Quanmax QBox Mini-1000 User Manual

Download

Page 1

QBOX Mini-1000 Series User’s Manual

QBOX Mini-1000 Series

Fanless Box PC with Intel® Atom™ E640T Processor

User’s Guide

Page 2

QBOX Mini-1000 Series User’s Manual

Contact Info: Quanmax Inc.

4F, No. 415, Ti-Ding Blvd. Sec. 2NeiHu District, Taipei 114Taiwan Tel: +886-2-2799-2789 Fax: +886-2-2799-7399

Visit our site at: www.quanmax.com

The information in this user’s guide is provided for reference only. Quanmax does not assume any liability arising out of the application or use of the information or products described herein. This user’s guide may contain or reference information and products protected by copyrights or patents and does not convey any license under the patent rights of Quanmax, nor the rights of others. Quanmax is a registered trademark of Quanmax. All trademarks, registered trademarks, and trade names used in this user’s guide are the property of their respective owners. All rights reserved. This user’s guide contains information proprietary to Quanmax. Customers may reprint and use this user’s guide in other publications. Customers may alter this user’s guide and publish it only after they remove the Quanmax name, cover, and logo. Quanmax reserves the right to make changes without notice in product or component design as warranted by evolution in user needs or progress in engineering or manufacturing technology. Changes which affect the operation of the unit will be documented in the next revision of this user’s guide.

Page 3

Content

QBOX Mini-1000 Series User’s Manual

Content

Content ....................................................................................................................... 3

Figures ....................................................................................................................... 4

Tables ......................................................................................................................... 5

Safety Instructions ...................................................................................................... 6

Before You Begin ......................................................................................... 6

When Working Inside a Computer ............................................................... 7

Preventing Electrostatic Discharge .............................................................. 8

Instructions for Lithium Batt ery .................................................................... 9

Preface ..................................................................................................................... 10

How to Use This Guide .............................................................................. 10

Unpacking .................................................................................................. 10

Regulatory Compliance Statements .......................................................... 10

Warranty Policy ......................................................................................... 11

Maintaining Your Computer ....................................................................... 12

Chapter 1 Introduction ........................................................................................... 15

Overview ................................................................................................... 15

Product Specifications ............................................................................... 16

System Tour ............................................................................................... 17

Mechanical Dimensions ............................................................................. 19

Chapter 2 Getting Started ...................................................................................... 20

Setting up your PC .................................................................................... 20

Chapter 3 AMI BIOS Setup .................................................................................... 22

Overview ................................................................................................... 22

Main Menu ................................................................................................. 23

Advanced Menu ......................................................................................... 24

Boot Menu ................................................................................................. 28

Security Menu ............................................................................................ 29

Save & Exit Menu ...................................................................................... 29

Chapter 4 Driver Installation .................................................................................. 31

Page 4

Figures

QBOX Mini-1000 Series User’s Manual

Figures

Figure 1 I/Os .............................................................................................. 17

Figure 2 Mechanical Dimensions ............................................................... 19

Figure 3 VGA/HDMI ................................................................................... 20

Figure 4 Connect USB mouse & keyboard ................................................ 20

Figure 5 Turning on the system .................................................................. 21

Page 5

Tables

QBOX Mini-1000 Series User’s Manual

Tables

Table 1 QBOX Mini-1000 Series Specification ........................................... 16

Table 2 BIOS Main Menu ........................................................................... 23

T a ble 3 Advanced Menu ............................................................................. 24

Table 4 Advanced Menu – ACPI Settings ................................................... 24

Table 5 Advanced Menu – CPU Configuration ........................................... 25

T a ble 6 Advanced Menu –USB Configuration ............................................ 26

T a ble 7 Advanced Menu –H/W Monitor ...................................................... 26

Table 6 Advanced Menu –JMB36X ATA Controller Configuration .............. 27

Table 6 Advanced Menu – Wa tchD og Timer Configurati on ........................ 27

Table 10 Boot Menu ................................................................................... 28

Table 11 Security Menu .............................................................................. 29

Table 12 Save & Exit Menu ........................................................................ 29

Page 6

Safety Instructions

QBOX Mini-1000 Series User’s Manual

Safety Instructions

 Before You Begin

Before handling the product, read the instructions and safety guidelines on the following pages to prevent damage to the product and to ensure your own personal safety. Refer to the “Advisories” section in t he Pre face for adv isory conventions us ed in this user’s guide, including the distinction between Warnings, Cautions, Important Notes, and Notes.

