYOUT>
<ID NAME="[name of layout]">
<[Item being addressed]>
<[Parameters of item]>
</[Item being addressed]>
</LAYOUT>
</PROJECT>
For more information, see the QuarkXPress Server Web Integration Guide.
Layer XTensions software
QUARKXPRESS SERVER XTENSIONS SOFTWARE
You can use QuarkXPress Server Layer XTensions software to control the visibility of
specific layers in a rendered QuarkXPress project. You can also add layers, delete layers,
edit layer attributes, and control whether layers are rendered.
When you use the getdocinfo namespace, QuarkXPress Server returns information about
items on all of the layers in the QuarkXPress project, including layers that are not visible.
Clients can use the layer parameter to specify a layer (even a hidden layer) to be rendered.
For example, the URL http://QXPServer:8080/doc.qxp?layer=layer1 renders only
the layer named "layer1" in the project named "doc.qxp."
Clients can specify more than one layer in a single URL. For example, the URL
http://QXPServer:8080/doc.qxp?layer=layer1,layer2 renders the layers named
"layer1" and "layer2."
For information about layer preferences, see "Preferences — Layers." For information about
the parameters for this feature, see the QuarkXPress Server Web Integration Guide.
If Suppress Output is selected for a layer, QuarkXPress Server does not render that layer
when producing PDF, EPS, or PostScript files.
InteractiveDesignerSXT Server XTensions software
InteractiveDesignerSXT XTensions software allows QuarkXPress Server to render both Print
and Interactive layouts in QuarkXPress projects as SWF (Flash) files. If you render a Print
layout as an SWF file, you can use the right and left arrow keys to navigate between pages
in the SWF file.
A GUIDE TO QUARKXPRESS SERVER 9.0 | 41
QUARKXPRESS SERVER XTENSIONS SOFTWARE
To render an Interactive layout in a QuarkXPress project as a SWF file when SWF is not
the QuarkXPress Server default render type, use the SWF namespace, as follows:
http://[server]:[port]/swf/[projectname]?layout="[layoutname]"
For information about the parameters for exporting in this format, see the
QuarkXPress Server Web Integration Guide.
42 | A GUIDE TO QUARKXPRESS SERVER 9.0
TELEGRAPH XTENSIONS SOFTWARE
Telegraph XTensions software
Unlike the other XTensions software described in this guide, Telegraph XTensions software
works with QuarkXPress, rather than with QuarkXPress Server. You can use Telegraph
XTensions software to create QuarkXPress projects that can serve as templates in
QuarkXPress Server. Using Telegraph XTensions software, you can assign unique names
to individual items, define server caching parameters, and upload the template directly to
a QuarkXPress Server computer.
These topics explain how to use Telegraph XTensions software. It is assumed that you are
already familiar with the functionality and user interface of QuarkXPress.
Setting Telegraph preferences
Telegraph XTensions software adds the QuarkXPress Server pane to the QuarkXPress
Preferences dialog box (QuarkXPress/Edit menu). You can use this pane to configure
settings for QuarkXPress Server templates, specify where to store your projects on the
server, and control how projects are cached.
A GUIDE TO QUARKXPRESS SERVER 9.0 | 43
TELEGRAPH XTENSIONS SOFTWARE
QuarkXPress Server pane of Preferences dialog box (QuarkXPress/Edit menu)
For information on adding a server, see "Adding a server."
To edit the properties of a server in the Server list, select the server name and then click
Edit.
To remove a server from the Server Setup list, select the server and then click Remove.
To allow projects checked in from this copy of QuarkXPress to remain open on the server
after it has been served, check Allow Document to Stay Open.
To load projects checked in from this copy of QuarkXPress into the server memory cache,
check Allow Document in Memory Cache.
Specifying a server for template upload
Before you can upload a template to a server with Telegraph XTensions software, you must
add that server to the QuarkXPress preferences. To do so:
Choose QuarkXPress/Edit > Preferences. The Preferences dialog box displays.
1
Click QuarkXPress Server in the list on the left. The QuarkXPress Server pane displays.
2
44 | A GUIDE TO QUARKXPRESS SERVER 9.0
TELEGRAPH XTENSIONS SOFTWARE
QuarkXPress Server pane of Preferences dialog box
Click Add. The Add Server dialog box displays.
3
Add Server dialog box
Enter a human-readable name for the server in the Server Name field.
4
Enter the server's name or IP address in the Address field.
5
Enter the server's port number in the Port field. The default port number is 8080. Valid
6
values are from 1 to 65535.
In the Document Pool Path field, enter the path to the document pool directory on the
7
server, or to a subdirectory within the document pool. If you leave this field blank, the
path defaults to the document pool directory path specified in the QuarkXPress Server
Document Root field (QuarkXPress Server > Server Configuration > Server tab).
If you enter a folder path that does not exist, QuarkXPress Server can create the folders in
the path when you upload the template to a QuarkXPress Server. To create folders when
you upload, check Generate Hierarchy On Document Upload in the Server tab of the
QuarkXPress Server Server Configuration dialog box (QuarkXPress Server > Server
Configuration) before you upload the template to the server.
A GUIDE TO QUARKXPRESS SERVER 9.0 | 45
TELEGRAPH XTENSIONS SOFTWARE
Click OK, then close the Preferences dialog box.
8
Using Telegraph XTensions software
Once you have configured preferences for Telegraph QuarkXTensions software, you can
begin creating QuarkXPress Server templates. After you complete a template, Telegraph
XTensions software can upload the file to a QuarkXPress Server computer.
Identifying QuarkXPress items and groups
The Box Identifiers palette lets you associate names with items and groups. To display
this palette, choose Window > Box Identifiers.
Box Identifiers palette
To edit the name of an item or group, select its name in the Box Identifiers palette and
then click Edit Box Name .
To scroll to the location of a named item or group, double-click the target item or group’s
name in the Box Identifiers palette. Alternatively, you can select the name and click Go
To .
To delete an item’s or group’s name (without deleting the item or group itself), select the
name in the Box Identifiers palette and then click Delete .
