QUANTA NL8K Schematics

5

www.vinafix.com

4

3

2

1

NL8K Block Diagram

27MHz

D D

PCIeX16 Gen3

Intel Proccesor

DDR4 SODIMM1

KabyLake-H

NVIDIA GPU

N17P-G0/G1

GDDR5 256Mbx32x4

HDMI Port

01

Processor : Daul / Quad Core

DDR4 SODIMM2

MIC Jack +
Headphone

Power : 45 (Watt)

DDR SYSTEM MEMORY

Package : BGA1400

DMI

Graphics Interfaces

eDP 1.3 X 4

DP

15.6"/17.3" eDP FHD
1920 X 1080 LCD

DDI

MIC Jack +

C C

SPDIF

AUDIO CODEC

HDA

Internal SPK*2
2W/Ch

ALC255

DMI

DMI X 4

CC+PD

CYPD2122-24LQIT

USB 3.1
Type-C X 1

Mux

Amplifer

ALC1003-VB-CGT

Sub-Woofer
3W

DMIC I2C

USB 3.0 Port X 3

USB2.0
USB3.0

32.768KHz25MHz

Intel KBL PCH-H

Platform Controller Hub

USB 2.0 Port X 1

B B

1 W/AOU TPS2546

USB2.0

TDP : W

Camera W/DMIC

SATA HDD

USB2.0

SATA

Package : FCBGA837

Size : 23 x 23 (mm)

PCIex2

PCIE

PCIE

USB2.0
PCIE

USB3.1 host

ASM1142

20MHz

Card Reader
RTS5227S

LAN

RTL8111H-CGT

25MHz

mPCIE WIFI/BT

TUSB1046

USB 3.1
Type-A X 1

2 in 1 Socket

SD/MMC (SD3.0)

RJ45

BIOS

SPI

LPC

SATA

NGFF - SSD

SPI Flash (8MB)

EC
IT8987

A A

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

Monday, October 17, 2016

Monday, October 17, 2016

Monday, October 17, 2016

1

PROJECT :

NL8E Block Diagram

NL8E Block Diagram

NL8E Block Diagram

1

1

1

Int. KB ClickPad

5

4

Charger BatteryThermal

3

2

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

1ACustom

1ACustom

1ACustom

66

66

66

5

4

3

2

1

Host CLK:
Trace length < 11000 MILS
Trace spacing = 15 ,20 MILS, Impendence 90 ohm

CLK_CPU_BCLKP(11)

H_PECI (50ohm)

D D

CPU RESET#

+VCCSTPLL

C C

THERMTRIP# (50ohm)
Trace Length: 1.1~12 inches

Ra

R492

Ra(R10804) Not install in SKL-H

*10K_4

PROC_SEL#

R493
*0_4

HPECI Ra,Ca need placement close to PCH.

PCH_PECI(11)
EC_PECI(32)

CPU_PLTRST# (50ohm)
Trace Length: 10~17 inches

CPU_PLTRST#R(11)

PLTRST#(12,23,24,25,26,29,30,32,53)

R590 12.1/F_4

Ra

C777 *47P/50V_4

Ca

Trace Length: <0.5 iches

EC_PECI

PROCHOT# (50ohm)
Trace Length <11 inches

H_PROCHOT#(32,33,39,52)

C688 *47P/50V_4

Cb

DDR_VTT_CNTL(16)

R479 *1.5K/F_4
R480 *750/F_4

H_PM_DOWN(11)

PM_SYNC (50ohm)
Trace Length: 1~11.25 inches

PM_THRMTRIP#(11,16,17,32)

CPU_PCI_BCLKN(11)

R483 499K/F_4

PROCPWRGD(10)

SKTOCC_N_R(13)

+VCCSTPLL

CLK_CPU_BCLKN(11)

CPU_PCI_BCLKP(11)

CLK_DPLL_NSCCLKP(11)

CLK_DPLL_NSCCLKN(11)

Cb need placment near VR

PROCPWRGD (50ohm)
Trace Length: 1~11.25 inches

R75 *10K_4

PM_SYNC(11)

R488 *10K_4

R481 20_4

CFG

CPU CORE SVID

Layout note: need routing together and ALERT need between CLK and DATA.

B B

CLOSE TO CPU
PLACE THE PU RESISTORS

H_CPU_SVIDALRT#

PLACE THE PU RESISTORS
CLOSE TO VR
PULL UP IS IN THE VR MODULE

VR_SVID_CLK_R

CLOSE TO CPU
PLACE THE PU RESISTORS

A A

H_CPU_SVIDDAT

R489 220/F_4

R486 *0_4/S

R499 *0_4/S

5

+VCCSTPLL

+VCCSTPLL

R485
*54.9/F_4

+VCCSTPLL

R487

56.2/F_4

C694
*0.1U/16V_4

R498
100/F_4

SVID ALERT

VR_SVID_ALERT# (39)

SVID CLK

VR_SVID_CLK (39)

SVID DATA

VR_SVID_DATA (39)

Configuration Signals:

CFG[0] Stall reset sequence after PCU PLL

lock until de-asserted

PCI Express Static Lane ReversalCFG[2]

eDP enable

CFG[4]

CFG[6:5]

PCI Express Bifurcation

PEG defer training

CFG[7]

4

SKYLAKE Processor (CLK,MISC,JTAG)

SKYLAKE_HALO

U34E

BCLKP
BCLKN

PCI_BCLKP
PCI_BCLKN

CLK24P
CLK24N

VIDALERT#
VIDSCK
VIDSOUT
PROCHOT#

DDR_VTT_CNTL

VCCST_PWRGD
PROCPWRGD

RESET#
PM_SYNC
PM_DOWN
PECI
THERMTRIP#

SKTOCC#
PROC_SELECT#

CATERR#

SKL_H_BGA_BGA

BGA1440

5 OF 14

CFG[0]
CFG[1]
CFG[2]
CFG[3]
CFG[4]
CFG[5]
CFG[6]
CFG[7]
CFG[8]

CFG[9]
CFG[10]
CFG[11]
CFG[12]
CFG[13]
CFG[14]
CFG[15]

CFG[17]
CFG[16]
CFG[19]
CFG[18]

BPM#[0]
BPM#[1]
BPM#[2]
BPM#[3]

PROC_TDO

PROC_TDI
PROC_TMS
PROC_TCK

PROC_TRST#
PROC_PREQ#
PROC_PRDY#

CFG_RCOMP

The CFG signals have a default value of '1' if not terminated on the board.

3

H_CPU_SVIDALRT#
VR_SVID_CLK_R
H_CPU_SVIDDAT

H_PROCHOT#_R

DDR_VTT_CNTL

PM_THRMTRIP#

R482 *0_4/S

H_PM_DOWN_R

CLK_CPU_BCLKP
CLK_CPU_BCLKN

CPU_PCI_BCLKP
CPU_PCI_BCLKN

CLK_DPLL_NSCCLKP
CLK_DPLL_NSCCLKN

H_VCCST_PWRGD

H_PM_DOWN_R
EC_PECI

CATERR#

SKTOCC_NSKTOCC_N_R
PROC_SEL#

BH31
BH32
BH29
BR30

BT13

BT31
BP35
BM34
BP31
BT34

BR33

BM30

B31
A32

D35
C36

E31
D31

H13

J31

BN1

0 Enable; SET DFX ENABLED BIT IN DEBUG

1 , Disable;

R77 *1K_4

CFG3

Note that some of the Intel reference designs board might connect CFG[0] to
HOOK[2]. This route is not needed on a OxM board.

x1 = Normal operation
x0 = Lane numbers reversed
x1 = Disabled
x0 = Enabled
x00 = 1 x8 & 2 x4 PCI Express
x01 = reserved
x10 = 2 x8 PCI Express
x11 = 1 x16 PCI Express
x1 = PEG train follow RESETB de-asseted
x0 = PEG wait for BIOS fro training

BN25

CFG0

BN27
BN26

CFG2

BN28

CFG3

BR20

CFG4

BM20

CFG5

BT20

CFG6

BP20

CFG7

BR23
BR22
BT23
BT22
BM19
BR19
BP19
BT19

BN23
BP23
BP22
BN22

XDP_BPM0

BR27

XDP_BPM1

BT27

XDP_BPM2

BM31

XDP_BPM3

BT30

XDP_TDO_CPU

BT28

XDP_TDI_CPU

BL32

XDP_TMS_CPU

BP28

XDP_TRST#_CPU

BR28

XDP_TRST#

BP30

XDP_PREQ#

BL30

XDP_PRDY#

BP27

CFG_RCOMP

BT25

a

Design Note(CFG_RCOMP):
DEFENSIVE DESIGN 50-OHM FOR R40PR (SV REQ)

TP11

TP10
TP9
TP12
TP60

XDP_TRST# (15)
XDP_PREQ# (15)
XDP_PRDY# (15)

R50149.9/F_4

HWPD

R10479 close to CPU side
H_VCCST_PWRGD trace 0.3" - 1.5"

D14

HWPG(10,32,34,35,36,38,49)

R83 1K_4

CFG2

R507 1K_4

CFG4

R509 *1K_4

CFG6

R508 *1K_4

CFG5

R505 *1K_4

CFG7

2

02

Processor pull-up (CPU)

H_PROCHOT#

XDP_TDO_CPU
XDP_TMS_CPU
XDP_TDI_CPU
XDP_PREQ#
XDP_TRST#_CPU
XDP_TRST#

EC-A-16

21

RB501V-40

XDP_TDO_CPU
XDP_TMS_CPU
XDP_TDI_CPU
XDP_TRST#_CPU

R783
R780
R781
R782

+1.0V

+VCCSTPLL

R504
1K_4

H_VCCST_PWRGD_R H_VCCST_PWRGD

C708
*10P/50V_4

CPU VDDQ

Note: please keep plane is enough for VDDQ 2.8A

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

Custom

Custom

Custom

R4841K_4

R500 51_4
R495 *51_4
R66 *51_4
R491 *51_4
R497 51_4
R72 *51_4

*0_4/S
*0_4/S
*0_4/S
*0_4/S

R503
*1K_4

R506 60.4/F_4

+1.2VSUS

+1.0V

+1.0V

JTAG_TDO_PCH (10)
JTAG_TMS_PCH (10)
JTAG_TDI_PCH (10)
JTAGX (10)

Placement close to CPU.

C274 0.1U/16V_4
C281 *0.1U/16V_4

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

PROJECT :

02 -- SKYPAKE 1/20(eDP/DDI)

02 -- SKYPAKE 1/20(eDP/DDI)

02 -- SKYPAKE 1/20(eDP/DDI)

1

2 66Wednesday, October 26, 2016

2 66Wednesday, October 26, 2016

2 66Wednesday, October 26, 2016

1A

1A

1A

5

PEG_RX15(53)
PEG_RX#15(53)

PEG_RX14(53)
PEG_RX#14(53)

PEG_RX13(53)

+VCCIO

PEG_RX#13(53)
PEG_RX12(53)

PEG_RX#12(53)
PEG_RX11(53)

PEG_RX#11(53)
PEG_RX10(53)

PEG_RX#10(53)
PEG_RX9(53)

PEG_RX#9(53)
PEG_RX8(53)

PEG_RX#8(53)
PEG_RX7(53)

PEG_RX#7(53)
PEG_RX6(53)

PEG_RX#6(53)
PEG_RX5(53)

PEG_RX#5(53)
PEG_RX4(53)

PEG_RX#4(53)
PEG_RX3(53)

PEG_RX#3(53)
PEG_RX2(53)

PEG_RX#2(53)
PEG_RX1(53)

PEG_RX#1(53)
PEG_RX0(53)

PEG_RX#0(53)

DMI_RXP0(9)
DMI_RXN0(9)

DMI_RXP1(9)
DMI_RXN1(9)

DMI_RXP2(9)
DMI_RXN2(9)

DMI_RXP3(9)
DMI_RXN3(9)

R542 24.9/F_4

D D

C C

PEG_RCOMP
Trace length < 400 MILS
Trace width = 5 MILS

Change PWR rail from +1.0V to +VCCIO_20141216

Trace spacing = 15 MILS

4

SKYLAKE Processor (DMI,PEG,FDI)

PEG_RCOMP

E25
D25

E24

F24

E23
D23

E22

F22

E21
D21

E20

F20

E19
D19

E18

F18

D17
E17

F16

E16
D15

E15

F14

E14
D13

E13

F12

E12
D11

E11

F10

E10

G2

D8
E8

E6

F6

D5
E5

J8
J9

U34C

PEG_RXP[0]
PEG_RXN[0]

PEG_RXP[1]
PEG_RXN[1]

PEG_RXP[2]
PEG_RXN[2]

PEG_RXP[3]
PEG_RXN[3]

PEG_RXP[4]
PEG_RXN[4]

PEG_RXP[5]
PEG_RXN[5]

PEG_RXP[6]
PEG_RXN[6]

PEG_RXP[7]
PEG_RXN[7]

PEG_RXP[8]
PEG_RXN[8]

PEG_RXP[9]
PEG_RXN[9]

PEG_RXP[10]
PEG_RXN[10]

PEG_RXP[11]
PEG_RXN[11]

PEG_RXP[12]
PEG_RXN[12]

PEG_RXP[13]
PEG_RXN[13]

PEG_RXP[14]
PEG_RXN[14]

PEG_RXP[15]
PEG_RXN[15]

PEG_RCOMP

DMI_RXP[0]
DMI_RXN[0]

DMI_RXP[1]
DMI_RXN[1]

DMI_RXP[2]
DMI_RXN[2]

DMI_RXP[3]
DMI_RXN[3]

SKL_H_BGA_BGA

SKYLAKE_HALO

BGA1440

3 OF 14

PEG_TXP[0]
PEG_TXN[0]

PEG_TXP[1]
PEG_TXN[1]

PEG_TXP[2]
PEG_TXN[2]

PEG_TXP[3]
PEG_TXN[3]

PEG_TXP[4]
PEG_TXN[4]

PEG_TXP[5]
PEG_TXN[5]

PEG_TXP[6]
PEG_TXN[6]

PEG_TXP[7]
PEG_TXN[7]

PEG_TXP[8]
PEG_TXN[8]

PEG_TXP[9]
PEG_TXN[9]

PEG_TXP[10]
PEG_TXN[10]

PEG_TXP[11]
PEG_TXN[11]

PEG_TXP[12]
PEG_TXN[12]

PEG_TXP[13]
PEG_TXN[13]

PEG_TXP[14]
PEG_TXN[14]

PEG_TXP[15]
PEG_TXN[15]

DMI_TXP[0]
DMI_TXN[0]

DMI_TXP[1]
DMI_TXN[1]

DMI_TXP[2]
DMI_TXN[2]

DMI_TXP[3]
DMI_TXN[3]

B25
A25

B24
C24

B23
A23

B22
C22

B21
A21

B20
C20

B19
A19

B18
C18

A17
B17

C16
B16

A15
B15

C14
B14

A13
B13

C12
B12

A11
B11

C10
B10

B8
A8

C6
B6

B5
A5

D4
B4

C_PEG_TX15
C_PEG_TX#15

C_PEG_TX14
C_PEG_TX#14

C_PEG_TX13
C_PEG_TX#13

C_PEG_TX12
C_PEG_TX#12

C_PEG_TX11
C_PEG_TX#11

C_PEG_TX10
C_PEG_TX#10

C_PEG_TX9
C_PEG_TX#9

C_PEG_TX8
C_PEG_TX#8

C_PEG_TX7
C_PEG_TX#7

C_PEG_TX6
C_PEG_TX#6

C_PEG_TX5
C_PEG_TX#5

C_PEG_TX4
C_PEG_TX#4

C_PEG_TX3
C_PEG_TX#3

C_PEG_TX2
C_PEG_TX#2

C_PEG_TX1
C_PEG_TX#1

C_PEG_TX0
C_PEG_TX#0

3

C690 0.22U/10V_4
C687 0.22U/10V_4

C691 0.22U/10V_4
C692 0.22U/10V_4

C695 0.22U/10V_4
C693 0.22U/10V_4

C696 0.22U/10V_4
C697 0.22U/10V_4

C705 0.22U/10V_4
C704 0.22U/10V_4

C706 0.22U/10V_4
C707 0.22U/10V_4

C710 0.22U/10V_4
C709 0.22U/10V_4

C711 0.22U/10V_4
C712 0.22U/10V_4

C713 0.22U/10V_4
C714 0.22U/10V_4

C716 0.22U/10V_4
C715 0.22U/10V_4

C717 0.22U/10V_4
C718 0.22U/10V_4

C721 0.22U/10V_4
C719 0.22U/10V_4

C724 0.22U/10V_4
C725 0.22U/10V_4

C728 0.22U/10V_4
C727 0.22U/10V_4

C729 0.22U/10V_4
C730 0.22U/10V_4

C732 0.22U/10V_4
C731 0.22U/10V_4

PEG_TX15 (53)
PEG_TX#15 (53)

PEG_TX14 (53)
PEG_TX#14 (53)

PEG_TX13 (53)
PEG_TX#13 (53)

PEG_TX12 (53)
PEG_TX#12 (53)

PEG_TX11 (53)
PEG_TX#11 (53)

PEG_TX10 (53)
PEG_TX#10 (53)

PEG_TX9 (53)
PEG_TX#9 (53)

PEG_TX8 (53)
PEG_TX#8 (53)

PEG_TX7 (53)
PEG_TX#7 (53)

PEG_TX6 (53)
PEG_TX#6 (53)

PEG_TX5 (53)
PEG_TX#5 (53)

PEG_TX4 (53)
PEG_TX#4 (53)

PEG_TX3 (53)
PEG_TX#3 (53)

PEG_TX2 (53)
PEG_TX#2 (53)

PEG_TX1 (53)
PEG_TX#1 (53)

PEG_TX0 (53)
PEG_TX#0 (53)

DMI_TXP0 (9)
DMI_TXN0 (9)

DMI_TXP1 (9)
DMI_TXN1 (9)

DMI_TXP2 (9)
DMI_TXN2 (9)

DMI_TXP3 (9)
DMI_TXN3 (9)

2

1

03

SKYLAKE_HALO

U34D

B B

HDMI

DP

USB3.1 type-C

A A

5

HDMI_D2(20)
HDMI_D2#(20)
HDMI_D1(20)
HDMI_D1#(20)
HDMI_D0(20)
HDMI_D0#(20)
HDMI_CLK(20)
HDMI_CLK#(20)

DP_TX0P(19)
DP_TX0N(19)
DP_TX1P(19)
DP_TX1N(19)
DP_TX2P(19)
DP_TX2N(19)
DP_TX3P(19)
DP_TX3N(19)

DP_AUXP(19)
DP_AUXN(19)

DDI3_TX0P(27)
DDI3_TX0N(27)
DDI3_TX1P(27)
DDI3_TX1N(27)
DDI3_TX2P(27)
DDI3_TX2N(27)
DDI3_TX3P(27)
DDI3_TX3N(27)

DDI3_AUXP(27)
DDI3_AUXN( 27)

K36
K37

J35

J34
H37
H36

J37

J38
D27

E27
H34

H33

F37
G38

F34

F35
E37
E36

F26
E26

C34
D34
B36
B34

F33
E33
C33
B33

A27
B27

4

DDI1_TXP[0]
DDI1_TXN[0]
DDI1_TXP[1]
DDI1_TXN[1]
DDI1_TXP[2]
DDI1_TXN[2]
DDI1_TXP[3]
DDI1_TXN[3]

DDI1_AUXP
DDI1_AUXN

DDI2_TXP[0]
DDI2_TXN[0]
DDI2_TXP[1]
DDI2_TXN[1]
DDI2_TXP[2]
DDI2_TXN[2]
DDI2_TXP[3]
DDI2_TXN[3]

DDI2_AUXP
DDI2_AUXN

DDI3_TXP[0]
DDI3_TXN[0]
DDI3_TXP[1]
DDI3_TXN[1]
DDI3_TXP[2]
DDI3_TXN[2]
DDI3_TXP[3]
DDI3_TXN[3]

DDI3_AUXP
DDI3_AUXN

SKL_H_BGA_BGA

BGA1440

4 OF 14

EDP_TXP[0]
EDP_TXN[0]
EDP_TXP[1]
EDP_TXN[1]
EDP_TXN[2]
EDP_TXP[2]
EDP_TXN[3]
EDP_TXP[3]

EDP_AUXP
EDP_AUXN

EDP_DISP_UTIL

EDP_RCOMP

PROC_AUDIO_CLK

PROC_AUDIO_SDI

PROC_AUDIO_SDO

D29
E29
F28
E28
B29
A29
B28
C28

C26
B26

EDP_DISP_UTIL

A33

EDP_RCOMP

D37

y

DP & PEG Compensation

eDP_RCOMP
Trace length < 100 Mils
Trace Width 5 mils Trace Spacing 25 mils

AUD_AZACP U_SCLK

G27

AUD_AZACP U_SDO_R

G25

AUD_AZACP U_SDI_R

G29

TP59

R47824.9/F_4

R70 20_4

3

EDP_TXP0 (18)
EDP_TXN0 (18)
EDP_TXP1 (18)
EDP_TXN1 (18)
EDP_TXP2 (18)
EDP_TXN2 (18)
EDP_TXP3 (18)
EDP_TXN3 (18)

EDP_AUXP (18)
EDP_AUXN (18)

+VCCIO

AUD_AZACP U_SCLK (10)

AUD_AZACP U_SDO_R (10)

AUD_AZACP U_SDI ( 10)

+VCCIO (37,6)
+1.2VSUS (10,16,17,2 ,35,43,44,50,6)
+3V_S5 (10,12,14,21,23,25,26,27,28,31,32,34,37,38,39,4 3,49,52)
+3V (10,11,12,13,14,16,17,18,19,20,21,22,23,24,26,27,28,29,30,31,32,36,43 ,45,50,52,9)