 Always use caution when handling/operating a computer. Only qualified,

experienced, authorized electronics service personnel should access the interior of a computer. The power supplies produce high voltages and energy hazards, which can cause bodily harm.

 Use extreme caution when installing or removing components. Refer to the

installation instructions in this user’s guide for precautions and procedures. If you have any questions, please contact Quanmax Post-Sales Technical Support.

 Access can only be gained by service persons or by users who have

been instructed about the reasons for the restrictions applied to the location and about any precautions that shall be taken; and access is through the use of a tool or lock and key, or other means of security, and is controlled by authority responsible for the location.

WARNING

High voltages are present i nside the ch assis w hen the unit’ s pow er cor d is plugged into an electrical outlet. Turn off system power, turn off the power supply, and then disconnect the power cord from its source before removing the chassi s c ov er. Turning of f the sy stem pow er sw i tch does not remove power to components.

The product chassis may be hot when the system is working. Please do not touch the surface before turn off the system power and wait for about 5 minutes until the system cools down.

Page 7

Safety Instructions

QBOX Mini-1000 Series User’s Manual

 When Working Inside a Computer

Before taking covers off a computer, perform the following steps:

1. Turn off the computer and any peripher al s.

2. Disconnect the computer and peripherals from their power sources or subsystems to prevent electric shock or system board damage. This does not apply when hot swapping parts.

3. Follow the guidelines provided in “Preventing Electrostatic Discharge” on the following page.

4. Disconnect any teleph one or telec om m uni cations lines from the computer.

In addition, take note of these safety guidelines when appropriate:

 To help avoid possible damage to system boards, wait five seconds after

turning off the computer before removing a component, removing a system board, or disconnecting a peripheral device from the computer.

 When you disconnect a cable, pull on its connector or on its strain-relief loop,

not on the cable itself. Some cables have a connector with locking tabs. If you are disconnecting this type of cable, press in on the locking tabs before disconnecting the cable. As you pull connectors apart, keep them evenly aligned to avoid bending any connector pins. Also, before connecting a cable, make sure both connectors are correctly oriented and aligned.

CAUTION

Do not attempt to service the system yourself except as explained in this user’s guide. Follow installation and troubleshooting instructions closely.

Page 8

Safety Instructions

QBOX Mini-1000 Series User’s Manual

 Preventing Electrostatic Discharge

Static electricity can harm system boards. Perform service at an ESD workstation and follow proper ESD procedure to reduce the risk of damage to components. Quanmax strongly encourages you to follow proper ESD procedure, which can include wrist straps and smocks, when servicing equipment. You can also take the following steps to prevent damage from electrostatic discharge (ESD):

 When unpacking a static-sensitive component from its shipping carton, do not

remove the compon ent’s antistatic packi ng m at eri al u nti l you are ready t o install the component in a computer. Just before unwrapping the antistatic packaging, be sure you are at an ESD workstation or grounded. This will discharge any static electricity that may have built up in your body.

 When transporting a sensitive component, first place it in an antistatic container

or packaging.

 Handle all sensitive compo ne nts at an ESD workst ati o n. If possi bl e, use

antistatic floor p ads an d w or kbench p a ds.

 Handle components and boards with care. Don’t touch the components or

contacts on a boar d. H old a b oard by it s e dge s or by it s met al mou nti ng br acket .