To make sure that all named boxes display in the Box Identifiers palette, click Populate
Named Boxes .
Each QuarkXPress item also has an identification number that you can use when you want
to render individual project items in QuarkXPress Server. The number displays in the Box
ID field in the upper right corner of the palette.
In a chain of text boxes, all boxes use the same Box Name. However, each box has a unique
Box ID number.
Naming items and groups
To specify a name for an item or group:
46 | A GUIDE TO QUARKXPRESS SERVER 9.0
TELEGRAPH XTENSIONS SOFTWARE
Using the Item tool, select the target item or group.
1
2
In the Box Identifiers palette, click New Box Name . The New Box Name dialog box
displays.
New Box Name dialog box
Enter a name for the item or group in the Box Name field.
3
Click OK. The name of the item or group displays on the Box Identifiers palette, next to
4
the item’s item ID and page number.
In addition to items on layout pages, you can also name items on master pages. Items on
layout pages that are based on items on master pages have a default name of "<Item name
on master page><New box UID>"
Uploading templates
Telegraph QuarkXTensions software can upload a project to the QuarkXPress Server
computer in one simple step. You can also upload any required pictures and fonts, if you
choose to collect the fonts and pictures during the upload.
QuarkXPress Server automatically generates any file hierarchy necesary when you upload
content to the document pool from Telegraph XTensions software.
You must have Telegraph XTensions software 9.0 or later to upload templates to
QuarkXPress Server 9.0 or later. (You can use previous versions of Telegraph with previous
versions of QuarkXPress, but if you do so you must upload projects to the server using the
document pool upload capability in the QuarkXPress Server Web interface.)
To upload the active project:
Choose Utilities > Upload Template. The Upload Template dialog box displays.
1
If you have edited the project since you last saved it, QuarkXPress prompts you to save
the project.
A GUIDE TO QUARKXPRESS SERVER 9.0 | 47
TELEGRAPH XTENSIONS SOFTWARE
Upload Template dialog box
Choose a server from the Server drop-down menu. This drop-down menu includes the
2
servers listed in the QuarkXPress Server pane of the Preferences dialog box
(QuarkXPress/Edit menu).
If you specified a directory path for the server, that path automatically displays in the
3
Directory Path field. If you did not specify a directory path in the preferences, this field
remains blank. This path defaults to the document pool directory specified in
QuarkXPress Server.
If you are uploading to QuarkXPress Server, and you have configured that server to require
4
authentication, enter a valid user name and password in the User Name and Password
fields. (If the QuarkXPress Server application does not require authentication, leave these
fields empty.)
To specify authentication information for a QuarkXPress Server application, choose
Administration > Preferences > General in the QuarkXPress Server Web interface, check
Authenticate for Admin Requests box and enter a user name and password.
To indicate which protocol to use for uploading, click HTTP or HTTPS.
5
Enter the port for QuarkXPress Server in the Port field.
6
To collect and upload fonts used by the project, check Fonts.
7
To collect and upload pictures used by the project, check Pictures. This will upload high-
8
or low-resolution pictures that are linked to or embedded in the project.
If picture files are missing or have been modified since they were imported into the project,
an alert displays. For more information about missing or modified picture files, see
"Uploading missing or modified pictures."
48 | A GUIDE TO QUARKXPRESS SERVER 9.0
TELEGRAPH XTENSIONS SOFTWARE
Click OK.
9
If you check Fonts, an alert reminds you of possible restrictions regarding copying font
software. Click OK to continue uploading the project with the fonts, click Do Not Collect
Fonts to upload the project without the fonts, or click Cancel to stop the upload.
The Upload Status window displays a progress bar that displays the status of the upload.
When the upload is complete, a message notifies you whether the project uploaded
successfully.
Uploading missing or modified pictures
If the picture files linked to the project are missing or have been modified since they were
imported into the project, an alert displays at upload. Choose from among the following
options:
• To continue the upload with low-resolution versions of the pictures, click OK.
• To stop the upload, click Cancel.
• To locate missing pictures or update modified pictures, click List Pictures.
If you click List Pictures, the Missing/Modified Pictures dialog box displays:
• To view a picture in the project, select the picture's name in the list and click Show.
• To locate a missing picture file, select it and click Update. The Find dialog box displays.
Locate and choose the appropriate file, and then click Open.
• To update a modified picture file, click Update. Every instance of the modified picture in
the project is updated.
• When OK displays in the Status column for each picture, click Collect. If the status of
any picture is still Missing or Modified when you click Collect, that picture file will not
be uploaded, but a low-resolution preview will remain in the project.
• To stop the upload and return to the project window, click Cancel.
A GUIDE TO QUARKXPRESS SERVER 9.0 | 49
QUARKXPRESS SERVER MANAGER
QuarkXPress Server Manager
QuarkXPress Server Manager is a server application that efficiently routes rendering requests
in an environment that uses one or more QuarkXPress Server applications.
QuarkXPress Server Manager uses load-balancing methods to determine which server in
the QuarkXPress Server pool can best process a document request, and uses caching to
improve speed and efficiency. QuarkXPress Server Manager also provides failsafe capability
by reliably resubmitting failed requests, either to the same QuarkXPress Server instance
or to a different one (depending on the error message returned by the server instance).
QuarkXPress Server does not require QuarkXPress Server Manager, but a QuarkXPress Server
Manager server can coordinate multiple QuarkXPress Server applications so that they work
together with maximum speed, reliability, and availability.
QuarkXPress Server Manager also provides a Web services interface that allows developers
to use QuarkXPress Server features without having to use the HTTP interface.
To configure a QuarkXPress Server Manager server application, you must use the
QuarkXPress Server Manager client application. The topics below explain how the
QuarkXPress Server Manager client application works and provide examples for using it.
Understanding QuarkXPress Server Manager
Before you begin, take time to review the topics below so that you understand how this
chapter is structured and how you can get the most out of it.
Load balancing
Load balancing ensures that each rendering request is sent to a server that is likely to be
able to handle it quickly. QuarkXPress Server Manager lets you use choose from three
load-balancing settings:
• Random: Each rendering request is sent to a random server.