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

Custom

Custom

Custom

PROJECT :

SNB 1/5 (PCIE&DMI&FDI)

SNB 1/5 (PCIE&DMI&FDI)

SNB 1/5 (PCIE&DMI&FDI)

1

2A

2A

2A

3 66Wednesd ay, October 19, 2016

3 66Wednesd ay, October 19, 2016

3 66Wednesd ay, October 19, 2016

Size Docum ent Number Rev

Size Docum ent Number Rev

Size Docum ent Number Rev

Date: Sheet of

Date: Sheet of

2

Date: Sheet of

5

4

3

2

1

SKYLAKE Processor (DDR4)

DDR CHANNEL B

SKYLAKE_HALO

BGA1440

DDR1_RAS#/DDR1_CAB[3]/DDR1_MA[16]

DDR1_WE#/DDR1_CAB[2]/DDR1_MA[14]

DDR1_CAS#/DDR1_CAB[1]/DDR1_MA[15]

DDR1_BA[0]/DDR1_CAB[4]/DDR1_BA[0]
DDR1_BA[1]/DDR1_CAB[6]/DDR1_BA[1]
DDR1_BA[2]/DDR1_CAA[5]/DDR1_BG[0]

DDR1_MA[0]/DDR1_CAB[9]/DDR1_MA[0]
DDR1_MA[1]/DDR1_CAB[8]/DDR1_MA[1]
DDR1_MA[2]/DDR1_CAB[5]/DDR1_MA[2]

DDR1_MA[5]/DDR1_CAA[0]/DDR1_MA[5]
DDR1_MA[6]/DDR1_CAA[2]/DDR1_MA[6]
DDR1_MA[7]/DDR1_CAA[4]/DDR1_MA[7]
DDR1_MA[8]/DDR1_CAA[3]/DDR1_MA[8]

DDR1_MA[9]/DDR1_CAA[1]/DDR1_MA[9]
DDR1_MA[10]/DDR1_CAB[7]/DDR1_MA[10]
DDR1_MA[11]/DDR1_CAA[7]/DDR1_MA[11]
DDR1_MA[12]/DDR1_CAA[6]/DDR1_MA[12]
DDR1_MA[13]/DDR1_CAB[0]/DDR1_MA[13]

DDR1_MA[14]/DDR1_CAA[9]/DDR1_BG[1]
DDR1_MA[15]/DDR1_CAA[8]/DDR1_ACT#

DDR1_DQSN[0]/DDR0_DQSN[2]
DDR1_DQSN[1]/DDR0_DQSN[3]
DDR1_DQSN[2]/DDR0_DQSN[6]
DDR1_DQSN[3]/DDR0_DQSN[7]
DDR1_DQSN[4]/DDR1_DQSN[2]
DDR1_DQSN[5]/DDR1_DQSN[3]

DDR1_DQSP[0]/DDR0_DQSP[2]
DDR1_DQSP[1]/DDR0_DQSP[3]
DDR1_DQSP[2]/DDR0_DQSP[6]
DDR1_DQSP[3]/DDR0_DQSP[7]
DDR1_DQSP[4]/DDR1_DQSP[2]
DDR1_DQSP[5]/DDR1_DQSP[3]

2 OF 14

DDR1_CKP[0]
DDR1_CKN[0]
DDR1_CKP[1]

DDR1_CKN[1]
DDR1_CLKP[2]
DDR1_CLKN[2]
DDR1_CLKP[3]
DDR1_CLKN[3]

DDR1_CKE[0]

DDR1_CKE[1]

DDR1_CKE[2]

DDR1_CKE[3]

DDR1_CS#[0]

DDR1_CS#[1]

DDR1_CS#[2]

DDR1_CS#[3]

DDR1_ODT[0]

DDR1_ODT[1]

DDR1_ODT[2]

DDR1_ODT[3]

DDR1_MA[3]
DDR1_MA[4]

DDR1_PAR

DDR1_ALERT#

DDR1_DQSN[6]
DDR1_DQSN[7]

DDR1_DQSP[6]
DDR1_DQSP[7]

DDR1_DQSP[8]
DDR1_DQSN[8]

DDR_VREF_CA
DDR0_VREF_DQ
DDR1_VREF_DQ

AM9
AN9
AM7
AM8
AM11
AM10
AJ10
AJ11

AT8
AT10
AT7
AT11

AF11
AE7
AF10
AE10

AF7
AE8
AE9
AE11

AH10
AH11
AF8

AH8
AH9
AR9

AJ9
AK6
AK5
AL5
AL6
AM6
AN7
AN10
AN8
AR11
AH7
AN11
AR10
AF9
AR7
AT9

AJ7
AR8

BP9
BL9
BG9
BC9
AC9
W9
R9
M9

BR9
BJ9
BF9
BB9
AA9
V9
P9
L9

AW9
AY9

BN13
BP13
BR13

M_B_BA#0
M_B_BA#1
M_B_BG#0

M_B_A0
M_B_A1
M_B_A2
M_B_A3
M_B_A4
M_B_A5
M_B_A6
M_B_A7
M_B_A8
M_B_A9
M_B_A10
M_B_A11
M_B_A12
M_B_A13
M_B_BG#1
M_B_ACT#

M_B_PARITY
M_B_ALERT#

M_B_DQSN0
M_B_DQSN1
M_B_DQSN2
M_B_DQSN3
M_B_DQSN4
M_B_DQSN5
M_B_DQSN6
M_B_DQSN7

M_B_DQSP0
M_B_DQSP1
M_B_DQSP2
M_B_DQSP3
M_B_DQSP4
M_B_DQSP5
M_B_DQSP6
M_B_DQSP7

+SM_VREF
SMDDR_VREF_DQ0_M3
SMDDR_VREF_DQ1_M3

R514*1K_4
R510*1K_4

M_B_CLKP0 (17)
M_B_CLKN0 (17)
M_B_CLKP1 (17)
M_B_CLKN1 (17)

M_B_CKE0 (17)
M_B_CKE1 (17)

M_B_CS#0 (17)
M_B_CS#1 (17)

M_B_ODT0_CPU (17)
M_B_ODT1_CPU (17)

M_B_RAS# (17)

M_B_WE# (17)

M_B_CAS# (17)

M_B_BA#0 (17)
M_B_BA#1 (17)
M_B_BG#0 (17)

M_B_A[13:0] (17)

M_B_BG#1 (17)
M_B_ACT# (17)

M_B_PARITY (17)
M_B_ALERT# (17)

M_B_DQSN[7:0] (17)

M_B_DQSP[7:0] (17)

D D

C C

B B

M_A_DQ[63:0](16)

M_A_DQ0
M_A_DQ1
M_A_DQ2
M_A_DQ3
M_A_DQ4
M_A_DQ5
M_A_DQ6
M_A_DQ7
M_A_DQ8
M_A_DQ9
M_A_DQ10
M_A_DQ11
M_A_DQ12
M_A_DQ13
M_A_DQ14
M_A_DQ15
M_A_DQ16
M_A_DQ17
M_A_DQ18
M_A_DQ19
M_A_DQ20
M_A_DQ21
M_A_DQ22
M_A_DQ23
M_A_DQ24
M_A_DQ25
M_A_DQ26
M_A_DQ27
M_A_DQ28
M_A_DQ29
M_A_DQ30
M_A_DQ31
M_A_DQ32
M_A_DQ33
M_A_DQ34
M_A_DQ35
M_A_DQ36
M_A_DQ37
M_A_DQ38
M_A_DQ39
M_A_DQ40
M_A_DQ41
M_A_DQ42
M_A_DQ43
M_A_DQ44
M_A_DQ45
M_A_DQ46
M_A_DQ47
M_A_DQ48
M_A_DQ49
M_A_DQ50
M_A_DQ51
M_A_DQ52
M_A_DQ53
M_A_DQ54
M_A_DQ55
M_A_DQ56
M_A_DQ57
M_A_DQ58
M_A_DQ59
M_A_DQ60
M_A_DQ61
M_A_DQ62
M_A_DQ63

RSVD_V10 must be grounded

U34A

BR6

DDR0_DQ[0]

BT6

DDR0_DQ[1]

BP3

DDR0_DQ[2]

BR3

DDR0_DQ[3]

BN5

DDR0_DQ[4]

BP6

DDR0_DQ[5]

BP2

DDR0_DQ[6]

BN3

DDR0_DQ[7]

BL4

DDR0_DQ[8]

BL5

DDR0_DQ[9]

BL2

DDR0_DQ[10]

BM1

DDR0_DQ[11]

BK4

DDR0_DQ[12]

BK5

DDR0_DQ[13]

BK1

DDR0_DQ[14]

BK2

DDR0_DQ[15]

BG4

DDR0_DQ[16]/DDR0_DQ[32]

BG5

DDR0_DQ[17]/DDR0_DQ[33]

BF4

DDR0_DQ[18]/DDR0_DQ[34]

BF5

DDR0_DQ[19]/DDR0_DQ[35]

BG2

DDR0_DQ[20]/DDR0_DQ[36]

BG1

DDR0_DQ[21]/DDR0_DQ[37]

BF1

DDR0_DQ[22]/DDR0_DQ[38]

BF2

DDR0_DQ[23]/DDR0_DQ[39]

BD2

DDR0_DQ[24]/DDR0_DQ[40]

BD1

DDR0_DQ[25]/DDR0_DQ[41]

BC4

DDR0_DQ[26]/DDR0_DQ[42]

BC5

DDR0_DQ[27]/DDR0_DQ[43]

BD5

DDR0_DQ[28]/DDR0_DQ[44]

BD4

DDR0_DQ[29]/DDR0_DQ[45]

BC1

DDR0_DQ[30]/DDR0_DQ[46]

BC2

DDR0_DQ[31]/DDR0_DQ[47]

AB1

DDR0_DQ[32]/DDR1_DQ[0]

AB2

DDR0_DQ[33]/DDR1_DQ[1]

AA4

DDR0_DQ[34]/DDR1_DQ[2]

AA5

DDR0_DQ[35]/DDR1_DQ[3]

AB5

DDR0_DQ[36]/DDR1_DQ[4]

AB4

DDR0_DQ[37]/DDR1_DQ[5]

AA2

DDR0_DQ[38]/DDR1_DQ[6]

AA1

DDR0_DQ[39]/DDR1_DQ[7]

V5

DDR0_DQ[40]/DDR1_DQ[8]

V2

DDR0_DQ[41]/DDR1_DQ[9]

U1

DDR0_DQ[42]/DDR1_DQ[10]

U2

DDR0_DQ[43]/DDR1_DQ[11]

V1

DDR0_DQ[44]/DDR1_DQ[12]

V4

DDR0_DQ[45]/DDR1_DQ[13]

U5

DDR0_DQ[46]/DDR1_DQ[14]

U4

DDR0_DQ[47]/DDR1_DQ[15]

R2

DDR0_DQ[48]/DDR1_DQ[32]

P5

DDR0_DQ[49]/DDR1_DQ[33]

R4

DDR0_DQ[50]/DDR1_DQ[34]

P4

DDR0_DQ[51]/DDR1_DQ[35]

R5

DDR0_DQ[52]/DDR1_DQ[36]

P2

DDR0_DQ[53]/DDR1_DQ[37]

R1

DDR0_DQ[54]/DDR1_DQ[38]

P1

DDR0_DQ[55]/DDR1_DQ[39]

M4

DDR0_DQ[56]/DDR1_DQ[40]

M1

DDR0_DQ[57]/DDR1_DQ[41]

L4

DDR0_DQ[58]/DDR1_DQ[42]

L2

DDR0_DQ[59]/DDR1_DQ[43]

M5

DDR0_DQ[60]/DDR1_DQ[44]

M2

DDR0_DQ[61]/DDR1_DQ[45]

L5

DDR0_DQ[62]/DDR1_DQ[46]

L1

DDR0_DQ[63]/DDR1_DQ[47]

BA2

DDR0_ECC[0]

BA1

DDR0_ECC[1]

AY4

DDR0_ECC[2]

AY5

DDR0_ECC[3]

BA5

DDR0_ECC[4]

BA4

DDR0_ECC[5]

AY1

DDR0_ECC[6]

AY2

DDR0_ECC[7]

DDR CHANNEL A

SKL_H_BGA_BGA

SKYLAKE_HALO

BGA1440

DDR0_BA[0]/DDR0_CAB[4]/DDR0_BA[0]
DDR0_BA[1]/DDR0_CAB[6]/DDR0_BA[1]

DDR0_BA[2]/DDR0_CAA[5]/DDR0_BG[0]

DDR0_RAS#/DDR0_CAB[3]/DDR0_MA[16]

DDR0_WE#/DDR0_CAB[2]/DDR0_MA[14]

DDR0_CAS#/DDR0_CAB[1]/DDR0_MA[15]

DDR0_MA[0]/DDR0_CAB[9]/DDR0_MA[0]
DDR0_MA[1]/DDR0_CAB[8]/DDR0_MA[1]
DDR0_MA[2]/DDR0_CAB[5]/DDR0_MA[2]

DDR0_MA[5]/DDR0_CAA[0]/DDR0_MA[5]
DDR0_MA[6]/DDR0_CAA[2]/DDR0_MA[6]
DDR0_MA[7]/DDR0_CAA[4]/DDR0_MA[7]
DDR0_MA[8]/DDR0_CAA[3]/DDR0_MA[8]

DDR0_MA[9]/DDR0_CAA[1]/DDR0_MA[9]
DDR0_MA[10]/DDR0_CAB[7]/DDR0_MA[10]
DDR0_MA[11]/DDR0_CAA[7]/DDR0_MA[11]
DDR0_MA[12]/DDR0_CAA[6]/DDR0_MA[12]
DDR0_MA[13]/DDR0_CAB[0]/DDR0_MA[13]

DDR0_MA[14]/DDR0_CAA[9]/DDR0_BG[1]
DDR0_MA[15]/DDR0_CAA[8]/DDR0_ACT#

DDR0_DQSN[2]/DDR0_DQSN[4]
DDR0_DQSN[3]/DDR0_DQSN[5]
DDR0_DQSN[4]/DDR1_DQSN[0]
DDR0_DQSN[5]/DDR1_DQSN[1]
DDR0_DQSN[6]/DDR1_DQSN[4]
DDR0_DQSN[7]/DDR1_DQSN[5]

DDR0_DQSP[2]/DDR0_DQSP[4]
DDR0_DQSP[3]/DDR0_DQSP[5]
DDR0_DQSP[4]/DDR1_DQSP[0]
DDR0_DQSP[5]/DDR1_DQSP[1]
DDR0_DQSP[6]/DDR1_DQSP[4]
DDR0_DQSP[7]/DDR1_DQSP[5]

1 OF 14

DDR0_CKP[0]
DDR0_CKN[0]
DDR0_CKP[1]
DDR0_CKN[1]

DDR0_CLKP[2]

DDR0_CLKN[2]

DDR0_CLKP[3]

DDR0_CLKN[3]

DDR0_CKE[0]
DDR0_CKE[1]
DDR0_CKE[2]
DDR0_CKE[3]

DDR0_CS#[0]
DDR0_CS#[1]
DDR0_CS#[2]
DDR0_CS#[3]

DDR0_ODT[0]
DDR0_ODT[1]
DDR0_ODT[2]
DDR0_ODT[3]

DDR0_MA[3]
DDR0_MA[4]

DDR0_PAR

DDR0_ALERT#

DDR0_DQSN[0]
DDR0_DQSN[1]

DDR0_DQSP[0]
DDR0_DQSP[1]

DDR0_DQSP[8]
DDR0_DQSN[8]

AG1
AG2
AK2
AK1
AL3
AK3
AL2
AL1

AT1
AT2
AT3
AT5

AD5
AE2
AD2
AE5

AD3
AE4
AE1
AD4

AH5
AH1
AU1

AH4
AG4
AD1

AH3
AP4
AN4
AP5
AP2
AP1
AP3
AN1
AN3
AT4
AH2
AN2
AU4
AE3
AU2
AU3

AG3
AU5

BR5
BL3
BG3
BD3
AA3
U3
P3
L3

BP5
BK3
BF3
BC3
AB3
V3
R3
M3

AY3
BA3

M_A_BA#0
M_A_BA#1
M_A_BG#0

M_A_A0
M_A_A1
M_A_A2
M_A_A3
M_A_A4
M_A_A5
M_A_A6
M_A_A7
M_A_A8
M_A_A9
M_A_A10
M_A_A11
M_A_A12
M_A_A13
M_A_BG#1
M_A_ACT#

M_A_PARITY
M_A_ALERT#

M_A_DQSN0
M_A_DQSN1
M_A_DQSN2
M_A_DQSN3
M_A_DQSN4
M_A_DQSN5
M_A_DQSN6
M_A_DQSN7

M_A_DQSP0
M_A_DQSP1
M_A_DQSP2
M_A_DQSP3
M_A_DQSP4
M_A_DQSP5
M_A_DQSP6
M_A_DQSP7

M_B_DQ[63:0](17)

M_A_CLKP0 (16)
M_A_CLKN0 (16)
M_A_CLKP1 (16)
M_A_CLKN1 (16)

M_A_CKE0 (16)
M_A_CKE1 (16)

M_A_CS#0 (16)
M_A_CS#1 (16)

M_A_ODT0_CPU (16)
M_A_ODT1_CPU (16)

M_A_BA#0 (16)
M_A_BA#1 (16)
M_A_BG#0 (16)

M_A_RAS# (16)

M_A_WE# (16)

M_A_CAS# (16)

M_A_A[13:0] (16)

M_A_BG#1 (16)
M_A_ACT# (16)

M_A_PARITY (16)
M_A_ALERT# (16)

M_A_DQSN[7:0] (16)

M_A_DQSP[7:0] (16)

R541121/F_4

R54075/F_4

R539100/F_4

M_B_DQ0
M_B_DQ1
M_B_DQ2
M_B_DQ3
M_B_DQ4
M_B_DQ5
M_B_DQ6
M_B_DQ7
M_B_DQ8
M_B_DQ9
M_B_DQ10
M_B_DQ11
M_B_DQ12
M_B_DQ13
M_B_DQ14
M_B_DQ15
M_B_DQ16
M_B_DQ17
M_B_DQ18
M_B_DQ19
M_B_DQ20
M_B_DQ21
M_B_DQ22
M_B_DQ23
M_B_DQ24
M_B_DQ25
M_B_DQ26
M_B_DQ27
M_B_DQ28
M_B_DQ29
M_B_DQ30
M_B_DQ31
M_B_DQ32
M_B_DQ33
M_B_DQ34
M_B_DQ35
M_B_DQ36
M_B_DQ37
M_B_DQ38
M_B_DQ39
M_B_DQ40
M_B_DQ41
M_B_DQ42
M_B_DQ43
M_B_DQ44
M_B_DQ45
M_B_DQ46
M_B_DQ47
M_B_DQ48
M_B_DQ49
M_B_DQ50
M_B_DQ51
M_B_DQ52
M_B_DQ53
M_B_DQ54
M_B_DQ55
M_B_DQ56
M_B_DQ57
M_B_DQ58
M_B_DQ59
M_B_DQ60
M_B_DQ61
M_B_DQ62
M_B_DQ63

SM_RCOMP_0
SM_RCOMP_1
SM_RCOMP_2

U34B

BT11

DDR1_DQ[0]/DDR0_DQ[16]

BR11

DDR1_DQ[1]/DDR0_DQ[17]

BT8

DDR1_DQ[2]/DDR0_DQ[18]

BR8

DDR1_DQ[3]/DDR0_DQ[19]

BP11

DDR1_DQ[4]/DDR0_DQ[20]

BN11

DDR1_DQ[5]/DDR0_DQ[21]

BP8

DDR1_DQ[6]/DDR0_DQ[22]

BN8

DDR1_DQ[7]/DDR0_DQ[23]

BL12

DDR1_DQ[8]/DDR0_DQ[24]

BL11

DDR1_DQ[9]/DDR0_DQ[25]

BL8

DDR1_DQ[10]/DDR0_DQ[26]

BJ8

DDR1_DQ[11]/DDR0_DQ[27]

BJ11

DDR1_DQ[12]/DDR0_DQ[28]

BJ10

DDR1_DQ[13]/DDR0_DQ[29]

BL7

DDR1_DQ[14]/DDR0_DQ[30]

BJ7

DDR1_DQ[15]/DDR0_DQ[31]

BG11

DDR1_DQ[16]/DDR0_DQ[48]

BG10

DDR1_DQ[17]/DDR0_DQ[49]

BG8

DDR1_DQ[18]/DDR0_DQ[50]

BF8

DDR1_DQ[19]/DDR0_DQ[51]

BF11

DDR1_DQ[20]/DDR0_DQ[52]

BF10

DDR1_DQ[21]/DDR0_DQ[53]

BG7

DDR1_DQ[22]/DDR0_DQ[54]

BF7

DDR1_DQ[23]/DDR0_DQ[55]

BB11

DDR1_DQ[24]/DDR0_DQ[56]

BC11

DDR1_DQ[25]/DDR0_DQ[57]

BB8

DDR1_DQ[26]/DDR0_DQ[58]

BC8

DDR1_DQ[27]/DDR0_DQ[59]

BC10

DDR1_DQ[28]/DDR0_DQ[60]

BB10

DDR1_DQ[29]/DDR0_DQ[61]

BC7

DDR1_DQ[30]/DDR0_DQ[62]

BB7

DDR1_DQ[31]/DDR0_DQ[63]

AA11

DDR1_DQ[32]/DDR1_DQ[16]