 Do not handle or stor e sy stem boar ds near st r ong el ectros t ati c, el ectr omagn etic,

magnetic, or radioactive fields.

Page 9

Safety Instructions

QBOX Mini-1000 Series User’s Manual

 Instructions for Lithium Battery

WARNING

Danger of explosion when battery is replaced with incorrect type. Only repl ace with the same or equivalent type recommended by the manufacturer.

Do not dispose of lithium batteries in domestic waste. Dispose of the battery according to the local regulations dealing with the disposal of these special materials (e.g. to the collecting points for disposal of batteries)

Page 10

Preface

QBOX Mini-1000 Series User’s Manual

Preface

 How to Use This Gui de

This guide is designe d to be used as st ep-by-step instructions for inst allati on, and a s a reference for operation, troubleshooting, and upgrades.

NOTE

Driver downloads and additional information are available under Downloads on our web site: www.quanmax.com.

 Unpacking

When unpacking, follow these steps:

1. After opening the box, save it and the packing mater i al for possible future

shipment.

2. Remove all items from the box. If any items listed on the purchase order

are missing, notify Quanmax customer service immediately.

3. Inspect the product for damage. If there is damage, notify Quanmax

customer service immediately. Refer to “Warranty Policy” for the return procedure.

 Regulatory Co mpliance Statements

This section provides the FCC compliance statement for Class A devices.

FCC Compliance Statement for Class A De vi c e s

The product(s) described in this user’s guide has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the user’s guide, may cause harmful interference to radio communications. Operation of this equipment in a residential

Page 11

Preface

QBOX Mini-1000 Series User’s Manual

area (domestic environment) is likely to cause harmful interference, in which case the user will be required to correct the interference (take adequate measures) at their own expense. The user is encouraged to try to correct the interference by one or more of the following measures:

 Reorient or relocate the receiving antenna.

 Increase the separation between the equipment and receiver.  Connect the equipment to an outlet on a circuit different from that to which the

receiver is connected.

 Consult the dealer or an experienced radio/TV technician for help.

Changes or modific atio ns not ex pressl y appr ov ed by Q uanmax could v oid the us er's authority to operate the equipment.

NOTE

The assembler of a personal computer system may be required to test

the system and/or mak e necess ar y modific ati ons i f a sy stem is found to cause harmful interference or to be noncompliant with the appropriate

standards for its intended use.

 Warranty Policy

Limited Warranty

Quanmax Inc.’s detailed Limited Warranty policy can be found under Support at www.quanmax.com. Please consult your distributor for warranty verification. The limited warranty is void if the product has been subjected to alteration, neglect, misuse, or abuse; if any repairs have been attempted by anyone other than Quanmax or its authorized agent ; or if the failure is ca used by accident , acts of God, or other causes beyond the control of Quanmax or the manufacturer. Neglect, misuse, and abuse shall include any installation, operation, or maintenance of the product other than in accordance with the user’s guide. No agent, dealer, distributor , serv ice comp any, or other party i s authoriz ed to change , modify, or extend the terms of this Limited Warranty in any manner whatsoever. Quanmax reserves the right to make changes or improvements in any product without incurring any obligation to similarly alter products previously purchased.

Page 12

Preface

QBOX Mini-1000 Series User’s Manual

Return Procedure

For any Limited Warranty return, please contact Support at www.quanmax.com and login to obtain a Return Material Authorization (RMA) Number. If you do not have an account, send an email to [email protected] to apply for one. All product(s) returned to Quanmax for service or credit must be accompanied by a Return Material Authorization (RMA) Number. Freight on all returned items must be prepaid by the customer who is responsible for any loss or damage caused by common carrier in transit. Returns for Warranty must include a Failure Report for each unit, by serial number(s), as well as a copy of the original invoice showing the date of purchase. To reduce risk of damage, returns of product must be in a Quanmax shipping container. If the original container has been lost or damaged, new shipping containers may be obtained from Quanmax Customer Service at a nominal cost. Quanmax owns all parts removed from repaired products. Quanmax uses new and reconditioned parts made by various manufacturers in performing warranty repairs and building replacement products. If Quanmax repairs or replaces a product, its warranty term is not extended. Shipments not in compliance with this Limited Warranty Return Policy will not be accepted by Quanmax.