50 | A GUIDE TO QUARKXPRESS SERVER 9.0
QUARKXPRESS SERVER MANAGER
• Round robin: Requests are sent to servers in a set order. For example, if you have three
QuarkXPress Server instances and QuarkXPress Server Manager receives ten rendering
requests, the requests are distributed as follows:
QuarkXPress Server instance usedRequest
11
22
33
14
25
36
17
• Dynamic: The QuarkXPress Server Manager server considers file size and throughput
requirements for each request. For example, assume the following series of requests is sent
to QuarkXPress Server Manager in an environment that uses two QuarkXPress Server
instances:
SizeRequest
8MB1
1MB2
2MB3
The first request is assigned to server #1, and the second request is assigned to server #2.
When the third request arrives, QuarkXPress Server Manager checks the loads that the two
servers are already handling and assigns the task to the server with the smallest load — in
this case, server #2.
If a request fails because a server stops responding or because of a "File Not Found" error,
QuarkXPress Server Manager does not resubmit that request to that server.
The Dynamic setting is typically the most efficient setting for environments with more
than one QuarkXPress Server instance.
For information about choosing a load-balancing setting, see "Controlling load balancing."
Developers can implement their own load-balancing systems; for more information, see
the QuarkXPress Server Web Integration Guide.
Request timeout interval
QuarkXPress Server Manager attempts to send each request to a QuarkXPress Server instance
that can promptly handle that request. However, in some situations a QuarkXPress Server
A GUIDE TO QUARKXPRESS SERVER 9.0 | 51
QUARKXPRESS SERVER MANAGER
instance might be unable to process a request in a reasonable amount of time (for example,
if the server is working on a large rendering job, or if the server computer has stopped
functioning). If you specify a certain period of time as the request timeout interval,
QuarkXPress Server Manager will wait for the response until that period of time elapses,
and then send the request to a different QuarkXPress Server instance. This ensures that a
request does not get "lost" if its assigned QuarkXPress Server instance does not become
available promptly.
For information about setting a request timeout interval, see "Using other global settings."
If a client request fails despite being sent to multiple QuarkXPress Server instances,
QuarkXPress Server sends the end user a customizable error message or exception so that
the end user can appropriately handle the failure. A QuarkXPress Server Manager server
can also automatically send e-mail to an administrator in the event of a problem; for more
information, see "Generating automatic e-mail messages."
Determining QuarkXPress Server instance availability
QuarkXPress Server Manager uses two methods to determine the availability of a
QuarkXPress Server instance: ping and ping document.
Ping
QuarkXPress Server Manager periodically sends a ping request to all of its QuarkXPress Server
instances to determine whether they are available. Ping requests use the following format:
http://[Server]:[Port]/getprocessid
Ping document
QuarkXPress Server Manager periodically sends a render request to all of its QuarkXPress
Server instances to determine whether they can render a document. Ping document requests
use the following format:
http://[Server]:[Port]/[PingDocumentName.qxp]
You can specify the document to be used for this render request. To avoid long ping
document rendering times, use a simple document.
You can specify the interval between pings and ping documents in the Other Settings
pane in the Global Settings pane of the QuarkXPress Server Manager window (see "Using
other global settings").
Logging
QuarkXPress Server Manager logs all interactions with QuarkXPress Server instances.
QuarkXPress Server Manager log files contain the following information:
• Render requests
• QuarkXPress Server responses
52 | A GUIDE TO QUARKXPRESS SERVER 9.0
QUARKXPRESS SERVER MANAGER
• Information about events (such as alerts) that occur during the render-request process
• Details about requests that were sent to a different QuarkXPress Server instance after the
first assigned QuarkXPress Server instance was unable to process the request
Within the logs, each QuarkXPress Server instance is identified by its IP address and port
number.
You can export log files in XML (Extensible Markup Language) or comma-separated values
(CSV) format. For more information, see "Exporting log files"
Caching
To increase speed and efficiency, QuarkXPress Server Manager caches information in
memory. If the response to a render request, URL request, or file request is included in the
QuarkXPress Server Manager memory cache, QuarkXPress Server Manager returns the
response from the disk cache instead of sending the request to a QuarkXPress Server
instance. For more information, see "Managing the cache"
Requests that contain a binary parameter and multipart responses are not cached, regardless
of whether global caching or command-specific caching is enabled.
When the QuarkXPress Server Manager server application receives response data from a
QuarkXPress Server instance, QuarkXPress Server Manager can return that response directly
or write it as a file and return the file's URL. The second approach maximizes efficiency
for SOAP-based clients, because SOAP transfers binary data very slowly. Cached response
files have names that begin with "TMP_", and they are removed when they reach the age
specified in the cache settings (see "Managing the cache"). QuarkXPress Server Manager uses
the cache file this way regardless of whether caching is turned on or off; however, you can
override this behavior by setting the responseasurl parameter to false for every request.
Web services
QuarkXPress Server Manager provides a Web services interface that makes it easy for
developers to create applications that use QuarkXPress Server. This Web services interface
provides the same functionality that is available through the QuarkXPress Server HTTP
interface. For more information about the Web services interface, see the QuarkXPress Server
Web Integration Guide.
Working with QuarkXPress Server Manager
The general process for using QuarkXPress Server Manager is as follows:
Install QuarkXPress Server Manager software.
1
Launch one or more QuarkXPress Server instances on your network.
2
A GUIDE TO QUARKXPRESS SERVER 9.0 | 53
QUARKXPRESS SERVER MANAGER
Launch the QuarkXPress Server Manager Console server application (see Starting the Manager
3
server application").
Launch the QuarkXPress Server Manager client application (see Starting the Manager
4
client application").
Using the QuarkXPress Server Manager client application, connect to a QuarkXPress Server
5
Manager server (see "Starting QuarkXPress Server Manager").
Use the Manage QuarkXPress Server pane of the QuarkXPress Server Manager window
6
to add QuarkXPress Server instances and specify information about those servers (see
"Configuring QuarkXPress Server instances").