AA10

DDR1_DQ[33]/DDR1_DQ[17]

AC11

DDR1_DQ[34]/DDR1_DQ[18]

AC10

DDR1_DQ[35]/DDR1_DQ[19]

AA7

DDR1_DQ[36]/DDR1_DQ[20]

AA8

DDR1_DQ[37]/DDR1_DQ[21]

AC8

DDR1_DQ[38]/DDR1_DQ[22]

AC7

DDR1_DQ[39]/DDR1_DQ[23]

W8

DDR1_DQ[40]/DDR1_DQ[24]

W7

DDR1_DQ[41]/DDR1_DQ[25]

V10

DDR1_DQ[42]/DDR1_DQ[26]

V11

DDR1_DQ[43]/DDR1_DQ[27]

W11

DDR1_DQ[44]/DDR1_DQ[28]

W10

DDR1_DQ[45]/DDR1_DQ[29]

V7

DDR1_DQ[46]/DDR1_DQ[30]

V8

DDR1_DQ[47]/DDR1_DQ[31]

R11

DDR1_DQ[48]

P11

DDR1_DQ[49]

P7

DDR1_DQ[50]

R8

DDR1_DQ[51]

R10

DDR1_DQ[52]

P10

DDR1_DQ[53]

R7

DDR1_DQ[54]

P8

DDR1_DQ[55]

L11

DDR1_DQ[56]

M11

DDR1_DQ[57]

L7

DDR1_DQ[58]

M8

DDR1_DQ[59]

L10

DDR1_DQ[60]

M10

DDR1_DQ[61]

M7

DDR1_DQ[62]

L8

DDR1_DQ[63]

AW11

DDR1_ECC[0]

AY11

DDR1_ECC[1]

AY8

DDR1_ECC[2]

AW8

DDR1_ECC[3]

AY10

DDR1_ECC[4]

AW10

DDR1_ECC[5]

AY7

DDR1_ECC[6]

AW7

DDR1_ECC[7]

G1

DDR_RCOMP[0]

H1

DDR_RCOMP[1]

J2

DDR_RCOMP[2]

SKL_H_BGA_BGA

04

SM_VREF (16)

TP23

SMDDR_VREF_DQ1_M3 (17)

A A

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet of

Date: Sheet of

5

4

3

2

Date: Sheet of

Custom

Custom

Custom

PROJECT :

SNB 2/5 (DDR4 I/F)

SNB 2/5 (DDR4 I/F)

SNB 2/5 (DDR4 I/F)

1

2A

2A

4 66Wednesday, October 19, 2016

4 66Wednesday, October 19, 2016

4 66Wednesday, October 19, 2016

2A

5

4

3

2

1

SKYLAKE Processor (POWER)

05

Follow SKL H EDS page 133 to 45W(GT4+OPC): +VCCGT=104A/12A (GTx)
Follow SKL H EDS page 133 to 45W(GT2): +VCCGT=55A

D D

C126
22U/6.3V_6

C138
22U/6.3V_6

C154
22U/6.3V_6

C169

C C

B B

22U/6.3V_6

C226
10U/6.3V_6

C111
1U/6.3V_4

C234
1U/6.3V_4

C251
1U/6.3V_4

C137
22U/6.3V_6

C153
22U/6.3V_6

C168
22U/6.3V_6

C185
22U/6.3V_6

C91
10U/6.3V_6

C112
1U/6.3V_4

C235
1U/6.3V_4

C236
1U/6.3V_4

C152
22U/6.3V_6

C167
22U/6.3V_6

C184
22U/6.3V_6

C209
22U/6.3V_6

C222
10U/6.3V_6

C113
1U/6.3V_4

C117
1U/6.3V_4

C238
1U/6.3V_4

C166
22U/6.3V_6

C183
22U/6.3V_6

C208
22U/6.3V_6

C227
22U/6.3V_6

C90
10U/6.3V_6

C106
1U/6.3V_4

C247
1U/6.3V_4

C254
1U/6.3V_4

C182
22U/6.3V_6

C207
22U/6.3V_6

C128
22U/6.3V_6

C225
22U/6.3V_6

C223
10U/6.3V_6

C114
1U/6.3V_4

C116
1U/6.3V_4

C282
1U/6.3V_4

C206
22U/6.3V_6

C127
22U/6.3V_6

C140
22U/6.3V_6

C220
22U/6.3V_6

C224
10U/6.3V_6

C92

47U/6.3VS_8

C115
1U/6.3VS_4

C253
1U/6.3VS_4

C283
1U/6.3VS_4

C133
22U/6.3V_6

C139
22U/6.3V_6

C155
22U/6.3V_6

C89
22U/6.3V_6

C221
10U/6.3V_6

C93

47U/6.3VS_8

C252
1U/6.3V_4

C255
1U/6.3V_4

C237
1U/6.3V_4

+VCCGT

AJ29
AJ30
AJ31
AJ32
AJ33
AJ34
AJ35

AJ36
AK31
AK32
AK33
AK34
AK35
AK36
AK37
AK38
AL13
AL29
AL30
AL31
AL32
AL35
AL36
AL37
AL38
AM13
AM14
AM29
AM30
AM31
AM32
AM33
AM34
AM35
AM36
AN13
AN14
AN31
AN32
AN33
AN34
AN35
AN36
AN37
AN38
AP13
AP14
AP29
AP30
AP31
AP32
AP35
AP36
AP37
AP38
AR29
AR30
AR31
AR32
AR33
AR34
AR35
AR36
AT14
AT31
AT32
AT33
AT34
AT35
AT36
AT37
AT38
AU14
AU29
AU30
AU31
AU32
AU35
AU36
AU37
AU38

U34N

VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT

SKL_H_BGA_BGA

SKYLAKE_HALO

BGA1440

14 OF 14

VCCGTX
VCCGTX
VCCGTX
VCCGTX
VCCGTX
VCCGTX
VCCGTX
VCCGTX
VCCGTX
VCCGTX
VCCGTX
VCCGTX
VCCGTX
VCCGTX
VCCGTX
VCCGTX
VCCGTX
VCCGTX
VCCGTX
VCCGTX
VCCGTX
VCCGTX

VCCGT_SENSE

VSSGTX_SENSE

VSSGT_SENSE

VCCGTX_SENSE

AF29
AF30
AF31
AF32
AF33
AF34
AG13
AG14
AG31
AG32
AG33
AG34
AG35
AG36
AH13
AH14
AH29
AH30
AH31
AH32
AJ13
AJ14

AH38
AH35
AH37
AH36

4+4e, Support eDRAM Only, GTX 12A

VCCGT_SENSE (39)
VSSGT_SENSE (39)

+VCC_CORE (40,44,7)
+1.2VSUS (10,16,17,2,35,43,44,50,6)

A A

VCC Output Decoupling Recommendations

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet of

Date: Sheet of

5

4

3

2

Date: Sheet of

Custom

Custom

Custom

PROJECT :

SNB 3/5 (POWER)

SNB 3/5 (POWER)

SNB 3/5 (POWER)

1

2A

2A

2A

5 66Wednesday, October 19, 2016

5 66Wednesday, October 19, 2016

5 66Wednesday, October 19, 2016

5

4

3

2

1

06

Follow SKL H EDS page 135 to 45W(GT2): VCCSA=11.1A (GTx)

D D

C35

C36

C657
10U/6.3V_6

C669

C59

10U/6.3V_6

10U/6.3V_6

C C

Follow SKL H EDS P136 to 45W: VCCIO
+VCCIO = 0.95V

B B

+VDDQC +VC CSTG +VCCPLL_OC

+VCCIO

10U/6.3V_6

C109
1U/6.3V_4

C135
1U/6.3V_4

C367
10U/6.3V_6

C660
10U/6.3V_6

C94

22U/6.3VS_6

C38
10U/6.3V_6

C108
1U/6.3V_4

C149
22U/6.3VS_6

C215
1U/6.3V_4

C720

1U/6.3V_4

+VCCSA

C665
22U/6.3VS_6

C52
10U/6.3V_6

C680
1U/6.3V_4

+VCCIO

AG12

C163
22U/6.3VS_6

C203
10U/6.3V_6

C277

1U/6.3V_4 C123

J30
K29
K30
K31
K32
K33
K34
K35
L31
L32
L35
L36
L37
L38
M29
M30
M31
M32
M33
M34
M35
M36

G15
G17
G19
G21
H15
H16
H17
H19
H20
H21
H26
H27
J15
J16
J17
J19
J20
J21
J26
J27

U34I

VCCSA

11.1 A

VCCSA
VCCSA
VCCSA
VCCSA
VCCSA
VCCSA
VCCSA
VCCSA
VCCSA
VCCSA
VCCSA
VCCSA
VCCSA
VCCSA
VCCSA
VCCSA
VCCSA
VCCSA
VCCSA
VCCSA
VCCSA

VCCIO

5.5 A

VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO

SKL_H_BGA_BGA

C245

1U/6.3V_4

SKYLAKE_HALO

BGA1440

Close CPUUnder CPU

1U/6.3V_4

0.26 A

0.145 A

9 OF 14

+VCCPLL+V CCIO

VCCPLL_OC
VCCPLL_OC

0.12 A

VCCSA_SENSE
VSSSA_SENSE

VCCIO_SENSE
VSSIO_SENSE

Follow SKL H EDS page 135 45W: VDDQ=2.8A

+1.2VSUS

AA6

VDDQ

AE12

VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ

VDDQC

VCCST
VCCSTG
VCCSTG

VCCPLL
VCCPLL

AF5
AF6
AG5
AG9
AJ12
AL11
AP6
AP7
AR12
AR6
AT12
AW6
AY6
J5
J6
K12
K6
L12
L6
R6
T6
W6

Y12
BH13

G11

H30
H29
G30
H28

J28

M38
M37

H14
J14

C369

C742

22U/6.3VS_6

22U/6.3VS_6

C745

C379

10U/6.3V_6

10U/6.3V_6

C743

C372

10U/6.3V_6

10U/6.3V_6

+VDDQC
+VCCPLL_OC

+VCCSTG

+VCCPLL

VCCSA_SENS E (39)
VSSSA_SENSE (39)

VCCIO_VCCSE NSE
VSSIO_VSSSENSE

+VCCSTPLL

C107
1U/6.3V_4

C740
22U/6.3VS_6

C741
10U/6.3V_6

C366
10U/6.3V_6

+VCCIO

C365
22U/6.3VS_6

C370
10U/6.3V_6

C744
10U/6.3V_6

R87
100_4

R90
100_4

C746
10U/6.3V_6

C368
10U/6.3V_6

+1.2VSUS+VDDQC

+VCCPLL_OC +1.2VSUS

+VCCPLL +VCCSTPLL

+VCCSTG +1.0V

R97*0_6/S

R515*0_6/S

R74*0_6/S

R68 *0_4/S

R73 *0_4

+VCCSTPLL

EDRAM Only, PLACE CAPS IN ACK SIDE

TP25
TP26

TP22
TP21

CPU_OPC_C OMP

R490*49.9/F_4

CPU_OPCE_C OMP

R502*49.9/F_4

CPU_OPCE_C OMP2

R496*49.9/F_4

Unconnected for Processors without OPC.

BJ17
BJ19

BJ20
BK17
BK19

BK20

BL16

BL17

BL18

BL19

BL20

BL21
BM17
BN17

BJ23

BJ26

BJ27
BK23
BK26
BK27

BL23

BL24

BL25

BL26

BL27

BL28
BM24

BL15
BM16

BL22
BM22

BP15
BR15

BT15
BP16

BR16

BT16

BN15
BM15

BP17
BN16

BM14

BL14

BJ35

BJ36

AT13
AW13

AU13
AY13

BT29
BR25
BP25

SKYLAKE_HALO

U34J

BGA1440

VCCOPC

3.8 A

VCCOPC
VCCOPC
VCCOPC
VCCOPC
VCCOPC
VCCOPC
VCCOPC
VCCOPC
VCCOPC
VCCOPC
VCCOPC
VCCOPC
VCCOPC

RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD

VCCOPC_SENSE
VSSOPC_SENSE

RSVD
RSVD

VCCEOPIO

2.8 A

VCCEOPIO
VCCEOPIO

RSVD
RSVD
RSVD

VCCEOPIO_SENSE
VSSEOPIO_SENSE

RSVD
RSVD

VCC_OPC_1P8
VCC_OPC_1P8

RSVD
RSVD

ZVM#
MSM#

ZVM2#
MSM2#

OPC_RCOMP
OPCE_RCOMP
OPCE_RCOMP2

0.05 A

10 OF 14

SKL_H_BGA_BGA

C179

C124

*22U/6.3V_6

A A

*1U/6.3V_4

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

Custom

Custom

Custom

PROJECT :

SNB 4/5 (POWER & GND)

SNB 4/5 (POWER & GND)

SNB 4/5 (POWER & GND)

1

2A

2A

2A

6 66Wednesd ay, October 19, 2016

6 66Wednesd ay, October 19, 2016

6 66Wednesd ay, October 19, 2016

Size Docum ent Number Rev

Size Docum ent Number Rev

Size Docum ent Number Rev

Date: Sheet of

Date: Sheet of

5

4

3

2

Date: Sheet of

5

4

3

2

1

07

+VCC_COR E

U34G

AA13
AA31
AA32
AA33
AA34
AA35
AA36
AA37
AA38
AB29
AB30
AB31
AB32
AB35
AB36
AB37
AB38
AC13
AC14
AC29
AC30
AC31
AC32
AC33
AC34
AC35
AC36
AD13
AD14
AD31
AD32
AD33
AD34
AD35
AD36
AD37
AD38
AE13
AE14
AE30
AE31
AE32
AE35
AE36
AE37
AE38
AF35
AF36
AF37
AF38

K13
K14
L13
N13
N14
N30
N31
N32
N35
N36
N37
N38
P13

SKYLAKE_HALO

BGA1440

VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC

SKL_H_BGA_BGA

7 OF 14

D D

C141

C129

22U/6.3V_6

22U/6.3V_6

C171

C157

47U/6.3V_6

47U/6.3V_6

C188

C212

22U/6.3V_6

22U/6.3V_6

C C

B B

C173
47U/6.3V_6

C118
1U/6.3V_4

C189
47U/6.3V_6

C83
10U/6.3V_6

C119
1U/6.3V_4

Follow SKL H EDS page 131 to 45W(GT2): VCC_CORE=68A

C156
22U/6.3V_6

C187
47U/6.3V_6

C132
47U/6.3V_6

C82
22U/6.3V_6

C80
10U/6.3V_6

C120
1U/6.3V_4

C170
22U/6.3V_6

C211
47U/6.3V_6

C144
47U/6.3V_6

C79
22U/6.3V_6

C73
10U/6.3V_6

C121
1U/6.3V_4

C186
22U/6.3V_6

C131
22U/6.3V_6

C75
22U/6.3V_6

C68
10U/6.3V_6

C122
1U/6.3V_4

C210
22U/6.3V_6

C143
22U/6.3V_6

C256
1U/6.3V_4

C130
47U/6.3V_6

C158
22U/6.3V_6

C159
47U/6.3V_6

C81
22U/6.3V_6

C78
10U/6.3V_6

C257
1U/6.3VS_4

C142
47U/6.3V_6

C172
22U/6.3V_6

C213
47U/6.3V_6

C77
22U/6.3V_6

C86
10U/6.3V_6

C258
1U/6.3V_4

VCC_SENSE
VSS_SENSE

+VCC_COR E

V32

VCC

V33

VCC

V34

VCC

V35

VCC

V36

VCC

V37

VCC

V38

VCC

W13

VCC

W14

VCC

W29

VCC

W30

VCC

W31

VCC

W32

VCC

W35

VCC

W36

VCC

W37

VCC

W38

VCC

Y29

VCC

Y30

VCC

Y31

VCC

Y32

VCC

Y33

VCC

Y34

VCC

Y35

VCC

Y36

VCC

L14

VCC

P29

VCC

P30

VCC

P31

VCC

P32

VCC

P33

VCC

P34

VCC

P35

VCC

P36

VCC

R13

VCC

R31

VCC

R32

VCC

R33

VCC

R34

VCC

R35

VCC

R36

VCC

R37

VCC

R38

VCC

T29

VCC

T30

VCC

T31

VCC

T32

VCC

T35

VCC

T36

VCC

T37

VCC

T38

VCC

U29

VCC

U30

VCC

U31

VCC

U32

VCC

U33

VCC

U34

VCC

U35

VCC

U36

VCC

V13

VCC

V14

VCC

V31

VCC

P14

VCC

VCC_SENSE

AG37
AG38

VSS_SENSE

1 2

1 2

1 2

C259

0.1U/16V_4

C240

0.1U/16V_4

C675

0.1U/16V_4

C101

0.1U/16V_4

1 2

C239

0.1U/16V_4

1 2

C672

0.1U/16V_4

1 2

R477 100_4

R476 100_4

C102

0.1U/16V_4

1 2

C671

0.1U/16V_4

1 2

C673

0.1U/16V_4

1 2

+VCC_COR E

VCC_SENSE (39)

VSS_SENSE (39)

C103

C104

0.1U/16V_4

0.1U/16V_4

1 2

1 2

C678

C69

0.1U/16V_4

0.1U/16V_4

1 2

1 2

C674

C676

0.1U/16V_4

0.1U/16V_4

1 2

1 2

Sense resistor should be placed within 2
inches (50.8 mm) of the processor socket

Trace Impendence 50 ohm

1 2

1 2

1 2

C105

0.1U/16V_4

C679

0.1U/16V_4

C670

0.1U/16V_4

1 2

1 2

1 2

C260

0.1U/16V_4

C677

0.1U/16V_4

C74

0.1U/16V_4

1 2

1 2

1 2

C242

0.1U/16V_4

C71

0.1U/16V_4

C667

0.1U/16V_4

1 2

1 2

1 2

C241

0.1U/16V_4

C668

0.1U/16V_4

C243

0.1U/16V_4

+VCCGT

BM36
BM37

BG34
BG35
BG36
BH33
BH34
BH35
BH36
BH37
BH38

BN36
BN37
BN38
BP37
BP38
BR37
BT37
BE38
BF13
BF14
BF29
BF30
BF31
BF32
BF35
BF36
BF37
BF38
BG29
BG30
BG31
BG32
BG33
BC36
BC37
BC38
BD13
BD14
BD29
BD30
BD31
BD32
BD33
BD34
BD35
BD36
BE31
BE32
BE37

BJ37
BJ38
BL36
BL37

U34H

SKYLAKE_HALO

VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT

SKL_H_BGA_BGA

BGA1440

8 OF 14

VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT
VCCGT

AV29
AV30
AV31
AV32
AV33
AV34
AV35
AV36
AW14
AW31
AW32
AW33
AW34
AW35
AW36
AW37
AW38
AY29
AY30
AY31
AY32
AY35
AY36
AY37
AY38
BA13
BA14
BA29
BA30
BA31
BA32
BA33
BA34
BA35
BA36
BB13
BB14
BB31
BB32
BB33
BB34
BB35
BB36
BB37
BB38
BC29
BC30
BC31
BC32
BC35
BE33
BE34
BE35
BE36

+VCCGT

VCC_SENSE VSS_SENSE

A A

5

4

R474*49.9/F_4

+VCC_COR E (40,44)

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

Custom

Custom

Custom

PROJECT :

SNB 4/5 (POWER & GND)

SNB 4/5 (POWER & GND)

SNB 4/5 (POWER & GND)

1

2A

2A

2A

7 66Wednes day, October 19, 201 6

7 66Wednes day, October 19, 201 6

7 66Wednes day, October 19, 201 6

Size Docu ment Number Rev

Size Docu ment Number Rev

Size Docu ment Number Rev

Date: Sheet of

Date: Sheet of

3

2

Date: Sheet of

5

4

3

2

1

U34F

SKYLAKE_HALO

BGA1440

Y38

VSS

Y37

VSS

Y14

VSS

Y13

VSS

Y11

VSS

Y10

VSS

Y9

D D

C C

B B

W34
W33
W12

M14
M13
M12

Y8
Y7

W5
W4

W3
W2
W1

V30
V29
V12

V6
U38
U37

U6
T34
T33
T14
T13
T12
T11
T10

T9

T8

T7

T5

T4

T3

T2

T1
R30
R29
R12
P38
P37
P12

P6
N34
N33
N12
N11
N10

N9

N8

N7

N6

N5

N4

N3

N2

N1

M6
L34
L33
L30
L29

K38
K11
K10

K9
K8
K7
K5
K4
K3
K2

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

SKL_H_BGA_BGA

6 OF 14

Haswell Processor (GND)

