Quantum Tape Drive A-Series, SDLT 600A, LTO-3A User Manual

$
$6HULHV7DSH'ULYHV
$6HULHV7DSH'ULYHV
5SERS'UIDE5SERS'UIDE5SERS'UIDE5SERS'UIDE5SERS'UIDE5SERS'UIDE5SERS'UIDE
Quantum A-Series Tape Drives User’s Guide, 81-81487-03 A01, May 2007.
Quantum Corporation provides this publication “as is” without warranty of any kind, either express or implied, including but not limited to the implied warranties of merchantability or fitness for a particular purpose. Quantum Corporation may revise this publication from time to time without notice.
COPYRIGHT STATEMENT
Copyright 2007 by Quantum Corporation. All rights reserved.
Your right to copy this manual is limited by copyright law. Making copies or adaptations without prior written authorization of Quantum Corporation is prohibited by law and constitutes a punishable violation of the law.
TRADEMARK STATEMENT
Quantum, DLT, DLTtape, The Quantum Logo, and The DLTtape Logo are all registered trademarks of Quantum Corporation. SuperLoader, SDLT, and Super DLTtape are trademarks of Quantum Corporation. Other trademarks may be mentioned herein which belong to other companies.
Quantum A-Series Tape Drives User’s Guide iii
Contents
Preface xi
Chapter 1 Introduction 1
Overview............................................................................................................. 1
Product Features ................................................................................................ 3
Chapter 2 Getting Started 5
Java Plug-in........................................................................................................ 6
The Java Plug-in.......................................................................................... 6
Certificate of Security................................................................................. 6
Resetting System Defaults ................................................................................ 7
Warranty Note.................................................................................................... 9
Safety, Handling, and ESD Protection............................................................ 9
Safety Precautions ...................................................................................... 9
Handling .................................................................................................... 10
Electrostatic Discharge Protection.......................................................... 11
Quantum A-Series Tape Drives User’s Guide iv
Chapter 3 Using Your Tape Drive 12
Front Panel LEDs and Tape Eject .................................................................. 13
SDLT 600A ................................................................................................. 13
LTO-3A....................................................................................................... 16
A-Series Data Cartridges................................................................................. 18
Write-Protect Switch ................................................................................ 18
Write Protecting a SDLT 600A Data Cartridge .................................... 18
Write Protecting an Ultrium Data Cartridge ........................................ 20
Loading a Data Cartridge ........................................................................ 20
Unloading a Data Cartridge.................................................................... 21
Data Cartridge Care and Maintenance.................................................. 22
Power On Self-Test (POST) Troubleshooting .............................................. 23
POST Operation ........................................................................................ 23
POST Troubleshooting Tips .................................................................... 24
Over Temperature Condition ................................................................. 25
Frequently Asked Questions................................................................... 26
Appendix A Specifications 27
A-Series SDLT 600A Tape Drive.................................................................... 28
Laser Guided Magnetic Recording ........................................................ 28
Pivoting Optical Servo ............................................................................. 28
Magneto Resistive Cluster Heads ..........................................................28
Advanced Partial Response Maximum Likelihood............................. 29
Advanced Metal Powder Media............................................................. 29
Positive Engagement Tape Leader Buckling Mechanism................... 29
Modular Design ............................................................................................... 29
Data Control Module ............................................................................... 31
Tape Control Module............................................................................... 31
Front Panel Module.................................................................................. 32
Electronic Interface Module .................................................................... 33
Super DLTtape II Data Cartridge ........................................................... 33
Product Specifications ..................................................................................... 34
Positive Engagement Tape Leader Buckling Mechanism................... 34
Functional Specifications ................................................................................ 34
Performance Data ..................................................................................... 34
Shock and Vibration Specifications........................................................ 35
Current and Power Requirements ......................................................... 38