Configure logging options, caching options, a load-balancing method, proxy server settings,
7
automatic e-mail settings, and various other settings in the Global Settings pane of the
QuarkXPress Server Manager window (see "Controlling load balancing," "Using a proxy
server," "Generating automatic e-mail messages," and "Using other global settings").
As necessary, export and delete logs using the Manage Logs pane of the
8
QuarkXPress Server Manager window (see "Managing logs").
As necessary, delete cache items and clear the QuarkXPress Server Manager server cache
9
using the Manage Cache pane of the QuarkXPress Server Manager window (see "Managing
the cache").
Starting QuarkXPress Server Manager
You can use one copy of the QuarkXPress Server Manager client application to administer
multiple copies of the QuarkXPress Server Manager server application (but only one at a
time). Each QuarkXPress Server Manager server can handle multiple QuarkXPress Server
instances.
QuarkXPress Server Manager diagram
54 | A GUIDE TO QUARKXPRESS SERVER 9.0
QUARKXPRESS SERVER MANAGER
Starting the Manager server application
To launch the QuarkXPress Server Manager server application:
•
Mac OS: Open the QuarkXPress Server Manager/Server folder inside the applications
folder and double-click "QXPSMServerStart.command."
• Windows (if you have not installed QuarkXPress Server Manager as a service): Choose Start >
Programs > QuarkXPress Server Manager 9 > Start QuarkXPress Server Manager.
Alternatively, open the "Server" folder in the QuarkXPress Server Manager application
folder and double-click the "QXPSMServerStart.bat" file as an admnistrator.
You can access API documentation in HTML format by navigating to
http://[server]:[port], where [server] identifies the computer on which
QuarkXPress Server Manager is running and [port] identifies the port it is running on.
Starting the Manager client application
To launch the QuarkXPress Server Manager client application:
•
Mac OS: Open the QuarkXPress Server Manager/Client folder inside the applications
folder and double-click the "QuarkXPress Server Manager Client" icon.
• Windows: Choose Start > Programs > QuarkXPress Server Manager 9 > Client
Administrator. Alternatively, open the "Client" folder in the QuarkXPress Server Manager
application folder and double-click the "AdminClientStartup.bat" file.
When you launch the QuarkXPress Server Manager client application, the Log On dialog
box displays.
Log On dialog box
To log on to a particular QuarkXPress Server Manager server:
Do one of the following things:
1
• Choose the server name or IP address from the Server Name/IP Address drop-down menu.
A GUIDE TO QUARKXPRESS SERVER 9.0 | 55
QUARKXPRESS SERVER MANAGER
• Choose Add Server from the Server Name/IP Address drop-down menu, choose http or
https, and then enter the server's DNS name or IP address, followed by the server's port
number, in the fields below the drop-down menu.
Click OK. The QuarkXPress Server Manager window displays.
2
Request handler binding
When you add a QuarkXPress Server instance to QuarkXPress Server Manager, you can
choose to bind that server instance to particular rendering type or request type. When
QuarkXPress Server Manager receives a matching request, it will send the request to only
those server instances that are bound to that rendering type or request type. If multiple
server instances are bound to a particular rendering type or request type, QuarkXPress Server
Manager balances the load of such requests between the server instances.
An instance of QuarkXPress Server Manager that is not bound to any specific type of
request is called a generic server. If a request is not bound to a particular server instance,
QuarkXPress Server Manager sends that request to a generic server. If more than one generic
server is available, QuarkXPress Server Manager balances the load of such requests between
them.
You can bind a server to more than one rendering type or request type.
Configuring QuarkXPress Server instances
The Manage QuarkXPress Server pane of the QuarkXPress Server Manager window lists
the QuarkXPress Server instances the QuarkXPress Server Manager server is handling. You
can use this pane to add QuarkXPress Server instances, edit the description of existing
QuarkXPress Server instances, and delete QuarkXPress Server instances.
56 | A GUIDE TO QUARKXPRESS SERVER 9.0
Manage QuarkXPress Server pane
QUARKXPRESS SERVER MANAGER
Adding and enabling a QuarkXPress Server instance
When you add and enable a QuarkXPress Server instance in the Manage
QuarkXPress Server pane of the QuarkXPress Server Manager window, the
QuarkXPress Server Manager server begins routing rendering requests to that
QuarkXPress Server instance.
If you add and enable a QuarkXPress Server instance in this pane, be sure that clients are
no longer sending rendering requests directly to that QuarkXPress Server instance; otherwise,
the server will be handling both direct requests and routed requests, and the server might
become overly busy. Note also that requests sent directy to such a QuarkXPress Server
instance do not benefit from QuarkXPress Server Manager features such as load balancing,
caching, and logging.
To add and enable a QuarkXPress Server instance:
Display the Manage QuarkXPress Server pane of the QuarkXPress Server Manager
1
window.
Click Add. The Add QuarkXPress Server dialog box displays.
2
A GUIDE TO QUARKXPRESS SERVER 9.0 | 57
QUARKXPRESS SERVER MANAGER
Add QuarkXPress Server dialog box
Enter the QuarkXPress Server instance's DNS name or IP address in the Name/IP Address
3
field.
Enter the QuarkXPress Server instance's port number in the Port Number field.
4
If the QuarkXPress Server instance is running with the HTTPS protocol, check Use HTTPS.
5
To specify an alternate name for the server, enter a value in the Alias field. The Alias value
6
displays in the Manage QuarkXPress Server pane of the QuarkXPress Server Manager
window.
If you choose to use a particular ping document for this server (see "Ping document"), make
7
sure the project file is in the QuarkXPress Server instance's document pool and then enter
the project's file name in the Ping Document field. The ping document is used only if
the global Ping Type is set to Ping Document (see "Using other global settings"). Note that
if you do not set a ping document here, and no global ping document is set (see "Using
other global settings"), an error message might display to indicate that the server is registered
but inactive.
Enter the QuarkXPress Server instance user name and password in the Admin User and
8
Admin Password fields.