K1

VSS

J36

VSS

J33

VSS

J32

VSS

J25

VSS

J22

VSS

J18

VSS

J10

VSS

J7

VSS

J4

VSS

H35

VSS

H32

VSS

H25

VSS

H22

VSS

H18

VSS

H12

VSS

H11

VSS

G28

VSS

G26

VSS

G24

VSS

G23

VSS

G22

VSS

G20

VSS

G18

VSS

G16

VSS

G14

VSS

G12

VSS

G10

VSS

G9

VSS

G8

VSS

G6

VSS

G5

VSS

G4

VSS

F36

VSS

F31

VSS

F29

VSS

F27

VSS

F25

VSS

F23

VSS

F21

VSS

F19

VSS

F17

VSS

F15

VSS

F13

VSS

F11

VSS

F9

VSS

F8

VSS

F5

VSS

F4

VSS

F3

VSS

F2

VSS

E38

VSS

E35

VSS

E34

VSS

E9

VSS

E4

VSS

D33

VSS

D30

VSS

D28

VSS

D26

VSS

D24

VSS

D22

VSS

D20

VSS

D18

VSS

D16

VSS

D14

VSS

D12

VSS

D10

VSS

D9

VSS

D6

VSS

D3

VSS

C37

VSS

C31

VSS

C29

VSS

C27

VSS

D38

NCTFVSS

BT32
BT26
BT24
BT21
BT18
BT14
BT12

BR36
BR34
BR29
BR26
BR24
BR21
BR18
BR14
BR12

BP34
BP33
BP29
BP26
BP24
BP21
BP18
BP14
BP12

BN34
BN31
BN30
BN29
BN24
BN21
BN20
BN19
BN18
BN14
BN12

BM38
BM35
BM28
BM27
BM26
BM23
BM21
BM13
BM12

BL29
BK29
BK15
BK14
BJ32
BJ31
BJ25
BJ22
BH14
BH12

BG38
BG13
BG12
BF33
BF12
BE29

BC34
BC12
BB12

C17
C13

C9

BT9
BT5

BR7

BP7

BN9
BN7
BN4
BN2

BM9
BM6
BM2

BH9
BH8
BH5
BH4
BH1

BE6

BD9

U34L

SKYLAKE_HALO

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

SKL_H_BGA_BGA

BGA1440

12 OF 14

NCTFVSS
NCTFVSS
NCTFVSS
NCTFVSS
NCTFVSS
NCTFVSS

U34M

SKYLAKE_HALO

AW5
AW4
AW3
AW2
AW1

AT30
AT29

AM5
AM4
AM3
AM2
AM1
AL34
AL33
AL14
AL12
AL10

BB4
BB3
BB2
BB1

BA9
BA8
BA7
BA6

B9

AU9
AU8
AU7
AU6

AT6

AR5
AR4
AR3
AR2
AR1

AP9
AP8

AN6
AN5

AL9
AL8
AL7
AL4

BGA1440

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

SKL_H_BGA_BGA

13 OF 14

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

NCTFVSS
NCTFVSS
NCTFVSS
NCTFVSS
NCTFVSS

AK30
AK29
AK4
AJ38
AJ37
AJ6
AJ5
AJ4
AJ3
AJ2
AJ1
AH34
AH33
AH12
AH6
AG30
AG29
AG11
AG10
AG8
AG7
AG6
AF14
AF13
AF12
AF4
AF3
AF2
AF1
AE34
AE33
AE6
AD30
AD29
AD12
AD11
AD10
AD9
AD8
AD7
AD6
AC38
AC37
AC12
AC6
AC5
AC4
AC3
AC2
AC1
AB34
AB33
AB6
AA30
AA29
AA12
A30
A28
A26
A24
A22
A20
A18
A16
A14
A12
A10
A9
A6

B37
B3
A34
A4
A3

PCH_2_CPU_TRIG(15)

C25

VSS

C23

VSS

C21

VSS

C19

VSS

C15

VSS

C11

VSS

C8

VSS

C5

VSS

BM29

VSS

BM25

VSS

BM18

VSS

BM11

VSS

BM8

VSS

BM7

VSS

BM5

VSS

BM3

VSS

BL38

VSS

BL35

VSS

BL13

VSS

BL6

VSS

BK25

VSS

BK22

VSS

BK13

VSS

BK6

VSS

BJ30

VSS

BJ29

VSS

BJ15

VSS

BJ12

VSS

BH11

VSS

BH10

VSS

BH7

VSS

BH6

VSS

BH3

VSS

BH2

VSS

BG37

VSS

BG14

VSS

BG6

VSS

BF34

VSS

BF6

VSS

BE30

VSS

BE5

VSS

BE4

VSS

BE3

VSS

BE2

VSS

BE1

VSS

BD38

VSS

BD37

VSS

BD12

VSS

BD11

VSS

BD10

VSS

BD8

VSS

BD7

VSS

BD6

VSS

BC33

VSS

BC14

VSS

BC13

VSS

BC6

VSS

BB30

VSS

BB29

VSS

BB6

VSS

BB5

VSS

C2
BT36
BT35
BT4
BT3
BR38

BA38
BA37
BA12
BA11
BA10

AY34
AY33
AY14

AY12
AW30
AW29
AW12

AV38

AV37

AU34

AU33

AU12

AU11

AU10

AR38

AR37

AR14

AR13

AP34

AP33

AP12

AP11

AP10

AN30

AN29

AN12

AM38
AM37
AM12

Haswell Processor (RESERVED, CFG)

U34K

TP68
TP67
TP65
TP66

TP24
TP27

EC-C-01

CPU_2_PCH_TRIG_R

CPU_2_PCH_TRIG_R CPU_2_PCH_TRIG

D1
E1
E3
E2

BR1
BT2

BN35

J24

H24

BN33

BL34

N29

R14
AE29
AA14

A36

A37

H23

J23

F30

E30

B30

C30

G3

J3

BR35
BR31
BH30

R79 30_4

RSVD_TP
RSVD_TP
RSVD_TP
RSVD_TP

RSVD_TP
RSVD_TP

RSVD
RSVD

RSVD
RSVD
RSVD

RSVD
RSVD
RSVD
RSVD

RSVD
RSVD

PROC_TRIGIN
PROC_TRIGOUT

RSVD
RSVD

RSVD
RSVD

RSVD
RSVD

RSVD
RSVD
RSVD

SKL_H_BGA_BGA

SKYLAKE_HALO

BGA1440

11 OF 14

CPU_2_PCH_TRIG (15)

RSVD_TP
RSVD_TP

RSVD_TP
RSVD_TP

RSVD
RSVD

RSVD_TP
RSVD_TP

RSVD_TP
RSVD_TP

RSVD
RSVD

RSVD
RSVD

RSVD_TP
RSVD_TP

RSVD
RSVD
RSVD

NCTF
NCTF
NCTF
NCTF
NCTF
NCTF

08

BM33
BL33

BJ14
BJ13

BK28
BJ28

BJ18

VSS

BJ16
BK16

BK24
BJ24

BK21
BJ21

BT17
BR17

BK18

VSS

BJ34
BJ33

G13
AJ8
BL31

B2
B38
BP1
BR2
C1
C38

TP16
TP17

TP14
TP15

TP7
TP5

TP8
TP13

TP18
TP20

A A

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet of

Date: Sheet of

5

4

3

2

Date: Sheet of

Custom

Custom

Custom

PROJECT :

SNB 5/5 (GND)

SNB 5/5 (GND)

SNB 5/5 (GND)

1

2A

2A

8 66Wednesday, October 19, 2016

8 66Wednesday, October 19, 2016

8 66Wednesday, October 19, 2016

2A

5

4

3

2

1

Change DMI TX/RX connect_20150109

DMI_TXN0(3)
DMI_TXP0(3)

DMI_RXN0(3)

DMI_RXP0(3)

DMI_TXN1(3)
DMI_TXP1(3)

DMI_RXN1(3)

DMI_RXP1(3)

D D

PCIE_U3P1_RXN5(26)
PCIE_U3P1_RXP5(26)

C C

USB3.1 Host x2

Cardreader(DB)

WLAN

B B

USB3.0 (DB)

USB3.0 (DB)

A A

5

PCIE_U3P1_TXN5(26)
PCIE_U3P1_TXP5(26)
PCIE_U3P1_RXP6(26)
PCIE_U3P1_RXN6(26)
PCIE_U3P1_TXP6(26)
PCIE_U3P1_TXN6(26)

PCIE_RXN7_CARD(29)
PCIE_RXP7_CARD(29)
PCIE_TXN7_CARD(29)
PCIE_TXP7_CARD(29)
PCIE_RXN8_WLAN(25)
PCIE_RXP8_WLAN(25)
PCIE_TXN8_WLAN(25)
PCIE_TXP8_WLAN(25)

USB30_TX2-(29)
USB30_TX2+(29)
USB30_RX2-(29)
USB30_RX2+(29)

USB30_TX3+(29)
USB30_TX3-(29)
USB30_RX3+(29)
USB30_RX3-(29)

DMI_TXN2(3)
DMI_TXP2(3)

DMI_RXN2(3)

DMI_RXP2(3)

DMI_TXN3(3)
DMI_TXP3(3)

DMI_RXN3(3)

DMI_RXP3(3)

R637 100/F_4

cap @ host ic

C832 0.1U/16V_4
C827 0.1U/16V_4

C839 0.1U/16V_4
C836 0.1U/16V_4

U49F

C11

USB3_1_TXN

B11

USB3_1_TXP

B7

USB3_1_RXN

A7

USB3_1_RXP

B12

USB3_2_TXN/SSIC_1_TXN

A12

USB3_2_TXP/SSIC_1_TXP

C8

USB3_2_RXN/SSIC_1_RXN

B8

USB3_2_RXP/SSIC_1_RXP

B15

USB3_6_TXN

C15

USB3_6_TXP

K15

USB3_6_RXN

K13

USB3_6_RXP

B14

USB3_5_TXN

C14

USB3_5_TXP

G13

USB3_5_RXN

H13

USB3_5_RXP

D13

USB3_3_TXP/SSIC_2_TXP

C13

USB3_3_TXN/SSIC_2_TXN

A9

USB3_3_RXP/SSIC_2_RXP

B10

USB3_3_RXN/SSIC_2_RXN

B13

USB3_4_TXP

A14

USB3_4_TXN

G11

USB3_4_RXP

E11

USB3_4_RXN

SPT_PCH_H

PCIECOMP_N
PCIECOMP_P

PCIE_TXN7_CARD_C
PCIE_TXP7_CARD_C

PCIE_TXN8_WLAN_C
PCIE_TXP8_WLAN_C

SPT-H_PCH

USB

4

U49B

L27

DMI_RXN0

N27

DMI_RXP0

C27

DMI_TXN0

B27

DMI_TXP0

E24

DMI_RXN1

G24

DMI_RXP1

B28

DMI_TXN1

A28

DMI_TXP1

G27

DMI_RXN2

E26

DMI_RXP2

B29

DMI_TXN2

C29

DMI_TXP2

L29

DMI_RXN3

K29

DMI_RXP3

B30

DMI_TXN3

A30

DMI_TXP3

B18

PCIE_RCOMPN

C17

PCIE_RCOMPP

H15

PCIE1_RXN/USB3_7_RXN

G15

PCIE1_RXP/USB3_7_RXP

A16

PCIE1_TXN/USB3_7_TXN

B16

PCIE1_TXP/USB3_7_TXP

B19

PCIE2_TXN/USB3_8_TXN

C19

PCIE2_TXP/USB3_8_TXP

E17

PCIE2_RXN/USB3_8_RXN

G17

PCIE2_RXP/USB3_8_RXP

L17

PCIE3_RXN/USB3_9_RXN

K17

PCIE3_RXP/USB3_9_RXP

B20

PCIE3_TXN/USB3_9_TXN

C20

PCIE3_TXP/USB3_9_TXP

E20

PCIE4_RXN/USB3_10_RXN

G19

PCIE4_RXP/USB3_10_RXP

B21

PCIE4_TXN/USB3_10_TXN

A21

PCIE4_TXP/USB3_10_TXP

K19

PCIE5_RXN

L19

PCIE5_RXP

D22

PCIE5_TXN

C22

PCIE5_TXP

G22

PCIE6_RXN

E22

PCIE6_RXP

B22

PCIE6_TXN

A23

PCIE6_TXP

L22

PCIE7_RXN

K22

PCIE7_RXP

C23

PCIE7_TXN

B23

PCIE7_TXP

K24

PCIE8_RXN

L24

PCIE8_RXP

C24

PCIE8_TXN

B24

PCIE8_TXP

SPT_PCH_H

LPC/eSPI

GPP_A7/PIRQA#/ESPI_ALERT0#

GPP_A0/RCIN#/ESPI_ALERT1#

GPP_A14/SUS_STAT#/ESPI_RESET#

GPP_A9/CLKOUT_LPC0/ESPI_CLK

SATA

6 OF 12

GPP_A5/LFRAME#/ESPI_CS0#

GPP_A6/SERIRQ/ESPI_CS1#

SPT-H_PCH

DMI

PCIe/USB 3

GPP_A1/LAD0/ESPI_IO0
GPP_A2/LAD1/ESPI_IO1
GPP_A3/LAD2/ESPI_IO2
GPP_A4/LAD3/ESPI_IO3

GPP_A10/CLKOUT_LPC1

GPP_G19/SMI#
GPP_G18/NMI#

GPP_E6/DEVSLP2
GPP_E5/DEVSLP1
GPP_E4/DEVSLP0
GPP_F9/DEVSLP7
GPP_F8/DEVSLP6
GPP_F7/DEVSLP5
GPP_F6/DEVSLP4
GPP_F5/DEVSLP3

USB 2.0

GPP_E10/USB2_OC1#
GPP_E11/USB2_OC2#

GPP_E12/USB2_OC3#
GPP_F15/USB2_OCB_4
GPP_F16/USB2_OCB_5
GPP_F17/USB2_OCB_6
GPP_F18/USB2_OCB_7

2 OF 12

AT22
AV22
AT19
BD16

BE16
BA17

SERIRQ

BOARD_ID8

AW17
AT17

BOARD_ID7

BC18

CLK_PCI_EC_R

BC17

CLK_PCI_LPC_R

AV19
M45

N43

AE45

GC6FBEN_Q

AG43

SSD_DEVSLP

AG42

DGPU_HOLD_RST#

AB39

GPU_EVENT#

AB36
AB43

GFXON
DGPU_PWROK_Q

AB42

GPU_OVERT#_PCH

AB41

USB2N_1
USB2P_1
USB2N_2
USB2P_2
USB2N_3
USB2P_3
USB2N_4
USB2P_4
USB2N_5
USB2P_5
USB2N_6
USB2P_6
USB2N_7
USB2P_7
USB2N_8
USB2P_8
USB2N_9

USB2P_9
USB2N_10
USB2P_10
USB2N_11
USB2P_11
USB2N_12
USB2P_12
USB2N_13
USB2P_13
USB2N_14
USB2P_14

GPP_E9/USB2_OC0#

USB2_COMP

USB2_VBUSSENSE

RSVD_AB13

USB2_ID

GPD7/RSVD

AF5
AG7
AD5
AD7
AG8
AG10
AE1
AE2
AC2
AC3
AF2
AF3
AB3
AB2
AL8
AL7
AA1
AA2
AJ8
AJ7
W2
W3
AD3
AD2
V2
V1
AJ11
AJ13

AD43
AD42
AD39

USB_OC3#

AC44

USB_OC4#

Y43

USB_OC5#

Y41

USB_OC6#

W44

PCH_AOCS#

W43

USB2_COMP

AG3
AD10
AB13
AG2

BD14

LPC_LAD0 (25,32)
LPC_LAD1 (25,32)
LPC_LAD2 (25,32)
LPC_LAD3 (25,32)

LPC_LFRAME# (25,32)

R252 8.2K_4

BOARD_ID8 (13)
EC_RCIN# (32)
BOARD_ID7 (13)

SIO_EXT_SMI# (26,32)

SSD_DEVSLP (24)

DGPU_HOLD_RST# (53)
GPU_EVENT# (55)
GFXON (45,50,51,56)

GPU_OVERT#_PCH (56)

3

USB_OC3# (26)
USB_OC4# (26)
USB_OC5# (29)
USB_OC6# (29)

R211 113/F_4

+3V

SERIRQ (32)

R640 22/F_4

R258 22/F_4

USBP3- (18)

Camera

USBP3+ (18)

USBP6- (29)

USB2.0 Combo USB3.0 DB

USBP6+ (29)
USBP7- (25)

WLAN/BT

USBP7+ (25)
USBP8- (29)

USB DB

USBP8+ (29)

EC70 18P/50V_4

EC35 18P/50V_4

PU at USB3.1 host

CLK_24M_KBC (32)
PCLK_DEBUG (25)

EMI(near PCH)

2

EC-A-10

GC6FBEN(51,55,56)

09

GPU Strap

DFX TEST MODE

XTAL INPUT IS SINGLE ENDED IF
SAMPLED LOW ELSE
DIFFERENTIAL

DGPU_PWROK_Q

RING OSCILLATOR BYPASS

DGPU_HOLD_RST#

XTAL INPUT FREQUENCY[0]

GPU_EVENT#

XTAL INPUT FREQUENCY[1]

GFXON

DGPU_EVENT#-- For BIOS check

GPU_OVERT#_PCH
GPU_EVENT#
DGPU_HOLD_RST#
GFXON
DGPU_PWROK_Q
SIO_EXT_SMI#
EC_RCIN#

USB_OC5#
USB_OC3#

USB_OC4#
USB_OC6#
PCH_AOCS#

1V8_AON

DGPU_PWROK_Q

3

+3V

R766
10K_4

3

2

Q72

DMG1012T-7

1

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

Custom

Custom

Custom

R736*10K_4

R739100K_4

R738*100K_4

R347*10K_4

+3V

R714*10K_4
R72710K_4
R729*10K_4
R35610K_4

10K_4

R732
R71510K_4
R24810K_4

+3V_DEEP_SUS

R71610K_4
R737*10K_4

R72610K_4

R71810K_4
R71710K_4

2

1

Q66DMG1012T-7

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

PROJECT :

PCH 1/6 (DMI/FDI/VIDEO)

PCH 1/6 (DMI/FDI/VIDEO)

PCH 1/6 (DMI/FDI/VIDEO)

C934

*0.1U/16V_4

+3V_DEEP_SUS(10,12,13,14,16,43)

1

R74410K_4

DGPU_PWROK (32,53,56)

2

GC6FBEN_Q

3

DMG1012T-7

1

Q71

9 66Wednesday, October 26, 2016

9 66Wednesday, October 26, 2016

9 66Wednesday, October 26, 2016

2A

2A

2A

5

HDA Bus(CLG)

R596 1K_4

RV9 *EGA-0402
RV25 *EGA-0402
RV8 *EGA-0402

C461 *220P/50V_4
C440 *220P/50V_4

MBCLK2(32)

MBDATA2(32)

+3V

+3V

R606 33_4
R619 33_4

R597 33_4

R622 33_4

SMB_ME0_CLK
SMB_ME0_DAT
SMB_ME1_CLK
SMB_ME1_DAT
SMB_PCH_CLK
SMB_PCH_DAT

RF_OFF_PCH
SUSWARN#
SUSACK#

R361 4.7K_4

R366 4.7K_4

ACZ_BIT_CLK_AUDIO(21)

ACZ_RST#_AUDIO(21)
ACZ_SDOUT(12)
ACZ_SDOUT_AUDIO(21)

ACZ_SYNC_AUDIO(21)

D D

+3V_DEEP_SUS

Add PU _20141212

R354 2.2K_4
R355 2.2K_4
R723 2.2K_4
R724 2.2K_4
R353 2.2K_4
R352 2.2K_4

R626 10K_4
R646 10K_4
R649 *10K_4

GPIO33_EC(32)

DDR3_DRAMRST#
PCIE_WAKE#
SYS_RESET#

C C

RSMRST#
EC_PWROK

SMB_RUN_DAT(16,17)

B B

SMB_RUN_CLK(16,17)

R623
*1M_4

ACZ_BCLK
ACZ_RST#

ACZ_SDOUT
ACZ_SYNC

ACZ_SDOUT

Reserve for EMI

EC66
*10P/50V_4

Change R2032 from 33 to 30_20141218

AUD_AZACPU_SDO_R(3)
AUD_AZACPU_SDI(3)
AUD_AZACPU_SCLK(3)

AUD_AZACPU_SCLK

EMI

EC65

*33P/50V_4

ACZ_SDOUT

RSMRST#(32) AC_PRESENT (32,55)

SML0ALERT#(12)

DRAMRST_CNTRL_PCH(12)

SML1ALERT#_R(12)

TP49

Q65

4 3

1

*2N7002DW

Q30

4 3

1

2N7002KDW

+3V

5

SMB_ME1_CLK

2

SMB_ME1_DAT

6

+3V

5

SMB_PCH_DAT

2

SMB_PCH_CLK

6

RTC Circuitry(RTC)

+5VPCU

R397

1.2K_4

R396

4.7K/F_4

R395
15K/F_4

A A

+3V_RTC_0

12

RTC_B

CN22

3

4

Q35

MMBT3904

R398

13

1K_4

2

RTC Power trace width 20mils.