Limitation of Liability

In no event shall Quanmax be liable for any defect in hardware, software, loss, or inadequacy of data o f any kind, or for any direct, indirect, incidental, or consequential damages in connection with or arising out of the performance or use of any product furnished hereunder. Quanmax’s liability shall in no event exceed the purchase price of the product pur chased hereunder. The foregoing limitation o f liability shall be equally applicable to any service provided by Quanmax or its authorized agent.

 Maint ainin g Your Computer

Environmental Factors

 Temperature

The ambient temperature within an enclosure may be greater than room ambient temperature. Installation in an enclosure should be such that the amount of air flow required for safe operation is not compromised. Consideration should be given to the maximum rated ambient temperature. Overheating can cause a variety of problems, including premature aging and

Page 13

QBOX Mini-1000 Series User’s Manual

failure of chips or mechanical failure of devices. If the system has been exposed to abnormally cold temperatures, allow a two-hour warm-up period to bring it up to normal operating temperature before turning it on. Failure to do so may cause damage to internal components, particularly the hard disk drive.

 Humidity

High-humidity can cause moisture to enter and accumulate in the system. This moisture can cause corrosion of internal components and degrade such properties as electrical resistance and thermal conductivity. Extreme moisture buildup inside the system can result in electrical shorts, which can cause serious damage to the sy st em. Buildings in which climate is controlled usually maintain an acceptable level of humidity for system equipment. However, if a system is located in an unusually humid location, a dehumidifier can be used to maintain the humidity within an

Preface

acceptable range. Refer to the “Specifications” section of this user’s guide for the operating and storage humidity specifications.

Power Protection

The greatest threats to a system’s supply of power are power loss, power spikes, and power surges caused by electrical storms, which interrupt system operation and/or damage system components. To protect your system, always properly ground power cables and one of the following devices.

 Surge Protector

Surge protectors are available in a variety of types and usually provide a level of protection proportional with the cost of the device. Surge protectors prevent voltage spikes from entering a system through the AC power cord. Surge protectors, however, do not offer protection against brownouts, which occur when the voltage drops more than 20 percent below the normal AC line voltage level.

 Line Conditioner

Line conditioners go beyond the over voltage protection of surge protectors. Line conditioners keep a system’s AC power source voltage at a fairly constant level and, therefore, can handle brownouts. Because of this added protection, line conditioners cost more than surge protectors. However, line conditioners cannot protect against a co mplete loss of power.

Page 14

QBOX Mini-1000 Series User’s Manual

 Uninterruptible Power Supply

Uninterruptible power supply (UPS) systems offer the most complete protection against variations on power because they use battery power to keep the server running when AC power is lost. The battery is charged by the AC power while it is available, so when AC power is lost, the battery can provide power to the system for a limited amount of time, depending on the UPS system. UPS systems range in price from a few hundred dollars to several thousand dollars, with the more expensive unit s allowing you to run larger systems for a longer period of time when AC power is lost. UPS systems that provide only 5 minutes of battery power let you conduct an orderly shutdown of the system, but are not inten ded to pr ov ide conti nue d oper ati on. Sur ge pr otect or s shoul d b e used with all UPS systems, and the UPS system should be Underwriters Laboratories (UL) safety approved.

Preface

Page 15

Chapter 1

QBOX Mini-1000 Series User’s Manual

Chapter 1

Introduction

 Overview

The QBOX Mini-1000 series ,a fan-less Box PC, is ideal for s pace criti cal appl ica tions. This embedded hardware platform is designed with Intel® Atom™ E640T Processor

which provides with excellent performance. The system is supported with on board DDR2 memory to 1GB. Feat ur ed ar e 1x mSATA,1x mini-PCIe socket for Wifi module, 1 x USB 2.0, 2x internal USB, 1x VGA (For QBOX Mini-1000), 1x HDMI ( For QBOX Mini-1010) and 1x Phone Jack for both Line-Out & Mic-In.