To restrict this server to one or more particular types of rendering, check the appropriate
9
boxes in the Request Binding area. To add additional render types (for example, render
types provided by QuarkXPress Server XTensions software), check Other and enter the
58 | A GUIDE TO QUARKXPRESS SERVER 9.0
QUARKXPRESS SERVER MANAGER
appropriate namespaces in the corresponding field as a comma-separated list. For more
information, see "Request handler binding."
To specify that QuarkXPress Server Manager should begin sending rendering requests to
10
this QuarkXPress Server instance, check Enable.
Click OK.
11
Editing a QuarkXPress Server instance
To edit the description of a QuarkXPress Server instance, display the Manage
QuarkXPress Server pane of the QuarkXPress Server Manager window, select the server
in the list, and then click Edit. The options in the Edit QuarkXPress Server dialog box
are the same as the options in the Add QuarkXPress Server dialog box (see "Adding and
enabling a QuarkXPress Server instance").
Enabling and disabling routing to QuarkXPress Server instances
The Status column in the Manage QuarkXPress Server pane of the QuarkXPress Server
Manager window shows the status of each QuarkXPress Server instance. A green icon
indicates that the server successfully replied to the last ping or ping document request, a
red icon indicates that the server is not responding, and a gray icon indicates that the
server is inactive or disabled.
The status list is not updated automatically. To update the list with the current status of
all servers, click Refresh.
To enable routing to a QuarkXPress Server instance, do one of the following things:
• Control+click/right-click the server name to display a context menu and then choose
Enable.
• Select the server, click Edit to display the Edit QuarkXPress Server dialog box, check
Enable, and then click OK.
To disable routing to a QuarkXPress Server instance, do one of the following things:
• Control+click/right-click the server name to display a context menu and then choose
Disable.
• Select the server, click Edit to display the Edit QuarkXPress Server dialog box, uncheck
Enable, and then click OK.
A GUIDE TO QUARKXPRESS SERVER 9.0 | 59
QUARKXPRESS SERVER MANAGER
Manage QuarkXPress Server pane
Displaying information about a QuarkXPress Server instance
To display information about a QuarkXPress Server instance, double-click the server's name
in the Manage QuarkXPress Server pane of the QuarkXPress Server Manager window.
The QuarkXPress Server Details dialog box displays.
QuarkXPress Server Details dialog box
Deleting a QuarkXPress Server instance
To delete a QuarkXPress Server instance from the list of available servers in the
QuarkXPress Server Manager window, display the Manage QuarkXPress Server pane of
60 | A GUIDE TO QUARKXPRESS SERVER 9.0
the QuarkXPress Server Manager window, select the server name or IP address, and then
click Delete.
Deleting a QuarkXPress Server instance from this dialog box does not shut down the
QuarkXPress Server instance, but it does prevent the QuarkXPress Server Manager server
from routing rendering requests to the QuarkXPress Server instance.
Managing the cache
Each QuarkXPress Server Manager server has an in-memory cache (in which it stores the
keys to recently accessed items) and a disk-based cache (in which the items themselves
are stored). If a request for a recently used item arrives, and a QuarkXPress Server Manager
server has that request in its memory cache, the server can simply return the response
from its disk cache instead of having to send the request to a QuarkXPress Server instance.
Requests are stored in the cache only if the cache is turned on. For more information, see
"Configuring cache options."
The cache stores only the results of requests that do not deliberately bypass the cache.
QUARKXPRESS SERVER MANAGER
Viewing a QuarkXPress Server Manager server cache
To view QuarkXPress Server Manager cache information, display the Manage Cache pane
of the QuarkXPress Server Manager window. For each file in the cache, this pane lists
the command, URL, size, and time and date it was generated. To view a cache file,
double-click the file name in the list.
Manage Cache pane
A GUIDE TO QUARKXPRESS SERVER 9.0 | 61
QUARKXPRESS SERVER MANAGER
Deleting files from the cache
There is usually no need to manually delete files from a QuarkXPress Server Manager
server's cache. When the cache reaches 95% of its capacity, QuarkXPress Server Manager
automatically begins deleting the least recently used files in the cache to make room for
new files. However, you can also manually clear files from the cache.
To manually delete cache files:
If you want to delete specific files, select those files in the list.
1
Click Clear Cache. The Clear Cache alert displays.
2
If you want to delete specific files, uncheck Delete all cache files. If you want to clear all
3
files from the cache, check Delete all cache files.
Click OK.
4
Configuring cache options
To configure cache options, display the Cache Settings pane in the Global Settings pane
of the QuarkXPress Server Manager window.
• To set the maximum number of files allowed in the cache, enter a value in the Cache
Count field. When the number of files in the cache reaches the number you set here,
QuarkXPress Server Manager begins deleting the least recently used files to make room in
the cache.
• To set the maximum disk cache size, enter a value in the Cache Disk Size field. When the
disk cache reaches this size, QuarkXPress Server Manager begins deleting the least recently
used files to make room in the cache.
• To specify an interval after which the cache should be periodically cleared, enter a value
in the Cache Cleanup Interval field.
• To specify where cache files for the QuarkXPress Server Manager server should be stored,
enter a path in the Cache Folder field.
• The Cache radio buttons let you control caching for the QuarkXPress Server Manager
server. To turn caching on, click On. To turn caching off, click Off.
62 | A GUIDE TO QUARKXPRESS SERVER 9.0
Cache Settings pane
QUARKXPRESS SERVER MANAGER
Managing logs
A QuarkXPress Server Manager server maintains logs of all of the requests it receives, the
responses from the QuarkXPress Server instances, information about events (such as alerts)
that occur during the render-request process, dates and times, and details about each
request that was sent to a different QuarkXPress Server instance after its first assigned
QuarkXPress Server instance was unable to process the request.
To control what information is stored in the logs, use the Log Settings pane in the Global
Settings pane of the QuarkXPress Server Manager window. For more information, see
"Configuring logging options."
A GUIDE TO QUARKXPRESS SERVER 9.0 | 63
QUARKXPRESS SERVER MANAGER
Manage Logs pane
Exporting log files
You can export log files to your local file system in XML and CSV format. To export a log
file, display the Manage Logs pane of the QuarkXPress Server Manager window,
Control+click/right-click the log file's name and choose Export as XML or Export to CSV
format.