+3VPCU

R752 1K_4

+3V_RTC_1

5

D21
BAT54CW

1U/6.3V_4

C850

30mils

+3V_RTC

R659

20K/F_4

R669
20K/F_4

J1

1 2

C830
1U/6.3V_4

C849
1U/6.3V_4

4

ACZ_BCLK

AUD_AZACPU_SDO
AUD_AZACPU_SDI
AUD_AZACPU_SCLK_R

+3V_DEEP_SUS

R598
*4.7K_4

PCH_PWROK

RSMRST#

DSWROK_EC_R
SML0ALERT#

SMB_PCH_CLK
SMB_PCH_DAT
DRAMRST_CNTRL_PCH
SMB_ME0_CLK
SMB_ME0_DAT

SMB_ME1_CLK
SMB_ME1_DAT

3

1

4

ACZ_RST#

ACZ_SDOUT
ACZ_SYNC

RTC_RST#
SRTC_RST#

2

Q64

2N7002K

RTC_RST#

ACZ_SDIN0(21)

R601 30_4
R608 30_4

SML1ALERT#_R

CPU heat pipe local thermal sensor
DDR thermal sensor
EC

DPt o CRT
DDR4

*SOLDERJUMPER-2

RTC_RST#

SRTC_RST#

U49D

BA9

HDA_BCLK

BD8

HDA_RST#

BE7

HDA_SDI0

BC8

HDA_SDI1

BB7

HDA_SDO

BD9

HDA_SYNC

BD1

RSVD_BD1

BE2

RSVD_BE2

AM1

DISPA_SDO

AN2

DISPA_SDI

AM2

DISPA_BCLK

AL42

GPP_D8/I2S0_SCLK

AN42

GPP_D7/I2S0_RXD

AM43

GPP_D6/I2S0_TXD

AJ33

GPP_D5/I2S0_SFRM

AH44

GPP_D20/DMIC_DATA0

AJ35

GPP_D19/DMIC_CLK0

AJ38

GPP_D18/DMIC_DATA1

AJ42

GPP_D17/DMIC_CLK1

BC10

RTCRST#

BB10

SRTCRST#

AW11

PCH_PWROK

BA11

RSMRST#

AV11

DSW_PWROK

BB41

GPP_C2/SMBALERT#

AW44

GPP_C0/SMBCLK

BB43

GPP_C1/SMBDATA

BA40

GPP_C5/SML0ALERT#

AY44

GPP_C3/SML0CLK

BB39

GPP_C4/SML0DATA

AT27

GPP_B23/SML1ALERT#/PCHHOT#

AW42

GPP_C6/SML1CLK

AW45

GPP_C7/SML1DATA

SPT_PCH_H

EC_RTC_RST (32)

R680
10K_4

SPT-H_PCH

GPP_A12/BMBUSY#/ISH_GP6/SX_EXIT_HOLDOFF#

AUDIO

SMBUS

4 OF 12

System PWR_OK(CLG)

For HWPG Sequence

+1.0V

R344
15K/F_4

+1.0V_PWRGD_G1

C525

0.1U/16V_4

3

GPP_A8/CLKRUN#
GPD11/LANPHYPC

GPD9/SLP_WLAN#

GPP_B2/VRALERT#

GPP_G17/ADR_COMPLETE

GPP_B12/SLP_S0#

R343
100K_4

+5V_S5

2

GPP_A15/SUSACK#

GPD2/LAN_WAKE#
GPD1/ACPRESENT

4

TC7SH08FU

R364
100K_4

+1.0V_PWRGD_G2

Q31
METR3904-G

1 3

GPP_A13/SUSWARN#/SUSPWRDNACK

JTAG

PCH_PWROK

3

DRAM_RESET#

GPP_B1
GPP_B0

GPP_B11

SYS_PWROK

WAKE#

GPD6/SLP_A#

SLP_LAN#

GPD4/SLP_S3#
GPD5/SLP_S4#

GPD10/SLP_S5#

GPD8/SUSCLK

GPD0/BATLOW#

SLP_SUS#

GPD3/PWRBTN#

SYS_RESET#

GPP_B14/SPKR

PROCPWRGD

ITP_PMODE

JTAGX
JTAG_TMS
JTAG_TDO

JTAG_TDI

JTAG_TCK

+3V_S5

C424 *0.1U/10V_4

U13

3 5

R195 *0_4

2
1

BB17
AW22

AR15
AV13
BC14

BD23
AL27
AR27
N44
AN24
AY1

BC13
BC15
AV15
BC26
AW15
BD15
BA13

AN15
BD13
BB19
BD19

BD11
BB15
BB13
AT13
AW1
BD26
AM3

AT2
AR3
AR2
AP1
AP2
AN3

2

CLKRUN#
LAN_DISABLE

DDR3_DRAMRST#
GPP_B2

EC_PWROK
PCIE_WAKE#

PCH_SLP_S0_N

PCH_SUSCLK
RF_OFF_PCH
SUSACK#
SUSWARN#

EC-A-15
EC-B-05

AC_PRESENT_R
SLP_SUS#_EC
DNBSWON#
SYS_RESET#
ACZ_SPKR
PROCPWRGD

ITP_PMODE

JTAGX
JTAG_TMS_PCH
JTAG_TDO_PCH
JTAG_TDI_PCH
JTAG_TCK_PCH

IMVP_PWRGD
EC_PWROK

R200
100K_4

+3V_S5

R340
10K_4

3

Q29
2N7002K

1

R593 1K_4

HWPG

R341
100K_4

2

TP47

CLKRUN# (32)

TP46
TP43

TP44

PCH_SLP_S0_N (32,37)

TP90
TP40

R645*0_4/S
R643*0_4/S

R644*0_4

SUSWARN#

R246*0_4

TP81

TP6

TP74
TP78
TP75
TP77
TP76

IMVP_PWRGD (39)
EC_PWROK (21,32)

HWPG (2,32,34,35,36,38,49)

2

+1.2VSUS

R630
470/F_4

PCIE_WAKE# (23,25,26,32)

SUSB# (32)
SUSC# (32)

RF_OFF_PCH (25)

SUSACK#_EC (32)

SUSWARN#_EC (32)

SLP_SUS#_EC (32)
DNBSWON# (32)

ACZ_SPKR (12,21)

PROCPWRGD (2)
+1.0V_DEEP_SUS

For DS3 Sequence

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

DDR3_DRAMRST# (16,17)

R604
*51_4

R612
*51_4

RSMRST#

DSWROK_EC(32)

+3V_S5

+3V

Custom

Custom

Custom

1

SYS_RESET#
GPP_B2

R600 10K_4
R678 10K_4

+1.0V

JTAGX

R602

R603

*51_4

*51_4

JTAG_TMS_PCH
JTAG_TDI_PCH
JTAG_TDO_PCH

R611

R610

*51_4

*51_4

For DS3 -->Ra<---­Non-DS3 -->Rb

Rb

R226 *0_4

R205 *0_4/S

JTAG_TCK_PCH

R616
51_4

Ra

R625 1K_4
R629 10K_4

R284 8.2K/F_4

RSMRST#
DSWROK_EC
IMVP_PWRGD

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

PROJECT :

PCH 2/6 (SATA/HDA/SPI)

PCH 2/6 (SATA/HDA/SPI)

PCH 2/6 (SATA/HDA/SPI)

PCIE_WAKE#
AC_PRESENT_R

CLKRUN#

R240 10K_4
R193 100K_4
R176 *100K_4

1

10

+3V

JTAGX (2)

DSWROK_EC_R

10 66Wednesday, October 26, 2016

10 66Wednesday, October 26, 2016

10 66Wednesday, October 26, 2016

JTAG_TMS_PCH (2)
JTAG_TDI_PCH (2)
JTAG_TDO_PCH (2)

EC-A-16

2A

2A

2A

5

D D

SSD X4 lane

NGFF_SSD_PRESENT#
PM_THRMTRIP#
PCH_PECI

C C

PM_SYNC
CPU_PLTRST#R
H_PM_DOWN

The 24 MHz (50 Ohm ESR) XTAL used for Skylake-H
needs to be replaced by 38.4 MHz (30 Ohm ESR) XTAL for Cannonlake-H.

RV11 *EGA-0402
RV7 *EGA-0402
RV20 *EGA-0402

RV23 *EGA-0402
RV21 *EGA-0402
RV24 *EGA-0402

9/10/11/12

4

U49C

AV2

CL_CLK

AV3

CL_DATA

AW2

CL_RST#

R44

GPP_G8/FAN_PWM_0

R43

GPP_G9/FAN_PWM_1

U39

GPP_G10/FAN_PWM_2

N42

GPP_G11/FAN_PWM_3

U43

GPP_G0/FAN_TACH_0

U42

GPP_G1/FAN_TACH_1

U41

GPP_G2/FAN_TACH_2

M44

GPP_G3/FAN_TACH_3

U36

GPP_G4/FAN_TACH_4

P44

GPP_G5/FAN_TACH_5

T45

GPP_G6/FAN_TACH_6

T44

GPP_G7/FAN_TACH_7

PCIE_TXP11(24)
PCIE_TXN11(24)
PCIE_RXP11(24)
PCIE_RXN11(24)

PCIE_TXP12(24)
PCIE_TXN12(24)
PCIE_RXP12(24)
PCIE_RXN12(24)

B33

PCIE11_TXP

C33

PCIE11_TXN

K31

PCIE11_RXP

L31

PCIE11_RXN

AB33

GPP_F10/SCLOCK

AB35

GPP_F11/SLOAD

AA44

GPP_F13/SDATAOUT0

AA45

GPP_F12/SDATAOUT1

B38

PCIE14_TXN/SATA1B_TXN

C38

PCIE14_TXP/SATA1B_TXP

D39

PCIE14_RXN/SATA1B_RXN

E37

PCIE14_RXP/SATA1B_RXP

C36

PCIE13_TXN/SATA0B_TXN

B36

PCIE13_TXP/SATA0B_TXP

G35

PCIE13_RXN/SATA0B_RXN

E35

PCIE13_RXP/SATA0B_RXP

A35

PCIE12_TXP

B35

PCIE12_TXN

H33

PCIE12_RXP

G33

PCIE12_RXN

J45

PCIE20_TXP/SATA7_TXP

K44

PCIE20_TXN/SATA7_TXN

N38

PCIE20_RXP/SATA7_RXP

N39

PCIE20_RXN/SATA7_RXN

H44

PCIE19_TXP/SATA6_TXP

H43

PCIE19_TXN/SATA6_TXN

L39

PCIE19_RXP/SATA6_RXP

L37

PCIE19_RXN/SATA6_RXN

SPT_PCH_H

SPT-H_PCH

CLINK

FAN

3 OF 12

3

PCIE9_RXN/SATA0A_RXN

PCIE9_RXP/SATA0A_RXP
PCIE9_TXN/SATA0A_TXN
PCIE9_TXP/SATA0A_TXP

PCIE10_RXN/SATA1A_RXN

PCIE10_RXP/SATA1A_RXP
PCIE10_TXN/SATA1A_TXN
PCIE10_TXP/SATA1A_TXP

PCIE15_RXN/SATA2_RXN
PCIE15_RXP/SATA2_RXP
PCIE15_TXN/SATA2_TXN

PCIE15_TXP/SATA2_TXP

PCIe/SATA

PCIE16_RXN/SATA3_RXN
PCIE16_RXP/SATA3_RXP
PCIE16_TXN/SATA3_TXN

PCIE16_TXP/SATA3_TXP

PCIE17_RXN/SATA4_RXN
PCIE17_RXP/SATA4_RXP
PCIE17_TXN/SATA4_TXN

PCIE17_TXP/SATA4_TXP

PCIE18_RXN/SATA5_RXN
PCIE18_RXP/SATA5_RXP
PCIE18_TXN/SATA5_TXN

PCIE18_TXP/SATA5_TXP

GPP_E8/SATALED#

GPP_E0/SATAXPCIE0/SATAGP0
GPP_E1/SATAXPCIE1/SATAGP1
GPP_E2/SATAXPCIE2/SATAGP2
GPP_F0/SATAXPCIE3/SATAGP3
GPP_F1/SATAXPCIE4/SATAGP4
GPP_F2/SATAXPCIE5/SATAGP5
GPP_F3/SATAXPCIE6/SATAGP6
GPP_F4/SATAXPCIE7/SATAGP7

GPP_F21/EDP_BKLTCTL

GPP_F20/EDP_BKLTEN

GPP_F19/EDP_VDDEN

HOST

PLTRST_PROC#

THERMTRIP#

PM_SYNC

PM_DOWN

PECI

G31
H31
C31
B31

G29
E29
C32
B32

F41
E41

PCIE_TXN15_LAN_C

B39

PCIE_TXP15_LAN_C

A39
D43

E42
A41
A40

H42
H40
E45
F45

K37
G37
G45
G44

AD44
AG36

AG35
AG39
AD35
AD31
AD38
AC43
AB44

W36
W35
W42

PM_THRMTRIP#_R

AJ3
AL3

PM_SYNC_R

AJ4

CPU_PLTRST#

AK2

H_PM_DOWN

AH2

PCIE_SATA_RXN9 (24)
PCIE_SATA_RXP9 (24)
PCIE_SATA_TXN9 (24)
PCIE_SATA_TXP9 (24)

PCIE_RXN10 (24)
PCIE_RXP10 (24)
PCIE_TXN10 (24)
PCIE_TXP10 (24)

C860 0.1U/16V_4
C859 0.1U/16V_4

R728 10K_4

HDD_LED# (29)
NGFF_SSD_PRESENT# (24)

TP52

R615 30_4
R609 *0_4/S

+3V

LCD_PWM (18)
PANEL_BKEN (18)
ENVDD (18)

CPU_PLTRST#R (2)
H_PM_DOWN (2)

2

SSD X4 lane

PCIE_RXN15_LAN (23)
PCIE_RXP15_LAN (23)
PCIE_TXN15_LAN (23)
PCIE_TXP15_LAN (23)

SATA_RXN3 (24)
SATA_RXP3 (24)
SATA_TXN3 (24)
SATA_TXP3 (24)

R190 619_4

PM_SYNC (2)

9/10/11/12

LAN

HDD (SATA0 6Gb/s)

Need placment near PCH

R599
*10K_4

R1851K_4

+VCCSTPLL

PM_THRMTRIP# (16,17,2,32)
PCH_PECI (2)

NGFF_SSD_PRESENT#

1

11

+3V

R367 10K_4

C45312P/50V_4

1

2

24MHZ +-30PPM

B B

R214

Y1

4

3

C43912P/50V_4

RTC Clock 32.768KHz

C802 18P/50V_4

C807 18P/50V_4

A A

2 1

5

1M_4

Y5

32.768KHZ/20PPM

XTAL24_IN
XTAL24_OUT

R624
10M_4

RTC_X1

RTC_X2

+1.0V_DEEP_SUS

R617

2.7K/F_4

PCIE_CLKREQ_CR#(29)

PCIE_CLKREQ_WLAN#(25)

PCIE_CLKREQ_LAN#(23) CLK_VGA_N (53)
PCIE_CLKREQ_SSD#(24)

PCIE_CLKREQ_U3P1#(26)

GPP_A16(29)

CLK_DPLL_NSCCLKP(2)
CLK_DPLL_NSCCLKN(2) CPU_PCI_BCLKN (2)

CLK_CPU_BCLKP(2)

CLK_CPU_BCLKN(2)

XCLK_RBIAS

RTC_X1
RTC_X2

PCIE_CLKREQ0#
PCIE_CLKREQ_CR#
PCIE_CLKREQ_WLAN#
PCIE_CLKREQ_LAN#
PCIE_CLKREQ_VGA#
PCIE_CLKREQ_SSD#
PCIE_CLKREQ_U3P1#
PCIE_CLKREQ7#
PCIE_CLKREQ8#
PCIE_CLKREQ9#
PCIE_CLKREQ10#
PCIE_CLKREQ11#
PCIE_CLKREQ12#
PCIE_CLKREQ13#
PCIE_CLKREQ14#
PCIE_CLKREQ15#

4

XTAL24_OUT
XTAL24_IN

U49G

AR17

GPP_A16/CLKOUT_48

G1

CLKOUT_CPUNSSC_P

F1

CLKOUT_CPUNSSC

G2

CLKOUT_CPUBCLK_P

H2

CLKOUT_CPUBCLK

A5

XTAL24_OUT

A6

XTAL24_IN

E1

XCLK_BIASREF

BC9

RTCX1

BD10

RTCX2

BC24

GPP_B5/SRCCLKREQ0#

AW24

GPP_B6/SRCCLKREQ1#

AT24

GPP_B7/SRCCLKREQ2#

BD25

GPP_B8/SRCCLKREQ3#

BB24

GPP_B9/SRCCLKREQ4#

BE25

GPP_B10/SRCCLKREQ5#

AT33

GPP_H0/SRCCLKREQ6#

AR31

GPP_H1/SRCCLKREQ7#

BD32

GPP_H2/SRCCLKREQ8#

BC32

GPP_H3/SRCCLKREQ9#

BB31

GPP_H4/SRCCLKREQ10#

BC33

GPP_H5/SRCCLKREQ11#

BA33

GPP_H6/SRCCLKREQ12#

AW33

GPP_H7/SRCCLKREQ13#

BB33

GPP_H8/SRCCLKREQ14#

BD33

GPP_H9/SRCCLKREQ15#

R13

CLKOUT_PCIE_N15

R11

CLKOUT_PCIE_P15

P1

CLKOUT_PCIE_N14

R2

CLKOUT_PCIE_P14

W7

CLKOUT_PCIE_N13

Y5

CLKOUT_PCIE_P13

U2

CLKOUT_PCIE_N12

U3

CLKOUT_PCIE_P12

SPT_PCH_H

SPT-H_PCH

CLKOUT_CPUPCIBCLK

CLKOUT_CPUPCIBCLK_P

7 OF 12

CLKOUT_ITPXDP

CLKOUT_ITPXDP_P

CLKOUT_PCIE_N0
CLKOUT_PCIE_P0

CLKOUT_PCIE_N1
CLKOUT_PCIE_P1

CLKOUT_PCIE_N2
CLKOUT_PCIE_P2

CLKOUT_PCIE_N3
CLKOUT_PCIE_P3

CLKOUT_PCIE_N4
CLKOUT_PCIE_P4

CLKOUT_PCIE_N5
CLKOUT_PCIE_P5

CLKOUT_PCIE_N6
CLKOUT_PCIE_P6

CLKOUT_PCIE_N7
CLKOUT_PCIE_P7

CLKOUT_PCIE_N8
CLKOUT_PCIE_P8

CLKOUT_PCIE_N9
CLKOUT_PCIE_P9

CLKOUT_PCIE_N10
CLKOUT_PCIE_P10

CLKOUT_PCIE_N11
CLKOUT_PCIE_P11

3

L1
L2
J1
J2

N7
N8

L7
L5

D3
F2

E5
G4

D5
E6

D8
D7

R8
R7

U5
U7

W10
W11

N3
N2

P3
P2

R3
R4

CK_XDP_N_R
CK_XDP_P_R

TP82
TP80

CLK_PCIE_CRN (29)

CLK_PCIE_CRP (29)

CLK_PCIE_WLANN (25)
CLK_PCIE_WLANP (25)

CLK_PCIE_LANN (23)
CLK_PCIE_LANP (23)

CLK_VGA_P (53)PCIE_CLKREQ_VGA#(53)
CLK_PCIE_SSDN (24)

CLK_PCIE_SSDP (24)
CLK_PCIE_U3P1N (26)

CLK_PCIE_U3P1P (26)

CPU_PCI_BCLKP (2)

Card Reader

WLAN
LAN
VGA
SSD
USB3.1 Host

+3V

PCIE_CLKREQ_WLAN#
PCIE_CLKREQ_LAN#
PCIE_CLKREQ_CR#
PCIE_CLKREQ_VGA#
PCIE_CLKREQ0#
PCIE_CLKREQ_SSD#
PCIE_CLKREQ_U3P1#
PCIE_CLKREQ7#
PCIE_CLKREQ8#
PCIE_CLKREQ9#
PCIE_CLKREQ10#
PCIE_CLKREQ11#
PCIE_CLKREQ12#
PCIE_CLKREQ13#
PCIE_CLKREQ14#
PCIE_CLKREQ15#

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet of

Date: Sheet of

2

Date: Sheet of

R294 10K_4
R675 10K_4
R293 10K_4
R672 10K_4
R676 *10K_4
R671 10K_4
R324 10K_4
R315 *10K_4
R694 *10K_4
R683 *10K_4
R682 *10K_4
R697 *10K_4
R314 *10K_4
R313 *10K_4
R698 *10K_4
R693 *10K_4

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

PROJECT :

Custom

Custom

Custom

PCH 3/6 (PCIE/USB/CLK)

PCH 3/6 (PCIE/USB/CLK)

PCH 3/6 (PCIE/USB/CLK)

1

2A

2A

11 66Wednesday, October 19, 2016

11 66Wednesday, October 19, 2016

11 66Wednesday, October 19, 2016

2A

5

SPT-H_PCH

1 OF 12

GPP_B13/PLTRST#

GPP_G16/GSXCLK

GPP_G12/GSXDOUT

GPP_G13/GSXSLOAD

GPP_G14/GSXDIN

GPP_G15/GSXSRESET#

GPP_E3/CPU_GP0
GPP_E7/CPU_GP1
GPP_B3/CPU_GP2
GPP_B4/CPU_GP3

GPP_H18/SML4ALERT#

GPP_H17/SML4DATA

GPP_H16/SML4CLK

GPP_H15/SML3ALERT#

GPP_H14/SML3DATA

GPP_H13/SML3CLK

GPP_H12/SML2ALERT#

GPP_H11/SML2DATA

GPP_H10/SML2CLK

TP84

D D

C C

PCI_PME#

PCH_SPI1_SI
PCH_SPI1_SO
PCH_SPI_CS0#
PCH_SPI1_CLK

PCH_SPI_IO2
PCH_SPI_IO3

BD17
AG15

AG14
AF17
AE17

AR19
AN17

BB29
BE30
BD31
BC31

AW31

BC29
BD30
AT31

AN36
AL39
AN41
AN38
AH43
AG44

U49A

GPP_A11/PME#
RSVD

RSVD
RSVD
RSVD

TP2
TP1

SPI0_MOSI
SPI0_MISO
SPI0_CS0#
SPI0_CLK
SPI0_CS1#

SPI0_IO2
SPI0_IO3
SPI0_CS2#

GPP_D1/SPI1_CLK
GPP_D0/SPI1_CS#
GPP_D3/SPI1_MOSI
GPP_D2/SPI1_MISO
GPP_D22/SPI1_IO3
GPP_D21/SPI1_IO2

SPT_PCH_H

PCH SPI ROM(CLG)

Vender P/N
EON
Winbond 16MB

GigaDevice

Socket

B B

TP66-71 need place to TOP

TP86
TP55
TP56
TP87
TP85
TP54

EC-A-04

A A

C872 1U/10V_4

Size

PCH_SPI_CS0#_R
PCH_SPI1_CLK_R
PCH_SPI1_SI_R
PCH_SPI1_SO_R
BIOS_WP#
HOLD#

PCH_SPI_CS0#
PCH_SPI1_CLK

+3VSPI

PCH_SPI_IO2

AKE3DZN0N01

DFHS08FS023

4M SPI ROM Socket

PCH_SPI_CS0#_R(32)
PCH_SPI1_CLK_R(32)
PCH_SPI1_SI_R(32)
PCH_SPI1_SO_R(32)

PCH_SPI_CS0#_R
PCH_SPI1_CLK_R
PCH_SPI1_SI_R
PCH_SPI1_SO_R

BIOS_WP#

U53

1

CE#

6

SCK

5

SI

2

SO

3

WP#

*A25LQ32AM-F/Q

DFHS08FS023

91960-0084L-8P-SOCKET

U2003&U2004 footprint must overlap

PCH SPI ROM(CLG)

R707 *0_4

+3V_S5

R692 15/F_4
R375 15/F_4
R376 15/F_4
R690 15/F_4

R691 1K_4

R684 15/F_4

5

PCH_SPI_CS0#_R
PCH_SPI1_CLK_R
PCH_SPI1_SI_RPCH_SPI1_SI
PCH_SPI1_SO_RPCH_SPI1_SO

C539
22P/50V_4

BIOS_WP#

+3V_DEEP_SUS

U52

1

CE#

6

SCK

5

SI

2

SO

3

WP#

GD25B64BSIGR

VDD

HOLD#

VSS

R710 *0_4/S

8

7

HOLD#

4

PCH_SPI_IO3

INTRUDER#

8

VDD

7

HOLD#

4

VSS

+3VSPI

R358 1K_4

R363 15/F_4

C874

0.1U/16V_4

4

BB27

P43
R39
R36
R42
R41

AF41
AE44
BC23
BD24

BC36
BE34
BD39
BB36
BA35
BC35
BD35
AW35
BD34

BE11

HOLD#

4

MC74VHC1G08DFT2G

PCI_PLTRST#

EC-A-03

SML4ALERT#
SMB_ME4_DAT
SMB_ME4_CLK

SML3ALERT#
SMB_ME3_DAT
SMB_ME3_CLK

SML2ALERT#
SMB_ME2_DAT
SMB_ME2_CLK

SM_INTRUDER#

+3VSPI

+3V

R6521M_4

C546

0.1U/10V_4

4

R380

100K_4

TEMP_ALERT# (30)

+3V_RTC

U24

2
1

3 5

R383 *0_4

TP89

TP88

TOP SWAP OVERRIDE STRAP

HIGH:TOP SWAP ENABLED

LOW:TOP SWAP

(CRB)

DISABLED(DEFAULT)

ACZ_SPKR(10,21)

NO REBOOT IF SAMPLED HIGH

HIGH:Enable No Reboot mode.
This function is useful when running
ITP/XDP.