Checklist

 QBOX Mini-1000 Series  Power Adapter  Power Cord  Driver CD  Quick installation Guide  Wireless LAN (optional)

Features

 Intel® Atom™ Processor E640T  QBOX Mini-1000 - VGA Output  QBOX Mini-1010 - HDMl Output  On Board DDR2 memory ( 1GB max )  1x Phone Jack for both Line-Out & Mic-In  1x mSATA  1x mPCIe Socket for Wifi Module.  2x internal USB, 1x external USB

Page 16

QBOX Mini-1000 Series User’s Manual

QBOX Mini 1000 : VGA ( Chrontel CH7317B ) QBOX Mini 1010 : HDMI ( Chrontel CH7315B )

Storage

1x mSAT A

Expansion

1 x Mini PCI-Express Socket for WiFi module

2x internal USB 1x external USB

Cooling

Fanless

1x Power On/Off Button ( With Power LED) 1x Clear CMOS Switch

ACPI 3.0 supported

 Product Specificatio ns

Chapter 1

CPU Support Memory On board DDR2 Memory ( 1GB max )

BIOS

Display

Audio

USB

Switch & LED Watchdog Ti mer Intel® Atom™ E640T processor integrated WDT 1us to 10mins selectable Hardware Monitor Real Time Clock Intel® Atom™ E640T processor integrated RTC

Power DC 12V Input Environment Operating: 0°C to 40°C Dimensions 130.11 x 83.06 x19.2 mm (D x W x H) Weight 174. 4 (g) Certifications CE, FCC Class A

Intel® Atom™ E640T (1GHz, 512KB Cache (TDP: 3.3W) )

AMI uEFI BIOS 1x 8Mb SPI flash ROM

Realtek ALC662 HD Codec 1x Phone Jack for both Line-Out & Mic-In

Temperature & Voltage Monitoring

Table 1 QBOX Mini-1000 Series Specification

Page 17

QBOX Mini-1000 Series User’s Manual

 System Tour

Refer to the figure below to identify the components of the system.

 QBOX Mini-1000 Series I/Os

Chapter 1

Figure 1 I/Os

Page 18

QBOX Mini-1000 Series User’s Manual

Power Button

The power button with power LED allows powering ON and OFF the system.

Phone Jack Audio Out

The green stereo headphone jack is used to connect the system’s audio out signal to amplified speakers or headphones.

MIC-IN

The pink microphone jack is designed to connect the microphone used for video conferencing, voice narrations, or simple audio recordings.

USB

The USB (Universal Serial Bus) port is compatible with USB devices such as keyboards, mouse devices, cameras, and hard disk drives. USB allows many devices to run simultaneously on a single computer, with some peripheral

Chapter 1

acting as additional plug-in sites or hubs.

DC Jack

The supplied power adapter converts AC power to DC for use with this jack. Power supplied through this jack supplies power to the PC. To prevent damage to the PC, always use the supplied power adapter.

VGA ( For QBOX Mini-1000 )

D-Sub 15 pin VGA connector for display output

HDMI ( For QBOX Mini-1010 )

HDMI connector for disp lay output

Reset Button

1x reset button for clear CMOS.

Page 19

QBOX Mini-1000 Series User’s Manual

 Mechanical Dimensions

QBOX Mini-1000 : QBOX Mini-1010 :

Chapter 1

130.11 x 83.06 x19.2 mm (D x W x H)

Figure 2 Mechanical Dimensions

Page 20

VGA

HDMI

Chapter 2

USB

Getting Started

 Setting up your PC

Connect the VGA/ HDMI cable from your display to the VGA/HDMI port.