SDLT 600A Tape Drive Recording Method.......................................... 41
Environmental Specifications......................................................................... 41
Quantum A-Series Tape Drives User’s Guide v
Air Flow Requirements............................................................................ 41
Temperature and Humidity.................................................................... 41
Storage and Shipment .............................................................................. 42
Altitude ...................................................................................................... 43
Recording Media Specifications..................................................................... 43
Media Structure......................................................................................... 43
Physical Data Cartridge ........................................................................... 44
Media Shipping, Operating, and Storage Specifications ....................45
A-Series LTO-3A Tape Drive ......................................................................... 46
Power Specifications........................................................................................46
Drive Performance Specifications.................................................................. 47
Environmental Requirements ........................................................................ 49
Reliability Specifications ................................................................................. 50
Mean Time Between Failures.................................................................. 50
Mean Time to Replace.............................................................................. 51
LTO Cartridge Specifications ......................................................................... 51
Environmental Considerations............................................................... 51
Cartridge Memory....................................................................................52
Cartridge Reliability ................................................................................. 52
Appendix B Data Cartridges 53
Using Data Cartridges for the SDLT 600A................................................... 53
Data Cartridge Handling Guidelines............................................................ 54
Data Cartridge Inspection Procedure ........................................................... 56
Data Cartridge Write-Protect Switch ............................................................ 60
Using Data Cartridges for the LTO-3A......................................................... 62
Loading a Tape Cartridge........................................................................ 62
Unloading a Tape Cartridge ................................................................... 62
Write Protecting a Tape Cartridge ......................................................... 63
Tape Cartridge Care and Maintenance ................................................. 64
Cleaning the Tape Mechanism....................................................................... 65
Occasional Cleaning of Tape Head ........................................................ 65
SDLT 600A ................................................................................................. 65
Life Expectancy of the Cleaning Tape ................................................... 65
Compatibility of the Cleaning Tape....................................................... 66
Loading the Cleaning Tape Into a Tabletop Tape Drive..................... 66
LTO-3A....................................................................................................... 66
Performing an Emergency Reset and Cartridge Eject ................................ 68
Loading a Data Cartridge ............................................................................... 69
Unloading a Data Cartridge ...........................................................................70
Quantum A-Series Tape Drives User’s Guide vi
Appendix C Regulatory Compliance 71
SDLT 600A ........................................................................................................ 72
Safety Certifications.................................................................................. 72
Electromagnetic Field Specifications ..................................................... 72
Electromagnetic Emissions...................................................................... 72
Electromagnetic Interference Susceptibility ......................................... 73
Immunity and ESD Limits....................................................................... 73
Acoustic Noise Emissions........................................................................74
LTO-3A.............................................................................................................. 75
Environmental Compliance............................................................................ 77
Perchlorate Material ................................................................................. 77
Disposal of Electrical and Electronic Equipment ....................................... 78
Glossary 79
Quantum A-Series Tape Drives User’s Guide vii
Figures
Figure 1 SDLT 600A Tabletop Drive......................................................... 2
Figure 2 Certificate of Security .................................................................. 7
Figure 3 SDLT 600A Front Panel Display .............................................. 13
Figure 4 LTO-3A Front Panel Display.................................................... 16
Figure 5 Super DLTtape II Data Cartridge ............................................ 18
Figure 6 Write-protect Switch on Super DLTtape II Data Cartridge . 19