LOW: Disable "No Reboot" mode.
(Default)

BBS_BIT1(13)

TLS CONFIDENTIALITY ENABLED

HIGH:T Enable Intel ME Crypto Transport Layer
Security
(TLS) cipher suite (with confidentiality). (CRB)

LOW: Disable Intel ME Crypto Transport Layer
Security
(TLS) cipher suite (no confidentiality). (Default)

SML0ALERT#(10)

R674

*150K/F_4

ACZ_SPKR

R673

20K/F_4

R704
*4.7K_4

BBS_BIT1

R689
20K/F_4

+3V_DEEP_SUS

*4.7K_4

SML0ALERT#

R325

*20K/F_4

EC-A-11

3

PLTRST# (2,23,24,25,26,29,30,32,53)

SMB_ME4_CLK
SMB_ME4_DAT
SMB_ME3_CLK
SMB_ME3_DAT
SMB_ME2_CLK
SMB_ME2_DAT

TEMP_ALERT#

PCH Strap Pin

+3V

+3V

R326

BOOT SELECT STRAP

HIGH:LPC

LOW: SPI.
(Default)

S_GPIO(13)

ESPI/LPC SELECT STRAP

HIGH:eSPI Is selected for EC.

LOW: LPC Is selected for EC.
(Default)

DRAMRST_CNTRL_PCH(10)

RESERVED

This strap should sample
HIGH.

There should NOT be any on-board
device

driving it to opposite direction
during
strap sampling.

3

R725 499/F_4
R706 499/F_4
R711 499/F_4
R321 499/F_4
R709 499/F_4
R320 499/F_4

R677 *10K_4

+3V_DEEP_SUS

S_GPIO

+3V_DEEP_SUS

DRAMRST_CNTRL_PCH

+3V_DEEP_SUS

PCH_SPI1_SI

+3V_DEEP_SUS

+3V

R300
*4.7K_4

R304
20K/F_4

R346
*4.7K_4

R345

4.7K_4

R702

*20K/F_4

R687
*4.7K_4

2

RESERVED

This strap should sample
HIGH.

There should NOT be any on-board
device

driving it to opposite direction
during
strap sampling.

RESERVED

This strap should sample
There should NOT be any on-board

LOW.
driving it to opposite direction

device
during
strap sampling.

SML1ALERT#_R(10)

RESERVED

This strap should sample
HIGH.
There should NOT be any on-board
device

driving it to opposite direction
during
strap sampling.

RESERVED

This strap should sample
HIGH.

There should NOT be any on-board
device

driving it to opposite direction
during
strap sampling.

2

+3V_DEEP_SUS

PCH_SPI1_SO

SML1ALERT#_R

PCH_SPI_IO2

PCH_SPI_IO3

1

ESPI FLASH SHARING MODE

R700

*20K/F_4

R685
*4.7K_4

+3V_DEEP_SUS

R302
*4.7K_4

R301
*20K/F_4

+3V_DEEP_SUS

R703

*20K/F_4

R688
*4.7K_4

+3V_DEEP_SUS

R701

*20K/F_4

R686
100_4

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

HIGH:SLAVE ATTACEHD FLASH

SHARING

LOW: 0: MASTER ATTACHED FLASH
SHARING

This strap should sample
LOW.

driving it to opposite direction
during
strap sampling.

There should NOT be any on-board

device

SML2ALERT#

DFX TEST MODE QUALIFIER FOR OTHER DFX
WHEN SAMPLED

STRAP
LOW

PGDMON(15)

TLS CONFIDENTIALITY ENABLED

HIGH: Flash Descriptor Security (override). This
strap should only be asserted high using external
pull-up in manufacturing/debug environments ONLY.(CRB)

LOW: security measures defined in the Flash
Descriptor. (Default)

ACZ_SDOUT(10)

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

PROJECT :

Custom

Custom

Custom

PCH 4/6 (GPIO/MISC)

PCH 4/6 (GPIO/MISC)

PCH 4/6 (GPIO/MISC)

PGDMON

ACZ_SDOUT

1

12

+3V_DEEP_SUS

R713
*4.7K_4

R712
*20K/F_4

+3V_DEEP_SUS

R286
*1K_4

R285
*1K_4

+3V_DEEP_SUS

R605
*1K_4

R614
1K_4

12 66Wednesday, October 19, 2016

12 66Wednesday, October 19, 2016

12 66Wednesday, October 19, 2016

2A

2A

2A

5

4

3

2

+3V_DEEP_SUS(10,12,14,16,43,9)

1

13

+3V_DEEP_SUS

BOARD_ID0 (18)

BOARD_ID7 (9)
BOARD_ID8 (9)

DDPD_CTRLDATA
DP_HDMI_SCL
DP_HDMI_SDA

EC-B-01

BT_OFF

NVDDS_EN
NVDD_EN

1V8AON_EN

+3V_DEEP_SUS

R225 2.2K_4
R156 2.2K_4
R784 2.2K_4

D D

Need check PCI_GNT3#_20141119

+3V_DEEP_SUS

R721

49.9K/F_4

UART2_TXD(29)
UART2_RXD(29)

C C

Reserve EDP_HPD opposites circuit!

+3V

B B

EDP_HPD

R202

*10K/F_4

R227
100K_4

R722

49.9K/F_4

HDMI_HPD_CON(20,55)

TypeC1_DDI1_HPD(13,27,28)

S_GPIO(12)

TP50

BBS_BIT1(12)

PM_EXTTS#0(16)

EXTTS#1(16)

+3V_DEEP_SUS

SIO_EXT_SCI#(32)

DP_HPD_Q

R201
100K_4

TDH

R720 10K_4

SIO_EXT_SCI#

UART2_TXD
UART2_RXD

HDMI_HPD_CON

DP_HPD_Q(19)

EDP_HPD(18)

1

R30
*1M/F_4

Q69

+3V

2

*2N7002K

S_GPIO
PCI_GNT3#

BBS_BIT1

R233 *0_4_S

DP_HPD_Q

R166 *0_4_S

EDP_HPD

3

R759
100K_4

U49K

AT29

GPP_B22/GSPI1_MOSI

AR29

GPP_B21/GSPI1_MISO

AV29

GPP_B20/GSPI1_CLK

BC27

GPP_B19/GSPI1_CS#

BD28

GPP_B18/GSPI0_MOSI

BD27

GPP_B17/GSPI0_MISO

AW27

GPP_B16/GSPI0_CLK

AR24

GPP_B15/GSPI0_CS#

AV44

GPP_C9/UART0_TXD

BA41

GPP_C8/UART0_RXD

AU44

GPP_C11/UART0_CTS#

AV43

GPP_C10/UART0_RTS#

AU41

GPP_C15/UART1_CTS#/ISH_UART1_CTS#

AT44

GPP_C14/UART1_RTS#/ISH_UART1_RTS#

AT43

GPP_C13/UART1_TXD/ISH_UART1_TXD

AU43

GPP_C12/UART1_RXD/ISH_UART1_RXD

AN43

GPP_C23/UART2_CTS#

AN44

GPP_C22/UART2_RTS#

AR39

GPP_C21/UART2_TXD

AR45

GPP_C20/UART2_RXD

AR41

GPP_C19/I2C1_SCL

AR44

GPP_C18/I2C1_SDA

AR38

GPP_C17/I2C0_SCL

AT42

GPP_C16/I2C0_SDA

AM44

GPP_D4/ISH_I2C2_SDA/ISH_I2C3_SDA

AJ44

GPP_D23/ISH_I2C2_SCL/ISH_I2C3_SCL

SPT_PCH_H

U49E

HHC_R

AW4

GPP_I0/DDPB_HPD0

AY2

GPP_I1/DDPC_HPD1

AV4

TDH

GPP_I2/DDPD_HPD2

BA4

GPP_I3/DDPE_HPD3

BD7

GPP_I4/EDP_HPD

SPT_PCH_H

TypeC1_DDI1_HPD (13,27,28)

SPT-H_PCH

GPP_D10
GPP_D11

GPP_D16/ISH_UART0_CTS#

11 OF 12

GPP_I7/DDPC_CTRLCLK

GPP_I8/DDPC_CTRLDATA
GPP_I6/DDPB_CTRLDATA

GPP_I9/DDPD_CTRLCLK

GPP_I10/DDPD_CTRLDATA

5 OF 12

GPP_D15/ISH_UART0_RTS#

GPP_I5/DDPB_CTRLCLK

GPP_D14/ISH_UART0_TXD/SML0BCLK/I2C2_SCL

GPP_D13/ISH_UART0_RXD/SML0BDATA/I2C2_SDA

SPT-H_PCH

GPP_D12

GPP_H20/ISH_I2C0_SCL
GPP_H19/ISH_I2C0_SDA

GPP_H22/ISH_I2C1_SCL
GPP_H21/ISH_I2C1_SDA

GPP_A23/ISH_GP5
GPP_A22/ISH_GP4
GPP_A21/ISH_GP3
GPP_A20/ISH_GP2
GPP_A19/ISH_GP1
GPP_A18/ISH_GP0
GPP_A17/ISH_GP7

GPP_F14
GPP_F23
GPP_F22

GPP_G23
GPP_G22
GPP_G21
GPP_G20

GPP_H23

GPP_D9

BB3
BD6
BA5
BC4
BE5
BE6

Y44
V44
W39

L43
L44
U35
R35
BD36

AL44
AL36
AL35
AJ39

AJ43
AL43
AK44
AK45

BC38
BB38

BD38
BE39

BC22
BD18
BE21
BD22
BD21
BB22
BC19

CAM_EN_R
RF_OFF
BT_OFF

NVDDS_EN
NVDD_EN
1V8AON_EN

BOARD_ID6
BOARD_ID5
BOARD_ID4
BOARD_ID3
BOARD_ID2
BOARD_ID1
BOARD_ID0

Model

Definition

EC-B-01

DP_HDMI_SCL
DP_HDMI_SDA

DDPD_CTRLCLK
DDPD_CTRLDATA

SKTOCC_N_R

R318 *0_4/S

NVDDS_EN (46)
NVDD_EN (45)
1V8AON_EN (50)

R641 *10K_4
R662 *10K_4
R647 10K_4
R660 10K_4

R634 10K_4
R653 10K_4
R636 10K_4
R271 10K_4

BOARD_ID[8:7]

Reserve

(Default = 00)

DP_HDMI_SCL (19)
DP_HDMI_SDA (19)
HDMI_SCL (20)
HDMI_SDA (20)

TP94
TP39

SKTOCC_N_R (2)

CAM_EN (18)

TP51

BT_OFF (25)

BOARD_ID0
BOARD_ID1
BOARD_ID2
BOARD_ID3
BOARD_ID4
BOARD_ID5
BOARD_ID6
BOARD_ID7
BOARD_ID8

Reserve

(Default = 00)

R642 10K_4
R663 10K_4
R648 *10K_4
R661 *10K_4
R656 10K_4R655 *10K_4
R635 *10K_4
R654 *10K_4
R639 *10K_4

R277 *10K_4

BOARD_ID7
BOARD_ID8

Board ID [4]

1:DDR4 (default)

This signal has a weak internal

pull-down.

0 = Port C D is not detected.

1 = Port C D is detected.

10K_4

R365
R740 10K_4
R741 10K_4

R719 10K_4

BOARD_ID[3:2]BOARD_ID[6:5]

N17P-G1

00
01

N17P-G0

10

BOARD_ID[1:0]

10 NL8E
11 NL9E

Cable detect

+3V

A A

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet of

Date: Sheet of

5

4

3

2

Date: Sheet of

Custom

Custom

Custom

PROJECT :

PCH 4/6 (GPIO/MISC)

PCH 4/6 (GPIO/MISC)

PCH 4/6 (GPIO/MISC)

1

2A

2A

13 66Wednesday, October 19, 2016

13 66Wednesday, October 19, 2016

13 66Wednesday, October 19, 2016

2A

5

4

3

2

1

U49H

+VCCCLK1
+VCCCLK3
+VCCCLK4
+VCCCLK2

+VCCCLK5

C495

0.1U/16V_4

AA23
AA26
AA28
AC23
AC26
AC28
AE23
AE26

Y23
Y25

BA29

N17
R19
U20
V17
R17

U21
U23
U25
U26
V26
A43
B43
C44
C45

V28

AC17

AJ5
AL5

AN19
BA15

W15

K2
K3

VCCPRIM_1P0
VCCPRIM_1P0
VCCPRIM_1P0
VCCPRIM_1P0
VCCPRIM_1P0
VCCPRIM_1P0
VCCPRIM_1P0
VCCPRIM_1P0
VCCPRIM_1P0
VCCPRIM_1P0
DCPDSW_1P0

VCCCLK1
VCCCLK3
VCCCLK4
VCCCLK2
VCCCLK2

VCCCLK5
VCCCLK5

VCCMPHY_1P0
VCCMPHY_1P0
VCCMPHY_1P0
VCCMPHY_1P0
VCCMPHY_1P0
VCCMPHYPLL_1P0
VCCMPHYPLL_1P0
VCCPCIE3PLL_1P0
VCCPCIE3PLL_1P0

VCCAPLLEBB_1P0
VCCPRIM_1P0
VCCUSB2PLL_1P0
VCCUSB2PLL_1P0
VCCHDAPLL_1P0

VCCHDA
VCCDSW_3P3

SPT_PCH_H

+VCCRTCPRIM_3.3V+3V_RTC

C485

1U/6.3V_4

+1.0V_DEEP_SUS

D D

+1.0V_DEEP_SUS

+3V

C C

B B

This rail is generated by on die DSW voltage regulator to
supply DSW GPIOs, DSW core logic and DSW USB 2.0 logic. Board needs to
connect 1 uF capacitor to this rail and power should NOT be driven from the board.
When primary well power is up, this rail is bypassed from VCCPRIM_1p0.

+V3.3DX_1.5DX_ADO

+1.0V_DEEP_SUS

R250*0_4/S

R241 *0_4/S

+3V_S5

+1.0V_DEEP_SUS +VCCDSW_1.0V

L4*0_6

+1.0V_DEEP_SUS

+1.0V_DEEP_SUS

+1.0V_DEEP_SUS
+1.0V_DEEP_SUS
+1.0V_DEEP_SUS

+V3.3DX_1.5DX_ADO

**Layout Note: +VCCPRIM_1P0 total :2.899A**

+VCCDSW_1.0V

+1.0V_DEEP_SUS

R305 *0_6/S

R733 *0_6/S
R734 *0_6/S

R306 *0_6/S
R280 *0_6/S
R247 *0_6/S
R263 *0_6/S

C463 1U/6.3V_4

C466 *1U/6.3V_4

C506 *1U/6.3V_4

C507 1U/6.3V_4

R216*0_6/S
R218*0_6/S
R217*0_6/S
R259*0_6/S

R215*0_6/S

C444 *1U/6.3V_4

C503 1U/6.3V_4
C492 22U/6.3V_6

0.08A

C877 1U/6.3V_4

0.03A

C878 1U/6.3V_4
C487 1U/6.3V_4

0.03A

0.3A

0.012A

0.033A

0.06A

0.195A

0.0454A

0.021A

0.05A

0.024A

0.137A

0.006A

+VCCMPHY_1P0

+VCCAMPHYPLL_1P0
+VCCPCIE3PLL_1P0

+VCCAPLLEBB
+VCCPRIM_1.0V_AC17
+VCCUSB2PLL_1P0

+VCCHDAPLL_1P0

+VCCDSW3P3

C496

1U/6.3V_4

SPT-H_PCH

C484

0.1U/16V_4

+VCCPRIM_1.0V_AL22

0.0908A

VCCGPIO

8 OF 12

VCCRTCPRIM_3P3

+VCCATS

1U/6.3V_4

VCCPRIM_1P0

VCCDSW_3P3

VCCPGPPBCH
VCCPGPPBCH

VCCPGPPEF
VCCPGPPEF

VCCPRIM_3P3

VCCPRIM_1P0

VCCPRIM_1P0
VCCPRIM_1P0
VCCPRIM_1P0
VCCPRIM_1P0

VCCPRIM_3P3
VCCPRIM_3P3
VCCPRIM_3P3

C455

CORE

MPHY

USB

VCCPGPPA

VCCPGPPG

VCCATS
VCCRTC

DCPRTC

VCCSPI
VCCSPI
VCCSPI

VCCPGPPD

VCCPGPPD
VCCPGPPD
VCCPGPPD

AL22

0.195A

BA24

0.082A

BA31

0.229

BC42
BD40
AJ41

0.114A

AL41

0.065A

AD41

0.2875A

AN5

+VCCPRIM_1.0V_AJ20_AD15

AD15
AD13

+VCCATS
+VCCRTCPRIM_3.3V

BA20
BA22
BA26

DCPRTC

AJ20
AJ21
AJ23
AJ25

0.029A

BE41
BE43
BE42

0.078A

BC44
BA45
BC45
BB45

0.117A

BD3
BE3
BE4

+VCCPGPPEF

+VCCPGPPA

+VCCPGPPEF
+VCCPRIM_3P3

C458 *0.1U/16V_4

0.007A

0.002A

C505 0.1U/16V_4

C504 *0.1U/16V_4

+VCCSPI

+VCCPGPPD

R351 *0_6/S

+3V_DEEP_SUS(10,12,13,16,43,9)

R210 *0_6/S

R212 *0_6/S
R275 *0_6/S

C789 *1U/6.3V_4

+3V_DEEP_SUS

R290*0_6/S

R254*0_6/S

**Layout Note: +VCCPRIM_1P0 total :2.899A**

R731*0_6/S

R730*0_6/S

C5011U/6.3V_4

C493*1U/6.3V_4

C531*0.1U/16V_4
C530*0.1U/16V_4

+3V_DEEP_SUS

+3V_DEEP_SUS
+3V_DEEP_SUS
+3V_RTC

+3V_DEEP_SUS

+1.0V_DEEP_SUS

+VCCDSW3P3

+VCCPGPPBCH

+VCCPGPPG

+1.0V_DEEP_SUS

+1.0V_DEEP_SUS

+3V_DEEP_SUS

+3V_DEEP_SUS

R359*0_6/S

14

R312*0_6/S

+3V_DEEP_SUS

R349*0_6/S

+3V_DEEP_SUS

+3V_DEEP_SUS

A A

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet of

Date: Sheet of

5

4

3

2

Date: Sheet of

Custom

Custom

Custom

PROJECT :

PCH 5/6 (POWER)

PCH 5/6 (POWER)

PCH 5/6 (POWER)