QBOX Mini-1000 : QBOX Mini-1010 :

Figure 3 VGA/HDMI

 Connect USB mouse & keyboard

Your QBOX Mini-1000 series does not come with a keyboard and mouse

connector, but you can use any USB keyboard or mouse to connect with your computer.

Figure 4 Connect USB mouse & keyboard

NOTE

Using a third-party USB mouse or keyboard may require software drivers. Check the manufactur er ’s website for the latest software drivers.

Page 21

QBOX Mini-1000 Series User’s Manual

DC Jack

Power switch

 Turning on the system

1. Connect the power adapter cable to the DC Jack (DC IN) of the QBOX Mini-1000 series

2. Connect the power cable to the power adapter

3. Connect the power cable to a power outlet

4. Press the power button to turn on the sy st e m

Chapter 2

Figure 5 Turning on the system

Page 22

Chapter 3

QBOX Mini-1000 Series User’s Manual

Chapter 3

AMI BIOS Setup

 Overview

This chapter provides a description of the AMI BIOS. The BIOS setup menus and available selectio ns may v ary from t hose of your prod uct. F or sp eci fic i nform ation on the BIOS for your product, please contact Quanmax.

NOTE: The BIOS menus and selections for your product may vary from those in this chapter. For the BIOS manual specific to your product, please contact Quanmax

AMI's ROM BIOS pr ov i des a b ui l t-i n Setup program, which allows th e use r to modify the basic system configuration and hardware parameters. The modified data will be stored in a battery-backed CMOS, so th at da t a w il l be r et aine d ev en when t he p ow er is turned of f. In general, the i n for mation saved in the C M OS R AM will not need to be changed unless there is a configuration change in the system, such as a hard drive replacement or when a device is added.

It is possible for the CMOS battery to fail, which will cause data loss in the CMOS only. If this happens you will need to reconfigure your BIOS settings.

Page 23

Chapter 3

QBOX Mini-1000 Series User’s Manual

BIOS Build Date

09/19/2012

MRC Version

01.00

 Main Menu

The BIOS Setup is accessed by pressing the DEL key after the Power-On Self-Test (POST) memory test beg ins an d be fore the oper ating sy ste m boot b egi ns. Onc e y ou enter the BIOS Setup Utility, the Main Menu will appear on the screen. The Main Menu provides Syst em Ov erv iew i nformation and all ows you t o set t he Syst em Time and Date. Use the “<” and “>” cursor keys to navigate between menu screens.

Table 2 BIOS Main Menu

BIOS SETUP UTILITY

Main Advanced Boot Security Save & Exit

Product Information

Product Name BIOS V e rs ion 0.01

CPU Information

Genuine Intel®

Microcode Revision 104

Processor Cores 2

Memory Information

Total Size 1024 MB (DDR2) Frequency 800 MHz

Syst em date [Wed 09/19/2012] System time [13:38:27]

CPU @1.00GHz

QBOX Mini-1000

  Select Screen ↑↓ Select Item Enter: Select +- Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4 Save & Exit ESC Exit

Page 24

QBOX Mini-1000 Series User’s Manual

>ACPI Settings

> USB Configuration

> JMB36X ATA Controller Configuration

ESC Exit

 Advanced Menu

Main Advanced Boot Security Server Mgmt Save & Exit

Chapter 3

Table 3 Advanced Menu

BIOS SETUP UTILITY

> CPU Configuration

> H/W Monitor

> WatchDog Timer Configuration

Table 4 Advanced Menu – ACPI Settings

BIOS SETUP UTILITY

Main Advanced Boot Security Server Mgmt Save & Exit

Enable ACPI Auto Configuration

Enable Hibernation [Enabled]

ACPI Sleep State [S3 (Suspend to RAM)]

[ Disabled ]

  Select Screen ↑↓ Select Item Enter: Select +- Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4 Save & Exit