Figure 7 Write-protect Switch on Ultrium Data Cartridge.................. 20
Figure 8 Loading a Super DLTtape II Data Cartridge.......................... 21
Figure 9 SDLT 600A Tape Drive Front Panel LEDs.............................. 24
Figure 10 SDLT 600A Tape Drive Modular Design................................ 30
Figure 11 Multiple Layers Comprise Super DLTtape II Media ............ 44
Figure 12 Super DLTtape II Data Cartridge ............................................ 44
Figure 13 Super DLTtape II Media Shipping Limits .............................. 45
Figure 14 Super DLTtape II Data Cartridge ............................................ 54
Figure 15 Bottom View of Super DLTtape II Data Cartridge................ 57
Figure 16 Super DLTtape II Data Cartridge Reel Locks ........................ 58
Figure 17 Opening the Super DLTtape II Data Cartridge Door ........... 58
Quantum A-Series Tape Drives User’s Guide viii
Figure 18 Problems to Look for Inside the Data Cartridge Door.......... 59
Figure 19 Write-Protect Switch on Super DLTtape II Data Cartridge . 60
Figure 20 Ultrium Tape Cartridge Write-Protect Switch....................... 63
Figure 21 Loading a Super DLTtape II Data Cartridge.......................... 69
Quantum A-Series Tape Drives User’s Guide ix
Tables
Table 1 Storage Capacity and Transfer Rates ........................................ 3
Table 2 System Defaults............................................................................ 8
Table 3 SDLT 600A LED Codes ............................................................. 14
Table 4 LTO-3A LED Codes ................................................................... 17
Table 5 LED Lighting Pattern During Power-On Self-Test (POST).. 23
Table 6 Troubleshooting Chart .............................................................. 25
Table 7 SDLT 600A Tape Drive Performance Data............................. 34
Table 8 Non-operating Shock Specifications (Unpackaged) ............. 35
Table 9 Non-Operating Shock Specifications (Packaged, Drop)....... 36
Table 10 Non-Operating Vibration Specifications (Unpackaged) ...... 36
Table 11 Non-Operating Vibration Specifications (Packaged)............ 37
Table 12 Operating Shock and Vibration Specifications ...................... 37
Table 13 Current Requirements — SCSI Interface ................................ 38
Table 14 Power Requirements — SCSI Interface................................... 40
Table 15 Temperature and Humidity Specification.............................. 42
Table 16 Tape Drive Storage and Shipment Specifications ................. 42
Table 17 Super DLTtape II Media Specifications .................................. 43
Quantum A-Series Tape Drives User’s Guide x
Table 18 Super DLTtape II Media Operating Limits ............................ 45
Table 19 Super DLTtape II Media Storage Limits ................................. 45
Table 20 LTO-3A Physical Specifications ............................................... 46
Table 21 Drive Performance Specifications............................................47
Table 22 Environmental Requirements................................................... 49
Table 23 Reliability Specifications ........................................................... 50
Table 24 Environmental Tolerances ........................................................ 51
Table 25 Write-Protect Switch Positions.................................................61
Table 26 EMI Regulations and Certifications......................................... 73
Table 27 Immunity and ESD Failure Level Limits ................................ 73
Table 28 Acoustic Noise Emissions, Nominal........................................ 74
Table 29 Safety Compliance...................................................................... 75
Table 30 Electromagnetic Compatibility (EMC) Compliance.............. 76
Quantum A-Series Tape Drives User’s Guide xi
Preface
This document serves as an easy-to-use information source to familiarize Quantum customers and systems professionals with the A-Series tape drives.
Audience
The primary audience for this document consists of end users installing and using the tape drive.
Purpose
This document provides information on the A-Series tape drives including:
•Product features
Safety, handling, and ESD protection
Resetting system defaults
The Java Plug-in
Front panel LEDs
Regulatory compliance and statements
Quantum A-Series Tape Drives User’s Guide xii
Document Organization
This document is organized as follows:
Chapter 1,
Introduction, provides an overview of the tape drive and
product features.
Chapter 2,
Getting Started, includes information on the Java Plug-in,
resetting system defaults, and warranty, safety, handling, and ESD precautions.
Chapter 3,
Using Your Tape Drive, provides information on the front
panel controls and LEDs, data cartridges, and POST.
Appendix A,
Specifications, provides product, functional,
environmental, and recording media specifications.
Appendix B,
Data Cartridges, provides information on recognizing,
handling, inspecting, write-protecting, loading, and unloading cartridges.
Appendix C,
Regulatory Compliance, provides electromagnetic field
specifications, acoustic noise emissions, and environmental compliance.
This document concludes with a glossary.
Notational Conventions
This document uses the following conventions:
Note: Notes emphasize important information related to the main
topic.
Caution: Cautions indicate potential hazards to equipment and are
included to prevent damage to equipment.
Warning: Warnings indicate potential hazards to personal safety and
are included to prevent injury.
Quantum A-Series Tape Drives User’s Guide xiii
This document uses the following:
Right side of the tape drive — Refers to the right side as you face the component being described.