Viewing log file details
To view information about a log file, display the Manage Logs pane of the
QuarkXPress Server Manager window, and then either double-click the log file name or
Control-click/right-click the log file name and choose View Log Details. The log detail
information displays in your system's default Web browser.
Deleting log files
To delete log files:
Display the Manage Logs pane of the QuarkXPress Server Manager window.
1
Select the one or more log file names in the list.
2
Click Delete. The Clear Logs dialog box displays.
3
To delete only the selected files, uncheck Delete all log files and then click OK. To delete
4
all log files, check Delete all log files and then click OK.
Configuring logging options
To configure logging options, display the Log Settings pane in the Global Settings pane
of the QuarkXPress Server Manager window.
64 | A GUIDE TO QUARKXPRESS SERVER 9.0
QUARKXPRESS SERVER MANAGER
To set the maximum log file size, enter a value in the Max Log File Size field. When a log
file reaches this size, the current log file is closed and a new log file is created.
To specify the maximum number of log files to keep, enter a value in the Max Rolling
Count field. When the number of log files reaches this limit, QuarkXPress Server Manager
deletes the oldest log file each time a new log file is created.
To specify the root name of the log file for the QuarkXPress Server Manager server, enter
that name in the Log File field. To place the log file in a particular directory, precede the
file name with an absolute path. QuarkXPress Server Manager appends numbers to this
name to create consecutively named log files.
To control how much information is stored in the log files, check a box in the Logging
Level area:
• Debug: Stores information such as the commands executed and the servers where those
commands are executed. Also stores all of the information that is stored when Information,
Warning, and Error are checked.
• Information: Stores informational messages such as startup messages and command-retry
messages. Also stores all of the information that is stored when Warning and Error are
checked.
• Warning: Stores warning messages. Also stores all of the information that is stored when
Error is checked.
• Error: Stores error messages and stack traces for exceptions.
The Debug and Information settings produce large logs that grow rapidly, so you might
want to use these settings for troubleshooting only.
A GUIDE TO QUARKXPRESS SERVER 9.0 | 65
QUARKXPRESS SERVER MANAGER
Log Settings pane
Controlling load balancing
Load balancing ensures that each rendering request is sent to a QuarkXPress Server instance
that is most likely to be able to handle it quickly. To define a load-balancing setting for
the QuarkXPress Server Manager server, display the Load Balancer Method pane in the
Global Settings pane of the QuarkXPress Server Manager window and then choose an
option from the Choose Load Balancer drop-down menu.
QuarkXPress Server Manager lets you use choose from three load-balancing settings:
• Dynamic: Sends requests to servers based on file size
• Random: Sends each rendering request to a random server
• Round robin: Sends requests to servers in a set order
For more information about these load-balancing settings, see "Load balancing"
66 | A GUIDE TO QUARKXPRESS SERVER 9.0
Load Balancer Method pane
QUARKXPRESS SERVER MANAGER
Using a proxy server
Some networks route network traffic through a proxy server for reasons of efficiency or
security. To use a proxy server for all requests and responses between QuarkXPress Server
Manager and QuarkXPress Server:
Display the Proxy Server Settings pane in the Global Settings pane of the
1
QuarkXPress Server Manager window.
Check Use a Proxy Server for my LAN.
2
Enter the proxy server's DNS name or IP address in the Address field.
3
Enter the proxy server's port number in the Port Number field.
4
Enter the proxy server's user name in the User Name field.
5
Enter the proxy server's password in the Password field.
6
A GUIDE TO QUARKXPRESS SERVER 9.0 | 67
QUARKXPRESS SERVER MANAGER
Proxy Server Settings pane
Generating automatic e-mail messages
You can configure a QuarkXPress Server Manager server to automatically generate and
send e-mail messages if particular events occur. To configure the QuarkXPress Server
Manager server to automatically send e-mail messages:
Display the SMTP Settings pane in the Global Settings pane of the QuarkXPress Server
1
Manager window.
Enter a valid SMTP server name or IP address in the SMTP Server field and then enter the
2
corresponding port number in the Port Number field.
Enter the e-mail address to which messages should be sent in the Admin Email ID field.
3
If this SMTP server requires validation, enter a valid user name in the UserName field and
4
a valid password in the Password field.
68 | A GUIDE TO QUARKXPRESS SERVER 9.0
SMTP Settings pane
QUARKXPRESS SERVER MANAGER
Two events can cause QuarkXPress Server Manager to generate an e-mail message:
• If Inactive Host E-mail Notification is checked (see "Using other global settings"), a message
is sent when a QuarkXPress Server instance goes from the active state to the inactive state.
• If you have set up custom error messages (as described in "Using custom error messages"),
certain QuarkXPress Server errors result in e-mail messages.
Using other global settings
To configure other global settings, display the Other Settings pane in the Global Settings
pane of the QuarkXPress Server Manager window and then use the following controls:
• Max Retries: To specify the maximum number of times the QuarkXPress Server Manager
server should submit a request to the QuarkXPress Server instances, enter a value in this
field. When QuarkXPress Manager has unsucessfully submitted a request this many times,
the application returns an error message.
• Request Timeout: To specify the maximum number of minutes the QuarkXPress Server
Manager server should wait for a response from a QuarkXPress Server instance, enter a
value in this field. When this time has elapsed, the QuarkXPress Server Manager server
retries the request (unless the Max Retries value has been reached).
• Connection Timeout: To specify the maximum number of seconds the QuarkXPress Server
Manager server should spend attempting to establish a connection with a particular
QuarkXPress Server instance, enter a value in this field.
• Max Connections Per Host: To specify the maximum number of connections the
QuarkXPress Server Manager server should open for a particular QuarkXPress Server instance
before it begins queuing requests, enter a value in this field.
A GUIDE TO QUARKXPRESS SERVER 9.0 | 69
QUARKXPRESS SERVER MANAGER
• Max Total Connections: To specify the maximum number of connections the
QuarkXPress Server Manager server should open for all hosts before it begins queuing
requests, enter a value in this field.