Enable ACPI Auto Configuration

Options: Disabled, Enabled

Enable Hibernation

Options: Disabled, Enabled

ACPI Sleep State

Options: Suspend Disabled, S3 (Suspend to RAM)

Page 25

QBOX Mini-1000 Series User’s Manual

Table 5 Advanced Menu – CPU Configuration

System Bus Speed

400 MHz

Processor Stepping

20661

Microcode Revision

260

L1 Cache RAM

56 k

L2 Cache RAM

512 k

Processor Core

Single

Hyper-Threading

Supported

Limit CPUID Maximum

[ Disabled]

Intel Virtualization Technology

[ Disabled]

C-States

[Enabled]

Enhanced C1

[ Disabled]

Enhanced C2

[Enabled]

Enhanced C3

[ Disabled]

BIOS SETUP UTILITY

Main Advanced Boot Security Server Mgmt Save & Exit

CPU Configuration   Select Screen Processor Type Genuine Intel ® CPU

EMT64 Supported Processor Speed 1000 MHz System Bus Speed 400 MHZ

Ratio Status 10 Actual Ratio 10

↑↓ Select Item Enter: Select +- Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4 Save & Exit ESC Exit

Chapter 3

Intel SpeedStep Hyper-Threading Execute Disable Bit

Intel SpeedStep Options: Disabled, Enabled Hyper-Threading Options: Disabled, Enabled Execute Disable Bit Options: Disabled, Enabled Limit CPUID Maximum

Options: Disabled, Enabled

[Enabled] [Enabled] [Enabled]

Intel Virtualization Technology Options: Disabled, Enabled C-States Options: Disabled, Enabled Enhanced C1 Options: Disabled, Enabled Enhanced C2 Options: Disabled, Enabled Enhanced C3

Options: Disabled, Enabled

Page 26

QBOX Mini-1000 Series User’s Manual

Table 6 Advanced Menu –USB Configurati on

Sa n Disk CPU Temperature

: +92.0 C

+5V

: +5.120V

BIOS SETUP UTILITY

Main Advanced Boot Security Save & Exit

USB Configuration

USB Devices:

1 Drive, 1 Keyboard, 1 Mouse, 1 Hub

Legacy USB Support [Enabled] EHCI Hand-off [Disabled]

Mass Storage Devices:

Legacy USB Support

Options: Disabled, Enabled, Auto

EHCI hand-off

[Auto]

Chapter 3

  Select Screen ↑↓ Select Item Enter: Select +- Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4 Save & Exit ESC Exit

Options: Disabled, Enabled

Mass Storage Device

Options: Auto, Floppy, Forced FDD, Hard Disk, CD-ROM

Table 7 Advanced Menu –H/W Monitor

BIOS SETUP UTILITY

Main Advanced Boot Security Save & Exit

PC Health Status

SYS Temperature : +91.7 C +3.3V : +3.264V

+VIN : +12.160V

+VCORE : +0.832V

  Select Screen ↑↓ Select Item Enter: Select +- Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4 Save & Exit ESC Exit

Page 27

QBOX Mini-1000 Series User’s Manual

Table 8 Advanced Menu –JMB36X ATA Controller Configuration

SATA Port 0

WDT Function

BIOS SETUP UTILITY

Main Advanced Boot Security Save & Exit

ATA Controller [ IDE Mode ]

SanDisk SSD P4 (8GB)

ATA Controller

Options: Disabled, IDE Mode, AHCI Mode

Table 9 Advanced Menu – WatchDog Timer Configuration

Chapter 3

  Select Screen

↑↓ Select Item Enter: Select +- Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4 Save & Exit ESC Exit

Main Advanced Boot Security Save & Exit

WDT Function

Options: Disabled, Enabled

BIOS SETUP UTILITY

[Disabled ]

Page 28

QBOX Mini-1000 Series User’s Manual

 Boot Menu

Fast Boot

[Disabled]

Setup Prompt Timeout

Boot Option #1

[SATA PM: SanDISK…]

Boot Option#2

[UEFI: SanDisk]