Left side of the tape drive — Refers to the left side as you face the component being described.
Power cycle — Means to turn the tape drive or system on, then turn them off (or off, then on).
Dimensions in figures — All dimensions are shown with no units specified (Inches understood unless otherwise specified).
Related Documents
The following documents are related to the A-Series tape drives:
Contacts
Quantum company contacts are listed below.
Quantum Corporate Headquarters
0
To order documentation on the A-Series tape drives or other Quantum products, contact:
Quantum Corporation P.O. Box 57100 Irving, CA 92619-7100 (949) 856-7800 (800) 284-5101
Document No. Document Title Document Description
81-81488-0x A-Series Tape Drives
Quick Start Guide
Provides “quick” instructions on how to install and run the tape drive.
81-81800-0x A-Series FTP File Server
User’s Guide
Provides information on how to use the FTP file server.
Quantum A-Series Tape Drives User’s Guide xiv
Technical Publications 0
To comment on existing documentation send e-mail to:
doc-comments@quantum.com
Quantum Home Page 0
Visit the Quantum home page at:
http://www.quantum.com
Getting More Information or Help
StorageCare™, Quantum’s comprehensive service approach, leverages advanced data access and diagnostics technologies with cross­environment, multi-vendor expertise to resolve backup issues faster and at lower cost.
Accelerate service issue resolution with these exclusive Quantum StorageCare services:
Service and Support Website - Register products, license software,
browse Quantum Learning courses, check backup software and operating system support, and locate manuals, FAQs, firmware downloads, product updates and more in one convenient location. Benefit today at: www.quantum.com/support
.
eSupport - Submit online service requests, update contact
information, add attachments, and receive status updates via email. Online Service accounts are free from Quantum. That account can also be used to access Quantum’s Knowledge Base, a comprehensive repository of product support information. Sign up today at:
www.quantum.com/support
.
For further assistance, or if training is desired, contact Quantum Technical Assistance Center:
North America: +1-800-284-5101
UK, France and Germany 00800 4 QUANTUM
EMEA +44 1256 848 766
For worldwide support: www.quantum.com/contactsupport
For the most up to date information on Quantum Global Services, please visit www.quantum.com/support
.
Quantum A-Series Tape Drives User’s Guide xv
Software License
The A-Series Tape Drives use edtFTPj 1.4.5 Java API which is under the GNU Lesser General Public License (LGPL) and hence can be freely used in commercial or non-commercial products.
It should be noted, however, that under the LGPL, edtFTPj must be used as a library and not directly incorporated into codebase.
edtFTPj Web site: www.enterprisedt.com/products/edtftpj/
overview.html
GNU Lesser General Public License: www.gnu.org/licenses/
lgpl.html
Quantum A-Series Tape Drives User’s Guide xvi
Quantum A-Series Tape Drives User’s Guide 1
Chapter 1
1Introduction
The Quantum A-Series Tape Drives:
SDLT 600A
•LTO-3A
This chapter describes the features of the tape drives and covers the following topics:
Overview
describes a basic overview of the A-Series tape drives.
Product Features
lists product features of the A-Series tape drives.
Overview
The Quantum A-Series Tape Drives are an extension to the family of products with video professionals in mind. Using the built-in FTP client in conjunction with a standard Web browser, Material Exchange Format (MXF) files can be stored and retrieved. A Gigabit Ethernet (GigE) interface allows these drives to be quickly connected and accessed on your network.
The A-Series tape drives are ideal for serving a full range of video applications; from hand-carrying video content out to a truck for live production to facility-wide, long-term, secure archive.
Chapter 1 Introduction
Overview
Quantum A-Series Tape Drives User’s Guide 2
The A-Series tape drives are available in two configurations, tabletop (as shown in figure 1
) and rackmount.
Figure 1 SDLT 600A Tabletop Drive
Chapter 1 Introduction
Product Features
Quantum A-Series Tape Drives User’s Guide 3
Product Features
The A-Series tape drives offer the following product features:
Table 1 Storage Capacity and Transfer Rates
• The SDLT 600A tape drive allows for over 6 hours of HD (high definition) and over 25 hours of SD (standard definition) storage on a single Super DLTtape II media cartridge.