• Ping Interval: To set the amount of time the QuarkXPress Server Manager server should
wait between ping attempts (see "Determining QuarkXPress Server instance availability"), enter
a value in this field.
• Ping Type: To indicate whether QuarkXPress Server Manager should use a simple ping or
a ping document to test a QuarkXPress Server instance, choose an option from this
drop-down menu.
• Ping Document: To indicate which QuarkXPress project the QuarkXPress Server Manager
server should use for ping document requests, enter the project file name in this field.
Make sure a copy of the project file is in each QuarkXPress Server instance's document
pool. Note that individual QuarkXPress Server instances can override this this value by
providing another document name. Note also that a ping document is used only if Ping
Type is set to Ping Document.
• Common Document Pool Usage: Check this box if all managed QuarkXPress Server
instances are using the same document pool. If this box is checked, then upload, delete,
and saveas requests are sent to one of the available servers. If this box is unchecked, then
upload, delete, and saveas requests are sent to all managed servers. Note that you must
manually set each server to point at the common document pool.
• Platform-specific Rendering: A QuarkXPress Server Manager server can send requests
that involve Mac OS project files to a Mac OS-based QuarkXPress Server instance, and send
requests that involve Windows project files to a Windows-based QuarkXPress Server
instance. Setting up the server in this manner can be desirable if the project files involved
use fonts that are available on only one platform or the other. To enable platform-specific
rendering for the QuarkXPress Server Manager server, check this box.
• Inactive Host E-mail Notification: To automatically generate an e-mail message when a
QuarkXPress Server instance becomes inactive, check this box. The e-mail message is sent
to the address specified in the SMTP Settings pane.
70 | A GUIDE TO QUARKXPRESS SERVER 9.0
Other Settings pane
QUARKXPRESS SERVER MANAGER
Saving a server configuration
Changes that you make to a server configuration in the QuarkXPress Server Manager client
are not made to the QuarkXPress Server Manager server until you click Save at the bottom
of the QuarkXPress Server Manager window.
To discard any changes you have made since logging on to the QuarkXPress Server Manager
server, click Refresh. The configuration of the QuarkXPress Server Manager server remains
as it was.
To discard any changes and exit the application, click Quit.
Disabling or enabling a QuarkXPress Server instance from the QuarkXPress Server Manager
client is not considered a configuration change.
Exporting a server configuration
To export a description of the current server configuration in XML format, click Export
Configuration at the bottom of the QuarkXPress Server Manager window and then
specify a location to save the XML file.
Using custom error messages
You can control which errors cause the QuarkXPress Server Manager server application to
send e-mail messages to the address specified in the SMTP Settings pane (see "Generating
automatic e-mail messages"). You can also define which messages are sent when such errors
occur. The first step is to create a custom error code that corresponds to a QuarkXPress Server
error code. After you set up this custom error code, you can specify whether that code
generates an e-mail message and then create custom error messages.
A GUIDE TO QUARKXPRESS SERVER 9.0 | 71
QUARKXPRESS SERVER MANAGER
Creating a custom error code
To create a custom error code:
On the computer where the QuarkXPress Server Manager server application is running,
1
open the following file in a text-editing application:
[application folder]\server\conf\Manager_Server_ErrorCodeMapping.properties
Create a new line containing a QuarkXPress Server specific error code for which you want
2
to generate automatic e-mail messages (with or without a custom text message). Follow
the error code with an equals sign, a unique custom error code, and a return.
Save and close the file.
3
This change will not take effect until you quit and restart the QuarkXPress Server Manager
server application.
dFlagging an error code to generate an e-mail message
To specify that a custom error code should cause an e-mail message to be generated:
Create a unique custom error code for the target QuarkXPress Server error. For more
1
information, see "Creating a custom error code").
On the computer where the QuarkXPress Server Manager server application is running,
2
open the following file in a text-editing application:
[application folder]\server\conf\ManagerErrorCodeMailOption.properties
Create a new line containing the unique custom error code you defined in step 2. Follow
3
the custom error code with a tab, enter a 1 (to send the message) or a 0 (to suppress the
message), and then press Return.
Save and close the file.
4
This change will not take effect until you quit and restart the QuarkXPress Server Manager
server application.
Creating custom error text
To define the text that should be sent in an e-mail message when an error occurs:
Create a unique custom error code for the target QuarkXPress Server error (as described in
1
"Creating a custom error code").
On the computer where the QuarkXPress Server Manager server application is running,
2
open the following file in a text-editing application:
[application folder]\server\conf\ManagerErrorCodeMessage.properties
72 | A GUIDE TO QUARKXPRESS SERVER 9.0
Create a new line containing the unique custom error code you defined in step 2. Follow
3
the custom error code with a tab and then enter the custom text to be returned for that
error.
Save and close the file.
4
This change will not take effect until you quit and restart the QuarkXPress Server Manager
server application.
Sending requests from a browser
Like QuarkXPress Server, QuarkXPress Server Manager lets you send requests from a Web
browser. This capability helps to ensure that you need to make only minimal changes
when you update an application so that it sends requests to a QuarkXPress Server Manager
server instead of a QuarkXPress Server instance.
Assume that a QuarkXPress Server instance expects requests in the following format:
http://[QXPServer]:[port]/[request]?[request_parameters]
If this is the case, a QuarkXPress Server Manager server will expect requests in the following
format:
QUARKXPRESS SERVER MANAGER
http://[QXPSManagerServer]:[port]/qxpsm/request/[request]?[request_parameters]
In other words, a QuarkXPress Server Manager server accepts requests in a format that is
similar to the request format used with a QuarkXPress Server instance. That means you
can get the benefits of QuarkXPress Server Manager without having to completely rewrite
your applications.
Additional parameters
In addition to request-specific parameters, QuarkXPress Server Manager accepts the
following request parameters. These parameters can be submitted in the standard
QuarkXPress Server GET format joined by an ampersand (&) with the other parameters in
the body of the request.