1

2A

2A

2A

14 66Wednesday, October 19, 2016

14 66Wednesday, October 19, 2016

14 66Wednesday, October 19, 2016

5

4

3

2

1

15

U49I

SPT-H_PCH

AC18

D D

C C

B B

A A

AN4
AN10
BE14
BE18
BE23
BE28
BE32
BE37
BE40

BE9

C10
C28

C37
K10

K27
K33
K36

K42
K43
L12
L13
L15

L41

M35

M42

N10
N15
N19
N22
N24
N35
N36

N41
P17

P19
P22
P45
R10
R14
R22
R29
R33
R38

Y18
Y20
Y21
Y26
Y28
Y29
A18
A25
A32

A37
AA17
AA18
AA20
AA21
AA25
AA29

AA4
AA42
AB10

C2

J7

K4

L4
L8

N4
N5

R5
T1
T2
T4

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

SPT_PCH_H

5

9 OF 12

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

AR5
AR7
U15
AL4
AE29
AE4
AE42
AF18
AF20
AF21
AF23
AF25
AF26
AF28
AF29
AG11
AG13
AG31
AG32
AG33
AG38
AG4
AH1
AH17
AH18
AH20
AH21
AH23
AH25
AH26
AH28
AH29
AH45
AJ10
AJ14
AJ15
AJ17
AJ18
AJ26
AJ28
AJ29
AJ31
AJ32
AJ36
AK4
AK42
AU7
AV17
AV24
AV27
AV31
AV33
AV6
AW13
AW19
AW29
AW37
AW9
AY38
AY45
B25
B3
B37
B40
B6
BA1
BB11
BB16
BB21
BB25
BB30
BB34
BC2
BD43

C42
D10
D12
D15
D16
D17
D19
D21
D24
D25
D27
D29
D30
D31
D33
D35
D36
E13
E15
E31
E33

F44
G42
H17

H19
H22
H24
H27
H29

H35

J10

J11

J39

T42
U10
U11
U14
U17
U18
U28
U29
U31
U32
U33
U38

V18
V20
V21
V23
V25
V29

V45

W14
W31
W32
W33
W38

Y17

F8

G9

H3

U4
U8

V3

W4
W8

J3
J5

SPT-H_PCH

U49L

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

SPT_PCH_H

12 OF 12

4

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

AB11
AB7
AB14
AB31
AB32
AB38
AB4
AB5
AC1
AC20
AC21
AC25
AC29
AC45
AB8
AD11
AD14
AB15
AD32
AD33
AD36
AD4
AD8
AE18
AE20
AE21
AE25
AE28
AL10
AL11
AL13
AL17
AL19
AL24
AL29
AL32
AL33
AL38
AM15
AM17
AM19
AM22
AM24
AM27
AM29
AM45
AN11
AN22
AN27
AN31
AN39
AN7
AN8
AP11
AP4
AR33
AR34
AR42
AR9
AT10
AT15
AT36
AT9
AU1
AU35
AU36
AU39
AU45
C4

BD2
BD45
BD44
BE44

D45
A42
B45
B44

BB1

BC1

A44

A4
A3
B2
A2
B1

C1
D1

U49J

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

RSVD
RSVD

SPT_PCH_H

PCH_2_CPU_TRIG(8)

SPT-H_PCH

AR22
W13
U13
P31
N31

P27
R27
N29
P29
AN29
R24

P24
AT3
AT4
AY5
AL2
AK1

R613 30_4

PGDMON

PCH_2_CPU_TRIG_R

2

RSVD
RSVD
RSVD
RSVD
RSVD

RSVD
RSVD
RSVD
RSVD
RSVD
RSVD

RSVD

PREQ#

PRDY#

CPU_TRST#

PCH_TRIGOUT

PCH_TRIGIN

10 OF 12

PCH_2_CPU_TRIG PCH_2_CPU_TRIG_R

3

PGDMON (12)

XDP_PREQ# (2)
XDP_PRDY# (2)
XDP_TRST# (2)

CPU_2_PCH_TRIG (8)

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

B

B

B

PROJECT :

PCH 6/6 (GND)

PCH 6/6 (GND)

PCH 6/6 (GND)

15 66Wednesday, October 19, 2016

15 66Wednesday, October 19, 2016

15 66Wednesday, October 19, 2016

1

2A

2A

2A

5

4

3

2

1

M_A_A[13:0](4) M_A_DQ[63:0] (4)

D D

M_A_WE#(4)
M_A_CAS#(4)
M_A_RAS#(4)

+1.2VSUS

R269
240_4

M_A_EVENT#

PM_THRMTRIP#(11,17,2,32)

M_A_ACT#(4)
M_A_PARITY(4)
M_A_ALERT#(4)

DDR3_DRAMRST#(10,17)

R270 *1K_4

M_A_A0
M_A_A1
M_A_A2
M_A_A3
M_A_A4
M_A_A5
M_A_A6
M_A_A7
M_A_A8
M_A_A9
M_A_A10
M_A_A11
M_A_A12
M_A_A13

M_A_EVENT#

C476 *0.1U/16V_4

M_A_EVENT#

TP48
TP45

Close to PCH

M_A_ODT0_CPU(4)
M_A_ODT1_CPU(4)

SMB_RUN_CLK(10,17)
SMB_RUN_DAT(10,17)

+1.2VSUS

U21

8
7
6
4

*EMC1412-1-ACZL-TR

Need Check PN(EOD)

M_A_BA#0(4)
M_A_BA#1(4)
M_A_BG#0(4)
M_A_BG#1(4)

M_A_CS#0(4)
M_A_CS#1(4)
M_A_CKE0(4)
M_A_CKE1(4)

M_A_CLKP0(4)
M_A_CLKN0(4)
M_A_CLKP1(4)
M_A_CLKN1(4)

SCLK
SDA
ALERT#
OVERT#

R266 240_4
R220 240_4
R223 240_4
R224 240_4
R265 240_4
R219 240_4
R267 240_4
R268 240_4

+1.2VSUS

1

VCC

2

DXP

3

DXN

5

GND

CHA_SA0
CHA_SA1
CHA_SA2

M_A_CB0
M_A_CB1
M_A_CB2
M_A_CB3
M_A_CB4
M_A_CB5
M_A_CB6
M_A_CB7

C497 *0.01U/50V_4

+3V

C C

Local Thermal Sensor

B B

SMB_RUN_CLK(10,17)
SMB_RUN_DAT(10,17)
PM_EXTTS#0(13)

R278

R272
*10K_4

CHA_SA0 CHA_SA1 CHA_SA2

R273
10K_4

+3V

EXTTS#1(13)

R283

*10K_4

*10K_4

R279

R287

10K_4

10K_4

SMB_RUN_CLK
SMB_RUN_DAT
PM_EXTTS#0

R298 *10K/F_4

P/N and F/P

JDIM2A

144
133
132
131
128
126
127
122
125
121
146
120
119
158
151
156
152

162
165

114
143
116
134
108

150
145
115
113

149
157
109
110

137
139
138
140

155
161

253
254

256
260
166

92

91
101
105

88

87
100
104

12

33

54

75
178
199
220
241

96

DDR_THERMDA

C499
*2200P/50V_4

DDR_THERMDC

A0
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10/AP
A11
A12
A13
A14/WE#
A15/CAS#
A16/RAS#

S2#/C0
S3#/C1

ACT#
PARITY
ALERT#
EVENT#
RESET#

BA0
BA1
BG0
BG1

S0#
S1#
CKE0

DDR4 SODIMM 260 PIN

CKE1
CK0

CK0#
CK1
CK1#

ODT0
ODT1

SCL
SDA

SA0
SA1
SA2

CB0
CB1
CB2
CB3
CB4
CB5
CB6
CB7

DM0
DM1
DM2
DM3
DM4
DM5
DM6
DM7
DM8

+3V

DDR3 Thermal Sensor

2

(260P)

DQS#0
DQS#1
DQS#2
DQS#3
DQS#4
DQS#5
DQS#6
DQS#7
DQS#8

Q18
*METR3904-G

1 3

DQ10
DQ11
DQ12
DQ13
DQ14
DQ15
DQ16
DQ17
DQ18
DQ19
DQ20
DQ21
DQ22
DQ23
DQ24
DQ25
DQ26
DQ27
DQ28
DQ29
DQ30
DQ31
DQ32
DQ33
DQ34
DQ35
DQ36
DQ37
DQ38
DQ39
DQ40
DQ41
DQ42
DQ43
DQ44
DQ45
DQ46
DQ47
DQ48
DQ49
DQ50
DQ51
DQ52
DQ53
DQ54
DQ55
DQ56
DQ57
DQ58
DQ59
DQ60
DQ61
DQ62
DQ63

DQS0
DQS1
DQS2
DQS3
DQS4
DQS5
DQS6
DQS7
DQS8

8

DQ0

7

DQ1

20

DQ2

21

DQ3

4

DQ4

3

DQ5

16

DQ6

17

DQ7

28

DQ8

29

DQ9

41
42
24
25
38
37
50
49
62
63
46
45
58
59
70
71
83
84
66
67
79
80
174
173
187
186
170
169
183
182
195
194
207
208
191
190
203
204
216
215
228
229
211
212
224
225
237
236
249
250
232
233
245
246

13
34
55
76
179
200
221
242
97

11
32
53
74
177
198
219
240
95

Main:AL001412003 EMC1412-1-ACZL-TR(98h)

M_A_DQ1
M_A_DQ4
M_A_DQ3
M_A_DQ7
M_A_DQ0
M_A_DQ5
M_A_DQ2
M_A_DQ6
M_A_DQ12
M_A_DQ8
M_A_DQ10
M_A_DQ14
M_A_DQ9
M_A_DQ13
M_A_DQ11
M_A_DQ15
M_A_DQ16
M_A_DQ20
M_A_DQ19
M_A_DQ22
M_A_DQ21
M_A_DQ17
M_A_DQ18
M_A_DQ23
M_A_DQ28
M_A_DQ24
M_A_DQ31
M_A_DQ26
M_A_DQ29
M_A_DQ25
M_A_DQ30
M_A_DQ27
M_A_DQ33
M_A_DQ36
M_A_DQ38
M_A_DQ35
M_A_DQ32
M_A_DQ37
M_A_DQ34
M_A_DQ39
M_A_DQ41
M_A_DQ40
M_A_DQ43
M_A_DQ42
M_A_DQ45
M_A_DQ44
M_A_DQ47
M_A_DQ46
M_A_DQ48
M_A_DQ50
M_A_DQ49
M_A_DQ55
M_A_DQ52
M_A_DQ54
M_A_DQ51
M_A_DQ53
M_A_DQ60
M_A_DQ57
M_A_DQ59
M_A_DQ62
M_A_DQ56
M_A_DQ61
M_A_DQ63
M_A_DQ58

M_A_DQSP0
M_A_DQSP1
M_A_DQSP2
M_A_DQSP3
M_A_DQSP4
M_A_DQSP5
M_A_DQSP6
M_A_DQSP7
M_A_DQSP8

M_A_DQSN0
M_A_DQSN1
M_A_DQSN2
M_A_DQSN3
M_A_DQSN4
M_A_DQSN5
M_A_DQSN6
M_A_DQSN7
M_A_DQSN8

0-7

8-15

16-23

24-31

33-39

40-47

48-55

56-63

M_A_DQSP[7:0] (4)

M_A_DQSN[7:0] (4)

+1.2VSUS

R222

240_4

M_A_DQSP8

+1.2VSUS

R221

240_4

M_A_DQSN8

VREF DQ0 M1 Solution

SM_VREF(4)

1023 Change R10410
from 2ohm to 24.9ohn

+1.2VSUS

2250mA

2 1

C480

0.022U/25V_4

SM_VREF_C

JDIM2B

111

VDD1

112

VDD2

117

VDD3

118

VDD4

123

VDD5

124

VDD6

129

VDD7

130

VDD8

135

VDD9

136

VDD10

141

VDD11

142

VDD12

147

VDD13

148

VDD14

153

VDD15

154

VDD16

159

VDD17

160

VDD18

163

VDD19

1

VSS1

5

VSS2

9

VSS3

15

VSS4

19

VSS5

23

VSS6

27

VSS7

31

VSS8

35

VSS9

39

VSS10

43

VSS11

47

VSS12

51

VSS13

57

VSS14

61

VSS15

65

VSS16

69

VSS17

73

VSS18

77

VSS19

81

VSS20

85

VSS21

89

VSS22

93

VSS23

99

VSS24

103

VSS25

107

VSS26

167

VSS27

171

VSS28

175

VSS29

181

VSS30

185

VSS31

189

VSS32

193

VSS33

197

VSS34

201

VSS35

205

VSS36

209

VSS37

213

VSS38

217

VSS39

223

VSS40

227

VSS41

231

VSS42

235

VSS43

239

VSS44

243

VSS45

247

VSS46

251

VSS47

R261 2/F_6

R264 24.9/F_4

DDR4 SODIMM 260 PIN

+1.2VSUS

VDDSPD

VPP1
VPP2

VREF_CA

VSS48
VSS49
VSS50
VSS51
VSS52
VSS53
VSS54
VSS55
VSS56
VSS57
VSS58
VSS59
VSS60
VSS61
VSS62
VSS63
VSS64
VSS65
VSS66
VSS67
VSS68

(260P)

VSS69
VSS70
VSS71
VSS72
VSS73
VSS74
VSS75
VSS76
VSS77
VSS78
VSS79
VSS80
VSS81
VSS82
VSS83
VSS84
VSS85
VSS86
VSS87
VSS88
VSS89
VSS90
VSS91
VSS92
VSS93
VSS94

GND
GND

R274
1K/F_4

VREF_CA_DIMM0

R288
1K/F_4

VTT

255

257
259

258

VREF_CA_DIMM0

164

2
6
10
14
18
22
26
30
36
40
44
48
52
56
60
64
68
72
78
82
86
90
94
98
102
106
168
172
176
180
184
188
192
196
202
206
210
214
218
222
226
230
234
238
244
248
252

261
262

C447 2.2uF/10V_4

C448 0.1U/16V_4

0.5A

600mA

R281*0_4

+3V

+2.5V_SUS

DDR_VTTREF

16

+VDDQ

2nd:AL000431014 TMP431ADGKR(98h)

Co-lay for ODT
From Intel MOW, ODT directly connection to CPU

47K/F_4

DDR_VTT_CNTL(2)

A A

DDR_VTT_CNTL

R519 *10K_4

5

R518

+1.2VSUS

R517
47K/F_4

2

1 3

Q48
RC5144E0L

+3V_DEEP_SUS

R516
47K_4

DDR_VTT_PG_CTRL (35)

+1.2VSUS(10,17,2,35,43,44,50,6)

DDR_VTTREF(17,35,44)

4

+3V(10,11,12,13,14,17,18,19,20,21,22,23,24,26,27,28,29,30,31,32,36,43,45,50,52,9)

Place these Caps near So-Dimm1.

1uF/10uF 4pcs on each side of connector

+1.2VSUS

C449 1U/6.3V_4
C450 1U/6.3V_4
C445 1U/6.3V_4
C456 1U/6.3V_4
C475 1U/6.3V_4
C477 1U/6.3V_4
C478 1U/6.3V_4
C479 1U/6.3V_4
C442 10U/6.3V_6

C380 10U/6.3V_6
C443 10U/6.3V_6

C481 10U/6.3V_6
C473 10U/6.3V_6

C482 10U/6.3V_6
C472 10U/6.3V_6

C483 10U/6.3V_6

DDR_VTTREF

3

C471 1U/6.3V_4
C467 1U/6.3V_4
C468 1U/6.3V_4
C465 1U/6.3V_4
C457 10U/6.3V_6

+3V

C446 0.1U/16V_4
C435 2.2uF/10V_4

VREF_CA_DIMM0

+2.5V_SUS

C489 0.1U/16V_4
C486 2.2uF/10V_4

C441 0.1U/16V_4
C452 2.2uF/10V_4

PROJECT :ZRY

PROJECT :ZRY

PROJECT :ZRY

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

18 -- DDR3 DIMM1-RVS(8.0H)

18 -- DDR3 DIMM1-RVS(8.0H)

18 -- DDR3 DIMM1-RVS(8.0H)

Date: Sheet of

Date: Sheet of

2

Date: Sheet of

1

1A

1A

1A

16 66Monday, October 17, 2016

16 66Monday, October 17, 2016

16 66Monday, October 17, 2016

5

4

3

2

1

M_B_A[13:0](4)

D D

M_B_WE#(4)
M_B_CAS#(4)
M_B_RAS#(4)

M_B_ACT#(4)
M_B_PARITY(4)

+1.2VSUS

R173
240_4

M_B_EVENT#

PM_THRMTRIP#(11,16,2,32)

M_B_ALERT#(4)

DDR3_DRAMRST#(10,16)

R188 *1K_4

M_B_A0
M_B_A1 M_B_DQ0
M_B_A2
M_B_A3
M_B_A4
M_B_A5
M_B_A6
M_B_A7
M_B_A8
M_B_A9
M_B_A10
M_B_A11
M_B_A12
M_B_A13

TP36
TP30

M_B_EVENT#

C425 *0.1U/16V_4

M_B_EVENT#

Close to PCH

+1.2VSUS

M_B_ODT0_CPU(4)
M_B_ODT1_CPU(4)

SMB_RUN_CLK(10,16)
SMB_RUN_DAT(10,16)

M_B_BA#0(4)
M_B_BA#1(4)
M_B_BG#0(4)
M_B_BG#1(4)

M_B_CS#0(4)
M_B_CS#1(4)
M_B_CKE0(4)
M_B_CKE1(4)

M_B_CLKP0(4)
M_B_CLKN0(4)
M_B_CLKP1(4)
M_B_CLKN1(4)

R181 240_4
R139 240_4
R142 240_4
R143 240_4
R180 240_4
R138 240_4
R178 240_4
R179 240_4

+1.2VSUS

CHB_SA0
CHB_SA1
CHB_SA2

M_B_CB0

M_B_CB1
M_B_CB2
M_B_CB3

M_B_CB4
M_B_CB5
M_B_CB6
M_B_CB7

+3V

C C

R187
10K_4

R196
*10K_4

R209
*10K_4

R208
10K_4

R172
*10K_4

CHB_SA0 CHB_SA1 CHB_SA2

R186
10K_4

B B

P/N and F/P

JDIM1A

144

A0

133

A1

132

A2

131

A3

128

A4

126

A5

127

A6

122

A7

125

A8

121

A9

146

A10/AP

120

A11

119

A12

158

A13

151

A14/WE#

156

A15/CAS#

152

A16/RAS#

162

S2#/C0

165

S3#/C1

114

ACT#

143

PARITY

116

ALERT#

134

EVENT#

108

RESET#

150

BA0

145

BA1

115

BG0

113

BG1

149

S0#

157

S1#

109

CKE0

110

CKE1

137

CK0

139

CK0#

138

CK1

140

CK1#

155

ODT0

161

ODT1

253

SCL

254

SDA

256

SA0

260

SA1

166

SA2

92

CB0

91

CB1

101

CB2

105

CB3

88

CB4

87

CB5

100

CB6

104

CB7

12

DM0

33

DM1

54

DM2

75

DM3

178

DM4

199

DM5

220

DM6

241

DM7

96

DM8

DQ1
DQ2
DQ3
DQ4
DQ5
DQ6
DQ7
DQ8

DQ9
DQ10
DQ11
DQ12
DQ13
DQ14
DQ15
DQ16
DQ17
DQ18
DQ19
DQ20
DQ21
DQ22
DQ23
DQ24
DQ25
DQ26
DQ27
DQ28
DQ29
DQ30
DQ31
DQ32
DQ33
DQ34
DQ35
DQ36
DQ37
DQ38
DQ39
DQ40
DQ41
DQ42
DQ43
DQ44
DQ45
DQ46
DQ47
DQ48

(260P)

DDR4 SODIMM 260 PIN

DQ49
DQ50
DQ51
DQ52
DQ53
DQ54
DQ55
DQ56
DQ57
DQ58
DQ59
DQ60
DQ61
DQ62
DQ63

DQS0
DQS1
DQS2
DQS3
DQS4
DQS5
DQS6
DQS7
DQS8

DQS#0
DQS#1
DQS#2
DQS#3
DQS#4
DQS#5
DQS#6
DQS#7
DQS#8

M_B_DQ7

20

M_B_DQ2

21

M_B_DQ4

4

M_B_DQ1

3

M_B_DQ6

16

M_B_DQ3

17

M_B_DQ9

28

M_B_DQ10

29

M_B_DQ11

41

M_B_DQ15

42

M_B_DQ8

24

M_B_DQ14

25

M_B_DQ12

38

M_B_DQ13

37

M_B_DQ16

50

M_B_DQ17

49

M_B_DQ23

62

M_B_DQ21

63

M_B_DQ22

46

M_B_DQ18

45

M_B_DQ19

58

M_B_DQ20

59

M_B_DQ30

70

M_B_DQ25

71

M_B_DQ29

83

M_B_DQ24

84

M_B_DQ27

66

M_B_DQ28

67

M_B_DQ26

79

M_B_DQ31

80

M_B_DQ34

174

M_B_DQ35

173

M_B_DQ36

187

M_B_DQ33

186

M_B_DQ39

170

M_B_DQ38

169

M_B_DQ37

183

M_B_DQ32

182

M_B_DQ40

195

M_B_DQ44

194

M_B_DQ47

207

M_B_DQ46

208

M_B_DQ45

191

M_B_DQ41

190

M_B_DQ42

203

M_B_DQ43

204

M_B_DQ51

216

M_B_DQ48

215

M_B_DQ50

228

M_B_DQ55

229

M_B_DQ52

211

M_B_DQ54

212

M_B_DQ49

224

M_B_DQ53

225

M_B_DQ59

237

M_B_DQ62

236

M_B_DQ63

249

M_B_DQ60

250

M_B_DQ57

232

M_B_DQ61

233

M_B_DQ58

245

M_B_DQ56

246

M_B_DQSP0

13

M_B_DQSP1

34

M_B_DQSP2

55

M_B_DQSP3

76

M_B_DQSP4

179

M_B_DQSP5

200

M_B_DQSP6

221

M_B_DQSP7

242

M_B_DQSP8

97

M_B_DQSN0

11

M_B_DQSN1

32

M_B_DQSN2

53

M_B_DQSN3

74

M_B_DQSN4

177

M_B_DQSN5

198

M_B_DQSN6

219

M_B_DQSN7

240

M_B_DQSN8

95

M_B_DQ5

8

DQ0

7

M_B_DQ[63:0] (4)