• The LTO-3A tape drive allows for over 8 hours of HD and over 33 hours of SD storage on a single Ultrium 3 media cartridge.
• Convergent technology — the benefits of file-based data tape storage and the accessibility of video tape.
• Built-in Gigabit Ethernet (GigE) interface.
• Access to metadata and clip content by timecode-indexed in and out points through a web-based interface.
• A standard 5.25-inch full-height form factor to simplify integration into system and tape library solutions.
• iTalk (and Pocket DLTSage iTalk)—Infrared (wireless) interface on the SDLT 600A that provides a remote testing base allowing customers and integrators to access system diagnostic information from the front of the tape drive.
A-Series
Tape Drive
Maximum Storage
Capacity
Maximum Native
Data Transfer Rate
SDLT 600A 300 GB 36 MB/sec
LTO-3A 400 GB 68 MB/sec
Note: There is a limitation on the number of files that can be
stored on a media cartridge based on the size of the files and the size of the filenames stored on the table of contents (TOC) region of the tape. For example, the A-Series SDLT 600A tape drive can hold approximately 8,000 files. This limit can be significantly smaller if the filenames are long and/or there are many MXF files.
Chapter 1 Introduction
Product Features
Quantum A-Series Tape Drives User’s Guide 4
• For more information on the SDLT tape products and other product information, go to www.dlttape.com
.
This Web page provides information that is constantly updated as needed. Refer to this Web site often to obtain the most current information.
Quantum A-Series Tape Drives User’s Guide 5
Chapter 2
2Getting Started
This chapter provides pointers to information you need to install and configure your A-Series tape drive and also to access and use the A-Series FTP file server.
This chapter covers the following topics:
Java Plug-in
provides information about the only software required
on your system.
Resetting System Defaults
provides information on what to do
should you lose the IP address of the A-Series tape drive.
Warranty Note
provides basic warranty information
Safety, Handling, and ESD Protection
describes appropriate
safeguards to use when working with the tape drive.
Note: For information on installing and configuring the Quantum
A-Series Tape Drive, see the Quantum A-Series Tape Drives Quick Start Guide (81-81488-0x).
Note: For information on accessing and using the Quantum A-Series
FTP File Server, see the Quantum A-Series FTP File Server User’s Guide (81-81800-0x).
Chapter 2 Getting Started
Java Plug-in
Quantum A-Series Tape Drives User’s Guide 6
Java Plug-in
The A-Series tape drive utilizes a Web-based interface allowing you to manage the tape drive from a remote workstation on the same network.
The tape drive is configured and managed through Web pages accessible by Internet browser software installed on the host computer.
The only software required on your system is the Java Plug-in. The
Java
Plug-in
is the virtual machine software that allows the execution of Java
applets.
The Java Plug-in 2
The Java FTP client needs the Java Virtual Machine to run. This Java Plug-
in
is provided by Sun Microsystems.
The Java FTP client will install immediately. When you load the Java FTP client for the first time, a display window may ask you to download and install the Java plug-in. If you need that plug-in you can just follow the instructions on the screen or go to www.java.com
to download it.
If you have
Java Plug-in version 1.5 or later or the Java Runtime
Environment
version 1.5 or later installed on your computer, you should not need to download new software. The plug-in should activate on your Web browser automatically once installed. For Mac OSX, the supported JRE version is 1.4.2.
Certificate of Security 2
Since the Java FTP client reaches the local directories of your computer, a certificate of security is required. When the Java FTP client is loaded, the
Java Plug-in displays a window prompting you to accept our certificate of
security (see figure 2
).
Chapter 2 Getting Started
Resetting System Defaults
Quantum A-Series Tape Drives User’s Guide 7
Figure 2 Certificate of Security
Resetting System Defaults
As there is no access to the A-Series tape drive other than the Ethernet port, a mechanism has been implemented to reset the settings to their default values. This is useful if an end user loses the IP address of the A-Series tape drive. The settings can all be set up through the Web manager (i.e. IP settings, root password, ...).