Hard Drive BBS Priorities

Main Advanced Boot Security Save & Exit

Boot Configuration

Quiet Boot

Bootup NumLock State [On]

Boot Option Priorities

Table 10 Boot Menu

BIOS SETUP UTILITY

[Disabled]

Chapter 3

  Select Screen

↑↓ Select Item Enter: Select +- Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4 Save & Exit ESC Exit

Quiet Boot

Options: Disabled, Enabled

Fast Boot

Options: Disabled, Enabled

Boot Option #1

Options: SATA PM: SanDisk SSD P4 8GB

UEFI : SanDisk Disabled

Boot Option #2

Options: SATA PM: SanDisk SSD P4 8GB

UEFI : SanDisk Disabled

Hard Drive BBS Priorities

■ Boot Option # 1 【SATA PM: SanDisk…】

Options: SATA PM: SanDisk SSD P4 8GB

SanDisk Disabled

■ Boot Option # 2 【SanDisk】

Options: SATA PM: SanDisk SSD P4 8GB

SanDisk Disabled

Page 29

QBOX Mini-1000 Series User’s Manual

s password is set, then this only limits access to

s password is set, then this is a power on password and

he User will have

ESC Exit

 Security Menu

Main Advanced Boot Security Save & Exit

Password Description

If ONLY the Administrator’ Setup and is only asked for when entering Setup If ONLY the User’ must be entered to boot or enter Setup. In Setup t Administrator rights

The password length must be in the following range:

Administrator Password

User Password

Chapter 3

Table 11 Security Menu

BIOS SETUP UTILITY

  Select Screen

↑↓ Select Item Enter: Select +- Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4 Save & Exit

 Save & Exit Menu

Table 12 Save & Exit Menu

Main Advanced Boot Security Save & Exit

Save Changes and Reset Discard Changes and Reset

Save Options Save Changes Discard Changes

Restore Defaults

Boot Override SATA PM : SanDisk SSD P4 8GB SanDisk UEFI : SanDisk

BIOS SETUP UTILITY

  Select Screen

↑↓ Select Item Enter: Select +- Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4 Save & Exit ESC Exit

Page 30

Chapter 3

QBOX Mini-1000 Series User’s Manual

Save Changes and Exit

Exit system setup after saving the changes. Once you are finished making your selections, choose this option from the Exit menu to ensure the values you selected are saved to the CMOS RAM. The CMOS RAM is sustained by an onboard backup battery and stays on even when the PC is turned off. When you select this option, a confirmation window appears. Select [Yes] to save changes and exit.

Discard Changes and Exit

Exit system setup without saving any changes. Select this option only if you do not want to save the changes that you made to the Setup program. If you made changes to fields other than system date, system time, and password, the BIOS asks for a confirmation before exiting.

Discard Changes

Discards changes done so far to any of the setup values. This option allows you to discard the selections you made and restore the previously saved values. After selecting this optio n, a con firmation a ppears. Select [Y es] to disca rd any changes and load the previously saved values.

Load Optimal Defaults

Load Optimal Default values for all the setup values. This option allows you to load optimal default values for each of the parameters on the Setup menus, which will provide the best performance settings for your system. The F9 key can be used for this operation.

Load Failsafe Defaults

Load Optimal Default values for all the setup values. This option allows you to load failsafe default values for each of the parameters on the Setup menus, which will provide the most stable performance settings. The F8 key can be used for this operation.

Page 31

Chapter 4

QBOX Mini-1000 Series User’s Manual

Chapter 4

Driver Installation

If your QBOX Mini-1000 series does not come with an operating system pre-installed, you will need to install an operating system and the necessary drivers to operate it. After you have finished assembling your system and connected the appropriate pow er so urce, power i t up using the power supply and i n stall the desir e d operating system. You can download the drivers for the QBOX Mini-1000 series from the Quanmax website at www.quanmax.com and install as instructed there. For other operating systems, please contact Quanmax.