0-7

8-15

16-23

24-31

32-39

40-47

48-55

56-63

M_B_DQSP[7:0] (4)

M_B_DQSN[7:0] (4)

M_B_DQSP8

M_B_DQSN8

R141

240_4

R140

240_4

+1.2VSUS

+1.2VSUS

+1.2VSUS

2250mA

JDIM1B

111

VDD1

112

VDD2

117

VDD3

118

VDD4

123

VDD5

124

VDD6

129

VDD7

130

VDD8

135

VDD9

136

VDD10

141

VDD11

142

VDD12

147

VDD13

148

VDD14

153

VDD15

154

VDD16

159

VDD17

160

VDD18

163

VDD19

1

VSS1

5

VSS2

9

VSS3

15

VSS4

19

VSS5

23

VSS6

27

VSS7

31

VSS8

35

VSS9

39

VSS10

43

VSS11

47

VSS12

51

VSS13

57

VSS14

61

VSS15

65

VSS16

69

VSS17

73

VSS18

77

VSS19

81

VSS20

85

VSS21

89

VSS22

93

VSS23

99

VSS24

103

VSS25

107

VSS26

167

VSS27

171

VSS28

175

VSS29

181

VSS30

185

VSS31

189

VSS32

193

VSS33

197

VSS34

201

VSS35

205

VSS36

209

VSS37

213

VSS38

217

VSS39

223

VSS40

227

VSS41

231

VSS42

235

VSS43

239

VSS44

243

VSS45

247

VSS46

251

VSS47

VDDSPD

VPP1
VPP2

VREF_CA

VSS48
VSS49
VSS50
VSS51
VSS52
VSS53
VSS54
VSS55
VSS56
VSS57
VSS58
VSS59
VSS60
VSS61
VSS62
VSS63
VSS64
VSS65
VSS66
VSS67
VSS68

(260P)

DDR4 SODIMM 260 PIN

VSS69
VSS70
VSS71
VSS72
VSS73
VSS74
VSS75
VSS76
VSS77
VSS78
VSS79
VSS80
VSS81
VSS82
VSS83
VSS84
VSS85
VSS86
VSS87
VSS88
VSS89
VSS90
VSS91
VSS92
VSS93
VSS94

GND
GND

VTT

255

257
259

258

VREF_CA_DIMM1

164

2
6
10
14
18
22
26
30
36
40
44
48
52
56
60
64
68
72
78
82
86
90
94
98
102
106
168
172
176
180
184
188
192
196
202
206
210
214
218
222
226
230
234
238
244
248
252

261
262

C407 2.2uF/10V_4

C400 0.1U/16V_4

0.5A

600mA

+3V

+2.5V_SUS

DDR_VTTREF

DDR_VTTREF(16,35,44)

17

+3V(10,11,12,13,14,16,18,19,20,21,22,23,24,26,27,28,29,30,31,32,36,43,45,50,52,9)

+1.2VSUS(10,16,2,35,43,44,50,6)

For EMI RESERVE

+1.2VSUS

EC24 *120P/50V_4
EC23 120P/50V_4
EC16 *120P/50V_4
EC28 *120P/50V_4
EC36 *120P/50V_4

A A

DDR_VTTREF

EC21 *120P/50V_4
EC22 *120P/50V_4

5

+1.2VSUS

EC14 *120P/50V_4
EC18 *120P/50V_4
EC26 *120P/50V_4
EC34 *0.1U/16V_4
EC29 *0.1U/16V_4
EC38 *0.1U/16V_4
EC37 *0.1U/16V_4

4

1uF/10uF 4pcs on each side of connector

+1.2VSUS DDR_VTTREF

Place these Caps near So-Dimm0.

C401 1U/6.3V_4
C395 1U/6.3V_4
C396 1U/6.3V_4
C398 1U/6.3V_4
C438 1U/6.3V_4
C422 1U/6.3V_4
C409 1U/6.3V_4
C423 1U/6.3V_4

C393 10U/6.3V_6
C387 10U/6.3V_6
C392 10U/6.3V_6
C397 10U/6.3V_6
C427 10U/6.3V_6
C394 10U/6.3V_6
C433 10U/6.3V_6
C426 10U/6.3V_6

VREF_CA_DIMM1

+2.5V_SUS

+3V

C405 1U/6.3V_4
C408 1U/6.3V_4EC15 *120P/50V_4
C410 1U/6.3V_4EC17 *120P/50V_4
C412 1U/6.3V_4
C413 1U/6.3V_4

C451 0.1U/16V_4
C432 2.2uF/10V_4

C399 0.1U/16V_4
C402 2.2uF/10V_4

C406 0.1U/16V_4
C470 2.2uF/10V_4

3

VREF DQ1 M1 Solution

SMDDR_VREF_DQ1_M3(4)

1022 Del R10432

+1.2VSUS

R189

SMDDR_VREF_DQ1_M3 VREF_CA_DIMM1

R171 2/F_6

C428

0.022U/25V_4

2 1

R191

24.9/F_4

2

1K/F_4

R232
1K/F_4

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Date: Sheet of

Date: Sheet of

Date: Sheet of

R197*0_4

+VDDQ

PROJECT :ZRY

PROJECT :ZRY

PROJECT :ZRY

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

17 -- DDR3 DIMM0-STD(4.0H)

17 -- DDR3 DIMM0-STD(4.0H)

17 -- DDR3 DIMM0-STD(4.0H)

1

17 66Monday, October 17, 2016

17 66Monday, October 17, 2016

17 66Monday, October 17, 2016

1A

1A

1A

5

4

3

2

1

LCDVCC

+3V +LCD VCC

80mil

C29
1U/6.3V_4

ENVDD(11)

D D

Back light

EMU_LID(32)

C C

PANEL_BKEN(11)

GFX_PWR_SRC

+VIN GFX_PWR_SRC

40mil

B B

R35
100K/F_4

R466 *0_8_S

*10U/25V/X6S_12

U5

5

IN

4

IN

3

ON/OFF

G5245AT11U

1

OUT

2

GND

+3V

R40
*4.7K_4

R41 *0_4/S DISPON

R39 2.2K_4

R38

10K_4

D4

C30

*1U/10V/X7R_6

40mil

C637

C634

C635

0.1U/25V_6

*0.1U/25V_6

RB500V-40

80mil

R34
100K_4

C22 10U/6.3V_6
C25 *0.01U/16V/X7R_ 4
C24 0.1U/10V_4

C28
*47P/50V/NPO_4

LCD_PWM(1 1)

R32 *0_4_S

C27

*47P/50V/NPO_4

VADJ_PWM

10K_4

+3V

R25 100K_4
R26 100K_4

R33

EDP_AUXN_C
EDP_AUXP_C

EDP_TXN1(3 )
EDP_TXP1(3)

EDP_TXN0(3 )
EDP_TXP0(3)

EDP_AUXP(3)
EDP_AUXN(3)

EDP_TXN2(3 )
EDP_TXP2(3)

EDP_TXN3(3 )
EDP_TXP3(3)

+LCDVCC

EDP_HPD(13)

BOARD_ID0(13)

GFX_PWR_SRC

C14 0.1U/10V_ 4
C17 0.1U/10V_ 4

C20 0.1U/10V_ 4
C21 0.1U/10V_ 4

C19 0.1U/10V_ 4
C18 0.1U/10V_ 4

C626 0.1U/10V_4
C629 0.1U/10V_4

C630 0.1U/10V_4
C631 0.1U/10V_4

EDP_TXN1_C
EDP_TXP1_C

EDP_TXN0_C
EDP_TXP0_C

EDP_AUXP_C
EDP_AUXN_C

EDP_TXN2_C
EDP_TXP2_C

EDP_TXN3_C
EDP_TXP3_C

EDP_HP

DISPON
VADJ_PWM

30Pin eDP CN

LCD_CONN

30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1

CN5

G_3

G_2

G_1

G_0

+3V(10,11,12,13,14,16 ,17,19,20,21,22,23,24 ,26,27,28,29,30,31,32 ,36,43,45,50,52,9)
+3VPCU(10,21,29,31 ,32,33,34,55)

+VIN(33,34,35,36,39,40 ,41,42,47,50,52,63)

18

CAMERA/DMIC CONN

CAMERA VCC Control

+CAM_VCC
Max Current : 800mA

C638 2200P/50V/X7R _4

CAM_EN(13)

A A

2

R463

4.7K_4

G

Q45
LTC044EUBFS8TL

1 3

5

+3V

S

Q44
AO3413

D

+V3.3DX_CAMERA_R

+V3.3DX_CAMERA

R467
*0_6_S

C639

0.1U/10V_4

4

USBP3-(9)
USBP3+(9)

DMIC_CLK(21 )
DMIC_DATA(2 1)

R461 FCM1005 KF-601T02
R462 FCM1005 KF-601T02

+3V

C636

0.1U/10V_4

USBP3+_R
USBP3-_R

CML5

4 3
1

MCM2012D900 FBE

RV18*EG A-0402

FOR ESD

U33

2

VIN

IO1

3

GND

IO2

*PJSR05

3

+V3.3DX_CAMERA

2

+3V

DMIC_CLK_C
DMIC_DATA_C

RV19

*EGA-0402

+V3.3DX_CAMERA

4
1

USBP3-_R
USBP3+_R

EC-A-08

CAMERA_CONN

8

8

7

7

6

6

GND

5

5

4

4

3

3

GND

2

2

1

1

CN6

9

10

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

Monday, October 17, 2016

Monday, October 17, 2016

2

Monday, October 17, 2016

PROJECT :

eDP LCD/CAMERA

eDP LCD/CAMERA

eDP LCD/CAMERA

1

3BCustom

3BCustom

3BCustom

66

66

66

18

18

18

EC-A-01

+3V

R760 *0_6/S

A

+3V_DP

EC-B-02

+3V_DP

B

R443 100K_4
R446 100K_4

R444 *100K_4

EXT_AUX_SINK_P
EXT_AUX_SINK_N

C

D

+3V(10,11,12,13,14,16,17,18,20,21,22,23,24,26,27,28,29,30,31,32,36,43,45,50,52,9)
+5V(20,21,22,24,30,31,43,45,52,63)

+3V
+5V

E

19

4 4

C26

0.1U/10V_4

C13

0.1U/16V_4

EC-A-02

R761
1K_4

DP_HPD_Q(13)

Q70A

34

DPC_HPD_R

5

3 3

2N7002KDW

Dual

Q70B

2N7002KDW

Dual

2KV ESD protection

DP_AUXP(19,3)

DP_AUXN(19,3)

R457 *0_4

R456 *0_4

EC-B-01

2 2

DP_AUXN(19,3)

DP_AUXP(19,3)

DP_HDMI_SDA(13)
DP_HDMI_SCL(13)

C785 0.1U/16V_4
C803 0.1U/16V_4

+5V+3V_DP

R762
100K_4

61

2

DP_AUXP_R

DP_AUXN_R

C813

0.01U/50V_4

R764 200K/F_4

C628 *0.1U/16V_4

C627 *0.1U/16V_4

DP_AUXN_M
DP_AUXP_M

TS3USB221ARSER

R765

100K/F_4

U4

4

2D_

3

2D+

2

1D-

1

1D+

DPC_HPD_C

+3V

10

OE#

VCC

D+

GND

5

C9

6

8
7

D-

9

S

EXT_AUX_SINK_P

EXT_AUX_SINK_N

0.1U/10V_4

R14

EXT_AUX_SINK_P
EXT_AUX_SINK_N

AUX_EN

DP_TX0P(3)
DP_TX0N(3)

DP_TX1P(3)

DP_TX1N(3)

DP_TX2P(3)
DP_TX2N(3)
DP_TX3P(3)
DP_TX3N(3)

100K_4

C613 0.1U/16V_4
C614 0.1U/16V_4
C5 0.1U/16V_4
C6 0.1U/16V_4

C15 0.1U/16V_4
C16 0.1U/16V_4
C622 0.1U/16V_4
C623 0.1U/16V_4

DPC_LANE0_P_C
DPC_LANE0_N_C
DPC_LANE1_P_C
DPC_LANE1_N_C

DPC_LANE2_P_C
DPC_LANE2_N_C
DPC_LANE3_P_C
DPC_LANE3_N_C

For ESD

+3V_DP

DPC_LANE0_P_C
DPC_LANE0_N_C

DPC_LANE1_P_C
DPC_LANE1_N_C

DPC_LANE2_N_C
DPC_LANE2_P_C

DPC_LANE3_N_C
DPC_LANE3_P_C

EXT_AUX_SINK_N

DPC_HPD_C

12

FUSE1A8V_POLY

F2

DPC_LANE3_N_C
DPC_LANE3_P_C

R11 5.1M_4
R19 1M/F_4

DPC_HPD_C(55)

DPC_LANE2_N_C
DPC_LANE2_P_C

DPC_LANE1_N_C
DPC_LANE1_P_C

DPC_LANE0_N_C
DPC_LANE0_P_C

+3V_DP_F

EXT_AUX_SINK_N
EXT_AUX_SINK_P

AUX_EN

DPC_HPD_C

U1

6

NC

7

NC

9

NC

10

NC

U29

6

NC

7

NC

9

NC

10

NC

U30

6

NC

7

NC

9

NC

10

NC

CH4
CH3

GND

CH2
CH1

*AZ1045-04F

CH4
CH3

GND

CH2
CH1

*AZ1045-04F

CH4
CH3

GND

CH2
CH1

*AZ1045-04F

CN3

20

PWR

18

AUXN

16

AUXP

14

GND

12

LANE_3N

10

LANE_3P

8

GND

6

CONFIG2

4

CONFIG1

2

HPD

19

GND

17

LANE_2N

15

LANE_2P

13

GND

11

LANE_1N

9

LANE_1P

7

GND

5

LANE_0N

3

LANE_0P

1

GND

3VT2121-24CB1-7H

DPC_LANE0_P_C

5

DPC_LANE0_N_C

4
3

DPC_LANE1_P_C

2

DPC_LANE1_N_C

1

DPC_LANE2_N_C

5

DPC_LANE2_P_C

4
3

DPC_LANE3_N_C

2

DPC_LANE3_P_C

1

EXT_AUX_SINK_PEXT_AUX_SINK_P

5

EXT_AUX_SINK_N

4
3

+3V_DP+3V_DP

2

DPC_HPD_C

1

GND
GND
GND
GND

21
22
23
24

Layout note:Place close to DP Conn

1 1

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Date: Sheet of

Date: Sheet of

Date: Sheet of

A

B

C

D

Friday, October 28, 2016

Friday, October 28, 2016

Friday, October 28, 2016

PROJECT :

DP Conn

DP Conn

DP Conn

1A

1A

19

19

19

E

1A

66

66

66

A

B

C

D

E

+5V

20

U28

+3V_HDMI

C617

0.1U/16V_4

C604

0.1U/16V_4

HDMI_CLK-_C

18

HDMI_CLK+_C

19

HDMI_TX0-_C

21

HDMI_TX0+_C

22

HDMI_TX1-_C

23

HDMI_TX1+_C

24

HDMI_TX2-_C

26

HDMI_TX2+_C

27
20

17

C620

0.1U/16V_4

PS8203TQFN32GTR-A3

HDMI_ALS_PD
HDMI_HPD
HDMI_DDC_DAT

4 4

DIFF: 100 ohm

HDMI_CLK#(3)
HDMI_CLK(3)
HDMI_D0#(3)
HDMI_D0(3)
HDMI_D1#(3)
HDMI_D1(3)
HDMI_D2#(3)
HDMI_D2(3)

3 3

R449 *0_4_S
R447 *0_4_S
R445 *0_4_S
R442 *0_4_S
R441 *0_4_S
R440 *0_4_S
R437 *0_4_S
R435 *0_4_S

HDMI_CLK#_R
HDMI_CLK_R
HDMI_D0#_R
HDMI_D0_R
HDMI_D1#_R
HDMI_D1_R
HDMI_D2#_R
HDMI_D2_R

HDMI_HPD_CON(13,55)

HDMI_SDA(13)
HDMI_SCL(13)

+3V_HDMI

C618 0.1U/16V_4
C612 0.1U/16V_4
C610 0.1U/16V_4
C609 0.1U/16V_4
C608 0.1U/16V_4
C607 0.1U/16V_4
C606 0.1U/16V_4
C605 0.1U/16V_4

R432 2.2K_4
R434 2.2K_4

DCIN_EN
EQ0
PRE

HDMI_ALS_PD

HDMI_DDC_CLK

HDMI_CLK#_C
HDMI_CLK_C
HDMI_D0#_C
HDMI_D0_C
HDMI_D1#_C
HDMI_D1_C
HDMI_D2#_C
HDMI_D2_C

DCIN_EN

R438 *0_4_S

R2 *0_4_S
R1 *0_4_S

HDMI_SCL_R
HDMI_SDA_R

R18 *4.7K_5%_4
R452 *4.7K_5%_4
R451 *4.7K_5%_4
R453 *4.7K_5%_4

10

IN_CKN

9

IN_CKP

7

IN_D0N

6

IN_D0P

5

IN_D1N

4

IN_D1P

2

IN_D2N

1

IN_D2P

8

DCIN_EN

HDMI_HPD_DC

HDMI_SDA_R
HDMI_SCL_R

+3V_HDMI

29

28

25

33

EPAD

SCL_SNK

SDA_SNK

HPD_SNK

HPD_SRC

SDA_SRC32SCL_SRC

3

31

0.1U/16V_4

11

12

30

PD#

VDD

VDDIO

OUT_CKN
OUT_CKP
OUT_D0N

OUT_D1N
OUT_D2N

EQ13GND14PRE15REXT

16

R450 5.9K_1%_4

C619

37

THM#134THM#235THM#336THM#4

OUT_D0P
OUT_D1P
OUT_D2P

CEXT

THM#539THM#640THM#741THM#8

38

EQ0
PRE

CFG

EC-A-03

+3V_HDMI+3V

2 2

1 1

R763 *0_6/S

C11

0.1U/10V_4

C10

0.1U/16V_4

C621

0.01U/50V_4

EMI reserve for HDMI

HDMI_TX2+_C

HDMI_TX2-_C
HDMI_TX1+_C

HDMI_TX1-_C
HDMI_TX0+_C

HDMI_TX0-_C
HDMI_CLK+_C

HDMI_CLK-_C

R17
150/F_4

R15
150/F_4

R12
150/F_4

R9
150/F_4

C603

0.1U/16V_4

RB500V-40

HDMIC_5V

D13

R436

2.2K_4

EC53
*220P/50V/X7R_4

D1
RB500V-40

R4

2.2K_4

HDMI_DDC_CLK
HDMI_DDC_DAT

DIFF:100 ohm

+5V

For ESD

HDMI_TX2+_C
HDMI_TX2-_C

HDMI_TX1+_C
HDMI_TX1-_C

HDMI_TX0+_C
HDMI_TX0-_C

HDMI_CLK+_C
HDMI_CLK-_C

HDMI_DDC_CLK

HDMI_HPD

HDMI_TX2+_C
HDMI_TX2-_C

HDMI_TX1+_C
HDMI_TX1-_C

HDMI_TX0+_C
HDMI_TX0-_C

HDMI_CLK+_C
HDMI_CLK-_C

HDMI_DDC_CLK
HDMI_DDC_DAT

HDMIC_5V

F1FUSE1A8V_POLY

HDMI_HPD

R439
*20K/F_4

U3

6

NC

7

NC

9

NC

10

NC

*AZ1045-04F

U2

6

NC

7

NC

9

NC

10

NC

*AZ1045-04F

U27

6

NC

7

NC

9

NC

10

NC

*AZ1045-04F

GND

GND

GND

CH4
CH3

CH2
CH1

CH4
CH3

CH2
CH1

CH4
CH3

CH2
CH1

HDMI_TX2+_C

5

HDMI_TX2-_C

4
3

HDMI_TX1+_C

2

HDMI_TX1-_C

1

HDMI_TX0+_C

5

HDMI_TX0-_C

4
3

HDMI_CLK+_C

2

HDMI_CLK-_C

1

HDMI_DDC_DATHDMI_DDC_DAT

5

HDMI_DDC_CLK

4
3

HDMIC_5VHDMIC_5V

2

HDMI_HPD

1

Layout note:Place close to HDMI Conn

1
2
3
4
5
6
7
8

9
10
11
12
13
14
15
16
17
18
19

CN2

D2+
D2 Shield
D2­D1+
D1 Shield
D1­D0+
D0 Shield
D0­CK+
CK Shield
CK­CE Remote
NC
DDC CLK
DDC DATA
GND
+5V
HP DET

HDMI CONN

SHELL1

GND
GND

SHELL2

+3V(10,11,12,13,14,16,17,18,19,21,22,23,24,26,27,28,29,30,31,32,36,43,45,50,52,9)
+5V(19,21,22,24,30,31,43,45,52,63)
+1.5V(21,38,44)

20

23
22

21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

Wednesday, November 02, 2016

Wednesday, November 02, 2016

A

B

C

D

Wednesday, November 02, 2016

PROJECT :

HDMI CONN

HDMI CONN

HDMI CONN

3BCustom

3BCustom

3BCustom

66

66

20

20

20

E

66