To have the settings set back to their default values:
1 Switch off your tape drive.
2 Disconnect the network cable from the drive.
3 Repeat the following procedure three times:
a Insert a write protected cartridge into the drive.
b Switch on the tape drive.
c After approximately one minute, the cartridge will be ejected.
d Switch off the drive.
Chapter 2 Getting Started
Resetting System Defaults
Quantum A-Series Tape Drives User’s Guide 8
4 After the third ejection, connect your network cable and switch your
cartridge write protection on or off (as you need it), then reboot the drive.
You can now set up the drive using the default IP address (10.10.10.10) as the flash memory has been erased.
Table 2 System Defaults
Name Password/Setting
Static IP address 10.10.10.10
Netmask 255.255.255.0
Main login admin
Username root
Default password password
Chapter 2 Getting Started
Warranty Note
Quantum A-Series Tape Drives User’s Guide 9
Warranty Note
See the warranty before installing your tape drive. Certain actions taken during installation could void the warranty if not properly conducted.
Generally, the Limited Product and Limited Repair Warranties are contingent upon proper use in the application for which the product is intended; and do not cover the product if you perform any of the following actions:
• Modify the product without the manufacturer’s written approval.
• Subject the product to unusual physical, environmental, or electrical stress, including damage caused by handling or shipping in unapproved containers or packaging.
• Disturb any warranty labels, or the integrity of the product in any other way.
• Remove or damage the serial number label to the extent that warranty status of the product cannot be determined.
Safety, Handling, and ESD Protection
Inappropriate or careless handling of the A-Series tape drives may result in damage to the product. Follow the precautions and directions to prevent damaging the tape drive.
Safety Precautions 2
For your safety, follow all safety procedures described here and in other sections of the manual.
1 Power off the system before installing or removing the tape drive to
prevent the possibility of electrical shock or damage to the tape drive. Unplug the unit that contains—or is to contain—the tape drive from AC power to provide an added measure of safety.
2 Read, understand, and observe all label warnings.
Chapter 2 Getting Started
Safety, Handling, and ESD Protection
Quantum A-Series Tape Drives User’s Guide 10
3 The Pivoting Optical Servo (POS) uses a Class I laser product. This
laser product complies with 29 CFR 1200 and 29 CFR 1910 as applicable on the date of manufacture.
Handling 2
Damage to the tape drive can occur as the result of careless handling, vibration, shock, or electrostatic discharge (ESD). For more details about ESD, see Electrostatic Discharge Protection
.
Follow these guidelines to avoid damage to the tape drive:
• Always observe prescribed ESD precautions.
• Keep the external tape drive in its anti-static bag until ready to install.
• Always use a properly fitted wrist strap or other suitable ESD protection when handling the tape drive.
• Hold the tape drive only by its sides.
• Do not bump, jar, or drop the tape drive. Use care when transporting the tape drive.
• Always handle the tape drive carefully and gently. A drop of ¼ inch onto a bench or desktop may damage a tape drive.
• Never place the tape drive so that it rests on its front bezel. Always gently place the tape drive flat, bottom side down, on an appropriate ESD-protected work surface to avoid the tape drive being accidentally knocked over.
• Do not pack other materials with the tape drive in its anti-static bag.
• Place the tape drive in the anti-static bag before placing it in a shipping container.
• Do not stack objects on the tape drive.
Warning: If you open the tape drive chassis, you may become
exposed to invisible laser emission which could be harmful if you are directly exposed to the beam.
Caution: Always handle the A-Series tape drive with care to avoid
damage to the precision internal components. Hold the tape drive only by its sides. Never hold the tape drive by inserting fingers into the receiver area on the front of the tape drive. Damage to the receiver area may occur if you lift or carry it in this manner.
Chapter 2 Getting Started
Safety, Handling, and ESD Protection
Quantum A-Series Tape Drives User’s Guide 11
• Do not expose the tape drive to moisture.