•
qxpsm_bypassfileinfo: When QuarkXPress Server Manager receives a request, it executes
a fileinfo request on the document to get the document's size and last-modified date
and time. These values are used for load balancing and for determining whether to serve
the document from the cache. If the value of this parameter is set to true, the fileinfo
request is not made, file size is considered to be zero for load-balancing purposes, and the
document in the cache is considered to have changed.
•
qxpsm_context: Set this value if you need to use it in a custom load balancer.
•
qxpsm_maxtries: This parameter lets you specify a maximum number of retries for a
specific request. If this parameter is absent or set to 0, the global maximum retries value
is used. To disable maximum retries for a request, use the value –1.
•
qxpsm_password: The value of this parameter, if supplied, is used as the "Admin Password"
value when the request is forwarded to a QuarkXPress Server instance.
A GUIDE TO QUARKXPRESS SERVER 9.0 | 73
QUARKXPRESS SERVER MANAGER
•
qxpsm_responseasurl: By default, QuarkXPress Server Manager writes responses as
temporary files in the cache folder and returns a URL to the client. This approach prevents
the performance degradation that can result from sending binary data using SOAP. However,
you might want QuarkXPress Server Manager to return the response directly if you are
creating an application that processes that response (simple or multipart) with its own
logic. To make QuarkXPress Server Manager send a response to the browser rather than
the URL of the temporary files in the cache, set this value to false. (Note that setting this
value to false might result in decreased performance.)
•
qxpsm_responseredirect: If you use servlet methodology to send a request to
QuarkXPress Server Manager with qxpsm_responseasurl=true, QuarkXPress Server
Manager returns a frameset page with one or more frames. If the response is not multipart,
the frameset contains a single page with a URL pointing to a response file in the temporary
cache. This can be problematic if, for example, you want to use the returned URL as an
image link in an HTML page. In such situations, submit the request with both
qxpsm_responseredirect=true and qxpsm_responseasurl=true. If you do this,
QuarkXPress Server Manager returns the URL of the rendered file in the temporary cache
instead of returning a frameset page. Note, however, that if the request results in a multipart
response (such as the response returned by the boxes parameter), QuarkXPress Server
Manager ignores the qxpsm_responseredirect=true parameter and returns the frameset
page.
•
qxpsm_servername: By default, the target QuarkXPress Server instance for each request
is determined by the QuarkXPress Server Manager server's load-balancing system. To send
a request to a specific QuarkXPress Server instance, set this parameter to the name or IP
address of that QuarkXPress Server instance. Note that if you use this parameter with an
IP address, you must also submit the port number using the qxpsm_serverport parameter.
•
qxpsm_serverport: If you use the qxpsm_servername parameter with an IP address,
supply the corresponding port number as this parameter's value.
•
qxpsm_timeout: This parameter lets you specify a timeout (in milliseconds) for a specific
request. If this parameter is absent or set to 0, the global timeout value is used. To disable
timeout for a request, use the value –1.
•
qxpsm_usecache: If you set this value to false, the request will be rendered regardless of
whether it is cached and regardless of whether caching is enabled at the global level.
•
qxpsm_username: The value of this parameter, if supplied, is used as the "Admin User"
value when the request is forwarded to a QuarkXPress Server instance.
•
qxpsm_userpassword: The value of this parameter, if supplied, is used as the "Admin
User" password when the request is forwarded to a QuarkXPress Server instance. Default
value is null, which means no password information. If this is not null, you must also
provide qxpsm_username.
74 | A GUIDE TO QUARKXPRESS SERVER 9.0
Glossary
Document pool: The document pool contains the projects that are available for rendering.
By default, the document pool is a collection of discrete files or folders in a specific,
identified folder located on the local server or on a connected network drive. When some
type of external document provider (such as a content management system or database)
is used, projects are not stored in the local document pool.
Document provider: The document provider is the source for projects that
QuarkXPress Server renders. The most basic document provider is the local document
pool. Other document providers can be enabled through the creation of Server XTensions
software, which establish a virtual file system. Server XTensions software can register for
control of a specified range of the QuarkXPress Server namespace. When a project is
requested from this range, server XTensions software retrieves the file from the specified
source and hands it to the server. Examples of document providers include content
management systems such as a standard database,or a live data feed from an HTTP agent.
GLOSSARY
Layout: A layout is a sequence of same-sized pages in a QuarkXPress project. A project can
contain one or more layouts. A layout is functionally equivalent to a QuarkXPress document
in QuarkXPress 5 and earlier.
Project: A QuarkXPress project is a file created by QuarkXPress. A project can contain one
or more layouts.
Rendering: Rendering is the process of generating a file in a particular format (such as
JPEG, EPS, or PDF) from a QuarkXPress layout.
Rendering type: The rendering type is the format in which QuarkXPress Server can render
QuarkXPress layouts. Some rendering types, such as JPEG and PNG, can be displayed in a
Web browser, while others must be saved to the hard drive.
Server XTensions Software (SXT): Server XTensions software is XTensions software written
specifically for QuarkXPress Server. For more information, see the QuarkXPress Server
XTensions Developer's Kit.
Renderer: A renderer is a process launched by QuarkXPress Server to help process rendering
requests. Renderers reside on the same server as QuarkXPress Server and share the same
memory and preferences. When renderers are launched, QuarkXPress Server becomes a
load-balancing "master server," passing incoming requests to renderers for faster response
times.
A GUIDE TO QUARKXPRESS SERVER 9.0 | 75
LEGAL NOTICES
Legal notices
© 1986-2011 Quark, Inc. and its licensors. All rights reserved.
Protected by the following United States Patents: 5,541,991; 5,907,704; 6,005,560;
6,052,514; 6,081,262; 6,633,666 B2; 6,947,959 B1; 6,940,518 B2; 7,116,843; and other
patents pending.
Quark, the Quark logo, Quark Publishing System, and QPS are trademarks or registered
trademarks of Quark, Inc. and its affiliates in the U.S. and/or other countries. All other
marks are the property of their respective owners.
76 | A GUIDE TO QUARKXPRESS SERVER 9.0