• Do not place foreign objects inside the tape drive’s receiver area.
Electrostatic Discharge Protection 2
Several electrical components of the A-Series tape drive are sensitive to static electricity and electrostatic discharge (ESD). Even a static buildup or discharge that is too slight to feel can be sufficient to destroy or degrade a component’s operation.
To minimize the possibility of ESD-related damage to the system, the drive’s manufacturer strongly recommends using both a workstation anti-static mat and an ESD wrist strap. When correctly installed and properly used, these devices reduce the buildup of static electricity that might harm the system.
Observe the following precautions to avoid ESD-related problems:
• Leave the tape drive in its anti-static bag until you are ready to install it in the system.
• Always use a properly fitted and grounded wrist strap or other suitable ESD protection when handling the tape drive and observe proper ESD grounding techniques.
• Hold the tape drive only by its sides.
• Place the tape drive on a properly grounded anti-static work surface pad when it is out of its protective anti-static bag.
• Do not use the bag as a substitute for the work surface anti-static pad. The outside surface of the bag may not have the same anti-static properties as the inside surface. It could actually increase the possibility of ESD problems.
• Do not remove covers to use any test equipment to check components on the PCBAs. There are no user-serviceable components on the tape drive.
Quantum A-Series Tape Drives User’s Guide 12
Chapter 3
3Using Your Tape Drive
This chapter provides information about the LEDs and buttons on the front panels of the A-Series tape drives, A-Series data cartridges, formatting tape media cartridges, updating the firmware, cleaning the A-Series tape mechanism, and troubleshooting.
For information on the A-Series FTP file server, see the Quantum A-Series FTP File Server User’s Guide (81-81800-0x).
This chapter covers the following topics:
Front Panel LEDs and Tape Eject
describes the functionality of the
front panel controls and LEDs.
A-Series Data Cartridges
provides information about write protecting, loading and unloading, and data cartridge care and maintenance.
Power On Self-Test (POST) Troubleshooting
provides basic
troubleshooting information.
Chapter 3 Using Your Tape Drive
Front Panel LEDs and Tape Eject
Quantum A-Series Tape Drives User’s Guide 13
Front Panel LEDs and Tape Eject
All LEDs are on the front panel of the A-Series tape drives along with the manual tape cartridge eject button. Use these LEDs to monitor the activity of your A-Series tape drive as necessary.
SDLT 600A
LTO-3A
SDLT 600A 3
As shown in figure 3, the SDLT 600A tape drive front panel display has three LED indicators that reflect the operating condition of the drive:
The left LED is dual color (green/orange). This LED is the density indicator. When you insert a Super DLTtape II data cartridge, this LED illuminates green.
Table 3
describes control and LED functionality.
Figure 3 SDLT 600A Front Panel Display
Green/Orange LED
Green LED
Yellow LED
Eject Button
iTalk Port
(Cleaning Required)
(Cartridge Status)
(Drive Status)
Chapter 3 Using Your Tape Drive
Front Panel LEDs and Tape Eject
Quantum A-Series Tape Drives User’s Guide 14
Table 3 SDLT 600A LED Codes
LED/Button/ Port Title
Color/ Symbol Action Explanation
All LEDs All LEDs illuminate
briefly and then illuminate in sequence until the reset completes
SDLT 600A tape drive reset
No LED No LEDs illuminate No data cartridge is inserted
Cartridge Status LED
Green Remains OnSuper DLTtape II data cartridge ejected
Remains OnBlank Super DLTtape II data cartridge inserted
Remains OnSDLT 600A tape drive formatted Super DLTtape II
data cartridge inserted
Cartridge Status LED
Orange On/Off Incorrect cartridge inserted
Drive Status LED
Green
Flashing
The tape drive is in use. This includes functions such as:
• The tape is moving.
• The tape drive is calibrating, reading, writing, or rewinding the tape.
• The tape drive is loading, unloading, or rewinding.
On The tape drive is idle. There may or may not be a data
cartridge in the tape drive.
Off The tape drive has not been powered on or is not
plugged into a power source.
Loading...
+ 75 hidden pages
